KL-8215 Power Supply
This power supply is designed for used in the Step/Servo
motor drive and high over loaded applications. It will work
on both standard 115V and 230V at 50Hz or 60Hz. This
toroidal transformer has heavier gauge wires then the normal
requirement to avoid the copper lost during the full load
output and over load output.
The power supply has a flexible add on option that allows
more outputs as needed. Those isolated outputs can be used
as logic control or encoder power supply. The main output
has 2 large capacitors (10000uF x2) to guaranty the output
ripple to minimum.
The chassis is made of 3/32” thick aluminum for strength and
heat dissipation from rectifier and linear regulators. It will
work continuous without an
y
over heat
p
roblem.
KELING INC.
www.kelingInc.net
Volta
g
e out
p
ut 1 Out
p
ut current
82.0 V 0
Volta
g
e ri
pp
le
0
Out
p
ut 2
5.0 V*
78.2 V 5.7 A .68 Vrms 5.0 V*
75.0 V 14.2 A 1.1 Vrms 5.0 V*
70.6 V 17.4 A 1.6 Vrms 5.0 V*
- - - -
- - - -
- - - -
Input voltage is 120Vac at
60Hz.
* linear regulated output at
1A max.
Note:
AC power connections:
115Vac – 2 red wires to neutral & 2 black wires to hot.
220Vac – 1st red wire to neutral, 1st black wire to 2nd red wire, and
the 2nd black wire to hot.
68.5 V 22.3 A 2.4 Vrms 5.0 V*
Out
p
ut 3
-
-
-
-
-
-
-
-
_
+
_
+
_
+
XYZ
To Z motor driver power
To Y motor driver power
To X motor driver power
Fuse Z
Fuse Y
Fuse X
5Vdc 1A regulated
Ø 0.25" Mounting holes x4
_
+
4.5
6.3
8.9
5.1
115V
Black
Red
2
3
Red
Black
1
C
-
+
-
+
LM78xx
DC output
unregulated
1A regulated
115V
