December 12, 2012
To Our Valued Customers:
At the close of business Monday, January 14, 2013 we will implement a group of list price changes.
These changes include increases on product lines placed in the market by some of our key manufacturers.
In addition to these changes will be NEW catalog pages for additional No Lead products. More No Lead
products and product groups will be introduced in the weeks and months ahead.
The following page is a tab listing of the product groups that are changing at the close of business Monday,
January 14, 2013. These new list prices will be available on our website at www.amerciangranby.com on or
about January 9, 2013 and will be indicated in bold type. Catalog pages with list pricing can be viewed and
downloaded for printing to update your AGI catalog. Excel files are also available for download on the site.
We will not be mailing a hard-copy price change mailing.
If you do not have access to our website, please contact your sales representative or Customer Service and
we will forward you a copy of the Excel spreadsheet or the new catalog pages.
Sincerely,
Gary Palley
V.P. Sales & Marketing
7652 Morgan Road
Liverpool, New York 13090
(315) 451-1100
Fax: (315) 451-6928
www.americangranby.com
The Original Source of Vendor Consolidation
Product Page Numbers
Heater Union Nuts P.05
Union Nuts & Fittings P.07 - P.08
Flowmeters P.12
Slice Gate Valves P.20
Check Valves P.21 - P.22
Spray Adhesives P.43
Repair Fittings P.45 - P.47
Pool Service Accy P.49
Sourceline Tanks 1.01
Tank Crosses 1.7 - 1.11
Tank Crosses - NEW 1.12a
Tank Fitings Packages 1.14 - 1.20e
Air Releases and Controls 1.28
Installation Accy 1.29
Insert Fittings 1.32a
Liquid Level Controls 1.45
Pitless Adapters 1.54a
Well Caps 1.57
Well Seals 1.60
Drive Shoes 1.69
Pitcher pump parts 1.71
Cylinders 1.73 - 1.74
Cup Leathers 1.81 - 1.88
Check Valves 2.07 - 2.10
Repair kits 2.16
Gas Ball Valves 3.03
Swing Check Valves 3.06
Plumbing Valves 3.07 - 3.08
Slice Gate Valves 3.22
INSTRUCTIONS FOR OBTAINING LIST PRICE CHANGE DATA - JANUARY 15, 2013
To obtain copies of our list price changes go to www.americangranby.com. Click the DOWNLOAD tab.
There are multiple options for you to download.
• For an Excel file of the latest list price changes in alpha numeric order: On the left under PRICE CHANGE UPDATES click on the
Jan 15 13 List Price Change File. This Excel file can be re-sorted or filtered as you need and includes both old and new list
prices plus the % change. This file can be used as a reference or update to your operating system.
• For a .PDF version of only the updated catalog pages: On the left under PRICE CHANGE UPDATES click on the Jan 15 13
Catalog Page Updates. Print out only the catalog pages with changes and insert into your current product catalog.
• Click on FULL CATALOG and SECTION DOWNLOADS for .PDF files of the Full Granby Catalog or for specific sections.
Product Page Numbers
Economy Filter Systems 4.01 - 4.04
Big Bubba Filter Cartiridges 4.08
Economy Drinking Water Systems 4.10
Filter Housings 4.11 - 4.12
Filter Cartridges 4.14 - 4.18
Filter Kits & Accy 4.19
UV Systems 4.46
Pulsafeeder 4.49 - 4.54
Sump Check Valves 5.04
Compression Fittings 6.02
Thermal Expansion Tanks 6.05 - 6.06
Trap Wrap 6.21
Hangers 6.28
Hangers 6.37 - 6.38
Tapes 7.01, 7.03
Spray Adhesives 7.06
Concrete Repair 7.07
PVC Solvent Cements Primers Cleaners 7.17 - 7.26
Super Lube 8.05 - 8.09
Irrigation Installation Accy 10.28, 10.37
Repair Couplings 10.48
Insert Fittings - Nylon 12.01
Insert Fittings - Steel 12.05 - 12.06
Insert Fittings - Stainless Steel 12.07
Insert Fittings - Red Brass 12.10
Union Nuts 12.12
CPVC Fittings 12.13 - 12.14
Compression Fittings 12.16
1/15/13
P.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pool Heater Accessories
LR SERIES Features:
• For use with Laars-Raypak pool and spa heaters.
• Available in copper or stainless steel, with plastic quick connect union or
bronze male adapter.
Part Number Size Ctn Qty List Price
Copper Tube with 1 Bronze Male Adapter
LR617 1-1/2” x 6” x 17” 12 $ 195.16
LR619 1-1/2” x 6” x 19” 12 203.68
LR623 1-1/2” x 6” x 23” 12 221.59
LR626 1-1/2” x 6” x 26” 12 234.45
LR623-2 2” x 6” x 23” 6 300.11
Copper Tube with Plastic Quick Connect Union
LR617UN 1-1/2” x 6” x 17” 8 149.29
LR623UN 1-1/2” x 6” x 23” 8 174.84
Stainless Steel Tube with Plastic Quick Connect Union
LR617SSUN 1-1/2” x 6” x 17” 8 168.13
LR619SSUN 1-1/2” x 6” x 19” 8 178.30
LR621SSUN 1-1/2” x 6” x 21” 8 214.12
LR623SSUN 1-1/2” x 6” x 23” 8 230.38
LR626SSUN 1-1/2” x 6” x 26” 8 245.55
LR617-2SSUN 2” X 6” X 17” 6 196.43
LR619-2SSUN 2” X 6” X 19” 6 209.78
LR623-2SSUN 2” X 6” X 23” 6 236.43
Replacement Union Assembly
PHU150 LR/PL Series-1-1/2” 1 23.41
PHU200 LR/PR Series-2” 1 26.54
Union O-Ring
PHU150 O-RING 1 1/2” o-ring 1 2.64
PHU200 O-RING 2” o-ring 1 2.64
Heater Union Repair Split Nut
HSNR150 1 1/2” FBT Heater Split Nut Set w/ screws 125 4.69
HSNR200 2” FBT Heater Split Nut Set w/ screws 100 5.25
LR Series LRUN Series
Hot Water Swimming Pool Heater
Safety Relief Valve Features:
• Bronze safety relief valve protects ASME Section IV hot water
heating boilers and hydronic heating systems.
• High capacity design features corrosion resistant construction.
• Ideal for use in swimming pool heater applications, hot water boilers and
hydronic heating systems.
• ASME Section IV.
• Set pressure 75 psi. 20-80 psig certified pressure range.
• Maximum temperature service 250ºF
• Stainless steel springs.
• Registered in all Canadian provinces and territories, CRN #0G8547.5C
• Made in USA.
Part Number Description Height Ctn Qty List Price
10-417-15 3/4” M/F Safety relief valve 3” 100 $ 43.39
10-417-15
4/17/12
P.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Equipment Pads
HEF-T-PADTM Features:
• Injection molded from high impact polyolefin for strength and durability.
• Resistant to impact, UV degradation and weathering.
• Will not crack, flake or warp.
• Virtually impervious to climate changes.
• Drillable, permits installation of refrigerant
and electrical lines under and through pad.
Also permits equipment to be easily secured
to pad.
• Unique, non-creep surface absorbs vibration
and noise and keeps equipment in it’s original
position.
• Gray
Part Number Size Pallet Qty List Price
2” HEF-T-PADS
X2424211 24” x 24” x 2” one piece 24 $ 54.27
X2430211 24” x 30” x 2” one piece 24 69.07
X2436211 24” x 36” x 2” one piece 24 83.45
X3232211 32” x 32” x 2” one piece 24 88.74
X3244211 32” x 44” x 2” one piece 24 111.81
X3636211 36” x 36” x 2” one piece 24 110.94
X3830211 38” x 30” x 2” one piece 24 89.53
X3836211 38” x 36” x 2” one piece 24 115.12
X3842211 38” x 42” x 2” one piece 24 143.96
3” HEF-T-PADS
X2424311 24” x 24” x 3” one piece 16 66.55
X2436311 24” x 36” x 3” one piece 16 101.58
X3030311 30” x 30” x 3” one piece 16 85.02
X3232311 32” x 32” x 3” one piece 16 100.82
X3244311 32” x 44” x 3” one piece 16 135.34
X3636311 36” x 36” x 3” one piece 16 139.26
X3848311 38” x 48” x 3” one piece 16 177.74
X5055301 50” x 55” x 3” modular 16 321.06
X2600311 26” diameter round x 3” one piece 16 62.86
1/15/13
P.7
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Unions - PVC Sch 80
PVC Sch 80 Union Features:
• Ideal for swimming pool, spa and plumbing installations.
• EPDM O-Ring seal.
• Working pressure: 150 PSI at 72ºF, 100 PSI at 120ºF.
• Meets ASTM standards for Schedule 80 construction.
• Manufactured for AGI in an ISO 9002 facility.
• NSF listed.
• Available white or gray.
• Imported.
Part Number IPS Size Ctn Qty List Price
SCHEDULE 80 - WHITE PV797 PV798 PV799
SLIP X SLIP FIPT X FIPT SLIP X FIPT SXS TXT SXT
PV797-1/2 PV798-1/2 1/2” 36 $ 2.93 $ 3.06
PV797-3/4 PV798-3/4 3/4” 24/144 3.85 4.00
PV797-1 PV798-1 1” 12/96 4.95 5.30
PV797-11/4 PV798-11/4 1 1/4” 12/96 8.82 9.28
PV797-11/2 PV798-11/2 PV799-11/2 1 1/2” 8/64 11.14 11.59 $ 11.34
PV797-2 PV798-2 PV799-2 2” 4/48 15.50 16.30 16.20
SCHEDULE 80 - GRAY PV697 PV698
slip x slip FIPT x FIPT SxS TXT
PV697-1/2 PV698-1/2 1/2” 36/288 $ 2.93 $ 3.09
PV697-3/4 PV698-3/4 3/4” 24/144 3.86 4.08
PV697-1 PV698-1 1” 12/96 4.95 5.40
PV697-11/4 PV698-11/4 1 1/4” 12/96 8.82 9.16
PV697-11/2 PV698-11/2 1 1/2” 8/64 11.14 11.81
PV697-2 PV698-2 2” 4/48 15.80 16.61
PV697-3 PV698-3 3” 2/12 39.95 41.31
PV697-4 4” 1/4 88.67
Replacement O-Ring for PV797, PV798, PV799, PV697, PV698
PV796-1/2 1/2” 1 $ 0.35
PV796-3/4 3/4” 1 0.35
PV796-1 1” 1 0.42
PV796-11/4 1 1/4” 1 0.42
PV796-11/2 1 1/2” 1 0.70
PV796-2 2” 1 0.70
Union Repair Split Nut
SNR150 1 1/2” FBT Repair Split Nut w/ Screw 125 4.73
SNR200 2” FBT REpair Split Nut w/ Screw 100 5.25
PV79, PV69 Series
MATERIAL SPECIFICATIONS
Body PVC
End Connector PVC
Union Nut PVC
O-Ring EPDM
DIMENSIONS (IN.) SIZE d3 D1 D2 L
1/2” .51 1.21 1.80 2.11
3/4” .71 1.45 2.15 2.42
1” .92 1.76 2.58 2.69
1 1/4” 1.17 2.11 3.20 3.32
1 1/2” 1.52 2.54 3.83 3.40
2” 1.92 3.05 4.68 3.71
3” 2.84 3.52 6.10 4.96
4” 3.94 4.52 8.86 6.30
ISO 9002
1/15/13
P.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Specialty Pool & Spa Fittings
Part Number Description Ctn Qty List Price
Venturi Tee
473-825 3/4” x 1” x 3/4” Venturi Tee 50 $ 11.19
473-210 1 1/2” x 1 1/2” x 3/4” Venturi Tee 25 13.62
Wye
B1640-00 1” Wye, Slip 50 10.71
Fittings
B1221-00 1/2” plug, inverted, spigot 50 2.38
B1231-00 1” Plug, Inverted, spigot 50 2.84
B1241-00 1 1/2” 90 elbow, spigot x spigot 25 9.45
B1251-00 2 x 1 1/2” Male adapter, MIPT x Red Slip 25 8.37
B1171-00 1” x 1 x 1 1/2” Bullhead Tee, S x S x Spigot 25 9.42
0660-20 2” PVC 90 elbow, s x s 65 7.79
0661-20 2” PVC 90 elbow, s x spigot 65 7.79
473-210
B1640-00
Pool/Spa Hose Adapter Features:
• Larger hex nut than most other styles
• Ribbed insert end to promote a tight seal and tapered
thread to prevent “bottoming out” during installation
• White ABS plastic
SPA1512 Part Number Description Ctn Qty List Price
SPA1512 1 1/2" mip x 1 1/2”, 1 1/4” combo hose adapter 100 $ 1.58
Schedule 80 CPVC Nipple Features:
• Sturdy.
• Lightweight.
• Chemical Resistant.
• Gray.
• Threaded on both ends.
Part Number Description Ctn Qty List Price
CPVC1XCLOSE 1 X CLOSE 25 $ 2.40
CPVC11/2xCLOSE 1 1/2 x CLOSE 25 3.48
CPVC11/2X6 1 1/2X 6 25 10.03
CPVC11/2x8 1 1/2 x 8 25 12.19
CPVC11/2X12 1 1/2 X 12 25 18.98
CPVC2XCLOSE 2 X CLOSE 25 5.80
CPVC2X6 2 X 6 25 14.30
CPVC2x8 2 x 8 25 16.93
CPVC2X12 2 X 12 25 26.09
CPVC2x24 2 x 24 BULK 43.74
7/17/12
P.11
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pressure Gauges - Liquid Filled
Liquid Filled Pressure Gauge Features:
• Stainless steel or black steel case
• Glycerine Filled, Phosphor bronze bourdon tube
• Accuracy +/- 3-2-3%
• 2” or 2 1/2” Dial face with clear acrylic lens
• Crimped stainless steel ring
• For use in high vibration, corrosion situations
• TO BE USED WITH AIR OR WATER ONLY.
ILPG Series
EILPG Series
Part Number Case Range Type Dial Size MIP Conn. Ctn Qty List Price
2” DIAL SIZE, LIQUID FILLED
EILPG302-4L Steel 0-30# Pressure 2” 1/4” Lower 100 $ 8.62
EILPG602-4L Steel 0-60# Pressure 2” 1/4” Lower 100 8.62
EILPG602-4B Steel 0-60# Pressure 2” 1/4” Back 100 9.45
EILPG1002-4L Steel 0-100# Pressure 2” 1/4” Lower 100 8.62
EILPG1002-4B Steel 0-100# Pressure 2” 1/4” Back 100 9.45
EILPG1002-8L Steel 0-100# Pressure 2” 1/8” Lower 100 8.62
EILPG1002-8B Steel 0-100# Pressure 2” 1/8” Back 100 9.19
EILPG1602-4L Steel 0-160# Pressure 2” 1/4” Lower 100 8.62
EILPG2002-4L Steel 0-200# Pressure 2” 1/4” Lower 100 8.62
EILVG302-4L Steel 0-30 Hg” Vacuum 2" 1/4” Lower 100 10.36
EILPG302-4LSS Stainless Steel 0-30# Pressure 2” 1/4” Lower 100 13.69
EILPG602-4LSS Stainless Steel 0-60# Pressure 2” 1/4” Lower 100 13.69
EILPG602-4BSS Stainless Steel 0-60# Pressure 2” 1/4” Back 100 14.25
EILPG1002-4LSS Stainless Steel 0-100# Pressure 2” 1/4” Lower 100 13.69
EILPG1002-4BSS Stainless Steel 0-100# Pressure 2” 1/4” Back 100 14.25
EILPG1002-8LSS Stainless Steel 0-100# Pressure 2” 1/8” Lower 100 13.69
EILPG1002-8BSS Stainless Steel 0-100# Pressure 2” 1/8” Back 100 14.25
EILPG1602-4LSS Stainless Steel 0-160# Pressure 2” 1/4” Lower 100 13.69
EILPG2002-4LSS Stainless Steel 0-200# Pressure 2” 1/4” Lower 100 13.69
EILVG302-4LSS Stainless Steel 0-30 Hg” Vacuum 2" 1/4” Lower 100 14.82
2 1/2” DIAL SIZE, LIQUID FILLED
ILPG3025-4L Stainless Steel 0-30# Pressure 2 1/2” 1/4 Lower 50 14.63
ILPG6025-4L Stainless Steel 0-60# Pressure 2 1/2” 1/4 Lower 50 14.63
ILPG10025-4L Stainless Steel 0-100# Pressure 2 1/2” 1/4 Lower 50 14.63
ILPG16025-4L Stainless Steel 0-160# Pressure 2 1/2” 1/4 Lower 50 14.63
ILPG20025-4L Stainless Steel 0-200# Pressure 2 1/2” 1/4 Lower 50 14.63
ILPG30025-4L Stainless Steel 0-300# Pressure 2 1/2” 1/4 Lower 50 14.63
ILPG40025-4L Stainless Steel 0-400# Pressure 2 1/2” 1/4 Lower 50 14.63
ILVG3025-4L Stainless Steel 0-30 Hg” Vacuum 2 1/2" 1/4 Lower 50 16.68
ILCG36025-4L Stainless Steel 30 Hg"/60# Vacuum/Press 2 1/2" 1/4 Lower 50 17.29
1/15/13
P.12
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Flowmeters
Flow Meter Features:
• Economical, easy to install, easy to maintain.
• Calibrated in GPM/LPM with easy-to-read numbering.
• Available 1”- 4” pipe size.
• Durable acrylic construction.
• Supplied with 2 clamps and rubber gasket seal.
• Maximum temperature limit = 120°F, Maximum pressure limit = 120 psi.
U88 Series
Part Number Nominal Pipe Size Range GPM/LPM List Price
U8800424 1” 5-35 / 20-130 $ 141.18
U8800438 1 1/4” 10-60 / 40-220 141.18
U8800439 1 1/2” 20-80 / 80-300 141.18
U8800440 2” 30-140 / 120-550 141.18
U8800441 2 1/2” 40-200 / 160-750 141.18
U8800442 3” 80-350 / 300-1300 141.18
U8800443 4” 150-600 / 600-2200 141.18
ISO 9002
10/23/12
P.19
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Slice Gate Valves - PVC
Part Number Description Max PSI Ctn Qty List Price
Uni-Body
VSGV2101 1 1/2” slip x slip 50 30 $ 16.95
VSGV2201 2” slip x slip 50 20 23.91
* Unibody 2” slip hubs are 2” slip or 2 1/2” spig
Three Piece Body
VSGV150SL 1 1/2” slip x slip 50 30 19.57
VSGV150FIPTXMIPT 1 1/2” fipt x mipt 50 40 23.41
VSGV150FIPTxMIPTABS 1 1/2" fipt x mipt ABS 50 26 23.41
VSGV150SLU 1 1/2” slip x union slip 50 38 31.00
VSGV150MTU 1 1/2" mipt x union slip 50 38 29.48
VSGV150SP 1 1/2” slip x spigot 50 30 18.62
VSGV150SD 1 1/2" step down pool hose x mipt ABS 40 22.25
VSGV200SL 2” slip x slip 50 20 24.89
VSGV200SP 2” slip x spigot 50 34 23.69
VSGV300SL 3” slip x slip 20 15 39.32
VSGV400SL 4” slip x slip w/ metal handle 15 6 167.22
VSGV600SL 6” slip x slip w/ stainless handle 10 1 696.67
VSGV800SL 8” slip x slip w/ stainless handle 10 1 975.45
VSGV1000SL 10” slip x slip w/ stainless handle 10 1 1778.33
VSGV1200SL 12” slip x slip w/ stainless handle 10 1 1868.19
VSGV 3 piece body
VSGV Uni-Body
PVC Slice Gate Valve Features:
• Designed for pool & spa, irrigation, plumbing, waste water
and agricultural applications.
• Stainless steel shaft prevent rust and corrosion.
• Ozone & chemical resistant Santoprene™ materials.
• Santoprene™ seals are integrated to the paddle to eliminate any chance of torn or
punctured gaskets.
• Maximun working pressure 50 psi (through 2”).
• Solvent cement traps to catch excess glue.
• Every valve tested at double recommended working pressure.
• Valterra’s patent pending triple o-ring neck seal to ensure against any chance of shaft
leakage.
Unibody Design
• One piece uni-body design.
• Combination socket ID x spigot OD for installation flexibility.
• Locking handle provides positive shutt-off and easy gate opening.
3 Piece body
• Three piece configuration allows for repair or can be used as a union.
• Three piece configuration easily disassembles for inline service.
VSGV 3 piece body
with union
1/15/13
P.20
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Slice Gate Valves - PVC
PVC Slice Gate Valve
• One piece “Uni-Body” PVC Construction. Guaranteed
NO HUB LEAKS or loose bolts.
• 1/4 turn “Cam-Lock” for 100% shut-off..
• Internal “snap-lock” feature ensures valve will remain totally open,
providing 100% flow with no restriction.
• Stainless steel shaft prevents rust and corrosion.
• Glass filled poly-pro tapered gate design for 100% sealing.
• Integrally molded seal on gate. - No pinched or torn gaskets.
• Seals are “Santoprene” that have been impregnated with a permanent
lubricant. Never needs lube yet will provide continuous smooth operation.
Ozone and chemical resistant for much longer life.
• Santoprene buttons on gate provides smooth operation without sticking.
• Every valve water tested at 100PSI and random quick burst tested at 400 PSI.
Virtually no chance of leaky valves in the field at standard operating pressures.
• Maximum recommended operating pressure is 50 PSI.
• Glue wells on all slip-socket configuration catches excess glue during plumbing.
• Constructed and tested for use in pool & spa applications.
• Made in USA
Part Number Size Description Ctn/Case Qty List Price
SGV150SL 1 1/2” Slip x Slip 14/56 $ 19.75
SGV200SL 2” Slip x Slip 12/48 20.89
SGV250SL 2 1/2” Slip x Slip 5/20 44.30
SGV150SP 1 1/2” Slip x Spigot 14/56 19.75
SGV200SP 2” Slip x Spigot 12/48 20.89
SGV150SLU 1 1/2” Slip x Slip with Union 10/40 31.97
SGV200SLU 2” Slip x Slip with Union 10/40 38.60
SGV - SL Series
SGV-Sp and SGV-SLU Series
1/15/13
P.21
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Check Valves - PVC Swing
“CR” Full Flow Corrosion Resistant Check Valve
Features:
• Protects heat exchangers from potential damage by inline chlorinators.
• Maintains full flow circulation system.
• Propriatary designed Hastelloy spring.
• Glass filled Noryl injection molded shaft.
• 100% silicone gasket never requires lubrication.
• Clear sight glass. Removable, servicable.
• 3 IPS sizes in one valve. 1 1/2” slip with bushing, 2” slip and 2 1/2”
spigot. ( 1 1/2” bushing sold separately.)
• Spring loaded flapper/gate mechanism assures full flow and minimum
cavatation.
• Positive water seal when in the closed position.
• “CR” valve can be installed in virtually any position.
• Use in highly corrosive conditions and conditions needing backflow
prevention.
Part Number Description Size Ctn Qty List Price
MCRV801-20H PVC CR Swing Check Valve 2” Slip x Slip 12 $ 80.81
60104028 CR Swing Check Bushing 2” Sp x 1 1/2” Slip 1 3.61
MCRV Series
MCRV Series
Bushing
CR VALVE REPLACEMENT PARTS
ID Part Number Description Ctn Qty List Price
1 M04030066 #14 x 1” Phillips Pan Head SS Screw 6 $ 13.59
2 M0191401020 Lid 1 16.63
3 0301-154 O-Ring 1 5.50
4 M0405001 Spring 1 6.43
4 0405-001-H Hastelloy Spring 1 26.83
5 M0401005P Shaft 1 7.09
6 M0081201020 Gate Assembly 1 25.33
7 M0060504028 Adapter 2” sp x 1 1/2” Slip, Black 1 4.12
8 M0060104028 Adapter, 2” sp x 1 1/2” Slip, White 1 4.00
1/15/13
P.22
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Check Valves - PVC Swing
“Smart” Swing Check Valve Features:
• Patented innovation in swing check valve technology
eliminates in-line flow restriction of conventional check
valves.
• Spring loaded swing check flapper/gate allows full flow
and reliable back flow prevention.
• Standard “smart” check valve remains closed to 1/2 psi,
then open for full flow.
• Magnetic “smart” check valves remain closed to 2 psi,
then open for full flow.
Part Number Size Description Spring Tension Ctn Qty List Price
MCV821-10 1” Slip x Slip 1/2 lb. 12 $ 21.20
MCV821-10C 1” Slip x Slip CLEAR 1/2 lb. 12 24.16
MCV821-15 1 1/2” Slip x Slip 1/2 lb. 12 31.96
MCV821-15C 1 1/2” Slip x Slip CLEAR 1/2 lb. 12 35.24
MCV821-20 2” Slip x Slip 1/2 lb. 12 37.58
MCV821-20C 2” Slip x Slip CLEAR 1/2 lb. 12 40.52
MCV821-20M 2” Slip x Slip w/magnet 2 lb. 12 41.03
MCV821-20MC 2” Slip x Slip w/magnet CLEAR 2 lb. 12 43.77
MCV823-10 1” Union x Union 1/2 lb. 12 31.96
MCV823-10C 1” Union x Union CLEAR 1/2 lb. 12 35.24
MCV823-15 1 1/2” Union x Union 1/2 lb. 12 50.03
MCV823-15C 1 1/2” Union x Union CLEAR 1/2 lb. 12 53.87
MCV823-20 2” Union x Union 1/2 lb. 12 54.40
MCV823-20C 2” Union x Union CLEAR 1/2 lb. 12 57.38
MCV823-20M 2” Union x Union w/magnet 2 lb. 12 57.38
MCV823-20MC 2” Union x Union w/magnet CLEAR 2 lb. 12 60.92
MCV850-15 1 1/2” Check/Slice Combo Union x Slip 12 55.70
MCV850-20 2” Check/Slice Combo Union x Slip 12 80.88
MCV Series
MCV821 Series
MCV823 Series
MCV850 Series
2/2/13
P.43
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Installation & Repair
Part Number Size Ctn Qty List Price
82093 7” stick 12 $ 21.22
PERMAPOXY
Underwater Repair
Epoxy
• Ideal for pool & spa
repairs.
• Resin and hardener in
same stick
• Hand kneadable.
• Unaffected by chlorinated
or salt water.
• Sets in 5 minutes, cures in
1 hour.
• Dries White.
• Can be sanded and drilled.
3M Spray Adhesives
BLUE 72
• Repositionable BLUE pressure sensitive
spray adhesive.
• One side bonds in 8 hours, aggressive
tack, low soak in.
• Covers 100 sq ft.
• Ideal for pool liner installation.
ORANGE FOAM FAST 74
• Permanent, light orange, fast tack.
• Two sides bond in 15 minutes.
• Covers 260 sq. ft.
Both manufactured for AGI in an ISO 900
facility.
Pallet pricing available. Call your sales rep.
Part Ctn/Pallet
Number Size Qty List Price
BLUE 72 Blue Spray Adhesive 12/768 $ 40.55
24 fl oz can, 17.3 oz net wt.
ORANGE 74 Orange spray adhesive 12/768 49.20
24 fl oz can, 17.3 oz net wt
ISO 9001 ISO 9001
Fix A Leak Features:
Fix A Leak is a blended material, designed to
seal leaks in just about anything. It works in
any kind of pool, spa or hot tub, regardless of
constructed material, concrete, fiberglass,
acrylic, wood, etc. It works equally well in all
plumbing materials including PVC, ABS, poly
plastics, vulcathen, copper, steel, etc.
• Seals leaks up to 1/8” in diameter.
• Forms a permanent seal.
• One quart is designed to seal leaks in up to
20,000 gallons. Do not use in excess of 1
quart per 5,000 gallons of water.
• Cures in 24-48 hours.
• Patented by Marlig Industries, Inc.
Part
Number Description Ctn Qty List Price
FAL32 Fix A Leak Sealant, 32 oz. 12 $ 50.14
FAL8 Fix A Leak Sealant, 8 oz. 20 20.98
FAL32
Part
Number Width x Length Ctn Qty List Price
HDT260 2” x 60 yards 24 $ 23.04
Contractor/Industrial Grade
Cloth Reinforced Duct Tape
• Multi-purpose duct tape.
• Polyethylene coated cloth backing.
• Natural rubber based adhesive.
• Temperature range: 40ºF to 200°F.
• Superior tensile strength, adhesion
& tack.
• Recommended for pool liner instal-
lations.
• Conformable and will not curl or
twist during application.
• 10 mil thickness
• Silver
• Manufactured for AGI in an
ISO 9002 facility.
HDT Series
ISO 9002
See the “Tapes, Sealants, Cements” and “Permatex Industrial” tabs for more installation & repair materials.
9/7/11
P.44
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Installation & Repair
HARVARD CONTRACTOR’S
Anchor Kit Features:
• Anchor kits complete with 100 plastic anchors, 100 screws and 1/4”
masonry drill bit in a plastic case.
• Plastic gray ribbed anchors with lip design for electronic timer, pump start
relay installations. Use with concrete block, brick and wallboard.
• Anchors have internal ribs for better centering of screws, locking lugs
against pull and twist. Exterior design prevents fall out in overhead holes.
• Kit available with combination slotted/phillips head or tri-combination,
slotted/phillips/hex head #10 x 1” screws.
• Kits complete with 1/4” x 4” masonry drill bit.
• Clear, unbreakable plastic case with molded-in hanging tab.
Combo Tri Combo
Head Head
Part Number Description Ctn Qty List Price
AK10CSPR Ribbed Combo Head 36 $14.11
AK10TCR Ribbed Tri Combo Head 36 15.00
HARVARD CONTRACTOR’S
Power Cord Features:
• Three prong straight (115V) or right angle (115V, 220V) molded plugs.
• 16 gauge, 3 conductor, 13 amp, 125 Volt rating.
• 14 gauge, 3 conductor, 15 amp, 250 Volt rating.
• Six foot cord length.
• Free end is split, stripped 3/8”.
• UL and CSA listed in US and Canada.
PTC163-6ST PTC163-6RA
PTC143-6RA220
Part Number Description Wire Gauge Volt Rating Ctn Qty List Price
PTC163-6ST Straight plug cord 16 125 V 50 $ 6.61
PTC163-6RA Right angle plug cord 16 125 V 50 12.07
PTC143-6RA220 Right angle plug cord 14 250 V 50 14.11
1/15/13
P.45
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Installation & Repair
ET1983 Electrical Tester Features:
• Checks 120, 240, 440VAC and 150, 300, 500VDC
• Handy, economical, durable.
• Ideal for any electrical installation or repair.
• Extra long insulated lead with test probe for added convenience.
• Easy to read, bright indicator light.
• Requires no batteries.
• Packaged in slide blister card.
• Meets CE requirements.
• UL listed.
Part Number Description Ctn/Case Qty List Price
ET1983 120, 240, 440V tester 10/120 $ 10.18
ET1983
2135
Scotchcast™ 2135 Wet-Niche Potting Features:
• Product meets NEC requirements to allow the use of rigid nonmetallic
conduit in the installation of wet-niche underwater lighting fixtures.
• Provides protection against corrosion and deteriorating effects of pool water
by encapsulating the 8 AWG ground connection in a wet niche shell.
• The wet-niche shell is a corrosion-resistant metal housing for underwater
fixtures in permanently installed pools.
• Packaged in easy-mix, single use, 1.8 oz. container.
• Will not sag or drip. Gels in minutes and can be submerged within 4 hrs.
Part Number Description Ctn Qty List Price
2135 Wet-Niche Potting 1.8 oz. 10 $ 93.94
1/15/13
P.46
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Repair Fittings for Sch 40 Pipe
Pipe Extender and Inside Connector Repair Fitting Features:
• For Sch 40 pipe.
• Saves labor.
• Invisible after installation.
• Permanent repair.
• Insignificant flow restriction.
• PVC Construction.
• PIC Series connects two pieces of Sch 40 pipe with flush joint.
Part Number Description IPS Size Ctn Qty List Price
Pipe Extender Repair Fitting
PEX50 Pipe Extender 1/2” 48 $ 2.10
PEX75 Pipe Extender 3/4” 48 2.66
PEX100 Pipe Extender 1” 48 3.41
PEX125 Pipe Extender 1 1/4” 48 4.00
PEX150 Pipe Extender 1 1/2” 48 4.73
PEX200 Pipe Extender 2” 48 5.32
PEX250 Pipe Extender 2 1/2” 96 7.23
PEX300 Pipe Extender 3" 96 10.45
PEX400 Pipe Extender 4" 48 12.32
Inside Connector Repair Fitting
PIC100 Inside Connector 1” 48 3.41
PIC150 Inside Connector 1 1/2” 48 4.73
PIC200 Inside Connector 2” 48 5.32
PEX Series
PIC Series
1/15/13
P.47
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Concrete Repair
DP600
Part Number Description Ctn Qty List Price
DP600 Concrete Repair, 8.4 fl oz cartridge 6 $ 136.72
supplied with 2 nozzles
Horizontal Concrete Repair Features:
Hardens in as little at 5 minutes,
Cracks and spalls in concrete floors are an eyesore as well as a potential
safety risk. Fixing them has meant either hiring and waiting for an outside
contractor or doing it youself with a repair method that takes the floor out of
service for up to 24 hours. Now with 3M Concrete Repair, you save money
and time.
• Self-leveling urethane flows
smoothly into cleaned cracks and
gaps and hardens in as little as 5
minutes. A fork lift can pass over a
repair in as few as 15 minutes.
• Hardens to any depth without
cracking or shrinking.
• Flexible urethane expands and
contracts for durability that outlasts
repairs made with concrete.
• Do it yourself with a common
caulking gun and eliminate the cost
and wait for an outside contractor.
• Easy to use - Just clean damaged
area and fill. With every squeeze of
the caulking gun trigger, cartridge
nozzle meters and mixes precise
proportions for optimum
performance.
Part Number Size Color Ctn Qty List Price
CG9 9” Ratchet Blue 20 6.36
9” Ratchet Style Caulking Gun
4/2009
P.48
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Concrete Repair
Horizontal Concrete Repair Specifications:
• Gray, self-leveling urethane concrete repair.
• 8.4 fl oz. cartridge of concrete repair and 2 nozzles.
• Work life of 70 sec.
• Handling time of 5 minutes
• Cure time of 60 minutes
Applications:
• Repairing cracks and spalls on concrete floors or horizontal surfaces.
• Setting anchors in concrete floors or horizontal surfaces.
• Light-duty custom threading and anchoring.
• Use outdoors or in highly ventilated area.
Clean
Remove all loose
material from area
to be filled.
Concrete should be
dry and grease-free.
Fill
Dispense product
into deepest part of
repair areas, slightly
overfilling. Product
self-levels and is
tack-free in as little
as one minute.
Finish
In as little as 15 min-
utes, product can be
sanded to remove
rough edges. It can
be painted within
one hour.
Bead Size Linear Feet per
dimension 8.4 fl oz.
1/16” 815.0
1/8” 205.0
1/4” 51.9
3/8” 22.2
1/2” 12.4
Approximate coverage:
Crack Crack Lineat Feet per
Width Depth 8.4 fl. oz.
1/4” 1/4” 19.3
1/2” 1/4” 9.9
3/4” 1/4” 6.4
1” 1/4” 4.9
1/4” 1/2” 9.9
1/2” 1/2” 4.9
3/4” 1/2” 3.0
1” 1/2” 2.0
Quick and Easy Spall Repair
1/15/13
P.49
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pool Service Accessories
Universal Motor Cover Features:
• Fits all motors from 1/3 hp to 2 hp.
• Shields and protects outdoor motors from sun, rain and dust.
• Made of heavy duty plastic for long life and durability.
• Heat resistant white top and attractive blue sides.
• Sturdy, will not fade from sun or ultraviolet rays.
• Assembles in minutes. No tools needed.
Part Number Description Ctn Qty List Price
B8200C Universal Motor Cover 12 $ 39.52
B8200C
2 in 1 Swimming Pool Plug Wrench Features:
• Fits 1 1/2” or 2” cleanout plugs.
• 31” long.
• Removable 18” plated steel handle.
• Heavy duty, powder coated steel to resist rust and corrosion.
• No welds to corrode.
Part Number Description Ctn Qty List Price
SPPW405 1 1/2” / 2” pool plug wrench with handle 24 $ 46.25
SPPW405H Replacement handle only for SPPW405 250 6.97
SPPW405
AGLFB19
Part Number Description Fits Tubes Ctn Qty List Price
AGLFB19 Male Ladder bumper 1.9” OD 200 $ 4.09
MBC75
Part Number Description Size Ctn Qty List Price
MBC75 Master Blaster Cleaner 3/4" 12 $ 20.81
Master Blaster Cleaner Features:
• 3/4" FGHT connection.
• Handy on/off lever.
• For general pool/spa cleanup of filters, under copings.
Ladder Bumper Features:
• White, molded EPDM.
4/2009
P.50
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pool Service Accessories
Brusher Features:
• Brusher attaches to back of existing pool cleaner.
• Brushes and scrubs the floor and walls of your pool
as your pool cleaner does its job.
• Dislodges dirt, algae and bacteria spores while
reducing calcium and scale build-up.
• Ideal for use in all pools including plaster, aggregate, painted and vinyl.
• Eliminates manual pool brushing.
• Made of ABS plastic with nylon bristles.
• Installs in minutes with stainless steel mounting screws included.
• Sizes to fit Legend and Polaris brand pool cleaners.
• Patent Pending.
Part Number Description Ctn Qty List Price
25550 Brusher for Legend Models 12 $ 32.07
25560 Brusher for Polaris 180/280 Models 12 32.07
25570 Brusher for Polaris 360/380 Models 12 32.07
Brusher
Align top of brusher to
frame seam while cen-
tering rear thruster jet.
Thread in self tapping
screws to secure.
TM
Pump Tanks - Sourceline™
VERTICAL STAND MODELS
• Appliance Gray finish
• Malleable elbow system connection.
• Maximum working temperture: 200°F.
• Maximum working pressure: 100 psig
INLINE MODELS
• Appliance Gray finish
• Maximum working temperture: 200°F.
• Maximum working pressure: 100 PSIG
HORIZONTAL PUMP STAND MODELS
• Appliance Gray finish
• Maximum working temperture: 200°F.
• Maximum working pressure: 100 PSIG
Total Max Shipping System Precharge
Part Dimensions (ins) Volume Accept Drawdown (gal) Wt (Vol) Pallet Conn. Pressure List
Number H W L (gal) Factor 20/40 30/50 40/60 lbs (cu ft) Qty NPTM (psig) Price
SL5H 11 10 9/16 18 1/4 5.3 0.80 2.1 1.8 1.6 13 (1.5) 72 3/4” 20 $ 248.85
SL14H 16 15 3/8 20 7/8 14.0 0.81 5.6 4.8 4.1 29 (4.0) 18 1” 38 434.70
Total Max Shipping System Precharge
Part Dimensions (ins) Volume Accept Drawdown (gal) Wt (Vol) Pallet Conn. Pressure List
Number Dia Height (gal) Factor 20/40 30/50 40/60 lbs (cu ft) Qty NPTM (psig) Price
SL2I 8 12 5/8 2.0 0.45 0.8 0.7 0.6 5 (0.6) 75 3/4” 18 $ 91.98
SL4I 11 15 4.4 0.55 1.8 1.5 1.3 9 (1.2) 48 3/4” 18 126.00
SL8I 11 22 1/4 7.4 0.43 3.1 2.6 2.2 15 (2.0) 32 3/4” 28 203.70
SL10I 15 3/8 17 3/4 10.3 1.00 4.1 3.5 3.0 20 (3.0) 18 1”* 38 227.85
SL14I 15 3/8 22 14.0 0.81 5.6 4.8 4.1 22 (4.1) 18 1”* 38 242.55
* NPTF connection.
Total Max Shipping System Precharge
Part Dimensions (ins) Volume Accept Drawdown (gal) Wt (Vol) Pallet Conn. Pressure List
Number Dia Height (gal) Factor 20/40 30/50 40/60 lbs (cu ft) Qty NPTF (PSIG) Price
SL14V 15 3/8 25 1/8 14.0 0.81 5.6 4.8 4.1 25 (3.8) 18 1” 38 $ 295.05
SL20V 15 3/8 32 1/8 20.0 0.57 8.0 6.8 5.9 33 (4.9) 18 1” 38 347.55
SL32V 15 3/8 46 1/2 32.0 0.35 - 10.9 9.4 43 (7.0) 9 1” 38 593.25
SL34V 22 29 5/8 34.0 1.00 13.7 11.6 10.0 61 (9.5) 4 1 1/4” 38 651.00
SL44V 22 36 44.0 0.77 17.7 15.0 12.9 69 (11.0) 4 1 1/4” 38 751.80
SL62V 22 46 3/4 62.0 0.55 24.9 21.1 18.2 92 (13.9) 4 1 1/4” 38 887.25
SL86VT 22 62 1/4 86.0 0.39 - 29.2 25.3 114 (18.1) 4 1 1/4” 38 1080.45
SL86VS 26 47 1/4 86.0 0.54 34.6 29.2 25.3 123 (18.9) 4 1 1/4” 38 1054.20
SL119V 26 61 7/8 119.0 0.39 - 40.5 35.0 166 (24.5) 4 1 1/4” 38 1502.55
ANSI/NSF 61
ANSI/NSF 61
ANSI/NSF 61
™
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/2/13
1.1
Pre-Pressurized Water System Tanks Cross Reference
( ) represents total volume (gals.)
™
SOURCELINE™ Characteristics
•Projection welded airtight valve
• Durable steel tank with appliance-like finish
• Pre-pressurized, sealed-in air chamber
• Butyl/EPDM diaphragm isolates water from air
• Separate polypropylene liner
• 100% non-metallic reservoir
• Water-tight, welded system connection
• 100 PSIG maximum working pressure
• NSF Standard 61 listed
SOURCELINE™ Facts
• Seamless liner
• Diaphragm never creases like bladder
tank designs
• No bubbles or corners to trap sediment
• Does not promote bacteria growth
• 5 year limited warranty
AGI Flexcon Flexcon AO Smith Sta-Rite State Elbi Wessels Str. Fibers Amtrol Amtrol Amtrol Amtrol
Sourcline Challenger Well-Rite Goulds Pro-Source PermaAir Top Pro Well Mate Well-X-Trol Wel-Flo Champion ProLine
SL2I (2) JR6(2.1) JR6(2.1) V6P(2) PIL-2(2) D-8(2.1) FX8(2.1) WX101(2)
SL4I(4.4) JR15(4.5) JR15(4.5) V15P(4.5) PIL-5(4.6) D-18(5) FX19(5) WM-2(3.6) WX102(4.4)
SL5H(5.3) JR44HS(5.2) JR44HS(5.2) PS15H-S05(6) FX20H(5.3) WX105PS(5.3)
JR20(6.0) JR20(6.0) PS15-S02(6) D-25(6.5)
SL8I(7.4) JR25(8.5) JR25(8.5) V25P(8.2) PIL-7(7.3) WX103(7.4)
SL10I(10.3) D-35(9) WX104(10.3)
SL14I(14) PIL-14(14) WX200(14)
SL14V(14) PC44(14) WR45(14) V45P(13.9) PS30-T01(14) PAD-14(14) DV-50(13.5) FX60V(16) WM-4(14.5) WX201(14)
SL20V(20) PC66(20) WR60(20) V60(19.9) PS42T-T02(19) PAD-20(20) DV-80(21) FX80V(21) WM-6(19.8) WX202(20) WF60(20) CH4202(20) CA4202(20)
PC88(26) WR80(26) DV-100(27) FX100V(26)
SL32V(32) PC111(32) WR100(32) V100(31.8) PS75T-T03(32) WM-9(29.5) WX203(32) WF100(32) CH8003(32) CA8003(32)
SL34V(34) PC122(33.4) WR120(33.4) PS82T-T05(35) PAD-36S(36) WX205(34) WF110(34) CH8205(34) CA8205(34)
SL44V(44) PC144(44) WR140(44) V140(45.2) DV-150(40) WM-12(40.3) WX250(44) WF140(44) CH10050(44) CA10050(44)
PS120-T50(50) PAD-52(52) FX200V(52)
SL62V(62) PC211(62) WR200(62) V200(65.1) PS200-T51(62) DV-200(53) WM-20WB(60) WX251(62) WF200(62) CH12051(62) CA12051(62)
SL86VT(86) PC244(81) WR240(81) V260(84.9) PAD-86(86) WX252(86) WF252(86) CH252(86) CA17252(86)
SL86VS(86) PC266(85) WR260(85) V250(83.5) PS220-T52(85) DV-300(80) FX300V(80) WM-25WB(86.7) WX302(86) WF260(86) CH17002(86) CA17002(86)
PAD-96(96)
SL119V(119) PC366(119) WR360(119) V350(115.9) PAD-119(119.5) DV-450(119) WM-35WB(119.7) WX350(119) WF360(119) CH22050(119) CA22050(119)
DV-500(132) FX500V(132)
Pump Tanks - Sourceline™
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.7
Tank Crosses - Short Cast
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHT100FB 2 1/2” 1” fpt 1” X 3/4” 3/4” (1) 1/4” (2) Bronze Import 5/40 $ 31.31
CCAT100BS 4 1/4” 1” x 3/4” 1” x 3/4” 1/2” (1) 1/4” (2), 1/2” (1) Brass Import 4/40 52.54
CHC125B 4 1/4” 1 1/4” x 1” 1” x 3/4” 1/2” (1) 1/4” (3) Bronze USA 12 51.43
CHC12550BS 4 1/2" 1 1/4" x 1" 1" x 3/4" 3/4" (1) 1/4" (2) Brass Import 5/40 41.00
CIC701B 3 3/4” 1 1/4” x 1” 1 1/4” x 1” 3/4” (1) 1/4” (3) Bronze USA 12 56.61
CHT125B 3 3/4” 1 1/4” x 1” 1 1/4” x 1” 3/4” (1) 1/4” (2) Bronze Import 5/30 22.63
CIC701BS 4 1/2" 1 1/4" x 1" 1 1/4" x 1" 3/4" (1) 1/4" (2) Brass Import 4/32 39.11
CIC125B 4 1/4” 1 1/4” x 1” 1” x 3/4” 3/4” (1) 1/4” (2), 1/2” (1) Bronze Import 4/40 51.66
CIC125 4 1/4” 1 1/4” x 1” 1” x 3/4” 3/4” (1) 1/4” (2), 1/2” (1) PVC* USA 100 12.32
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CICS100B 4 3/4” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze USA 12 $ 46.71
CICS100BS 4 1/2” 1” x 3/4” 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 5/40 27.79
CIC3125B 5” 1 1/4” x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Bronze USA 12 62.87
CIC3125BS 4 1/2” 1 1/4” x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 4/32 41.00
CIC71250BS 4 1/2" 1 1/4" x 1" 1" x 3/4" 1/2" (2) 1/4" (2) Brass Import 5/40 39.71
CIC712B 4” 1 1/4” x 1” 1” x 3/4” 3/4” (2) 1/4” (2) Bronze USA 12 53.45
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
• Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• Prices are for bulk packaged tank crosses.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Short Cast Crosses with 1 drain and 2 or 3 top
ports.
* Do not use teflon tape with
PVC tank cross applications.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CICS100BSUE** 5 1/2” 1” 1”x3/4” 1/2” (2) 1/4” (2) Brass Import 4/24 $ 31.05
CICS100BSU* 5 1/2” 1” 1”x3/4” 1/2” (2) 1/4” (2) Brass Import 4/24 49.61
☺CICS100BU** 5 1/2” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze Import 4/24 29.00
CICS125BSUE** 5 1/2” 1 1/4”x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 4/24 33.93i
CICS125BSU* 5 1/2” 1 1/4”x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 4/24 62.78
☺CICS125BU** 5 1/2” 1 1/4” x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Bronze Import 4/24 41.00
Short Cast Crosses with Union Disconnect
* with Teflon gasket seal
** with metal to metal ball joint seal
“E” Series light pattern brass tank crosses compete with Merrill & Boshart equivalents.
☺CICS100BU, CICS125BU bronze metal to metal seal are Closeout - Limited Quantities
Short Cast Crosses with 2 drain and 2 top ports.
CHT100FB CHT125B
Tank Crosses - Short Cast, Specialty
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CWM100BS 4 1/2” 1” (FIP) 1”x3/4” 1/2” (2) 1/4” (2) Brass Import 5/40 $ 34.07
CWM125BS 4 3/4” 1 1/4” (FIP) 1 1/4”x1” 3/4” (2) 1/4” (2) Brass Import 4/32 43.04
CICS736BS 2 1/2” 1 1/4” MIP x 1” FIP 1”x3/4” 1/2” (2) 1/4” (2) Brass Import 5/40 24.82i
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CFC100BS 4 1/2” 1” Union Th. 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 5/40 $ 36.36
CFC125BS 4 1/2” 1 1/4” Union Th. 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 5/30 32.68i
Short cast crosses for use with Flexcon Well-Rite, Online Series
Short cast crosses for use with Flexcon Flex-Lite Series, WellMate Tanks
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
•Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• Prices are for bulk packaged tank crosses.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CICS100BSFTU 4” 1” fpt union 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 4/32 $ 43.97
CICS100BSFTU65 6 1/2” 1” fpt union 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 4/32 30.00i
CICS1251BSFTU 4” 11/4” fpt union 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 4/32 43.57
CICS125BSFTU 4” 11/4” fpt union 11/4” x 1” 3/4” (2) 1/4” (2) Brass Import 4/24 56.96
Short cast female union tank crosses for use with Flexcon “Flex-Lite” Series,
WellMate Tanks. FPT brass union w/ American Standard Buna-N o-ring.
•1” uses AS 568-212 o-ring
•1 1/4” uses AS 568-320 o-ring.
• CICS100BSFTU65 for use with WellMate Low Profile Series or other 1” mpt
connection tanks that need extra length.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CWM100BSQC 4 1/2" Quick Connect 1” x 3/4” 1/2" (2) 1/4" (2) Brass Import 4/32 $ 35.96
CWM125BSQC 4 1/2" Quick Connect 11/4" x 1” 3/4" (2 1/4" (2) Brass Import 3/24 37.04
Short cast quick connect (w/ Buna-N oring) tank crosses
for use with WellMate “Quick Connect” Series tanks.
• 1” and 1 1/4” uses AS 568-220 o-ring.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.8
Tank Crosses - Short Cast, Fabricated
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
• Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• Prices are for bulk packaged tank crosses.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
TM75BS 2 1/2" 3/4" (FIP) 1" (FIP) 1/2" (1) 1/4" (2) Brass Import 5/50 $ 18.32
TM100BS 2 1/2" 1" (FIP) 1" (FIP) 1/2" (1) 1/4" (2) Brass Import 5/50 19.64
TM125BS 3" 1 1/4" (FIP) 1 1/4" (FIP) 3/4" (1) 1/4" (2) Brass Import 5/50 25.18
Compact cast crosses with one drain, two top ports
TM75BS TM100BS, TM125BS
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC100BSSWT * 2 1/2” 1” sweat 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 4/48 21.82
CIC125BSSWT ** 3” 1 1/4” sweat 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 4/32 22.32
Short cast cross heads and end fittings with 2 drain and 2
top ports
* Includes sweat x 1” MIP end fitting.
** Includes sweat x 1 1/4” MIP end fitting.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
7/17/12
1.9
Tank Crosses - Short Cast
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
HC100G 3 3/4” 1” (FIP) 1” (FIP) 1/2” (1) 1/4” (2) Ductile Iron Import 30 $ 19.25
HC10075G 4” 1” (FIP) 1” (FIP) 3/4” (1) 1/4” (2) Ductile Iron Import 40 14.82
HC125G 3 3/4” 1 1/4” (FIP) 1 1/4” (FIP) 1/2” (1) 1/4” (2) Ductile Iron Import 24 21.90
HC12575G 4” 1 1/4” (FIP) 1 1/4” (FIP) 3/4” (1) 1/4” (2) Ductile Iron Import 25 23.18
Short cast galvanized crosses with one drain, two top ports
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
IC100G 3" 1" (FIP) 1" (FIP) 3/4" (1) 1/4" (2) Ductile Iron Import 28 $ 19.53
IC125G 3 1/2" 1 1/4" (FIP) 1 1/4" (FIP) 3/4" (1) 1/4" (2) Ductile Iron Import 24 22.49
Short cast galvanized crosses with one drain, two top ports
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
•Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• Prices are for bulk packaged tank crosses.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
IC200G 3" 1" (FIP) 1" (FIP) 1/2" (2) 1/4" (2) Ductile Iron Import 48 $ 15.00i
IC225G 3 1/2" 1 1/4" (FIP) 1 1/4" (FIP) 3/4" (2) 1/4" (2) Ductile Iron Import 24 17.86
Short cast galvanized crosses with two drain, two top ports
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.10
7/17/12
1.10e
Tank Crosses - Long Cast NO LEAD Brass
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
General Tank Cross Features:
• Internal and external threads reduce fittings needed & installation time.
• Reduces turbulence and waterlogging in tanks without separate air
chambers.
• Cast NO LEAD brass <0.25% Pb weighted average.
•NO LEAD brass tank crosses are CA AB1953 certified.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
NO LEAD Brass
CIC100BSENL 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) NL Brass Import 2/24 $ 52.68
CIC100BS14ENL 14” 1” 1” x 3/4” 1/2” (2) 1/4” (2) NL Brass Import 2/12 55.51
CIC125BS14ENL 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) NL Brass Import 2/12 100.27
NO LEAD BRASS Long Cast Tank Crosses
with 2 drain & 2 top ports.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHC100BSENL 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) NL Brass Import 2/24 $ 54.89
NO LEAD BRASS Long Cast Tank Crosses
with 1 drain & 2 top ports.
1/15/13
1.10f
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Tank Crosses - Long Cast NO LEAD Brass, Stainless Steel
TM
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
NO LEAD Brass
CIC100BSUENL 11” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) NL Brass Import 2/20 $ 72.87
CIC100BSU14ENL 14” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) NL Brass Import 2/12 84.19
CIC125BSU14ENL 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4 “(2) NL Brass Import 2/12 116.02
304 Stainless Steel *
CIC100SSU 11” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) 304 Stainless Import 2/20 88.81
CIC100SSU14 14” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) 304 Stainless Import 2/20 104.98
CIC125SSU14 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4 “(2) 304 Stainless Import 2/12 141.90
NO LEAD BRASS or 304 STAINLESS STEEL Long Cast Tank Crosses
with union disconnect,
with 2 drain & 2 top ports.
• Metal to metal ball joint seal on NO LEAD brass crosses.
• Teflon gasket seal on 304SS crosses.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHC100BSUENL 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) NL Brass Import 2/20 $ 72.87
CHC125BSU14ENL 14” 1 1/4” 1 1/4” x 1” 3/4” (1) 1/4’ (2) NL Brass Import 2/12 106.66
NO LEAD BRASS Long Cast Tank Crosses
with union disconnect,
with 1 drain & 2 top ports.
• Metal to metal ball joint seal.
General Tank Cross Features:
• Internal and external threads reduce fittings needed & installation time.
• Reduces turbulence and waterlogging in tanks without separate air
chambers.
• Cast NO LEAD brass <0.25% Pb weighted average or 304 Stainless Steel.
•NO LEAD brass tank crosses are CA AB1953 certified.
• 304 Stainless Steel crosses contain no lead.
*
Tank Crosses - Long Cast
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
• Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHC100BSE 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Brass Import 2/24 $ 44.29
CHC100BS 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Brass Import 2/24 50.64
CHC100B 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Bronze USA 12 62.32
Long Cast Tank Crosses with 1 drain and 2 top ports.
“E” Series light pattern brass tank crosses compete with Merrill & Boshart equivalents.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC100BSE 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 2/24 $ 42.32
CIC100BS 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 2/24 50.64
CIC100B 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze USA 12 62.89
CIC100BS14 14” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 2/20 56.39
CIC125BS14E 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 2/12 86.81
CIC125BS14 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 15 101.96
Long Cast Tank Crosses with 2 drain and 2 top ports.
“E” Series light pattern brass tank crosses compete with Merrill & Boshart
equivalents.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC100BU85 8 1/2” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze Import 2/20 $ 67.61
CIC100BSUE 11” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) Brass Import 2/20 59.64
CIC100BU 11” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) Bronze Import 2/20 72.86
CIC100BU14 14” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) Bronze Import 2/20 64.29i
CIC125BSU14E 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4 “(2) Brass Import 2/12 95.61
CIC125BU14 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4 “(2) Bronze Import 2/12 115.70
Long Cast Tank Crosses with union disconnect, 2 drain and 2 top ports.
“E” Series light pattern brass tank crosses compete with Merrill & Boshart
equivalents.
• Metal to metal ball joint seal.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHC100BU 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Bronze Import 2/20 $ 72.86
CHC125BU14 14” 1 1/4” 1 1/4” x 1” 3/4” (1) 1/4’ (2) Bronze Import 2/12 108.95
Long Cast Tank Crosses with union disconnect, 1 drain and 2 top ports.
• Metal to metal ball joint seal.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.11
Tank Crosses - Long, Fabricated
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHC100BF 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Bronze/Copper USA 12 $ 65.82
CHC100BF13 13” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Bronze/Copper USA 12 71.54
CHC125BF 14” 1 1/4” 1 1/4” x 1” 3/4” (1) 1/4” (2) Bronze/Copper USA 12 81.94
CHC125BF16 16” 1 1/4” 1 1/4” x 1” 3/4” (1) 1/4” (2) Bronze/Copper USA 6 87.04
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC740BF 18” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze/Copper USA 9 $ 151.46
CIC741BF 18” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4“(2) Bronze/Copper USA 6 243.05
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC100BF 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze/Copper USA 12 $ 65.00
CIC100BF13 13” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze/Copper USA 12 71.54
CIC125BF 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) Bronze/Copper USA 12 80.36
CIC125BF16 16” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) Bronze/Copper USA 6 83.46
Long Fabricated Tank Crosses with 2 drain and 2 top taps.
• Crosses fabricated with 96.5% tin, 3.5% lead free solder.
Long Fabricated Tank Crosses with 1 drain and 2 top taps.
• Crosses fabricated with 96.5% tin, 3.5% lead free solder.
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
•Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• Prices are for bulk packaged tank crosses.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Long Fabricated Elevated Tank Crosses with union disconnect.
• Crosses fabricated with 96.5% tin, 3.5% lead free solder.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
2/15/11
1.12
1/15/13
1.12a
Tank Crosses - Long, Fabricated
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHC100BFNL 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) NL Bronze/Copper USA 12 $ 79.79
CHC100BF13NL 13” 1” 1” x 3/4” 1/2” (1) 1/4” (2) NL Bronze/Copper USA 12 95.39
CHC125BFNL 14” 1 1/4” 1 1/4” x 1” 3/4” (1) 1/4” (2) NL Bronze/Copper USA 12 104.75
CHC125BF16NL 16” 1 1/4” 1 1/4” x 1” 3/4” (1) 1/4” (2) NL Bronze/Copper USA 6 107.39
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC740BFNL 18” 1” 1” x 3/4” 1/2” (2) 1/4” (2) NL Bronze/Copper USA 9 $ 172.39
CIC741BFNL 18” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4“(2) NL Bronze/Copper USA 6 270.39
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC100BFNL 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) NL Bronze/Copper USA 12 $ 82.00
CIC100BF13NL 13” 1” 1” x 3/4” 1/2” (2) 1/4” (2) NL Bronze/Copper USA 12 85.29
CIC125BFNL 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) NL Bronze/Copper USA 12 104.14
CIC125BF16NL 16” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) NL Bronze/Copper USA 6 108.39
NO LEAD Long Fabricated Tank Crosses with 2 drain and 2 top taps.
NO LEAD Long Fabricated Tank Crosses with 1 drain and 2 top taps.
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
NO LEAD Long Fabricated Elevated Tank Crosses with union disconnect.
4/2009
1.12b
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Tank Installation Packages - 1” Bottom Discharge
Part Number Cross Included Material Length List Price
TP100BS CHC100BS Cast brass 11” $ 110.08
TP100B CHC100B Cast bronze 11” 133.82
• see above 1”x11” Long Brass or Bronze Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4x3 Brass Nipple.
• IPG1002-4L 0-100lb. Steel Case Pressure Gauge.
Part Number Cross Included Material Length List Price
IP100BSR CIC100BS Cast brass 11” $ 134.85
IP100BSR14 CIC100BS14 Cast Brass 14" 138.92
IP100BR CIC100B Cast bronze 11” 165.35
IP100BFR CIC100BF Fab. bronze 11” 166.61
IP100BF13R CIC100BF13 Fab. bronze 13” 179.45
• see above 1” Long Brass or Bronze Safety Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4x3 Brass Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• RV50* 1/2” Relief Valve. * IRV50 with IP100BSR, IP100BSR14
• HNKD50 1/2” No Kink Boiler Drain.
OPTIONS: Add suffix letter to end of part number.
SUFFIX PRODUCT SUBSTITUTION LIST ADDER
L 9013FSG2M4 30/50 Low Pressure Cutoff Switch. $ 10.86
Special order custom fitting packages are available. Contact your representative or customer service for quotation.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.15
TP100BSNL CHC100BSENL NO LEAD Brass 11” $ 121.59
• see above 1”x11” Long NO LEAD Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4x3 Brass Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge.
IP100BSENL CIC100BSENL NO LEAD Brass 11” $136.38
IP100BS14ENL CIC100BS14ENL NO LEAD Brass 14" 128.83
IP100BFRNL CIC100BFNL NO LEAD Brass 11” 161.95
IP100BF13RNL CIC100BF13NL NO LEAD Brass 13” 169.82
• see above 1” Long NO LEAD Brass Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4x3 Brass Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• IRV50NL 1/2” NO LEAD Brass Relief Valve
• HNKD50NL 1/2” NO LEAD Brass No Kink Boiler Drain
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
10/23/12
1.16
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Tank Installation Packages - 1” Bottom Discharge
TM
Part Number Cross Included Material Length List Price
IP100BRU CIC100BU Cast bronze 11” $ 156.03
IP100BRU14 CIC100BU14 Cast bronze 14” 171.58
• see above 1” Long Bronze Safety Tank Cross with union
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4x3 Brass Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• IRV50 1/2” Imported Relief Valve.
• HNKD50 1/2” No Kink Boiler Drain.
IP100BSUENL CIC100BSUENL NO LEAD Brass 11” $ 145.12
IP100BSU14ENL CIC100BSU14ENL NO LEAD Brass 14” 141.45
• see above 1” Long NO LEAD Safety Tank Cross with union
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4x3 Brass Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• IRV50NL 1/2” NO LEAD Brass Relief Valve
• HNKD50NL 1/2” NO LEAD Brass No Kink Boiler Drain
OPTIONS: Add suffix letter to end of part number.
SUFFIX PRODUCT SUBSTITUTION LIST ADDER
L 9013FSG2M4 30/50 Low Pressure Cutoff Switch. $ 10.86
Special order custom fitting packages are available. Contact your representative or customer service for quotation.
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
• ALL stainless steel tank installation package components contain NO LEAD.
IP100SSUNL CIC100SSU Stainless Steel 11” $ 203.68
IP100SSU14NL CIC100SSU14 Stainless Steel 14” 228.08
• see above 1” Long Stainless Steel Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• SS80-1/4x3 Stainless Steel Nipple.
• EIPG1002-4LNL 100lb No Lead Pressure Gauge.
• IRV50SS 1/2” Stainless Steel Relief Valve.
• IHBB50SS 1/2” Stainless Steel Hose Bibb.
• HTT120-1/2SS 1/2” x 120” Stainless Steel Teflon Tape
1/15/13
1.17
Tank Installation Packages - 1” Bottom Discharge
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
OPTIONS: Add suffix letter to end of part number.
SUFFIX PRODUCT SUBSTITUTION LIST ADDER
L 9013FSG2M4 30/50 Low Pressure Cutoff Switch. $ 10.86
Special order custom fitting packages are available. Contact your representative or customer service for quotation.
Part Number Cross Included Material Length List Price
TP100GF HC100GF Fab Galvanized 11 1/2” $ 81.33
• HC100G 1” Galvanized Tank Cross.
• GS80-1/4x3 Galvanized Steel Nipple.
• GS80-1x8 Galvanized Steel Nipple.
• 9013FSG2 30/50 Pressure Switch.
• IPG1002-4L 100 lb. Steel Case Pressure Gauge.
• HNKD50 1/2” No Kink Boiler Drain.
TP100GFNL HC100GF Fab Galvanized 11 1/2” $ 84.96
• HC100G 1” Galvanized Tank Cross.
• GS80-1/4x3 Galvanized Steel Nipple.
• GS80-1x8 Galvanized Steel Nipple.
• 9013FSG2 30/50 Pressure Switch.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• HNKD50NL 1/2” NO LEAD Brass No Kink Boiler Drain
Part Number Cross Included Material Length List Price
IP100PFR IC100F Fab. PVC 14” $ 86.93
• IC100F 1”x14” Long PVC Fabricated Safety Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• 1/4 x 3 PVC Schedule 80 Nipple.
• IPG1002-4L 100lb.Steel Case Pressure Gauge.
• IRV50 1/2” Relief Valve.
• HNKD75 3/4” No Kink Boiler Drain.
IP100PFRNL IC100F Fab. PVC 14” $ 94.38
• IC100F 1”x14” Long PVC Fabricated Safety Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• 1/4 x 3 PVC Schedule 80 Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• IRV50NL 1/2” NO LEAD Brass Relief Valve
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain
Part Number Cross Included Material Length List Price
TP100PF IC100F Fab. PVC 14” $ 67.68
• IC100F 1” x 14” Long PVC Fabricated Safety Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• 1/4x3 PVC Schedule 80 Nipple.
• 450-005 PVC Schedule 40 Threaded Plug.
• IPG1002-4L 0-100lb. Steel Case Pressure Gauge.
TP100PFNL IC100F Fab. PVC 14” $ 69.49
• IC100F 1” x 14” Long PVC Fabricated Safety Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• 1/4x3 PVC Schedule 80 Nipple.
• 450-005 PVC Schedule 40 Threaded Plug.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• Do not use teflon tape with PVC tank cross applications.
• Use thread paste without teflon approved for plastic threaded fittings only.
Tank Installation Packages - 1 1/4” Bottom Discharge
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.18
Part Number Cross Included Material Length List Price
IP125BFR7 CIC125BF Fab. bronze 14” $ 205.01
IP125BF16R7 CIC125BF16 Fab. bronze 16” 207.94
• See above 1 1/4” Long Bronze Fabricated Safety Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb. Steel Case Pressure Gauge.
• RV75 3/4” Relief Valve.
• HNKD75 3/4” No Kink Boiler Drain.
Part Number Cross Included Material Length List Price
TP125BF CHC125BF Fab. bronze 14” $ 164.41
• CHC125BF 1 1/4” Long Bronze Fabricated Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb. Steel Case Pressure Gauge.
Part Number Cross Included Material Length List Price
IP125BS14 CIC125BS14 Cast bronze 14” $ 186.60
• CIC125BS14 1 1/4” Long Bronze Tank Cross
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb. Steel Case Pressure Gauge.
• IRV75 3/4” Relief Valve.
• HNKD75 3/4” No Kink Boiler Drain.
IP125BS14ENL CIC125BS14ENL NO LEAD Brass 14” $ 174.47
• CIC125BS14ENL 1 1/4” Long NO LEAD Brass Tank Cross
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb. NO LEAD Brass Pressure Gauge.
• IRV75NL 3/4” NO LEAD Brass Relief Valve.
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain.
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
TP125BFNL CHC125BFNL NO LEAD Brass 14” $ 156.08
• CHC125BFNL 1 1/4” Long NO LEAD Brass Tank Cross
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4LNL 100lb. NO LEAD Brass Pressure Gauge.
IP125BFR7NL CIC125BFNL NO LEAD Brass 14” $ 192.10
IP125BF16R7NL CIC125BF16NL NO LEAD Brass 16” 197.87
• see above 1 1/4” Long NO LEAD Brass Tank Cross
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4LNL 100lb. NO LEAD Brass Pressure Gauge.
• RV75NL 3/4” NO LEAD Brass Relief Valve.
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Tank Installation Packages - 1 1/4” Bottom Discharge
10/23/12
1.19
IP125BSU14ENL CIC125BSU14ENL NO LEAD Brass 14” $ 191.34
• See above 1 1/4” Long NO LEAD Brass Tank Cross
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb. NO LEAD Brass Pressure Gauge.
• IRV75NL 3/4” NO LEAD Brass Relief Valve.
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain.
IP125SSU14NL CIC125SSU14 Stainless Steel 14” $ 265.68
• see above 11/4” Long Stainless Steel Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• SS80-1/4x3 Stainless Steel Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge.
• IRV75SS 3/4” Stainless Steel Relief Valve.
• IHBB75SS 3/4” Stainless Steel Hose Bibb.
• HTT120-1/2SS 1/2” x 120” Stainless Steel Teflon Tape.
Part Number Cross Included Material Length List Price
IP125BRU14 CIC125BU14 Cast bronze 14” $ 201.88
• See above 1 1/4” Long Bronze Tank Cross with union
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb. Steel Case Pressure Gauge.
• IRV75 3/4” Relief Valve.
• HNKD75 3/4” No Kink Boiler Drain.
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
• ALL stainless steel tank installation package components contain NO LEAD.
OPTIONS: Add suffix letter to end of part number.
SUFFIX PRODUCT SUBSTITUTION LIST ADDER
L 9013FSG2M4 30/50 Low Pressure Cutoff Switch. $ 10.86
Special order custom fitting packages are available. Contact your representative or customer service for quotation.
Tank Installation Packages - 1” Side Discharge
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.20
Part Number Cross Included Material Length List Price
TP100BR CCAT100BS Cast brass 4 1/4” $ 123.21
• CCAT100BS 1” Bronze Safety Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• iRV50 1/2” Relief Valve.
• HNKD50 1/2” No Kink Boiler Drain.
Part Number Cross Included Material Length List Price
IPS100BS CICS100BS Cast brass 4 1/2” $ 103.86
• see above 1” Brass or Bronze Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 0-100lb Steel Case Pressure Gauge.
• RV50 * 1/2” Relief Valve. * IRV50 with IPS100BS
• HNKD50 1/2” No Kink Boiler Drain.
TP100BRNL CCAT100BSNL NO LEAD Brass 4 1/4” $ 132.03
• CCAT100BSNL 1” NO LEAD Brass Safety Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• IRV50NL 1/2” NO LEAD Brass Relief Valve
• HNKD50NL 1/2” NO LEAD Brass No Kink Boiler Drain
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
IPS100BSENL CICS100BSENL NO LEAD Brass 4 1/2” $ 98.66
• see above 1” NO LEAD Brass Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• IRV50NL 1/2” NO LEAD Brass Relief Valve
• HNKD50NL 1/2” NO LEAD Brass No Kink Boiler Drain
Tank Installation Packages - 1” Side Discharge
OPTIONS: Add suffix letter to end of part number.
SUFFIX PRODUCT SUBSTITUTION LIST ADDER
L 9013FSG2M4 30/50 Low Pressure Cutoff Switch. $ 10.86
Special order custom fitting packages are available. Contact your representative or customer service for quotation.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.20a
Part Number Cross Included Material Length List Price
IPWM100BS CWM100BS Cast brass 4 1/2” $ 122.21
• CWM100BS 1” Brass Tank Cross for FLEXCON “Flex-Lite”, WELLMATE tanks
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 0-100lb Steel Case Pressure Gauge.
• IRV50 1/2” Relief Valve.
• HNKD50 1/2” No Kink Boiler Drain.
Part Number Cross Included Material Length List Price
IPS100BSFTU CICS100BSFTU Cast brass 4” $ 127.74
• CICS100BSFTU 1” Brass Tank Cross for FLEXCON “Flex-Lite”, WELLMATE tanks
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 0-100lb Steel Case Pressure Gauge.
• IRV50 1/2” Relief Valve.
• HNKD50 1/2” No Kink Boiler Drain.
IPWM100BSNL CWM100BSNL NO LEAD brass 4 1/2” $ 117.50
• CWM100BSNL 1” NO LEAD Brass Tank Cross for FLEXCON “Flex-Lite” WELLMATE tanks
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• IRV50NL 1/2” NO LEAD Brass Relief Valve
• HNKD50NL 1/2” NO LEAD Brass No Kink Boiler Drain
IPS100BSFTUNL CICS100BSFTUNL NO LEAD brass 4” $ 142.36
• CICS100BSFTUNL 1” NO LEAD Brass Tank Cross for FLEXCON “Flex-Lite”, WELLMATE tanks
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• IRV50NL 1/2” NO LEAD Brass Relief Valve
• HNKD50NL 1/2” NO LEAD Brass No Kink Boiler Drain
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
Tank Installation Packages - 1” Side Discharge
OPTIONS: Add suffix letter to end of part number.
SUFFIX PRODUCT SUBSTITUTION LIST ADDER
L 9013FSG2M4 30/50 Low Pressure Cutoff Switch. $ 10.86
Special order custom fitting packages are available. Contact your representative or customer service for quotation.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
10/23/12
1.20b
IPS100BSUENL CICS100BSUENL NO LEAD Brass 5 1/2” $ 115.18
• CICS100BSUENL 1” NO LEAD Brass Tank Cross with union
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• IRV50NL 1/2” NO LEAD Brass Relief Valve
• HNKD50NL 1/2” NO LEAD Brass No Kink Boiler Drain
IPS100SSUNL CICS100SSU Stainless Steel 5 1/2” $ 187.60
• see above 1” Short Stainless Steel Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• SS80-1/4x3 Stainless Steel Nipple.
• EIPG1002-4LNL 100lb No Lead Pressure Gauge.
• IRV50SS 1/2” Stainless Steel Relief Valve.
• IHBB50SS 1/2” Stainless Steel Hose Bibb.
• HTT120-1/2SS 1/2” x 120” Stainless Steel Teflon Tape.
Part Number Cross Included Material Length List Price
IPS100BSU CICS100BSU Cast brass 5 1/2” $ 134.55
• CICS100BSU 1” Brass Tank Cross with union
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• IRV50 1/2” Relief Valve.
• HNKD50 1/2” No Kink Boiler Drain.
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
• ALL stainless steel tank installation package components contain NO LEAD.
OPTIONS: Add suffix letter to end of part number.
SUFFIX PRODUCT SUBSTITUTION LIST ADDER
L 9013FSG2M4 30/50 Low Pressure Cutoff Switch. $ 10.86
Special order custom fitting packages are available. Contact your representative or customer service for quotation.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Tank Installation Packages - 1 1/4” Side Discharge
1/15/13
1.20c
IP3125BSENL CIC3125BSENL NO LEAD Brass 4 1/2” $ 110.21
• CIC3125BSENL 1 1/4” NO LEAD Brass Safety Tank Cross
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb. NO LEAD Brass Pressure Gauge.
• IRV75NL 3/4” NO LEAD Brass Relief Valve.
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain
Part Number Cross Included Material Length List Price
IP125BR CIC125B Cast bronze 4 1/4” $ 127.50
• CIC125B 1 1/4” Bronze Safety Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• iRV50 1/2” Relief Valve.
• HNKD75 3/4” No Kink Boiler Drain.
Part Number Cross Included Material Length List Price
IP3125BS CIC3125BS Cast brass 4 1/2” $ 125.10
IP3125B CIC3125B Cast bronze 5” 175.57
• see above 1 1/4” Brass or Bronze Safety Tank Cross
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• RV75 * 3/4” Relief Valve. * IRV75 with IP3125BS
• HNKD75 3/4” No Kink Boiler Drain.
IP125BSNL CIC125BSNL NO LEAD Brass 4 1/4” $ 136.38
• CIC125BSNL 1 1/4” NO LEAD Brass Safety Cross.
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge
• IRV50NL 1/2” NO LEAD Brass Relief Valve
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
OPTIONS: Add suffix letter to end of part number.
SUFFIX PRODUCT SUBSTITUTION LIST ADDER
L 9013FSG2M4 30/50 Low Pressure Cutoff Switch. $ 10.86
Special order custom fitting packages are available. Contact your representative or customer service for quotation.
Tank Installation Packages - 1 1/4” Side Discharge
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
10/23/12
1.20d
Part Number Cross Included Material Length List Price
IPWM125BS CWM125BS Cast brass 4 3/4” $ 118.26
• CWM125BS 1 1/4” Brass Cross for FLEXCON “Flex-Lite”, WELLMATE tanks
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• IRV75 3/4” Relief Valve.
• HNKD75 3/4” No Kink Boiler Drain.
Part Number Cross Included Material Length List Price
IPS125BSFTU CICS125BSFTU Cast brass 4” $ 134.19
• CICS125BSFTU 1 1/4” Brass Cross for FLEXCON “Flex-Lite”, WELLMATE tanks
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• IRV75 3/4” Relief Valve.
• HNKD75 3/4” No Kink Boiler Drain.
IPWM125BSNL CWM125BSNL No Lead brass 4 3/4” $ 132.41
• CWM125BSNL 1 1/4” NO LEAD Brass Cross for FLEXCON “Flex-Lite”, WELLMATE tanks
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb. NO LEAD Brass Pressure Gauge.
• IRV75NL 3/4” NO LEAD Brass Relief Valve.
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain
IPS125BSFTUNL CICS125BSFTUNL NO LEAD brass 4” $ 153.80
• CICS125BSFTUNL 1 1/4” NO LEAD Brass Cross for FLEXCON “Flex-Lite”, WELLMATE tanks
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb. NO LEAD Brass Pressure Gauge.
• IRV75NL 3/4” NO LEAD Brass Relief Valve.
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
Tank Installation Packages - 1 1/4” Side Discharge
OPTIONS: Add suffix letter to end of part number.
SUFFIX PRODUCT SUBSTITUTION LIST ADDER
L 9013FSG2M4 30/50 Low Pressure Cutoff Switch. $ 10.86
Special order custom fitting packages are available. Contact your representative or customer service for quotation.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.20e
Part Number Cross Included Material Length List Price
IP125PR CIC125 PVC 4 1/4” $ 90.92
• CIC125 1-1/4” PVC Safety Cross.
• 9013FSG2 30/50 Pressure Switch.
• 1/4 x 3 Schedule 80 PVC Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• IRV50 1/2” Relief Valve.
• HNKD75 3/4” No Kink Boiler Drain.
Part Number Cross Included Material Length List Price
IPS125BSU CICS125BSU Cast brass 5 1/2” $ 143.21
• CICS125BSU 1 1/4” Brass Cross with union
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• IPG1002-4L 100lb Steel Case Pressure Gauge.
• IRV75 3/4” Relief Valve.
• HNKD75 3/4” No Kink Boiler Drain.
IPS125BSUENL CICS125BSUENL NO LEAD Brass 5 1/2” $ 133.05
• CICS125BSUENL 1 1/4” NO LEAD Brass Cross with union
• 9013FSG2 30/50 Pressure Switch.
• B80-1/4 x 3 Brass Nipple.
• EIPG1002-4LNL 100lb. NO LEAD Brass Pressure Gauge.
• IRV75NL 3/4” NO LEAD Brass Relief Valve.
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain
IPS125SSUNL CICS125SSU Stainless Steel 5 1/2” $ 189.72
• CICS125SSU 11/4” Short Stainless Steel Tank Cross.
• 9013FSG2 30/50 Pressure Switch.
• SS80-1/4x3 Stainless Steel Nipple.
• EIPG1002-4LNL 100lb No Lead Pressure Gauge.
• IRV75SS 3/4” Stainless Steel Relief Valve.
• IHBB75SS 3/4” Stainless Steel Hose Bibb.
• HTT120-1/2SS 1/2” x 120” Stainless Steel Teflon Tape.
• ALL NO LEAD brass tank installation package components are CA AB1953 certified.
• ALL stainless steel tank installation package components contain NO LEAD
• Do not use teflon tape with PVC tank cross applications.
• Use thread paste without teflon approved for plastic threaded fittings only.
IP125PRNL CIC125 PVC 4 1/4” $ 98.99
• CIC125 1-1/4” PVC Safety Cross.
• 9013FSG2 30/50 Pressure Switch.
• 1/4 x 3 Schedule 80 PVC Nipple.
• EIPG1002-4LNL 100lb NO LEAD Pressure Gauge.
• IRV50NL 1/2” NO LEAD Brass Relief Valve.
• HNKD75NL 3/4” NO LEAD Brass No Kink Boiler Drain
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
9/7/11
1.20f
Part Number Tank Tank Suction Ctn Qty Tapped Standard
(Tapped) Capacity Port Port List Price List Price
Non-repairable *
AV45E 80 1/4” pipe 7/16”-24 pipe 50 $ 10.18 i
AV45 80 1/4” pipe 7/16”-24 pipe 50 37.98
AV45F 80 1/4” pipe 1/8” pipe tap 50 39.74
AV100E 120 3/8” pipe 7/16”-24 pipe 50 10.18 i
AV100 120 3/8” pipe 7/16”-24 pipe 50 43.01
AV100F 120 3/8” pipe 1/8” pipe tap 50 45.59
Repairable *
AV30 42 1/4” pipe 7/16”-24 pipe 100 41.83
AV42 AV42T 80 1/4” pipe tap 1/4” pipe tap 50 57.15 54.63
AV80 AV80T 120 1/4” pipe tap 1/4” pipe tap 50 66.92 63.36
AV120 AV120T 220 3/8” pipe tap 1/4” pipe tap 25 87.80 84.16
Repair Kits• Fits all makes of repairable diaphragm type controls
AV30-3A For Brady AV30 controls 42 27.65
AV42-3A For Brady AV42 controls 42 32.49
AV80-3A For Brady AV80 controls 42 37.98
AV120-3A For Brady AV120 controls 42 49.75
Plastic Air Charger *
AC100 30 21.13
CAC100 Bulk Packed 17.88
Air Charger with Tubing and Fittings **
AC100TF 20 31.48
AC100TFBT Black Tubing 20 31.48
Air Charger Installation Kit with Tubing and Fittings **
UTF1 24 18.37
UTF1BT Black Tubing 24 18.37
1/15/13
1.27
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Air Volume Controls
AC100
AV Non-Repairable
Brady Air Volume Control Features:
• Maintains water flow-stretches pump life.
• Repairable and non-repairable offering.
• Diaphragm-type air volume control maintains correct proportions of air &
water in jet systems.
• Die Cast, 96% Zinc.
• Individually cartoned.
• Available with or without Tapped Gauge Port.
• “E” Series compares to Boshart “AVC” and Merrill “AV” series non-repairable controls.
Air Charger Features:
• For jet systems.
• Positive action control.
• No flexing diaphragm or metal springs to malfunction.
• Will not corrode in a moist environment.
• Fits all tanks up to and including 82 gallon.
• Available with tube & fittings as an optional extra, specify AC100TF. Includes 60” tubing &
assortment of special brass fittings & adapters, eliminates duplication of inventories with a
single kit for all applications.
Universal Air Charger Installation Kit Features:
• Fits all air volume controls.
• Includes 60” polyethylene tubing and assortment of special brass fittings and
adapters, eliminating duplication of inventories with a single kit for all applications.
** See page 6.7 for additional lengths of MV4040 1/2” OD x 0.17” ID translucent and black tubing.
*
AV Repairable
Air Releases & Controls
HARVARD
All Plastic Deep Well Air Release Features:
• Formerly Robert Shaw* AE10
(*used with permission of Invensys Controls)
• Maintains proper ratio of air to water in submersible water
systems.
• All polyethylene construction eliminates corrosion.
• Includes gauge port and 0-40 psi limited bleed adjustment.
• NO LEAD - Third party certified.
• Made in USA.
Brady Plastic Deep Well Air Release Features:
• Maintains the proper ratio of air to water.
• Constructed of ABS resin grade plastic.
• Non-corrosive, non-conductive and completely serviceable.
• Release mechanism consists of a Buna-N procession ball &
316 stainless steel spring.
• Factory set at 20 P.S.I., adjustable from 0 to 40 P.S.I.
Deep Well Air Release Features:
• Maintains proper ratio of air to water in
submersible water systems.
• Deluxe deep well air release features ABS float and cast body
which prevents galvanic action at pump tank tapping.
• WJ1NL NO LEAD - Third party certified.
• WJ1, WJ1NL Imported.
Shallow Well Control Features:
• Preserves correct proportion of water and air in
shallow well reciprocating pump systems.
• SWCLNL NO LEAD - Third party certified.
• Imported.
Part Number Tapping Manufacturer Ctn Qty List Price
All Plastic Deep Well Air Release
HAE1 1 1/4” Harvard (formerly Robert Shaw) 49 $ 45.71
BAR125N 1 1/4” Brady 50 44.39
Deep Well Air Release
WJ1 1 1/4” Ametek 20 56.82
WJ1NL 1 1/4” NO LEAD Ametek 20 65.36
HF93B-1 1 1/4” Johnson 50 36.25
Shallow Well Control
SWCL 1 1/4” Ametek 20 66.35
SWCLNL 1 1/4” NO LEAD Ametek 20 76.05
HAE1
WJ1
SWCL
HF93B1
BAR125N
Formerly Robert
Shaw/Invensys
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.28
Installation Accessories - Submersible
Deluxe Torque Arrestor Features:
• Two piece design, molded from PVC or rubber.
• PVC torque arrestor is 40% heavier than competitors
to resist long-term casing abrasion.
• Field adjustable to hold pump centered in well.
• Fits all well casings from 4” to 8” I.D.
• Torque Arrestor is securely fastened to 1” or 1 1/4” drop pipe
w/ 2 Ideal all stainless steel clamps included.
• Available bagged, boxed or bulk without clamps.
Submersible Torque Arrestor Features:
• "Spider" style molded from rubber.
• Installs at discharge cap of submersible pump.
• Tabs are easily cut for field alteration.
• 4”-6” casing, 1” center hole.
Natural Rubber Pump Guide Features:
• Installed at the top of the submersible discharge cap.
• Permits the pump to be lowered without damage from abrading
against the well casing & ledge while centering the pump in the well.
Cable Guard Features:
• Snap-in and self clamping styles.
• Keeps power cable from abrading against well casing.
• A minimum of three to five should be used; one at the pump,
one no further than 15’ above the pump, and one between 25’ and 30’
above the pump.
• Adjustable - use in 4”, 5” and 6” wells. Available for 1” or 1 1/4” drop pipe.
• Made of polyethylene and will float.
• MG6, WG100, WG125 are IAPMO certified to CA AB1953.
Part Number Description Color Ctn Qty List Price
Deluxe PVC Torque Arrestor
TA48 Bagged, with 2 Ideal all stainless steel clamps Black 16 $ 13.88
TA48B Boxed, with 2 Ideal all stainless steel clamps Black 12 18.58
CTA48 Bulk, no clamps Black Bulk 10.84
Deluxe Rubber Torque Arrestor
TA48R Bagged with 2 Ideal all stainless steel clamps Black 16 15.68
TA48RB Boxed, with 2 Ideal all stainless steel clamps Black 12 18.36
CTA48R Bulk, No clamps Black Bulk 13.93
Standard Rubber Torque Arrestor
TA6100 6x1, (spider type) Black 50 27.47
Natural Rubber Pump Guides Fits Casing ID Guide OD Drop Pipe
SG400-3X1 4” 3” 1” Bulk 4.89
SG400-3X11/4 4” 3” 1 1/4” Bulk 4.89
SG500-4X1 5” 4” 1” Bulk 5.30
SG558-5X1 5-5/8” 5” 1” Bulk 8.74
SG600-55/8X1 6” 5 5/8” 1” Bulk 10.31
SG600-55/8X11/4 6” 5 5/8” 1 1/4” Bulk 10.31
SG625-6X1 6 1/4” 6” 1” Bulk 10.31
SG625-6X2 6 1/4” 6” 2” Bulk 10.31
Cable Guard
MG6 With two cable holes, fits 4”-6” casing, Polyethylene 100 0.96
WG100 1” Self-clamping style, fits 4”-6” casing 48 2.93
WG125 1 1/4” Self-clamping style, fits 4”-6” casing 48 4.86
TA48
TA6100
MG6 WG Series
SG Series
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.29
Installation Accessories - Submersible
PO100
ES
Part Number Description Ctn Qty List Price
Braided Safety Rope
MR25-500 Blue/White, 1/4” x 500’ Plastic Reel, 1000# 1 $ 34.93
MR25-1 Blue/White, 1/4” x 1000’ Plastic Reel, 1000# 1 62.57
MR25-3 Blue/White, 1/4” x 3000’ Plastic Reel, 1000# 1 197.32
Twisted Safety Rope
SR25-500 Black, 1/4” x 500’ Plastic Reel, 1200# 1 50.89
SR25-1 Black, 1/4” x 1000’ Plastic Reel, 1200# 1 98.93
SR25-3 Black, 1/4” x 3000’ Plastic Reel, 1200# 1 305.54
Bleeder Orifices
PO75B 3/4”, Brass 25/250 9.82
PO100 1”, Rubber, 25 per bag 100 2.04
BOT100 Yellow Brass Insert Tee 1”, w/rubber bleeder orifice 6 45.18
Ejector Screen
ES1 Brass Screen 1 9.78
ES1S Stainless Steel Screen 1 10.19
Cable Ties
CT150 Bag of 100 Nylon, 1” to 1 1/4” diameter pipe, 8” long 1 6.50 /100
CT300 Bag of 100 Nylon, 1 1/2” to 4” diameter pipe, 15 ” long 1 15.18 /100
Submersible Safety Rope Features:
• Custom extruded from tough polypropylene fiber.
• Highly resistant to chafing, abrasion &corrosion.
• Recommended wherever minimum stretch and maximum strength are required.
• Twisted SR25 Series tested in excess of 1,200 lbs.. Braided MR25 Series tested in
excess of 1,000 lbs.
• Plastic or wood reels.
Bleeder Orifices Features:
• Provides a fast bleed through its large opening.
• Complete closure prevents loss of pumping volume.
• Full 1” size molded of virgin rubber increases bleed capacity & reduces cost of pipe fitting.
• 3/4” available in brass.
• Bleeder orifice tee available. Includes yellow brass insert tee w/ 1” rubber bleeder orifice.
Ejector Screen Features:
• Protects heat pumps against plugged nozzles and clogged venturis.
• Non-corrosive brass or stainless steel screen.
• Installs easily in discharge side of ejector.
Cable Tie Features:
• UL approved, self-clinching nylon fastener.
• Ideal for holding cable to drop pipe, positioning cable guards, etc.
• Withstands -65º to 225ºF.
• Packaged in bags of 100.
• Manufactured for AGI in an ISO 9002 facility.
CT Series ISO 9002
MR Series
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
7/17/12
1.30
Features:
• Heavy pattern, contractor grade cast bronze or stainless steel material.
• Rope adapters have integral pad eye for easy use with submersible rope.
SEE PAGE 12.4c and 12.4d for a complete line of imported NO LEAD cast bronze insert fittings.
Part Number Size Style # Barbs Ctn/CaseQty List Price
No Lead Cast Bronze Male Insert Adapters (INS x MIP)
NLRBMA1/2 1/2” x 1/2” Hex 5 10/200 $ 10.42
NLRBMA3/4 3/4” x 3/4” Hex 5 10/200 13.24
NLRBMA1 1” x 1” Hex 7 10/100 23.80
NLRBMA1X3/4 1” x 3/4” Hex 5 10/100 15.90
NLRBMA1X11/4 1” x 11/4” Hex 6 10/100 27.20
NLRBMA11/4 1 1/4” x 1 1/4” Hex 6 10/100 27.26
NLRBMA11/4X1 1 1/4” x 1” Hex 7 10/100 28.00
NLRBMA11/2 1 1/2” x 1 1/2” Hex 6 5/50 32.74
NLRBMA11/2X11/4 11/2” x 1 1/4” Hex 6 10/100 25.06
NLRBMA2 2” x 2” Hex 7 5/50 59.76
No Lead Cast Bronze Extra Long Male Adapters (INS x MIP)
NLXLRBMA1 1” x 1” Hex 12 10/100 28.59
NLXLRBMA1x11/4 1” x 1 1/4” Hex 12 10/100 32.35
NLXLRBMA11/4 1 1/4” x 1 1/4” Hex 12 10/100 39.00
NLXLRBMA2 2” x 2” Hex 12 5/50 66.65
No Lead Cast Bronze Male Union Adapters (INS x MIP) - Available March 2012
NLRBMUA1 1” x 1” Hex 6 10/80 34.17
NLRBMUA11/4 1 1/4” x 1 1/4” Hex 6 10/40 50.02
No Lead Cast Bronze Rope Adapter (INS x MIP)
NLRBRA1 1” x 1” Round w/ rope eye 7 10/100 25.43
NLRBRA1X11/4 1” x 1 1/4” Round w/ rope eye 6 10/100 31.01
NLRBRA11/4 1 1/4” x 1 1/4” Round w/ rope eye 6 10/100 32.45
No Lead Cast Bronze Female Adapters (INS x FIP)
NLRBFA1/2 1/2” x 1/2” Round 5 10/200 14.22
NLRBFA3/4 3/4” x 3/4” Round 5 10/100 15.26
NLRBFA1 1” x 1” Round 5 10/100 25.19
NLRBFA11/4 1 1/4” x 1 1/4” Round 7 10/100 30.08
NLRBFA11/2 1 1/2” x 1 1/2” Round 6 5/50 35.20
NLRBFA2 2” x 2” Round 7 5/50 57.27
Cast Stainless Steel Male Insert Adapters (MIP xINS) Grade 304 *
SSMA1/2 1/2" Hex 6 10/100 8.18
SSMA3/4 3/4" Hex 6 10/200 12.21
SSMA1 1” Hex 6 10/100 17.11
SSMA11/4 1 1/4” Hex 6 5/100 21.25
SSMA11/4X1 1 1/4” x 1” Hex 6 10/100 18.82
XLSSMA11/4X1 1 1/4” x 1” Hex (Heavy pattern xlong) 13 5/60 25.54
SSMA11/2 1 1/2" Hex 6 5/80 29.94
SSMA2 2" Hex 6 5/40 41.64
NLRBMA
NLXLRBMA
NLRBFA
NLRBRA
NLRBMUA
SSMA
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Pump Installation Adapters & Fittings - NO LEAD
1/15/12
1.32a
Part Number Size Style # Barbs Ctn/CaseQty List Price
Cast Stainless Steel Male Insert Adapters (MIPxINS) Made in USA Grade 316 *
SS12-1/2 1/2” Round 6 25/300 21.17
SS12-3/4 3/4” Round 7 25/200 19.49
SS12-1 1” Round 7 20/160 22.08
SS12-11/4 1 1/4” Round 6 20/120 36.20
SS12-11/2 1 1/2” Round 6 10/60 49.01
SS12-2 2” Round 7 10/40 64.41
SS38-11/4 X1 1 1/4” x 1” Round 7 25 52.13
Cast Stainless Steel Hex Bushing (MIPxFIP) Grade 304 *
SSHB1X1/4 1” x 1/4” Hex - 10/200 8.62
SSHB1X1/2 1” x 1/2” Hex - 10/200 8.62
SSHB1X3/4 1” x 3/4" Hex - 10/200 8.62
SSHB11/4x1 1 1/4" x 1" Hex - 10/160 15.38
Steel Well Seal Elbows (INS x INS) **
S99-1 1” 10 26.66
S99-11/4 1 1/4” 10 36.03
Steel Well Seal Elbows (INS x INS) *
ISWSE100 1” 25 13.11
ISWSE125 1 1/4” 15 21.54
Brass Well Seal Elbow, ins x ins**
B99-1 1” 5 96.50
B99-11/4 1-1/4” 5 181.67
Steel Venturi Adapter, mipt x ins **
S86-3/4X6 3/4" x 6” 25 18.05
S86-3/4X10 3/4" x 10" 25 21.49
S86-3/4X12 3/4 x 12” 25 21.76
S86-1X6 1" x 6" 25 13.71
S86-1X8 1" x 8" 25 16.56
S86-1x10 1" x 10" 25 18.60
S86-1X12 1" x 12" 25 21.24
S86-11/4X6 1-1/4" x 6" 25 18.66
S86-11/4X8 1-1/4" x 8" 25 21.01
S86-11/4X10 1-1/4" x 10" 20 25.34
S86-11/4X12 1-1/4" x 12” 25 32.46
Steel Venturi Adapter, mipt x ins *
ISVMA1X6 1" x 6" 60 5.50
ISVMA1X8 1" x 8" 50 7.95
ISVMA1X10 1" x 10" 40 9.44
ISVMA11/4X6 1-1/4" x 6" 50 7.46
ISVMA11/4X8 1-1/4" x 8" 40 9.27
ISVMA11/4X10 1-1/4" x 10" 30 12.52
Red Brass Venturi Adapter, ins x mipt **
B86-1X6 1" x 6" 25/100 44.84
B86-1X8 1" x 8" 25/100 59.07
B86-11/4X6 1-1/4" x 6" 25/100 66.40
B86-11/4X8 1-1/4" x 8" 25/100 87.43
SS12
S86, ISVMA, B86
S99, ISWSE, B99
SSHB
*
**
Pump Installation Adapters & Fittings - NO LEAD
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
10/23/12
1.32b
Liquid Level Controls
Liquid Level Control Features:
• Provides automatic low level cutoff protection for submersible pumps & deep well turbines.
• Liquid level submersible pump control system consists of a standard enclosed type
induction relay which operates from two insulated electrodes suspended at desired levels.
• Permits efficient operation at full capacity and eliminates danger of pumping air or sand.
• Wiring diagrams and complete installation instruction are included with each control.
1500G SERIES INDUCTION RELAY:
• Two way control system for pump up or pump down.
• Rated at 1 hp single phase, 115 or 230 volts A.C.
• For use in controlling hydropneumatic tanks and motorized valve installations.
1500C and 1500D SERIES INDUCTIONRELAY:
• Rated at 1 h.p. single phase, 110 or 220 volts and furnished in a NEMA 1 metal enclosure.
• For control of a larger motor, it can also be supplied in a common enclosure with an
auxiliary relay without overload protection or with a magnetic starter that has overload
protection.
• 1500C Series for sewage & sump pump, low level cutoff for submersible pump application.
• 1500D Series for supply pumps on elevated tanks &towers, high level cutoff for pumps &
valves.
6013 SERIES ELECTRODES:
• Made of brass or 303 stainless steel.
• 2” long.
• Assembled in molded plastic insulating shield 9/16” in diameter.
• Use in submersible pump installations by suspending to desired length w/ suspension wire.
NEW Part OLD Part
Number Number Description Volts Ctn Qty List Price
1500G-L1-S7-N1X DH110-220 Pump-up/Pump-down 110/220 volts 1 $ 631.24
1500G-L1-S8-N1X DH110-360 Pump-up/Pump-down 110/360 volts 1 631.24
1500G-L2-S7-N1X DH220-220 Pump-up/Pump-down 220/220 volts 1 631.24
1500G-L2-S8-N1X DH220-360 Pump-up/Pump-down 220/360 volts 1 631.24
1500G-L3-S8-N1X DH440-360 Pump-up/Pump-down 440/360 volts 1 631.24
1500G-L4-S11-N1 DH550-600 Pump-up/Pump-down 550/600 volts 1 631.24
1500C-L1-S4-N1X LH110-110 Pump-down 110/120 volts 1 560.28
1500C-L1-S7-N1X LH110-220 Pump-down 110/220 volts 1 560.28
1500C-L1-S8-N1X LH110-360 Pump-down 110/360 volts 1 560.28
1500C-L2-S7-N1X LH220-220 Pump-down 220/220 volts 1 560.28
1500C-L2-S8-N1X LH230-360 Pump-down 230/360 volts 1 560.28
1500C-L2-S9-N1X LH220-480 Pump-down 220/480 volts 1 560.28
1500C-L3-S8-N1X LH440-360 Pump-down 440/360 volts 1 560.28
1500D-L1-S7-N1X RH110-220 Pump-up 110/220 volts 1 560.28
1500D-L1-S8-N1X RH110-360 Pump-up 110/360 volts 1 560.28
1500D-L2-S7-N1X RH220-220 Pump-up 220/220 volts 1 560.28
1500D-L2-S9-N1X RH220-480 Pump-up 220/480 volts 1 560.28
1500D-L2-S8-N1X RH230-360 Pump-up 230/360 volts 1 560.28
1500D-L3-S8-N1X RH440-360 Pump-up 440/360 volts 1 560.28
Electrodes
6013-W6 E1S Stainless Steel * 1 76.58
6013-W5 E1SB Brass 1 65.65
Liquid Level Control
Electrode
*
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.45
Liquid Level Controls
Induction Relay Coil Selection Data
Primary Coil:
The primary coil voltage should be chosen to match the line volt-
age of the control system. The 1500 Series Induction Relay can
be supplied with any of the following line voltages.
Line Frequency Max Amps
Voltage (Hertz) (Secondary Shorted)
110-120 50-60 .075
208-240 50-60 .038
440-480 50-60 .019
Secondary Coil:
Since B/W level control systems use liquid as an electrical con-
ductor to complete the relay’s secondary circuit - and since the
resistance of liquid varies, it is necessary that each induction
relay be equipped with a secondary coil that will operate over the
resistance of the liquid it controls. The table below lists the oper-
ating characteristics of various coils available. All values are
based on line voltage of 115, 230, 460 volts at 60 hertz.
Liquid Secondary
Description Coil
Acetic Acid - up to 75% 90 volt
- 75 - 90% 220 volt
Acids - General 40 or 90 volt
Alkalies - General 40 or 90 volt
Alum Solutions 220 volt
Aluminum Sulphate 90 volt
Aluminum Hydroxide 90 volt
Amino Acids 90 volt
Ammonium Chloride 40 volt
Ammonium Hydroxide (Ammonia) 220 volt
Ammonium Sulphate 220 volt
Baby foods 90 volt
Barium Chloride 40 volt
Barium Nitrate 40 volt
Beer 90 volt
Black liquor 40 volt
Blood 220 volt
Borax - up to 10% 220 volt
- Greater than 10% 90 volt
Bread dough 90 volt
Buttermilk 24 or 40 volt
Cadmium Chloride 40 volt
Cake batter 220 volt
Calcium Chloride 40 volt
Calcium Hydroxide 220 volt
Liquid Secondary
Description Coil
Carbolic Acid - up to 90% 220 volt
Catsup 90 volt
Caustic Soda (Sodium Hydroxide) 40 volt
Cement slurry 220 volt
Chromic acid 40 volt
Citric acid 40 or 90 volt
Coffee 90 volt
Condensate - ordinary water 480 volt
Corn syrup 480 volt
Corn - cream style 90 volt
Ferrous Sulphate 220 volt
Formic acid - up to 75% 90 volt
- 75 to 90% 220 volt
Hydrofluoric acid - up to 20% 220 volt
- above 20% 40 volt
Hydrofluorsilicic acid 90 volt
Jams & jellies 360 volt
Juices - fruit & vegetable 40 or 90 volt
Lithium Chloride 40 volt
Magnesium Hydroxide 90 volt
Mayonnaise 220 volt
Milk 40 volt
Molasses 220 volt
Muriatic acid 40 volt
Mustard 40 volt
Liquid Secondary
Description Coil
Nitric acid 40 or 90 volt
Orange juice 90 volt
Paper stock 220 volt
Penicillin 220 volt
Phosphoric acid 40 volt
Plating solutions 40 or 90 volt
Salts - chemical 40 or 90 volt
Sodium Carbonate (soda ash) 90 volt
Sodium Chloride (table salt) 40 volt
Sodium Hydroxide (caustic soda) 40 volt
Sodium Hypochlorate 40 volt
Sodium Silicate (water glass) 90 volt
Soups 40 volt
Starch solutions 220 volt
Sugar - low concentrations 220 volt
- high concentrations 360 volt
Vinegar 90 volt
Water - Sea 40 volt
- Ordinary potable 220 volt
- ordinary soft 360 volt
- Ordinary condensate 480 volt
Zinc Chloride 40 volt
Typical Liquids:
The following recommendations are satisfactory for general use, but because the conductivity of liquids varies greatly
with concentration, purity, temperature and other factors, some applications may require a different selection.
A number of the products listed are produced as solids such as crystals or powders, and the relay selection is based
on the normally used commercial solutions of these materials.
NOTE: Maximum distance limitations for typical induc-
tion relay secondary circuits are: 220 secondary - 900
feet, 360 secondary - 350 ft, 480 secondary - 250 ft.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
4/2009
1.46
Part Drop Pipe Nominal Well Casing Hole Max Load
Number Size Casing Opening Capacity (lbs.) Ctn Qty List Price
NO LEAD Cast Bronze
PT300NL 1” 5” through 8” 1 3/4” 800 10 $ 97.32
PT800NL * 1” 5” through 8” 1 3/4” 900 10 113.39
PT825NL * 1-1/4” 5” through 8” 2 1/4” 2,000 10 135.38
PT3000NL 2” 5 5/8” through 12” 3 1/8” 5,000 4 603.21
PT900NL 1” & 11/4” (2 Hole) 5” through 8” 1 3/4” & 2 1/4” 2,000 6 510.72
TAPPED NO LEAD Cast Bronze for Underground tanks
PT800TNL * 1” 5” through 8” 1 3/4” 900 10 120.18
Cast 304 STAINLESS STEEL
PT800SS 1” 5” through 8” 1 3/4” 6,000 10 119.07
PT825SS 1-1/4” 5” through 8” 2 1/4” 6,000 10 180.38
PT3000SS 2” 5 5/8” through 12” 3 1/8” 6,000 4 531.97
1/15/13
1.54a
Pitless Adapters - NO LEAD Bronze, Stainless Steel
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pitless Adapter Features:
• Cast from 81% COPPER content alloy NO LEAD bronze or 304
cast stainless steel to insure long life and durability in the most
aggressive well conditions.
• Extended casing nipple makes installation easy.
• Rubber inner and outer casing gaskets for certified & approved
water tight seal from ground water contamination.
• Built-in lowering eyelet for easier installation.
• All PT Series pitless adapters are individually boxed.
• All PT Series adapters are certified and approved
watertight to PAS-97(2012) standards.
•NO LEAD brass is CA AB1953 certified.
• 304 Stainless Steel is Lead Free.
PT825NL
PT825SS
PT3000SS
PT800NL
PT800SS
PT300NL
*
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
4/2009
1.54b
Well Caps - Cast Iron, Plastic
Nominal Well Maximum Conduit Master
Part Number Material Casing Casing OD Tap Ctn Qty List Price
WC6 Cast Iron 6” and 6 1/4” 6 5/8” 1” 6 $ 70.89
WC6-11/4 Cast Iron 6” and 6 1/4” 6 5/8” 1 1/4” 6 86.79
WC625 Cast Iron 6 1/4” SDR27.6 PVC 6.9” 1” 6 70.89
WC625-11/4 Cast Iron 6 1/4” SDR27.6 PVC 6.9” 1 1/4” 6 83.39
WTC6 ABS Plastic 6” and 6 1/4” 6 5/8” 1 1/4” 1 64.96
PWTC6 Thermoplastic 6” and 6 1/4” 6 5/8” 1” 8 43.59
PSC5 Thermoplastic 5” 5 9/16” 1” 12 38.45
PSC614 Thermoplastic 6 1/4” SDR27.6 PVC 6.9” 1” 12 35.54
C56V Cast Iron 5-5/8” , 6”, 6 1/4” 6 5/8” 1” 6 30.00
HARVARD WC SERIES Cast Iron Watertight Well Cap
Features:
• WC6 fits 6”and 6-1/4” I.D. 6 5/8” OD well casing.
• WC625 fits SDR27.6 6 1/4” ID PVC well casing, with 6.9” OD.
• 1”or 1 1/4” IPS conduit tap and factory installed screen vents.
• Heavy cast iron body. 20% heavier than any other comparable
watertight well caps available.
• Wide rubber gasket provides positive watertight seal.
• Blue powder coat paint finish.
• Individually packaged. Includes all hardware.
• All WC Series well caps are certified and approved watertight
to PAS-97 (04) standards.
WTC6 Plastic Watertight Well Cap Features:
• Fits 6” ID, 6 1/4” ID, 6 5/8” OD well casing
• 1 1/4” IPS conduit tap.
• Hi-impact blue ABS plastic with UV inhibitors.
• Especially formulated for outdoor weatherability.
• Stainless steel bolts, washers and nuts are included.
• Factory installed screen vents.
• Made in USA. Patented
HARVARD Plastic Watertight Well Cap Features:
• PWTC6 Fits 6” and 6 1/4” ID, 6 5/8” OD well casing.
• PSC614 fits SDR27.6 6 1/4” ID PVC well casing with 6.9” OD.
• Gray, glass-filled thermoplastic with UV stabilizers.
• White ABS bottom casing seal for PSC Series.
• Especially formulated for outdoor weatherability.
• Stainless steel bolts, nuts included.
• Factory installed stainless steel vents. 1” conduit tap.
• Made in USA.
HARVARD C56V Cast Iron Multi-Size Well Cap Features :
• Heavy cast iron construction. 30% heavier than any other
comparable cap available.
• Quick installation.
• Fits 5-5/8” and 6” well casing, Maximum 6 5/8” OD.
• 1” conduit opening.
• Blue finish for easy site location.
• Individually packaged. Includes bolts.
WC Series
C56V
WTC6
Custom personalization of the caps above is available. Self adhering, engraved brushed aluminum.
Minimum of 24 of one size. One time set-up charge of $10.00. Allow 2-3 weeks for delivery.
PWTC6 PSC Series
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.57
Well Caps - Cast Aluminum
Nominal Well Casing Conduit Vent Ctn List
Part Number Casing Size O.D. Conn. Size Weight Qty Price
Aluminum Watertight Vermin–Proof Well Cap
AWTC4 4” 4 1/2” 1” 1” 2.2 25 $ 89.36
AWTC45 ☺4 1/2” 5” 1” 1” 2.7 20 121.39
AWTC5 5” 5 9/16” 1” 1” 2.4 20 107.90
AWTC55 ☺5 1/2” 6” 1” 1” 3.1 15 133.44
AWTC6 6” 6 5/8” 1 1/4” 1” 2.8 15 113.15
AWTC7 ☺6 1/2” 7” 1 1/4” 1” 3.1 13 157.29
AWTC8 8” 8 5/8” 1 1/4” 1” 4.3 1 234.85
AWTC10 10” 10 3/4” 2” 1” (2) 9.0 1 748.85
AWTC12 12” 12 3/4” 2” 1” (2) 11.0 1 1405.10
☺ Fits Whitewater pitless units
Aluminum Watertight Vermin–Proof Well Cap w/ 1-1/4” Top Tap for use w/ pellet chlorinators
AWTC45T ☺4 1/2” 5” 1” 1” 2.7 20 141.46
AWTC55T ☺5 1/2” 6” 1” 1” 3.1 15 153.40
AWTC6T 6” 6 5/8” 1 1/4” 1” 2.8 15 133.29
AWTC8T 8” 8 5/8” 1 1/4” 1” 4.3 1 256.28
☺ Fits Whitewater pitless units
Aluminum/ABS Combination Watertight Well Cap
SC4 4” 4 1/2” 1 “ 1.5 12 47.49
SC45 4 1/2” 4.95” 1 “ 1.7 15 56.63
SC5 5” 5 9/16” 1 “ 2.3 10 64.50
SC6 6” 6 5/8” 1” 2.5 8 69.18
SC614 6 1/4”(SDR27.6) 6.9” 1” 2.5 12 66.03
Standard Ventilated Cap with Conduit Opening
C4 4” 4 1/2” 3/4” 1.6 25 44.68
C5 5” 5 9/16” 3/4” 2.0 15 64.07
C6 6” 6 5/8” 3/4” 2.3 15 68.68
C7 7” 7 5/8” 1” 2.9 15 101.15
C8 8” 8 5/8” 1” 3.4 1 107.57
AWTC-Series Watertight Vermin- Proof Cap Features:
• Cast aluminim for strength and weather resistance.
• All stainless bolts and ground screws.
• Molded 3/16” gasket.
SC-Series Watertight Cap Features:
• For use on plastic casing only.
• Injection molded ABS & grade 319 aluminum, can be solvent
welded directly to PVC well casing.
• Stainless steel nuts, bolts & screened vents.
• All SC Series well caps are certified and approved watertight
to PAS-97 Standards.
C-Series Standard Conduit Cap Features:
• For use on steel or plastic casing.
• Stainless steel set screws.
AWTC--T SeriesAWTC Series
SC Series C Series
Custom personalization available - minimum of 48 of one size. Add “P”
suffix. fo part number. One time set-up charge of $20.00. Allow 2-3
weeks for delivery.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
4/17/12
1.58
ABS Well Seals
PSWS and PJWS Series Features:
• Well seals are molded from high impact ABS for extra strength.
• Exclusive design of extra thick (1-1/4”) PVC gland enables the
sanitary sealing of a wide range of casing sizes.
• Zinc plated steel bolts.
Fits Well Well Casing ID Drop Conduit Vent Ctn List
Part Number Casing ID Size Range Pipe Size Tap IPS Tap IPS Weight Qty Price
Single Hole
PSWS2x1 2” 2” 1” –– –– .25 lbs 50 $ 18.02
PSWS4xBLANK 4” 4 - 4 1/4” blank 3/4” 3/8” 1.5 lbs. 10 27.21
PSWS4x1 4” 4 - 4 1/4” 1” 3/4” 1/2” 1.5 lbs. 10 27.21
PSWS4x11/4 4” 4 - 4 1/4” 1 1/4” 3/4” 1/2” 1.5 lbs. 10 27.21
PSWS4x11/2 4” 4 - 4 1/4” 1 1/2” 3/4” 1/2” 1.5 lbs. 10 27.21
PSWS4x2 4” 4 - 4 1/4” 2” 3/8” 1/4” 1.5 lbs. 10 27.21
PSWS41/2x1 4 1/2” 4 3/8 - 4 7/8” 1” 3/4” 1/2” 1.75 lbs. 10 30.24
PSWS41/2x11/4 4 1/2” 4 3/8- 4 7/8” 1 1/4” 3/4” 1/2” 1.75 lbs. 10 30.24
PSWS5xBLANK 5” 4 7/8 - 5 1/4” blank 3/4” 1/2” 2.0 lbs. 10 41.18
PSWS5x1 5” 4 7/8 - 5 1/4” 1” 3/4” 1/2” 2.0 lbs. 10 41.18
PSWS5x11/4 5” 4 7/8 - 5 1/4” 1 1/4” 3/4” 1/2” 2.0 lbs. 10 41.18
PSWS5x11/2 5” 4 7/8 - 5 1/4” 1 1/2” 3/4” 1/2” 2.0 lbs. 10 41.18
PSWS5x2 5” 4 7/8 - 5 1/4” 2 3/4” 1/2” 2.0 lbs. 10 41.18
PSWS51/2xBLANK 5 1/2” 5 3/8 - 5 7/8” blank 3/4” 1/2” 2.25 lbs. 10 43.10
PSWS51/2x1 5 1/2” 5 3/8 - 5 7/8” 1” 3/4” 1/2” 2.25 lbs. 10 43.10
PSWS51/2x11/4 5 1/2” 5 3/8 - 5 7/8” 1 1/4” 3/4” 1/2” 2.25 lbs. 10 43.10
PSWS51/2x11/2 5 1/2” 5 3/8 - 5 7/8” 1 1/2” 3/4” 1/2” 2.25 lbs. 10 43.10
PSWS6xBLANK 6” 5 7/8 - 6 1/4” blank 3/4” 1/2” 3.0 lbs. 10 40.10
PSWS6x1 6” 5 7/8 - 6 1/4” 1” 3/4” 1/2” 3.0 lbs. 10 40.10
PSWS6x11/4 6” 5 7/8 - 6 1/4” 1 1/4” 3/4” 1/2” 3.0 lbs. 10 40.10
PSWS6x11/2 6” 5 7/8 - 6 1/4” 1 1/2” 3/4” 1/2” 3.0 lbs. 10 40.10
PSWS6x2 6” 5 7/8 - 6 1/4” 2” 3/4” 1/2” 3.0 lbs. 10 40.10
PSWS61/4xBLANK 6 1/4” 6 1/4 - 6 1/2” blank 3/4” 1/2” 3.25 lbs. 10 41.18
PSWS61/4x1 6 1/4” 6 1/4 - 6 1/2” 1” 3/4” 1/2” 3.25 lbs. 10 41.18
PSWS61/4x11/4 6 1/4” 6 1/4 - 6 1/2” 1 1/4” 3/4” 1/2” 3.25 lbs. 10 41.18
PSWS61/4x11/2 6 1/4” 6 1/4 - 6 1/2” 1 1/2” 3/4” 1/2” 3.25 lbs. 10 41.18
PSWS61/4x2 6 1/4” 6 1/4 - 6 1/2” 2” 3/4” 1/2” 3.25 lbs. 10 41.18
PSWS8x1 8” 8 - 8 1/4” 1” 1” 1/2” 5.0 lbs. 6 52.68
PSWS8x11/4 8” 8 - 8 1/4” 1 1/4” 1” 1/2” 5.0 lbs. 6 52.68
PSWS8x2 8” 8 - 8 1/4” 2” 1” 1/2” 5.0 lbs. 6 52.68
Double Hole
PJWS4x1x11/4 4” 4 - 4 1/4” 1x1 1/4” n/a 1/2” 1.5 lbs. 10 27.21
PJWS5x1x11/4 5” 4 7/8 - 5 1/4” 1x1 1/4” n/a 1/2” 2.0 lbs. 10 39.91
PJWS51/2x1x11/4 5 5/8” 5 3/8 - 5 7/8” 1x1 1/4” n/a 1/2” 2.5 lbs 10 40.93
PJWS6x1x11/4 6” 5 7/8 - 6 1/4” 1x1 1/4” n/a 1/2” 3.0 lbs. 10 42.27
PJWS61/4x1x11/4 6 1/4” 6 1/4 - 6 3/8” 1x1 1/4” n/a 1/2” 3.25 lbs. 10 41.18
PSWS
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
4/17/12
1.59
Cast Iron Well Seals - Import, Submersible & Jet
Part Well Drop Cable Hole Vent
Number Casing ID Pipe Tapping Tapping Ctn Qty List Price
Single Drop Pipe, SPLIT TOP, for submersible pumps (* Fits outside of well casing)
SWS2X1 2” 1” - 1/8” 50 $ 20.03
SWS2X11/4 * 2” 1 1/4” - 1/8” 12 27.49
SWS3X1 3” 1” 3/8” 1/8” 16 21.65
SWS3X11/4 3” 1 1/4” (2) 5/16” drilled 1/8” 16 21.65
SWS4X1 4” 1” 3/4” 1/2” 12 26.61
SWS4X11/4 4” 1 1/4” 3/4” 1/2” 12 26.61
SWS4X11/4S 4” 1 1/4” center 3/4” 1/4” 12 26.61
SWS4X11/2 4” 1 1/2” 3/4” 1/4” 12 26.61
SWS4X2 4” 2” 1/2” 1/4” 12 26.61
SWS4X2 SOLID 4” 2” 3/4” 1/2” 12 26.61
SWS41/4X1 4 1/4” 1” 3/4” 1/2” 12 26.61
SWS41/4X11/4 4 1/4” 1 1/4” 3/4” 1/2” 12 26.61
SWS5X1 5” 1” 1” 1/2” 6 39.86
SWS5X11/4 5” 1 1/4” 1” 1/2” 6 39.86
SWS5X2 5” 2” 3/4” 1/2” 6 39.86
SWS55/8X1 5 5/8” 1” 3/4” 1/2” 6 49.59
SWS6X1 6” 1” 1” 1/2” 6 50.54
SWS6X11/4 6” 1 1/4” 1” 1/2” 6 50.54
SWS6X11/2 6” 1 1/2” 1” 1/2” 6 50.54
SWS6X2 6” 2” 1” 1/2” 6 50.54
SWS6X3 SOLID 6” 3” 1” 1/2” 6 50.54
SWS6BLANK 6” - - - 6 53.24
SWS61/4X1 6 1/4” 1” 1” 1/2” 6 53.24
SWS61/4X11/4 6 1/4” 1 1/4” 1” 1/2” 6 53.24
Two Hole Drop Pipe, SPLIT TOP, for jet pumps
JWS3X1X3/4 3” 1” X 3/4” 1/8” 16 17.73
JWS4x11/4x1 4” 1 1/4” x 1” 1/2” 12 26.61
JWS5X11/4X1 5” 1 1/4” X 1” 1/2” 6 39.86
JWS55/8X11/4X1 5 5/8” 1 1/4” X 1” 1/2” 6 49.59
JWS6x11/4x1 6” 1 1/4” x 1” 1/2” 6 50.54
JWS61/4x11/4x1 6 1/4” 1 1/4” x 1” 1/2” 6 53.24
Cast Iron Well Seal for Submersible & Jet Pumps Features:
• Highest quality smooth grey-iron castings accurately machined
to narrowest tolerances.
• Finest heavy duty 3/4” molded rubber packing gland
assures seal regardless of minor imperfections in well casing.
• Corrosion resistant, zinc plated steel bolts, rugged
construction provides for maximum torque.
• Long lasting painted finish.
• Complete with electrical conduit kit and plug for SWS and
plastic plugs for JWS series.
• Individually cartoned.
• Imported.
SWS Series JWS Series
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.60
Drive Shoes
Drive Shoe Features:
• Alloy grade seamless stock.
• Special process to strengthen the material before heat treating.
• All drive shoes are heat treated.
• All drive tips are flame hardened for superior driving strength.
• All drive shoes are tested for dimensional accuracy and tip hardness.
• Baked on phosphate coating to protect from corrosion.
• Cable and Rotary style.
• Weld-on and threaded.
Part Nominal
Number Pipe Size Description Ctn Qty List Price
421 Series Threaded Cable Tool Style
7000A 2” 421 Open Pattern 25 $ 35.11
7000D 2” 421 Closed Pattern, extended threads (P&R) 28 28.89i
7000E 3” 421 Open Pattern 12 60.72
7000G 4” 421 Open Pattern 8 58.83
7000GL 4” 421 Open Pattern, THIN WALL 8 48.57i
7000J 5” 421 Open Pattern 4 82.86
7000K 6” 421 Open Pattern 4 123.81
7000N 6” 421 Short Pattern 4 110.00i
7059X 8” 421 Open Pattern 1 167.41i
421W Series Weld-On Cable Tool Style
7055E 3” 421W Open Pattern 12 52.43
7055G 4” 421W Open Pattern 8 48.57i
7055GL 4” 421W Open Pattern, THIN WALL 8 48.57i
7055J 5” 421W Open Pattern 4 114.58
7055K 6” 421W Open Pattern 4 123.81i
7055R 6” 421W Short Pattern 4 122.20
7055M 8” 421W Open Pattern 1 380.72
7055N 10” 421W Open Pattern 1 952.70
421R Series Threaded Rotary Style
7005A 4” 421R Open Pattern 8 75.97
7005B 5” 421R Open Pattern 4 84.19
7005C 6” 421R Open Pattern 4 112.25
7005H 6” 421R Short Pattern 4 112.25
421 RW Series Weld-on Rotary Style
7007A 4” 421RW Open Pattern 8 55.51
7007C 6” 421RW Open Pattern 4 123.81
Drive Shoes
7000 Series
7055 Series
7005 Series
7007 Series
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM 1/15/13
1.69
Drive Shoes
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
4/2009
1.70
Pitcher Pump
Part
Number Description List Price
118P1 Complete Plunger Assembly (includes *) 36.98
118P2 * Cup Leather for Plunger only 13.89
118P3 Plunger Rod and Cage (no cup leather) 14.26
118P4 * Plunger Rod 7.34
118P5 * Plunger Cage 9.15
118P6 * Plunger Weight 5.03
118P7 Flat Leather for Base Valve 10.02
118P8 Weight and Screw for Flat Valve 6.54
118P9 Flat Valve Leather and Weight 15.99
118P10 * Threaded Nut for Plunger Cage 10.60
118P11 Pump Base with Bolts (118P15) 34.10
118P12 Pump Cylinder 38.79
118P13 Pump Top with Set Screw (118P17) 17.48
118P14 Pump Handle with Two Bolts (118P16) 29.34
118P15 3/8 x1-1/4 Bolts for Pump Base 12.62
118P16 3/8 x 2 bolts for Pump Handle 4.46
118P17 Set Screw for Pump Top 3.81
PITCHER PUMP REPLACEMENT PARTS
Pitcher Pump Features:
• Recommended for shallow pump applications – depth rating up to 30'.
• Easily installed.
• Made of heavy cast iron.
• Dark green hard enamel paint finish.
• Has open spout.
• 15-3/4” high.
• Tapped for 1-1/4” drop pipe.
• 15 lbs.
• Pumps are individually packaged 4 per master carton.
• Parts are carton qty 1.
HPP10
Master
Part Number Description Ctn Qty List Price
HPP10 Pitcher Pump, Cast Iron, Size #2 4 $ 118.75
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.71
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
4/2009
1.72
Cylinders - All Brass
449B ALL BRASS Features:
• Corrosion resistant, all brass construction.
• Brass tubing offers a smooth working surface and extends the life of the leathers.
• Open top cylinder, threaded valves screw together for one-step removal.
• No need to pull cylinder to replace inner components.
• Reliable BALL plunger.
• Contains 707/45 series graphite leathers.
449B All Brass Smallest
Inside Caps Tapped Size Rod Well Capacity Cup Leather
Diameter Barrel Pipe Size in Cylinder Per Stroke Sizing
Part X Stroke Length Top/Bottom Plunger will enter US O.D. Hole List Price
Number (inches) (inches) (inches) (inches) (inches) Gallons (inches) (inches)
7037H 1-7/8 x 14 24 2 x 1-1/4 5/8 3 .1680 1-7/8 1-5/16 $ 554.35
7037HNL 1-7/8 x 14 24 2 x 1-1/4 5/8 3 .1680 1-7/8 1-5/16 831.25
7037R 1-7/8 x 20 30 2 x 1-1/4 5/8 3 .2400 1-7/8 1-5/16 571.82
7037W 1-7/8 x 26 36 2 x 1-1/4 5/8 3 .3120 1-7/8 1-5/16 589.29
7037BA 2-1/4 x 13 24 2-1/2 x 1-1/2 7/8 3-1/2 .2237 2-1/4 1-1/2 598.61
7037GA 2-1/4 x 19 30 2-1/2 x 1-1/2 7/8 3-1/2 .3270 2-1/4 1-1/2 848.81
7037LA 2-1/4 x 25 36 2-1/2 x 1-1/2 7/8 3-1/2 .4303 2-1/4 1-1/2 965.11
7037UA 2-3/4 x 12 24 3 x 2 7/8 4-1/2 .3085 2-3/4 1-7/8 366.70i
7037ZA 2-3/4 x 18 30 3 x 2 7/8 4-1/2 .4628 2-3/4 1-7/8 903.68
7037EB 2-3/4 x 24 36 3 x 2 7/8 4-1/2 .6171 2-3/4 1-7/8 1274.91
449B Replacement Parts
1-7/8” 2-1/4” 2-3/4”
Part Number Part Number Part Number
Plunger assembly w/ leathers 8599A 8599C 8599E
Check assembly w/ leathers 8533C 8533D1 8533E1
Leather for Plunger (707/45) Qty 3 707-221 707-334 707-384
17/8”x1 5/16” 21/4x11/2 23/4x17/8
Leather for Check (702/41) Qty 1 702-216 702-334 702-384
17/8”x1 5/16” 21/4x11/2 23/4x17/8
Barrel Only (less caps) 24” 8334N 8334ZA 8334XC
Barrel Only (less caps) 30” 8334P 8334AB 8334YC
Barrel Only (less caps) 36” 8334R 8334BB 8334ZC
Top Cap 8015C 8015D 8015E
Bottom Cap 8042C 8042D 8042E
Ball Selection Chart 449B Plunger and Checks
Part Number Plunger & Check Ball Size Cylinder I. D.
8546B 1-1/16” 1-7/8”
8546D 1-5/16” 2-1/4”
8546E 1-11/16” 2-3/4”
NOTE: PLEASE SEE PAGES 77-79 FOR
REPLACEMENT PART PRICING
449 B Replacement
Parts
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.73
Cylinders - All Brass
442 All Brass Inside Caps Tapped Size Well Smallest
Diameter Barrel Pipe Size Rod in Cylinder Capacity Cup Leather Sizing List
Part x Stroke Length Top/Bottom Plunger will enter Per Stroke O.D. Hole Price
Number (inches) (inches) (inches) (inches) (inches) US Gallons (inches) (inches)
7027A 1-11/16 x 8 16 1 x 1 7/16 2 .0768 1-11/16 1-3/16 $ 273.09
7027B 1-11/16 x 10 16 1 x 1 7/16 2 .0960 1-11/16 1-3/16 385.67
7027M 1-11/16 x 12 20 1 x 1 7/16 2 .1152 1-11/16 1-3/16 404.95
7027C 1-13/16 x 8 16 1 x 1 7/16 2 .0896 1-13/16 1-3/16 287.17
7027D 1-13/16 x 10 18 1 x 1 7/16 2 .1120 1-13/16 1-3/16 323.05
7027DNL 1-13/16 x 10 18 1 x 1 7/16 2 .1120 1-13/16 1-3/16 480.94
7027D3NL 1-13/16 x 12 20 1 x 1 7/16 2 .1344 1-13/16 1-3/16 461.44
7027E 2 x 8 16 11/4 x 11/4 7/16 2-1/2 .1088 2 1-5/16 306.11
7027F 2 x 10 18 11/4 x 11/4 7/16 2-1/2 .1360 2 1-5/16 432.09
7027FNL 2 x 10 18 11/4 x 11/4 7/16 2-1/2 .1360 2 1-5/16 550.93
7027F1 2 x 12 20 11/4 x 11/4 7/16 2-1/2 .1632 2 1-5/16 468.83
7027H 2-1/4 x 8 16 11/4 x 11/4 7/16 3 .1377 2-1/4 1-3/8 424.24
7027J 2-1/4 x 10 18 11/4 x 11/4 7/16 3 .1721 2-1/4 1-3/8 502.52
7027JNL 2-1/4 x 10 18 11/4 x 11/4 7/16 3 .1721 2-1/4 1-3/8 748.82
7027DANL 2-1/4 x 10 18 11/2 x 11/4 7/16 3 .1721 2-1/4 1-3/8 748.39
7027P2 2-1/4 x 12 20 11/4 x 11/4 7/16 3 .2071 2-1/4 1-3/8 362.72
7027P2NL 2-1/4 x 12 20 11/4 x 11/4 7/16 3 .2071 2-1/4 1-3/8 791.99
7027S3 2-1/2 x 8 18 11/4 x 11/4 7/16 3 .1700 2-1/2 1-5/8 382.04
7027L 2-1/2 x 10 20 11/4 x 11/4 7/16 3 .2125 2-1/2 1-5/8 637.35
7027LNL 2-1/2 x 10 20 11/4 x 11/4 7/16 3 .2125 2-1/2 1-5/8 907.69
7027T 2-1/2 x 10 20 11/2 x 11/4 7/16 3 .2125 2-1/2 1-5/8 600.41
7027T1 2-1/2 x 12 22 11/4 x 11/4 7/16 3 .2550 2-1/2 1-5/8 669.22
7027FA3NL 3 x 10 20 11/4 x 11/4 7/16 3-1/2 .3060 3 2-1/8 1128.61
7027UNL 3 x 10 20 2 x 11/4 7/16 3-1/2 .3060 3 2-1/8 1155.39
7027FA4 3 x 12 22 11/4 x 11/4 7/16 3-1/2 .3672 2 2-1/8 885.48
442 Replacement Parts 1-11/16” 1-13/16” 2” 2-1/4” 2-1/2” 3”
Description Part Number Part Number Part Number Part Number Part Number Part Number
Plunger Assembly w/ leather 8522A 8522B 8522CNL 8522D 8522F/8522FNL 8522J
Bottom Cap Check assembly 8853U 8853V 8853W 8853X 8853Z 8853DA
Plunger Poppet 8099B 8099B 8099C 8099D 8099E 8099G
Check Poppet w/Facing 8854A 8854BNL 8854C 8854D 8854D 8854G
Leather for Plunger (711/44) 711-151 711-198 711-264 711-333 711-358 711-638
2 each required 1-11/16x1-3/16 1-13/16x1-3/16 2x1-5/16 2-1/4x1-3/8 2-1/2x1-5/8 3x2-1/8
Top Caps (tapping) 1” 8248B 8248D –– –– –– ––
Top Caps (tapping) 1-1/4” –– –– 8248E 8248G 8248J 8248R
Top Caps (tapping) 1-1/2” –– –– –– 8248H 8248K ––
Top Caps (tapping) 2” –– –– –– –– –– 8248T
Barrel Only 16” 8333H 8333JA 8333DB 8333ZB –– ––
Barrel Only 18” 8333D 8333LA 8333FB 8333BC 8333NC
Barrel Only 20” 8333R 8333NA 8333HB 8333DC 8333PC 8333ND
Barrel Only 22” –– –– –– –– 8333RC 8333PD
442 ALL BRASS Features:
• All brass plunger, plain poppet and two leathers.
• Closed flush cap, recommended for all types of working heads and small
diameter, shallow wells.
• Perma-Kleen®, Buna N rubber check poppet facing for smooth, quiet operation and
tight seal.
• Clearance of two inches is provided between plunger and check.
• Contains 711/44 Series waterproof leathers.
• “NL” designates NO LEAD.
NOTE: PLEASE SEE PAGE 77-79 FOR REPLACEMENT PART PRICING.
442
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.74
Cup Leathers
702/41 Universal Features:
• Untreated economy leathers.
• Flesh side out.
• Used for open type hand pumps (pitcher pumps), jet packers and on
any application calling for a stationary seal.
• Made in USA.
ORDER IN TUBE QUANTITY ONLY
ABC
NEW Part OLD Part Finish Cylinder I.D. Hole Size Height Tube Qty List
Number Number Leather O.D. Leather I.D. Price
702/41 Universal
702-022 L101000006 702/41 1” 3/8” 7/16” 12 $ 5.61
702-048 L101020006 702/41 1-1/8” 3/8” 1/2” 12 6.20
702-061 L101040006 702/41 1-1/4” 3/8” 1/2” 12 6.20
702-063 L101040008 702/41 1-1/4” 1/2” 1/2” 12 6.20
702-095 L101060010 702/41 1 3/8” 5/8” 12 7.00
702-109 L101080006 702/41 1-1/2” 3/8” 5/8” 12 7.00
702-169 L101120010 702/41 1-3/4” 5/8” 11/16” 12 7.54
702-198 L101130103 702/41 1-13/16” 1-3/16” 3/4” 12 7.54
702-216 L101140105 * 702/41 1-7/8” 1-5/16” 3/4” 12 7.54
702-220 L101140104 ** 702/41 1-7/8” 1-1/4” 3/4” 12 7.54
702-263 L102000104 702/41 2” 1-1/4” 3/4” 12 8.95
702-264 L102000105 702/41 2” 1-5/16” 3/4” 12 8.95
702-333 L102040106 702/41 2-1/4” 1-3/8” 3/4” 12 9.81
702-334 L102040108 * 702/41 2 1/4” 1 1/2” 3/4” 12 9.81
702-358 L102080110 702/41 2-1/2” 1-5/8” 13/16” 12 10.93
702-384 L102120114 * 702/41 2-3/4” 1-7/8” 13/16” 12 11.90
702-410 L103000200 702/41 3” 2” 13/16” 12 13.30
702-464 L103080208 702/41 3-1/2” 2-1/2” 1” 12 16.76
702-521 L104000300 702/41 4” 3” 1-1/16” 6 24.62
702-636 L106000408 702/41 6” 4 1/2” 6 81.33
* Standard Clayton Mark hole size
** Standard Midland hole size
702/41
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.81
Cup Leathers
704/46 Oil Fill Features:
• Oak tanned leather and oil treated.
• Oil treatment waterproofs and retards swelling of leather inside cylinders.
• Reduces rod breakage or overloading motors.
• Oil treatment preserves leather insuring longer life.
• Flesh side out.
• Used in cylinders and piston pumps.
• Made in USA.
ORDER IN TUBE QUANTITY ONLY
ABC
NEW Part OLD Part Cylinder I.D. Hole Size Tube List
Number Number Finish Leather O.D. Leather I.D. Height Qty Price
704/46 Oil Fill
704-010 L600140002 704/46 7/8” 1/8” 12 $ 5.61
704-044 L601100000 704/46 1-1/8” - 1/2” 12 6.20
704-048 L601020006 704/46 1-1/8” 3/8” 1/2” 12 6.20
704-092 L601060006 704/46 1-3/8” 3/8” 5/8” 12 7.00
704-105 L601080000 704/46 1 1/2” SOLID 5/8” 12 7.00
704-109 L601080006 704/46 1-1/2” 3/8” 5/8” 12 7.00
704-198 L601130103 704/46 1-13/16” 1-3/16” 3/4” 12 7.54
704-220 L601140104 ** 704/46 1-7/8” 1-1/4” 3/4” 12 7.54
704-255 L602000010 704/46 2” 5/8” 3/4” 12 8.95
704-264 L602000105 704/46 2” 1-5/16” 3/4” 12 8.95
704-333 L602040106 704/46 2-1/4” 1-3/8” 3/4” 12 9.81
704-334 L602040108 * 704/46 2-1/4” 1-1/2” 12 9.81
704-354 L602080104 704/46 2-1/2” 1-1/4” 12 10.93
704-358 L602080110 704/46 2-1/2” 1-5/8” 13/16” 12 10.93
704-384 L602120114 * 704/46 2-3/4” 1-7/8” 13/16” 12 11.90
704-409 L603000105 704/46 3” 1-7/8” 12 13.25
704-410 L603000200 704/46 3” 2” 13/16” 12 13.25
704-464 L603080208 704/46 3-1/2” 2-1/2” 1” 12 16.76
704-521 L604000300 704/46 4” 3” 1-11/16” 6 24.62
* Standard Clayton Mark hole size
** Standard Midland hole size
704/46
Oil Fill
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.82
Cup Leathers
706/42 Black Perfection Features:
• Hard, high-polished black finish leather
• Hair side out.
• Used for deep well cylinders as well as developing & testing new wells.
• Made in USA.
ORDER IN TUBE QUANTITY ONLY
NEW Part OLD Part Cylinder I.D. Hole Size C Tube List
Number Number Finish Leather O.D. Leather I.D. Height Qty Price
706/42 Black Perfection
706-022 L201000006 706/42 1 3/8” 7/16” 12 $ 5.61
706-063 L201040008 706/42 1-1/4” 1/2” 1/2” 12 6.20
706-064 L201040010 706/42 1 1/4” 5/8” 1/2” 12 6.20
706-073 L201050002 706/42 1 5/16” 1/8” 12 6.20
706-095 L201060010 706/42 1-3/8” 5/8” 5/8” 12 7.00
706-105 L201080000 706/42 1-1/2” - 5/8” 12 7.00
706-112 L201080010 706/42 1-1/2” 5/8” 5/8” 12 6.79
706-127 L201100006 706/42 1-5/8” 3/8” 5/8” 12 7.00
706-155 L201110102 706/42 1-11/16” 1-1/8” 5/8” 12 7.54
706-166 L201120006 706/42 1 3/4” 3/8” 12 7.54
706-175 L201120102 706/42 1-3/4” 1-1/8” 11/16” 12 7.54
706-198 L201130103 706/42 1-13/16” 1-3/16” 3/4” 12 7.54
706-219 L201140103 706/42 1-7/8” 1-3/16” 3/4” 12 7.54
706-220 L201140104 ** 706/42 1-7/8” 1-1/4” 3/4” 12 7.54
706-221 L201140105 * 706/42 1-7/8” 1-5/16” 3/4” 12 7.54
706-255 L202000010 706/42 2” 5/8” 3/4” 12 8.95
706-262 L202000103 706/42 2” 1-3/16” 3/4” 12 8.95
706-263 L202000104 706/42 2” 1-1/4” 3/4” 12 8.95
706-264 L202000105 706/42 2” 1-5/16” 3/4” 12 8.95
706-285 L202010104 706/42 2-1/16” 1-1/4” 3/4” 12 9.81
706-286 L202010105 706/42 2-1/16” 1-5/16” 3/4” 12 9.81
706-308 L202020104 706/42 2-1/8” 1-1/4” 3/4” 12 9.81
706-310 L202020106 706/42 2-1/8” 1-3/8” 3/4” 12 9.81
706-333 L202040106 706/42 2-1/4” 1-3/8” 3/4” 12 9.81
706-334 L202040108 * 706/42 2-1/4” 1-1/2” 3/4” 12 9.81
706-335 L202040110 706/42 2-1/4” 1-5/8” 3/4” 12 9.81
706-345 L202080008 706/42 2-1/2” 1/2” 12 10.93
706-358 L202080110 706/42 2-1/2” 1-5/8” 13/16” 12 10.93
706-359 L202080111 706/42 2-1/2” 1-11/16” 13/16” 12 10.93
706-360 L202080114 706/42 2-1/2” 1-7/8” 13/16” 12 10.93
706-384 L202120114 * 706/42 2-3/4” 1-7/8” 13/16” 12 11.90
706-409 L203000114 706/42 3” 1-7/8” 13/16” 12 13.30
706-410 L203000200 706/42 3” 2” 13/16” 12 13.30
706-435 L203010114 706/42 3 1/16” 1 7/8” 12 15.50
706-436 L203010200 706/42 3-1/16” 2” 12 15.50
706-464 L203080208 706/42 3-1/2” 2-1/2” 1” 12 16.76
706-492 L203120210 706/42 3-3/4” 2-5/8” 1” 12 21.11
706-520 L204000212 706/42 4” 2-3/4” 1-1/16” 6 24.62
706-521 L204000300 706/42 4” 3” 1-1/16” 6 24.62
* Standard Clayton Mark hole size
** Standard Midland hole size
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.83
Cup Leathers
707/45 Graphite Features:
• Selected from the center of hides.
• Flesh side out.
• Graphite coating prevents fast absorption of water and acts as a
lubricant to reduce binding of the plunger in the cylinder.
• Made in USA.
ORDER IN TUBE QUANTITY ONLY
ABC
NEW Part OLD Part Cylinder I.D. Hole Size Tube List
Number Number Finish Leather O.D. Leather I.D. Height Qty Price
707/45 Graphite
707-061 L501040006 707/45 1-1/4” 3/8” 1/2” 12 $ 6.20
707-063 L501040008 707/45 1-1/4” 1/2” 1/2” 12 6.20
707-064 L501040010 707/45 1-1/4” 5/8” 1/2” 12 6.20
707-092 L501060006 707/45 1-3/8” 3/8” 5/8” 12 7.00
707-095 L501060010 707/45 1-3/8” 5/8” 5/8” 12 7.00
707-109 L501080006 707/45 1-1/2” 3/8” 5/8” 12 7.00
707-112 L501080010 707/45 1-1/2” 5/8” 5/8” 12 7.00
707-130 L501100010 707/45 1-5/8” 5/8” 12 7.00
707-149 L501110010 707/45 1-11/16” 5/8” 12 7.54
707-175 L501120102 707/45 1-3/4” 1-1/8” 12 7.54
707-198 L501130103 707/45 1-13/16” 1-3/16” 3/4” 12 7.54
707-215 L501140114 707/45 1-7/8” 7/8” 3/4” 12 7.54
707-220 L501140104 ** 707/45 1-7/8” 1-1/4” 3/4” 12 7.54
707-221 L501140105 * 707/45 1-7/8” 1-5/16” 3/4” 12 7.54
707-255 L502000010 707/45 2” 5/8” 3/4” 12 8.95
707-264 L502000105 707/45 2” 1-5/16” 3/4” 12 8.95
707-286 L502010105 707/45 2-1/16” 1-5/16” 3/4” 12 9.81
707-300 L502020010 707/45 2-1/8” 5/8” 3/4” 12 9.81
707-333 L502040106 707/45 2-1/4” 1-3/8” 3/4” 12 9.81
707-334 L502040108 * 707/45 2-1/4” 1-1/2” 3/4” 12 9.81
707-639 L502060108 707/45 2 3/8” 1 1/2” 3/4” 12 10.93
707-357 L502080108 707/45 2-1/2” 1-1/2” 3/4” 12 10.93
707-358 L502080110 707/45 2-1/2” 1-5/8” 13/16” 12 10.93
707-359 L502080111 707/45 2-1/2” 1-11/16” 13/16” 12 10.93
707-384 L502120114 * 707/45 2-3/4” 1-7/8” 13/16” 12 11.90
707-410 L503000200 707/45 3” 2” 13/16” 12 13.25
707-436 L503010200 707/45 3 1/16” 2” 12 15.50
707-464 L503080208 707/45 3-1/2” 2-1/2” 1” 12 16.76
707-492 L503120210 707/45 3-3/4” 2-5/8” 1” 12 21.11
707-520 L504000212 707/45 4” 2-3/4” 6 24.62
707-521 L504000300 707/45 4” 3” 1-1/16” 6 24.62
707-615 L506000010 707/45 6” 5/8” 6 81.33
* Standard Clayton Mark hole size
** Standard Midland hole size
707/45
Graphite
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.84
Cup Leathers
711/44 Waterproof Features:
• Soft, pliable waterproof.
• Hair side out.
• For use on piston pumps, shallow setting brass-cylinder barrels, air
pumps and other applications where minimum water absorption and
swelling is desired.
• Made in USA.
ORDER IN TUBE QUANTITY ONLY
NEW Part OLD Part Cylinder I.D. Hole Size Tube List
Number Number Finish Leather O.D. Leather I.D. Height Qty Price
711/44 Waterproof
711-021 L401000004 711/44 1” 1/4” 7/16” 12 $ 5.61
711-022 L401000006 711/44 1” 3/8” 7/16” 12 5.61
711-024 L401000008 711/44 1” 1/2” 7/16” 12 5.61
711-037 L401010010 711/44 1-1/16” 5/8” 12 6.20
711-048 L401020006 711/44 1-1/8” 3/8” 1/2” 12 6.20
711-050 L401020008 711/44 1-1/8” 1/2” 1/2” 12 6.20
711-057 L401040000 711/44 1 1/4” - 1/2” 12 6.20
711-061 L401040006 711/44 1-1/4” 3/8” 1/2” 12 6.20
711-062 L401040007 711/44 1-1/4” 7/16” 1/2” 12 6.20
711-063 L401040008 711/44 1-1/4” 1/2” 1/2” 12 6.20
711-064 L401040010 711/44 1-1/4” 5/8” 12 6.20
711-076 L401050006 711/44 1-5/16” 3/8” 12 7.00
711-078 L401050008 711/44 1-5/16” 1/2” 12 7.00
711-092 L401060006 711/44 1-3/8” 3/8” 5/8” 12 7.00
711-094 L401060008 711/44 1-3/8” 1/2” 5/8” 12 7.00
711-095 L401060010 711/44 1-3/8” 5/8” 5/8” 12 7.00
711-098 L401060014 711/44 1-3/8” 7/8” 5/8” 12 7.00
711-109 L401080006 711/44 1-1/2” 3/8” 5/8” 12 7.00
711-111 L401080008 711/44 1-1/2” 1/2” 5/8” 12 7.00
711-112 L401080010 711/44 1-1/2” 5/8” 5/8” 12 7.00
711-129 L401100008 711/44 1-5/8” 1/2” 5/8” 12 7.00
711-130 L401100010 711/44 1-5/8” 5/8” 5/8” 12 7.00
711-135 L401100100 711/44 1-5/8” 1” 5/8” 12 7.00
711-149 L401110010 711/44 1-11/16” 5/8” 5/8” 12 7.54
711-151 L401110103 711/44 1 11/16” 1 3/16” 12 7.54
711-154 L401110100 711/44 1-11/16” 1” 5/8” 12 7.54
711-155 L401110102 711/44 1-11/16” 1-1/8” 5/8” 12 7.54
711-169 L401120010 711/44 1-3/4” 5/8” 11/16” 12 7.54
711-174 L401120100 711/44 1 3/4” 1” 11/16” 12 7.54
711-175 L401120102 711/44 1-3/4” 1-1/8” 11/16” 12 7.54
711-192 L401130012 711/44 1-13/16” 3/4” 12 7.54
711-198 L401130103 711/44 1-13/16” 1-3/16” 3/4” 12 7.54
711-211 L401140008 711/44 1-7/8” 1/2” 3/4” 12 7.54
711-212 L401140010 711/44 1-7/8” 5/8” 3/4” 12 7.54
711-217 L401140100 711/44 1-7/8” 1” 3/4” 12 7.54
711-219 L401140103 711/44 1-7/8” 1-3/16” 3/4” 12 7.54
711-220 L401140104 ** 711/44 1-7/8” 1-1/4” 3/4” 12 7.54
711-221 L401140105 * 711/44 1-7/8” 1-5/16” 3/4” 12 7.54
* Standard Clayton Mark hole size
** Standard Midland hole size
711/44
Waterproof
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.85
Cup Leathers
NEW Part OLD Part Cylinder I.D. Hole Size Tube List
Number Number Finish Leather O.D. Leather I.D. Height Qty Price
711/44 Waterproof - Continued
711-233 L401150010 711/44 1-15/16” 5/8” 3/4” 12 $ 8.95
711-240 L401150103 711/44 1-15/16” 1-3/16” 3/4” 12 8.95
711-242 L401150105 711/44 1-15/16” 1-5/16” 3/4” 12 8.95
711-248 L402000000 711/44 2” SOLID 3/4” 12 8.95
711-254 L402000008 711/44 2” 1/2” 3/4” 12 8.95
711-255 L402000010 711/44 2” 5/8” 3/4” 12 8.95
711-259 L402000015 711/44 2” 15/16” 3/4” 12 8.95
711-262 L402000103 711/44 2” 1-3/16” 3/4” 12 8.95
711-263 L402000104 711/44 2” 1-1/4” 3/4” 12 8.95
711-264 L402000105 711/44 2” 1-5/16” 3/4” 12 8.95
711-267 L402000110 711/44 2” 1-5/8” 3/4” 12 8.95
711-277 L402010010 711/44 2-1/16” 5/8” 3/4” 12 9.81
711-284 L402010103 711/44 2-1/16” 1-3/16” 3/4” 12 9.81
711-285 L402010104 711/44 2-1/16” 1-1/4” 3/4” 12 9.81
711-286 L402010105 711/44 2-1/16” 1-5/16” 3/4” 12 9.81
711-300 L402020010 711/44 2-1/8” 5/8” 3/4” 12 9.81
711-308 L402020104 711/44 2-1/8” 1-1/4” 3/4” 12 9.81
711-316 L402040000 711/44 2 1/4” SOLID 3/4” 12 9.81
711-323 L402040010 711/44 2-1/4” 5/8” 3/4” 12 9.81
711-331 L402040104 711/44 2-1/4” 1-1/4” 3/4” 12 9.81
711-332 L402040105 711/44 2-1/4” 1-5/16” 3/4” 12 9.81
711-333 L402040106 711/44 2-1/4” 1-3/8” 3/4” 12 9.81
711-334 L402040108 * 711/44 2-1/4” 1-1/2” 3/4” 12 9.81
711-335 L402040110 711/44 2-1/4” 1-5/8” 3/4” 12 9.81
711-339 L402080000 711/44 2-1/2” SOLID 13/16” 12 10.93
711-346 L402080010 711/44 2-1/2” 5/8” 13/16” 12 10.93
711-354 L402080104 711/44 2-1/2” 1-1/4” 13/16” 12 10.93
711-355 L402080105 711/44 2-1/2” 1-5/16” 13/16” 12 10.93
711-356 L402080106 711/44 2-1/2” 1-3/8’ 13/16” 12 10.93
711-357 L402080108 711/44 2-1/2” 1-1/2” 13/16” 12 10.93
711-358 L402080110 711/44 2-1/2” 1-5/8” 13/16” 12 10.93
711-359 L402080111 711/44 2-1/2” 1-11/16” 13/16” 12 10.93
711-384 L402120114 * 711/44 2-3/4” 1-7/8” 13/16” 12 11.90
711-637 L402140114 711/44 2-7/8” 1-7/8” 13/16” 12 11.90
711-406 L403000108 711/44 3” 1-1/2” 13/16” 12 13.30
711-409 L403000114 711/44 3” 1-7/8” 13/16” 12 13.30
711-410 L403000200 711/44 3” 2” 13/16” 12 13.30
711-638 L403000202 711/44 3” 2 1/8” 13/16” 12 13.25
711-435 L403010114 711/44 3-1/16” 1-7/8” 13/16” 12 15.50
711-436 L403010200 711/44 3-1/16” 2” 13/16” 12 15.50
711-464 L403080208 711/44 3-1/2” 2-1/2” 1” 12 16.76
711-492 L403120210 711/44 3-3/4” 2-5/8” 1” 12 21.11
711-495 L404000000 711/44 4” SOLID 1-1/16” 6 24.62
711-518 L404000208 711/44 4’ 2-1/2” 1-1/16” 6 24.62
711-520 L404000212 711/44 4” 2-3/4” 1-1/16” 6 24.62
711-521 L404000300 711/44 4” 3” 1-1/16” 6 24.62
* Standard Clayton Mark hole size
** Standard Midland hole size
711/44 Waterproof - continued.
ORDER IN TUBE QUANTITY ONLY
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.86
Cup Leathers
NEO/86 NEOFAB CUP Features:
• Enhanced endurance with lower replacement rates.
• Neoprene material with fabric insert in base.
• Outlasts all other leathers.
• Made in USA.
ORDER IN TUBE QUANTITY ONLY
ABC
NEW Part OLD Part Cylinder I.D. Hole Size Tube List
Number Number Finish Leather O.D. Leather I.D. Height Qty Price
NEO/86 NEOFAB CUP
NEO-220 L901140104 ** NEO/86 1-7/8” 1-1/4” 3/4” 3 $ 24.61
NEO-221 L901140105 * NEO/86 1-7/8” 1-5/16” 3/4” 3 24.61
NEO-255 L902000010 NEO/86 2” 5/8” 3/4” 3 26.16
NEO-264 L902000105 NEO/86 2” 1-5/16” 3/4” 3 26.16
NEO-334 L902040108 * NEO/86 2-1/4” 1-1/2” 3/4” 3 27.25
NEO-358 L902080110 NEO/86 2-1/2” 1-5/8” 13/16" 3 31.95
NEO-384 L902120114 * NEO/86 2-3/4” 1-7/8” 13/16” 3 31.95
NEO-410 L903000200 NEO/86 3” 2” 13/16” 3 37.90
NEO-464 L903080208 NEO/86 3-1/2” 2-1/2” 1” 3 46.02
* Standard Clayton Mark hole size
** Standard Midland hole size
NEO/86 NEOFAB Cup
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.87
Leathers - Universal
708/57 Universal Packing Ring Features:
• General purpose leather washer or flat ring gasket.
• Universal finish for all applications.
• Soft, pliable leather for long life.
• Made in USA.
Part Finish Outside Hole Size Thickness List
Number Diameter Price
708/57 Universal Packing Ring
R702000106 708/57 2” 1-3/8” 1/8” $ 2.04
R702080114 708/57 2-1/2” 1-7/8” 1/8” 3.07
R702120202 708/57 2-3/4” 2-1/8” 1/8” 3.64
R703000206 708/57 3” 2-3/8” 1/8” 4.21
R703080214 708/57 3-1/2” 2-7/8” 5/32” 5.61
708/57 Universal
Packing Ring
Valve Leathers for use with pitcher pumps and cylinders
700/55 Universal Features:
• Lower valve leather.
• Uniform, heavy stock with russet finish.
• Made in USA.
Part Cylinder Leather Standard Ctn List
Number I.D. O.D. I.D. Qty Price
700/55 Universal
V502080200 2” 2 1/2” 2” 6 $ 5.93
V502120204 2 1/4” 2 3/4” 2 1/4” 6 6.90
V503000206 2 1/2” 3” 2 3/8” 6 7.54
V503080214 3” 3 1/2” 2 7/8” 6 9.27
V503120302 3 1/4”” 3 3/4” 3 1/8” 6 9.27
V504000304 3 1/2” 4” 3 1/4” 6 10.83
V504080312 4” 4 1/2” 3 3/4” 6 11.42
V505000404 4 1/4” 5” 4 1/4” 6 11.42
V505040408 4 1/2” 5 1/4” 4 1/2” 6 12.12
V506120512 6” 6 3/4” 5 3/4” 6 30.21
Pitcher Pump Leather Selection Chart
Pump Size Part Number Cylinder I.D. Leather O.D.
No. 1 V503000206 2-1/2” 3
No. 2 V503080214 3” 3-1/2”
No. 3 V504000304 3-1/2” 4”
No. 4 V504080312 4” 4-1/2”
V5 Series
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
1.88
1/15/13
2.7
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Check Valves - Clayton Mark
Part Number Size Enters Casing Ctn Qty List Price
6300-3/4 3/4” 1-1/2” 48 $ 36.96
6300-1 1” 2” 35 38.60
6300-11/4 1-1/4” 2-1/2” 24 52.93
6300-11/2 1-1/2” 3” 20 73.96
6300-2 2” 3-1/2” 12 119.64
6300 Bronze Check Valve Features:
• The Buna-N rubber coated poppet seals
under high & low pressure applications.
• Delrin Stem Guide to improve flow.
• Self locking nut is vibration proof.
• Stainless steel spring.
• 400 PSI rated (WOG).
• Maximum operating temperature 140ºF.
• Hex ends for easy installation.
Part Number Size Enters Casing Ctn Qty List Price
5300-1/2 1/2” 1-1/2” 48 $ 36.21
5300-21/2 2-1/2” 5” 1 510.57
5300-3 3” 6” 1 687.75
5300-4 4” 8” 1 745.18
5300 Bronze Check Valve Features:
• Highly finished bronze body with a flat seated
poppet to withstand increased water
pressure for a continuous period of time.
• 400 PSI (W.O.G.)
• Maximum operating temperature 140ºF.
• Corrosion resistant, stainless steel poppet
core on 5300-1/2”.
• Bronze poppet on 5300-2 1/2, 3 and 4”.
• Not suitable for all types of oil and gas.
• Heavy hex ends for easy installation.
• FOR USE IN WATER WELL SYSTEMS
®
1/15/13
2.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Part Number Size Ctn Qty List Price
6300218-1 1” 35 $ 55.79
6300218-11/4 1-1/4” 30 53.61
63000218 Bronze Two Hole Control Center
• Two 1/4”-18NPS tappings on outlet side.
Check Valves - Clayton Mark
Part Number Size Ctn Qty List Price
63003-1 1” 35 $ 42.18
63003-11/4 1-1/4” 30 80.43
6300-3 Bronze Three Hole Control Center
• 1/8”-27NPS tapping on inlet side for snifter valve.
• 1/4”-18NPS tapping on outlet side for pressure switch.
• 1/4”-18NPS tapping on outlet side for pressure gauge.
Part Number Size Ctn Qty List Price
63002-1 1” 35 $ 54.65
63002-11/4 1-1/4” 30 47.32
63002-11/2 1-1/2” 20 88.75
63002-2 2” 12 61.43
6300-2 Bronze Two Hole Control Center
• 1/8”-27NPS tapping on inlet side for snifter valve.
• 1/4”-18NPS tapping on outlet side for pressure switch.
• NOTE: 4 inch has the 5300 poppet design.
Part Number Size Ctn Qty List Price
63001-1 1” 35 $ 52.12
63001-11/4 1-1/4” 30 73.39
63001-11/2 1-1/2” 20 39.50
63001-2 2” 12 56.43
6300-1 Bronze One Hole Control Center
• 1/8”-27NPS tapping on inlet side for snifter valve.
• NOTE: 2-1/2 inch size has the 5300 poppet design.
• FOR USE IN WATER WELL SYSTEMS
®
1/15/13
2.9
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Check Valves - Clayton Mark
Part Number Size (mpt x fpt) Ctn Qty List Price
6302-11/4x1 1-1/4” x 1” 30 $ 41.14
6302-11/4x11/4 1-1/4” x 1-1/4” 30 54.68
6302-2x2 2” x 2” 12 141.39
6302-3x3 3” x 3” 1 436.32
6302-4x4 4” x 4” 1 666.82
6302 Bronze Submersible Check Valves
• Fits directly on pump discharge.
Part Number Size Ctn Qty List Price
8669A 2” 12 $ 59.82
8034C 2” Rubber Check Packer 11.17
479 BRONZE BREMER CHECK VALVES
• Non corrosive bronze with tapered seat and poppet with Perma-Kleen facing for
positve seal.
• Uses a tapered rubber packer to seal in the well bore.
Part Number Size Ctn Qty List Price
63004-1 1” 35 $ 52.96
63004-11/4 1-1/4” 30 68.57
6300-4 Bronze Four Hole Control Center
• 1/8”-27NPS tapping on inlet side for snifter valve.
• 1/4”-18NPS tapping on outlet side for pressure gauge.
• 1/4”-18NPS tapping on outlet side for pressure switch.
• 1/8” tapping on outlet side for drain(1/8” brass plug furnished).
• FOR USE IN WATER WELL SYSTEMS
Part Number Size Ctn Qty List Price
8663A 2” 24 $ 49.29
461 BRONZE CHECK VALVES
• Non corrosive brass check valve designed to be set in 2” casing.
• Uses a tapered rubber packer to seal in the well bore.
®
1/15/13
2.10
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Foot Valves - Clayton Mark
Part Number Size Enters Casing Ctn Qty List Price
6340-3/4 3/4” 1-1/2” 48 $ 32.29
6340-1 1” 2” 35 35.89
6340-11/4 1-1/4” 2” 30 43.29
6340-11/2 1-1/2” 3” 20 69.89
6340-2 2” 3-1/2” 12 110.89
6340 SERIES Bronze Foot Valves
• 400 PSI rating. (W.O.G.)
• Tapered ABS strainer.
• Corrosion resistant, stainless steel core with exclusive cup shape.
• Maximum operating temperature is 140ºF.
• Jam proof delrin stem guide.
Part Number Size Enters Casing Ctn Qty List Price
5340-3/4 3/4” 1 1/4” 48 $ 35.54
5340-1 1” 1 1/2” 35 39.51
5340-11/4 1 1/4” 2” 24 47.73
5340-11/2 1 1/2” 2 1/2” 20 87.32
5340-2 2” 3 1/2” 12 123.89
5340 SERIES Bronze Foot Valves
• No. 8 perforated brass screen strainer.
• 400 PSI rating.
• Corrosion resistant, stainless steel core with exclusive cup shape.
• Maximum operating temperature is 140ºF.
• FOR USE IN WATER WELL SYSTEMS
Part Number Size Enters Casing Ctn Qty List Price
5330-21/2 2-1/2” 5” 1 $ 423.57
5330-3 3” 6” 1 585.11
5330-4 4” 6” 1 942.18
5330 Bronze Foot Valves
• All bronze.
• No 8 perforated strainer.
• Heavy hex end.
®
10/23/12
2.15
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Foot & Check - Plastic
HARVARD Four in One Plastic Foot Valve
• Positive sealing - spring loaded valve poppet closes against
a smooth tapered seat.
• Corrosion resistant nylon body and internals.
• Self cleaning design for continuous positive sealing.
• Large screen designed to assure smooth water passage and better suction.
• Tapered screen eliminates pipe joint hang-ups during installation.
• Fits four pipe sizes., 3/4" through 1 1/2"
Part Number Size Ctn Qty List Price
Brady Foot Valve - Spring Loaded
FV75 3/4” 12 $ 22.03
FV100 1” 30 25.75
FV125 1-1/4” 32 37.00
FV150 1-1/2” 21 44.48
Brady Check Valve- Spring Loaded
LC75 3/4” 24 18.80
LC100 1” 24 22.03
LC125 1-1/4” 24 33.05
LC150 1-1/2” 12 39.57
Brady Foot Valve Strainer
FV75SN 3/4” 50 2.26
FV100SN 1” 50 2.50
FV125SN 1-1/4” 50 3.64
FV150SN 1-1/2” 50 3.51
Brady Plastic Foot & Check Valve Features:
• “Nose Cone” diffuser reduces friction.
• 50% greater water flow.
• Acetal copolymer construction.
• Non-electrolytic, non-corrosive.
• Spring loaded, 316 stainless steel
• BUNA-N seal
• Pressure max: 175 psi
• Temperature max: 180 F
• LC check valve, FPT x FPT
LC Series
FV441
Part Number Size Ctn Qty List Price
FV441 3/4” through 1 1/2” 100 $ 16.61
FV Series
FV SN Series
1/15/13
2.16
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Foot Valves - Cast Iron, Steel Suction Strainer
Replacement Parts for 5400 Series Foot Valves
LEATHER NEOPRENE COMPLETE REPAIR KIT
Valve FLAPPER ONLY FLAPPER ONLY (w/ neoprene flapper)
Size Part No. List Price Part No. List Price Part No. List Price
1” 5400-1LR $ 5.93 8367A $ 4.91
1 1/4” 5400-11/4LR 6.95 CIRK125 28.08
1 1/2” 5400-11/2LR 7.54 8367C 5.33 CIRK150 32.01
2” 5400-2LR 10.83 8367D 7.54 CIRK200 40.57
2 1/2” 5400-21/2LR 11.48 8367E 8.08 CIRK250 53.23
3” 5400-3LR 16.17 8367F 19.11 CIRK300 65.88
4” 5400-4LR 39.97 8367G 27.80 CIRK400 88.31
5” 5400-5LR 53.27 - - CIRK500 113.04
6” 5400-6LR 65.55 8367J 45.84 CIRK600 187.56
8” 5400-8LR 102.60 8367K 63.02 CIRK800 271.58
Valve Flapper PAINTED GALVANIZED
Part Number Size OD Size List Price List Price
PAINTED RED GALVANIZED
5400-1 1” 2 1/2” $ 26.82
5400-11/4 1-1/4” 2 3/4” 40.95
5400-11/2 1-1/2” 3 1/4” 49.18
5400-2 2” 4 1/4” 52.61
5400-21/2 5400-21/2G 2-1/2” 5” 89.80 94.29
5400-3 5400-3G 3” 5 3/4” 93.99 150.48
5400-4 4” 7” 190.00
5400-5 5” 9” 345.24
5400-6 5400-6G 6” 10 1/8” 480.13 511.19
5400-8 8” 12 7/8” 912.24
Cast Iron Foot Valve Features:
• Available in painted red or galvanized finish.
• Includes neoprene flapper check to maintain prime.
• For use in drainage on construction sites, irrigation projects,
pumping from ponds or streams.
5400 Series Complete Repair Kits
• Single kit to repair both painted and galvanized versions.
• Replacement strainers available in galvanized finish only.
• Contains all components required to replace inner flapper assembly.
• Includes valve weight, neoprene flapper, sealing washer, bolt, washer and nut.
5400 Series
FLAT STEEL ROUND HOLE STRAINERS
• General purpose strainer, zinc plated to prevent corrosion.
• 16 gauge steel.
Part Number Pipe Size Hole Size Height Diameter Ctn Qty List Price
8800B 2” .375” 4” 6” 20 $ 30.22
®
7/17/12
2.17
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Yard Hydrants - Frost Proof
5451 Series Frost Proof Yard Hydrant
Features:
• Fully frost proof, shut-off valve below frost line.
• Heavy cast iron head with 3/4” brass discharge connection
and bucket hook.
• Heavy, galvanized steel, corrosion resistant, 1” stand-pipe.
• Galvanized carbon steel connecting rod. Brass operating rod.
• Long lasting Buna-N rubber plunger with solid brass core.
• Integral valve seat cast into BRONZE valve body. 3/4” FPT connection with
double bypass bottom valve for superior flow, less risk of debris blockage.
• 1/8” FPT drain hole.
• Rated to 80 PSI, adjustable. See page 2.18 for adjustment procedure.
• Packed securely in individual heavy weight carton.
• Independent lab tested.
• CE certified.
Part Number Bury Overall Weight List Price
Depth Length (Pounds)
54511 1 42” 12.4 $ 124.52
54512 2 54” 15.2 132.01
54513 3 66” 17.8 142.83
54514 4 78” 21.0 153.11
54515 5 90” 22.3 163.93
54516 6 102” 26.2 170.96
54518 8 126” 30.7 195.85
5451 Series
Part Number Size # Barbs Ctn/Case Qty List Price
Vacuum Breaker
HVB75 3/4” Meets ASSE 1011 specifications 20/200 $ 7.54
Cast Bronze Hydrant Elbow (INSxMIP)
RBHE3/4 3/4”x 3/4” 5 10/100 12.14
RBHE1X3/4 1” x 3/4” 5 10/100 16.39
RBHE1 1” x 1” 5 10/100 16.75
RBHE11/4 1 1/4” x 1 1/4” 5 5/50 29.46
Cast Bronze Extra Long Hydrant Elbow (INS x MIP)
XLRBHE1 1”x 1” 8 10/100 19.46
XLRBHE1X3/4 1” x 3/4” 10 10/100 19.46
Cast Bronze Hydrant Tee (INS x MIP)
RBHT3/4 3/4” x 3/4” 4 10/100 15.54
RBHT1x3/4 1” x 3/4” 6 10/100 21.25
RBHT1 1” x 1” 4 10/100 21.61
RBHE
RBHT
HVB75
# Item Material
9 Handle Cast iron
10 Clevis Rod 360 brass
11 Head Cast Iron
13 Hose Adpt 3/4" 360 brass
14 Bottom valve Bronze 81-3-7-9
Stand Pipe Steel - galvanized 1”
Materials of Construction
# Item Material
1 Plunger Buna-N/360 brass
2 Fulcrum Bolt Steel - Zinc plated
3 Fulcrum Nut Steel - Zinc plated
4 Links Steel - Zinc plated
5 Set Screw Steel - Zinc plated
6 Packing Nut 360 brass
7 Packing Teflon filled graphite
8 Connector Brass
®
NEW, Improved
flow rates*
45 gpm @ 50 psi
1/15/13
2.18
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Yard Hydrants - Replacement Parts
5451 Series Hydrant Replacement Parts
Part Number Item Number Description List Price
YRK1 Repair Kit (Items 1-8) $ 17.33
9175B 1 Plunger - rubber 6.37
9023B 2 Fulcrum Bolt - steel 0.36
9023C 3 Nut - steel 0.27
9023D 4 Links (set of 2) - steel 2.38
9023E 5 Set Screw square head - steel 0.47
9023A 6 Packing Nut - brass 3.18
29609G 7 Packing - graphite (2 - 1 old, 1 new style) 4.03
9023G 8 Connector - brass 5.79
2506K 9 Handle - painted cast iron 10.14
2222AHNS 10 Clevis Rod - brass NEW STYLE (double bypass) 11.77
2500K 11 Head only - painted cast iron 34.19
382914 13 Hose Adapter - brass 7.31
381504 14 Valve Body - bronze 45.00
2575K Complete Head Assembly (Items 2-13) 56.18
STEEL ROD (use with double bypass valve 5451 Series)
TA7100099NS 54511 Rod (32 5/8” old or 32.4” new) 7.49
TA7100100NS 54512 Rod (44 5/8” old or 44.4” new) 10.62
TA7100101NS 54513 Rod (56 5/8” old or 56.4” new) 13.67
TA7100102NS 54514 Rod (68 5/8” old or 68.4” new) 18.39
TA7100103NS 54515 Rod (80 5/8” old or 80.4” new) 19.39
TA7100104NS 54516 Rod (92 5/8” old or 92.4” new) 22.28
TA7100105NS 54518 Rod (116 5/8” old or 116.4” new) 30.17
®
5451 HYDRANT ADJUSTMENT PROCEDURE
1. Turn water supply OFF.
2. Open hydrant to relieve pressure.
3. Loosen set screw. (Item 1)
4. Push brass rod down as far as it will go by hand to be sure the plunger is touching the seat.
5. Open handle (Item 2) approximately 30° from closed position.
6. Tighten set screw snugly.
7. Turn water supply ON.
8. Operate hydrant and make sure the hydrant is shutting off properly and flowing properly.
9. If hydrant still does not shut off, repeat steps 1 through 8.
10. Flow water through hydrant and then close completely to check for proper drainage by:
a) listening for water draining down pipe or
b) putting your hand over the hose connection to feel for a vacuum.
If hydrant does not drain, see step 11.
11. To clear drain hole blockage, close off hydrant spout by using hose cap or by attaching and kinking a hose. Open and close
hydrant to allow water pressure to clear blockage. Repeat step 10 to verify proper drainage. If hydrant still does not drain, repeat
steps 1 through 10 to fully uncover drain hole.
CAUTION: Do not try to make the shutoff adjustment in one attempt or you may overadjust and cause damage to the plunger and
rods. For this reason adjust in multiple small increments.
3/4” 5451 Hydrant Flow Rates
PSI
10
15
20
25
30
35
40
45
50
GPM 15 20 25 30 35 40 45
45 GPM @ 50 PSI
42.5 GPM @ 45 PSI
37.5 GPM @ 35 PSI
40 GPM @ 40 PSI
35 GPM @ 30 PSI
32.5 GPM @ 25 PSI
29.3 GPM @ 20 PSI
25.7 GPM @ 15 PSI
20 GPM @ 10 PSI
NOTE: All 5451 Series Hydrants are preset at factory. There should be no need for any adjustment on initial installation. Adjust
only if water does not shut off or hydrant does not operate properly.
1/15/13
3.3
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Ball Valves - Gas
Forged Brass Gas Ball Valve Features:
• Heavy duty two piece forged brass body.
• For use with natural, manufactured, mixed, liquified petroleum
and LP gas/air mixtures.
• Meets ANSI standard Z21.15 for use as a gas appliance
connector valve (1/2 lb. system). CSA, US/AGA B-16.44
• Pressure rated at 175 psi W.O.G. non-shock.
• Imported, Mfg for American Granby in an ISO 9001 facility.
Lever Style Tee Style Size
Part Number Part Number t x t Ctn/Case Qty List Price
HGBVL50T 1/2” 12/144 $ 8.89
HGBVL75T 3/4” 12/96 13.05
HGBVL100T 1” 6/96 18.11
HGBVT50T 1/2” 12/144 9.85
HGBVT75T 3/4” 12/96 14.75
HGBVT100T 1” 6/96 28.99
HGBVL Series HGBVT Series
MATERIAL SPECIFICATIONS
Handle Screw Steel
Handle Aluminum
Stem O-Rings NBR
Stem Forged Brass
Ball Chrome Plated Brass
Seats Teflon®
Body Forged Brass
End Adapter Forged Brass
DIMENSIONS (IN.) BTU
SIZE A B C Capacity/Hr.
1/2” 2.21 1.46 1.81 295,000
3/4” 2.38 1.75 1.81 795,000
1” 2.91 1.89 1.81 1,200,000
ISO 9001
7/17/12
3.4
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Float Valves - Bronze, NO LEAD Bronze
Bronze, NO LEAD Bronze Float Valve Features:
• Cast bronze or NO LEAD bronze body
• Buna-N Disc
• Heavy Duty
• Tapped for 1/4-20SAE rod
• Threaded outlet
• Rated at 125 psi
BFV Series
Part Number Size Inlet Outlet Tapped Ctn Qty List Price
BFV1/2 1/2” 1/2” mpt 1/2” mpt 1/4”-20SAE 10/100 $ 29.70
BFV3/4 3/4” 3/4” mpt 3/4” mpt 1/4”-20SAE 10/80 35.83
BFV1 1” 1” mpt 1” mpt 1/4”-20SAE 10/40 54.00
NO LEAD BRONZE
BFVNL1/2 1/2” 1/2” mpt 1/2” mpt 1/4”-20SAE 10/100 42.69
BFVNL3/4 3/4” 3/4” mpt 3/4” mpt 1/4”-20SAE 10/80 44.14
BFVNL1 1” 1” mpt 1” mpt 1/4”-20SAE 10/40 68.65
Stainless Steel Rods Features:
• Stainless Steel SAE
• Male thread both ends
BFVR Series Part Number Length Thread Fits Valve Size Ctn Qty List Price
BFVR8 8” 1/4”-20SAE 1/2” - 1” 50/400 $ 6.62
BFVR10 10” 1/4”-20SAE 1/2” - 1” 50/300 7.67
BFVR12 12” 1/4”-20SAE 1/2” - 1” 50/300 8.59
Plastic Float Features:
• PVC, Corrosion resistant.
• Lightweight
• Up to 175°F
• For open tank service only
• Bronze or NO LEAD bronze threaded connection.
BFVFP Series
Part Number Float Diam. Buoyancy Female Connection Ctn Qty List Price
BFVFP5 5” 2.17 lbs. 1/4”-20SAE 100 $ 21.23
BFVFP6 6” 3.8 lbs. 1/4”-20SAE 100 25.00
BFVFP8 8” 9.87 lbs. 1/4”-20SAE 20 31.08
NO LEAD BRONZE
BFVFPNL5 5” 2.17 lbs. 1/4”-20SAE 100 21.23
BFVFPNL6 6” 3.8 lbs. 1/4”-20SAE 100 25.00
BFVFPNL8 8” 9.87 lbs. 1/4”-20SAE 20 31.08
10/23/12
3.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Valves - Brass Gate
GV200 Series Forged Brass Gate Valve Features:
• Constructed of heavy duty forged brass.
• Die-cast body, forged bonnet are connected with a Teflon® body to bonnet
gasket for a leak proof seat.
• Screwed bonnet, non-rising stem, solid wedge disc and integral seats.
• Graphite stem seal packing.
• Cast iron hand wheel
• Rated at 200 PSI WOG; 125 PSI SWP (working pressure, non shock)
• Threaded ends produced to ANSI/ASME B1.20.1 (NPT) standards.
• Sweat ends produced to ANSI B16.18-1984 standards
• Imported
Teflon® is a registered trademark of Dupont.
Threaded Sweat Ctn/Case
Part Number Part Number Size Qty List Price
GV200-50T 1/2” 10 / 100 $ 12.46
GV200-50S 1/2” 10 / 100 13.23
GV200-75T 3/4” 10 / 100 14.97
GV200-75S 3/4” 10 / 100 14.88
GV200-100T 1” 5 / 50 21.16
GV200-100S 1” 5 / 50 20.39
GV200-125T 1 1/4” 5 / 50 32.50
GV200-125S 1 1/4” 5 / 50 30.05
GV200-150T 1 1/2” 2 / 30 44.36
GV200-150S 1 1/2” 2 / 30 45.75
GV200-200T 2” 2 / 20 63.59
GV200-200S 2” 2 / 20 70.29
GV200-250T 2 1/2” 1 / 10 143.45
GV200-300T 3” 1 / 10 182.12
GV200-400T 4” 1 / 4 315.40
MATERIAL SPECIFICATIONS
Wheel Nut Stainless
Steel
Hand Wheel Gray Iron
Packing Nut Brass
Gland Follower Brass
Stem Seal Packing Graphite
Bonnet Brass
Body-Bonnet Gasket Teflon
Lock Nut Brass
Stem Brass
Disc Brass
Body Brass
DIMENSIONS (IN.) SIZE A (IPS) A (CxC) B (IPS) B (CxC) C d
1/2” 1.68 1.76 2.80 2.79 2.17 .51
3/4” 1.76 2.34 2.99 3.10 2.17 .67
1” 1.97 2.69 3.45 3.63 2.36 .83
1 1/4” 2.30 3.01 4.06 4.37 2.84 1.07
1 1/2” 2.46 3.36 4.47 4.96 2.84 1.34
2” 2.69 3.98 5.26 6.13 3.15 1.77
2 1/2” 3.43 6.44 3.94 2.21
3” 3.71 7.48 4.33 2.68
4” 4.45 9.25 5.12 3.55
GV200 Series
1/15/13
3.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Valves - Brass Swing Check
Brass Swing Check Valve Features:
• Constructed of heavy duty cast brass.
• Screwed cap, swing type disc and integral seat.
• Prevents backflow while offering full flow performance with a minimum
of turbulence or pressure loss.
• Rated 200 PSI W.O.G. (working pressure non-shock)
• Imported.
• Manufactured for American Granby in an ISO 9001 factory.
Threaded Sweat Ctn/Case
Part Number Part Number Size Qty List Price
HSCV50T 1/2” 10/120 $ 16.57
HSCV50S 1/2” 10/120 17.36
HSCV75T 3/4” 10/80 20.50
HSCV75S 3/4” 10/80 20.99
HSCV100T 1” 5/60 25.39
HSCV100S 1” 5/60 26.55
HSCV125T 1-1/4” 5/40 43.53
HSCV125S 1-1/4” 5/40 43.92
HSCV150T 1-1/2” 5/30 56.10
HSCV150S 1-1/2” 5/30 57.35
HSCV200T 2” 2/24 83.09
HSCV200S 2” 2/24 84.43
HSCV250T 2-1/2” 1/15 156.65
HSCV300T 3” 1/10 220.38
HSCV400T 4” 1/6 336.67
MATERIAL SPECIFICATIONS
Cap Brass
Body Brass
Disc Brass
Hinge Pin Brass
Screw Brass
DIMENSIONS (IN.) SIZE A (IPS) A (CxC) B (IPS) B (CxC)
1/2” 2.05 2.05 1.47 1.49
3/4” 2.32 2.32 1.58 1.58
1” 2.56 2.56 1.68 1.68
1 1/4” 3.12 3.12 1.84 1.84
1 1/2” 3.45 3.45 2.15 2.15
2” 4.16 4.16 2.69 2.69
2 1/2” 5.11 2.93
3” 5.74 3.78
4” 6.79 3.90
HSCV Series
ISO 9001
1/15/13
3.7
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Plumbing Valves - BRASS, Low Pressure
BOILER DRAINS • HOSE BIBBS
• 125 PSI WOG (working pressure - non-shock), 200 PSI WOG (1/4 turn ball valve hose bibbs)
• All valves shown below are CSA rated except THBB/IHBB Series
• Imported
HBD Series
HBD-SB Series IBD-SB Series
HNKD Series
HHB Series
THBB Series
IHBB Series
HHBNHT Series
IHBBNHT Series
☺Has combination 1/2” mip and
1/2” solder connection
IBDBV Series
Part Number Size Description Ctn/Case Qty List Price
Brass No-Kink Boiler Drains
HNKD50 ☺1/2” mip x ght 12/144 $ 7.45
HNKD75 3/4” mip x ght 12/144 8.76
Brass Boiler Drains
HBD50 ☺1/2” mip x ght 12/144 7.69
HBD75 3/4” mip x ght 12/144 8.52
HBD50SB ☺1/2 w/ stuffing box mip x ght 12/144 8.95
HBD75SB 3/4” w/ stuffing boxmip x ght 12/144 10.33
Brass Full Flow Boiler Drains
IBD50SB ☺1/2” w/ stuffing box mip x ght 12/144 9.83
IBD75SB 3/4” w/ stuffing box mip x ght 12/144 10.06
1/4 turn Ball Valve Brass Boiler Drain w/ Butterfly Handle
IBDBV50 ☺ 1/2” mip x ght 12/144 8.28 i
IBDBV75 3/4” mip x ght 12/144 10.85
Brass Hose Bibbs
HHB50 ☺1/2” mip x ght 12/144 8.20
HHB75 3/4” mip x ght 12/144 8.90
Brass Hose Bibbs - No Garden Hose Thread, Sampling Valve
HHB50NHT ☺1/2” mip x spout 12/144 8.91
HHB75NHT 3/4” mip x spout 12/144 9.49
1/4 turn Ball Valve Brass Hose Bibbs w/ T Handle - 200 psi WOG non-shock
IHBB50 ☺1/2” mip x ght (blue handle) 12/144 10.56
IHBB75 3/4” mip x ght (blue handle) 12/144 12.57
THBB50 1/2” mip x ght ITALY (red handle) 10/100 17.14
THBB75 3/4” mip x ght ITALY (red handle) 10/100 20.50
1/4 turn Ball Valve Brass Hose Bibbs w/ T Handle - 200 psi WOG non-shock
No garden hose thread - Sampling valve
IHBB50NHT ☺1/2” mip x spout (blue handle) 12/144 11.06
IHBB75NHT 3/4” mip x spout (blue handle) 12/144 11.47
1/15/13
3.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Plumbing Valves - Brass, Low Pressure
Part Number Size Description Ctn/Case Qty List Price
Full Flow Bent Nose Garden Valves
HBNG50 1/2” fip x ght 12/72 $ 14.93
HBNG75 3/4” fip x ght 12/72 14.90
HBNG100 1” fip x ght 12/72 17.64
Brass Angle Sill Cocks
HSC50T 1/2” fip x ght 12/144 9.29
HSC75T 3/4” fip x ght 12/144 10.33
HSC50C 1/2” swt x ght 12/144 10.63
HSC75C 3/4” swt x ght 12/144 10.56
Chrome Plated Brass Frost Proof Sill Cocks, IPS x Sweat Fitting
H504 1/2 x 4” 2/40 31.04
H506 1/2 x 6” 2/40 32.68
H508 1/2 x 8” 2/40 36.50
H510 1/2 x 10” 2/40 34.70
H512 1/2 x 12” 2/40 39.00
H514 1/2 x 14” 2/40 36.71
Chrome Plated Brass Frost Proof Sill Cocks w/ 3/4” mpt x 1/2” fip connection
H506-3/4 3/4 x 1/2 x 6” 2/40 18.47
H508-3/4 3/4 x 1/2 x 8” 2/40 27.54
H510-3/4 3/4 x 1/2 x 10” 2/40 28.29
H512-3/4 3/4 x 1/2 x 12” 2/40 29.00
H514-3/4 3/4 x 1/2 x 14” 2/40 34.22
Chrome Plated Brass Anti-Siphon Sill Cocks* w/ 1/2” mip x 1/2” swt connection
H504AS 1/2 x 4” 2/30 33.81
H506AS 1/2 x 6” 2/30 39.95
H508AS 1/2 x 8” 2/30 36.51
H510AS 1/2 x 10” 2/30 42.77
H512AS 1/2 x 12” 2/30 38.92
H514AS 1/2 x 14” 2/30 40.18
* with integral vacuum breaker
Vacuum Breaker
HVB75 3/4” Meets ASSE 1011 specifications 20/200 $ 7.54
BENT NOSE GARDEN • ANGLE SILL COCKS • FROST PROOF SILL COCKS
• 125 PSI WOG (working pressure - non-shock)
• Imported
HBNG Series
HSC Series
H500 Series
H500AS Series
HVB75
10/23/12
3.21
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Slice Gate Valves - PVC
Part Number Description Max PSI Ctn Qty List Price
Uni-Body
VSGV2101 1 1/2” slip x slip 50 30 $ 16.95
VSGV2201 2” slip x slip 50 20 23.91
* Unibody 2” slip hubs are 2” slip or 2 1/2” spig
Three Piece Body
VSGV150SL 1 1/2” slip x slip 50 30 19.57
VSGV150FIPTXMIPT 1 1/2” fipt x mipt 50 40 23.41
VSGV150FIPTxMIPTABS 1 1/2" fipt x mipt ABS 50 26 23.41
VSGV150SLU 1 1/2” slip x union slip 50 38 31.00
VSGV150MTU 1 1/2" mipt x union slip 50 38 29.48
VSGV150SP 1 1/2” slip x spigot 50 30 18.62
VSGV150SD 1 1/2" step down pool hose x mipt ABS 40 22.25
VSGV200SL 2” slip x slip 50 20 24.89
VSGV200SP 2” slip x spigot 50 34 23.69
VSGV300SL 3” slip x slip 20 15 39.32
VSGV400SL 4” slip x slip w/ metal handle 15 6 167.22
VSGV600SL 6” slip x slip w/ stainless handle 10 1 696.67
VSGV800SL 8” slip x slip w/ stainless handle 10 1 975.45
VSGV1000SL 10” slip x slip w/ stainless handle 10 1 1778.33
VSGV1200SL 12” slip x slip w/ stainless handle 10 1 1868.19
VSGV 3 piece body
VSGV Uni-Body
PVC Slice Gate Valve Features:
• Designed for pool & spa, irrigation, plumbing, waste water
and agricultural applications.
• Stainless steel shaft prevent rust and corrosion.
• Ozone & chemical resistant Santoprene™ materials.
• Santoprene™ seals are integrated to the paddle to eliminate any chance of torn or
punctured gaskets.
• Maximum working pressure 50 psi (through 2”).
• Solvent cement traps to catch excess glue.
• Every valve tested at double recommended working pressure.
• Valterra’s patent pending triple o-ring neck seal to ensure against any chance of shaft
leakage.
Unibody Design
• One piece uni-body design.
• Combination socket ID x spigot OD for installation flexibility.
• Locking handle provides positive shut-off and easy gate opening.
3 Piece body
• Three piece configuration allows for repair or can be used as a union.
• Three piece configuration easily disassembles for inline service.
VSGV 3 piece body
with union
1/15/13
3.22
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Slice Gate Valves - PVC
PVC Slice Gate Valve Features:
• One piece “Uni-Body” PVC Construction. Guaranteed
NO HUB LEAKS or loose bolts.
• 1/4 turn “Cam-Lock” for 100% shut-off..
• Internal “snap-lock” feature ensures valve will remain totally open,
providing 100% flow with no restriction.
• Stainless steel shaft prevents rust and corrosion.
• Glass filled poly-pro tapered gate design for 100% sealing.
• Integrally molded seal on gate. - No pinched or torn gaskets.
• Seals are “Santoprene” that have been impregnated with a permanent
lubricant. Never needs lube yet will provide continuous smooth operation.
Ozone and chemical resistant for much longer life.
• Santoprene buttons on gate provides smooth operation without sticking.
• Every valve water tested at 100PSI and random quick burst tested at 400 PSI.
Virtually no chance of leaky valves in the field at standard operating pressures.
• Maximum recommended operating pressure is 50 PSI.
• Glue wells on all slip-socket configuration catches excess glue during plumbing.
• Constructed and tested for use in pool & spa applications.
• Made in USA
Part Number Size Description Ctn/Case Qty List Price
SGV150SL 1 1/2” Slip x Slip 14/56 $ 19.75
SGV200SL 2” Slip x Slip 12/48 20.89
SGV250SL 2 1/2” Slip x Slip 5/20 44.30
SGV150SP 1 1/2” Slip x Spigot 14/56 19.75
SGV200SP 2” Slip x Spigot 12/48 20.89
SGV150SLU 1 1/2” Slip x Slip with Union 10/40 31.97
SGV200SLU 2” Slip x Slip with Union 10/40 38.60
SGV - SL Series
SGV-Sp and SGV-SLU Series
TM 1/15/13
4.1
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
EH Series Economy Housing Features:
• Manufactured from NSF listed, FDA grade 100% polypropylene.
• Available in slim, standard and large diameter styles.
• 10” and 20” lengths.
• Opaque and clear sumps.
• 3/8” - 1 1/2” inlet/outlets. VIH clear has stainless steel 3/4” FPT inserts.
• All housings have a pressure relief button.
• EPDM o-ring seals.
• Rated for temperature to 125° F and pressures to 125 psi.
• Filter housings are bulk packed. Cartridges available separately.
Part No. Style Sump Head Inlet/Outlet Length Ctn Qty List Price
SLIM STYLE Housings with pressure relief for 2 1/2” OD cartridges
EH38BSLBP Slim Blue Black 3/8” 10” 12 $ 25.69
EH38CSLWP Slim Clear White 3/8” 10” 12 33.16
EH50BSLBP Slim Blue Black 1/2” 10” 12 24.00
EH50CSLWP Slim Clear White 1/2” 10” 12 36.13
EH75BSLBP Slim Blue Black 3/4” 10” 12 27.50
EH75CSLWP Slim Clear White 3/4” 10” 12 36.00
EH75CSLWPSS Slim Clear White 3/4” w SS inserts 10” 12 55.16
Valve-in-Head SLIM STYLE Housings for 2 1/2” OD cartridges (allows by-pass during cartridge replacement)
EH75VCP Slim VIH Clear White 3/4” SS FPT 10” 12 86.07
EH75VWP Slim VIH White White 3/4” FPT 10” 12 75.76
STANDARD STYLE Housings with pressure relief for 2 1/2” OD cartridges
EH75BP Standard Blue Black 3/4” 10” 12 48.60
EH75CP Standard Clear Black 3/4” 10” 12 55.64
EH75B20P Standard Blue Black 3/4” 20” 12 80.75
EH75C20P Standard Clear Black 3/4” 20” 12 121.72
LARGE DIAMETER STYLE Housings with pressure relief for 4 1/2” O.D. cartridges
EHLD75BP Lg. Diam Blue Black 3/4” 10” 4 94.78
EHLD10BP Lg. Diam Blue Black 1” 10” 4 95.93
EHLD10CP Lg. Diam Clear Black 1” 10” 4 166.16
EHLD15BP Lg. Diam Blue Black 1 1/2” 10” 4 96.08
EHLD75B20P Lg. Diam Blue Black 3/4” 20” 4 137.60
EHLD10B20P Lg. Diam Blue Black 1” 20” 4 140.26
EHLD15B20P Lg. Diam Blue Black 1 1/2” 20” 4 139.55
Economy Filter Housings & Kits
Filter Housing Kit Features:
•Slim, VIH, Standard and Large diameter styles.
• Complete with mounting bracket (with stainless steel screws) and sump removal wrench.
• Individually cartoned with label.
• Custom kits available. Call Customer Service for quotations.
Part Number Style Sump Inlet/Outlet Length Bracket Case Qty List Price
EFHP75BSLBP Slim Blue 3/4" 10" YES 6 $ 38.97
EFHP75CSLWP Slim Clear 3/4" 10" YES 6 46.38
EFHP75VCP Slim VIH Clear 3/4" 10" YES 6 94.14
EFHP75VWP Slim VIH White 3/4" 10" YES 6 88.64
EFHP75BP Standard Blue 3/4" 10" YES 4 65.78
EFHP75CP Standard Clear 3/4" 10" YES 4 72.54
EFHPLD75BP Large Dia Blue 3/4" 10" YES 1 152.03
EFHPLD10BP Large Dia Blue 1" 10" YES 1 143.42
EFHPLD15BP Large Dia Blue 1 1/2" 10" YES 1 143.42
EFHP Series
TM
1/15/13
4.2
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Economy Filter Accessories
Part Number Fits Style Material Color Ctn Qty List Price
Mounting Brackets for EH Series Filter Housings
Includes stainless steel head and wall mounting screws
ES10BA EH Slim (L) Aluminum White $ 6.25
ES15BA EH Valve in Head (U) Aluminum -- 10.06
ES20BA EH Standard (L) Aluminum White 13.28
ES25BA EH Large Diam. (L) Aluminum --- 59.24
Wrenches for EH Series Filter Housing sump removal
EWSL Slim Polypropylene White 3.86
EWSTND Standard Polypropylene White 3.86
EWLD Large Diam. Polypropylene Black 9.27
O-rings for EH Series Filter Housings
EOR4 Slim EPDM 2.19
EOR-VIH Slim VIH EPDM 2.18
EOR8 Standard EPDM 3.30
EOR5 Large Diam. EPDM 4.37
Inline Ice Maker Carbon Filter Features:
• NSF listed.
• Granular activated carbon medium.
• Removes chlorine, taste and odor from water
• Ideal for refrigerator ice makers, water dispensers and coffee makers.
• Furnished with or without 1/4" fittings.
Part Number OD Length Fits Pipes Pipe Ftgs Ctn Qty List Price
EIC100 2” 10” 1/4" FPT NO 25 $ 14.26
EIC100JG 2" 10" 1/4" plastic or 1/4" John 25 19.54
copper tubing Guest
EW Series
EOR Series
EIC100
RV & Marine Water Filter Features:
• Long life exterior inline water filter effectively reduces chlorine,
tastes and odors, sediment, volatile organic chemicals and
inhibits bacterial growth.
• Working pressure: 20-125 psi
• Maximum flow rate: 2.5 gpm.
• Temperature range: 40-100°F
• Ideal for RV, boats and camping.
• Uses KDF/GAC media to control microorganisms
while reducing lime and scale buildup.
• Includes connector hose (3/4” MGHT x 3/4” FGHT).
Part Number Description Ctn Qty List Price
EFRVM75 RV/Marine Inline Water Filter Kit (hose & cart in box) 1 $ 44.90
FP12NK Connector Hose 1 22.32
FP12GE Inline GAC Cartridge 1 25.70
EFRVM75
ES-BA Series
1/15/13
4.3
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Economy Filter Cartridges
EFP Series Melt Blown Polypropylene Filter Cartridge Features:
• Melt blown polypropylene for purity and chemical compatibility.
• Ideal for aggressive chemicals and general sediment filtration when depth
filtration is required.
• Max Flow rate 2-8 gpm based on micron.
• Contains no binders, agents, solvents, antistatic materials or wetting agents.
• Meets FDA requirements for food and beverage contact.
• No leachables or extractables to contaminate.
• No surface binders to reduce flow & increase change-out frequency.
• Rated for tempertures up to 140° F
• Shrink wrapped for purity.
Part Number Micron O.D. Length Ctn Qty List Price
MELT BLOWN POLYPROPYLENE Filter cartridges for SLIM and STANDARD style housings
EFP1 1 2 1/2” 9 7/8” 48 $ 5.15
EFP5 5 2 1/2” 9 7/8” 48 4.32
EFP20 20 2 1/2” 9 7/8” 48 4.32
EFP50 50 2 1/2” 9 7/8” 48 4.32
EFP1-20 1 2 1/2” 20” 24 8.77
EFP5-20 5 2 1/2” 20” 24 8.74
EFP20-20 20 2 1/2” 20” 24 8.74
EFP50-20 50 2 1/2” 20” 24 8.74
MELT BLOWN POLYPROPYLENE Filter cartridges for LARGE DIAMETER style housings
EFPBB1 1 4 1/2” 9 3/4” 24 32.72
EFPBB5 5 4 1/2” 9 3/4” 24 27.60
EFPBB20 20 4 1/2” 9 3/4” 24 27.60
EFPBB50 50 4 1/2” 9 3/4” 24 27.60
EFPBB1-20 1 4 1/2” 20” 12 65.29
EFPBB5-20 5 4 1/2” 20” 12 50.37
EFPBB20-20 20 4 1/2” 20” 12 52.38
EFPBB50-20 50 4 1/2” 20” 12 52.38
EFP Series
EFP-G Series Grooved Melt Blown Polypropylene Filter Cartridge Features:
• Grooved cartridges for increased surface area and greater dirt handling capacity.
• Melt blown polypropylene.
• Maximum tempertures 140° F
• Maximum pressure: 40 psid
• Recommended change out 30 psid.
• Maximum flow rate 2-8 gpm based on micron.
• Shrink wrapped for purity.
• Fits slim and standard style housings.
EFP_G Series
Part Number Micron OD Length Ctn Qty List Price
EFP5G 5 2 1/2” 9 3/4” 48 $ 6.02
EFP20G 20 2 1/2” 9 3/4” 48 6.02
EFP1G-20 1 2 1/2” 20” 24 12.02
EFP5G-20 5 2 1/2” 20” 24 11.15
TM
1/15/13
4.4
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
EFWP Series
EFW Series Wound Filter Cartridge Features:
• Excellent depth filtration.
• FDA grade polypropylene fibers.
• Polypropylene center tubes.
• For tempertures to 140 F.
• Individually wrapped.
Part Medium Type of Micron O.D. Length Ctn Qty List Price
Number Construct
WOUND POLYPROPYLENE Filter cartridges for SLIM and STANDARD style housings
EFWP1 Polypropylene Wound 1 2 1/2” 9 7/8” 30 $ 9.25
EFWP5 Polypropylene Wound 5 2 1/2” 9 7/8” 30 8.88
EFWP10 Polypropylene Wound 10 2 1/2” 9 7/8” 30 8.95
EFWP20 Polypropylene Wound 20 2 1/2” 9 7/8” 30 8.88
EFWP30 Polypropylene Wound 30 2 1/2” 9 7/8” 30 8.96
EFWP50 Polypropylene Wound 50 2 1/2” 9 7/8” 30 8.74
EFWP1-20 Polypropylene Wound 1 2 1/2” 20” 15 18.43
EFWP5-20 Polypropylene Wound 5 2 1/2” 20” 15 17.86
EFWP10-20 Polypropylene Wound 10 2 1/2” 20” 15 17.88
EFWP20-20 Polypropylene Wound 20 2 1/2” 20” 15 17.86
EFWP30-20 Polypropylene Wound 30 2 1/2” 20” 15 17.90
EFWP50-20 Polypropylene Wound 50 2 1/2” 20” 15 17.65
WOUND POLYPROPYLENE Filter cartridges for LARGE DIAMETER style housings
EFWPBB1 Polypropylene Wound 1 4 1/2” 9 3/4” 8 $ 30.98
EFWPBB5 Polypropylene Wound 5 4 1/2” 9 3/4” 8 30.33
EFWPBB20 Polypropylene Wound 20 4 1/2” 9 3/4” 8 30.10
EFWPBB50 Polypropylene Wound 50 4 1/2” 9 3/4” 8 29.39
EFWPBB1-20 Polypropylene Wound 1 4 1/2” 20” 4 62.27
EFWPBB5-20 Polypropylene Wound 5 4 1/2” 20” 4 60.03
EFWPBB20-20 Polypropylene Wound 20 4 1/2” 20” 4 60.59
EFWPBB50-20 Polypropylene Wound 50 4 1/2” 20” 4 58.56
Economy Filter Cartridges
EFGAC Series
EFGAC Series Granulated Activated Carbon Filter Cartridge Features:
• For removal of taste, odor, organic chemicals and chlorine.
• 5 micron
Part Number Fits Housing Style O.D. Length Ctn Qty List Price
EFGAC10 Slim, Standard 2 1/2” 9 3/4” 24 $ 15.34
EFGAC20 Slim, Standard 2 1/2” 20” 24 34.61
EFGACBB Large Diameter 4 1/2” 9 3/4” 8 48.49
EFGACBB20 Large Diameter 4 1/2” 20” 4 81.09
TM 2/15/11
4.7
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Big-Bubba Filter Housings
Big-Bubba® High Flow Non-Metallic Filter Housing Features:
Big-Bubba® high flow filters are bigger and better than other non-metallic filter hous-
ings because of their economical plastic construction, while pressure rating is nearly
equal to stainless steel.
Features:
• Made of glass-reinforced polypropylene for greater strength and chemical
resistance.
• Will not dent, rust, chip or corrode.
• Filters accept a single cartridge for convenience.
• Swing-bolt lid closure is easy, safe and secure.
• Pressure release for safety.
• Cartridge “lock” adapter to hold cartridge in place.
• Double o-rings on cartridges for superior sealing.
• Two outlets on opposite sides to allow more flexibility with piping configurations.
Typical Applications:
• Whole house filtration for chlorine, taste, odor and sediment reduction.
• Industrial applications for chemical compatability.
• Pre-filtration for reverse osmosis.
• Community water systems for cyst reduction.
• Sea water filtration for non corrosion.
Parallel installations are recommended
to achieve high flow rates, by installing
filters on a common manifold, feeding
all filters installed in a row.
Series installations are recommended
for applications such as surface
water filtration, where cartridges hav-
ing different micron ratings are used.
Part No. Description Max Flow Rate Pipe Fitting List Price
BBH150 Big-Bubba Housing 150 gpm 2” slip $ 1964.33
Specifications:
Materials
Body, cartridge end caps Glass reinforced PP
Swing Bolts 304SS
O-Ring (lid) EPDM
Lid closure Swing Bolt
Pipe Fittings (2 inlet, 1 outlet) 2” slip
Overall height 40”
Width(vessel OD) 12”
Maximum Flow Rate 150 gpm *
Maximum temperature (housing) 175° F
Maximum working pressure 125 psi
Burst test 300 psi
Cycle test (0 to 150 psi) 100,000
Parallel Installation Series Installation
* Dependent on micron rating (see pressure drop chart)
TM
1/15/13
4.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Big Bubba Filter Cartridges
Big-Bubba® High Flow Filter Cartridge Features:
Replacement cartridges for Big-Bubba filters, all with double o-ring
seals for superior performance.
Cartridges are easy to install, service and replace.
Pleated:
• Pleated cartridges are recommended for typical water filtration
applicaitons to remove sediment, hard solids and when high efficiency
filtration is required. Available in a wide range of micron ratings,
including one micron absolute for surface water filtration to reduce
Giardia Cycts and Cryptosporidium.
Depth:
• Select depth cartridges to remove sediment, gelatinous sub-
stances and when chemical compatibility is an issue. Big-Bubba melt
blown depth cartridges are 100% polypropylene with EPDM o-rings.
Activated Carbon Cartridges:
• Ideal for whole house filtration and other applications to reduce
chlorine, tastes, odors and sediment from water. Rated at 5 micron.
BBC-P Series
BBC-D Series
Part Number Micron Media Type Seals Ctn Qty List Price
PLEATED
BBC-150-P1A 1 absolute Polypropylene 5 ply Double O-rings 1 $ 556.40
BBC-150-P1 1 Polypropylene Double O-rings 1 533.80
BBC-150-P5 5 Polypropylene Double O-rings 1 508.58
BBC-150-P20 20 Polypropylene Double O-rings 1 452.61
BBC-150-P50 50 Polypropylene Double O-rings 1 432.93
DEPTH
BBC-150-D1 1 Polypropylene Double O-rings 1 173.54
BBC-150-D5 5 Polypropylene Double O-rings 1 150.68
BBC-150-D20 20 Polypropylene Double O-rings 1 150.68
BBC-150-D50 50 Polypropylene Double O-rings 1 150.68
ACTIVATED CARBON
BBC-150-AC 5 nominal Activated carbon Double O-rings 1 818.52
Specifications:
PLEATED DEPTH
Media PP PP
End Caps PP & FG PP & FG
Center Tubes PP PP
Maximum Flow Rate* 150 gpm 100 gpm
Maximum temperature 175° F 175° F
Maximum Chg pressure (psi) 30 40
Chemical Resistance Excellent Excellent
Length (media) 26 1/4” 26 1/4”
O-rings (dual) EPDM EPDM
PLEATED Cartridge Pressure drop
* Flow rates based on each specific application, micron rating,
solids content and other factors. End user should consider these
factors when selecting the filter housing (or housings) needed for
their particular requirement.
BBC-AC Series
TM 12/13/11
4.9
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Economy Residential R.O. Systems
Economy Residential RO System Features:
• Pre-assembled, easy to install 4 or 5 stage RO system.
• Complete with all installation accessories and instructions.
• High rejection, thin film membrane up to 98% efficient with 50 gallon
per day capacity. (Note: Feed water requirements below)
• NSF Standard 58 listed, FDA approved, polypropylene tank rated to 100
psi. (Steel tank for ROK2050MT Economy System)
• All cartridges, valves, fittings included.
• All fittings, tubing, housings, valves, cartridges and membranes are NSF
listed or made from NSF listed materials.
• WQA validated, patented automatic shut-off valve made from NSF listed
materials.
• Lead free, long reach chrome faucet included. Meets State of California
requirements.
• Sump wrench, white aluminum bracket included.
Part No. Description List Price
ROK1050 4 stage RO system, 50 gpd $ 598.71
ROK2050 5 stage RO system, 50 gpd 640.75
ROK2050MT 5 stage RO economy system, steel 50 gpd 553.11
ROK1050MEM TFC membrane 50 gpd 135.02
ROK1050
ROK Systems Include:
•NSF listed Jaco fittings.
•NSF listed filter housings.
•NSF standard 58 listed white poly-
propylene tank. (9” diam x 20” high)
* (Steel storage tank for ROK2050MT)
•NSF listed 5 micron carbon block
cartridge.
•NSF listed in-line post carbon cartridge.
•NSF component thim film membrane,
Dow/Filmtec 50 gpd.
•Coconut shell GAC carbon cartridge made
with NSF listed materials (ROK2050).
•5 micron sediment pre-filter cartridge
made with NSF listed materials.
•WQA validated, patented automatic
shutoff valve made w/ NSF materials.
•Long reach, lead free chrome faucet,
meets State of California requirements.
•Sump wrench, tubing, saddle valve, check
valve, ball valves, flow restrictor included.
•Complete installation instructions.
ROK2050
Note: For cold water use only. Do not install on hot water line. To insure
that the membrane is fuctioning properly, the product water must be tested
regularly.
Feed Water Requirements:
• Maximum TDS: 2,000 ppm • Maximum hydrogen sulfate:0
• Maximum Iron: 0.3 ppm • Maximum manganese: 0.05 ppm
• Maximum hardness: 12 gpg • Pressure: 30-100 psi (min/max)
• Temperture: 45-100°F • pH: 4-10
Aluminum 96-98%
Ammonium 80-90%
Borate 30-50%
Boron 50-70%
Bromide 90-95%
Cadmium 93-97%
Calcium 93-98%
Chloride 92-95%
Chromate 85-95%
Copper 96-98%
Cyanide 85-95%
Fluoride 92-95%
Hardnes Ca & Mg 93-97%
Iron 96-98%
Lead 95-98%
Magnesium 93-98%
Manganese 96-98%
Mercury 94-97%
Nickel 96-98%
Nitrate 90-95%
Orthophosphate 96-98%
Phosphate 95-98%
Polyphosphate 96-98%
Potassium 92-96%
Radioactivity 93-97%
Silica 80-90%
Silicate 92-95%
Silver 93-96%
Sodium 92-98%
Sulfate 96-98%
Thiosulfate 96-98%
Zinc 96-98%
The Benefits (nominal ion rejection characteristics)*
• The above percent rejection is for reference only. Actual rejection will depend
heavily on the exact chemistry, temperture, pressure &TDS content of the feed
water
TM
1/15/12
4.10
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Economy Drinking Water Systems
Economy Drinking Water System Features:
• Pre-assembled, easy to install.
• Complete with all installation accessories and instructions.
• Carbon and sediment filter cartridges sold separately.
• Select the appropriate carbon cartridge to reduce taste and odor, chlorine,
giardia, cryptosporidium, VOC’s, lead and mercury. See page 4.7 - 4.8 for full
selection of carbon filter cartridges to fit the specific need.
DWS Series Includes:
• NSF listed housings
• NSF listed John Guest fittings.
• NSF listed tubing.
• Lead free, long reach chrome faucets. Meets State of California requirements.
• WQA validated, 1800 gallon, patented automatic shut-off valve made from NSF
listed materials. (DWS-M Series only)
• White aluminum bracket with stainless steel mounting screws.
• Saddle valve.
• Carbon filter cartridges NOT included. See page 4.7-4.8 for a full selection.
Part No. Description List Price
DWS2 2 Stage system (no Auto shut-off) $ 174.93
DWS2M 2 Stage systrem w/ Auto shut-off 229.21
DWS3M 3 Stage system w/ Auto shut-off 263.39
DWS2
DWS2M
DWS3M
Series PFC PFGAC PFCEP PFCC PFCBC PFCBR2
Sediment 5 micron N/A 5 micron N/A 1 micron 0.5 micron
Taste & Odor Yes Yes Yes Yes Yes Yes
Chlorine Yes Yes Yes Yes Yes Yes
Cyst Reduction No No No No Yes Yes
Giardia & Cryptosporidium
VOC Reduction No No No Yes Yes Yes
Lead & Mercury No No No No No Yes
Available Carbon
Filter Cartridges
See page 4.13-14 for
description and list
prices.
TM 1/15/13
4.11
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Filter Housings
PFH38SLC
PFH75B
PFH38SLC5
Part No. Style Sump Head Inlet/Outlet Length Width Ctn Qty List Price
PFH38SLB5 Slimline Blue Black 3/8” NPT 7” 4 3/8” 12 $ 42.17
PFH38SLC5 Slimline Clear Blue 3/8” NPT 7” 4 3/8” 12 62.95
PFH38SLB Slimline Blue Black 3/8” NPT 11 3/4” 4 3/8” 12 31.26
PFH38SLC Slimline Clear Blue 3/8” NPT 11 3/4” 4 3/8” 12 46.88
Slim Line™ Housing Features:
• Ideal for a wide range of residential, commercial and industrial applications.
• 3/8” NPT inlet/outlet.
• Available in 5” and 10” lengths.
• Equipped with pressure relief button on the inlet side of the head.
• Available with either clear or opaque sump.
• Maximum operating pressure 125 PSI @ 125° F
Part No. Style Sump Head Inlet/Outlet Length Width Ctn Qty List Price
PFH75B Standard Blue Black 3/4” NPT 12 1/4” 5 1/8” 12 $ 55.41
PFH75C Standard Clear Black 3/4” NPT 12 1/4” 5 1/8” 12 76.71
PFH75B20 Standard Blue Black 3/4” NPT 22 3/8” 5 1/8” 8 100.22
Standard Housing Features:
• Ideal for a wide range of residential, commercial and industrial applications.
• 3/4” NPT inlet/outlet.
• Available in 10” and 20” lengths.
• Equipped with pressure relief button on the inlet side of the head.
• NPsuffix - no pressure relief button.
• Available with either clear or opaque sump.
• Maximum operating pressure 125 PSI @ 125° F
Styles:
• Standard
• Slim Line™
• Valve-in-Head
• High Temperature
• Big Blue®
Materials:
• Opaque - Reinforced Polypropylene
• Clear - FDA Styrene-Acrylonitrile (SAN)
Applications:
• Residential/Whole house,
Commercial/Industrial, Institutional, OEM
ISO 9001
TM
1/15/13
4.12
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Filter Housings
Part No. Style Sump Head Inlet/Outlet Length Width Ctn Qty List Price
PFH75VB VIH Blue Black w/ VIH 3/4” NPT 12 1/2” 5 1/8” 12 $ 98.19
PFH75VC VIH Clear Blue w/ VIH 3/4” NPT 12 1/2” 5 1/8” 12 105.69
PFH75VB20 VIH Blue Black w/ VIH 3/4” NPT 22 3/8” 5 1/8” 8 141.62
PFH75VB20
CPFHD10
PFH75HR
Part No. Style Sump Head Inlet/Outlet Length Width Ctn Qty List Price
CPFHD75 Big Blue® Blue Black 3/4” NPT 13 1/8” 7 1/4” 6 $ 88.84
CPFHD75BB Big Blue® Blue Black 3/4” NPT 23 3/8” 7 1/4” 4 125.58
CPFHD10 Big Blue® Blue Black 1” NPT 13 1/8” 7 1/4” 6 87.16
PFHD10 Big Blue® Blue Black 1” NPT 13 1/8” 7 1/4” 1 106.41
PFHD10HFP20 Big Blue® Blue Black 1” NPT 23 3/8” 7 1/4” 4 152.51
CPFHD15 Big Blue® Blue Black 1 1/2” NPT 13 5/8” 7 1/4” 6 95.36
PFHD15 Big Blue® Blue Black 1 1/2” NPT 13 5/8 7 1/4” 4 114.45
Valve-in-Head Housing Features:
• Valve-in-Head (VIH) feature closed both the inlet and outlet
ports simultaneously with a half turn of the handle.
• Makes cartridge change outs quick and easy.
• Available in 5”, 10” and 20” lengths.
• Can be equipped with an optional pressure relief button
on the inlet side of the head.
• Available with either clear or opaque sump.
• Maximum operating pressure 125 PSI @ 125° F
Big Blue® Large Diameter Housing Features:
• Large capacity housing designed for whole house and high-flow applications.
• Available with 3/4”, 1” or 1 1/2” NPT inlet/outlet.
• Available in 10” and 20” lengths.
• Equipped with a pressure relief button on the inlet side of the head.
• Accepts large capacity 4 1/2” diameter cartridges.
• Maximum operating pressure 100PSI @ 100° F
• PFHD10 and PFHD15 packed in white box with a spanner wrench.
• Bulk packed without spanner wrench
Part No. Style Sump Head Inlet/Outlet Length Width Ctn Qty List Price
PFH75HR High Temp Black Black 3/4” NPT 12 1/8” 5 1/8” 12 $ 265.16
High Temperature Housing Features:
• Low cost alternative to stainless and carbon steel housings.
• Durable glass reinforced nylon construction.
• Available with 1/2” and 3/4” NPT inlet/outlet
• Maximum temperature rating of 160°F.
• Maximum operating pressure 125 PSI.
ISO 9001
4/2009
4.13
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Filter Cartridges
Cartridge Selection Guide
Series PFC PFGAC PFCEP PFCBC PFCBR2
Sediment 5 micron N/A 5 micron 1 micron 0.5 micron
Taste & Odor Yes Yes Yes Yes Yes
Chlorine Yes Yes Yes Yes Yes
Cyst Reduction No No No Yes Yes
Giardia & Cryptosporidium
VOC Reduction No No No Yes Yes
Lead & Mercury No No No No Yes
Avail for Big Blue No Yes Yes Yes No
Est Filter Life 6 mo. 12 mo. 12 mo. 12 mo. 12 mo.
TASTE/ODOR &
SEDIMENT
Series PFWP PFS PFR PFP PFPD
Micron Rating 5, 25, 50 20 30, 50 1, 5, 25 1, 5,25
Avail Lengths 10” 10” & 20” 10” 10” & 20” 10” & 20”
Construction Style String Wound Pleated Pleated Spun Therm Bonded
Medium Polypropylene Cellulose Polyester Polypropylene Polypropylene
Filtration Style Depth Surface Surface Depth Depth
Applications Chlorinated & Chlorinated Chlorinated & Chlorinated & Chlorinated &
Non-Chlorinated Non-Chlorinated Non-Chlorinated Non-Chlorinated
Avail for Big Blue Yes Yes Yes No No
SEDIMENT
ISO 9001
TM
1/15/13
4.14
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Filter Cartridges
Sediment Cartridges:
• String wound
• Pleated cellulose
• Pleated polyester
• Spun polypropylene
• Thermally Bonded polypropylene
PFWP & PFCW Series String Wound Polypropylene Cartridges
• Ideal for fine sediment reduction, including sand, silt , scale and rust.
• These cord wound cartridges are compatible with most acids, alkalies,
corrosive fluids & gases.
• Precise winding pattern ensures high efficiency rate and high dirt loading capacity.
• Core material: FDA Polypropylene
• Max temperture: 180° F
• General purpose filtration.
PFWP-BB Series String Wound Polypropylene Cartridges
• Constructed of fiberous polypropylene over polypropylene core.
Note: An antistatic agent has been used in the processing of the fiberous
polypropylene and may cause some foaming in water.
PFWPX-BB String Wound Fibrillated Polypropylene Cartridges
• Constructed of fibrillated polypropylene on a polypropylene core.
• For use when pressures require minimization of exactables and/or fiber migration.
PFWP
String
Wound
Part No. Medium Type of Micron GPM Length Ctn Qty List Price
Construction Opening
Standard Housings 2 3/8” diameter
PFWP1 Polypropylene Wound 1 5 9-7/8” 30 $ 4.96
PFWP5 Polypropylene Wound 5 5 9-7/8” 30 4.96
PFWP10 Polypropylene Wound 10 5 9-7/8” 30 4.96
PFWP20 Polypropylene Wound 20 5 9-7/8” 30 4.96
PFWP30 Polypropylene Wound 30 5 9-7/8” 30 4.96
PFWP50 Polypropylene Wound 50 5 9-7/8” 30 4.96
PFCWMF Polypropylene Wound med. fine 10 9 7/8” 24 8.46
PFCW50 Polypropylene Wound 50 10 9-7/8” 24 8.12
PFWP1-20 Polypropylene Wound 1 5 20” 30 11.98
PFWP5-20 Polypropylene Wound 5 5 20” 30 10.57
PFWP10-20 Polypropylene Wound 10 5 20” 30 10.57
PFWP20-20 Polypropylene Wound 20 5 20” 30 10.57
Large Diameter Housings 4 1/2” diameter
PFWP.5BB97P Polypropylene Wound 0.5 5 9-7/8” 9 23.04
PFWP1BB97P Polypropylene Wound 1 5 9-7/8” 9 23.04
PFWP5BB97P Polypropylene Wound 5 5 9-7/8” 9 23.04
PFWP10BB97P Polypropylene Wound 10 5 9-7/8” 9 23.04
PFWP20BB97P Polypropylene Wound 20 5 9-7/8” 9 23.04
PFWP30BB97P Polypropylene Wound 30 5 9-7/8” 9 23.04
PFWP50BB97P Polypropylene Wound 50 5 9-7/8” 9 23.04
PFWP.5BB20P Polypropylene Wound 0.5 5 20” 9 40.32
PFWP1BB20P Polypropylene Wound 1 5 20” 9 40.32
PFWP5BB20P Polypropylene Wound 5 5 20” 9 37.32
PFWP10BB20P Polypropylene Wound 10 5 20” 9 37.32
PFWP20BB20P Polypropylene Wound 20 5 20” 9 37.32
PFWP25BB20P Polypropylene Wound 25 5 20” 9 37.32
PFWPX5BB97P Fibrillated Polypropylene Wound 5 10 9-7/8” 8 46.88
PFWPX10BB97P Fibrillated Polypropylene Wound 10 15 9-7/8” 8 44.92
PFWPX25BB97P Fibrillated Polypropylene Wound 25 20 9-7/8” 8 49.27
PFWPX50BB97P Fibrillated Polypropylene Wound 50 30 9-7/8” 8 42.46
PFWP-BB
String
Wound
PFWPX-BB
Fibrillated
String Wound Cartridges
ISO 9001
TM 1/15/13
4.15
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Filter Cartridges
PFS
PFR
PFCP
PFS Series Pleated Cellulose Cartridge
• Used for general water filtration purposes.
• This filter is comprised of four square feet of cellulose, providing
maximum suface area and strength to prolong cartridge life.
• End caps fused to body assure an integral sealing area and prevent by-pass.
• Nominal 20 micron rating.
Part No. Medium Type of Micron GPM Fits Length Ctn Qty List Price
Construct Opening Housing
PFS1 Cellulose Pleated 20 12 Standard 9-3/4” 24 $ 9.22
PFS1-20 Cellulose Pleated 20 15 Standard 20” 14 23.09
PFS1BB Cellulose Pleated 20 10 Big Blue 9-3/4” 8 29.55
PFS1-20BB Cellulose Pleated 20 12 Big Blue 20” 6 51.78
PFR Series Pleated Polyester Cartridges
• Excellent for water well, institutional and light industrial applications.
• Four square feet of media on standard and 20 square feet of media on BB
• Pleated polyester fabric filter can be washed and resued several times.†Reuse is not recommended
in potable water applications.
• Synthetic construction will not support bacteria growth.
• Available with nominal 30 and 50 micron ratings.
Part No. Medium Type of Micron GPM Fits Length Ctn Qty List Price
Construction Opening Housing
PFR30-478 Polyester Pleated 30 5 Compact 4-7/8 24 $ 19.07
PFR30 Polyester Pleated 30 12 Standard 9-3/4” 24 24.41
PFR50 Polyester Pleated 50 12 Standard 9-3/4” 24 21.17
PFR30BB Polyester Pleated 30 25 Big Blue 9 3/4” 8 38.13
PFR50BB Polyester Pleated 50 25 Big Blue 9 3/4” 8 36.02
PFCP Series Pleated Cellulose Polyester Cartridges
• 6 sq. feet of media on standard and 16 sq.ft. on BB provide additional surface area and
allow increased dirt holding capacity and low pressure drop
• Ideal for high flow applications.
• Cartridges are encapsulated in polyester outer sheath for added support.
Part No. Medium Type of Micron GPM Fits Length Ctn Qty List Price
Construction Opening Housing
PFCP1 Cellulose Polyester Pleated 1 15 Standard 9-3/4” 24 $ 15.62
PFCP5 Cellulose Polyester Pleated 5 15 Standard 9-3/4” 24 14.55
PFCP20 Cellulose Polyester Pleated 20 15 Standard 9-3/4” 24 14.25
PFCP5BB Cellulose/Poly Blend Pleated 5 30 Big Blue 9-3/4 8 34.00
ISO 9001
TM
1/15/13
4.16
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Filter Cartridges
PFPD Series Thermally Bonded Polypropylene Cartridge
•Manufactured from pure 100% polypropylene.
•98% efficient, more efficient than resin bonded cartridges.
•Thermal bonded micro-fiber construction.
•Withstands high temperature and pressure differentials.
•No fiber release, brittleness or growth/shrinkage due to climate conditions.
•Available in a wide range of micron ratings and lengths.
Part No. Medium Type of Micron GPM Fits Length Ctn Qty List Price
Constructions Opening Housing
PFPD-10 Polypropylene Therm Bonded 10 10 Standard 9-7/8” 24 $ 12.64
PFPD-5 Polypropylene Therm Bonded 5 10 Standard 9-7/8” 24 13.27
PFPD-25 Polypropylene Therm Bonded 25 10 Standard 9-7/8” 24 12.23
PFPD
PFP
PFP Series Spun Polypropylene Fiber Cartridges
• Excellent bacteria and chemical resistance.
• Manufactured from pure 100% polypropylene.
• Fibers are carefully spun to form a cartridge w/ variable density.
The density increases closer to core.
• Available in three different lengths and micron ratings
Part No. Medium Type of Micron GPM Fits Length Ctn Qty List Price
Construct Opening Housing
PFP5-478 Polypropylene Spun 5 5 Compact 4-7/8” 24 $ 8.31
PFP1 Polypropylene Spun 1 10 Standard 9-7/8” 24 11.10
PFP5 Polypropylene Spun 5 10 Standard 9-7/8” 24 9.70
PFP25 Polypropylene Spun 25 10 Standard 9-7/8” 24 9.70
PFP1-20 Polypropylene Spun 1 20 Standard 20” 20 23.15
PFP5-20 Polypropylene Spun 5 20 Standard 20” 20 18.44
PFP25-20 Polypropylene Spun 25 20 Standard 20” 20 18.90
ISO 9001
Part No. Medium Type of Micron GPM Fits Length Ctn Qty List Price
Construct Opening Housing
PFDGD2501-10 Polypropylene Spun Pre 25/Post 1 10 Big Blue 10” 8 $ 32.42
PFDGD2501-20 Polypropylene Spun Pre 25/Post 1 20 Big Blue 20” 6 59.45
PFDGD5005-10 Polypropylene Spun Pre 50/Post 5 10 Big Blue 10” 8 31.14
PFDGD5005-20 Polypropylene Spun Pre 50/Post 5 20 Big Blue 20” 6 57.60
PFDGD7525-10 Polypropylene Spun Pre 75/Post 25 10 Big Blue 10” 8 30.93
PFDGD7525-20 Polypropylene Spun Pre 75/Post 25 20 Big Blue 20” 6 56.81
PFDGD Spun Polypropylene Dual Gradient Cartridge
• Dual gradient filter included pre and post filtration reduce large and fine particles to enhance
cartridge performance.
• Eliminates need for multiple housing step-down systems
• Three times the dirt holding capacity
1/15/13
4.17
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Filter Cartridges
Part No. Medium Type of Micron Chlorine Fits Length Ctn Qty List Price
Construction Opening Reduction gal Housing
PFGAC5 Granular Carbon Canister 20 750 @ .5gpm Compact 4 7/8” 24 $ 24.85
PFGAC10 Granular Carbon Canister 20 5000 @ 1gpm Standard 9 7/8” 12 25.96
PFGAC20 Granular Carbon Canister 20 10000 @ 2gpm Standard 20” 6 57.35
PFGACBB Granular Carbon Canister 20 12500 @ 2gpm Big Blue 9 3/4” 8 66.64
PFGAC20BB Granular Carbon Canister 20 30000@ 4gpm Big Blue 20” 10 150.97
PFCC10 Granular Carbon Canister 20 7500 @ 1gpm Standard 9 3/4” 12 29.98
PFGAC
PFGAC Series Granular Activated Carbon (GAC) Cartridges
• Designed to reduce or eliminate unwanted tastes and odors such as chlorine.
• Water enters the filter from the bottom and travels through the entire charcoal bed before
exiting at the top. This filtration technique maximizes contact time with carbon to insure
maximum absorption.
• Internal expansion pad maintains a tight compact column to minimize channeling or
by-pass.
• Nominal 20 micron post filter reduces the content of carbon fines & suspended particles
PFCC Series Granular Activated Coconut Carbon Cartridges
• Coconut Shell based activated carbon to reduce organic chemicals like EDB, TCE & THM
plus chlorine.
• Nominal 20 micron post filter to reduce carbon fines and other particles.
PFCC
Taste/Odor/Sediment Cartridges:
•Carbon Impregnated
•Granular Activated Carbon (GAC)
•Carbon Block
PFC Series Carbon Impregnated Cellulose Cartridges
• Dual purpose cartridge provides taste/odor/chlorine reduction plus sediment filtration.
• A combination of carbon and cellulose creates a dual filter used for removing fine
particles and reducing unwanted tastes and odors occasionally found in tap water.
• Excellent “polishing” filter when used in process or closed loop systems.
• Design maximuzed dirt holding capacity.
PFC1
Part No. Medium Type of Micron Chlorine Fits Length Ctn Qty List Price
Construction Opening Reduction gal Housing
PFC2 Carbon/Cellulose Wrap 5 2500 @ 2 gpm Compact 4 3/4” 24 $ 15.33
PFC1 Carbon/Cellulose Wrap 5 5000 @1 gpm Standard 9 7/8” 24 15.25
PFC1-20 Carbon/Cellulose Wrap 5 10,000 @1 gpm Standard 20” 24 38.50
ISO 9001
TM
1/15/13
4.18
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Filter Cartridges
PFCBR
PFCEP Series Carbon Block Cartridges
• Designed for post RO applications.
• Minimizes chlorine and pH rise and produces low extractables.
• Acid washed coconut formulation
• Light brown end cap
PFCBC Series Carbon Block Cartridges
• Designed to reduce VOC’s, chlorine, color bodies, plus remove fine sediment from the
residual, commercial & industrial liquids. Filters giardia & cryptosporidium cysts from
potable water.
• High chemical adsorption provided by acid washed bituminous powdered, activated carbon
block.
• Sediment filter eliminates unwanted particles down to 0.5 nominal micron.
• Excellent polishing filter or prefilter.
PFCBR Series Carbon Block Multimedia Cartridge
• Removes both metals and chemicals with one cartridge.
• All purpose carbon block cartridge removes unpleasant tastes and odors plus greatly reduces
the amount of dissolved heavy metals and the taste of chlorine.
• Removes lead up to 96% and mercury up to 98%.
• Also removes up to 99% of giardia and cryptosporidium cysts and sediment particles down
to .5 micron in size.
Part No. Medium Type of Micron Chlorine Fits Length Ctn Qty List Price
Construction Opening Reduction gal Housing
PFCEP10 Acid washed Carbon Block 5 5000 @ 1 gpm Standard 9 3/4” 12 $ 33.23
PFCEP20E Acid washed Carbon Block 5 10000 @ 2 gpm Standard 20” 6 80.77
PFCEPBB20 Acid washed Carbon Block 10 32000 @ 4 gpm Big Blue 20” 6 137.59
PFCBC10 Acid washed Carbon Block 0.5 20000 @ 1 gpm Standard 9 3/4” 12 49.24
PFCBC20 Acid washed Carbon Block 0.5 45000 @ 1 gpm Standard 20” 12 71.21
PFCBCBB Acid washed Carbon Block 0.5 50000 @ 2 gpm Big Blue 9 3/4” 4 131.70
PFCBCBB20 Acid washed Carbon Block 0.5 150000 @ 4 gpm Big Blue 20” 6 262.79
PFCBR2-10 Acid washed Carbon Block 0.5 20000 @ 1 gpm Standard 9 3/4 12 62.80
PFCBC
PFCEP
ISO 9001
1/15/13
4.19
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Filter Cartridges
Specialty Cartridges
PFRFC Series Radial Flow Carbon Cartridges
• Radial flow carbon cartridge designed for gas and liquid filtration.
• Activated carbon bed and inner layers of polypropylene remove
particles over nominal 7 microns.
• Removes organic and particulate contaminates from plating, acid alkaline and hydrocarbon
solutions when used for liquid filtration.
PFRFC
Part No. Medium Type of Micron GPM Fits Length Ctn Qty List Price
Construction Opening Housing
PFRFC93 Carbon/Polypropylene Canister 7 1-3 Standard 9 3/4” 24 $ 58.01
PFRFCBB Carbon/Polypropylene Canister 7 3-10 Big Blue 9 3/4” 8 99.63
PFRFC20BB Carbon/Polypropylene Canister 7 5-15 Big Blue 20” 6 196.07
Part Number Description Casing Length Ctn Qty List Price
Ice Maker Carbon Filter
PFIC100 Granular Activated Carbon plastic 10 5/8” 6 $ 35.55
PFIC100
Sealed In-Line Cartridges
• Ideal for refrigerator icemakers and water dispensers, coffee makers and other 1/4” in-line
applications.
• Granular activated carbon removes chlorine, bad taste and odor from water.
• TS100 includes phosphate crystals for clear ice cubes and to prevent line/scale build-up.
• Connects easily to 1/4” copper or plastic cold water lines.
• Capacity of 2000 gallons, estimated life of 12 months.
ISO 9001
TM
1/15/13
4.20
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Filter Kits & Accessories
Part Number Description Ctn Qty List Price
PFC38BL Blue Head for 3/8” Housing 1 $ 23.88
PFC75BL Blue Head for 3/4” Housing 1 28.24
PF75CS Clear Sump for 3/4” Housing 1 70.17
PFBBS Big Blue Sump only 1 73.33
PFOR38 O-Ring for 3/8” Series 1 4.67
PFOR75 O-Ring for 3/4” Series 1 4.67
PFBBOR O-Ring for Big Blue 1 13.98
PFMB3814 Mounting Bracket for 3/8” 1 9.61
PFMB75 Mounting Bracket for 3/4” - U Shaped 1 14.17
PFMC1 Mounting Bracket for 3/4” caps w/ Bosses 1 14.90
PFWBBS Mount Bracket for 1-1 1/2”Big Blue, Stainless, 1 89.71
PFCC Standard Cartridge Coupler 1 3.87
PFCCBB Large Diameter Cartridge Coupler 1 5.64
Housing Wrenches
PFSW1 3/8” Black Wrench for Slimline Housing 1 10.55
PFSW2 3/4” Black Wrench for Standard Housing 1 10.55
PFSW3 Black Wrench for Large Diameter Housing 1 15.91
“PF” Series Housing Replacement Parts:
Including replacement heads, sumps, o-rings, mounting brackets and wrenches.
Part Number Size Sump Cartridge List Price
Housing & Cartridge Combination Kits
PFH75C-S1 3/4" standard transparent general purpose/sediment $ 95.26
PFH75C-C1 3/4" standard transparent taste/odor/sediment 102.08
Housing & Cartridge Combination Kit Features:
• Each kit contains one complete housing, one cartridge
and installation sheet.
PFWBBS
PFMC1
PFSW
PFMB75
ISO 9001
4/2009
4.45
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Ultraviolet Disinfection Systems
SAFE LITE Economy Series UV Disinfection System
Features:
• Quick installation.
• Economical.
• 304 stainless steel chamber. Electropolished.
• Powered by wall mounted ballast with lamp on indicator.
• 8 gallon complete with flow control.
Standard Series UV Disinfection System Features:
UV Series:
• Constructed for wall mounting.
• 304 stainless steel chamber. Electropolished.
• Sight port to safely view operation.
• 7 & 15 gallon complete with flow control.
• CSA approved.
UV-W Series:
• Same as UV series with:
• Internal wiper unit for manual cleaning of quartz sleeve.
• 8 & 15 gallon complete with flow control.
UV-SE Series:
• Same as UV series with:
• 7 & 15 gallon complete with flow control. Remote flow
control adder for 24 gallon (not included)
• Electronic built-in “lamp-out” circuit/alarm.
• ON/OFF indicator light.
• Standard auxillary output terminal for optional solenoid
shut-off (UVS077 not included).
• CSA pending
• Completely automatic.
• Compact and easy to install.
• No chemicals required.
• Low operating costs.
• Low maintenance.
• No taste or odor.
UVSL Series
UV, UV-SE &
UV-W Series
Ultraviolet disinfection is an effective way to pro-
vide bacteria free water for home or industry.
TM
1/15/13
4.46
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Ultraviolet Disinfection Systems
Part Max # of KW @ AMPS @ Pipe Dimensions Flow Lamp Out List
Number GPM Lamps 120V 120V 220V Size LxWxD Weight Control Alarm Price
Safe Lite Economy Series
UVSL8 8 1 0.07 .60 .30 3/4” MIP 18”x4”x7” 28 Yes No $ 901.64
Standard Series
UV7 7 1 0.07 .60 .30 3/4” MIP 18”x4”x7” 19 Yes No 1042.15
UV15 15 1 0.07 .60 .30 3/4” MIP 36”x4”x7” 28 Yes No 1280.37
Standard Series w/ Lamp out alarm
UV7SE 7 1 0.07 .60 .30 3/4” MIP 18”x4”x7” 19 Yes Yes 1108.78
UV15SE 15 1 0.07 .60 .30 3/4” MIP 36”x4”x7” 28 Yes Yes 1353.95
Lamp out circuit board provides a visual and audible alarm when a lamp outage occurs.
Solenoid protection can be added via the on-board relay and the purchase of an UVS077 Solenoid.
220V 50Hz less power cord net adder $ 35.72. Not available on SE series.
Non standard porting net adder $ 75.00
Water entering the disinfection
unit flows in the space between
the quartz sleeve and the cham-
ber wall. Turbulent flow through
the unit insures exposure of
micro-organisms to lethal
dosages of ultraviolet rays.
Water exiting the chamber is
safe and ready to use.
Typical Installation
1/15/13
4.49
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Chemical Feed Pumps - CHEMTECH
CHEM-TECH Series 100 Features:
• Positive displacement diaphragm metering
pump.
• Feed ranges of 15 and 30 gallons per day.
• Operating pressure up to 100 PSI.
• Life-time lubricated, sealed and self-maintaining gear train.
• Four ball valve design for trouble-free operation.
• Strong chemical resistant, flame retardant housing.
• Metal reinforced, short-stroke diaphragm for extra-long life.
• Injection back pressure valve assembly enables injection at an angle and
inhibits syphoning.
• Fully adjustable output capacity over operating range.
• Bleed valve assembly aids in priming and relieves pressure from discharge.
• UL, CSA approved for outdoor and indoor applications.
• Manufactured for AGI in an ISO9002 facility.
CHEM-TECH Series 200 Features:
• Heavy duty diaphragm feed pump allows for continuous operation.
• Feed ranges of 15 and 30 gallons per day.
• Operating pressure up to 125 PSI.
• High torque motor-gear coupling ensures start-up un maximum pressure.
• Strong fiber core casing & corrosion resistant rubber & plastic components.
• Metal reinforced, short-stroke diaphragm for extra-long life.
• Oil immersed gear train and heavy duty, fan cooled motor with thermal over
load protection.
• All wetted components including diaphragm are interchangable between all
Series 200 models.
• Bleed valve assembly aids in priming and relieves pressure from discharge.
• UL, CSA approved for outdoor and indoor applications.
• Manufactured for AGI in an ISO9002 facility.
CHEM-TECH Motorized Models:
Includes tubing and suction & discharge fittings
Max Output capacity OD
Pressure @ Max psi Strokes/ Tube
Part Number Series PSI GPD Volts Min. Size Ctn Qty List Price
015-115 100 100 15 115 25 1/2” 1 $ 740.28
015-230 100 100 15 230 25 1/2” 1 777.51
030-115 100 100 30 115 51 1/2” 1 740.28
030-230 100 100 30 230 51 1/2” 1 777.51
230-115 200 125 30 115 44 1/2” 1 1571.18
230-230 200 125 30 230 44 1/2” 1 1595.41
260-115 200 125 60 115 88 1/2” 1 1670.78
Additional ChemTech models are available, please contact your sales representative.
Chem Tech Series 100
Chem Tech Series 200
ISO 9002
Materials of Construction:
Pump Head SAN
Diaphragm Hypalon
Valve Seats Hypalon
Gaskets Teflon
Disch. Tubing Polyethylene
Suct. Tubing Flexible PVC
Ball Checks Ceramic
Fittings PVC
TM
1/15/13
4.50
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Chemical Feed Pumps - CHEMTECH Parts
Chem Tech Series 100 Chem Tech Series 200
ISO 9002
Stocked KOP Kits for Repairs: Keep-On-Pumping Kits
Part Number Series Fits Models Tubing Size List Price
KX030XAAAAAXXX 100&200 3-100 GPD 1/2” OD $ 248.48
Stocked* Parts for Series 100 and Series 200 CHEMTECH Pumps
NEW OLD
Part Number Part Number Description List Price
25704 228P Hypalon Diaphragm $ 84.71
28800 242P SAN Head 89.03
28903 A51P Head Assembly 192.57
38981 682P Coupling Spring 10.88
41624 A53P Anti Siphon valve assembly, 1/2” OD 157.65
J20560 278P Ceramic Ball Check 10.55
J24960 240P 1/2” OD Standard CPLG nut 10.55
J26907 A54P PVC Bulk Head Fitting, 1/2” OD, BFH not installed 98.32
J26908 A54Q 3/8” OD BFH not installed 98.32
J27903 237P Teflon Gasket 11.15
J30515 J30515 PVC Bleed Valve Kit w/Tubing, 1/2” OD 137.44
J37440 638P Hypalon Valve Seat 6.71
J38985 285P Valve Spring 10.88
J40117 A50P Foot Valve and Strainer Assembly, 1/2” OD 87.56
J41540 244P Valve Housing Discharge, 1/2” OD 47.06
J41548 247P Valve Housing, Suction, 1/2” OD 47.06
J41658 A52P PVC Back Check Valve Assembly, 1/2” OD 99.65
J41694 J41694 1 1/2” long PVC Injection Ftg 1/2” OD tube size 140.53
J61516 J61516 Head Mounting Bolts, S.S. 10 x 24 (4 included) with washers 23.56
* Other Series 100 & 200 parts may be ordered. Contact your sales representative.
KOP Kit® for Series 100 & Series 200 CHEMTECH Pumps Feature:
• Designed to guard against unnecessary down time.
• Kop Kit contains recommended spare parts most likely to require normal
maintenance.
• Contains valve cartridges with o-rings, head, diaphragm, secondary o-ring seal,
head screen, & washers.
• Carded and shrink wrapped for display.
Kop Kit®
1/15/13
4.51
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Chemical Feed Pumps - PULSATRON
PULSATRON Stocked Electronic Models Suction &
Pressure Max Discharge
Part Number Series PSI GPD Voltage Tube OD List Price
LC54SA-VHC1-XXX C 80 30 115 3/8” $ 801.89
LD54SA-VHC1-xxx C Plus 80 30 115 3/8” 959.37
LD54SA-VHCA-xxx C Plus 80 30 115 1/2” 959.37
LD54SB-VHCA-xxx C Plus 80 30 230 1/2” 940.99
* Additional Pulsatron models are available. Contact your sales representative.
PULSATRON “C” Series Electronic Metering Pump
Features:
• Solenoid driven assembly - no motors.
• Reliable metering performance.
• Rated “hot” for continuous use.
• High viscosity capable up to 1000 cps.
• Leak free, sealless liquid end.
• Diaphragms are teflon-faced, bonded to a composite of Hypalon & fabric
layers and reinforced with a metal insert.
• Manual control by on-line adjustable stroke length (fixed stroke length.)
• Agency approved for outdoor and indoor use.
• Water resistant for outdoor applications.
• Highly reliable timing circuit.
• Guided ball check valve system to reduce back flow and enhance oustanding
running characteristics.
• Premium stnadard wetted component material.
• Few moving parts, wall mountable.
• Safe and easy priming with durable leak-free bleed valve assembly.
• Max pressure rating: 80 psi.
• Maximum 30 gallons per day.
PULSATRON “C PLUS” Series Electronic Metering Pump Features:
• Same as above plus:
• Manual control by on-line adjustable stroke length and stroke rate.
• Manufactured for AGI in a ISO 9002 facility.
ISO 9002
C Plus Series
Materials of Construction:
Pump Head PVC
Diaphragm Teflon faced,
Hypalon backed
Valve Seats/ Hypalon
O-rings
Tubing Clear PVC
Ball Checks Ceramic
Fittings PVC
TM
1/15/13
4.52
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Chemical Feed Pumps - PULSATRON Parts
Stocked K.O.P. Kits for Repairs: Keep-On-Pumping Kits
NEW Suction Disch.
Part Number Series Fits Models Tubing Size List Price
K4VHC1 C 30 GPD 3/8” OD $ 211.72
K3VHC1 C Plus 12 GPD 3/8” OD 190.94
K3VHCA C Plus 12 GPD 1/2” OD 190.94
K4VHC1 C Plus 30 GPD 3/8” OD 211.72
K4VHCA C Plus 30 GPD 1/2” OD 211.72
ISO 9002
KOP Kit® for PULSATRON Series Pumps Feature:
• Designed to guard against unnecessary down time.
• Kop Kit contains recommended spare parts most likely to require normal
maintenance.
• Contains valve cartridges with o-rings, head, diaphragm, secondary o-ring seal,,
head screen, & washers.
• Carded and shrink wrapped for display.
Stocked* Parts for PULSATRON C and C Plus Series Pumps
Part Number Description List Price
L9906202-00 Replacement C+ Circuit board, 230V $ 258.91
L3300H01-PVC 3/8” OD Bleed Valve Assembly 126.82
L3300H03-PVC 1/2” OD Bleed Valve Assembly 126.82
L3101HC1-PVC 3/8” OD C+ Suction valve 58.49
L3101HCA-PVC 1/2” OD Suction Valve 58.49
L3201HC1-PVC 3/8” OD C+ Discharge Valve 58.49
L3201HCA-PVC 1/2” OD C+ Discharge valve 58.49
* Other Series C and C Plus parts may be ordered. Contact your sales representative.
C Plus Series
Kop Kit®
CHEM-TECH XP Series Peristaltic Pump Features:
• Peristaltic technology delivers worry-free dosing, easy
operations and minimal maintenance.
• Include adjustable, on/off with current interrupter timer.
• All metal drive gears and gear train. Metal gear housing.
• 3 piece roller design.
• Self priming.
• 115 V, 60 Hz
XP Series
Max
Part Number PSI GPD RPM Ctn Qty List Price
XP015LAHX 100 15 30 1 $ 977.21
XP030LAHX 100 30 30 1 977.21
Additional models are available with or without complete tank system.
1/15/13
4.53
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Chemical Feed Pumps - Accessories
Part Number Description O-rings Valve Body Connection List Price
L385KH03-PVD DG/5VF De-Gas Valve Hypalon PVD 1/2” OD tubing $ 389.50
L385KV03-PVD DG/5FV De-Gas Valve Viton PVD 1/2” OD tubing 387.15
L385 Series
Materials of Construction:
Valve Body PVD
Diaphragm Teflon faced
Hypalon
O-rings Viton or Hypalon
Hardware 188 Stainless
steel (recessed)
Specifications:
Maximum Flow 240 gpd
Minimum Flow 3 gpd
Max Viscosity 1000 cps
Max Pressure Up to 250 psi
Operation:
• The functions are selected by setting two,
independent dual position selector knobs.
• The DG/5FV’ s compatible with most PUL-
SATRON and CHEMTECH series pumps.
Connected to the existing discharge valve the
DG/5FV is capable of handling a large output
flow as well as viscous liquids. A return port
located on the side body provides flow of chemi-
cal back to the solution tank when in the degas,
air bleed or drain discharge mode.
• Degas/bypass volume is adjustable, typically 1-
10% of pump output.
DG/5FV De-gas Five Function Valve Features:
• De-Gas - Bypass gasses and fluid during normal pump operation.
Allows for the constant removal of gases that would otherwise “air bind” the pump.
• Back Pressure - Maintains output reproducibility and allows metering into
atmospheric discharge.
• Anti-siphon - Prevents siphoning through the pump when point of injection is
lower than the pump or into the suction line of another pump. Rated at total vacuum.
• Air Bleed - Used during priming to manually remove air from the pump head.
• Discharge Drain - Depressurize pump discharge line without loosening tubing or
fittings. Protects the operator from chemical exposure.
Flow Meter Features:
• Economical, easy to install, easy to maintain.
• Calibrated in GPM/LPM with easy-to-read numbering.
• Available 1”- 4” pipe size.
• Durable acrylic construction.
• Supplied with 2 clamps and rubber gasket seal.
• Maximum temperature limit = 120°F, Maximum pressure limit = 120 psi.
U88 Series
Part Number Nominal Pipe Size Range GPM/LPM List Price
U8800424 1” 5-35 / 20-130 $ 141.18
U8800438 1 1/4” 10-60 / 40-220 141.18
U8800439 1 1/2” 20-80 / 80-300 141.18
U8800440 2” 30-140 / 120-550 141.18
U8800441 2 1/2” 40-200 / 160-750 141.18
U8800442 3” 80-350 / 300-1300 141.18
U8800443 4” 150-600 / 600-2200 141.18
ISO 9002
TM
1/15/13
4.54
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Chemical Feed Pumps - Accessories
Part Number Description List Price
J40442 15 Gallon TSF for Series 100 with 1/2” OD tubing $ 398.34
J40444 15 Gallon TSF for Pulsatron with 1/2” OD tubing 398.34
ISO 9002
TFS System Features:
• For use with PULSATRON pumps.
• Plastic base
• 15 gallon solution tank
• 2 bulkhead fittings
• Liquid level indication
Part Number Description List Price
40375 15 Gallon liner with cover 25” x 14 1/2” $ 199.94
40360 30 Gallon liner with cover 32” x 18 1/2” Brine Tank 251.37
J40366 55 Gallon liner with rigid cover 42 1/2” x 18 1/2” (b) 23 (t) 468.68
26859 1/2” Bulk Head Fitting (BHF) installed at factory 44.81
26860 3/8” Bulk Head Fitting (BHF) installed at factory 44.81
TFS System
Integrated Tank System (ITS) Features:
• Completely integrated system molded polyethylene
• 15 gallon capacity
• Translucent with 5 gallon increment marks.
• Low level indicator allows visual monitoring without opening tank.
• Child proof lid
• Flooded suction - No loss of prime.
• Universal pump mount.
• Built-in grip for easy lifting.
• Optional PVC shut-off valve.
• PUMP NOT INCLUDED.
ITS System
Part Number Description Dim. “A” List Price
39320 15 Gallon with pump mounting shelf 14.13” $ 265.77
39322 30-40 Gallon with pump mounting shelf 18.63” 300.53
39321 55 Gallon with pump mounting shelf 18.13” 356.01
Solution Tank Stand for CHEMTECH Series Features:
• Tri-pod stand with pump mounting shelf.
• 12 gauge, 304 stainless steel.
Solution Tank Features:
• High density polyethylene
• 5 gallon marked increments.
• Add “BHF” to part number for factory installed bulkhead fittings.
Solution Tanks
Part Number Description List Price
J40490 15 Gallon ITS w/ 1/2” PVC bulkhead for CHEMTECH 100 $ 565.29
J40493 15 Gallon ITS w/ 1/2” PVC bulkhead for PULSATRON 565.29
2/15/11
5.3
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Sump Pump Discharge Kits
SPDK Sump Pump Discharge Kits Feature:
• 24 ft of heavy duty corrugated polyethylene tubing, with 8' cutting intervals.
• 1-1/4" or 1 1/2" full size plastic male adapter with stainless steel clamp.
• Individually packaged with instructions included.
Part List
Number Description Ctn Qty Price
SPDK125M Male adapter to fit 1-1/4" FIPT pump discharge 8 $ 16.62
SPDK150M Reducing male adapter (1 1/2" mip x 1-1/4" ins) to fit 8 17.36
1-1/2" FIPT pump discharge with 1 1/4" sump hose
SPDK150MHD Male adapter to fit 1 1/2" FIPT pump discharge 6 25.12
w/ 1 1/2” sump hose
SPDH125-300 1 1/4” bulk hose, 300’ 1 183.02
SPDH150-150 1 1/2” bulk hose, 150’ 1 168.54
SPDK Series
1/15/13
5.4
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
SS&E Check Valves
2200 Series Checkmate Features:
• One piece ball/check valve combination.
• Save time, labor and hassle to applications requiring in-line ball
valves and check valves.
• True union or compression design allows for
removal of check valve for cleaning or repairs.
• Rates at 125 psi. May be installed in vertical
or horizontal position.
• Made of PVC type 1 grade 1 material meeting
ASTM-D1784.
2200 Series
Part Number Description Ctn Qty List Price
2200-15 1 1/2” Union x Slip 12 $ 50.48
2200-20 2” Union x Slip 12 78.86
2200-15TU 1 1/2” Union x Union 12 66.87
2200-20TU 2” Union x Union 12 88.69
2200-15UC 1 1/2” Compression x Compression 12 61.06
2200-20UC 2” Compression x Compression 12 84.29
“Smart” Swing Check Valve Features:
• Patented innovation in swing check valve technology
eliminates in-line flow restriction of conventional
check valves.
• Spring loaded swing check flapper/gate allows full
flow and reliable back flow prevention.
• Standard “smart” check valve remains closed to 1/2 psi,
then open for full flow.
• Magnetic “smart” check valves remain closed to 2 psi,
then open for full flow.
Part Number Size Description Spring Tension Ctn Qty List Price
MCV821-10 1” Slip x Slip 1/2 lb. 12 $ 21.20
MCV821-10C 1” Slip x Slip CLEAR 1/2 lb. 12 24.16
MCV821-15 1 1/2” Slip x Slip 1/2 lb. 12 31.96
MCV821-15C 1 1/2” Slip x Slip CLEAR 1/2 lb. 12 35.24
MCV821-20 2” Slip x Slip 1/2 lb. 12 37.58
MCV821-20C 2” Slip x Slip CLEAR 1/2 lb. 12 40.52
MCV821-20M 2” Slip x Slip w/magnet 2 lb. 12 41.03
MCV821-20MC 2” Slip x Slip w/magnet CLEAR 2 lb. 12 43.77
MCV823-10 1” Union x Union 1/2 lb. 12 31.96
MCV823-10C 1” Union x Union CLEAR 1/2 lb. 12 35.24
MCV823-15 1 1/2” Union x Union 1/2 lb. 12 50.03
MCV823-15C 1 1/2” Union x Union CLEAR 1/2 lb. 12 53.87
MCV823-20 2” Union x Union 1/2 lb. 12 54.40
MCV823-20C 2” Union x Union CLEAR 1/2 lb. 12 57.38
MCV823-20M 2” Union x Union w/magnet 2 lb. 12 57.38
MCV823-20MC 2” Union x Union w/magnet CLEAR 2 lb. 12 60.92
MCV850-15 1 1/2” Check/Slice Combo Union x Slip 12 55.70
MCV850-20 2” Check/Slice Combo Union x Slip 12 80.88
MCV Series
MCV821 Series
MCV823 Series
MCV850 Series
12/13/11
6.1
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Compression Couplings-Imported, PVC/CPVC
MATERIAL SPECIFICATIONS
# Part Material
1 Body UPVC, CPVC
2 Compression Nut UPVC, CPVC
3 Gasket - PVC NR
Gasket - CPVC EPDM
Part Number Material Size Case Qty List Price
PC10-1/2 PVC 1/2” IPS 100 $ 2.56
PC10-3/4 PVC 3/4” IPS 90 2.97
PC10-1 PVC 1” IPS 60 3.84
PC10-11/4 PVC 1 1/4” IPS 40 4.62
PC10-11/2 PVC 1 1/2” IPS 30 6.37
PC10-2 PVC 2” IPS 20 8.87
PC10-21/2 PVC 2 1/2” IPS 10 20.26
PC10-3 PVC 3” IPS 4 28.67
PC10-4 PVC 4” IPS 2 37.83
PC10-6 PVC 6” IPS 2 91.00
HW10CTS1/2 CPVC 1/2” CTS 20/360 4.48
HW10CTS3/4 CPVC 3/4” CTS 20/240 5.42
PVC Compressing Coupling Features:
• Iron Pipe Size (PVC), Copper Tube Size (CPVC)
• For use with cold water (PVC) or hot water (CPVC-CTS)
• Natural rubber gasket seals
• Rated at 200 psi at 70°F
• Imported
"PC" Series IPS DIMENSIONS (IN.)
SIZE D d d1 L
1/2” 1.85 .91 .83 5.24
3/4” 2.09 1.18 1.04 5.32
1” 2.40 1.42 1.31 5.75
1 1/4” 2.87 1.81 1.65 6.30
1 1/2” 3.15 2.05 1.89 6.89
2” 3.62 2.56 2.37 7.87
2 1/2” 4.53 2.52 2.87 9.92
3” 5.28 3.62 3.49 10.87
4” 6.34 4.65 4.49 11.93
6” 8.78 6.85 6.62 11.22
"HW" Series CTS DIMENSIONS (IN.)
1/2” 1.30 .71 .63 4.49
3/4” 1.85 .95 .88 5.00
For Use with
Part Number Coupling Sizes Ctn Qty List Price
Adjustable Strap Wrench
SW400 1/2” through 4” 10/60 $ 19.47
SW600 1/2” through 6” 10/60 22.05
SW Series
1/15/13
6.2
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Compression Fittings, Galvanized
Recommended Maximum Pressure
(PSI)
Size Torque Anchored
Ft. Lbs Piping
1/2” 150 150
3/4” 150 150
1” 225 100
1-1/4” 225 100
1-1/2” 225 100
2” 300 75
Coupling GC10 - Made in U.S.A. - Steel Tube
Part Number Size Pipe O.D. Ctn Qty List Price
GC10-1/2 1/2” .840 12 $ 28.23
GC10-3/4 3/4” 1.050 12 30.78
GC10-1 1” 1.315 12 36.34
GC10-11/4 1-1/4” 1.660 6 48.53
GC10-11/2 1-1/2” 1.900 6 53.60
GC10-2 2” 2.375 6 67.36
Coupling GC10C - Long Pattern - Imported - Malleable Iron, 125 PSI, 120° F
Part Number Size Pipe O.D. Ctn/Case Qty List Price
GC10C1/2 1/2” .840 30 / 60 $ 11.89
GC10C3/4 3/4” 1.050 25 / 50 13.33
GC10C1 1” 1.315 15 / 30 15.65
GC10C11/4 1-1/4” 1.660 12 / 24 19.86
GC10C11/2 1-1/2” 1.900 9 / 18 23.54
GC10C2 2” 2.375 14 35.21
Adapters GC12 - Made in U.S.A. - Steel Tube
Part Number Size Pipe O.D. Ctn Qty List Price
GC12-1/2 1/2” .840 12 $ 39.75
GC12-3/4 3/4” 1.050 12 41.61
GC12-1 1” 1.315 12 42.14
GC12-11/4 1-1/4” 1.660 6 50.09
GC12-11/2 1-1/2” 1.900 6 69.65
GC12-2 2” 2.375 6 69.78
Galvanized Long Pattern Compressing Fitting Features:
• Bodies made of steel tubing. (GC 10), malleable iron (GC10C)
• End nuts made of malleable iron.
• Galvanized finish
• Buna-N gaskets on domestic fittings.
• SBR gaskets on GC10C series.
• Maximum rated service temperature for gaskets: 212°F (100º C).
WARNING: Designer and/or contractor must provide suitable anchoring
of piping to prevent pull-out from fittings when applications subject piping
to external forces such as ground shift and temperature variations that
cause linear pipe contraction.
GC10C Series
GC10 Series
GC12 Series
ISO 9002
1/15/13
6.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Tanks - Thermal Expansion
THERM-X-SPAN™
Hot Water Heater Safety Expansion Tank
THERM-X-SPAN™ tanks are diaphragm-type, pre-pressur-
ized expansion tanks specifically designed for use with
domestic hot water heaters. They act as a safety tank to
accept the increased volume of water created when a
water storage tank is heated, therefore keeping the system
below the relief valve setting. These tanks are recom-
mended in areas where a backflow preventer, check valve
or pressure reducing valve is used, creating a closed sys-
tem.
Features and Benefits:
• Eliminates relief valve spillage
• Controls pressure build-up
• Protects plumbing fixtures
• Smothers water hammer
• Extends water heater life
• Eliminates hot water waste
Specifications:
• Steel shell
• Polypropylene liner, butyl diaphragm
• Brass system connection on G5 and G12
• Stainless steel connection on ST25V, ST30V and ST42V
• 200° F maximum operating temperature
• 150 PSI maximum working pressure
• 40 PSI factory precharge
Part Tank System Dimensions
Number Configuration Volume Connection Diameter Height Weight List Price
G5 IN-LINE 2 gal 3/4” NPTM 8” 12 5/8” 5 lbs. $ 135.57
G12 IN-LINE 4.4 gal 3/4” NPTM 11” 15” 9 lbs. 181.90
ST25V STAND 10.3 gal 1” NPTF 15 3/8” 19 1/4” 23 lbs. 514.56
ST30V STAND 14.0 gal 1” NPTF 15 3/8” 23 7/8” 25 lbs. 630.43
IAPMO
City of Los
Angeles
Approved
ANSI/NSF 61
1/15/13
6.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Air Purgers, Vents, Water Hammer Arrestors
Air Purger Features:
• Reliable and continuous air separation with maintenance free operation.
• Designed using a double water passage way with internal contours and baffles.
• Efficiently separates air from water sending it to the vent for removal.
• In-line unit –– one piece cast iron construction.
• Individually packaged.
Float Type Air Vent Features:
• Designed to be installed at the hydronic system high points on
heaters and baseboard convectors directly on top of the air purger.
• Improves system efficiency.
• Compact size to fit the smallest spaces.
• Rugged cast bronze body construction for durability.
• Industry proven servicable design with take-apart feature.
• Individually packaged.
Mini Trol® Water Hammer Arrestor Features:
• Intercepts surges in water lines, preventing damage and annoying shock waves
set in motion by quick closing valves.
• Polypropylene liner and diaphragm totally separates water from body.
• Guaranteed not to waterlog or lose air.
Air Vent
Part Number Maximum PSI Maximum Temp Connection Ctn Qty List Price
700-C 150 PSI 230 oF (110 oF) 1/8 MPS (NPTM) 1 $ 22.46
Mini Trol®
Part Number Description Connection Ctn Qty List Price
500 Mini Trol 1/2 Male 24 $ 86.32
Air Purger
Part Number Pipe Size Dimensions(Ins.) Tank Vent Ctn Qty List Price
“L” “W” “H” Conn Conn
443-1 1” 6 2-1/2 4 1/2 FIPT 1/8 FPS 1$ 49.29
444-11/4 1-1/4” 6 2-1/2 4 1/2 fipt 1/8 fps 1 50.79
445-11/2 1-1/2” 8 3-1/2 5 1/2 fipt 1/8 fps 1 108.55
446-2 2” 8 3-1/2 5 1/2 fipt 1/2 fps 1 123.76
700-C
443
500
1/15/13
6.21
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Trap Wrap ™
Trap Wrap™ brand insulation kits
offer an economical way to profes-
sionally insulate exposed undersink piping.
Integrally molded fasteners press together
to provide an easy, seamless, retrofit installation.
Trap Wrap™ Features:
• Press-snap™ fasteners.
• Molded-in measurements.
• A.D.A. compliant.
• China White in color.
• Removable for service.
• Completely covers pipes and supplies.
• Sanitary surface.
• 2 piece P-trap assembly, 1 piece angle valve.
• Patented.
Satisfies the following requirements:
• A.D.A article 4.19.4
• A.N.S.I. A117.1
• California article P.1504B
• B.O.C.A. article P1203.4
Part Number Description Ctn Qty List Price
HC500R Standard Trap Wrap 15 $ 89.09
HC500RHS Trap Wrap with extra sink bend 15 119.54
TrapWrap is a trademark of Brocar Products, Inc.
Angle valve cover allows for easy
and quick emergency shut-off
without removing cover
HC500R Series
• Virtually seamless for enhanced appearance
• Reinstallable after service
• Highly tamper resistant
• Easily cleaned.
4/2009
6.22
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Trap Wrap ™
Formerly Brocar Products, Inc.
Includes all parts of
HC500R plus C500HS off-
set grid drain cover.
Includes 15” tail piece
and trap cover, 8” waste
arm insulation, fasteners,
and hot and cold angle
valve cover.
Sample Specification:
Wheelchair accessible lavatories and sinks shall be insu-
lated with TrueBro Trap Wrap™ Insulation Kit (indicate
model #, color and accessories). Trap assemblies shall
have vinyl insulating outer shell with concealed integral
fasteners for a virtually seamless finished installations.
Angle stop covers shall permit unrestricted access to
angle valves without removal of cover.
ASTM DATA
ASTM G21 Anti-Bacterial No measurable bacterial growth
ASTM G22 Anti-Fungal No measurable fungal growth
ASTM D635 Burning Characteristics Less then 5 sec (ATB) 10 MM (AEB)
ASTM C177 Thermal conductivity BTU - in/hr - ft2 -°F k value = 1.02
6/14/11
6.27
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Perforated Hanger Strapping
101 Series Galvanized Duct Tape
• 24 and 28 gauge
• Alternate 1/4” and 5/16” bolt and nail holes
• 3/4” width
102 Series Plastic Polypropylene Hanger Strapping
• 1/8” dia. holes
• Max working load - 15# @ 85° F
• Breaking Strength - 100# @ 68° F
100G Series Galvanized or Zinc Plated
• Perforated hanger strapping
• 20 to 28 gauge
• 1/4” bolt holes
• 3/4” width
Part Number Size Ctn Qty List Price
101 Series - Galvanized Duct Tape
101-10 3/4” x 10’ x 24 gauge 50 $ 2.57
101-50 3/4” x 50’ x 24 gauge 10 14.78
101-100 3/4” x 100’ x 24 gauge 5 28.60
101-10-28 3/4” x 10’ x 28 gauge 50 2.28
101-50-28 3/4” x 50’ x 28 gauge 10 13.56
101-100-28 3/4” x 100’ x 28 gauge 5 24.64
102 Series - Plastic Polypropylene
102-10 3/4” x 10' x .05 gauge BULK/100 2.42
102-25 3/4” x 25' x .05 gauge 1/40 4.71
102-50 3/4” x 50' x .05 gauge 1/20 12.59
102-100 3/4” x 100' x .05 gauge 1/10 22.50
100G Series - Galvanized or Zinc Plated
100G-10-24 3/4” x 10’ x 24 gauge 50 2.56
100G-50-24 3/4” x 50’ x 24 gauge 10 14.78
100G-100-24 3/4” x 100’ x 24 gauge 5 28.60
100G-10-28 3/4” x 10’ x 28 gauge 50 2.12
100G-10-22 3/4” x 10’ x 22 gauge 50 3.21
100G-50-22 3/4” x 50’ x 22 gauge 10 18.48
100G-100-22 3/4” x 100’ x 22 gauge 5 34.56
100G-10-20 3/4” x 10’ x 20 gauge 50 3.75
100G-50-20 3/4” x 50’ x 20 gauge 10 20.19
100G-100-20 3/4” x 100’ x 20 gauge 5 23.42
100S Series - Steel Plain
100S-10-24 3/4” x 10’ x 24 gauge 50 2.28
101 Series
100G and 100S Series
102 Series
1/15/13
6.28
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Clip & Van Hangers
604 Series Insulated Glide Clip Features:
• Specially compounded material wrapped around copper clad steel
permits smooth, silent pipe movement.
• Prevents electrolysis and corrosion.
• Resists temperature up to 280º F(137º C). Ideal for hot water heating or supply lines ––
eliminates creaking noises made by pipe expanding and contracting against wood
surfaces.
606 Series Van Hanger Features:
• Unique design for applications that require space between pipe and mounting surface.
• Copper clad steel, heavy duty metal construction.
608 Series Copper Tube Strap Features:
• Copper clad steel; heavy duty metal construction.
Part Number Size Mounting Hardware (incl) Ctn Qty List Price
Insulated Glide Clips
604-1/2 1/2” Copper Clad Nails 10 $ 3.79
604-3/4 3/4” Copper Clad Nails 10 4.08
604-1 1” Copper Clad Nails 10 5.11
604-11/4 1-1/4” Copper Clad Nails 10 5.76
Copper Clad Van Hangers
606-1/2 1/2” Copper Clad Screw 20 2.94
606-3/4 3/4” Copper Clad Screw 20 3.15
606-1 1” Copper Clad Screw 20 3.44
Copper Tube Straps
608-1/2 1/2” Copper Clad Nails 100 0.42
608-3/4 3/4” Copper Clad Nails 50 0.48
608-1 1” Copper Clad Nails 50 0.63
608-11/4 1-1/4” Copper Clad Nails 50 0.75
604 Series
606 Series
608 Series
1/15/13
6.37
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Strap & Tube Hangers
601 Series American Tube Hanger Features:
• Designed to utilize scrap 1/2” copper tube for extension.
• Packaged 10 sets (hanger clamp and tube brace).
• Copper clad wood mounting screws are included.
602 Series Insulated Strap Hanger Features:
• Specially compounded material prevents pipe noise from reaching the
floor joists.
• Copper clad steel with mounted machine screw and fiber washer.
• Copper clad nails are included.
Part Number Pipe Fits Extension Mounting Hardware Ctn Qty List Price
Diameter Tube Size Included
American Tube Hangers
601-1/2 1/2” 1/2” Wood Screws 10 $ 3.61
601-3/4 3/4” 1/2” Wood Screws 10 4.48
601-1 1” 1/2” Wood Screws 10 5.16
601-11/4 1-1/4” 1/2” Wood Screws 10 6.25
601-11/2 1-1/2” 1/2” Wood Screws 10 6.77
601-2 2” 1/2” Wood Screws 10 7.18
Insulated Strap Hangers Hanger Length
602-1/2x6 1/2” 6” Copper Clad Nails 25 5.30
602-1/2x12 1/2” 12” Copper Clad Nails 25 6.15
602-3/4x6 3/4” 6” Copper Clad Nails 25 5.41
602-3/4x12 3/4” 12” Copper Clad Nails 25 6.21
602-1x6 1” 6” Copper Clad Nails 25 5.55
602-1x12 1” 12” Copper Clad Nails 25 6.38
602-11/4x6 1-1/4” 6” Copper Clad Nails 25 5.73
602-11/4x12 1-1/4” 12” Copper Clad Nails 25 6.42
601 Series
602 Series
J-Hook Features:
• Made of high impact ABS for increased load capacity.
• Supports copper, CPVC, drain, waste and vent plastic pipe from joists and rafters.
Part Number Description Bag/Ctn Qty List Price
J-Hooks
33745 1/2” x 4” CTS 25/300 $ 1.81
33746 3/4” x 4” CTS 25/300 1.80
33747 1” x 4” CTS 25/200 2.15
33740 1 1/2” x 7 1/2” DWV 25/300 2.42
33741 2” x 7 1/2” DWV 25/300 2.57
33742 3” x 7 1/2” DWV 25/300 2.53
337 Series
1/15/13
6.38
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Strap & Tube Hangers
Part Number For Pipe Hanger Mounting Hardware Ctn Qty List Price
Size Length Included
Natick Strap Hangers
603-1/2x6 1/2” 6” Copper Clad Nails 25 $ 3.01
603-1/2x12 1/2” 12” Copper Clad Nails 25 3.70
603-3/4x6 3/4” 6” Copper Clad Nails 25 3.03
603-3/4x12 3/4” 12” Copper Clad Nails 25 3.71
603-1x6 1” 6” Copper Clad Nails 25 3.08
603-1x12 1” 12” Copper Clad Nails 25 3.89
603-11/4x6 1-1/4” 6” Copper Clad Nails 25 3.05
603-11/4x12 1-1/4” 12” Copper Clad Nails 25 3.87
603 Series Natick Strap Hanger Features:
• Made from copper clad steel, will not rust or rot.
• A tapered end, copper clad machine screw with fiber washer is mounted
on every hanger for quick, tumble free installations.
• Can be mounted cross beam or along the beam.
• Copper clad mounting nails are included.
603 Series
Tapes - Teflon® Thread Seal
1/15/13
7.1
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Imported Teflon® Thread Seal Tape Features:
• Medium density thread seal tape requires fewer wraps.
• Manufactured from 100% virgin PTFE.
• 3.5 mil thick.
• Mil. Spec. T-27730A.
• Meets ASTM D-3308.
Part Number Width Length Color Ctn/Case Qty List Price
HTST260-1/2 1/2” 260 inches White 144/576 $ 0.95
HTST260-3/4 3/4” 260 inches White 144/576 1.38
HTST260-1 1” 260 inches White 144/576 1.44
HTST520-1/2 1/2” 520 inches White 144/576 1.42
HTST520-3/4 3/4” 520 inches White 144/576 1.68
HTST520-1 1” 520 inches White 144/576 1.72
• Telfon® is a Dupont registered trademark
HTST Series
Part Number Width Length Color Case Qty List Price
HTT260 1/2” 260 in White 144 $ 2.98
HTT520 1/2” 520 in White 144 4.26
HTT520-3/4 3/4” 520 in White 144 5.90
HTT520-1 1” 520 in White 144 7.50
HTT260-1/2OXY 1/2” 260 in Green 144 7.03
HTT260-1/2PP 1/2” 260 in Pink 144 7.03
HTT260-1/2XHD 1/2” 260 in White 144 7.03
HTT120-1/2SS 1/2” 120” Light Gray 144 4.42
HTT260-1/2SS 1/2” 260 in Light Gray 144 7.03
HTT260-1/2GAS 1/2” 260 in Yellow 144 7.03
Made in USA PTFE Thread Seal Tape Features:
• UL Listed.
• 100% virgin PTFE.
HTT260/HTT520 Medium Density PTFE Tape
• White general purpose
• Medium density.
HTT260-1/2SS Gray Stainless Steel PTFE Tape
• Nickel pigment added for use on all stainless steel threads.
• Prevents galling, seizing and corrosion.
• High density for course SS threads.
HTT260-1/2PP Pink Plumbers PTFE Tape
• For plumbers and pipe fitters.
• Pink to signify heavier than standard or medium density.
HTT260-1/2GAS Yellow Gas Service PTFE Tape
• For gas lines of all types- Natural gas, butane, propane.
HTT260-1/2OXY Green Oxygen PTFE Tape
• Green for oxygen applications. Grease free.
• For all oxygen lines. Will not support combustion.
HTT260-1/2XHD White Extra High Density PTFE Tape
• For all industrial applications.
• Can be used for water, oil, chemical, medical or food processing.
HTT Series
Part Number Color Usage Thickness Density Temp Range Specs
HTT260 White General 3.5 mil .90 -450°F to +550°F Mil T-27730A
HTT520 White General 3.5 mil .90 -450°F to +550°F Mil T-27730A
HTT260-1/2OXY Green Oxygen lines 3.5 mil 1.55 -450°F to +550°F Mil T-27730A/AA58092
HTT260-1/2PP Pink Plumbing 3.5 mil 1.55 -450°F to +550°F Mil T-27730A/AA
HTT260-1/2XHD White Industrial 3.5 mil 1.20 -450°F to +550°F Mil T-27730A
HTT260-1/2SS Light Gray Stainless Steel 3.5 mil 1.55 -450°F to +550°F Mil T-27730A/AA58092
HTT260-1/2GAS Yellow Gas lines 3.5 mil 1.20 -450°F to +550°F Mil T-27730A
Tapes - Electrical, Vinyl
5/11/12
7.2
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Part Number Thickness WidthxLength Color Ctn Qty List Price
AWT60 7 mil 3/4” x 60 feet Black 64 $ 2.22
AWT60-2 7 mil 2” x 60 feet Black 48 5.64
Part Number Thickness WidthxLength Color Ctn Qty List Price
T60 7 mil 3/4” x 60 feet Black 64 $ 1.97
Premium All Weather Vinyl Electrical and Pipe Wrap Tape Features:
• For use in all weather applications.
• Use for insulation, protective jacketing and harnessing and pipe wrap.
• 7 mil thickness, 3/4” or 2” width.
• Temperature range 14°F and 176°F.
• Meets Mil. Spec. MIL-1-7798A.
• Tested to ASTM D-1000
• Imported
General Purpose Vinyl Electrical Tape Features:
• Economical, flexible, general purpose electrical tape.
• Use for insulation, protective jacketing and harnessing.
• 7 mil thickness.
• Temperature Range 32ºF and 176ºF.
• Meets mil spec. MIL-I-7798A.
• Imported
T60
AWT60 Series
Part Number Thickness WidthxLength Color Ctn Qty List Price
T60NL 7 mil 3/4” x 60 feet Black 64 $ 2.12
General Purpose NO LEAD Vinyl Electrical Tape Features:
• < 0.25% Pb by weighted average.
• Economical, flexible, general purpose electrical tape.
• Use for insulation, protective jacketing and harnessing.
• 7 mil thickness.
• Temperature Range 32ºF and 176ºF.
• Meets mil spec. MIL-I-7798A.
• Imported
T60NL
Part Number Thickness WidthxLength Color Ctn Qty List Price
AWT60NL 7 mil 3/4” x 60 feet Black 64 $ 2.39
AWT60-2NL 7 mil 2” x 60 feet Black 48 6.07
Premium All Weather NO LEAD Vinyl Electrical and Pipe Wrap Tape
Features:
• < 0.25% Pb by weighted average.
• For use in all weather applications.
• Use for insulation, protective jacketing and harnessing and pipe wrap.
• 7 mil thickness, 3/4” or 2” width.
• Temperature range 14°F and 176°F.
• Meets Mil. Spec. MIL-1-7798A.
• Tested to ASTM D-1000
• Imported
AWT60NL Series
1/15/13
7.3
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Tapes - 3M Vinyl, Rubber
Part Number Thickness WidthxLength Ctn Qty List Price
2242 30 mil 3/4” x 15 feet 24 $ 21.48
3M® 2242 Linerless Electrical Rubber Tape Features:
• Multi-purpose rubber insulating tape.
• Designed for use in splicing and terminating wires and cables.
• Rated up to 194°F (90°C) continuous.
• Highly comformable, linerless EPR (Ethylene Propylene Rubber) based tape.
• No Liner for easier handling.
• Excellent thermal dissipation for longer cable life.
• Excellent moisture seal.
• With Flame retartant.
• Meets HH-I-553C and ASTM D-4388 Type I, II, III.
2242
ISO 900 X
Part Number Thickness WidthxLength Color Ctn Qty List Price
TS33-20 7 mil 3/4” x 20 feet Black 10/100 $ 6.49
TS33-44 7 mil 3/4” x 44 feet Black 10/100 11.76
TS33-66 7 mil 3/4” x 66 feet Black 10/100 14.61
TS88-66 8.5 mil 3/4” x 66 feet Black 10/100 18.60
3M® Scotch® Professional Use Premium Vinyl Plastic Tape Features:
• Highly comformable, super stretchy in all weather applications.
• Resists UV rays, abrasion, corrosion, alkalies and acids.
• Flame Retardent.
• 7 mil tape thickness Super 33+. 8.5 mil thickness Super 88
• Temperature range 0°F to 220°F.
• Use as a primary insulation for wire cable splices up to 600V.
• Use as protective jacketing.
• Made in USA. Made for AGI in a ISO 900X facility.
TS Series
• Scotch® is a 3M registered
trademark
ISO 900 X
Super 33+
ASTM D-3005 Type I
UL273 & CSA LR48769
Super 88
MIL-I-24391C
ASTM D-3005 Type I
UL 539H & CSA LR48769
Part Number Thickness WidthxLength Color Ctn Qty List Price
1700 7 mil 3/4” x 60 feet Black 100 $ 3.73
3M® 1700 Temflex™ Vinyl Electrical Tape Features:
• Economical, flexible, general purpose electrical tape.
• Use for protective jacketing and harnessing.
• 7 mil thickness.
• Temperature rating to 176°F, 80°C.
• Meets ASTM D-2301 Type 1.
• Imported
1700
LISTED
539H
Insulating Tape
LR48769
5/3/11
7.4
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Tapes - Duct
Part Total Tensile Adhesion to Flame Smoked
Number Adhesive Thickness (mil) Strength (lb/in) Steel (oz/in) Spread Developed Index
EDT260 Rubber 7.5 19.0 28 -- --
AGDUCT Rubber 9.0 29.0 45 -- --
HDT260 Rubber 10.0 24.0 60 10 5
Part Number Thickness Width x Length Color Ctn Qty List Price
EDT260 7.5 mil 48mm x 55m (2” x 60 yds) Silver 24 $ 12.20
AGDUCT 9 mil 48mm x 55m (2” x 60 yds) Silver 24 19.48
HDT260 10 mil 48mm x 55m (2” x 60 yds) Silver 24 23.04
HDT260 BLUE 10 mil 48mm x 55m (2” x 60 yds) Blue 24 23.04
HDT260 GREEN 10 mil 48mm x 55m (2” x 60 yds) Green 24 23.04
HDT260 RED 10 mil 48mm x 55m (2” x 60 yds) Red 24 23.04
HDT260 YELLOW 10 mil 48mm x 55m (2” x 60 yds) Yellow 24 23.04
HDT260 BLACK 10 mil 48mm x 55m (2” x 60 yds) Black 24 23.04
HDT260 WHITE 10 mil 48mm x 55m (2” x 60 yds) White 24 23.04
Contractor/Industrial Grade Cloth
Reinforced Duct Tape Features:
• Multi-purpose duct tapes.
• Polyethylene coated cloth backing.
• Natural rubber based adhesive.
• Temperature range: 40ºF to 200°F.
• Superior tensile strength, adhesion and tack.
• For seaming, sealing and hanging polyethylene or vinyl.
• HDT Series recommended for pool liner installations.
• Conformable and will not curl or twist during application.
• Manufactured for AGI in an ISO9001 facility.
AGDUCT / HDT / EDT Series
ISO 9001
Meets UL723
4/17/12
7.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Hand Cleaner Towels
SCRUBS® WATERLESS HAND CLEANING TOWELS
So unique they needed a patent! Powerful yet safe cleaning
agents work together with an absorbent, non scratching abra-
sive hand cleaning towel. The result is hands that are clean
and protected, with a pleasant fragrance...and are residue
free. These shop size, durable towels quickly remove tough to clean
substances including: Dirt, Heavy Grease, Adhesives, Lubricants, Oils,
Ink, Tar, Wax, Caulk, Sealants, Paint and more.
Part
Number Description Ctn Qty List Price
SCRB72 Scrubs 72 Count Bucket 6 $ 37.50
42293 Scrubs Attachable Bracket 1 26.65
Scrubs® is registered
by Dymon Inc.
Features:
• Pre-moistened, heavy duty towel with pumice scrubbing power.
• Works fast to loosen, dissolve and absorb dirt & grease.
• Deep cleaning scrubbers remove embedded grime easily.
• Conditions and softens hands... No rinsing. No drying. No residue.
PERMATEX FAST ORANGE® HAND CLEANER WIPES
Fast Orange Hand Cleaner Wipes remove the toughest grease,
tar, grime, ink, paints, sealants, adhesives and other difficult
soils. Each pre-moistened wipe has a textured surface on one
side that is ideal for cleaning heavy-duty soils from hands, tools
and work areas. The wipes also have a smooth side for general
purpose cleaning.
Suggested applications: Fields service trucks, industrial work stations, construc-
tion, utility maintenance, transportation, printing, municipal maintenance, marine
and warehouse personnel.
Part
Number Description Ctn Qty List Price
25072 72 count bucket 6 $ 51.56
2/2/13
7.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
3M™Spray Adhesive
ISO 9002
3M™ BLUE 72 Spray Adhesives
• Pressure sensitive repositionable adhesive
• Aggressive tack and low soak-in.
• Use it for temporarily positioning and holding many fabrics.
• Precise spray control with a wide spray pattern.
• Ideal for pool liner installation
• Manufactured for AGI in an ISO 900 facility.
Part Ctn/Pallet
Number Can Size Qty List Price
BLUE 72 Blue Spray Adhesive 24 fl oz. can 12/768 $ 40.55
17.33 oz. net
ORANGE74 Orange spray adhesive 24 fl oz. can 12/768 49.20
17.33 oz. net
3M™ ORANGE FOAM FAST 74 Spray Adhesives
• 74 Foam Fast Adhesive gives fast tack with foam-tearing strength and a soft, non-
dimpling glue line.
• Bonds foam to foam, foam to metal.
• Non-misting, precise spray pattern.
• Not for sale in California. Does not meet Aerosol Consumer Products VOC limits.
• Manufactured for AGI in an ISO 900 facility.
Product Bond Bonding Spray Spray Color Temperature Coverage
Type Time Width Pattern Resistance
72 Temp or One side-8 hrs 3-3.5 in Controlled Blue 120°F 100 sq ft.
Permanent Two sides-7 days Lace 48°C 9.3 m2
74 Permanent One side -not recommended 1-3 in Lace Light Orange 120°F 260 sq ft.
Two sides-15 minutes variable 48°C 25 m2
Pallet pricing available. Call your Sales Representative.
1/15/13
7.7
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Concrete Repair
DP600
Part Number Description Ctn Qty List Price
DP600 Concrete Repair, 8.4 fl oz cartridge 6 $ 136.72
supplied with 2 nozzles
Horizontal Concrete Repair Features:
Hardens in as little at 5 minutes,
Cracks and spalls in concrete floors are an eyesore as well as a potential
safety risk. Fixing them has meant either hiring and waiting for an outside
contractor or doing it youself with a repair method that takes the floor out of
service for up to 24 hours. Now with 3M Concrete Repair, you save money
and time.
• Self-leveling urethane flows
smoothly into cleaned cracks and
gaps and hardens in as little as 5
minutes. A fork lift can pass over a
repair in as few as 15 minutes.
• Hardens to any depth without
cracking or shrinking.
• Flexible urethane expands and
contracts for durability that outlasts
repairs made with concrete.
• Do it yourself with a common
caulking gun and eliminate the cost
and wait for an outside contractor.
• Easy to use - Just clean damaged
area and fill. With every squeeze of
the caulking gun trigger, cartridge
nozzle meters and mixes precise
proportions for optimum
performance.
Part Number Size Color Ctn Qty List Price
CG9 9” Ratchet Blue 20 $ 6.36
9” Ratchet Style Caulking Gun
4/2009
7.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Concrete Repair
Horizontal Concrete Repair Specifications:
• Gray, self-leveling urethane concrete repair.
• 8.4 fl oz. cartridge of concrete repair and 2 nozzles.
• Work life of 70 sec.
• Handling time of 5 minutes
• Cure time of 60 minutes
Applications:
• Repairing cracks and spalls on concrete floors or horizontal surfaces.
• Setting anchors in concrete floors or horizontal surfaces.
• Light-duty custom threading and anchoring.
• Use outdoors or in highly ventilated area.
Clean
Remove all loose
material from area
to be filled.
Concrete should be
dry and grease-free.
Fill
Dispense product
into deepest part of
repair areas, slightly
overfilling. Product
self-levels and is
tack-free in as little
as one minute.
Finish
In as little as 15 min-
utes, product can be
sanded to remove
rough edges. It can
be painted within
one hour.
Bead Size Linear Feet per
dimension 8.4 fl oz.
1/16” 815.0
1/8” 205.0
1/4” 51.9
3/8” 22.2
1/2” 12.4
Approximate coverage:
Crack Crack Lineat Feet per
Width Depth 8.4 fl. oz.
1/4” 1/4” 19.3
1/2” 1/4” 9.9
3/4” 1/4” 6.4
1” 1/4” 4.9
1/4” 1/2” 9.9
1/2” 1/2” 4.9
3/4” 1/2” 3.0
1” 1/2” 2.0
Quick and Easy Spall Repair
1/15/13
7.17
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC Solvent Cements
PVC REGULAR CLEAR CEMENTS LO-VOC
Part List
Number Size Case Qty Price
2266S 4 oz. 24 $ 7.80
2256S 8 oz. 24 11.42
2246S 16 oz. 24 17.10
2236S 32 oz. 12 32.75
2224 1 gallon 6 125.51
• Regular bodied, clear cement for use
on PVC pipe and fittings. Up to 4” for
DWV Sch 40 and up to 2” for Sch 80.
• Recommended for ALL grades and types
of PVC pipe and fittings, potable water
and DWV.
• Sets up quickly.
• Recommended application temperature
40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other environ-
mental disctict rules.
2200 Series
CLEAR
2800 Series
CLEAR
• Regular bodied, clear cement for use
on PVC pipe and fittings. Up to 4” for
DWV Sch 40 and up to 2” for Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe, gas, conduit and
DWV.
• Sets up quickly.
• Recommended application tempera-
ture 40°F to 100°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
Part List
Number Size Case Qty Price
2866S 4 oz. 24 $ 6.93
2856S 8 oz. 24 11.64
2846S 16 oz. 24 20.30
2836S 32 oz. 12 35.83
2824 1 gallon 6 125.99
PVC REGULAR CLEAR ADVANCED CEMENTS LO-VOC
PVC MEDIUM CLEAR CEMENTS LO-VOC
Part List
Number Size Case Qty Price
1266S 4 oz. 24 $ 7.80
1256S 8 oz. 24 11.47
1246S 16 oz. 24 20.07
1236S 32 oz. 12 31.94
1224 1 gallon 6 105.78
1200 Series
CLEAR
• Medium bodied, clear cement for use
on PVC pipe and fittings. Up to 6” for
Sch 40 and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, drain,
waste and vent pipe, and potable
water
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
1/15/13
7.18
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC Solvent Cements
PVC MEDIUM GRAY CEMENTS LO-VOC
Part List
Number Size Case Qty Price
1666S 4 oz. 24 $ 8.62
1656S 8 oz. 24 13.21
1646S 16 oz. 24 21.56
1636S 32 oz. 12 37.78
1624 1 gallon 6 119.01
1600 Series
GRAY
• Medium bodied, gray colored cement
for use on PVC pipe and fittings. Up to
6” for Sch 40 and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water and DWV.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
PVC MEDIUM “HOT” BLUE CEMENTS LO-VOC PLUMB-TITE™
Part List
Number Size Case Qty Price
2066S 4 oz. 24 $ 8.70
2056S 8 oz. 24 13.58
2046S 16 oz. 24 20.67
2036S 32 oz. 12 37.32
2024 1 gallon 6 180.55
2000 Series
BLUE
• Medium bodied, blue colored cement
for PVC pipe and fittings. Up to 6” for
Sch 40 and Sch 80.
• Very fast setting cement formulated
for wet conditions and/or quick pres-
surization and fast installation.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe and DWV.
• Blue color fades to clear in direct sun-
light.
• No primer needed on non-pressure
DWV, where local codes permit.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
1/15/13
7.19
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC Solvent Cements
PVC ALL WEATHER CEMENTS LO-VOC POLAR-WELD
Part List
Number Size Case Qty Price
2666S 4 oz. 24 $ 10.21
2656S 8 oz. 24 11.97
2646S 16 oz. 24 20.52
2636S 32 oz. 12 32.34
2624 1 gallon 6 185.47
2600 Series
CLEAR
• Medium bodied, clear cement for PVC
pipe and fittings. Up to 6” for Sch 40
and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe and DWV.
• Non-pressure DWV, up through 4”
diameter: No primer needed, where
local codes permit.
• Formulated for fast initial set-up at
temperatures down to -5°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
PVC MEDIUM RAIN-R-SHINE® BLUE CEMENTS LO-VOC
Part List
Number Size Case Qty Price
30890 4 oz. 24 $ 8.24
30891 8 oz. 24 13.31
30893 16 oz. 24 19.11
30894 32 oz. 12 38.55
30895 1 gallon 6 127.40
308 Series
BLUE
• Medium bodied, blue colored cement
for PVC pipe and fittings. Up to 6” for
Sch 40 and Sch 80.
• Very fast setting cement formulated
for wet conditions and/or quick pres-
surization and fast installation.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water and DWV.
• Pool/Irrigation installations.
• No primer needed on non-pressure
DWV, where local codes permit.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
1/15/13
7.20
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC Solvent Cements
PVC MEDIUM “HOT” BLUE CEMENTS LO-VOC TURF-TITE
Part List
Number Size Case Qty Price
2466S 4 oz. 24 $ 8.70
2456S 8 oz. 24 13.58
2446S 16 oz. 24 20.67
2436S 32 oz. 12 37.32
2424 1 gallon 6 117.05
2400 Series BLUE
• Medium bodied, blue colored cement
for PVC pipe and fitting. Up to 6” for
Sch 40 and Sch 80.
• Very fast setting cement formulated
for wet conditions and/or quick pres-
surization and fast installation.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe and DWV.
• Irrigation installations.
• Fades to clear in sunlight.
• No primer needed on non-pressure
DWV, where local codes permit.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
PVC MEDIUM “HOT” BLUE CEMENTS LO-VOC POOL-TITE
Part List
Number Size Case Qty Price
2366S 4 oz. 24 $ 8.70
2356S 8 oz. 24 13.58
2346S 16 oz. 24 20.67
2336S 32 oz. 12 37.32
2324 1 gallon 6 117.05
2300 Series
BLUE
• Medium bodied, blue colored cement
for PVC pipe and fittings. Up to 6” for
Sch 40 and Sch 80.
• Very fast setting cement formulated for
wet conditions.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe, gas, conduit, PVC
flex pipe and DWV.
• Color fades to clear in sunlight.
• No primer needed on non-pressure
DWV, where local codes permit.
• Recommended application tempera-
ture 40°F to 100°F.
• Works on flex to rigid pipe applications.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
1/15/13
7.21
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC, CPVC Solvent Cements
PVC MEDIUM CLEAR FAST SET CEMENTS LO-VOC POOL-CLEAR
Part List
Number Size Case Qty Price
30875 4 oz. 24 $ 8.29
2946S 16 oz. 24 20.27
2936S 32 oz. 12 35.71
2924 1 gallon 6 154.39
2900 Series
CLEAR
• Medium bodied, clear cement for PVC
pipe and fitting. Up to 6”
• Recommended for Sch 40 and Sch 80
pipe and fittings.
• Also recommended for PVC flex pipe.
• Meets ASTM D-2564.
• Meets California Air
Quality Management
District and other environmental disc-
tict rules.
CPVC MEDIUM ORANGE CEMENTS LO-VOC
Part List
Number Size Case Qty Price
3266S 4 oz. 24 $ 10.35
3256S 8 oz. 24 16.00
3246S 16 oz. 24 31.20
3236S 32 oz. 12 39.82
3200 Series
ORANGE
• Medium bodied, orange colored
cement for use on CPVC pipe and fit-
tings. Up to 6”.
• For copper tube size (CTS) and Sch
80, potable water pressure pipe.
• Recommended application tempera-
tures down to 40°F to 110°F.
• Meets ASTM F-493.
• Meets California Air
Quality Management District and other
environmental disctict rules.
CPVC FLOWGUARD® GOLD™ LO-VOC 1-STEP YELLOW CEMENTS
Part List
Number Size Case Qty Price
31910 4 oz. 24 $ 11.19
31911 8 oz. 24 17.89
31912 16 oz. 24 32.27
319 Series
• Exceeds new environmental require-
ments and meets various CA district
rules.
• For copper tube size (CTS) CPVC hot
and cold potable water pipe and fit-
tings up to 2” interference fit only.
• May be used without primer where
local codes permit.
• For cold water systems and hot water
systems up to 180°F.
• Faster cure time/reduced installation
time.
• Meets ASTM F-493.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
1/15/13
7.22
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC and Multipurpose Solvent Cements
PVC HEAVY DUTY CLEAR CEMENTS LO-VOC
Part List
Number Size Case Qty Price
1566S 4 oz. 24 $ 6.77
1556S 8 oz. 24 10.64
1546S 16 oz. 24 23.29
1536S 32 oz. 12 38.02
1524 1 gallon 6 117.80
1500 Series
CLEAR
• Heavy bodied, clear cement for PVC
pipe and fittings. Up to 18” for Sch 40
and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water and DWV.
• Thick formula fills gaps in large diame-
ter pipe and loose fitting joints.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
PVC HEAVY DUTY GRAY CEMENTS LO-VOC
Part List
Number Size Case Qty Price
1756S 8 oz. 24 $ 14.03
1746S 16 oz. 24 25.65
1736S 32 oz. 12 42.15
1724 1 gallon 6 157.42
1700 Series
GRAY
• Heavy bodied, gray colored cement
for use on PVC pipe and fittings. Up to
18” for Sch 40 and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water and DWV.
• Thick formula fills gaps in large diame-
ter pipe and fitting.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
MULTI PURPOSE REGULAR CLEAR CEMENTS LO-VOC
Part List
Number Size Case Qty Price
6266S 4 oz. 24 $ 9.33
6256S 8 oz. 24 14.91
6246S 16 oz. 24 20.39
6236S 32 oz. 12 35.26
30848 1 gallon 6 129.99
• Regular bodied, clear cement for ABS,
PVC or CPVC up to 4”.
• Recommended for pipe and fittings Sch
40 and Sch 80, potable water, pressure
pipe and DWV.
• Recommended application temperature
40°F to 110°F.
• Meets performance requirements of
ASTM D-2564, D-2235, F-493.
• Meets California Air Quality
Management District and other environ-
mental disctict rules.
6200 Series
CLEAR
1/15/13
7.23
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
ABS Solvent Cements
ABS MEDIUM BLACK CEMENTS LO-VOC
Part List
Number Size Case Qty Price
4466S 4 oz. 24 $ 8.05
4456S 8 oz. 24 11.32
4446S 16 oz. 24 12.85
4436S 32 oz. 12 37.91
4424 1 gallon 6 108.67
4400 Series BLACK
• Medium bodied, black cement for
ABS pipe and fittings. Up to 6”.
• For ALL types and grades or ABS pipe
and fittings for DWV.
• For all non-pressure applications.
• Recommended application tempera-
tures 40°F to 110°F.
• Meets ASTM D-2235.
• Meets California Air
Quality Management District and other
environmental disctict rules.
ABS TO PVC TRANSITION GREEN CEMENTS LO-VOC
Part List
Number Size Case Qty Price
30900 4 oz. 24 $ 9.25
30925 16 oz. 24 23.74
30926 32 oz. 12 42.08
• Medium bodied, green colored cement
for use in joining ABS to PVC in non-
pressure transition joints.
• All schedules up to 6” pipe fittings.
• Recommended application temperature
40°F to 110°F.
• Meets ASTM D-3138.
• Meets California Air Quality
Management District and other environ-
mental disctict rules.
309 Series
GREEN
1/15/13
7.24
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Primers
CLEAR PRIMER - NSF LISTED LO-VOC
Part List
Number Size Case Qty Price
9366S 4 oz. 24 $ 8.40
9356S 8 oz. 24 10.92
9346S 16 oz. 24 20.52
9336S 32 oz. 12 29.33
9324 1 gallon 6 115.59
9300 Series
CLEAR
• A clear aggresive primer for use on
PVC and CPVC pipe and fittings.
• All schedules and diameters.
• Removes all surface dirt, grease and
grime as well as softens pipe to allow
a fast, secure solvent weld.
• Meets ASTM F-656.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
PURPLE PRIMER - NSF LISTED LO-VOC
Part List
Number Size Case Qty Price
8766S 4 oz. 24 $ 8.20
8756S 8 oz. 24 13.20
8746S 16 oz. 24 23.25
8736S 32 oz. 12 29.88
8724 1 gallon 6 123.45
8700 Series
PURPLE
• A purple tinted aggresive primer for
use on PVC and CPVC pipe and fit-
tings.
• Exceeds new environmental require-
ments and meets various CA district
rules.
• For use in areas where plumbing code
calls for verification that a primer has
been used.
• Removes all surface dirt, grease and
grime as well as softens pipe to allow
a fast, secure solvent
weld.
BLUE PRIMER - NSF LISTED LO-VOC PRIME-TITE™
Part List
Number Size Case Qty Price
8056S 8 oz. 24 $ 15.02
8046S 16 oz. 24 25.66
8036S 32 oz. 12 45.98
8000 Series
BLUE
• A blue-tinted aggresive primer for use
on PVC and CPVC pipe and fittings.
• Blue color fades to clear in direct sun-
light.
• Formulated to work with “TITE” prod-
ucts.
• Meets ASTM F-656.
• Meets California Air
Quality Management District and other
environmental disctict rules.
1/15/13
7.25
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Primers and Cleaners
PURPLE PRIMER/CLEANER LO-VOC
Part List
Number Size Case Qty Price
8866S 4 oz. 24 $ 8.26
8856S 8 oz. 24 12.33
8846S 16 oz. 24 20.37
8836S 32 oz. 12 29.28
8824S 1 gallon 6 114.95
8800 Series
PURPLE
• Purple tinted all purpose
primer/cleaner for PVC and CPVC pipe
and fittings.
• Removes surface dirt, grease and
grime as well as softens pipe to allow
a fast, secure solvent weld.
• Less aggressive than clear primer and
purple primer.
• Purple tint for verification for code.
• Exceeds new environmental require-
ments and meets various CA district
rules.
CLEANER LO-VOC
Part List
Number Size Case Qty Price
7366S 4 oz. 24 $ 6.84
7356S 8 oz. 24 9.51
7346S 16 oz. 24 15.74
7336S 32 oz. 12 22.54
7324 1 gallon 6 78.67
7300 Series
CLEAR
• Clear cleaner for ABS, PVC and CPVC
pipe and fittings.
• All schedules and diameters.
• Exceeds new environmental require-
ments and meets various CA district
rules.
• Fast-acting cleaner removes surface
dirt, grease and grime.
•Flows freely and evaporates quickly.
DAUBERS and EMPTY CANS
Part List
Number Size Case Qty Price
DAUBERS
31312 Fits 32 oz quart can 48 $ 3.73
31310 Fits 16 oz pint can 48 3.09
31309 Fits 8 oz 1/2 pint can 24 3.52
EMPTY CANS
30901 Gallon 2 7/8” mouth 6 29.39
• Replacement product daubers.
• Reusable cone top metal con-
tainers.
4/2009
7.26
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM 1/15/13
8.5
Super Lube®is a patented, multi-purpose synthetic lubricant,
containing SYNCOLON® (PTFE) particles held in suspension.
Super Lube lasts longer and outperforms convential petrole-
um-based greases and oils. Packaging includes tubes,
grease cartridges, aerosols, bottles, pails and drums.
How does the chemistry of SuperLube differ from conventional petroleum-based
greases and mineral oils? Super Lube grease and oils are exceptionally pure lubri-
cants because they are synthetic. This gives SuperLube very stable and predictable
chemical properties. Petroleum-based machine and gear oils are made from refined
crude oil and contain impurities which cannot be removed. These impurities interfere
with film strength and wear protection. They also form deposits at high temperatures
and solidify at low temperatures. Petroleum-based greases are formulated by adding lithium, calcium or sodium thick-
eners to petroleum-based oil.
Lubricants - Super Lube®
Part Number (old) Description Case Qty List Price
31040 (23755) 6 oz. aerosol 12 $ 13.93
31110 (20029) 11 oz. aerosol 12 16.73
51600 (24575) 32 oz. non-aerosol trigger spray 12 39.34
31110
51600
Benefits:
• Synthetic with PTFE
• Provides more reliable lubrication and outlasts petroleum based
greases & oils
• Non-toxic, odorless
• USDA H--1 for use in federally inspected meat & poultry plants.
• Remains free flowing in freezing temperatures
• High dielectric strength
• Water and saltwater waterproof
• Will not stain or harm wood, rubber, leather, plastics, fabric & paint
• Won't drip, run or evaporate
• 1A copper corrosion
• Excellent salt spray performance
• Repels dirt, dust, grit and grime
• Prevents rust and corrosion while reducing friction
• Reduces maintenance for longer machinery life
Applications:
• Plain & anti-friction bearings
• Ball & roller bearings
• Wheel bearings
• Chassis points
• Fifth wheels
• Electric motor bearings
• Disc brake assemblies
• Pumps
• Blowers
• Cams
• Slides
• Conveyors
• Chains
• Water pumps
• Valves
• Open gears
Super Lube ® and
SYNCOLON ® are
trademarks of SYNCO
Chemical Corp.
Super Lube Aerosol
A multi-purpose PTFE based synthetic lubricant available in aerosol form. Super Lube aerosol dis-
perses and penetrates while lubricating & loosening rust and dirt. Super Lube aerosol offers con-
tinuous protection as it "sets up" and forms a grease film barrier that defends against oxidation.
This barrier helps extend the life of equipment and reduces maintenance.
Super Lube Non-Aerosol Pump
Because of environmental concerns, many industrial facilities do not allow the use of aerosol prod-
ucts. Super Lube Oil with PTFE is available in a one quart trigger spray container to address these
needs.
1/15/13
8.6
TM
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Lubricants - Super Lube®
11016
Benefits:
• Clean, non-staining
• For uses from -40°F to +500°F
• Non-conducting
• Easy to use
• Resists acid attacks
• Dries on contact
• Effective mold release agent
• Not affected by oil, water or solvents
• Long lasting lubrication
• Cleans while lubricating
• Stops squeaking, sticking
• Prevents corrosion
Applications:
• Industrial slides and glides
• High speed machinery
• Precision instruments
• Door and trunk hinges
• Pipe fittings
• Electronic & electrical equipment
• Chains
• Tools
• Zippers
• Lock cylinders
• Rusted nuts and bolts
• Cable pivots
Part Number Description Case Qty List Price
11016 11 oz. aerosol 12 $ 19.23
Benefits:
• Waterproof
• Non-toxic (USDA rating H1)
• Synthetic with PTFE
• Reduces friction and wear
• Extends machinery &
equipment life
• Reduces maintenance
• Viscosity stable
• Long-lasting
Applications:
• Plain, anti-friction & roller bearings
• Enclosed industrial gears
• Enclosed chains
• Gearhead motors
• Paper machines
• Conveyors
• Machine ways
• Reciprocating compressor
lubricant additive
• Machine tools
• Centralized systems
• Straight, helical, bevel & spiral gears
Part Number (old) Description Case Qty List Price
51010SL (82333) 7 ml precision oiler 12 $ 7.99
51040 (82334) 1 gallon 4 143.71
82337 (52040) Light Weight Oil 1 gallon 4 126.36
51010
Typical Properties:
Color: Translucent white
Viscosity tested to ASTM D445
cSt@ 100°F: 14-17
cSt @ 40°F: 118-122
ISO grade: 220
Replaces ISO grade: 150-320
Replaces SAE grade gear oils: 90
Viscosity index: 145
Shelf Life: 24 months
Super Lube Dri Lube (Dri-Film)
Super Lube Dri-Lube is a self-cleaning lubricant that actually cleans while lubri-
cating. Super Lube Dri-Lube leaves behind a protective shield lubricant that will
not attract dust. The dry coating provides a low coefficient of friction which
gives excellent lubrication and release properties. Dri-Lube can be used on
wood, metal and most plastics not under stress and has excellent thermal and
chemical stability, forming a natural insulating barrier when used on electronics.
Super Lube Oil with PTFE
Super Lube Oil with PTFE is a premium synthetic oil with suspended PTFE particles that bond to
surfaces to add lubricity to moving parts. Super Lube Oil with PTFE is used for applications which
allow parts to be confined (ie. gear box). Use it as a general purpose lubricant for industrial
machinery and equipment. Super Lube Oil with PTFE provides long life protection against friction,
wear, rust and corrosion. Machinery lasts longer, downtime is reduced, and productivity is
increased. Super Lube Oil with PTFE is safe on metal, rubber, plastic, wood, leather, fabric & paint-
ed surfaces.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM 1/15/13
8.7
Lubricants - Super Lube®
41150 21030
Benefits:
• Clean
• Non-toxic
• Non-staining
• Dielectric
• USDA Rating H1
• Will not drip, run or evaporate
• Impervious to salt water, safe in potable water
• Long lasting
• Prevents rust & corrosion while reducing
friction
• Compatible with conventional lubricants
• Repels dirt, dust, grit & grime
• Extends machinery and equipment life
• Reduces maintenance while saving time & money
• Reduces friction and wear
• Will not stain or harm wood, rubber, leather,
plastic, fabrics and paint.
Applications:
• Plain and anti-friction bearings
• Ball and roller bearings
• Wheel bearings
• Chassis points
• Fifth wheels
• Electric motor bearings
• Disc brake assemblies
• Pumps
• Blowers
• Cams
• Slides
• Conveyors
• Chains
• Water pumps
• Valves
• Open gears
• Switch assemblies
• Cables
• Fans
• Electronic equipment
• Deep drawing application
Super Lube Grease Replaces
• Lithium, Bentone, Calcium or
Aluminim complex grease
• High & low temperature greases
• Electric motor grease
• Food grade grease
• Bearing, wheel bearing grease
• Multi-purpose grease
• Dielectric grease
• Valve sealant
• O-ring lubricant
Part Number (old) Description Case Qty List Price
21010 (82324) 1/2 oz. tube 12 $ 6.78
21030 (82325) 3 oz. tube 12 11.24
72350 (41150) 400 g cartridge 12 24.02
41160 (82329) 400 g jar 12 24.75
41050 (82330) 5 lb. pail 4 128.81
41030 (82331) 30 lb. pail 1 733.06
TYPICAL PROPERTIES
Color: Translucent white
Operating Temperature
Range: -45° to 450°F
NLGI Grade (ASTM D1092): 2
Dropping point (ASTM D566):
>500°F (260C)
Four ball test (ASTM D2783):
Load wear index: 81.73 kg
Weld point: 400 kg
Oxidation stability 100 hrs.
(ASTM D942): 0 psi
Wheel bearing leakage
(ASTM D1263): 0.2g
Copper corrosion 24 hrs @
100°C (ASTM D4048): 1B,
shiny
Shelf life: 24 months
Super Lube Grease
Super Lube is a patented synthetic NLGI grade 2 heavy-duty, multi-pur-
pose lubricant with PTFE. Synthetic base fluids and the addition of
PTFE micro powders combine to form a premium lubricant that pro-
vides long life protection against friction, wear, rust and corrosion.
Machinery lasts longer, downtime is reduced, and productivity is
increased.
Super Lube is a USDA listed Food Grade Lubricant, rated H1 for incidental food contact.
Super Lube will not run or drip, does not evaporate or form gummy deposits and will not
dry out, melt or separate.
Super Lube is a synthetic, heavy duty lubricant that is compatible with most other lubri-
cants. Super Lube Grease outlasts conventional greases 50-100% and has excellent
adhesion.
1/15/13
8.8
TM
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Lubricants - Super Lube®
Part Number Description Display Qty List Price
21013 Counter display w/ Grease 40 271.82
51013 Counter display w/ Oiler 48 385.38
Super Lube Grease w/ PTFE Counter display
• Packaged in a cardboard counter display
• Contains 40, 1/2 oz. tubes Super Lube w/ PTFE grease
Super Lube Precision Oiler w/ PTFE Counter display
• Packaged in a cardboard counter display
• Contains 48, 7 ml precision oiler pens of Super Lube w/ PTFE
21013 and 51013
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM 1/15/13
8.9
Lubricants - Super Lube®
Benefits:
• Wide temperture range
• Works on types of pneumatic equipment
• Prevents rust and corrosion
• Can be used as a light oil
• Gives worn tools new life
• Less friction and wear
• Protects against corrosives
• Less tendancy for bubbles
• Absorbs moisture
• Eliminates ice buildup and frost in air tools.
Applications:
• Air impact tools
• Drills
• Grinders
• Screwdrivers
• Sanders
• Percussion tools
• Household shop tools
• All air tool oil lubricated
Super Lube Air Tool Lubricant
Super Lube Air Tool Lubricant is formulated to meet the special require-
ments for industrial, household and agricultural tools. It absorbs water
and eliminates any ice buildup and frost in air tools. Blended rust and
corrosion inhibitors and a special base fluid oil minimizes wear and
allows operation of air tools at temperatures as low as -40°F.
Part Number Description Case Qty List Price
12004 4 oz. bottle 6 $ 9.35
12016 16 oz. bottle 12 20.63
Benefits:
• Cleans and Penetrates
• Loosens rusted parts
• Frees sticky mechanisms
• Stops squeaks
• Protects against rust &
corrosion
• Drives out moisture
• Leaves a protective
lubricating film
Typical Properties:
TEST METHOD SYNCOPEN
Color Translucent Brown
Specific Gravity ASTM D1298 .85
Pour Point ASTM D97 -40°F
Salt Spray Test ASTM B117 Pass
(500 hrs)
Copper Corrosion ASTM D130 1A
24 hrs @ 100°C
USDA Rating NSF H1
Shelf Life 24 months
Super Lube Syncopen
Super LubeSynthetic Penetrant is a super fast acting, penetrating, synthetic oil that
cuts through rust or corrosion. Syncopen penetrates hard to reach areas to allow
easy removal of rusted and corroded screws, nuts or bolts. Syncopen penetrates,
lubricates and leaves a protective film to help prevent future rusting or corrosion.
Part Number Description Case Qty List Price
85011 11 oz. aerosol 12 $ 15.80
85010 1 gallon 4 140.67
4/2009
8.10
TM
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
9/7/11
10.27
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Irrigation Installation Accessories
Part Number Description Ctn Qty List Price
Cut-off Nipples
P73-1/2 1/2” MIPT X 1/2” MIPT X 6” 50 $ 1.09
P73-3/4 3/4” mipt x 3/4” mipt x 6” 25 2.60
P73-3/4x1/2 Reducing, 3/4” mipt x 1/2” mipt, 6” 40 2.05
Poly Cut-off Nipples
PCO1/2X4 1/2” x 4” MPT X MPT 500 0.43
PCO1/2X6 1/2” x 6” mpt x mpt 500 0.50
PCO1/2X3/4X4 1/2” x 3/4” x 4” mpt x mpt 500 0.66
PCO1/2X3/4X6 1/2” x 3/4” x 6” mpt x mpt 400 0.78
PCO3/4X4 3/4” x 4” mpt x mpt 400 0.61
PCO3/4X6 3/4” x 6” mpt x mpt 400 0.95
Riser Extensions
RE1/2X1 1/2” x 1” fpt x mpt 1000 0.29
RE1/2X11/2 1/2” x 1 1/2” fpt x mpt 1000 0.30
RECO1/2X4 1/2” x 4” fpt x mpt 500 0.64
RECO3/4XSHORT 3/4” x Short fpt x mpt 500 0.74
RECO3/4X4 3/4” x 4” fpt x mpt 400 0.85
Poly Nipples
PN1/2XCLOSE 1/2” x close 1000 0.22
PN1/2X3/4XCLOSE 1/2” x 3/4” x close 1000 0.30
PN3/4XCLOSE 3/4” x close 1000 0.33
PN1/2X2 1/2” x 2” 1000 0.23
PN1/2X3 1/2” x 3” 500 0.29
PN1/2X4 1/2” x 4” 500 0.32
PN1/2X5 1/2” x 5” 500 0.43
PN1/2X6 1/2” x 6” 500 0.50
PN1/2X8 1/2” x 8” 50 1.66
PN1/2X10 1/2” x 10” 50 1.91
PN1/2X12 1/2” x 12” 50 2.15
PN1/2X18 1/2” x 18” 50 3.01
PN1/2X24 1/2” x 24” 50 3.91
Nipple Extractors
SW500C Stub Wrench 50 6.43
P-73 Series
SW500C
P73 Cut-off Nipples Features:
• Patented design 4 in 1 nipple allows choice of length, excess becomes
additional useable nipples.
• 100 PSI (max) and 201°F max temperature.
• Green
Poly Cut-off Nipple, Riser Extension and Poly Nipple Features:
• Black poly
SW500 Nipple Extractor Features:
• For 1/2” or 3/4” plastic nipples.
• Easy to remove broken plastic riser from sprinkler pipe and fittings.
• Insert tip and turn.
PCO Series
RE Series
RECO Series
PN Series
Irrigation Installation Accessories
Mini Trol® Water Hammer Arrestor Features:
• Mini Trol takes the bang out of water lines.
• Effectively intercepts surges in water lines.
• Prevents damage and shock waves by quick closing valves.
• Designed with pre-pressurized, permanent air chamber separated from
water by a sealed-in heavy duty diaphragm.
• Chamber is polypropylene lined. Water never touches steel.
• Guaranteed not to waterlog or lose air.
• Manufactured for AGI in a ISO9001 facility.
500
ISO 9001
Precharge Pressure: 22 psi
Max. Working Pressure: 125 psi
Max. Shock Pressure: 200 psi
Max. Operating Pressure: 200° F
Max. Velocity: 100 FPS
Part Number Description Ctn Qty List Price
500 Mini-Trol 4 1/2” H x 3 3/8” W x 1/2” MPT 24 $ 86.32
HP Series Drain and Adapter Features:
• Freeze protection.
• Easy installation without tools.
• Dirt stopper screen keeps sand, dirt and sediment out of system.
• Hammer slug for easy installation on reducing elbows.
• Recessed wicking pad.
SD1000 Siphon Drain Features:
• Freeze protection. Protects mainlines, sprinkler heads, pipe, low
spots, and end lines.
• New or existing irrigation systems. 3 sec. installation, no tools
necessary.
• One drain for 1/2” thru 1” polyethylene and PVC pipe.
Part Number Description Use For Ctn Qty List Price
Drains
HP2000 1/2” MPT Drain Lateral line 25/500 $ 5.39
HP3000 3/4” MPT Drain Lateral line 25/400 5.72
HP4000 1/2” MPT Drain Main line 25/500 5.36
SD1000 Fits 1/2” thru 1” pipe Siphon Drain 25/200 8.82
Reducing Elbows
HP1500 3/4” ins x 1/2” fpt Elbow Poly end of line 10/250 7.54
HP1600 1” ins x 1/2” fpt Elbow Poly end of line 10/250 7.54
HP1700 1” ins x 3/4” fpt Elbow Poly end of line 10/250 7.54
HP1500
SD1000
HP2000
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
1/15/13
10.28
1/15/13
10.37
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Electrical Installation Accessories
3M® SSP Series Insulation Displacement Connector
Features:
• Used to electrically connect two or three wire ends & insulate the connection.
• #22-#14 AWG range on SSP314. SSP314 is UL and CSA listed.
• #22-#16 AWG range on SSP316.
• Also used for pigtail 2- and 3-wire splicing.
• Connector provides a moisture-resistant seal and is flame retardant.
Tom King Harmony Snaplock Wire Connector Features:
• Gel-filled 100% waterproof.
• Double o-ring, double-latch locking system.
• For low voltage connections.
Part Number Description Ctn Qty List Price
SSP314 3M® Insulation Displacement Connectors #22-#14 AWG 1000 $ 1.77
SSP316 3M® Insulation Displacement Connectors #22-#16 AWG 300 1.65
Snaplock Gel-filled Wire Connector
LV9000 Small- fits two #24 - seven #18 AWG 24/720 1.42
LV9500 Large - Fits two #18 - three #10 & one #18 AWG 12/432 2.07
SSP314
LV9000
82-A
Scotchcast™ 82-A Series Inline Resin Splice Kit Features:
• Insulate and seal single conductor, unshielded cable splices & multiple
conductor cables.
• Connector is not included.
Part Number Conductor Cable OD Conn OD Ctn Qty List Price
82-A2 2-3/0 AWG 1” 0.625” 10 $ 146.78
Electrical Installation Accessories
ET1983 Electrical Tester Features:
• Checks 120, 240, 440VAC and 150, 300, 500VDC
• Handy, economical, durable.
• Ideal for any electrical installation or repair.
• Extra long insulated lead with test probe for added convenience.
• Easy to read, bright indicator light.
• Requires no batteries.
• Packaged in slide blister card.
• Meets CE requirements.
• UL listed.
Part Number Description Ctn/Case Qty List Price
ET1983 120, 240, 440V tester 10/120 $ 10.18
ET1983
VL1
CLICK-IT™ Valve Locator Features:
• Water resistant.
• Compact design.
• For location of solenoid valve quickly and easily.
• Practical and cost effective.
Part Number Description Ctn Qty List Price
VL1 Click-It Valve Locator 10 $ 113.69
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
2/15/11
10.38
4/17/12
10.47
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Expandable Repair Couplings
Poly-Stretch Repair Coupling Features:
• For repair of polyethylene irrigation pipe.
• Avoid extra digging and buckled pipe.
• Couplings are made of ABS
• O-ring seal is made of Buna 70
• Pressure rated at 160 psi.
• Designed for irrigation operation pressures of polyethylene pipe and more.
Part
Number Description Ctn Qty List Price
PSC07 3/4” Poly-stretch coupling 50 $ 11.13
PSC10 1” Poly-stretch coupling 50 11.53
PSC12 1 1/4” Poly-stretch coupling 25 17.28
PSC15 1 1/2” Poly-stretch coupling 25 19.98
PSC20 2” Poly-stretch coupling 20 31.19
PSC Series
Dimensions:
ABC DE
3/4” 4.0 .575 .820 1.50 5.625
1” 4.0 .770 1.075 1.50 5.625
1 1/4” 5.0 1.109 1.415 1.755 6.70
1 1/2” 5.0 1.310 1.63 1.755 6.70
2” 5.0 1.825 2.125 1.755 6.70
Instructions for Installation:
•Cut out approximately 4” of
pipe where repair is needed.
•Place clamps over ends of pipe
•Insert end marked with “END
FIRST” arrow by pushing and
turning at same time.
•Insert other end by pushing &
turning.
•Place clamps over ribbed ends
& tighten.
Part Number IPS Size Body Length Ctn Qty List Price
PVC Flo-Span Expansion Couplings
w/ union no union
117-05 118-05 1/2” 5-3/4” 28 $ 7.71
117-07 118-07 3/4” 6-3/4” 24 8.03
117-10 118-10 1” 7-3/4” 15 9.50
117-12 118-12 1-1/4” 9” 10 17.50
117-15 118-15 1-1/2” 10” 16 19.18
117-20 118-20 2” 10-1/2” 12 29.94
118-25 2-1/2” 13” 3 50.45
118-30 3” 14-1/2” 3 63.09
118-40 4” 14-1/2” 3 110.26
Flo Span Expandable Repair Coupling Features:
• Double EPDM o-ring seal gives more protection from posible leakage due
to deflection of piston in the extended position.
• EPDM o-ring seal also protects against contamination on the cylinder wall.
• Solvent cement trap located in cap to capture excess solvent cement.
• Made from PVC type I grade I material meeting ASTM D-1784
• 117 Series has union end, 118 Series does not have union end.
117 Series 118 Series
1/15/13
10.48
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Repair Fittings for Sch 40 Pipe
Pipe Extender and Inside Connector Repair Fitting Features:
• For Sch 40 pipe.
• Saves labor.
• Invisible after installation.
• Permanent repair.
• Insignificant flow restriction.
• PVC Construction.
• PIC Series connects two pieces of Sch 40 pipe with flush joint.
Part Number Description IPS Size Ctn Qty List Price
Pipe Extender Repair Fitting
PEX50 Pipe Extender 1/2” 48 $ 2.10
PEX75 Pipe Extender 3/4” 48 2.66
PEX100 Pipe Extender 1” 48 3.41
PEX125 Pipe Extender 1 1/4” 48 4.00
PEX150 Pipe Extender 1 1/2” 48 4.73
PEX200 Pipe Extender 2” 48 5.32
PEX250 Pipe Extender 2 1/2” 96 7.23
PEX300 Pipe Extender 3" 96 10.45
PEX400 Pipe Extender 4" 48 12.32
Inside Connector Repair Fitting
PIC100 Inside Connector 1” 48 3.41
PIC150 Inside Connector 1 1/2” 48 4.73
PIC200 Inside Connector 2” 48 5.32
PEX Series
PIC Series
1/15/13
12.1
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Nylon
Nylon Insert Fitting Features:
• White nylon insert fittings
• Meets ASTM-2609
• NSF for potable water
N401 Series
Inner/Master
Part Number Description Ctn Qty List Price
N401-005 NYLON INS X INS TEE 1/2" 10/180 $ 2.23
N401-007 NYLON INS X INS TEE 3/4" 10/100 2.64
N401-010 NYLON INS X INS TEE 1" 10/60 4.23
N401-012 NYLON INS X INS TEE 11/4" 5/40 7.22
N401-015 NYLON INS X INS TEE 11/2" 5/30 10.21
N401-020 NYLON INS X INS TEE 2" 5/15 13.80
N406-005 NYLON INS X INS 90 ELBOW 1/2" 10/300 1.91
N406-007 NYLON INS X INS 90 ELBOW 3/4" 10/180 2.18
N406-010 NYLON INS X INS 90 ELBOW 1" 10/100 2.64
N406-012 NYLON INS X INS 90 ELBOW 11/4" 5/60 4.47
N406-015 NYLON INS X INS 90 ELBOW 11/2" 5/40 6.79
N406-020 NYLON INS X INS 90 ELBOW 2" 5/25 9.08
N413-005 NYLON INS X MIPT 90 ELL 1/2" 10/300 3.33
N413-007 NYLON INS X MIPT 90 ELL 3/4" 10/200 4.64
N413-010 NYLON INS X MIPT 90 ELL 1" 10/100 6.53
N413-012 NYLON INS X MIPT 90 ELL 1 1/4” 5/60 8.59
N413-015 NYLON INS X MIPT 90 ELL 11/2" 5/50 12.76
N429-005 NYLON INS X INS COUPLING 1/2" 10/400 1.14
N429-007 NYLON INS X INS COUPLING 3/4" 10/250 1.34
N429-010 NYLON INS X INS COUPLING 1" 10/160 1.79
N429-012 NYLON INS X INS COUPLING 11/4" 10/80 3.22
N429-015 NYLON INS X INS COUPLING 11/2' 5/60 4.35
N429-020 NYLON INS X INS COUPLING 2" 5/40 5.51
N436-005 NYLON INS X MIPT M/A 1/2" 10/400 1.14
N436-007 NYLON INS X MIPT M/A 3/4" 10/250 1.40
N436-010 NYLON INS X MIPT M/A 1" 10/160 1.79
N436-012 NYLON INS X MIPT M/A 11/4" 10/80 2.87
N436-015 NYLON INS X MIPT M/A 11/2" 5/60 4.12
N436-020 NYLON INS X MIPT M/A 2" 5/40 6.47
N406 Series
N413 Series
N429 Series
N436 Series
MAXIMUM DIAMETERS
SIZE C E F
1/2” .605 .445 .665
3/4” .800 .630 .865
1” 1.005 .805 1.095
1 1/4” 1.325 1.105 1.425
1 1/2” 1.565 1.345 1.665
2” 2.020 1.800 2.125
• DO NOT USE NYLON INSERT FITTINGS FOR
COMPRESSED AIR OR GASES.
• DO NOT TEST PIPING SYSTEMS WITH NYLON INSERT
FITTING WITH COMPRESSED AIR OR GASES.
• DO NOT USE FITTINGS WITH LIQUIDS NOT
RECOMMENDED BY MANUFACTURER.
• MODIFICATIONS OF FITTINGS VOIDS THE
WARRANTY.
Recommended Installation Procedures:
• Sizes 1/2, 3/4 and 1” - one clamp directly over barbs.
• Sizes 1 1/4” and greater - one clamp directly over barbs
PLUS one clamp behind barbs.
Insert Diameter Dimensions
4/2009
12.2
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
1/15/13
12.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Steel, Zinc Plated
Part Number Size Ctn/Case Qty List Price
Male Adapter, mipt x ins *
S12-1/2 1/2" 25 $ 4.63
S12-3/4 3/4” 25 4.95
S12-1 1” 20 6.34
S12-11/4 1-1/4” 20 8.03
S12-11/2 1-1/2” 10 9.95
S12-2 2” 10 14.36
S12-21/2 ☺ 2-1/2” BULK 37.66
S12-3 ☺ 3” BULK 50.80
S12-4 ☺ 4” BULK 82.29
Male Adapter, mipt x ins IMPORTED **
IMAS50 1/2" 50/300 1.65
IMAS75 3/4" 50/200 2.28
IMAS100 1" 25/200 2.95
IMAS125 1 1/4" 12/108 4.49
IMAS150 1 1/2" 6/90 5.67
IMAS200 2" 5/60 8.26
IMAS250 2 1/2” 2/10 21.95
IMAS300 3” 2/10 29.15
IMAS400 4” 2/10 45.69
Extra Long Male Adapter, mipt x ins *
XS12-1 1” 25 12.30
XS12-11/4 1-1/4” 25 16.25
XS12-11/2 1-1/2” 25 18.71
Extra Long Male Adapter, mipt x ins IMPORTED **
IMAS100XL 1” 10/120 4.68
IMAS125XL 1 1/4” 10/80 7.58
Reducing Male Adapter, mipt x ins *
S38-3/4X1/2 3/4" x 1/2" 25 20.10
S38-1X3/4 1" x 3/4” 25 22.16
S38-11/4X1 1-1/4" x 1” 25 25.29
S38-11/2X11/4 1-1/2" x 1-1/4” 25 31.42
S38-2X11/2 2" x 1-1/2” 25 42.17
Reducing Male Adapter, ins x mipt *
S74-1X3/4 1" x 3/4” 25 12.44
S74-11/4X1 1-1/4" x 1 25 17.80
S74-11/2X11/4 1-1/2" x 1-1/4” 25 21.20
Reducing Male Adapter, ins x mipt IMPORTED **
IMAS7550 3/4” x 1/2” 250 4.47
IMAS1075 1” x 3/4” 250 5.14
Venturi Adapter, mipt x ins *
S86-3/4X6 3/4" x 6” 25 18.05
S86-3/4X10 3/4" x 10" 25 21.48
S86-3/4X12 3/4 x 12” 25 21.76
S86-1X6 1" x 6" 25 13.71
S86-1X8 1" x 8" 25 16.56
S86-1x10 1" x 10" 25 18.60
S86-1X12 1" x 12" 25 21.24
S86-11/4X6 1-1/4" x 6" 25 18.66
S86-11/4X8 1-1/4" x 8" 25 21.01
S86-11/4X10 1-1/4" x 10" 25 25.34
S86-11/4X12 1-1/4" x 12” 25 32.46
• For use with flexible poly pipe
• Made in North America.
• IMAS Imported
• Made from Sch 40 C.W. steel pipe,
zinc plated.
S12, IMAS
S38
S74, IMAS
XS12, IMAS--XL
S86
***
☺ NO wrench-grip shoulder
1/15/13
12.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Steel, Zinc Plated
Part Number Size Ctn/Case Qty List Price
Venturi Adapter, mipt x ins IMPORTED **
ISVMA1X6 1" x 6" 60 $ 5.50
ISVMA1X8 1" x 8" 50 7.95
ISVMA1X10 1" x 10" 40 9.44
ISVMA11/4X6 1-1/4" x 6" 50 7.46
ISVMA11/4X8 1-1/4" x 8" 40 9.27
ISVMA11/4X10 1-1/4" x 10" 30 12.52
Well Seal Elbow, ins x ins *
S99-1 1” 10 26.66
S99-11/4 1-1/4” 10 36.03
Well Seal Elbow, ins x ins IMPORTED **
ISWSE100 1” BULK 13.11
ISWSE125 1-1/4” BULK 21.54
Coupling, ins x ins *
S10-1/2 1/2” 25 4.18
S10-3/4 3/4” 25 4.95
S10-1 1” 20 6.70
S10-11/4 1-1/4” 20 9.51
S10-11/2 1-1/2” 10 10.64
S10-2 2” 10 19.60
S10-3 3” BULK 65.36
S10-4 4” BULK 104.56
Coupling, ins x ins IMPORTED **
ICS50 1/2" 50/300 1.54
ICS75 3/4" 50/200 2.25
ICS100 1" 25/200 2.80
ICS125 1 1/4" 20/120 4.86
ICS150 1 1/2" 10/60 6.49
ICS200 2" 10/60 8.59
ICS250 2 1/2” 2/10 21.99
ICS300 3” 2/10 25.92
ICS400 4” 2/10 29.46
Extra Long Coupling, ins x ins *
XS10-1 1” 25 22.32
XS10-11/4 1-1/4” 25 32.08
Extra Long Coupling, ins x ins IMPORTED **
ICS100XL 1” 10/120 3.93
ICS125XL 1-1/4” 10/80 6.96
Female Adapter, fipt x ins *
S90-1/2 1/2” 25/300 12.82
S90-3/4 3/4” 25/200 16.76
S90-1 1” 20/160 21.61
S90-11/4 1-1/4” 20/120 26.93
S90-11/2 1-1/2” 10/60 31.99
S90-2 2” 10/40 38.79
Female Adapter, fipt x ins IMPORTED **
IFAS50 1/2” 25/200 2.57
IFAS75 3/4” 25/150 3.59
IFAS100 1” 125 4.82
IFAS125 1 1/4” 100 11.11
IFAS150 1 1/2” 10/60 10.75
IFAS200 2” 4/20 17.92
S90, IFAS
S10, ICS
XS10, ICS--XL
S99, ISWSE
• For use with flexible poly pipe
• Made in North America.
• ISVMA, ISWSE, IFAS, ICS - Imported
• Made from Sch 40 C.W. steel pipe,
zinc plated.
ISVMA
***
1/15/13
12.7
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Stainless Steel
SS12 Series SS38 Series
Part Number Size # Barbs Ctn/Case Qty List Price
Grade 316 SS, MADE IN U.S.A.
Male Adapter, MIPT X INS, HEX PATTERN
SS12-1/2 1/2” 6 25/300 $ 21.17
SS12-3/4 3/4” 7 25/200 19.49
SS12-1 1” 7 20/160 22.08
SS12-11/4 1-1/4” 6 20/120 36.20
SS12-11/2 1-1/2” 6 10/60 49.01
SS12-2 2” 7 10/40 64.41
Male Reducing Adapter mipt x red. ins
SS38-11/4x1 1-1/4 x 1” 7 25/100 52.13
Grade 316 SS, EXTRA LONG, MADE IN U.S.A.
Male Adapter, MIPT X INS, ROUND PATTERN
XSS12-1 1 14 25 43.07
XSS12-11/4 11/4 14 25 56.11
Grade 316 SS, MADE IN U.S.A.
Coupling, INS X INS, ROUND PATTERN
SS10-1 1 7 20 31.50
SS10-11/4 11/4 7 20 41.64
Grade 316 SS, EXTRA LONG, MADE IN U.S.A.
Coupling, INS X INS, ROUND PATTERN
XSS10-1 1 14 25 56.98
Features:
• Imported cast from Grade 304 Stainless Steel.
• Made in U.S.A. from Grade 316 Stainless Steel.
• For use with flexible poly pipe.
Part Number Size # Barbs Ctn/Case Qty List Price
Grade 304 SS, IMPORTED
Male Adapters, MIPT X INS, HEX PATTERN
SSMA1/2 1/2" 6 10/200 $ 8.18
SSMA3/4 3/4" 6 10/200 12.21
SSMA1 1” 6 10/100 17.11
SSMA11/4 1 1/4” 6 5/100 21.25
SSMA11/4X1 1 1/4” x 1” 6 10/100 18.82
SSMA11/2 1 1/2" 6 5/80 29.94
SSMA2 2" 6 5/40 41.64
Grade 304 SS, HEAVY PATTERN EXTRA LONG, IMPORTED
Male Adapters, MIPT X INS, HEX PATTERN
XLSSMA11/4X1 1 1/4” x 1” 13 5/60 25.54
SSMA Series XLSSMA
SS10 Series
7/17/12
12.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Yellow Brass, NO LEAD Yellow Brass
Part Number Size Ctn/Case Qty List Price
Yellow Brass Adapters, ins x solder
YB00-1/2 1/2” 10/200 $ 2.57
YB00-3/4 3/4” 10/200 5.86
YB00-1 1” 10/200 7.93
YB00-11/4 1-1/4” 10/200 9.38
YB00-11/2 1-1/2” 5/80 29.46
NO LEAD Yellow Brass Adapters, ins x solder
YB00NL3/4 3/4” 10/200 8.20
YB00NL1 1” 10/200 11.68
Yellow Brass Couplings, ins x ins
YB10-3/4 3/4 “ 10/200 3.41
YB10-1 1” 10/200 7.48
YB10-11/4 1-1/4” 10/200 9.69
Yellow Brass Adapters, ins x mipt
YB12-1 1” 10/200 9.20
YB00
YB10 YB12
• For use with flexible poly pipe
• Imported
7/17/12
12.9
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Red Brass
Part Number Size Ctn/Case Qty List Price
Male Adapter, mipt x ins *
B12-1/2 1/2” 25/300 $ 13.36
B12-3/4 3/4” 25/200 16.73
B12-1 1” 20/160 20.93
B12-11/4 1-1/4” 20/120 38.89
B12-11/2 1-1/2” 10/60 47.41
B12-2 2” 10/40 62.07
B12-21/2 ☺2-1/2” 10 128.56
B12-3 ☺3” 10 205.66
B12-4 ☺4” 10 368.85
Male Adapter, mipt x ins IMPORTED **
IMAB50 1/2" 50/300 9.10
IMAB75 3/4" 50/200 12.75
IMAB100 1" 25/100 14.11
IMAB125 1 1/4" 20/80 31.68
IMAB150 1 1/2" 10/60 44.05
IMAB200 2" 10/60 57.54
IMAB250 2 1/2” 2/10 121.02
IMAB300 3” 2/10 165.56
IMAB400 4” 2/10 202.78
Extra Long Adapter, mipt x ins *
XB12-1 1” 25/100 38.32
XB12-11/4 1-1/4” 25/50 56.65
XB12-11/2 1-1/2” 25/50 72.55
Extra Long Adapter, mipt x ins IMPORTED **
IMAB100XL 1” 10/120 30.17
IMAB125XL 1-1/4” 10/80 38.78
Reducing Male Adapter, mipt x ins *
B38-3/4X1/2 3/4" x 1/2" 25/200 59.46
B38-1X3/4 1" x 3/4" 25/150 66.20
B38-11/4X1 1-1/4” x 1" 25/100 79.03
B38-11/2X11/4 1-1/2" x 1-1/4" 25/50 104.50
B38-2X11/2 2” x 1 1/2” 25/50 125.85
Reducing Male Adapter, ins x red. mipt *
B74-3/4x1/2 3/4” x 1/2” 25/200 26.63
B74-1X3/4 1" x 3/4" 25/200 30.58
B74-11/4X1 1-1/4" x 1" 25/100 36.79
B74-11/2X11/4 1-1/2" x 1-1/4" 25/100 49.67
Venturi Adapter, ins x mipt *
B86-1X6 1" x 6" 25/100 44.84
B86-1X8 1" x 8" 25/100 59.07
B86-11/4X6 1-1/4" x 6" 25/100 66.40
B86-11/4X8 1-1/4" x 8" 25/100 87.43
B12, IMAB
B38
XB12, IMAB---XL
• For use with flexible poly pipe
• Made in North America
• B and XB Series ANSI/NSF61
• IMAB Imported
• Made from 85% copper alloy
seamless brass pipe with 0.05%
lead.
B74
B86
ANSI/NSF Standard 61
Drinking Water System Components
***
☺ NO wrench-grip shoulder
1/15/13
12.10
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Red Brass
Part Number Size Ctn/Case Qty List Price
Well Seal Elbow, ins x ins *
B99-1 1” Bulk $ 96.50
B99-11/4 1-1/4” Bulk 181.67
Coupling, ins x ins *
B10-1/2 1/2” 25/300 17.65
B10-3/4 3/4” 25/300 19.86
B10-1 1” 20/160 29.63
B10-11/4 1-1/4” 20/120 45.35
B10-11/2 1-1/2” 10/60 53.82
B10-2 2” 10/40 84.06
B10-21/2 2-1/2” BULK 236.43
B10-3 3” BULK 394.76
B10-4 4” BULK 685.26
Coupling, ins x ins IMPORTED **
ICB50 1/2" 50/300 3.95
ICB75 3/4" 50/200 12.43
ICB100 1" 25/100 20.44
ICB125 1 1/4" 20/80 34.58
ICB150 1 1/2" 10/60 43.67
ICB200 2" 10/60 59.78
ICB250 2 1/2” 2/10 64.63
ICB300 3” 2/10 161.71
ICB400 4” 2/10 154.40
Extra Long Coupling, ins x ins *
XB10-1 1” 25/100 57.56
XB10-11/4 1-1/4” 25/50 81.56
Extra Long Coupling, ins x ins IMPORTED **
ICB100XL 1” 10/120 22.92
ICB125XL 1-1/4” 10/80 23.39
Female Adapter, fipt x ins *
B90-1/2 1/2” 25/300 30.26
B90-3/4 3/4” 25/200 33.80
B90-1 1” 20/160 41.46
B90-11/4 1-1/4” 20/120 60.02
B90-11/2 1-1/2” 10/60 71.16
B90-2 2” 10/40 99.98
B90
B10, ICB
XB10, ICB--XL
• For use with flexible plastic pipe
• Made in North America
• B and XB Series ANSI/NSF61
• IMAB, ICB Imported
• Made from 85% copper alloy
seamless brass pipe with 0.05% lead.
B99
ANSI/NSF Standard 61
Drinking Water System Components
***
9/7/11
12.11
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Unions - PVC Sch 80
PVC Sch 80 Union Features:
• Ideal for swimming pool, spa and plumbing installations.
• EPDM O-Ring seal.
• Working pressure: 150 PSI at 72ºF, 100 PSI at 120ºF.
• Meets ASTM standards for Schedule 80 construction.
• Manufactured for AGI in an ISO 9002 facility.
• NSF listed.
• Available white or gray.
• Imported.
Part Number IPS Size Ctn Qty List Price
SCHEDULE 80 - WHITE PV797 PV798 PV799
SLIP X SLIP FIPT X FIPT SLIP X FIPT SXS TXT SXT
PV797-1/2 PV798-1/2 1/2” 36 $ 2.93 $ 3.06
PV797-3/4 PV798-3/4 3/4” 24/144 3.85 4.00
PV797-1 PV798-1 1” 12/96 4.95 5.30
PV797-11/4 PV798-11/4 1 1/4” 12/96 8.82 9.28
PV797-11/2 PV798-11/2 PV799-11/2 1 1/2” 8/64 11.14 11.59 $ 11.34
PV797-2 PV798-2 PV799-2 2” 4/48 15.50 16.30 16.20
SCHEDULE 80 - GRAY PV697 PV698
slip x slip FIPT x FIPT SxS TXT
PV697-1/2 PV698-1/2 1/2” 36/288 $ 2.93 $ 3.09
PV697-3/4 PV698-3/4 3/4” 24/144 3.86 4.08
PV697-1 PV698-1 1” 12/96 4.95 5.40
PV697-11/4 PV698-11/4 1 1/4” 12/96 8.82 9.16
PV697-11/2 PV698-11/2 1 1/2” 8/64 11.14 11.81
PV697-2 PV698-2 2” 4/48 15.80 16.61
PV697-3 PV698-3 3” 2/12 39.95 41.31
PV697-4 4” 1/4 88.67
Replacement O-Ring for PV797, PV798, PV799, PV697, PV698
PV796-1/2 1/2” 1 $ 0.35
PV796-3/4 3/4” 1 0.35
PV796-1 1” 1 0.42
PV796-11/4 1 1/4” 1 0.42
PV796-11/2 1 1/2” 1 0.70
PV796-2 2” 1 0.70
PV79, PV69 Series
MATERIAL SPECIFICATIONS
Body PVC
End Connector PVC
Union Nut PVC
O-Ring EPDM
DIMENSIONS (IN.) SIZE d3 D1 D2 L
1/2” .51 1.21 1.80 2.11
3/4” .71 1.45 2.15 2.42
1” .92 1.76 2.58 2.69
1 1/4” 1.17 2.11 3.20 3.32
1 1/2” 1.52 2.54 3.83 3.40
2” 1.92 3.05 4.68 3.71
3” 2.84 3.52 6.10 4.96
4” 3.94 4.52 8.86 6.30
ISO 9002
1/15/13
12.12
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Union, PVC Sch 80
1600 Series
Part Number IPS Size Ctn Qty List Price
SCHEDULE 40 - MADE IN USA
SLIP X SLIP
1600-15 1 1/2” Socket both ends, 2” spigot one end 24 $ 15.72
1600-20 2” Socket both ends, 2 1/2” spigot one end 20 20.76
Part Number Description Ctn Qty List Price
UNION REPAIR SPLIT NUT
SNR150 1 1/2” FBT Repair Split Nut w/ Screw 125 $ 4.73
SNR200 2” FBT REpair Split Nut w/ Screw 100 5.25
SNR Series
1/15/13
12.13
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
CPVC Plastic Fittings - CTS
CPVC CTS Plastic Fitting Features:
• For CPVC copper tube size 1/2” and 3/4”.
• For hot and cold water service.
• Meets ASTM-D-2846.
• NSF Approved.
• Rated 100 PSI at 180ºF, 400 psi at 73ºF.
•14NSF Standard 61
Part Number Size Description Ctn Qty List Price
CPVC Coupling
2429-005 1/2” s x s 25/500 $ 0.36
2429-007 3/4” s x s 25/250 0.45
2429-010 1” s x s 10/100 2.02
2429-101 3/4 x 1/2” s x s 25/250 0.84
2429-131 1” x 3/4” s x s 10/100 2.53
2413-007 3/4 x 3/4” pvc slip x cpvc slip 25/250 1.62
2413-010 1” x 1” pvc slip x cpvc slip 25/100 3.07
CPVC 90º Elbow
2406-005 1/2” s x s 50/500 0.41
2406-007 3/4” s x s 25/250 0.68
2406-010 1” s x s 10/100 1.99
2406-101 3/4 x 1/2” s x s 25/250 1.57
CPVC 90º Street Elbow
2410-005 1/2” ms x fs 25/500 0.52
2410-007 3/4” ms x fs 25/250 0.81
2410-010 1” ms x fs 10/100 3.69
CPVC Drop Ear Elbow
2415-005 1/2” s x s 25/250 1.30
2424-005 1/2” s x ft 25/250 2.43
CPVC 45º Elbow
2417-005 1/2” s x s 50/500 0.55
2417-007 3/4” s x s 25/250 0.96
2417-010 1” s x s 10/100 2.30
CPVC Tee
2401-005 1/2” s x s x s 50/500 0.56
2401-007 3/4” s x s x s 25/250 0.99
2401-010 1” s x s x s 10/100 5.21
2401-094 3/4 x 1/2 x 1/2 s x s x s 25/250 1.95
2401-095 3/4 x 1/2 x 3/4 s x s x s 25/250 1.41
2401-101 3/4 x 3/4 x 1/2 s x s x s 25/250 1.08
2401-125 1” x 3/4” x 3/4” s x s x s 1/25 6.32
2401-126 1” x 3/4” x 1” s x s x s 1/25 9.25
2401-131 1” x 1” x 3/4” s x s x s 10/100 5.65
CPVC Male Adapter
2436-005 1/2” s x mipt 25/250 0.45
2436-007 3/4” s x mipt 25/250 0.77
2436-010 1” s x mipt 10/100 3.46
2429 Series
2406 Series 2410 Series
2401 Series
2415 Series
2436 Series
2417 Series
2424 Series
1/15/13
12.14
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
CPVC Plastic Fittings - CTS
Part Number Size Description Ctn Qty List Price
CPVC Female Adapter
2435-005 1/2” s x fipt 25/250 $ 1.53
2435-007 3/4” s x fipt 25/250 2.18
2435-010 1” s x fipt 10/100 2.47
CPVC Reducing Bushing
2437-101 3/4 x 1/2” spigot x s 25/250 0.54
2437-130 1” x 1/2” spigot x s 10/100 1.78
2437-131 1” x 3/4” spigot x s 10/100 1.78
CPVC Cap
2447-005 1/2” slip 25/500 0.37
2447-007 3/4” slip 25/250 0.50
2447-010 1” slip 10/100 1.83
CPVC to Brass Transition Fittings
2438-005 1/2 x 1/2” cpvc x fipt 10/50 13.35
2439-005 1/2 x 1/2 cpvc x mipt 10/50 13.35
Tubing Straps
2492-005 1/2” 100/1000 0.57
2492-007 3/4” 100/1000 0.46
CPVC Union
2457-005 1/2” slip 10/50 3.88
2457-007 3/4” slip 10/50 5.56
2438 Series
2492 Series
2457 Series
2439 Series
2435 Series
2447 Series
2437 Series
12/13/11
12.15
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Compression Couplings-Imported, PVC/CPVC
MATERIAL SPECIFICATIONS
# Part Material
1 Body UPVC, CPVC
2 Compression Nut UPVC, CPVC
3 Gasket - PVC NR
Gasket - CPVC EPDM
Part Number Material Size Case Qty List Price
PC10-1/2 PVC 1/2” IPS 100 $ 2.56
PC10-3/4 PVC 3/4” IPS 90 2.97
PC10-1 PVC 1” IPS 60 3.84
PC10-11/4 PVC 1 1/4” IPS 40 4.62
PC10-11/2 PVC 1 1/2” IPS 30 6.37
PC10-2 PVC 2” IPS 20 8.87
PC10-21/2 PVC 2 1/2” IPS 10 20.26
PC10-3 PVC 3” IPS 4 28.67
PC10-4 PVC 4” IPS 2 37.83
PC10-6 PVC 6” IPS 2 91.00
HW10CTS1/2 CPVC 1/2” CTS 20/360 4.48
HW10CTS3/4 CPVC 3/4” CTS 20/240 5.42
PVC Compressing Coupling Features:
• Iron Pipe Size (PVC), Copper Tube Size (CPVC)
• For use with cold water (PVC) or hot water (CPVC-CTS)
• Natural rubber gasket seals
• Rated at 200 psi at 70°F
• Imported
"PC" Series IPS DIMENSIONS (IN.)
SIZE D d d1 L
1/2” 1.85 .91 .83 5.24
3/4” 2.09 1.18 1.04 5.32
1” 2.40 1.42 1.31 5.75
1 1/4” 2.87 1.81 1.65 6.30
1 1/2” 3.15 2.05 1.89 6.89
2” 3.62 2.56 2.37 7.87
2 1/2” 4.53 2.52 2.87 9.92
3” 5.28 3.62 3.49 10.87
4” 6.34 4.65 4.49 11.93
6” 8.78 6.85 6.62 11.22
"HW" Series CTS DIMENSIONS (IN.)
1/2” 1.30 .71 .63 4.49
3/4” 1.85 .95 .88 5.00
For Use with
Part Number Coupling Sizes Ctn Qty List Price
Adjustable Strap Wrench
SW400 1/2” through 4” 10/60 $ 19.47
SW600 1/2” through 6” 10/60 22.05
SW Series
1/15/13
12.16
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Compression Fittings, Galvanized
Recommended Maximum Pressure(PSI)
Size Torque Anchored
Ft. Lbs Piping
1/2” 150 150
3/4” 150 150
1” 225 100
1-1/4” 225 100
1-1/2” 225 100
2” 300 75
Galvanized Long Pattern Compression Fitting Features:
• Bodies made of steel tubing (GC10), malleable iron (GC10C)
• End nuts made of malleable iron.
• Galvanized finish
• Buna-N gaskets on domestic fittings.
• SBR gaskets on GC10C series.
• Maximum rated service temperature for gaskets: 212°F (100º C).
• GC10C manufactured for AGI in an ISO9002 facility.
WARNING: Designer and/or contractor must provide suitable anchor-
ing of piping to prevent pull-out from fittings when applications sub-
ject piping to external forces such as ground shift and temperature
variations that cause linear pipe contraction.
GC10C Series
GC10 Series
GC12 Series
ISO 9002
Coupling GC10C - Long Pattern - Imported - Malleable Iron, 125 PSI, 120° F
Part Number Size Pipe O.D. Ctn/Case Qty List Price
GC10C1/2 1/2” .840 30 / 60 $ 11.89
GC10C3/4 3/4” 1.050 25 / 50 13.33
GC10C1 1” 1.315 15 / 30 15.65
GC10C11/4 1-1/4” 1.660 12 / 24 19.86
GC10C11/2 1-1/2” 1.900 9 / 18 23.54
GC10C2 2” 2.375 14 35.21
Coupling GC10 - Made in U.S.A. - Steel Tube
Part Number Size Pipe O.D. Ctn Qty List Price
GC10-1/2 1/2” .840 12 $ 28.23
GC10-3/4 3/4” 1.050 12 30.78
GC10-1 1” 1.315 12 36.34
GC10-11/4 1-1/4” 1.660 6 48.53
GC10-11/2 1-1/2” 1.900 6 53.60
GC10-2 2” 2.375 6 67.36
Adapters GC12 - Made in U.S.A. - Steel Tube
Part Number Size Pipe O.D. Ctn Qty List Price
GC12-1/2 1/2” .840 12 $ 39.75
GC12-3/4 3/4” 1.050 12 41.61
GC12-1 1” 1.315 12 42.14
GC12-11/4 1-1/4” 1.660 6 50.09
GC12-11/2 1-1/2” 1.900 6 69.65
GC12-2 2” 2.375 6 69.78
