Mobile SATA

Spinpoint M8

160GB 250GB 320GB 500GB 640GB 750GB 1TB

Model 8 MB HN-M160MBB HN-M250MBB

HN-M320MBB

HN-M500MBB HN-M640MBB HN-M750MBB

HN-M101MBB

FEATURES

• Max. 500GB formatted capacity per disk • ATA Security Mode Feature Set

• SATA Native Command Queuing Feature • ATA S.M.A.R.T. Feature Set

• TuMR/PMR head with FOD technology

• SilentSeek™

• Serial ATA 3.0Gbps Interface Support • NoiseGuard™

• Load/Unload Head Technology

Capacity1160~750GB, 1TB Temperature

Interface SATA 3.0 Gbps (1.5Gbps) Operating 5 ~ 55 ℃

Buffer DRAM Size28 MB Non-operating -40 ~ 70 ℃

Rotational Speed 5,400 RPM class Humidity (non-condensing)

Operating 5-90 %

Non-operating 5-95 %

Average Seek time (typical) 12 ms Linear Shock (1/2 sine pulse)

Average Latency 5.6 ms Operating, 2ms 325 G

Data Transfer Rate Non-operating, 2ms 750 G

Media to/from Buffer (Max.) 145 MB/s

Vibration (swept sine, 1/4 octave per minute)

Buffer to/from Host (Max.) 300 MB/s Operating 1 .5 Grms

Drive Ready Time (typical)3 4 sec Altitude (relative to sea level)

Operating -300 to 3000 m

Non-operating -400 to 15000 m

Non-recoverable Read Error 1 sector in 1014 bits

Controlled Ramp Load/Unload 600,000

Height 9.5 ± 0.2 mm

Idle 2.4 Bel Width 69.75 ± 0.25 mm

Performance Seek 2.6 Bel Length 100.3 ± 0.4 mm

Weight (max.) 107 g

Voltage +5V±5% * Note : Design and specifications are subject to change without prior notice.

Spin-up Current (Max.) 1000 mA 1.1MB = 1,000,000 Bytes, 1GB = 1,000,000,000 Bytes

Seek (AVG)4 2 W Accessible capacity may vary as some OS uses binary numbering system

Read/Write (AVG) 2.2 W for reported capacity

Low Power Idle (AVG) 0.7 W 2 A small portion of the 8MB buffer memory is reserved for firmware use

Standby (AVG) 0.2 W 3 Power-On to Drive Ready

Sleep (AVG) 0.2 W 4 30% duty cycle, random seek

2.5" HDD product specification Rev 1.1

Match with product manual Rev 00

POWER REQUIREMENTS

ACOUSTICS

Capacity

DRIVE CONFIGURATION

ENVIRONMENTAL SPECIFICATIONS

PERFORMANCE SPECIFICATIONS

RELIABILITY SPECIFICATIONS

PHYSICAL DIMENSION
