LAWN &GARDEN BELTS

Ariens

A-07219600 1/2" X 126.75" (3219.45) Ariens/Gavely, (MOWER: 28 INCH CUT, 30 INCH CUT, 32 INCH CUT)

A-38745 1/2 X 89.75" (2279.65) Belt, Blade Drive, (COMMERCIAL W ALK BEHIND: PRO 36)

A-41545 1/2 X 35.1" (891.54) Belt, Engine/Transmission, (MOWER: PRO SERIES)

A-41599 5/8 X 45.8" (1163.32) Belt, Wheel Drive, (COMMERCIAL W ALK BEHIND: PRO 36 40" Whl Drive, PRO 36 50" Whl

Drive)

A-49029 1/2 X 45.6" (1158.24) Belt, Drive, (MOWER: PRO SERIES Walk Behind)

A-49270 1/2 X 40" (1016) V -Belt, (MOWER: PRO 150)

A-7085 3/8 X 31.5" (800.0) Belt, Drive,

A-72023 1/4 X 27.75" (704.85) Ariens/Gravely Belt (set/2), (SNOWBLOWER: Sno-Tro 922018: 1969-1974, Sno-Tro 922019:

1969-1974, Sno-Tro 922020: 1969-1974, Sno-Tro 922021: 1969-1974)

A-72047 3/8 X 35.5" (901.70) Belt, (SNOWBLOWER: SEVERAL Older Model)

A-72052 5/8 X 69" (1752.6) Belt, Blade Drive, (MOWER: PRE-1980 30 INCH CUT)

A-72056 1/2 X 32" (812.80) Belt, Auger Drive, (SNOWBLOWER: 922002, 922003, 922006, 922008, 922009, 922010,

922999),

(TILLER: FT424, FT524)

A-72066 3/8 X 34" (863.60) Belt, Engine, (SNOWBLOWER: 8-12HP, 924080, 924082, 924084, 924085, 924086, 924087)

A-72074 1/4 X 27" (685.8) Belt, Drive, (SNOWBLOWER: Sno-Tro 6HP)

A-72080 1/2 X 89.5" (2273.30) Belt, Drive, Mower, (MOWER: 42 INCH CUT)

A-72081 1/2 X 105" (2667.00) Belt, Blade Drive, (MOWER: 831002, 831012, 831028, 831031, 834001, 834002, 834008,

834010,

834011, 834015, 834016)

A-72086 1/2 X 40" (1016.0) Belt, Engine, (SNOWBLOWER: 8HP, 924082)

A-72096 1/2 X 50" (1270) Ariens/Gravely,

A-72098 1/2 X 33" (838.20) Belt, (SNOWBLOWER: 00026, 27, 32, 33, 36, 38, 39, 46, 49, 51, 52, 92400)

A-72108 1/2 X 37" (939.80) Belt, Engine, (SNOWBLOWER: 10HP, 924084, 924086)

A-72112 3/8 X 35" (889) Belt, Drive, (MOWER: SEVERAL)

A-72114 1/2 X 34.5" (876.30) Cogged Belt, Drive, (SNOWBLOWER: 832004)

A-72118 1/2 X 46.75" (1187.45) Belt, Drive, (MOWER: SEVERAL LT & YT), (SNOWBLOWER: 834006)

A-72130 1/2 X 39" (990.60) Belt, (SNOWBLOWER: 10HP, 924087, 924091, 924092, 94085)

A-72131 3/8 X 36" (914.4) Ariens/Gravely, (SNOWBLOWER: 924085, 924087, 924091, 924092)

A-72169 1/2 X 64.5" (1638.30) Belt, Blade Drive, (MOWER: 831026, 1981 >, 30 INCH CUT)

A-72171 3/8 X 32" (812.8) Cogged Belt, Drive, (MOWER: WALK BEHIND 21 INCH)

A-72224 1/2 X 46.6" (1183.63) Belt, Drive, (COMMERCIAL W ALK BEHIND: PRO SERIES)

A-72231 1/2 X 59" (1498.6) Belt, Drive, (MOWER: PRO 300, PRO MASTER 100, PRO MASTER 200)

A-72238 1/2 X 59" (1498.6) Belt, Transmission Drive, (COMMERCIAL W ALK BEHIND: PRO 36, PRO 38, PRO 40, PRO 50)

A-72242 1/2 X 59" (1498.6) Belt, Drive, (MOWER: PRO MASTER 100 50" cut)

A-72250 1/2 X 37.6" (955.04) Belt, PT O , (MOWER: 36 CUT, 38 CUT, 40 CUT, 50 CUT, PRO 200, PRO 300, PRO MASTER

100, PRO MASTER 200)

A-72258 1/2 X 52.8" (1341.44) Belt, PT O , (MOWER: PRO 150)

A-72260 1/2 X 120" (3048) Ariens/Gravely,

A-72266 1/2 X 126.5" (3213.10) Belt, Blade Drive, (MOWER: 50 INCH CUT)

A-72345 1/2 X 50" (1270) Belt, Clutch to Deck,

A-72350 5/8 X 60.8" (1544.32) Belt,

A-72363 3/8 X 33" (838.8) Ariens/Gravely, (MOWER: SEVERAL)

A-72382 1/2 X 85.2" (2164.08) Ariens/Gravely,

A-7221200 1/2" X 37.6" (955.04) P TO Clutch Belt, (MOWER: 36 CUT, 38 CUT, 40 CUT, 50 CUT, PRO 200, PRO 300,

PRO MASTER 100, PRO MASTER 200)

A-7235500 1/2 X 73.81" (1874.77) Ariens/Gravely,

A-7241600 1/2 X 142.7" (3624.58) Deck Belt,

A-9240 1/2 X 37.5" (952.5) Belt, Blade Drive, (MOWER: WALK BEHIND 40 INCH)

Bobcat / Ransome

A-128003 5/8 X 131.75" (3346.45) Belt, Deck, (MOWER: T-3100 T O T -3104 SERES), (ZERO TURN MOWER: 61 INCH)

A-128004 5/8 X 90" (2286) Belt, PT O , (MOWER: T-3100 T O T -3104 SERES)

A-128005 1/2 X 37" (939.8) Belt, Drive, (MOWER: T-3100 T O T-3104 SERES)

A-128099 1/2 X 36" (914.40) Belt, Transmission Drive, (MOWER: SEVERAL NEW GEAR DRIVE)

A-2188128 1/2 X 63" (1600.2) Belt, Pump Drive, (ZERO TURN MOWER: 52 INCH, 61 INCH, 72 INCH)

A-2188134 5/8 X 100.6" (2555.24) Belt, Engine, (ZERO TURN MOWER: 61 INCH)

A-2308052 1/2 X 46" (1168.4) Belt, Mower, (WALK BEHIND MOWER: XM SERIES- HYDRO)

A-2720815 5/8 X 95.7" (2430.78) Belt, PT O, (MOWER: 48 INCH Side Discharge)

A-2720948 Dbl V belt 21/32 X 136" (3454.4) Bobcat/Ransome, (ZERO TURN MOWER: 72 INCH)

A-38015N 5/8 X 86.875" (2206.63) Belt, Blade Drive, (MOWER: 36 INCH)

A-38016N 5/8 X 35.6" (904.24) Belt, (MOWER: (M32-12, M32-12KA ALL 32", 36", 48" and 54" vari-speed)), (WALK BEHIND

Bobcat / Ransome

Ariens

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

MOWER: (XM3601, XM3602, XM3620, XM4801, XM4805 ALL 32", 36", 48" and 54" vari-speed))

A-38017N 5/8 X 44.125" (1120.76) Belt, Wheel Drive, (MOWER: 36 INCH, 48 INCH, 61 INCH)

A-38030N 5/8 X 93" (2362.20) Belt, Engine, (MOWER: 48 INCH 5 SPEED GEAR DRIVEN (PEERLESS))

A-38030N 5/8 X 93" (2362.20) Belt, Engine, (WALK BEHIND MOWER: XM SERIES- HYDRO 54" Deck)

A-38031N 5/8 X 51.82" (1316.23) Belt, Deck, (MOWER: 48 INCH)

A-38111 5/8 X 86.75" (2203.45) Belt, Engine, (MOWER: 36 INCH)

A-38136 5/8 X 97" (2463.8) Belt, Cutter Deck, (MOWER: 54 INCH Variable Speed Trans)

A-38211 1/2 X 35.68" (906.27) Belt, Trans Drive, (MOWER: (36, 48 ALL 5 SPEED GEAR DRIVEN (PEERLESS)))

A-38212 A A belt X 55.95" (1421.13) Belt, Drive, (MOWER: (M36, M48 ALL gear driven), (M36, M48 A L L wheel driven))

A-38234 5/8 X 91" (2311.40) Belt, Engine to Deck, (MOWER: 36 INCH Mulching 54")

A-38249 A A belt X 44.70" (1135.38) Belt, Wheel Drive, (MOWER: 36 INCH, 48 INCH)

A-38275 1/2 X 83" (2108.2) Belt, Deck, (MOWER: 32 INCH Variable Speed)

A-38330 5/8 X 133" (3378.2) Belt, Engine, (WALK BEHIND MOWER: XM SERIES- GEAR 61" Deck)

A-38331 5/8 X 105" (2667) Belt, Deck, (WALK BEHIND MOWER: XM SERIES- GEAR/ HYDRO 61" Deck)

A-38362 5/8 X 70.5" (1790.7) Belt, Deck, (WALK BEHIND MOWER: XM SERIES- GEAR/ HYDRO 54" Deck)

A-38363 5/8 X 75.5" (1917.7) Belt, Engine, (WALK BEHIND MOWER: XM SERIES- HYDRO 61" Deck)

A-38385 1/2 X 55.7" (1414.78) Belt, Hydo Pump, (WALK BEHIND MOWER: XM SERIES- HYDRO)

A-38389 5/8 X 51.125" (1425.575) Belt, Deck, (WALK BEHIND MOWER: XM SERIES- GEAR/ HYDRO 36" Deck)

A-38439 5/8 X 70" (1778) Belt, Engine, (WALK BEHIND MOWER: XM SERIES- GEAR 48" Deck)

A-38440 5/8 X 82.25" (2089.15) Belt, Deck, (WALK BEHIND MOWER: XM SERIES- GEAR/ HYDRO 48" Deck)

A-38442 5/8 X 67.75" (1720.85) Belt, Engine, (WALK BEHIND MOWER: XM SERIES- HYDRO 48" Deck)

A-38458 5/8 X 61.187" (1579.5498) Belt, PT O Deck, (WALK BEHIND MOWER: XM3630, XM4810, XM4831, XM5430), (DECK:

933000, 933001, 933002, 933004, 933005, 934000, 934001, 934002, 934004, 934005, 935002)

A-38462 5/8" X 52.375" (1330.325) Deck Belt, (WALK BEHIND MOWER: XM3203, XM3205, XM3211, XM3603, XM3605, XM3608,

XM3609, XM3611, XM4803, XM4803, XM4805, XM4808, XM4809, XM4810, XM5412), (DECK:

930105, 930106, 930107, 930305, 932400, 932401, 932402, 932501, 933400, 933401, 933501,

933600, 934400, 934

A-38463 5/8 X 62.187" (1579.5498) Belt, Engine, (WALK BEHIND MOWER: XM SERIES- HYDRO, XM3203, XM3205, XM3211,

XM3603, XM3605, XM3608, XM3609, XM3611, XM4803, XM4805, XM4808, XM4809, XM4810,

XM5412), (DECK: 633003, 633400, 634003, 634400, 635400, 636400, 930105, 930106, 930107,

930305, 932010, 932010A,

A-38470 5/8 X 64.25" (1631.95) Belt, Engine, (WALK BEHIND MOWER: XM SERIES- GEAR 36" Deck)

A-38523 1-1/8 X 55" (1397.00) Belt, Drive, (MOWER: 94, 95, 96, 67 SERIES NEW STYLE W/ 36" VARIABLE SPEED TRANS.)

A-38528 1-1/8 X 51.25" (1301.75) Belt, Wheel Drive, (W ALK BEHIND MOWER: XM SERIES- HYDRO Dual)

A-38670 5/8 X 82.75" (2101.85) Belt, T ransmission Drive, (WALK BEHIND MOWER: XM SERIES- HYDRO)

A-48019 3V X 37.5" band (942.34) Belt, PT O,

A-48238A BB belt 21/32 X 156" (3962.4) Belt, Deck, (RIDING LAWN MOWER: 74 INCH)

A-48280A BB belt 21/32 X 116.5" (2959.1) Belt, Main, (RIDING LAWN MOWER: 48 INCH 5 Speed Gear Drive)

A-48376 3/8 X 37.5/ 3 band (952.5) Belt, PT O, (RIDING LAWN MOWER: (48 INCH, 74 INCH ALL Diesel))

A-78030N 3/8 X 25.687" (625.46) Belt, Jackshaf t , (MOWER: (M214SP, M21SP ALL 21"))

A-78031N 3/8 X 36" (914.4) Belt, Wheel Drive, (MOWER: (M214SP, M21SP ALL 21"))

A-041-1420-00 5/8 X 145.25" (3689.35) Belt, Deck, (RIDING LAW N MOWER: (LIGHTNING Z, PUP SERIES ALL w/ 48" Deck), ZT

SERIES w/ 50" Deck)

A-041-1470-00 5/8 X 148.25" (3765.55) Belt, Deck, (RIDING LAW N MOWER: 26 HP BRIGGS 2006> w/ 50" deck)

A-041-1490-00 5/8 X 150" (3810) Belt, Deck, (RIDING LAW N MOWER: PUP SERIES w/ 52" Deck)

A-041-1560-00 5/8 X 154.5" (3924.3) Belt, Deck, (RIDING LAW N MOWER: 28 HP C AT DIESEL 2006> w/ 60" deck, 28 HP C AT DIESEL

2006> w/ 72" deck)

A-041-1650-00 5/8 X 167.33" (4250.18) Belt, Deck, (RIDING LAW N MOWER: (LIGHTNING Z, PUP SERIES, ZT SERIES ALL w/60"

deck))

A-041-5048-00 5/8 X 80.25" (2038.35) Pump Belt, (RIDING LAW N MOWER: AOS SERIES, LIGHTNING Z, PUP SERIES)

A-041-5200-00 5/8 X 113" (2870.2) Belt, Deck, (RIDING LAW N MOWER: 19 HP K AW ASAKI 2006> w/ 36" deck, 26 HP BRIGGS

2006> w/ 30" deck, 27 HP K AW ASAKI 2006> w/ 52" deck)

A-041-6027-00 5/8 X 128.25" (3257.55) Belt, Deck, (RIDING LAW N MOWER: (27 HP K AW ASAKI, 28 HP C AT DIESEL, 31 HP BRIGGS,

35 HP BRIGGS ALL 2006> w/ 60" deck))

A-041-6400-00 1/2 X 66.25" (1682.75) Belt, Deck, (RIDING LAW N MOWER: 26 HP BRIGGS 2006> w/ 36" deck, 26 HP BRIGGS 2006>

w/ 50" deck, 26 HP BRIGGS 2006> w/ 60" deck)

Bush Hog

A-65482 5/8 X 46.45" (1179.83) Belt, Drive, (ROTA R Y CUTTER: GT42-01, GT42-02, GT42-03, GT42-04, GT42-07, GT42-08)

A-66474 5/8 X 133" (3378.2) Belt, Drive, (FINISHING MOWER: TM5 RM-2)

A-66542 21/32 X 151" (3835.4) Belt, Drive, (FINISHING MOWER: TM6 RM-2)

A-66552 5/8 X 70.5" (1790.7) Belt, Drive, (FINISHING MOWER: TM4 RM-2)

A-81751 5/8 X 39" (990.6) Belt, Drive, (ROTA R Y CUTTER: GT42-05, GT42-06)

A-83120 Set of 2 Belt s Belt, Drive, (FINISHING MOWER: TH60-01, TH60-02)

A-83121 5/8 X 80.5" (2044.7) Belt, Drive, (FINISHING MOWER: TH72-01, TH72-02)

A-83136 7/8 X 100.9" (2562.86) Belt, Drive, (ROTA R Y CU T T E R : B D 9 0 )

A-84302 5/8 X 121" (3073.40) Belt, Drive, (DISC MOWER: DM7, DM701, DM702)

LAWN & GARDEN BELTS

Bush Hog

Bobcat / Ransome

OrderForm

LAWN &GARDEN BELTS

A-84303 5/8 X 121.5" (3086.10) Belt, Drive, (DISC MOWER: DM8)

A-86326 Set of 2 belt s Belt, Drive, (FINISHING MOWER: TH48-01, TH48-02)

A-88667 5/8 X 142" (3606.80) Belt, Drive, (ROTA R Y CUTTER: ATH600, FTH600), (FINISHING MOWER: RDTH60, TD-1500)

A-88843 5/8 X 155.5" (3949.7) Belt, Drive, (ROTA R Y CUTTER: ATH720, FTH720), (FINISHING MOWER: RDTH72, TD-1700)

A-90699 7/8 X 213" (5410.2) Belt, Drive, (ROTA R Y CUTTER: ATH900)

A-90880 5/8 X 77.5" (1968.5) Belt, Drive, (ROTA R Y CUTTER: FTH480)

A-93991 29/64 X 121" (3073.4) Belt, Drive, (ZERO TURN MOWER: ZT-2200, ZT-2200W)

A-94144 1/2 X 108" (2743.2) Belt, Drive, (ZERO TURN MOWER: ZT-1800, ZT-1800W)

A-94897 24/32 X 128" (3251.2) Belt, Drive, (ROTA R Y CUTTER: MTH720), (FINISHING MOWER: TDM17)

A-94898 5/8 X 160.5" (4076.7) Belt, Drive, (ROTA R Y CUTTER: MTH720), (FINISHING MOWER: TDM17)

A-94899 5/8 X 116.5" (2959.1) Belt, Drive, (ROTA R Y CUTTER: MTH600), (FINISHING MOWER: TDM15)

A-94900 Belt, Drive, (ROTA R Y CUTTER: MTH600), (FINISHING MOWER: TDM15)

A-98479 61"(1549.4) Belt, Drive, (ZERO TURN MOWER: TC220)

A-98481 48"(1219.2) Belt, Drive, (ZERO TURN MOWER: TC180)

Bunton

A-128110 21/32 X 111.33" (2827.78) Belt, Cutter Deck,

A-PG757 1/2 X 30" (762.00) Belt, Drive, (MOWER: 760, BIM, ET10)

A-PL1443 1/2 X 45.6" (1158.24) Belt, Blade Drive, (MOWER: FLAT FRONT DECK 48" Deck)

A-PL4275 Dbl band X 45.406" (1153.31) Belt, Wheel, Dual, (MOWER: SS SERIES)

A-PL4511 5/8 X 47" (1193.8) Belt, Engine, (MOWER: FLAT FRONT DECK LL 36" Deck)

A-PL4511 5/8 X 47" (1193.8) Belt, Engine, (MOWER: SS SERIES 36" Deck)

A-PL4513 5/8 X 57.5" (1460.5) Belt, Engine, (MOWER: HYDRO DRIVE 36" Deck)

A-PL4732 5/8 X 63" (1600.20) Belt, Engine, (MOWER: HYDRO DRIVE 48" Deck)

A-PL4733 5/8 X 56.67" (1439.42) Belt, Engine, (MOWER: HYDRO DRIVE 36" cut)

A-PL4734 1/2 X 95" (2413) Belt, Blade Drive, (MOWER: HYDRO DRIVE 48" Deck)

A-PL4739 5/8 X 65" (1651.00) Belt, Engine, (MOWER: HYDRO DRIVE 52" Deck)

A-PL4740 1/2 X 102" (2590.8) Belt, Blade Drive, (MOWER: HYDRO DRIVE 52" Deck)

A-PL4811 5/8 X 63.16" (1604.26) Belt, Engine, (MOWER: SS SERIES 48" Deck)

A-PL4813 1/2 X 47" (1193.8) Belt, Blade Drive, (MOWER: SS SERIES 48" Deck)

A-PL5039 5/8 X 41" (1041.4) Belt, V ariable S p e e d , ( M O WER: SS SERIES)

A-PL6011 5/8 X 45" (1143) Belt, Pump Drive, (MOWER: SS SERIES)

A-PL6062 5/8 X 71" (1803.4) Belt, Engine, (MOWER: SS SERIES 62" Deck)

A-PL7014 5/8 X 93.406" (2372.51) Belt, Engine, (MOWER: HYDRO DRIVE 61" cut)

A-PL7332 5/8 X 123" (3124.2) Belt, Deck, (MOWER: ZTR 60" Deck)

A-PL7436 5/8 X 121" (3073.4) Belt, Engine, (MOWER: ZTR 50" Deck, ZTR 60" Deck)

A-PL8519 5/8 X 131" (3327.4) Belt, Blade Drive, (MOWER: HYDRO DRIVE 61" Deck)

A-PLO511 5/8 X 53.75" (1365.25) Belt, Engine, (MOWER: FLAT FRONT DECK GG 32" Deck, FLAT FRONT DECK GG 36" Deck)

A-PLO543 1/2 X 43" (1092.2) Belt, Blade Drive, (MOWER: FLAT FRONT DECK 32" Deck)

A-PLO619 5/8 X 44" (1117.60) Belt, Wheel Drive, (MOWER: FLAT FRONT DECK)

A-PLO643 1/2 X 49.875" (1266.83) Belt, Blade Drive, (MOWER: FLAT FRONT DECK 52" Deck)

A-PLO643 1/2 X 49.875" (1266.83) Belt, Blade Drive, (MOWER: SS SERIES 36" Deck)

A-PLO643 1/2 X 49.875" (1266.83) Belt, Blade Drive, (MOWER: SS SERIES 52" Deck)

A-PLO643 1/2 X 49.875" (1266.83) Belt, Blade Drive, (MOWER: HYDRO DRIVE 36" Deck)

A-PLO648 5/8 X 28.14" (714.76) Belt, Transmission Drive, (MOWER: FLAT FRONT DECK 32")

A-PLO661 5/8 X 58" (1473.2) Belt, Blade Drive, (MOWER: FLAT FRONT DECK NN 36" Deck)

A-PLO848 5/8 X 39.875" (1012.83) Belt, Deck, (MOWER: FLAT FRONT DECK)

A-PLO861 5/8 X 46.16" (1172.46) Belt, Engine, (MOWER: FLAT FRONT DECK 52" Deck)

A-PLO861 5/8 X 46.16" (1172.46) Belt, Engine, (MOWER: SS SERIES 52" Deck)

A-PM221 11/16 X 58.828" (1494.23) Belt, Blade Drive, (MOWER: SS SERIES 61" Deck)

A-7540468 5/8 X 41.5" (1054.1) Belt, Drive, Upper, (LAWN/ GARDEN TRACTOR: A U TODRIVE STEP THRU FRAME 1999>)

A-7540497 1/2 X 60.5" (1536.7) Belt, Deck, (LAWN/ GARDEN TRACTOR: A U TODRIVE Step Thru Frame 2001-2003 w/ 42" Deck)

Comet

A-203589A 3/4 X 27.375" (695.33) Belt, Drive,

A-D3644 1/2 X 113.5" (2895.6) Belt,

A-D3645 39/64 X 111.5" (2832.1) Belt, Engine to Deck,

A-D3664 1/2 X 113.25" (2876.55) Belt, Hydro Pump, (MOWER: MOWER SN 7050>)

A-D3727W 31/64 X 145" (3683) Belt, Deck, (ZERO TURN MOWER: JAZEE 42" Deck, JAZEE 48" Deck)

A-D3733 1/2 X 158.5" (4025.9) Belt, Deck, (ZERO TURN MOWER: JAZEE 48" Deck, JAZEE 52" Deck, JAZEE-I 42" Deck)

A-D3776W 1/2 X 69" (660.4) Belt, Engine to Deck, (ZERO TURN MOWER: CHARGER 60" Deck)

Case - IH

A-C23358 1/2 X 66.5" (1689.10) Belt, Drive, (MOWER: 200 SERIES, 400 SERIES)

A-C23359 1/2 X 71" (1803.40) Belt, Drive, (MOWER: 400 SERIES)

A-CC195SP 7/8" X 199" (5054.6) Tree Shaker Belt,

Comet

Bush Hog

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

A-CC210SP 7/8" X 214" (5435.6) Tree Shaker Belt,

LAWN & GARDEN BELTS

Exmark

Case - IH

OrderForm

LAWN &GARDEN BELTS

Dixon

A-1300A 11/16 X 99.82" (2535.43) Belt, Blade Drive, (RIDING LAW N M O W E R : 3 6 I N C H C U T, 50 INCH CUT)

A-1684 1/2 X 42.5" (1079.50) Belt, Drive, (RIDING LAW N M O W E R : 4 2 I N C H C U T w/ T ransaxle drive)

A-1714 1/2 X 52" (1320.80) Belt, Drive, (RIDING LAW N M O W E R : 5 0 I N C H C U T w/ t-box drive)

A-1860 1/2 X 57" (1447.80) Belt, Drive, (RIDING LAW N MOWER: 5421)

A-12172 5/8 X 141.5" (3594.1) Belt,

A-2412 5/8 X 74" (1879.60) Belt, Drive, (RIDING LAW N MOWER: 30 INCH CUT)

A-6109 1/2 X 82" (2082.80) Belt, Blade Drive, (RIDING LAWN MOWER: (ZTR421, ZTR422, ZTR424, ZTR426, ZTR427,

ZTR428, ZTR429 ALL w/ 42" cut))

A-6111 5/8 X 78" (1981.20) Belt, Deck, (RIDING LAWN MOWER: (501, 503, 542 ALL w/ 42" cut))

A-7650 1/2 X 41.5" (1054.10) Belt, Transmission Drive, (RIDING LAWN MOWER: 2301 1994-95, (3303, 3304, 3362 ALL 1995))

A-7725 5/8 X 72" (1828.80) Belt, Deck, (RIDING LAWN MOWER: 2301 1994-95, (3303, 3304 ALL 1995))

A-965300470 3/8" X 32" (812.8) Drive Belt, (Happy Start Saw: PC6412, PC6414, PC7312, PC7314)

Dixie

A-20256 5/8 X 38" (965.2) Belt, Engine, (RIDING LAWN MOWER: HYDRO DRIVE 1992>, 42 CUT HYDRO DRIVE, 50

CUT

HYDRO DRIVE, 60 CUT HYDRO DRIVE, 72 XXW SERIES)

A-302360 5/8 X 130.25" (3308.35) Belt, Engine, (RIDING LAW N M O W E R : 6 0 I N C H C U T HYDRO DRIVE)

Encore

A-363210 5/8 X 82" (2082.80) Belt, Main, (WALK BEHIND MOWER: 36 INCH)

A-363211 1-1/8 X 51.5" (1308.10) Belt, Wheel Drive, (WALK BEHIND MOWER: 32 INCH, 48 INCH)

A-363312 1/2 X 51.375" (1304.93) Belt, Transmission Drive, (RIDING LAWN MOWER: 52 INCH)

A-423018 1/2 X 144" (3657.6) Deck Drive Belt,

A-483030 5/8 X 89" (2260.60) Belt, Main, (WALK BEHIND MOWER: 48 INCH)

A-483031 5/8 X 52.5" (1333.50) Belt, Blade Drive, (WALK BEHIND MOWER: 48 INCH)

A-523106 1/2 X 60" (1524) Belt, Pump Drive, (RIDING LAWN MOWER: 52 INCH, 61 INCH)

A-523107 5/8 X 130" (3302) Belt, Engine, (RIDING LAWN MOWER: 52 INCH)

A-523108 5/8 X 118.75" (3016.25) Belt, Blade Drive,

A-523349 1/2 X 132" (3352.8) Belt, Engine, (RIDING LAWN MOWER: 61 INCH)

A-523366 5/8 X 55.75" (1416.05) Belt, Gearbox, (RIDING LAWN MOWER: 52 INCH, 61 INCH)

A-603050 5/8 X 126" (3200.4) Belt, Blade Drive, (RIDING LAW N MOWER: 61 INCH)

Exmark

A-1030881 1/2 X 121" (3073.4) Belt, Mile Drive, (ZERO TURN MOWER: XP MODEL Lazer w/60" Deck, XP MODELLazer w/72"

Deck, Z MODEL Lazer w/60" Deck, Z MODEL Lazer w/72" Deck)

A-1030882 1/2 X 70.75" (1797.05) Belt, Pump Drive, (ZERO TURN MOWER: Z MODEL Lazer XP Series)

A-1031297 5rib 25.38" polyV (644.65) Blade Belt, (ZERO TURN MOWER: Z MODEL Lazer w/60" LP)

A-1034014 5/8 X 116.1" (2948.94) Belt, Pump Drive, (ZERO TURN MOWER: Z MODEL Lazer w/EFI SN>370000, Z MODEL Lazer

Advantage Series SN>370000, Z MODEL Lazer, Liquid Cooled SN>370000)

A-1034760 1/2 X 52.25 (1327.15) Belt, Mower,

A-1035598 5rib 25.38" polyV (644.65) Belt, Blade Drive,

A-1036906 5rib 59.25" polyV (1504.95) Belt, Pump Drive, (ZERO TURN MOWER: Z MODEL Lazer w/EFI SN>510000, Z MODEL Lazer,

Advantage Series SN>510000, Z MODEL Lazer, Liquid Cooled SN>510000)

A-1091057 1/2 X 50.5" (1282.7) Belt, Pump Drive, (HYDRO WALK BEHIND: HP Turf Tracer), (ZERO TURN MOWER: (52, 60

ALL

T urf Ranger))

A-1092584 1/2 X 59.5" (1511.3) Belt, Mower,

A-1323735 19/32 X 83.5" (2120.9) Belt, Mower,

A-1403174 5/8 X 115.28" (2928.11) Belt, Mower,

A-1613271 1/2 X 59.5" (1511.3) Belt, Pump Drive,

A-303078 5/8 X 36" (914.40) Belt, Engine, (WALK BEHIND MOWER: OLD STYLE SN 40000> Vari-speed trans.)

A-303079 5/8 X 44" (1117.60) Belt, Wheel Drive, (WALK BEHIND MOWER: OLD STYLE SN 40000> Vari-speed trans.)

A-303080 5/8 X 89" (2260.60) Belt, Drive, (W ALK BEHIND MOWER: 5 SPEED GEARBOX Viking w/36" Deck)

A-303499 5/8 X 89.75" (2279.65) Belt, Engine, (HYDRO WALK BEHIND: HYDRO Viking SN 90000> w/48" Deck), (WALK BEHIND

MOWER: 5 SPEED Viking SN 90000> w/36" Deck)

A-323051 5/8 X 44.875" (1139.825) Belt, Wheel, Single, (W ALK BEHIND MOWER: 5 SPD GEARBOX Viking w/32" Deck, 5 SPD

GEARBOX Viking w/36" Deck, 5 SPD GEARBOX Viking w/48" Deck)

A-323200 5/8 X 84.125" (2136.775) Belt, Engine, (HYDRO WALK BEHIND: HYDRO Viking SN <140000 w/36" Deck)

A-323280 1/2 X 39.64" (1006.86) Belt, T rans Drive, (WALK BEHIND MOWER: (36, 48, 52 ALL Metro SN <190000), HP Metro SN

150000>)

A-323288 1-1/8" X 49.75" (1263.65) Belt, Double, (W ALK BEHIND MOWER: (32, 48 ALL Metro), 5 SPD GEARBOX Viking)

A-323299 82.344" (2091.54) Belt, Engine, (WALK BEHIND MOWER: 36 INCH Metro SN <190000)

A-323300 5/8 X 88" (2235.20) Belt, Engine, (WALK BEHIND MOWER: 48 Metro SN <190000), (ZERO TURN MOWER: 60 Turf

Exmark

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

Ranger SN <115000)

A-323344 5/8 X 48.687" (1236.65) Belt, Wheel Drive, (WALK BEHIND MOWER: 32 INCH Metro)

A-323733 5/8 X 82.625" (2098.675) Belt, Deck, (WALK BEHIND MOWER: 36 INCH Metro SN 22000 >)

A-323734 5/8 X 82.625" (2098.675) Belt, Blade Drive, (WALK BEHIND MOWER: 32 INCH Metro SN 22000 >)

A-323735 5/8 X 83.5" (2120.9) Belt, Deck, (HYDRO WALK BEHIND: HYDRO Viking w/36" deck)

A-403018 5/8 X 36.8" (934.72) Belt, T rans Drive, (W ALK BEHIND MOWER: 5 SPD Viking SN 90000> w/ 48" Deck, 5 SPD GEAR

BOX Viking w/36" Deck, 5 SPD GEARBOX Viking w/48" Deck)

A-403024 5/8 X 93.9" (2385.06) Belt, Main, (WALK BEHIND MOWER: 5 SPD GEARBOX Viking w/48" Deck, OLD STYLE SN

40000> Vari-spd trans. w/48" Deck)

A-403025 5/8 X 52" (1320.80) Belt, Blade Drive, (HYDRO WALK BEHIND: HYDRO Viking w/48" Deck), (W ALK BEHIND

MOWER: 48 Metro SN <190000, 5 SPD Viking SN 90000> w/ 48" Deck, 5 SPD GEARBOX

Viking

w/48" Deck, OLD STYLE SN 40000> Vari-spd trans. w/48" Deck)

A-403088 5/8 X 95.5" (2425.70) Belt, Engine, (HYDRO WALK BEHIND: HYDRO Viking w/52" Deck), (WALK BEHIND MOWER:

5 SPD Viking SN 90000> w/ 48" Deck)

A-403105 5/8 X 55" (1397) Belt, Blade Drive, (HYDRO WALK BEHIND: HYDRO Viking w/52" Deck), (W ALK BEHIND

MOWER: 5 SPD Viking SN 90000> w/ 52" Deck, 52 Metro SN <190000)

A-403174 5/8 X 115.25" (2927.35) Belt, Blade Drive, (WALK BEHIND MOWER: M4815KC Metro w/ 48" cut)

A-413093 5/8 X 136.64" (3470.656) Belt, Deck, (HYDRO WALK BEHIND: HP Turf T racer w/48" Deck), (WALK BEHIND MOWER: HP

Metro SN 150000> w/ 48" Deck), (ZERO TURN MOWER: HP MODELLazer w/44" Deck)

A-413094 5/8 X 103.75 (2635.25) Belt, Deck, (HYDRO WALK BEHIND: HP Turf T racer w/36" Deck), (WALK BEHIND MOWER: HP

Metro SN 150000> w/ 36" Deck)

A-413095 1/2 X 50.5" (1282.7) Belt, Pump Drive, (HYDRO WALK BEHIND: HP Turf T racer)

A-413096 5/8 X 36.06" (915.92) Belt, Blade Drive, (HYDRO WALK BEHIND: HP Turf T racer), (W ALK BEHIND MOWER: HP Metro

SN 150000>)

A-413308 5/8 X 141.25" (3587.75) Belt, Deck, (HYDRO WALK BEHIND: HP Turf T racer w/52" Deck), (WALK BEHIND MOWER: HP

Metro SN 150000> w/ 52" Deck), (ZERO TURN MOWER: HP MODELLazer w/48" Deck)

A-523175 1/2 X 134.25" (3409.95) Belt, Deck, (ZERO TURN MOWER: Z MODEL Lazer w/60 INCH)

A-543028 5/8 X 90" (2286) Belt, Engine, (ZERO TURN MOWER: 52 INCH Turf Ranger SN <115000)

A-543521 5/8 X 87.5" (2222.5) Belt, Drive, (ZERO TURN MOWER: 60 INCH Turf Ranger SN 1115000>)

A-543523 5/8 X 88" (2235.20) Belt, Engine, (ZERO TURN MOWER: 60 INCH Turf Ranger SN 130000>)

A-543548 1/2 X 36.875" (936.625) Belt, Engine, (ZERO TURN MOWER: 60 INCH Turf Ranger SN 130000>)

A-543749 5/8 X 91" (2311.4) Belt, Engine, (ZERO TURN MOWER: 52 INCH Turf Ranger SN 115000>)

A-603045 1/2 X 112.734" (2863.4436) Belt, Blade Drive, (HYDRO WALK BEHIND: HYDRO Turf Tracer w/60" Deck, HYDRO Turf T racer

SN <320000 w/ 60" Deck), (ZERO TURN MOWER: 60 Turf Ranger)

A-603193 5/8 X 53.25" (1352.55) Belt, Wheel Drive, (HYDRO WALK BEHIND: HYDRO Turf T racer)

A-603295 5/8 X 41.625" (1057.28) Belt, Transmission Drive, (HYDRO WALK BEHIND: HYDRO Turf T racer)

A-603306 5/8 X 81.308" (2065.2232) Belt, Engine, (HYDRO WALK BEHIND: HYDRO Turf T racer w/60" Deck)

A-603576 1/2 X 104.25" (2647.95) Belt, Blade Drive, (HYDRO WALK BEHIND: HYDRO Turf Tracer w/52" Deck), (ZERO TURN

MOWER: 52 Turf Ranger)

A-603582 5/8 X 84" (2133.6) Belt, Engine, (HYDRO WALK BEHIND: HYDRO Turf T racer w/52" Deck)

A-603809 5/8 X 59.638" (1514.8052) Belt, Hydro Pump, (HYDRO WALK BEHIND: HYDRO Turf Tracer SN <160000)

A-613271 1/2 X 59.5" (1511.3) Belt, Pump Drive, (ZERO TURN MOWER: Z MODEL Lazer w/ 60" deck)

A-633127 5/8 X 146.17" (3712.718) Belt, Deck, (ZERO TURN MOWER: Z MODEL Lazer w/60" Deck)

A-633162 8 rib 3/4 X 58" (1473.2) Belt, Pump Drive, (ZERO TURN MOWER: Z MODEL Lazer w/52" Deck, Z MODEL Lazer w/60"

Deck Before 1997 SN<130000)

A-633173 5/8 X 111.44" (2830.576) Belt, Engine, (ZERO TURN MOWER: Z MODEL Lazer, SN <369999 w/ 52", Z MODEL Lazer,

SN <369999 w/ 60")

A-633366 5/8 X 128.81" (3271.8) Belt, Deck, (WALK BEHIND MOWER: HP Metro SN 150000> w/ 52" Deck), (ZERO TURN

MOWER: Z MODEL Lazer w/52" Deck)

A-633569 3/4 X 57" (1447.8) Belt, Pump Drive, (WALK BEHIND MOWER: HP Metro SN 150000>), (ZERO TURN MOWER: Z

MODELLazer)

A-633853 7/16 X 25.75" (654.05) Belt, Alternator , (ZERO TURN MOWER: Z MODEL Lazer)

A-643052 5/8 X 169.46" (4304.284) Belt, Deck, (WALK BEHIND MOWER: HP Metro SN 150000> w/ 72" Deck), (ZERO TURN

MOWER: Z MODEL Lazer w/72" Deck)

A-653163 1/2 X 52.25" (1327.15) Belt, Pump Drive, (ZERO TURN MOWER: HP MODEL Lazer)

A-653332 1/2 X 37.75" (958.85) Belt, Blower, (ZERO TURN MOWER: HP MODELLazer w/44 INCH)

A-653333 1/2 X 38.5" (977.9) Belt, Blower, (ZERO TURN MOWER: HP MODELLazer w/48 INCH)

A-653368 5/8 X 154" (3911.6) Belt, Drive, (ZERO TURN MOWER: HP MODELLazer w/52" Deck)

A-653416 5/8 X 51.4" (1305.56) Pump Drive Belt, (ZERO TURN MOWER: HP MODELLazer w/52")

A-653438 1/2 X 39.5" (1003.3) Belt, Blower, (ZERO TURN MOWER: HP MODELLazer w/46 INCH, (HP MODEL, Z MODEL ALL

Lazer w/52))

E-Z

A-S335 1/2 X 30" (762) Belt, (EDGER: SEVERAL)

LAWN & GARDEN BELTS

Huskee

Exmark

OrderForm

LAWN &GARDEN BELTS

Ferris

A-1520873 5/8 X 115.75" (2940.05) Belt, Deck, (WALK BEHIND MOWER: 48 INCH HYDRO)

A-1521427 1/2 X 62" (1574.8) Belt, (W ALK BEHIND MOWER: HYDRO)

A-20824 5/8 X 131.75" (3346.45) Belt, Deck, (WALK BEHIND MOWER: 61 INCH HYDRO)

A-21063 5/8 X 91.5" (2324.1) Belt, Engine, (RIDING LAWN MOWER: 22 SERIES 61" Deck)

A-21106 5/8 X 88.625" (2251.08) Belt, Engine, (RIDING LAWN MOWER: 32 SERIES 72" Deck)

A-21261 5/8 X 54.75" (1390.65) Belt, Engine, (WALK BEHIND MOWER: 48 INCH HYDRO)

A-21297 5/8 X 118.875" (3019.425) Belt, Deck, (W ALK BEHIND MOWER: 52 INCH HYDRO)

A-21684 5/8 X 39.5" (1003.3) Belt, Pump Drive, (RIDING LAWN MOWER: 32 SERIES 72" Deck)

A-21724 5/8 X 197.25" (5010.15) Belt, Deck, (RIDING LAWN MOWER: 32 SERIES 72" Deck)

A-22061 5/8 X 175.9375" (4468.8125) Belt, Deck, (RIDING LAWN MOWER: ISZ ZERO TURN 61" Deck)

A-22062 4PL-105.7" (2684.78) Belt, Deck, (RIDING LAW N MOWER: ISZ ZERO TURN 52 & 61 INCH)

A-22148 5/8 X 150.9375" (3833.8125) Belt, Deck, (RIDING LAWN MOWER: ISZ ZERO TURN 52" Deck)

A-22173 1/2 X 66.625" (1692.275) Update Belt, (WALK BEHIND MOWER: 36 HYDRO, 48H HYDRO, 52 HYDRO, 61 HYDRO)

A-22314 1 1/8" X 66" (1676.4) 2 band Belt, Transmission Drive, (RIDING LAWN MOWER: IS1000Z, IS3000Z, IS4000Z)

A-22667 5/8 X 139.2" (3535.68) Belt, Deck, (RIDING LAWN MOWER: IS1000Z 48" deck)

A-5100555 1 1/8 X 66" (1676.4) Belt, T ransmission Drive,

Grasshopper

A-382025 5/8 X 55" (1397.00) Belt, Blade Drive, Short, (LA W N MOWER: 61 INCH)

A-382037 5/8 X 64" (1625.60) Belt, Blade Drive, Long, (LAW N MOWER: 52 INCH)

A-382049 5/8 X 82" (2082.80) Belt, Blade Drive, Long, (LAW N MOWER: 61 INCH)

A-381904 1/2 X 34" (863.60) Belt, Pump Drive, (LAWN MOWER: 1210, 1620, 1820, 1822)

A-381914 1/2 X 36" (914.40) Belt, PT O, (LAWN MOWER: 1822 Diesel)

A-382035 5/8 X 65.75" (1670.05) Belt, Drive,

A-382095 5/8 X 147.5" (3746.5) Belt, Mule Drive,

A-382627 1/2 X 37.42" (950.47) Belt, Transmission Drive, (RIDING LAWN MOWER: 614, 616)

A-382777 5/8 X 38.125" (968.375) Belt, Blade Drive, Short, (LA W N MOWER: 48 INCH)

A-382800 5/8 X 52" (1320.80) Belt, Blade Drive, Short, (LA W N MOWER: 52 INCH)

A-382836 5/8 X 62.125" (1577.975) Belt, Blade Drive, Long, (LAW N MOWER: 48 INCH)

Great Dane

A-D18004 9/16 X 62" (1574.8) Belt, Pump Drive,

A-D18005 5/8 X 82" (2082.8) Belt, Engine,

A-D18006 5/8 X 56.375" (1431.93) Belt, Deck,

A-D18007 5/8 X 88.5" (2247.9) Belt, Engine,

A-D18008 11/16 X 60.5" (1536.7) Belt, Deck,

A-D18087 5/8 X 77.625" (1971.675) Belt, Engine,

A-D18088 5/8 X 53.125" (2111.38) Belt, Deck,

A-D18303 1/2 X 68.5" (1739.9) Great Dane,

A-D28028 BB X 132.625" (3368.675) Belt, Blade Drive,

A-D28029 5/8 X 106.875" (2714.625) Belt, Blade Drive,

A-D28030 1/2 X 76" (1930.4) Belt, Pump Drive,

A-D28031 BB X 117.5" (2984.5) Belt, Blade Drive,

Huskee

A-7540280 5/8 X 52.50" (1333.5) Belt, Drive,

A-7540329A 5/8 X 69" (1752.60) Belt, Blade Drive,

A-7540349 1/2 X 79" (2006.6) Belt, Drive,

A-7540350 5/8 X 64" (1625.6) Belt, Drive,

A-7540370 5/8 X 48.5" (1231.9) Belt, Drive,

A-7540371A 5/8 X 74" (1879.6) Belt, Drive,

A-7540467 5/8 X 90.5" (2298.7) Belt, Drive,

A-7540468 5/8 X 41.5" (1054.1) Belt, Drive, Upper, (LAWN/ GARDEN TRACTOR: A U TODRIVE STEP THRU FRAME 1999>)

A-7540475 5/8 X 108.5" (2755.9) Belt, Drive,

A-7540497 1/2 X 60.5" (1536.7) Belt, Deck, (LAWN/ GARDEN TRACTOR: A U TODRIVE Step Thru Frame 2001-2003 w/ 42" Deck)

A-9540486 5/8 X 67" (1701.8) Belt, Drive,

Honda

A-23161952771 3/8 X 35.5" (901.70) Belt, (SELF PROPELLED: HR21)

A-781310 5/8 X 179.5" (4559.3) Belt, Deck,

A-781443 1/2 X 61.97" (1574.04) Belt, Hydro Pump,

A-782292 5/8 X 165.5" (4203.7) Belt, Deck,

A-784207 5/8 X 195" (4953) Belt, Deck,

John Deere

Huskee

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

A-784249 5/8 X 145" (3683) Belt, Deck,

A-789388 5/8 X 152.5" (3873.5) Belt, Deck,

Husqvarna

A-PP13007 5/8 X 89.5" (2273.3) Belt, Main Deck, (RIDING LAW N MOWER: HAU18H48A, YTH1848XPA, YTH1848XPB,

YTH1848XPC, YTH2048A)

A-PP13008 5/8 X 89" (2260.60) Belt, Secondary Deck, (RIDING LAW N MOWER: HAU18H48A, YTH1848XPA, YTH1848XPB,

YTH1848XPC, YTH2048A)

A-PP13009 5/8 X 97.625" (2479.68) Belt, Deck, Electric, (RIDING LAW N MOWER: (YTH1542B, YTH1542C, YTH1542XPB, YTH1642A

A L L w/ 42" Deck))

A-144959 1/2 X 95.5" (2425.7) Belt, Blade Drive, (RIDING LAW N MOWER: LTH1342, LTH1742, LTH18542, LTH2042, YTH1746,

YTH1842, YTH2046)

A-180808 5/8 X 89.25" (2266.95) Belt, Secondary Deck, (RIDING LAW N MOWER: HAU18H48A, YTH1848XP, YTH1848XPA,

YTH1848XPB, YTH1848XPC, YTH2048A)

A-506033033 5/16 X 34.25" (869.95) Belt, Drive, (CUT-OFF SAW : 272K)

A-506070520 3/8 X 35.1" (891.54) Transmission Belt,

A-506372720 3/8 X 35.1" (891.54) Transmission Belt,

A-531030352 5/16 X 34" (863.60) Belt, Wheel Drive, (CUT-OFF SAW : 272K)

A-532130969 1/2 X 92" (2336.8) Belt, Mower, (RIDING LAW N MOWER: GTH2654T, GTH26K54T, LOYTH20F42T, LT40, YT160,

YTH1542XPT, YTH1848XPT, YTH20B42T, YTH20F42T, YTH2242T, YTH2448T, YTH2454T)

A-532157769 3/8 X 32.625" (828.68) Belt, Drive,

A-532196103 5/8 X 147.75" (3752.85) Belt, Mower Deck, (RIDING LAW N MOWER: GTH2454T, GTH2654T, GTH26K54T, YTH2454T)

A-539101956 1/2 X 50.5" (1282.7) Wheel Drive Belt, (WALK BEHIND MOWER: 36 INCH, 48 INCH)

A-539110411 1/2 X 56.5" (1435.1) Belt, Mower, (ZERO TURN MOWER: CZ3815, CZ4217, CZ42175, Z3815, Z3815BIA, Z4217,

Z4217BIA, Z4218, Z4218KOA, Z4822, Z4824)

A-539110832 5/8 X 145" (3683) Belt, Mower, (RIDING LAWN MOWER: IZ4217, IZ4217TSKAA)

A-539110859 1/2 X 50.5" (1282.7) Belt, Wheel Drive, (WALK BEHIND MOWER: 36 INCH, 48 INCH)

A-606000226 3/8 X 32.67" (829.82) Belt, Drive,

Jacobsen

A-182185 1-1/4" X 52.5" Banded (1333.5) Belt, Wheel Drive, (WALK BEHIND MOWER: CREW KING)

A-182214 1/2 X 40" (1016) Belt, T ransmission Drive, (WALK BEHIND MOWER: CREW KING 5 Speed)

John Deere

A-AM100465 1/2 X 32.677" (829.99) Belt, PT O , (FRONT MOWER: F910, F911, F912, F915, F925, F930, F932, F935)

A-AM102190 1/2 X 43.3" Set/2 (1099.82) Belt, Deck, (LAWN/GARDEN TRACTOR: F900 RIDER 76")

A-BB111 Belt, Deck, (LAWN/GARDEN TRACTOR: 425 w/ 48" Deck)

A-GX20006 1/2 X 88.9" (2258.06) Belt, Traction Drive, Mower, (SABO LAW N TRACTOR: 108-14.5, 108-17HS), (SABRE LAW N

TRACTOR: 1642HS, 17.542HS, 1742HS), (LAWN/GARDEN TRACTOR: L105, L107, L110, L120,

L130), (SCOTTS LAWN TRACTOR: L17.542, L2048, L2548)

A-GX20241 1/2 X 92" (2336.8) Belt, Traction Drive, Mower, (SABRE LAW N TRACTOR: 14.542GS), (LAWN/GARDEN TRACTOR:

L100), (SCOTTS LAWN TRACTOR: L1742)

A-GX20305 1/2 X 138.5" (3517.9) Mower Platform Drive Belt, (LA WN/GARDEN TRACTOR: L120, L130)

A-GY20570 1/2 X 103.3" (2623.82) Belt, Plat form Drive, Mower, (SABO LAW N TRACTOR: 108-14.5, 108-17HS), (SABRE LAW N

TRACTOR: 14.542GS, 1642HS, 17.542HS, 1742HS), (LAWN/GARDEN TRACTOR: L100, L105,

L107, L110), (SCOTTS LAWN TRACTOR: L17.542, L1742)

A-GY20571 1/2 X 138.5" (3517.9) Belt, Plat form Drive, Mower, (SCOTTS LAWN TRACTOR: L2048, L2548)

A-GY20572 1/2 X 65.15" (1654.81) Belt, Plat form Drive, Mower, (SABRE LAWN TRACTOR: 1842GV, 1842HV, 1848GV, 1848HV,

1948GV, 1948HV, 2048HV, 2148HV, 2254HV, 2354HV, 2554HV), (LAWN/GARDEN TRACTOR:

G100, GT242, GT262, GT275, LX172, LX173, LX176, LX178, LX186, LX188), (SCOTTS LAW N

TRACTOR: GT2554, S2048, S2348, S2554)

A-GX21395 5/8 X 161.4" (4099.56) Belt, Drive, Mower, (LAWN/GARDEN TRACTOR: 316, 318, 322, 325, 332, 335, 345, 355, 355D,

425, 445, 455, G100, G110, GT225, GT235, GT242, GT245, GT262, GT275, GX255, GX325,

GX335, GX345, GX355, X300, X304, X320, X324, X340, X465, X475, X485, X495, X500, X520,

X534, X540, X575,

A-GX21833 1/2 X 141.7" (3599.18) Belt, Deck, (LAWN/GARDEN TRACTOR: LA130 48" w/ 21 HP)

A-GX22036 1/2 X 92" (2336.8) Belt, Drive, (LA WN/GARDEN TRACTOR: LA100 42" w/ 18.5 HP)

A-M40223 1/2 X 87" (2209.8) Belt, Secondary Blade, (LAWN/GARDEN TRACTOR: (110, 1 11, 112 A L L w/ 38" & 36" decks)),

(MOWER: 38, 39)

A-M41668 Mower Belt, (LAWN/GARDEN TRACTOR: (120, 140, 300 A L L 46" Mid Mount), 300 50" Rotary

Mower), (MOWER: 48), (SNOWTHROWER: (32, 32A ALL <400000))

A-M43569 1/2" X 50" (1270) Belt, Hay & Forage, (MOWER: 34), (SNOWTHROWER: 36)

A-M44121 5/8 X 67.5" (1714.5) Belt, V ariable S peed to T rans, (LA WN/GARDEN TRACTOR: 110, 110H, 112, 1 12H, 200, 208, 210,

212, 214, 216)

A-M47765 .56 X 84" (2133.6) Belt, Drive, (MOWER: 39 SN <176558, 46 MID MOUNT, 47 SN <176558), (TILLER: 30

HYDRAULIC 46" MMRM)

A-M47766 1/2" X 80" (2032) Belt, Deck, (MOWER: 38 MID MOUNT, 39 MOUNT S/N 176559>), (TILLER: 30 HYDRAULIC)

LAWN & GARDEN BELTS

John Deere

OrderForm

LAWN &GARDEN BELTS

A-M74747 1/2 X 105" (2667.00) Belt, Drive, (LA WN/GARDEN TRACTOR: STX30, STX38)

A-M77988 .559 X 59.9" (1521.46) Belt, V ariable Drive, (LA WN/GARDEN TRACTOR: 108, 111, 111H, 112L, 130, 160, 165, 170, 175,

180, 185, 240, 245, 260, 265, 285, 320, GT242, GT262, GT275, LX172, LX173, LX176, LX178,

LX186, LX188)

A-M82167 1/2" X 51" (1295.4) Drive Belt, (LA WN/GARDEN TRACTOR: 66, 68, S82, S92)

A-M82258 5/8 X 40" (1016) Belt, Drive, (LA WN/GARDEN TRACTOR: 110, 112, 200, 208, 210, 214)

A-M82538 1/2 X 63.375" (1609.73) Belt, Deck, (MOWER: 38 MID MOUNT), (LAWN/GARDEN TRACTOR: (66, 68 A L L SN <222000),

S80, S82)

A-M84136 15/32 X 101" (2565.40) Belt, Secondary Drive, (LAWN/GARDEN TRACTOR: 116, 1 16H, 180, 185, 240, 280, 285)

A-M86248 1/2" X 103" (2616.2) Belt, Deck, (LA WN/GARDEN TRACTOR: S92)

A-M87373 CC X 154" (3911.6) Belt, Blade Drive, (FRONT MOUNT MOWER: 50 INCH, 60 INCH, 72 INCH, 76 INCH)

A-M110313 5/8 X 111.3" (2813.05) Belt, Drive, (LA WN/GARDEN TRACTOR: 240, 260, 265, 285, 320)

A-M110978 1/2 X 102.25" (2597.15) Belt, Hydro Pump, (LAWN/GARDEN TRACTOR: LX176, LX178, LX186, LX188)

A-M111534 BB X 130.5" (3314.7) Belt, Deck, (LAWN/GARDEN TRACTOR: (F710, F725, F735 ALL w/ 54" deck))

A-M115776 5/8 X 107.6" (2733.04) Belt, Drive, Mower, (LAWN/GARDEN TRACTOR: 316, 318, 322, 325, 332, 335, 345, 355, 355D,

425, 445, 455, G100, G110, GT225, GT235, GT242, GT245, GT262, GT275, GX255, GX325,

GX335, GX345, GX355, X300, X304, X320, X324, X340, X465, X475, X485, X495, X500, X520,

X534, X540, X575,

A-M117608 5/8 X 107.6" (2733.04) Belt, Drive, (LA WN/GARDEN TRACTOR: 240, 245, 260, 265, 285, 320, GT225, GT235, GT235E,

GT242, GT245, GT262, GT275, LX255, LX266, LX277, LX279)

A-M118685 5/8 X 120" (3048) Belt, Secondary Drive, Mower, (SABRE LAW N TRACTOR: (2254HV, 2354HV, 2554HV AL L w/ 54"

Deck Only)), (SCOTTS LAW N TRACTOR: (GT2554, S2554 ALL w/ 54" Deck Only)),

(LAWN/GARDEN TRACTOR: (325, 335, 345, 355D, G100, GT225, GT235, GT235E, GT245,

GX325, GX335, GX345, GX355, LX255, LX266, LX27

A-M119539 .559 X 137.48" (3492) Belt, Drive, (LA WN/GARDEN TRACTOR: STX38, STX48)

A-M119872 5/8 X 93.8" (2382.52) Belt, Deck, (LAWN/GARDEN TRACTOR: 316, 318, 322, 325, 332, 335, 345, 355, 355D, 425, 445,

455, G100, G110, GT225, GT235, GT242, GT245, GT262, GT275, GX255, GX325, GX335,

GX345, GX355, X300, X304, X320, X324, X340, X465, X475, X485, X495, X500, X520, X534,

X540, X575,

A-M120381 BB X 124" (3149.6) Belt, Deck, (LAWN/GARDEN TRACTOR: F900 RIDER 60")

A-M122907 .638 X 50.488" (1282.4) Belt, Drive, (W ALK BEHIND MOWER: G15, GS25, GS30, GS45, GS75)

A-M123281 1/2 X 142.75" (3625.85) Belt, Drive, (LA WN/GARDEN TRACTOR: LT166)

A-M125218 .559 X 95.748" (2432) Belt, Drive, (LA WN/GARDEN TRACTOR: STX38, STX46)

A-M125383 1 1/4" X 56.122" (1425.4988) Belt, T ransaxle Driven Clutch, (UTILITY VEHICLE: 6X4 GATOR, DIESEL G ATOR, TRAIL G ATOR,

WORKSITE GATOR)

A-M126536 1/2 X 114.5" (2908.3) Belt, Deck, (LAWN/GARDEN TRACTOR: LT133, LT150, LT155, LT160, LT166, LT180)

A-M136927 1/2 X 108" (2743.2) Belt, Traction Drive, Mower, (LAWN/GARDEN TRACTOR: G100), (SABRE LAWN TRACTOR:

1842GV, 1842HV, 1848GV, 1848HV, 1948GV, 1948HV, 2048HV, 2148HV, 2254HV, 2354HV,

2554HV), (SCOTTS LAW N TRACTOR: GT2554, S2048, S2348, S2554)

A-M143019 .559 X 63.386" (1610) Belt, Drive, (LA WN/GARDEN TRACTOR: 325, 335, 345, 355D, GT225, GT235, GT235E, GT245,

GX255, GX325, GX335, GX345, GX355, LX255, LX266, LX277, LX279, LX280, LX288, LX289)

A-M147278 1/2 X 90.2" (2291.08) Belt, Power Mower, (LAWN/GARDEN TRACTOR: Z425 48" convertible deck)

A-M148556 .559 X 54.4" (1381.76) Belt, Primary, (LAWN/GARDEN TRACTOR: 316, 318, 322, 325, 332, 335, 345, 355D, 425, 445,

455, G100, G110, GT225, GT235, GT242, GT245, GT262, GT275, GX255, GX325, GX335,

GX345, GX355, X300, X304, X320, X324, X340, X465, X475, X485, X495, X500, X520, X534,

X540, X575, X585

A-M154157 1/2 X 42.25" (1073.15) Belt, Hydro, Mower, (LAWN/GARDEN TRACTOR: Z425 48" w/ 23 HP)

A-M154294 1/2 X 119.25" (3028.95) Belt, Deck, (LAWN/GARDEN TRACTOR: Z225 42" w/ 18.5 HP)

A-M154295 1/2 X 150.5" (3822.7) Belt, Deck, (LAWN/GARDEN TRACTOR: Z425 48" convertible deck)

A-M155343 1/2 X 60" (1524) Belt, Drive, (LA WN/GARDEN TRACTOR: Z225 42" w/ 18.5 HP)

A-PT8675 5/8 X 44" (1117.60) Belt, Wheel Drive, (WALK BEHIND MOWER: FLAT DECK)

A-PT8676 1/2 X 50" (1270) Belt, Blade Drive, (W ALK BEHIND MOWER: 36 INCH FLAT DECK)

A-PT8697 21/32 X 37" (939.80) Belt, T ransmission Drive, (WALK BEHIND MOWER: FLAT DECK)

A-PT8875 5/8 X 44" (1117.6) John Deere,

A-PT12668 5/8 X 53.75" (1365.25) Belt, Engine, (WALK BEHIND MOWER: 32 INCH FLAT DECK, 36 INCH FLAT DECK)

A-TCU13198 5/8 X 142" (3606.80) V -Belt, Deck Drive, (ZERO TURN MOWER: 737, 757, 777, 797)

A-TCU16092 5/8 X 150.2" (3815.08) Belt, Deck, (LAWN/GARDEN TRACTOR: Z-TRAK 48" Deck)

A-TCU16495 39/64 X 125.7" (3192.78) V -Belt, PT O Clutch, (ZERO TURN MOWER: 777, 797)

A-TCU16841 8rib 32.5" (825.5) V -Belt, Hydraulic Pump Drive, (ZERO TURN MOWER: 777, 797)

A-TCU18602 5/8 X 147.5" (3746.5) Belt, Deck, (ZERO TURN MOWER: 667A, 717A, 727A)

Kubota

A-K5112-51310 5/8 X 94" (2387.6) Belt, PT O , (MID MOUNT MOWER: RCK40LT)

A-K5112-71420 5/8 X 69" (1752.60) Belt, Deck, (MID MOUNT MOWER: RCK40LT, (RCK44LT-17, RCK48LT-17, RCK48LTB ALL P TO Belt))

A-K5142-51310 5/8 X 71" (1803.4) Belt, PT O , (MID MOUNT MOWER: RCK44LT, RCK44LTB)

A-K514271420 5/8 X 95" (2413) Belt, Deck, (MID MOUNT MOWER: RCK44LT, RCK44LT-17, RCK44LTB)

A-K5182-71420 5/8 X 98" (2489.2) Belt, Deck, (MID MOUNT M OWER: RCK48LT-17, RCK48LTB)

Kubota

John Deere

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

A-K5201-71410 5/8 X 106.5" (2705.1) Belt, Deck, (MID MOUNT MOWER: RCK48-20ZG, RCK48-GR, RCK48TG)

A-K5221-51350 5/8 X 60" (1524) Belt, PT O , (MID MOUNT MOWER: RCK54TG)

A-K5221-71410 5/8 X 113" (2870.2) Belt, Deck, (MID MOUNT MOWER: RCK54-23ZG, RCK54GR, RCK54TG)

A-K5351-34710 1-1/2 X 113.25" (2876.55) Belt, Deck, (MID MOUNT MOWER: RCK54-15BX, RCK54-22BX, RCK54-24G, RCK54-75B)

A-K5410-71410 5/8 X 53" (1346.2) Belt, Deck LH, (MID MOUNT MOWER: RCK48R-21G)

A-K5410-71420 BB 5/8 X 102.375" (2600.3) Belt, Deck RH, (MID MOUNT MOWER: RCK48R-21G)

A-K5645-34710 1-1/8 X 120" 2 band (3048) Belt, Deck, (MID MOUNT MOWER: RCK60-21Z, RCK60-28Z)

A-K5647-34710 1-1/8 X 123" 2 band (3124.2) Belt, Deck, (MID MOUNT MOWER: RCK60P-21Z, RCK60P-28Z)

A-K5651-34710 1-1/8 X 128" 2 band (3251.2) Belt, Tension Pulley, (MID MOUNT MOWER: RCK60-28Z), (FRONT MOUNTMOWER: RCK60-F30)

A-K5671-34710 1-1/4 X 136.5" 2 band (3467.1) Belt, Tension Pulley, (FRONT MOUNTMOWER: RC72-F30), (MID MOUNT MOWER: RCK72-

28Z)

A-K5677-34710 1-1/8 X 136.5" 2 band (3467.1) Belt, Deck, (MID MOUNT MOWER: RCK72P-28Z)

A-K5700-34710 1-1/8 X 104.5" 2 band (2654.3) Belt, Deck, (MID MOUNT MOWER: RCK48-15BX)

A-K5763-34710 1-1/8 X 119" 2 band (3022.6) Belt, Deck, (MID MOUNT MOWER: RCK60-24B, RCK60-27B, RCK60-30B, RCK60B-22BX,

RCK60B-24G, RCK60B-75B)

A-K5764-34710 1-1/8 X 113" 2 band (2870.0) Belt, Deck, (MID MOUNT MOWER: RCK54-18Z)

A-14911-97010 3/8 X 37.875" (962.03) Belt, Fan, F2260, F2400, F2560, F2560E, F3060, FZ2400

A-15533-72530 3/8 X 35.5" (901.7) Belt, Fan NEW, (FRONT MOWER: F2000, F2100E)

A-66021-25080 Set of 2 Belt, PT O Shaft (Set/2), G3200, G4200, G4200H, G5200H, G6200H, RC40-G, RC44G, RC48-G

A-66071-61720 5/8 X 68" (1727.20) Belt, PT O , (MID MOUNT MOWER: RC40LT), (LA WN/GARDEN TRACTOR: T1400H)

A-66091-61650 5/8 X 97" (2463.8) Belt, Mower, (MID MOUNT MOWER: RC44LT)

A-66101-25080 5/8 X 33.5" (850.9) Belt, Mower, (MID MOUNT MOWER: RC48-G20, RC48-G20S, RC54-G20, RC60-G20)

A-70050-93960 5/8 X 161" (4089.4) Belt, Mower, (FRONT MOUNT MOWER: RC60R-F30, RC60R-FD)

A-70050-94495 5/8 X 175.75" (4464.05) Belt, Mower, (FRONT MOUNTMOWER: RC72R-F30)

A-70050-94497 5/8 X 102.5" (2603.5) Belt, Mower, (FRONT MOUNTMOWER: RC48R-GF)

A-70050-94786 5/8 X 136" (3454.40) Belt, Mower, (FRONT MOUNTMOWER: RC48R-F30)

A-70080-00247 1/2 X 83" (2108.2) Belt, Deck, (MID MOUNT MOWER: K44)

A-70706-34710 7/8 X 113" (2870.2) Belt, Mower, RC60-20, RC60-25

A-70712-34710 5/8 X 90" (2286) Belt, Deck, (MID MOUNT MOWER: RC44-42, RC44G)

A-70713-34770 5/8 X 84" (2133.6) Belt, Deck, (MID MOUNT MOWER: RC40-42, RC40-G)

A-70720-34710 5/8 X 111" (2819.4) Belt, Mower, RC60-71H

A-70722-32430 5/8 X 41.5" (1054.1) Belt, PT O, Front, (MID MOUNT MOWER: RC48-62A, RC48-62F, RC60-20, RC60-72, RC60-72A,

RCB60-I, RCB60-IA, RCB60-IAE, RCB60-IE)

A-70722-34710 5/8 X 113" (2870.2) Belt, Mower, RC60-72H, RC60-82H, RCB60-I, RCB60-IA, RCB60-IAE, RCB60-IE

A-70725-34710 5/8 X 122" (3098.8) Belt, Mower, (MID MOUNT MOWER: RC60-72, RC60-72A), (FRONT MOUNTMOWER: RC60-

F20, RC60-F24)

A-76500-34710 5/8 X 91" (2311.4) Belt, Mower, (MID MOUNT MOWER: RC48-62H)

A-76505-34710 1/2 X 96.75" (2457.45) Belt, Mower, (FRONT MOUNT MOWER: RC48-F19), (MID MOUNT MOWER: RC48-G, RC48-

G20, RC48-G20S)

A-76516-61510 5/8 X 62.5" (1587.5) Belt, Tension Pulley, (MID MOUNT MOWER: RC44LT-17, RC48LT-17)

A-76516-61660 5/8 X 98.5" (2501.9) Belt, Deck, (MID MOUNT MOWER: RC44LT-17)

A-76517-61660 5/8 X 70.5" (1790.7) Belt, Deck, (MID MOUNT MOWER: RC40LT, RC40LT-17)

A-76521-34710 5/8 X 106" (2692.4) Belt, Tension Pulley, (MID MOUNT MOWER: RC48-62A, RC48-62F)

A-76529-34710 1/2 X 112.5" (2857.5) Belt, Tension Pulley, (MID MOUNT MOWER: RC54-24B, RC54-71B, RC54-B), (FRONT MOUNT

MOWER: RC54-F19, RC54-FZ21), (MID MOUNT MOWER: RC54-G20)

A-76535-34710 5/8 X 111" (2819.4) Belt, Mower, (MID MOUNT MOWER: RC60-92H)

A-76539-34710 1-1/4 X 121" (3073.4) Belt, Tension Pulley, (MID MOUNT MOWER: RC60-21B, RC60-24B, RC60-71B, RC60-B),

(FRONT MOUNTMOWER: RC60-F19, RC60-FZ21), (MID MOUNT MOWER: RC60-G20)

A-76539-34710 1-1/4 X 121" (3073.4) Belt, Tension Pulley, (MID MOUNT MOWER: RC60-21B, RC60-24B, RC60-71B, RC60-B),

(FRONT MOUNTMOWER: RC60-F19, RC60-FZ21), (MID MOUNT MOWER: RC60-G20)

A-76550-34710 7/8 X 144" (3657.6) Belt, Mower, RC72-25, RC72-28, RC72-29, RC72-36, RC72-F20, RC72-F24

A-76553-34710 1-1/8 X 141.25 (3587.75) Belt, Tension Pulley, (MID MOUNT MOWER: RC72-B), (FRONT MOUNT MOWER: RC72-FZ21)

A-167149 5/8 X 151.5" (3848.1) Belt, Deck, (FINISHING MOWER: 6’)

A-167163 5/8 X 165.5" (4203.7) Belt, Drive,

Lawn Boy

A-608574 3/8 X 34" RE (864.6) Belt, Drive,

A-700370 3/8 X 31.5" (800.10) Belt, T ransmission Drive,

A-702451 1/2 X 102" (2590.80) Belt, T ransmission Drive,

A-702553 3/8 X 46" (1168.40) Belt, Drive,

A-704868 1/2 X 103.5" (2628.90) Belt, T ransmission Drive,

A-705361 3/8 X 46" (1168.40) Belt, Drive,

A-921043 3/8 X 33" (838.20) Belt, Transmission Drive, (SELF PROPELLED MOWER: SILVER SERIES)

LAWN & GARDEN BELTS

MTD / White

Kubota

OrderForm

LAWN &GARDEN BELTS

Lesco

A-021947 5/8 X 89" (2260.60) Belt, Engine, (WALK BEHIND MOWER: 48 INCH)

A-021947 5/8 X 89" (2260.60) Belt, Engine, (HYDRO WALK BEHIND: 48 INCH)

A-023887 1/2 X 48" (1219.2) Belt, Pump Drive, (HYDRO WALK BEHIND: 36 INCH, 48 INCH, 52 INCH)

A-050441 5/8 X 82.25" (2089.15) Belt, Engine, (WALK BEHIND MOWER: 36 INCH)

A-050441 5/8 X 82.25" (2089.15) Belt, Engine, (HYDRO WALK BEHIND: 36 INCH)

A-050480 5/8 X 53" (1346.20) Belt, Blade Drive, (WALK BEHIND MOWER: 48 INCH)

A-050480 5/8 X 53" (1346.20) Belt, Blade Drive, (HYDRO WALK BEHIND: 48 INCH)

A-068093 5/8 X 56.25" (1428.75) Belt, Engine, (HYDRO WALK BEHIND: 52 INCH)

A-700151 1-1/8 X 52.75" 2 band (1339.85) Belt, Wheel Drive, (WALK BEHIND MOWER: 36 INCH, 48 INCH)

A-705010 1/2" X 47.5" (1206.5) Belt, Pump Drive,

A-705375 1/2 X 114" (2895.6) Belt, Deck,

A-705376 1/2" X 122.75" (3117.85) Lesco Belt,

A-705377 5/8" X 91.5" (2324.1) Belt, Engine,

A-705378 5/8 X 87" (2209.8) Belt, Engine,

Little Wonder

A-177 1/2 X 30" (762) Belt, Drive, (EDGER: SEVERAL)

McLane

A-1060 1/2 X 19.5" (495.30) Belt, Drive, (MOWER: FRONT THROW REEL 1991>), (EDGER: SEVERAL 1991>)

A-2058 1/2 X 30" (762) Belt, Drive, (EDGER: SEVERAL)

A-4060 1/2 X 20" (508) Belt, Drive, (EDGER: SEVERAL)

A-7102 1/2 X 24.5" (622.30) Belt, Drive, (SELF PROPELLED: 21 INCH)

A-338213 3/8" X 39.25" (996.95) Mit subishi, A L L MODELS

A-100026 1 1/8" X 45.8125" (1163.6375) Cogged Kees Belt,

A-5959 3/4 X 27.75" (704.85) Manco, SEVERAL

MTD / White

A-00050441 5/8 X 82.21" (2088.13) Belt, PT O, (RIDING LAWN MOWER: Z-Force 48)

A-01000399 1/2 X 106.25" (2698.75) Belt, Deck, Drive, (RIDING LAWN MOWER: Z-Force 48)

A-01002391 5/8 X 63.04" (1601.22) Belt, PT O, (RIDING LAWN MOWER: Z-Force 44)

A-01004752 1/2 X 119.25" (3028.95) Belt, Deck, Drive, (RIDING LAWN MOWER: (Z-Force 44, Z-Force 48, Z-Force 50 ALL w/60"

deck))

A-01005011 5/8 X 83" (2108.2) Belt, PT O, (RIDING LAWN MOWER: (Z-Force 44, Z-Force 48 ALL w/ 50" Deck))

A-01005012 5/8 X 84" (2133.6) Belt, Deck, Drive, (RIDING LAWN MOWER: (Z-Force 44, Z-Force 48, Z-Force 50 ALL w/60"

deck))

A-01005375 1/2 X 114.3" (2903.22) Belt, Deck, Drive,

A-01005376 1/2 X 121.97 (3098.04) Belt, Deck, Drive,

A-01005377 5/8 X 94.2" (2392.68) Belt, Deck, Drive,

A-01005378 5/8 X 87.2" (2214.88) Belt, Deck, Drive,

A-01008349 1/2 X 55.5" (1409.7) Belt, T raction Drive,

A-02000103 1/2 X 81.5" (2070.1) Belt, S pindle Deck, (RIDING LAW N MOWER: (Z-Force 44, Z-Force 48, Z-Force 50 A L L w/50"

deck))

A-02000653 1/2 X 90.9" (2308.86) Belt, Mower,

A-490489R2 1/2 X 81.5" (2070.10) Belt, Drive, (RIDING LAWN MOWER: (123, 169, 70, 86 ALL 38", 42", 48" cut))

A-56629C1 3/8 X 35.5" (901.7) Belt, Transmission Drive, (RIDING LAW N MOWER: 50748)

A-56629C1 3/8 X 35.5" (901.7) Belt, Transmission Drive, (SNOWBLOWER: 314-600, 314-800)

A-7540101A 1/2 X 35" (889.00) Belt, (SNOWTHROWER: 20 INCH 4 and 5 HP)

A-7540125 1/2 X 105" (2667.00) Belt, Drive, (DECK: (962, 982 A L L 3 blade, shaft drive, 42"))

A-7540131 3/8 X 35.5" (901.70) Belt, Drive, (SNOWTHROWER: 310-840-000, 310-850-000, 310-960-000 1990, 311-840-000, 311-

850-000 1991, 31AE880-4352 1989, 31AE993J401 2002, 840-027, 840-050, 840-051, 840-095,

840-105 1997)

A-7540142 3/8 X 31.3" (795.02) Belt, Blade Drive, (TILLER: 546, 586)

A-7540145A 5/8 X 69" (1752.60) Belt, Blade Drive, (RIDING LAWN MOWER: (400 SERIES, 500 SERIES, 600 SERIES, 800

SERIES ALL 38" cut w/ side discharge))

A-7540151 5/8 X 67" (1701.80) Belt, Transmission Drive, (RIDING LAWN MOWER: 132-480)

A-7540155 3/8 X 40" (1016) Belt, Transmission Drive, (TILLER: 370, 375)

A-7540181 1/2 X 99.5" (2527.30) Belt, Blade Drive, (RIDING LAW N M O W E R : S E V E R A L 42" cut)

A-7540190 1/2 X 39" (990.60) Belt, (TILLER: FORW ARD DRIVE)

A-7540194 1/2 X 45" (1143) Belt, (SNOWBLOWER: 980 AUGER)

A-7540197 1/2 X 117" (2971.80) Belt, (LA WN/GARDEN TRACTOR: 900 SERIES w/ 50" deck)

A-7540218 5/8 X 59" (1498.60) Belt,

A-7540226 1/2 X 85" (2159) Belt, T rans Drive, (RIDING LAWN MOWER: (495 SERIES, 497 SERIES, 498 SERIES ALL 1977-1990))

A-7540228 5/8 X 62" (1574.8) Belt, Deck, (LAWN/GARDEN TRACTOR: A U TO DRIVE 2003> w/ 46" Deck)

MTD / White

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

A-7540230 1/2 X 56" (1422.40) Belt, Engine, (LA WN/GARDEN TRACTOR: (700 SERIES, 800 SERIES, 900 SERIES ALL 1977-

1990 w/ 42" or 50" deck))

A-7540240 5/8 X 38.187" (969.96) Belt, T ransmission Drive,

A-7540241A 5/8 X 35.25" (895.35) Belt, Drive, (LA WN/GARDEN TRACTOR: 30 INCH REAR ENGINE)

A-7540264 52.18" (1325.56) Belt, Blade Drive, (RIDING LAWN MOWER: (139-501, 139-502, 139-503, 139-504, 139-505, 139-

506, 139-507, 139-508, 139-511, 139-512, 139-513, 139-514 A L L 30" Deck))

A-7540266 1/2 X 85.2" (2,164.08) Belt, Engine, (LA WN/GARDEN TRACTOR: 600 SERIES 1985-1986)

A-7540271 3/8" X 39" (990.6) Drive, SEVERAL w/ rear discharge & self-propelled rear drive discharge

A-7540280 5/8 X 52.50" (1333.5) Belt, Eng, (RIDING LAWN MOWER: (300 SERIES, 400 SERIES, 500 SERIES, 600 SERIES ALL

36", 38", 42", 46", 50")), (LA WN/GARDEN TRACTOR: 400 SERIES, 600 SERIES, 800 SERIES)

A-7540281 5/8 X 44.22" (1123.16) Belt, (RIDING LAWN MOWER: (300 SERIES, 400 SERIES, 500 SERIES, 600 SERIES ALL w/ 38"

cut), SEVERAL 38", 40", 42" older unit s)

A-7540291 1/2 X 74" (1879.6 ) MTD/Cub Cadet, 50 DECK, 50 DECK w/ Auto Drive step thru frame 1999>, 800 SERIES w/ 50" deck

A-7540291A 1/2 X 88" (2235.2) Belt, Drive, (LA WN/GARDEN TRACTOR: 50 DECK w/ Auto Drive step thru frame 1999>),

(RIDING LAWN MOWER: 800 SERIES w/ 50" deck)

A-7540293 1/2 X 74" (1879.60) Belt, Engine, (LA WN/GARDEN TRACTOR: (803, 935 A L L 44" side discharge))

A-7540325 1/2 X 57" (1447.80) Belt, Drive, (TILLER: 218-430 SERIES)

A-7540329A 5/8 X 69" (1752.60) Belt, Blade Drive, (LA WN/GARDEN TRACTOR: (400, 600 SERIES ALL w/ 38" deck)), (Deck: 805

SERIES)

A-7540343 3/8 X 31" (787.40) Belt, Drive, (SNOWTHROWER: 600 SERIES two-stage), (SELF PROPELLED MOWER:

SEVERAL walk behind 1987 to 1996)

A-7540346 3/8 X 30" (762) Belt, Drive, (SNOWTHROWER: 644 SERIES, 317E642E088, 317E642E120, 317E642E352,

317E644E000642), (SELF PROPELLED MOWER: 474, 475, 476, 477)

A-7540349 1/2 X 79" (2006.6) Belt, Drive, (LA WN/GARDEN TRACTOR: (1600, 1800 ALL 46" Deck)), (RIDING LAW N MOWER:

(600 SERIES, 800 SERIES ALL 46" deck)), (LAWN/GARDEN TRACTOR: A U TO DRIVE 1999>,

LT1018 42" 18.5 HP B&S ELS Hydro, 14AK13CK709 54" 27 HP Kohler Hydro)

A-7540350 5/8 X 64" (1625.6) Belt, Engine, (RIDING LAWN MOWER: 800 SERIES w/ 46" deep deck)

A-7540355 1/2 X 67.16" (1705.86) Belt, Blade Drive, (RIDING LAWN MOWER: 300 SERIES 1987-1989 w/ 32" deck)

A-7540358 7/8 X 51" (1295.40) Belt, (RIDING LAWN MOWER: 800 SERIES 1996, variable speed pulley to engine pulley)

A-7540362 5/8 X 50" (1270) Belt, Transmission Drive, (LAWN/GARDEN TRACTOR: 800 SERIES 2-speed 1996>)

A-7540364 5/8 X 68" (1727.20) Belt, Blade Drive, (RIDING LAWN MOWER: 400 SERIES 36" & 38" deep deck), 800 SERIES 50" deep

deck

A-7540367 3/8 X 34.5" (876.3) Belt, (SNOWTHROWER: 140 Single Stage 1995>, SINGLE STAGE 1990-1996)

A-7540369 3/8 X 33" (838.2) Belt, Drive, (SELF PROPELLED MOWER: (230 SERIES, 526R, 528B ALL 22"))

A-7540370 5/8 X 48.5" (1231.9) Belt, (LA WN/GARDEN TRACTOR: 600 SERIES 1990>, (750, 769 ALL 36", 38" and 42" cut))

A-7540371A 5/8 X 74" (1879.6) Belt, Deck Drive, (LAWN/GARDEN TRACTOR: 600 SERIES 42" deep deck)

A-7540430 3/8 X 35.1" (891.54) Belt, Drive, (SNOWTHROWER: DUAL S TAGE 1992-1997 w/ 5HP)

A-7540433 21/32 X 69.25" (1758.95) Belt, Blade Drive, (LA WN/GARDEN TRACTOR: (400, 600 SERIES ALL w/ 38" deck)), (Deck: 805

SERIES)

A-7540438 1/2 X 51" (1295.4) MTD/Cub Cadet,

A-7540439 5/8 X 60" (1524) Belt, Deck, (LA WN/GARDEN TRACTOR: 600 SERIES 46" deep deck)

A-7540440 7/16 X 99" (2514.6) Belt, Deck, (RIDING LAWN MOWER: 600 SERIES w/ 46" deep deck)

A-7540443A H A A X 90.2" (2291.08) Belt, Deck, (LAWN/GARDEN TRACTOR: 765 rear discharge)

A-7540446 5/8 X 45.87" (1165.1) MTD/Cub Cadet, (LAWN/GARDEN TRACTOR: 800 SERIES 1997>, 2 speed)

A-7540456 3/8 X 28.6" (726.44) Belt, Wheel Drive, (SNOWTHROWER: (500 SERIES, 600 SERIES ALL Two-Stage 2005>))

A-7540460 3/8 X 39.24" (99.67) Belt, Drive, (LA W N MOWER: (959C, 979C, 999C, E979E ALL rear wheel drive/ rear discharge 1997>))

A-7540461 7/16 X 78.25" (1987.55) Belt, Drive, Front, (LA WN/GARDEN TRACTOR: LT1022 46" 22 HP B&S Hydro, LT1024 50" 24 HP

B&S Hydro, 13AK11CK709 Super LT 54" 27 HP Kohler Hydro, 13AP11CH709 46" 23 HP Kohler

Hydro, 13AQ11CP709 50" 26 HP Kohler Hydro, 13AX11CH709 46" 20 HP Kohler Hydro,

13BX11CG709 42" 19 HP Ko

A-7540465 3/8 X 36" (914.4) Belt, Drive, (SELF PROPELLED MOWER: (400 SERIES, 500 SERIES ALL FWD))

A-7540467 5/8 X 90.5" (2298.7) Belt, Drive, Lower, (LAWN/GARDEN TRACTOR: A U TO DRIVE 1999- 2003)

A-7540468 5/8 X 41.5" (1054.1) Belt, Drive, Upper, (LAWN/GARDEN TRACTOR: A U TODRIVE STEP THRU FRAME 1999>)

A-7540472 5/8 X 83.75" (2127.25) Belt, Deck, Drive, (RIDING LAWN MOWER: (600 SERIES, 800 SERIES, RT-99 A L L 42" Deck))

A-7540472 5/8 X 83.75" (2127.25) Belt, Deck, Drive, (LA WN/GARDEN TRACTOR: (1600, 1800 AL L 42" Deck))

A-7540474 5/8 X 102.125" (2593.975) MTD/Cub Cadet, (RIDING LAWN MOWER: (600 SERIES, 800 SERIES, RT-99 A L L 46" Spindle Deck))

A-7540475 5/8 X 108.5" (2755.9) Belt, Drive, 50 1999> w/ electric PT O, A U TO DRIVE Af ter 600 & 800 step thru frame w/ electric PT O

A-7540483 3/8 X 38.1" (967.74) Belt, Drive, (SELF PROPELLED MOWER: 263, 264, 525, 528, 529)

A-7540485 5/8" X 97" (2463.8) MTD/Cub Cadet, 600 SERIES 1999, 42" w/ step thru frame & manual PTO

A-7540486A 5/8 X 67" (1701.8) Belt, Deck, 600 SERIES 1999>, 42", step thru frame & manual PTO deck-engine pulley

A-7540489 3/8 X 44.5" (1130.3) MTD,

A-7540497 1/2 X 60.5" (1536.7) Belt, Deck, (DECK: 46 1999>, step thru frame), (RIDING LAW N MOWER: REVOLUTION 2001)

A-7540497 1/2 X 60.5" (1536.7) Belt, Deck, (DECK: 42 INCH 2001-2003 w/ auto drive step thru fram)

A-7540497 1/2 X 60.5" (1536.7) Belt, Deck, (LAWN/GARDEN TRACTOR: LT1018 42" 18.5 HP B&S ELS Hydro)

A-7540498 1/2" X 67" (1701.8) MTD/Cub Cadet,

A-7540625 3/8 X 44.5" (1130.3) MTD,

LAWN & GARDEN BELTS

MTD / White

OrderForm

LAWN &GARDEN BELTS

A-7540637 3/8" X 31.25" (793.75) MTD/Cub Cadet,

A-7540641 1/2 X 105" (2667) Belt, Deck, (LAWN/GARDEN TRACTOR: 1515 38" 15HP Kohler Hydro, 1525 38" 15HP Kawa Hydro)

A-7540642 5/8 X 138.5" (3517.9) Belt, Deck, Drive, (DECK: 54 INCH DECK 2002> w/ manual PTO auto step thru frame)

A-7540644 1/2 X 60" (1524) Belt, Drive, (LA WN/GARDEN TRACTOR: 1500 42" Deck w/ electric PTO, 1517 42" 17 HP Kohler Hydro)

A-7540645 1/2 X 67" (1701.8) Belt, Deck, (LAWN/GARDEN TRACTOR: 1517 42" 17 HP Kohler Hydro)

A-7540935 1/2 X 31" (787.4) Belt, Drive, (SELF PROPELLED MOWER: 352R, 359R), (SNOWBLOWER: 640, 642, 646, 660, 666)

A-7543039 1/2 X 103" (2616.2) Belt, Deck, (LAWN/GARDEN TRACTOR: 2000 SERIES w/ 44" Deck), (ZERO TURN MOWER:

1500 w/ 44" Deck)

A-7543041 .511 X 105" (2667) Belt, Deck, (LAWN/GARDEN TRACTOR: 2000 SERIES w/ 48" Deck)

A-7543048 5/8 X 107.8" (2738.12) MTD/Cub Cadet,

A-7543055 5/8 X 112.687" (2862.26) Belt, (LAWN/GARDEN TRACTOR: 2166 42" 16 HP Kohler Hydro w/ electric PT O)

A-7543068 21/32 X 110.6" (2809.24) Belt, PT O, (LA WN/GARDEN TRACTOR: 2000 SERIES w/ 44" Deck & electric PTO, 2000 SERIES

w/ 48" Deck & electric PT O)

A-7543073 1/2 X 62.1" (1577.34) Belt, Deck, (LAWN/GARDEN TRACTOR: LT2180 42" 18 HP B&S Hydro, 2166 42" 16 HP Kohler Hydro)

A-75404001 5/8 X 68.9" (1750.06) Belt, Tension Pulley, (LAWN/GARDEN TRACTOR: 600 SERIES 2003>)

A-75404002 .70 X 31.63" (803.4) Belt, T ransmission Drive, (LAWN/GARDEN TRACTOR: 600 SERIES 2003>)

A-75404043 1/2 X 57.09" (1450.1) Belt, Transmission Drive, (ZERO TURN MOWER: 42 INCH, 50 INCH)

A-75404045 1/2 X 109" (2768.6) Belt, Deck, (ZERO TURN MOWER: 42 INCH)

A-75404048 5/8 X 131.5" (3340.1) Belt, Deck, (DECK: 50 INCH)

A-75404057 5/8 X 34.18" (868.17) MTD Belt,

A-75404060 1/2 X 96" (2438.4) Belt, Deck, Drive, (LA WN/GARDEN TRACTOR: 700 SERIES 2005> w/ 42" Deep Deck)

A-75404077 5/8 X 134.25" (3409.95) Belt, Deck, (LAWN/GARDEN TRACTOR: 50 INCH w/ Electric Clutch)

A-75404093 3/8" X 35" (889) MTD/Cub Cadet,

A-75404118 1/2" X 112.5" (2857.5) MTD/Cub Cadet,

A-9540180 5/8" X 54" (1371.6) Belt, Drive, (RIDING LAW N M O W E R : S E V E R A L 42" cut)

A-9540441 1/2 X 75.995" (1930.27) Belt, Trans Drive, (RIDING LAWN MOWER: 600 SERIES <2000 Hydrostatic 46" cut 13AS6938131)

A-9540441 1/2 X 75.995" (1930.27) Belt, T rans Drive, (LA WN/GARDEN TRACTOR: HYDROSTATIC 38" deck, HYDROSTATIC 42"

deck, HYDROSTATIC 46" deck)

A-9540453 5/8 X 36.25" (920.75) Belt, Drive,

A-9540461 7/16 X 78.25" (1987.55) Belt, Transmission Drive, (RIDING LAWN MOWER: 800 SERIES Hydro, 1997>)

A-9540476 5/8 X 100" (2540) Belt, Engine, (DECK: 46 1999> w/ electric PTO), (LAWN/GARDEN TRACTOR: A U TO DRIVE w/

step thru & 46" decks)

A-9540486 5/8 X 67" (1701.8) Belt, Engine, (DECK: 46 1999> w/ electric PTO), (LAWN/GARDEN TRACTOR: A U TO DRIVE

1999-2003 w/ step thru & 46"decks)

A-9543001 5/8 X 92" (2336.8) Belt, Drive,

A-9543084 1/2 X 37.625" (955.68) Belt, PT O, (LA WN/GARDEN TRACTOR: 3000 SERIES)

A-95404013 3/8" X 21.65" (549.91) MTD/Cub Cadet,

A-95404014 3/8" X 27.5" (698.5) Cogged MTD/Cub Cadet,

A-95404041 5/8 X 111.5" (2832.1) Repl. MTD/Cub Cadet PTO Belt, (LA WN/GARDEN TRACTOR: LT2138 w/ 38" Deck)

A-95404044 1/2 X 133.5" (2882.9) Belt, Deck, (ZERO TURN M OWER: (RZT42 , RZT 50 A L L 50" Deck))

A-95404047 1/2 X 144" (3657.6) Belt, S pindle Deck, (LAWN/GARDEN TRACTOR: (LT2138, 2130, 2135, 2140, 2145, 2146, 2150,

2155, 2160, 2164, 2165, 2166, 2176, 2180, 2185, 2186, 2206, 2518, 2521, 2523 A L L w/ 54" deck))

A-95404050 1/2" X 34.9" (886.46) Cogged MTD/Cub Cadet,

A-95404055 5/8 X 111.5" (2832.1) Belt, PT O, (LAWN/GARDEN TRACTOR: (LT2138, 2130, 2135, 2140, 2145, 2146, 2150, 2155,

2160, 2164, 2165, 2166, 2176, 2180, 2185, 2186, 2206, 2518, 2521, 2523 A L L w/ 54" deck))

A-95404062 1/2" X 78.06" (1982.724) MTD/Cub Cadet,

A-95404118 1/2" X 112.5" (2857.5) MTD/Cub Cadet,

Murray

A-37X3 1/2 X 46" (1168.4) Belt, Cross Drive, (RIDING LAW N MOWER: 36 INCH FRONT ENGINE)

A-37X11 1/2 X 95" (2413) Belt, Drive, (MOWER: (36 INCH, 38 INCH, 42 INCH AL L 16 & 18 HP engines from 1981-1990))

A-37X12 1/2 X 54.937" (1395.40) Belt, Blade Drive, (RIDING LAWN MOWER: 30 INCH REAR ENGINE 36" w/ 8HP)

A-37X22 1/2 X 99" (2514.6) Belt, Cross Drive, (MOWER: 42 INCH w/ 11, 14, 16, & 18HP engines)

A-37X24 1/2 X 58.5" (1485.9) Belt, Deck, (MOWER: 36 INCH 1976-1988)

A-37X26 1/2 X 88.3" (2242.82) Belt, Drive, (MOWER: 39 INCH, 40 INCH, 42 INCH)

A-37X37 1/2 X 50" (1270) Murray, (RIDING LAW N MOWER: (30 REAR ENGINE, 36 FRONT ENGINE ALL 8HP))

A-37X38 1/2 X 40.3" (1023.62) Belt, Transmission Drive, (MOWER: 30 INCH)

A-37X40 1/2 X 62.1" (1577.34) Belt, Blade Drive, (MOWER: 39 INCH, 40 INCH, 42 INCH)

A-37X43 1/2 X 82.1" (2085.34) Belt, Blade Drive, (MOWER: 36 INCH w/ rear & side discharge)

A-37X45 1/2 X 90.5" (2298.7) Belt, Drive, (MOWER: 39 INCH, 40 INCH, 42 INCH)

A-37X49 3/8 X 40.15" (1019.81) Belt, Drive,

A-37X57 1/2 X 53.68" (1363.47) Belt, Blade Drive, (MOWER: 30 INCH)

A-37X61 1/2 X 95" (2413) Belt, Drive, (MOWER: 30 1992-1995, (38, 40, 42 INCH, 46 ALL 1989-1995))

A-37X62 1/2 X 86" (2184.40) Belt, Blade Drive, (LA WN/GARDEN TRACTOR: 40 INCH side discharge)

A-37X63 1/2 X 83.1" (2110.74) Belt, Blade Drive, (MOWER: 38 INCH)

Murray

MTD / White

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

A-37X64 1/4 X 36.78" (934.21) Belt, Drive, (W ALK BEHIND MOWER: AEROVAC 21" w/ 5-5.5HP)

A-37X65 1/2 X 30.187" (766.75) Belt, Drive, (RIDING LAW N MOWER: (25 REAR ENG, 30 REAR ENG ALL w/ transaxle),

25515B, 305351B)

A-37X66 1/2 X 47.1" (1196.34) Belt, Blade Drive, (LA WN/GARDEN TRACTOR: 46300 SERIES ULT R A 46" cut w/ 18 HP)

A-37X67 1/2 X 77.69" (1973.33) Belt, Blade Drive, (MOWER: 46 INCH 14-18HP, 1990-1994)

A-37X68 1/2 X 101.68" (2582.67) Belt, Drive, (LA WN/GARDEN TRACTOR: 46300 SERIES ULT R A 46" cut w/ 18 HP)

A-37X69 1/2 X 80.3" (2039.62) Belt, Engine, (LA WN/GARDEN TRACTOR: 46300 SERIES ULT R A 46" cut w/ 18 HP)

A-37X70 1/2 X 77.69" (1973.33) Belt, Blade Drive, (MOWER: 46 INCH 14-18HP, 1990-1994)

A-37X73 3/8 X 44" (1117.6) Belt, Drive, (SELF PROPELLED: 22 INCH 1994-1997)

A-37X74 1/2 X 57" (1447.8) Belt, Blade Drive, (MULCHING MOWER: 30 INCH)

A-37X75 1/2 X 91.25" (2317.75) Belt, Blade Drive, (MOWER: 42 INCH 12-18HP, 1990-1994)

A-37X76 1/2 X 93.25" (2368.55) Belt, Blade Drive,

A-37X80 5/8 X 86.12" (2085.85) Belt, Drive,

A-37X81 1/2 X 81" (2057.4) Belt, Drive, (MOWER: (42 INCH, 46 INCH ALL w/ Dana Trans))

A-37X83 1/2 X 81.75" (2076.45) Belt, Drive, (LA WN/GARDEN TRACTOR: (42910X92C, 42910X192C, 42910X292C ALL 1996))

A-37X86 1/2 X 84.5" (2146.3) Belt, Blade Drive, (LA WN/GARDEN TRACTOR: 38 INCH 1997> w/ lift handle on lef t side)

A-37X87 7/16 X 97.5" (2476.5) Belt, Drive, (MOWER: 30 INCH, 38 INCH, 40 INCH, 46 INCH)

A-37X88 1/2 X 88.24" (2241.296) Belt, Drive, (MOWER: 42 INCH Hydro)

A-37X89 1/2 X 87" (2209.8) Belt, Deck, (MOWER: 46 INCH LT Rail Frame)

A-37X90 1/4 X 36.5" (927.1) Belt, Drive,

A-37X92 1/2 X 53" (1346.2) Belt, Deck,

A-37X93 5/8 X 107.75" (2736.85) Belt, Deck,

A-37X94 3/7 X 34" (863.6) Belt, Drive, (SELF PROPELLED: 22 INCH)

A-37X96 1/2 X 88.5" (2247.9) Belt, Deck, (MOWER: 46 INCH GT Rail Frame)

A-37X97 1/2 X 95.75" (2432.05) Belt, Drive,

A-37X100 3/8 X 34" (863.6) Belt, Drive, (SELF PROPELLED: 22 since 1999 dbl idler mower, 22 3 N 1 w/ Briggs & Tecumseh

magnum torque)

A-37X101 1/2 X 34.125" (866.78) Belt, Drive, (SELF PROPELLED: 22 INCH Side Discharge w/ Tecumseh Engine)

A-37X110 1/2 X 43.875" (1114.43) Belt, Transmission Drive, (RIDING LAW N MOWER: 30 INCH REAR ENGINE)

A-3887 1/2 X 31.5" (800.1) Belt, Drive,

A-579932 3/8 X 33.1" (840.74) Belt, Drive,

A-581264 1/2 X 35.2" (894.08) Belt, Drive,

A-585416 1/2 X 38.375" (974.725) Belt, Drive, (SNOWTHROWER: MID FRAME WHEEL DRIVE 1997-2000)

A-585436 1/2 X 37.8" (960.12) Belt, Drive,

A-760928 3/8 X 89" (2260.6) Belt, Drive,

Noma / AMF

A-3526 1/2 X 30.2" (767.08) Belt, Drive,

A-300142 1/2 X 40.5" (1028.7) Belt, Drive,

A-300575 1/2 X 34" (863.6) Belt, Drive,

A-300680 5/8 X 77.75" (1974.85) Belt, Deck, Drive,

A-300842 5/8 X 79" (2006.6) Belt, Blade Drive, (MOWER: 3912-1500, 3912-1600, 3912-2200, 3912-2201)

A-301935 1/2 X 108.5" (2755.9) Belt, Blade Drive, (DECK: 42 INCH)

A-302289 3/8 X 73.75" (1873.25) Belt, Deck,

A-303241 1/2 X 90" (2286) Belt, Drive,

A-305148 5/8 X 83" (2108.2) Belt, Drive,

A-308701 5/8 X 80" (2032) Belt, Deck,

A-314108 5/8 X 85" (2159) Belt, Blade Drive, (MOWER: (D4314-060, D4315-000, D4318-060 ALL 43" cut))

A-43066 5/8 X 71" (1803.4) Belt, Blade Drive, (MOWER: 36 INCH SIDE DISCHARGE)

A-45186 1/2 X 63" (1600.2) Belt, Deck,

A-48044 5/8 X 82" (2082.8) Belt, Blade Drive, (MOWER: 36 INCH REAR DISCHARGE)

A-49878 5/8 X 84" (2133.6) Belt, Blade Drive, (MOWER: 36 INCH REAR DISCHARGE)

A-54758 1/2 X 82" (2082.8) Belt, Drive, (LA WN/GARDEN TRACTOR: (3610 SERIES, 3612 SERIES ALL 36" cut), 3812

SERIES 38" & 39" cut)

A-57214 1/2 X 84.75" (2152.65) Belt, Transmission Drive, (MOWER: 38 INCH, 39 INCH, 45 INCH)

A-57556 1/2 X 89.25" (2266.95) Belt, Drive,

A-58170 1/2 X 75.25" (1911.35) Belt, Blade Drive, (RIDING LAW N MOWER: 3611-5600 w/ 36" & 45" side discharge decks)

A-506033031 5/16" X 31.5" (800.1) Belt, Mower, (Power Cutter: 650, 700, K540)

A-506070503 1/2" X 35.1" (891.54) Belt, Mower, K950

A-506070504 1/2" X 36.4" (924.56) Belt, Mower, (Power Cutter: K950 16")

A-506070506 3/8" X 31.7" (805.18) Belt, Mower, (Power Cutter: 650, 700)

A-506070507 1/2" X 39.7" (1008.38) Belt, Mower, (Power Cutter: K1250)

A-506296702 6 Rib x 32.1" (815.34) Belt, Mower, (Power Cutter: K750)

A-PP12001 1/2 X 88.375" (2244.725) Belt, Deck, (Pro T ractors: (38 DECK, 42 DECK ALL < 2001)), PC1338A, PC1338B,

PP125H38KA, PP125H38LMA, PP125H38LMB, PP125R38JA, PP1338A, PP1338B, PP1338C,

PP1338D, PP14542KA, PP14542KB, PP14542LMA, PP145H42A, PP145H42B, PP15H42KA,

LAWN & GARDEN BELTS

Scag

Murray

OrderForm

LAWN &GARDEN BELTS

PP15H42KB, PP15H42LMA, PP15

A-PP12002 1/2 X 95.25" (2419.35) Belt, T rans, Gear Drive, (LA WN/GARDEN TRACTOR: PD1842ST, PD18542ST, PD2042ST,

PO1538, PO15538, PO1742ST, PO17542ST)

Simplicity

Scag

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

A-PP12008 1/2 X 82" (2082.8) Belt, T rans, Auto Drive, (LA WN/GARDEN TRACTOR: (PD185H42ST, PD18H42ST, PD20H42ST,

PD20PH48ST, PD22H42ST, PD25PH48ST, PO17H42ST ALL w/ Hydro Transmission)),

DPR20H46STA, DPR20H46STB, DPR22H46STA, DPR22H46STB, DPR22H48STA,

DPR22H48STB, DPR22H48STC, PO165H42A, PO165H42B, PO165H42C,

A-PP12012 1/2 X 95.5" (2425.7) Belt, Deck, Manual Clutch, (Pro T ractors: (38 DECK, 42 DECK ALL 2001 >)), DPR20H46STA,

DPR22H46STA, PC14542A, PD1842ST, PD18542ST, PD185H42ST, PD18H42ST, PD2042ST,

PD20H42ST, PD22H42ST, PO14542A, PO145K42A, PO16542A, PO165H42A, PO165H42STA,

PO1742ST, PO17542ST, PO17H42ST,

A-PP13006 3/8 X 32" (812.8) Belt, Deck, (LAWN/GARDEN TRACTOR: P555DE, P555DF, P555DG, PC55HY22CA, PP2260A,

PP2260B, PP2265A, PP65Y22CHA, PR65Y22CHA, PR65Y22CHB, PR6Y22CA, PR6Y22SHA)

A-PP13007 5/8 X 89.5" (2273.3) Belt, Main Deck, (LAWN/GARDEN TRACTOR: DPR22H48STA, DPR22H48STB, DPR22H48STC,

PD20PH48ST, PD25PH48ST, PDGT26H48, PR24PH48STA)

A-PP13008 5/8 X 89" (2260.60) Belt, Secondary Deck, (Pro Tractors: 48 DECK, 54 DECK), (LAWN/GARDEN TRACTOR:

DPR22H48STA, DPR22H48STB, DPR22H48STC, PD20H48ST, PD25PH48ST, PDGT26H48,

PR24PH48STA)

A-PP13009 5/8 X 97.625" (2479.68) Belt, Deck, Electric, (Pro T ractors: 42 INCH DECK w/ electric clutch)

A-PP13010 1/2 X 82.5" (2095.5) Belt, Transmission, GT, (LAWN/GARDEN TRACTOR: PDGT26H48, PDGT26H54)

A-PP13011 5/8 X 142.5" (3619.5) Belt, Deck, GT, (Pro Tractors: 54 INCH DECK 2005 >)

Power Trim

A-238 1/2 X 29" (736.6) Belt, Drive, (EDGER: SEVERAL)

A-339 1/2 X 27.5" (698.5) Belt, Drive, (EDGER: SEVERAL)

A-PP12008 1/2 X 82" (2082.8) Belt, T rans, Auto Drive, (LA WN/GARDEN TRACTOR: Q165H46A, Q165H46B, Q165H46C,

Q185H46A, Q185H46B, Q20H46A, QP17H42STA, QP17H42STB, QP20H46A, QP20H46B)

A-00776768 5/8 X 71" 5 band (1816.1) Belt, Deck,

Scag

A-A48083 5/8 X 88.375" (2244.73) Belt, Engine,

A-A48286 5/8 X 92.6" (2352.04) Belt, Engine, (WALK BEHIND MOWER: BELT DRIVEN 52" Deck)

A-A48286 5/8 X 92.6" (2352.04) Belt, Engine, (WA LK BEHIND MOWER: HYDRO DRIVE 52" Deck)

A-48084 BB X 134.5" (3416.3) Belt, Blade Drive, (MOWER: SM61)

A-48085 1/2 X 38" (965.2) Belt, Blade Drive, (MOWER: SLM 46"-48", SM 48"-61")

A-48086 5/8 X 106.5" (2705.1) Belt, Engine, (W A L K B E H I N D M O W E R : ( B E LT DRIVEN, HYDRO DRIVE ALL 40" Deck))

A-48087 5/8 X 52.9" (1343.66) Belt, Blade Drive, (WA L K B E H I N D M O W E R : ( B E LT DRIVEN, HYDRO DRIVE ALL 48" Deck)),

(ZERO TURN MOWER: (SSZ, SUPER Z SN 60000> ALL 48" Deck))

A-48089 5/8 X 89.75" (2279.65) Belt, Engine, (W A L K B E H I N D M O W E R : ( B E LT DRIVEN, HYDRO DRIVE ALL 48" Deck)),

(MOWER: (SW, SWZ ALL 48" cut mid))

A-48202A 1/2 X 51.5" (1308.1) Belt, Wheel, Dual, (WALK BEHIND MOWER: BELT DRIVEN)

A-48203 1/2 X 39.8" (1010.92) Belt, T ransmission Drive, (WALK BEHIND MOWER: BELT DRIVEN)

A-48204 5/8 X 82" (2082.8) Belt, Engine, (W A L K B E H I N D M O W E R : ( B E LT DRIVEN, HYDRO DRIVE ALL 36" Deck))

A-48207 5/8 X 86.125" (2187.58) Belt, (W ALK BEHIND MOWER: BELT DRIVEN)

A-48264 5/8 X 101" (1574.8) Belt, Engine, (W A L K B E H I N D M O W E R : ( B E LT DRIVEN, HYDRO DRIVE ALL 61" Deck w/

Kohler))

A-48265 1/2 X 62" (1574.8 ) Belt, Blade Drive, (WA L K B E H I N D M O W E R : ( B E LT DRIVEN, HYDRO DRIVE ALL 61" w/ Kohler)),

(ZERO TURN MOWER: HYDRO STHM Three Wheel Rider w/61" Deck, (SSZ, SUPER Z SN

60000> ALL 61" Deck))

A-48285 5/8 X 56.125" (1425.57) Belt, Blade Drive, (WALK BEHIND MOWER: BELT DRIVEN 52" Deck, HYDRO DRIVE 52" RH

Blade), (ZERO TURN MOWER: HYDRO STHM Three Wheel Rider w/52" Deck, (SSZ, SUPER Z

SN 60000> ALL 52" Deck))

A-48344 1/2 X 35" (889.00) Belt, Blade, (ZERO TURN MOWER: HYDRO STHM)

A-48553 1/2 X 50.4" (1280.16) Belt, Drive, (MOWER: SWZ 36 INCH, SWZ 48 INCH)

A-48585 1/2 X 40" (1016) Belt, Pump Drive, (ZERO TURN MOWER: HYDRO STHM SN <40000)

A-48587 1/2 X 56.75" (1441.45) Belt, Hydro Pump, (WALK BEHIND MOWER: HYDRO DRIVE 1991>)

A-48607 11/16 X 134.75" (3422.65) Belt, Main,

A-48799 5/8 X 117" (2971.8) Belt, Blade Drive, (ZERO TURN MOWER: (SSZ, SUPER Z SN 60000> ALL 48" Deck))

A-48854 1/2 X 42.3" (1074.42) Belt, Pump Drive,

A-48912 5/8 X 117" (2971.8) Belt, Deck, (WALK BEHIND MOWER: BELT DRIVEN Three Wheel Rider w/61" Deck), (ZERO

TURN MOWER: HYDRO STHM Three Wheel Rider w/61" New Style, (STHM20 KOHLER,

STHM22 KOHLER ALL Three Wheel Rider w/61" on 20 & 22 HP))

A-48996 5/8 X 135.625" (3444.875) Belt, Engine, (ZERO TURN MOWER: SUPER Z SN 60000> 61" Deck)

A-481001 5/8 X 128" (3251.2) Belt, Blade Drive, (MOWER: SMZ-52), (ZERO TURN MOWER: SUPER Z SN 60000> 52" Deck)

A-481460 11/16 X 43" (1092.2) Belt, Deck, (MOWER: Turf Tiger)

A-481461 1/2 X 61" (1549.4) Belt, Pump Drive, (MOWER: Turf Tiger)

A-481498 1/2 X 41.75" (1060.45) Belt, Transmission, LH, (MOWER: STR TURF RUNNER)

A-481499 1/2 X 34" (863.6) Belt, Transmission, RH, (MOWER: STR T URF RUNNER)

A-481557 5/8 X 123.7" (3141.98) Belt, Blade Drive, (MOWER: Turf T iger 52" cut)

A-481558 5/8 X 139.6" (3545.84) Belt, Blade Drive, (MOWER: Turf T iger 61" cut)

A-481980 5/8 X 162.1" (4117.34) Belt, Drive, (MOWER: SMST 72")

LAWN & GARDEN BELTS

Snapper

Simplicity

OrderForm

LAWN &GARDEN BELTS

A-482171 1/2 X 60" (1524) Belt, Drive, (MOWER: Turf T iger 52 INCH, T urf Tiger 61 INCH)

A-482281 5/8 X 121.2" (3078.48) Belt, Drive, (MOWER: Turf T iger 52 INCH)

A-482529 5/8 X 148.4" (3769.36) Belt, Deck, (MOWER: 48 INCH Tiger Cub)

A-482530 5/8 X 154.7" (3929.38) Belt, Deck,

A-483031 5/8 X 52.5" (1333.50) Belt, Blade Drive, (MOWER: 48 INCH)

A-710213 1/2 X 88.24" (2241.296) Belt, Deck,

A-710217 1/2" X 86.09" (2186.686) Belt, Deck,

A-710533A 5/8 X 107.75" (2736.85) Belt, Blade Drive,

A-SM31150 5/8" X 70.625" (1798.32) Belt, Drive, (MOWER: SEVERAL)

Simplicity

A-108209 1/2 X 82" (2082.8) Belt, Drive,

A-163011 1/2 X 71.5" (1816.1) Belt, Drive, (LA WN/GARDEN TRACTOR: (1800, GTH-L ALL <1980))

A-1607967 1/2 X 52" (1320.8) Belt, Drive, (LA WN/GARDEN TRACTOR: GTH-L)

A-1650502 1/2 X 46" (1168.4) Belt, Hydro Pump, (LAWN/GARDEN TRACTOR: GTH-L)

A-1656960 1/2 X 84.1" (2136.14) Belt, Drive, (MOWER: 1600 SERIES, 1700 SERIES, 500 SERIES, 5000 SERIES, 600 SERIES,

900 SERIES, LTH SERIES)

A-1657044 1/2 X 93.25" (2368.55) Belt, Drive, 14GT SERIES, 16GT SERIES, 1700 SERIES, 7000, GTH-L

A-1665024 1/2 x 54" (1371.6) Belt, Drive, (RER: 3000 SERIES)

A-1666698 1/2 x 90.5" (2298.7) Belt, Drive, (LA WN/GARDEN TRACTOR: 1600 SERIES, 4000 SERIES, 500 SERIES)

A-1666801 1/2 X 79.5" (2019.3) Belt, Drive, (LA WN/GARDEN TRACTOR: GTH-L)

A-1668066 1/2 X 120" (3048) Belt, Blade Drive, (MOWER: (5000 SERIES, 6000 SERIES ALL 42" cut))

A-1670835 1/2 X 78.5" (1993.9) Belt, Drive, (MOWER: (4000, 5000 SERIES, 5200 SERIES, 600 SERIES ALL < Broadmoor))

A-1672135 1/2 X 80.25" (2038.35) Belt, Hydro Pump, (MOWER: (5000 SERIES, 6000 SERIES ALL <1980 Broadmoor series))

A-176439 1/2 X 74.375" (1889.125) Belt, Drive, (MOWER: 42 INCH)

A-1703466 1/2 X 126" (3200.4) Belt, Blade Drive, (MOWER: GTH w/ 48" deck)

A-1703836 1/2 X 91.25" (2317.75) Belt, Drive, (MOWER: 14GT SERIES, 1600 SERIES, 16GT SERIES, 1700 SERIES, LTH SERIES)

A-1713515 1/2 X 78" (1981.2) Belt, Blade Drive, (MOWER: 7100, 900 ALLIS CHALMERS)

A-1713549 1/2 X 70" (1778) Belt, Drive, (MOWER: HOMESTEADER 6 HP (1971-74)), (LA WN/GARDEN TRACTOR: 3008

SERIES, 5000 SERIES, 4000 SERIES), (MOWER: 36 arbor drive), (TILLER: YEOMAN 30")

A-1718017 1/2" X 114.75" (2914.65) Simplicity,

A-1722039 1/2" X 72" (1828.8) Belt, Drive,

Snapper

A-10749 A A X 68" (1727.2) Belt, Deck, (MOWER: 0-6 SERIES (handle bar models) 25", 26", 28", 30" cut)

A-11117 6 rib X 20" (508) Belt, Deck, (SELF PROPELLED: V-21 w/ cast deck)

A-12353 3/8 X 25.5" (647.7) Belt, Drive, (SELF PROPELLED: 21PC 21" Commercial), (DECK: (0 SERIES, 6 SERIES, 7 SERIES,

8 SERIES, 9 SERIES ALL S teel Deck), (1 SERIES, 7 SERIES, 9 SERIES ALL Commercial))

A-12354 1/2 X 22" (558.8) Belt, Drive, (SELF PROPELLED: V-21), (DECK: 21P steel deck)

A-12508 3/8 X 24.5" (622.3) Belt, Drive, (SELF PROPELLED: V-21 3.5- 4 HP)

A-14398 1/2 X 135" (3429) Snapper,

A-14525 1/2 X 108.4" (2753.36) Belt, Deck, (MOWER: 41 INCH rear rider, 48 INCH tractor)

A-14799 3/32 X 103" (2616.2) Belt, Blade Drive, (MOWER: GT180H, LT11, LT16, YT12D, YT18H), (DECK: 1 SERIES, 2

SERIES)

A-14800 1/2 X 139" (3530.6) Belt, Deck, (MOWER: (LT, Y T A L L 41" cut w/ 18 HP))

A-17053 1/2 X 55.953" (1421.21) Belt, Drive, (COMMERCIAL W ALK BEHIND: (36, 48, 52, 61 ALL mid size Pro))

A-17333 1/2 X 33.75" (857.25) Belt, Drive, (COMMERCIAL W ALK BEHIND: 36 INCH, 48 INCH, 52 INCH, 61 INCH)

A-18236 1/2 X 73" (1854.2) Belt, Drive, (MOWER: 0-6 SERIES (handle bar models) 33" cut, 7-14 SERIES (steering wheel

models) 25", 26", 28", 30", 33" cut)

A-19205 5/8 X 52" (1320.8) Belt, Blade Drive, (MOWER: PRO GEAR 48" series 0-4)

A-19205 5/8 X 52" (1320.8) Belt, Blade Drive, (MOWER: PRO 7 SERIES 48" Deck)

A-22252 A A X 73" (1854.2) Belt, Blade Drive, (MOWER: 7-9 SERIES 25"- 33" rear engine riders)

A-23416 3/8" X 31" (787.4) Snapper,

A-23710 1/2 X 61.5" (1562.1) Belt, Drive, (SELF PROPELLED: ELT115D331B, ELT140H331K, LT115D331B, LT140H331K,

R LT115D331B, RLT140H331K)

A-24497 A A X 68" (1727.2) Belt, Deck, (MOWER: 0-14 SERIES, 48 INCH <1992)

A-24614 1/2 X 98" (2489.2) Snapper,

A-24618 3/8" X 34.5" (876.3) Snapper,

A-24891 1-1/8 X 51.75" (1314.45) Belt, Drive, (MOWER: PRO GEAR w/ 36", 48", 52" deck)

A-24891 1-1/8 X 51.75" (1314.45) Belt, Wheel Drive, (MOWER: PRO 7 SERIES)

A-26305 1/2" X 98" (2489.2) Snapper,

A-27346 5/8" X 52" (1320.8) Belt, Engine, (MOWER: PRO GEAR 52" Deck)

A-27347 5/8" X 52" (1320.8) Belt, Blade Drive, (MOWER: PRO GEAR 52" Deck)

A-28334 1/2 X 94.25" (2393.95) Snapper,

A-28619 5/8 X 75.18" (1909.572) Belt, Drive, (MOWER: (28 INCH, 30 INCH, 33 INCH ALL Rear Engine Riders))

Sears

Snapper

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

A-28784 5/8 X 110.28" (2801.1) Belt, Blade Drive, (MOWER: 42 INCH rear engine riders)

A-29101 3/8" X 36" (914.4) Snapper,

A-29262 5/8" X 66" (1676.4) Belt, Engine, (MOWER: PRO HYDRO 48" Deck)

A-29308 1/2" X 90" (2286) Belt, Deck, (MOWER: 38 INCH)

A-29604 3/8 X 33" (838.2) Belt, Drive, (SNOWTHROWER: C3201, C3202, C3203, C3203 3 series single stage)

A-29641 1/2 X 97.75" (2482.85) Snapper,

A-29907 5/8" X 91.25" (2317.75) Belt, Engine, (MOWER: PRO GEAR 48" Deck)

A-29908 11/16 X 83.5" (2120.9) Belt, Engine, (MOWER: PRO 7 SERIES 36" Deck)

A-35710 5/8" X 85" (2159) Belt, Engine, (MOWER: PRO HYDRO 36" Deck)

A-36585 1/2 X 94.5" (2400.3) Snapper,

A-42735 5/8" X 74" (1879.6) Belt, Engine, (MOWER: PRO HYDRO 61" Deck)

A-42813 5/8" X 68" (1727.2) Belt, Engine, (MOWER: PRO HYDRO 52" Deck)

A-43844 A A X 73.75" (1873.25) Belt, Drive, (RIDING LAWN MOWER: SERIES 16 28" Deck, SERIES 16 30" Deck, SERIES 16 33"

Deck)

A-44637 5/8 X 75.125" (1908.175) Belt, Deck, (RIDING LAWN MOWER: REAR ENG 28", REAR ENG 30", REAR ENG 33")

A-62064 5/8" X 88" (2235.2) Snapper, (ZERO TURN MOWER: 1810, 2010)

A-62465 1/2 X 81.75" (207.645) Snapper,

A-76496 5/8 X 88.375" (2244.73) Belt, Blade Drive, (MOWER: 61 INCH w/ 18HP Briggs)

A-76497 5/8 X 44" (1117.6) Belt, Drive, (MOWER: 32-48 INCH)

A-76498 5/8 X 36.2" (919.48) Belt, T ransmission Drive,

A-76676 5/8" X 46" (1168.4) Belt, Blade Drive,

A-76677 5/8 X 92.6" (2352.04) Belt, Main,

A-76680 21/32 X 36" (914.4) Belt, Transmission Drive, (DECK: (0 SERIES, 1 SERIES ALL 48"))

A-79181 1/2 X 56.375" (1431.93) Belt, Hydro Pump, (ZERO TURN MOWER: HYDRO chain drive w/ LB & S frame)

A-79186 1/2 X 114" (2895.6) Belt, Drive, (ZERO TURN MOWER: (2 SERIES, 3 SERIES, 4 SERIES, 5 SERIES ALL gear drive

w/ SK & S frames))

A-79776 1/2 X 72.5" (1841.5) Belt, Hydro Pump, (ZERO T URN MOWER: (2 SERIES, 3 SERIES ALL gear drive joy stick models))

A-79778 1/2 X 91" (2311.4) Belt, Cross Drive, (ZERO TURN MOWER: (3 SERIES, 4 SERIES, 5 SERIES ALL gear drive w/ 42" deck))

A-79779 5/8 X 85.25" (2165.35) Belt, Deck, (ZERO TURN MOWER: (2 SERIES, 3 SERIES, 4 SERIES, 5 SERIES ALL gear drive

w/ 42" & 48" deck))

A-79781 5/8 X 84.25" (2139.95) Belt, Deck, (ZERO TURN MOWER: (2 SERIES, 3 SERIES, 4 SERIES, 5 SERIES ALL gear drive

w/ 60" deck))

A-79934 1/2" X 129.75" (3295.65) Snapper, (ZERO TURN MOWER: 1810, 2010)

Sears

A-PP13007 5/8 X 89.5" (2273.3) Belt, Main Deck, (LAWN/GARDEN TRACTOR: 251160, 275010, 275011, 275020, 275021,

601900, 601901)

A-PP13008 5/8 X 89" (2260.60) Belt, Secondary Deck, (LAWN/GARDEN TRACTOR: 251160, 275010, 275011, 275020, 275021,

601900, 601901)

A-PP13009 5/8 X 97.625" (2479.68) Belt, Deck, Electric, (LA WN/GARDEN TRACTOR: (272410, 272420, 272421, 272220D ALL w/ 42"

Deck))

A-102655X 1/2 X 38" (965.2) Belt, Drive,

A-106085X 1/2" X 79" Belt, Drive, (RIDING LAW N MOWER: 18HP w/ elec. Clutch, 36 INCH, 38 INCH, 44 INCH)

A-106412X 1/2 X 69" (1752.60) Belt, Drive, (RIDING LAW N MOWER: L0815AR FRONT ENGINE 36" cut w/ 11HP)

A-106729X 5/8 X 47.5" (1206.5) Belt, Drive, (RIDING LAW N MOWER: (10HP FRONT ENG, 11HP FRONT ENG ALL 38" cut)),

(ROPER: 917-252674, 917-252930, 917-252931, 917-262683)

A-106863X 1/2 X 92" (2336.8) Belt, Drive,

A-110883X 1/2 X 99" (2514.6) Belt, Drive, (RIDING LAW N MOWER: 951940 FRONT ENGINE 50" cut w/ 20HP)

A-110884X 1/2 X 93.75" (2381.25) Belt, Drive, (POULAN PRO: PP2050, XEG11082HAR)

A-111924X 7/16 X 31.75" (806.45) Belt, Drive,

A-123796X 1/2 X 94.75" (2406.65) Belt, Drive,

A-124293X 1/2 X 80" (2032) Belt, Drive,

A-124525X 1/2 X 88.75" (2254.25) Belt, Drive,

A-125907X 1/2 X 90" (2286) Belt, Drive, (RIDING LAW N MOWER: 38 INCH YT14)

A-126520X 1/2 X 88.5" (2247.9) Sears/Roper/AY P, (POULAN PRO: PP125R38J, PP125R38JA)

A-130801 1/2 X 95.5" (2425.7) Belt, Blade Drive,

A-130969 1/2 X 92.5" (2349.5) Belt, Deck, (RIDING LAWN MOWER: (12.5HP FRONT ENG, 12HP FRONT ENG, 14HP F RONT

ENG ALL 42" cut)), (DECK: RL1242A), (RIDING LAWN MOWER: WP12542A), (DECK: Y1442A)

A-131006 1/2 X 98.25" (2495.55) Belt, Drive, (RIDING LAW N MOWER: 18HP 42" cut), (DECK: R Y1842A), (RIDING LAW N

MOWER: WP1842A)

A-131264 1/2 X 78.5" (1993.9) Belt, Deck, (RIDING LAW N MOWER: 18HP 42" cut), (DECK: R Y1842A), (RIDING LAW N

MOWER: WP1842A)

A-131290 1/2 X 88" (2235.2) Belt, Blade Drive, (RIDING LAW N MOWER: 7122A29 FRONT ENGINE 38" cut)

A-132801 1/2 X 52" (1320.8) Sears/Roper/AY P,

A-133035 1/2" X 41.5" (1054.1) Sears/Roper/AY P,

A-137078 3/8 X 32.5" (825.5) Sears/Roper/AY P, (SELF PROPELLED: 22 INCH)

LAWN & GARDEN BELTS

Toro / Wheel Horse

Sears

OrderForm

LAWN &GARDEN BELTS

A-137153 1/2 X 83.5" (2120.9) Belt, Drive,

A-138255 1/2 X 95.25" (2419.35) Belt, Deck,

A-139573 1/2 X 83.5" (2120.9) Belt, Deck,

A-1316861 1/2 X 32.5" (825.5) Belt, Blade Drive, (RIDING LAW N MOWER: 7122A29 FRONT ENGINE 38" Inch)

A-140067 1/2 X 82.5" (2095.5) Belt, Blade Drive, (RIDING LAW N MOWER: L1252AR FRONT ENGINE 36" cut w/ 8HP)

A-140218 1/2 X 82.5" (2095.5) Belt, Drive,

A-140294 1/2 X 82.25" (2089.15) Belt, Drive, (RIDING LAW N MOWER: 18HP, 44 INCH)

A-141416 1/2 X 83.75" (2127.25) Belt, Hydro Pump,

A-144200 1/2 X 88.375" (2244.725) Belt, Deck, (RIDING LAWN MOWER: 38 INCH w/ Dbl Idler Pulleys)

A-146527 3/8 X 32.5" (825.5) Belt, Drive,

A-148763 5/8 X 85" (2159) Belt, Drive,

A-158818 1/2 X 83.75" (2127.25) Belt, Blade Drive,

A-1629J 1/2 X 83" (2108.2) Belt, Drive,

A-160816 3/8 X 35" (889) Sears/Roper/AY P,

A-160855 1/2 X 95" (2413) Sears/Roper/AY P,

A-161588 1/2 X 83.25" (2114.55) Belt, Drive,

A-161597 1/2 X 82.5" (2095.5) Belt, Drive,

A-161741 1/2 X 79" (2006.6) Belt, Drive,

A-161850 1/2 X 85" (2159) Belt, Drive, (RIDING LAWN MOWER: 917.270622, 917.270641)

A-165555 1/2 X 107" (2717.8) Belt, Drive,

A-165631 1/2" X 111" (2819.4) Sears/Roper/AY P,

A-165632 1/2 X 111.375" (2828.925) Sears/Roper/AY P,

A-165813 1/2 X 85" (2159) Belt, Drive, (RIDING LAWN MOWER: 917.270622, 917.270641)

A-165897 3/8" X 34.75" (882.65) Sears/Roper/AY P,

A-166060 3/8" X 38.75" (984.25) Sears/Roper/AY P, (SELF PROPELLED: 21 INCH Rear Bagger 2000-2002)

A-169178 3/8 X 113.5" (2882.9) Sears/Roper/AY P,

A-169790 3/8" X 43.2" (1104.9) Sears/Roper/AY P,

A-170140 1/2 X 112.25" (2851.15) Sears/Roper/AY P,

A-174368 5/8 X 89.5" (2273.3) Sears/Roper/AY P,

A-174369 5/8 X 89" (2260.60) Sears/Roper/AY P, (LAWN/GARDEN TRACTOR: 251160, 275010, 275011, 275020, 275021,

601900, 601901)

A-174883 5/8 X 97.625" (2479.675) Sears/Roper/AY P, (LAWN/GARDEN TRACTOR: (272220D, 272410, 272420, 272421 ALL w/ 42" Deck))

A-174978 1/2 X 84.5" (2146.3) Sears/Roper/AY P,

A-175436 3/8" X 32" (812.8) Sears/Roper/AY P, (SELF PROPELLED: 21 INCH Rear Bagger 2002-2003)

A-178138 1/2 X 87.5" (2222.5) Sears/Roper/AY P,

A-179092 1/2" X 34.5" (876.3) Belt, Traction, Mower,

A-191273 5/8" X 143" (3632.2) Belt, Deck, (RIDING LAWN MOWER: 917.276240, 54 INCH)

A-2614J 3/8" X 44.25" (1123.95) Sears/Roper/AY P,

A-62828 1/2 X 69.5" (1765.3) Belt, Blade Drive, (RIDING LAW N MOWER: (L1252AR FRONT E N G, L8212AR FRONT ENG ALL

36" cut w/ 8HP))

A-74977 3/8 X 35" (889) Sears/Roper/AY P,

A-83691 3/8 X 34.5" (876.3) Belt, Drive,

A-88074 3/8" X 39.125" (993.775) Sears/Roper/AY P,

A-850053 3/8" X 15" (381) Sears/Roper/AY P,

A-9180R 1/2 X 42" (1066.8) Sears/Roper/AY P,

Stihl

A-94900007850 3/8 X 33.75" (857.25) Belt, Deck, (CUT-OFF SAW : TS08, TS350, TS35OAVE, TS360, TS460)

A-94900007851 5/8" X 34.3" (871.22) Belt, Mower,

A-94900007891 3/8 X 36.5" (927.1) Belt, Deck, (CUT-OFF SAW : TS510)

A-A120.5K 1/2" X 122.5" (3111.5) Belt, Deck,

A-A144.5K 1/2" X 146.5" (3721.1) Belt, Mower,

Toro / Wheel Horse

A-1594 1/2 X 107" (2717.8) Belt, Blade Drive, (RIDING LAW N M O W E R : 4 8 I N C H C U T w/ 3 blade side discharge)

A-102741 1/2 X 97" (2463.8) Belt, Drive, (RIDING LAW N M O W E R : 3 6 I N C H C U T w/ 3 blade side discharge)

A-102742 1/2 X 103" (2616.2) Belt, Drive, (RIDING LAW N MOWER: (42 INCH CUT, 48 CUT ALL w/ 3 blade side discharge))

A-106125 1/2 X 89" (2260.6) Belt, Drive, (RIDING LAW N MOWER: 42 INCH CUT)

A-109909 1/2 X 116.75" (2965.45) Belt, Blade Drive, (RIDING LAW N MOWER: 50 INCH CUT)

A-114200 1/2 X 123.75" (3143.25) Belt, Drive, (ZERO TURN MOWER: 50 INCH), (RIDING LAWN MOWER: 48 INCH CUT)

A-114202 1/2 X 125.75" (3194.05) Toro/Wheel Horse,

A-1046397 1/2" X 108.25" (2749.55) Toro/Wheel Horse,

A-1046398 5/8" X 75.125" (1908.175) Toro/Wheel Horse,

A-1048152 1-1/8 X 48.5" (1231.9) 2/band Belt, Drive,

A-1120317 1/2 X 79.1" (2009.14) Blade Belt,

Troy Bilt

Toro / Wheel Horse

A&I Part No. Inches (mm) Model/Application

OrderForm

A&I Part No. Inches (mm) Model/Application

A-210890 5/8 X 72" (1828.8) Belt, Deck,

A-256430 9/16 X 33.25" (844.55) Belt, Drive, (SNOWTHROWER: 200E, 620, 620E, CR20, S-200)

A-271160 1/2 X 105.5" (2679.7) Belt, Drive, (W ALK BEHIND MOWER: HYDRO 44" Deck, HYDRO 52" Deck)

A-271160 1/2 X 105.5" (2679.7) Belt, Deck,

A-271160 1/2 X 105.5" (2679.7) Belt, Deck, (ZERO TURN MOWER: (2 SERIES, 3 SERIES, 4 SERIES, 5 SERIES ALL gear drive

w/ 44" or 52" deck))

A-271160 1/2 X 105.5" (2679.7) Belt, Drive,

A-420884 1/2 X 23.92" (607.568) Belt, Drive,

A-446260 1/2 X 123.5" (3136.9) Belt, Deck, (W A L K B E H IND M O W E R : H YDR O 6 2 " D e c k)

A-446260 1/2 X 123.5" (3136.9) Belt, Deck,

A-446260 1/2 X 123.5" (3136.9) Belt, Deck, (ZERO TURN MOWER: Z250 62" Deck)

A-446260 1/2 X 123.5" (3136.9) Belt, Deck, (ZERO TURN MOWER: Z252)

A-448990 1-1/4 X 33.5" (850.9) Belt, Torque,

A-471410 1/2 X 47.5" (1206.5) Belt, Drive, (RIDING LAW N MOWER: 32 INCH REAR ENGINE)

A-471420 1/2 X 65.5" (1663.7) Belt, Drive, (RIDING LAW N MOWER: 32 INCH REAR ENGINE)

A-54505 3/8 X 31.5" (800.1) Belt, Drive, (SELF PROPELLED: (FIESTA, GUARDIAN, WHIRLWIND ALL 21" side discharge))

A-514290 1-1/4 X 51.5" (1308.1) Belt, Drive, (PRO-LINE: 30117, 30165, 30170, 30175, 30180), (PISTON GRIP: 30115)

A-514291 1 1/8" X 47.25" (1200.15) 2 band Toro/Wheel Horse,

A-517434 3/8" X 33.5" (850.9) Cogged Transmission Belt,

A-539660 1-1/8 X 43.375" (1101.725) Belt, Drive,

A-542750 5/8 X 70" (1778) Belt, Deck, (WALK BEHIND MOWER: 36, 44, 52), (PRO-LINE: (30117, 30136, 30144, 30165,

30170, 30180 ALL 36" & 44" cut))

A-542750 5/8 X 70" (1778) Belt, Engine, (WALK BEHIND MOWER: HYDRO 36", HYDRO 44", HYDRO 52"), (PRO-LINE:

(30117, 30136, 30144, 30165, 30170, 30180 AL L 36" & 44" cut))

A-557660 21/32 X 68" (1727.2) Belt, Blade Drive,

A-559300 9/16 X 34.75" (882.65) Belt, Drive, (SNOWTHROWER: CCR2000)

A-570240 A A X 150" (3810) Belt, Deck,

A-570240 A A X 150" (3810) Toro/Wheel Horse, (ZERO TURN MOWER: Z250 72" Deck)

A-570240 A A X 150" (3810) Belt, Deck, (ZERO TURN MOWER: Z252 72" Deck)

A-6738 1/2 X 86" (2184.4) Belt, Blade Drive, (RIDING LAW N M O W E R : 4 2 I N C H C U T w/ 3 blade side discharge)

A-633569 3/4 X 57" (1447.8) Belt, Pump Drive, (ZERO TURN MOWER: Z252)

A-657270 1/2 X 22" (558.8) Belt, Engine,

A-660210 7/16 X 34" (863.6) Belt, Drive,

A-671390 1/2 X 51" (1295.4) Belt, Drive, (RIDING LAW N MOWER: (56128 REAR ENGINE, 56132 REAR ENGINE ALL 25"))

A-696220 5/8 X 138" (3505.2) Belt, Main Drive, (LA WN/GARDEN TRACTOR: 580D)

A-7478 5/8 X 84" (2133.6) Belt, Drive,

A-715381 3/8 X 34.75" (882.65) Belt, Drive, (SNOWTHROWER: CCR1000)

A-741330 5/8" X 82.25" (2089.15) Belt, Engine, (W ALK BEHIND MOWER: HYDRO 62")

A-759010 3/8 X 20.2" (513.08) Belt, Drive,

A-8411 1/2 X 77" (1955.8) Belt, Blade Drive, (RIDING LAW N M O W E R : 3 6 I N C H C U T 3 blade side discharge)

A-822390 1/2" X 127.5" (3238.5) Belt, Deck, (WALK BEHIND MOWER: HYDRO 48" Mulching Deck)

A-824110 1/2 X 47.125" (1196.975) Belt, Pump Drive, (WALK BEHIND MOWER: HYDRO)

A-826420 5/8" X 85" (2159) Belt, Engine, (W A L K B E H I N D M O W E R: H Y D RO 4 8 " D e c k )

A-844390 5/8" X 76.5" (1943.1) Belt, Engine, (W A L K BE H I N D M O W E R: H Y D R O 3 7 " D e c k )

A-861960 1/2 X 162" (4114.8) Toro/Wheel Horse,

A-861970 1 1/4" X 114.75" (2914.65) 3 band Toro/Wheel Horse,

A-886250 1/2 X 87.5" (2222.5) Belt, Blade Drive, (RIDING LAW N MOWER: 71191 38" Deck)

A-925588 1/2" X 139.375" (3540.125) Toro/Wheel Horse,

A-933884 1/2" X 130" (3302) Belt, Deck, (RIDING LAW N MOWER: XL RANGE w/ 44" Deck)

A-938457 5/8" X 138" (3505.2) Belt, Main Drive, 580D

A-980710PIX 1/2 X 51" (1295.4) Toro/Wheel Horse,

A-983764 1/2" X 142.5" (3619.5) Belt, Engine, (ZERO TURN MOWER: Z250 62" Deck SN <990000)

A-983780 5/8 X 141.125" (3584.57) Belt, Engine, (ZERO TURN MOWER: Z250 52" Deck SN <992000)

A-983780 5/8 X 141.125" (3584.57) Belt, Engine, (ZERO TURN MOWER: Z252 52" Deck SN <992000)

A-993904 1/2" X 157.5" (4000.5) Toro/Wheel Horse, (RIDING LAWN MOWER: Z MASTER)

A-994627 5/8 X 147" (3733.8) Belt, Engine, (ZERO TURN MOWER: Z250 72" Deck)

A-994627 5/8 X 147" (3733.8) Belt, Engine, (ZERO TURN MOWER: Z252 72" Deck)

A-994647 5/8 X 141.75" (3600.45) Belt, Engine, (ZERO TURN MOWER: Z250 62" Deck SN 990000>)

A-994647 5/8 X 141.75" (3600.45) Belt, Engine, (ZERO TURN MOWER: Z252 62" Deck SN 990000>)

Troy Bilt

A-W5L290 5/8" X 26" (660.4) Belt, Drive, (CHIPPER: Super Tomahawk II)

A-1128 1/2 X 22.0" (558.8) Belt, Drive, (TILLER: HORSE MODELS)

A-1185651 1/2 X 114.156" (2899.56) Belt, Drive,

A-1723661 3/8 X 40.5" (1028.7) Belt, Drive, (MULCHING MOWER: FRONTWHEEL DRIVE)

LAWN & GARDEN BELTS

Woods - Copeland

Walker

OrderForm

Catalog !! Lawn Garden

Navigation menu

Versions of this User Manual:

Views

Navigation
