ML1200 D M Feature Sheet

User Manual: ML1200-D-M - Feature sheet

Open the PDF directly: View PDF .
Page Count: 1

FEATURES

• Standard double magnet.

• Clean and compact design in

aluminium.

• Multi LED indication on

ML1200-D-M

Suitable brackets:

• BK1200ZL (ZL Brackets)

• BK1200L (L Brackets)

• AH1200 (Armature Housing)

Electronic Locking

Magnet Range

• Aluminium housing.

• 12/24vdc @600/300mA.

• 2 x 545kgs (1200lb) holding force.

• Built in surge protection.

• ML1200-D-M = Monitored

Technical specications

p:+44 (0) 1902 656667 | www.rgl.co

Magnet Range

Other items in the RGL range.

ML1200-D-M 530x73x40 (mm) Double Magnetic Lock 1200lb / 545kg x 2 8.54Kg (Boxed) / 5.58Kg (Unboxed)

Armature 185x60x15 (mm) Metal armature plate 1.26Kg (Unboxed)

BK1200ZL Z = 266L (mm) ZL Bracket 1.26Kg (Boxed) / 1.12Kg (Unboxed)

BK1200L L = 185L (mm) L Bracket 524g (Boxed) / 426g (Unboxed)

Double Standard Magnetic Lock (1200lb)

FIRE TESTED

The ML600 range of magnets

and brackets have been fire

tested to BSEN1634-1-2014

(30 & 60 minute timber door-sets)
