Manual of Kirchhoff depth migration on GPU by overlapping ray
tracing and imaging kernel
Contents
1.Introduction .......................................................................................................................... 2
2.Computer operation system and hardware........................................................................ 2
3. How to compile the code ..................................................................................................... 2
4. Parameters introduction ..................................................................................................... 3
5. Run the examples ................................................................................................................. 6
2
1.Introduction
This code is designed to run the Kirchhoff depth migration on GPU,
in that the ray tracing and imaging kernel can be ran overlapped to save
more time, you can download this code and use it after a little
adjustment to computer environment.
2.Computer operation system and hardware
(1). The user needs a computer with GPU that supports CUDA with
computer ability >3.0
(2).This code run on Linux operation system, the original codes were
compiled on Centos 6.4, so we highly recommend that the user run this
code on the same level system or some higher version. The CUDA
version is CUDA 9.0 and the Seismic Unix version is 4.3.
3. How to compile the code
(1) down load, the code and examples, unzip it with
tar –zxvf kpsdm.tgz
(2) go to the src directory, change some include and library detail in
Makefile for the CUDA and Seismic Unix, then run: make in the
command line.
(3). Go to the examples director , run the code by
./cudakpsdm par=mar.par
(4). The imaging result is marmig.0, this is a sub file, you can
display by :
3
suximage < marmig.0 perc=99
4. Parameters introduction
(1) .The user can put all the parameters in a *.par file, like outflag=1.
The necessary parameters are as follows:
Table 1. the parameters of this program
Number
Parameters
Introduction of this parameters
1
Infile
su format seismic data for
imaging
2
project
directory of this imaging project
3
status name
tell the status when running
4
inner
number of traces in the infile
5
slineXY
where the subline is : 1 in x
direction, 2 in y direction
6
outflag
1: output stack 2. Output gather
7
weightflag
if with amplitude preserve :1 yes
0 : no
8
mute
if with mute ,please write 0
9
vpickf
velocity file ,format introduced
below
10
TTTdir
where the ray path files in
11
TTToldnew
if ray tracing with new velocity,1:
no 2 : yes
4
12
gridfile
geometry of this
project ,introduced below
13
vsubmin
min velocity subline
14
vsubmax
max velocity subline
15
vsubinc
interval of subline velocity
14
vcrsmin
min velocity crsline
15
vcrsmax
max velocity crsline
16
vcrsinc
interval of crsline velocity
17
submin,sbumax,subinc
imaging region of subline
18
crsmin,crsmax,crsinc
imaging region of crsline
19
off=
output offset bin if outflag=2
20
maxoff
maximum offset in su infile
21
daperture , xaperture
provide the aperture of imaging
process
22
maxapertue
the maximum aperture
23
nz
imaging point in depth
24
dz
interval of imaging point in depth
25
fz
first imaging point in depth
26
device_list
the GPU number of running the
GPU code
27
verbose
show information when running
28
maxmem
maximum memory of used GPU
5
(2) The velocity format
The velocity format should be like this:
(3) The Geometry format(take example of 2D marmousi )
1
1
minimum subline of project
2
10
maximum subline of project
3
1
increased of subline
4
1
minimum of crstline
5
737
maximum of crsline
6
1
increased of crsline
7
0
x coordinate of minimum subline and
crsline points
8
0
y coordinate of minimum subline and
crsline points
HANDVEL cdpnmber subline crsline
5(depth) 3000(velocity) 10 32000
HANDVEL cdpnmber2 subline2 crsline2
5(depth) 3200(velocity) 10 32000
6
9
0
subline increasment in x direction
10
12.5
subline increasment in ydirection
11
12.5
crsline increasment in x direction
12
0
crsline increase in direction
5. Run the examples
The examples are to test the code by Marmousi model, you can run
the code after compiling the source code. Goto the examples directory
and run :
./ cudakpsdm par=mar.par
After finished, you can display by :
suximage < marmig.0 perc=99
you can change the parameters to further test of this code.
