Linear Guide Applicaon Sheet

Rail Width: mm (3, 5, 7, 9, 12, 15, 20, 25, 30, 35, 45, 55, 65)

mm inches

*Denotes Standard Opon

Rail Length:

Linear Block Requirements:

Height of Assembly:

S: Low-Assembly

C: Middle Assembly H: High Assembly

Flange Type:

F: With Flange V: Without Flange

Length of Block:

S: Short N: Normal L: Long E: Extra Long

Accuracy Grade

N: Normal H: High P: Precision

SP: Super Precision

Preload:

ZF: Slight Clearance Z0: No Preload Z1: Light Preload

Z2: Medium Preload

End Seals:

U: Inner Seal UZ: Double Seals

UP: Ultra Precision

Z3: Heavy Preload































 











S: Standard

Please return via fax or email: (714) 992-0471, applications@anaheimautomation.com
