M 88
Hypercardioid
Moving Coil
Microphone
Version Order #
M 88 N(C) Dynamic microphone 437.107
M 88 TG TourGroup™version 437.117
APPLICATIONS
The M 88 offers both a wide frequency response and rugged construction making
an ideal combination for many applications.
In the studio and live use its high SPL capability allows the microphone to be placed
close to loud sound sources such as kick drum and bass guitar. It is also equally
impressive as a vocal microphone or for brass and windwood instruments.
The TourGroup version (M 88 TG) has a reinforced basket to withstand rough
handling when being used for more demanding applications. The M 88 is often used
in a broadcast environment as an announcers or EFP microphone.
FEATURES
• Highly defined hypercardioid polar characteristic
• Sensitive, accurate response
• Extended frequency range with rising high end and exceptional bass reproduction
• High SPL handling capability
• Integral -20 dB humbucking filter
TECHNICAL SPECIFICATIONS
Transducer type . . . . . . . . . . . . Dynamic moving coil
Operating principle . . . . . . . . . Pressure gradient
Frequency response . . . . . . . . . 30 - 20,000 Hz
Polar pattern . . . . . . . . . . . . . . Hypercardioid
Open circuit voltage
at 1 kHz (0 dB =
^1 V/Pa). . . . . . 2.3 mV/Pa =
^-53 dBV
Nominal impedance. . . . . . . . . 200 Ω
Load impedance. . . . . . . . . . . . ≥1000 Ω
Weight w/out cable. . . . . . . . . . 320 g
M 88 TG
Germany
Theresienstr. 8
74072 Heilbronn
Tel. (07131) 617-0
Fax (07131) 60459
beyerdynamic@t-online.de
www.beyerdynamic.de
United States
56 Central Ave.
Farmingdale, NY 11735
Tel. (516) 293-3200
Fax (516) 293-3288
salesUSA@beyerdynamic.com
www.beyerdynamic.com
France
7, Rue Labie
F-75017 Paris
Tél. 0144.09.93.93
Fax 0144.09.82.33
beyer_france@compuserve.com
www.beyerdynamic.com
Great Britain
17 Albert Drive
Burgess Hill RH15 9TN
Tel. (01444) 258258
Fax (01444) 258444
sales@beyerdynamic.co.UK
www.beyerdynamic.com
FREQUENCY RESPONSE & POLAR PATTERN
This polar pattern and frequency response curve (measuring distance 1 m) correspond to typical production run
specifications for this microphone.
WIRING DIAGRAM
Positive pressure produces positive voltage
on red lead (+).
MEASUREMENTS
In millimetres (inches in brackets)
SUPPLIED ACCESSORIES
MKV 8 mic clip with 3/8" / 5/8" internal thread
Black, padded protective zipper bag
OPTIONAL ACCESSORIES
Highly flexible cables with industry standard Neutrik jack and XLR connectors
MKV 6 mic clamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 407.208
PS 88 popscreen, charcoal-grey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 111.414
WS 59 windshield, charcoal-grey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 419.087
Photos are non-contractual. Contents subject to change without notice. Printed in Germany.
181 (7.12)
Ø 25,5
(1.0)
Ø 48,5
(1.90)
120 (4.72)
white
red
Frequency response ± 2.5 dB 0 dB 2,3 mV/Pa M 88
=
^
beyerdynamic M 88
