LIN Slave Driver
How to Get Started
Changes Date Name
Short
0.1 – Initial draft 2013-05-06 Barbara Rögl BR
1.0 – Initial release 2013-05-29 Barbara Rögl BR
1.1 – Corrected cycle time for ISR routine in
polling mode, removed HW reference 2013-11-21 Barbara Rögl BR
1.2 – Added Quick Start Instructions 2015-08-28 Paul Park / Barbara
Rögl PP & BR
ihr GmbH
Airport Boulevard B210
77836 Rheinmuenster
Tel.: +49 7229 / 18475-0
Fax: +49 7229 / 18475-11
homepage: http://www.ihr.de
e-mail: ihr-online@ihr.de
Author Barbara Rögl
Version 1.2
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 2 of 11
1
REFERENCES ..................................................................................................................................................... 3
2
LIN DETAILS ....................................................................................................................................................... 3
3
QUICK START STEP-BY-STEP INSTRUCTIONS ........................................................................................ 4
3.1
D
OWNLOAD
LDS
P
ACKAGE FROM IHR
S
ERVER
. ............................................................................................... 4
3.2
E
XTRACT
LDS
P
ACKAGE
&
V
ERIFY
C
ONTENTS
............................................................................................... 4
3.3
C
OMPILE
D
EMO
A
PPLICATION
P
ROJECT
.......................................................................................................... 4
3.4
G
ENERATE
N
EW
C
ONFIGURATION
F
ILES
(LDC-T
OOL
) ................................................................................... 4
3.5
C
OPY
C
ONFIGURATION
F
ILES INTO
LIN
S
TACK
F
OLDER
................................................................................. 4
3.6
C
OPY
LIN
S
TACK INTO
E
XISTING
P
ROJECT
...................................................................................................... 4
3.7
I
MPLEMENT
I
NITIALIZATION OF
I/O,
I
NTERRUPTS
,
LIN
T
ASK
C
YCLE
............................................................ 4
4
LDC-TOOL CONFIGURATION ....................................................................................................................... 5
5
NECESSARY CALLBACK FUNCTIONS ........................................................................................................ 5
5.1
L
_
IRQMASK L
_
SYS
_
IRQ
_
DISABLE
(
VOID
) ........................................................................................................... 5
5.2
VOID L
_
SYS
_
IRQ
_
RESTORE
(
L
_
IRQMASK MASK
)................................................................................................ 5
5.3
VOID
LIN_E
NABLE
_T
RANSCEIVER
(
VOID
) ........................................................................................................ 5
5.4
VOID
LIN_D
ISABLE
_T
RANSCEIVER
(
VOID
) ....................................................................................................... 5
6
NECESSARY CALLS IN APPLICATION ........................................................................................................ 6
6.1
L
_
IFC
_
RX
() .......................................................................................................................................................... 6
6.2
L
_
CYCLIC
_
COM
_
TASK
() ..................................................................................................................................... 6
6.3
LD
_
TASK
() ........................................................................................................................................................... 6
6.4
L
_
SYS
_
INIT
() ........................................................................................................................................................ 6
7
PSEUDO CODE FOR MINIMALISTIC DRIVER INTEGRATION: ............................................................ 7
8
OTHER RECOMMENDED CALLS .................................................................................................................. 8
8.1
L
_
IFC
_
READ
_
STATUS
()........................................................................................................................................ 8
8.2
F
RAME AND
S
IGNAL
U
PDATE
F
LAGS
.................................................................................................................. 8
8.3
R
EAD AND
W
RITE
S
IGNAL
A
CCESS
.................................................................................................................... 8
9
DIAGNOSTIC MESSAGE HANDLING ........................................................................................................... 9
9.1
U
SER DEFINED DIAGNOSTICS
.............................................................................................................................. 9
9.2
C
OOKED
API ..................................................................................................................................................... 10
9.3
R
AW
API ........................................................................................................................................................... 11
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 3 of 11
1 References
No. Document/Description Rev./
Date
1 LIN Driver API Description M&S v1.1 2010-10-28.pdf 1.1
2 User Guide – LDC-Tool.pdf 2.0.x.x
3 Release Notes – LDC-Tool.pdf 2.0.x.x
4 LIN Specification 1.3 1.3
5 LIN Specification 2.0 2.0
6 LIN Specification 2.1 2.1
2 LIN Details
LIN Version supported 1.3, 2.0 (tested), 2.1 (tested)
Diagnostic Api RAW API (LIN 2.0, 2.1),
Cooked (LIN 2.0, 2.1)
Baudrate 2400, 9600, 10417, 19200 (tested), 20000 bps
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 4 of 11
3 Quick Start Step-by-Step Instructions
3.1 Download LDS Package from ihr Server.
3.2 Extract LDS Package & Verify Contents
1. LDS-Pack: Demo Application (main.c and main.h) and LIN Driver stack (/Protocol and /Hal folder
or for older packages /LIN_DRIVER)
2. LDC-Tool: LIN Configuration generation tool (generates configuration files genLinConfig.c and .h)
3. Documents: All documentation for LIN Driver Package
3.3 Compile Demo Application Project
Verify that the Demo Application provided with LIN Driver package compiles using the IDE and Compiler
installed on the user’s machine.
3.4 Generate New Configuration Files (LDC-Tool)
Using the LDC-Tool, create a new set of configuration files (genLinConfig.c and genLinConfig.h) using the
application-specific LIN Description File (LDF). For further information on using the LDC-Tool, please
consult [2].
3.5 Copy Configuration Files into LIN Stack Folder
Copy the genLinConfig.c and genLinConfig.h files from LDC-Tool into LIN_Driver folder, overwriting the
configuration files from the Demo Application.
3.6 Copy LIN Stack into Existing Project
Copy the LIN Stack with updated configuration files (/Protocol and /Hal folder or for older packages
/LIN_DRIVER) into the Main Application project.
3.7 Implement Initialization of I/O, Interrupts, LIN Task Cycle
1. Setup UART RX/TX pins as Input/Output pins respectively to make sure there is no bus
disturbance while the UART peripheral is not yet initialized or when it does not control the pins
during re-initialization.
2. Define UART Interrupt Service Routine, and call l_ifc_rx() routine inside UART ISR.
3. Call l_cyclic_com_task() routine inside UART ISR. Alternatively, setup fast task cycle (check the
datasheet for more detailed information on timing requirements).
4. Setup LIN Task Cycle as defined in LDC-Tool “Operation Mode” and call ld_task() routine inside
LIN Task Cycle.
5. Verify that the LIN tasks are protected from IRQs as necessary (check the datasheet for more
detailed information or “AN001 LIN Driver Integration – Interrupt Protection V1.0.pdf”
Please use Demo Application provided (main.c & main.h) as a reference when implementing these
functions into user’s Main Application.
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 5 of 11
4 LDC-Tool Configuration
The first step in a new project is to choose a new LDF (LIN Definition File) and generated the driver stack
accordingly with the files generated by the LDC-Tool. For further information how to use the LDC-Tool
please see [2].
The two files have to be put in the correct build directories so that the compiler is able to find all
necessary files.
5 Necessary Callback functions
The user’s application has to implement several calls that the API requires.
5.1 l_irqmask l_sys_irq_disable (void)
This function will activate or deactivate the interrupt of the UART / SCI so that the data can be fetched
from or written to registers without interference from possible interrupts. This function is used within the
driver. Usually the LIN is slow enough that the data can be fetched without filling the call, the latency for
calling the ISR is usually less that one byte.
5.2 void l_sys_irq_restore (l_irqmask mask)
This function will reactivate the interrupts after reading from / writing to registers.
5.3 void LIN_Enable_Transceiver (void)
This function will enable the transceiver if the transceiver is to be enabled via a pin externally during
startup initialization. If the user’s application does not wish that the enable is set during initialization
routines, this function has to be left blank.
5.4 void LIN_Disable_Transceiver (void)
This function will disable the transceiver if the transceiver is to be enabled via a pin externally. However
this function is never called within the driver. Going to sleep and waking up should be done in the
application.
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 6 of 11
6 Necessary calls in application
The driver itself consists of three tasks that have to be embedded into the application and one
initialization routine.
6.1 l_ifc_rx()
This is the ISR of the driver. This function will check the state of the UART / SCI registers and react
accordingly. It will also fetch the data from the receive register and put it into a temporary buffer to
process later by a cyclic call.
The interval this function has to be called in polling mode varies depending on the UART / SCI of the
device. If the UART / SCI has a buffer of at least one byte available the function has to be called once
each byte. If the UART /SCI has no such buffer the function has to be called once per bit time.
6.2 l_cyclic_com_task()
This is the fast cyclic task. It will process the data fetched by the l_ifc_rx() function and therefore has only
workload if data was received. It can be called immediately after the l_ifc_rx() in the ISR (if interrupt mode
is used) if the interrupt load and latency for other interrupts with lower priority is allowing this. Another
method would be to call it cyclically in the application, when used this way, it has to be called at least
once each byte-time. It does not matter if it is called more frequently, because the workload is only
generated by data marked for processing by the ISR.
6.3 ld_task()
This task has two major responsibilities:
• It is used as time base of the driver to calculate timeouts. The cyclic time is configured in the
LDC-Tool. This includes timeout when using baud rate synchronization, timeout if a frame was
not finished within a very generous timeslot (usually a timeout is recognized after not receiving a
byte for 10ms), diagnostic messages timeout.
• It also handles the diagnostic messages. The configuration messages are handled directly by the
configuration layer within the driver. When using user defined diagnostics, cooked or raw API all
other diagnostic requests are forwarded to the application. Please see chapter diagnostics for
further information.
6.4 l_sys_init()
This function will initialize the driver and UART / SCI for LIN communication according to the chosen LDF.
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 7 of 11
7 Pseudo code for minimalistic driver integration:
int main(void)
{
l_sys_init(); /* initialize LIN stack */
while(1)
{
l_cyclic_com_task(); /* call task every loop */
if(1ms_timer) /* call function every 1ms */
{
ld_task();
}
}
}
void interrupt_handler (void)
{
if (RX IRQ)
{
l_ifc_rx(); /* call ISR function */
}
}
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 8 of 11
8 Other Recommended Calls
8.1 l_ifc_read_status()
This statusword is defined for LIN 2.0 and LIN 2.1 and contains useful state information about the LIN
communication. The word is deleted once it is called, so if there is information available, the user can be
sure that it is new information.
The statusbyte consist of 16 bit where the higher 8 bits contains the PID of the last transmitted frame and
the lower 8 bits are status information.
8.2 Frame and Signal Update Flags
For subscribed frames there exists a update flag framework that allows checking for new available
information independently from every other state information. If an update flag is set the frame was
successfully received and the data is consistent and can be used by application. Additional checks
according to valid range and values may be user specific and have to be implemented by the application
engineer accordingly. The macro for flag checks and clearing can be found in the genlinconfig.h file (part
Signal Access Macros).
8.3 Read and Write Signal Access
These macros are as defined by LIN specifications. It allows easy access to LIN signals without bothering
about their actual position in the frame data or byte borders. They are also found in the genlinconfig.h file
(part Signal Access Macros).
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 9 of 11
9 Diagnostic Message Handling
The driver stack supports different kinds of diagnostics. The simplest ones are the node configuration
services specified in LIN specification. The LDC-Tool has a tab for configuring them separately. Each
service can be activated or deactivated. No additional diagnostic API is needed for this (Class I).
Classes II and III need additional services which are not covered by the LIN specification. There are 3
different ways to achieve this.
The driver demo does not include diagnostic or node configuration services.
9.1 User defined diagnostics
This method allows the application engineer to define the behaviour of the driver upon receiving
diagnostic messages on his own.
No retransmission is made on errors, so complete flow control has to be implemented in the application.
This method has the advantage that the code size of the driver is smaller than with the other two APIs.
The LDC-Tool gives here the option to at least activate the mandatory node configuration services
(otherwise they have to be implemented anew).
A small example is given in the main.c of the driver delivery.
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 10 of 11
9.2 Cooked API
This API has a very good flow control, and diagnostic message headers and formatting is done by the
driver itself. Supports multi frame diagnostics automatically. This API does not allow setting the first three
bytes of a single frame (NAD, PCI, and SID) and the first four bytes of a multiframe message (NAD, PCI,
LEN, and SID). This formatting is defined by LIN specification.
If a transmission error occurred, frame is automatically retransmitted. No header is responded to if no
diagnostic message was buffered.
Example:
/* Diagnostic Handling */
switch (lin_diag_statemachine)
{
case 0u:
/* Start diagnostic state machine
* Prepare buffer and wait for masterrequest */
ld_receive_message (&lin_diag_buffer_length, lin_diag_buffer);
lin_diag_statemachine++;
break;
case 1u:
if (ld_rx_status() > LD_COMPLETED)
{
/* some error occured, dummy implementation - reset transport layer
* and restart diagnostic */
ld_init();
lin_diag_statemachine = 0u;
} else {
if (ld_rx_status() != LD_IN_PROGRESS)
{
/* Buffer is filled with data, check data and prepare response */
/* dummy implementation - send data received back as response */
ld_send_message (lin_diag_buffer_length, lin_diag_buffer);
lin_diag_statemachine++;
}
}
break;
case 2u:
if (ld_tx_status() > LD_COMPLETED)
{
/* some error occured, dummy implementation - reset transport layer
* and restart diagnostic */
ld_init();
lin_diag_statemachine = 0u;
} else {
if (ld_tx_status() == LD_COMPLETED)
{
lin_diag_statemachine = 0u;
}
}
break;
default:
break;
}
Author: B.Rögl
Version: V1.2
Date: 2015-08-28
LIN Slave Driver
How to Get Started
LDS_Driver_Startup_Guide_V1.2.doc page 11 of 11
9.3 Raw API
This API also supports multi frame diagnostics. But assembling and disassembling of messages as well
as formatting has to be done by the application engineer. This API allows setting all bytes of a diagnostic
frame as by the application engineer desired. The first bytes are not restricted to NAD, PCI and SID
information.
If a transmission error occurred, frame is automatically retransmitted. No header is responded to if no
diagnostic message was put into queue.
Example:
/* Diagnostic Handling */
switch (lin_diag_statemachine)
{
case 0u:
/* Start diagnostic state machine
* Prepare buffer and wait for masterrequest */
if (ld_raw_rx_status() == LD_DATA_AVAILABLE)
{
ld_get_raw(data_buffer);
lin_diag_statemachine = 1;
}
break;
case 1u:
if (ld_raw_tx_status() <= LD_QUEUE_AVAILABLE)
{
/* put two frames into transmit queue*/
ld_put_raw (data_buffer);
lin_diag_statemachine++;
}
break;
case 2u:
if (ld_raw_tx_status() > LD_TRANSMIT_ERROR)
{
/* some error occured, dummy implementation - reset transport layer
* and restart diagnostic */
ld_init();
lin_diag_statemachine = 0u;
} else {
if (ld_raw_tx_status() == LD_QUEUE_EMPTY)
{
lin_diag_statemachine = 0u;
}
}
break;
default:
break;
}
