SHARP CORPORATION This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

qPARTS GUIDE

本書はサービス活動用に作成した資料です｡

一部内容が製品の改良・改善等により予告

なしに変わることがあります。

CODE:00ZMX2700NP4/

デジタルフルカラー複合機

デジタルフルカラー複合機デジタルフルカラー複合機

デジタルフルカラー複合機

Digital Full Color Multifunction System

MX-2300G/MX-2300FG

MX-2700G/MX-2700FG

MODEL MX-2300N/MX-2700N

このパーツガイドに掲載されている表示価格ランクは消費税抜きです。

CONTENTS

1 AC 基板 (AC PWB)

2 HL 基板 (HL PWB)

3 PCU 基板 (PCU PWB)

4 MFP ｺﾝﾄﾛｰﾙ基板 (MFP control PWB)

5 MFP OPE 基板 (MFP OPE PWB)

6 ﾄﾞﾗｲﾊﾞｰﾒｲﾝ基板 (Driver Main PWB)

7 ﾄﾞﾗｲﾊﾞｰｻﾌﾞ基板 (Driver Sub PWB)

8 ｽｷｬﾅｰｺﾝﾄﾛｰﾙ基板 (Scanner control PWB)

9 ｽｷｬﾝｲﾝ基板 (Scan in PWB)

F ﾏｻﾞｰ基板 (Mother PWB)

G LVDS 基板 (LVDS PWB)

H LSU ｺﾝﾄﾛｰﾙ基板 (LSU control PWB)

I FAX ﾒｲﾝ基板 (FAX main PWB)

J LIU 基板 (LIU PWB)...(for MX-FLX1)

K LIU 基板 (LIU PWB)...(for MX-FXX1 Japan)

L LIU 基板 (LIU PWB)...(for MX-FXX1 U.S.A,Canada)

M LIU 基板 (LIU PWB)...(for MX-FXX1 Europe,Oceania)

N RSPF ﾄﾞﾗｲﾊﾞｰ基板 (RSPF driver PWB)...(for MX-RPX1)

■索引 (Index)

MODEL

MX-2300G/MX-2300FG

MX-2700G/MX-2700FG

MX-2300N/MX-2700N

[Option]

MX-FLX1/MX-FXX1

MX-RPX1

Digital Full Color Multifunction System

< PWB Section >

– 1 –

補修部品のランク付

市場における補修部品の在庫管理が、適正に運営出来る手助けとなることを、目的とします。

Aランク :メンテナンスパーツ、メンテナンスパーツには入っていないがメンテナンスパーツに近い消耗パーツ。

Bランク :性能・機能パーツ（センサー、クラッチ等の電気パーツ）、消耗パーツ。

Eランク :基板含むユニットパーツ。

Dランク :整備パーツ（外装、パッキング、同梱パーツ）。

Cランク :上記ランク以外のパーツ（基板の子部品を除いたもの）。

DEFINITION

Rank A : Maintenance parts, and consumable parts which are not included in but closely related to maintenance parts

Rank B : Performance/function parts (sensors, clutches, and other electrical parts), consumable parts

Rank E : Unit parts including PWB

Rank D : Preparation parts (External fitting, packing, parts packed together)

Rank C : Parts other than the above (excluding sub components of PWB)

安全性・信頼性確保のため部品は、必ず正規のものをご使用下さい。

!印の商品は、安全上重要な部品です。交換をする時は、安全及び性能維持のため必ず指定の部品をご使用下さい。

Because parts marked with "!" is indispensable for the machine safety maintenance and operation, it must be replaced with

the parts specific to the product specification.

F当モデルのサービス資料には、この資料以外にサービスマニュアル (回路図含む )があります。合わせてご利用下さい。

FOther than this Parts Guide, please refer to documents Service Manual(including Circuit Diagram)of this model.

FPlease use the 13 digit code described in the right hand corner of front cover of the document, when you place an order.

FFor U.S. only-Use order codes provided in advertising literature. Do not order from parts department.

1AC 基板 (AC PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

!1QFS-A2700QCZZ AD DJ A Fuse(J20/125NR) (Japan)[F1,F2] ﾋｭｰｽﾞ

!2QFS-B3631QCPZ AH DS A Fuse(15A 250V) (100V Series except Japan)[F1] ﾋｭｰｽﾞ

!3QFS-D1421QCPZ AE DJ A Fuse(T10A H250V) (200V Series)[F1,F2] ﾋｭｰｽﾞ

4QFSHD0026FCZZ AC DJ C Fuse holder(TP00335-31) (Japan)[F1,F2] ﾋｭｰｽﾞﾎﾙﾀﾞｰ

QFSHD0026FCZZ AC DJ C Fuse holder(TP00335-31) (100V Series except Japan)[F2] ﾋｭｰｽﾞﾎﾙﾀﾞｰ

QFSHB0028FCZZ AC DJ C Fuse holder(TP00351-31) (Japan)[F1,F2] ﾋｭｰｽﾞﾎﾙﾀﾞｰ

QFSHB0028FCZZ AC DJ C Fuse holder(TP00351-31) (100V Series except Japan)[F4] ﾋｭｰｽﾞﾎﾙﾀﾞｰ

QFSHB0028FCZZ AC DJ C Fuse holder(TP00351-31) (200V Series)[F1,F2,F3,F4] ﾋｭｰｽﾞﾎﾙﾀﾞｰ

6QTANP0210FCPZ AC DJ N C Earth terminal(TP00451-21) [FG2] ｱｰｽﾀﾐﾅﾙ

!7QFS-E1311QCPZ AD DJ N A Fuse(T2.0AH250V) (100V Series except Japan)[F3] ﾋｭｰｽﾞ

!QFS-E1311QCPZ AD DJ N A Fuse(T2.0AH250V) (Japan,200V Series)[F3,F4] ﾋｭｰｽﾞ

8QSPGC0001FCZZ AK DX C Surge absorber(2700V) (Except 200V Series)[A3] ｻｰｼｱﾌﾞｿｰﾊﾞｰ

10 VHV10V471K+-1 AD DJ B Varistor(10V471K) [VR3] ﾊﾞﾘｽﾀｰ

12 RC-KZ0017QCZZ AE DJ C Capacitor(250WV 4700pF) [C2,C3] ｺﾝﾃﾞﾝｻｰ

15 VRD-HT2HY474J AA DD C Resistor(1/2W 470KΩ ±5%) [R1] ﾃｲｺｳ

17 QCNCM1234FCPZ AF DS N C Connector(B03P-VL-K) [CN2] ｺﾈｸﾀｰ

19 QCNCM1232FCPZ AC DJ N C Connector(B2P4-VH-B) [CN4] ｺﾈｸﾀｰ

20 QCNCM1235FCPZ AF DS N C Connector(B03P-VL-E) [CN5] ｺﾈｸﾀｰ

21 QCNCM0843FCPZ AC DJ N C Connector(B2P3-VH-R) [CN6] ｺﾈｸﾀｰ

23 QCNCM0042ESPZ AB DJ C Connector(B3B-PH-K-S) [CN9] ｺﾈｸﾀｰ

24 QCNCM0168QSPZ AB DJ N C Connector(B4B-PH-K-S) [CN10] ｺﾈｸﾀｰ

25 RRLYD1391QCPZ AP EQ N B Relay(G2RG-2A4) [RY1] ﾘﾚｰ

26 VHD1SS133++-1 AA DJ B Diode(1SS133) [D1] ﾀﾞｲｵｰﾄﾞ

27 VHDDSM1D1//-1 AB DJ B Diode(DSM1D1) [D2] ﾀﾞｲｵｰﾄﾞ

28 VRD-HT2EY242J AA DD C Resistor(1/4W 2.4KΩ ±5%) [R2,R3] ﾃｲｺｳ

30 VS2SJ494+++-1 AL EB B Transistor(2SJ494) [Q1] ﾄﾗﾝｼﾞｽﾀｰ

(Unit)

901

CPWBF1663FC31 BD GN E AC PWB (Japan) AC 基板

CPWBF1664FC31 BF GN E AC PWB (100V Series except Japan) AC 基板

CPWBF1665FC31 BE GN E AC PWB (200V Series) AC 基板

– 2 –

2HL 基板 (HL PWB)

3PCU 基板 (PCU PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1RRLYD1192QCPZ AQ EQ N B Relay(250V/16A) [RY1] ﾘﾚｰ

2VHD1SS133++-1 AA DJ B Diode(1SS133) [D1] ﾀﾞｲｵｰﾄﾞ

3VS2SC1815-GRC AB DD B Transistor(2SC1815-GRC) [Q1] ﾄﾗﾝｼﾞｽﾀｰ

5VRS-HT2HA101J AA DD C Resistor(1/2W 100Ω ±5%) [R3,R5,R7] ﾃｲｺｳ

6VRS-HT2HA121J AA DD C Resistor(1/2W 120Ω ±5%) [R9,R10,R11] ﾃｲｺｳ

7VRS-HT2HA181J AA DD C Resistor(1/2W 180Ω ±5%) (100V Series)[R4,R6,R8] ﾃｲｺｳ

10 VHRF11YVZBF-1 AG DX N B Photo triac(PC3SF11YVZBF) [SSR1,SSR2,SSR3] ﾌｫﾄﾄﾗｲｱｯｸ

15 VRD-HT2EY362J AA DD C Resistor(1/4W 3.6KΩ ±5%) [R1] ﾃｲｺｳ

16 VRD-HT2EY101J AA DD C Resistor(1/4W 100Ω ±5%) [R2] ﾃｲｺｳ

17 PRDAR0057FCZ1 AS EZ C Heat sink(TMA16*S-L-LF625) [TD2] ﾋｰﾄｼﾝｸ

19 XBPS730P10K00 AB DD C Screw(3×10K) [TD1,TD2,TD3] ﾋﾞｽ

21 QCNCM1234FCPZ AF DS N C Connector(B03P-VL-K) [CN2] ｺﾈｸﾀｰ

23 QCNCM0170QSPZ AC DJ N C Connector(B6B-PH-K-S) [CN4] ｺﾈｸﾀｰ

24 RCILF0120FCPZ AK EB N C Coil(100µH/13A) [L2] ｺｲﾙ

RCILF0120FCPZ AK EB N C Coil(100µH/13A) (100V Series)[L1] ｺｲﾙ

(Unit)

901 CPWBF1666FC31 BG GT E HL PWB (100V Series) HL 基板

CPWBF1667FC31 BH GX E HL PWB (200V Series) HL 基板

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1QCNCM0923FC10 AE DJ C Connector(10pin) [CN5] ｺﾈｸﾀｰ

2QCNCM0923FC24 AF DS C Connector(24pin) [CN6] ｺﾈｸﾀｰ

3QCNCM0879FCZZ AF DS C Connector(28Pin) [CN23] ｺﾈｸﾀｰ

4QCNCM0880FCZZ AF DS C Connector(26pin) [CN21] ｺﾈｸﾀｰ

5QCNCM0878FCZZ AF DS C Connector(30pin) [CN9] ｺﾈｸﾀｰ

6QCNCM0923FC32 AG DS C Connector(32pin) [CN12,CN17,CN26,CN13] ｺﾈｸﾀｰ

8QCNCW0864FCZZ AG DX C Connector(12pin) [CN3] ｺﾈｸﾀｰ

9QCNCM7014SC0C AA DD C Connector(3pin) [CN16] ｺﾈｸﾀｰ

10 QCNCM7014SC0E AB DJ C Connector(5pin) [CN10] ｺﾈｸﾀｰ

11 QCNCM0068QSZZ AL EB C Connector(40pin) [CN15,CN34] ｺﾈｸﾀｰ

12 QCNCW1170FCZZ AG DS C Connector(28pin) [CN7] ｺﾈｸﾀｰ

14 QSOCZ0002QSPZ AC DJ C Socket(MY02-0830-2L) [for IC6] ｿｹｯﾄ

15 QSOCZ0094FCPZ AL EG C Socket(DMM2-SD72AR-1131-F) [CN1] ｿｹｯﾄ

17 VHI658920130C AQ EQ N B IC(uPD65892GC-013-8EU) [IC8] IC

18 RH-IX7001XCPZ AR EQ B IC(IS63LV1024L-12J-TR) [IC5] IC

20 VHITD62064AF/ AM EG B IC(TD62064AF) [IC53] IC

21 VHILM358DR+-1 AF DS B IC(LM358D) [IC69,IC70] IC

23 VHILM324D++-1 AE DJ B IC(LM324D) [IC63,IC65,IC72,IC64] IC

24 VHIC24FC64L-1 AL EB N B IC(CAT24FC64LI) [IC6] IC

26 VHILM393D++-1 AE DJ B IC(LM393D) [IC62] IC

27 VHILM339D++-1 AE DJ B IC(LM339D) [IC40,IC61,IC67,IC66] IC

28 VHITA7291AS-1 AF DX B IC(TA7291S) [IC54,IC55,IC56,IC58,IC59] IC

29 VHID65503F+-1 AG DS B IC(D65503F) [IC12,IC39,IC41,IC42,IC43] IC

VHID65503F+-1 AG DS B IC(D65503F) [IC45,IC48] IC

30 VHID65001AF-1 AG DS B IC(D65001AF) [IC46,IC47,IC52] IC

31 VHIMK5811SF-1 AK EB N B IC(MK5811SLFTR) [IC2] IC

33 VHI74LVC14A-1 AE DS B IC(SN74LVC14A) [IC3,IC29] IC

34 VHILVC574AP-1 AL EB B IC(SN74LVC574APWR) [IC7] IC

43 VSTPC6004F+-1 AE DS B Transistor(TPC6004) [IC60] ﾄﾗﾝｼﾞｽﾀｰ

45 RCRSP0016QSZZ AD DJ B Crystal(19.6608MHz) [X1] ｸﾘｽﾀﾙ

!46 QFS-L0001QSZZ AD DJ A Fuse(TR/SG0603FA1.0-T) [F4,F3,F5,F7,F1] ﾋｭｰｽﾞ

!QFS-L0001QSZZ AD DJ A Fuse(TR/SG0603FA1.0-T) [F2,F11,F12,F14,F16] ﾋｭｰｽﾞ

!47 QFS-L0002QSZZ AD DD A Fuse(TR/SG0603FA1.5-T) [F10] ﾋｭｰｽﾞ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR1,BR2,BR3,BR5,BR6] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR8,BR9,BR10,BR11,BR13] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR21,BR24,BR25,BR26,BR27] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR28,BR29,BR30,BR31,BR32] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR33,BR34,BR35,BR43,BR44] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR51,BR62,BR63,BR64,BR67] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR68,BR69,BR70,BR71,BR72] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR73,BR79,BR77,BR78] ﾌﾞﾛｯｸﾃｲｺｳ

49 RMPTR4000ACZZ AB DD B Block resistor(0Ω×4) [BR45,BR46] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR12,BR14,BR15,BR16,BR17] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR18,BR19,BR20,BR22,BR23] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR36,BR37,BR38,BR39,BR40] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR41,BR42,BR47,BR49,BR74] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR75,BR76] ﾌﾞﾛｯｸﾃｲｺｳ

52 RMPTR4472ACZZ AB DD B Block resistor(4.7KΩ×4) [BR52,BR53,BR54] ﾌﾞﾛｯｸﾃｲｺｳ

53 RMPTR4102ACZZ AB DD B Block resistor(1KΩ×4) [BR48] ﾌﾞﾛｯｸﾃｲｺｳ

54 VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R129,R132,R135,R136,R137] ﾃｲｺｳ

VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R582,R106] ﾃｲｺｳ

55 VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R41,R59,R103,R112,R115] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R117,R124,R128,R143,R145] ﾃｲｺｳ

– 3 –

3PCU 基板 (PCU PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R157,R158,R166,R169,R171] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R217,R226,R235,R238,R239] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R248,R258,R265,R274,R296] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R297,R298,R299,R300,R301] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R302,R303,R305,R306,R307] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R308,R309,R310,R318,R319] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R328,R329,R330,R331,R332] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R333,R335,R336,R337,R338] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R340,R354,R355,R356,R357] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R358,R359,R361,R363,R365] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R367,R368,R380,R381,R382] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R383,R384,R385,R386,R387] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R399,R400,R401,R402,R403] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R404,R405,R406,R413,R414] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R415,R416,R417,R418,R419] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R420,R424,R428,R429,R438] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R442,R458,R460,R474,R489] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R493,R512,R577,R596,R597] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R598,R599,R636] ﾃｲｺｳ

56 VRS-CZ1JD203J AA DD C Resistor(1/16W 20KΩ ±5%) [R192,R193,R195,R196,R369] ﾃｲｺｳ

VRS-CZ1JD203J AA DD C Resistor(1/16W 20KΩ ±5%) [R388,R100,R350] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R15,R22,R23,R237,R352] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R353,R360,R362,R378,R389] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R573,R579,R592,R3,R459] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R603,R240,R40] ﾃｲｺｳ

58 VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R20,R27] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R163,R180,R181,R182,R183] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R184,R185,R186,R187,R188] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R189,R433,R439,R441,R444] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R462,R469,R476,R511,R513] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R528,R529,R530,R533,R541] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R542,R544,R548,R549,R553] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R556,R562,R580,R594,R612] ﾃｲｺｳ

60 VRS-CZ1JD201J AA DD C Resistor(1/16W 200Ω ±5%) [R24,R55,R538] ﾃｲｺｳ

61 VRS-CZ1JD102F AA DD C Resistor(1/16W 1KΩ ±1%) [R507] ﾃｲｺｳ

62 VRS-CZ1JD202F AA DD C Resistor(1/16W 2KΩ ±1%) [R431,R435,R465,R498,R500] ﾃｲｺｳ

VRS-CZ1JD202F AA DD C Resistor(1/16W 2KΩ ±1%) [R504,R557] ﾃｲｺｳ

63 VRS-CZ1JD332F AA DD C Resistor(1/16W 3.3KΩ ±1%) [R437,R450,R467,R480] ﾃｲｺｳ

VRS-CZ1JD103F AA DD C Resistor(1/16W 10KΩ ±1%) [R25,R34,R139,R452,R470] ﾃｲｺｳ

VRS-CZ1JD103F AA DD C Resistor(1/16W 10KΩ ±1%)

[R472,R481,R483,R484,R503,R521] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R4,R5,R7,R9,R10] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R13,R16,R35,R36,R43] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R45,R50,R51,R53,R54] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R63,R66,R68,R70,R71] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R73,R74,R78,R84,R85] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R86,R87,R88,R90,R96] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R101,R104,R110,R111,R116] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R130,R131,R134,R142,R147] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R148,R149,R150,R161,R162] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R165,R172,R173,R178,R179] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R201,R206,R209,R212,R214] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R234,R242,R243,R247,R252] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R253,R257,R261,R266,R268] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R276,R279,R280,R281,R282] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R283,R284,R285,R289,R290] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R291,R292,R295,R304,R314] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R315,R316,R344,R348,R349] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R351,R370,R371,R409,R410] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R411,R412,R446,R448,R478] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R515,R517,R519,R524,R526] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R527,R539,R572,R604,R637] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R649,R49,R334,R219] ﾃｲｺｳ

VRS-CZ1JD105J AA DD C Resistor(1/16W 1.0MΩ ±5%) [R232,R531,R534,R543,R545] ﾃｲｺｳ

VRS-CZ1JD105J AA DD C Resistor(1/16W 1.0MΩ ±5%)

[R559,R564,R569,R570,R151,R190] ﾃｲｺｳ

VRS-CZ1JD301J AA DD C Resistor(1/16W 300Ω ±5%) [R440,R468,R510,R547,R583] ﾃｲｺｳ

VRS-CZ1JD301J AA DD C Resistor(1/16W 300Ω ±5%) [R584,R585,R586,R587,R588] ﾃｲｺｳ

VRS-CZ1JD301J AA DD C Resistor(1/16W 300Ω ±5%) [R589,R590] ﾃｲｺｳ

68 VRS-CZ1JD391J AA DD C Resistor(1/16W 390Ω ±5%) [R537] ﾃｲｺｳ

69 VRS-CZ1JD332J AA DD C Resistor(1/16W 3.3KΩ ±5%) [R33,R99] ﾃｲｺｳ

70 VRS-CZ1JD152J AA DD C Resistor(1/16W 1.5KΩ ±5%) [R213,R215] ﾃｲｺｳ

71 VRS-CZ1JD162J AA DD C Resistor(1/16W 1.6KΩ ±5%) [R535] ﾃｲｺｳ

72 VRS-CZ1JD622J AA DD C Resistor(1/16W 6.2KΩ ±5%) [R546,R552,R554,R561] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R123,R191,R216,R220,R223] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R227,R228,R231,R249,R259] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R267,R275,R102,R97] ﾃｲｺｳ

74 VRS-CZ1JD104J AA DD C Resistor(1/16W 100KΩ ±5%)

[R98,R436,R449,R466,R479,R44] ﾃｲｺｳ

VRS-CZ1JD104J AA DD C Resistor(1/16W 100KΩ ±5%) [R39,R79,R89,R80] ﾃｲｺｳ

– 4 –

3PCU 基板 (PCU PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

75 VRS-CZ1JD821J AA DD C Resistor(1/16W 820Ω ±5%) [R536] ﾃｲｺｳ

76 VRS-CZ1JD122F AA DD C Resistor(1/16W 1.2KΩ ±1%) [R555] ﾃｲｺｳ

77 VRS-CZ1JD152F AA DD C Resistor(1/16W 1.5KΩ ±1%) [R164,R494,R495,R514,R523] ﾃｲｺｳ

78 VRS-CZ1JD113F AA DD C Resistor(1/16W 11KΩ ±1%) [R32] ﾃｲｺｳ

79 VRS-CZ1JD153F AB DD C Resistor(1/16W 15KΩ ±1%) [R502] ﾃｲｺｳ

80 VRSCZ1JD1912F AA DD C Resistor(1/16W 19.1KΩ ±1%) [R423,R427,R457,R488,R492] ﾃｲｺｳ

81 VRS-CZ1JD203F AA DD C Resistor(1/16W 20KΩ ±1%) [R471,R473,R482,R485] ﾃｲｺｳ

82 VRS-CZ1JD223F AA DD C Resistor(1/16W 22KΩ ±1%) [R578,R595] ﾃｲｺｳ

83 VRS-CZ1JD243F AA DD C Resistor(1/16W 24KΩ ±1%) [R425,R455,R486] ﾃｲｺｳ

84 VRS-CZ1JD473F AA DD C Resistor(1/16W 47KΩ ±1%) [R509] ﾃｲｺｳ

85 VRS-CZ1JD204F AA DD C Resistor(1/16W 200KΩ ±1%) [R434,R464,R497] ﾃｲｺｳ

91 VRS-CZ1JD304F AA DD C Resistor(1/16W 300KΩ ±1%) [R426,R456,R487] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R67,R75,R76,R94,R140,R105] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R141,R153,R154,R160,R167] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R168,R224,R230,R236,R244] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R246,R250,R260,R269,R273] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R286,R287,R288,R311,R312] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R313,R317,R372,R373,R374] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R375,R376,R377,R390,R391] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R392,R393,R394,R395,R396] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R397,R550,R551,R294,R200] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R210,R233,R241,R343,R293] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R347,R342,R341,R345,R346] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%)

[R320,R322,R323,R324,R325,R327] ﾃｲｺｳ

93 VRS-CZ1JD474J AA DD C Resistor(1/16W 470KΩ ±5%) [R159] ﾃｲｺｳ

94 VRS-CZ1JD272J AA DD C Resistor(1/16W 2.7KΩ ±5%) [R379,R398,R532] ﾃｲｺｳ

95 VRS-CZ1JD202J AA DD C Resistor(1/16W 2.0KΩ ±5%) [R1,R2] ﾃｲｺｳ

96 VRS-CZ1JD472F AA DD C Resistor(1/16W 4.7KΩ ±1%) [R508,R152] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R11,R12,R21,R29,R30] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R31,R38,R119,R120,R121] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R122,R125,R126,R138,R177] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R321,R558,R563,R568,R107] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R109,R108] ﾃｲｺｳ

98 VRS-CZ1JD621F AA DD C Resistor(1/16W 620Ω ±1%) [R447,R477,R516] ﾃｲｺｳ

100 VRS-CY1JD201J AA DD C Resistor(1/16W 200Ω ±5%) [R176,R77] ﾃｲｺｳ

101 VRS-TW2ED201J AA DD C Resistor(1/4W 200Ω ±5%) [R26,R28,R174,R175,R574,R575] ﾃｲｺｳ

103 VRS-TW2ED152J AC DD C Resistor(1/4W 1.5KΩ ±5%) [R454] ﾃｲｺｳ

104 VRS-TW2ED102J AA ZZ C Resistor(1/4W 1KΩ ±5%) [R198,R211] ﾃｲｺｳ

106 VRS-TW2ED472J AA DD C Resistor(1/4W 4.7KΩ ±5%) [R218,R221,R203,R204] ﾃｲｺｳ

107 VRS-TW2ED562J AB DD C Resistor(1/4W 5.6KΩ ±5%) [R408,R91] ﾃｲｺｳ

108 VRS-TW2ED103J AB DD C Resistor(1/4W 10KΩ ±5%) [R407] ﾃｲｺｳ

109 VRS-TX2HD560J AB DD C Resistor(1/2W 56Ω ±5%) [R245,R255,R264,R272] ﾃｲｺｳ

111 VCCCCZ1HH330J AA DD C Capacitor(50WV 33pF) [C15,C84,C85,C86,C100] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH330J AA DD C Capacitor(50WV 33pF) [C112,C113,C119,C125,C117] ｺﾝﾃﾞﾝｻｰ

112

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C64,C126,C128,C129,C131] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C132,C136,C137,C167,C168] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C169,C171,C172,C173,C174] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C175,C176,C177,C178,C180] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C181,C182,C183,C184,C185] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C186,C187,C188,C190,C191] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C192,C193,C195,C196,C197] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C198,C199,C200,C201,C202] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C203,C204,C209,C211,C212] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C213,C214,C215,C216,C217] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C218,C220,C221,C222,C223] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C224,C225,C226,C227,C234] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C235,C236,C237,C46,C74,C79] ｺﾝﾃﾞﾝｻｰ

113

VCCCCZ1HH102J AA DD C Capacitor(50WV 1000pF) [C43,C44,C45,C73,C130] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH102J AA DD C Capacitor(50WV 1000pF) [C133,C138,C158,C160,C161] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH102J AA DD C Capacitor(50WV 1000pF) [C164,C253,C265,C304,C309] ｺﾝﾃﾞﾝｻｰ

VCCCCZ1HH102J AA DD C Capacitor(50WV 1000pF) [C310,C148,C151] ｺﾝﾃﾞﾝｻｰ

114

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C7,C9,C13,C14,C16] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C20,C21,C22,C23,C24] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C26,C27,C28,C29,C30] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C31,C32,C33,C34,C35] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C36,C37,C38,C47,C52] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C53,C54,C55,C56,C57] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C58,C59,C60,C61,C62] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C63,C65,C66,C67,C68] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C69,C70,C75,C76,C80] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C81,C82,C83,C87,C88] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C89,C90,C91,C92,C95] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C96,C98,C99,C101,C102] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C111,C115,C116,C118,C120] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C121,C122,C124,C127,C139] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C140,C142,C145,C147,C150] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C157,C163,C210,C219,C228] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C238,C239,C240,C241,C243] ｺﾝﾃﾞﾝｻｰ

– 5 –

3PCU 基板 (PCU PWB)

4MFP ｺﾝﾄﾛｰﾙ基板 (MFP control PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

114

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C245,C246,C247,C251,C252] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C255,C257,C261,C263,C267] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C269,C270,C273,C274,C275] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C276,C277,C278,C279,C280] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C281,C282,C283,C284,C285] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C286,C287,C288,C289,C290] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C291,C292,C301,C303,R463] ｺﾝﾃﾞﾝｻｰ

115 VCKYCZ1CB223K AB DD C Capacitor(16WV 0.022µF) [C244,C248,C249,C254,C259,C266] ｺﾝﾃﾞﾝｻｰ

116 VCCCCZ1HH120J AA DD C Capacitor(50WV 12pF) [C6,C8,C10] ｺﾝﾃﾞﾝｻｰ

117 VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C294,C296,C298,C29,C306] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C307,C308] ｺﾝﾃﾞﾝｻｰ

118 VCKYCY1HB473K AA DD C Capacitor(50WV 0.047µF) [C311] ｺﾝﾃﾞﾝｻｰ

119 VCKYCZ1CB103K AA DD C Capacitor(16WV 0.010µF) [C264,C93] ｺﾝﾃﾞﾝｻｰ

120 VCKYTV1AB225K AC DD C Capacitor(10WV 2.2µF) [C135] ｺﾝﾃﾞﾝｻｰ

121 VCKYTV1CB105K AC DD C Capacitor(16WV 1µF) [C134] ｺﾝﾃﾞﾝｻｰ

127

VHDKDS226++-1 AC DJ B Diode(KDS226) [D65,D76,D97,D101,D103] ﾀﾞｲｵｰﾄﾞ

VHDKDS226++-1 AC DJ B Diode(KDS226) [D105,D107,D112,D114,D117] ﾀﾞｲｵｰﾄﾞ

VHDKDS226++-1 AC DJ B Diode(KDS226) [D124,D131,D135,D140,D141] ﾀﾞｲｵｰﾄﾞ

VHDKDS226++-1 AC DJ B Diode(KDS226) [D142,D143,D144,D145,D146] ﾀﾞｲｵｰﾄﾞ

VHDKDS226++-1 AC DJ B Diode(KDS226) [D147,D148,D149,D150] ﾀﾞｲｵｰﾄﾞ

128 VHDKDS226++-1 AC DJ B Diode(KDS226) [D163] ﾀﾞｲｵｰﾄﾞ

129

VHD1SS355//-1 AB DJ B Diode(1SS355) [D7,D10,D11,D12,D13] ﾀﾞｲｵｰﾄﾞ

VHD1SS355//-1 AB DJ B Diode(1SS355) [D14,D16,D18,D19,D49] ﾀﾞｲｵｰﾄﾞ

VHD1SS355//-1 AB DJ B Diode(1SS355) [D70,D71,D77,D86,D138] ﾀﾞｲｵｰﾄﾞ

VHD1SS355//-1 AB DJ B Diode(1SS355) [D139,D151,D153,D155,D156,D157] ﾀﾞｲｵｰﾄﾞ

130 VHEMTZJ20B/-1 AB DD B Zener diode(MTZJ20B) [D152] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

131 VHDMA704A//-1 AC DJ B Diode(MA704A) [D99,D109,D115] ﾀﾞｲｵｰﾄﾞ

133 VHPLT1D67A/-1 AC DJ B LED(LT1D67A) [D2] LED

134 VSKTA1505S+-1 AC DJ B Transistor(KTA1505S) [Q14,Q24] ﾄﾗﾝｼﾞｽﾀｰ

136 VSKRA119S++-1 AB DJ B Transistor(KRA119S) [Q8,Q9,Q10,Q11,Q12] ﾄﾗﾝｼﾞｽﾀｰ

137

VSKRC106S++-1 AB DJ B Transistor(KRC106S) [Q2,Q23,Q13,Q48,Q49] ﾄﾗﾝｼﾞｽﾀｰ

VSKRC106S++-1 AB DJ B Transistor(KRC106S) [Q51,Q20,Q56,Q57,Q58] ﾄﾗﾝｼﾞｽﾀｰ

VSKRC106S++-1 AB DJ B Transistor(KRC106S) [Q59,Q25,Q50] ﾄﾗﾝｼﾞｽﾀｰ

139 VS2SA1576A/-1 AB DJ B Transistor(2SA1576A) [Q32,Q33,Q36,Q38] ﾄﾗﾝｼﾞｽﾀｰ

140 VS2SK3018++-1 AC DJ B Transistor(2SK3018) [Q1,Q41,Q42,Q43,Q44,Q19] ﾄﾗﾝｼﾞｽﾀｰ

141 VS2SB1240-/-1 AD DJ B Transistor(2SB1240) [Q16,Q15] ﾄﾗﾝｼﾞｽﾀｰ

143 VS2SD1898//-1 AD DJ B Transistor(2SD1898) [Q3,Q6] ﾄﾗﾝｼﾞｽﾀｰ

144 VS2SC2411K/-1 AB DD B Transistor(2SC2411K) [Q22,Q21,Q55] ﾄﾗﾝｼﾞｽﾀｰ

145 VSRN1422-//-1 AD DJ B Transistor(RN1422) [Q52] ﾄﾗﾝｼﾞｽﾀｰ

147 RFILZ0004QSZZ AM EG C Filter(ZJSR5101-223) [NF1,NF4,NF10,NF11,NF12] ﾌｨﾙﾀｰ

148 RFILN0062FCPZ AC DJ C Filter(ZJSR5101-102TA-01) [NF2] ﾌｨﾙﾀｰ

(Unit)

901 CPWBX1714FCE4 BZ TF E PCU PWB [MX-2300G/FG/N] PCU 基板

CPWBX1714FCE1 BZ TF E PCU PWB [MX-2700G/FG/N] PCU 基板

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1VHI24F256LI-1 AP EQ B IC(CAT24FC256LI) [AS2] IC

2QSOCN0108FCPZ AD DJ N C Socket(JM-2R-64) [AS3] ｿｹｯﾄ

!3UBATL0017FCZZ AL EB B Battery(CR2450) [AS4] ﾊﾞｯﾃﾘｰ

4PCOVP1945FCZZ AC DJ N D Battery cover [AS5] ﾊﾞｯﾃﾘｰｶﾊﾞｰ

RMPTR4103ACPZ AA DD N B Block resistor(10KΩ×4) [BR3,BR37,BR38,BR44,BR46] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACPZ AA DD N B Block resistor(10KΩ×4) [BR120,BR121,BR122,BR123,BR124] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACPZ AA DD N B Block resistor(10KΩ×4) [BR125,BR126,BR127,BR128,BR154] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACPZ AA DD N B Block resistor(10KΩ×4) [BR155,BR156,BR157,BR158,BR159] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACPZ AA DD N B Block resistor(10KΩ×4) [BR160,BR161,BR162,BR229,BR248] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACPZ AA DD N B Block resistor(10KΩ×4) [BR249,BR250,BR251,BR252,BR253] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACPZ AA DD N B Block resistor(10KΩ×4) [BR265,BR353,BR354,BR355,BR356] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACPZ AA DD N B Block resistor(10KΩ×4) [BR357,BR358,BR359,BR360,BR361] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACPZ AA DD N B Block resistor(10KΩ×4) [BR362,BR363] ﾌﾞﾛｯｸﾃｲｺｳ

12 RMPTR4822ACZZ AA DD B Block resistor(8.2KΩ×4) [BR115,BR116,BR117,BR118,BR119] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4822ACZZ AA DD B Block resistor(8.2KΩ×4) [BR130,BR141,BR142,BR143,BR144] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR129,BR131,BR132,BR133,BR134] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR136,BR138,BR139,BR140,BR145] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR146,BR147,BR148,BR149,BR150] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR151,BR152,BR153,BR167,BR170] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR175,BR181,BR182,BR183,BR184] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR185,BR186,BR188,BR189,BR190] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR191,BR192,BR193,BR194,BR195] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR196,BR197,BR198,BR199,BR200] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR207,BR208,BR210,BR211,BR213] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR214,BR218,BR220,BR221,BR222] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR225,BR226,BR228,BR255,BR256] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR257,BR258,BR259,BR260,BR310] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR311,BR312,BR313,BR314,BR315] ﾌﾞﾛｯｸﾃｲｺｳ

– 6 –

4MFP ｺﾝﾄﾛｰﾙ基板 (MFP control PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR316,BR317,BR322,BR326,BR331] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR334,BR335,BR336,BR337,BR338] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR339,BR340,BR341,BR342,BR343] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR344,BR345,BR346,BR347,BR348] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR349,BR350,BR351,BR352,BR373] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR375,BR376,BR387,BR388] ﾌﾞﾛｯｸﾃｲｺｳ

16 QSOCZ0107FCPZ AH DX N C Socket(BV-50N) [BT1] ｿｹｯﾄ

17 QSOCZ0103FCPZ AQ EQ N C Socket(MM50-200A1-1) [CN2,CN3,CN23,CN24] ｿｹｯﾄ

19 QSOCN0005ESPZ AE DJ C Socket(UBR23-4K2200) [CN8] ｿｹｯﾄ

20 QSOCN0012QSPZ AE DS C Socket(UAR27-4K5J00) [CN9] ｿｹｯﾄ

21 QSOCZ0094FCPA AL EB C Socket(DMM2-SD72AR-113-F)

[CN11,CN12,CN13,CN14,CN15] ｿｹｯﾄ

22 QSOCZ0079FCPZ AP EQ C Socket(DMM-100G-133FNK31-F)

[MX-2300G/MX-2300FG/MX-2700G/MX-2700FG][CN16] ｿｹｯﾄ

23 QSOCN0111FCPZ AF DJ C Socket(DBR30-091F100) [CN18] ｿｹｯﾄ

24 QCNCM1348FCPZ AE DJ N C Connector(B32B-PHDSS-B) [CN19] ｺﾈｸﾀｰ

25 QCNCW1345FCPZ AP EQ N C Connector(FX8C-60S-SV5) [CN20,CN22] ｺﾈｸﾀｰ

26 QCNCW1190FCPZ AN EG C Connector(TX24-100R-LT-H1E) [CN21] ｺﾈｸﾀｰ

27 QJAKT0003FCPZ AQ EQ N C Jack(J10-0036NL) [CN26] ｼﾞｬｯｸ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C1,C2,C3,C4,C9] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C10,C11,C12,C48,C58] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C64,C65,C68,C95,C96] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C157,C158,C167,C168,C179] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C224,C225,C226,C307,C318] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C323,C337,C340,C347,C356] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C358,C359,C391,C393,C395] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C397,C407,C426,C448,C457] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C507,C508,C535,C536,C557] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C558,C560,C567,C639,C676] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C717,C731,C732,C798,C799] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C800,C806,C809,C810,C812] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AF106Z AC DD C Capacitor(10WV 10µF) [C815,C816,C821,C826] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C17,C18,C19,C21,C52] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C63,C72,C75,C77,C79] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C81,C83,C85,C87,C89] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C91,C93,C102,C104,C106] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C107,C110,C112,C114,C116] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C118,C120,C121,C123,C125] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C127,C178,C252,C254,C256] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C258,C260,C262,C264,C266] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C268,C270,C272,C274,C276] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C278,C280,C282,C284,C286] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C288,C290,C292,C294,C296] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C298,C300,C302,C304,C306] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C330,C341,C342,C343,C344] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C346,C348,C350,C352,C353] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C389,C390,C409,C411,C413] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C415,C417,C419,C421,C423] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C425,C428,C430,C432,C434] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C473,C475,C484,C487,C493] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C495,C505,C559,C563,C565] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C571,C579,C580,C582,C584] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C586,C588,C590,C594,C596] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C598,C601,C602,C604,C608] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C612,C614,C615,C616,C617] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C620,C621,C624,C625,C627] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C629,C631,C632,C634,C637] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C644,C645,C651,C656,C658] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C662,C665,C669,C679,C682] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C683,C685,C687,C688,C690] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C695,C698,C703,C706,C707] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C723,C794,C820,C822] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C126,C128,C129,C130,C131] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C132,C133,C134,C135,C136] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C137,C138,C139,C140,C141] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C142,C143,C144,C145,C146] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C147,C148,C149,C150,C151] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C152,C153,C154,C155,C156] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C159,C160,C161,C162,C163] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C164,C165,C171,C172,C173] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C174,C175,C176,C177,C180] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C181,C182,C183,C184,C185] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C186,C187,C188,C191,C192] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C197,C198,C199,C200,C201] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C504,C511,C512,C513,C514] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C515,C516,C517,C518,C519] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C520,C521,C522,C523,C524] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C525,C526,C527,C528,C529] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C530,C531,C532,C533,C534] ｺﾝﾃﾞﾝｻｰ

– 7 –

4MFP ｺﾝﾄﾛｰﾙ基板 (MFP control PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C537,C538,C539,C540,C541] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C542,C543,C544,C575,C578] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C787,C788,C789,C790,C817] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C818,C824,C825] ｺﾝﾃﾞﾝｻｰ

33 VCCCRZ1HH150J AA DD N C Capacitor(50WV 15pF) [C42,C43] ｺﾝﾃﾞﾝｻｰ

34 VCCCRZ1HH270J AA DD N C Capacitor(50WV 27pF) [C46,C47] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C20,C24,C25,C28,C29] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C32,C41,C44,C45,C49] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C50,C51,C56,C59,C60] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C61,C62,C67,C69,C71] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C73,C74,C76,C78,C80] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C82,C84,C86,C88,C90] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C92,C97,C101,C103,C105] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C108,C109,C111,C113,C115] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C117,C119,C122,C124,C169] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C170,C204,C205,C206,C207] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C213,C214,C218,C219,C220] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C222,C251,C253,C255,C257] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C259,C261,C263,C265,C267] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C269,C271,C273,C275,C277] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C279,C281,C283,C285,C287] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C289,C291,C293,C295,C297] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C299,C301,C303,C305,C308] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C309,C310,C311,C312,C313] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C314,C315,C316,C317,C319] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C320,C321,C322,C326,C332] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C333,C336,C345,C357,C360] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C361,C362,C363,C364,C365] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C366,C367,C368,C369,C370] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C371,C372,C373,C374,C375] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C376,C377,C378,C379,C380] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C381,C382,C383,C386,C387] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C394,C396,C400,C401,C405] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C408,C410,C412,C414,C416] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C418,C420,C422,C424,C427] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C429,C431,C433,C436,C437] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C438,C439,C440,C441,C442] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C443,C444,C445,C446,C453] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C454,C455,C456,C458,C459] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C460,C464,C469,C470,C471] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C472,C474,C476,C477,C478] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C479,C480,C481,C482,C483] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C486,C488,C490,C491,C492] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C494,C496,C497,C499,C500] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C501,C503,C509,C510,C555] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C556,C562,C564,C566,C568] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C569,C570,C572,C574,C576] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C577,C581,C583,C585,C587] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C589,C591,C592,C593,C595] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C600,C603,C605,C607,C609] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C611,C618,C622,C633,C636] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C640,C641,C646,C647,C652] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C654,C655,C657,C661,C664] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C667,C678,C681,C684,C686] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C689,C692,C694,C697,C700] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C702,C705,C708,C714,C716] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C718,C719,C720,C721,C727] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C728,C729,C733,C734,C735] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C740,C747,C748,C756,C757] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C758,C759,C760,C761,C765] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C766,C767,C768,C778,C779] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C780,C781,C782,C783,C785] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C797,C807,C808,C813,C814] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C823,C832,C833,C834,C835] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C836,C837,C838,C839,C840] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C841,C842] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C57,C66,C349,C351,C399] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C737,C738,C739,C741,C743] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C746,C802,C803] ｺﾝﾃﾞﾝｻｰ

VCCCRZ1HH151J AA DD C Capacitor(50WV 150pF) [C202,C203,C215,C217,C221] ｺﾝﾃﾞﾝｻｰ

VCCCRZ1HH151J AA DD C Capacitor(50WV 150pF) [C329,C335,C354,C384,C402] ｺﾝﾃﾞﾝｻｰ

VCCCRZ1HH151J AA DD C Capacitor(50WV 150pF) [C403,C498,C545,C546,C548] ｺﾝﾃﾞﾝｻｰ

VCCCRZ1HH151J AA DD C Capacitor(50WV 150pF) [C549,C550,C551,C553,C638] ｺﾝﾃﾞﾝｻｰ

VCCCRZ1HH151J AA DD C Capacitor(50WV 150pF) [C710,C711,C712,C713,C804] ｺﾝﾃﾞﾝｻｰ

VCCCRZ1HH221J AA DD N C Capacitor(50WV 220pF) [C94,C98,C99,C100,C388] ｺﾝﾃﾞﾝｻｰ

VCCCRZ1HH221J AA DD N C Capacitor(50WV 220pF) [C447,C449,C450,C451,C452] ｺﾝﾃﾞﾝｻｰ

VCCCRZ1HH221J AA DD N C Capacitor(50WV 220pF) [C724,C792,C793,C795,C796] ｺﾝﾃﾞﾝｻｰ

– 8 –

4MFP ｺﾝﾄﾛｰﾙ基板 (MFP control PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

VCKYCZ1HB471K AA DD C Capacitor(50WV 470pF) [C216,C327,C385,C552,C643] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB471K AA DD C Capacitor(50WV 470pF) [C722,C742,C745,C749,C750] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB471K AA DD C Capacitor(50WV 470pF) [C751,C752,C753,C754,C755] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB471K AA DD C Capacitor(50WV 470pF) [C762,C763,C764,C801] ｺﾝﾃﾞﾝｻｰ

41 VCCCRZ1HH220J AA DD C Capacitor(50WV 22pF) [C324,C325] ｺﾝﾃﾞﾝｻｰ

42 VCEASX1CN476M AC DD C Capacitor(16WV 47µF) [C398] ｺﾝﾃﾞﾝｻｰ

43 VCEASX1CN477M AE DS C Capacitor(16WV 470µF) [C461] ｺﾝﾃﾞﾝｻｰ

44 VCKYCY1EB104K AG DX C Capacitor(25WV 0.1µF) [C465,C466,C467,C468] ｺﾝﾃﾞﾝｻｰ

45 VCEASX1EN337M AE DS C Capacitor(25WV 330µF) [C485,C730] ｺﾝﾃﾞﾝｻｰ

46 VHPLT1F67AF-1 AC DJ B LED(LT1F67AF) [D1,D2,D3] LED

47 VHEHZM6R2Z4-1 AC DJ N B Diode(HZM6.2Z4MWATL-E) [D4,D7] ﾀﾞｲｵｰﾄﾞ

48 VHD1SS355//-1 AB DJ B Diode(1SS355) [D5,D6,D8,D9,D31] ﾀﾞｲｵｰﾄﾞ

49 VHDDAN202U/-1 AB DD B Diode(DAN202U) [D10,D11,D16,D17,D20] ﾀﾞｲｵｰﾄﾞ

VHDDAN202U/-1 AB DD B Diode(DAN202U) [D22,D23] ﾀﾞｲｵｰﾄﾞ

VHDDAP202U/-1 AB DD B Diode(DAP202U) [D13,D14,D15,D18,D19] ﾀﾞｲｵｰﾄﾞ

VHDDAP202U/-1 AB DD B Diode(DAP202U) [D21,D24,D25,D26,D27] ﾀﾞｲｵｰﾄﾞ

VHDDAP202U/-1 AB DD B Diode(DAP202U) [D28,D29,D30] ﾀﾞｲｵｰﾄﾞ

51 VSSSM3J09FF-1 AD DJ N B Transistor(SSM3J09FU) [FET1] ﾄﾗﾝｼﾞｽﾀｰ

VHIVC244APW-1 AE DJ N B IC(SN74LVC244APWR) [IC4,IC9,IC11,IC18,IC20] IC

VHIVC244APW-1 AE DJ N B IC(SN74LVC244APWR) [IC35,IC37,IC39,IC41,IC42] IC

VHIVC244APW-1 AE DJ N B IC(SN74LVC244APWR) [IC77,IC86,IC89] IC

55 VHILVC74APW-1 AD DJ N B IC(SN74LVC74APWR) [IC12,IC84] IC

58 VHI7965835R-1 BZ TR N B IC(RM7065C-600R) [IC19] IC

59 VHIL7B1916+-1 BS MJ N B IC(L7B1916) [IC21] IC

61 RH-IX0016FCPZ BD GN N B IC(NT5DS32M16BS-6K) [IC23,IC24] IC

62 QSOCZ0002QSPZ AC DJ C Socket(MY02-0830-2L) [IC28] ｿｹｯﾄ

63 VHIVC2G66UR-1 AD DJ N B IC(SN74LVC2G66DCUR) [IC29,IC60,IC61,IC90] IC

64 VHI65547Y030C BC GJ N B IC(UPD65547GJ-Y03-UEN-A) [IC30] IC

65 VHIDP83816N-1 AY FQ B IC(DP83816) [IC32] IC

66 VHI93C46VI+-1 AE DS B IC(CAT93C46VI-TE13) [IC33] IC

67 VHILVC574AP-1 AL EB B IC(SN74LVC574APWR) [IC34,IC36,IC38,IC40] IC

68 VHIVC245APW-1 AE DJ N B IC(SN74LVC245APWR) [IC43,IC44,IC45,IC46,IC47,IC48] IC

69 VHILVC08APW-1 AD DJ N B IC(SN74LVC08APWR) [IC49,IC50,IC56,IC87] IC

70 VHIL7C1922+0C BE GN N B IC(L7C1922) [IC51] IC

71 VHI24WC02WI-1 AE DS N B IC(CAT24WC02WI) [IC52] IC

72 VHIBD6512LF-1 AH DX N B IC(BD6512F-E2) [IC53] IC

73 VHILHF80JZN-1 AN EG N B IC(LH28F800BJE) [MX-2300FG/MX-2700FG][IC57,IC59] IC

74 VHI1G04DCKR-1 AH DX B IC(SN74LVC1G04DCKR) [IC58,IC62,IC92,IC93] IC

75 VHI23WAT255-1 AU EZ B IC(N02L163WC2AT2-55I) [IC63] IC

76 VHILM393D++-1 AE DJ B IC(LM393D) [IC64] IC

78 VHIHI207ECB0C AN EG B IC(HIN207ECBZ-T) [IC66] IC

80 VHIDS90C386-1 AR EQ N B IC(DS90CF386MTDX/NOPB) [IC70] IC

81 VHIDS90C385-1 AR EQ N B IC(DS90C385AMTX/NOPB) [IC71,IC72] IC

82 VHILV048TC+-1 AL EB N B IC(DS90LV048ATMTCX/NOPB) [IC73,IC74] IC

84 VHIL7A1920+0C BX TF N B IC(L7A1920) [IC80] IC

86 VHILHF00L28-1 AP EQ B IC(LHF00L28) [IC83] IC

87 VHI658920130C AQ EQ N B IC(uPD65892GC-013-8EU) [IC85] IC

88 VHI2474AF06-1 AH DX N B IC(ASM3P2474AF-06OR) [IC14,IC91] IC

RCILF0128FCPZ AA DJ N C Coil(BLM15AG121SN1) [L2,L3,L4,L5,L7] ｺｲﾙ

RCILF0128FCPZ AA DJ N C Coil(BLM15AG121SN1) [L9,L10,L11,L12,L18] ｺｲﾙ

RCILF0128FCPZ AA DJ N C Coil(BLM15AG121SN1) [L24,L25,L41,L45,L49] ｺｲﾙ

RCILF0128FCPZ AA DJ N C Coil(BLM15AG121SN1) [L50,L52,L53,L56] ｺｲﾙ

90 RCILF0127FCPZ AB DJ N C Coil(BLM21PG600SN1D) [L6,L13,L42,L47] ｺｲﾙ

RFILN1062ACZZ AA DJ C Filter(BLM18PG121SN1) [L8,L14,L15,L16,L17] ﾌｨﾙﾀｰ

RFILN1062ACZZ AA DJ C Filter(BLM18PG121SN1) [L20,L21,L22,L23,L27] ﾌｨﾙﾀｰ

RFILN1062ACZZ AA DJ C Filter(BLM18PG121SN1) [L29,L30,L31,L32,L43] ﾌｨﾙﾀｰ

RFILN1062ACZZ AA DJ C Filter(BLM18PG121SN1) [L44,L46,L51,L54,L55] ﾌｨﾙﾀｰ

92 RCILF0126FCPZ AE DJ N C Coil(ACM2012-900-2P-T000) [L26,L28] ｺｲﾙ

94 RCNVD0008FCPZ AU EZ N B Converter(MPD6S012S) [MOD1,MOD2,MOD3,MOD4] ｺﾝﾊﾞｰﾀｰ

RCNVD0008FCPZ AU EZ N B Converter(MPD6S012S) [MOD5,MOD6,MOD7,MOD8] ｺﾝﾊﾞｰﾀｰ

VSDTC114YUA-1 AB DJ B Transistor(DTC114YUA) [Q1,Q2,Q3,Q4,Q5] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC114YUA-1 AB DJ B Transistor(DTC114YUA) [Q6,Q7,Q8,Q9,Q10] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC114YUA-1 AB DJ B Transistor(DTC114YUA) [Q13,Q14,Q15,Q16,Q17] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC114YUA-1 AB DJ B Transistor(DTC114YUA) [Q18,Q19,Q20,Q21,Q22] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC114YUA-1 AB DJ B Transistor(DTC114YUA) [Q23,Q24,Q26,Q27] ﾄﾗﾝｼﾞｽﾀｰ

96 VS2SB1198K/-1 AC DJ B Transistor(2SB1198K) [Q11,Q25] ﾄﾗﾝｼﾞｽﾀｰ

97 VS2SC2412K/-1 AB DD B Transistor(2SC2412K) [Q12] ﾄﾗﾝｼﾞｽﾀｰ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R25,L33,L34,L37,L48] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R61,R63,R92,R102,R126] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R141,R144,R146,R273,R274] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R278,R281,R293,R314,R315] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R381,R538,R545,R548,R553] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R554,R555,R557,R574,R608] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R609,R610,R618,R619,R627] ﾃｲｺｳ

99 RR-SZ0407FCPZ AA DD N C Resistor(3.16KΩ ±1%) [R1,R4,R692] ﾃｲｺｳ

100 VRS-CZ1JD152F AA DD C Resistor(1/16W 1.5KΩ ±1%) [R2,R5,R10,R11,R15,R16] ﾃｲｺｳ

101 RR-SZ0412FCPZ AA DD N C Resistor(68.1KΩ ±1%) [R3,R6,R7,R8,R105,R112] ﾃｲｺｳ

102 RR-SZ0408FCPZ AA DD N C Resistor(31.0KΩ ±1%) [R9,R14,R104] ﾃｲｺｳ

103 RR-SZ0409FCPZ AA DD N C Resistor(267KΩ ±1%) [R12,R13] ﾃｲｺｳ

– 9 –

4MFP ｺﾝﾄﾛｰﾙ基板 (MFP control PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

104

VRS-CZ1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R17,R18,R19,R90,R183] ﾃｲｺｳ

VRS-CZ1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R184,R270,R284,R289,R309] ﾃｲｺｳ

VRS-CZ1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R356,R379,R380,R493,R590] ﾃｲｺｳ

VRS-CZ1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R625,R626] ﾃｲｺｳ

105

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R85,R106,R113,R115,R116] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R130,R133,R150,R151,R154] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R171,R187,R197,R207,R213] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R236,R250,R264,R266,R277] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R303,R304,R312,R313,R317] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R326,R337,R341,R347,R364] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R372,R374,R378,R384,R393] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R396,R406,R408,R409,R423] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R426,R449,R469,R494,R497] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R572,R582,R587,R588,R589] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R591,R721] ﾃｲｺｳ

106 VRS-CZ1JD105J AA DD C Resistor(1/16W 1.0MΩ ±5%) [R23,R54,R70,R88,R246] ﾃｲｺｳ

VRS-CZ1JD105J AA DD C Resistor(1/16W 1.0MΩ ±5%) [R368,R375] ﾃｲｺｳ

107

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R24,R26,R28,R37,R38] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R40,R43,R49,R50,R51] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R55,R66,R67,R68,R75] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R76,R79,R107,R123,R134] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R142,R172,R173,R177,R179] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R185,R186,R189,R190,R192] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R198,R200,R201,R202,R203] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R218,R234,R235,R252,R253] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R257,R258,R259,R260,R306] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R327,R328,R329,R330,R343] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R344,R345,R346,R353,R359] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R414,R415,R418,R422,R446] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R447,R470,R471,R509,R510] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R511,R512,R514,R516,R521] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R522,R523,R524,R525,R526] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R529,R530,R541,R563,R567] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R568,R569,R570,R571,R575] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R576,R577,R578,R585,R586] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R592,R593,R594,R595,R596] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R597,R598,R599,R600,R601] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R630,R633,R634,R635,R636] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R637,R640,R702] ﾃｲｺｳ

108

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R80,R96,R109,R188,R199] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R256,R351,R357,R387,R388] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R397,R401,R416,R417,R419] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R420,R421,R432,R435,R436] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R438,R439,R440,R444,R448] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R450,R496,R689,R709,R723] ﾃｲｺｳ

109

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R71,R93,R217,R240,R242] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R243,R244,R265,R275,R279] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R365,R366,R377,R385,R386] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R389,R412,R413,R433,R434] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R527,R528,R534,R535,R539] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R544,R562,R564,R565,R566] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R580,R581,R611,R691] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R693,R700] ﾃｲｺｳ

110 VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R135,R248,R276,R292,R321] ﾃｲｺｳ

VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R382,R430,R431,R499,R504] ﾃｲｺｳ

111

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R91,R97,R138,R139,R140] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R152,R153,R155,R156,R157] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R158,R159,R160,R161,R162] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R163,R164,R166,R167,R168] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R169,R220,R239,R354,R361] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R452,R453,R454,R455,R456] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R457,R458,R459,R460,R461] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R462,R463,R464,R465,R467] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R468,R500,R501,R502,R506] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R531,R532,R638,R639,R641] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R642,R643,R644,R645,R646] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R647,R648,R649,R650,R651] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R652,R653,R654,R655,R656] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R658,R659,R660,R661,R662] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R663,R664,R665,R666,R667] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R668,R669,R670] ﾃｲｺｳ

112

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R111,R119,R122,R228,R231] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R237,R305,R320,R350,R371] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R390,R394,R400,R407,R437] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R477,R503,R508,R515,R533] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R536,R542,R547,R558,R559] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R560,R561,R623] ﾃｲｺｳ

113

VRS-CZ1JD560J AA DD C Resistor(1/16W 56Ω ±5%) [R31,R84,R170,R671,R672] ﾃｲｺｳ

VRS-CZ1JD560J AA DD C Resistor(1/16W 56Ω ±5%) [R673,R674,R675,R676,R677] ﾃｲｺｳ

VRS-CZ1JD560J AA DD C Resistor(1/16W 56Ω ±5%) [R678,R679,R680,R681,R682] ﾃｲｺｳ

– 10 –

4MFP ｺﾝﾄﾛｰﾙ基板 (MFP control PWB)

5MFP OPE 基板 (MFP OPE PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

113 VRS-CZ1JD560J AA DD C Resistor(1/16W 56Ω ±5%)

[R683,R684,R685,R686,R687,R688] ﾃｲｺｳ

114

VRS-CZ1JD222J AA DD C Resistor(1/16W 2.2KΩ ±5%) [R131,R143,R222,R223,R224] ﾃｲｺｳ

VRS-CZ1JD222J AA DD C Resistor(1/16W 2.2KΩ ±5%) [R232,R299,R300,R301,R302] ﾃｲｺｳ

VRS-CZ1JD222J AA DD C Resistor(1/16W 2.2KΩ ±5%) [R311,R324,R338,R339,R340] ﾃｲｺｳ

VRS-CZ1JD222J AA DD C Resistor(1/16W 2.2KΩ ±5%) [R348,R362,R363,R367,R383] ﾃｲｺｳ

VRS-CZ1JD222J AA DD C Resistor(1/16W 2.2KΩ ±5%) [R395,R402,R404,R405,R410] ﾃｲｺｳ

VRS-CZ1JD222J AA DD C Resistor(1/16W 2.2KΩ ±5%) [R411,R546,R550,R579,R617] ﾃｲｺｳ

VRS-CZ1JD222J AA DD C Resistor(1/16W 2.2KΩ ±5%) [R699,R704] ﾃｲｺｳ

115 RR-SZ0410FCPZ AA DD N C Resistor(49.9Ω ±1%) [R165,R180,R196,R212,R285] ﾃｲｺｳ

RR-SZ0410FCPZ AA DD N C Resistor(49.9Ω ±1%) [R288,R466,R498] ﾃｲｺｳ

116

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R30,R33,R41,R46,R48] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R73,R86,R114,R117,R118] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R132,R174,R175,R176,R178] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R191,R193,R194,R204,R205] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R206,R208,R209,R210,R211] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R214,R352] ﾃｲｺｳ

117 VRS-CZ1JD121J AA DD C Resistor(1/16W 120Ω ±5%) [R181] ﾃｲｺｳ

118

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R20,R21,R145,R233,R254] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R316,R424,R428,R537,R621] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R622,R720] ﾃｲｺｳ

119 VRS-CZ1JD562J AA DD C Resistor(1/16W 5.6KΩ ±5%) [R267] ﾃｲｺｳ

120 RR-SZ0411FCPZ AA DD N C Resistor(6.81KΩ ±1%) [R322] ﾃｲｺｳ

122 VRS-CZ1JD153J AA DD C Resistor(1/16W 15KΩ ±5%) [R333,R334,R703,R708] ﾃｲｺｳ

123 VRS-CZ1JD333J AA DD C Resistor(1/16W 33KΩ ±5%) [R370] ﾃｲｺｳ

124 VHQNSMDC110-1 AF DS B Switch(nanoSMDC110F) [R451] ｽｲｯﾁ

125 QSW-S0545FCPZ AM EG B Switch(KSP22) [SW2] ｽｲｯﾁ

126 RCRSC0094FCPZ AD DJ N B Crystal(16.6666MHz) [X7] ｸﾘｽﾀﾙ

127 RCRSC0093FCPZ AD DJ N B Crystal(25.0000MHz) [X4] ｸﾘｽﾀﾙ

128 RCRSC0095FCPZ AD DJ N B Crystal(14.7456MHz) [X5] ｸﾘｽﾀﾙ

129 RCRUA0040FCPZ AM EG N B Crystal(27.5000MHz) [X6] ｸﾘｽﾀﾙ

130 RCRUA0034FCPZ AR EQ B Crystal(25.0000MR) [X8] ｸﾘｽﾀﾙ

131 RCRUA0037FCPZ AM EG N B Crystal(48.0000MHz) [X9] ｸﾘｽﾀﾙ

132 RCRUA0038FCPZ AM EG N B Crystal(32.0000MHz) [X11] ｸﾘｽﾀﾙ

133 RCRSC0097FCPZ AF DS N B Crystal(32.768KHz) [X12] ｸﾘｽﾀﾙ

134 RR-SZ0413FCPZ AA DD N C Resistor(54.9Ω ±1%) [R282,R287] ﾃｲｺｳ

135 RCRUA0035FCPZ AN EQ N B Crystal(12.000MHz) [X13] ｸﾘｽﾀﾙ

136 VHDRB461F//-1 AD DJ B Diode(RB461F) [D32,D33,D34,D35,D36] ﾀﾞｲｵｰﾄﾞ

VHDRB461F//-1 AD DJ B Diode(RB461F) [D37,D38,D39] ﾀﾞｲｵｰﾄﾞ

137 QCNCM1366FCPZ AG DX N C Connector(HU5-400PNA-S53T-FA) [CN5] ｺﾈｸﾀｰ

138 QPIN-0003GCPZ AC DJ C Pin(T3B-SQ) [CN17] ﾋﾟﾝ

139

VCKYCY1AB105K AB DD C Capacitor(10WV 1µF) [C338,C819,C830,C831,C843] ｺﾝﾃﾞﾝｻｰ

VCKYCY1AB105K AB DD C Capacitor(10WV 1µF) [C844,C845,C846,C847,C848] ｺﾝﾃﾞﾝｻｰ

VCKYCY1AB105K AB DD C Capacitor(10WV 1µF) [C849,C850,C851,C852,C853] ｺﾝﾃﾞﾝｻｰ

VCKYCY1AB105K AB DD C Capacitor(10WV 1µF) [C854,C855,C856,C857,C858] ｺﾝﾃﾞﾝｻｰ

VCKYCY1AB105K AB DD C Capacitor(10WV 1µF) [C859,C860,C861,C862,C863] ｺﾝﾃﾞﾝｻｰ

140 VHI23S09SZ+-1 AV EZ B IC(CY23S09SXC-1T) [IC5] IC

141 VRS-CZ1JD221J AA DD C Resistor(1/16W 220Ω ±5%) [R22,R35,R39,R69,R87] ﾃｲｺｳ

VRS-CZ1JD221J AA DD C Resistor(1/16W 220Ω ±5%) [R245,R373] ﾃｲｺｳ

142 VRS-CZ1JD103F AA DD C Resistor(1/16W 10KΩ ±1%) [R296,R620] ﾃｲｺｳ

143 VRS-CZ1JD104J AA DD C Resistor(1/16W 100KΩ ±5%) [R238,R624,R722] ﾃｲｺｳ

144 VRS-CZ1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [RJ1,R472,R473,R474,R475] ﾃｲｺｳ

145 RCRSC0098FCPZ AD DJ N B Crystal(32.875MHz) [X1] ｸﾘｽﾀﾙ

146 VHILP2996MP-1 AT EZ B IC(LP2996MRX/NOPB) [IC22,IC81] IC

147 VHIC25814SZ-1 AL EB B IC(CY25814SXCT) [IC31] IC

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

2QCNCM1171FCZZ AE DS C Connector(B6B-PH-SM3-TB) [CN2] ｺﾈｸﾀｰ

3QCNCM1031MP0C AE DS C Connector(B3B-PH-SM) [CN3] ｺﾈｸﾀｰ

4RCRS-0007FCZZ AD DJ B Crystal(CSB480EB) [X1] ｸﾘｽﾀﾙ

5VHIM34282M1-1 AG DX B IC(M34282M1-F57GP) [IC1] IC

VHP1LHG002A-1 AB DJ B IC(LTL-1LHG-002A) [LED1,LED2,LED3,LED4,LED5] IC

VHP1LHG002A-1 AB DJ B IC(LTL-1LHG-002A) [LED6,LED7,LED8,LED9,LED10] IC

VHP1LHG002A-1 AB DJ B IC(LTL-1LHG-002A) [LED11,LED12,LED13,LED14] IC

VHP1LHG002A-1 AB DJ B IC(LTL-1LHG-002A) [LED15,LED16,LED18,LED19] IC

VHP1LHG002A-1 AB DJ B IC(LTL-1LHG-002A) [LED20,LED21,LED22] IC

9VSDTC114YS/-1 AB DD B Transistor(DTC114YS) [Q1] ﾄﾗﾝｼﾞｽﾀｰ

10 VRD-HT2EY151J AA DD C Resistor(1/4W 150Ω ±5%) [R5,R6,R7,R8,R9,R11] ﾃｲｺｳ

11 VRD-HT2EY102J AA DD C Resistor(1/4W 1KΩ ±5%) [R10] ﾃｲｺｳ

QSW-P0001ESZZ AC DJ B Tact switch(SKQNAB010) [SW1,SW2,SW3,SW4,SW5] ﾀｸﾄｽｲｯﾁ

QSW-P0001ESZZ AC DJ B Tact switch(SKQNAB010) [SW6,SW7,SW8,SW9,SW10] ﾀｸﾄｽｲｯﾁ

QSW-P0001ESZZ AC DJ B Tact switch(SKQNAB010) [SW11,SW12,SW14,SW15] ﾀｸﾄｽｲｯﾁ

QSW-P0001ESZZ AC DJ B Tact switch(SKQNAB010) [SW16,SW17] ﾀｸﾄｽｲｯﾁ

– 11 –

5MFP OPE 基板 (MFP OPE PWB)

6ﾄﾞﾗｲﾊﾞｰﾒｲﾝ基板 (Driver Main PWB)

7ﾄﾞﾗｲﾊﾞｰｻﾌﾞ基板 (Driver Sub PWB)

8ｽｷｬﾅｰｺﾝﾄﾛｰﾙ基板 (Scanner control PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

13 QSW-P0469FCZZ AD DS B Push switch(SKHWAC) [SW13,SW18,SW19,SW20] ﾌﾟｯｼｭｽｲｯﾁ

QSW-P0469FCZZ AD DS B Push switch(SKHWAC) [SW21,SW22,SW23] ﾌﾟｯｼｭｽｲｯﾁ

15 VCKYPU1EB223Z AB DD C Capacitor(25WV 0.022µF) [C2,C3,C4] ｺﾝﾃﾞﾝｻｰ

16 VCKYPU1HB101K AA DD C Capacitor(50WV 100pF) [C5,C6] ｺﾝﾃﾞﾝｻｰ

17 RALMB1002LCZZ AE DS B Alarm(PKM13EPY-4000-TF01) [BZ1] ｱﾗｰﾑ

(Unit)

901 CPWBF1657FCE1 BB GD E MFP OPE PWB MFP OPE 基板

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

2QCNCM7014SC1B AD DJ C Connector(12pin) [CN5,6] ｺﾈｸﾀｰ

3QCNCM7014SC0F AB DD C Connector(6pin) [CN1] ｺﾈｸﾀｰ

4QCNCM1006MCZZ AB DD C Connector(3pin) [CN3] ｺﾈｸﾀｰ

5QCNCM0879FCZZ AF DS C Connector(28pin) [CN2] ｺﾈｸﾀｰ

6QCNCM0878FCZZ AF DS C Connector(30pin) [CN4] ｺﾈｸﾀｰ

7VRS-RE3DA1R0J AB DD C Resistor(2W 1.0Ω ±5%) [R1,5,28,40,2,8,41,64,35,39] ﾃｲｺｳ

8VRNHT2EK2201F AA DD C Resistor(1/4W 2.2KΩ ±1%) [R37] ﾃｲｺｳ

9VRNHT2EK2701F AA DD C Resistor(1/4W 2.7KΩ ±1%) [R20,17,51,30] ﾃｲｺｳ

10 VRNHT2EK5100F AA DD C Resistor(1/4W 510Ω ±1%) [R7,27,12,45,24] ﾃｲｺｳ

11 VRNHT2EK1301F AB DD C Resistor(1/4W 1.3KΩ　±1%) [R10,50] ﾃｲｺｳ

12 VRNHT2EK4700F AA DD C Resistor(1/4W 470Ω ±1%) [R14] ﾃｲｺｳ

13 VRNHT2EK3601F AB DD C Resistor(1/4W 3.6KΩ ±1%) [R38] ﾃｲｺｳ

14 VRD-HT2EY103J AA DD C Resistor(1/4W 10KΩ ±5%) [R19,34,18,58] ﾃｲｺｳ

17 RC-KZ1054CCN2 AB DD C Capacitor(50WV 0.1µF) [C1,11,13,2,10,3,8,4,12,16] ｺﾝﾃﾞﾝｻｰ

18 VSDTC114YS/-1 AB DD B Transistor(DTC114YS) [Q1∼3,5] ﾄﾗﾝｼﾞｽﾀｰ

(Unit)

901 CPWBN1668FCE1 BE GN E Driver Main PWB ﾄﾞﾗｲﾊﾞｰﾒｲﾝ基板

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

2QCNCM7014SC1B AD DJ C Connector(12pin) [CN1] ｺﾈｸﾀｰ

3QCNCM1006MCZZ AB DD C Connector(3pin) [CN2] ｺﾈｸﾀｰ

4QCNCM0923FC12 AE DJ C Connector(12pin) [CN3] ｺﾈｸﾀｰ

5VRS-RE3DA1R0J AB DD C Resistor(2W 1.0Ω ±5%) [R19,20,9,10] ﾃｲｺｳ

6VRNHT2EK2701F AA DD C Resistor(1/4W 2.7KΩ ±1%) [R15] ﾃｲｺｳ

7VRNHT2EK5100F AA DD C Resistor(1/4W 510Ω ±1%) [R18] ﾃｲｺｳ

8VRNHT2EK7500F AA DD C Resistor(1/4W 750Ω ±1%) [R17] ﾃｲｺｳ

9VRD-HT2EY103J AA DD C Resistor(1/4W 10KΩ ±5%) [R16] ﾃｲｺｳ

12 RC-KZ1054CCN2 AB DD C Capacitor(50WV 0.1µF) [C6,4,5,1] ｺﾝﾃﾞﾝｻｰ

13 VSDTC114YS/-1 AB DD B Transistor(DTC114YS) [Q2] ﾄﾗﾝｼﾞｽﾀｰ

(Unit)

901 CPWBF1669FCE1 AY FQ E Driver Sub PWB ﾄﾞﾗｲﾊﾞｰｻﾌﾞ基板

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1QCNCM0878FCZZ AF DS C Connector(30pin) [CN144] ｺﾈｸﾀｰ

2QCNCM0923FC10 AE DJ C Connector(10pin) [CN146] ｺﾈｸﾀｰ

3QCNCM0923FC3D AF DS C Connector(34pin) [CN142] ｺﾈｸﾀｰ

4QCNCM1230FCPZ AD DJ N C Connector(B6P-VH-R) [CN138] ｺﾈｸﾀｰ

5QCNCM1306FCPZ AG DS N C Connector(501190-2017) [CN147] ｺﾈｸﾀｰ

6QCNCM1308FCPZ AH DX N C Connector(501190-4017) [CN148] ｺﾈｸﾀｰ

7QCNCM2401SC0F AB DJ C Connector(6pin) [CN145] ｺﾈｸﾀｰ

8QCNCM7014SC0C AA DD C Connector(3pin) [CN134] ｺﾈｸﾀｰ

9QCNCM7014SC0D AB DD C Connector(4pin) [CN137] ｺﾈｸﾀｰ

10 QCNCM7014SC0F AB DD C Connector(6pin) [CN136] ｺﾈｸﾀｰ

11 QCNCM7014SC1C AC DD C Connector(13pin) [CN131] ｺﾈｸﾀｰ

12 QCNCM7014SC1E AC DJ C Connector(15pin) [CN143] ｺﾈｸﾀｰ

15 QCNCW1251FCPZ AD DJ N C Connector(5597-05CPB7F) [CN130] ｺﾈｸﾀｰ

!16 QFS-L0004QSPZ AD DJ A Fuse(TR/SG0603FA2.5-T) [F1] ﾋｭｰｽﾞ

17 QSOCZ0002QSPZ AC DJ C Socket(MY02-0830-2L) [IC174] ｿｹｯﾄ

18 QSOCZ0094FCPZ AL EG C Socket(DMM2-SD72AR-1131-F) [SOCKET1] ｿｹｯﾄ

19 RCRSP0016QSZZ AD DJ B Crystal(19.6608MHz) [X6] ｸﾘｽﾀﾙ

RFILZ0004QSZZ AM EG C Filter(ZJSR5101-223) [NF110,NF112,NF114,NF115,NF117] ﾌｨﾙﾀｰ

RFILZ0004QSZZ AM EG C Filter(ZJSR5101-223) [NF118,NF120,NF121,NF122,NF123] ﾌｨﾙﾀｰ

RFILZ0004QSZZ AM EG C Filter(ZJSR5101-223) [NF124,NF127,NF128,NF130,NF131] ﾌｨﾙﾀｰ

– 12 –

8ｽｷｬﾅｰｺﾝﾄﾛｰﾙ基板 (Scanner control PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

23 RH-IX0001QSZZ BD GN B IC(MT48LC8M16ATG-8E) [IC164] IC

24 RH-IX7001XCPZ AR EQ B IC(IS63LV1024L-12J-TR) [IC172] IC

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR126,BR127,BR135,BR136,BR137] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR138,BR160,BR161,BR164,BR165] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR166,BR167,BR168,BR169,BR568] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR569,BR570,BR571,BR584,BR585] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR586,BR587,BR598,BR599,BR600] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR601,BR716,BR718,BR755,BR756] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR757,BR758,BR966,BR971,BR972] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR973,BR976,BR977,BR978] ﾌﾞﾛｯｸﾃｲｺｳ

27 RMPTR4220ACZZ AB DD B Block resistor(22Ω×4) [BR711,BR712] ﾌﾞﾛｯｸﾃｲｺｳ

28 RMPTR4222ACZZ AB DD B Block resistor(2.2KΩ×4) [BR121] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR125,BR128,BR129,BR130,BR131] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR132,BR133,BR134,BR148,BR149] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR150,BR151,BR152,BR153,BR162] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR163,BR730,BR734,BR739,BR742] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR748,BR760,BR761,BR762] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR763,BR974] ﾌﾞﾛｯｸﾃｲｺｳ

30 RMPTR4470ACZZ AB DD B Block resistor(47Ω×4) [BR139,BR140,BR141,BR142,BR143] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4470ACZZ AB DD B Block resistor(47Ω×4) [BR144,BR145] ﾌﾞﾛｯｸﾃｲｺｳ

31 RMPTR4473ACZZ AB DD B Block resistor(47KΩ×4) [BR146,BR147] ﾌﾞﾛｯｸﾃｲｺｳ

32 VCCCCZ1HH150J AA DD C Capacitor(50WV 15pF) [C595,C596,C497,C498] ｺﾝﾃﾞﾝｻｰ

33 VCCCCZ1HH470J AA DD C Capacitor(50WV 47pF) [C956] ｺﾝﾃﾞﾝｻｰ

34 VCCCCZ1HH820J AA DD C Capacitor(50WV 82pF) [C877,C878] ｺﾝﾃﾞﾝｻｰ

37 VCEASX1HN105M AC DD C Capacitor(50WV 1µF) [C409] ｺﾝﾃﾞﾝｻｰ

41 VCEASX1VN226M AC DD N C Capacitor(50WV 22µF) [C343] ｺﾝﾃﾞﾝｻｰ

42 VCKYCY1CB224K AE DJ C Capacitor(35WV 0.22µF) [C407] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C377,C388,C405,C406,C411] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C430,C433,C437,C464,C465] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C499,C501,C503,C504,C505] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C506,C508,C532,C533,C542] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C570,C571,C572,C573,C576,C583] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C341,C439,C442,C447,C450] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C462,C605,C608,C610,C612] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C615,C1017,C1018,C1037] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C323,C324,C325,C328,C330] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C331,C332,C333,C334,C335] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C340,C345,C350,C351,C354] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C376,C378,C380,C381,C382] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C385,C394,C400,C414,C415] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C416,C417,C427,C431,C432] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C436,C440,C443,C449,C451] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C463,C470,C502,C507,C538] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C556,C582,C592,C606,C613] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C661,C666,C667,C668,C669] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C670,C675,C1010,C1026,C1027] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C1028,C1039,C1040,C1041] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C1043,C344,C384,C429] ｺﾝﾃﾞﾝｻｰ

VCKYRI0JB106K AC DD C Capacitor(6.3WV 10µF) [C555,C577,C590,C901,C974] ｺﾝﾃﾞﾝｻｰ

VCKYRI0JB106K AC DD C Capacitor(6.3WV 10µF) [C975,C978,C979,C982,C983] ｺﾝﾃﾞﾝｻｰ

VCKYRI0JB106K AC DD C Capacitor(6.3WV 10µF) [C987,C990,C991,C996,C997] ｺﾝﾃﾞﾝｻｰ

VCKYRI0JB106K AC DD C Capacitor(6.3WV 10µF) [C998,C1001,C1006,C1009,C1016] ｺﾝﾃﾞﾝｻｰ

50 VHD1N4448WS-1 AB DJ B Diode(1N4448WS) [D27,D29,D30,D31,D45] ﾀﾞｲｵｰﾄﾞ

VHD1N4448WS-1 AB DJ B Diode(1N4448WS) [D58,D66,D67,D70] ﾀﾞｲｵｰﾄﾞ

VHDBAV70W++-1 AC DJ B Diode(BAV70W) [D8,D14,D16,D34,D39] ﾀﾞｲｵｰﾄﾞ

VHDBAV70W++-1 AC DJ B Diode(BAV70W) [D42,D44,D49,D50,D51] ﾀﾞｲｵｰﾄﾞ

VHDBAV70W++-1 AC DJ B Diode(BAV70W) [D52,D53,D54,D55,D56] ﾀﾞｲｵｰﾄﾞ

VHDBAV70W++-1 AC DJ B Diode(BAV70W) [D57,D59,D61,D63,D64] ﾀﾞｲｵｰﾄﾞ

VHDBAV70W++-1 AC DJ B Diode(BAV70W) [D65,D91] ﾀﾞｲｵｰﾄﾞ

VHDBAV99W++-1 AB DJ N B Diode(BAV99W) [D7,D11,D18,D19,D20] ﾀﾞｲｵｰﾄﾞ

VHDBAV99W++-1 AB DJ N B Diode(BAV99W) [D28,D38,D40,D48,D60] ﾀﾞｲｵｰﾄﾞ

VHDBAV99W++-1 AB DJ N B Diode(BAV99W) [D62,D92,D93] ﾀﾞｲｵｰﾄﾞ

VHDBAW56W++-1 AC DJ B Diode(BAW56W) [D9,D10,D13,D15,D17] ﾀﾞｲｵｰﾄﾞ

VHDBAW56W++-1 AC DJ B Diode(BAW56W) [D35,D37,D46,D69,D76] ﾀﾞｲｵｰﾄﾞ

VHDBAW56W++-1 AC DJ B Diode(BAW56W) [D77,D78,D79,D80,D82] ﾀﾞｲｵｰﾄﾞ

VHDBAW56W++-1 AC DJ B Diode(BAW56W) [D83,D84,D85,D86,D87] ﾀﾞｲｵｰﾄﾞ

VHDBAW56W++-1 AC DJ B Diode(BAW56W) [D88,D89,D90,D103,D104] ﾀﾞｲｵｰﾄﾞ

VHDBAW56W++-1 AC DJ B Diode(BAW56W) [D105,D106,D21] ﾀﾞｲｵｰﾄﾞ

55 VHDES1D++++-1 AC DJ B Diode(ES1D) [D36,D47] ﾀﾞｲｵｰﾄﾞ

56 VHI63LVD104-1 AZ FQ N B IC(THC63LVD104A) [IC180] IC

57 VHI658920130C AQ EQ N B IC(SC65892) [IC170] IC

58 VHI74LVC14A-1 AE DS B IC(SN74LVC14A) [IC100,IC101,IC102,IC103] IC

VHI74LVC14A-1 AE DS B IC(SN74LVC14A) [IC104,IC105,IC106] IC

59 VHI856320111C BM HV B IC(UPD85632GN-011-LMU-A) [IC166] IC

63 VHIB25BC0FP-1 AG DS N B IC(BA25BC0FP-E2) [IC642] IC

64 VHIC24FC32L-1 AH DX N B IC(CAT24FC32LI) [IC174] IC

65 VHID62503FG-1 AG DS B IC(TD62503FG(EL)) [IC155] IC

66 VHIDS90C385-1 AR EQ N B IC(DS90C385AMTDX) [IC158] IC

67 VHIDS90LV47-1 AL EB N B IC(DS90LV047ATMTCX) [IC178,IC179] IC

– 13 –

8ｽｷｬﾅｰｺﾝﾄﾛｰﾙ基板 (Scanner control PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

69 VHIK78R033P-1 AG DX N B IC(KIA78R33PI/P) [IC171] IC

71 VHIKA7812AP-1 AE DJ B IC(KIA7812API/P) [IC150] IC

72 VHIKIA393F/-1 AK DX B IC(KIA393F) [IC23] IC

73 VHIL1087MAN-1 AF DS B IC(L1087MPX-ADJ) [IC160] IC

74 VHILM324D++-1 AE DJ B IC(LM324D) [IC619] IC

75 VHILVC08APW-1 AD DJ N B IC(SN74LV08APW) [IC144] IC

76 VHIM87S1210-1 BK HC B IC(MB87S1210PMC-G-BNDE1) [IC162] IC

77 VHIC25811SZ-1 AN EB B IC(CY25811) [IC177] IC

78 VHIC25812SZ-1 AL EB B IC(CY25812) [IC163] IC

79 VHITD62003AF/ AE DS B IC(TD62003AF) [IC156] IC

80 VHIVC244APW-1 AE DJ N B IC(SN74LVC244APWR) [IC145,IC147,IC148,IC152] IC

81 VHIVC245APW-1 AE DJ N B IC(SN74LVC245APWR) [IC142,IC186] IC

82 VHPLT1P67A+-1 AC DJ B IC(LT1P67A) [LED1] IC

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R887,R888,R892,R893,R921] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R940,R962,R966,R988,R1023] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R572,R574,R575,R576,R577] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R579,R580,R581,R589,R590] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R591,R593,R594,R595,R596] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R597,R604,R605,R607,R608] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R611,R612,R613,R614,R622] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R623,R625,R626] ﾃｲｺｳ

84 VRS-CY1JD331J AA DD C Resistor(1/16W 330Ω ±5%) [R764,R767,R768,R769] ﾃｲｺｳ

VRS-CY1JD331J AA DD C Resistor(1/16W 330Ω ±5%) [R770,R771] ﾃｲｺｳ

VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R725,R728,R729,R881,R889] ﾃｲｺｳ

VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R890,R891,R902,R903] ﾃｲｺｳ

VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R904,R905] ﾃｲｺｳ

86 VRS-CY1JD201J AA DD C Resistor(1/16W 200Ω ±5%) [R726] ﾃｲｺｳ

VRS-CY1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R862,R863,R864,R865,R866] ﾃｲｺｳ

VRS-CY1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R867,R868,R869,R870,R871] ﾃｲｺｳ

VRS-CY1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R872,R873,R874,R878] ﾃｲｺｳ

VRS-CY1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R879,R880] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R475,R616,R637,R640,R647] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R677,R680,R702,R735,R747] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R759,R765,R773,R779,R780] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R782,R784,R785,R789,R801] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R852,R908,R909,R925,R950] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R951,R972,R973,R974,R976] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R978,R1002,R1006,R743,R744] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R786,R733,R755,R1030,R674] ﾃｲｺｳ

89 VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R848] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R468,R478,R483,R484,R493] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R499,R521,R530,R531,R536] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R538,R557,R587,R600,R618] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R621,R656,R658,R659,R660] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R661,R662,R663,R664,R665] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R666,R667,R703,R712,R731] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R739,R742,R748,R750,R791] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R792,R993,R794,R795,R907] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R922,R941,R949,R952,R953] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R954,R955,R956,R957,R958] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R960,R980,R982,R983,R1004] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R516,R619,R946,R1026,R1027] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R899,R683,R689,R690,R989] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R990,R991] ﾃｲｺｳ

91 VRS-CZ1JD102F AA DD C Resistor(1/16W 1KΩ ±1%) [R497,R545,R553] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R466,R470,R476,R480,R486] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R488,R491,R506,R584,R585] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R606,R649,R985,R986,R1000] ﾃｲｺｳ

93 VRS-CZ1JD103F AA DD C Resistor(1/16W 10KΩ ±1%) [R544,R564] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R465,R469,R474,R479,R481] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R482,R485,R487,R490,R500] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R503,R504,R505,R508,R512] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R513,R518,R532,R534,R540] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R542,R558,R559,R560,R586] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R588,R592,R599,R602,R603] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R609,R629,R630,R657,R670] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R672,R704,R710,R721,R722] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R727,R734,R751,R760,R761] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R762,R763,R774,R775,R790] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R832,R844,R845,R846,R847] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R849,R850,R851,R861,R928] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R942,R968,R984,R987,R998] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R1003,R1025,R838,R839,R840] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R841,R900,R911,R121,R122] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R123,R912] ﾃｲｺｳ

95 VRS-CZ1JD105F AA DD C Resistor(1/16W 1.0MΩ ±1%) [R546,R730,R833] ﾃｲｺｳ

96 VRS-CZ1JD105J AA DD C Resistor(1/16W 1.0MΩ ±5%) [R948,R994,R996] ﾃｲｺｳ

97 VRS-CZ1JD122J AA DD C Resistor(1/16W 1.2KΩ ±5%) [R549,R550,R551,R552,R895] ﾃｲｺｳ

98 VRS-CZ1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R501,R796,R797,R798,R799] ﾃｲｺｳ

VRS-CZ1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R800,R804,R805] ﾃｲｺｳ

– 14 –

8ｽｷｬﾅｰｺﾝﾄﾛｰﾙ基板 (Scanner control PWB)

9ｽｷｬﾝｲﾝ基板 (Scan in PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

99 VRS-CZ1JD202J AA DD C Resistor(1/16W 2.0KΩ ±5%) [R809,R923,R929,R714,R715] ﾃｲｺｳ

100

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R684,R685,R686,R687,R688] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R713,R716,R717,R718,R834] ﾃｲｺｳ

VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R835,R836,R992,R793] ﾃｲｺｳ

101 VRS-CZ1JD221F AA DD C Resistor(1/16W 220Ω ±1%) [R568] ﾃｲｺｳ

102 VRS-CZ1JD243J AA DD C Resistor(1/16W 24KΩ ±5%) [R522] ﾃｲｺｳ

103 VRS-CZ1JD303F AA DD C Resistor(1/16W 30KΩ ±1%) [R803] ﾃｲｺｳ

104 VRS-CZ1JD303J AA DD C Resistor(1/16W 30KΩ ±5%) [R525,R533,R535,R554,R709] ﾃｲｺｳ

VRS-CZ1JD303J AA DD C Resistor(1/16W 30KΩ ±5%) [R807,R894,R896] ﾃｲｺｳ

105 VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R510,R570,R638,R752] ﾃｲｺｳ

106 VRS-CZ1JD331J AA DD C Resistor(1/16W 330Ω ±5%) [R740] ﾃｲｺｳ

107 VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R526,R528,R969,R970,R741] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R711,R766] ﾃｲｺｳ

108

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R467,R498,R509,R537,R547] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R548,R578,R582,R583,R601] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R620,R655,R806,R808,R813] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R924,R926,R947,R981,R515] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R520,R555] ﾃｲｺｳ

109

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R644,R645,R646,R681] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R694,R695,R696,R697] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R700,R701,R705] ﾃｲｺｳ

110 VRS-CZ1JD511F AA DD C Resistor(1/16W 510Ω ±1%) [R569] ﾃｲｺｳ

111 VRS-CZ1JD562J AA DD C Resistor(1/16W 5.6KΩ ±5%) [R561,R562,R563,R810] ﾃｲｺｳ

VRS-CZ1JD562J AA DD C Resistor(1/16W 5.6KΩ ±5%) [R812,R927,R943] ﾃｲｺｳ

112 VRS-CZ1JD624J AA DD C Resistor(1/16W 620KΩ ±5%) [R511] ﾃｲｺｳ

113 VRS-CZ1JD752J AA DD C Resistor(1/16W 7.5KΩ ±5%) [R502] ﾃｲｺｳ

114 VRSRCZ1JD561J AA DD C Resistor(1/16W 560Ω ±5%) [R967,R997] ﾃｲｺｳ

115 VRS-RE3AAR39J AB DD C Resistor(1W 0.39Ω ±5%) [R517,R523] ﾃｲｺｳ

116 VRS-TP2BD000J AA DD C Resistor(1/8W 0Ω ±5%) [R853,R856,R936,R939] ﾃｲｺｳ

117 VRS-TP2BD151J AA DD C Resistor(1/8W 150Ω ±5%) [R567,R756,R757,R758] ﾃｲｺｳ

119 VS2SB1197KR-1 AC DJ B Transistor(2SB1197K) [Q15,Q16,Q17] ﾄﾗﾝｼﾞｽﾀｰ

120 VS2SC2412KS-1 AB DD B Transistor(2SC2412KS) [Q41] ﾄﾗﾝｼﾞｽﾀｰ

121 VSKRA102S//-1 AD DJ B Transistor(KRA102S-RTK/P) [Q24,Q25,Q26] ﾄﾗﾝｼﾞｽﾀｰ

124 VSTPC8010HQ-1 AG DS B Transistor(TPC8010-H) [Q10,Q38] ﾄﾗﾝｼﾞｽﾀｰ

126 VSUPA502TA+-1 AD DJ B Transistor(uPA502T-T1) [Q28] ﾄﾗﾝｼﾞｽﾀｰ

(Unit)

901 CPWBX1713DS548 CD UD E Scanner control PWB [MX-2300G/FG/N] ｽｷｬﾅｰｺﾝﾄﾛｰﾙ基板

CPWBX1713DS518 CD UD E Scanner control PWB [MX-2700G/FG/N] ｽｷｬﾅｰｺﾝﾄﾛｰﾙ基板

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR1,BR2,BR3,BR4,BR5,BR6] ﾌﾞﾛｯｸﾃｲｺｳ

2QCNCW0153QSPZ AK DX C Connector(TX24-30R-12ST-H1E) [CN5] ｺﾈｸﾀｰ

3QPIN-0011FCPZ AF DS N C Pin(RE-H082TD-1130) [CN1] ﾋﾟﾝ

4QCNCM1354FCPZ AD DJ N C Connector(B15B-PH-K-S) [CN3] ｺﾈｸﾀｰ

5QCNCM0156QSPZ AD DJ N C Connector(B12B-PHDSS-B) [CN4] ｺﾈｸﾀｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C1,C2,C3,C4,C5] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C9,C10,C11,C12,C13] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C16,C17,C20,C21,C22] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C24,C25,C31,C32,C33] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C34,C35,C37,C38,C41] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C42,C43,C46,C47,C49] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C51,C52,C53,C54] ｺﾝﾃﾞﾝｻｰ

7VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C7,C56] ｺﾝﾃﾞﾝｻｰ

8VCKYCZ1EB103K AB DD C Capacitor(25WV 0.01µF) [C6,C19,C44,C55] ｺﾝﾃﾞﾝｻｰ

9VCEASX1CN107M AF DS C Capacitor(16WV 100µF) [C8,C36] ｺﾝﾃﾞﾝｻｰ

10 VCKYCZ1HB222K AA DD C Capacitor(50WV 2200pF) [C14,C18,C29] ｺﾝﾃﾞﾝｻｰ

11 VHIDS90C385-1 AR EQ N B IC(DS90C385A) [IC3] IC

12 VHIPT591IMT-1 AF DS B IC(PST591IMT) [IC1] IC

13 RH-IX0022FCPZ AU EZ N B IC(LC4128V-75TN100C) [IC2] IC

14 VHIDS90C386-1 AR EQ N B IC(DS90CF386) [IC5] IC

16 VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R3,R5,R10,R14,R26,R33] ﾃｲｺｳ

17 VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R20,R22,R24,R25,R27] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R2,R11,R12,R13,R15] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R16,R19,R28,R29,R34] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R35,R36,R37,R43,R44] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R45,R46,R47,R48] ﾃｲｺｳ

19 VRS-CZ1JD104J AA DD C Resistor(1/16W 100KΩ ±5%) [R50] ﾃｲｺｳ

20 VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R1,R6,R7,R8,R9] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R18,R21,R30,R31,R32] ﾃｲｺｳ

(Unit)

901 CPWBX1712FCE1 BG GN E Scan in PWB ｽｷｬﾝｲﾝ基板

– 15 –

Fﾏｻﾞｰ基板 (Mother PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1QJAKT0002FCPZ AE DJ N C Modular Jack(MJ-66J-RD315) [CN1] ｼﾞｬｯｸ

2QCNCW1170FCPZ AG DS N C Connector(28FMZ-BT) [CN2] ｺﾈｸﾀｰ

5QCNCM0168QSPZ AB DJ N C Connector(B4B-PH-K-S) [CN13,CN14] ｺﾈｸﾀｰ

6QCNCM0170QSPZ AC DJ N C Connector(B6B-PH-K-S) [CN9] ｺﾈｸﾀｰ

7QCNCM1354FCPZ AD DJ N C Connector(B15B-PH-K-S) [CN5] ｺﾈｸﾀｰ

8QCNCM0155QSPZ AC DJ N C Connector(B10B-PHDSS-B) [CN17] ｺﾈｸﾀｰ

9QCNCM0156QSPZ AD DJ N C Connector(B12B-PHDSS-B) [CN19] ｺﾈｸﾀｰ

10 QCNCM0160QSPZ AE DJ N C Connector(B22B-PHDSS-B) [CN6] ｺﾈｸﾀｰ

11 QCNCM0877FCPZ AD DJ N C Connector(B20B-PHDSS-B) [CN7] ｺﾈｸﾀｰ

12 QCNCM0878FCPZ AE DS N C Connector(B30B-PHDSS-B) [CN3] ｺﾈｸﾀｰ

13 QCNCM1348FCPZ AE DJ N C Connector(B32B-PHDSS-B) [CN8] ｺﾈｸﾀｰ

14 QCNCM1356FCPZ AC DJ N C Connector(B06B-XASK-1) [CN10] ｺﾈｸﾀｰ

16 QCNCM1069ACPZ AD DJ N C Connector(B6P-VH) [CN11] ｺﾈｸﾀｰ

17 QCNCM0787FCPZ AE DS N C Connector(B10P-VH-B) [CN12] ｺﾈｸﾀｰ

18 QPIN-0003GCPZ AC DJ C Pin(T3B-SQ) [JP11] ﾋﾟﾝ

19 PCAPH0010GCPZ AC DJ D Cap(JM-2W-96) [JP11] ｷｬｯﾌﾟ

20 VCKYCZ1EF223Z AA DD C Capacitor(25WV 0.022µF) [C15] ｺﾝﾃﾞﾝｻｰ

21 VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C8,C9,C11,C19,C25] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C1,C2,C6,C7,C10] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C12,C20,C21,C22,C26] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C100,C101,C102] ｺﾝﾃﾞﾝｻｰ

23 VCCCCZ1HH150J AA DD C Capacitor(50WV 15pF) [C13,C14] ｺﾝﾃﾞﾝｻｰ

24 VCEASM1CM106M AB DD C Capacitor(16WV 10µF) [C16,C24] ｺﾝﾃﾞﾝｻｰ

25 VCEASX1CN226M AC DD C Capacitor(16WV 22µF) [C4,C17,C18,C23] ｺﾝﾃﾞﾝｻｰ

26 RC-EZ0357FCPZ AD DD C Capacitor(16WV 470µF) [C3] ｺﾝﾃﾞﾝｻｰ

27 VHDDAN202U/-1 AB DD B Diode(DAN202U) [D2,D5] ﾀﾞｲｵｰﾄﾞ

28 VHDDA204U//-1 AB DD B Diode(DA204U) [D3,D6,D8,D9,D10] ﾀﾞｲｵｰﾄﾞ

VHDDA204U//-1 AB DD B Diode(DA204U) [D11,D13] ﾀﾞｲｵｰﾄﾞ

29 VHDRLS73///-1 AA DD B Diode(RLS73) [D4] ﾀﾞｲｵｰﾄﾞ

32 RH-IX0013FCP1 AW FG N B IC(PIC16F870-I/SOG) [IC2] IC

VSDTC114EUA-1 AC DJ B Transistor(DTC114EUA) [Q1,Q2,Q8,Q9,Q10] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC114EUA-1 AC DJ B Transistor(DTC114EUA) [Q11,Q13,Q14,Q16,Q17] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC114EUA-1 AC DJ B Transistor(DTC114EUA) [Q21,Q22] ﾄﾗﾝｼﾞｽﾀｰ

36 VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [Q3,Q4,Q12,Q18,Q20] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [Q23,Q100,Q102,Q103] ﾄﾗﾝｼﾞｽﾀｰ

37 VSDTA143ZUA-1 AB DJ B Transistor(DTA143ZUA) [Q7,Q101] ﾄﾗﾝｼﾞｽﾀｰ

38 VS2SC4081-/-1 AC DD B Transistor(2SC4081) [Q19] ﾄﾗﾝｼﾞｽﾀｰ

39 VSTPC8010HQ-1 AG DS B Transistor(TPC8010-H) [Q15] ﾄﾗﾝｼﾞｽﾀｰ

40 VS2SK3018++-1 AC DJ B Transistor(2SK3018) [Q106] ﾄﾗﾝｼﾞｽﾀｰ

41 VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R12,R36,R39,R41,R43,R51] ﾃｲｺｳ

42 VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R52,R53,R215] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R2,R3,R6,R8,R9] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R19,R20,R21,R25,R26] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R27,R38,R42,R46,R56] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R57,R200,R201,R217,R218] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R5,R14,R15,R16,R22] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R23,R34,R47,R48,R55] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R202,R208,R209,R216] ﾃｲｺｳ

45 VRS-CZ1JD104J AA DD C Resistor(1/16W 100KΩ ±5%) [R17,R18,R204,R205,R206] ﾃｲｺｳ

VRS-CZ1JD104J AA DD C Resistor(1/16W 100KΩ ±5%) [R207,R226] ﾃｲｺｳ

46 VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R214,R225] ﾃｲｺｳ

47 VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R4,R37,R45,R49] ﾃｲｺｳ

48 VRS-TP2BD102J AA DD C Resistor(1/8W 1.0KΩ ±5%) [R24] ﾃｲｺｳ

49 VRS-TP2BD103J AA DD C Resistor(1/8W 10KΩ ±5%) [R29,R30] ﾃｲｺｳ

(Unit)

901 CPWBX1672FCE2 BL HL E Mother PWB ﾏｻﾞｰ基板

– 16 –

GLVDS 基板 (LVDS PWB)

HLSU ｺﾝﾄﾛｰﾙ基板 (LSU control PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

4QCNCW1303FCPZ AE DS N C Connector(04FM-1.0SP-1.9-GW-TF) [CN4] ｺﾈｸﾀｰ

5VHIDS90C386-1 AR EQ N B IC(DS90CF386MTDX) [IC1] IC

6VHINJ2360AM-1 AG DX B IC(NJM2360AM) [IC2] IC

7VHILM358DR+-1 AF DS B IC(LM358D) [IC3] IC

8VHDES1D++++-1 AC DJ B Diode(ES1D) [D1] ﾀﾞｲｵｰﾄﾞ

11 RFILN5022NCZZ AC DJ C EMI filter(BLM11A12PT) [L1,L2] EMI ﾌｨﾙﾀｰ

13 VCEASX1HN106M AC DD N C Capacitor(16WV 10µF) [C7] ｺﾝﾃﾞﾝｻｰ

14 VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C1] ｺﾝﾃﾞﾝｻｰ

15 VCKYCZ1CB103K AA DD C Capacitor(16WV 0.010µF) [C2,C5] ｺﾝﾃﾞﾝｻｰ

16 VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C3,C8,C4] ｺﾝﾃﾞﾝｻｰ

17 VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C11] ｺﾝﾃﾞﾝｻｰ

18 VCKYCZ1HB331K AA DD C Capacitor(50WV 330pF) [C9] ｺﾝﾃﾞﾝｻｰ

19 VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R15,R13,R18] ﾃｲｺｳ

20 VRS-CZ1JD331F AA DD C Resistor(1/16W 330Ω ±1%) [R1,R2,R3,R4] ﾃｲｺｳ

21 VRS-CZ1JD750J AA DD C Resistor(1/16W 75Ω ±5%) [R7,R16] ﾃｲｺｳ

22 VRS-CZ1JD242F AA DD C Resistor(1/16W 2.4KΩ ±1%) [R14] ﾃｲｺｳ

24 VRS-CZ1JD243F AA DD C Resistor(1/16W 24KΩ ±1%) [R8] ﾃｲｺｳ

26 VCKYCZ1HB222K AA DD C Capacitor(50WV 2200pF) [C14] ｺﾝﾃﾞﾝｻｰ

27 VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C13,C15,C16] ｺﾝﾃﾞﾝｻｰ

(Unit)

901 CPWBN1659FCE1 AZ FX E LVDS PWB LVDS 基板

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1VHIM4U2088C0C BC GD N B IC(KS6M4U2088CBP) [IC9] IC

5QCNCM7014SC0C AA DD C Connector(3pin) [CN2] ｺﾈｸﾀｰ

6QCNCM7014SC0F AB DD C Connector(6pin) [CN8] ｺﾈｸﾀｰ

7QCNCM7014SC0G AB DD C Connector(7pin) [CN6] ｺﾈｸﾀｰ

8QCNCM2649RC0F AE DJ N C Connector(6pin) [CN9] ｺﾈｸﾀｰ

9QCNCM0923FC12 AE DJ C Connector(12pin) [CN1] ｺﾈｸﾀｰ

10 QCNCM1176FCZZ AF DS C Connector(20pin) [CN5] ｺﾈｸﾀｰ

11 QCNCM0998FCZZ AF DS C Connector(22pin) [CN3] ｺﾈｸﾀｰ

12 QCNCM0923FC3D AF DS C Connector(34pin) [CN4] ｺﾈｸﾀｰ

13 QCNCM0923FC10 AE DJ C Connector(10pin) [CN7] ｺﾈｸﾀｰ

14 VHI74LVC14A-1 AE DS B IC(SN74LVC14A) [IC11,IC16] IC

15 VHILVC74APW-1 AD DJ N B IC(SN74LVC74APWR) [IC14,IC15] IC

16 VHILVC08APW-1 AD DJ N B IC(SN74LVC08APWR) [IC13] IC

17 VHIKIA358F+-1 AE DS B IC(KIA358F) [IC1] IC

18 VHIDS90LV47-1 AL EB N B IC(DS90LV047ATMTCX/NOPB) [IC7,IC12] IC

19 VHIDS90C386-1 AR EQ N B IC(DS90CF386MTDX/NOPB) [IC3] IC

20 VHIBU2500FV-1 AL EB N B IC(BU2500FV-E2) [IC8] IC

21 VHIL1087MAN-1 AF DS B IC(L1087MPX_ADJ/NOPB) [IC10,IC18] IC

22 VHIM51957BFP1 AH DX B IC(M51957BFP1) [IC17] IC

24 VHID65503F+-1 AG DS B IC(D65503F) [IC4] IC

27 VSKRC106S++-1 AB DJ B Transistor(KRC106S) [Q1] ﾄﾗﾝｼﾞｽﾀｰ

28 RMPTR4101ACZZ AB DD B Block resistor(100Ω×4) [BR7,BR8,BR9] ﾌﾞﾛｯｸﾃｲｺｳ

29 RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR1,BR2,BR3,BR4,BR5,BR6] ﾌﾞﾛｯｸﾃｲｺｳ

30 VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R2,R94,R95,R96,R97,R118] ﾃｲｺｳ

31 VRS-CZ1JD103F AA DD C Resistor(1/16W 10KΩ ±1%) [R1,R30,R119,R134,R136,R144] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R25,R28,R29,R42,R43] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R44,R45,R69,R72,R74] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R83,R86,R87,R88,R89] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R101,R105,R115,R116,R117] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R120,R121,R124,R155] ﾃｲｺｳ

33 VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R122,R126,R127,R129] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R32,R33,R34,R35,R36] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R37,R38,R39,R40,R41] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R46,R47,R48,R50,R77] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R84,R85,R90,R107,R109] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R110,R123,R125,R128,R131] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R132,R149,R150,R151] ﾃｲｺｳ

35 VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R15,R31,R75,R78,R81] ﾃｲｺｳ

VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R106,R114,R148] ﾃｲｺｳ

38 VRS-CZ1JD202J AA DD C Resistor(1/16W 2.0KΩ ±5%) [R26,R82,R137,R138,R143] ﾃｲｺｳ

VRS-CZ1JD202J AA DD C Resistor(1/16W 2.0KΩ ±5%) [R152,R153] ﾃｲｺｳ

39 VRS-CZ1JD102F AA DD C Resistor(1/16W 1KΩ ±1%) [R4,R10,R57,R93] ﾃｲｺｳ

40 VRS-CZ1JD181F AA DD C Resistor(1/16W 180Ω ±1%) [R3,R9,R52,R91] ﾃｲｺｳ

41 VRS-CZ1JD123F AA DD C Resistor(1/16W 12KΩ ±1%) [R62,R63,R68,R100] ﾃｲｺｳ

42 VRS-CZ1JD182J AA DD C Resistor(1/16W 1.8KΩ ±5%) [R61,R65,R66,R99] ﾃｲｺｳ

43 VRS-CZ1JD112J AA DD C Resistor(1/16W 1.1KΩ ±5%) [R60,R64,R67,R98] ﾃｲｺｳ

44 VRS-CZ1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R76,R139,R141,R145] ﾃｲｺｳ

45 VRS-CZ1JD201F AA DD C Resistor(1/16W 200Ω ±1%) [R6,R12,R51,R53] ﾃｲｺｳ

46 VRS-CZ1JD512J AA DD C Resistor(1/16W 5.1KΩ ±5%) [R7,R13,R54,R58] ﾃｲｺｳ

47 VRS-CZ1JD105J AA DD C Resistor(1/16W 1.0MΩ ±5%) [R79] ﾃｲｺｳ

– 17 –

HLSU ｺﾝﾄﾛｰﾙ基板 (LSU control PWB)

IFAX ﾒｲﾝ基板 (FAX main PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C2,C3,C4,C5,C7] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C8,C9,C12,C16,C21] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C22,C26,C33,C34,C36] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C38,C39,C42,C43,C44] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C45,C51,C52,C53,C57] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C58,C59,C60,C63,C64] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C65,C66,C67,C68,C69] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C70,C71,C72,C73,C74] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C75,C76,C78,C79,C81] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C82,C87,C88,C89,C90] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C91,C92,C94,C95,C101] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C106,C107,C108,C109,C110] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C111,C118,C119,C120,C123] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C124,C126,C127,C128,C129] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C130,C131,C132,C133,C134] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C136,C137,C138,C142,C143] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C144,C145,C147,C148,C151] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C156,C158,C159,C160,C161] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C163,C166,C167,C168,C169] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C171,C172,C173,C174,C175] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C176,C177,C154,C155] ｺﾝﾃﾞﾝｻｰ

49 VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C85,C98,C99,C102,C150,C153] ｺﾝﾃﾞﾝｻｰ

50 VCKYTV1AB225K AC DD C Capacitor(10WV 2.2µF) [C13,C17,C19,C23,C27,C49] ｺﾝﾃﾞﾝｻｰ

VCKYTV1AB225K AC DD C Capacitor(10WV 2.2µF) [C50,C103,C104,C116,C117] ｺﾝﾃﾞﾝｻｰ

51 VCCCCZ1HH100D AA DD C Capacitor(50WV 10pF) [C31,C84] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CB103K AA DD C Capacitor(16WV 0.010µF) [C10,C18,C28,C37,C40] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CB103K AA DD C Capacitor(16WV 0.010µF) [C47,C83,C86,C93,C97] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CB103K AA DD C Capacitor(16WV 0.010µF) [C100,C115] ｺﾝﾃﾞﾝｻｰ

53 VCCCCZ1HH151J AC DD C Capacitor(50WV 150pF) [C122,C162,C164,C165] ｺﾝﾃﾞﾝｻｰ

54 VCKYTV0JB106M AF DS C Capacitor(6.3WV 10µF) [C61,C62,C139,C140] ｺﾝﾃﾞﾝｻｰ

55 VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C14,C24,C46,C48] ｺﾝﾃﾞﾝｻｰ

56 VCEASX1HN106M AC DD N C Capacitor(50WV 10µF) [C179] ｺﾝﾃﾞﾝｻｰ

57 VCEASX1CN476M AC DD C Capacitor(16WV 47µF) [C146,C178] ｺﾝﾃﾞﾝｻｰ

58 VCEASX1VN226M AC DD N C Capacitor(35WV 22µF) [C152,C181] ｺﾝﾃﾞﾝｻｰ

59 VHDKDS121++-1 AC DJ B Diode(KDS121) [D2,D8,D9] ﾀﾞｲｵｰﾄﾞ

60 VHDKDS120++-1 AC DJ B Diode(KDS120) [D1,D6,D7] ﾀﾞｲｵｰﾄﾞ

61 VHD1SS355//-1 AB DJ B Diode(1SS355) [D3,D4,D5,D11] ﾀﾞｲｵｰﾄﾞ

62 RFILN0053FCZZ AA DJ C Filter(BLM18PG121SN1D) [L5,L12,L13,L17] ﾌｨﾙﾀｰ

65 RFILN5022NCZZ AC DJ C EMI filter(BLM11A12PT) [L1,L2,L3,L4,L6] EMI ﾌｨﾙﾀｰ

RFILN5022NCZZ AC DJ C EMI filter(BLM11A12PT) [L7,L8,L10,L11] EMI ﾌｨﾙﾀｰ

!66 QFS-L0004QSPZ AD DJ A Fuse(TR/0603FA2.5A-T) [F2] ﾋｭｰｽﾞ

!67 QFS-L0002QSZZ AD DD A Fuse(TR/0603FA1.5A-T) [F1] ﾋｭｰｽﾞ

(Unit)

901 CPWBX1662DS53 BR LX E LSU control PWB [MX-2300G/FG/N] LSU ｺﾝﾄﾛｰﾙ基板

CPWBX1662DS51 BR LX E LSU control PWB [MX-2700G/FG/N] LSU ｺﾝﾄﾛｰﾙ基板

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1QCNCM1315FCPZ AK DX C Connector(TX25-40P-8ST-H1) [CN7] ｺﾈｸﾀｰ

2QCNCM2654SCPZ AF DS C Connector(S32B-PHDSS-B) [CN3] ｺﾈｸﾀｰ

3QCNCM0042ESPZ AB DJ C Connector(B3B-PH-K-S) [CN2] ｺﾈｸﾀｰ

4QSOCZ0095FCPZ AR EQ C Socket(5179707-1) [CN1] ｿｹｯﾄ

5RCRSP0069FCPZ BA FX B Crystal(14.7456MHz) [X3] ｸﾘｽﾀﾙ

6RCRUA0030FCPZ BE GN B Crystal(24.576MHz) [X2] ｸﾘｽﾀﾙ

7RFILN0309FCPZ AC DJ C Filter(ZBF503D-00) [FL2] ﾌｨﾙﾀｰ

8RFILN0310FCPZ AC DJ C Filter(ZJSR5101-331) [FL4] ﾌｨﾙﾀｰ

9RH-IX0014FCPZ BD GN B IC(HD6417706F133V) [IC15] IC

10 RH-IX0015FCPZ AX FG B IC(HY57V641620) [IC2,IC1] IC

RMPTR4220ACZZ AB DD B Block resistor(22Ω×4) [BR29,BR30,BR31,BR32,BR33] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4220ACZZ AB DD B Block resistor(22Ω×4) [BR34,BR35,BR36,BR37,BR38] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4220ACZZ AB DD B Block resistor(22Ω×4) [BR42,BR43,BR44,BR45] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4470ACZZ AB DD B Block resistor(47Ω×4) [BR1,BR2,BR3,BR4,BR5,BR6] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4470ACZZ AB DD B Block resistor(47Ω×4) [BR8,BR9,BR10,BR11,BR12] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4470ACZZ AB DD B Block resistor(47Ω×4) [BR13,BR14,BR15,BR16,BR17] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4470ACZZ AB DD B Block resistor(47Ω×4) [BR21,BR22,BR23,BR24,BR25] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4470ACZZ AB DD B Block resistor(47Ω×4) [BR26,BR27,BR28,BR39,BR40] ﾌﾞﾛｯｸﾃｲｺｳ

RMPTR4470ACZZ AB DD B Block resistor(47Ω×4) [BR41,BR46,BR47,BR48] ﾌﾞﾛｯｸﾃｲｺｳ

13 VCCCCZ1HH270J AA DD C Capacitor(50WV 27pF) [C225,C224] ｺﾝﾃﾞﾝｻｰ

14 VCEASM1CM106M AB DD C Capacitor(16WV 10µF) [C10,C38,C97,C129,C139] ｺﾝﾃﾞﾝｻｰ

VCEASM1CM106M AB DD C Capacitor(16WV 10µF) [C145,C241,C242,C245,C251] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C1,C3,C4,C5,C9,C12,C14] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C16,C18,C19,C21,C22,C53] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C74,C76,C79,C121,C123] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C125,C127,C169,C170,C171] ｺﾝﾃﾞﾝｻｰ

VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C172,C174,C175,C212,C214] ｺﾝﾃﾞﾝｻｰ

– 18 –

IFAX ﾒｲﾝ基板 (FAX main PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

17 VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C215,C255] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C2,C6,C7,C8,C11,C13,C15] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C17,C23,C25,C26,C27,C28] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C29,C30,C31,C32,C34,C35] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C36,C37,C39,C40,C41,C42] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C43,C44,C45,C46,C47,C48] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C49,C51,C52,C54,C55,C56] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C57,C58,C59,C60,C61,C62] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C63,C64,C65,C66,C67,C68] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C69,C73,C78,C80,C81,C82] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C83,C84,C85,C86,C87,C88] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C89,C90,C91,C92,C93,C94] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C95,C96,C98,C99,C100,C101] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C102,C103,C104,C105,C106] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C107,C108,C111,C112,C117] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C118,C120,C122,C130,C131] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C132,C133,C134,C135,C136] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C137,C138,C141,C143,C144] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C147,C150,C151,C152,C153] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C154,C155,C156,C157,C158] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C159,C160,C161,C162,C164] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C165,C166,C168,C177,C178] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C179,C180,C182,C184,C186] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C187,C188,C190,C191,C192] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C193,C194,C195,C196,C198] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C199,C200,C201,C202,C203] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C204,C206,C207,C208,C209] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C210,C211,C222,C223,C226] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C227,C228,C229,C232,C233] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C234,C237,C238,C239,C240] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C243,C244,C246,C247,C248] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C249,C250,C252,C253,C254] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C262,C267,C268,C269,C270] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C271,C272] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C70,C71,C72,C113,C114] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C115,C116,C119,C124,C146] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C148,C149,C163,C181,C183] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C185,C216,C217,C221,C256] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C257,C258,C259,C260,C261] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C263,C264,C265,C266] ｺﾝﾃﾞﾝｻｰ

20 VCKYCZ1HB222K AA DD C Capacitor(50WV 2200pF) [C173] ｺﾝﾃﾞﾝｻｰ

21 VCKYCZ1HB471K AA DD C Capacitor(50WV 470pF) [C140,C230,C231] ｺﾝﾃﾞﾝｻｰ

22 VCKYCZ1HB472K AA DD C Capacitor(50WV 4700pF) [C176] ｺﾝﾃﾞﾝｻｰ

23 VCKYCY1HB273K AC DD C Capacitor(50WV 0.027µF) [C75] ｺﾝﾃﾞﾝｻｰ

24 VHD1SS355//-1 AB DJ B Diode(1SS355) [D2,D5] ﾀﾞｲｵｰﾄﾞ

25 VHDDA204K//-1 AC DD B Diode(DA204K) [D1,D3,D4,D6] ﾀﾞｲｵｰﾄﾞ

26 VHI16F627AG-1 AR EQ B IC(PIC16F627AG) [IC16] IC

27 VHI87F4930E1C AZ FQ B IC(MB87F4930) [IC12] IC

28 VHIBU4066FV-1 AL EB B IC(BU4066F) [IC14] IC

29 VHIC24WC02L-1 AF DS B IC(CAT24WC02LI) [IC3] IC

30 VHILM1117DJ-1 AG DX B IC(LM1117DTX-ADJ) [IC19] IC

31 VHILVC1G00C-1 AD DJ B IC(SN74LVC1G00DCKR) [IC7] IC

32 VHIC25811SZ-1 AN EB B IC(CY25811SXCT) [IC18] IC

33 VHIN195006E-1 BK HC B IC(MN195006E) [IC10] IC

34 VHINJM2113M-1 AG DS B IC(NJM2113-M) [IC6] IC

35 VHINJM3414M-1 AF DX B IC(NJM3414M) [IC9] IC

36 VHIPT591IMT-1 AF DS B IC(PST591IMT) [IC20] IC

37 VHISLV14APW-1 AE DJ B IC(74LV14) [IC8,IC11,IC13,IC17] IC

38 VHPSLR322VC3F AC DJ B LED(Red)(SLR322VC3F) [ED2] LED

39 VRS-CY1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R257,R256] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [C110,R149,R211,R217,R223] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R225,R231,R233,R237,R259] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R260,R261,R262,R263,R268] ﾃｲｺｳ

VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R269,R270,R281,R284,R285] ﾃｲｺｳ

41 VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R16,R114,R165] ﾃｲｺｳ

42 VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R126,R111] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R12,R47,R48,R82,R84] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R88,R89,R95,R109] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R113,R115,R132,R138] ﾃｲｺｳ

VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R139,R196,R228] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R11,R54,R87,R90,R91,R96] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R97,R98,R127,R134,R158] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R191,R201,R203,R205,R206] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R210,R224,R236,R265,R267] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R286] ﾃｲｺｳ

45 VRS-CZ1JD104J AA DD C Resistor(1/16W 100KΩ ±5%) [R53] ﾃｲｺｳ

46 VRS-CZ1JD105J AA DD C Resistor(1/16W 1.0MΩ ±5%) [R4] ﾃｲｺｳ

48 VRS-CZ1JD122J AA DD C Resistor(1/16W 1.2KΩ ±5%) [R202] ﾃｲｺｳ

50 VRS-CZ1JD201J AA DD C Resistor(1/16W 200Ω ±5%) [R43,R44,R45,R46,R60,R61] ﾃｲｺｳ

VRS-CZ1JD201J AA DD C Resistor(1/16W 200Ω ±5%) [R62,R63] ﾃｲｺｳ

– 19 –

IFAX ﾒｲﾝ基板 (FAX main PWB)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

51 VRS-CZ1JD202J AA DD C Resistor(1/16W 2.0KΩ ±5%) [R227] ﾃｲｺｳ

52 VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R272,R271] ﾃｲｺｳ

53 VRS-CZ1JD242J AA DD C Resistor(1/16W 2.4KΩ ±5%) [R204,R142] ﾃｲｺｳ

54 VRS-CZ1JD271J AA DD C Resistor(1/16W 270Ω ±5%) [R108] ﾃｲｺｳ

55 VRS-CZ1JD272J AA DD C Resistor(1/16W 2.7KΩ ±5%) [R105,R106,R107,R110] ﾃｲｺｳ

VRS-CZ1JD272J AA DD C Resistor(1/16W 2.7KΩ ±5%) [R162,R164] ﾃｲｺｳ

57 VRS-CZ1JD303J AA DD C Resistor(1/16W 30KΩ ±5%) [R52] ﾃｲｺｳ

58 VRS-CZ1JD331F AA DD C Resistor(1/16W 330Ω ±1%) [R25] ﾃｲｺｳ

59 VRS-CZ1JD332J AA DD C Resistor(1/16W 3.3KΩ ±5%) [R140] ﾃｲｺｳ

60 VRS-CZ1JD391F AA DD C Resistor(1/16W 390Ω ±1%) [R23] ﾃｲｺｳ

61 VRS-CZ1JD393J AA DD C Resistor(1/16W 39KΩ ±5%) [R136] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R5,R7,R17,R18,R19,R20,R21] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R22,R27,R29,R32,R34,R35] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R36,R37,R38,R40,R41,R42] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R49,R50,R51,R56,R59,R64] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R65,R66,R71,R72,R73,R75] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R76,R78,R80,R81,R83,R92] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R93,R94,R99,R100,R101] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R118,R119,R120,R130,R131] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R148,R152,R154,R156,R157] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R167,R168,R170,R171,R172] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R173,R174,R175,R176,R177] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R178,R179,R180,R181,R186] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R187,R197,R198,R199,R200] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R207,R209,R213,R215,R216] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R218,R220,R222,R226,R235] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R238,R239,R242,R243,R244] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R245,R246,R247,R248,R264] ﾃｲｺｳ

VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R266] ﾃｲｺｳ

63 VRS-CZ1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R1,R2,R3] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R6,R10,R14,R15,R39] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R55,R68,R85,R86] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R102,R103,R104,R112] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R116,R117,R121,R122] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R123,R124,R125,R128] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R129,R135,R153,R155] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R159,R160,R161,R163] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R166,R169,R182,R183] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R184,R185,R194,R208] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R212,R214,R219,R221] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R230,R240,R241,R251] ﾃｲｺｳ

VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R254,R255] ﾃｲｺｳ

65 VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R57,R141,R143,R144,R145] ﾃｲｺｳ

VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R146,R147,R151] ﾃｲｺｳ

67 VRS-CZ1JD513J AA DD C Resistor(1/16W 51KΩ ±5%) [R137] ﾃｲｺｳ

69 VRS-CZ1JD752J AA DD C Resistor(1/16W 7.5KΩ ±5%) [R133] ﾃｲｺｳ

70 VRS-CZ1JD820J AA DD C Resistor(1/16W 82Ω ±5%) [R190,R192,R258] ﾃｲｺｳ

VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [TR2,TR3,TR4,TR5,TR6,TR7] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [TR8,TR9,TR10,TR11,TR12] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [TR14,TR15,TR16,TR17,TR18] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [TR19,TR20,TR21,TR22,TR24] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [TR25,TR26,TR27,TR28,TR29] ﾄﾗﾝｼﾞｽﾀｰ

VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [TR30,TR31,TR32,TR33] ﾄﾗﾝｼﾞｽﾀｰ

72 VSSSM3J05FF-1 AD DJ B Transistor(SSM3J05FU) [TR1] ﾄﾗﾝｼﾞｽﾀｰ

73 RFILN0317FCPZ AD DJ C Filter(MEM2012P101R0) [FB7] ﾌｨﾙﾀｰ

74 RFILN0308FCPZ AG DX C Filter(TCM2010-201-4P) [FB1,FB4] ﾌｨﾙﾀｰ

75 LHLDW2135SCZZ AB DD C PWB holder(KGLS-6RT) [SP1] 基板ﾎﾙﾀﾞｰ

(Unit)

901 CPWBX1647FCE3 BZ TR E FAX main PWB FAX ﾒｲﾝ基板

– 20 –

JLIU 基板 (LIU PWB)...(for MX-FLX1)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1QCNCW1316FCPZ AK DX C Connector(TX24-40R-10ST-H1) [CN2] ｺﾈｸﾀｰ

3VCFYPU2EA474K AF DS C Capacitor(250WV 0.47µF) [C6] ｺﾝﾃﾞﾝｻｰ

4VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C8,C26,C27,C57,C58] ｺﾝﾃﾞﾝｻｰ

5VCKYTV1CB684K AC DD C Capacitor(16WV 0.68µF) [C15] ｺﾝﾃﾞﾝｻｰ

6VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C16,C42,C46,C62] ｺﾝﾃﾞﾝｻｰ

8VCKYTW1HB104K AC DD C Capacitor(50WV 0.1µF) [C20] ｺﾝﾃﾞﾝｻｰ

9VCKYCY1HB332K AA DD C Capacitor(50WV 3300pF) [C21,C24] ｺﾝﾃﾞﾝｻｰ

10 VCKYCY1HB182K AA DD C Capacitor(50WV 1800pF) [C22] ｺﾝﾃﾞﾝｻｰ

11 VCKYTV1HB224K AC DD C Capacitor(50WV 0.22µF) [C41,C23] ｺﾝﾃﾞﾝｻｰ

12 VCKYCY1HB103K AA DD C Capacitor(50WV 0.01µF) [C25] ｺﾝﾃﾞﾝｻｰ

14 VCCCCY1HH100D AA DD C Capacitor(50WV 10pF) [C43] ｺﾝﾃﾞﾝｻｰ

16 VCKYTV1CB105K AC DD C Capacitor(16WV 1µF) [C45] ｺﾝﾃﾞﾝｻｰ

17 VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C49] ｺﾝﾃﾞﾝｻｰ

19 VCKYCY1HF104Z AA DD C Capacitor(50WV 0.10µF) [C70] ｺﾝﾃﾞﾝｻｰ

20 VHD1SS355//-1 AB DJ B Diode(1SS355) [D3] ﾀﾞｲｵｰﾄﾞ

21 VHDS1ZB60//-1 AC DJ B Diode(S1ZB60) [D6] ﾀﾞｲｵｰﾄﾞ

22 VHDDAN217//-1 AC DD B Diode(DAN217) [D10,D9] ﾀﾞｲｵｰﾄﾞ

23 VHISI3015FS-1 AZ FQ B IC(Si3015-FS) [IC3] IC

24 VHISI3021FS-1 AU EZ B IC(Si3021-FS) [IC6] IC

25 RFILN2011SCZZ AC DJ C Coil(SBT-0260) [L1,L8] ｺｲﾙ

26 RCILZ0124FCPZ AG DX C Coil(ST-110AH) [L4] ｺｲﾙ

27 RCORF1003MCZZ AC DJ C Coil(BLM31AJ601SN1) [L5,L6] ｺｲﾙ

28 VRS-CY1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [L16,L15] ﾃｲｺｳ

29 QJAKT0001FCPZ AD DJ C Modular Jack(MJ-62J-RD315) [MJ1] ｼﾞｬｯｸ

32 VSDTD113ZK/-1 AC DJ B Transistor(DTD113ZK) [Q5] ﾄﾗﾝｼﾞｽﾀｰ

35 VS2SA1759++-1 AE DJ B Transistor(2SA1759) [Q11] ﾄﾗﾝｼﾞｽﾀｰ

36 RRLYD3213QCZZ AH DX B Relay(OUAZ-SH-112) [RY3] ﾘﾚｰ

38 VRD-HT2EY222J AA DD C Resistor(1/4W 2.2KΩ ±5%) [R9] ﾃｲｺｳ

40 VRS-HT3AA153J AB DD C Resistor(1W 15KΩ ±5%) [R11] ﾃｲｺｳ

41 VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R14,R38,R39,R59,R60] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R76,R77,R81] ﾃｲｺｳ

42 VRSCY1JD2150F AA DD C Resistor(1/16W 215Ω ±1%) [R25] ﾃｲｺｳ

43 VRS-TS2AD563J AA DD C Resistor(1/10W 56KΩ ±5%) [R27,R26] ﾃｲｺｳ

45 VRSCY1JD78R7F AA DD C Resistor(1/16W 78.7Ω ±1%) [R29] ﾃｲｺｳ

47 VRS-TS2AD222J AA DD C Resistor(1/10W 2.2KΩ ±5%) [R31] ﾃｲｺｳ

48 VRS-CY1JD104F AA DD C Resistor(1/16W 100KΩ ±1%) [R33] ﾃｲｺｳ

49 VRS-CY1JD124J AA DD C Resistor(1/16W 120KΩ ±5%) [R34] ﾃｲｺｳ

50 VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R35] ﾃｲｺｳ

51 VRD-HT2EY152J AA DD C Resistor(1/4W 1.5KΩ ±5%) [R36,R37] ﾃｲｺｳ

52 VRS-TS2AD100J AA DD C Resistor(1/10W 10Ω ±5%) [R56,R57] ﾃｲｺｳ

53 VRS-CY1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R82,R58] ﾃｲｺｳ

54 VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R78] ﾃｲｺｳ

55 VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R79] ﾃｲｺｳ

56 VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R80] ﾃｲｺｳ

57 VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R83] ﾃｲｺｳ

58 VRS-CY1JD752J AA DD C Resistor(1/16W 7.5KΩ ±5%) [R97] ﾃｲｺｳ

59 VHVDSS-401M// AH DX B Varistor(DSS-401M) [SA1,SA3] ﾊﾞﾘｽﾀｰ

60 VHVDSS301L/-1 AF DS B Varistor(DSS301L) [SA2,SA4] ﾊﾞﾘｽﾀｰ

61 VHEMTZJ33B+-1 AC DJ B Zener diode(MTZJ33B) [ZD3,ZD4] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

62 VHERLZ5.6B/-1 AC DJ B Zener diode(RLZ5.6B) [ZD5,ZD11] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

63 VHERD43FMAZ-1 AE DS B Zener diode(RD43FM) [ZD6] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

64 VHEHZS2C1//-1 AB DJ B Zener diode(HZS2C1) [ZD7,ZD8] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

65 VRS-TP2BD000J AA DD C Resistor(1/8W 0Ω ±5%) [L2,L18,L21,L23,L24,L25] ﾃｲｺｳ

– 21 –

KLIU 基板 (LIU PWB)...(for MX-FXX1 Japan)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

!1QFS-E0006QSPZ AG DX A Fuse(125V/630mA) [F1] ﾋｭｰｽﾞ

2RCILZ7012XCPZ AC DJ C Coil(B-01-AT1F) [JP4,JP3] ｺｲﾙ

4RCORF1003MCZZ AC DJ C Coil(BLM31AJ601SN1) [L5,L6,L7,L9] ｺｲﾙ

5RFILN2011SCZZ AC DJ C Coil(SBT-0260) [L1,L8,L10,L11] ｺｲﾙ

6RRLYD1426QCPZ AL EB B Relay(RSB-5) [RY2] ﾘﾚｰ

7RRLYD3213QCZZ AH DX B Relay(OUAZ-SH-112) [RY1,RY3,RY4] ﾘﾚｰ

9VCCCCY1HH100D AA DD C Capacitor(50WV 10pF) [C43] ｺﾝﾃﾞﾝｻｰ

11 VCFYPU2EA474K AF DS C Capacitor(250WV 0.47µF) [C6] ｺﾝﾃﾞﾝｻｰ

12 VCKYCY1CF105Z AC DD C Capacitor(16WV 1µF) [C30,C31] ｺﾝﾃﾞﾝｻｰ

13 VCKYCY1HB103K AA DD C Capacitor(50WV 0.01µF) [C75,C25] ｺﾝﾃﾞﾝｻｰ

14 VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C16,C42,C46,C62] ｺﾝﾃﾞﾝｻｰ

15 VCKYCY1HB182K AA DD C Capacitor(50WV 1800pF) [C22] ｺﾝﾃﾞﾝｻｰ

16 VCKYCY1HB273K AC DD C Capacitor(50WV 0.027µF) [C10] ｺﾝﾃﾞﾝｻｰ

17 VCKYCY1HB332K AA DD C Capacitor(50WV 3300pF) [C21,C24] ｺﾝﾃﾞﾝｻｰ

18 VCKYCY1HF104Z AA DD C Capacitor(50WV 0.10µF) [C13,C34,C70] ｺﾝﾃﾞﾝｻｰ

19 VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C11,C36,C37,C39,C48] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C49,C56] ｺﾝﾃﾞﾝｻｰ

20 VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C8,C14,C26,C27,C52] ｺﾝﾃﾞﾝｻｰ

VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C57,C58,C66] ｺﾝﾃﾞﾝｻｰ

23 VCKYTV1CB105K AC DD C Capacitor(16WV 1µF) [C45] ｺﾝﾃﾞﾝｻｰ

24 VCKYTV1CB684K AC DD C Capacitor(16WV 0.68µF) [C15] ｺﾝﾃﾞﾝｻｰ

25 VCKYTV1HB224K AC DD C Capacitor(50WV 0.22µF) [C41,C23] ｺﾝﾃﾞﾝｻｰ

26 VCKYTW1HB104K AC DD C Capacitor(50WV 0.1µF) [C20] ｺﾝﾃﾞﾝｻｰ

27 VHD1SS355//-1 AB DJ B Diode(1SS355) [D1,D2,D3,D5,D7] ﾀﾞｲｵｰﾄﾞ

VHD1SS355//-1 AB DJ B Diode(1SS355) [D8,D15,D16,D17,D18] ﾀﾞｲｵｰﾄﾞ

28 VHDDAN217//-1 AC DD B Diode(DAN217) [D10,D9] ﾀﾞｲｵｰﾄﾞ

29 VHDERB3806+-1 AF DS B Diode(ERB3806) [D12,D13,D14,D20] ﾀﾞｲｵｰﾄﾞ

30 VHEMTZJ33B+-1 AC DJ B Zener diode(MTZJ33B) [ZD3,ZD4] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

31 VHERD43FMAZ-1 AE DS B Zener diode(RD43FM) [ZD6] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

32 VHERLZ5.6B/-1 AC DJ B Zener diode(RLZ5.6B) [ZD5,ZD11] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

33 VHERZ1175++-1 AF DS B Zener diode(RZ1175) [ZD9] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

34 VHINJM2135M-1 AG DS N B IC(NJM2135M) [IC1] IC

35 VHINJM4558MF1 AE DJ B IC(NJM4558MF1) [IC2] IC

36 VHISI3000FS-1 AT EZ B IC(Si3000-FS) [IC5] IC

37 VHISI3015FS-1 AZ FQ B IC(Si3015-FS) [IC3] IC

38 VHISI3021FS-1 AU EZ B IC(Si3021-FS) [IC6] IC

39 VHVDSS301L/-1 AF DS B Varistor(DSS301L) [SA2,SA4] ﾊﾞﾘｽﾀｰ

40 VHVDSS-401M// AH DX B Varistor(DSS-401M) [SA1,SA3] ﾊﾞﾘｽﾀｰ

42 VRD-FN2EY103J AB DD C Resistor(1/4W 10KΩ ±5%) [R40,R19] ﾃｲｺｳ

43 VRD-FN2EY104J AB DD C Resistor(1/4W 100KΩ ±5%) [R41] ﾃｲｺｳ

45 VRD-FN2EY224J AB DD C Resistor(1/4W 220KΩ ±5%) [R43] ﾃｲｺｳ

49 VRD-HT2EY000J AA DD C Resistor(1/4W 0Ω ±5%) [R85,R62,L13] ﾃｲｺｳ

50 VRD-HT2EY102J AA DD C Resistor(1/4W 1KΩ ±5%) [R50,R49,R91,R65] ﾃｲｺｳ

51 VRD-HT2EY103J AA DD C Resistor(1/4W 10KΩ ±5%) [R52] ﾃｲｺｳ

52 VRD-HT2EY121J AA DD C Resistor(1/4W 120Ω ±5%) [R53,R6] ﾃｲｺｳ

53 VRD-HT2EY152J AA DD C Resistor(1/4W 1.5KΩ ±5%) [R36,R37] ﾃｲｺｳ

54 VRD-HT2EY203J AA DD C Resistor(1/4W 20KΩ ±5%) [R84,R61] ﾃｲｺｳ

55 VRD-HT2EY222J AA DD C Resistor(1/4W 2.2KΩ ±5%) [R15,R9] ﾃｲｺｳ

56 VRD-HT2EY300J AA DD C Resistor(1/4W 30Ω ±5%) [R23] ﾃｲｺｳ

57 VRD-HT2EY472J AA DD C Resistor(1/4W 4.7KΩ ±5%) [R92,R89] ﾃｲｺｳ

64 VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R14,R24,R38,R39,R59] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R60,R74,R76,R77,R81] ﾃｲｺｳ

65 VRS-CY1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [L16,L15] ﾃｲｺｳ

66 VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R80] ﾃｲｺｳ

67 VRS-CY1JD104F AA DD C Resistor(1/16W 100KΩ ±1%) [R33] ﾃｲｺｳ

69 VRS-CY1JD124J AA DD C Resistor(1/16W 120KΩ ±5%) [R34] ﾃｲｺｳ

70 VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R35] ﾃｲｺｳ

71 VRSCY1JD2150F AA DD C Resistor(1/16W 215Ω ±1%) [R25] ﾃｲｺｳ

72 VRS-CY1JD271J AA DD C Resistor(1/16W 270Ω ±5%) [R97] ﾃｲｺｳ

74 VRS-CY1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R82,R58] ﾃｲｺｳ

75 VRSCY1JD78R7F AA DD C Resistor(1/16W 78.7Ω ±1%) [R29] ﾃｲｺｳ

77 VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R70,R83,R109,R110] ﾃｲｺｳ

78 VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R78] ﾃｲｺｳ

79 VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R21] ﾃｲｺｳ

80 VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R47,R20] ﾃｲｺｳ

81 VRS-CZ1JD153J AA DD C Resistor(1/16W 15KΩ ±5%) [R46] ﾃｲｺｳ

82 VRS-CZ1JD203J AA DD C Resistor(1/16W 20KΩ ±5%) [R45] ﾃｲｺｳ

83 VRS-CZ1JD222J AA DD C Resistor(1/16W 2.2KΩ ±5%) [R75] ﾃｲｺｳ

84 VRS-CZ1JD272J AA DD C Resistor(1/16W 2.7KΩ ±5%) [R22] ﾃｲｺｳ

85 VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R51] ﾃｲｺｳ

86 VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R68,R69,R71,R72,R73] ﾃｲｺｳ

87 VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R79] ﾃｲｺｳ

88 VRS-HT3AA102J AA DD C Resistor(1W 1.0KΩ ±5%) [R54] ﾃｲｺｳ

89 VRS-HT3AA153J AB DD C Resistor(1W 15KΩ ±5%) [R11] ﾃｲｺｳ

91 VRS-RE3DA511J AC DD C Resistor(2W 510Ω ±5%) [R3] ﾃｲｺｳ

92 VRS-TS2AD100J AA DD C Resistor(1/10W 10Ω ±5%) [R56,R57] ﾃｲｺｳ

93 VRS-TS2AD222J AA DD C Resistor(1/10W 2.2KΩ ±5%) [R31] ﾃｲｺｳ

94 VRS-TS2AD563J AA DD C Resistor(1/10W 56KΩ ±5%) [R27,R26] ﾃｲｺｳ

95 VS2SA1759++-1 AE DJ B Transistor(2SA1759) [Q11] ﾄﾗﾝｼﾞｽﾀｰ

96 VS2SA1776++-1 AF DS B Transistor(2SA1776) [Q6] ﾄﾗﾝｼﾞｽﾀｰ

– 22 –

KLIU 基板 (LIU PWB)...(for MX-FXX1 Japan)

LLIU 基板 (LIU PWB)...(for MX-FXX1 U.S.A,Canada)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

98 VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [Q13,Q16,Q17] ﾄﾗﾝｼﾞｽﾀｰ

99 VSDTD113ZK/-1 AC DJ B Transistor(DTD113ZK) [Q1,Q3,Q4,Q5,Q8] ﾄﾗﾝｼﾞｽﾀｰ

103 VS2SA2034NQ-1 AF DS N B Transistor(2SA2034) [Q7,Q19] ﾄﾗﾝｼﾞｽﾀｰ

109 VHEHZS2A1//-1 AB DJ B Zener diode(HZS2A1) [ZD1,ZD2] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

110 VHEHZS2C1//-1 AB DJ B Zener diode(HZS2C1) [ZD7,ZD8] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

113 VHILM2524DN-1 AN EG N B IC(LM2524D) [IC7,IC4] IC

114 QSOCD0081FCPZ AL EB N C Socket(MD-S6350-90) [CN1] ｿｹｯﾄ

115 QJAKT0001FCPZ AD DJ C Modular Jack(MJ-62J-RD315) [MJ1] ｼﾞｬｯｸ

116 QJAKT0002FCPZ AE DJ N C Modular Jack(MJ-66J-RD315) [MJ2] ｼﾞｬｯｸ

117 VHDS1ZB60//-1 AC DJ B Diode(S1ZB60) [D6] ﾀﾞｲｵｰﾄﾞ

119 RCILZ0124FCPZ AG DX C Coil(ST-110AH) [L4] ｺｲﾙ

125 RCILP0024QSZZ AD DJ N C Coil(TSL0808RA100K) [L20,L17] ｺｲﾙ

126 RCILP0122FCPZ AE DJ N C Coil(TSL1112S-332JR26) [L14,L22] ｺｲﾙ

127 QCNCW1316FCPZ AK DX C Connector(TX24-40R-10ST-H1) [CN2] ｺﾈｸﾀｰ

129 RC-EZ0369FCPZ AB DD C Capacitor(50WV 4.7µF) [C74] ｺﾝﾃﾞﾝｻｰ

130 RFILN0013QSPZ AB DJ N C Filter(MMZ1005D680C) [R44,L26] ﾌｨﾙﾀｰ

131 VRS-TP2BD000J AA DD C Resistor(1/8W 0Ω ±5%) [L2,L18,L21,L23,L24] ﾃｲｺｳ

VRS-TP2BD000J AA DD C Resistor(1/8W 0Ω ±5%) [L25,R111] ﾃｲｺｳ

132 VCKYCZ1AB104K AC DD C Capacitor(10WV 0.1µF) [C53,C72] ｺﾝﾃﾞﾝｻｰ

(Unit)

901 CPWBN1648FCE3 BT MW E LIU PWB [MX-FXX1](Japan) LIU 基板

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1RCILZ7012XCPZ AC DJ C Coil(B-01-AT1F) [JP4,JP5] ｺｲﾙ

3RCORF1003MCZZ AC DJ C Coil(BLM31AJ601SN1) [L6,L8,L10,L14] ｺｲﾙ

4RFILN2011SCZZ AC DJ C Coil(SBT-0260) [L1,L9,L11,L18] ｺｲﾙ

5RRLYD1426QCPZ AL EB B Relay(RSB-5) [RY1] ﾘﾚｰ

6VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R28,R30,R34] ﾃｲｺｳ

8VCCCCY1HH100D AA DD C Capacitor(50WV 10pF) [C27] ｺﾝﾃﾞﾝｻｰ

11 VCKYCY1HB103K AA DD C Capacitor(50WV 0.01µF) [C24] ｺﾝﾃﾞﾝｻｰ

12 VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C14,C15,C39,C43] ｺﾝﾃﾞﾝｻｰ

13 VCKYCY1HB182K AA DD C Capacitor(50WV 1800pF) [C17] ｺﾝﾃﾞﾝｻｰ

14 VCKYCY1HB332K AA DD C Capacitor(50WV 3300pF) [C20,C22] ｺﾝﾃﾞﾝｻｰ

15 VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C47,C45] ｺﾝﾃﾞﾝｻｰ

16 VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C34,C36,C37] ｺﾝﾃﾞﾝｻｰ

19 VCKYTV1CB105K AC DD C Capacitor(16WV 1µF) [C30] ｺﾝﾃﾞﾝｻｰ

20 VCKYTV1CB684K AC DD C Capacitor(16WV 0.68µF) [C16] ｺﾝﾃﾞﾝｻｰ

21 VCKYTV1HB224K AC DD C Capacitor(50WV 0.22µF) [C28,C29] ｺﾝﾃﾞﾝｻｰ

22 VCKYTW1HB104K AC DD C Capacitor(50WV 0.1µF) [C18] ｺﾝﾃﾞﾝｻｰ

23 VHD1SS355//-1 AB DJ B Diode(1SS355) [D3,D2] ﾀﾞｲｵｰﾄﾞ

24 VHDDAN217//-1 AC DD B Diode(DAN217) [D4,D5] ﾀﾞｲｵｰﾄﾞ

25 VHEMTZJ30B/-1 AB DJ B Zener diode(HZ3B1) [ZD6] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

26 VHERD43FMAZ-1 AE DS B Zener diode(RD43FM) [ZD2] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

27 VHERLZ5.6B/-1 AC DJ B Zener diode(RLZ5.6B) [ZD1,ZD8] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

28 VHISI3015FS-1 AZ FQ B IC(Si3015-FS) [IC1] IC

29 VHISI3021FS-1 AU EZ B IC(Si3021-FS) [IC4] IC

30 VHVDSS-401M// AH DX B Varistor(DSS-401M) [SA1,SA2,SA3,SA4] ﾊﾞﾘｽﾀｰ

31 VRD-HT2EY000J AA DD C Resistor(1/4W 0Ω ±5%) [F1,L7,L15,L16] ﾃｲｺｳ

32 VRD-HT2EY300J AA DD C Resistor(1/4W 30Ω ±5%) [R20] ﾃｲｺｳ

33 VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R24,R25,R29,R35,R37] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R39,R40,R42,R43] ﾃｲｺｳ

34 VRS-CY1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [L21,L20] ﾃｲｺｳ

35 VRS-CY1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R41] ﾃｲｺｳ

36 VRS-CY1JD104F AA DD C Resistor(1/16W 100KΩ ±1%) [R11] ﾃｲｺｳ

38 VRS-CY1JD124J AA DD C Resistor(1/16W 120KΩ ±5%) [R19] ﾃｲｺｳ

39 VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R21] ﾃｲｺｳ

40 VRSCY1JD2150F AA DD C Resistor(1/16W 215Ω ±1%) [R14] ﾃｲｺｳ

42 VRS-CY1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R26,R36] ﾃｲｺｳ

43 VRS-CY1JD621J AA DD C Resistor(1/16W 620Ω ±5%) [R44] ﾃｲｺｳ

44 VRSCY1JD78R7F AA DD C Resistor(1/16W 78.7Ω ±1%) [R15] ﾃｲｺｳ

46 VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R32,R38] ﾃｲｺｳ

47 VRS-HT3AA393J AC DD C Resistor(1W 39KΩ ±5%) [R12] ﾃｲｺｳ

48 VRS-TS2AD100J AA DD C Resistor(1/10W 10Ω ±5%) [R23,R22] ﾃｲｺｳ

49 VRS-TS2AD222J AA DD C Resistor(1/10W 2.2KΩ ±5%) [R16] ﾃｲｺｳ

50 VRS-TS2AD563J AA DD C Resistor(1/10W 56KΩ ±5%) [R8,R6] ﾃｲｺｳ

51 VS2SA1759++-1 AE DJ B Transistor(2SA1759) [Q2] ﾄﾗﾝｼﾞｽﾀｰ

53 VSDTC114EK/-1 AB DD B Transistor(DTC114EK) [Q8,Q9,Q10] ﾄﾗﾝｼﾞｽﾀｰ

54 VSDTD113ZK/-1 AC DJ B Transistor(DTD113ZK) [Q4] ﾄﾗﾝｼﾞｽﾀｰ

57 RCILP0017QSZZ AG DX C Coil(EL0607RA-331J) [R5,R4] ｺｲﾙ

58 VHEHZS2C1//-1 AB DJ B Zener diode(HZS2C1) [ZD3,ZD4] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

59 QJAKT0001FCPZ AD DJ C Modular Jack(MJ-62J-RD315) [MJ2] ｼﾞｬｯｸ

60 QJAKT0004QSPZ AE DJ C Modular Jack(MJ-64J-RD315) [MJ1] ｼﾞｬｯｸ

61 VHDS1ZB60//-1 AC DJ B Diode(S1ZB60) [D1] ﾀﾞｲｵｰﾄﾞ

62 RCILZ0124FCPZ AG DX C Coil(ST-110AH) [L13] ｺｲﾙ

– 23 –

LLIU 基板 (LIU PWB)...(for MX-FXX1 U.S.A,Canada)

MLIU 基板 (LIU PWB)...(for MX-FXX1 Europe,Oceania)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

64 QCNCW1316FCPZ AK DX C Connector(TX24-40R-10ST-H1) [CN1] ｺﾈｸﾀｰ

65 RC-EZ0368FCPZ AB DD C Capacitor(50WV 0.33µF) [C35] ｺﾝﾃﾞﾝｻｰ

66 VRS-TP2BD000J AA DD C Resistor(1/8W 0Ω ±5%) [L2,L22,L24,L25] ﾃｲｺｳ

68 VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [Q6] ﾄﾗﾝｼﾞｽﾀｰ

69 VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R33] ﾃｲｺｳ

70 VRD-HT2EY121J AA DD C Resistor(1/4W 120Ω ±5%) [R3] ﾃｲｺｳ

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1RCILP0018QSZZ AE DS C Coil(LHL10TB151K) [L15,L7] ｺｲﾙ

2RCILZ7012XCPZ AC DJ C Coil(B-01-AT1F) [JP4,JP5] ｺｲﾙ

4RCORF1003MCZZ AC DJ C Coil(BLM31AJ601SN1) [L6,L8,L10,L14] ｺｲﾙ

5RFILN2011SCZZ AC DJ C Coil(SBT-0260) [L1,L9,L11,L18] ｺｲﾙ

6RRLYD1426QCPZ AL EB B Relay(RSB-5) [RY1] ﾘﾚｰ

7RR-SZ0002QCZZ AD DJ C Resistor(2W 1.78KΩ ±1%) [R27,R18] ﾃｲｺｳ

8VCCCCY1HH100D AA DD C Capacitor(50WV 10pF) [C27] ｺﾝﾃﾞﾝｻｰ

11 VCKYCY1HB103K AA DD C Capacitor(50WV 0.01µF) [C24] ｺﾝﾃﾞﾝｻｰ

12 VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C14,C15,C39,C43] ｺﾝﾃﾞﾝｻｰ

13 VCKYCY1HB182K AA DD C Capacitor(50WV 1800pF) [C17] ｺﾝﾃﾞﾝｻｰ

14 VCKYCY1HB332K AA DD C Capacitor(50WV 3300pF) [C20,C22] ｺﾝﾃﾞﾝｻｰ

15 VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C33,C45,C47] ｺﾝﾃﾞﾝｻｰ

16 VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C36,C37] ｺﾝﾃﾞﾝｻｰ

19 VCKYTV1CB105K AC DD C Capacitor(16WV 1µF) [C30] ｺﾝﾃﾞﾝｻｰ

20 VCKYTV1CB684K AC DD C Capacitor(16WV 0.68µF) [C16] ｺﾝﾃﾞﾝｻｰ

21 VCKYTV1HB224K AC DD C Capacitor(50WV 0.22µF) [C28,C29] ｺﾝﾃﾞﾝｻｰ

22 VCKYTW1HB104K AC DD C Capacitor(50WV 0.1µF) [C18] ｺﾝﾃﾞﾝｻｰ

23 VHD1SS355//-1 AB DJ B Diode(1SS355) [D3,D2] ﾀﾞｲｵｰﾄﾞ

24 VHDDAN217//-1 AC DD B Diode(DAN217) [D4,D5] ﾀﾞｲｵｰﾄﾞ

25 VHEMTZJ30B/-1 AB DJ B Zener diode(HZ3B1) [ZD6] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

26 VHERD43FMAZ-1 AE DS B Zener diode(RD43FM) [ZD2] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

27 VHERLZ5.6B/-1 AC DJ B Zener diode(RLZ5.6B) [ZD1,ZD8] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

28 VHISI3015FS-1 AZ FQ B IC(Si3015-FS) [IC1] IC

29 VHISI3021FS-1 AU EZ B IC(Si3021-FS) [IC4] IC

30 VHVDSS301L/-1 AF DS B Varistor(DSS301L) [SA1,SA4] ﾊﾞﾘｽﾀｰ

31 VHVDSS-401M// AH DX B Varistor(DSS-401M) [SA3,SA2] ﾊﾞﾘｽﾀｰ

32 VRD-HT2EY000J AA DD C Resistor(1/4W 0Ω ±5%) [F1,R3,L16] ﾃｲｺｳ

33 VRD-HT2EY100J AA DD C Resistor(1/4W 10Ω ±5%) [R5,R4] ﾃｲｺｳ

34 VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R24,R25,R29,R35,R37] ﾃｲｺｳ

VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R39,R40,R42,R43] ﾃｲｺｳ

35 VRS-CY1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [L21,L20] ﾃｲｺｳ

36 VRS-CY1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R44,R41] ﾃｲｺｳ

37 VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R28,R30,R34] ﾃｲｺｳ

38 VRS-CY1JD104F AA DD C Resistor(1/16W 100KΩ ±1%) [R11] ﾃｲｺｳ

40 VRS-CY1JD124J AA DD C Resistor(1/16W 120KΩ ±5%) [R19] ﾃｲｺｳ

41 VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R21] ﾃｲｺｳ

42 VRSCY1JD2150F AA DD C Resistor(1/16W 215Ω ±1%) [R14] ﾃｲｺｳ

44 VRS-CY1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R36,R26] ﾃｲｺｳ

45 VRSCY1JD78R7F AA DD C Resistor(1/16W 78.7Ω ±1%) [R15] ﾃｲｺｳ

47 VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R32,R38] ﾃｲｺｳ

48 VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R33] ﾃｲｺｳ

49 VRS-HT3AA393J AC DD C Resistor(1W 39KΩ ±5%) [R12] ﾃｲｺｳ

50 VRS-TS2AD222J AA DD C Resistor(1/10W 2.2KΩ ±5%) [R16] ﾃｲｺｳ

51 VRS-TS2AD563J AA DD C Resistor(1/10W 56KΩ ±5%) [R8,R6] ﾃｲｺｳ

52 VRS-TS2AD100J AA DD C Resistor(1/10W 10Ω ±5%) [R23,R22] ﾃｲｺｳ

53 VS2SA1759++-1 AE DJ B Transistor(2SA1759) [Q2] ﾄﾗﾝｼﾞｽﾀｰ

55 VSDTC114EK/-1 AB DD B Transistor(DTC114EK) [Q7,Q8,Q9,Q10] ﾄﾗﾝｼﾞｽﾀｰ

56 VSDTD113ZK/-1 AC DJ B Transistor(DTD113ZK) [Q4] ﾄﾗﾝｼﾞｽﾀｰ

59 QJAKT0001FCPZ AD DJ C Modular Jack(MJ-62J-RD315) [MJ2] ｼﾞｬｯｸ

60 QJAKT0004QSPZ AE DJ C Modular Jack(MJ-64J-RD315) [MJ1] ｼﾞｬｯｸ

61 VHDS1ZB60//-1 AC DJ B Diode(S1ZB60) [D1] ﾀﾞｲｵｰﾄﾞ

62 RCILZ0124FCPZ AG DX C Coil(ST-110AH) [L13] ｺｲﾙ

63 VHITC7SET8F-1 AD DJ N B IC(TC7SET08F) [IC3] IC

64 VHITHS56F++-1 AT EZ B IC(THS_56F) [IC2] IC

65 QCNCW1316FCPZ AK DX C Connector(TX24-40R-10ST-H1) [CN1] ｺﾈｸﾀｰ

66 RC-EZ0368FCPZ AB DD C Capacitor(50WV 0.33µF) [C35] ｺﾝﾃﾞﾝｻｰ

69 VSDTC143ZUA-1 AC DJ B Transistor(DTC143ZUA) [Q6] ﾄﾗﾝｼﾞｽﾀｰ

– 24 –

NRSPF ﾄﾞﾗｲﾊﾞｰ基板 (RSPF driver PWB)...(for MX-RPX1)

NO. PARTS CODE PRICE RANK NEW

MARK

PART

RANK DESCRIPTION

Ex. Ja.

1QCNCM0923FC3D AF DS C Connector(34pin) [CNA] ｺﾈｸﾀｰ

2QCNCM2401SC0F AB DJ C Connector(6pin) [CNH] ｺﾈｸﾀｰ

3QCNCM7014SC0C AA DD C Connector(3pin) [CNC] ｺﾈｸﾀｰ

4QCNCM7014SC0F AB DD C Connector(6pin) [CNF] ｺﾈｸﾀｰ

5QCNCM7014SC0G AB DD C Connector(7pin) [CNB] ｺﾈｸﾀｰ

6QCNCM7014SC1A AC DJ C Connector(11pin) [CNE] ｺﾈｸﾀｰ

7QCNCM7014SC1B AD DJ C Connector(12pin) [CND] ｺﾈｸﾀｰ

8QCNCM7014SC1C AC DD C Connector(13pin) [CNG] ｺﾈｸﾀｰ

9VCEAGA1VW476M AB DD C Capacitor(35WV 47µF) [C10,16,33] ｺﾝﾃﾞﾝｻｰ

10 VCEAJA1CW476M AB DD C Capacitor(16WV 47µF) [C13,22,28] ｺﾝﾃﾞﾝｻｰ

11 VCKYCY1HB223K AC DD C Capacitor(50WV 0.022µF) [C12,17,34] ｺﾝﾃﾞﾝｻｰ

12 VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C7,14,20,25,31] ｺﾝﾃﾞﾝｻｰ

13 VCKYCZ1CF473Z AA DD C Capacitor(16WV 0.047µF) [C11,15] ｺﾝﾃﾞﾝｻｰ

14 VCKYCZ1HB222K AA DD C Capacitor(50WV 2200pF) [C3,4,5,6,29,30] ｺﾝﾃﾞﾝｻｰ

15 VHDDAN202K/-1 AB DD B Diode(DAN202K) [D13,15,16] ﾀﾞｲｵｰﾄﾞ

16 VHDDAP202K/-1 AB DD B Diode(DAP202K) [D11,12,14] ﾀﾞｲｵｰﾄﾞ

17 VHDDSS133//-1 AA DD B Diode(1SS133) [D5,6,18] ﾀﾞｲｵｰﾄﾞ

18 VHEMTZJ20B/-1 AB DD B Zener diode(MTZJ20B) [ZD1] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ

21 VHITD62003AP1 AG DX B IC(TD620003AP1) [IC1] IC

22 VHI74HC151M-1 AD DJ B IC(74HC151M) [IC4] IC

23 VHVICPN15//-1 AD DJ B IC protector(ICP-N15) [ICP1,2,4] IC ﾌﾟﾛﾃｸﾀｰ

24 VHVICPN20//-1 AD DS B IC protector(ICP-N20) [ICP6] IC ﾌﾟﾛﾃｸﾀｰ

25 VRD-HT2EY221J AA DD C Resistor(1/4W 220Ω ±5%) [R5,10,13,18] ﾃｲｺｳ

26 VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R1,4,7,9,30,32,34,36,39] ﾃｲｺｳ

VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R41,42,47,48] ﾃｲｺｳ

27 VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R2,3,6,8,11,26,27,28,45] ﾃｲｺｳ

VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R46,51] ﾃｲｺｳ

28 VRS-CZ1JD391F AA DD C Resistor(1/16W 390Ω ±1%) [R22,23] ﾃｲｺｳ

30 VRS-CZ1JD472F AA DD C Resistor(1/16W 4.7KΩ ±1%) [R20,24] ﾃｲｺｳ

31 VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R40,43,44] ﾃｲｺｳ

32 VRS-CZ1JD511F AA DD C Resistor(1/16W 510Ω ±1%) [R21] ﾃｲｺｳ

33 VRS-CZ1JD511J AA DD C Resistor(1/16W 510Ω ±5%) [R49,50] ﾃｲｺｳ

34 VRS-RE3DAR47J AC DD C Resistor(2W 0.47Ω ±5%) [R15,17,29,38] ﾃｲｺｳ

36 VS2SK3065++-1 AG DX B Transistor(2SK3065) [Q5] ﾄﾗﾝｼﾞｽﾀｰ

(Unit)

901 CPWBN1680FCE1 BB GD E RSPF driver PWB RSPF ﾄﾞﾗｲﾊﾞｰ基板

– 25 –

■索引 (Index)

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

[C]

CPWBF1657FCE1 5- 901 BB GD E

CPWBF1663FC31 1- 901 BD GN E

CPWBF1664FC31 1- 901 BF GN E

CPWBF1665FC31 1- 901 BE GN E

CPWBF1666FC31 2- 901 BG GT E

CPWBF1667FC31 2- 901 BH GX E

CPWBF1669FCE1 7- 901 AY FQ E

CPWBN1648FCE3 15- 901 BT MW E

CPWBN1659FCE1 11- 901 AZ FX E

CPWBN1668FCE1 6- 901 BE GN E

CPWBN1680FCE1 18- 901 BB GD E

CPWBX1647FCE3 13- 901 BZ TR E

CPWBX1662DS51 12- 901 BR LX E

CPWBX1662DS53 12- 901 BR LX E

CPWBX1672FCE2 10- 901 BL HL E

CPWBX1712FCE1 9- 901 BG GN E

CPWBX1713DS518 8- 901 CD UD E

CPWBX1713DS548 8- 901 CD UD E

CPWBX1714FCE1 3- 901 BZ TF E

CPWBX1714FCE4 3- 901 BZ TF E

[L]

LHLDW2135SCZZ 13- 75 AB DD C

[P]

PCAPH0010GCPZ 10- 19 AC DJ D

PCOVP1945FCZZ 4- 4 AC DJ N D

PRDAR0057FCZ1 2- 17 AS EZ C

[Q]

QCNCM0042ESPZ 1- 23 AB DJ C

"13- 3 AB DJ C

QCNCM0068QSZZ 3- 11 AL EB C

QCNCM0155QSPZ 10- 8 AC DJ N C

QCNCM0156QSPZ 10- 9 AD DJ N C

"9- 5 AD DJ N C

QCNCM0160QSPZ 10- 10 AE DJ N C

QCNCM0168QSPZ 10- 5 AB DJ N C

"1- 24 AB DJ N C

QCNCM0170QSPZ 10- 6 AC DJ N C

"2- 23 AC DJ N C

QCNCM0787FCPZ 10- 17 AE DS N C

QCNCM0843FCPZ 1- 21 AC DJ N C

QCNCM0877FCPZ 10- 11 AD DJ N C

QCNCM0878FCPZ 10- 12 AE DS N C

QCNCM0878FCZZ 3- 5 AF DS C

"6- 6 AF DS C

"8- 1 AF DS C

QCNCM0879FCZZ 3- 3 AF DS C

"6- 5 AF DS C

QCNCM0880FCZZ 3- 4 AF DS C

QCNCM0923FC10 12- 13 AE DJ C

"3- 1 AE DJ C

"8- 2 AE DJ C

QCNCM0923FC12 12- 9 AE DJ C

"7- 4 AE DJ C

QCNCM0923FC24 3- 2 AF DS C

QCNCM0923FC32 3- 6 AG DS C

QCNCM0923FC3D 12- 12 AF DS C

"18- 1 AF DS C

"8- 3 AF DS C

QCNCM0998FCZZ 12- 11 AF DS C

QCNCM1006MCZZ 6- 4 AB DD C

"7- 3 AB DD C

QCNCM1031MP0C 5- 3 AE DS C

QCNCM1069ACPZ 10- 16 AD DJ N C

QCNCM1171FCZZ 5- 2 AE DS C

QCNCM1176FCZZ 12- 10 AF DS C

QCNCM1230FCPZ 8- 4 AD DJ N C

QCNCM1232FCPZ 1- 19 AC DJ N C

QCNCM1234FCPZ 1- 17 AF DS N C

"2- 21 AF DS N C

QCNCM1235FCPZ 1- 20 AF DS N C

QCNCM1306FCPZ 8- 5 AG DS N C

QCNCM1308FCPZ 8- 6 AH DX N C

QCNCM1315FCPZ 13- 1 AK DX C

QCNCM1348FCPZ 10- 13 AE DJ N C

"4- 24 AE DJ N C

QCNCM1354FCPZ 10- 7 AD DJ N C

"9- 4 AD DJ N C

QCNCM1356FCPZ 10- 14 AC DJ N C

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

QCNCM1366FCPZ 4- 137 AG DX N C

QCNCM2401SC0F 18- 2 AB DJ C

"8- 7 AB DJ C

QCNCM2649RC0F 12- 8 AE DJ N C

QCNCM2654SCPZ 13- 2 AF DS C

QCNCM7014SC0C 12- 5 AA DD C

"18- 3 AA DD C

"3- 9 AA DD C

"8- 8 AA DD C

QCNCM7014SC0D 8- 9 AB DD C

QCNCM7014SC0E 3- 10 AB DJ C

QCNCM7014SC0F 12- 6 AB DD C

"18- 4 AB DD C

"6- 3 AB DD C

"8- 10 AB DD C

QCNCM7014SC0G 12- 7 AB DD C

"18- 5 AB DD C

QCNCM7014SC1A 18- 6 AC DJ C

QCNCM7014SC1B 18- 7 AD DJ C

"6- 2 AD DJ C

"7- 2 AD DJ C

QCNCM7014SC1C 18- 8 AC DD C

"8- 11 AC DD C

QCNCM7014SC1E 8- 12 AC DJ C

QCNCW0153QSPZ 9- 2 AK DX C

QCNCW0864FCZZ 3- 8 AG DX C

QCNCW1170FCPZ 10- 2 AG DS N C

QCNCW1170FCZZ 3- 12 AG DS C

QCNCW1190FCPZ 4- 26 AN EG C

QCNCW1251FCPZ 8- 15 AD DJ N C

QCNCW1303FCPZ 11- 4 AE DS N C

QCNCW1316FCPZ 14- 1 AK DX C

"15- 127 AK DX C

"16- 64 AK DX C

"17- 65 AK DX C

QCNCW1345FCPZ 4- 25 AP EQ N C

QFS-A2700QCZZ 1- 1 AD DJ A

QFS-B3631QCPZ 1- 2 AH DS A

QFS-D1421QCPZ 1- 3 AE DJ A

QFS-E0006QSPZ 15- 1 AG DX A

QFS-E1311QCPZ 1- 7 AD DJ N A

QFSHB0028FCZZ 1- 5 AC DJ C

QFSHD0026FCZZ 1- 4 AC DJ C

QFS-L0001QSZZ 3- 46 AD DJ A

QFS-L0002QSZZ 12- 67 AD DD A

"3- 47 AD DD A

QFS-L0004QSPZ 12- 66 AD DJ A

"8- 16 AD DJ A

QJAKT0001FCPZ 14- 29 AD DJ C

"15- 115 AD DJ C

"16- 59 AD DJ C

"17- 59 AD DJ C

QJAKT0002FCPZ 10- 1 AE DJ N C

"15- 116 AE DJ N C

QJAKT0003FCPZ 4- 27 AQ EQ N C

QJAKT0004QSPZ 16- 60 AE DJ C

"17- 60 AE DJ C

QPIN-0003GCPZ 10- 18 AC DJ C

"4- 138 AC DJ C

QPIN-0011FCPZ 9- 3 AF DS N C

QSOCD0081FCPZ 15- 114 AL EB N C

QSOCN0005ESPZ 4- 19 AE DJ C

QSOCN0012QSPZ 4- 20 AE DS C

QSOCN0108FCPZ 4- 2 AD DJ N C

QSOCN0111FCPZ 4- 23 AF DJ C

QSOCZ0002QSPZ 3- 14 AC DJ C

"4- 62 AC DJ C

"8- 17 AC DJ C

QSOCZ0079FCPZ 4- 22 AP EQ C

QSOCZ0094FCPA 4- 21 AL EB C

QSOCZ0094FCPZ 3- 15 AL EG C

"8- 18 AL EG C

QSOCZ0095FCPZ 13- 4 AR EQ C

QSOCZ0103FCPZ 4- 17 AQ EQ N C

QSOCZ0107FCPZ 4- 16 AH DX N C

QSPGC0001FCZZ 1- 8 AK DX C

QSW-P0001ESZZ 5- 12 AC DJ B

QSW-P0469FCZZ 5- 13 AD DS B

QSW-S0545FCPZ 4- 125 AM EG B

QTANP0210FCPZ 1- 6 AC DJ N C

– 26 –

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

[R]

RALMB1002LCZZ 5- 17 AE DS B

RC-EZ0357FCPZ 10- 26 AD DD C

RC-EZ0368FCPZ 16- 65 AB DD C

"17- 66 AB DD C

RC-EZ0369FCPZ 15- 129 AB DD C

RCILF0120FCPZ 2- 24 AK EB N C

RCILF0126FCPZ 4- 92 AE DJ N C

RCILF0127FCPZ 4- 90 AB DJ N C

RCILF0128FCPZ 4- 89 AA DJ N C

RCILP0017QSZZ 16- 57 AG DX C

RCILP0018QSZZ 17- 1 AE DS C

RCILP0024QSZZ 15- 125 AD DJ N C

RCILP0122FCPZ 15- 126 AE DJ N C

RCILZ0124FCPZ 14- 26 AG DX C

"15- 119 AG DX C

"16- 62 AG DX C

"17- 62 AG DX C

RCILZ7012XCPZ 15- 2 AC DJ C

"16- 1 AC DJ C

"17- 2 AC DJ C

RC-KZ0017QCZZ 1- 12 AE DJ C

RC-KZ1054CCN2 6- 17 AB DD C

"7- 12 AB DD C

RCNVD0008FCPZ 4- 94 AU EZ N B

RCORF1003MCZZ 14- 27 AC DJ C

"15- 4 AC DJ C

"16- 3 AC DJ C

"17- 4 AC DJ C

RCRS-0007FCZZ 5- 4 AD DJ B

RCRSC0093FCPZ 4- 127 AD DJ N B

RCRSC0094FCPZ 4- 126 AD DJ N B

RCRSC0095FCPZ 4- 128 AD DJ N B

RCRSC0097FCPZ 4- 133 AF DS N B

RCRSC0098FCPZ 4- 145 AD DJ N B

RCRSP0016QSZZ 3- 45 AD DJ B

"8- 19 AD DJ B

RCRSP0069FCPZ 13- 5 BA FX B

RCRUA0030FCPZ 13- 6 BE GN B

RCRUA0034FCPZ 4- 130 AR EQ B

RCRUA0035FCPZ 4- 135 AN EQ N B

RCRUA0037FCPZ 4- 131 AM EG N B

RCRUA0038FCPZ 4- 132 AM EG N B

RCRUA0040FCPZ 4- 129 AM EG N B

RFILN0013QSPZ 15- 130 AB DJ N C

RFILN0053FCZZ 12- 62 AA DJ C

RFILN0062FCPZ 3- 148 AC DJ C

RFILN0308FCPZ 13- 74 AG DX C

RFILN0309FCPZ 13- 7 AC DJ C

RFILN0310FCPZ 13- 8 AC DJ C

RFILN0317FCPZ 13- 73 AD DJ C

RFILN1062ACZZ 4- 91 AA DJ C

RFILN2011SCZZ 14- 25 AC DJ C

"15- 5 AC DJ C

"16- 4 AC DJ C

"17- 5 AC DJ C

RFILN5022NCZZ 11- 11 AC DJ C

"12- 65 AC DJ C

RFILZ0004QSZZ 3- 147 AM EG C

"8- 22 AM EG C

RH-IX0001QSZZ 8- 23 BD GN B

RH-IX0013FCP1 10- 32 AW FG N B

RH-IX0014FCPZ 13- 9 BD GN B

RH-IX0015FCPZ 13- 10 AX FG B

RH-IX0016FCPZ 4- 61 BD GN N B

RH-IX0022FCPZ 9- 13 AU EZ N B

RH-IX7001XCPZ 3- 18 AR EQ B

"8- 24 AR EQ B

RMPTR4000ACZZ 3- 49 AB DD B

RMPTR4101ACZZ 12- 28 AB DD B

RMPTR4102ACZZ 3- 53 AB DD B

RMPTR4103ACPZ 4- 6 AA DD N B

RMPTR4103ACZZ 3- 48 AB DD B

"8- 25 AB DD B

RMPTR4220ACZZ 13- 11 AB DD B

"8- 27 AB DD B

RMPTR4222ACZZ 8- 28 AB DD B

RMPTR4330ACZZ 12- 29 AB DD B

"3- 50 AB DD B

"4- 13 AB DD B

"8- 29 AB DD B

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

RMPTR4330ACZZ 9- 1 AB DD B

RMPTR4470ACZZ 13- 12 AB DD B

"8- 30 AB DD B

RMPTR4472ACZZ 3- 52 AB DD B

RMPTR4473ACZZ 8- 31 AB DD B

RMPTR4822ACZZ 4- 12 AA DD B

RRLYD1192QCPZ 2- 1 AQ EQ N B

RRLYD1391QCPZ 1- 25 AP EQ N B

RRLYD1426QCPZ 15- 6 AL EB B

"16- 5 AL EB B

"17- 6 AL EB B

RRLYD3213QCZZ 14- 36 AH DX B

"15- 7 AH DX B

RR-SZ0002QCZZ 17- 7 AD DJ C

RR-SZ0407FCPZ 4- 99 AA DD N C

RR-SZ0408FCPZ 4- 102 AA DD N C

RR-SZ0409FCPZ 4- 103 AA DD N C

RR-SZ0410FCPZ 4- 115 AA DD N C

RR-SZ0411FCPZ 4- 120 AA DD N C

RR-SZ0412FCPZ 4- 101 AA DD N C

RR-SZ0413FCPZ 4- 134 AA DD N C

[U]

UBATL0017FCZZ 4- 3 AL EB B

[V]

VCCCCY1HH100D 14- 14 AA DD C

"15- 9 AA DD C

"16- 8 AA DD C

"17- 8 AA DD C

VCCCCZ1HH100D 12- 51 AA DD C

VCCCCZ1HH101J 11- 27 AA DD C

"3- 112 AA DD C

VCCCCZ1HH102J 3- 113 AA DD C

VCCCCZ1HH120J 3- 116 AA DD C

VCCCCZ1HH150J 10- 23 AA DD C

"8- 32 AA DD C

VCCCCZ1HH151J 12- 53 AC DD C

VCCCCZ1HH270J 13- 13 AA DD C

VCCCCZ1HH330J 3- 111 AA DD C

VCCCCZ1HH470J 8- 33 AA DD C

VCCCCZ1HH820J 8- 34 AA DD C

VCCCRZ1HH150J 4- 33 AA DD N C

VCCCRZ1HH151J 4- 37 AA DD C

VCCCRZ1HH220J 4- 41 AA DD C

VCCCRZ1HH221J 4- 38 AA DD N C

VCCCRZ1HH270J 4- 34 AA DD N C

VCEAGA1VW476M 18- 9 AB DD C

VCEAJA1CW476M 18- 10 AB DD C

VCEASM1CM106M 10- 24 AB DD C

"13- 14 AB DD C

VCEASX1CN107M 9- 9 AF DS C

VCEASX1CN226M 10- 25 AC DD C

VCEASX1CN476M 12- 57 AC DD C

"4- 42 AC DD C

VCEASX1CN477M 4- 43 AE DS C

VCEASX1EN337M 4- 45 AE DS C

VCEASX1HN105M 8- 37 AC DD C

VCEASX1HN106M 11- 13 AC DD N C

"12- 56 AC DD N C

VCEASX1VN226M 12- 58 AC DD N C

"8- 41 AC DD N C

VCFYPU2EA474K 14- 3 AF DS C

"15- 11 AF DS C

VCKYCY1AB105K 4- 139 AB DD C

VCKYCY1CB224K 8- 42 AE DJ C

VCKYCY1CF105Z 15- 12 AC DD C

VCKYCY1EB104K 4- 44 AG DX C

VCKYCY1HB103K 14- 12 AA DD C

"15- 13 AA DD C

"16- 11 AA DD C

"17- 11 AA DD C

VCKYCY1HB104K 11- 17 AA DD C

"13- 17 AA DD C

"14- 6 AA DD C

"15- 14 AA DD C

"16- 12 AA DD C

"17- 12 AA DD C

"3- 117 AA DD C

"8- 43 AA DD C

VCKYCY1HB182K 14- 10 AA DD C

"15- 15 AA DD C

"16- 13 AA DD C

– 27 –

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

VCKYCY1HB182K 17- 13 AA DD C

VCKYCY1HB223K 18- 11 AC DD C

VCKYCY1HB273K 13- 23 AC DD C

"15- 16 AC DD C

VCKYCY1HB332K 14- 9 AA DD C

"15- 17 AA DD C

"16- 14 AA DD C

"17- 14 AA DD C

VCKYCY1HB473K 3- 118 AA DD C

VCKYCY1HF104Z 14- 19 AA DD C

"15- 18 AA DD C

VCKYCZ1AB104K 12- 55 AC DD C

"15- 132 AC DD C

"4- 31 AC DD C

"4- 35 AC DD C

VCKYCZ1CB103K 11- 15 AA DD C

"12- 52 AA DD C

"3- 119 AA DD C

VCKYCZ1CB223K 3- 115 AB DD C

VCKYCZ1CF104Z 10- 21 AB DD C

"11- 16 AB DD C

"12- 48 AB DD C

"13- 18 AB DD C

"14- 17 AB DD C

"15- 19 AB DD C

"16- 15 AB DD C

"17- 15 AB DD C

"18- 12 AB DD C

"3- 114 AB DD C

"9- 6 AB DD C

VCKYCZ1CF473Z 18- 13 AA DD C

VCKYCZ1EB103K 4- 30 AB DD C

"8- 45 AB DD C

"9- 8 AB DD C

VCKYCZ1EF223Z 10- 20 AA DD C

VCKYCZ1HB102K 10- 22 AA DD C

"11- 14 AA DD C

"12- 49 AA DD C

"13- 19 AA DD C

"14- 4 AA DD C

"15- 20 AA DD C

"16- 16 AA DD C

"17- 16 AA DD C

"4- 36 AA DD C

"8- 47 AA DD C

"9- 7 AA DD C

VCKYCZ1HB222K 11- 26 AA DD C

"13- 20 AA DD C

"18- 14 AA DD C

"9- 10 AA DD C

VCKYCZ1HB331K 11- 18 AA DD C

VCKYCZ1HB471K 13- 21 AA DD C

"4- 40 AA DD C

VCKYCZ1HB472K 13- 22 AA DD C

VCKYPU1EB223Z 5- 15 AB DD C

VCKYPU1HB101K 5- 16 AA DD C

VCKYRI0JB106K 8- 48 AC DD C

VCKYTV0JB106M 12- 54 AF DS C

VCKYTV1AB225K 12- 50 AC DD C

"3- 120 AC DD C

VCKYTV1AF106Z 4- 29 AC DD C

VCKYTV1CB105K 14- 16 AC DD C

"15- 23 AC DD C

"16- 19 AC DD C

"17- 19 AC DD C

"3- 121 AC DD C

VCKYTV1CB684K 14- 5 AC DD C

"15- 24 AC DD C

"16- 20 AC DD C

"17- 20 AC DD C

VCKYTV1HB224K 14- 11 AC DD C

"15- 25 AC DD C

"16- 21 AC DD C

"17- 21 AC DD C

VCKYTW1HB104K 14- 8 AC DD C

"15- 26 AC DD C

"16- 22 AC DD C

"17- 22 AC DD C

VHD1N4448WS-1 8- 50 AB DJ N B

VHD1SS133++-1 1- 26 AA DJ B

"2- 2 AA DJ B

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

VHD1SS355//-1 12- 61 AB DJ B

"13- 24 AB DJ B

"14- 20 AB DJ B

"15- 27 AB DJ B

"16- 23 AB DJ B

"17- 23 AB DJ B

"3- 129 AB DJ B

"4- 48 AB DJ B

VHDBAV70W++-1 8- 52 AC DJ B

VHDBAV99W++-1 8- 53 AB DJ N B

VHDBAW56W++-1 8- 54 AC DJ B

VHDDA204K//-1 13- 25 AC DD B

VHDDA204U//-1 10- 28 AB DD B

VHDDAN202K/-1 18- 15 AB DD B

VHDDAN202U/-1 10- 27 AB DD B

"4- 49 AB DD B

VHDDAN217//-1 14- 22 AC DD B

"15- 28 AC DD B

"16- 24 AC DD B

"17- 24 AC DD B

VHDDAP202K/-1 18- 16 AB DD B

VHDDAP202U/-1 4- 50 AB DD B

VHDDSM1D1//-1 1- 27 AB DJ B

VHDDSS133//-1 18- 17 AA DD B

VHDERB3806+-1 15- 29 AF DS B

VHDES1D++++-1 11- 8 AC DJ B

"8- 55 AC DJ B

VHDKDS120++-1 12- 60 AC DJ B

VHDKDS121++-1 12- 59 AC DJ B

VHDKDS226++-1 3- 127 AC DJ B

"3- 128 AC DJ B

VHDMA704A//-1 3- 131 AC DJ B

VHDRB461F//-1 4- 136 AD DJ B

VHDRLS73///-1 10- 29 AA DD B

VHDS1ZB60//-1 14- 21 AC DJ B

"15- 117 AC DJ B

"16- 61 AC DJ B

"17- 61 AC DJ B

VHEHZM6R2Z4-1 4- 47 AC DJ N B

VHEHZS2A1//-1 15- 109 AB DJ B

VHEHZS2C1//-1 14- 64 AB DJ B

"15- 110 AB DJ B

"16- 58 AB DJ B

VHEMTZJ20B/-1 18- 18 AB DD B

"3- 130 AB DD B

VHEMTZJ30B/-1 16- 25 AB DJ B

"17- 25 AB DJ B

VHEMTZJ33B+-1 14- 61 AC DJ B

"15- 30 AC DJ B

VHERD43FMAZ-1 14- 63 AE DS B

"15- 31 AE DS B

"16- 26 AE DS B

"17- 26 AE DS B

VHERLZ5.6B/-1 14- 62 AC DJ B

"15- 32 AC DJ B

"16- 27 AC DJ B

"17- 27 AC DJ B

VHERZ1175++-1 15- 33 AF DS B

VHI16F627AG-1 13- 26 AR EQ B

VHI1G04DCKR-1 4- 74 AH DX B

VHI23S09SZ+-1 4- 140 AV EZ B

VHI23WAT255-1 4- 75 AU EZ B

VHI2474AF06-1 4- 88 AH DX N B

VHI24F256LI-1 4- 1 AP EQ B

VHI24WC02WI-1 4- 71 AE DS N B

VHI63LVD104-1 8- 56 AZ FQ N B

VHI65547Y030C 4- 64 BC GJ N B

VHI658920130C 3- 17 AQ EQ N B

"4- 87 AQ EQ N B

"8- 57 AQ EQ N B

VHI74HC151M-1 18- 22 AD DJ B

VHI74LVC14A-1 12- 14 AE DS B

"3- 33 AE DS B

"8- 58 AE DS B

VHI7965835R-1 4- 58 BZ TR N B

VHI856320111C 8- 59 BM HV B

VHI87F4930E1C 13- 27 AZ FQ B

VHI93C46VI+-1 4- 66 AE DS B

VHIB25BC0FP-1 8- 63 AG DS N B

VHIBD6512LF-1 4- 72 AH DX N B

VHIBU2500FV-1 12- 20 AL EB N B

– 28 –

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

VHIBU4066FV-1 13- 28 AL EB B

VHIC24FC32L-1 8- 64 AH DX N B

VHIC24FC64L-1 3- 24 AL EB N B

VHIC24WC02L-1 13- 29 AF DS B

VHIC25811SZ-1 13- 32 AN EB B

"8- 77 AN EB B

VHIC25812SZ-1 8- 78 AL EB B

VHIC25814SZ-1 4- 147 AL EB B

VHID62503FG-1 8- 65 AG DS B

VHID65001AF-1 3- 30 AG DS B

VHID65503F+-1 12- 24 AG DS B

"3- 29 AG DS B

VHIDP83816N-1 4- 65 AY FQ B

VHIDS90C385-1 4- 81 AR EQ N B

"8- 66 AR EQ N B

"9- 11 AR EQ N B

VHIDS90C386-1 11- 5 AR EQ N B

"12- 19 AR EQ N B

"4- 80 AR EQ N B

"9- 14 AR EQ N B

VHIDS90LV47-1 12- 18 AL EB N B

"8- 67 AL EB N B

VHIHI207ECB0C 4- 78 AN EG B

VHIK78R033P-1 8- 69 AG DX N B

VHIKA7812AP-1 8- 71 AE DJ B

VHIKIA358F+-1 12- 17 AE DS B

VHIKIA393F/-1 8- 72 AK DX B

VHIL1087MAN-1 12- 21 AF DS B

"8- 73 AF DS B

VHIL7A1920+0C 4- 84 BX TF N B

VHIL7B1916+-1 4- 59 BS MJ N B

VHIL7C1922+0C 4- 70 BE GN N B

VHILHF00L28-1 4- 86 AP EQ B

VHILHF80JZN-1 4- 73 AN EG N B

VHILM1117DJ-1 13- 30 AG DX B

VHILM2524DN-1 15- 113 AN EG N B

VHILM324D++-1 3- 23 AE DJ B

"8- 74 AE DJ B

VHILM339D++-1 3- 27 AE DJ B

VHILM358DR+-1 11- 7 AF DS B

"3- 21 AF DS B

VHILM393D++-1 3- 26 AE DJ B

"4- 76 AE DJ B

VHILP2996MP-1 4- 146 AT EZ B

VHILV048TC+-1 4- 82 AL EB N B

VHILVC08APW-1 12- 16 AD DJ N B

"4- 69 AD DJ N B

"8- 75 AD DJ N B

VHILVC1G00C-1 13- 31 AD DJ B

VHILVC574AP-1 3- 34 AL EB B

"4- 67 AL EB B

VHILVC74APW-1 12- 15 AD DJ N B

"4- 55 AD DJ N B

VHIM34282M1-1 5- 5 AG DX B

VHIM4U2088C0C 12- 1 BC GD N B

VHIM51957BFP1 12- 22 AH DX B

VHIM87S1210-1 8- 76 BK HC B

VHIMK5811SF-1 3- 31 AK EB N B

VHIN195006E-1 13- 33 BK HC B

VHINJ2360AM-1 11- 6 AG DX B

VHINJM2113M-1 13- 34 AG DS B

VHINJM2135M-1 15- 34 AG DS N B

VHINJM3414M-1 13- 35 AF DX B

VHINJM4558MF1 15- 35 AE DJ B

VHIPT591IMT-1 13- 36 AF DS B

"9- 12 AF DS B

VHISI3000FS-1 15- 36 AT EZ B

VHISI3015FS-1 14- 23 AZ FQ B

"15- 37 AZ FQ B

"16- 28 AZ FQ B

"17- 28 AZ FQ B

VHISI3021FS-1 14- 24 AU EZ B

"15- 38 AU EZ B

"16- 29 AU EZ B

"17- 29 AU EZ B

VHISLV14APW-1 13- 37 AE DJ B

VHITA7291AS-1 3- 28 AF DX B

VHITC7SET8F-1 17- 63 AD DJ N B

VHITD62003AF/ 8- 79 AE DS B

VHITD62003AP1 18- 21 AG DX B

VHITD62064AF/ 3- 20 AM EG B

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

VHITHS56F++-1 17- 64 AT EZ B

VHIVC244APW-1 4- 54 AE DJ N B

"8- 80 AE DJ N B

VHIVC245APW-1 4- 68 AE DJ N B

"8- 81 AE DJ N B

VHIVC2G66UR-1 4- 63 AD DJ N B

VHP1LHG002A-1 5- 6 AB DJ B

VHPLT1D67A/-1 3- 133 AC DJ B

VHPLT1F67AF-1 4- 46 AC DJ B

VHPLT1P67A+-1 8- 82 AC DJ B

VHPSLR322VC3F 13- 38 AC DJ B

VHQNSMDC110-1 4- 124 AF DS B

VHRF11YVZBF-1 2- 10 AG DX N B

VHV10V471K+-1 1- 10 AD DJ B

VHVDSS301L/-1 14- 60 AF DS B

"15- 39 AF DS B

"17- 30 AF DS B

VHVDSS-401M// 14- 59 AH DX B

"15- 40 AH DX B

"16- 30 AH DX B

"17- 31 AH DX B

VHVICPN15//-1 18- 23 AD DJ B

VHVICPN20//-1 18- 24 AD DS B

VRD-FN2EY103J 15- 42 AB DD C

VRD-FN2EY104J 15- 43 AB DD C

VRD-FN2EY224J 15- 45 AB DD C

VRD-HT2EY000J 15- 49 AA DD C

"16- 31 AA DD C

"17- 32 AA DD C

VRD-HT2EY100J 17- 33 AA DD C

VRD-HT2EY101J 2- 16 AA DD C

VRD-HT2EY102J 15- 50 AA DD C

"5- 11 AA DD C

VRD-HT2EY103J 15- 51 AA DD C

"6- 14 AA DD C

"7- 9 AA DD C

VRD-HT2EY121J 15- 52 AA DD C

"16- 70 AA DD C

VRD-HT2EY151J 5- 10 AA DD C

VRD-HT2EY152J 14- 51 AA DD C

"15- 53 AA DD C

VRD-HT2EY203J 15- 54 AA DD C

VRD-HT2EY221J 18- 25 AA DD C

VRD-HT2EY222J 14- 38 AA DD C

"15- 55 AA DD C

VRD-HT2EY242J 1- 28 AA DD C

VRD-HT2EY300J 15- 56 AA DD C

"16- 32 AA DD C

VRD-HT2EY362J 2- 15 AA DD C

VRD-HT2EY472J 15- 57 AA DD C

VRD-HT2HY474J 1- 15 AA DD C

VRNHT2EK1301F 6- 11 AB DD C

VRNHT2EK2201F 6- 8 AA DD C

VRNHT2EK2701F 6- 9 AA DD C

"7- 6 AA DD C

VRNHT2EK3601F 6- 13 AB DD C

VRNHT2EK4700F 6- 12 AA DD C

VRNHT2EK5100F 6- 10 AA DD C

"7- 7 AA DD C

VRNHT2EK7500F 7- 8 AA DD C

VRS-CY1JD000J 14- 41 AA DD C

"15- 64 AA DD C

"16- 33 AA DD C

"17- 34 AA DD C

"8- 83 AA DD C

VRS-CY1JD101J 14- 28 AA DD C

"15- 65 AA DD C

"16- 34 AA DD C

"17- 35 AA DD C

VRS-CY1JD102J 13- 39 AA DD C

"16- 35 AA DD C

"17- 36 AA DD C

VRS-CY1JD103J 14- 56 AA DD C

"15- 66 AA DD C

"16- 6 AA DD C

"17- 37 AA DD C

"8- 85 AA DD C

VRS-CY1JD104F 14- 48 AA DD C

"15- 67 AA DD C

"16- 36 AA DD C

"17- 38 AA DD C

– 29 –

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

VRS-CY1JD124J 14- 49 AA DD C

"15- 69 AA DD C

"16- 38 AA DD C

"17- 40 AA DD C

VRS-CY1JD151J 14- 50 AA DD C

"15- 70 AA DD C

"16- 39 AA DD C

"17- 41 AA DD C

VRS-CY1JD201J 3- 100 AA DD C

"8- 86 AA DD C

VRSCY1JD2150F 14- 42 AA DD C

"15- 71 AA DD C

"16- 40 AA DD C

"17- 42 AA DD C

VRS-CY1JD271J 15- 72 AA DD C

VRS-CY1JD331J 8- 84 AA DD C

VRS-CY1JD470J 14- 53 AA DD C

"15- 74 AA DD C

"16- 42 AA DD C

"17- 44 AA DD C

VRS-CY1JD471J 8- 87 AA DD C

VRS-CY1JD621J 16- 43 AA DD C

VRS-CY1JD752J 14- 58 AA DD C

VRSCY1JD78R7F 14- 45 AA DD C

"15- 75 AA DD C

"16- 44 AA DD C

"17- 45 AA DD C

VRS-CZ1JD000J 10- 41 AA DD C

"11- 19 AA DD C

"13- 40 AA DD C

"14- 57 AA DD C

"15- 77 AA DD C

"16- 46 AA DD C

"17- 47 AA DD C

"3- 57 AA DD C

"4- 98 AA DD C

"8- 88 AA DD C

"9- 16 AA DD C

VRS-CZ1JD100J 13- 41 AA DD C

"3- 54 AA DD C

"4- 110 AA DD C

"8- 89 AA DD C

VRS-CZ1JD101J 10- 42 AA DD C

"12- 34 AA DD C

"13- 42 AA DD C

"14- 54 AA DD C

"15- 78 AA DD C

"18- 26 AA DD C

"3- 59 AA DD C

"4- 108 AA DD C

"8- 90 AA DD C

"9- 17 AA DD C

VRS-CZ1JD102F 12- 39 AA DD C

"3- 61 AA DD C

"8- 91 AA DD C

VRS-CZ1JD102J 10- 43 AA DD C

"12- 30 AA DD C

"13- 43 AA DD C

"15- 79 AA DD C

"3- 55 AA DD C

"4- 112 AA DD C

"8- 92 AA DD C

VRS-CZ1JD103F 12- 31 AA DD C

"3- 64 AA DD C

"4- 142 AA DD C

"8- 93 AA DD C

VRS-CZ1JD103J 10- 44 AA DD C

"13- 44 AA DD C

"15- 80 AA DD C

"18- 27 AA DD C

"3- 65 AA DD C

"4- 105 AA DD C

"8- 94 AA DD C

"9- 18 AA DD C

VRS-CZ1JD104J 10- 45 AA DD C

"13- 45 AA DD C

"3- 74 AA DD C

"4- 143 AA DD C

"9- 19 AA DD C

VRS-CZ1JD105F 8- 95 AA DD C

VRS-CZ1JD105J 12- 47 AA DD C

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

VRS-CZ1JD105J 13- 46 AA DD C

"3- 66 AA DD C

"4- 106 AA DD C

"8- 96 AA DD C

VRS-CZ1JD112J 12- 43 AA DD C

VRS-CZ1JD113F 3- 78 AA DD C

VRS-CZ1JD121J 4- 117 AA DD C

VRS-CZ1JD122F 3- 76 AA DD C

VRS-CZ1JD122J 13- 48 AA DD C

"8- 97 AA DD C

VRS-CZ1JD123F 12- 41 AA DD C

VRS-CZ1JD151J 4- 144 AA DD C

"8- 98 AA DD C

VRS-CZ1JD152F 3- 77 AA DD C

"4- 100 AA DD C

VRS-CZ1JD152J 3- 70 AA DD C

VRS-CZ1JD153F 3- 79 AB DD C

VRS-CZ1JD153J 15- 81 AA DD C

"4- 122 AA DD C

VRS-CZ1JD162J 3- 71 AA DD C

VRS-CZ1JD181F 12- 40 AA DD C

VRS-CZ1JD182J 12- 42 AA DD C

VRSCZ1JD1912F 3- 80 AA DD C

VRS-CZ1JD201F 12- 45 AA DD C

VRS-CZ1JD201J 13- 50 AA DD C

"3- 60 AA DD C

VRS-CZ1JD202F 3- 62 AA DD C

VRS-CZ1JD202J 12- 38 AA DD C

"13- 51 AA DD C

"3- 95 AA DD C

"8- 99 AA DD C

VRS-CZ1JD203F 3- 81 AA DD C

VRS-CZ1JD203J 15- 82 AA DD C

"3- 56 AA DD C

VRS-CZ1JD204F 3- 85 AA DD C

VRS-CZ1JD220J 13- 52 AA DD C

"3- 58 AA DD C

"4- 111 AA DD C

"8- 100 AA DD C

VRS-CZ1JD221F 8- 101 AA DD C

VRS-CZ1JD221J 4- 141 AA DD C

VRS-CZ1JD222J 15- 83 AA DD C

"4- 114 AA DD C

VRS-CZ1JD223F 3- 82 AA DD C

VRS-CZ1JD242F 11- 22 AA DD C

VRS-CZ1JD242J 13- 53 AA DD C

VRS-CZ1JD243F 11- 24 AA DD C

"3- 83 AA DD C

VRS-CZ1JD243J 8- 102 AA DD C

VRS-CZ1JD271J 13- 54 AA DD C

VRS-CZ1JD272J 13- 55 AA DD C

"15- 84 AA DD C

"3- 94 AA DD C

VRS-CZ1JD301J 3- 67 AA DD C

VRS-CZ1JD303F 8- 103 AA DD C

VRS-CZ1JD303J 13- 57 AA DD C

"8- 104 AA DD C

VRS-CZ1JD304F 3- 91 AA DD C

VRS-CZ1JD330J 12- 35 AA DD C

"15- 85 AA DD C

"3- 97 AA DD C

"4- 107 AA DD C

"8- 105 AA DD C

"9- 20 AA DD C

VRS-CZ1JD331F 11- 20 AA DD C

"13- 58 AA DD C

VRS-CZ1JD331J 8- 106 AA DD C

VRS-CZ1JD332F 3- 63 AA DD C

VRS-CZ1JD332J 13- 59 AA DD C

"3- 69 AA DD C

VRS-CZ1JD333J 4- 123 AA DD C

VRS-CZ1JD391F 13- 60 AA DD C

"18- 28 AA DD C

VRS-CZ1JD391J 3- 68 AA DD C

VRS-CZ1JD393J 13- 61 AA DD C

VRS-CZ1JD470J 13- 62 AA DD C

"15- 86 AA DD C

"4- 116 AA DD C

"8- 107 AA DD C

VRS-CZ1JD471J 12- 44 AA DD C

"13- 63 AA DD C

– 30 –

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

VRS-CZ1JD471J 4- 104 AA DD C

VRS-CZ1JD472F 18- 30 AA DD C

"3- 96 AA DD C

VRS-CZ1JD472J 10- 46 AA DD C

"12- 33 AA DD C

"13- 64 AA DD C

"14- 55 AA DD C

"15- 87 AA DD C

"16- 69 AA DD C

"17- 48 AA DD C

"3- 92 AA DD C

"4- 118 AA DD C

"8- 108 AA DD C

VRS-CZ1JD473F 3- 84 AA DD C

VRS-CZ1JD473J 10- 47 AA DD C

"12- 32 AA DD C

"13- 65 AA DD C

"18- 31 AA DD C

"3- 73 AA DD C

"4- 109 AA DD C

"8- 109 AA DD C

VRS-CZ1JD474J 3- 93 AA DD C

VRS-CZ1JD511F 18- 32 AA DD C

"8- 110 AA DD C

VRS-CZ1JD511J 18- 33 AA DD C

VRS-CZ1JD512J 12- 46 AA DD C

VRS-CZ1JD513J 13- 67 AA DD C

VRS-CZ1JD560J 4- 113 AA DD C

VRS-CZ1JD562J 4- 119 AA DD C

"8- 111 AA DD C

VRS-CZ1JD621F 3- 98 AA DD C

VRS-CZ1JD622J 3- 72 AA DD C

VRS-CZ1JD624J 8- 112 AA DD C

VRS-CZ1JD750J 11- 21 AA DD C

VRS-CZ1JD752J 13- 69 AA DD C

"8- 113 AA DD C

VRS-CZ1JD820J 13- 70 AA DD C

VRS-CZ1JD821J 3- 75 AA DD C

VRS-HT2HA101J 2- 5 AA DD C

VRS-HT2HA121J 2- 6 AA DD C

VRS-HT2HA181J 2- 7 AA DD C

VRS-HT3AA102J 15- 88 AA DD C

VRS-HT3AA153J 14- 40 AB DD C

"15- 89 AB DD C

VRS-HT3AA393J 16- 47 AC DD C

"17- 49 AC DD C

VRSRCZ1JD561J 8- 114 AA DD C

VRS-RE3AAR39J 8- 115 AB DD C

VRS-RE3DA1R0J 6- 7 AB DD C

"7- 5 AB DD C

VRS-RE3DA511J 15- 91 AC DD C

VRS-RE3DAR47J 18- 34 AC DD C

VRS-TP2BD000J 14- 65 AA DD C

"15- 131 AA DD C

"16- 66 AA DD C

"8- 116 AA DD C

VRS-TP2BD102J 10- 48 AA DD C

VRS-TP2BD103J 10- 49 AA DD C

VRS-TP2BD151J 8- 117 AA DD C

VRS-TS2AD100J 14- 52 AA DD C

"15- 92 AA DD C

"16- 48 AA DD C

"17- 52 AA DD C

VRS-TS2AD222J 14- 47 AA DD C

"15- 93 AA DD C

"16- 49 AA DD C

"17- 50 AA DD C

VRS-TS2AD563J 14- 43 AA DD C

"15- 94 AA DD C

"16- 50 AA DD C

"17- 51 AA DD C

VRS-TW2ED102J 3- 104 AA ZZ C

VRS-TW2ED103J 3- 108 AB DD C

VRS-TW2ED152J 3- 103 AC DD C

VRS-TW2ED201J 3- 101 AA DD C

VRS-TW2ED472J 3- 106 AA DD C

VRS-TW2ED562J 3- 107 AB DD C

VRS-TX2HD560J 3- 109 AB DD C

VS2SA1576A/-1 3- 139 AB DJ B

VS2SA1759++-1 14- 35 AE DJ B

"15- 95 AE DJ B

PARTS CODE NO. PRICE R. NEW P/R

Ex. Ja.

VS2SA1759++-1 16- 51 AE DJ B

"17- 53 AE DJ B

VS2SA1776++-1 15- 96 AF DS B

VS2SA2034NQ-1 15- 103 AF DS N B

VS2SB1197KR-1 8- 119 AC DJ B

VS2SB1198K/-1 4- 96 AC DJ B

VS2SB1240-/-1 3- 141 AD DJ B

VS2SC1815-GRC 2- 3 AB DD B

VS2SC2411K/-1 3- 144 AB DD B

VS2SC2412K/-1 4- 97 AB DD B

VS2SC2412KS-1 8- 120 AB DD B

VS2SC4081-/-1 10- 38 AC DD B

VS2SD1898//-1 3- 143 AD DJ B

VS2SJ494+++-1 1- 30 AL EB B

VS2SK3018++-1 10- 40 AC DJ B

"3- 140 AC DJ B

VS2SK3065++-1 18- 36 AG DX B

VSDTA143ZUA-1 10- 37 AB DJ B

VSDTC114EK/-1 16- 53 AB DD B

"17- 55 AB DD B

VSDTC114EUA-1 10- 35 AC DJ B

VSDTC114YS/-1 5- 9 AB DD B

"6- 18 AB DD B

"7- 13 AB DD B

VSDTC114YUA-1 4- 95 AB DJ B

VSDTC143ZUA-1 10- 36 AC DJ B

"13- 71 AC DJ B

"15- 98 AC DJ B

"16- 68 AC DJ B

"17- 69 AC DJ B

VSDTD113ZK/-1 14- 32 AC DJ B

"15- 99 AC DJ B

"16- 54 AC DJ B

"17- 56 AC DJ B

VSKRA102S//-1 8- 121 AD DJ B

VSKRA119S++-1 3- 136 AB DJ B

VSKRC106S++-1 12- 27 AB DJ B

"3- 137 AB DJ B

VSKTA1505S+-1 3- 134 AC DJ B

VSRN1422-//-1 3- 145 AD DJ B

VSSSM3J05FF-1 13- 72 AD DJ B

VSSSM3J09FF-1 4- 51 AD DJ N B

VSTPC6004F+-1 3- 43 AE DS B

VSTPC8010HQ-1 10- 39 AG DS B

"8- 124 AG DS B

VSUPA502TA+-1 8- 126 AD DJ B

[X]

XBPS730P10K00 2- 19 AB DD C

MEMO

CAUTION FOR BATTERY REPLACEMENT

(Danish) ADVARSEL !

Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering.

Udskiftning må kun ske med batteri

af samme fabrikat og type.

Levér det brugte batteri tilbage til leverandoren.

(English) Caution !

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type

recommended by the manufacturer.

Dispose of used batteries according to manufacturer's instructions.

(Finnish) VAROITUS

Paristo voi räjähtää,jos se on virheellisesti asennettu.

Vaihda paristo ainoastaan laitevalmistajan suosittelemaan

tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden

mukaisesti.

(French) ATTENTION

ll y a danger d'explosion s'il y a remplacement incorrect

de la batterie. Remplacer uniquement avec une batterie du

même type on d'un type équivalent recommandé par

le constructeur.

Mettre au rébut les batteries usagées conformément aux

instructions du fabricant.

(Swedish) VARNING

Explosionsfara vid felaktigt batteribyte.

Använd samma batterityp eller en ekvivalent

typ som rekornmenderas av apparattillverkaren.

Kassera använt batteri enligt fabrikantens

Instruktion.

(German) Achtung

Explosionsgefahr bei Verwendung inkorrekter Batterien.

Als Ersatzbatterien dürfen nur Batterien vom gleichen Typ oder

vom Hersteller empfohlene Batterien verwendet werden.

Entsorgung der gebrauchten Batterien nur nach den vom

Hersteller angegebenen Anwerisugen.

CAUTION FOR BATTERY DISPOSAL

(For USA,CANADA)

"BATTERY DISPOSAL"

THIS PRODUCT CONTAINS A LITHIUM PRIMARY

(MANGANESS DIOXIDE) MEMORY BACK-UP BATTERY

THAT MUST BE DISPOSED OF PROPERLY. REMOVE THE

BATTERY FROM THE PRODUCT AND CONTACT YOUR

LOCAL ENVIRONMENTAL AGENCIES FOR INFORMATION

ON RECYCLING AND DISPOSAL OPTIONS.

"TRAITEMENT DES PILES USAGÉES"

CE PRODUIT CONTIENT UNE PILE DE SAUVEGARDE DE

MÉMOIRE LITHIUM PRIMAIRE (DIOXYDE DE MANGANESE)

QUI DOIT ÊTRE TRAITÉE CORRECTEMENT. ENLEVEZ LA

PILE DU PRODUIT ET PRENEZ CONTACT AVEC VOTRE

AGENCE ENVIRONNEMENTALE LOCALE POUR DES

INFORMATIONS SUR LES MÉTHODES DE RECYCLAGE ET

DE TRAITEMENT.

SHARP CORPORATION

Digital Document System Group

CS Promotion Center

Yamatokoriyama, Nara 639-1186, Japan

2006 February Printed in Japan t

Printed in Japan.

No part of this publication may be reproduced,

stored in a retrieval system, or transmitted.

In any form or by any means,

electronic, mechanical, photocopying, recording, or otherwise,

without prior written permission of the publisher.

MX2700_PWB Parts Guide MX2700 PWB

Navigation menu

Versions of this User Manual:

Views

Navigation
