ELITE1ELITE10™&ELITE1 2™
ELITE10
™&ELITE12
™
Efficiency and quiet operation combined with easy serviceability and
installation to provide premium Lennox quality and comfort.
Blower Coils
Match
the right blower
coil with the
right quality
Lennox home
comfort system
and you’ll
notice a
difference in
comfort and
savings. That’s
because when
it comes to
moving air,
nothing else
can compare.
Since 1895, people have
trusted Lennox to
make their lives
more comfortable.
Lennox adds to that legacy with
the Elite 10™ and Elite 12™
blower coils.
It’s the job of blower coil to
circulate warm or cool air
throughout your home. That’s
an important job, and that’s
why it’s critical to have a blower
coil that can handle the task.
With the Elite 10 and Elite 12
blower coils, Lennox has
designed products that provide
unsurpassed comfort. Our
multi-position design allows the
Elite 10 and Elite 12 blower
coils to fit any indoor space.
We build according to
internationally recognized
ISO 9002 manufacturing
standards. And, we stand behind
our products
with some
of the best
warranties* in
the industry. The Elite 10 and
Elite 12 blower coils are backed
by a 5-year limited parts warranty
on covered components. That’s
one more reason to trust Lennox.
The correct combination of
a blower coil with a heat pump
or air conditioner that are
designed to work together will
not only extend the life of your
units, but ensure that you will
get maximum efficiency from
your units. That’s why we call
them “matched systems.”
With the efficient design of
the Elite 10 and the higher
efficiency Elite 12, you can
expect to see a savings on your
monthly utility bill. Ask your
independent Lennox dealer for
the right match.
Thanks to our direct-drive
blower motor, our extra-thick
insulation and our durable,
tightly-sealed cabinet, the
Elite 10 and 12 blower coils are
so quiet, you’ll hardly notice
them. Doesn’t that sound great?
PERFORMANCE
WARRANTIES
ENERGY SAVINGS
quiet operation
* Warranties noted apply to residential applications only.
ELITE1LITE10™&ELITE&ELITE1 2™
ELITE10
™&ELITE12
™
QUALITY
COMPONENTS
EASY MAINTENANCE
EFFICIENT DESIGN
LOOKS GOOD YEAR
AFTER YEAR
High Static Capability — Airflow
can be adjusted to meet any home’s
comfort requirements.
Quiet Direct-Drive Multi-Speed
Blower Motor — Provides quiet operation
with no pulleys or belts to break.
1
High-Efficiency Evaporator Coil
— Provides exceptional heat transfer
and refrigerant flow for efficient operation.
3
Optional Electric Heat —A wide
range of electric heat options are available
including the EvenHeater
™
Supplemental
Heater to provide backup resistance heat.
2
No External Side Screws —
Eliminates scraping walls or doors, no
matter how tight the space.
7
Compact Size &
Convertible Airflow Design —
Enables the Elite 10 and Elite
12 blower coils to be installed
almost anywhere. Available in
upflow, downflow,
horizontal and side
return applications.
Efficient Check and Expansion
Device — Ensures efficiency is provided
over a large variety of operations.
4
Quiet Operation — Insulated
blower compartment and cabinet,
combined with quiet blowers, help mute
sound levels.
6
1
3
2
4
5
6
7
Corrosion-Resistant Cabinet
— Durable, baked-on enamel finish
protects the heavy-gauge, galvanized
steel cabinet against rust and corrosion.
8
9
Easy Filter Access — Tool-free filter
access makes it easy and convenient to
change filters for high efficiency.
5
Multi-Position Plastic Drain Pans
— Guard against corrosion and prevent
leaks and water damage.
9
Litho U.S.A.
Choosing the right dealer for your heating and cooling needs is
every bit as important as choosing a particular brand of equipment.
That’s why Lennox has the industry’s only Quality Dealer Standards
program. Independent Lennox dealerships have to meet Lennox’ high
standards. We think you’ll agree they’re a big reason why
you can always count on getting a quality product whenever
you call on Lennox.
Lennox is committed to providing
you with the finest in quality home
comfort. That commitment includes
offering accessories that can make
your home even more energy
efficient and comfortable.
quality DEALERS
YOU CAN COUNT ON
TOTAL HOME COMFORT
A proven energy saver, an
electronic thermostat provides
added comfort, convenience,
and time-saving fingertip
programming.
ELECTRONIC
THERMOSTATS
Note: Due to Lennox’ ongoing commitment to quality, all specifications, ratings and dimensions are subject to change without notice.
Elite 10™ & Elite 12™ Blower Coil Specifications
ELITE 10 CB29M 21/26 31 41 46 51 65
Nominal Cooling - Tons 1.5 – 2 2.5 3 3.5 4 5
kW 5.3-7.0 8.8 10.6 6.3 14.1 17.6
Blower Motor Output – hp (W) 1/5 (149) 1/3 (249) 1/3 (249) 1/2 (373) 3/4 (560) 3/4 (560)
Electrical Data-60hz 208/230v-1ph 208/230v-1ph 208/230v-1ph 460v-1ph 208/230v-1ph 208/230v-1ph 460v-1ph 208/230v-1ph 460v-1ph
Shipping Weight – lbs. (kg) 121 (55) 123 (56) 156 (71) 160 (73) 181 (83) 181 (83)
Upflow/Downflow Dimensions
H.W.D. (in.) 45-1/4x16-1/4x20-5/8 45-1/4x16-1/4x20-5/8 49-1/4x21-1/4x20-5/8 49-1/4x21-1/4x20-5/8 52-1/2x21-1/4x22-5/8 52-1/2x21-1/4x22-5/8
H.W.D. (mm) 1149x413x524 1149x413x524 1251x540x524 1251x540x524 1334x540x575 1334x540x575
Horizontal Dimensions
H.L.D. (in.) 16-1/4x45-1/4x20-5/8 16-1/4x45-1/4x20-5/8 21-1/4x49-1/4x20-5/8 21-1/4x49-1/4x20-5/8 21-1/4x52-1/2x22-5/8 21-1/4x52-1/2x22-5/8
H.L.D. (mm) 413x1149x524 413x1149x524 540x1251x524 540x1251x524 540x1334x557 540x1334x557
ELITE 12 CB30M 21/26 31 41 46 51 65
Nominal Cooling - Tons 1.5 – 2 2.5 3 3.5 4 5
kW 5.3-7.0 8.8 10.6 12.3 14.1 17.6
Blower Motor Output – hp (W) 1/5 (149) 1/3 (249) 1/3 (249) 1/3 (249) 1/3 (249) 1/2 (373)
Electrical Data-60hz 208/230v-1ph 208/230v-1ph 208/230v-1ph 460v-1ph 208/230v-1ph 208/230v-1ph 460v-1ph 208/230v-1ph 460v-1ph
Shipping Weight – lbs. (kg) 136 (62) 157 (71) 177 (80) 181 (82) 206 (93) 206 (93)
Upflow/Downflow Dimensions
H.W.D. (in.) 45-1/4x16-1/4x20-5/8 49-1/4x21-1/4x20-5/8 51x21-1/4-x22-5/8 52-1/2x21-1/4x22-5/8 58-1/2x21-1/4x24-5/8 58-1/2x21-1/4x24-5/8
H.W.D. (mm) 1149x413x524 1251x540x524 1295x540x575 1334x540x575 1486x540x625 1486x540x625
Horizontal Dimensions
H.L.D. (in.) 16-1/4x45-1/4x20-5/8 21-1/4x49-1/4x20-5/8 21-1/4x51-1/4x22-5/8 21-1/4x52-1/4x22-5/8 21-1/4x58-1/4x24-5/8 21-1/4x58-1/2x24-5/8
H.L.D. (mm) 413x1149x524 540x1251x524 540x1295x575 540x1334x575 540x1486x625 540x1486x625
ELITE 12 CB30U 21/26 31 41 46 51 65
Nominal Cooling - Tons 1.5 – 2 2.5 3 3.5 4 5
kW 5.3-7.0 8.8 10.6 12.3 14.1 17.6
Blower Motor Output – hp (W) 1/5 (149) 1/3 (249) 1/3 (249) 1/3 (249) 1/3 (249) 1/2 (373)
Electrical Data-60hz 208/230v-1ph 208/230v-1ph 208/230v-1ph 460v-1ph 208/230v-1ph 208/230v-1ph 460v-1ph 208/230v-1ph 460v-1ph
Shipping Weight – lbs. (kg) 136 (62) 157 (71) 177 (80) 181 (82) 206 (93) 206 (93)
Upflow/Downflow Dimensions
H.W.D. (in.) 45-1/4x16-1/4x20-5/8 49-1/4x21-1/4x20-5/8 51x21-1/4-x22-5/8 52-1/2x21-1/4x22-5/8 58-1/2x21-1/4x24-5/8 58-1/2x21-1/4x24-5/8
H.W.D. (mm) 1149x413x524 1251x540x524 1295x540x575 1334x540x575 1486x540x625 1486x540x625
Horizontal Dimensions
H.L.D. (in.) 16-1/4x45-1/4x20-5/8 21-1/4x49-1/4x20-5/8 21-1/4x51-1/4x22-5/8 21-1/4x52-1/4x22-5/8 21-1/4x58-1/4x24-5/8 21-1/4x58-1/2x24-5/8
H.L.D. (mm) 413x1149x524 540x1251x524 540x1295x575 540x1334x575 540x1486x625 540x1486x625
(45K66) E10/12BCB–8/98 © Lennox Industries Inc., 1996 Visit us at http://www.Lennox.com or contact us at 1-800-9-LENNOX
COMPLETE CARE
Extended Protection Plan
™
®
WINTER SUMMER
The EfficiencyPlus™ system
allows you to adjust the
relative humidity inside your
home without affecting room
temperatures for maximum
comfort and energy efficiency.
Humidity
Control
An electronic air cleaner
purifies the air and provides
respiratory relief by removing
dust, dirt and pollen.
ELECTRONIC
AIR CLEANERS
