MSR605
Magnetic Stripe Card Reader/Writer
(High & Low Coercivity)
Programmer’s Manual
Revision B
2009-06-01
MSR605 Programmer’s Manual Rev. A
Table of Contents
SECTION 1 INTRODUCTION.....................................................................３
¾ Accessories of MSR605.................................................................................３
¾ Warranty........................................................................................................３
SECTION 2 GENERAL DESCRIPTION ...................................................... 4
SECTION 3 TECHNICAL SPECIFICATIONS.............................................. 2
SECTION 4 SETUP ..................................................................................... 4
SECTION 5 UTILITIES TEST PROGRAM .................................................. 5
¾ System Requirement .......................................................................................5
¾ Test Program Installation...............................................................................5
SECTION 6 COMMAND AND RESPONSE................................................. 6
SECTION 7 DATA FORMAT...................................................................... 11
SECTION 8 COMMUNICATION SEQUENCE ........................................... 13
¾ MSR 605 INITIALIZATION .......................................................................13
¾ Write Data to MSR 605 ................................................................................13
¾ Read Data to MSR605...................................................................................14
SECTION 9 ADDENDUM........................................................................... 15
¾ Write Data to Magnetic Card ......................................................................15
¾ Write Raw Data to Magnetic Card..............................................................16
２
MSR605 Programmer’s Manual Rev. A
３
Section 1 Introduction
Thank you for purchasing the MSR605 Manual Swipe Magnetic Card Reader/Writer. It is ideal for access control,
time keeping, banking, ID recognition & credit verification and related applications. In fact, wherever a magnetic
stripe ID or transaction card is used, one can find a related use for the versatile, user-friendly MSR605 reader/writer.
The MSR605 is designed to offer a reading and writing solution of high and/or low coercivity cards that will
attractively complement an existing system.
¾ Accessories of MSR605
Make sure all the following accessories are contained in your package:
1. Switch power Supply, AC 110~240V in / DC 24V, 2.2~3A out.
2. Power cord.
3. Signal cable (USB).
4. Utility disk (A/P S/W).
5. Programmer’s manual.
¾ Warranty
One year after purchase of MSR605, any alteration and/or erasure or modification of the MSR605 will void the
warranty.
MSR605 Programmer’s Manual Rev. A
Section 2 General Description
The MSR605 series is designed to read and/or write high or low coercivity magnetic cards. It can encode and verify
up to 3 tracks of data simultaneously. It communicates with a host computer or other terminal using a usb interface.
4
MSR605 Programmer’s Manual Rev. A
Section 3 Technical Specifications
ITEM SPECIFICATION
Standard ISO7811
Electrical
Current/operating Typical 350mA Max
Consumption 600mA plus for each writing track
Communication Standard RS232 signal voltage levels. Default, 9600 Baud, None Parity, 8 bits
Power supply External switching Power 24V/2.2A regulated
Interconnection
Cable USB
1,VBUS
2. D-
3.D+
Pin Assignment
USB 4. GND
Mechanical
Body ABS 94V-0 / Metal housing optional
Swipe Manual, single direction
Outline 212Lx64Wx63H mm
Weight 1.4Kg approx.
Environment
Operation -10ºC to 60ºC
10 to 85% humidity, non condensing
Storage -30ºC to 70ºC
10 to 90% humidity, non condensing
Performance
Track 1&3 210bpi
Read Circuit Track 2,75 or 210 bpi
Bit per Char 5-7 bit per char.
Read, 5-50 ips (read speed 5-40 ips for track 2 at 210bpi)
Media Speed Write, 5-30
Read 300-4000 Oe Mag. Card
Media Coercivity Write 300-4000 Oe Mag. Card
Media Thickness 0.76-1.2mm
Read bit to bit interval <+/-15% card
Jitter Card Write bit to bit interval <+/-10%,Sub interval<+/-12% at 30ips
2
MSR605 Programmer’s Manual Rev. A
3
Low amplitude Card Read 60% for both 75& 210bpi
Error Rate Read < 0.5%
Write < 0.8%
Media Swipe Head life 1,000,000 passes for both read & write head
Model Read/Write Track Hi-C Lo-C
MSR605 1&2&3 R/W R/W
Configuration
Available Model
MSR605 Programmer’s Manual Rev. A
Section 4 Setup
1. Power on your system (PC).
2. Setup the usb driver(for windows xp or vista) and Setup the driver for MSR605,all driver in the cd.
3. Connect USB of the MSR605 signal cable to a free serial port .
4. Connect Power-in cable to Power supply and AC receptacle (110V~240V).
5. Now you can use the MSR605 like MSR206.
4
MSR605 Programmer’s Manual Rev. A
Section 5 Utilities Test Program
Every MSR605 comes with a utilities test program disk that includes a Windows version. This program is to verify
and demonstrate the functionality of the MSR605. In some cases, it can be used as a card reading and writing
program.
¾ System Requirement
1. 80286 PC/AT compatibles or later model with color display.
2. Either the following operating systems: Windows 95,98,2000,XP,VISTA
3. 256K available conventional memory.
4. A free serial port (Com 1 or Com 2) with DB9 male connector.
¾ Test Program Installation
User shall follow the steps below in order to install test program.
A. Connect MSR605 to USB port, and power on it.
B. Execute test program from the subdirectory of ‘Demo AP’ (e.g. MSR605.exe)
D. When the test program is first opened, a password dialog box will ask whether you wish a first time
password.
D The test program will auto-detect communication port. If there is any errors occurred, it’ll appear in the
information dialog box after opening the program. User can close the AP by pressing OK button.
E. If “Not Find Reader/Writer!” appears in the information dialog box after opening the program, check to
see that the USB connector is plugged into the correct USB port and the power cord/connector is also
attached to USB thus lighting the green LED on the MSR605.
F. When the test program is opened, you’ll see the main window of the READER/WRITER UTILITY
PROGRAM.
From this main window you can activate all functions by clicking the appropriate buttons and following the
on screen instructions.
5
MSR605 Programmer’s Manual Rev. A
Section 6 Command and Response
This section gives detailed description of commands to the MSR605 and the corresponding responses from MSR605.
Notional Conventions:
<ESC> Control character named
Special string named sname, meaning can be found in section 7.
[[[[ [sname]
ie.[Data Block] [Status Byte] [Select Byte] etc.
X Standard ANSI character
Command Description:
1. Command: RESET
Command code: <ESC> a
Hex code: 1B 61
Response: none
Description: This command reset the MSR605 to initial state.
2. Command: READ (ISO format only)
Command code: <ESC> r
Hex code: 1B 72
Response: [Data Block] <ESC> [Status Byte]
Description: This command request MSR605 to read a card swiped and respond with the data read.
3. Command: WRITE (ISO format only)
Command code: <ESC> w [Data Block]
Hex code: 1B 77 [Data Block]
Response: <ESC> [Status Byte]
Description: This command request MSR605 to write the Data Block into the card swiped.
4. Command: Communication test
Command code: <ESC> e
Hex code: 1B 65
Response: <ESC> y [1B] [79]
Description: This command is used to verify that the communication link between computer and MSR605 is up
and good.
5. Command: All LED off
Command code: <ESC> <81>
Hex code: 1B 81
Response: none
Description: This command is used to turn off all the LEDs.
6
MSR605 Programmer’s Manual Rev. A
6. Command: All LED on
Command code: <ESC> <82>
Hex code: 1B 82
Response: none
Description: This command is used to turn on all the LEDs.
7. Command: GREEN LED on
Command code: <ESC> <83>
Hex code: 1B 83
Response: none
Description: This command is used to turn on the Green LED.
8. Command: YELLOW LED on
Command code: <ESC> <84>
Hex code: 1B 84
Response: none
Description: This command is used to turn on the Yellow LED.
9. Command: RED LED on
Command code: <ESC> <85>
Hex code: 1B 85
Response: none
Description: This command is used to turn on the Red LED.
10. Command: Sensor test
Command code: <ESC> <86>
Hex code: 1B 86
Response: <ESC> 0 (1B 30) if test ok
Description: This command is used to verify that the card sensing circuit of MSR605 is working properly.
MSR605 will not response until a card is sensed or receive a RESET command.
11. Command: Ram test
Command code: <ESC> <87>
Hex code: 1B 87
Response: <ESC> 0 (1B 30) ram test ok; <ESC> A (1B 41) ram test fail
Description: This command is used to request MSR605 to perform a test on its on board RAM.
7
MSR605 Programmer’s Manual Rev. A
12. Command: Set leading zero
Command code: <ESC> z [leading zero of track 1 & 3] [leading zero of track 2]
Hex code: 1B 7A [00~ff] [00~ff]
Response: <ESC> 0 (1B 30) set ok
<ESC> A (1B 41) set fail
Description: This command is used to set how many leading zeros will be written before the card data starts, and
the space should calculated as [leading zero] X25.4 / BPI (75or210) =mm
Default setting of leading zero: [3D] [16]
TK1 & TK3: [3D] means leading zero=61
TK2: [16] means leading zero=22
13. Command: Check leading zero
Command code: <ESC> l
Hex code: 1B 6C
Response: 1B [00~ff] [00~ff]
Description: This command is used to ask MSR605 the present setting number of leading zeros.
14. Command: Erase card
Command code: <ESC> c [Select Byte]
Hex code: 1B 63 [Select Byte]
Response: <ESC> 0 [1B] [30] command Select Byte ok
<ESC> A [1B] [41] command Select Byte fail
Description: This command is used to erase the card data when card swipe.
*[Select Byte] format:
00000000: Track 1 only
00000010: Track 2 only
00000100: Track 3 only
00000011: Track 1 & 2
00000101: Track 1 & 3
00000110: Track 2 & 3
00000111: Track 1, 2 & 3
15. Command: Select BPI
Command code: <ESC> b [Density]
Hex code:
track2：1B 62 [D2 or 4B] // [D2]: 210bpi, [4B]: 75bpi
track1：1B 62 [A1 or A0] // [A1]: 210bpi, [A0]: 75bpi
track3：1B 62 [C1 or C0] // [C1]:210bpi, [C0]: 75bpi
Response: <ESC> 0 [1B] [30] select ok
<ESC> A [1B] [41] select fail
Description: This command is used to select the density
8
MSR605 Programmer’s Manual Rev. A
16. Command: Read raw data
Command code: <ESC> m
Hex code: 1B 6D
Response: [Raw Data Block] <ESC> [Status Byte]
Description: This command requests MSR605 to read a card swipe but send without ASCII decode.
Refer to [Raw Data Block] & [Raw Data] format.
17. Command: Write raw data
Command code: <ESC> n [Raw Data Block]
Hex code: 1B 6E [Raw Data Block]
Response: <ESC> [Status Byte]
Description: This command requests MSR605 to write raw Data Block into the card swiped.
Refer to [Raw Data Block] & [Raw Data] format.
18. Command: Get device model
Command code: <ESC> t
Hex code: 1B 74
Response: <ESC> [Model] S
Description: This command is used to get the model of MSR605.
19. Command: Get firmware version
Command code: <ESC> v
Hex code: <ESC> 76
Response: <ESC> [version]
Description: This command can get the firmware version of MSR605.
20. Command: Set BPC
Command code: <ESC> o [tk1bit][tk2bit][tk3bit]
Hex code: <ESC> 6F [05-08][05-08][05-08]
Response: <ESC> 30 [tk1bit][tk2bit][tk3bit]
Description: This command is used to set the bit per character of every track.
21. Command: Set Hi-Co
Command code: <ESC> x
Hex code: 1B 78
Response: <ESC> 0
Description: This command is used to set MSR605 status to write Hi-Co card.
22. Command: Set Low-Co
Command code: <ESC> y
Hex code: 1B 79
9
MSR605 Programmer’s Manual Rev. A
10
Response: <ESC> 0
Description: This command is used to set MSR605 status to write Low-Co card.
23. Command: Get Hi-Co or Low-Co status
Command code: <ESC> d
Hex code: 1B 64
Response: <ESC> H -------to write Hi-Co
: <ESC> L ------- to write Low-Co
Description: This command is to get MSR605 write status.
MSR605 Programmer’s Manual Rev. A
Section 7 Data Format
* [Data Block] format:
Start Field R/W Data Field Ending Field
Command code <ESC> s [Card data] ? <FS> <ESC> [Status]
Hex code 1B 73 [Card data] 3F 1C 1B [Status]
* [Card data] format:
Card Data
Char Code <ESC> 1[string1] <ESC> 2 [string2] <ESC> 3 [string3]
Hex Code 1B 01 [string1] 1B 02 [string2] 1B 03 [string3]
* [Status Byte] format:
Status description HEX ASCII
Ok If read, write or command ok 30h 0
Write or read error 31h 1
Command format error 32h 2
Error
Invalid command 34h 4
Invalid card swipe when in write mode 39h 9
* Note:
1. When [Status Byte] equal 39h means card moving error.
2. None available and none data tracks will not be transmitted when swipe of card.
For example, when read card with data encoded on track 2 only for MSR605, it will transmit data like 1B 73 1B 01
1B 02 [string] 3F 1C, for no data on track 1 so it shown 1B 01 only.
* [Raw Data Block] format:
Start Field R/W Data Field Ending Field
Command code <ESC> s [Raw data] ? <FS> <ESC> [Status]
Hex code 1B 73 [Raw data] 3F 1C 1B [Status]
* [Raw Data] format:
Raw Data
Char Code <ESC>1[L1][string1]<ESC>2[L2][string2]<ESC>3[L3][string3]
Hex Code 1B 01[L1][string1]1B 02[L2][string2]1B 03[L3][string3]
Note:
1. [L1], [L2], [L3] is the length of [string1],[string2],and [string3]
2. None available and none data tracks will not output when swipe of card.
For example, when read card (encoded data on track 2 only) on MSR605, it will transmit data like 1B 73 1B 01 00
1B 02 [L2] [string] 3F 1C.
11
MSR605 Programmer’s Manual Rev. A
* [Raw Data] bit orientation:
Track 1 for 8 BPC
Read
1B0 1B1 1B2 1B3 1B4 1B5 1B6 2B0 2B1 2B2
2B3
2B4
2B5
2B6
3B0
3B1
3B2
3B3
3B4
3B5 3B6 4B0 4B1 4B2
…
Write
2B0 1B6 1B5 1B4 1B3 1B2 1B1 1B0 3B1 3B0
2B6
2B5
2B4
2B3
2B2
2B1
4B2
4B1
4B0
3B6 3B5 3B4 3B3 3B2
…
Track 2 & 3 for 8 BPC
Read
1B0 1B1 1B2 1B3 1B4 2B0 2B1 2B2 2B3 2B4
3B0
3B1
3B2
3B3
3B4
4B0
4B1
4B2
4B3
4B4 5B0 5B1 5B2 5B3
…
Write
2B2 2B1 2B0 1B4 1B3 1B2 1B1 1B0 4B0 3B4
3B3
3B2
3B1
3B0
2B4
2B3
5B3
5B2
5B1
5B0 4B4 4B3 4B2 4B1
…
MSB LSB MSB LSB MSB LSB
1
st byte 2
nd byte 3
rd byte
*Refer to Section 9 ADDENDUM.
12
MSR605 Programmer’s Manual Rev. A
Section 8 Communication Sequence
The examples below assumes data on track1, 2 & 3 to be 01, 23, 45 respectively.
¾ MSR605 INITIALIZATION
HOST Direction MSR605
Command code: <ESC>a
HEX code: [1B][61]
(Reset)
Command code: <ESC>e
HEX code: [1B][65]
(Serial port test)
Command test ACK: <ESC> y
HEX code: [1B][79]
Command code: <ESC>a
HEX code: [1B][61]
(Reset)
¾ Write Data to MSR605
HOST Direction MSR605
Command code:
<ESC>w<ESC>s<ESC>[01]01
<ESC>[02]23<ESC>[03]45?<FS>
HEX code:
[1B][77][1B][73][1B][01][30][31][1B]
[02][32][33][1B][03][34][35][3F][1C]
(write command)
(status ACK)
(Wait until swipe card)
Command ACK: <ESC> <status>
HEX code: [1B][status]
Status =[30] no error
Status =[31]~[3F] if error
13
MSR605 Programmer’s Manual Rev. A
¾ Read Data to MSR605
HOST Direction MSR605
Command code: <ESC> r
HEX code: [1B][72]
(read command)
(Wait until swipe card)
Command ACK:
<ESC>s<ESC>[01]%01?<ESC>[02];23?<ESC>[03];45??<
FS><ESC><status>
HEX code:
(status ACK)
[1B][73][1B][01][25][30][31][3F][1B][02][3B][32][33][3F]
[1B][03][3B][34][35][3F][3F][1C][1B][status]
Status=[30] ok
Status=[31]~[3F] if error
* [XX] = HEX Code XX
14
MSR605 Programmer’s Manual Rev. A
Section 9 Addendum
¾ Write Data to Magnetic Card
The WRITE command:
Command WRITE
<ESC> w [Data Block] Command code
Hex code 1B 77 [Data Block]
Response <ESC> [Status Byte]
Description This command request MSR605 to write the Data Block into the card swiped.
[Data Block] format:
Start Field R/W Data Field Ending Field
Command code <ESC>s [card data] ?<FS>
HEX code 1B 73 [card data] 3F 1C
[card data] format:
card data
Char. code <ESC>[01] [string] <ESC> [02] [string] <ESC> [03] [string3]
HEX code 1B 01 [string1] 1B 02 [string2] 1B 03 [string3]
As an example the following information will be written to the card:
Track1: %ABC123?
Track2: ;12345?
Track3: ;12345?
HOST DIRECTION MSR605
Command code:
<esc>w<ESC>s<ESC>[01]ABC123<ESC>
[02]12345<ESC>[03]12345?<FS>
HEX code:
[1B][77][1B][73][1B][01][41][42][43][31][
32][33][1B][02][31][32][33][34][35][1B][0
3][31][32][33][34][35][3F][1C]
(write command)
After send command to MSR605 Yellow LED on, then swipe
card write data to the magnetic card
(status ACK)
(wait until swipe card)
Command ACK: <ESC><status>
HEX code: [1B][status]
Status = [30] no error
Status = [31] ~ [3F] if error
15
MSR605 Programmer’s Manual Rev. A
¾ Write Raw Data to Magnetic Card
Converting Card Data Information to Hexadecimal for the Binary Write Function
Converting track one ASCll information into HEX
B5 0 0 1 1
B3 B2 B1 B0 B4 0 1 0 1
0 0 0 0 0 (sp) 0 @ P
1 0 0 0 1 ! 1 A Q
2 0 0 1 0 “ 2 B R
3 0 0 1 1 # 3 C S
4 0 1 0 0 $ 4 D T
5 0 1 0 1 % 5 E U
6 0 1 1 0 & 6 F V
7 0 1 1 1 ‘ 7 G W
8 1 0 0 0 ( 8 H X
9 1 0 0 1 ) 9 I Y
A 1 0 1 0 * : J Z
B 1 0 1 1 + ; K [
C 1 1 0 0 ` < L \
D 1 1 0 1 , = M ]
E 1 1 1 0 . > N ^
F 1 1 1 1 / ? O _
Converting track two and three ASCll information into HEX
Data p B3 B2 B1 B0
0 1 0 0 0 0
1 0 0 0 0 1
2 0 0 0 1 0
3 1 0 0 1 1
4 0 0 1 0 0
5 1 0 1 0 1
6 1 0 1 1 0
7 0 0 1 1 1
8 0 1 0 0 0
9 1 1 0 0 1
: 1 1 0 1 0
; (*) 0 1 0 1 1
< 1 1 1 0 0
= 0 1 1 0 1
> 0 1 1 1 0
? (*) 1 1 1 1 1
* Note: The “;” is start sentinel and “?” is end sentinel of tk2 & 3 of ISO format.
16
MSR605 Programmer’s Manual Rev. A
As an example the following information will be written to the card:
Track1: %ABC123?
Track2: ;12345?
Track3: ;12345?
We use three different data bits to write raw data on the cards. The procedures are listed as below:
08, 08, 08 BITS
Set each track as 08.
First of all, set BPC command:
1B, 6F, 08, 08, 08
Present the information to the card encoder, as follows:
Start Field 1B6E1B73
Track1 header 1B01
Length 08
Track1 data C5B07814954E3E2A
Track header 1B02
Length 05
Track2 data 2B8849EAAF
Track3 header 1B03
Length 05
Track3 data 2B8849EAAF
Ending Field 3F1C
Transfer the track1 data to HEX under 08 bits:
B0 B1 B2 B3 B4 B5 P
% 1 0 1 0 0 0 1
A 1 0 0 0 0 1 1
B 0 1 0 0 0 1 1
C 1 1 0 0 0 1 0
1 1 0 0 0 1 0 1
2 0 1 0 0 1 0 1
3 1 1 0 0 1 0 0
? 1 1 1 1 1 0 0
LRC 0 1 0 1 0 1 0
Calculate Odd Parity (P column)
If there is an Even Number of 1’s in the row of data for each character, put a 1 in the P column. Other wise, put a 0 in
the column.
17
MSR605 Programmer’s Manual Rev. A
LRC: If there is an Even Number of 1’s in the column of data for each character, put a 0 in the LRC row. Other wise,
put a 0 in the row. The last LRC will be considered as the parity rule of this row.
B0 B1 B2 B3 B4 B5 B6 B7
1 0 1 0 0 0 1 1
0 0 0 0 1 1 0 1
0 0 0 1 1 1 1 0
0 0 1 0 1 0 0 0
1 0 1 0 1 0 0 1
0 1 1 1 0 0 1 0
0 1 1 1 1 1 0 0
0 1 0 1 0 1 0 0
B7 B6 B5 B4 B3 B2 B1 B0 HEX
1 1 0 0 0 1 0 1 C5
1 0 1 1 0 0 0 0 B0
0 1 1 1 1 0 0 0 78
0 0 0 1 0 1 0 0 14
1 0 0 1 0 1 0 1 95
0 1 0 0 1 1 1 0 4E
0 0 1 1 1 1 1 0 3E
0 0 1 0 1 0 1 0 2A
Transfer track 2 (track 3) data to HEX under 08 bits:
B0 B1 B2 B3 P
; 1 1 0 1 0
1 1 0 0 0 0
2 0 1 0 0 0
3 1 1 0 0 1
4 0 0 1 0 0
5 1 0 1 0 1
? 1 1 1 1 1
LRC 1 0 1 0 1
B0 B1 B2 B3 B4 B5 B6 B7
1 1 0 1 0 1 0 0
0 0 0 1 0 0 0 1
1 0 0 1 0 0 1 0
0 1 0 1 0 1 1 1
1 1 1 1 0 1 0 1
18
MSR605 Programmer’s Manual Rev. A
B7 B6 B5 B4 B3 B2 B1 B0 HEX
0 0 1 0 1 0 1 1 2B
1 0 0 0 1 0 0 0 88
0 1 0 0 1 0 0 1 49
1 1 1 0 1 0 1 0 EA
1 0 1 0 1 1 1 1 AF
07, 05, 05 BITS
Set TK1, TK2 & TK3 as 07, 05, 05
1B, 6F, 07, 05, 05
First of all, set BPI command:
Present the information to the card encoder, as follows:
Start Field 1B6E1B73
Track1 header 1B01
Length 09
Track1 data 456162235152131F2A
Track2 header 1B02
Length 08
Track2 data 0B01021304151F15
Track3 header 1B03
Length 08
Track3 data 0B01021304151F15
Ending Field 3F1C
Transfer the track1 data to HEX under 07 bits:
B0 B1 B2 B3 B4 B5 P
% 1 0 1 0 0 0 1
A 1 0 0 0 0 1 1
B 0 1 0 0 0 1 1
C 1 1 0 0 0 1 0
1 1 0 0 0 1 0 1
2 0 1 0 0 1 0 1
3 1 1 0 0 1 0 0
? 1 1 1 1 1 0 0
LRC 0 1 0 1 0 1 0
Calculate Odd Parity (P column)
If there is an Even Number of 1’s in the row of data for each character, put a 1 in the P column. Other wise, put a 0 in
19
MSR605 Programmer’s Manual Rev. A
the column.
Add P B5 B4 B3 B2 B1 B0 HEX
% 0 1 0 0 0 1 0 1 45
A 0 1 1 0 0 0 0 1 61
B 0 1 1 0 0 0 1 0 62
C 0 0 1 0 0 0 1 1 23
1 0 1 0 1 0 0 0 1 51
2 0 1 0 1 0 0 1 0 52
3 0 0 0 1 0 0 1 1 13
? 0 0 0 1 1 1 1 1 1F
LRC 0 0 1 0 1 0 1 0 2A
HEX
B3 B2 B1 B0
0 0 0 0 0
1 0 0 0 1
2 0 0 1 0
3 0 0 1 1
4 0 1 0 0
5 0 1 0 1
6 0 1 1 0
7 0 1 1 1
8 1 0 0 0
9 1 0 0 1
A 1 0 1 0
B 1 0 1 1
C 1 1 0 0
D 1 1 0 1
E 1 1 1 0
F 1 1 1 1
Transfer track 2 (track 3) data to HEX under 05 bits:
B0 B1 B2 B3 P
; 1 1 0 1 0
1 1 0 0 0 0
2 0 1 0 0 0
3 1 1 0 0 1
4 0 0 1 0 0
5 1 0 1 0 1
? 1 1 1 1 1
LRC 1 0 1 0 1
20
MSR605 Programmer’s Manual Rev. A
Add 0 Add 0 Add 0 P B3 B2 B1 B0 HEX
; 0 0 0 0 1 0 1 1 0B
1 0 0 0 0 0 0 0 1 01
2 0 0 0 0 0 0 1 0 02
3 0 0 0 1 0 0 1 1 13
4 0 0 0 0 0 1 0 0 04
5 0 0 0 1 0 1 0 1 15
? 0 0 0 1 1 1 1 1 1F
LRC 0 0 0 1 0 1 0 1 15
06, 05, 06 BITS
Set TK1, TK2 & TK3 as 06, 05, 06
First of all, set BPI command:
1b, 6F, 06, 05, 06
Present the information to the card encoder, as follows:
Start Field 1B6E1B73
Track1 header 1B01
Length 09
Track1 data 052122231112131F2A
Track2 header 1B02
Length 08
Track2 data 0B01021304151F15
Track3 header 1B03
Length 08
Track3 data 0101020304051F1F
Ending Field 3F1C
Transfer track1 data to HEX under 06 bits:
B0 B1 B2 B3 B4 B5
% 1 0 1 0 0 0
A 1 0 0 0 0 1
B 0 1 0 0 0 1
C 1 1 0 0 0 1
1 1 0 0 0 1 0
2 0 1 0 0 1 0
3 1 1 0 0 1 0
? 1 1 1 1 1 0
LRC 0 1 0 1 0 1
21
MSR605 Programmer’s Manual Rev. A
22
Add 0 Add 0 B5 B4 B3 B2 B1 B0 HEX
% 0 0 0 0 0 1 0 1 05
A 0 0 1 0 0 0 0 1 21
B 0 0 1 0 0 0 1 0 22
C 0 0 1 0 0 0 1 1 23
1 0 0 0 1 0 0 0 1 11
2 0 0 0 1 0 0 1 0 12
3 0 0 0 1 0 0 1 1 13
? 0 0 0 1 1 1 1 1 1F
LRC 0 0 1 0 1 0 1 0 2A
Transfer track 2 data to HEX under 05 bits:
B0 B1 B2 B3 P
; 1 1 0 1 0
1 1 0 0 0 0
2 0 1 0 0 0
3 1 1 0 0 1
4 0 0 1 0 0
5 1 0 1 0 1
? 1 1 1 1 1
LRC 1 0 1 0 1
Add 0 Add 0 Add 0 P B3 B2 B1 B0 HEX
; 0 0 0 0 1 0 1 1 0B
1 0 0 0 0 0 0 0 1 01
2 0 0 0 0 0 0 1 0 02
3 0 0 0 1 0 0 1 1 13
4 0 0 0 0 0 1 0 0 04
5 0 0 0 1 0 1 0 1 15
? 0 0 0 1 1 1 1 1 1F
LRC 0 0 0 1 0 1 0 1 15
MSR605 Programmer’s Manual Rev. A
Transfer track 3 data to HEX under 06 bits:
B0 B1 B2 B3 B4 B5
! 1 0 0 0 0 0
1 1 0 0 0 0 0
2 0 1 0 0 0 0
3 1 1 0 0 0 0
4 0 0 1 0 0 0
5 1 0 1 0 0 0
? 1 1 1 1 1 0
LRC 1 1 1 1 1 0
Add 0 Add 0 B5 B4 B3 B2 B1 B0 HEX
! 0 0 0 0 0 0 0 1 01
1 0 0 0 0 0 0 0 1 01
2 0 0 0 0 0 0 1 0 02
3 0 0 0 0 0 0 1 1 03
4 0 0 0 0 0 1 0 0 04
5 0 0 0 0 0 1 0 1 05
? 0 0 0 1 1 1 1 1 1F
LRC 0 0 0 1 1 1 1 1 1F
23
MSR605 Programmer’s Manual Rev. A
24

Navigation menu
