Java Modeling Language
Reference Manual
David R. Cok, Gary T. Leavens, Mattias Ulbrich, TBD
DRAFT March 26, 2018
Copyright (c) 2010-2017 TBD
Contents
1 Introduction 3
1.1 Behavioral Interface Specifications . . . . . . . . . . . . . . . . . . . 3
1.2 AFirstExample............................. 4
1.3 WhatisJMLGoodFor? ........................ 4
1.4 Status, Plans and Tools for JML . . . . . . . . . . . . . . . . . . . . 4
1.5 Purpose of this document . . . . . . . . . . . . . . . . . . . . . . . . 5
1.6 Previous JML reference manual . . . . . . . . . . . . . . . . . . . . 5
1.7 Historical Precedents and Antecedents . . . . . . . . . . . . . . . . . 5
1.8 Acknowledgments ........................... 7
2 Structure of this Manual 9
2.1 Typographical conventions . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Grammar ................................ 9
3 JML concepts 11
3.1 JML and Java compilation units . . . . . . . . . . . . . . . . . . . . 12
3.2 .jml files ................................ 12
3.2.1 Combining Java and JML files . . . . . . . . . . . . . . . . . 14
3.3 Specification inheritance . . . . . . . . . . . . . . . . . . . . . . . . 15
3.4 JML modifiers and Java annotations . . . . . . . . . . . . . . . . . . 16
3.4.1 Modifiers............................ 16
3.4.2 Typemodifiers ......................... 17
3.5 ModelandGhost ............................ 17
3.6 Visibility ................................ 17
3.7 Evaluation and well-formedness of JML expressions . . . . . . . . . 17
3.8 Null and non-null references . . . . . . . . . . . . . . . . . . . . . . 17
3.9 StaticandInstance ........................... 18
3.10Observablepurity............................ 18
3.11 Location sets and Dynamic Frames . . . . . . . . . . . . . . . . . . . 18
3.12Arithmeticmodes............................ 18
3.13 Immutable types and functions . . . . . . . . . . . . . . . . . . . . . 18
3.14 Race condition detection . . . . . . . . . . . . . . . . . . . . . . . . 18
3.15 Redundant specifications . . . . . . . . . . . . . . . . . . . . . . . . 18
3.16 Controlling warnings . . . . . . . . . . . . . . . . . . . . . . . . . . 18
i
CONTENTS ii
3.17 org.jmlspecs.lang package . . . . . . . . . . . . . . . . . . . . . . . 19
3.18 Interaction with other tools . . . . . . . . . . . . . . . . . . . . . . . 19
3.18.1 Interaction with Type Annotations in Java 1.8 . . . . . . . . . 19
3.18.2 Interaction with the Checker framework . . . . . . . . . . . . 19
3.18.3 Interaction with FindBugs . . . . . . . . . . . . . . . . . . . 19
3.19CoreJML ................................ 19
4 JML Syntax 24
4.1 Textual form of JML specifications . . . . . . . . . . . . . . . . . . . 24
4.2 JMLSyntax............................... 26
4.2.1 Syntax of JML specifications . . . . . . . . . . . . . . . . . . 26
4.2.2 Conditional JML specifications . . . . . . . . . . . . . . . . 26
5 JML Types 28
5.1 \bigint ................................. 28
5.2 \real .................................. 29
5.3 \TYPE .................................. 29
6 JML Specifications for Packages and Compilation Units 30
6.1 Model import statements . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2 Defaultimports ............................. 31
6.3 Issues with model import statements . . . . . . . . . . . . . . . . . . 31
7 Specifications for Java types in JML 33
7.1 Modifiers for type declarations . . . . . . . . . . . . . . . . . . . . . 33
7.1.1 non_null_by_default, nullable_by_default, @NonNullByDefault,
@NullableByDefault . . . . . . . . . . . . . . . . . . . . . . 34
7.1.2 pureand@Pure......................... 34
7.1.3 @Options............................ 34
7.2 invariantclause ............................. 34
7.3 constraintclause............................. 35
7.4 initiallyclause.............................. 35
7.5 ghostfields ............................... 35
7.6 modelfields............................... 35
7.7 representsclause ............................ 35
7.8 model methods and model classes . . . . . . . . . . . . . . . . . . . 35
7.9 initializer and static_initializer . . . . . . . . . . . . . . . . . . . . . 35
7.10axiom .................................. 36
7.11 readable if clause and writable if clause . . . . . . . . . . . . . . . . 36
7.12monitors_forclause........................... 36
8 JML Method specifications 37
8.1 Structure of JML method specifications . . . . . . . . . . . . . . . . 37
8.1.1 Behaviors............................ 39
8.1.2 Nested specification clauses . . . . . . . . . . . . . . . . . . 39
8.1.3 Specification inheritance and the code modifier . . . . . . . . 40
CONTENTS iii
8.1.4 Visibility ............................ 40
8.1.5 Grammar of method specifications . . . . . . . . . . . . . . . 41
8.2 Method specifications as Annotations . . . . . . . . . . . . . . . . . 42
8.3 Modifiersformethods.......................... 42
8.4 Common JML method specification clauses . . . . . . . . . . . . . . 42
8.4.1 requires clause........................ 42
8.4.2 ensures clause......................... 42
8.4.3 assignable clause....................... 42
8.4.4 signals clause......................... 42
8.4.5 signals_only clause ..................... 42
8.5 Advanced JML method specification clauses . . . . . . . . . . . . . . 43
8.5.1 accessible clause....................... 43
8.5.2 diverges clause........................ 43
8.5.3 measured_by clause...................... 43
8.5.4 when clause........................... 43
8.5.5 old clause ........................... 43
8.5.6 forall clause ......................... 43
8.5.7 duration clause........................ 43
8.5.8 working_space clause .................... 43
8.5.9 callable clause........................ 44
8.5.10 captures clause........................ 44
8.6 Model Programs (model_program clause)............... 44
8.6.1 Structure and purpose of model programs . . . . . . . . . . . 44
8.6.2 extract clause......................... 44
8.6.3 choose clause ......................... 44
8.6.4 choose_if clause ....................... 44
8.6.5 or clause ............................ 44
8.6.6 returns clause......................... 44
8.6.7 continues clause ....................... 44
8.6.8 breaks clause ......................... 45
8.7 Modifiers for method specifications . . . . . . . . . . . . . . . . . . 45
8.7.1 pureand@Pure......................... 45
8.7.2 non_null, nullable, @NonNull, and @Nullable . . . . . . . . 45
8.7.3 model and @Model . . . . . . . . . . . . . . . . . . . . . . . 45
8.7.4 spec_public, spec_protected, @SpecPublic, and @SpecProtected 45
8.7.5 helper and @Helper . . . . . . . . . . . . . . . . . . . . . . 45
8.7.6 function and @Function . . . . . . . . . . . . . . . . . . . . 45
8.7.7 query, secret, @Query, and @Secret . . . . . . . . . . . . . . 45
8.7.8 code_java_math, code_bigint_math, code_safe_math . . . . . 46
8.7.9 skip_esc, skip_rac, @SkipEsc, and SkipRac . . . . . . . . . . 46
8.7.10 options and @Options . . . . . . . . . . . . . . . . . . . . . 46
8.7.11 extract and @Extract . . . . . . . . . . . . . . . . . . . . . . 46
8.8 TODOSomewhere ........................... 46
9 Field Specifications 47
9.1 Field and Variable Modifiers . . . . . . . . . . . . . . . . . . . . . . 47
CONTENTS iv
9.1.1 non_null and nullable (@NonNull, @Nullable) . . . . . . . . 47
9.1.2 spec_public and spec_protected (@SpecPublic, @SpecProtected) 47
9.1.3 ghost and @Ghost ....................... 49
9.1.4 model and @Model ....................... 49
9.1.5 uninitialized and @Uninitialized ............ 49
9.1.6 instance and @Instance ................... 49
9.1.7 monitored and @Monitored ................. 49
9.1.8 query,secret and @Query,@Secret ............ 49
9.1.9 peer,rep,readonly (@Peer,@Rep,@Readonly) ...... 49
9.2 Datagroups: in and maps clauses.................... 49
9.3 Ghostfields ............................... 49
9.4 Modelfields............................... 49
10 JML Statement Specifications 50
10.1 assert statement and Java assert statement . . . . . . . . . . . . . . 50
10.2 assume statement............................ 51
10.3 ghost and model declarations . . . . . . . . . . . . . . . . . . . . . . 51
10.4 unreachable statement ........................ 51
10.5 reachable statement.......................... 52
10.6 set and debug statements ....................... 53
10.7loopspecifications ........................... 53
10.8 statement (block) specification . . . . . . . . . . . . . . . . . . . . . 54
10.9 hence_by statement .......................... 55
11 JML Expressions 56
11.1Syntax.................................. 57
11.2 Purity (no side-effects) . . . . . . . . . . . . . . . . . . . . . . . . . 57
11.3 Java operations used in JML . . . . . . . . . . . . . . . . . . . . . . 57
11.4 Precedence of infix operations . . . . . . . . . . . . . . . . . . . . . 57
11.5 Well-defined expressions . . . . . . . . . . . . . . . . . . . . . . . . 59
11.6 org.jmlspecs.lang.JML . . . . . . . . . . . . . . . . . . . . . . . . . 60
11.7 Implies and reverse implies: ==> <== ................. 60
11.8 Equivalence and inequivalence: <==> <=!=> ............. 61
11.9 JML subtype: <: ............................ 61
11.10Lock ordering: <# <#= ......................... 62
11.11\result ................................. 62
11.12\exception .............................. 63
11.13\old,\pre, and \past ......................... 63
11.14\key ................................... 64
11.15\lblpos,\lblneg,\lbl, and
JML.lblpos(),JML.lblneg(),JML.lbl() ............. 64
11.16\nonnullelements .......................... 65
11.17\fresh ................................. 66
11.18informal expression: (*...*) and JML.informal() ......... 67
11.19\type .................................. 68
11.20\typeof ................................. 68
CONTENTS v
11.21\elemtype ............................... 69
11.22\is_initialized ........................... 69
11.23\invariant_for ............................ 70
11.24\not_modified ............................ 71
11.25\lockset and \max .......................... 71
11.26\reach ................................. 71
11.27\duration ............................... 72
11.28\working_space ............................ 72
11.29\space ................................. 73
12 Arithmetic modes 74
12.1 Description of arithmetic modes . . . . . . . . . . . . . . . . . . . . 74
12.2 Semantics of Java math mode . . . . . . . . . . . . . . . . . . . . . . 75
12.3 Semantics of Safe math mode . . . . . . . . . . . . . . . . . . . . . . 76
12.4 Semantics of Bigint math mode . . . . . . . . . . . . . . . . . . . . . 77
12.5 Real arithmetic and non-finite values . . . . . . . . . . . . . . . . . . 77
13 Universe types 78
14 Model Programs 79
15 Obsolete and Deprecated Syntax 80
A Summary of Modifiers 81
B Grammar Summary 84
C Type Checking Summary 85
D Verification Logic Summary 86
E Differences in JML among tools 87
F Misc stuff to move, incorporate or delete 88
F.0.1 Finding specification files and the refine statement . . . . . . 88
F.0.2 Model import statements . . . . . . . . . . . . . . . . . . . . 89
F.0.3 Modifiers............................ 89
F.0.4 JMLexpressions ........................ 91
F.0.5 Codecontracts ......................... 91
F.1 JML modifiers and Java annotations . . . . . . . . . . . . . . . . . . 91
F.2 org.jmlspecs.lang package . . . . . . . . . . . . . . . . . . . . . . . 93
F.3 JMLSyntax............................... 94
F.3.1 Syntax of JML specifications . . . . . . . . . . . . . . . . . . 94
F.3.2 Conditional JML specifications . . . . . . . . . . . . . . . . 94
F.3.3 Finding specification files and the refine statement . . . . . . 95
F.3.4 Model import statements . . . . . . . . . . . . . . . . . . . . 96
F.3.5 Modifiers............................ 97
CONTENTS vi
F.3.6 JMLexpressions ........................ 98
F.3.7 JMLtypes ........................... 98
G Statement translations 99
G.1 Whileloop ............................... 99
H Java expression translations 101
H.1 Implicit or explicit arithmetic conversions . . . . . . . . . . . . . . . 101
H.2 Arithmetic expressions . . . . . . . . . . . . . . . . . . . . . . . . . 101
H.3 Bit-shift expressions . . . . . . . . . . . . . . . . . . . . . . . . . . 102
H.4 Relational expressions . . . . . . . . . . . . . . . . . . . . . . . . . 102
H.5 Logicalexpressions........................... 102
CONTENTS 1
General notes on things not to forget:
- enum types
- default specs for binary classes
- datagroups, JML.* utility functions, @Requires-style annotations. arithmetic modes,
universe types
- interaction with JSR 308
- various @NonNull annotations in different packages
- visibility in JML
– Sorted First-order-logic
– individual subexpressions; optional expression form; optimization; usefulness for
tracing
– RAC vs. ESC
– nomenclature
– lambda expressions
– other Java 6,7,8 features
– Specification of subtypes - cf Clyde Ruby’s thesis
Preface
This document gives the definition of the Java Modeling Language (JML), a language
in which to write behavioral specifications for Java programs. Since about 2000 or
so, JML has been the de facto language for writing behavioral specifications for Java
programs. It was first a vehicle for discussing theoretical and soundness issues in spec-
ification and verification of software. It then also became the language to use in educa-
tion about verification, since Java was a commonly taught language in undergraduate
curricula; it is also frequently a basis for master’s and Ph.D. theses, sometimes not even
known to the core JML researchers until questions arise. Finally, JML is now being
used to help verify, or at least increase confidence in, critical industrial software.
With this broadening of the scope of JML, the JML community, and in particular
the participants in the more-or-less annual JML workshops, considered that the long-
standing and evolving Draft JML Reference manual [?] should be rewritten and ex-
panded to represent the current state of JML. In the process, many outstanding seman-
tic and syntactic issues have been either resolved or clearly stated. This document is the
result of that collaborative effort. Consequently this document is a completely revised,
rewritten and expanded reference maual for JML, while borrowing (and copying) much
from the original document.
The document does not do some other things in which the reader may be interested:
• This document does not describe tools that implement JML or how to use those
tools. Some such tools are
–OpenJML — www.openjml.org — and its user guide: TBD
–the KeY tool — https://www.key-project.org/ — including a book
about KeY: https://www.key-project.org/thebook2/
• This document is not a tutorial about writing specifications in JML. For such a
tutorial, see TBD .
2
Chapter 1
Introduction
1.1 Behavioral Interface Specifications
JML is a behavioral interface specification language (BISL) that builds on the Larch
approach [?][?] and that found in APP [?] and Eiffel [?][?]. In this style of speci-
fication, which might be called model-oriented [?], one specifies both the interface of
a method or abstract data type and its behavior [?]. In particular JML builds on the
work done by Leavens and others in Larch/C++ [?][?][?]. (Indeed, large parts of
this manual are adapted wholesale from the Larch/C++ reference manual [?].) Much
of JML’s design was heavily influenced by the work of Leino and his collaborators
[?][?][?][?][?] and then subsequently by Cok’s work on ESC/Java2 [?] and Open-
JML [?]. JML continues to be influenced by ongoing work in formal specification and
verification. A collection of papers relating directly to JML and its design is found at
http://www.jmlspecs.org/papers.shtml.
The interface of the method or type is the information needed to use it from other parts
of a program. In the case of JML, this is the Java syntax and type information needed
to call a method or use a field or type. For a method the interface includes such things
as the name of the method, its modifiers (including its visibility and whether it is final)
its number of arguments, its return type, what exceptions it may throw, and so on.
For a field the interface includes its name and type, and its modifiers. For a type, the
interface includes its name, its modifiers, its package, whether it is a class or interface,
its supertypes, and the interfaces of the fields and methods it declares and inherits. JML
specifies all such interface information using Java’s syntax.
Abehavior of a method or type describes a set of state transformations that it can
perform. A behavior of a method is specified by describing
• a set of states in which calling the method is defined,
• a set of locations that the method is allowed to assign to (and hence change),
3
CHAPTER 1. INTRODUCTION 4
• and the relations between the calling state and the state in which it either returns
normally, throws an exception, or for which it might not return to the caller.
The states for which the method is defined are formally described by a logical asser-
tion, called the method’s precondition. The allowed relationships between these states
and the states that may result from normal return are formally described by another
logical assertion called the method’s normal postcondition. Similarly the relationships
between these pre-states and the states that may result from throwing an exception are
described by the method’s exceptional postcondition. The states for which the method
need not return to the caller are described by the method’s divergence condition; how-
ever, explicit specification of divergence is rarely used in JML. The set of locations the
method is allowed to assign to is described by the method’s frame condition [?]. In
JML one can also specify other aspects of behavior, such as the time a method can use
to execute and the space it may need.
The behavior of an abstract data type (ADT), which is implemented by a class in Java,
is specified by describing a set of abstract fields for its objects and by specifying the
behavior of its methods (as described above). The abstract fields for an object can be
specified either by using JML’s model and ghost fields [?], which are specification-only
fields, or by specifying some of the fields used in the implementation as spec_public or
spec_protected . These declarations allow the specifier using JML to model an instance as
a collection of abstract instance variables, in much the same way as other specification
languages, such as Z [?][?] or Fresco [?].
To write - take from DRM?
1.2 A First Example
To write - take from DRM?
Does the formal standard document require such an example? Would a reference to a
good JML tutorial not be better?
1.3 What is JML Good For?
To write - take from DRM?
1.4 Status, Plans and Tools for JML
To write - take from DRM? Include somewhere a discussion of available tools and
other resources, to include at least OpenJML, Key, OpenJML tutorial, Key book, etc.
CHAPTER 1. INTRODUCTION 5
1.5 Purpose of this document
The purpose of this standardization document is to define the syntax and formal se-
mantics of JML as a language. The document also distinguishes core aspects of JML,
which over the years have proved to be the most used and most important specification
elements.
While the standard means to set a fixed meaning, JML is also a research vehicle. Con-
sequently the community’s understanding of the best semantics and of best practices
evolves with further research. Thus the standard intends to be a common basis for
tools and for discussion but does not mean to inhibit experimentation and proposals
for change. Therefore we present a semantical framework in which new tools and ap-
proaches can be defined such that a deviation of the semantics from the standard can
be clearly stated.
The purpose of JML is the specification of Java code in various contexts, ranging from
dealing with isolated research challenges to covering industrial application cases.Moreover,
JML specifications are to be interpreted by tools covering a wide variety of applica-
tions: from formal documentation, runtime assertion checking to full deductive verifi-
cation. To make JML a versatile specification vehicle, the meaning of its annotations
must be unambiguously clear. And if tools interpret a few language constructs differ-
ently, these differences must be easily and concise stated.
1.6 Previous JML reference manual
This reference manual builds on the previous draft JML Reference Manual [1], which
has been evolving over many years and has many contributors. This current edition of
the reference manual is largely a rewrite of the previous draft; it incorporates the expe-
rience of building tools for JML by the OpenJML and Key developers, many decisions
about new features or deprecated features made at JML workshops, and discussions
about JML on the JML mailing lists. This edition of the reference manual includes
features that are proposed enhancements or clarifications of the consensus language
definition. It also includes rationale for non-obvious language features and discussion
of points that are under current debate or require extended explanation.
JML changes as the current version of Java changes. As this document is being written,
Java 8 is the current version of Java, with Java 9 on the horizon. The version of JML
presented here corresponds to Java 8. Java 8 has affected JML by, for example, the
introduction of type annotations and lambda expressions.
1.7 Historical Precedents and Antecedents
To write - take from DRM? INclude description of other languages that have been
CHAPTER 1. INTRODUCTION 6
inspired by JML for other source languages
JML combines ideas from Eiffel [?][?][?] with ideas from model-based specification
languages such as VDM [?] and the Larch family [?][?][?][?]. It also adds some
ideas from the refinement calculus [?][?][?][?][?]. In this section we describe the
advantages and disadvantages of these approaches. Readers not interested in these
historical precedents may want to skip this section.
Formal, model-based languages such as those typified by the Larch family build on
ideas found originally in Hoare’s work. Hoare used pre- and postconditions to describe
the semantics of computer programs in his famous article [?]. Later Hoare adapted
these axiomatic techniques to the specification and correctness proofs of abstract data
types [?]. To specify an ADT, Hoare described a mathematical set of abstract values
for the type, and then specified pre- and postconditions for each of the operations of
the type in terms of how the abstract values of objects were affected. For example, one
might specify a class IntHeap using abstract values of the form empty and add(i,h),
where iis an int and his an IntHeap. These notations form a mathematical vocabu-
lary used in the rest of the specification.
There are two advantages to writing specifications with a mathematically-defined ab-
stract values instead of directly using Java variables and data structures. The first is
that by using abstract values, the specification does not have to be changed when the
particular data structure used in the program is changed. This permits different im-
plementations of the same specification to use different data structures. Therefore the
specification forms a contract between the rest of the program and the implementation,
which ensures that the rest of the program is also independent of the particular data
structures used [?][?][?][?]. Second, it allows the specification to be written even
when there are no implementation data structures, as is the case for IntHeap.
This idea of model-oriented specification has been followed in VDM [?], VDM-SL [?]
[?], Z [?][?], and the Larch family [?]. In the Larch approach, the essential elaboration
of Hoare’s original idea is that the abstract values also come with a set of operations.
The operations on abstract values are used to precisely describe the set of abstract
values and to make it possible to abbreviate interface specifications (i.e., pre- and post-
conditions for methods). In Z one builds abstract values using tuples, sets, relations,
functions, sequences, and bags; these all come with pre-defined operations that can be
used in assertions. In VDM one has a similar collection of mathematical tools to de-
scribe abstract values, and another set of pre-defined operations. In the Larch approach,
there are some pre-defined kinds of abstract values (found in Guttag and Horning’s LSL
Handbook, Appendix A of [?]), but these are expected to be extended as needed. (The
advantage of being able to extend the mathematical vocabulary is similar to one advan-
tage of object-oriented programming: one can use a vocabulary that is close to the way
one thinks about a problem.)
However, there is a problem with using mathematical notations for describing abstract
values and their operations. The problem is that such mathematical notations are an
extra burden on a programmer who is learning to use a specification language. The
solution to this problem is the essential insight that JML takes from the Eiffel lan-
CHAPTER 1. INTRODUCTION 7
guage [?][?][?]. Eiffel is a programming language with built-in specification con-
structs. It features pre- and postconditions, although it has no direct support for frame
axioms. Programmers like Eiffel because they can easily read the assertions, which
are written in Eiffel’s own expression syntax. However, Eiffel does not provide sup-
port for specification-only variables, and it does not provide much explicit support for
describing abstract values. Because of this, it is difficult to write specifications that
are as mathematically complete in Eiffel as one can write in a language like VDM or
Larch/C++.
JML attempts to combine the good features of these approaches. From Eiffel we have
taken the idea that assertions can be written in a language that is based on Java expres-
sions. We also adopt the “old” notation from Eiffel, which appears in JML as \old,
instead of the Larch-style annotation of names with state functions. To make it easy
to write more complete specifications, however, we use various semantic ideas from
model-based specification languages. In particular we use a variant of abstract value
specifications, where one describes the abstract value of an object implicitly using sev-
eral model fields. These specification-only fields allow one to implicitly partition the
abstract value of an object into smaller chunks, which helps in stating frame axioms.
More importantly, we hide the mathematical notation behind a facade of Java classes.
This makes it so the operations on abstract values appear in familiar (although per-
haps verbose) Java notation, and also insulates JML from the details of the particular
mathematical logic used to do reasoning.
1.8 Acknowledgments
Current version: This current rewrite is largely the work of David R. Cok, Gary
Leavens, and Mattias Ulbrich, building on the previous Draft Reference Manual [?]
and discussions by the JML community at various JML workshops [?].
Contributions from David Cok are supported in part by the National Science Founda-
tion: This material is based upon work supported by the National Science Foundation
under Grant No. ACI-1314674. Any opinions, findings, and conclusions or recom-
mendations expressed in this material are those of the author(s) and do not necessarily
reflect the views of the National Science Foundation.
Previous versions:
This is taken from the DRM and needs to be edited/revised/updated.
The work of Leavens and Ruby was supported in part by a grant from Rockwell Inter-
national Corporation and by NSF grant CCR-9503168. Work on JML by Leavens, and
Ruby was also supported in part by NSF grant CCR-9803843. Work on JML by Cheon,
Clifton, Leavens, Ruby, and others has been supported in part by NSF grants CCR-
0097907, CCR-0113181, CCF-0428078, and CCF-0429567. Support from the NSF
continues under a Computing Research Infrastructure (CRI) grant jointly to several in-
stitutions: CNS 08-08913 (Leavens at U. of Central Florida, and a subcontact to Rajan
CHAPTER 1. INTRODUCTION 8
and Basu at Iowa State Unviversity), CNS 07-07874 (Cheon at UTEP), CNS 07-07701
(Clifton at Rose Hulman), CNS 07-07885 (Flanagan at U. Cal. Santa Cruz), CNS 07-
08330 (Naumann at Stevens), and CNS 07-09169 (Robby at Kansas State). The work
of Poll is partly supported by the Information Society Technologies (IST) Programme
of the European Union, as part of the VerifiCard project, IST-2000-26328.
Thanks to Bart Jacobs, Rustan Leino, Peter Müller, Arnd Poetzsch-Heffter, and Joachim
van den Berg, for many discussions about the semantics of JML specifications. Thanks
for Raymie Stata for spearheading an effort at Compaq SRC to unify JML and ESC/-
Java, and to Rustan and Raymie for many interesting ideas and discussions that have
profoundly influenced JML.
Thanks to Leo Freitas, Robin Greene, Jesus Ravelo, and Faraz Hussain for comments
and questions on earlier versions of this document. Thanks to the many who have
worked on the JML checker used to check the specifications in this document. Leavens
thanks Iowa State University and its computer science department for helping foster
and support the initial work on JML.
See the “Preliminary Design of JML” [?] for more acknowledgments relating to the
earlier history, design, and implementation of JML.
Chapter 2
Structure of this Manual
Describe overall organization
2.1 Typographical conventions
The remaining chapters of this book follow some common typographical conventions.
This style of text is used for commentary on the JML language itself, such as outstand-
ing issues or now-obsolete practice.
Boxed examples
comments on how grammars are written; reference to Java grammar
2.2 Grammar
The grammar of JML is intertwined with that of Java. The grammar is given in this
Reference Manual as extensions of the Java grammar, using conventional BNF-style
productions. The meta-symbols of the grammar are in slightly larger, normal-weight,
mono-spaced font. The productions of the grammar use the following syntax:
• non-terminals are written in italics and enclosed in angle brackets: <expression>
• terminals, including punctuation as non-terminals, are written in bold typewriter
font: forall ( ) .
• parentheses express grouping: (... )
9
CHAPTER 2. STRUCTURE OF THIS MANUAL 10
• an infix vertical bar expresses mutually-exclusive alternatives: ... |... |...
• optional elements and repetitions of 0 or more and 1 or more use post-fixed
symbols: ?*+
• a post-fixed ... indicates a comma-separated list of 0 or more elements:
<expression> ...
• a production has the form: <non-terminal> ::= ...
Chapter 3
JML concepts
This chapter describes some general design principles and concepts of the Java Mod-
eling Language. Say more by way of introduction and motivation
JML specifications are declarative statements about the behavior of Java entities, namely,
packages, classes, methods, and fields. is behavioral good for fields? Typically JML
does not make assertions about how a method or class is implemented, only about the
net behavior of the implementation. However, to aid in proving assertions about the
behavior of methods, JML does include statement and loop specifications.
JML is a versatile specifiation vehicle. It can be used to add lightweight specifications
(e.g., specifying ranges for integer values or when a field may hold null) to a program
but also to formulate more heavyweight concepts (like abstracting a linked list into a
sequence of values).
JML annotations are not bound to a particular tool or approach, but can serve as input
to a variety of tools that have different purposes, such as runtime assertion checking,
test case generation, extended static checking, full deductive verification, and docu-
mentation generation.
To date, most work with JML has been concerned with deductive verification. In that
context, specifications and corresponding proof obligations may be considered at dif-
ferent levels of granularities. JML typically is concerned with modular proofs at the
level of Java methods. That is, a verification system will establish that each Java
method of a program is consistent with its own specifications, presuming the speci-
fications of all methods and classes it uses are correct. If this statement is true for
all methods in the program, and all methods terminate, then the system as a whole is
consistent with its specifications. Reference for this claim?
say more about what it would mean to be modular at a different granularity. Perhaps
There should be an entire section on degrees of modularity.
11
CHAPTER 3. JML CONCEPTS 12
3.1 JML and Java compilation units
A Java program is organized as a set of compilation units grouped into packages. The
Java language specification does not stipulate a particular means of storing the Java
program text that constitutes each compilation unit. However, the vast majority of
systems supporting Java programs store each compilation unit as a separate file; the
files constituting a package are organized into directory hierarchies corresponding the
package and class names.
The simplest way of specifying a Java program with JML is to include the text of the
JML specifications directly in the Java source text, as specially formatted comments.
By using specially formatted comments to express JML, any existing Java tools will
ignore the JML text.
However, in some cases the source Java files are not permitted to be modified or it is
preferable not to modify them. Also, the source files may not be available, such as for
a Java class library that is shipped only in byte-code form. In these cases, the JML
specifications must be expressed separate from the Java source program text in a way
that the specifications of packages, classes, methods, and fields can be associated with
the correct Java entity.
Thus, specifications written in JML may either (a) be part of the same text that consti-
tutes a Java compilation unit or (b) be in a separate body of text associated with the Java
compilation unit. For Java language systems in which Java source material is stored in
files, the JML specifications are either in the same file (case (a)) or in a separate file
(case (b)). In case (b), the separate file has a .jml suffix, the same root name as the
corresponding Java source file (typically the name of the public class in the compila-
tion unit), the same package designation, and is stored in the file system’s directory
hierarchy according to its package and class name, similarly to the Java compilation
unit source files. For the rare case in which files are not the basis of Java compilation
units, the JML tools must implement a means, not specified here, to recover JML text
that is associated with Java source text (case (b) above).
3.2 .jml files
MU: I think this section should go into a later chapter, it is to technical here. We
mention all JML artifacts before actually having introduced them.
JML files have a .jml extension and have a similar appearance to the corresponding
.java file. The form follows the following rules. Every .jml files has a corresponding
.java or .class file; where no .java file is available, the rules below refer to the
.java file that would have been compiled to produce the .class file.
The principle present throughout these rules is that declarations in a JML file either
(1) correspond to a declaration in the Java file, having the same name, types, non-JML
modifiers and annotations, or (2) do not correspond to a Java declaration, and then must
CHAPTER 3. JML CONCEPTS 13
have a different name. Declarations that correspond to a Java declaration must not be
in JML comments and must not be marked ghost or model; JML declarations that do
not correspond to Java declarations must be in JML comments and must be marked
ghost or model.
File-level rules
• The .jml file has the same package declaration as the .javafile.
• The .jml file may have a different set of import statements and may, in addition,
include model import statements.
• The .jml file must include a JML declaration of the public type (i.e., class or
interface) declared in the .java file. It may but need not have JML declarations
of non-public types present in the .java class. Any type declared in the .jml
file that is not present in the .java file must be in a JML comment and must
have a model modifier.
Class declarations
• The JML declaration of a class and the corresponding Java declaration must
extend the same superclass, implement the same set of interfaces, and have
the same set of non-JML modifiers (public,protected,private,static,
final,What others ). The JML declaration may add additional JML modifiers
or annotations.
• Nested and inner class declarations within an enclosing non-model JML class
declaration must follow the same rules as file-level class declarations: they must
either correspond in name and properties to a corresponding nested or inner Java
class declaration or be a model class.
• JML model classes need not have full implementations, as if they were Java
declarations. However, if runtime-assertion checking tools are expected to check
or use a model class, it must have a compilable and executable declaration.
Interface declarations
• The JML declaration of a interface and the corresponding Java declaration must
extend the extend the same set of interfaces and have the same set of non-JML
modifiers (public,protected,private,static,What others ). The JML
declaration may add additional JML modifiers or annotations.
•Comment on static and instance; no initializer for JML field declarations
Method declarations
• Methods declared in a non-model JML type declaration must either correspond
precisely to a method declared in the corresponding Java type declaration or be a
model method. Correspond precisely means having the same name, exactly the
same argument and return types, and the same set of exceptions. MU: look into
JLS and check if that is “same signature”
CHAPTER 3. JML CONCEPTS 14
• Methods that correspond to Java methods must not be declared model and must
not have a body. They must have the same set of non-JML modifiers and an-
notations as the Java declaration, but may add additional JML modifiers and
annotations.
• A Java method of a class or interface need not have a JML declaration (in which
case various default specifications might apply).
Field declarations
• Fields declared in a non-model JML type declaration must either correspond
precisely to a field declared in the corresponding Java type declaration or be a
model or ghost field. Correspond precisely means having the same name and
type and non-JML modifiers and annotations. The JML declaration may add
additional JML modifiers and annotations.
• A JML field declaration that corresponds to a Java field declaration may not be
in a JML comment, may not be model or ghost and must not have an initializer.
• A JML field declaration that does not correspond to a Java field declaration must
be in a JML comment and must be either ghost or model.
•ghost field declarations have the same grammatical form as Java declarations,
except that they may use JML types and operators and may refer to names de-
clared in other ghost or model declarations.
•model field declarations have the same grammatical form as Java declarations,
except that they may use JML types and operators; they may not have initializers.
• A Java field of a class or interface need not have a JML declaration (in which
case various default specifications might apply).
Initializer declarations
• A Java class may contain declarations of static or instance initializers. A JML
redeclaration of a Java class may not have any initializers.
• A JML model class may have initializer blocks.
3.2.1 Combining Java and JML files
The specifications for the Java declarations within a Java compilation unit are deter-
mined as follows.
• If there is a .java file and no corresponding .jml file, then the specifications
are those present in the .java file.
• If there is no .java file, but there is a class files and a corresponding .jml file,
then the specifications are those present in the .jml file.
• If there is no .java file and no .jml file, only a .class file, then default speci-
fications are used. Where described?
CHAPTER 3. JML CONCEPTS 15
If there is a .java file and a corresponding to a .jml file, then the JML specification
present in the .jml file supersedes all of the JML specifications in the .java file; those
in the .java file are ignored, even where there is no method declared in the .jml
file corresponding to a method in the .java file. In this case processing proceeds as
follows. First all matches among type declarations are established recursively:
• Top-level types in each file are matched by name. The type-checking pass checks
that the modifiers, superclass and super interfaces match. JML classes that match
are not model and are not in JML comments; JML classes that do not match must
be model and must be in JML comments. Not all Java declarations need have
a match in JML; those that have no match will have default specifications. The
specifications for a Java
• Model types contain their own specifications and are not subject to further match-
ing.
• For each non-model type, matches are established for the nested and inner type
declarations in the .jml and .java declarations by the same process, recur-
sively.
The for each pair of matching JML and Java declarations, matches are established for
method and field declarations.
• Field declarations are matched by name. Type-checking assures that declarations
with the same name have the same type, modifiers and annotations.
• Method declarations are matched by name and signature. This requires that all
the processing of import statements and type declarations is complete so that
type names can be properly resolved.
For each pair of matching declarations, the JML specifications present in the .jml file
give the specifications for the Java entity being declared. If there is a .jml file but
no match for a particular Java declaration in the corresponding .java file, then that
declaration uses default specifications, even if the h.java file contains specifications.
The contents of the .jml file supersede all the JML contents of the .java file; there is
no merging of the files’ contents. 1Be sure we want
this superseding
deign rather than
merging – could
use specs in the
Java file if there
is no JML dec-
laration, just not
merge when both
have JML decla-
rations.
3.3 Specification inheritance
Object-oriented programming with inheritance requires that derived classes satisfy the
specifications of a parent class, a property known as behavioral subtyping[?]. Strong
behavioral subtyping is a design principle in JML: any visible specification of a par-
ent class is inherited by a derived class. Thus derived types inherit invariants from
1Previous definitions of JML did require merging of specifications from multiple files; this requirement
added complexity without appreciable benefit. The current design is simpler for tools, with the one drawback
that the JML contents of a .java file is silently ignored when a .jml file is present, even if that .jml file
does not contain a declaration of a particular entity.
CHAPTER 3. JML CONCEPTS 16
their parent types and methods inherit behaviors from supertype methods they over-
ride.
For example, suppose method min derived class Coverrides method min parent class
P. In a context where we call method mon an object owith static type P, we will expect
the specifications for P.m to be obeyed. However, omay have dynamic type C. Thus
C.m, the method actually executed by the call o.m(), must obey all the specifications of
P.m.C.m may have additional specifications, that is, additional behaviors, constraining
its behavior further, but it may not relax any of the specifications given for P.m.
Specifications that are not visible in derived classes, such as those marked private,
are not inherited, because a client cannot be expected to obey specifications that it
cannot see. One additional exception to specification inheritance is method behaviors
that are marked with the code modifier??. these behaviors apply only to the method of
the class in which the behavior textually appears.
3.4 JML modifiers and Java annotations
The Java Modeling Language was defined prior to the introduction of annotations in
Java. Some, but not all, of the features of JML can now be textually represented as Java
annotations. Currently JML supports both the old and new syntactic forms.
3.4.1 Modifiers
Modifiers are JML keywords that specify JML characteristics of methods, classes,
fields, or variables. Examples are pure,model, and ghost. They are syntactically
placed just like Java modifiers, such as public.
Each such modifier has an equivalent Java annotation. For example
/*@ pure */ public int m(int i) ...
can be written equivalently as
@org.jmlspecs.annotation.Pure public int m(int i) ...
The org.jmlspecs.annotation prefix can be made implicit in the usual way by in-
cluding the import statement
import org.jmlspecs.annotation.Pure;
@Pure public int m(int i) ...
Note that in the second and third forms, the pure designation is now part of the Java
program and so the import of the org.jmlspecs.annotation package must also be
in the Java program, and the package must be available to the Java compiler.
CHAPTER 3. JML CONCEPTS 17
All of the modifiers, their corresponding Java annotations, and the locations in which
they may be used are described in §F.3.5.
3.4.2 Type modifiers
Some modifiers are actually type modifiers. In particular non_null and nullable are
in this category. Thus the description of the previous subsection (§F.1) apply to these
as well.
However, Java 1.8 allows Java annotations to be applied to types wherever type names
may appear. For example
(@NonNull String)toUpper(s)
is allowed in Java 1.8 but is forbidden in Java 1.7.
Need additional discussion of the change in JML for Java 1.8, especially for arrays.
3.5 Model and Ghost
To be written
3.6 Visibility
To be written - note material written in Method Specifications section
3.7 Evaluation and well-formedness of JML expressions
To be written - note material written in Expressions chapter
3.8 Null and non-null references
To be written
Discuss defaults for binary classes; also default specification
Nonnullbydfault is an extension?
CHAPTER 3. JML CONCEPTS 18
3.9 Static and Instance
To be written
3.10 Observable purity
To be written - perhaps this is a separate chapter It might be early days to put this into
the standard.
3.11 Location sets and Dynamic Frames
To be written - see section in DRM on Data Groups
3.12 Arithmetic modes
To be written - see later chapter - where shall we put this discussion
3.13 Immutable types and functions
To be written These are the abstract data types I take it.
3.14 Race condition detection
To be written - see later chapter - where shall we put this discussion Should that be
part of the standard?
3.15 Redundant specifications
To be written
3.16 Controlling warnings
To be written - nowarn specifications - perhaps in the Syntax chapter; comment on
possibility of unsoundness
CHAPTER 3. JML CONCEPTS 19
3.17 org.jmlspecs.lang package
Some JML features are defined in the org.jmlspecs.lang package. The org.jmlspecs.lang
package is included as a model import by default, just as the java.lang package is
imported by default in a Java file. org.jmlspecs.lang.* contains (at least2) these
elements:
•JML.informal(<string> ): This method is a replacement for (and is equiv-
alent to) the informal expression syntax (§??)(* ... *). Both expressions
return a boolean value, which is always true.
• TBD
3.18 Interaction with other tools
3.18.1 Interaction with Type Annotations in Java 1.8
To be written
3.18.2 Interaction with the Checker framework
To be written
3.18.3 Interaction with FindBugs
To be written
3.19 Core JML
This standardization document describes all of JML. However, some portions of the
language are considered Core, whereas others might be conveniences, are rarely used
or applicable only in less common situations. This leaves it possible that some tools
might only implement the Core.
The following table identifies the Core functionality and indicates which tools imple-
ment which items.
Also some syntactical redundancy features are not part of the core.
The entries in the table have these meanings:
2Tools implementing JML may add additional methods.
CHAPTER 3. JML CONCEPTS 20
•Core– an JML construct in the Core
• 1 – part of level 1 above Core
•Ext- an extension to JML (not defined as standard)
•Dep- deprecated features of JML
•–– not supported by tool
•––– not supported by tool
•+– supported by tool
•ESC– supported by tool for static checking only (not runtime)
•RAC– supported by tool for runtime checking only (not static)
•++- supported by tool
This table is being edited and is not correct
keyword Core KeY OpenJML Comments
<== 1++
<==> Core ++ +
==> Core ++ +
//@ Core ++ +
/*@ @*/ Core ++ +
(* *) 1–– + MU: If we find a
good semantics
accessible ++ –
also + ++ +
assert + ++ +
assignable + ++ + KeY: also for loops!
assume ++ +
axiom ++ +
behavior + ++ + MU: BrE is syntactic
sugar
\\bigint + ++ +
code +– +
constraint ++ +
\count +– +
decreases + ++ +
diverges + ++ +
\dl_ –– MU: or some other
means of tool-spec
exts.
\elemtype ++
ensures + ++
\everything ++
exceptional_behavior + ++
CHAPTER 3. JML CONCEPTS 21
keyword Core KeY OpenJML Comments
\exists + ++
\forall + ++
\fresh + ++
ghost + ++
helper + ++
\\index + ++ the new addition dis-
cussed in Bad Her.
initially +?
instance +––
\invariant_for + ++
\locset + ++ builtin datatype
loop_invariant + ++ maintains might be
more systematic
\max + ++ semantics interesting
measured_by ++ generalised version with list of items
\min + ++
model + ++ fields, methods
model –– classes
model ––– import statements
non_null + ++
\nonnullelements ++
normal_behavior + ++
no_state –+
\nothing + ++
nullable + ++
nullable_by_default + ++
\num_of ++
\old + ++ w/o label
\old –+ w/ label
private + ++ for invariants and
contracts
\product + ++
protected +– for invariants and
contracts. Meaning
must be clarified.
pure + ++ @Pure is syntactic
sugar
\real + ++
represents + ++
requires + ++
\result + ++
signals + ++
signals_only + ++
spec_bigint_math ++
spec_java_math ++
CHAPTER 3. JML CONCEPTS 22
keyword Core KeY OpenJML Comments
spec_protected + ++
spec_public + ++
spec_safe_math +–
\static_invariant_for – ++
\strictly_nothing Ext – +
strictly_pure Ext – +
\sum 1++
two_state Ext + –
\type 1–+
\TYPE 1–+
\typeof Core – +
\values Core + +
block contracts 1 ++ +
annotations instead of modifiers 1 –+I would not add them
to the core, but ex-
plain them only in an
appendix on syntac-
tical variations. It
should be added to
the core when anno-
tations are an alterna-
tive for all specifica-
tions
// comments in specs 1 ++ +
// JML in Javadoc Dep – –
{| ... |} –not widely used, is it?
New primitive datatype \locset with the following operators: (Reification of data-
groups / regions)
•\nothing only existing locations
•\everything all locations
•\empty no location at all: The empty set.
•\union(...)arbitrary arity
•\intersect(...)arbitrary arity
•\minus(·,·)
•\subset(·,·)
•\disjoint(...)pairwise disjointness
CHAPTER 3. JML CONCEPTS 23
•(\collect ...; ...; ...) a variable binder in the sense of
[
x|j
locs(x)=(\collect Tx;j;locs(x)),
e.g., (\collect int i; 0<=i && 2*i<a.length; a[2*i]) is the set of all
locations in a[⇤]with even index.
Often needed for things like (\collect Person p; set.contains(p); p.footprint).
•\new_elements_fresh(·)with the meaning
\new_elements_fresh(ls):=8l2ls.l2\old(ls)_\fresh(ob ject(l))
. This is used to confine the extension of a location set in a postcondition to
objects which have been recently created. This is important to guarantee framing
in dynamic frame specifications. This is sometimes called the swinging pivot
property. (Reasoning is usually: If ls1and ls2are disjoint before a method and
both ls1is not touched and ls2grows only into fresh objects, then ls1and ls2are
still disjoint after the method.)
Chapter 4
JML Syntax
These first two sections need to be merged
4.1 Textual form of JML specifications
JML text is expressed in specially-formatted Java comments. Java comments either
• (a) begin with the characters // and extend through the end of the line or
• (b) begin with the characters /* and extend through the next occurrence of the
characters */, possibly spanning multiple lines.
Unconditional JML text either
• (a) begins with the text //@ and extends through the end of the line or
• (b) begins with the text /*@ and extends through the next occurrence of */.
Any @symbols within JML text and not inside string or character constants are consid-
ered white space. Typical uses of such white space @ symbols are at the beginning of
JML text, the end of text or the beginnings of lines within text, as shown in the example
below. Only the use at the beginning of lines or just before the closing */ is common
(or suggested).
/*
@@@@@@@@@@@@@@@@@@@@@@@@
@ requires x > 0;
@ensures\result<0;
@@@@@@@@@@@@@@@@@@@@@@@@ */
Conditional JML text includes some non-whitespace characters between the // or /*
and the @at the beginning of the comment. That text has the syntax ([+|-]<java-identifier>)+,
that is, one or more Java-identifiers, each preceded by either a +or a -. No white space
is permitted between the initial // or /* and the @that follows the conditional keys. A
24
CHAPTER 4. JML SYNTAX 25
Java-identifier is a sequence of alphanumeric characters, underscores and dollar signs,
that does not begin with a digit.
The conditional JML text feature presumes that the JML tool processing the JML text
has a means to define various identifiers for the purpose of selecting or deselecting
JML text. An identifier occurring before the @in a given JML comment is positive if it
is directly preceded by a +sign and negative if directly preceded by a -sign. The JML
text in a conditional comment is included or ignored according to this rule.
• A conditional JML comment is included if (and only if) none of its negative
identifiers (if any) are defined and there is at least one positive identifier that is
defined.
Here are some examples, presuming the JML tool has defined the identifiers OPTA and
OPTB, but not the identifier OPTC.
/*@... */ included unconditionally
/*+OPTA@ . . . */ included because OPTA is defined and is positive
/*+OPTC@ . . . */ ignored because OPTC is not defined
/*OPTA@ . . . */ ignored because OPTA is defined and but is negative
/*OPTC@ . . . */ ignored because OPTC is not defined
/*+OPTA+OPTC@ . . . */ ignored because OPTA is defined and positive , even though OPTC is not defined
/*+OPTAOPTC@ . . . */ ignored because OPTA is defined and positive , because though OPTC is negative it is not defined
/*+OPTAOPTB@ . . . */ ignored because OPTB is defined and is negative , even though OPTA is defined and positive
JML reserves the following identifiers:
•DEBUG : not defined by default; when defined, the JML debug statement is en-
abled
•ESC : tools should define this identifier when doing static checking
•RAC : tools should define this identifier when doing runtime checking
Issues with the JML textual format There are two issues that can arise with the
syntactical design of JML. First, other tools may also use the @symbol to designate
comments that are special to that tool. If JML tools are trying to process files with such
comments, the tolls will interpret the comments as JML comments, likely causing a
myriad of parsing errors.
Second, Java uses the @sign to designate Java annotations. That in itself is not an ambi-
guity, but sometimes users will comment out such annotations with a simple preceding
//, as in
//@MyAnnotation
This construction now looks like JML. The solution is to be sure there is whitespace
between the // and the @, but it may not always be possible for the user to perfom such
edits.
CHAPTER 4. JML SYNTAX 26
4.2 JML Syntax
4.2.1 Syntax of JML specifications
JML specifications may be written as Java annotations. Currently these are only imple-
mented for modifiers (cf. section TBD). In Java 8, the use of Java annotations for JML
features will be expanded.
JML specifications may also be written in specially formatted Java comments: a JML
specification includes everything between either (a) an opening /*@ and closing */ or
(b) an opening //@ and the next line ending character (\n or \r) that is not within a
string or character literal.
Such comments that occur within the body of a class or interface definition are consid-
ered to be a specification of the class, a field, or a method, depending on the kind
of specification clause it is. JML specifications may also occur in the body of a
method.
Obsolete syntax. In previous versions of JML, JML specifications could be placed
within javadoc comments. Such specifications are no longer standard JML.
4.2.2 Conditional JML specifications
JML has a mechanism for conditional specifications, based on a system of keys. A
key is an identifier (consisting of ASCII alphanumeric and underscore characters, and
beginning with a non-digit). A conditional JML comment is guarded by one or more
positive or negative keys (or both). The keys are placed just before the @character that
is part of the opening sequence of the JML comment (the //@ or the /*@). Each key
is preceded by a ’+’ or a ’-’ sign, to indicate whether it is a positive or negative key,
respectively. No white-space is allowed. If there is white-space anywhere between the
initial // or /* and the first @character, the comment will appear to be a normal Java
comment and will be silently ignored.
The keys are interpreted as follows. Each tool that processes the Java+JML input will
have a means (e.g., by command-line options) to specify the set of keys that are en-
abled.
• If the JML annotation has no keys, the annotation is always processed.
• If there are only positive keys, the annotation is processed only if at least one of
the keys is enabled.
• If there are only negative keys, the annotation is processed unless one of the keys
is enabled.
CHAPTER 4. JML SYNTAX 27
• If there are both positive and negative keys, the annotation is processed only if
(a) at least one of the positive keys is enabled AND (b) none of the negative keys
are enabled.
JML previously defined one conditional annotation: those that began with /*+@ or
//+@. ESC/Java2 also defined /*-@ and //-@. Both of these are now deprecated.
JML defines the following keys, which conforming tools must support. Tools may also
define keys of their own and should silently ignore keys they do not recognize. It is
expected that each tool will define at least one key that can enable any extensions that
tool implements or disable JML features not supported by the tool.
•ESC : the ESC key is enabled when a tools is performing ESC static checking;
•RAC : the RAC key is enabled when a tool is compiling for Runtime-Assertion-
Checking.
•DEBUG : The DEBUG key is not implicitly enabled. However it is defined as
the key that enables the debug JML statement. That is the debug statement is
ignored by default and is used by tools if the user enables the DEBUG key.
•OPENJML : The OPENJML key is enabled whenever the OpenJML tool is
processing annotations (and presumably is not enabled by other tools).
•KEY: The KEY key is reserved for use by the KeY tool [?], and should be ignored
by other tools.
Thus, for example, one can turn off a non-executable assert statement for RAC-processing
but retain it for ESC and for type-checking by writing //-RAC@ assert ...
Chapter 5
JML Types
All of the Java type names are legal and useful in JML: int short long byte char
boolean double real and class and interface types. In addition, JML defines some
additional types, described in subsections below. There are two needs that JML ad-
dresses:
• Specifications are sometimes best written using infinite-precision mathematical
types, rather than the fixed bit-width types of Java. JML’s arithmetic modes (§??)
allow choosing among various numerical precisions.
• Java’s handling of class types only expresses erased types; JML adds a type and
operations for expressing and reasoning about generic types.
Location set type? Object set type?
5.1 \bigint
The \bigint type is the set of mathematical integers (i.e., Z). Just as Java primitive
integral types are implicitly converted to int or long, all Java primitive integral types
implicitly convert to \bigint where needed. When \bigint values need to be auto-
boxed into an Object, they are boxed as java.math.BigInteger values; similarly
when JML specifications are compiled for runtime checking, \bigint values are rep-
resented as java.math.BigInteger values. Within JML specifications, however, the
\bigint type is treated as a primitive type.
For example, == with two \bigint eperands expresses equality of the represented
integers, not (Java) identity of BigInteger objects.
The familiar operators are defined on values of the \bigint type: unary and binary +
and -,*,/,%. Also, these types can be used in quantified expressions and variables of
these types can be declared as ghost or model variables.
28
CHAPTER 5. JML TYPES 29
5.2 \real
The \real type is the set of mathematical real numbers (i.e., R). Just as the Java
primitive type float is implicitly converted to double, both real and double values
implicitly convert to \real where needed. When \real values need to be auto-boxed
into an Object, they are boxed as ???TODO values; similarly when JML specifications
are compiled for runtime checking, \real values are represented as ???TODO values.
Within JML specifications, however, the \real type is treated as a primitive type.
Integral values, including \bigint, are implicitly converted to \real where neces-
sary.
The familiar operators are defined on values of the \real type: unary and binary +and
-,*,/,%. Also, these types can be used in quantified expressions and variables of these
types can be declared as ghost or model variables.
5.3 \TYPE
TODO
OLD STUFF:
The set of \TYPE values includes non-generic types such has \type(org.lang.Object),
fully parameterized generic types, such as \type(org.utils.List<Integer>), and
primitive types, such as \type(int). The subtype operator (<:) is defined on values
of type \TYPE.
TBD - what about other constructors or acccessors of TYPE values
Chapter 6
JML Specifications for Packages
and Compilation Units
There are no JML specifications at the package level. If there were, they would likely
be written in package-info.java file. The only JML specifications that are defined
at the file level, applying to all classes defined in the file, are model import state-
ments.
6.1 Model import statements
Add in top-level model classes
Java’s import statements allow class and (with static import statements) field names to
be used within a file without having to fully qualify them. The same import statements
apply to names in JML annotations. In addition, JML allows model import statements.
The effect of a JML model import statement is the same as a Java import statement,
except that the names imported by the JML statement are only visible within JML
annotations. If the model import statement is within a .jml file, the imported names are
visible only within annotations in the .jml file, and not outside JML annotations and
not in a corresponding .java file. These are import statements that only affect name
resolution within JML annotations and are ignored by Java. They have the form
//@ model <Java import statement>
Note that the Java import statement ends with a semicolon.
Note that both
model <Java import statement>;
30
CHAPTER 6. JML SPECIFICATIONS FOR PACKAGES AND COMPILATION UNITS31
and
/*@ model */<Java import statement>;
are invalid. The first is not within a JML comment and is illegal Java code. The sec-
ond is a normal Java import with a comment in front of it that would have no addi-
tional effect in JML, even if JML recognized it (tools should warn about this erroneous
use).
6.2 Default imports
The Java language stipulates that java.lang.* is automatically imported into ev-
ery Java compilation unit. Similarly in JML there is an automatic model import of
org.jmlspecs.lang.*. However, there are not yet any standard-defined contents of
the org.jmlspecs.lang package. Is this correct?
6.3 Issues with model import statements
As of this writing, no tools distinguish between Java import statements and JML import
statements. Such implementations may resolve names in Java code differently than the
Java compiler does. Consider two packages pa and pb each declaring a class N.
1)
import pa.N;
//@ model import pb.N;
Correct behavior: In Java code Nis pa.N; in JML code, Nis ambiguous.
Non-conforming behavior: JML tools consider Nin Java code to be ambiguous.
2)
import pa.N;
//@ model import pb.*;
Correct behavior: In Java code Nis pa.N; in JML code, Nis pa.N.
Non-conforming behavior: non-conforming JML tools will act correctly in this case.
3)
import pa.*;
//@ model import pb.N;
Correct behavior: In Java code Nis pa.N; in JML code, Nis pb.N.
Non-conforming behavior: JML tools consider Nin Java code to be pb.N.
CHAPTER 6. JML SPECIFICATIONS FOR PACKAGES AND COMPILATION UNITS32
4)
import pa.*;
//@ model import pb.*;
Correct behavior: In Java code Nis pa.N; in JML code, Nis ambiguous.
Non-conforming behavior: JML tools consider Nin Java code to be ambiguous.
Chapter 7
Specifications for Java types in
JML
By types in this reference manual we mean classes, enums, and interfaces, whether
global, secondary, local, or anonymous. Some aspects of JML, such as the allowed
modifiers, will depend on the kind of type being specified.
Need to work out specs for enum types
Specifications at the type level serve three different primary purposes: specifications
that are applied to all methods in the type, specifications that state properties of the data
structures in the type, and declarations that help with information hiding.
7.1 Modifiers for type declarations
Modifiers are placed just before the construct they modify. Example Java modifiers
are public and static. JML modifiers may be in their own annotation comments or
grouped with other modifiers, as shown in the following example code.
//@ pure
public class C {...}
public /*@ pure nullable_by_default */ class D {...}
33
CHAPTER 7. SPECIFICATIONS FOR JAVA TYPES IN JML 34
7.1.1 non_null_by_default, nullable_by_default, @NonNullByDe-
fault, @NullableByDefault
The non_null_by_default and nullable_by_default modifiers or, equivalently,
the @NonNullByDefault and @NullableByDefault Java annotations, specify the
default nullity declaration within the class. The default applies to all field and local
variable declarations, to formal parameters and method return values, and recursively
to any nested or inner classes that do not have default nullity declarations of their
own.
These default nullity modifiers are not inherited by derived classes.
A class cannot be modified by both modifiers at once. If a class has no nullity modifier,
it uses the nullity modifier of the enclosing class; the default for a top-level class is
non_null_by_default. This top-level default may be altered by tools.
7.1.2 pure and @Pure
Specifying that a class is pure means that each method and nested class within the class
is specified as pure. The pure modifier on a class is not inherited by derived classes,
though pure modifiers on methods are.
There is no modifier to disable an enclosing pure specification.
7.1.3 @Options
The @Options modifier takes a String argument, which is a string of command-line
options and corresponding arguments. These command-line options are applied to the
processing (e.g., ESC or RAC) of each method within the class. The options may be
augmented or disabled by corresponding @Options modifiers on nested methods or
classes. In effect, the options that apply to a given class are the concatenation of the
options given for each enclosing class, from the outermost in.
An Options modifier is not inherited by derived classes.
Or does Option take an array of String
7.2 invariant clause
TODO
CHAPTER 7. SPECIFICATIONS FOR JAVA TYPES IN JML 35
7.3 constraint clause
TODO
7.4 initially clause
Grammar:
An initially clause for a type is equivalent to an additional postcondition for each
constructor of the type, as if an additional ensures clause (with the predicate stated by
the initially clause) is added to every behavior of each constructor in the type.
Say more about initially clauses in interfaces and enums
7.5 ghost fields
TODO
7.6 model fields
TODO
7.7 represents clause
TODO
7.8 model methods and model classes
TODO
7.9 initializer and static_initializer
TODO
CHAPTER 7. SPECIFICATIONS FOR JAVA TYPES IN JML 36
7.10 axiom
TODO
7.11 readable if clause and writable if clause
TODO
7.12 monitors_for clause
TODO
Chapter 8
JML Method specifications
Method specifications describe the behavior of the method. JML is a modular speci-
fication methodology, with the Java method being the fundamental unit of modularity.
The specifications may under-specify a method. For example, the specifications may
simply say that the method always returns normally (that is, without throwing an ex-
ception), but give no constraints on the value returned by the method. The degree of
precision needed will depend on the context.
8.1 Structure of JML method specifications
<method-spec> ::= (also )?<behavior-seq>
(also implies_that <behavior-seq> )?
(also for_example <behavior-seq> )?
<behavior-seq> ::= <behavior> (also <behavior> )*
<behavior> ::=
((<java-visibility> (code )?<behavior-id> )?<clause-seq> )
|<java-visibility> (code )?<model-program>
<java-visibility> ::= (public |protected |private )?
<behavior-id> ::= behavior |normal_behavior |exceptional_behavior
|behaviour |normal_behaviour |exceptional_behaviour
<clause-seq> ::= (<clause> |<nested-clause> )+
<clause> ::=
<requires-clause>
|<assignable-clause>
|<ensures-clause>
|<signals-clause>
37
CHAPTER 8. JML METHOD SPECIFICATIONS 38
|<signals-only-clause>
|<diverges-clause>
|<measured-by-clause>
|<duration-clause>
|<when-clause>
|<old-clause>
|<forall-clause>
|<working-space-clause>
|<accessible-clause>
|<callable-clause>
|<captures-clause>
|<method-program-block>
<nested-clause> ::= {| <clause-seq> (also <clause-seq> )*|}
Meta-parser rules:
• Each of the behavior keywords spelled behaviour is equivalent to the corre-
sponding keyword spelled behavior. The latter is more common.
• A behavior beginning with normal_behavior may not contain a <signals-clause>
or a <signals-only-clause>. It implicitly contains the clause signals (Exception
e) false;.
• A behavior beginning with exceptional_behavior may not contain a <ensures-
clause>. It implicitly contains the clause ensures false;.
• Clause ordering: in any consecutive sequence of <clause>, any <old-clause>
and <forall-clause> must appear before any <requires-clause>, which must ap-
pear before any other clauses. It is a JML extension to allow clauses in any order.
However, even in that case:
• The order of <requires-clause> and <old-clause> clauses is significant in the
same way that the order of terms in a short-circuit boolean expression is sig-
nificant: earlier <requires-clause> expressions may state conditions that enable
later ones to be well-defined.
• Any declarations in <old-clause> and <forall-clause> clauses must precede any
uses of the declared variables.
• The order of <ensures-clause>s is also significant in that earlier expressions can
assert conditions that are required for later expressions to be well-defined.
Is this a requirement or a style recommendation?
•May any clauses appear after a nested-clause?
Note that the vertical bars in the production for nested-clause are literals, not meta-
symbols.
OK to relax the rules on which clauses can be present where in parsing, and then
enforce or advise in later checking?
CHAPTER 8. JML METHOD SPECIFICATIONS 39
FIXME - the method-spec production is not correct - the first also might be omitted
whichever one it is
8.1.1 Behaviors
The basic structure of JML method specifications is as a set of behaviors. Each be-
havior contains a set of clauses. The various kinds of clauses are described in the
subsequent sections of this chapter. Each kind of clause has a default, which applies
if the clause is textually absent from the behavior. A particular kind of clause is the
requires clause, which gives the precondition for the behavior; the other clauses state
the properties that are true about the method’s execution.
For each behavior, if the method is called in a context in which the behavior’s precon-
dition is true, then the method must adhere to the constraints specified by the remaining
clauses of the behavior. Not all of the preconditions need be true, but at least one of
them must be, otherwise the method is being called in a context in which its behavior
is undefined. For example, a method’s specification may have two behaviors, one with
a precondition that the method’s argument is not null, and the other behavior with a
precondition that the method’s argument is null. In this case, in any context, one or the
other behavior will be active. If however, the second behavior were not specified, then
it would be a violation to call the method in any context other than those in which the
first precondition, that the argument is not null, is true. More than one behavior may be
active (have its precondition true); every active behavior must be obeyed by the method.
Where preconditions are not mutually exclusive, care must be taken that the behaviors
themselves are not contradictory, or it will not be possible for any implementation to
satisfy the combination of behaviors.
8.1.2 Nested specification clauses
Nested specification clauses are syntactic shorthand for an expanded equivalent in
which clauses are replicated. The nesting syntax simply allows expressing common
subsequences of clauses to be expressed without repetition, where that helps under-
standability.
In particular, referring to the grammar above, a <behavior> whose <clause-seq> con-
tains a <nested-clause> is equivalent to a sequence of <behavior>s as follows:
if <nested-clause>Ais a combination of n <clause-seq> as in
{| <clause-seq>S1(also <clause-seq>Si )*|}
then
(<java-visibility>V(code)?W<behavior-id>X)?<clause>⇤D<nested-clause>A<clause-seq>E
is equivalent to a sequence of n <behavior> constructions
(<java-visibility>V(code)?W<behavior-id>X)?<clause>⇤D<clause-seq>S1<clause-seq>E
also
...
CHAPTER 8. JML METHOD SPECIFICATIONS 40
also
(<java-visibility>V(code)?W<behavior-id>X)?<clause>⇤D<clause-seq>Sn<clause-seq>E
Is there a better way to describe this desugaring? and a better way to format it?
8.1.3 Specification inheritance and the code modifier
The behaviors that apply to a method are those that are textually associated with the
method (that is, they precede the method definition in the .java or .jml file) and those
that apply to methods overridden by the given method. In other words, method speci-
fications are inherited (with exceptions given below), as was described in §3.3.
Specification inheritance has important consequences. A key one relates to precondi-
tions. The composite precondition for a method is the disjunction of the preconditions
for each behavior, including the behaviors of overridden methods. Thus, just looking at
the behavior within a method, one might not immediately realize that other behaviors
are permitted and that the precondition is more accepting.
There are a few cases in which behaviors are not inherited:
• Since static methods are not overridden, their behaviors are also not inherited.
• Since private methods are not overridden, their behaviors are also not inherited.
•private behaviors are not inherited.
• Behaviors marked with the code modifier are not inherited.
The code modifier is unique in that it applies to method behaviors and nowhere else
in JML. It is specifically used to indicate that the behavior is not inherited. The code
modifier is allowed but not necessary if the behavior would not be inherited anyway.
The code modifier is not allowed if the method does not have a body; so it is not used
on an abstract method declaration, unless that method is marked default (in Java) and
has a body.
Java allows a class to extend multiple interfaces. More than one interface might de-
clare behaviors for the same method. An implementation of that method inherits the
behaviors from all of its interfaces (recursively) .
8.1.4 Visibility
The following discussion has some errors and needs fixing; also need to talk about
spec_public, spec_protected
Each method specification behavior has a java-visibility (cf. the discussion in §??).
Any of the kinds of behavior keywords (behavior,normal_behavior,exceptional_behavior)
may be prefixed by a Java visibility keyword (public,protected,private); the ab-
sence of a visibility keyword indicate package-level visibility. A lightweight behavior
(one without a behavior keyword) has the visibility of its associated method.
CHAPTER 8. JML METHOD SPECIFICATIONS 41
Table 8.1: Visibility rules for method specification behaviors
Behaviors with this visibility may contain names that are visible in
the class because of this visibility
public public
protected public, protected-by-inheritance
package public, protected-by-package, package
private any
The visibility of a behavior determines the names that may be referenced in the behav-
ior. The general principle is that a client that has permission to see the behavior must
have permission to see the entities in the behavior. Thus
any name (of a type, method or field) in a method specification
visible to a client must also be visible to the client.
For example, a public behavior may contain only public names. A private behavior may
contain any name visible to a client that can see the private names; this would include
other private entities in the same or enclosing classes, any public name, any protected
name from super classes, and any package or protected name from other classes in the
same package. The visibility for protected and package behaviors is more complex.
A protected behavior is visible to any client in the same or subclasses; since the sub-
classes may be in a different package, the protected behavior may contain other names
with protected visibility only if they are visible in the behavior by virtue of inheritance,
and not if the are visible only because of being in the same package. To be explicit,
suppose we have class A, unrelated class B in the same package, class C a superclass
of A in a different package, and class D derived from A but in a different package, with
identifiers A.a, B.b, and C.c each with protected visibility. Only A.a and C.c are visible
in class D; thus a protected behavior in class A, which is visible to D, may contain
A.a and C.c but not B.b. Similarly a behavior with package visibility may only con-
tain names that are visible by virtue of being in the same package (and public names);
names with protected visibility that are visible in a class by virtue of inheritance are
not necessarily visible to clients who can see the package-visible behavior.
The root of the complexity is that protected visibility is not transitive, whereas the other
kinds of Java visibility are. Conceptually, protected visibility must be separated into
two kinds of visibility: protected-by-inheritance and protected-by-package. Each of
these is separately transitive. Then the visibility rules can be summarized in Table 8.1.
8.1.5 Grammar of method specifications
Fillin – remember lightwieght, behavior, normal_behavior, exceptional_behavior, ex-
amples, implies_that, visibility, model program behaviors, also, nested behaviors
CHAPTER 8. JML METHOD SPECIFICATIONS 42
Do we relax the ordering and the constraints on nesting that are in the current Ref-
Man
Comment on comparison with ACSL
8.2 Method specifications as Annotations
8.3 Modifiers for methods
TODO
8.4 Common JML method specification clauses
TODO
8.4.1 requires clause
TODO
8.4.2 ensures clause
TODO
8.4.3 assignable clause
TODO
8.4.4 signals clause
TODO
8.4.5 signals_only clause
TODO
CHAPTER 8. JML METHOD SPECIFICATIONS 43
8.5 Advanced JML method specification clauses
TODO
8.5.1 accessible clause
TODO
8.5.2 diverges clause
TODO
8.5.3 measured_by clause
TODO
8.5.4 when clause
TODO
8.5.5 old clause
TODO
8.5.6 forall clause
TODO
8.5.7 duration clause
TODO
8.5.8 working_space clause
TODO
CHAPTER 8. JML METHOD SPECIFICATIONS 44
8.5.9 callable clause
TODO
8.5.10 captures clause
TODO
8.6 Model Programs (model_program clause)
8.6.1 Structure and purpose of model programs
8.6.2 extract clause
TODO
8.6.3 choose clause
TODO
8.6.4 choose_if clause
TODO
8.6.5 or clause
TODO
8.6.6 returns clause
TODO
8.6.7 continues clause
TODO
CHAPTER 8. JML METHOD SPECIFICATIONS 45
8.6.8 breaks clause
TODO
8.7 Modifiers for method specifications
8.7.1 pure and @Pure
TBD
8.7.2 non_null, nullable, @NonNull, and @Nullable
TBD
8.7.3 model and @Model
TBD
8.7.4 spec_public, spec_protected, @SpecPublic, and @SpecPro-
tected
These modifiers apply only to methods declared in Java code, and not to methods
declared in JML, such as model methods.
TBD
8.7.5 helper and @Helper
TBD
8.7.6 function and @Function
TBD
8.7.7 query, secret, @Query, and @Secret
TBD
CHAPTER 8. JML METHOD SPECIFICATIONS 46
8.7.8 code_java_math, code_bigint_math, code_safe_math
TBD - add rest and annotations
8.7.9 skip_esc, skip_rac, @SkipEsc, and SkipRac
These modifiers apply only to methods with bodies.
When these modifiers are applied to a method or constructor, static checking (respec-
tively, runtime checking) is not performed on that method. In the case of RAC, the
method will be compiled normally, without inserted checks. These modifiers are a
convenient way to exclude a method from being processed without needing to remem-
ber to use the correct command-line arguments.
8.7.10 options and @Options
This modifier takes one or more string literals as arguments. The literals a Get format
correct - one option per argument?
8.7.11 extract and @Extract
This modifier applies only to methods with bodies.
TBD
8.8 TODO Somewhere
constructor field method nowarn
<:: token
lots more backslash tokens
Chapter 9
Field Specifications
Fields may have various modifiers, each of which states a restriction on how the field
may be used. Fields may be part of data groups, which allow specifying frame con-
ditions on fields that may not be visible because of the Java visibility rules. Also, a
specification may introduce ghost or model fields that are used in the specification but
are not present in the Java program.
9.1 Field and Variable Modifiers
The modifiers permitted on a field, variable, or formal parameter declaration are shown
in Table 9.1.
9.1.1 non_null and nullable (@NonNull, @Nullable)
The non_null and nullable modifiers, and equivalent @NonNull and @Nullable anno-
tations, specify whether or not a field, variable, or parameter may hold a null value. The
modifiers are valid only when the type of the modified construct is either a reference or
array type, not a primitive type. Discuss @Non-
Null TestJava a,
b;
Need to discuss
relationship with
JSR308
9.1.2 spec_public and spec_protected (@SpecPublic, @SpecPro-
tected)
These modifiers are used to change the visibility of a Java field when viewed from
a JML construct. A construct labeled spec_public has public visibility in a JML
specification, even if the Java visibility is less than public; similarly, a construct labeled
spec_protected has protected visibility in a JML specification, even if the Java
47
CHAPTER 9. FIELD SPECIFICATIONS 48
Table 9.1: Modifiers allowed on field, variable and parameter declarations
Modifier Where Purpose
non_null field, var, param the variable may not be null (§9.1.1)
nullable field, var, param the variable may be null
spec_public field visibility is public in specs
spec_protected field visibility is protected in specs
model field representation field
ghost field, var specification only field
uninitialized var TBD
instance field not static
monitored field guarded by a lock
secret field, var, param hidden field
peer field, param TBD
rep field, param TBD
readonly field, param TBD
visibility is less than protected. Section ?? contains a detailed discussion of the effect
of information hiding using Java visibility on JML specifications.
Listing 9.1: Use of spec_public
private /*@ spec_public */int value ;
//@ ensures value == i;
public setValue ( int i) {
value = i ;
}
For example, Listing 9.1 shows a simple setter method that assigns its argument to
a private field named value. The visibility rules require that the specifications of a
public method (setValue) may reference only public entities. In particular, it may not
mention value, since value is private. The solution is to declare, in JML, that value
is spec_public, as show in the Listing.
CHAPTER 9. FIELD SPECIFICATIONS 49
9.1.3 ghost and @Ghost
9.1.4 model and @Model
9.1.5 uninitialized and @Uninitialized
9.1.6 instance and @Instance
9.1.7 monitored and @Monitored
9.1.8 query,secret and @Query,@Secret
9.1.9 peer,rep,readonly (@Peer,@Rep,@Readonly)
Check readonly
vs. read_only,
Readonly vs.
ReadOnly
9.2 Datagroups: in and maps clauses
TODO
9.3 Ghost fields
TODO
9.4 Model fields
TODO
Chapter 10
JML Statement
Specifications
JML Statement specifications are JML constructs that appear as statements within the
body of a Java method or initializer. Some are standalone statements, while others are
specifications for loops or blocks that follow.
Grammar:
<jml-statement> ::=
<jml-assert-statement>
|<jml-assume-statement>
|<jml-local-declaration>
|<jml-unreachable-statement>
|<jml-reachable-statement>
|<jml-set-statement>
|<jml-debug-statement>
|<jml-loop-specification>
|<jml-hence-by-statement>
|<jml-refining-specification>
10.1 assert statement and Java assert statement
Grammar:
<jml-assert-statement> ::= assert <jml-expression> ;
Type checking requirements:
• the <jml-expression> must be boolean
50
CHAPTER 10. JML STATEMENT SPECIFICATIONS 51
The assert statement that the given expression must be true at that point in the pro-
gram. A static checking tool is expected to require a proof that the asserted expression
is true and to issue a warning if the expression is not provable. A runtime assertion
checking tool is expected to check whether the asserted expression is true and to issue
a warning message if it is not true in the given execution of the program.
Note that a JML assert statement has a different effect than a Java assert statement.
When assertion checking is enabled, a Java assert statement will result in a Assertion-
Error at runtime if the corresponding assertion evaluates to false; if assertion checking
is disabled (the default), a Java assert statement is ignored. Runtime assertion checking
tools may implement JML assert statements as Java assert statements.
10.2 assume statement
Grammar:
<jml-assume-statement> ::= assume <jml-expression> ;
Type checking requirements:
• the <jml-expression> must be boolean
The assume statement adds an assumption that the given expression is true at that
point in the program.
Static analysis tools may assume the given expression to be true. Runtime assertion
checking tools may choose to check or not to check the assume statements.
An assume statement might be used to state an axiom or fact that is not easily proved.
However, assume statements should be used with caution. Because they are assumed
but not proven, if they are not actually true an unsoundness will be introduced into the
program. For example, the statement assume false; will render the following code
silently infeasible. Even this may be useful, since, during debugging, it may be helpful
to shut off consideration of certain branches of the program.
10.3 ghost and model declarations
10.4 unreachable statement
Grammar:
<jml-unreachable-statement> ::= unreachable <jml-expression> ?;
Type checking requirements:
• the optional <jml-expression> must be boolean; if not present its default value
is true.
CHAPTER 10. JML STATEMENT SPECIFICATIONS 52
The unreachable statement asserts that no feasible execution path will ever reach this
statement when the given expression is true.
The terminating semicolon is required and is easily forgotten, since statement is almost
always used without the optional expression.
The unreachable state-
ment with an expression
is an extension to stan-
dard JML.
It has been common practice to insert assert false; statements to check whether
a given program point is infeasible. The unreachable statement accomplished the
same purpose with clearer syntax.
10.5 reachable statement
Grammar:
<jml-reachable-statement> ::= reachable <jml-expression> ?;
Type checking requirements:
• the optional <jml-expression> must be boolean; if not present its default value
is true.
The reachable statement asserts that there exists a feasible execution path that reaches
this statement with the given expression true.
Not sure the above is worded correctly - is it that the statement is reachable and when-
ever it is reached the condition is true?
The terminating semicolon is required and is easily forgotten, since statement is almost
always used without the optional expression.
The usual execution of the underlying solver checks whether there are any feasible
paths for which an assertions are false. The reachability test is different and typically
requires separate executions of underlying solvers, as the test is now for at least one
path that reaches the given statement.
The reachable statement
is an extension to stan-
dard JML.
It has been common practice to insert assert false; statements to check whether
a given program point is feasible; if it is feasible, the assert false; statement will
cause a static checking warning. The reachable statement accomplished the same
purpose with clearer syntax.
CHAPTER 10. JML STATEMENT SPECIFICATIONS 53
10.6 set and debug statements
Grammar:
<jml-set-statement> ::= set <java-statement>
<jml-debug-statement> ::= debug <java-statement>
The java-statement in the grammar is not quite right since the statements can include
ghost variables.
Type checking requirements:
• the <java-statement> may be any single executable Java statement, including a
block statement
The DRM requires a set
statement to take an as-
signment expression; the
DRM is inconsistent in
how it describes debug
statements.
Aset statement marks a statement that is executed during runtime assertion checking
or symbolically executed during static checking. As such the statement must be fully
executable and may have side effects; also it may contain references and assignments
to local ghost variables and ghost fields, and calls of model methods and classes that
have executable implementations. The primary motivation for a set statement is to
assign values to ghost variables, but it can be used to execute any statement.
The semantics of a debug statement is the same as the set statement except that by
default a debug statement is ignored. A debug statement is only executed when en-
abled by enabling the optional annotation key DEBUG (cf. §??). That is, a (single-line,
standalone) debug statement
//@ debug statement
is equivalent to
//+DEBUG@ set statement
This connection between
debug and the DEBUG
optional key is an exten-
sion.
10.7 loop specifications
Grammar:
<loop-specification> ::= (<loop-clause> )*
<loop-clause> ::= <loop-invariant> |<loop-variant> |<loop-assignable>
CHAPTER 10. JML STATEMENT SPECIFICATIONS 54
<loop-invariant> ::= <loop-invariant-keyword> <jml-expression> ;
<loop-invariant-keyword> ::= loop_invariant |maintaining
|loop_invariant_redundantly
|maintaining_redundantly
<loop-variant> ::= <loop-variant-keyword> <jml-expression> ;
<loop-variant-keyword> ::= decreases |decreasing
|decreases_redundantly
|decreasing_redundantly
<loop-assignable> ::= <location-set> (,<location-set> )*gterm;
Type checking requirements:
• the <jml-expression> in a <loop-invariant> must be a boolean expression
• the <jml-expression> in a <loop-variant> must be a \bigint expression (or
just a long?)
• the <location-set>s in a <loop-assignable> clause may contain local variables
that are in scope at the program location of the loop
• a <loop-specification> may only appear immediately prior to a Java loop state-
ment
• the variable scope for the clauses of a <loop-specification> includes the decla-
ration statement within a for loop, as if the <loop-specification> were textually
located after the declaration and before the loop body
A special and common case of statement specifications is specifications for loops. In
many static checking tools loop specifications, either explicit or inferred, are essential
to automatic checks of implementations. Write this
10.8 statement (block) specification
Grammar: <statement-specification> ::= refining <behavior-seq>
The semantics of a statement specification are very similar to those of a method spec-
ification (cf. §??). A method specification states preconditions on the legal states in
which a method may be called and gives conditions on what the effects of a method’s
execution may be, including comparisons between the pre-state (before the method
call) and the post-state (after the method completion). Similarly, a statement specifica-
tion makes assertions about the execution of the statement (possibly a block statement)
that follows the statement specification:
• For at least one of the <behavior>s in the <behavior-seq>, all of the requires
clauses in that <behavior> must be true just prior to the statement being executed
• For any <behavior> for which all of the requires clauses are true, each other
clause must be satisfied.
CHAPTER 10. JML STATEMENT SPECIFICATIONS 55
• The \result expression may not be used in any clause
The primary conceptual differences between the method and statement specifications
are that
• in the pre- and post-states any local (including ghost) variables that are in scope
may be used in the clause expressions
• as there is no return statement, the \result expression may not be used
The motivation for a statement specification is that it summarizes the behavior of the
subsequent Java statement. The specification should state the behavior of the subse-
quent statement without reference to implementation details preceding the specification
and statement. That is, the preconditions of the statement specification should capture
all the requirements necessary to ensure that the statement will satisfy the specifica-
tions postconditions, without relying implicit behavior of the statements leading up to
the specification and statement.
For example, some block of code may implement a complicated algorithm. The im-
plementation writer may encapsulate that code in a syntactic block and include a spec-
ification that describes the effects of the algorithm. Then a tool may separate its static
checking task into two parts:
• checking that the implementation in the block does indeed have the effect de-
scribed by the specification
• checking that the surrounding method satisfies the method’s specification when,
within its body, the encapsulated block of code is replaced by its specification.
Write this more formally? as a desugaring?
Do we really need the refining keyword?
10.9 hence_by statement
Write this Should this be removed?
Chapter 11
JML Expressions
Grammar:
<jml-expression> ::=
«result-expression>
|«exception-expression>
|«informal-expression>
|«old-expression>
|«key-expression>
|«lbl-expression>
|«nonnullelements-expression>
|«fresh-expression>
|«type-expression>
|«typeof-expression>
|«elemtype-expression>
|«invariant-for-expression>
|«is-initialized-expression>
Missing some - check the list
|«duration-expression>
|«working-space-expression>
|«space-expression>
|(<jml-expression> )
|<jml-expression> ?<jml-expression> :<jml-expression>
|(+|-|!|)<jml-expression>
|<jml-expression> (+|-|*|/|%)<jml-expression>
|<jml-expression> (=|!= |<|<= |>|>= )<jml-expression>
|<jml-expression> (<==> |<=!=> |==> |<== |<: )<jml-expression>
|<jml-expression> (<# |<#= )<jml-expression>
shift bit logical dot cast new methodcall ops
Need sections on \count and \values
56
CHAPTER 11. JML EXPRESSIONS 57
11.1 Syntax
JML Expressions can include most of the operations defined in Java and additional
operations defined only in JML. JML operations are one of four types:
• infix operations that use non-alphanumeric symbols (e.g., <==>)
• identifiers that begin with a backslash (e.g.,
result)
• identifiers that begin with a backslash but have a functional form (e.g.,
old)
• methods defined in JML whose syntax is Java-like (e.g., JML.informal(...))
The Java-like forms replicate some of the backslash forms. The backslash forms are
traditional JML and more concise. However, the preference for new JML syntax is to
use the Java-like form since supporting such syntax requires less modification of JML
tools.
11.2 Purity (no side-effects)
Specification expressions must not have side effects. During run-time assertion check-
ing, the execution of specifications may not change the state of the program under test.
Even for static checking, the presence of side-effects in specification expressions would
complicate their semantics.
11.3 Java operations used in JML
Because of the pure expression rule (cf. §??, some Java operators are not permitted in
JML expressions:
• allowed: +-*/%==!=<=>=<>.ˆ&|&&||<<>>>>>?:
• prohibited: ++ -- = += -= *= /= %= &= |= ˆ= <<= >>= >>>=
11.4 Precedence of infix operations
JML infix operators may be mixed with Java operators. The new JML operators have
precedences that fit within the usual Java operator precedence order, as shown in Table
11.1. fix complement
operator
CHAPTER 11. JML EXPRESSIONS 58
Table 11.1: Java and JML precedence (cf. https://docs.oracle.com/javase/
tutorial/java/nutsandbolts/operators.html)
Java operator JML operator
highest precedence associativity
literals, names, parenthesis quantified
postfix: .[]method calls left
prefix: unary +-!˜cast new right
*/% left
binary +- left
<< >> >>> left
<= < >= > instanceof <: <# <#= left
== != left
&left
ˆleft
|left
&& left
|| left
==> <== right
<==> <=!=> left
?: right
assignment, assign-op right
lowest precedence
CHAPTER 11. JML EXPRESSIONS 59
11.5 Well-defined expressions
An expression used in a JML construct must be well-defined, in addition to being syn-
tactically and type-correct. This requirement disallows the use of partial functions with
arguments for which the result of the function is undefined. For example, the expres-
sion (x/0) == (x/0) is considered in JML to be not well-defined (that is, undefined),
rather than true by identity. An expression like (x/y) == (x/y) (for integer x and y)
is true if it can be proved that y is not 0.but undefined if y is possible 0. For example,
y!=0==>((x/y)==(x/y))is well-defined and true.
The well-definedness rules for JML operators are given in the section describing that
operator. The rules for Java operators are given here. They presume that the expressions
are type correct.
• literals and names are well-defined
• parenthesis operator: well-defined iff the operand is well-defined
• member-of (dot operator): well-defined iff the expression to the left of the dot is
well-defined and not null
• array element ([] operator): well-defined iff the array expression is well-defined
and not null and the index expression is well-defined and within range
• method calls: well-defined iff (a) the receiver and all arguments are well-defined
and (b) if the method is not static, the receiver is not null and (c) the method’s
precondition and invariants are true and (d) the method does not throw any Ex-
ceptions
• cast operator: well-defined iff the argument is well-defined and, for limited range
integral types, the result is not out of range for the type
• implicit unboxing (conversion from object to primitive): well-defined if the ar-
gument is well-defined and not null
• new operator: well-defined iff (a) all arguments to the constructor call are well-
defined, (b) the preconditions and static invariants of the constructor are satisfied
by the argument, (c) and the constructor does not throw any Exceptions
• bit operators and non-short-circuit boolean operators (&|ˆ˜): well-defined iff
all operands are well-defined
• shift operators (<< >> >>>): well-defined iff all operands are well-defined. Note
that Java defines the shift operations for any value of the right-hand operand; the
value is trimmed to 5 or 6 bits by a modulo operation appropriate to the bit-width
of the left-hand operand. JML tools may choose to raise a warning if the value
of the right-hand operand is outside the ‘expected’ range.
• divide and modulo operators: well-defined iff both operands are well-defined
and the divisor is not zero and, for limited range integral types, the result is not
out of range for the type
• other arithmetic operators: well-defined iff both operands are well-defined and,
for limited range integral types, the result is not out of range for the type
• string concatenation: well-defined if the operands are well-defined (they may be
null) floating point op-
erations?• boolean negation operator (!): well-defined iff the operand is well-defined
CHAPTER 11. JML EXPRESSIONS 60
• relational and equality operators: well-defined iff both operands are well-defined
• short-circuit boolean and operator (&&): well-defined iff
–the left operand is well-defined and
–either the left operand is false or the right-operand is well-defined
• short-circuit boolean or operator (||): well-defined iff
–the left operand is well-defined and
–either the left operand is true or the right-operand is well-defined
• ternary operator (?:): well-defined iff
–the condition is well-defined and
–the then operand is well-defined whenever the condition is true and
–the else operand is well-defined whenever the condition is false.
For example (o != null ? o.x : 0) is well-defined (if it is type-correct)
because (a) the condition o!=nullis well-defined and (b) the then expression
o.x is well-defined if the condition o!=nullis true and (c) the else expression
is always well-defined.
11.6 org.jmlspecs.lang.JML
Say more
11.7 Implies and reverse implies: ==> <==
Type information:
• two arguments, each an expression of boolean type
• a ==> expression is well-defined if the left operand is well-defined and either the
left operand is false or the right operand is well-defined
• a <== expression is well-defined if the left operand is well-defined and either the
left operand is true or the right operand is well-defined
• result is boolean
The ==> operator denotes implication and is a short-circuit operator. It is true if the
left-hand operand is false or the right-hand operand is true; if the left operand is false,
the right operand is not evaluated and may be undefined. The operation
<left> ==> <right>
is equivalent to
(!<left>)|| <right> .
The <== operator denotes reverse implication and is a short-circuit operator. It is true
if the left-hand operand is true or the right-hand operand is false; if the left operand is
true, the right operand is not evaluated and may be undefined. The operation
<left> <== <right>
is equivalent to
<left> || (!<right>).
CHAPTER 11. JML EXPRESSIONS 61
Both operators are right associative. For example P==>Q==>Ris parenthesized as
P==>(Q==>R). This is the natural association from logic: (P ==> Q) ==> R is
equivalent to (P && !Q) || R whereas P==>(Q==>R)is equivalent to !P ||
!Q || R.
Note that because of the short-circuit nature of these two operators <left> ==> <right>
is not necessarily equivalent to <right> <==<left>. In particular, if <right> is unde-
fined then <left> ==> <right> is either true or undefined, whereas <right> <== <left>
is always undefined.
11.8 Equivalence and inequivalence: <==> <=!=>
Type information:
• two arguments, each an expression of boolean type
• the expression is well-defined if both operands must be well-defined
• result is boolean
The <==> operator denotes equivalence: it is true if both operands are true or both are
false. It is equivalent to equality (==), except that it is lower precedence. For example,
P&&Q<==>R||Sis (P && Q) <==> (R || S), whereas P&&Q==R||S
is (P && (Q == R)) || S.
The <=!=> operator denotes inequivalence: it is true if one operand is true and the
other false. It is equivalent to inequality (!=), except that it is lower precedence. For
example, P&&Q<=!=>R||Sis (P && Q) <=!=> (R || S), whereas P&&Q
!= R || S is (P && (Q != R)) || S.
Both of these operators are associative and commutative. Accordingly left- and right-
associativity are equivalent. The operators are not chained: P<==>Q<==>Ris (P
<==> Q) <==> R, not (P <==> Q) && (Q <==> R); for example, P<==>Q<==>
Ris true if P is true and Q and R are false. Similarly P<=!=>Q<=!=>Ris (P
<=!=> Q) <=!=> R and is true if P is true and Q and R are false.
11.9 JML subtype: <:
Type information:
• two arguments, each of type \TYPE
• both operands must be well-defined
• result is boolean
The <: operator denotes JML subtyping: the result is true if the left operand is a sub-
type of the right operand. Note that the argument types are
TYPE, that is JML types (cf. §??). Say more about relationship to Java subtyp-
ing
CHAPTER 11. JML EXPRESSIONS 62
Note that the operator would be better named <:=, since it is true if the two operands
are the same type.
11.10 Lock ordering: <# <#=
Type information:
• two arguments, each of reference type
• both operands must be well-defined and both must not be null
• result is boolean
It is useful to establish an ordering of locks. If lock A is always acquired before lock
B (when both locks are needed) then the system cannot deadlock by having one thread
own A and ask for B while another thread holds B and is requesting A. Specifications
may specify an intended ordering using axioms and then check that the ordering is
adhered to in preconditions or assert statements. Neither Java nor JML defines any
ordering on locks; the lock ordering operator enables the specifier to write appropriate
statements about the desired ordering.
The <# operator is the ’less-than’ operator on locks; <#= is the ’less-than-or-equal’
version. That is
a<#=b===(a<#b|a==b)
Previously in JML, the lock ordering operators were just the <and <= comparison
operators. However, with the advent of auto-boxing and unboxing (implicit conversion
between primitive types and reference types) these operators become ambiguous. For
example, if aand bare Integer values, then a<bcould have been either a lock-
ordering comparison or an integer comparison after unboxing aand b. Since the lock
ordering is only a JML operator and not Java operator, the semantics of the comparison
could be different in JML and Java. To avoid this ambiguity, the syntax of the lock
ordering operator was changed and the old form deprecated.
11.11 \result
Grammar:
<result-expression> ::= \result
Type information:
• no arguments
• always well-defined, if type-correct
• result type is the return type of the method in whose specification the expression
appears
• may only be used in ensures,duration, and working_space clauses
CHAPTER 11. JML EXPRESSIONS 63
The \result expression denotes the value returned by a method. The expression is
only permitted in ensures clauses of the method’s specification. It is a type-error to
use \result in the specification of a constructor or a method whose return type is
void.
11.12 \exception
\exception is an Open-
JML extension
Grammar:
<exception-expression> ::= \exception
Type information:
• no arguments
• always well-defined, if type-correct
• result type is the type of the exception given in the signals clause
• only permitted in the signals,duration, and working_space clauses
The \exception expression denotes the exception object within a signals clause.
The expression is only permitted in signals clause of the method’s specification. It is
an alternative form to using a variable declared in the signals clauses’s declaration.
For example, the following two constructions are equivalent:
//@ signals (RuntimeException e) ... e ... ;
//@ signals (RuntimeException) ... \exception ... ;
11.13 \old,\pre, and \past
Grammar:
<old-expression> ::=
(\old( <jml-expression> (,<label> )?)
(\pre( <jml-expression> )
(\past( <jml-expression> )
<label> ::= <id>
Any pre-defined labels?
\past is an extension
Text needed
CHAPTER 11. JML EXPRESSIONS 64
11.14 \key
The \key expression is an
OpenJML extension
Grammar:
<key-expression> ::= (\key( <string-literal> )
Type information:
• The argument must be a compile-time string literal
• The result is a boolean
This expression enables a JML expression to vary depending on the settings of op-
tional, tool-specified keys. These are the same keys as are used for optional annotation
comments (cf. §??). The \key expression is translated to a boolean literal true or false
depending on whether the key is defined or not. Some tools may subsequently use con-
stant folding to avoid processing or executing unreachable parts of expressions.
Example: The expression
!\key("RAC") ==> state == 0
might be used in a situation where state is a model field that is not compiled in RAC
mode. This expression is equivalent to
•true if RAC is defined (so that \key("RAC") is true)
•state == 0 if RAC is not defined (so that \key("RAC") is false)
Mechanisms for defining keys are provided by tools and are not defined in JML it-
self.
11.15 \lblpos,\lblneg,\lbl, and
JML.lblpos(),JML.lblneg(),JML.lbl()
\lbl and the JML forms
are extensions Grammar:
<lbl-expression> ::=
(\lbl( <id> ,<jml-expression> )
|(\lblpos( <id> ,<jml-expression> )
|\lblneg( <id> ,<jml-expression> )
Type information: \lblpos,\lblneg
• special syntax, including a boolean expression
• well-defined if the boolean expression is well-defined
• result type is boolean; value is the same as the expression in the argument
CHAPTER 11. JML EXPRESSIONS 65
Type information: JML.lblpos(),JML.lblneg()
• first argument is a String literal, the second has boolean type
• well-defined if the arguments are well-defined
• result type is boolean; value is the second argument
Type information: \lbl
• special syntax, including an expression
• well-defined if the argument expression is well-defined
• result type is the same as the expression; value is the value of the expression
Type information: JML.lbl()
• first argument is a String literal, the second has any type
• well-defined if the arguments are well-defined
• result type is the same as the type of the second argument; value is the second
argument
These expressions are used for debugging. When static checking finds that some asser-
tion is invalid and generates a counterexample for that invalid assertion, then the value
of the expression in contained in the lbl expression is reported as part of the counterex-
ample. When runtime assertion checking is used, these expressions print the String id
and the value of expression. In each case, the construct simply passes on the type and
value of its expression, possibly generating some debug output in the process.
The \lblpos,\lblneg, and \lbl expressions have a non-standard syntax:
(\lbl<id> <expression )
with no comma between what would be the arguments. Here the <id> is a Java iden-
tifier. The JML.lbl forms are standard functional forms: the first argument is a String
literal; the second is an expression. A String literal is required instead of a String ex-
pression because the value is used to identify the output as coming from this expression
and it is not evaluated during static checking.
In the positive and negative forms, the argument is a boolean expression. Output is
generated by lblpos only if the expression is true; output is generated by lblneg only
if the expression is false. In the neutral form (\lbl and JML.lbl), output is gener-
ated whatever the value. For any type, the value is converted to a String value as is
customary in Java (e.g., using toString()).
Examples: Examples needed
11.16 \nonnullelements
Grammar:
<nonnullelements-expression> ::=
(\nonnullelements( <jml-expression> (,<jml-expression> )*
)
CHAPTER 11. JML EXPRESSIONS 66
(\nonnullelements( )
Type information:
• strict JML: one argument, an expression of array type, may be null
• OpenJML extensions: any number of arguments, each an expression of array
type
• always well-defined, if type-correct
• result type is boolean
The argument of the \nonnullelements expression must be an expression that eval-
uates to an array. The \nonnullelements expression is true if the argument is true
and each element of the array (if any) is not null.
If there are multiple arguments, then the result is true if all of the arguments are non-
null and have all non-null array elements. If \nonnullelements has no arguments,
its value is true.
Perhaps allow the argu-
ment to be reference type
- result is true if the ar-
gument is non-null and, if
an array, all elements are
non-null. Are elements
non-null recursively?
Allow any number of ar-
guments?
11.17 \fresh
Grammar:
<fresh-expression> ::=
(\fresh( <jml-expression> (,<jml-expression> )*)
(\fresh( )
Type information:
• strict JML: one argument, an expression of reference type
• OpenJML extensions: any number of arguments, each an expression of reference
type
• well-defined, if type-correct and all arguments are non-null
• result type is boolean
• use: \fresh may be used only in ensures and signals clauses
CHAPTER 11. JML EXPRESSIONS 67
The argument of the \fresh expression must be an expression that evaluates to a non-
null reference. The \fresh expression is true if the argument is a reference that was
not allocated in the pre-state.
If there are multiple arguments, then the result is true if each argument is itself \fresh;
that is, the value with narguments is the conjunction of nterms each of which is
\fresh applied to one of the arguments in turn. If \fresh has no arguments, its value
is true.
Standardize the JML ex-
tension?
11.18 informal expression: (*...*) and JML.informal()
Grammar:
<informal-expression> ::=
((* FIXME *)
Type information:
• one argument
• always well-defined, if type-correct
• result type is boolean; value is always true
The syntax of the informal expression is
(* ... *),
where the ... denotes any sequence of characters not including line breaks or the two-
character sequence *). An alternate form is
JML.informal(<expression> ),
where <expression> is a String expression, though typically a String literal. The char-
acter sequence and the string expression are natural language text that may be ignored
by JML tools; the intent is to convey to the reader some natural language specification
that will not be checked by automated tools.
In the second form, the argument is type checked and must have type java.lang.String;
it is not evaluated. It is generally a string literal.
The expression always has the value true.
Examples:
//@ ensures (* data structure is self-consistent *);
//@ ensures JML.informal("data structure is self-consistent");
public void m() ...
CHAPTER 11. JML EXPRESSIONS 68
11.19 \type
Grammar:
<type-expression> ::=
(\type( <jml-type-expression> )
Type information:
• one argument, a type name
• always well-defined, if type-correct
• result type is \TYPE
This expression is a type literal. The argument is the name of a type as might be used in
a declaration; the type may be a primitive type, a non-generic reference type, a generic
type with type arguments or an array type. The value of the expression is the JML
type value corresponding to the given type. It is analogous to .class in Java, which
converts a type name to a value of type Class. The type name is resolved like any
other type name, with respect to whatever type names are in scope.
Generic types must be fully parameterized; no wild card desingations are permit-
ted.
What about type variables
For more discussion of JML types and their relationships to Java type, see §??.
Examples:
//@ ... \type(int) ...
//@ ... \type(Integer) ...
//@ ... \type(java.lang.Integer) ...
//@ ... \type(java.util.LinkedList<String>) ...
//@ ... \type(java.util.LinkedList<String>[]) ...
11.20 \typeof
Grammar:
<typeof-expression> ::=
(\typeof( <jml-expression> )
Type information:
• one expression argument, of any type
• well-defined if the argument is well-defined and not null
• result type is \TYPE
CHAPTER 11. JML EXPRESSIONS 69
The \typeof expression returns the dynamic type of the expression that is its argu-
ment. In run-time checking this may require evaluating the argument. This operation
returns a JML type (\typeof); it is analogous to the Java method .getClass(), which
returns a Java type value (of type Class).
Verify that primitive types are allowed
Examples:
Object o = new Integer(5);
// o has static type Object, but dynamic type Integer
//@ assert \typeof(o) == \type(Integer); // - true
//@ assert \typeof(o) == \type(Object); // - false
//@ assert \typeof(5) == \type(int); // - true
11.21 \elemtype
Grammar:
<elemtype-expression> ::=
(\elemtype( <jml-expression> )
Type information:
• one argument, of type \TYPE
• well-defined iff the argument is well-defined and the value is an array type
• result type is \TYPE
This operator returns the element type of an array type.
What if the argument is not an array type? Should we allow a null value of \TYPE
Examples:
//@ assert \elemtype(\type(int[])) == \type(int);
//@ assert \elemtype(\type(int)) == \type(int); // – undefined
11.22 \is_initialized
Grammar:
<is-initialized-expression> ::=
(\is_initialized( <jml-expression> (,<jml-expression> )*)
|(\is_initialized( )
Text needed
CHAPTER 11. JML EXPRESSIONS 70
11.23 \invariant_for
Grammar:
<invariant-for-expression> ::=
(\invariant_for( <jml-expression> (,<jml-expression> )*
)|(\invariant_for( ) Allow expr or type in grammar
Type information:
• Strict JML: one argument, of type Object or a typename, but not a primitive
expression
• Extension: any number of arguments
• well-defined iff the argument is well-defined and the value is a reference type but
not an array type
• result type is boolean
This expression with one expression argument is equivalent to the conjunction (with
&&) of the static and non-static JML-visible invariants in the static type of the receiver
and all its super classes and interfaces (recursively), with the argument as the receiver
for the invariants.
OpenJML allows as an extension one typename argument. The expression with a type-
name argument is equivalent to the conjunction (with &&) of the static JML-visible in-
variants in the named type and all its super classes and interfaces (recursively).
In each case the order of invariants is (1) that invariants of super classes and interfaces
occur before derived classes and interfaces, (2) Object is first and the named type is
last, and (3) within a type, invariants occur in textual order.
Strict JML requires that there be just one argument. As an extension, OpenJML allows
any number of arguments. The expression is then equivalent to the conjunction of the
values for each argument, in order, conjoined by the short-circuit operator &&. When
there are no arguments, the value of \invariant_for() is true.
Are the invariants of su-
perclasses and interfaces
included?
Are both static and non-
static invariants included?
The DRAFT JML ref-
erence manual does not
mention JML-visibility,
but I presume that must
be the case.
multiple arguments, type-
name argument
CHAPTER 11. JML EXPRESSIONS 71
The DJMLRM does not
mention a static-only ver-
sion of \invariant_for - so
this is an extension?
11.24 \not_modified
Grammar:
<not-modified-expression> ::=
(\not_modified( <jml-expression> (,<jml-expression> )*
)|(\not_modified( )
Type information:
• Strict JML: one argument, an expression of any type other than void
• Extension: any number of arguments, each expression of any type other than
void
• well-defined iff the arguments are well-defined
• result type is boolean
• use: only in ensures or signals clauses
A\not_modified expression is a two-state expression that may occur only in ensures
or signals clauses. It satisfies this equivalence:
\not_modified(o)==(\old(o)==(o)))
The argument may be null.
A\not_modified expression with multiple arguments is the conjunction of the cor-
responding terms each with one argument; if \not_modified has no arguments, its
value is true.
The RM says the argument is a store-ref list, rather than an expression. Which do
we want? A store-ref-list allows constructions such as o.* or a[*] or a[1..6] but not
a+b.
11.25 \lockset and \max
Text needed
11.26 \reach
Text needed
CHAPTER 11. JML EXPRESSIONS 72
11.27 \duration
Grammar:
<duration-expression> ::=
(\duration( <jml-expression> )
Type information:
• one argument, an expression of any type
• well-defined
• result type is long
Here we say that the
argument is an expres-
sion, whereas the DRM
says it must be an ex-
plicit method or construc-
tor call.
The value of a \duration expression is the maximum number of virtual machine cy-
cles needed to evaluate the argument. The argument is not actually executed and need
not be pure. However, reasoning about assertions containing \duration expressions
is based on the specifications of method calls within the expression, not on their im-
plementation. Consequently, for a \duration expression to be useful, any methods
or constructors within its argument must have a duration expression as part of its
method specification.
The argument must be an executable expression because different expressions (e.g.,
method calls with different arguments) may consume different numbers of machine
cycles during execution.
Say more about what a virtual machine cycle is.
11.28 \working_space
Grammar:
<working-space-expression> ::=
(\working_space( <jml-expression> )
Type information:
• one argument, of any type
• well-defined
• result type is long
CHAPTER 11. JML EXPRESSIONS 73
Here we allow the ar-
gument to be any ex-
pression. The DRM re-
quires the argument to be
a method or constructor
call.
The result of the \working_space expression is the number of bytes of heap space that
would be required to evaluate the argument, if it were executed. The argument is not ac-
tually executed and may contain side-effects. That is, if \working_space(expr)free
bytes are available in the system, then evaluating expr will not cause an OutOfMemory
error. Is this last sentence true?
The argument must be an executable expression because different expressions (e.g.,
method calls with different arguments) may consume different amounts of memory
space during execution.
11.29 \space
Grammar:
<space-expression> ::=
(\space( <jml-expression> )
Type information:
• one argument, of any reference type
• well-defined iff the argument is well-defined Must the argument be well-defined?
• result type is long
The result of a \space expression is the number of bytes of heap space occupied by the
argument. This is a shallow measure of space: it does not include the space required
by objects that are referred to by members of the object, just the space to hold the ref-
erences themselves and any primitive values that are members of the argument.
not-assigned, not-modified, only-accessed, only-called, only-assigned, only-captured,
spec-quantified-expr Text needed
Chapter 12
Arithmetic modes
12.1 Description of arithmetic modes
Programming languages use integral and floating-point values of various ranges and
precisions. However, often specifications are written and understood as mathematical
integer and real values. Chalin [?] surveyed programmer expectations and desires and
identified three useful arithmetic modes:
• Java mode: values belong to one of Java’s fixed-bit-length data types; overflows
and underflows either occur silently or result in undefined values according to
the rules of Java arithmetic
• Safe mode: values belong to one of Java’s fixed-bit-length data types; overflows
and underflows cause static or dynamic warnings
• Math mode: numeric values are promoted to mathematical types prior to arith-
metic operations; warnings may be issued when values are stored back into fixed-
bit-length variables (in the description below, this mode is called ‘bigint’ mode,
but is the mathematical mode for both integers and reals).
Chalin proposed that most of the time, programmers would like Safe mode seman-
tics for programming language operations and Math mode for specification expres-
sions.
Question: In math mode is it just the operations that are on math types and then casts
or writes to variables might trigger warnings; or are all integral data types implicitly
bigint and real?
In JML, the type of mathematical integers is expressed as \bigint and the type of
mathematical reals is expressed as \real. Static checking can reason about these types
using usual logics with arithmetic; runtime checking uses java.math.BigInteger to
represent \bigint and ixorg.jmlspecs.openjml.Real to represent \real.
74
CHAPTER 12. ARITHMETIC MODES 75
JML contains a number of modifiers and pseudo-functions to control which mode is
operational for a given sub-expression. As would be expected, the innermost mode
indicator in scope for a given expression overrides enclosing arithmetic mode indica-
tors. The arithmetic mode can be set separately for the Java source code and the JML
specifications.
• the class and method modifiers code_java_math,code_safe_math, and code_bigint_math,
and corresponding annotation types CodeJavaMath,CodeSafeMath, and CodeBigintMath,
set the default arithmetic mode for all expressions in Java source code within the
class or method (unless overridden by a nested mode indicator).
• the class and method modifiers spec_java_math,spec_safe_math, and spec_bigint_math,
and corresponding annotation types SpecJavaMath,SpecSafeMath, and SpecBigintMath,
set the default arithmetic mode to be used within JML specifications, within the
respective class or method.
• the operators \java_math,\safe_math, and \bigint_math take one argu-
ment, an expression, and set the arithmetic mode for evaluating that expression
(unless overridden by a nested arithmetic mode operator); the result of these op-
erators has the type and value of its argument, adjusted for the arithmetic mode.
• the default arithmetic mode for the whole static or dynamic analysis can be
set using command-line options (or in the GUI preferences): -code-math and
-spec-math, which can have the values java,safe, and bigint.
• the default settings of the global options are -code-math=java and -spec-math=bigint.
Change the annotations to be simply @CodeMath and @SpecMath with a value?
The math mode affects the semantics of these operators:
• arithmetic: unary plus and minus and binary +-*/%
• shift operations: «»»>
• cast operation
•Math functions ???
The semantics of these operations in each mode are described in the following sec-
tions.
Say more about the explicit semantics
12.2 Semantics of Java math mode
Java defines several fixed-precision integral and floating-point data types. In addition
JML allows the \bigint and \real data types. The arithmetic and shift operators act
on these data types as follows:
CHAPTER 12. ARITHMETIC MODES 76
• implicit conversion. The operands are individually converted to potentially larger
data types as follows:
–if either operand is \real, the other is converted to \real, else
–if one operand is \bigint and the other either double or float, they both
are converted to \real, else
–if either operand is double, the other is converted to double, else
–if either operand is float, the other is converted to float, else
–if either operand is \bigint, the other is converted to \bigint, else
–if either operand is long, the other is converted to long, else
–both operands are converted to int.
• the result type of each arithmetic operator is the same as that of its implicitly
converted operands
• the result type of a shift operator is the same as its left-hand operand
•double and float operators behave as defined by the IEEE standard
• the unary plus operation simply returns its operand
• the unary minus operation, when applied to the least int or long value will
overflow, returning the value of the operand
• binary add, subtract, and multiply operations on int or long values may over-
flow or underflow; the result is truncated to the number of bits of the result type
• the binary divide operation will overflow when the least value of the type is
divided by 1. The result is the least value of the result type.
• the binary modulo operation does not overflow. Note that the sign of the result
is the same as the sign of the dividend, and that it is always true that x==
(x/y)⇤y+(x%y)for xand yboth int or both long.1
• the shift operators apply only to integral values. Note that in Java, x<< y==
x<< (y&n)where nis 31 when x is an int and 63 if xis a long. However, no
such adjustment to the shift amount happens when the type is \bigint.
• In narrowing cast operations, the value of the operand is truncated to the number
of bits of the given type.
12.3 Semantics of Safe math mode
The result of an operation in safe math mode is the same as in Java math mode, except
that any out of range value causes a warning in static or dynamic checking. These
1https://docs.oracle.com/javase/specs/jls/se7/html/jls-15.html#jls-15.17.3
CHAPTER 12. ARITHMETIC MODES 77
warnings are produced in these cases:
• arithmetic operations on fixed-bit-width integral types produce results that over-
flow or underflow; no warnings are produced for floating point or mathematical
types
•
12.4 Semantics of Bigint math mode
12.5 Real arithmetic and non-finite values
TBD -reference what is done in ACSL
Chapter 13
Universe types
78
Chapter 14
Model Programs
Describe the intent, syntax and semantics of model programs
79
Chapter 15
Obsolete and Deprecated
Syntax
describe deprecated syntax, obsolete syntax, incompatible changes from past versions
80
Appendix A
Summary of Modifiers
The tables on the following pages summarizes where the various Java and JML modi-
fiers may be used.
Fix up page break Review for correctness and completeness.
Missing: non_null_by_default
Add in secret, query
81
APPENDIX A. SUMMARY OF MODIFIERS 82
Grammatical construct Java modifiers JML modifiers
All modifiers public protected
private abstract static
final synchronized
transient volatile
native strictfp
spec_public
spec_protected
model ghost pure
instance helper
non_null nullable
nullable_by_default
monitored uninitialized
Class declaration public final abstract
strictfp
pure model
nullable_by_default
spec_public
spec_protected
Interface declaration public strictfp pure model
nullable_by_default
spec_public
spec_protected
Nested Class declaration public protected
private static final
abstract strictfp
spec_public
spec_protected model
pure
Nested interface declara-
tion
public protected
private static strictfp
spec_public
spec_protected model
pure
Local Class (and local
model class) declaration
final abstract strictfp pure model
APPENDIX A. SUMMARY OF MODIFIERS 83
Grammatical construct Java modifiers JML modifiers
Type specification (e.g.
invariant)
public protected
private static
instance
Field declaration public protected
private final volatile
transient static
spec_public
spec_protected non_null
nullable instance
monitored
Ghost Field declaration public protected
private static final
non_null nullable
instance monitored
Model Field declaration public protected
private static
non_null nullable
instance
Method declaration in a
class
public protected
private abstract final
static synchronized
native strictfp
spec_public
spec_protected pure
non_null nullable
helper extract
Method declaration in an
interface
public abstract spec_public
spec_protected pure
non_null nullable
helper
Constructor declaration public protected
private
spec_public
spec_protected helper
pure extract
Model method (in a class
or interface)
public protected
private abstract static
final synchronized
strictfp
pure non_null nullable
helper extract
Model constructor public protected
private
pure helper extract
Java initialization block static -
JML initializer and
static_initializer
annotation
- -
Formal parameter final non_null nullable
Local variable and local
ghost variable declaration
final ghost non_null nullable
uninitialized
Appendix B
Grammar Summary
Automatic collection of all of the grammar productions listed elsewhere in the docu-
ment
84
Appendix C
Type Checking Summary
This was in the DRM outline - is there something to be put in here? If it is to be col-
lected from the rest of the document, we need to place markers to identify the relevant
stuff.
85
Appendix D
Verification Logic Summary
This was in the DRM outline. What was its intent? Is it the same as a section on
semantics and translation?
86
Appendix E
Differences in JML among
tools
Some material is in the DRM. Needs to be enhanced. SHould have a detailed compar-
ison with ACSL, for example – see the appendix of the ACSL documentation.
87
Appendix F
Misc stuff to move, incorporate
or delete
F.0.1 Finding specification files and the refine statement
JML allows specifications to be placed directly in the .java files that contain the imple-
mentation of methods and classes. Indeed, specifications such as assert statements or
loop invariants are necessarily placed directly in a method body. Other specifications,
such as class invariants and method pre- and post-conditions, may be placed in auxil-
iary files. For classes which are only present as .class files and not as .java files, the
auxiliary file is a necessity.
Current JML allows one such auxiliary file per .java file or corresponding .class
file. It is similar to the corresponding .java file except that
• it has a .jml suffix
• it contains no method bodies (method declarations are terminated with semi-
colons, as if they were abstract)
• TBD - field initializations?
The .jml file must be in the same package as the corresponding .java file and has
the same name, except for the suffix. It need not be in the same folder, though the tail
of the path to the folder containing the .jml file must still correspond to the package
containing the .java and .jml files. If there is no source file, then there is a .jml file
for each compilation unit that has a specification. All the nested, inner, or top-level
classes that are defined in one Java compilation unit will have their specifications in
one corresponding .jml file.
The search for specification files is analogous to the way in which .class files are
found on the classpath, except that the specspath is used instead. To find the specifica-
tions for a public top-level class T:
88
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 89
• look in each element of the specspath (cf. section TBD), in order, for a fully-
qualified file whose name is T.jml. If found, the contents of that file are used as
the specifications of T.
• if no such .jml file is found, look in each element of the specspath, in order, for
a fully-qualified file whose name is T.java.
There are two (silent) consequences of this search algorithm that can be confusing:
• If both a .jml and a .java file exist on the specspath and both contain JML
specification text, the specifications in the .java file will be (silently) ignored.
• If a .java file is listed on the command-line it will be compiled (for its Java
content), but if it is not a member of an element of the specspath, it will (silently)
not be used as the source of specifications for itself.
Obsolete syntax. The refine and refines statements are no longer recognized.
The previous (complicated) method of finding specification files and merging the spec-
ifications from multiple files is also no longer implemented. The only specification
file suffix allowed is .jml; the others — .spec,.refines-java,.refines-spec,
.refines-jml — are no longer implemented.
In addition, the .jml file is now sought before seeking the .java file; if a .jml file is
found anywhere in the specs path, then any specifications in the .java file are ignored.
This is a different search algorithm than was previously used.
F.0.2 Model import statements
This section will be added later. Java import statements introduce class names into
the namespace of a .java file. JML has a model import statement:
//@ model import ...
The effect of a JML model import statement is the same as a Java import statement,
except that the names imported by the JML statement are only visible within JML an-
notations. If the model import statement is within a .jml file, the imported names are
visible only within annotations in the .jml file, and not outside JML annotations and
not in the .java file.
Note: Most tools only approximately implement this feature. For example, see FIXME
for a discussion of this feature in OpenJML.
F.0.3 Modifiers
Modifiers are JML keywords that specify JML characteristics of methods, classes,
fields, or variables. They are syntactically placed just like Java modifiers, such as
public.
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 90
JML Keyword Java annotation class interface method field declaration variable declaration
code Code X
code_bigint_math CodeBigintMath
code_java_math CodeJavaMath
code_safe_math CodeSafeMath
extract Extract
ghost Ghost X X
helper Helper X
instance Instance
model Model
monitored Monitored
non_null NonNull X X X
non_null_by_default NonNullByDefault X X X
nullable Nullable X X X
nullable_by_default NullableByDefault X X X
peer Peer
pure Pure X X X
query Query
readonly Readonly
rep Rep
secret Secret
spec_bigint_math SpecBigintMath
spec_java_math SpecJavaMath
spec_protected SpecProtected
spec_public SpecPublic
spec_safe_math SpecSafeMath
static Static
uninitialized Uninitialized
Table F.1: Summary of JML modifiers. All Java annotations are in the
org.jmlspecs.annotation package.
Reuse this table?
CHeck the table; add section references; add where allowed; indicate which are type
modifiers; turn headings 90 degrees.
Obsolete syntax. JML no longer defines the modifier weakly.
JML defines some statements that are used in the body of a method’s implementation.
These are not method specifications per se; rather, they are assertions or assumptions
that are used to aid the proof of the specifications themselves, in the way that lemmas
are aids to proving a resulting theorem. They can also be used to state predicates that
the user believes to be true, and wants checked, or assumptions that are true but are too
difficult for the prover to prove itself.
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 91
F.0.4 JML expressions
Expressions in JML annotations are Java expressions with three adjustments:
• Expressions with side-effects are not allowed. Specifically, JML excludes
–the ++ and –pre- and post- increment and decrement operations
–the assignment operator
–assignment operators that combine an operation with assignment (e.g., +=)
–method invocations that are not explicitly declared pure (cf. §TBD)
• JML adds additional operators to the Java set of operators, discussed in subsec-
tion §?? below.
• JML adds specific keywords that are used as constants or function-like expres-
sions within JML expressions, discussed in subsection §?? below
JML lock ordering operators (<#) and <#= ) The lock ordering operators are used
to determine ordering among objects used for locking in a multi-threaded application;
the operands are any Java objects. The only predefined property of these operators
is that for any two object references oand oo,o<#=oois equivalent to o==oo
|| o <# oo; that is <# is like less than and <#= is like less-than-or-equals. There
is no predefined ordering among objects. The user must define an intended ordering
with some axioms or invariants. An example of using the lock ordering operators for
specification and reasoning about concurrency is found in §??.
TBD - add ++ – into the table as Java only; check precedence
F.0.5 Code contracts
This section will be added later.
F.1 JML modifiers and Java annotations
The Java Modeling Language was defined prior to the introduction of annotations in
Java. Some, but not all, of the features of JML can now be textually represented as Java
annotations. Currently JML supports both the old and new syntactic forms.
Modifiers
Modifiers are JML keywords that specify JML characteristics of methods, classes,
fields, or variables. Examples are pure,model, and ghost. They are syntactically
placed just like Java modifiers, such as public.
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 92
new () [] . and method calls
unary +unary -!(typecast)-
*/% L
+(binary) -(binary) L
«»»> L
<<=>>=<: instanceof<#<#= -<: is the JML subtype operation (§??);
<# and <#= are lock ordering operators (§F.0.4)
== != L
&L
ˆL
|L
&& L
|| L
==> <== ? JML implies and reverse implies (§??)
<==> <=!=> ? JML equivalence and inequivalence (§??)
?: -
=*=/=%=+=-=«=»=»>=&=ˆ
=|= L Java only
Table F.2: Java and JML operators, in order of precedence, from highest (most tightly
binding) to lowest precedence. Operators on the same line have the same precedence.
The associativity is given in the central column.
Each such modifier has an equivalent Java annotation. For example
/*@ pure */ public int m(int i) ...
can be written equivalently as
org.jmlspecs.annotation.Pure public int m(int i) ...
The org.jmlspecs.annotation prefix can be made implicit in the usual way by in-
cluding the import statement
import org.jmlspecs.annotation.Pure;
Note that in the second form, the pure designation is now part of the Java program and
so the import of the org.jmlspecs.annotation package must also be in the Java
program, and the package must be available to the Java compiler.
All of the modifiers, their corresponding Java annotations, and the locations in which
they may be used are described in §F.3.5.
Type modifiers
Some modifiers are actually type modifiers. In particular non_null and nullable are
in this category. Thus the description of the previous subsection (§F.1) apply to these
as well.
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 93
However, Java 1.8 allows Java annotations to be applied to types wherever type names
may appear. For example
(@NonNull String)toUpper(s)
is allowed in Java 1.8 but is forbidden in Java 1.7.
Need additional discussion of the change in JML for Java 1.8, especially for arrays.
Method specification clauses
This section will be added later.
Class specification clauses
This section will be added later.
Statement specifications
JML specifications that are statements within the body of a method have no equivalent
as Java annotations. These include loop specifications, assert and assume statements,
ghost declarations, set and debug statements, and specifications on individual state-
ments.
F.2 org.jmlspecs.lang package
Some JML features are defined in the org.jmlspecs.lang package. The org.jmlspecs.lang
package is included as a model import by default, just as the java.lang package is in-
cluded by default in a Java file. org.jmlspecs.lang.* contains these elements:
•JML.informal(<string> ): This method is a replacement for (and is equiv-
alent to) the informal expression syntax (§??)(* ... *). Both expressions
return a boolean value, which is always true.
• TBD
The definition of the Java Modeling Language is contained in the JML reference manual.[?]
This document does not repeat that definition in detail. However, the following sections
summarize the features of JML, indicate what is and is not implemented in OpenJML,
describes any extensions to JML contained in OpenJML, and includes comments about
relevant implementation aspects of OpenJML.
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 94
F.3 JML Syntax
F.3.1 Syntax of JML specifications
JML specifications may be written as Java annotations. Currently these are only imple-
mented for modifiers (cf. section TBD). In Java 8, the use of Java annotations for JML
features will be expanded.
JML specifications may also be written in specially formatted Java comments: a JML
specification includes everything between either (a) an opening /*@ and closing */ or
(b) an opening //@ and the next line ending character (\n or \r) that is not within a
string or character literal.
Such comments that occur within the body of a class or interface definition are consid-
ered to be a specification of the class, a field, or a method, depending on the kind
of specification clause it is. JML specifications may also occur in the body of a
method.
Obsolete syntax. In previous versions of JML, JML specifications could be placed
within javadoc comments. Such specifications are no longer standard JML and are not
supported by OpenJML.
F.3.2 Conditional JML specifications
ofJML has a mechanism for conditional specifications, based on a system of keys. A
key is an identifier (consisting of ASCII alphanumeric and underscore characters, and
beginning with a non-digit). A conditional JML comment is guarded by one or more
positive or negative keys (or both). The keys are placed just before the @character that
is part of the opening sequence of the JML comment (the //@ or the /*@). Each key
is preceded by a ’+’ or a ’-’ sign, to indicate whether it is a positive or negative key,
respectively. No white-space is allowed. If there is white-space anywhere between the
initial // or /* and the first @character, the comment will appear to be a normal Java
comment and will be silently ignored.
The keys are interpreted as follows. Each tool that processes the Java+JML input will
have a means (e.g. by command-line options) to specify the set of keys that are en-
abled.
• If the JML annotation has no keys, the annotation is always processed.
• If there are only positive keys, the annotation is processed only if at least one of
the keys is enabled.
• If there are only negative keys, the annotation is processed unless one of the keys
is enabled.
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 95
• If there are both positive and negative keys, the annotation is processed only if
(a) at least one of the positive keys is enabled AND (b) none of the negative keys
are enabled.
JML previously defined one conditional annotation: those that began with /*+@ or
//+@. ESC/Java2 also defined /*-@ and //-@. Both of these are now deprecated.
OpenJML does have an option to enable the +-style comments.
The particular keys do not have any defined meaning in the JML reference manual.
OpenJML implicitly enables the following keys:
•ESC : the ESC key is enabled when OpenJML is performing ESC static checking;
•RAC : the RAC key is enabled when OpenJML is performing Runtime-Assertion-
Checking.
•DEBUG : The DEBUG key is not implicitly enabled. However it is defined as
the key that enables the debug JML statement. That is the debug statement is
ignored by default and is used by OpenJML if the user enables the DEBUG key.
•OPENJML : The OPENJML key is enabled whenever OpenJML is processing
annotations (and presumably is not enabled by other tools).
•KEY: The KEY key is reserved for annotations recognized by the KeY tool [?].
It is ignored by OpenJML.
Thus, for example, one can turn off a non-executable assert statement for RAC-processing
but retain it for ESC and for type-checking by writing //-RAC@ assert ...
F.3.3 Finding specification files and the refine statement
Discuss obsolete syntax somewhere - including the refines statement
JML allows specifications to be placed directly in the .java files that contain the imple-
mentation of methods and classes. Indeed, specifications such as assert statements or
loop invariants are necessarily placed directly in a method body. Other specifications,
such as class invariants and method pre- and post-conditions, may be placed in auxil-
iary files. For classes which are only present as .class files and not as .java files, the
auxiliary file is a necessity.
Current JML allows one such auxiliary file per .java file or corresponding .class
file. It is similar to the corresponding .java file except that
• it has a .jml suffix
• it contains no method bodies (method declarations are terminated with semi-
colons, as if they were abstract)
• TBD - field initializations?
The .jml file must be in the same package as the corresponding .java file and has
the same name, except for the suffix. It need not be in the same folder, though the tail
of the path to the folder containing the .jml file must still correspond to the package
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 96
containing the .java and .jml files. If there is no source file, then there is a .jml file
for each compilation unit that has a specification. All the nested, inner, or top-level
classes that are defined in one Java compilation unit will have their specifications in
one corresponding .jml file.
The search for specification files is analogous to the way in which .class files are
found on the classpath, except that the specspath is used instead. To find the specifica-
tions for a public top-level class T:
• look in each element of the specspath (cf. section TBD), in order, for a fully-
qualified file whose name is T.jml. If found, the contents of that file are used as
the specifications of T.
• if no such .jml file is found, look in each element of the specspath, in order, for
a fully-qualified file whose name is T.java.
There are two (silent) consequences of this search algorithm that can be confusing:
• If both a .jml and a .java file exist on the specspath and both contain JML
specification text, the specifications in the .java file will be (silently) ignored.
• If a .java file is listed on the command-line it will be compiled (for its Java
content), but if it is not a member of an element of the specspath, it will (silently)
not be used as the source of specifications for itself.
Obsolete syntax. The refine and refines statements are no longer recognized.
The previous (complicated) method of finding specification files and merging the spec-
ifications from multiple files is also no longer implemented. The only specification
file suffix allowed is .jml; the others — .spec,.refines-java,.refines-spec,
.refines-jml — are no longer implemented.
In addition, the .jml file is now sought before seeking the .java file; if a .jml file is
found anywhere in the specs path, then any specifications in the .java file are ignored.
This is a different search algorithm than was previously used.
F.3.4 Model import statements
This section will be added later. Java import statements introduce class names into
the namespace of a .java file. JML has a model import statement:
//@ model import ...
The effect of a JML model import statement is the same as a Java import statement,
except that the names imported by the JML statement are only visible within JML an-
notations. If the model import statement is within a .jml file, the imported names are
visible only within annotations in the .jml file, and not outside JML annotations and
not in the .java file.
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 97
JML Keyword Java annotation class interface method field declaration variable declaration
code Code X
code_bigint_math CodeBigintMath
code_java_math CodeJavaMath
code_safe_math CodeSafeMath
extract Extract
ghost Ghost X X
helper Helper X
instance Instance
model Model
monitored Monitored
non_null NonNull X X X
non_null_by_default NonNullByDefault X X X
nullable Nullable X X X
nullable_by_default NullableByDefault X X X
peer Peer
pure Pure X X X
query Query
readonly Readonly
rep Rep
secret Secret
spec_bigint_math SpecBigintMath
spec_java_math SpecJavaMath
spec_protected SpecProtected
spec_public SpecPublic
spec_safe_math SpecSafeMath
static Static
uninitialized Uninitialized
Table F.3: Summary of JML modifiers. All Java annotations are in the
org.jmlspecs.annotation package.
Note: Most tools only approximately implement this feature. For example, see FIXME
for a discussion of this feature in OpenJML.
F.3.5 Modifiers
Modifiers are JML keywords that specify JML characteristics of methods, classes,
fields, or variables. They are syntactically placed just like Java modifiers, such as
public.
CHeck the table; add section references; add where allowed; indicate which are type
modifiers; turn headings 90 degrees.
Obsolete syntax. JML no longer defines the modifier weakly.
APPENDIX F. MISC STUFF TO MOVE, INCORPORATE OR DELETE 98
F.3.6 JML expressions
Expressions in JML annotations are Java expressions with three adjustments:
• Expressions with side-effects are not allowed. Specifically, JML excludes
–the ++ and –pre- and post- increment and decrement operations
–the assignment operator
–assignment operators that combine an operation with assignment (e.g., +=)
–method invocations that are not explicitly declared pure (cf. §TBD)
• JML adds additional operators to the Java set of operators, discussed in subsec-
tion §?? below.
• JML adds specific keywords that are used as constants or function-like expres-
sions within JML expressions, discussed in subsection §?? below
F.3.7 JML types
Specifications are sometimes best written using infinite-precision mathematical types,
rather than the fixed bit-width types of Java. JML’s arithmetic modes (§??) allow
choosing among various numerical precisions. In this section we simply note the type
names that JML defines.
All of the Java type names are legal and useful in JML: int short long byte char
boolean double real and class and interface types. In addition, JML defines the
following:
•\bigint - the type of infinite-precision integers, represented as java.lang.BigInteger
during run-time checking
•\real - the type of mathematical real numbers, represented as TBD during
runtime-checking
•\TYPE - the type of JML type objects
The familiar operators are defined on values of the \bigint and \real types: unary
and binary +and -,*,/,%. Also, these types can be used in quantified expressions and
variables of these types can be declared as ghost or model variables.
The set of \TYPE values includes non-generic types such has \type(org.lang.Object),
fully parameterized generic types, such as \type(org.utils.List<Integer>), and
primitive types, such as \type(int). The subtype operator (<:) is defined on values
of type \TYPE.
TBD - what about other constructors or acccessors of TYPE values
Appendix G
Statement translations
TODO: Need to insert both RAC and ESC in all of the following.
G.1 While loop
Java and JML statement:
//@ invariant invariant_condition ;
//@ decreases counter ;
while (condition) {
body
}
Translation: TODO: Needs variant condition, havoc information
{
//@ assert jmltranslate(invariant_condition);
//@ assert jmltranslate(variant_condition)>0;
while (true) {
stats(tmp,condition)
if (!tmp){
//@ assume !tmp;
break;
}
//@ assume tmp;
stats(body)
99
APPENDIX G. STATEMENT TRANSLATIONS 100
}
}
Appendix H
Java expression translations
H.1 Implicit or explicit arithmetic conversions
TODO
H.2 Arithmetic expressions
TODO: need arithmetic range assertions
In these, Tis the type of the result of the operation. The two operands in binary op-
erations are already assumed to have been converted to a common type according to
Java’s rules.
stats(tmp, -a)==>
stats(tmpa, a)
T tmp =- tmpa ;
stats(tmp, a+b)==>
stats(tmpa, a)
stats(tmpb, b)
T tmp =tmpa +tmpb ;
stats(tmp, a-b)==>
stats(tmpa, a)
stats(tmpb, b)
T tmp =tmpa -tmpb ;
101
APPENDIX H. JAVA EXPRESSION TRANSLATIONS 102
stats(tmp, a*b)==>
stats(tmpa, a)
stats(tmpb, b)
T tmp =tmpa *tmpb ;
stats(tmp, a/b)==>
stats(tmpa, a)
stats(tmpb, b)
//@ assert tmpb != 0; // No division by zero
T tmp =tmpa /tmpb ;
stats(tmp, a%b)==>
stats(tmpa, a)
stats(tmpb, b)
//@ assert tmpb != 0; // No division by zero
T tmp =tmpa %tmpb ;
H.3 Bit-shift expressions
TODO
H.4 Relational expressions
No assertions are generated for the relational operations <><=>===!=. The
operands are presumed to have been converted to a common type according to Java’s
rules.
stats(tmp, aop b)==>
stats(tmpa, a)
stats(tmpb, b)
T tmp =tmpa op tmpb ;
H.5 Logical expressions
stats(tmp, !a)==>
stats(tmpa, a)
APPENDIX H. JAVA EXPRESSION TRANSLATIONS 103
T tmp =!tmpa ;
The && and || operations are short-circuit operations in which the second operand is
conditionally evaluated. Here &and |are the (FOL) boolean non-short-circuit con-
junction and disjunction.
stats(tmp, a&& b)==>
boolean tmp ;
stats(tmpa, a)
if ( tmpa ){
//@ assume tmpa ;
stats(tmpb, b)
tmp =tmpa &tmpb ;
}else{
//@ assume ! tmpa ;
tmp =tmpa ;
}
stats(tmp, a|| b)==>
boolean tmp ;
stats(tmpa, a)
if ( ! tmpa ){
//@ assume ! tmpa ;
stats(tmpb, b)
tmp =tmpa |tmpb ;
}else{
//@ assume tmpa ;
tmp =tmpa ;
}
Bibliography
[1] Gary T. Leavens, Erik Poll, Curtis Clifton, Yoonsik Cheon, Clyde Ruby, David R.
Cok, Peter Müller, Joseph Kiniry, Patrice Chalin, and Daniel M. Zimmerman. JML
reference manual. Available from http://www.jmlspecs.org, September 2009.
104
Index
spec_protected ,4
spec_public,4
old,7
m CodeBigintMath, 75
m CodeJavaMath, 75
m CodeSafeMath, 75
m SpecBigintMath, 75
m SpecJavaMath, 75
m SpecSafeMath, 75
(*...*), 67
.jml files, 12
<:, 61
JML.informal(), 67
JML.lbl(), 64
JML.lblneg(), 64
JML.lblpos(), 64
<#=, 62
<#, 62
accessible clause, 43
assert statement, 50
assignable clause, 42
assume statement, 51
breaks clause, 45
callable clause, 44
captures clause, 44
choose_if clause, 44
choose clause, 44
continues clause, 44
diverges clause, 43
duration clause, 43
ensures clause, 42
extract clause, 44
forall clause, 43
ghost, 49
hence_by statement, 55
instance, 49
in, 49
maps, 49
measured_by clause, 43
model_program clause, 44
model, 49
monitored, 49
old clause, 43
or clause, 44
peer, 49
query, 49
reachable statement, 52
readonly, 49
rep, 49
requires clause, 42
returns clause, 44
secret, 49
signals_only clause, 42
signals clause, 42
uninitialized, 49
unreachable statement, 51
when clause, 43
working_space clause, 43
@Ghost, 49
@Instance, 49
@Model, 49
@Monitored, 49
@Peer, 49
@Query, 49
@Readonly, 49
@Rep, 49
@Secret, 49
@Uninitialized, 49
\TYPE, 29
\bigint, 28
\duration, 72
\elemtype, 69
\exception, 63
105
INDEX 106
\fresh, 66
\invariant_for, 70
\is_initialized, 69
\key, 64
\lblneg, 64
\lblpos, 64
\lbl, 64
\lockset, 71
\max, 71
\nonnullelements, 65
\not_modified, 71
\old, 63
\past, 63
\pre, 63
\reach, 71
\real, 29
\result, 62
\space, 73
\typeof, 68
\type, 68
\working_space, 72
\bigint, 74
\real, 74
abstract data type, 4, 6
abstract fields, 4
abstract value, 6
abstract value, of an ADT, 4
ADT, 4
Arithmetic modes, 74
axiom, 36
behavior, 3
behavioral interface specification, 3
Borgida, 3
Cheon, 4
code_bigint_math, 46, 75
code_java_math, 46, 75
code_safe_math, 46, 75
constraint clause, 35
data groups, 47
datatype, 6
debug statement, 53
Eiffel, 3
extract, 46
field specifications, 47
Fitzgerald, 6
frame axiom, 3
Fresco, 4
function, 45
ghost fields, 35
Guttag, 3, 6
Handbook, for LSL, 6
Hayes, 4, 6
helper, 45
Hoare, 6
Horning, 3, 6
informal expression, 67
initializer, 35
initially clause, 35
interface, 3
interface specification, 3
interface, field, 3
interface, method, 3
interface, type, 3
invariant clause, 34
ISO, 6
java.math.BigInteger, 74
Jones, 6
Lamport, 3
Larch, 3
Larch Shared Language (LSL), 3
Larch style specification language, 3
Larch/C++, 6
Larsen, 6
Leavens, 3
Leino, 3
Liskov, 6
loop specifications, 53
LSL, 3
LSL Handbook, 6
method, behavior of, 3
Meyer, 3, 6
model, 45
INDEX 107
model classes, 35
model fields, 35
model import statement, 30
model methods, 35
model-oriented specification, 3
modifiers, 16, 91
monitors_for clause, 36
Nelson, 3
non_null, 45, 47
non_null_by_default, 34
nullable, 45, 47
nullable_by_default, 34
operation, 6
operator, of LSL, 6
options, 46
package-info.java, 30
Parnas, 6
peer, 48
postcondition, 3, 6
postcondition, exceptional, 3
postcondition, normal, 3
precondition, 3, 6
pure, 34, 45
query, 45
readable if clause, 36
represents clause, 35
Rosenblum, 3
Saxe, 3
secret, 45
set statement, 53
skip_esc, 46
skip_rac, 46
SkipRac, 46
spec_bigint_math, 75
spec_java_math, 75
spec_protected, 45, 47
spec_public, 45, 47
spec_safe_math, 75
Specification inheritance, 15
specification of fields, 47
specification, of interface behavior, 3
Spivey, 4, 6
statement specification, 54
static_initializer, 35
trait, 6
trait function, 6
type, abstract, 6
value, abstract, 6
VDM, 6
VDM-SL, 6
vocabulary, 3
Wills, 4
Wing, 3
writable if clause, 36
Z, 4, 6
