Table Of Contents

Contact And Support

Quick-start (Combining Meshs and Materials)

How It Works

Combining Skinned Meshes

Customizing Characters

Texture Packers

Baking Meshes Without Creating An Atlas First

Recommended Workow

Preparing Models For Static/Dynamic Batching (Batch Prefab Baker)

Preparing Models For Static/Dynamic Batching Legacy Method (Bake Mesh Assets In Place)

Combining Meshes at Runtime (Bake Texture Atlases Only)

Multiple Materials

MESH BAKER MANUAL

Digital Opus

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 2/22

Options

Fix Out-Of-Bounds UVs

Atlas Padding

Resize Power of 2 Textures

Blend Non-Texture Properties

Custom Shader Property Names

Lightmapping UVs

Best Practices

Creating Custom Group By Filters

Creating Custom Texture Blenders

Runtime Use (Advanced)

FAQ

Contact And Support

You can contact DigitalOpus for support or questions:

Unity forum Mesh Baker thread (preferred) :http://forum.unity3d.com/threads/mesh-baker-by-

digital-opus-released.159258/

DigitalOpus website: http://digitalopus.ca/

Email: contact.digitalopus@gmail.com

Quick-start (Combining Meshes and Materials)

This is not the only way to use Mesh Baker but it is a common use case.

1. Create a new Mesh Baker object in your scene. If your source objects exceed 64k vertices use a

TextureBaker & MultiMeshBaker

GameObject -> Create Other -> Mesh Baker ->TextureBaker & MeshBaker

2. Add objects to combine. For best results, these should use the same shader(s), but they don’t have to.

Use the provided tools to make this fast and easy.

3. Click ‘Create Empty Assets For Combined Material’. This will create material assets for the combined

material(s) and also an MB2_TextureBakeResults asset that contains information mapping materials

to UV rectangles in the atlases.

4. Select shader on Combined Mesh Material. Mesh Baker tries to duplicate the material settings on the

rst object in the list of objects to combine. Mesh Baker will build a texture atlas for each texture

property in this shader (main, bump, specular etc…).

5. Set any options then click ‘Bake Materials into a Combined Material’.

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 3/22

6. Look at warnings / errors in the console. Decide if action needs to be taken. Look at the combined

material asset in the inspector to see that the generated atlases look correct. You may need to adjust

non-texture properties in the combined material shader(s) to match the source material(s).

7. If your meshes are distributed throughout the scene or clustered you may want to use the

MB3_ClusterGrouper to group your meshes into multiple combined meshes. This will create several

MB3_MeshBaker components.

8. In the MB3_MeshBaker component click ‘Bake’. This will create the combined mesh and a new game

object that uses it. The combined mesh is an instance (not an asset) so it can’t be used in a prefab. If

you want to use the combined mesh in a prefab then select “output” -> “bake into prefab” (Create a

prefab with an empty GameObject and drag it to the resultPrefab slot). The mesh will be saved as an

asset and assigned to the provided prefab.

9. (optional) Disable renderers in source objects.

Once this has been done, you can remove the Mesh Baker object from the scene or keep it around for

easy re-baking. If anything changes in any of your source models or textures, just bake again to

regenerate the combined mesh and texture atlases.

How It Works

Mesh Baker consists of two core components. A MB3_TextureBaker component and a

MB3_MeshBaker component. These components can be used together or separately.

The MB3_TextureBaker creates atlas assets and a special Texture Bake Result assetthat maps the

source materials to UV rectangles in the atlases. Once this has been created then any mesh that uses

the source materials can be added to the combined mesh, even meshes that were not included in the

original texture bake.

The user must provide:

A Combined Mesh Material and set the shader on this material

A TextureBake Result (MB2_TextureBakeResults)

A list of game objects with MeshRenderers or SkinnedMeshRenderers to be combined

MB3_TextureBaker has a list of names of common texture properties that it looks for in the Combined

Mesh Material shader. An atlas will be created for each texture property found in this shader. If the

shader contains texture properties with non-standard names these should be added to the list of

“Custom Shader Property Names”. For each object to be combined, the materials on that object are

collected and the textures in those materials are added to the appropriate atlases. If a material does not

have a required texture property or a texture is not assigned for a property thenMesh Baker makes a

calculated guess at the correct color for theatlas based on the name of the texture property and other

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 4/22

properties that may be present. For example, if an Emission texture slot is empty Mesh Baker will use

the EmissionColor if it is present. If a source material has extra texture properties not included in

theCombined Mesh Material shader, then these are ignored. If a material uses tiling then that tiling will

be baked into the atlas up to the “maximum tiling bake size”. Textures that are used more than once on

the source objects will only be included once in the atlas provided they use the same tiling and offset.

The generated atlases are added to the Texture Bake Result (MB2_TextureBakeResults) asset. This asset

alsocontains information mapping source materials to their texture locations (UV rectangles) in the

atlases.

The Texture Bake Result asset can be used in other scenes or even exported with the combined material

and atlases and used in another project.

The user then uses the MB3_MeshBaker component to combine the meshes. This can step can happen

in a different scene or a different project as long as the user has generated a Texture Bake Result asset.

The user must provide:

A Texture Bake Result (MB2_TextureBakeResults) asset. This is usually the same as the one used by

the MB3_TextureBaker component.

A list of objects to be combined (game objects or prefabs with MeshRenderers or

SkinnedMeshRenderer components). This is usually the same as the list of objects used to build the

atlases, however, it can include objects not on that list as long as all materials on included objects

have been baked into the Texture Bake Result.

As each mesh in the list of objects to be combined isadded, mesh baker uses its materials to look up the

correct UV rectangle in theMB2_TextureBakeResults object. The UVs in the mesh to be added are

scaled to t this UV rectangle. If “x out of bounds UVs” was checked in the MB3_TextureBaker

component than UVs are scaled to be in the range 0,0 .. 1,1. All submeshes on the source objects are

collapsed into a single mesh unless the user is using the multiple combined materials option in which

case Mesh Baker creates submeshes.

The MB3_MeshBaker component internally keeps track of the objects in the combined mesh so it is

possible to quickly add and remove objects at runtime.

What is done with the combined mesh depends on the “output” option selected.

Bake into scene object: A new game object is created in this scene and a MeshRenderer or

SkinnedMeshRenderer is added. The mesh is an instance so the created game object won’t work as a

prefab.

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 5/22

Bake into prefab: The user must provide a prefab containing a game object. The mesh is saved as an

asset and it is added to the prefab.

Bake meshes in place: See the sectionPreparing Models For Static/Dynamic Batching (Bake Mesh

Assets In Place)

Combining Skinned Meshes

Combining SkinnedMeshRenderers is no different than combining ordinary meshes except that the

“Render” eld should be set to “SkinnedMeshRenderer”. You can even combine a group of

MeshRenderer objects into a single skinned mesh.

There are some specialconsiderations when combining meshes into SkinnedMeshRender:

You must leave the original SkinnedMeshRender bones in the scene, since the original bones are used

by the animations and the combined SkinnedMeshRender object. Disable the SkinnedMeshRender

component on the source objects.

If animations stop working after combining

Check the “culling type” on the animation. Unity is probably culling the animation:

Set the animation component culling type to “Based On Clip Bounds” or “Always animate”.

Avoid “based on renderers” since the original renderer is disabled.

Mesh Baker includes a component for culling out of bound animations.



Alternatively you can move the bones underneath the Animator component in the hierarchy.

You may need to update the “bounds” eld of the combined skinned mesh. This bounds is NOT

updated automatically. Unity culls a skinned meshes if its bounds are outside the camera frustum. If

you have combined several skinned meshes that can move some unpredictable distance apart then

you will need to update the bounds of the skinned mesh. Mesh Baker includes two scripts that can be

attached to your combined mesh that will update the bounds. You can also call the

UpdateSkinnedMeshBounds methods on the mesh baker components if these have been left in the

scene. Updating the bounds every frame is expensive so consider carefully if the bounds could be

static or adjusted infrequently THERE IS A BUG IN UNITY SET AND UNSET THE

updateWhenOffscreenFIELD OR THE UPDATED RENDER BOUNDS IS IGNORED:

MB2_UpdateSkinnedMeshBoundsFromBones

MB2_UpdateSkinnedMeshBoundsFromBounds

SkinnedMeshRender objects to be combined do not need to share a common parent.

You can combine MeshRenderer objects with SkinnedMeshRenderers.This is useful for adding

hats, weapons, armor etc. to skinned characters. The transform that the MeshRenderer is attached to

becomes a bone.

Parent the MeshRenderer object to the appropriate bone (for example a skinned character’s hand)

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 6/22

Position, rotate and scale it correctly

Include it in the list of objects to be combined

If you want to make a prefab out of the combined SkinnedMeshRenderer, then all the bones (source

objects) must be included in the prefab. See the FAQ for the procedure for this.

You can customize characters by adding or removing swords, weapons, armour, etc. while the game is

playing. To do so, you will need to bake all the textures that could possibly be added into the

combined material. A subset of the objects should be baked into the combined mesh. Uncheck the

Objects To Be Combined -> “Same As Texture Baker” eld. Then add this subset of objects that you

want to combine in the mesh.

Skinned Mesh Blend Shapes

Skinned meshes with Blend Shapes can be combined in Unity 5.2 and higher. If more than one source

mesh has blend shapes, then the indices of the blend shapes and names of the blend shapes in the

combined mesh will not match the indices and names in the source meshes. Mesh Baker can build a

dictionary to map blend shape indices in the source meshes to indices in the combined mesh.

MB3_MeshBaker myMeshBaker;

... do the baking

Dictionary<MBBlendShapeKey, MBBlendShapeValue> myMap =

myMeshBaker.meshCombiner.BuildSourceBlendShapeToCombinedIndexMap();

... use the map to map source indices to combined

Customizing Characters

It is possible to create characters by mixing and matching skinned mesh body and clothing parts. For

example a character could have different clothing (shirts, sweaters, coats, swimsuits, gloves etc..) and

different body parts (whole and damaged versions) of body parts etc… These can be baked into a single

skinned mesh. There are some considerations to keep in mind when creating these parts and Mesh

Baker includes a script to help with the process.

Vertices at the joins between parts (eg. a hand and arm). must have the same position, boneweight,

normal and tangent.

All parts must be skinned to the same skeleton. Don’t duplicate the skeleton for different outts.

Matching normals can be particularly difcult because some modelers like Blender do not let the user

edit the normal directly. Normals are calculated based on neighboring faces and edges. This usually

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 7/22

results in different normals for the two parts sharing a seam, even if the vertices were copied directly

from one mesh to another.

Mesh Baker provides a script (MB3_BoneWeightCopier) for copying position, boneweight, normal and

tangent from a master mesh to the other meshes. An imported mesh can be processed in Unity after

import to ensure that all meshes share the vertex properties at the joins.

To use the script create a new MB3_BoneWeightCopier object (GameObject -> Create Other -> Mesh

Baker -> Bone Weight Copier. Follow the instructions in the inspector.

Texture Packers

Mesh Baker includes several different Texture Packers:

Unity Texture Packer

This is the texture packer that is part of the Unity API. It can run out of memory (crashing Unity) when

packing many large textures.

Mesh Baker Texture Packer

This is the most full featured texture packer. It implements all Mesh Baker features.

Mesh Baker Texture Packer Fast

This is similar to the Mesh Baker Texture Packer but it is designed to be used at runtime. It packs

textures using render textures on the GPU. This is faster than the regular Mesh Baker Texture Packer

and does not require that textures be uncompressed. However it does not copy textures with perfect

delity, and does not implement all features.

Mesh Baker Texture Packer Vertical

Some meshes (eg. tree trunks) use a lot of tiling textures that are repeated many times vertically up the

trunk of the tree. Baking this tiling would exceed the maximum atlas size and atlas quality would be

poor. It would normally be impossible to pack these textures together effectively. However it is still

possible to pack the textures in an atlas if the textures are packedside by side and stretch to the top and

bottom of the atlas texture. Meshes that use the atlas can tile in the vertical direction but not the

horizontal direction. This is what the Texture Packer: Mesh Baker Texture Packer Vertical does. Note that it

is still possible to use the “Consider UVs” feature. UV tiling in the horizontal direction is baked into the

atlas. UV tiling in the vertical direction is left alone.

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 8/22

Mesh Baker Texture Packer Horizontal

This is the same as Mesh Baker Texture Packer Vertical but the directions are reversed.

Baking Meshes Without Creating An Atlas First

You can ignore the MB3_TextureBaker. Simply add your objects to the MB3_MeshBaker and bake. If

source objects used different materials they will be added to different submeshes.

Recommended Workow

To use Mesh Baker quickly and efciently, it is highly recommended that you use the“Tools For Adding

Objects”. These can save you hours of work.

1. Add a Mesh Baker object to your scene.

2. Click “Open Tools For Adding Objects” and then “List Shaders In Scene”. Use the Group By elds to

organize this list. You can create a MaterialBaker/MeshBaker object for each group by clicking the

button beside the group.If there is a Group By lter that you would like but is not provided it is easy

to create your own custom group by lters. See the section later in this manual.

3. If you want to add objects to an existing Mesh or Texture Baker you can use the “Search For Meshes

To Add” tab.

Drag the target Mesh or Texture Baker to the “Target to add objects to” slot.

Select objectsin the hierarchy and click “Add Selected Meshes”. Mesh Baker crawls through the

selected objects (including their children) and adds objects with Renderers attached. It applies the

lters as it goes.

4. Bake the materials and meshes.

5. Keep the Mesh Baker objects around. You can disable them if you like. If any of your source objects

change, then just re-bake.

If the source objects are have Collidersor have scripts on them, you may want to keep the source

objects in the scene with the render components disabled.

Preparing Models For Static/Dynamic Batching (Batch Prefab

Baker) AKA Combining Textures Without Combining Meshes

Unity’s static/dynamic batching only works with meshes that use the same material. If you have meshes

that use different materials, the Batch Prefab Baker feature can create a combined material, and copies

of your prefabs that use the combined material. The duplicate prefabs (using the combined material) will

now be batched by Unity.

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 9/22

1. (Optional) Open an empty scene for creating the prefabs.

2. Create a Batch Prefab Baker from GameObject -> Create Other -> Mesh Baker -> Batch Prefab

Baker.

3. Bake the materials together on the prefabs using the MB3_TextureBaker component on the Batch

Prefab Baker. You may need to create instances of the prefabs in your scene to do this step.

4. Enter the number of prefabs to bake in the ‘Prefab Rows Size’ eld.

5. Drag source prefab assets to the ‘Source Prefab’ slots. These need tobe project assets NOT scene

objects. Renderers

do not need to be in the root of the prefab. There can be more than one renderer in each prefab.

6. Create some prefab assets of empty game objects and drag them to the ‘Result Prefab’ slots.

7. Click Batch Bake Prefabs.

Preparing Models For Static/Dynamic Batching Legacy

Method (Bake Mesh Assets In Place)

This is an older method for preparing models for static/dynamic batching. It has more steps but is more

exible so it may work in cases where the previous method does not.

1. Create a new Mesh Baker object in your scene under the Game.

GameObject -> Create Other -> Mesh Baker -> TextureBaker & MeshBaker

2. Create combined material asset(s).

3. Select shader on result material(s). Mesh Baker will build a texture atlas for each texture property in

these shaders.

4. Add objects to combine. These can be prefabs. If youuse scene objects, the

translation/rotation/scaling will be baked into the saved meshes (which may not be what you want).

You probably want the prefab at position (0,0,0), rotation (0,0,0) scale (1,1,1).

5. Set any options, then click ‘Bake Materials into a Combined Material’.

6. Look at warnings / errors in the console. Decide if action needs to be taken.

7. Set the output to “bakeAssetsInPlace”.

8. Choose a directory where the generated meshes will be saved.

9. Click “bake”. This will create a new mesh asset for every mesh in the list of objects to combine. Look in

the console for a list of all the meshes that were created.

10. For each prefab in the list of objects to combine.

Replace the mesh with the generated mesh

Replace the material(s) with the combined material(s)

Your objects are now ready for static/dynamic batching!

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 10/22

Combining Meshes at Runtime (Bake Texture Atlases Only)

See below. This is an advanced topic.

Lightmapping



Unity 5

Unity 5 uses a completely different lightmapping system. The best documentation I have found on this is

herehttps://goo.gl/bHsCyq.

UV is used for color map, normal map, etc..

UV2 is used (in a modied form) for realtime and baked GI (UV is used if UV2 is not present)

UV3 can be optionally used for secondary detail maps or anything else

UV4 can be optionally used for secondary detail maps or anything else

For realtime and baked GI, UV2 is repacked and stored in Renderer.additionalVertexStreams. It is not

possible to preserve_existing_lightmapping for Baked GI. The preserve_existing_lightmapping does not

work in Unity 5.

The safest approach is togenerate_new_UV2 layout or copy_uv2_unchanged_to_separate_rects and re-

bake the lightmaps after the combined mesh has been generated. Note that if no UV2 is present in the

combined mesh Unity will try to use the UV channelwhen baking the lightmaps. This is a problem if

there are overlapping islands in the UV layout. There are some important settings in the lighting panel

that affect the quality of the lightmapping:

Ensure the combined mesh is marked “Lightmap Static” in the object tab

Lightmap Scale can affect quality. If it is set too large look for a warning “Objects size in lightmap has

reached maximum atlas size”. Reduce the scale until this warning does not appear.

In the Lighting -> Scenes tab experiment with the Baked Resolution and Baked Padding values.

Unity 5 does not like lightmapping objects that are very large scale in the scene. The performance and

quality are poor. Consider baking parts of the scene that are close together.

If using there are fuzzy spots on the lightmap after baking, try increasing the lightmap padding or the

lightmap resolution.

Multiple Materials:

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 11/22

Some meshes use submeshes. A submesh is nothing more than an extra list of triangles in a mesh so that

an extra material can be applied. A mesh can have a different material for every list of triangles

(submesh) it contains.

By default Mesh Baker will collapse all source submeshes into a single submesh in the combined mesh.

Mesh Baker treats each submesh as if it were its own mesh. Think of each submesh as its own entry in

the the list of Objects To Be Combined. This is often preferable to preserving the submeshes as it results

in fewer draw calls.

The Multiple Combined Materials feature allows you to create a combined mesh with submeshes and

gives you ne grained control over how the source submeshes map to the submeshes in the combined

mesh. To enable the feature check “Multiple Combined Materials.

If you are combining tree creator trees. There are additional tips in the FAQ.

To use this feature you must dene a mapping so that Mesh Baker knows which submesh in the

combined mesh a source submesh should map to. Mesh Baker uses the Material that is on a submesh in

the mapping denition. Consider this trees example:

We want the source submeshes with bark materials mapped into one submesh in the combined mesh,

and the all the submeshes with leaf materials combined into a different submesh in the combined mesh.

1. Add your objects to combine. If you do this rst then mesh baker can examine the shaders on these

objects and try to generate the source material to combined material mappings automatically for

you.

2. Click “Create Empty Assets For Combined Material”.

3. Click the “Multiple Combined Materials” checkbox. Notice that the “Combined Material” eld is

replaced by a list of materials.

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 12/22

4. Try the “Build Source To Combined Mapping From Objects To Combine” button. Look at the results.

You can modify it as desired.

5. Click the “+” or “-” buttons to add or remove mappings.

6. Drag material assets to the slots in the mapping list.

Here is how the inspector should look in the example given above.

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 13/22

Options

Consider Mesh UVs (was Fix Out-Of-Bounds UVs)

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 14/22

What It Does: Some models have UVs outside the range 0..1. This produces the same result as tiling.

These meshes are hard to combine, because the tiling will pick upneighboring textures in the atlases. Fix

Out-Of-Bounds UVs will scale the UVs in the model so that they t inside the 0..1 range. Tiling will be

baked into the combined texture.

Some source models already use an atlas and only use a tiny piece of the source texture. It would be

wasteful to copy the entire source atlas into another atlas. This feature will only copy the parts of the

source texture that are used by the source mesh UVs.

When To Use It: The “List Shaders In Scene” report will tell you if you have UVs outside the range 0..1 on

your models. Fix Out-Of-Bounds UVs is often the only way to have tiling models share textures in an

atlas. Be aware that using this feature is sometimes not the best choice. For example, consider a castle

model with many different parts (towers, walls, buttresses, etc). Each part tiles the same tiny brick

texture. These can all be combined together (with tiling) provided the brick texture is the only texture in

the atlas. This is probably a better choice than baking the tiling on each piece into one huge atlas.

Atlas Padding

What It Does: Adds a border around the textures in your atlas so that adjacent textures don’t bleed

into each other.

When To Use It: Normally, a value of 1 or 2 pixels produces good results. If your textures to be

combined already have a clear border, you could set the border to 0.

Texture Packer

What It Does: Mesh Baker can use three different texture packing algorithms.

Unity’s Pack Texturesalways packs textures into an atlas that has power-of-two dimensions. This

can lead to wasted space in atlases. This texture packer can also generate

MissingReferenceExceptions when combing many textures into a large atlas. If textures are too large

for the platform then they will be resized.

Mesh Baker Texture Packer A custom texture packer created for Mesh Baker that handles memory

better. If textures are too large for the platform then they will be resized.

Mesh Baker Texture Packer FastSame as the Mesh Baker Texture Packer but uses a RenderTexture

to pack the textures using the GPU instead of the CPU. This is faster and has the bonus that source

textures do not need to be in uncompressed format. Great for runtime texture baking. It requires

Unity 5 or Unity 4 Pro. If textures are too large for the platform then they will be resized. Not all

features are supported by this packer.

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 15/22

Mesh Baker Texture Packer HorizontalThis stacks images in atlas vertically. This makes it possible

to have images that use out of bounds UVs on the X axis share an atlas. It is best not to use ‘Consider

Mesh UVs’ when using this feature.

Mesh Baker Texture Packer VerticalThis stacks images in atlas horizontally. This makes it possible to

have images that use out of bounds UVs on the Y axis share an atlas. It is best not to use ‘Consider

Mesh UVs’ when using this feature.

Resize Power of 2 Textures

What It Does: If checked, this option shrinks power-of-two textures so they have a border of “atlas

padding” around them. For example, a 128×512 texture with 2-pixel padding is shrunk by 4 pixels, so

that it is 128×512 after padding. This only affects power-of-two textures (32, 64, 128, 512)

When To Use It: You will usually want to leave this feature on if using Unity’s Texture Packer. It is not

necessary if using Mesh Baker’s texture packer. This option can dramatically reduce wasted space in the

atlases. Unity’s texture packer likes to jump by powers of two (eg.. 512×512 jumps to 512×1024). If you

are combing two source textures that are 512×512 each then, after padding (514×514) the atlas will

jump to 1024×2048. If you have textures that you really do not want resized, then turn this feature off

or set the padding to 0.

Blend Non-Texture Properties

What It Does: If checked, Mesh Baker will attempt to blend non-texture properties such as _Color,

_Glossiness, _Emission with the texture when a texture is added to an atlas. Objects with different non-

texture properties will be written to different parts of the atlas even if they use the same texture. This

feature requires that a TextureBlender script exists for the result material shader. TextureBlenders are

easy to write. See the section later in this manual for details on how to write a TextureBlender.

When To Use It: Use this option if you are using properties such as _Color to tint different materials

different colors and want this preserved in the result material.

Custom Shader Property Names

What It Does: Mesh Baker looks at the properties in the combined mesh shader to decide which atlases

to build. It has a list of built-in texture property names to look for:“_MainTex”, “_BumpMap”,

“_BumpSpecMap”, “_DecalTex”, “_Detail”, “_GlossMap”, “_Illum”, “_LightTextureB0”,

“_ParallaxMap”,”_ShadowOffset”, “_TranslucencyMap”. If any of these are present, then it builds an atlas

for that texture property.

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 16/22

When To Use It: If you are using a custom shader, then it may include a texture property that is not on

this list. You can include this property by typing its name in the list of Custom Shader Property Names.

Do not type the name that is visible in the inspector. You will need to open the shader and look at thelist

of properties and use the name from there.

Lightmapping UVs:

Instructs Mesh Baker what to do with the UV2 channel in the combined mesh. The UV2 channel in Unity

is reserved for lightmapping.

ignore_UV2: No UV2 channel will be generated in the combined mesh.

copy_UV2_unchanged: Use this if all your source meshes use UV2 for a purpose other than

lightmapping and you want these values preserved in the combined mesh.

copy_UV2_unchanged_to_separate_rects: Use this if your source meshes have a custom UV2 layout

that you want to preserve in the combined mesh and use for lightmap baking.Each source mesh will

have its UV2 layout copied to a separate place in the combined UV2 layout. The source UV2s will be

scaled according to the size of the meshes in the scene.

preserve_current_lightmapping: This feature does not work inUnity 5Use this if your source

meshes are already lightmapped and you want to preserve the lightmap. All source meshes must use

the same lightmap index. NOTE: Lightmapping in Unity 5 is very different from Unity 4 and this

feature should be considered experimental in Unity 5.

generate_new_uv2_layout (RECOMMENDED APPROACH):Use this if you want to generate

lightmaps using the combined mesh after it has been generated. Make sure that the combined scene

object is ‘static’ and ‘enabled’ and that source objects are disabled before baking lightmaps. This is the

most robust approach for lightmapping.

The MultiMeshBaker Component

Use this component if the number of vertices in your source objects exceeds 64k. It will create as many

combined meshes as necessary toaccommodatethe objects.

Best Practices

For best results meshes and materials should:

Use the same shader

Have all textures present

Have all textures in a single material be the same size

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 17/22

The console is your friend. Look there for warnings and other information. Click on the line that says

“Report” to see a list of all the textures that were combined and the objects they are on. This is useful for

tracking down problems.

Use the “List Shaders In Scene” report to plan what to combine in your scene.

Experiment. Try different options to see what produces the best results.

If textures are missing, a default empty texture will be created. If textures are different sizes, they will

be copied and resized to the same size as the largest texture in each material.

Creating Custom Group By Filters

You can easily create your own Group By lters. The easiest wayto do this is to duplicate one of the

Group By scripts:

Search the Project tab for “GroupBy”

Select and duplicate one of the GroupBy scripts

Rename the script and the name of the class within the script. The script may reside anywhere in the

assets folder as long as it is contained within a folder called “Editor”.

Modify the script to lter the way you want. The le MB3_SearchFilter contains the interface

denition and theGameObjectFilterInfo class which contains useful information on which to base

your lter.

Mesh Baker will automatically nd your TextureBlender

Creating Custom Texture Blenders

You can easily create TextureBlenders for your shaders. The easiest way to do this is to duplicate one of

the existing TextureBlender scripts:

Search the Project tab for “TextureBlender”

Select and duplicate one of the TextureBlender scripts

Rename the script and the name of the class within the script. The script may reside anywhere in the

assets folder as long as it is contained within a folder called “Editor”.

Modify the script to work with the properties that are used by theshader.

Mesh Baker will automatically nd your TextureBlender.

Runtime Use (Advanced)

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 18/22

If you want to add, delete or move objects in a combined mesh, then you will need to use the runtime

API.

How it works:

When a MB3_TextureBaker creates combined materials, it creates an MB_TextureBakeResult asset

which contains a mapping of materials to UV rectangles in the atlases. It is recommended to do this

step in the editor since it is slow and only works with uncompressed textures. The

MB3_TextureBaker can be removed from the scene after it has baked the combined material.The

texture baking pipeline can be run as a coroutine to prevent the game from freezing while textures

bake. Textures will be baked in the background.

A MB3_MeshBaker component is added to the scene and the “Texture Bake Result” eld is set to the

MB_TextureBakeResult asset created in the previous step.

At runtime, when an object is added, MB3_MeshBaker uses the object’s material to look up the UV

Rect. The mesh uvs are adjusted as the object is being added to the combined mesh.

The API has methods AddDeleteGameObject() and UpdateGameObject() for adding and deleting and

updating the game objects. Apply() changes to the mesh.

Typical Use Pattern:

The developer decides which objects he would like to be able to combine at runtime in each Mesh Baker

instance.

Create a “Combine Materials Only Baker”

Bake a Combined Material as per instructions described in previous sections

Add a MB3_MeshBaker component to the scene either from the GameObject menu or create an

empty Game Object and add the script. The MB3_TextureBaker component won’t be needed.

Set the “Texture Bake Result” eld to the asset generated in the texture bake.

This Mesh Baker instance is ready to be used at runtime. A typical use pattern would be:

using UnityEngine;

using System.Collections;

public class MB_Example : MonoBehaviour {

public MB3_MeshBaker meshbaker;

public GameObject prefab;

GameObject go1, go2;

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 19/22

void Start(){

// Instantiate some prefabs

go1 = (GameObject) Instantiate(prefab);

go1.transform.position = new Vector3(5f,5f,5f);

// Can use a prefab not baked into the materials to combine

// as long as it uses a material that has been baked

go2 = (GameObject) Instantiate(prefab);

go1.transform.position = new Vector3(5f,5f,5f);

//Add the objects to the combined mesh

GameObject[] objsToCombine = new GameObject[2] {go1,go2};

meshbaker.AddDeleteGameObjects(objsToCombine, null);

//apply the changes we made this can be slow. See docs

meshbaker.ApplyAll();

}

void Update () {

go1.transform.position =

new Vector3(5f,5f*Mathf.Sin(Time.time),5f);

go2.transform.position =

new Vector3(5f,5f, 5f*Mathf.Cos(Time.time));

GameObject[] objsToUpdate = new GameObject[2] {go1,go2};

meshbaker.UpdateGameObjects(objsToUpdate);

}

void LateUpdate(){

//Apply, after this and other scripts have made changes

//Only want to call this once per frame since it is slow

//Only change verts since it is slow to update everything

meshbaker.Apply(false,true,false,

false,false,false,false,false);

}

Performance Considerations

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 20/22

Try to callAddDeleteGameObjects as few times as possible in a frame. It takes almost the same

amount of time to add one object as many so batch the adds and deletes. It is good practice to do this

in LateUpdate after collecting objects to add and delete.

You can delete and add the same game object in a single AddDeleteGameObjects call. This is useful if

you want to change the material on an object or you have changed the mesh in an objects MeshFilter.

Apply takes approximately the same amount of time to execute Apply asAddDeleteGameObjects.

There is a roughly linear relationship between the number of channels and time

toAddDeleteGameObjects/Apply. So a mesh with vertices, colors will bake twice as fast as one with

vertices, normals, tangents, uvs.

Update is about 3x as fast asAddDeleteGameObjects so if you want just want to move objects

around in the combined mesh use Update instead ofAddDeleteGameObjects. It also puts a much

lower load on the garbage collector.

If you want to move objects around almost every frame then consider baking into a

SkinnedMeshRenderer. It is much faster than Update.

There are effectively three copies of each mesh in memory when a mesh is baked (the source mesh,

the combined mesh and internal buffers of the MeshBaker object)If you don’t intend to modify a

combined mesh then consider deleting the source meshes and the MeshBaker object from the scene:

Baking Materials at Runtime

Baking textures at runtime does incur a serious performance hit. Expect baking to take 1-20 seconds or

longer to bake atlases at runtime. If possible use the “Mesh Baker Texture Packer Fast” option. It does

not require textures to be in uncompressed format.

For building atlases at runtime it is essential that:

textures be in trucolor/RBGA32 format (Not necessary if using the Mesh Baker Texture Packer Fast)

textures have read ag set (Not necessary if using the Mesh Baker Texture Packer Fast)

Try to avoid resizing and tiling. It can reduce bake time by 80%

build padding into textures so you don’t have to pad.

don’t use padding when creating atlases

don’t use tiled materials

If you are having problems look at the Debug Log on the device

Here is a simple example:

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 21/22

using UnityEngine;

using System.Collections;

public class BakeTexturesAtRuntime : MonoBehaviour {

public GameObject target;

float elapsedTime = 0;

void OnGUI(){

GUILayout.Label("Time to bake textures: " + elapsedTime);

if (GUILayout.Button("Combine textures & build combined mesh")){

MB3_MeshBaker meshbaker = target.GetComponent<MB3_MeshBaker>

();

MB3_TextureBaker textureBaker =

target.GetComponent<MB3_TextureBaker>();

//These can be assets configured in editor

// or you can create them

// on the fly like this

textureBaker.textureBakeResults =

new MB2_TextureBakeResults();

textureBaker.resultMaterial =

new Material( Shader.Find("Diffuse") );

textureBaker.CreateAtlases();

//only necessary if your not sure whats

//in the combined mesh

meshbaker.ClearMesh();

meshbaker.textureBakeResults =

textureBaker.textureBakeResults;

//Add the objects to the combined mesh

meshbaker.AddDeleteGameObjects(

textureBaker.GetObjectsToCombine().ToArray(),

null);

meshbaker.Apply();

}

9/12/2018 Mesh Baker Manual | Digital Opus

http://digitalopus.ca/site/mesh-baker-3-manual/ 22/22



Using An External Atlas Generator with Mesh Baker

Although MeshBaker does not directly support this it is not difcult to use a third party atlas generation

tool with Mesh Baker. The MB3_MeshBaker component does not need a MB3_TextureBaker

component, all it needs is the TextureBake Result asset. You can create on of these assets yourself and

populate. Try selecting this asset in the project to look atthe elds it contains in the inspector. All you

just need to populate is the “Materials” list and the “Prefab UV Rects” list

API

Full API Documentation

Mesh Baker was created by Ian Deane. Other assets by Ian Deane include:

Fast Shadows

Mesh Master

Ramp Brush

Crater Brush

Mesh Baker is available in the asset store.

Manual

Manual

Manual

Manual

Manual

Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
