JUnit - Quick GuideJUnit - Quick Guide
JUnit - Quick Guide
Advertisements
JUnit - OverviewJUnit - Overview
JUnit - Overview
Testing is the process of checking the functionality of an application to ensure it runs as
per requirements. Unit testing comes into picture at the developers’ level; it is the testing
of single entity (class or method). Unit testing plays a critical role in helping a software
company deliver quality products to its customers.
Unit testing can be done in two ways − manual testing and automated testing.
Manual Testing Automated Testing
Executing a test cases manually without
any tool support is known as manual
testing.
Taking tool support and executing the test cases
by using an automation tool is known as
automation testing.
Time-consuming and tedious − Since
test cases are executed by human
resources, it is very slow and tedious.
Fast − Automation runs test cases significantly
faster than human resources.
Huge investment in human resources
− As test cases need to be executed
manually, more testers are required in
manual testing.
Less investment in human resources − Test
cases are executed using automation tools, so
less number of testers are required in automation
testing.
Less reliable − Manual testing is less
reliable, as it has to account for human
errors.
More reliable − Automation tests are precise
and reliable.
Non-programmable − No programming
can be done to write sophisticated tests to
fetch hidden information.
Programmable − Testers can program
sophisticated tests to bring out hidden
information.
JUnit is a unit testing framework for Java programming language. It plays a crucial role
test-driven development, and is a family of unit testing frameworks collectively known as
xUnit.
JUnit promotes the idea of "first testing then coding", which emphasizes on setting up the
test data for a piece of code that can be tested first and then implemented. This approach
is like "test a little, code a little, test a little, code a little." It increases the productivity of
the programmer and the stability of program code, which in turn reduces the stress on the
programmer and the time spent on debugging.
JUnit is an open source framework, which is used for writing and running tests.
Provides annotations to identify test methods.
Provides assertions for testing expected results.
Provides test runners for running tests.
JUnit tests allow you to write codes faster, which increases quality.
JUnit is elegantly simple. It is less complex and takes less time.
JUnit tests can be run automatically and they check their own results and provide
immediate feedback. There's no need to manually comb through a report of test
results.
JUnit tests can be organized into test suites containing test cases and even other
test suites.
JUnit shows test progress in a bar that is green if the test is running smoothly, and
it turns red when a test fails.
A Unit Test Case is a part of code, which ensures that another part of code (method) works
as expected. To achieve the desired results quickly, a test framework is required. JUnit is a
perfect unit test framework for Java programming language.
A formal written unit test case is characterized by a known input and an expected output,
which is worked out before the test is executed. The known input should test a
precondition and the expected output should test a post-condition.
There must be at least two unit test cases for each requirement − one positive test and
one negative test. If a requirement has sub-requirements, each sub-requirement must
What is JUnit ?What is JUnit ?
What is JUnit ?
Features of JUnitFeatures of JUnit
Features of JUnit
What is a Unit Test Case ?What is a Unit Test Case ?
What is a Unit Test Case ?
have at least two test cases as positive and negative.
JUnit - Environment SetupJUnit - Environment Setup
JUnit - Environment Setup
JUnit is a framework for Java, so the very first requirement is to have JDK installed in your
machine.
JDK 1.5 or above.
Memory No minimum requirement.
Disk Space No minimum requirement.
Operating System No minimum requirement.
First of all, open the console and execute a java command based on the operating system
you are working on.
OS Task Command
Windows Open Command Console c:\> java -version
Linux Open Command Terminal $ java -version
Mac Open Terminal machine:~ joseph$ java -version
Let's verify the output for all the operating systems −
OS Output
Windows
java version "1.8.0_101"
Java(TM) SE Runtime Environment (build 1.8.0_101)
Linux
java version "1.8.0_101"
Java(TM) SE Runtime Environment (build 1.8.0_101)
Mac java version "1.8.0_101"
Java(TM) SE Runtime Environment (build 1.8.0_101)
Local Environment SetupLocal Environment Setup
Local Environment Setup
System RequirementSystem Requirement
System Requirement
Step 1: Verify Java Installation in Your MachineStep 1: Verify Java Installation in Your Machine
Step 1: Verify Java Installation in Your Machine
If you do not have Java installed on your system, then download the Java Software
Development Kit (SDK) from the following link https://www.oracle.com . We are
assuming Java 1.8.0_101 as the installed version for this tutorial.
Set the JAVA_HOME environment variable to point to the base directory location where
Java is installed on your machine. For example.
OS Output
Windows Set the environment variable JAVA_HOME to C:\Program
Files\Java\jdk1.8.0_101
Linux export JAVA_HOME = /usr/local/java-current
Mac export JAVA_HOME = /Library/Java/Home
Append Java compiler location to the System Path.
OS Output
Windows Append the string C:\Program Files\Java\jdk1.8.0_101\bin at the end
of the system variable, Path.
Linux export PATH = $PATH:$JAVA_HOME/bin/
Mac not required
Verify Java installation using the command java -version as explained above.
Download the latest version of JUnit jar file from http://www.junit.org . At the time of
writing this tutorial, we have downloaded Junit-4.12.jar and copied it into C:\>JUnit folder.
OS Archive name
Windows junit4.12.jar
Linux junit4.12.jar
Mac junit4.12.jar
Step 2: Set JAVA EnvironmentStep 2: Set JAVA Environment
Step 2: Set JAVA Environment
Step 3: Download JUnit ArchiveStep 3: Download JUnit Archive
Step 3: Download JUnit Archive
Step 4: Set JUnit EnvironmentStep 4: Set JUnit Environment
Step 4: Set JUnit Environment
Set the JUNIT_HOME environment variable to point to the base directory location where
JUNIT jar is stored on your machine. Let’s assuming we've stored junit4.12.jar in the
JUNIT folder.
Sr.No OS & Description
1Windows
Set the environment variable JUNIT_HOME to C:\JUNIT
2Linux
export JUNIT_HOME = /usr/local/JUNIT
3Mac
export JUNIT_HOME = /Library/JUNIT
Set the CLASSPATH environment variable to point to the JUNIT jar location.
Sr.No OS & Description
1Windows
Set the environment variable CLASSPATH to
%CLASSPATH%;%JUNIT_HOME%\junit4.12.jar;.;
2Linux
export CLASSPATH = $CLASSPATH:$JUNIT_HOME/junit4.12.jar:.
3Mac
export CLASSPATH = $CLASSPATH:$JUNIT_HOME/junit4.12.jar:.
Create a java class file name TestJunit in C:\>JUNIT_WORKSPACE
import org.junit.Test;
import static org.junit.Assert.assertEquals;
public class TestJunit {
Step 5: Set CLASSPATH VariableStep 5: Set CLASSPATH Variable
Step 5: Set CLASSPATH Variable
Step 6: Test JUnit SetupStep 6: Test JUnit Setup
Step 6: Test JUnit Setup
@Test
public void testAdd() {
String str = "Junit is working fine";
assertEquals("Junit is working fine",str);
}
}
Create a java class file name TestRunner in C:\>JUNIT_WORKSPACE to execute test
case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the classes using javac compiler as follows −
C:\JUNIT_WORKSPACE>javac TestJunit.java TestRunner.java
Now run the Test Runner to see the result as follows −
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output.
true
JUnit - Test FrameworkJUnit - Test Framework
JUnit - Test Framework
JUnit is a Regression Testing Framework used by developers to implement unit testing
in Java, and accelerate programming speed and increase the quality of code. JUnit
Framework can be easily integrated with either of the following −
Eclipse
Ant
Maven
Step 7: Verify the ResultStep 7: Verify the Result
Step 7: Verify the Result
Features of JUnit Test FrameworkFeatures of JUnit Test Framework
Features of JUnit Test Framework
JUnit test framework provides the following important features −
Fixtures
Test suites
Test runners
JUnit classes
Fixtures is a fixed state of a set of objects used as a baseline for running tests. The
purpose of a test fixture is to ensure that there is a well-known and fixed environment in
which tests are run so that results are repeatable. It includes −
setUp() method, which runs before every test invocation.
tearDown() method, which runs after every test method.
Let's check one example −
import junit.framework.*;
public class JavaTest extends TestCase {
protected int value1, value2;
// assigning the values
protected void setUp(){
value1 = 3;
value2 = 3;
}
// test method to add two values
public void testAdd(){
double result = value1 + value2;
assertTrue(result == 6);
}
}
A test suite bundles a few unit test cases and runs them together. In JUnit, both @RunWith
and @Suite annotation are used to run the suite test. Given below is an example that uses
TestJunit1 & TestJunit2 test classes.
import org.junit.runner.RunWith;
import org.junit.runners.Suite;
//JUnit Suite Test
@RunWith(Suite.class)
@Suite.SuiteClasses({
TestJunit1.class ,TestJunit2.class
})
FixturesFixtures
Fixtures
Test SuitesTest Suites
Test Suites
public class JunitTestSuite {
}
import org.junit.Test;
import org.junit.Ignore;
import static org.junit.Assert.assertEquals;
public class TestJunit1 {
String message = "Robert";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testPrintMessage() {
System.out.println("Inside testPrintMessage()");
assertEquals(message, messageUtil.printMessage());
}
}
import org.junit.Test;
import org.junit.Ignore;
import static org.junit.Assert.assertEquals;
public class TestJunit2 {
String message = "Robert";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testSalutationMessage() {
System.out.println("Inside testSalutationMessage()");
message = "Hi!" + "Robert";
assertEquals(message,messageUtil.salutationMessage());
}
}
Test runner is used for executing the test cases. Here is an example that assumes the test
class TestJunit already exists.
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Test RunnersTest Runners
Test Runners
JUnit classes are important classes, used in writing and testing JUnits. Some of the
important classes are −
Assert − Contains a set of assert methods.
TestCase − Contains a test case that defines the fixture to run multiple tests.
TestResult − Contains methods to collect the results of executing a test case.
JUnit - Basic UsageJUnit - Basic Usage
JUnit - Basic Usage
Let us now have a basic example to demonstrate the step-by-step process of using JUnit.
Create a java class to be tested, say, MessageUtil.java in C:\>JUNIT_WORKSPACE
/*
* This class prints the given message on console.
*/
public class MessageUtil {
private String message;
//Constructor
//@param message to be printed
public MessageUtil(String message){
this.message = message;
}
// prints the message
public String printMessage(){
System.out.println(message);
return message;
}
}
Create a java test class, say, TestJunit.java.
Add a test method testPrintMessage() to your test class.
Add an Annotaion @Test to method testPrintMessage().
Implement the test condition and check the condition using assertEquals API of JUnit.
Create a java class file name TestJunit.java in C:\>JUNIT_WORKSPACE.
JUnit ClassesJUnit Classes
JUnit Classes
Create a ClassCreate a Class
Create a Class
Create Test Case ClassCreate Test Case Class
Create Test Case Class
import org.junit.Test;
import static org.junit.Assert.assertEquals;
public class TestJunit {
String message = "Hello World";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testPrintMessage() {
assertEquals(message,messageUtil.printMessage());
}
}
Create a TestRunner java class.
Use runClasses method of JUnitCore class of JUnit to run the test case of the above
created test class.
Get the result of test cases run in Result Object.
Get failure(s) using the getFailures() method of Result object.
Get Success result using the wasSuccessful() method of Result object.
Create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to execute
test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the MessageUtil, Test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac MessageUtil.java TestJunit.java TestRunner.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output.
Create Test Runner ClassCreate Test Runner Class
Create Test Runner Class
Hello World
true
Now update TestJunit in C:\>JUNIT_WORKSPACE so that the test fails. Change the
message string.
import org.junit.Test;
import static org.junit.Assert.assertEquals;
public class TestJunit {
String message = "Hello World";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testPrintMessage() {
message = "New Word";
assertEquals(message,messageUtil.printMessage());
}
}
Let's keep the rest of the classes as is, and try to run the same Test Runner.
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output.
Hello World
testPrintMessage(TestJunit): expected:<[New Wor]d> but was:<[Hello Worl]d>
false
JUnit - APIJUnit - API
JUnit - API
The most important package in JUnit is junit.framework, which contains all the core
classes. Some of the important classes are as follows −
Sr.No. Class Name Functionality
1 Assert A set of assert methods.
2 TestCase A test case defines the fixture to run multiple tests.
3 TestResult A TestResult collects the results of executing a test case.
4 TestSuite A TestSuite is a composite of tests.
Following is the declaration for org.junit.Assert class −
public class Assert extends java.lang.Object
This class provides a set of assertion methods useful for writing tests. Only failed
assertions are recorded. Some of the important methods of Assert class are as follows −
Sr.No. Methods & Description
1void assertEquals(boolean expected, boolean actual)
Checks that two primitives/objects are equal.
2void assertFalse(boolean condition)
Checks that a condition is false.
3void assertNotNull(Object object)
Checks that an object isn't null.
4void assertNull(Object object)
Checks that an object is null.
5void assertTrue(boolean condition)
Checks that a condition is true.
6void fail()
Fails a test with no message.
Assert ClassAssert Class
Assert Class
Let's use some of the above-mentioned methods in an example. Create a java class file
named TestJunit1.java in C:\>JUNIT_WORKSPACE.
import org.junit.Test;
import static org.junit.Assert.*;
public class TestJunit1 {
@Test
public void testAdd() {
//test data
int num = 5;
String temp = null;
String str = "Junit is working fine";
//check for equality
assertEquals("Junit is working fine", str);
//check for false condition
assertFalse(num > 6);
//check for not null value
assertNotNull(temp);
}
}
Next, create a java class file named TestRunner1.java in C:\>JUNIT_WORKSPACE to
execute test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner1 {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit1.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac TestJunit1.java TestRunner1.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner1
Verify the output.
true
Following is the declaration for org.junit.TestCase class −
public abstract class TestCase extends Assert implements Test
A test case defines the fixture to run multiple tests. Some of the important methods of
TestCase class are as follows −
Sr.No. Methods & Description
1int countTestCases()
Counts the number of test cases executed by run(TestResult result).
2TestResult createResult()
Creates a default TestResult object.
3String getName()
Gets the name of a TestCase.
4TestResult run()
A convenience method to run this test, collecting the results with a default
TestResult object.
5void run(TestResult result)
Runs the test case and collects the results in TestResult.
6void setName(String name)
Sets the name of a TestCase.
7void setUp()
Sets up the fixture, for example, open a network connection.
8void tearDown()
Tears down the fixture, for example, close a network connection.
9String toString()
Returns a string representation of the test case.
TestCase ClassTestCase Class
TestCase Class
Let's use some of the above-mentioned methods in an example. Create a java class file
named TestJunit2.java in C:\>JUNIT_WORKSPACE.
import junit.framework.TestCase;
import org.junit.Before;
import org.junit.Test;
public class TestJunit2 extends TestCase {
protected double fValue1;
protected double fValue2;
@Before
public void setUp() {
fValue1 = 2.0;
fValue2 = 3.0;
}
@Test
public void testAdd() {
//count the number of test cases
System.out.println("No of Test Case = "+ this.countTestCases());
//test getName
String name = this.getName();
System.out.println("Test Case Name = "+ name);
//test setName
this.setName("testNewAdd");
String newName = this.getName();
System.out.println("Updated Test Case Name = "+ newName);
}
//tearDown used to close the connection or clean up activities
public void tearDown( ) {
}
}
Next, create a java class file named TestRunner2.java in C:\>JUNIT_WORKSPACE to
execute test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner2 {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit2.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac TestJunit2.java TestRunner2.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner2
Verify the output.
No of Test Case = 1
Test Case Name = testAdd
Updated Test Case Name = testNewAdd
true
Following is the declaration for org.junit.TestResult class −
public class TestResult extends Object
A TestResult collects the results of executing a test case. It is an instance of the Collecting
Parameter pattern. The test framework distinguishes between failures and errors. A failure
is anticipated and checked for with assertions. Errors are unanticipated problems like an
ArrayIndexOutOfBoundsException. Some of the important methods of TestResult class
are as follows −
Sr.No. Methods & Description
1void addError(Test test, Throwable t)
Adds an error to the list of errors.
2void addFailure(Test test, AssertionFailedError t)
Adds a failure to the list of failures.
3void endTest(Test test)
Informs the result that a test was completed.
4int errorCount()
Gets the number of detected errors.
5Enumeration<TestFailure> errors()
Returns an Enumeration for the errors.
TestResult ClassTestResult Class
TestResult Class
6int failureCount()
Gets the number of detected failures.
7void run(TestCase test)
Runs a TestCase.
8int runCount()
Gets the number of run tests.
9void startTest(Test test)
Informs the result that a test will be started.
10 void stop()
Marks that the test run should stop.
Create a java class file named TestJunit3.java in C:\>JUNIT_WORKSPACE.
import org.junit.Test;
import junit.framework.AssertionFailedError;
import junit.framework.TestResult;
public class TestJunit3 extends TestResult {
// add the error
public synchronized void addError(Test test, Throwable t) {
super.addError((junit.framework.Test) test, t);
}
// add the failure
public synchronized void addFailure(Test test, AssertionFailedError t) {
super.addFailure((junit.framework.Test) test, t);
}
@Test
public void testAdd() {
// add any test
}
// Marks that the test run should stop.
public synchronized void stop() {
//stop the test here
}
}
Next, create a java class file named TestRunner3.java in C:\>JUNIT_WORKSPACE to
execute test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner3 {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit3.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac TestJunit3.java TestRunner3.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner3
Verify the output.
true
Following is the declaration for org.junit.TestSuite class:
public class TestSuite extends Object implements Test
A TestSuite is a Composite of tests. It runs a collection of test cases. Some of the
important methods of TestSuite class are as follows −
Sr.No. Methods & Description
1void addTest(Test test)
Adds a test to the suite.
2void addTestSuite(Class<? extends TestCase> testClass)
Adds the tests from the given class to the suite.
3int countTestCases()
Counts the number of test cases that will be run by this test.
TestSuite ClassTestSuite Class
TestSuite Class
4String getName()
Returns the name of the suite.
5void run(TestResult result)
Runs the tests and collects their result in a TestResult.
6void setName(String name)
Sets the name of the suite.
7Test testAt(int index)
Returns the test at the given index.
8int testCount()
Returns the number of tests in this suite.
9static Test warning(String message)
Returns a test which will fail and log a warning message.
Create a java class file named JunitTestSuite.java in C:\>JUNIT_WORKSPACE to create
Test suite.
import junit.framework.*;
public class JunitTestSuite {
public static void main(String[] a) {
// add the test's in the suite
TestSuite suite = new TestSuite(TestJunit1.class, TestJunit2.class, TestJunit3.class );
TestResult result = new TestResult();
suite.run(result);
System.out.println("Number of test cases = " + result.runCount());
}
}
Compile the Test suite classes using javac.
C:\JUNIT_WORKSPACE>javac JunitTestSuite.java
Now run the Test Suite.
C:\JUNIT_WORKSPACE>java JunitTestSuite
Verify the output.
No of Test Case = 1
Test Case Name = testAdd
Updated Test Case Name = testNewAdd
Number of test cases = 3
JUnit - Writing a TestJUnit - Writing a Test
JUnit - Writing a Test
Here we will see one complete example of JUnit testing using POJO class, Business logic
class, and a test class, which will be run by the test runner.
Create EmployeeDetails.java in C:\>JUNIT_WORKSPACE, which is a POJO class.
public class EmployeeDetails {
private String name;
private double monthlySalary;
private int age;
/**
* @return the name
*/
public String getName() {
return name;
}
/**
* @param name the name to set
*/
public void setName(String name) {
this.name = name;
}
/**
* @return the monthlySalary
*/
public double getMonthlySalary() {
return monthlySalary;
}
/**
* @param monthlySalary the monthlySalary to set
*/
public void setMonthlySalary(double monthlySalary) {
this.monthlySalary = monthlySalary;
}
/**
* @return the age
*/
public int getAge() {
return age;
}
/**
* @param age the age to set
*/
public void setAge(int age) {
this.age = age;
}
}
EmployeeDetails class is used to −
get/set the value of employee's name.
get/set the value of employee's monthly salary.
get/set the value of employee's age.
Create a file called EmpBusinessLogic.java in C:\>JUNIT_WORKSPACE, which contains
the business logic.
public class EmpBusinessLogic {
// Calculate the yearly salary of employee
public double calculateYearlySalary(EmployeeDetails employeeDetails) {
double yearlySalary = 0;
yearlySalary = employeeDetails.getMonthlySalary() * 12;
return yearlySalary;
}
// Calculate the appraisal amount of employee
public double calculateAppraisal(EmployeeDetails employeeDetails) {
double appraisal = 0;
if(employeeDetails.getMonthlySalary() < 10000){
appraisal = 500;
}else{
appraisal = 1000;
}
return appraisal;
}
}
EmpBusinessLogic class is used for calculating −
the yearly salary of an employee.
the appraisal amount of an employee.
Create a file called TestEmployeeDetails.java in C:\>JUNIT_WORKSPACE, which
contains the test cases to be tested.
import org.junit.Test;
import static org.junit.Assert.assertEquals;
public class TestEmployeeDetails {
EmpBusinessLogic empBusinessLogic = new EmpBusinessLogic();
EmployeeDetails employee = new EmployeeDetails();
//test to check appraisal
@Test
public void testCalculateAppriasal() {
employee.setName("Rajeev");
employee.setAge(25);
employee.setMonthlySalary(8000);
double appraisal = empBusinessLogic.calculateAppraisal(employee);
assertEquals(500, appraisal, 0.0);
}
// test to check yearly salary
@Test
public void testCalculateYearlySalary() {
employee.setName("Rajeev");
employee.setAge(25);
employee.setMonthlySalary(8000);
double salary = empBusinessLogic.calculateYearlySalary(employee);
assertEquals(96000, salary, 0.0);
}
}
TestEmployeeDetails class is used for testing the methods of EmpBusinessLogic class.
It
tests the yearly salary of the employee.
tests the appraisal amount of the employee.
Next, create a java class filed named TestRunner.java in C:\>JUNIT_WORKSPACE to
execute test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestEmployeeDetails.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac EmployeeDetails.java
EmpBusinessLogic.java TestEmployeeDetails.java TestRunner.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output.
true
JUnit - Using AssertionJUnit - Using Assertion
JUnit - Using Assertion
All the assertions are in the Assert class.
public class Assert extends java.lang.Object
This class provides a set of assertion methods, useful for writing tests. Only failed
assertions are recorded. Some of the important methods of Assert class are as follows −
Sr.No. Methods & Description
1void assertEquals(boolean expected, boolean actual)
Checks that two primitives/objects are equal.
2void assertTrue(boolean condition)
Checks that a condition is true.
3void assertFalse(boolean condition)
Checks that a condition is false.
4void assertNotNull(Object object)
Checks that an object isn't null.
5void assertNull(Object object)
Checks that an object is null.
6void assertSame(object1, object2)
The assertSame() method tests if two object references point to the same
object.
7void assertNotSame(object1, object2)
The assertNotSame() method tests if two object references do not point to the
same object.
AssertionAssertion
Assertion
8void assertArrayEquals(expectedArray, resultArray);
The assertArrayEquals() method will test whether two arrays are equal to each
other.
Let's use some of the above-mentioned methods in an example. Create a java class file
named TestAssertions.java in C:\>JUNIT_WORKSPACE.
import org.junit.Test;
import static org.junit.Assert.*;
public class TestAssertions {
@Test
public void testAssertions() {
//test data
String str1 = new String ("abc");
String str2 = new String ("abc");
String str3 = null;
String str4 = "abc";
String str5 = "abc";
int val1 = 5;
int val2 = 6;
String[] expectedArray = {"one", "two", "three"};
String[] resultArray = {"one", "two", "three"};
//Check that two objects are equal
assertEquals(str1, str2);
//Check that a condition is true
assertTrue (val1 < val2);
//Check that a condition is false
assertFalse(val1 > val2);
//Check that an object isn't null
assertNotNull(str1);
//Check that an object is null
assertNull(str3);
//Check if two object references point to the same object
assertSame(str4,str5);
//Check if two object references not point to the same object
assertNotSame(str1,str3);
//Check whether two arrays are equal to each other.
assertArrayEquals(expectedArray, resultArray);
}
}
Next, create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to
execute test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner2 {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestAssertions.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the Test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac TestAssertions.java TestRunner.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output.
true
Annotations are like meta-tags that you can add to your code, and apply them to methods
or in class. These annotations in JUnit provide the following information about test
methods −
which methods are going to run before and after test methods.
which methods run before and after all the methods, and.
which methods or classes will be ignored during the execution.
The following table provides a list of annotations and their meaning in JUnit −
Sr.No. Annotation & Description
1@Test
The Test annotation tells JUnit that the public void method to which it is
attached can be run as a test case.
AnnotationAnnotation
Annotation
2@Before
Several tests need similar objects created before they can run. Annotating a
public void method with @Before causes that method to be run before each Test
method.
3@After
If you allocate external resources in a Before method, you need to release them
after the test runs. Annotating a public void method with @After causes that
method to be run after the Test method.
4@BeforeClass
Annotating a public static void method with @BeforeClass causes it to be run
once before any of the test methods in the class.
5@AfterClass
This will perform the method after all tests have finished. This can be used to
perform clean-up activities.
6@Ignore
The Ignore annotation is used to ignore the test and that test will not be
executed.
Create a java class file named JunitAnnotation.java in C:\>JUNIT_WORKSPACE to test
annotation.
import org.junit.After;
import org.junit.AfterClass;
import org.junit.Before;
import org.junit.BeforeClass;
import org.junit.Ignore;
import org.junit.Test;
public class JunitAnnotation {
//execute before class
@BeforeClass
public static void beforeClass() {
System.out.println("in before class");
}
//execute after class
@AfterClass
public static void afterClass() {
System.out.println("in after class");
}
//execute before test
@Before
public void before() {
System.out.println("in before");
}
//execute after test
@After
public void after() {
System.out.println("in after");
}
//test case
@Test
public void test() {
System.out.println("in test");
}
//test case ignore and will not execute
@Ignore
public void ignoreTest() {
System.out.println("in ignore test");
}
}
Next, create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to
execute annotations.
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(JunitAnnotation.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the Test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac JunitAnnotation.java TestRunner.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output.
in before class
in before
in test
in after
in after class
true
JUnit - Execution ProcedureJUnit - Execution Procedure
JUnit - Execution Procedure
This chapter explains the execution procedure of methods in JUnit, which defines the order
of the methods called. Discussed below is the execution procedure of the JUnit test API
methods with example.
Create a java class file named ExecutionProcedureJunit.java in C:\>JUNIT_WORKSPACE to
test annotation.
import org.junit.After;
import org.junit.AfterClass;
import org.junit.Before;
import org.junit.BeforeClass;
import org.junit.Ignore;
import org.junit.Test;
public class ExecutionProcedureJunit {
//execute only once, in the starting
@BeforeClass
public static void beforeClass() {
System.out.println("in before class");
}
//execute only once, in the end
@AfterClass
public static void afterClass() {
System.out.println("in after class");
}
//execute for each test, before executing test
@Before
public void before() {
System.out.println("in before");
}
//execute for each test, after executing test
@After
public void after() {
System.out.println("in after");
}
//test case 1
@Test
public void testCase1() {
System.out.println("in test case 1");
}
//test case 2
@Test
public void testCase2() {
System.out.println("in test case 2");
}
}
Next, create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to
execute annotations.
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(ExecutionProcedureJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the Test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac ExecutionProcedureJunit.java TestRunner.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output.
in before class
in before
in test case 1
in after
in before
in test case 2
in after
in after class
See the above output. The execution procedure is as follows −
First of all, the beforeClass() method executes only once.
The afterClass() method executes only once.
The before() method executes for each test case, but before executing the test case.
The after() method executes for each test case, but after the execution of test case.
In between before() and after(), each test case executes.
JUnit - Executing TestsJUnit - Executing Tests
JUnit - Executing Tests
The test cases are executed using JUnitCore class. JUnitCore is a facade for running tests.
It supports running JUnit 4 tests, JUnit 3.8.x tests, and mixtures. To run tests from the
command line, run java org.junit.runner.JUnitCore <TestClass>. For one-shot test runs,
use the static method runClasses(Class[]).
Following is the declaration for org.junit.runner.JUnitCore class:
public class JUnitCore extends java.lang.Object
Here we will see how to execute the tests with the help of JUnitCore.
Create a java class to be tested, say, MessageUtil.java, in C:\>JUNIT_WORKSPACE.
/*
* This class prints the given message on console.
*/
public class MessageUtil {
private String message;
//Constructor
//@param message to be printed
public MessageUtil(String message){
this.message = message;
}
// prints the message
public String printMessage(){
System.out.println(message);
return message;
}
}
Create a java test class, say, TestJunit.java.
Add a test method testPrintMessage() to your test class.
Add an Annotaion @Test to the method testPrintMessage().
Implement the test condition and check the condition using assertEquals API of
JUnit.
Create a ClassCreate a Class
Create a Class
Create Test Case ClassCreate Test Case Class
Create Test Case Class
Create a java class file named TestJunit.java in C:\>JUNIT_WORKSPACE.
import org.junit.Test;
import static org.junit.Assert.assertEquals;
public class TestJunit {
String message = "Hello World";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testPrintMessage() {
assertEquals(message,messageUtil.printMessage());
}
}
Now create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to
execute test case(s). It imports the JUnitCore class and uses the runClasses() method that
takes the test class name as its parameter.
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the Test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac MessageUtil.java TestJunit.java TestRunner.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output.
Hello World
true
JUnit - Suite TestJUnit - Suite Test
JUnit - Suite Test
Create Test Runner ClassCreate Test Runner Class
Create Test Runner Class
Test suite is used to bundle a few unit test cases and run them together. In JUnit, both
@RunWith and @Suite annotations are used to run the suite tests. This chapter takes an
example having two test classes, TestJunit1 & TestJunit2, that run together using Test
Suite.
Create a java class to be tested, say, MessageUtil.java in C:\>JUNIT_WORKSPACE.
/*
* This class prints the given message on console.
*/
public class MessageUtil {
private String message;
//Constructor
//@param message to be printed
public MessageUtil(String message){
this.message = message;
}
// prints the message
public String printMessage(){
System.out.println(message);
return message;
}
// add "Hi!" to the message
public String salutationMessage(){
message = "Hi!" + message;
System.out.println(message);
return message;
}
}
Create a java class file named TestJunit1.java in C:\>JUNIT_WORKSPACE.
import org.junit.Test;
import org.junit.Ignore;
import static org.junit.Assert.assertEquals;
public class TestJunit1 {
String message = "Robert";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testPrintMessage() {
System.out.println("Inside testPrintMessage()");
assertEquals(message, messageUtil.printMessage());
Create a ClassCreate a Class
Create a Class
Create Test Case ClassesCreate Test Case Classes
Create Test Case Classes
}
}
Create a java class file named TestJunit2.java in C:\>JUNIT_WORKSPACE.
import org.junit.Test;
import org.junit.Ignore;
import static org.junit.Assert.assertEquals;
public class TestJunit2 {
String message = "Robert";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testSalutationMessage() {
System.out.println("Inside testSalutationMessage()");
message = "Hi!" + "Robert";
assertEquals(message,messageUtil.salutationMessage());
}
}
Create a java class.
Attach @RunWith(Suite.class) Annotation with the class.
Add reference to JUnit test classes using @Suite.SuiteClasses annotation.
Create a java class file named TestSuite.java in C:\>JUNIT_WORKSPACE to execute test
case(s).
import org.junit.runner.RunWith;
import org.junit.runners.Suite;
@RunWith(Suite.class)
@Suite.SuiteClasses({
TestJunit1.class,
TestJunit2.class
})
public class JunitTestSuite {
}
Create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to execute
test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
Create Test Suite ClassCreate Test Suite Class
Create Test Suite Class
Create Test Runner ClassCreate Test Runner Class
Create Test Runner Class
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(JunitTestSuite.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile all the java classes using javac.
C:\JUNIT_WORKSPACE>javac MessageUtil.java TestJunit1.java
TestJunit2.java JunitTestSuite.java TestRunner.java
Now run the Test Runner, which will run the test case defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output.
Inside testPrintMessage()
Robert
Inside testSalutationMessage()
Hi Robert
true
JUnit - Ignore TestJUnit - Ignore Test
JUnit - Ignore Test
Sometimes it so happens that our code is not completely ready while running a test case.
As a result, the test case fails. The @Ignore annotation helps in this scenario.
A test method annotated with @Ignore will not be executed.
If a test class is annotated with @Ignore, then none of its test methods will be
executed.
Now let's see @Ignore in action.
Create a java class to be tested, say, MessageUtil.java in C:\>JUNIT_WORKSPACE.
/*
* This class prints the given message on console.
*/
public class MessageUtil {
private String message;
Create a ClassCreate a Class
Create a Class
//Constructor
//@param message to be printed
public MessageUtil(String message){
this.message = message;
}
// prints the message
public String printMessage(){
System.out.println(message);
return message;
}
// add "Hi!" to the message
public String salutationMessage(){
message = "Hi!" + message;
System.out.println(message);
return message;
}
}
Create a java test class, say, TestJunit.java.
Add a test method testPrintMessage() or testSalutationMessage() to your test
class.
Add an Annotaion @Ignore to method testPrintMessage().
Create a java class file named TestJunit.java in C:\ JUNIT_WORKSPACE.
import org.junit.Test;
import org.junit.Ignore;
import static org.junit.Assert.assertEquals;
public class TestJunit {
String message = "Robert";
MessageUtil messageUtil = new MessageUtil(message);
@Ignore
@Test
public void testPrintMessage() {
System.out.println("Inside testPrintMessage()");
message = "Robert";
assertEquals(message,messageUtil.printMessage());
}
@Test
public void testSalutationMessage() {
System.out.println("Inside testSalutationMessage()");
message = "Hi!" + "Robert";
assertEquals(message,messageUtil.salutationMessage());
}
}
Create Test Case ClassCreate Test Case Class
Create Test Case Class
Create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to execute
test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the MessageUtil, Test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac MessageUtil.java TestJunit.java TestRunner.java
Now run the Test Runner, which will not run the testPrintMessage() test case defined in the
provided Test Case class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output. testPrintMessage() test case is not tested.
Inside testSalutationMessage()
Hi!Robert
true
Now, update TestJunit in C:\>JUNIT_WORKSPACE to ignore all test cases. Add @Ignore at
class level.
import org.junit.Test;
import org.junit.Ignore;
import static org.junit.Assert.assertEquals;
@Ignore
public class TestJunit {
String message = "Robert";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testPrintMessage() {
System.out.println("Inside testPrintMessage()");
message = "Robert";
assertEquals(message,messageUtil.printMessage());
Create Test Runner ClassCreate Test Runner Class
Create Test Runner Class
}
@Test
public void testSalutationMessage() {
System.out.println("Inside testSalutationMessage()");
message = "Hi!" + "Robert";
assertEquals(message,messageUtil.salutationMessage());
}
}
Compile the test case using javac.
C:\JUNIT_WORKSPACE>javac TestJunit.java
Keep your Test Runner unchanged as follows −
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Now run the Test Runner, which will not run any test case defined in the provided Test
Case class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output. No test case is tested.
true
JUnit - Time TestJUnit - Time Test
JUnit - Time Test
JUnit provides a handy option of Timeout. If a test case takes more time than the specified
number of milliseconds, then JUnit will automatically mark it as failed. The timeout
parameter is used along with @Test annotation. Let us see the @Test(timeout) in action.
Create a java class to be tested, say, MessageUtil.java in C:\>JUNIT_WORKSPACE.
Add an infinite while loop inside the printMessage() method.
Create a ClassCreate a Class
Create a Class
/*
* This class prints the given message on console.
*/
public class MessageUtil {
private String message;
//Constructor
//@param message to be printed
public MessageUtil(String message){
this.message = message;
}
// prints the message
public void printMessage(){
System.out.println(message);
while(true);
}
// add "Hi!" to the message
public String salutationMessage(){
message = "Hi!" + message;
System.out.println(message);
return message;
}
}
Create a java test class, say, TestJunit.java. Add a timeout of 1000 to testPrintMessage()
test case.
Create a java class file named TestJunit.java in C:\>JUNIT_WORKSPACE.
import org.junit.Test;
import org.junit.Ignore;
import static org.junit.Assert.assertEquals;
public class TestJunit {
String message = "Robert";
MessageUtil messageUtil = new MessageUtil(message);
@Test(timeout = 1000)
public void testPrintMessage() {
System.out.println("Inside testPrintMessage()");
messageUtil.printMessage();
}
@Test
public void testSalutationMessage() {
System.out.println("Inside testSalutationMessage()");
message = "Hi!" + "Robert";
assertEquals(message,messageUtil.salutationMessage());
}
}
Create Test Case ClassCreate Test Case Class
Create Test Case Class
Create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to execute
test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the MessageUtil, Test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac MessageUtil.java TestJunit.java TestRunner.java
Now run the Test Runner, which will run the test cases defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output. testPrintMessage() test case will mark the unit testing failed.
Inside testPrintMessage()
Robert
Inside testSalutationMessage()
Hi!Robert
testPrintMessage(TestJunit): test timed out after 1000 milliseconds
false
JUnit - Exceptions TestJUnit - Exceptions Test
JUnit - Exceptions Test
JUnit provides an option of tracing the exception handling of code. You can test whether
the code throws a desired exception or not. The expected parameter is used along with
@Test annotation. Let us see @Test(expected) in action.
Create a java class to be tested, say, MessageUtil.java in C:\> JUNIT_WORKSPACE.
Add an error condition inside the printMessage() method.
Create Test Runner ClassCreate Test Runner Class
Create Test Runner Class
Create a ClassCreate a Class
Create a Class
/*
* This class prints the given message on console.
*/
public class MessageUtil {
private String message;
//Constructor
//@param message to be printed
public MessageUtil(String message){
this.message = message;
}
// prints the message
public void printMessage(){
System.out.println(message);
int a = 0;
int b = 1/a;
}
// add "Hi!" to the message
public String salutationMessage(){
message = "Hi!" + message;
System.out.println(message);
return message;
}
}
Create a java test class called TestJunit.java. Add an expected exception
ArithmeticException to the testPrintMessage() test case.
Create a java class file named TestJunit.java in C:\>JUNIT_WORKSPACE.
import org.junit.Test;
import org.junit.Ignore;
import static org.junit.Assert.assertEquals;
public class TestJunit {
String message = "Robert";
MessageUtil messageUtil = new MessageUtil(message);
@Test(expected = ArithmeticException.class)
public void testPrintMessage() {
System.out.println("Inside testPrintMessage()");
messageUtil.printMessage();
}
@Test
public void testSalutationMessage() {
System.out.println("Inside testSalutationMessage()");
message = "Hi!" + "Robert";
assertEquals(message,messageUtil.salutationMessage());
}
}
Create Test Case ClassCreate Test Case Class
Create Test Case Class
Create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to execute
test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(TestJunit.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the MessageUtil, Test case and Test Runner classes using javac.
C:\JUNIT_WORKSPACE>javac MessageUtil.java TestJunit.java TestRunner.java
Now run the Test Runner, which will run the test cases defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Verify the output. testPrintMessage() test case will be passed.
Inside testPrintMessage()
Robert
Inside testSalutationMessage()
Hi!Robert
true
JUnit - Parameterized TestJUnit - Parameterized Test
JUnit - Parameterized Test
JUnit 4 has introduced a new feature called parameterized tests. Parameterized tests
allow a developer to run the same test over and over again using different values. There
are five steps that you need to follow to create a parameterized test.
Annotate test class with @RunWith(Parameterized.class).
Create a public static method annotated with @Parameters that returns a
Collection of Objects (as Array) as test data set.
Create a public constructor that takes in what is equivalent to one "row" of test
data.
Create Test Runner ClassCreate Test Runner Class
Create Test Runner Class
Create an instance variable for each "column" of test data.
Create your test case(s) using the instance variables as the source of the test data.
The test case will be invoked once for each row of data. Let us see parameterized tests in
action.
Create a java class to be tested, say, PrimeNumberChecker.java in
C:\>JUNIT_WORKSPACE.
public class PrimeNumberChecker {
public Boolean validate(final Integer primeNumber) {
for (int i = 2; i < (primeNumber / 2); i++) {
if (primeNumber % i == 0) {
return false;
}
}
return true;
}
}
Create a java test class, say, PrimeNumberCheckerTest.java. Create a java class file
named PrimeNumberCheckerTest.java in C:\>JUNIT_WORKSPACE.
import java.util.Arrays;
import java.util.Collection;
import org.junit.Test;
import org.junit.Before;
import org.junit.runners.Parameterized;
import org.junit.runners.Parameterized.Parameters;
import org.junit.runner.RunWith;
import static org.junit.Assert.assertEquals;
@RunWith(Parameterized.class)
public class PrimeNumberCheckerTest {
private Integer inputNumber;
private Boolean expectedResult;
private PrimeNumberChecker primeNumberChecker;
@Before
public void initialize() {
primeNumberChecker = new PrimeNumberChecker();
}
// Each parameter should be placed as an argument here
// Every time runner triggers, it will pass the arguments
// from parameters we defined in primeNumbers() method
public PrimeNumberCheckerTest(Integer inputNumber, Boolean expectedResult) {
Create a ClassCreate a Class
Create a Class
Create Parameterized Test Case ClassCreate Parameterized Test Case Class
Create Parameterized Test Case Class
this.inputNumber = inputNumber;
this.expectedResult = expectedResult;
}
@Parameterized.Parameters
public static Collection primeNumbers() {
return Arrays.asList(new Object[][] {
{ 2, true },
{ 6, false },
{ 19, true },
{ 22, false },
{ 23, true }
});
}
// This test will run 4 times since we have 5 parameters defined
@Test
public void testPrimeNumberChecker() {
System.out.println("Parameterized Number is : " + inputNumber);
assertEquals(expectedResult,
primeNumberChecker.validate(inputNumber));
}
}
Create a java class file named TestRunner.java in C:\>JUNIT_WORKSPACE to execute
test case(s).
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
public class TestRunner {
public static void main(String[] args) {
Result result = JUnitCore.runClasses(PrimeNumberCheckerTest.class);
for (Failure failure : result.getFailures()) {
System.out.println(failure.toString());
}
System.out.println(result.wasSuccessful());
}
}
Compile the PrimeNumberChecker, PrimeNumberCheckerTest and Test Runner classes
using javac.
C:\JUNIT_WORKSPACE>javac PrimeNumberChecker.java PrimeNumberCheckerTest.java
TestRunner.java
Now run the Test Runner, which will run the test cases defined in the provided Test Case
class.
C:\JUNIT_WORKSPACE>java TestRunner
Create Test Runner ClassCreate Test Runner Class
Create Test Runner Class
Verify the output.
Parameterized Number is : 2
Parameterized Number is : 6
Parameterized Number is : 19
Parameterized Number is : 22
Parameterized Number is : 23
true
JUnit - Plug with ANTJUnit - Plug with ANT
JUnit - Plug with ANT
We will have an example to demonstrate how to run JUnit using ANT. Follow the steps
given below.
Download Apache Ant based on the operating system you are working on.
OS Archive Name
Windows apache-ant-1.8.4-bin.zip
Linux apache-ant-1.8.4-bin.tar.gz
Mac apache-ant-1.8.4-bin.tar.gz
Set the ANT_HOME environment variable to point to the base directory location, where
the ANT libraries are stored on your machine. Let us assume the Ant libraries are stored in
the folder apache-ant-1.8.4.
Sr.No. OS & Description
1Windows
Set the environment variable ANT_HOME to C:\Program Files\Apache Software
Foundation\apache-ant-1.8.4
2Linux
export ANT_HOME = /usr/local/apache-ant-1.8.4
3Mac
export ANT_HOME = /Library/apache-ant-1.8.4
Step 1: Download Apache AntStep 1: Download Apache Ant
Step 1: Download Apache Ant
Step 2: Set Ant EnvironmentStep 2: Set Ant Environment
Step 2: Set Ant Environment
Append Ant compiler location to the System Path as follows −
OS Output
Windows Append the string %ANT_HOME\bin at the end of the system variable,
Path.
Linux export PATH = $PATH:$ANT_HOME/bin/
Mac not required
Download a JUnit Archive that suits your operating system.
OS Archive Name
Windows junit4.10.jar
Linux junit4.10.jar
Mac junit4.10.jar
Create a folder TestJunitWithAnt in C:\>JUNIT_WORKSPACE.
Create a folder src in C:\>JUNIT_WORKSPACE>TestJunitWithAnt.
Create a folder test in C:\>JUNIT_WORKSPACE>TestJunitWithAnt.
Create a folder lib in C:\>JUNIT_WORKSPACE>TestJunitWithAnt.
Create MessageUtil class in C:\>JUNIT_WORKSPACE>TestJunitWithAnt>
srcfolder.
/*
* This class prints the given message on console.
*/
public class MessageUtil {
private String message;
//Constructor
//@param message to be printed
public MessageUtil(String message){
this.message = message;
}
Step 3: Download JUnit ArchiveStep 3: Download JUnit Archive
Step 3: Download JUnit Archive
Step 4: Create Project StructureStep 4: Create Project Structure
Step 4: Create Project Structure
// prints the message
public String printMessage(){
System.out.println(message);
return message;
}
// add "Hi!" to the message
public String salutationMessage(){
message = "Hi!" + message;
System.out.println(message);
return message;
}
}
Create TestMessageUtil class in the folder
C:\>JUNIT_WORKSPACE>TestJunitWithAnt>src.
import org.junit.Test;
import org.junit.Ignore;
import static org.junit.Assert.assertEquals;
public class TestMessageUtil {
String message = "Robert";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testPrintMessage() {
System.out.println("Inside testPrintMessage()");
assertEquals(message,messageUtil.printMessage());
}
@Test
public void testSalutationMessage() {
System.out.println("Inside testSalutationMessage()");
message = "Hi!" + "Robert";
assertEquals(message,messageUtil.salutationMessage());
}
}
Copy junit-4.10.jar onto the folder C:\>JUNIT_WORKSPACE>TestJunitWithAnt>lib.
We'll be using <junit> task in Ant to execute our JUnit test cases.
<project name = "JunitTest" default = "test" basedir = ".">
<property name = "testdir" location = "test" />
<property name = "srcdir" location = "src" />
<property name = "full-compile" value = "true" />
<path id = "classpath.base"/>
<path id = "classpath.test">
<pathelement location = "lib/junit-4.10.jar" />
<pathelement location = "${testdir}" />
<pathelement location = "${srcdir}" />
Create ANT Build.xmlCreate ANT Build.xml
Create ANT Build.xml
<path refid = "classpath.base" />
</path>
<target name = "clean" >
<delete verbose = "${full-compile}">
<fileset dir = "${testdir}" includes = "**/*.class" />
</delete>
</target>
<target name = "compile" depends = "clean">
<javac srcdir = "${srcdir}" destdir = "${testdir}"
verbose = "${full-compile}">
<classpath refid = "classpath.test"/>
</javac>
</target>
<target name = "test" depends = "compile">
<junit>
<classpath refid = "classpath.test" />
<formatter type = "brief" usefile = "false" />
<test name = "TestMessageUtil" />
</junit>
</target>
</project>
Run the following Ant command.
C:\JUNIT_WORKSPACE\TestJunitWithAnt>ant
Verify the output.
Buildfile: C:\JUNIT_WORKSPACE\TestJunitWithAnt\build.xml
clean:
compile:
[javac] Compiling 2 source files to C:\JUNIT_WORKSPACE\TestJunitWithAnt\test
[javac] [parsing started C:\JUNIT_WORKSPACE\TestJunitWithAnt\src\
MessageUtil.java]
[javac] [parsing completed 18ms]
[javac] [parsing started C:\JUNIT_WORKSPACE\TestJunitWithAnt\src\
TestMessageUtil.java]
[javac] [parsing completed 2ms]
[javac] [search path for source files: C:\JUNIT_WORKSPACE\
TestJunitWithAnt\src]
[javac] [loading java\lang\Object.class(java\lang:Object.class)]
[javac] [loading java\lang\String.class(java\lang:String.class)]
[javac] [loading org\junit\Test.class(org\junit:Test.class)]
[javac] [loading org\junit\Ignore.class(org\junit:Ignore.class)]
[javac] [loading org\junit\Assert.class(org\junit:Assert.class)]
[javac] [loading java\lang\annotation\Retention.class
(java\lang\annotation:Retention.class)]
[javac] [loading java\lang\annotation\RetentionPolicy.class
(java\lang\annotation:RetentionPolicy.class)]
[javac] [loading java\lang\annotation\Target.class
(java\lang\annotation:Target.class)]
[javac] [loading java\lang\annotation\ElementType.class
(java\lang\annotation:ElementType.class)]
[javac] [loading java\lang\annotation\Annotation.class
(java\lang\annotation:Annotation.class)]
[javac] [checking MessageUtil]
[javac] [loading java\lang\System.class(java\lang:System.class)]
[javac] [loading java\io\PrintStream.class(java\io:PrintStream.class)]
[javac] [loading java\io\FilterOutputStream.class
(java\io:FilterOutputStream.class)]
[javac] [loading java\io\OutputStream.class(java\io:OutputStream.class)]
[javac] [loading java\lang\StringBuilder.class
(java\lang:StringBuilder.class)]
[javac] [loading java\lang\AbstractStringBuilder.class
(java\lang:AbstractStringBuilder.class)]
[javac] [loading java\lang\CharSequence.class(java\lang:CharSequence.class)]
[javac] [loading java\io\Serializable.class(java\io:Serializable.class)]
[javac] [loading java\lang\Comparable.class(java\lang:Comparable.class)]
[javac] [loading java\lang\StringBuffer.class(java\lang:StringBuffer.class)]
[javac] [wrote C:\JUNIT_WORKSPACE\TestJunitWithAnt\test\MessageUtil.class]
[javac] [checking TestMessageUtil]
[javac] [wrote C:\JUNIT_WORKSPACE\TestJunitWithAnt\test\TestMessageUtil.class]
[javac] [total 281ms]
test:
[junit] Testsuite: TestMessageUtil
[junit] Tests run: 2, Failures: 0, Errors: 0, Time elapsed: 0.008 sec
[junit]
[junit] ------------- Standard Output ---------------
[junit] Inside testPrintMessage()
[junit] Robert
[junit] Inside testSalutationMessage()
[junit] Hi!Robert
[junit] ------------- ---------------- ---------------
BUILD SUCCESSFUL
Total time: 0 seconds
JUnit - Plug with EclipseJUnit - Plug with Eclipse
JUnit - Plug with Eclipse
To set up JUnit with eclipse, follow the steps given below.
Download a JUnit jar based on the operating system you have on your system.
OS Archive Name
Windows junit4.10.jar
Linux junit4.10.jar
Mac junit4.10.jar
Assume you have copied the above JAR file onto the folder C:\>JUnit.
Open eclipse → right click on project and click on property > Build Path > Configure Build
Path and add the junit-4.10.jar in the libraries using the button Add External Jar.
We assume that your Eclipse has inbuilt JUnit plugin. If it is not available in
C:\>eclipse\plugins directory, then you can download it from JUnit Plugin. Unzip the
downloaded zip file in the plugin folder of the Eclipse. Finally restart Eclipse.
Step 1: Download JUnit ArchiveStep 1: Download JUnit Archive
Step 1: Download JUnit Archive
Step 2: Set Eclipse EnvironmentStep 2: Set Eclipse Environment
Step 2: Set Eclipse Environment
Now your Eclipse is ready for the development of JUnit test cases.
Create a project TestJunit in Eclipse at any location. Then create a class MessageUtil to
test in the project.
/*
* This class prints the given message on console.
*/
public class MessageUtil {
private String message;
//Constructor
//@param message to be printed
public MessageUtil(String message){
this.message = message;
}
// prints the message
public String printMessage(){
System.out.println(message);
return message;
}
}
Create a test class TestJunit in the project.
import org.junit.Test;
import static org.junit.Assert.assertEquals;
public class TestJunit {
String message = "Hello World";
MessageUtil messageUtil = new MessageUtil(message);
@Test
public void testPrintMessage() {
assertEquals(message,messageUtil.printMessage());
}
}
Following should be the project structure −
Step 3: Verify JUnit installation in EclipseStep 3: Verify JUnit installation in Eclipse
Step 3: Verify JUnit installation in Eclipse
Finally, right click the program and run as JUnit to verify the output of the program.
Verify the result.
JUnit - ExtensionsJUnit - Extensions
JUnit - Extensions
Following are the JUnit extensions −
Cactus
JWebUnit
XMLUnit
MockObject
Cactus is a simple test framework for unit testing server-side java code (Servlets, EJBs,
Tag Libs, Filters). The intent of Cactus is to lower the cost of writing tests for server-side
code. It uses JUnit and extends it. Cactus implements an in-container strategy that
executes the tests inside a container.
Cactus ecosystem is made of several components −
Cactus Framework is the heart of Cactus. It is the engine that provides the API
to write Cactus tests.
CactusCactus
Cactus
Cactus Integration Modules are front-ends and frameworks that provide easy
ways of using the Cactus Framework (Ant scripts, Eclipse plugin, and Maven
plugin).
The following code demonstrates how Cactus can be used.
import org.apache.cactus.*;
import junit.framework.*;
public class TestSampleServlet extends ServletTestCase {
@Test
public void testServlet() {
// Initialize class to test
SampleServlet servlet = new SampleServlet();
// Set a variable in session as the doSomething()
// method that we are testing
session.setAttribute("name", "value");
// Call the method to test, passing an
// HttpServletRequest object (for example)
String result = servlet.doSomething(request);
// Perform verification that test was successful
assertEquals("something", result);
assertEquals("otherValue", session.getAttribute("otherName"));
}
}
JWebUnit is a Java-based testing framework for web applications. It wraps existing testing
frameworks such as HtmlUnit and Selenium with a unified, simple testing interface to test
the correctness of your web applications.
JWebUnit provides a high-level Java API for navigating a web application combined with a
set of assertions to verify the application's correctness. This includes navigation via links,
form entry and submission, validation of table contents, and other typical business web
application features.
The simple navigation methods and ready-to-use assertions allow for more rapid test
creation than using only JUnit or HtmlUnit. And if you want to switch from HtmlUnit to
other plugins such as Selenium (available soon), there is no need to rewrite your tests.
Here is a sample code.
import junit.framework.TestCase;
import net.sourceforge.jwebunit.WebTester;
public class ExampleWebTestCase extends TestCase {
private WebTester tester;
public ExampleWebTestCase(String name) {
JWebUnitJWebUnit
JWebUnit
super(name);
tester = new WebTester();
}
//set base url
public void setUp() throws Exception {
getTestContext().setBaseUrl("http://myserver:8080/myapp");
}
// test base info
@Test
public void testInfoPage() {
beginAt("/info.html");
}
}
XMLUnit provides a single JUnit extension class, XMLTestCase, and a set of supporting
classes that allow assertions to be made about −
The differences between two pieces of XML (via Diff and DetailedDiff classes).
The validity of a piece of XML (via Validator class).
The outcome of transforming a piece of XML using XSLT (via Transform class).
The evaluation of an XPath expression on a piece of XML (via classes implementing
the XpathEngine interface).
Individual nodes in a piece of XML that are exposed by DOM Traversal (via
NodeTest class).
Let us assume we have two pieces of XML that we wish to compare and assert that they
are equal. We could write a simple test class like this −
import org.custommonkey.xmlunit.XMLTestCase;
public class MyXMLTestCase extends XMLTestCase {
// this test method compare two pieces of the XML
@Test
public void testForXMLEquality() throws Exception {
String myControlXML = "<msg><uuid>0x00435A8C</uuid></msg>";
String myTestXML = "<msg><localId>2376</localId></msg>";
assertXMLEqual("Comparing test xml to control xml", myControlXML, myTestXML);
}
}
In a unit test, mock objects can simulate the behavior of complex, real (non-mock) objects
and are therefore useful when a real object is impractical or impossible to incorporate into
XMLUnitXMLUnit
XMLUnit
MockObjectMockObject
MockObject
Previous Page Next Page
a unit test.
The common coding style for testing with mock objects is to −
Create instances of mock objects.
Set state and expectations in the mock objects.
Invoke domain code with mock objects as parameters.
Verify consistency in the mock objects.
Given below is an example of MockObject using Jmock.
import org.jmock.Mockery;
import org.jmock.Expectations;
class PubTest extends TestCase {
Mockery context = new Mockery();
public void testSubReceivesMessage() {
// set up
final Sub sub = context.mock(Sub.class);
Pub pub = new Pub();
pub.add(sub);
final String message = "message";
// expectations
context.checking(new Expectations() {
oneOf (sub).receive(message);
});
// execute
pub.publish(message);
// verify
context.assertIsSatisfied();
}
}
Advertisements
