MS2400 Stratos Series
Honeywell’s MS2400 Stratos® 5-sided, 360°-bioptic scanner/scale
increases productivity in demanding, high-volume seated environments
where shorter vertical towers are required, and poor quality and high-
density bar codes are prevalent. Independent scanning planes and
a modular design lower maintenance costs and ensure continuous
operation.
The MS2400 Stratos series provides retailers with the ability to deploy
a single scanner platform across multiple store formats around the
world, including stores with 353 mm (13.9”), 399 mm (15.7”), and 508
mm (20”) scanner footprints.
Aggressive scan performance on high density and poor quality bar
codes minimizes the need for manual keying. The MS2400 also excels
at scanning GS1 DataBar™ codes, ensuring compliance with sunrise
initiatives.
Rapid pass-through scanning allows cashiers to maintain a constant
motion across a wide range of bar codes, leading to faster customer
processing, shorter lines, optimization of the number of open checkout
lanes, and lower labor and energy costs.
Unlike other bioptic devices, MS2400 is the only one to offer pre-aligned
optical scanning modules, and independent scanning planes which
enable the scanner to maximize uptime and maintain productivity.
The MS2400 Stratos maximizes return on investment with two analytical
tools for tracking, managing and improving checkout productivity and
efficiency. StratosSTATSTM provides real-time visibility into key data
points directly impacting checkout productivity. StratosSCHOOLTM
captures information necessary to improve operator scanning
techniques and safety.
Bioptic Scanner/Scale
• 5-sided, 360°-Scanning: Improves productivity and
operator ergonomics by reducing product orientation
• StratosSYNCTM Independent Scanning Planes:
Maintains
productivity and uptime via independent
scanning planes
• StratosSCHOOL Operator Training Software: Improves
productivity and promotes safer scanning techniques
• StratosSWAPTM Pre-Aligned Optical Scanning
Modules: Minimizes downtime and lowers the cost of
service via modular optical scan engines
• StratosSTATS Productivity Analytical Software:
Provides data critical to maintaining checkout
productivity
• Remote MasterMindTM Scanner Management
Sofware: Offers a quick and convenient solution for IT
administrators seeking to manage all scanners within
their network from a single remote location
• Flip-Up Weigh Bar: Single or three-sided options allow
cashiers to accurately weigh oversized produce, reducing
shrink loss
Features
MS2400-DS Rev B 10/09
© 2009 Honeywell International Inc.
Honeywell Scanning & Mobility
9680 Old Bailes Road
Fort Mill, SC 29707
800.582.4263
www.honeywell.com
For more information:
www.honeywellaidc.com
RoHS
2002/95/EC
MS2400 Stratos Technical Specifications
Operational
Light Source Visible Laser Diode 650 nm ± 10 nm
Visual Indicators
Steady Blue = ready to scan; Flashing Blue = good read; Amber = scale at zero; 7-segment display = diagnostic indicator
Host System Interfaces USB, RS232, IBM46xx (RS485)
Auxiliary Ports RS232: Secondary scanner, EAS
Mechanical
Electrical
Input Voltage 5.2 VDC ± 0.25 VDC; 12 VDC ± 0.5 VDC
Operating Power 11 W (1670 mA @ 5.2 V; 190 mA @ 12 V)
Standby Power 5.5 W (610 mA @ 5.2 V; 190 mA @ 12 V)
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Humidity 5% to 95% relative humidity, non-condensing
Environmental Sealing Sealed to resist airborne particulate contaminants
Light Levels 4842 Lux
Scan Performance
Depth of Scan Field (Horiz/Vert) H: 0 mm - 100 mm (0˝-4˝); V: 0 mm - 216 mm (0˝-8.5˝) for 0.33 mm (13 mil) bar code
Sides Read/Scan Zone 5 / 360°
Scan Pattern Omnidirectional: 54 scan lines (Horizontal: 38 scan lines; Vertical: 16 scan lines)
Scan Speed 5400 scan lines per second
Resolution 4.5 mil (0.114 mm)
Print Contrast 35% minimum reflectance difference
Decode Capability Reads standard 1D and GS1 DataBar symbologies.
Warranty 2 year factory warranty
For a complete listing of all compliance approvals and certifications please visit www.honeywellaidc.com/compliance
Scale Specifications
Capacity 15 kg (30 lb)
Minimum Legal Weight 0.005 kg (0.01 lb)
Maximum Static Weight 68 kg (150 lb)
Adjustments Required Field calibration if necessary
Applications Weight-only and price computing
Scale Partners Avery Berkel®, Bizerba®, Dibal®, Digi®, Herbert Retail
and Mettler Toledo®
Platter Options Single or three-sided flip-up bar for weighing
oversized produce
Product Length Width Depth (Below Counter) Height (Above Counter)
MS2420 (compact scanner with scale) 399 mm (15.7˝) 292 mm (11.5˝) 100 mm (4˝) 130 mm (5.1˝)
MS2421 (compact scanner only) 399 mm (15.7˝) 292 mm (11.5˝) 100 mm (4˝) 130 mm (5.1˝)
MS2422 (sub compact scanner only) 353 mm (13.9˝) 292 mm (11.5˝) 100 mm (4˝) 130 mm (5.1˝)
MS2430 (full-size scanner with scale) 508 mm (20˝) 292 mm (11.5˝) 100 mm (4˝) 130 mm (5.1˝)
MS2431 (full-size scanner only) 508 mm (20˝) 292 mm (11.5˝) 100 mm (4˝) 130 mm (5.1˝)
