SimBit

Simulating Individual Markers with Bits

User Manual

Author:

Remi Matthey-Doret

Important contributor:

Michael Whitlock

Main beta tester:

Pirmin Nietlisbach

Last revised December 16, 2018, for version 4.0.5

Contents

1 Correspondance 2

2 Getting started 2

2.1 SimBit in a few words . . . . . . . . . . . . . . . . . . . . . 2

2.2 How to obtain SimBit . . . . . . . . . . . . . . . . . . . . . 3

2.3 How to compile SimBit . . . . . . . . . . . . . . . . . . . . . 3

3 A few a priori information 3

3.1 How to give arguments to SimBit . . . . . . . . . . . . . . . 3

3.2 Presentation of options in the manual . . . . . . . . . . . . . 4

3.3 The three basic types of loci . . . . . . . . . . . . . . . . . . 4

3.4 unifandA............................ 6

3.5 seq, seqInt, rep and repeach . . . . . . . . . . . . . . . . . . 6

3.6 Listing all options . . . . . . . . . . . . . . . . . . . . . . . . 7

4 Species, Generation and Habitat speciﬁc options 7

4.1 Species speciﬁc options . . . . . . . . . . . . . . . . . . . . . 8

4.2 Generation speciﬁc options . . . . . . . . . . . . . . . . . . . 9

4.3 Habitat speciﬁc options . . . . . . . . . . . . . . . . . . . . . 11

5 Launching basic simulations 12

6 Selection and phenotype 17

7 Fecundity and patch size 21

8 Mating system 22

9 Multiple Species 23

10 Initial Population 25

11 Reset genetics 27

12 Advanced dispersal options 28

13 Technical options and performance 29

14 Outputs 32

14.1Logﬁle .............................. 33

14.2 Export population to a binary ﬁle . . . . . . . . . . . . . . . 34

14.3 User friendly outputs . . . . . . . . . . . . . . . . . . . . . . 35

1 Correspondance

I would be happy to hear about your questions, bug reports or requests for new

features. If you receive an error message starting by "Internal error", then please

send me an email with the error message, SimBit’s version and the input data.

Please, when applicable, always make sure to provide a reproducible example of

your problem (input data, SimBit version) and report the error message.

Remi Matthey-Doret

remi.b.md@gmail.com

matthey@zoology.ubc.ca

Beaty Biodiversity Research Center, room 205

Dept. of Zoology, University of British Columbia

6270 University Blvd, Vancouver, BC, V6T 1Z4

Phone: +1 (604) 369-5929

2 Getting started

2.1 SimBit in a few words

SimBit is a ﬂexible and fast forward in time simulation platform for ﬁnite site mu-

tation models with arbitrary genetic architecture, selection scenario (incl. local

selection, epistasis and all possible types of dominance) and demography. SimBit

has been created with the purpose of performing realistic simulations of large

portion of chromosomes in little time with little RAM usage. SimBit’s ﬂexibility

and performance has been shown to be a useful tool for a diversity of interest.

Depending on the selection scenario that is being inputted, SimBit will select the

fastest way to simulate it.

SimBit has ﬁrst and foremost been created to be extremeley fast and RAM eﬃ-

cient when dealing with large genomes. When using a selection scenario, please

consider that accepting the assumption that allelic eﬀect are multiplicative (the

ﬁtness of the three possible genotypes of a diploid individual is 1, 1-s and (1−s)2)

will drastically reduce the computational time. Today, SimBit became a ﬂexbile

tools allowing for example to simulate several species and their ecological inter-

actions.

2.2 How to obtain SimBit

SimBit is available on GitHub at https://github.com/RemiMattheyDoret/SimBit.

If you are experiencing trouble downloading from GitHub, you might want to

have a look at the following link .

2.3 How to compile SimBit

Using the command line (terminal), cd to the downloaded directory, notice the

presence of Makefile and do make. This is it! You should now have an executable

called SimBit in /bin.

By default, the Makeﬁle is using the standard C++ of 2014 (c++14) or any more

recent standards.

3 A few a priori information

3.1 How to give arguments to SimBit

SimBit works through the command line. To use SimBit, just call the executable

and follow it with options starting with the preﬁx -- (double dash). Each option

is followed by an entry. For example --nbGenerations 1000 indicates that you

want a simulation lasting for 1000 generations. SimBit will list all available

options if you just call the executable without giving it any arguments.

./SimBit --option1 arguments for option 1 --option2 arguments for option

For some options, there exists a short and a long name (or even several long

names). For example to set the carrying capacity per patch the short name is

--N and the long name is --PatchCapacity. In this manual, I will indicate such

options as --shortName (--LongName1, --LongName2) as for example --N (--

PatchCapacity). In general, I will prefer the usage of short names over long

names.

SimBit will reorder the options you input. As such, you do not need to bother

about the ordering. If an option is missing SimBit will use the default when a

default is available. If no default is available for a missing option, if an option is

present more than once, if two entries do not coincide or if an entry is none-sense,

then SimBit will throw an (hopefully explicit enough) error.

It is also possible to put all arguments (same format) in a ﬁle and specify the ﬁle

and the line of the ﬁle that contains the argument. If the argument ﬁle is called

ArgFile.txt and the arguments of interest are found in the 12th line (the ﬁrst

line is numbered 1, not 0), then one can do

./SimBit ﬁle ArgFile.txt 12

instead of file, one can equivalently just write F,for FILE. Note that, to make

the input commands easier to look at, one can escape newline characters in the

ﬁle.

3.2 Presentation of options in the manual

When options have a short and a long name I will refer to them as --ShortName

(--LongName). Some options expect you to input a Unit, a Mode (Mode of entry

or ways you input the information as the user). When the option expects one or

more integer values (e.g. --PatchNumber), I use int. When the option expects

one or more ﬂoat values (e.g. --T1_mu) I use float. When the type of entries

(int vs float) varies depending on the Mode, I use value.

3.3 The three basic types of loci

SimBit contain three types of loci, type 1 called "T1", type 2 called "T2" and

type 3 called "T3".

3.3.1 T1 loci

Each T1 locus is a coded as a single bit and the site can therefore take only

two states 0 and 1 (or wildtype allele and mutated allele if you prefer). A T1

locus can be thought as a single nucleotide site (although it can take only two

states and not four) or as any arbitrary longer stretch of DNA. The selection

pattern that can apply to T1 loci are numerous including local selection, all

types of dominance (incl. overdominance and heterozygote disadvantage) and

any epistatic relationships among any number of T1 loci.

A speciﬁc option exists for the initialization of T1 loci (see below --T1_ini (--

T1_Initial_AlleleFreqs)).

3.3.2 T2 loci

T2 loci are designed to be an approximation of many T1 loci to increase perfor-

mance. T2 is of particular interest when simulating long stretch of DNA. Each

T2 locus is coded as a single byte (8 bits). A T2 locus tracks the number of

mutations that has happened in this locus. In other words, one can think of a T2

locus as an arbitrary number of T1 loci gathered together. If more than 28= 256

mutations have happen in a speciﬁc T2 locus, the program will send an error

message and abort. There is probably much interest at creating loci which would

gather more than 256 mutations but if you are interested in it, it will be easy to

just change the size of each T2 locus from 1 byte to 2 bytes (or more).

Because a T2 locus represents a group to T1 loci, there are a number of selection

pattern that are impossible to apply. For example, it is impossible to compute

any epistatic relationship with T2 loci. It is also impossible to compute complex

dominance pattern with T2 loci.

All T2 loci are initialized at caring 0 mutation at the beginning of the simulation

(except eventually if the initial population is loaded form a binary ﬁle, see below

--ReadPopFromBinary)

3.3.3 T3 loci

T3 loci are designed for quantitative genetic simulations. Each T3 locus is a single

byte. The phenotype is multidimensional and each locus aﬀect each dimension

of the phenotype by a certain value set by the user. For example, consider a 3D

phenotype space and a given locus which aﬀect each of the three dimensions by 0,

0.1, 1.2 respectively. If an individual has the allele 12, then the contribution of this

allele to the individual ﬁtness is 0, 1.2, 14.4 for each dimension respectively. The

user can then deﬁne a ﬁtness landscape --T3_FitnessLandscape (--T3_fit))

to match a multidimensional phenotype into a single ﬁtness value allowing for the

simulation of directional selection or balancing selection. More complex ﬁtness

landscape can possibly be implemented in the code if needed.

As a T3 locus is coded as a single byte, it can take 28= 256 diﬀerent values

(from -128 to 127). If more precision is needed, it is easy to modify the code

to allocate more memory per T3 locus. All T3 loci are initialized at the central

value 0 (except eventually if the initial population is loaded form a binary ﬁle,

see below --ReadPopFromBinary).

3.3.4 T4 loci

T4 loci are just like T1 loci except that no selection can be applied to them

(and not exactly the same outputs are possible to request). Internally, however

T1 loci and T4 loci are dealt with very diﬀerently. T4 loci are not directly

simulated. Instead, a coalescent tree is being recorded from the simulations and

mutations are being added on to the tree whenever outputs are being requested.

The only advantage of T4 loci over T1 loci results in the computational time.

Use T4 loci if 1) you want many neutral loci (or the order of, say, 105at least), 2)

recombination rate is relatively low (of the order of, say, 10−7, on average between

any two locus). T4 loci are extremely fast when dealing with recombination rate

of the order of 10−9and lower but will be much slower than T1 loci for cases of

high recombination and cases with few loci. As a general advice: don’t assume

that one is faster but try it out.

3.4 unif and A

In order to indicate input data in a convenient way SimBit uses a number of

diﬀerent Mode of input. Each speciﬁc options has its list of Modes but two Modes

that come over and over again are "unif" and "A". "A" stands for "All entries"

indicating to SimBit as many values as needed. "unif" stands for "uniform" on

the other hand indicates that all elements will take the same value. In other

words, if SimBit expect three values for a given argument, you can either do

'A 10 10 10'or 'unif 10'.

The usage of these keywords are a bit more complicated, typically when talking

about the options T1_fit and T2_fit. See speciﬁc sections for more information.

3.5 seq, seqInt, rep and repeach

There are two special keywords seq,rep and repeach. When SimBit reads the

input, it ﬁrst tokenize the input by the option names (which start with a double

dash such as --T1_fit) and it then evaluates the keywords seq,rep and repeach.

The keywords seq and seqInt are analogous to the function "seq" in R. They

both expects three values the "from" value, the "to" value and the "by" value.

seqInt is to be sued for integer values while seq is for (double precision) ﬂoat

values. For example the input seqInt 5 17 2 can be read as "from 5 to 17 by

2" and is equivalent to 5 7 9 11 13 15 17

The keyword rep is analogous to the function "rep" in R. rep expects two values

the "whatToRepeat" value, the "howManyTimes" value. For example the input

rep 4 5 is equivalent to 4 4 4 4 4. It is also possible to feed a vector as the

ﬁrst argument. Vectors must be surrounded by curly braces, values must be sep-

arated by comas. Importantly there must be no space in a vector. For example

rep {0,0.5,1} 3 is equivalent to 0 0.5 1 0 0.5 1 0 0.5 1

The keyword repeach is analogous to the function "rep" when using the each

argument in R. repeach expects two values the "whatToRepeat" value, the "how-

ManyTimes" value. rep and repeach diﬀer only when we consider vectors. For

example the inputs rep 4 5 and repeach 4 5 are both equivalent to 4 4 4 4

4. For vectors things are diﬀerent. While rep {0,0.5,1} 3 is equivalent to

0 0.5 1 0 0.5 1 0 0.5 1,repeach {0,0.5,1} 3 is equivalent to 0 0 0 0.5

0.5 0.5 1 1 1. While the seq keywords expect numbers only, the rep and

repeach functions expects only the second argument to be an integer. The ﬁrst

argument can be any string (or a vector of any strings).

Standard ways of inputs and keywords can be mixed at will. For example 3

4 rep hello 3 0 seq 1 2 0.3 repeach {1,2,3} 3 4 4 4 is equivalent to 3

4 hello hello hello 0 1.0 1.3 1.6 1.9 3 1 1 1 2 2 2 3 3 3 4 4 4. In

older versions of SimBit a keyword Rexisted and was equivalent to the current

rep. For backward compatibility Ris still available but its usage is deprecated.

Note also that the Roption is available only for some options while rep is available

for any option.

3.6 Listing all options

If you run SimBit without giving it any arguments, then it will list all the available

options.

4 Species, Generation and Habitat speciﬁc op-

tions

Most options are species-speciﬁc, generation-speciﬁc and/or time-speciﬁc. SimBit

uses the markers @S for species, @G for generation and @H for habitat. As such to

refer to the, say, 120th generation one would write @G120.

Markers must always be indicated in order (you cannot indicate @G150 before

@G120). If one or several markers are missing, SimBit will assume that previous

markers apply. The ﬁrst marker (@G0,@H0 and @S0) is optional. More information

below.

In this section I will have to use some option that I will explain only later.

Hopefully, their name will be intuitive enough to not pose too much diﬃculty to

the reader.

4.1 Species speciﬁc options

Most options are species-speciﬁc. All species must share the same geographic

location. Therefore the number of patches is not speciﬁc per patch. However, the

carrying capacity can vary among species. If you want a species to be absent from

a patch, just set its carrying capacity to zero. All options regarding the genetic

archtecture, selection scnearios and dispersal scenarios are species speciﬁc.

You need to name (and number) your diﬀerent species with the option –S (–

species).

--S (--species)name1 name2 .... Species

Each species need a unique name. If you do not use the option --S SimBit, will

assume you won’t a single species and will simply name it "sp"!

For option that are species speciﬁc, you will refer to your species with the marker

@S and by either using the species index (ﬁrst species having index 0) or by the

species name. For example

--PatchNumber 1 --S Quercus Fagus --N @SQuercus A 1000 @SFagus A 60000

--PatchNumber 1 --S Quercus Fagus --N @S0 A 1000 @S1 A 60000

are equivalent. They both ask for two species, one patch the ﬁrst species having

a carrying capacity of 1000 and the second species a carrying capacity of 60000.

Note that

--PatchNumber 1 --S Quercus Fagus --N @S1 A 1000 @S0 A 60000

--PatchNumber 1 --S Quercus Fagus --N @SFagus A 1000 @SQuercus A 60000

are NOT be accepted as the markers must always be given in the order in which

the species names are given. If you want both species to have the same carrying

capacity you can just write

--PatchNumber 1 --S Quercus Fagus --N @S0 A 1000

--PatchNumber 1 --S Quercus Fagus --N @SQuercus A 1000

or even

--PatchNumber 1 --S Quercus Fagus --N A 1000

If you want three species with the ﬁrst two having same carrying capacity and

the last one having a diﬀerent carrying capacity you can do

--PatchNumber 1 --S sp0 sp1 sp2 --N @S0 A 1000 @S1 A 1000 @S2 A 200

--PatchNumber 1 --S sp0 sp1 sp2 --N @S0 A 1000 @S2 A 200

or even

--PatchNumber 1 --S sp0 sp1 sp2 --N A 1000 @S2 A 200

However, if you want sp2 to have a diﬀerent carrying capacity you can only do

--PatchNumber 1 --S sp0 sp1 sp2 --N @S0 A 1000 @S1 A 200 @S2 A 1000

--PatchNumber 1 --S sp0 sp1 sp2 --N A 1000 @S1 A 200 @S2 A 1000

In short, and as stated above, markers must always be indicated in order (you

cannot indicate @G150 before @G120). If one or several markers are missing,

SimBit will assume that previous markers apply. The ﬁrst marker (@G0,@H0 and

@S0) is optional.

4.2 Generation speciﬁc options

You need to indicate a priori the time for which you might want to indicate a

generation-speciﬁc marker with the option --T or --TemporalChanges.

--T (--TemporalChanges)int Temporal

Changes

You will note that --T is not species speciﬁc. Let’s start with an example. If you

require 1 patch from generation 0 to generation 1000, 5 patches from generation

1000 to generation 1200 and 1 patch again until the last generation (generation

2000) you will write

--T 1000 1200 --nbGenerations 2000 --PatchNumber @G0 1 @G1000 5 @G1200

--T 1000 1200 --nbGenerations 2000 --PatchNumber 1 @G1000 5 @G1200

but you cannot write

--T 1000 1200 --nbGenerations 2000 --PatchNumber @G1000 5 @G0 1 @G1200

You can also add a zero if it makes more sense to you but it is optional

--T 0 1000 1200 --nbGenerations 2000 --PatchNumber @G1000 5 @G0 1 @G1200

Note that if you add extra generations in --T, it won’t matter either (although

it will eventually make the simulations negligibly slower) because the missing

markers will be replaced with entries at previous markers. For example

--T 0 200 1000 1100 1200 --nbGenerations 2000 --PatchNumber @G0 1 @G1000

5 @G1200 1

For a simulation that has one patch for 1000 generations and then 3 patches

for 200 generations and ﬁnally back to 1 patch up to the end of the simulations

(given by --nbGenerations) one would write

If you wish to have 5 patches the whole simulation you still have to indicate @G0.

The input would be

--PatchNumber @G0 5

or simply

--PatchNumber 5

If you wish that the time-speciﬁc options to vary through time, then the speciﬁc

time points at which changes must occur should be indicated by

Here is another example

--nbGenerations 2000 --T 0 500 1000 1200 --PatchNumber @G0 1 @G1000

3 @G1200 1 --N @G0 unif 100 @G500 unif 1500

This command would indicate that temporal changes will occur at generations 0,

500, 1000 and 1200. From generation 0 to 500, there is 1 patch of 100 individual.

From generation 500 to 1000, there is still one patch but with 1500 individuals.

From generation 1000 to 1200 there are 3 patches of 1500 individuals each and

from generation 1200 to generation 2000, there is one patch of 1500 individuals.

If there is a mismatch between between arguments given to --PatchNumber and

--N for any generation, SimBit will raise an error message and abort. For example

the following would return an error

--nbGenerations 2000 --T 0 500 1000 1200 --PatchNumber @G0 1 @G1000

3 @G1200 1 --N @G0 unif 100 @G500 A 1500

The reason it fails is the from generation 500 to generation 2000, a single patch

size is indicated but from generation 1000 to 1200, there are three patches and

SimBit therefore does not know what the patch size should be for patch 2 and 3.

4.3 Habitat speciﬁc options

All options that relate to the selection scenario (such as --T1_fit for example)

are habitat-speciﬁc. A habitat has to be understood in its ecological deﬁnition.

Several patches may belong to the same habitat and a the habitat a given patch

belong to can change over time. Patches are associated to habitat and habitat

associated to speciﬁc selection scenario allowing local and temporal variation in

selection. Let me explain how.

With the option --Habitat or --H one can associate any patch at any generation

to a given habitat.

--H (--Habitats)@G0 Mode int @Gx ... Habitats

--H is therefore a time-speciﬁc option allowing one to change the association

between patch and habitat over time and therefore to change selection pressure

over both space and time. Two modes are available, Aand unif. When using

Mode A, the number of entries must be of the same length as the number of

patches. Consider for example

--nbGens 1000 --T 500 --PatchNumber @G0 1 @G500 4 --H @G0 unif 0 @G500

A 0 0 1 0

This indicates that from generation 0 to 500 there is only one patch which be-

longs to habitat 0. From generation 500 to 1000, there are 3 patches, the ﬁrst

two patches as well as the last one belong to habitat 0 and the third patch be-

long to habitat 1. Note that habitat 0 must always exists and it is impossible to

specify an habitat index without specifying the previous one. For example it is

impossible to specify habitat 5 without specifying habitats 0, 1, 2, 3 and 4. If

the option --H is absent, SimBit assumes that all patches belong to habitat 0.

This system of associating each patch at each habitat in a time-speciﬁc manner

is a very convenient solution to indicate variation in selection pressures through

time and space. For all options concerning selection (--T1_fit,--T2_fit and

--T1_epistasis), one must indicates for which patch a given selection scenario

applies using the @Hx notation, where x is the habitat in question. You will note

the similitude between the notation @Gx and the notation @Hx for time speciﬁc

and habitat speciﬁc arguments.

More information about ﬁtness related options in the section SELECTION

5 Launching basic simulations

SimBit requires a number of basic information to make a simulation. These infor-

mations are the number of patches (--PatchNumber), the number of individuals

per patch (--N or --PatchCapacity), the number of loci, their types and physical

ordering on the chromosome (–L or –Loci), the number of generations (--nbGens

or --nbGenerations), the mutation rate (--T1_mu or --T1_MutationRate for

T1 loci and --T2_mu or --T2_MutationRate for T2 loci), the recombination rate

(--r or --RecombinationRate; is required only if there is more than one locus

indicated by option --L) and the dispersal rate (--m or --DispMat; only required

if there is more than one patch). Note that I call diﬀerent panmictic patch

in a structured population, "patch" and not "population", "subpopulation" or

"deme".

For a start we will consider the following simple example

./SimBit --nbGens 5000 --PatchNumber 4 --N A 100 100 100 100 --m Island

0.01 --L T1 3 --T1_mu A 0.00001 1e-8 1e-8 --r rate A 1e-6 1e-6

This simulation should run in a few seconds (When copy-pasting code from the

manual to the terminal, be aware that depending on the position of a newline,

there might have issue. If there is any issue you might want to ﬁrst copy on

your favourite text editor and then onto the terminal). Note that this exact same

command can be found in the ﬁle exampleCommand. To run this simulation when

reading the command form the ﬁle, use

./SimBit file exampleCommand.txt 1

The number of 1at the end indicate that SimBit must read the ﬁrst line from the

ﬁle. This allows a user to gather a number of diﬀerent commands in the same ﬁle.

The above command probably makes little sense to you so far so let’s go through

it. The command asks for a simulation lasting 5000 generations with 4patches

of 100 individuals each. Migration follows a classical island Model in which the

probability of NOT migrating is 0.95. Each haplotpye is made of 3loci of type

T1. The mutation rate per locus is 0.00001 (1e−5), 1e−8and 1e−8respectively.

The recombination rate between any locus and the next is 1e−6.

The ﬁrst option is quite straightforward, the argument of --nbGeneration is a

single integer number

--nbGens (--nbGenerations)int Number of

generations

The second option here is --PatchNumber. This option indicates the time-speciﬁc

number of patches

--PatchNumber @G0 int @Gx ... Number of

patches

The third option is --N. This option indicates the time-speciﬁc number of in-

dividuals per patch. Above I used --N @G0 A 500. "A" is the ’Mode’ used to

input data. "A" stands for "All entries". For --N, there are two possible Modes

"A" and "unif".

--N (--PatchCapacity)@S0 @G0 Mode int ... Patch carry-

ing capacity

Because all patches have the same patch size in the above example (--N A 500

500 500 500), it would be equivalent to input --N 'unif 500'. When choosing

the Mode "A", the number of values to be inputted must be equal to the Patch-

Number for this speciﬁc range of generations. Note that in the current version,

the carrying capacity of a patch is not changing with any selection pressure.

Now comes option --m. This options speciﬁes the time-speciﬁc dispersal sce-

nario. Data can be inputted with diﬀerent Modes A,LSS,OnePatch,Island,

LinearNormal.Ais the most ﬂexible mode of entry and expect the user to input

the entire matrix of dispersal probabilities. More information about these diﬀer-

ent modes in table 1. By default --m is set to OnePatch.

--m (--DispMat)@S0 @G0 Mode value ... Migration

The next option is --L. This options speciﬁes the number, types and ordering of

loci.

--L (--Loci)@S0 LocusType NbLoci LocusType NbLoci LocusType NbLoci Loci

...

For example, if you want 23 T2 loci, followed by 1000 T1 loci followed by 12 T2

loci, followed by 50 T3 loci you could input

--L 'T2 23 T1 1e5 T2 12 T3 50'

Note that --L 'T2 23 T1 5000 T1 5000 T2 3 T2 9 T3 10 T3 40'would have

the same eﬀect. For backward compatibility the letter Tin input to the option

--Loci (--L) is optional. --L 1 3 is equivalent to --L T1 3 (you can also

write --L t1 3). The recombination rate between any of these loci, including,

the placing of loci on independent chromosomes is indicated via the option --r

(--RecombinationRate). For the above case, the option --r will expect 1034

entries as there are 1035 loci (see below).

The next option is --T1_mu. This option speciﬁes the mutation rate for each

T1 locus. There are two Modes of input Aand unif

--T1_mu (--T1_MutationRate)@S0 Mode float ... Mutation

Rate on T1

lociWhen using the Mode A, the number of entries must equal the number of T1

loci indicated by --L. Below is an example.

--T1_mu A 1e-8 1e-7 1e-7 1e-7 1e-7 1e-7 1e-9 1e-8 1e-8 1e-8

Using the rep keyword, this entry could be rewritten as

--T1_mu A 1e-8 rep 1e-7 5 1e-9 rep 1e-8 3

The options --T2_mu,--T3_mu and --T4_mu are not present in the above code

but I will mention it here for their similitude with --T1_mu.--T2_mu,--T3_mu

and --T4_mu speciﬁes the mutation rates for T2 loci, T3 loci and T4 loci respec-

Table 1: Inputing data for –m

Mode Meaning Example Default

A Input a PatchNumber x PatchNum-

ber square matrix with the proba-

bility of migration from each popu-

lation to any other population. The

values of such dispersal matrix are

indicated with patch of origin listed

downwards (i.e. row names), and

patch of destination listed horizon-

tally (i.e. column names), and that

the matrix is then listed by going

through rows ﬁrst (i.e. left to right,

then top to bottom)

’A 0.8 0.2 0 0 0.1 0.8 0.1 0 0 0.1 0.8

0.1 0 0 0.2 0.8’ would simulate a 4

patches stepping stone model

LSS It stands for 1D Linear Stepping

Stones. Here the ﬁrst element is

the number of probabilities to ex-

pect next. Then is a vector of prob-

abilities and ﬁnally is which element

of this vector (zero based counting)

corresponds to the probability of not

migrating. The resulting dispersal

matrix is corrected at the edge (re-

ﬂective boundary eﬀect).

’LSS NbProbabilities probabilities

center’. For example ’LSS 4 0.05

0.05 0.75 0.15 2’ indicates that the

probability of not migrating is 0.75,

the probability of migrating one

patch on the left is 0.05, the prob-

ability of migrating two patches on

the left is 0.05, the probability of

migrating one patch on the right is

0.15.

OnePatch It is the only possible entry when

there is only a single patch

’OnePatch’

Island This creates a classical island Model.

One value is expected which is the

probability of migrating

’Island ProbabilityOfMigrating’ For

example ’Island 0.01’ would create

an island Model where the probabil-

ity of migrating from any patch to

any other patch is 0.01.

Yes

LinearNormal This creates a 1D dispersal kernel

that is approximated by a normal

(guassian) function. The two en-

tries expected are the standard de-

viation of this Gaussian distribution

(in number of patch) and the num-

ber of standard deviation above and

below which the probability of mi-

grating will be approximated to zero

’LinearNormal SD nbSD’ For exam-

ple ’LinearNormal 2 4’ indicates a

1D gaussian distribution kernel with

2 patches of standard deviation and

that after 4 standard deviation, the

probability of migrating will be con-

sidered suﬃciently low to be approx-

imated to 0.

tively and work exactly as T1_mu works

--T2_mu (--T2_MutationRate)@S0 Mode float ... Mutation rate

on T2 loci

Mutation rate

on T3 loci--T3_mu (--T3_MutationRate)@S0 Mode float ...

Mutation rate

on T4 loci--T4_mu (--T4_MutationRate)@S0 Mode float ...

The last option in the above example is --r. This options speciﬁes the recom-

bination rate between any two loci (whether the two loci in question are T1 or

T2 loci). The ﬁrst element to input the the Unit of genetic distance used. There

are 3 possible Units; rate,cM and M.rate means that values represent rate of

recombination. cM indicates that values represent centiMorgans. Mindicates that

values represent Morgans (1 Morgan = 100 centiMorgans). Of course, there is

not much diﬀerence between Mand rate if distances are not too high (say below

0.1).

Again there are two Modes, Aand unif. For the Mode A, the keyword R(explained

above) is available and the number of entries should equal the total number of

loci minus 1, where the total number of loci equals the number of T1 loci plus the

number of T2 loci. The above --r 'rate A 1e-6 1e-6'could also be written

as --r 'rate A rep 1e-6 2'or --r 'rate unif 1e-6'. Perfect independence

has to be indicated with ’-1’ if Unit is cM or Mand can be indicated as ’0.5’ or

’-1’ if Unit is rate.

--r (--RecombinationRate)@S0 Unit Mode float ... Recombination

The option --r (--RecombinationRate) is the only option that requires the

input of a unit. s like it does in a Wright-Fisher population, that is at a rate of

1/2N (a little lower in fact when there is migration).

6 Selection and phenotype

Selection scenarios are quite ﬂexible in SimBit. In absence of epistasis (as indi-

cated by option --T1_epistasis), ﬁtness eﬀects among loci are multiplicative.

As calculating epistatic interactions is slow in comparison to other ﬁtness calcu-

lation, it would of interest to some to have ﬁtness eﬀects that are additive among

loci. If it is the case, please let Remi Matthey-Doret know and he can probably

help you to implement that.

For whatever selection scenario you suggest, SimBit will search for the fastest

way to make the simulation. There are three options here, all of them are habi-

tat speciﬁc. As a reminder from section HABITAT SPECIFIC OPTIONS, if there

is no need for local selection, then there is no need to use the option --H (or --

Habitats) and SimBit assumes that all patches belong to habitat 0. Therefore

the ﬂag @H0 is always required when giving arguments to selection related options.

--T1_fit (--T1_FitnessEffects)@S0 @H0 Mode float @Hx .. Selection on

T1 loci

There are ﬁve possible Modes; A,domA,unif,MultiplicityA,MultiplicityUnif

,MultiplicityAGamma. All Modes starting by "Multiplicity" means that you are

willing to assume "multiplicity of dominance eﬀects" that is genotype 0|0 has a

ﬁtness of 1, genotype 0|1 has a ﬁtness ’x’ given in input and genotype 1|1 has

a ﬁtness x2(hence the term multiplicity). The selection is therefore necessar-

ily against the allele 1. Making this assumption allows to considerably improve

SimBit performance (for several reasons not detailed here). In all Mode except

MultiplicityAGamma entries must be ﬁtness values and not selection coeﬃcients.

In other word, if a mutation has a selection coeﬃcient of 0.1, one must input the

value 0.9. More information in table 2. We highly recommend using the options

starting with "Multiplicity" as it will greatly improve the runtime.

Note that in the current version, it is impossible to make the multiplicity assump-

tion for a given habitat but not for another one. It will raise an error message.

This limitation could be eliminated if you really need to, please contact Remi

Matthey-Doret for help.

For T2 loci the logic is very similar

Table 2: Input of data for –T1_ﬁt

Mode Meaning Example Number of

entries

A Indicates the ﬁtness of all three

genotypes at all loci

A Locus1_G0|0 Locus1_G0|1 L1G1

|1 Locus2_G0|0 Locus2_G0|1

Locus2_G1|1

3 * number

of T1 loci

domA It is just like ’A’ but allow to reduce

the size of the input (and the com-

putation on the user side) when you

want to assume that the homozygote

wildtype has a ﬁtness of 1.0. First

indicate ’cst’ of ’fun’ followed by a

ﬂoat number indicating the average

dominance coeﬃcient ¯

h. if ’cst’ is

used, then all loci have the same

dominant coeﬃcient ¯

h. If ’fun’ is

used, then the dominance coeﬃcient

at all loci is given by hi=e−ksi

where k=

−log(2¯

¯s, where ¯sis the

average selection coeﬃcient.

domA fun 0.2 Locus1_G011

Locus2_G1|1 Locus3_G1|1

number of

T1 loci +

cst or fun +

unif Indicates the ﬁtness components for

all three genotype and assume that

all loci are under the same selection

scenario

unif G0|0 G0|1 G1|1 3

MultiplicityA Indicates the ﬁtness components of

the genotype 0|1 at each locus sepa-

rately and makes the assumption of

"multiplicative dominance eﬀect"

MultiplicityA Locus1 Locus2

Locus3

Number of

T1 loci

MultiplicityUnif Indicates the ﬁtness components of

the genotype 0|1 for all loci makes

the assumption of "multiplicative

dominance eﬀect"

MultiplicityUnif G0|1 1

MultiplicityAGamma Just like MultiplicityA except that

the ﬁtness values are 1 minus the se-

lection coeﬃcient which are drawn

from a gamma distribution with pa-

rameters alpha and beta given by

the user

MultiplicityAGamma alpha beta9 2

--T2_fit (--T2_FitnessEffects)@S0 @H0 Mode float ... Selection on

T2 loci

Here there are only three Modes: A, unif and gamma. In all cases, it assumes

multiplicity of dominance eﬀects. (One may argue that the Modes might better

be renamed MultiplicityA, MultiplicityUnif and MultiplicityGamma).

For epistatic interactions use

--T1_epistasis (--T1_EpistaticFitnessEffects)@S0 @H0 nbGroupsOfLoci Epistasis

nbLociUnderEpistasisFirstGroup

LociIndices fitnesses nbLociUnderEpistasisSecondGroup LociIndices fitnesses

...

Note that --T1_epistasis is completely independent of --T_fit. As such a

locus could be under both non-epistatic selection and epistatic selection. The

eﬀects would be multiplicative. It is up to the user to decide whether (s)he want

such thing or not. If this is the case SimBit shall throw a warning message though.

The user must indicate for each species and habitat the number of groups of loci

to be considered. Within each group, the user must indicate the number n(above

called nbLociUnderEpistasisFirstGroup and nbLociUnderEpistasisSecondGroup

) loci under epistasis. With nloci, there are nloci indices and 3nﬁtness values

to indicate. Let’s take the example of having 3 loci under epistasis, we have to

indicate 33= 27 ﬁtness values. Let’s call the three loci A, B and C and three

possible genotypes at each locus 0|0, 0|1 and 1|1. Let’s write the ﬁtness of the

genotype 0|0 at locus A, 0|1 at locus B and 0|1 at locus C by A0|0_B0|1_B0|1.

Let IA,IB,IC be the indices of each of these three loci. Please note that the

ﬁrst locus has index 0 and the last locus has index "Number_T1_Loci - 1". One

would write

--T1_epistasis 3 AI BI CI A0|0_B0|0_C0|0 A0|0_B0|0_C0|1 A0|0_B0|0_C1

|1 A0|0_B0|1_C0|0 A0|0_B0|1_C0|1 A0|0_B0|1_C1|1 A0|0_B1|1_C0|0 A0|0

_B1|1_C0|1 A0|0_B1|1_C1|1 A0|1_B0|0_C0|0 A0|1_B0|0_C0|1 A0|1_B0|0_C1

|1 A0|1_B0|1_C0|0 A0|1_B0|1_C0|1 A0|1_B0|1_C1|1 A0|1_B1|1_C0|0 A0|1

_B1|1_C0|1 A0|1_B1|1_C1|1 A1|1_B0|0_C0|0 A1|1_B0|0_C0|1 A1|1_B0|0_C1

|1 A1|1_B0|1_C0|0 A1|1_B0|1_C0|1 A1|1_B0|1_C1|1 A1|1_B1|1_C0|0 A1|1

_B1|1_C0|1 A1|1_B1|1_C1|1

For T3 loci, one must indicate how the genotypes match to phenotypes with

--T3_pheno (--T3_PhenotypicEffects)@S0 int @H0 Mode float @H0 Mode T3 phenotype

and plasticityfloat @Hx ... @Sx int @H0 ...

The input format is a bit unusual here as this option expects an integer value

and then habitat-speciﬁc arguments each with a mode a ﬂoat numbers. The in-

teger value is the number of dimensions of the phenotypic space. There are two

modes, ’A’ and ’unif’. For Mode ’unif’, the expected number of entries is the

number of dimensions of the phenotype and all loci will have the same impact on

the phenotype. For Mode ’A’, the expected number of entries is the number of

dimensions times the number of T3 loci. For example

--Loci 3 2 --T3_pheno 3 A 0 0 0.5 1.1 0.1 0.2

indicates a case where there are 2 T3 loci, the ﬁrst locus aﬀects only the last

dimension of the phenotypic space and the second locus aﬀects all dimensions.

If the ﬁrst locus has value -5 and the second locus has value 10, then the contri-

bution to the phenotype for this speciﬁc haplotype (which will be added to the

contribution of the other haplotype) is 11 1 -0.5. The phenotypic value along the

ith, Ziis therefore

Zi=

j=L

j=0

locj,i ·(A1,j +A2,j )

, where Lis the number of loci, locj,i

is the eﬀect of the jth locus on the ith phenotypic axis and A1,j and A2,j are

the allelic values at the jth locus of the alleles on the ﬁrst and second haplotype

respectively.

Because --T3_pheno is a habitat-speciﬁc variable, one can model phenotypic

plasticity.

The option --T3_fit (--T3_FitnessLandscape) allows to match a given phe-

notype to a ﬁtness value

--T3_fit (--T3_FitnessLandscape)'SelectionMode @H0 EntryMode Selection on

phenotype

(T3)

mean gradient/omega @Hx ...'

The ’SelectionMode’ can be ’linear’ or ’gauss’. If ’SelectionMode’ is ’linear’,

then the ﬁtness component of a given phenotypic axis is calculated as a linear

regression with ’mean’ and ’gradient’ (or slope) given after the EntryMode. Let

Dbe the number of dimensionszibe the phenotypic value along the ith axis, zopt,i

be the optimal phenotype and gibe the gradient (or slope) along this same axis,

then the ﬁtness is deﬁned by

i=D

i=1

1− |zi−zopt,i| · gi

, where |x|means absolute value of x. If for any dimension ithe quantity

1− |zi−zopt,i| · giis zero or negative, then of course, the ﬁtness is set to 0.

If ’SelectionMode’ is ’gauss’, then ﬁtness is given by a gaussian function with

mean and selectionStrength omega. Fitness is then given as

i=D

i=1

exp −(zi−zopt,i)2

ω!

The two possible ’EntryMode’ are ’A’ and ’unif’. For ’unif’, 2 values are ex-

pected (unif mean gradient or unif mean omega). For ’A’, 2·Dvalues are

expected (A mean_1 gradient_1 mean_2 gradient_2 ...).

7 Fecundity and patch size

One will note that I use the term patch size to refer to the number of individuals

in a patch at a given generation, and the term patch carrying capacity to refer to

a maximal limit of the patch size (imposed by option --N (--patchCapacity)). fecundity

--fec (--fecundityForFitnessOfOne)@S0 float ...

By default, this number is set to -1. In such case, the patch size is always at

carrying capacity. You could set the fecundity to an arbitrarily large value to

obtain the same eﬀect as -1 but that would (very slightly) slow down the sim-

ulation. The fecundity is understood as a per individual measure. Take note

that when using males and females, only the fecundity of females will aﬀect the

number of oﬀspring produced (as long as there is at least one male in the patch).

If we assume all ﬁtnesses are at 1, then if we have hermaphroidtes a fecundity

of at least 1 will be necessary to replenish the entire patch of individuals (there

is stochastic variation that will cause on average a decrease in the patch size).

If you use a males and females mating system with a sex ratio of say, 0.75 (3

male for 1 female), then you will need a fecundity of at least 4. The actual

number of individuals in the population at the next generation is sampled from

a Poisson distribution leading to some stochasticity in the patch size. The patch

size is truncated at carrying capacity and can never exceed it. For ﬂuctuations

in population size around a carrying capacity use option --growthk explained

below.

The fecundity will interact with the eﬀect of ecological relationships with other

species. See section "Multiple Species"

When dealing with a fecundity that is not inﬁnite, the patch size may diﬀer from

the carrying capacity. Part of why SimBit is so fast is due to the way it allocates

its memory and as a consequence SimBit will keep a hard limit on the carrying

capacity with no way to overshoot it. However, you can limit a logistic growth

with potential overshoot to another carrying capacity. This is where the option

--growthk comes into play. logistic

growth curve--growthk @S0 @G0 Mode float

There are two possible modes, unif and A. In the A, you have to indicate the

carrying capacity fora logistic growth for each patch. SimBit will not enforce

the fact that the value entered is lower that the hard coded carrying capacity

indicated with option --N (--patchCapacity) as some users may want for some

speciﬁc interest make this kind of simulations. For those of you that are used to

see matrix of species interaction, the values present in the diagonal of a matrix

of interaction are - −1

growthK . The diﬀerence in SimBit is that SimBit allows this

value to be set diﬀerentially in each patch.

8 Mating system

Cloning Rate

--cloningRate @S0 float ...

The rate at which cloning happen. Note while cloning, mutations are still hap-

pening so that oﬀspring might not be exactly a clone of its parent

--selfingRate @S0 float ... Selﬁng Rate

The rate at which selﬁng happen. When using a cloning rate diﬀerent from zero,

the selﬁng rate is the selﬁng rate for oﬀsprings that are not produced via cloning.

A selﬁng rate of 0.0 (default value; or -1.0) means that selﬁng rate occurs just

like it does in a Wright-Fisher population, that is at frequency 1/N.

Note that cloningRate has preceedence over selﬁngRate. This means that if you

use both options, then the selﬁng rate will be conditional on no cloning happened.

For example, if you set the cloningRate to 1, then no selﬁng (or any other sort

of sexual reproduction) will ever occur. If you set the cloningRate to 0.5 and the

selﬁng rate to 0.1, then 50% of the oﬀsprings will be made through cloning, 5%

through selﬁng (because 10% of 50% is 5%) and the other 45% through normal

reproduction.

To set whether it runs hermaphrodites or males and females, use Mating Sys-

tem--matingSystem @S0 system (sexRatio)...

There are two possible mating systems. ’h’ (or ’H’) for hermaphrodites. This is

the default. And ’fm’ (or ’mf’, ’FM,’MF’) for males and females. If you specify

males and females, you will then need to specify the sex ratio (the ratio of males)

in the population (e.g. --matingSystem fm 0.5 to set all species to a males and

females mating system with an even sex ratio).

9 Multiple Species

Most options are species speciﬁc (such as --L,--m,--H,--T1_fit, ...) and the

goal of this section is not to review them again. This section is here to present

ecological relationships and variation in generation time among species. Species Eco-

logical Rela-

tionships

--eco (--ecoRelation, --SpeciesEcologicalRelationships) type float

type float type float ...

The option expects a matrix of interaction between any two species present.

Each interaction between two species is characterized by a ’type of interaction’

and an ’eﬀect’ (or ’magnitude’). The three types are ’A’, ’B’, ’C’ and ’0’ (see

table below). An eﬀect of 0.0 means, no eﬀect. The diagonal of the input matrix

(the eﬀect of each species on itself) is necessarily made of zero ’0 0.0’ and you

must not indicate them. Note that the eﬀect of species A on species B is not

necessarily the opposite of the eﬀect of species B on species A. It is important to

understand how this eﬀect is aﬀected by the patch size of both species as given

by the diﬀerent types.

’A’ means ’eﬀect is multiplied by the patchSize of the causal species’

’B’ means ’eﬀect is multiplied by the patchSize of the causal species and divided

by the patchSize of the recipient species’

’C’ means ’eﬀect is divided by the patchSize of the recipient species’

’C’ means ’eﬀect is multiplied by both the patchSize of the recipient species and

of the causal species’

’0’ means no eﬀect. It must therefore necessarily be followed by an eﬀect (or

magnitude) of 0.0.

The eﬀect is added on the fecundity of individuals of the recipient species. Con-

sider a case where a ’focal’ species has one ’predator’ and one ’prey’ in the envi-

ronment. Their matrix of interaction could be

--S prey predator focal --eco 0 0.0 B 2 0 0.0 A -4 A -5 B 2.2

Here I assumed the prey and predator species do not aﬀect each other. I also

assumed the predatory eﬀect were causing a ﬁxed number of death based on the

number of predators but did not depend upon the number of preys. On the other

hand, I assumed the beneﬁcial eﬀect of preying on another species depends on

both the patch size of the prey and the predator.

It is also possible to vary generation time between species. This is achieved

with

--nbSubGens (--nbSubGenerations)@S0 int @S1 int ... Generation

time

A "SubGeneration" is a generation within a generation. This allows you to sim-

ulate a species that, say 4 generations, every time another has one generation.

It is impossible to have a species with a generation time 1.2 times faster than

another unfortunately as the number of "SubGeneration" per generation must

be an integer. For example

--nbSubGens (--nbSubGenerations)@S0 1 @S1 2

would cause species 0 to have a generation that twice the one of species 1. It

would make little sense to input something like

--nbSubGens (--nbSubGenerations)@S0 2 @S1 4

Each species would undergo a number of "SubGeneration" per generation but

it would probably be easier to just double the number of generation given to --

nbGens (--nbGenerations). Of course, by default all species only have a single

"SubGeneration".

10 Initial Population

By default All T2 loci are set to carrying 0 mutations and all T1 loci are set

to 0. It is possible however to indicate the per patch allele frequency with --

T1_Initial_AlleleFreqs

--T1_Initial_AlleleFreqs 'Mode (value)'T1 Initial

allele frequen-

ciesThere are four Modes; AllOnes,AllZeros,A,Shift. See table 3 for more infor-

mation. The parenthesis around "value" (value) above indicates that the input

of values depend on the Mode. --T1_Initial_AlleleFreqs is somewhat limited

by its ﬂexibility. For a more complex description of the starting population, it is

possible to use the option --resetGenetics at the ﬁrst generation.

Another option is to directly import a population saved in a binary ﬁle from

a previous simulation. For this use

--ReadPopFromBinary 'file'Import popu-

lation

In order to read a binary ﬁle correctly, one must know what it is reading. For

this reason it is essential to specify correctly the number of type of loci, number

of patches and number of individuals per patch with the usual --PatchNumber

--N and --L options.

--InitialpatchSize ints Initial patch

SizeSet the initial patch size for each patch. The expected number of values should

Table 3: Input data for –T1_Initial_AlleleFreqs

Mode Meaning Example Default

AllOnes Set all T1 loci to 0 AllOnes Yes

AllZeros Set all T1 loci to 0 AllZeros No

A Specify the per patch, per T1 lo-

cus allele frequency. Note that

all loci would then have the same

allele frequency. There is cur-

rently not option to set the per

locus allele frequency but it would

be easy to implement so please

just contact Remi Matthey-Doret

if you are interested in such fea-

ture

A AlleleFreqPatch1

AlleleFreqPatch2

AlleleFreqPatch3 ...

Shift Specify a given patch before

which allele frequencies (at all T1

loci) are set to 0 and after which

allele frequencies (at ll T1 loci)

are set to 1

'Shift

PatchWhereTheShiftOccurs'.

For example 'Shift 4'indicates

that for patches "0, 1, 2 and

3" allele frequencies are set to

0 and for patches "4, 5, 6, ...,

PatchNumber-1" allele frequen-

cies are set to 1. Please note that

ﬁrst patch is the patch 0.

equal the number of patches at the start of the simulation and no initial patch

size should be be larger than the initial carrying capacity.

11 Reset genetics

This option deserves its own section.

--resetGenetics @S0 event <generation> <TraitType> Reset genetics

<typeOfMutationsIfNeeded> <lociListInformation> <haplotypesInformation

> <patchAndIndividualInformation> event etc... @S1 etc...

This option allows a user to make "artiﬁcial modiﬁcation" to a simulation while

it is running. It allows for example to add a mutation to simulate a selective

sweep, or to reset an entire population to the wild type allele. Note that it does

not allow one to change the genetic architecture (number or type of loci) but only

the mutations that the diﬀerent individuals are carrying. The option will take

a number of events. An event is a set of actions that SimBit will take to aﬀect

the genetics of a population. Every event must start with the keyword ’event’

(without quotation mark).

Directly after the keyword "event" comes the trait type to be aﬀected in this

event (T1, T2 or T3). If the trait type is ’T2’ or ’T3’, then SimBit will just reset

the designated loci/individuals/patch to zero. If the trait type is T1, then an

extra speciﬁcation must be given to describe the type of mutations. There are

three possible types of mutations ’setTo0’, ’setTo1’ and ’toggle’.

It is followed by loci list information. The user can either say "allLoci" and

all loci will be aﬀected or list the loci with the keyword "lociList". For example

to aﬀect loci indices 0, 4 and 7, indicate "lociList 0 4 7".

Afterward comes the haplotypes information. It must start with the keyword

"haplo" and be followed by either ’0’, ’1’ or ’both’ to indicate on which set of

chromosome (individuals are diploid as a reminder) the mutation will happen.

Finally comes the patch and individual information. It must be formatted as

patch 0 <individuals information> patch 4 <individuals information>

. To aﬀect all individuals, use the keyword ’allInds’ and to aﬀect only speciﬁc

individuals use the keyword ’indsList’ (e.g. indsList 1 2 3 4 5). For example

to aﬀect all individuals of patch 0 and only individuals 10, 20 and 25 of patch 3,

you would write patch 0 allInds patch 3 10 20 25.

Let’s do a full example. Let’s assume we would like to simulation a selective

sweep. We want only one mutation on the 11th T1 locus (index 10 by zero based

counting) of the ﬁrst (index 0) individual in the ﬁrst (index 0) patch to happen

at generation 100. We could do

--resetGenetics event 100 T1 setTo1 lociList 10 haplo 0 patch 0 indList

Of course, if this speciﬁc individual, on this speciﬁc allele was already mutated,

nothing would happen as the mutation type was ’setTo1’.

Let’s consider another example. Let’s say we want to reset the loci 10 15 and 20

to be ﬁxed for allele 0 in one patch and ﬁxed for allele 1 in the other patch. We

would need to events for that.

--resetGenetics event 500 T1 setTo0 lociList 10 15 20 haplo both patch

0 allInds event 500 T1 setTo1 lociList 10 15 20 haplo both patch 1

allInds

Note that the genetic reset will happen at the end of the speciﬁed generation

but just before writing the outputs for this generation. So, in the above example,

the oﬀsprings of the generation 500 (that is the parents of the generation 501)

are going to be reciprocaly ﬁxed at loci 10, 15 and 20.

If the fecundity (–fec) is not set to -1, it is possible that the patch size diﬀers

from the carrying capacity. If an individual does not exist, SimBit will of course

not try to mutate this individual. If you want to simulate a single mutation, it

is therefore more strategic to indicate a small individual index.

12 Advanced dispersal options

In section, Launching Basic Simulations, I already described the basic –m (–

DispMat) option. I won’t talk about it again here. I just want to add a few more

options that relates to dispersal. Selection soft-

ness

--DispWeightByFitness 'int'

--DispWeightByFitness allows to specify whether the migration rate should

be weighted by the mean ﬁtness of the emigrant patch. If the migration rate

is weighted by ﬁtness, it would simulate a case of hard selection, otherwise it

would be a case of soft selection. Note that when the fecundity diﬀers from -1,

then dispersal is necessarily weighted by ﬁtness. Two entries are possible 0and

1.0is default and means soft selection and 1means hard selection. Choosing 0

might make the simulation a little bit faster especially for simulations with a lot

of generations. gamete dis-

persal--gameteDispersal @S0 yes/no ...

If the option ’gameteDispersal’ is set to ’yes’, then gametes disperse and the oﬀ-

spring will leave wherever the gametes meet. If ’no’, then the oﬀspring migrate.

Concretely, if gamete disperse, the two parents can be from diﬀerent patch. If

oﬀpsring disperse, then the two parents must be from the same patch. For most

case, the diﬀerence between the two won’t matter. Because oﬀspring dispersal is

computationally slightly faster (although often negligibly so), the default is ’no’.

13 Technical options and performance

Random seed

--random_seed (--seed)'Int'

--random_seed speciﬁes the random seed for the simulation. The seed will be

printed on the logﬁle if this info has been demanded. Knowing the random seed

allows one to replicate the exact same simulation which is often very handy. In-

stead of specifying an Int, you can also use the keyword ’binﬁle’ or ’f’ and give

the path to a binary ﬁle containing the seed. Such binary ﬁles can be produced

from other simulations and outputted thanks to

By default, the random seed is set on the computer current time.

It is sometimes helpful to start a simulation at a generation other than 0. This

is typically useful when restarting a simulation (from a binary ﬁle) who crashed

because of overpassing the walltime limit on a cluster). In such case, you can use

Table 4: Input data for –Overwrite

Entry Meaning Default

0 Do not overwrite No

1 Overwrite even if the logﬁle already exists but not if the last output ﬁles exist Yes

2 Overwrite in any case No

--startAtGeneration --startAtGeneration 'Int'Generation to

start from

By default, startAtGeneration is set to 0.

--Overwrite 'Int'Overwrite

--Overwrite can take values 0, 1 or 2.

By default Overwrite is set to 1.

--DryRun 'Int'DryRun

To ask for a DryRun indicate --DryRun '1'. In such case SimBit will do every-

thing as normal but will exit just because running the ﬁrst generation.

Just like any software, SimBit has its strengths and weakness when it comes to

performance. SimBit is extremely fast when it comes to T1 loci when performing

the assumption of multiplicity (MultiplicityUnif,MultiplicityA) or T2 loci

(T2 loci necessarily assume that dominance eﬀect are multiplicative). If you are

willing to assume that indeed the ﬁtness eﬀect for the three possible genotypes at

a given locus are 1,1−sand (1−s)2, then SimBit can remember the ﬁtness eﬀects

of individual sequences and won’t need to recompute the ﬁtness unless a mutation

or a recombination event occurred in this sequence. SimBit therefore partition

the genome to give each sequence the same probability of an event to occur that

would force SimBit to recompute the ﬁtness for this sequence. The probability

assigned to each of these sequence if given by the option --FitnessMapInfo

. By default, the probability is set to 0.001 (--FitnessMapInfo prob 0.008).

It is a value that generally speaking works pretty well but you might want to

tweak this number to optimize running time for your particular simulations. --

FitnessMapInfo use to take several modes but it was reduced to the mode that

worked best prob.

--FitnessMapInfo @S0 Mode float @S1 Mode float ... T1 Perfor-

mance tweak

1--FitnessMapInfo is an advanced option that serves no purpose but trying to

make your simulations faster but it is not going to change anything to what is

being simulated. You can try to tweak it (independently for each species) to

make your simulation faster if you use the assumption of multiplicity or T2 loci.

The only possible Mode is prob. To make a long story short, the default is a bit

more complex that what the user can input but it is something along the lines of

prob 0.008. Changing this option will only be eﬀective if you use the "multiplic-

ity assumption" under --T1_fit and/or if you T2 loci with selection (--T2_fit).

--resetTrackedT1Muts @S0 int @S1 int ... T1 Perfor-

mance tweak

For performance reasons, SimBit can compute ﬁtness for T1 loci by only looking

at "loci of interest". I call "loci of interest", here, the loci that are 1) either

are ﬁxed for an allele that might aﬀect ﬁtness in a given habitat or 2) are poly-

morphic and might aﬀect the ﬁtness. This allows to drastically boost the time to

compute ﬁtness, esp. noticeable when not using the multiplicity assumption. The

drawback is that it means that SimBit must keep track of the loci of interest and

doing so is computationally expensive. At the end, it is a complicated trade-oﬀ

between these two processes. When the option –resetTrackedT1Muts is set to -1,

then SimBit will just compute ﬁtness over all sites and not keep track of the "loci

of interest". If a strictly positive value, n, is inputted, SimBit will keep track

of loci of interest and will screen the population to remove the loci that are no

longer of interest every n generations.

By default, n is set to -1 if the assumption of multiplicity is asked for. If the

user does not ask for the assumption of multiplicity and if the expected fraction

of polymorphic sites is not too high, then n is set to 10 generations. While Sim-

Bit tend to do a pretty good job at estimating the --fitnessMapInfo, default

parameter, it appears quite harder to estimate a good --resetTrackedT1Muts

parameter. Hence, you might want to try out diﬀerent values to minimize the

computational time. Note that The computational time will depends upon the

number of poly

I recommend to try out diﬀerent inputs for --FitnessMapInfo if you use T1 with

multiplicity and/or T2 loci and try out diﬀerent inputs for --resetTrackedT1Muts

when using T1 loci (esp. when not using the multiplicity assumption but not

only) to try to tweak their simulation to make them as fast as possible!

T4 loci are not directly simulated. Instead a coalescent tree is being computed

and mutations are added on the coalescent tree. In presence of recombination,

every locus can potentially have its own evolutionary history. Instead of repre-

senting every lineage, SimBit record some ancestral recombination graph (ARG)

inspired by Keheller et al. (2018). At any time, a given haplotype can be de-

scribed by a number of nodes in the ARG. As the average number of nodes per

haplotypes increase, the simulations get slower. It is in general not too much of

an issue, as drift is often suﬃcient to avoid that this average number of nodes

per haplotypes to reach to a high value. That being said, it can become an issue.

For this, SimBit can redeﬁne the ancestral nodes and clear the tree on demand

when the average number of nodes per haplotype is too high. The threshold for

such action to be taken is given through the option. T4 loci perfor-

mance tweak--T4_maxAverageNbNodesPerHaplotype @S1 float @S2 ...

By default this option is set to 100.

14 Outputs

General Path

--GP (--GeneralPath)path

The option --GeneralPath indicates the path where all the outputs will be

printed. Other paths relative to outputs are all relative to the "GeneralPath".

SimBit does not add a terminal "/" to the path. So, if your path does not end

with a "/", then the characters after the last "/" are taken as a preﬁx of all

output ﬁles. There is no default for this option, so you have to input at least an

empty string if you wish any outputs, otherwise an error will be thrown.

In all of below outputs you have toinput a ﬁlename that comes after the "Gen-

eralPath". There are two important keywords; "nfn" and "NFN", which stand

for "No FileName". If you indicate "nfn" (or "NFN") as ﬁlename for a speciﬁc

output, then the ﬁle will have have a speciﬁc name (but only a speciﬁc extension

and generation speciﬁc information or other speciﬁc information). This is handy

because it allows the user to give a standard name for ﬁles directly in the "Gen-

eralPath". For example

--GP /path/to/directory/firstSimulation -- T1_vcf_file nfn 200 300

400 500 --T1_AlleleFreq_file nfn 500

will create the same output as

--GP /path/to/directory/ -- T1_vcf_file firstSimulation 200 300 400

500 --T1_AlleleFreq_file firstSimulation 500

There are 3 general classes of outputs; the Logﬁle, a binary ﬁle of the popu-

lation and various user friendly (tab separated values and VCF) outputs.

Each input requires ﬁrst a ﬁle name and then, if applicable, timing of when the

output must be produced. As a general advice: avoid using spaces in the names

of ﬁles or directory and this might eventually be misinterpreted. Outputs that

are species speciﬁc are automatically produced for each species and the ﬁle name

is then preceeded by the species name.

For all the outputs provided, you can ask for a version of these outputs containing

sequencing errors.

--sequencingErrorRate rate Sequencing

error

Using this option with a rate diﬀerent from 0.0 will cause SimBit to produce

all outputs as asked (original data without sequencing error) plus an extra set

of outputs with simulated sequencing errors. The ﬁles with sequencing error will

have the string "_sequencingError" added to the ﬁle name just before the exten-

sion.

14.1 Logﬁle

The ’logﬁle’ can be used to 1) remember what input has been given to SimBit

and 2) to make sure SimBit interpreted the input as we wished although this

second usage might not be for beginners. For all outputs that can be

Entry Meaning Default Comment

0 No Logﬁle is being printed No -

1 Logﬁle contains only the arguments that SimBit has

received through the command line

Yes -

2 Logﬁle contains the arguments that SimBit has re-

ceived through the command line and all the parame-

ters that has been set for the simulation

No logﬁle might be

very big

--Logfile 'filename'Logﬁle

SimBit will automatically add the extension ’.log’ to your ﬁlename. By default,

the ﬁlename is ’logﬁle.log’.

It is possible to specify the type of logﬁle we want

--LogfileType int Logﬁle Type

Three possible entries are possible; 0,1 and 2

For all ﬁle output for which generations at which we need the outputs must

be indicated, one can either write out every generations (e.g. --T1_vcf_file

filename 10 20 30 40 50 60 70 80 90 100) or use the keyword fromtoby (or

fromToBy or FromToBy) to indicate a sequence (e.g. --T1_vcf_file filename

fromtoby 10 100 10), where the ﬁrst value is the start of the sequence, (from),

the second value is the end of the sequence (to) and the third value is the in-

crement (by). One can also mix up these methods. For example --T1_vcf_file

filename 1 10 20 30 40 50 60 70 80 90 100 107 200 300 400 500 550 600

650 700 750 800 850 900 950 1000 can be rewritten --T1_vcf_file filename

1 fromtoby 10 100 10 107 fromtoby 200 500 100 fromtoby 550 1000 50

14.2 Export population to a binary ﬁle

It may be of interest to export the population in a binary ﬁle. The main reason

why you would want to do that would be to reuse the saved population as starting

population for another simulation (with the option --readPopFromBinary). It

can also be useful, to recalculate statistics about this population later via SimBit

by simulating 0 generation or (for advanced users) by directly treating the data

yourself from a format that takes very little storage.

To export the population in a binary ﬁle use the option --SaveBinary_file

--SaveBinary_file file generations Save Binary

ﬁles

such as for example

--S HomoSapiens PanTroglodytes --SavePopBinary MyBin 1 10 25 FromToBy

50 500 50

will save the ﬁles HomoSapiens_MyBin_G50 and PanTroglodytes_MyBin_G50,

HomoSapiens_MyBin_G100 and PanTroglodytes_MyBin_G100,HomoSapiens_MyBin_G500

and PanTroglodytes_MyBin_G500 at the generations 50, 100 and 500, respec-

tively. At each generation it will also save a binary ﬁle with the seed information.

Its name is just like the above except the the species name is replaced by ’seed’.

This also mean by the way that the ’seed’ cannot be used as a species name

(SimBit will send an error message if you try).

14.3 User friendly outputs

Outputs that are speciﬁc to certain type of loci have it clearly indicated in their

name (e.g. --T1_FST_file or --T3_MeanVar_file). Just like before the outputs

start with the name of the ﬁle (or the keywords nfn or NFN) and is followed by

the time at which the output is expected. Some options can also take a subset

keyword that will allow the user to indicate the set of loci over which the output

should be computed. For example:

--T1_FST_file evenLoci 50 100 subset 0 2 4 6 8 10 12 14

It will outputs data at generations 50 and 100 for loci 0 2 4 6 8 10 12 and 14. For

these outputs that can take a subset keyword, you can give the option several

times to ask for diﬀerent subset. For example

--T1_FST_file evenLoci 50 100 subset 0 2 4 6 8 10 12 14 --T1_FST_file

oddLoci 50 100 subset 1 3 5 7 9 11 13 15

When using the same option several, it is the user’s responsibility to give diﬀerent

names to these ﬁles otherwise the data will be confounded in the same ﬁle in

ways that can be confusing. The option --T1_fitness_file does not accept the

subset keyword because a more advanced subsetting solution exists already via

the option fitnessSubsetLoci_file.

14.3.1 Outputs for T1 loci

--T1_LargeOutput_file file generations outputs: T1

Large

It outputs the complete genotype of every individual in a TSV (Tab separated

Values). This can be a very large ﬁle (hence the silly name). The extension .T1LO

is added to the ﬁlename. For example, --T1_LargeOutput_file LO 100 200

300 400 500 will print the large outputs for generations 100, 200, 300, 400 and

500.

--T1_vcf_file filename generations outputs: T1

VCF

It outputs a VCF (Variant Call Format) ﬁle. This can be very handy for us-

age with the command line vcftools. With the help of the software PGDspider,

one can reach almost any commonly used ﬁle format from this VCF ﬁle. Some

software using VCF ﬁles do not accept that locus or chromosome to have an index

of 0. Hence, unlike everywhere else in SimBit, the ﬁrst locus has index 1 and the

ﬁrst chromosome has index 1. This leads to a shift of 1 when comparing outputs

of, say .T1LO ﬁles with .vcf ﬁles The extension .T1vcf is added to the ﬁlename.

This option accepts the subset keyword.

outputs:

T1 Allele

Frequencies

--T1_AlleleFreq_file filename generations

It outputs the allele frequency at each locus for each patch. The extension .

AlleleFreq is added to the ﬁlename. This option accepts the subset keyword.

outputs: FST

--T1_FST_file filename generations

It outputs FST measures (Weir and Cockerham, as well as Nei estimates for

both averaging over all loci and as the ratio of the averages of numerator and

denominator over all loci). The extension .T1FST is added to the ﬁlename. More

info can be given via --T1_FST_info. This option accepts the subset keyword.

outputs: FST

info--T1_FST_info [number of patches to consider]

Gives info about what patch comparisons must be performed for FST calcu-

lations. It is easier to explain with examples. If you input --T1_FST_info

allInteractions 2, then SimBit will output all pairwise FST measures. If you

input --T1_FST_info allInteractions 3, then SimBit will output FST mea-

sures for all possible triplets of patches.

--T1_MeanLD_file filename generations outputs: T1

Mean Linkage

Disequilib-

rium

It outputs the within and among chromosomes average linkage disequilibrium

per patch. The extension .MeanLD is added to the ﬁlename. This option accepts

the subset keyword.

--T1_LongestRun_file filename generations outputs: T1

Longest Run

It outputs the longest run (=consecutive series) of 0 or longest run of 1 for

each haplotype (of each individual in each patch). The extension .LR is added

to the ﬁlename. This option accepts the subset keyword.

--T1_HybridIndex_file filename generations outputs: T1

Hybrid Index

It outputs the hybrid index of each individual. Here, I call the hybrid index of an

individual, the fraction of T1 loci of this individual that carry the 1allele. This is

a helpful statistic when used alongside --T1_ini (--T1_Initial_AlleleFreqs

). It allows the user to specify speciﬁc patches where all individuals are ﬁxed

for the 0allele and other patches ﬁx for the 1allele and see how they interbreed

through time. With selection against heterozygotes, you can have some barrier

to gene ﬂow. This option accepts the subset keyword.

--T1_ExpectiMinRec_file filename generations T1 Aver-

age minimal

number re-

combination

events

--T1_ExpectiMinRec outputs the average (averaged among all haplotypes within

each patch) number of times a run of zero is stopped by a run of 1 and vice versa.

For example the haplotype ’1111011111100000000’ has 3 such events. The exten-

sion .EMR is added to the ﬁlename. This option accepts the subset keyword.

14.3.2 Outputs for T2 loci outputs: T2

Large

--T2_LargeOutput_file filename ints

It outputs all genotypes of all individuals. This can be a very large ﬁle. The

extension .T2LO is added to the ﬁlename.

14.3.3 Outputs for T3 loci outputs: T3

Large

--T3_LargeOutput_file filanem ints

It outputs all genotypes of all individuals (but not the phenotypes). This can be

a very large ﬁle. The extension .T3LO is added to the ﬁlename. outputs: T3

MeanVar--T3_MeanVar_file filename ints

It outputs the mean and variance in phenotype (along each dimension of the

phenotypic space) per patch.

14.3.4 Outputs for T4 loci

For T4 loci, there are two types of outputs. These outputs work exactly as the

T1 outputs of the same style except that they can’t take the subset keyword. outputs:

T4 Large

Outputs

--T4_LargeOutput_file filename ints

outputs: T4

VCF--T4_vcf_file (--T4_VCF_file)filename ints

14.3.5 Other Outputs Outputs: ﬁt-

ness

--fitness_file filename ints

it outputs the ﬁtness of every individual in the population. The extension .fit

is added to the ﬁle name.

--fitnessSubsetLoci_file filename ints @S0 LociSet T1 ints T2 ints Outputs:

ﬁtness subset

genome

T3 ints T1epistasis ints LociSet ints ... @S1 LociSet T2 ints ...

This option is very similar to --fitness_file except that it allows to output

ﬁtness for speciﬁc subset of the genome. The option is hence species speciﬁc and

allows to deﬁne an inﬁnite number of subset of genome (called LociSet) a user

may want. The argument comes like other outputs argument with the ﬁlename

followed by the time at which outputs must be produced. What follows the time

indication is a little bit unusual. First you have the species speciﬁc markers.

Then, you can create an indeﬁnite number of sets of loci from which ﬁtness will

be computed. Each set starts with the keyword ’LociSet’. After this keyword,

you specify what types of loci you are willing to consider and their associated

indices. The four possible types are T1 T2 T3 and T1epistasis. You can specify

several type per set if you want. For example

--fitnessSubsetLoci_file myFile LociSet T1epistasis 0 3 4 T1 0 5 10

T3 0 1 2 3 LociSet T1epistasis 0 1 2 3 4

will lead SimBit to consider two sets of loci. One for which it will compute

normal selection on the T1 0 5 and 10 as well as epistatic selection on T1 loci

0 3 and 4 and selection on T3 loci 0, 1, 2 and 3. The second set only computes

the epistatic selection on loci 0, 1, 2, 3 and 4. Note that for both LociSet, the 4

components of ﬁtness (T1Fitness, T2Fitness, T3Fitness and T1epistasisFitness)

are printed. Hence, it would serves no purpose to add a third LociSet LociSet

T1 0 5 10 and this information is already contained in the ﬁrst LociSet. The

example lack any species speciﬁc marker and therefore assumes either a single

species or that the same LociSet are required for all species.

Outputs: ﬁt-

ness Stats--fitnessStats_file filename ints

it outputs the ﬁtness mean and variance per patch. The extension .fitStats is

added to the ﬁlename

--patchSize_file filename ints Outputs:

patch sizes

it outputs the number of individuals in each patch. The extension .patchSize

is added to the ﬁlename.

--exctinction_file filename ints Outputs: Ex-

tinction

it outputs the extinction time (if it applies) for every species.

--genealogy_file filename ints Outputs: Ge-

nealogy

it outputs the entire genealogy between the two time points indicated (expects

only two time points). Because, this represents a lot of data, SimBit does not

keep the entire genealogy in the RAM but print it out in ﬁle that it later merge

together into a single ﬁle and then delete. Because a lot of ﬁles are being printed

during the simulation, we recommend that you indicate a directory to SimBit,

Something like

--genealogy_file genealogy/familyTree 1000 5000

At the end of the simulation, there is a single ﬁle left. Each generation is a

line that looks like this

G_1005 P0I0_P0I34_P3I102 P0I1_P0I121_P0I97 etc...

G_1005 indicates the generation (generation 1005) and is followed by tokens with

three values separated by _such as P0I0_P0I34_P3I102. The ﬁrst one is and ID

for the oﬀspring and the last two are IDs for the two parents. P0I0_P0I34_P3I102

means that the individual index 0of patch index 0is the descendent of a parent

from patch index 0individual index 34 and from a parent from patch index 3(a

migrant) individual index 102. I would not quite call it a user-friendly output

but this format can actually become quite handy esp. that it allows to match

individuals as identiﬁed here with their other attributes (such as their ﬁtness) as

given by other output ﬁles.

The option --coalesce allows SimBit to directly compute the coalescent tree

from the genealogy ﬁles. In other words, it removes all individuals that did not

leave oﬀspring at the last generation sampled for the genealogy.

-coalesce int Outputs: Co-

alescence

It takes a single value which is either 0 (which means don’t coalesce) and a

positive number. If a positive number is used, then SimBit will remove from the

genealogy, all ancestors that did not leave any oﬀspring at the last generation

sampled. Note that when cloning / selﬁng rates are high, coalescence happen

fast but in presence of sexual reproduction, very few ancestors leave absolutely

nothing to the current generation and the option becomes almost pointless.

The positive value chosen matters only for performance reasons. A value of

250 for example, means that SimBit will look back at previous generations (to

remove all ancestors that did not leave any oﬀspring) every 250 generations.

Because looking back at ancestors is a little bit slow (because the information is

kept on the hard drive, not on the RAM), SimBit will run faster if you input a

large number. However, keeping a very large geneaology on the hard drive may

become problematic and may saturate the hard drive. As such, it may be of

interest to remove all ancestors regularly enough so as to free up the storage. A

priori, we would suggest that hard drive storage is rarely a limitation, and we

would invite our user to use a large enough number. Without having done much

testing, I would a priori recommend using a value of about 4N (where N is the

total population size) generations.

Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
