MIXING CONSOLES

3

rd series

RD is LEM’s recent series of mixing consoles designed for getting the most

out of small P.A. systems as used by musicians, for home recording, multi-

media systems and small permanent installations.

All RD models feature mono channels with mic/line input and phantom

power supply and two stereo line input channels. Each channel has low-cut

filters, 3 band EQ, 2 auxiliary sends, Solo function, peak led and sliders.

RD 122 fx is also equipped with sweepable mid EQ, 3 aux sends and

selectable input sensitivity for stereo channels. The FX versions have a

built-in processor which is loaded with 16 practical preset banks where users

can choose between various reverbs, mono and stereo delays and combined

effects.

But this is not all: the Variations section adds 16 different settings (decay,

depth, harmonic content, etc.) to the selected preset, for a total of 256 pos-

sible combinations.

rd 82 fx

4 mic/line input channels

with Phantom power

low cut filter

2 stereo input channels

3 bands EQ

2 aux sends

solo with peak LED

45mm sliders

1 stereo return on master

1 return on monitor

balanced & unbalanced master outs

control room out

24 bit built-in digital effect processor

256 presets

12 LED bargraphs

246 x 73 x 306mm (L x H x D)

2,9kg

rd 82

4 mic/line input channels

with phantom power

low cut filter

2 stereo input channels

3 bands EQ

2 aux sends

solo with peak LED

45mm sliders

1 stereo return on master

1 return on monitor

balanced & unbalanced master outs

control room out

12 LED bargraphs

246 x 73 x 306mm (L x H x D)

2,9kg

LEM

Ever since its foundation in 1969, the Italian

sound reinforcement brand LEM has been

working with Italy’s finest artists and entertain-

ment shows. Based on the expertise achieved

in more than 30 years of continuous Research

and Development activity in the sector, LEM’s

goal is to produce innovative solutions wherever

a high sound quality is important.

From this approach derive state-of-the-art

products with vanguard technology, as a 40 bit

digital processor featuring a proprietary LEM

DSP, editor software for the control of

processing functions in the digital integrated

loudspeaker systems, high resolution 24 bit

converters, custom made loudspeakers, reliable

components and newest materials such as

neodymium together with an all-over product

design made in Italy.

LEM Professional Sound systems are chosen for

a wide range of applications, both indoor and

outdoor: installations, concerts, gigging bands,

theatres, discos and special events.

MIXING CONSOLES

5

rx series

Given the increasing demand of all-in-one systems, LEM has designed

the RX powered mixing consoles, where the big plus is to have

a single feature-packed device which manages the audio sources as

microphones and instruments, the effects and the speaker’s amplification.

LEM has also paid attention to easy handling and transport for these reliable

and great sounding tools: every part has been optimized by our engineers.

The power amplifiers feature oversized components assuring a trouble-free

nominal power supply.

Both models include a high quality 24 bit DSP which provides reverb, delay,

chorus, flanger and combined effects. 16 Preset banks with 16 variations

are available, for a total of 256 different effects (16 effects in RX 200).

rx 300

4 mono input channels

with phantom power

low cut filter

2 stereo input channels

3 bands Eq

2 aux sends

PFL and peak LED

45mm sliders

1 stereo return with monitor assign

sound processor on the main outs

with high and low enhancer

master out with insert and mono out

8 LED bargraphs

built-in power amplifier

150 + 150W on 8 Ohm

anti-clipping circuit

364 x 149 x 390mm (L x H x D)

8kg

MIXING CONSOLES

4

rd 122 fx

8 mic/line input channels

with phantom power

low cut filter and insert point

2 stereo input channels

3 bands Eq with sweep mid

3 aux sends

solo, mute and peak LED

ALT assign

60 mm sliders

1 stereo return on master

1 return on monitor

balanced & unbalanced master outs

insert point on master outs

control room out

24 bit built-in digital effect processor

256 presets

12 LED bargraphs

392 x 392 x 80mm (L x H x D)

6kg

rd 122

8 mic/line input channels

with phantom power

low cut filter and insert point

2 stereo input channels

3 band Eq with sweep mid

3 aux sends

solo, mute and peak LED

ALT assign

60mm sliders

1 stereo return on master

1 return on monitor

balanced & unbalanced master outs

insert point on master outs

12 LED bargraphs

392 x 392 x 80mm (L x H x D)

6kg

rx 200

4 mono input channels

2 stereo input channels

3 bands Eq

1 aux send

phantom power

24 bit built-in digital effect processor

16 presets

built-in power amplifier

100+100W on 4 Ohm

257 x 277 x 102mm (L x H x D)

5kg

7

MIXING CONSOLES

6

swing 32

24 mono input channels

4 stereo input channels

3 bands Eq with sweep mid

PFL/mute/assign

insert point

direct outputs

2 aux pre

2 aux pre/post

2 aux post

phantom power

100mm sliders

4 groups

mix b/control room outs

960 x 95 x 505mm (L x H x D)

16kg

swing 32

Thanks to the sophisticated set of features, the advanced technical solutions

and the high audio quality, Swing 32 is a professional console suitable for

the most demanding applications.

Swing 32 features 24 mono and 4 stereo channels, for a total of 32 inputs,

insert points on all microphone channels, a 3-band EQ with lo-cut and

sweep mid, solo function AFL and PFL and balanced master outputs with

xlr and jack trs connectors.

The superior audio quality is provided by lownoise, high-grade microphone

preamps, low-tolerance electronic components and accurate circuitry

designed to guarantee the maximum dynamics without distortion.

COMPACT P.A. SYSTEMS

system 200

System 200 is a very compact amplification system, which integrates RX 200

powered mixer, two reliable PFM 10.2 loudspeakers, a LM20 dynamic

microphone and a complete set of connection cables.

System 200 has been conceived for the maximum simplicity in handling

and transport and is an ideal solution for small P.A. applications, live or

recorded music to voice amplification, in conference rooms, public venues

or domestic systems.

system 200

rx 200 powered mixer

4 mono input channels

2 stereo input channels

phantom power

3 bands Eq

1 aux send

24 bit built-in digital effect processor

16 presets

built-in power amplifier

100+100 W on 4 Ohm

257 x 277 x 102mm (L x H x D)

5kg

2 pfm 10.2 on 4 Ohm

1 10" woofer

1 horn loaded tweeter

100W on 4 Ohm

340 x 458 x 285mm (L x H x D)

9kg

LM20 dynamic mic

with cardioids polar pattern

set of connection cables

AMPLIFIERS

8

AMPLIFIERS

9

procon series

Procon power amplifiers have been developed to provide great efficiency,

dynamics and reliability levels at a very affordable price. The accurately

designed circuitry and the selected components offer an excellent sound

quality and high fidelity audio reproduction in a metal chassis that assures

maximum sturdiness.

procon 400

2 x 200W on 4 Ohm, 2 x 125W on 8 Ohm, 2 rack units, 11kg

procon 750

2 x 375W on 4 Ohm, 2 x 215W on 8 Ohm, 2 rack units, 12,8kg

procon 950

2 x 475W on 4 Ohm, 2 x 275W on 8 Ohm, 2 rack units, 14,6kg

procon 1250

2 x 625W on 4 Ohm, 2 x 375W on 8 Ohm, 2 rack units, 18kg

procon 1500

2 x 750W on 4 Ohm, 2 x 450W on 8 Ohm, 2 rack units, 20kg

pfx 1.3

pfx 1.3

The switching power amplifier PFX 1.3 is designed to satisfy the professional

user requirements in the most demanding sound reinforcement applications.

PFX 1.3 is a class H-power amplifier with switching technology SMPS

(Switching Mode Power Supply). This technology offers increased efficiency

and better control of heat dissipation than conventional power supply

systems and a drastic reduction of dimensions and weight, for easy

transportation and handling.

650 + 650W on 4 Ohm

450 + 450W on 8 Ohm

1300W bridged 8 Ohm

thermal protection

reactive load driving capability

on/off mute

AC and DC protection

clip limiter

dual or bridge mode

combo connectors

speakon connectors

binding post

2 rack units

11,3kg

SPEAKERS

12

SPEAKERS

13

performance series

The Performance loudspeaker series (PFM) provides the most convenient

solution for a wide range of permanent and portable amplification systems

and offers a crisp and powerful sound, accurate construction and total

reliability. Versatile and efficient tools for live musicians, the Performance

loudspeakers are also suitable for installations in clubs, pubs, and public

venues.

At an optimum price/quality ratio, PFM loudspeakers feature a niobium horn

tweeter with polycarbonate diaphragm for the top end, ensuring brightness

and frequency extension. An electronic circuit protects the tweeter against

any possible overload for maximum reliability. The custom made woofers

deliver a tight bass with an even and smooth response. PFM cabinets are

lightweight and durable.

pfm 12.2 active

built-in 150W power amplifier

1 niobium tweeter

12" woofer

chipboard cabinet with blue carpet

and metal grid

390 x 508 x 325mm (L x H x D)

15,5kg

pfm 12.2

passive version

150W on 8 Ohm

11,5kg

pfm 10.2 active

built-in 100W power amplifier

1 niobium tweeter

10" woofer

chipboard cabinet with blue carpet

and metal grid

340 x 458 x 285mm (L x H x D)

12kg

pfm 10.2

passive version

100W on 8 Ohm

9kg

pfm 15.2 active

built-in 250W power amplifier

1 niobium tweeter

15" woofer

chipboard cabinet with blue carpet

and metal grid

458 x 578 x 405mm (L x H x D)

21,5kg

pfm 15.2

passive version

250W on 8 or 4 Ohm

16,5kg

pfm 15.3 active

built-in 250W power amplifier

for low section

built-in 80W power amplifier

for mid-high section

1 niobium tweeter

8" midrange

15" woofer

chipboard cabinet with blue carpet

and metal grid

482 x 608 x 405mm (L x H x D)

24,5kg

pfm 15.3

passive version

250W on 8 or 4 Ohm

19,5kg

pfm 15 sub active

built-in 350W power amplifier

internal electronic crossover

15" woofer

chipboard cabinet with blue carpet

and metal grid

470 x 508 x 478mm (L x H x D)

24,5kg

pfm 15 sub

passive version

350W on 4 Ohm

19,5kg

SPEAKERS

14

SPEAKERS

15

pfm 18 sub active

built-in 350W power amplifier

internal electronic cross-over

18" woofer

chipboard cabinet with blue carpet

and metal grid

630 x 540 x 550mm (L x H x D)

35kg

pfm 18 sub

passive version

350W on 4 Ohm

28,5kg

pfm 15.3 xl

500W on 4 Ohm power handling

1" driver loaded on ewt™ horn

2 x 15" woofer

speakon connectors

chipboard cabinet with blue carpet

and metal grid

477 x 1052 x 430mm (L x H x D)

27kg

pfm 8 ma

stage monitor

built-in 100W power amplifier

8" wide-range double cone

chipboard cabinet with blue carpet

and metal grid

305 x 395 x 275mm (L x H x D)

11,5kg

pfm 12.2 ma

stage monitor

built-in 250W power amplifier

1 niobium tweeter

12" woofer

chipboard cabinet with blue carpet

and metal grid

390 x 508 x 325mm (L x H x D)

15kg

pfm 15.2 ma

stage monitor

built-in 250W power amplifier

1 niobium tweeter

15" woofer

chipboard cabinet with blue carpet

and metal grid

450 x 572 x 400mm (L x H x D)

21,5kg

titanium series

17

Titanium is the new loudspeaker series with digital processor and cabinet

in plywood with a contemporary design. LEM has developed Titanium

as one of the first system of this type to combine a powerful digital

processor and the most advanced solutions as far as speaker construction

and the integrated power amplifier are concerned, positioning Titanium

on the top of its category for price/performance ratio.

Titanium’s digital processor features a 24 bit low-noise conversion system

and a 40 bit processing power and performs with the highest precision.

The processor’s 16 presets have been studied by our sound engineers in

order to provide the system with different acoustical and dynamic responses

in a vast series of applications.

All active versions feature bi-amplification modules able to drive each single

speaker with high dynamic range and real power values. The Titanium

series has been conceived for touring systems, live performances

and all permanent installations where the best acoustic results and high

performances in terms of reliability and efficiency are of the essence.

T4A

1" compression driver

horn loaded (100x60°)

12" neodimium woofer

built-in bi-amplification

300+100W

internal digital processor

with 16 presets

cabinet in plywood, scratch-resistant

paint, metal grid

400 x 608 x 390mm (L x H x D)

25kg

T300

passive version

300W on 8 or 4Ohm

400 x 608 x 340mm (L x H x D)

17,5kg

T3A

1" compression driver

horn loaded (90x65°)

10" woofer

built-in bi-amplification

200+100W

internal digital processor

with 16 presets

cabinet in plywood, scratch-resistant

paint, metal grid

357 x 490 x 355mm (L x H x D)

22kg

T200

passive version

200W on 8 Ohm

357 x 490 x 305mm (L x H x D)

14,5kg

SPEAKERS

SPEAKERS

19

T4MA

SPEAKERS

18

12" coaxial woofer

1" compression driver

horn loaded

built-in bi-amplification

250+50W

internal digital processor

with presets

cabinet in plywood, scratch-resistant

paint, metal grid

506 x 326 x 422mm (L x H x D)

26kg

T5MA

15" coaxial woofer

1" compression driver

horn loaded

built-in bi-amplification

100+350W

internal digital processor

with presets

cabinet in plywood, scratch-resistant

paint, metal grid

586 x 356 x 495mm (L x H x D)

33,5kg

T5A

1" compression driver

horn loaded (100x60°)

15" neodimium woofer

built-in bi-amplification

400+100W

internal digital processor

with 16 presets

cabinet in plywood, scratch-resistant

paint, metal grid

456 x 690 x 430mm (L x H x D)

32kg

T400

passive version

400W on 8 or 4 Ohm

456 x 690 x 380mm (L x H x D)

22,5kg

T5SA

15" neodimium sub

built-in 500W power amplifier

internal digital processor

with presets

cabinet in plywood, scratch-resistant

paint, metal grid

466 x 600 x 600mm (L x H x D)

43,5kg

T6A

1" compression driver

horn loaded (90x65°)

8" midrange

15" neodimium woofer

built-in bi-amplification

400+200W

internal digital processor

with 16 presets

cabinet in plywood, scratch-resistant

paint, metal grid

456 x 804 x 430mm (L x H x D)

37kg

T500

passive version

500W on 8 or 4 Ohm

456 x 804 x 380mm (L x H x D)

28kg

rear panel

SPEAKERS

21

SPEAKERS

20

sp series

The SP series is a set of multi-purpose professional speaker systems

developed for portable amplification sets-ups, live and studio performances

and a number of other installation possibilities.

The three models, SP live, SP media and SP sub, are equipped with a

powerful internal amplifier which allows simple and efficient multi-way

amplification systems to be set up. SP series are easily handled by one

person as the speaker cabinets are equipped with a special mounting

system which includes four different hugging points.

SP series offer an impressive sound quality in a surprisingly compact and

lightweight design.

sp media active

built-in 90W power amplifier

1" tweeter on ewt™ horn

6" woofer

cabinet in polypropylene with

mineral fibres

194 x 300 x 251mm (L x H x D)

6,8kg

sp media

passive version

90W on 8 Ohm

4,6kg

sp live active

built-in 90W power amplifier

6,5" wide-range

cabinet in polypropylene with

mineral fibres

194 x 300 x 251mm (L x H x D)

6,2kg

sp live

passive version

90W on 8 Ohm

4kg

sp sub active

built-in 350W power amplifier

stereo inputs and outputs

built-in electronic crossover with

variable frequency

12" woofer

cabinet in polypropylene with

mineral fibres

530 x 386 x 443mm (L x H x D)

21,5kg

totem system

stack system

T system

SPEAKERS

23

SPEAKERS

22

spx series

Derived from the highly successful SP systems, SPX are a series of speakers

for all those applications that require the maximum durability and studio-quality

sound.

The SPX speakers are equipped with a powerful internal amplifier.

The speaker cabinets of SPX live and SPX media are made of polypropylene -

reinforced with mineral fibres -, whereas the cabinet of the sub is in MDF.

The elegant cabinet grants durability, easy transportation versatile setups and

an excellent dimension/power ratio.

SPX utilize the same high-quality custom LEM speakers as the SP series offering

a linear frequency response without distortion. All amplifiers are equipped with

an anti-clipping circuit and feature highly professional connection panels.

spx media active

built-in 90W power amplifier

1" tweeter on ewt™ horn

6" woofer

cabinet in polypropylene with

mineral fibres

194 x 300 x 220mm (L x H x D)

6,8kg

spx media

passive version

90W on 8 Ohm

4,6kg

spx live active

built-in 90W power amplifier

6,5" wide-range

cabinet in polypropylene with

mineral fibres

194 x 300 x 220mm (L x H x D)

6,2kg

spx live

passive version

90W on 8 Ohm

4,6kg

spx sub active

built-in 350W power amplifier

stereo inputs and outputs

built-in electronic crossover with

variable frequency

12" woofer

MDF cabinet

486 x 340 x 350mm (L x H x D)

24kg

rear panel

25

d400

D400 is one of the first speakers in its category to combine a powerful digital

processor with state-of-the-art solutions as far as loudspeakers, power ampli-

fiers and cabinets are concerned. The integrated digital processor features

a 24 bit low-noise conversion system and a 40 bit processing power and

performs with the highest precision. The processor’s 16 presets - utilising

EQ, crossover settings, multiband compression, noise gate and anti-feedback -

have been studied by our sound engineers in order to provide a great variety

of acoustical and dynamic responses for different applications (i.e. Entertain

for a crisp sound and a clear response without massive external EQ; Max loud

gives a big boost in the high and low end and a slight cut in the mid region).

Based on it’s trapezoidal form, D400 can also be used as stage monitor. Even

though the new D400 speaker model is as technology-packed as a high-end

professional speakers, LEM has succeeded in giving D400 both a light weight

(only 19kg, aluminium carrying handles) and a light price, making it the ideal

product for gigging bands, DJs, pubs, clubs and other permanent installations.

d400

2 way bi-amplified system

1" compression driver

with titanium diaphragm

mounted on a high-efficiency CD horn

12” high-excursion woofer with

2.5” voice and neodimium magnet

built-in power amplifiers 300+100W

built-in digital processor with HPF and

LPF crossover filters

25 bands parametric eq delay and

phase alignment

additional processing plug-ins:

multicomp, noise gate, anti-feedback

16 presets

digital protection system

high-density polypropylene

4 M10 flying points

400 x 620 x 375mm (L x H x D)

20kg

x300

passive version

300W on 4 and 8 Ohm

power handling

13kg

SPEAKERS

rear panel

SPEAKER SYSTEMS

27

SPEAKER SYSTEMS

26

cyclop system

Cyclop is an integrated loudspeaker system designed to provide musicians

and audio professionals with the best solution for a high quality sound

reproduction.

Cyclop is a 3-way bi-amplified system consisting of two satellites and one

subwoofer. The amplifier module in the subwoofer feeds both the satellites

and the sub integrating loudspeakers, amplifiers and electronic controls in

one system. The sub also includes four wheels on the back panel; its front

panel is designed in order to accommodate the two satellites for

the easiest transportation possible. A stage pack containing all necessary

accessories for the installation is also available.

cyclop stage pack

1 carrying bag

2 aluminium stands

2 carrying bags for the aluminium

stands

2 speakon-speakon cables, 10m

2 jack-jack (bal.) cables, 10m

cyclop

3 ways active p.a. system

2 two-ways satellites with

tweeter and 8" woofer - 150W

15" subwoofer - 300W

with built-in power amplifier

300W for the sub

2 x 150W for the satellites

MDF cabinet, scratch-resistant paint

sat

274 x 430 x 242mm (L x H x D)

7kg

sub

546 x 476 x 630mm (L x H x D)

39kg

hercules system

Hercules is a three-way tri-amplified system based on a satellite and

a subwoofer, which combines in the same product loudspeakers, signal

processors and power amplifiers.

The amplification module in the subwoofer cabinet includes three different

power amplifiers (one for each loudspeaker) and a 24dB/oct. crossover

network that performs a perfect frequency separation.

The cabinets are made of MDF with scratch-resistant paint, which guaran-

tees maximum sturdiness and durability in all conditions. We have paid

maximum attention at the cabinet construction, in order to provide easy

transportation and handling.

Hercules is a professional integrated P.A. system which provides high

efficiency and superior audio quality. It can be used not only as a portable

live P.A. system for bands, but also for permanent installations in clubs

and conference rooms.

hercules sub

high efficiency 15" woofer

in bass-reflex configuration

integrated power amplifier module

with:

1 power amplifier 300W for sub

2 power amplifiers 50W and 150W

for satellites

active crossover for the frequency

separation

active eq circuit for the system

compensation

three different anti-clipping circuits

for the loudspeaker protection

4 wheels

MDF cabinet, scratch-resistant paint

546 x 476 x 630mm (L x H x D)

39kg

hercules sat

2 ways bi-amplified satellite

1" compression driver 50W

on ewt™ horn for the high section

12" woofer 150W

speakon connectors

to be used also as stage monitor

MDF cabinet, scratch-resistant paint

370 x 506 x 325mm (L x H x D)

16,4kg

SPEAKER SYSTEMS

29

SPEAKER SYSTEMS

28

hercules stage pack

1 carrying bag

2 aluminium telescopic stands

2 connection cables

jack-jack (bal.),15m

pegasus system

Pegasus is, together with Poseidon, part of LEM’s line of feature-packed

digitally integrated loudspeaker systems which have been conceived to meet

the requisites for extremely demanding applications. Pegasus systems are

equipped with the 400+400W Digitally Processed Power Module which

integrates the amplifiers with a sophisticated digital processor based on

a proprietary LEM DSP. The digital processor features 40 bit internal

processing and high resolution, low noise 24 bit converters for superb audio

quality and excellent dynamic range. Pegasus’ digital control features inclu-

de HPF and LPF crossover filters, 5 parametric EQ input and 10 parametric

EQ output filters, master delay compensation and individual loudspeaker

alignment, phase adjustment and high precision limiters. Four additional

plug-ins enhance the performances. The module’s power amplifiers include

a VDAT (Variable Damping Assisted Tuning) system which guarantees

maximum efficiency, particularly in the low frequency zone. Additional

limiters allow the constant control of the maximum output power, providing

optimal dynamics and avoiding the most annoying acoustical effects which

are typical of analogue systems. For demanding applications as live music

in clubs, theatres and concert halls, ballrooms, convention centers.

pegasus sub 118

18" woofer in bass reflex

built-in 800W power amplifier

VDAT system

40 bit built-in digital processor

editable via PC (dx editor)

with RS232 connection

4 plug-ins: noise gate, hum cancel,

multi-band compressor, antifeedback

plywood cabinet with protection foam

and metal grid

4 wheels

620 x 620 x 566mm (L x H x D)

60kg

pegasus sat 212

2" horn loaded driver

12" woofer in bass reflex

2 built-in 400W power amplifiers

VDAT system

40 bit built-in digital processor

editable via PC (dx editor)

with RS232 connection

4 plug-ins: noise gate, hum cancel,

multi-band compressor, antifeedback

plywood cabinet with protection foam

and metal grid

424 x 638 x 440mm (L x H x D)

44kg

hercules standard set-up

The standard setup consists of

two satellites and two subwoofers.

hercules double set-up

The double setup consists

of two satellites and four subs.

The two additional satellites

can be used as stage monitors.

SPEAKER SYSTEMS

31

dx editor

rs kit

SPEAKER SYSTEMS

30

poseidon system

Poseidon heads LEM’s line of high-quality amplified loudspeaker systems for

the most demanding indoor and outdoor applications, offering a

surprisingly cost efficient alternative to high-priced products.

Poseidon basically features the same technology as Pegasus (see p. 29),

but LEM has further enhanced Poseidon’s efficiency by adding a series of

particular elements: horn loaded drivers and woofers, push-pull systems

and band-pass cabinets assure the maximum acoustic diffusion and

an extraordinary sonic pressure for live music in stadiums, arenas, concert

halls, large theatres and ballrooms.

poseidon sat 212

2" horn loaded driver

12" horn loaded woofer

2 built-in 400W power amplifiers

VDAT system

40 bit built-in digital processor

editable via PC (dx editor)

with RS232 connection

4 plug-ins: noise gate, hum cancel,

multi-band compressor, antifeedback

plywood cabinet with protection foam

and metal grid

604 x 973 x 723mm (L x H x D)

67kg

poseidon sat 212 fly

8 flying bars

4 different positions for flying

poseidon sub 218

2 18" woofers in push-pull in a band-pass box

2 built-in 400W power amplifiers VDAT system

40 bit built-in digital processor editable via PC (dx editor)

4 plugins: noise gate, hum cancel, multi-band compressor, antifeedback

plywood cabinet with protection foam and metal grid

4 wheels

1460 x 540 x 735mm (L x H x D), 127kg

serial system connection

for processor software control

2 RSC serial converters

with external PSU

two RS232 serial cables

9-pin (1,5 m)

one RS485 serial cable

with 5-pin XLR on both ends (30m)

The DX editor software has been developed by LEM for the control from PC

of Poseidon, Pegasus and the dx series. It grants easy access to all

the processor’s parameters, allowing to control all functions from PC.

Download your free dx editor software at www.lemaudio.com

DIGITAL PROCESSORS

34

DIGITAL PROCESSORS

35

fx series

LEM digital multi-effects FX offer musicians, technicians and recording stu-

dios state-of-the-art algorithm effects and the purity of 40 bit digital sound.

FX 22 and FX 24 have some of the best reverb, delay and modulation

effects available: extremely realistic Hall and Plate reverbs, bounce and

tape-back vintage effects, rich Chorus as well as Flanger, Phaser and Rotary

Simulator in pure analogue style.

Fx are easy to use, high quality processors at an incredible price.

fx 22

digital double effect processor

40 bit internal processing

two independent stereo effects

dual or combi mode

121+121 presets

1/2 rack unit

1,2kg

fx 24

digital double effect processor

40 bit internal processing

two independent stereo effects

up to 3 effects for each preset

up to 3 editable parameters

128 factory presets + 128 user presets

3 digit LCD

MIDI interface

1 rack unit

4kg

dx series

DX 24 and DX 26 plus are the digital loudspeaker processors based on

a proprietary LEM DSP. This powerful 40 bit DSP, together with 20 bit

and 24 bit converters, ensures great audio quality and dynamics, suitable

for the most demanding applications.

Both models include factory presets with general purpose configurations

to be used in different kinds of systems. User presets for the storage of

personal setups are also available. Both DX models are equipped with

a remote control interface.

The DX Editor control software (see p. 31) grants easy access to all the

processor’s parameters and functions from PC.

dx 24

digital speaker processor

40 bit internal processing

20 and 24 bit A/D and D/A converters

2 way stereo (2 in/4 out)

up to 48dB/oct. digital crossover

and output delay, phase alignment, limiter

17 factory presets + 64 user presets

2 x 16 LCD

MIDI interface

DX Editor software PC control

1 rack unit

4kg

dx 26 plus

digital speaker processor

40 bit internal processing

24 bit 1 A/D and D/A converters

3 way stereo (2 in/6 out)

up to 48dB/oct. digital crossover

and output delay, phase alignment, limiter

21 factory presets + 128 user presets

memory card slot

AES/EBU digital input

2 x 16 LCD

RS485 e RS232 serial interface

DX Editor software PC control

1 rack unit

4kg

ANALOG PROCESSORS

37

ANALOG PROCESSORS

36

eq series

The EQ series is designed to guarantee high audio quality and maximum

reliability for DJ systems, live applications, home recording and permanent

installations.

The two mono models with 31 bands of EQ, 20 or 60mm faders and

the choice of several kinds of balanced and unbalanced connections.

Each model offers a selectable fader range (6/12dB) and hi-pass

and low-pass filters.

eq 3112

31 band graphic eq

20mm sliders

hpf + lpf

±6 / ±12 dB range

1 rack unit

3kg

eq 311 d2

31 band graphic eq

60mm sliders

hpf + lpf

±6 / ±12 dB range

2 rack units

3,7kg

clx 22

The CLX22is a sophisticated dynamics processor which includes three

different types of processing:

Compressor/Limiter with threshold, attack, release, compression ratio

and gain parameters

Expander/Gate for noise reduction

Dynamic Enhancer for high frequency compensation.

Preserving the acoustical properties of the signal and providing a

complete set of features and an extremely good price/performance ratio,

the CLX22is the ideal complement to any audio signal chain.

clx 22

compressor/limiter/expander

2 in/2 out

side chain insert

interactive compressor

adaptive expander

dynamic enhancer

1 rack unit

3kg

ANALOG PROCESSORS

39

xo series

The Signal Processor series includes two electronic crossovers:

the XO 2022as a stereo two-way and the XO 2032as a stereo

three-way crossover.

In a 1-rack unit chassis, the XO electronic crossovers can apply

high-precision, 24dB/oct. Linkwitz/Riley filters. The controls include

a constant directivity horn compensation and the connection panel

is fitted with balanced xlr and trs jack connectors.

xo 2022

two ways active crossover

2 in/4 out

24dB/oct.

Linkwitz/Riley a 24dB/oct. crossover filters

CD boost

1 rack unit

2,5kg

xo 2032

three ways active crossover

2 in/6 out

24dB/oct.

Linkwitz/Riley a 24dB/oct. crossover filters

CD boost

1 rack unit

2,5kg

WIRELESS MICROPHONES

41

HT version with hand-held mic

wireless hand-held mic

dynamic capsule

cardioid polar pattern

243mm (L)

LT version bodypack with lavalier mic

body-pack transmitter

lavalier condenser mic

ominidirectional polar pattern

ST version bodypack with mic headset

bodypack transmitter

headset dynamic mic

cardioid polar pattern

GT version bodypack with connection cable

body-pack transmitter

connection cable

for musical instruments

L2000/L3000 series

WIRELESS MICROPHONES

40

With the Wireless models, LEM offers a series of microphone systems

that combines absolute quality and professional performance.

LEM Wireless systems are available in VHF and UHF band, with the

possibility to choose up to 8 different frequencies for the simultaneous use

of multiple systems. All models can be used with several microphone types

granting maximum flexibility.

L2000 sd

VHF switching diversity

7 available frequencies

two antennas VHF receiver

volume and squelch controls

RF LED and signal LED

xlr and jack connectors

external PSU

1/2 rack unit

1,3kg

L2000 td

VHF true diversity

7 available frequencies

two antennas VHF receiver

volume and squelch controls

RF LED and signal LED

xlr and jack connectors

external PSU

1/2 rack unit

1,5kg

L3000 sd

UHF switching diversity

8 available frequencies

two antennas UHF receiver

volume and squelch controls

RF LED and signal LED

xlr and jack connectors

external PSU

1/2 rack unit

1,3kg

43

L 300

WIRELESS MICROPHONES

42

L300 is an efficient, user-friendly radio microphone system. The UHF band

overcomes the majority of interference problems which are recurrent

in the lower bands. L300 is therefore particularly suited to critical situations

such as stages and clubs with a lot of lights, amplifiers and reflections.

L300 is available in various versions: with handheld microphone (HT),

with headset mic and bodypack transmitter (ST), with lavalier mic and

bodypack transmitter (LT) and COMBI, including all three mic versions.

All models include a receiver (in a third of rack cabinet) and are housed

in a plastic hard bag for easy handling.

L 300

mono antenna UHF receiver

volume and squelch controls

RF LED and signal LED

xlr and jack connectors

external PSU

carrying case

1/3 rack unit

0,7g

WIRELESS MICROPHONES

HT version with hand-held mic

wireless hand-held mic

dynamic capsule

cardioid polar pattern

246mm (L)

LT version bodypack with lavalier mic

body-pack transmitter

lavalier condenser mic

ominidirectional polar pattern

ST version bodypack with mic headset

bodypack transmitter

headset dynamic mic

cardioid polar pattern

COMBI version

L300 receiver

wireless hand-held mic

bodypack transmitter

lavalier mic

headset mic

44

WIRELESS IN-EAR MONITORS WIRELESS IN-EAR MONITORS

45

pm 1C series

PM1C is a high quality VHF wireless personal monitor system.

The connection between transmitter and receiver is based on a factory

preset frequency. Various user-friendly presets are available, with frequency

intervals optimised to avoid any interferences with other systems.

The mono system includes the PM1C TX transmission unit, hosted in

a 1/2 rack unit chassis, and the PM1C RX single channel receiver,

combined with the earphones KOSS the plug.

pm 1C tx

VHF mono antenna transmitter

mic input

headphone output

volume control

external PSU

1/2 rack unit

1,4kg

pm 1C rx

bodypack mono receiver

VHF system

high quality earphones

KOSS the plug

pm 16C series

LEM PM16C is a high quality personal monitor system, designed for

live performances of musicians, performers and actors, for conference

rooms and for interpreters.

The PM16C is a stereo system which uses UHF PLL synthesized transmission

technology. The UHF band helps to overcome the typical problems of those

transmission systems that use lower frequency bands, while the PLL

synthesized quartz stabilization cancels RF oscillations preventing cutoffs

and interferences even in the most demanding situations. The connection

between the transmitter and the receiver can be easily set by selecting

one of the 16 channels, corresponding to 16 different frequencies.

The system includes the PM16C TX transmission unit, hosted in a 1/2 rack

unit chassis, the PM16C RX bodypack receiver and earphones.

pm 16C tx

UHF mono antenna transmitter

stereophonic transmission

up to 16 selectable channels

stereo input

mic input

headphone output

volume control

external PSU

1/2 rack unit

1,4kg

pm 16C rx k

body-pack stereo receiver

up to 16 selectable channels

UHF system

high quality earphones

KOSS the plug

pm 16C rx pro

body-pack stereo receiver

up to 16 selectable channels

UHF system

hi-end single drive

with foam adapter

ACCESSORIES

46

ACCESSORIES

47

code description

951354 Stage Pack Cyclop

951365 Stage Pack Hercules

951283 LM 20

dynamic microphone

950860 SC 20

metal telescopic stand

950199 SC 30

aluminium telescopic stand

950978 SC 31

aluminium telescopic stand

950444 SC 61

stand adaptor (SP and SPX series))

950445 SC 62

mounting clamp (SP and SPX series)

950446 SC 63

table fixing clamp (SP and SPX series)

951125 SC 64

"T" stand (SP and SPX series)

951137 SC 65

flange for speaker stand (SP and SPX series)

951126 SC 80

flange for "T" and "TOTEM" system (SP series)

951127 SC 81

male flange (SP series)

951128 SC 82

female flange (SP series)

951131 SC 85

TOTEM system stand (SP series)

code description

951136 Power connection cable (Pegasus & Poseidon)

951133 Power cable SPK2

speakon cable 2 x 1,5 - 15m

951151 Signal cable JJS

jack-jack cable 15m

970294 Rack Adaptor FX22 for FX 22, Wireless series, PM series
