Inventory Control Form

Modular Mini Fragment LCP System

2.0 mm, 2.4 mm and 2.7 mm Implants

2.0 mm Cortex Screws,

self-tapping, T6 StarDrive recess

LENGTH LENGTH

201.356.97 6 mm

201.357.97 7 mm

201.358.97 8 mm

201.359.97 9 mm

201.360.97 10 mm

201.361.97 11 mm

201.362.97 12 mm

201.363.97 13 mm

201.364.97 14 mm

201.366.97 16 mm

201.368.97 18 mm

201.370.97 20 mm

201.372.97 22 mm

201.374.97 24 mm

201.375.97 26 mm

201.376.97 28 mm

201.377.97 30 mm

201.378.97 32 mm

201.379.97 34 mm

201.380.97 36 mm

201.381.97 38 mm

201.382.97 40 mm

2.0 mm Locking Screws,

self-tapping, T6 StarDrive recess

LENGTH LENGTH

201.876 6 mm

201.877 7 mm

201.878 8 mm

201.879 9 mm

201.880 10 mm

201.881 11 mm

201.882 12 mm

201.883 13 mm

201.884 14 mm

201.886 16 mm

201.888 18 mm

201.890 20 mm

201.892 22 mm

201.894 24 mm

201.896 26 mm

201.898 28 mm

201.900 30 mm

2.4 mm Cortex Screws,

self-tapping, T8 StarDrive recess

LENGTH LENGTH

201.756 6 mm

201.757 7 mm

201.758 8 mm

201.759 9 mm

201.760 10 mm

201.761 11 mm

201.762 12 mm

201.763 13 mm

201.764 14 mm

201.766 16 mm

201.768 18 mm

201.770 20 mm

201.772 22 mm

201.774 24 mm

201.776 26 mm

201.778 28 mm

201.780 30 mm

201.782 32 mm

201.784 34 mm

201.786 36 mm

201.788 38 mm

201.790 40 mm

2.4 mm Locking Screws,

self-tapping, T8 StarDrive recess

LENGTH LENGTH

212.806 6 mm

212.807 7 mm

212.808 8 mm

212.809 9 mm

212.810 10 mm

212.811 11 mm

212.812 12 mm

212.813 13 mm

212.814 14 mm

212.816 16 mm

212.818 18 mm

212.820 20 mm

212.822 22 mm

212.824 24 mm

212.826 26 mm

212.828 28 mm

212.830 30 mm

Synthes is a trademark of Synthes, Inc. or its affiliates.

Implants (cont’d)

J7659-E  9/12

2.7 mm Cortex Screws,

self-tapping, T8 StarDrive recess

LENGTH LENGTH

202.870 10 mm

202.872 12 mm

202.874 14 mm

202.876 16 mm

202.878 18 mm

202.880 20 mm

202.882 22 mm

202.884 24 mm

202.886 26 mm

202.888 28 mm

202.890 30 mm

202.892 32 mm

202.894 34 mm

202.896 36 mm

202.898 38 mm

202.900 40 mm

202.962 42 mm

202.963 44 mm

202.965 46 mm

202.966 48 mm

202.967 50 mm

202.968 55 mm

202.969 60 mm

2.7 mm Locking Screws,

self-tapping, T8 StarDrive recess

LENGTH LENGTH

202.210 10 mm

202.212 12 mm

202.214 14 mm

202.216 16 mm

202.218 18 mm

202.220 20 mm

202.222 22 mm

202.224 24 mm

202.226 26 mm

202.228 28 mm

202.230 30 mm

202.232 32 mm

202.234 34 mm

202.236 36 mm

202.238 38 mm

202.240 40 mm

202.242 42 mm

202.244 44 mm

202.246 46 mm

202.248 48 mm

202.250 50 mm

202.255 55 mm

202.260 60 mm

2.0 mm LCP Plates

HOLES LENGTH

247.344 4 31 mm

247.345 5 38 mm

247.346 6 45 mm

247.347 7 52 mm

247.348 8 59 mm

247.360 10 73 mm

2.0 mm LCP Condylar Plate

SHAFT HOLES LENGTH

247.349 7 54 mm

2.0 mm LCP T-Plate, 3 holes head

SHAFT HOLES LENGTH

247.615 7 53 mm

2.0 mm LCP T-Plate, 2 holes head

SHAFT HOLES LENGTH

247.351 7 53 mm

2.0 mm LCP Y-Plate, 3 holes head

SHAFT HOLES LENGTH

247.350 7 55 mm

2.0 mm LCP Adaption Plate

SHAFT HOLES LENGTH

247.362 12 81 mm

Synthes is a trademark of Synthes, Inc. or its affiliates.

Inventory Control Form

Modular Mini Fragment LCP System

2.0 mm, 2.4 mm and 2.7 mm Implants

Implants (cont’d)

J7659-E  9/12

2.4 mm LCP Plates

HOLES LENGTH

249.674 4 36 mm

247.375 5 44 mm

249.676 6 52 mm

247.377 7 60 mm

249.678 8 68 mm

247.364 10 84 mm

2.4 mm LCP Condylar Plate

SHAFT HOLES LENGTH

249.679 7 59 mm

2.4 mm LCP T-Plate, 3 holes head

SHAFT HOLES LENGTH

249.615 7 58 mm

2.4 mm LCP T-Plate, 2 holes head

SHAFT HOLES LENGTH

249.670 7 58 mm

2.4 mm LCP Y-Plate, 3 holes head

SHAFT HOLES LENGTH

249.669 7 60 mm

2.4 mm LCP Adaption Plate

SHAFT HOLES LENGTH

247.366 12 88 mm

2.7 mm LCP Plates

HOLES LENGTH

249.680 4 40 mm

249.681 5 49 mm

249.682 6 58 mm

249.683 7 67 mm

247.372 8 76 mm

247.374 10 94 mm

2.7 mm LCP L-Plates, right, 2 holes head

SHAFT HOLES LENGTH

249.688 3 32 mm

249.701 4 40 mm

2.7 mm LCP L-Plates, oblique right, 2 holes head

SHAFT HOLES LENGTH

249.686 3 35 mm

249.698 4 42 mm

2.7 mm LCP L-Plates, oblique left, 2 holes head

SHAFT HOLES LENGTH

249.687 3 35 mm

249.699 4 42 mm

2.7 mm LCP Condylar Plate

SHAFT HOLES LENGTH

249.684 7 66 mm

2.7 mm LCP Adaption Plate

SHAFT HOLES LENGTH

247.370 12 97 mm

2.7 mm LCP L-Plates, left, 2 holes head

SHAFT HOLES LENGTH

249.689 3 32 mm

249.702 4 40 mm

Synthes is a trademark of Synthes, Inc. or its affiliates.

Inventory Control Form

Modular Mini Fragment LCP System

2.0 mm, 2.4 mm and 2.7 mm Implants

Implants (cont’d) Instruments

J7659-E  9/12

2.7 mm LCP T-Plates, 2 holes head

SHAFT HOLES LENGTH

249.685 3 32 mm

249.697 4 40 mm

Drill Bits

DIAMETER LENGTH

310.26 2.7 mm 100 mm

310.201 2.0 mm 65 mm

310.507 1.5 mm 96 mm

310.509 1.8 mm 110 mm

310.530 2.4 mm 100 mm

Kirschner Wires, Trocar Point (10/pkg.)

DIAMETER LENGTH

292.08 0.8 mm 70 mm

292.10 1.0 mm 150 mm

292.12 1.25 mm 150 mm

292.16 1.6 mm 150 mm

292.20 2.0 mm 150 mm

323.062 2.0 mm 140 mm
