APPLICANT: MOTOROLA INC. FCC ID: IHDP56JH3
INSTRUCTION MANUAL
A representative version of the user's manual follows:
Exhibit 8
1
HELLOMOTO
HELLOMOTO
congratulations
The MOTO
SURF
™ A3100 is a phone with a distinct
edge—personalization, music, videos, and e-mail—all in a
streamlined, intelligent, touchscreen phone.
The power to multitask is paired with cutting edge
Microsoft™ Windows™ Mobile technology:
Wi-Fi
,
Bluetooth®
,
3MP camera
,
full
HTML browser
,
GPS
satellite navigation
,
full multimedia support
, and
more…all in a stylish and ultra-thin design.
We’ve crammed all the main features of your phone into
this handy guide, and in a matter of minutes you’ll see just
how easy your phone is to use. Browse the menus to see
more. You may be surprised at what you discover.
So go on, check it out.
more information
on the Web
Download manuals and more:
www.motorola.com/myMotoSurf
Microsoft Windows Mobile Support:
www.microsoft.com/windowsmobile
on the phone
Tap
Start
>
Help
this guide
Caution:
Before using your phone for the first time,
please read the
important legal and safety
information
at the back of this guide (page 47).
symbols in this guide
This means a feature depends on your
network, SIM card, or subscription and may
not be available everywhere. Contact your
service provider for more information.
This means a feature needs an optional
accessory.
2
contents
contents
your phone . . . . . . . . . . . . . . . . . . 4
start menu. . . . . . . . . . . . . . . . . . . 5
assemble & charge . . . . . . . . . . . . 6
basics. . . . . . . . . . . . . . . . . . . . . . . 7
turn it on & off. . . . . . . . . . . . . . . 7
touch tips . . . . . . . . . . . . . . . . . . 7
jog ball. . . . . . . . . . . . . . . . . . . . . 8
make & answer calls. . . . . . . . . . 8
end calls . . . . . . . . . . . . . . . . . . . 8
adjust volume . . . . . . . . . . . . . . . 9
save a contact . . . . . . . . . . . . . . . 9
call a contact . . . . . . . . . . . . . . . . 9
transfer your contacts . . . . . . . . . 9
set up & go . . . . . . . . . . . . . . . . . 9
storage card . . . . . . . . . . . . . . . . 9
Today screen . . . . . . . . . . . . . . . . 10
status indicators . . . . . . . . . . . . . 11
calls . . . . . . . . . . . . . . . . . . . . . . . 12
video calls . . . . . . . . . . . . . . . . . 12
recent calls . . . . . . . . . . . . . . . . 12
redial a number . . . . . . . . . . . . . 12
return a missed call . . . . . . . . . . 12
go handsfree . . . . . . . . . . . . . . . 13
in-call options . . . . . . . . . . . . . . 13
three-way calling . . . . . . . . . . . . 13
speed dial . . . . . . . . . . . . . . . . . 14
more call features . . . . . . . . . . . 14
call times and costs. . . . . . . . . . 15
emergency calls . . . . . . . . . . . . 15
contacts . . . . . . . . . . . . . . . . . . . . 16
phone contacts &
SIM contacts . . . . . . . . . . . . . . . 16
edit or delete a contact . . . . . . . 16
store more than a number . . . . 16
more contacts features . . . . . . . 16
messages. . . . . . . . . . . . . . . . . . . 17
send a message . . . . . . . . . . . . 17
receive & read messages . . . . . 18
set up e-mail . . . . . . . . . . . . . . . 19
messaging quick reference . . . . 20
instant messaging . . . . . . . . . . . 23
text entry . . . . . . . . . . . . . . . . . . . 23
voicemail . . . . . . . . . . . . . . . . . . 24
tips & tricks . . . . . . . . . . . . . . . . . 25
personalize. . . . . . . . . . . . . . . . . . 26
Today screen . . . . . . . . . . . . . . . 26
profiles & sounds. . . . . . . . . . . . 26
time & date . . . . . . . . . . . . . . . . 26
screen settings . . . . . . . . . . . . . 26
task manager . . . . . . . . . . . . . . . 26
more personalize features . . . . . 27
photos . . . . . . . . . . . . . . . . . . . . . 27
take a photo. . . . . . . . . . . . . . . . 27
photo options. . . . . . . . . . . . . . . 28
manage your photos . . . . . . . . . 28
edit your photos. . . . . . . . . . . . . 28
videos . . . . . . . . . . . . . . . . . . . . . 29
record a video . . . . . . . . . . . . . . 29
3
contents
video options . . . . . . . . . . . . . . 29
play a video . . . . . . . . . . . . . . . . 29
manage your videos . . . . . . . . . 30
set up music . . . . . . . . . . . . . . . . 30
what music transfer tools do I
need? . . . . . . . . . . . . . . . . . . . . 30
do I need a storage card? . . . . . 30
what music file formats
can I play? . . . . . . . . . . . . . . . . . 30
what headphones
can I use? . . . . . . . . . . . . . . . . . 30
get music. . . . . . . . . . . . . . . . . . . 31
rip a CD . . . . . . . . . . . . . . . . . . . 31
transfer music . . . . . . . . . . . . . 31
play music & media . . . . . . . . . . 32
media player controls . . . . . . . . 32
wake up media player . . . . . . . . 33
turn off media player . . . . . . . . . 33
media player tips. . . . . . . . . . . . 33
streaming player . . . . . . . . . . . . 33
navigation . . . . . . . . . . . . . . . . . . 34
GPSXtra. . . . . . . . . . . . . . . . . . . 34
web browser . . . . . . . . . . . . . . . . 34
third-party applications . . . . . . . 35
Internet Sharing. . . . . . . . . . . . . 35
Google . . . . . . . . . . . . . . . . . . . . . 38
Bluetooth® wireless. . . . . . . . . . 38
turn Bluetooth power
on or off. . . . . . . . . . . . . . . . . . . 38
pair with a headset or handsfree
device . . . . . . . . . . . . . . . . . . . . 39
send (beam) objects to another
device . . . . . . . . . . . . . . . . . . . . 39
advanced Bluetooth features. . . 39
cable connections . . . . . . . . . . . . 40
connect your storage card
to a PC. . . . . . . . . . . . . . . . . . . . 40
synchronize . . . . . . . . . . . . . . . . . 42
sync with a computer . . . . . . . . 42
sync over the air . . . . . . . . . . . . 43
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . 44
turn Wi-Fi on . . . . . . . . . . . . . . . 44
Wi-Fi search & connect . . . . . . . 44
tools . . . . . . . . . . . . . . . . . . . . . . . 44
add calendar event. . . . . . . . . . . 44
set alarm . . . . . . . . . . . . . . . . . . 44
calculator . . . . . . . . . . . . . . . . . . 44
documents to go . . . . . . . . . . . . 44
tasks . . . . . . . . . . . . . . . . . . . . . 44
security. . . . . . . . . . . . . . . . . . . . . 45
lock & unlock phone. . . . . . . . . . 45
master clear. . . . . . . . . . . . . . . . 45
management . . . . . . . . . . . . . . . . 46
file explorer . . . . . . . . . . . . . . . . 46
wireless manager . . . . . . . . . . . 46
removing programs . . . . . . . . . . 46
Windows update . . . . . . . . . . . . 46
network . . . . . . . . . . . . . . . . . . . 46
legal & safety. . . . . . . . . . . . . . . . 47
index. . . . . . . . . . . . . . . . . . . . . . . 61
4
your phone
your phone
Call/Answer Key
Microphone
Navigate & select
menu items.
End/Back Key
Jog Ball
Power/Standby Key
Volume Keys
Charge & connect.
Micro USB Connector
Make & answer calls.
Video Call Lens
Camera Key
Stylus
3.5mm Headset Jack
To u chscreen Display
Camera Lens & Flash
End calls or return
to Today screen.
5
start menu
start menu
To open the menu from the Today screen,
tap
Start
.
é
Today
ê
Calendar
ë
Contacts
g
Internet Explorer
&
Messaging
l
Phone
c
Windows Media
Recent Programs
í
Settings
•
Personal
tab
•Buttons
• Input
•Lock
• Menus
• Owner Information
• Phone
• Sounds & Notifications
• Today
Settings (continued)
•
System
tab
• About
• Backlight
• Certificates
• Change Master Code
•Clock & Alarms
•Encryption
• Error Reporting
•External GPS
•Jog Ball
• Managed Programs
•Memory
•Power
• Profiles
• Regional Settings
• Remove Programs
•Screen
•SysInfo
• Task Manager
• Windows Update
•
Connections
tab
•Beam
• Bluetooth
• Connections
• Domain Enroll
• Network Wizard
• USB to PC
•Wi-Fi
• Wireless Manager
ì
Programs
• Documents To Go
•Games
•ActiveSync
•Calculator
•Camera
• File Explorer
• FlashLight
• Getting Started
• Getting Started
• Google
• Internet Sharing
• JBlend Java
• Master Clear
• Messenger
• Notes
• Pictures & Videos
• Remote Desktop
• RSS Reader
•Search
•SIM Manager
• Streaming Player
• Task Manager
• Tasks
•STK *
• Windows Live
4
Help
* Optional
This is the standard main menu layout.
Your
phone’s menu may be different
.
6
assemble & charge
assemble & charge
let’s get you up and running
Caution:
See page 47 for battery use & safety information.
23
56
2.5 Hrs
cover SIM storage card
battery replace cover charge
removing battery removing storage card
7
basics
basics
a few essential basics to get you started
turn it on & off
Press and hold
W
(top of phone) for a few seconds to turn
the phone on or off.
Tip:
Want to conserve battery power? Press
W
to put the
phone in standby mode.
touch tips
Four handy ways to navigate:
tap
Gently apply pressure on the
display screen to select an
item.
Tr y t h i s : tap
Start
to open the
start menu.
tap & hold
Tap and hold to see further
menu options.
Tr y th i s : tap and hold an
appointment in
Calendar
to view
the options.
Note:
Tap
x
or
ok
to close the
window.
drag
Tap and hold the scroll bars,
or centre of the screen, then
drag up, down or across.
Tr y t h i s : drag through a
website.
Programs
Aug 08,08
8
9
10
11
12
Menu
S M T W T F S
New Appointment
Beam Appoitment...
Delete Appointment
Send as Appointment
Reply
Reply All
Cut
Copy
Paste
Internet Explorer
Favorites
http://windowsmedia.com/
News Blogs
News Videos
Online Directory
Press Releases
Free Job Post
Celebrity News
World News
Menu
8
basics
flick
Similar to dragging, but with
lighter, quicker strokes, up or
down.
Tr y t h i s : flick through your list
of
Contacts
.
jog ball
Roll the jog ball
S
up, down, left, or right to scroll to and
highlight menu items. When you highlight something,
press the center of the jog ball
s
to select it.
Note:
This guide describes how to use the stylus and
touchscreen control to use features. In most cases, it
doesn’t include the equivalent jog ball control for using the
feature.
color status
The color of the jog ball changes to show the phone status:
•Blue
- (or yellow when roaming) - incoming call,
notification or missed call
Tip:
Want to customize your notifications?T ap
Start
>
Settings
>
Sounds & Notifications
>
Notifications
tab.
•Red
- low battery
•Amber
- charging
• Green
- fully charged
make & answer calls
To make a call, tap
Start
>
Phone
then
enter a number and tap
Talk
or
press
è
.
To answer a call, tap
Answer
or
press
è
when your phone rings
or vibrates.
end calls
Press
é
.
Phone
Menu Menu
Chris
Tom
Mandy
Paula
Scott
Sanjay
Adrian
Larry
Meera
Katherine
Julie
Donovan
9
basics
adjust volume
You can adjust the volume during a call by pressing the up
or down volume keys on the side of the phone (see
page 4). To mute a call, tap
Mute
.
save a contact
1
From the Today screen, tap
Start
>
Phone
and enter the
number.
2
Tap
Menu
>
Save to Contacts
>
New Contact
.
3
Select whether to save it on your phone (
Outlook Contact
)
or
on your SIM card (
SIM Contact
).
4
Enter the contact details and tap
Save
again.
call a contact
1
Tap
Start
>
Contacts
.
2
Flick through the list to highlight the contact.
3
Tap
Call
.
transfer your contacts
To transfer your contacts from your old phone to your new
phone, simply save all your contacts to your SIM card on
your old phone. When you put the SIM card into your new
phone, the contacts appear in your contacts list.
Note:
SIM contacts only let you store basic information,
such as name and number. Other details may be lost, and
multiple numbers may be stored as multiple contacts.
set up & go
Read how to set up all the most important features on your
phone, using the
Getting Started
application.
Find it:
Start
>
Programs
>
Getting Started
You can learn how to:
•
Make a call
•
Set the date and time
•
Personalize your phone
•
Set up a password
•
Set up your e-mail
•
Set up a Bluetooth® headset
•
Transfer music
•
Use the Today screen
storage card
View the available memory on your storage card.
Find it:
Start
>
Settings
>
System
tab >
Memory
>
Storage Card
tab
10
Today screen
Check out all the content on the microSD storage card
supplied with your phone. The content can include many
exciting applications to help you make the most of your
new phone.
You can use your microSD storage card (up to 32 GB) to
install your applications
and
store more content
, such
as music, photos, video clips, documents and data.
To install the applications, follow the on-screen instructions.
To c o py a f i l e
from your storage card to a computer
, you
can use a cable connection (see page 40) or a Bluetooth®
connection (see page 38).
Today screen
quick access to the information you need most
The Today screen appears when you turn on the phone.
Press
é
to return to the Today screen at any time.
Note:
Your Today screen may look different to this one
s
.
Tap
Start
to open the
start menu
and recently used
programs. Tap the
status fields
to access your messages
or view your upcoming tasks/appointments, and more.
Drag the
carousel
left or right to access the weather
Start
NO SIM
June 04, 2008
AM
PM
No upcoming appointments
0 Emails (Outlook)
0 Messages
Lock Contacts
Status Fields
Start Menu &
Status Indicators
Carousel
Drag left or
right to access
the weather
forecast,
bookmarks,
and more.
Tap to select
11
Today screen
forecast, your favourite contacts, programs, and websites ,
and more.
status indicators
Status indicators can appear at the top of the Today screen:
w
New voicemail.
C
New e-mail or multimedia message.
:
New text message.
E
Bluetooth
®
connected.
D
Call forwarding is on.
G
f
@
Network connection:
•
G
roaming
•
f
home GPRS
•
@
network & video calling
•
highest speed network & video calling
H
or
I
Your active line (if you have more than
one).
Q
<
Current ring style -
Q
(
Silent
),
<
(
Vibrate
), none
(
Normal
,
Outdoor
, or
Automatic
).
%
Speakerphone is on.
J
Battery level.
0
Signal strength.
12
calls
calls
it’s good to talk
For the basics, see page 7. Now do some clever stuff.
video calls
If you call someone who has a 3G video phone, you
can see each other while you talk. To use video
calling, you need to be on a
3G network
(look for
at the top of your display).
make a video call
1
Tap
Start
>
Phone
then enter a number and tap
Video Call
.
Note:
Ensure that you are facing the video call lens
(see page 4).
2
To end the call, press
é
.
recent calls
Your phone keeps lists of your recent calls, even if they
didn’t connect.
Find it:
Start
>
Phone
>
Call History
To
call an entry
, highlight it and tap
Call
.
To
send a message
to an entry, scroll to it, highlight it and
tap
Menu
>
Send Text Message
.
You can also tap
Menu
to
Video Call
,
Delete
or
Save
the entry.
redial a number
1
From the Today screen, press
è
to see a list of
recently dialed calls.
2
Scroll to the entry you want to call and tap
Call
.
return a missed call
If you miss a call, your phone alerts you on the Today
screen. To return a missed call:
1
Tap
À
on the Today screen.
2
Highlight the number and tap
Call
to call it, or tap the
number to view the missed call details.
13
calls
go handsfree
Make calls without holding the phone to your ear.
in-call options
During a call you can tap the in-call option to:
•
Hold
or
Unhold
- hold the call.
•
Mute
or
Unmute
- silence your microphone.
•
Speaker On
or
Off
- turn speakerphone on or off.
•
Contacts
- access list of contacts.
•
Note
- make a quick note.
Note:
You can access other in-call options, such as
Call History,
Conference
or
Turn Handsfree On
or
Off
, by tapping
Menu
.
three-way calling
While connected to a call:
features
use the speakerphone
Tap
Speaker On
during a call to turn the handsfree
speaker on. A
U
at the top of your display indicates the
speaker is on. Tap
Speaker Off
to turn the handsfree speaker
off.
Note:
The handsfree speaker won’t work when your
phone is connected to a car kit or headset.
use a Bluetooth® headset
Go wireless and use a mono or stereo Bluetooth
headset. See page 38 for more on Bluetooth.
Note:
During a call, tap
Menu
>
Turn Hands-free On
or
Off
to
switch between the phone and your headset.
set auto answer
Set how quickly calls are automatically answered
during handsfree operation:
Start
>
Settings
>
Phone
>
Auto Answer
tab
Note:
These settings do not apply when the ring style is
set to
Silent
.
features
14
calls
1
Place your current call on hold by tapping
Hold
.
2
Enter the number of the other person and tap
Talk
.
3
Once connected, tap
Swap
to switch between the calls,
or tap
Menu
>
Conference
to combine them.
If you
receive a second call
while you are already on a call:
•
To answer the second call and put the first call on hold,
tap
Talk
. Then, tap
Swap
to switch between the calls, or
tap
Menu
>
Conference
to combine them.
•
To send the second call to your voicemail, tap
Ignore
.
speed dial
To use speed dial entries, tap and hold the single-digit
speed dial number. If the speed dial is two digits, tap the
first digit, then tap and hold the second digit. Your phone
will dial the number.
To create a speed dial entry:
1
Tap
Start
>
Contacts
.
2
Tap the contact you want.
3
Tap
Menu
>
Add to Speed Dial
.
4
In
Location
, select the speed dial number to use.
Note:
Speed dial 1 is reserved for calling your
voicemail.
5
Tap
ok
.
To
delete
a speed dial entry, tap
Start
>
Phone
>
Speed Dial
, tap
the entry, then tap
Delete
.
more call features
features
make international calls
Tap and hold
0
to insert the international
access code (shown as
+
). Then, tap the keypad keys to
dial the country code and phone number.
forward calls
Forward calls to another number:
Start
>
Settings
>
Phone
>
Services
tab >
Call Forwarding
>
Get Settings
silence ringtone
When your phone rings, press the side volume keys to
silence your ringtone.
15
calls
call times and costs
These features give you a rough idea of how much call time
you’ve used and the cost. Note that these figures may not
match what your service provider charges you, as they’re
not measured in the same way.
emergency calls
To call an emergency number, tap
Start
>
Phone
then enter the
emergency number and press
è
.
Your service provider programs emergency phone numbers
(such as 112 or 911) that you can call under any
circumstances, even when your phone is locked.
Emergency numbers vary by country. Your phone’s
pre-programmed emergency number(s) may not work in all
locations, and sometimes an emergency call cannot be
placed due to network, environmental, or interference
issues.
restrict calls
Restrict outgoing or incoming calls:
Start
>
Settings
>
Phone
>
Services
tab >
Call Barring
>
Get Settings
Select which incoming and outgoing calls to block.
features
view call timers
Start
>
Phone
>
Call History
>
Menu
>
Call Timers
reset call timers
Start
>
Phone
>
Call History
>
Menu
>
Call Timers
>
Reset
features
16
contacts
contacts
met someone new? save their number.
For the basics see page 7.
phone contacts & SIM contacts
To create a new contact stored on your phone:
Find it:
Start
>
Contacts
>
New
>
Outlook Contact
To create a new contact stored on your SIM card:
Find it:
Start
>
Contacts
>
New
>
SIM Contact
edit or delete a contact
1
Tap
Start
>
Contacts
. Scroll to the contact.
2
Tap
Menu > Edit
or
Delete Contact
.
store more than a number
You can store more than just a number for a contact.
1
Create a new contact stored on your phone. Tap
Start
>
Contacts
>
New
>
Outlook Contact
.
2
Use the fields to enter details:
• Name & Numbers
: Store multiple numbers, such
as home, work and mobile.
•E-mail
: Store e-mail addresses.
• Address
: Store work and postal addresses.
• Categories
: Select from
Business
,
Holiday
,
Personal
and
Seasonal
.
•Picture
: Add a photo so you can see who’s calling.
• Custom ringtone
: Set a unique ringtone and
message alert so you can hear who’s calling.
•Others
: Add birthday, spouse’s name, and other
details.
3
Tap
ok
to save the contact.
more contacts features
features
search for contact
Tap
Start
>
Contacts
and enter the first few letters of the
contact's name. Your phone searches through the
contacts list and shows the name.
copy contact
Copy a contact to the SIM or to the phone:
Start
>
Contacts
>
Menu
>
Copy Contact
>
To SIM
or
To Contacts
.
17
messages
messages
sometimes it’s better 2 say it in a message
You can send and receive three types of messages using
the
Messaging
feature: text messages (SMS), multimedia
messages (MMS), and e-mail messages.
To set up e-mail on your phone, see page 19. If you have
trouble setting up e-mail or synchronizing, go to
www.motorola.com/myMotoSurf
.
send a message
Find it:
Start
>
Messaging
1
To send a message, tap
Messages
>
Menu
>
New
>
Multimedia
Message
or
Text Message
.
To send an email, tap email account.
2
For e-mail, in
To
,
Cc
, and/or
Bcc
, enter e-mail addresses
or names from your Outlook contacts (as you enter a
contact name, suggestions appear in a box below the
To
field). Insert a semicolon (;) between multiple
numbers or addresses.
For text messages, enter a phone number or contact
name. As you enter a contact name, suggestions
appear in a box below the
To
field.
filter categories
Filter the contacts that are displayed:
Start
>
Contacts
>
Menu
>
Filter
send contact to another device
Use a Bluetooth® connection to send a contact to
another phone, computer, or device:
Turn Bluetooth on
- tap
Start
>
Settings
>
Connections
tab >
Bluetooth
>
Mode
tab >
Turn on Bluetooth
.
Send the contact
- tap
Start
>
Contacts
, scroll to a contact,
and tap
Menu
>
Send Contact
>
Beam
.
Your phone searches for other Bluetooth devices. Select
the one you want and you will be told when the transfer
is complete.
For more about Bluetooth connections, see page 38.
features
18
messages
Tip:
You can quickly enter phone numbers or e-mail
addresses from your contacts. In
To
, tap
j
and select
a recipient from the list. Then select the recipient's
phone number or e-mail address.
3
Use the keypad to enter a message:
To insert
a picture, video, voice note or file in a
message, tap
Menu
>
Insert
.
To set message options
, tap
Menu
>
Message Options
.
To cancel a message
, tap
Menu
>
Cancel Message
.
4
Tap
Send
.
receive & read messages
When you receive a message, your phone plays an
alert and shows a message indicator, such as
C
or
:
.
To read a message:
on the Today screen, tap the message
notification area to open the message inbox.
When you have a message open
, you can enter a
response below the message text.
When you have an e-mail open
, tap
Reply
to enter a reply.
To mark as unread or choose other options, tap
Menu
.
To
access your messages at any time
from the menu, tap
Start
>
Messaging
>
Messages
.
To
access your emails at any time
from the menu, tap
Start
>
Messaging
> email account.
Tip:
Want to switch inboxes quickly? Flick left or right to
jump from one inbox to another.
message attachments
You can receive and save
e-mail attachments.
To
download
the attachment, select the file and follow the
prompts to open it.
To
transfer
attachments to your computer for editing, use
Microsoft™ ActiveSync. See page 42 for more information.
message options
With a message selected or open:
•
Tap
Menu
>
Delete
to delete the message.
•
Tap
Menu
>
Select Messages
>
All
,
All Below
,or
Several
, and then
tap
Menu
>
Delete
to delete multiple messages in a row.
•
Tap
Menu
>
Reply
>
Reply
or
Reply All
to reply to a message.
Enter the message and tap
Send
.
•
Tap
Menu
>
Reply
>
Forward
to forward a message. Enter
the message and tap
Send
.
Tip:
Need to check your e-mail inbox for any new e-mails?
Tap
Start
>
Messaging
. Select the account to send and receive
messages and tap
Menu
>
Send/Receive
. The phone connects to
19
messages
your Internet e-mail server and sends and receives your
messages. To stop this process, tap
Menu
>
Stop Send/Receive
.
set up e-mail
MSN or Hotmail e-mail
1
Tap
Start
>
Programs
>
Windows Live
>
Sign in to Windows Live
.
Note:
If your network service provider does not offer
Windows Live
, use the
personal e-mail account
procedure in the next section.
2
Enter your e-mail address and password, then tap
Next
.
3
Choose the options you want, then tap
Next
.
4
When synchronization is complete, tap
Done
.
personal e-mail (like Yahoo or Gmail)
1
Tap
Start
>
Messaging
>
Setup E-mail
.
2
Enter your e-mail address and password, then tap
Next
.
Your phone tries to retrieve your account settings from
your e-mail provider.
If your phone finds
your account settings, it tells you.
Yo u j u s t h a v e t o t a p
Next
.
If your phone doesn’t find
your account settings, it
gives you a chance to enter them. To get this
information, contact your e-mail provider.
3
Enter your name (the messages you send will show up
as “From” this name), then tap
Next
.
4
Choose how often you want your phone to check for
new e-mail, then tap
Finish
.
Note:
E-mail service depends on your e-mail and phone
network service providers. If you have problems setting up
e-mail or synchronizing, please visit
www.motorola.com/myMotoSurf
.
work e-mail
Note:
To get the information requested in these steps,
contact your company’s system administrator.
1
Tap
Start
>
Programs
>
ActiveSync
, then tap
Menu
>
Add Server Source
.
2
Enter your e-mail address and check
Attempt to detect
Exchange Server Settings automatically
, then tap
Next
.
3
Enter your
User Name
,
Password
, and the server’s
Domain
,
then tap
Next
.
If your phone finds
your server settings, it tells you.
You just have to tap
Next
.
If your phone doesn’t find
your server settings, or if
you skip the automatic detection, you can enter the
settings provided by your company’s system
administrator, enter the Exchange
Server Address
(if
20
messages
necessary, check
This server requires an encrypted (SSL) connection
),
then tap
Next
.
4
Choose if you want to synchronize
Contacts
,
Calendar
,
Email
,
and
Tasks
, then tap
Finish
.
5
Tap
Sync
to synchronize with the Exchange server.
messaging quick reference
Note:
Some features might not work if you set up
your e-mail account manually (without the e-mail
setup wizard).
features
send text message
Start
>
Messaging
>
Messages
>
Menu
>
New
>
Text Message
create and send e-mail
Start
>
Messaging
> e-mail account >
Menu
>
New
Note:
You need to set up your e-mail accounts
before you can send an e-mail (see page 19).
To add a picture, voice note, or file to an e-mail message,
open the message area and tap
Menu
>
Insert
>
,
Voice Note
,or
File
.
Tip:
You can save a draft of a message that you are
composing to finish and send later. Tap
Menu
>
Save to Drafts
.
A draft of the message is stored in the Drafts folder of
the account you are in.
use predefined text messages
Start
>
Settings
>
Phone
>
Predefined Text Message Settings
Use the most popular text message responses—perfect
when you’re in a hurry.
features
21
messages
create and add an e-mail signature
Start
>
Messaging
> e-mail account
>
Menu
>
Tools
>
Options
>
Signatures
Scroll to the account for which you are creating the
signature. Select
Use signature with this account
. Scroll to the
Signature
box, enter your signature, and tap
ok
.
Tip:
To insert a signature in every message you send,
select
Include when replying and forwarding
. Otherwise, a signature
is inserted only in new messages.
read messages
To quickly view new messages, select the
message notification area on the Today screen.
view attachment
While viewing the message, tap the attachment
to select it.
Note:
You can view attachments only for file types that
are supported by your phone.
read old e-mails
Start
>
Messaging
> e-mail account.
features
reply, reply all or forward e-mails
From your inbox or an open message, tap
Menu
>
Reply
>
Reply
,
Reply All
, or
Forward
Tip:
If you are replying to an e-mail, you will send
less data if you do not edit the original message. This
may reduce data transfer costs based on your rate plan.
download message objects
If an e-mail message includes an attachment,
when you open the message, the name of the
attachment is highlighted. To download the
attachment, select the highlighted attachment name.
The attachment is downloaded the next time you
synchronize or connect to your e-mail server.
Note:
If there are multiple attachments in the message,
only the selected attachments are downloaded.
download complete e-mail messages
Start
>
Messaging
> e-mail account. Select the
message and tap
Menu
>
Download Message
.
The complete message is retrieved the next time
you synchronize or connect to your e-mail server and
send and receive e-mail.
features
22
messages
mark a folder for synchronization
When you synchronize your e-mail account with
your PC, the same Inbox folders that are in
Outlook on your PC are created on your phone.
Start
>
Messaging
> e-mail account >
Menu
>
Tools
>
Manage
Folders
.
Highlight the folder/s you want to synchronize and tap
ok
.
The marked folders will be synchronized during the next
sync session.
Note:
Only e-mail folders stored on the server are
available for sync.
view status of sent e-mail
Start
>
Messaging
> e-mail account >
Menu
>
Go To
>
Folders
>
Outbox
Messages in the
Outbox
have not been sent. To send a
message, scroll to it and tap
Menu
>
Send/Receive
.
receive e-mail
If your phone is set up to automatically check for
new e-mails, your phone will show
e
when a
new e-mail arrives.
features
delete e-mail
From the Inbox or an open e-mail message, tap
Menu
>
Delete
.
manually send and receive e-mail
Start
>
Messaging
> e-mail account >
Menu
>
Send/Receive
call a phone number in e-mail
Highlight a phone number in a message and
press
è
.
move e-mail to personal folder
After you read the e-mail, tap
Menu
>
Move
> folder.
delete a mail account
Start
>
Messaging
> e-mail account >
Menu
>
Delete
.
Note:
You cannot delete your
Text Messages
,
MMS
, or
Exchange server e-mail accounts.
empty deleted items folder
Start
>
Messaging
> e-mail account >
Menu
>
Go To
>
Folders
,
scroll to
Deleted Items
, then tap
Menu
>
Delete All
.
features
23
text entry
instant messaging
Find it:
Start
>
Programs
>
Messenger
Connect to your Windows Live™ instant messaging
community with ease.
Once you are logged in, a list of your buddies is displayed
showing their online status.
To
add contacts
to your list, tap
Menu
>
Search for buddy
. Tap
Add
to add a contact to your list.
To
start a conversation
, scroll to an online contact and tap
Menu
>
Chat
.
To
end a conversation
, tap
Menu
>
End chat
.
To
log out
from your instant messaging session, tap
Menu
>
Logout
.
text entry
how fast can u text?
Multiple text entry methods make it easy for you to enter
names, numbers, and messages. Text entry options are
available when the keyboard icon shows at the bottom of
the screen. Tap
Y
to change to another method:
entry modes
Block Recognizer
Write letters, numbers, and punctuation
in one of the two writing blocks - letters
and punctuation on the left (
á
,
Â
or
Á
) and numbers on the right (
Ã
).
Keyboard
Tap the letters and numbers on the
keyboard to enter them in the text entry
window.
Letter Recognizer
Write letters, numbers, and punctuation
in one of the three writing blocks -
capitals letters and punctuation on the
left (
á
), no capitals in the middle (
Á
)
and numbers on the right (
Ã
).
24
text entry
Write a text character, then wait for your phone to
recognize and place it in the text entry window.
To
delete
characters, tap
n
. To start a
new line
, tap
j
.
To
enter a space
, tap the space bar.
Tip:
Tap a location in the text entry window to move the
cursor to that location.
text prediction
As you enter letters, your phone might try to
predict
the
word. For instance, it might predict “program” when you
enter “prog”.
To accept the prediction, tap the predicted word. To turn off
text prediction, tap
Start
>
Settings
>
Input
>input method
>
Word Completion
tab, then uncheck
Suggest words when entering text
.
adjust text input settings
Find it:
Start
>
Settings
>
Input
>input method
You can set your preferred input method, specify your
writing direction and the word recognition delay, activate
shorthand options, activate a user dictionary, and adjust
your pen width and color for the text you enter.
voicemail
When you receive a voicemail message, your phone
shows an indicator and
New Voicemail
. Follow the
prompts to access the voicemail message.
To listen to your voicemail at any time, tap and hold
1
.
Transcriber
Recognizes handwriting in cursive, print
and mixed styles, as well as numbers
and symbols. Simply write legibly
anywhere on the screen.
XT9
Shows larger key sizes. Tap the letters
and numbers on the keyboard, or
phonepad, to enter them in the window.
entry modes
25
tips & tricks
tips & tricks
a few ways to make your phone even easier to use
From the Today screen, use these shortcuts:
To... Do this...
lock/unlock
phone
From the Today screen, tap
Lock
or
Unlock
.
use most
recently used
feature
Icons for your most recently used
features appear when you tap
Start
.
Use the navigation keys to select one.
open recent
calls
Press
è
. To return a call, scroll to the
call, then tap
è
.
put phone in
standby mode
Press
W
.
make note of
tasks
Jot down all those important tasks:
Start
>
Programs
>
Tasks
. The task will
show on the Today screen until you
complete it.
view full
screen
View a picture, or play a video, in full
screen mode. Tap
Menu
>
Full Screen
.
use your
phone as a
torch
Turn on your phone’s flashlight and
find your way in the dark. Tap
Start
>
Programs
>
FlashLight
.
access
voicemail
Tap
Start
>
Phone
, then tap and hold
1
.
play music or
games on an
airplane
To keep using your games and music
on a flight, turn off your network and
Bluetooth® services. Tap
Start
>
Settings
>
Connections
tab >
Wireless Manager
>
All
.
To... Do this...
26
personalize
personalize
go on, add your personal touch
Today screen
Find it:
Start
>
Settings
>
Today
To change the theme and background picture
that is used
on the Today screen, tap the
Appearance
tab.
To change the list of items shown on the Today screen, tap
the
Items
tab.
profiles & sounds
For incoming calls and other events, use
Profiles
to set ring
styles and volume settings. Use
Sounds
to change the
sounds played (such as ringtones).
To select a profile:
Find it:
Start
>
Settings
>
System
tab >
Profiles
You can select and edit
Normal
,
Meeting
,
Outdoors
and
Personal
profiles.
To select sound & notification settings:
Find it:
Start
>
Settings
>
Phone
time & date
Find it:
Start
>
Settings
>
System
tab >
Clock & Alarms
You can specify the date and time style by changing the
regional settings. Tap
Start
>
Settings
>
System
tab >
Regional
Settings
.
screen settings
Find it:
Start
>
Settings
>
System
tab >
Screen
Change the orientation of the screen, align the screen or
toggle the screen text size.
task manager
See what programs are active on your phone.
Find it:
Start
>
Settings
>
System
tab >
Task Manager
To stop a program running
, select a program and
tap
End Task
.
To stop all programs
, tap
Menu
>
End All Tasks
.
27
photos
more personalize features photos
see it, capture it, send it!
take a photo
Tap
Start
>
Programs
>
Camera
, or press the camera key (see
page 4) to see the camera viewfinder.
To f o c u s
the picture, hold the camera key
halfway in
until
the autofocus box turns green.
features
set backlight timeout
Set the backlight timeout to save battery life:
Start
>
Settings
>
System
tab >
Backlight
>
Battery Power
tab
set battery timeout
Set the battery timeout to save battery life:
Start
>
Settings
>
System
tab >
Power
>
Advanced
tab
1228
Mode
Indicator
Memory
(Phone or
Storage Card)
Photos
Remaining
Tap to open Pictures & Videos Tap to open Camera Settings
Flash
White
Balance
Dimensions
28
photos
To t a k e
the picture, press the camera key
all the way in
.
After you’ve taken a photo, it shows on the screen.
Tap
Z
to return to the camera viewfinder. Tap
W
to delete
the photo. Tap
X
to edit the photo in
Pictures & Videos
. Tap
D
to share the photo with friends.
photo options
In the camera viewfinder, tap
8
to open the camera
menu. Use the menu bar to change
Capture Settings, Capture Mode,
Brightness, Flash, White Balance, Effect
and
Resoltuion
.
Select
Capture Mode
to use the following features:
manage your photos
Find it:
Start
>
Programs
>
Pictures & Videos
Tap the photo thumbnail to open it. Tap
Send
to send the
photo in a multimedia message. Tap
Menu
to save, zoom, set
as your Today screen background, send (beam) using
Bluetooth
®
, edit and more.
Tip:
To view pictures located in a folder other than the
default pictures folder, including a storage card, tap
Start
>
Pictures & Videos
, then tap
Menu
>
Go To
>
Folders
, and select the
folder that contains stored pictures.
edit your photos
Find it:
Start
>
Programs
>
Pictures & Videos
1
Tap the photo thumbnail to open it.
2
Tap
Menu
>
Edit
.
3
From the edit screen, tap
Rotate
to rotate, or tap
Menu
to
crop or auto correct.
4
Tap
Menu
>
Save As
to save your edited photo.
options
Timer
Open photo mode, and set a 10-second
timer.
Burst
Take multiple photos with a single key tap.
Frame
Select a frame for your photo.
Video
Switch to video mode.
MMS Video
Switch to video mode and make a video to
send in a multimedia message.
29
videos
videos
for those moments when you really had to be there
record a video
Tap
Start
>
Programs
>
Camera
>
8
>
Video
>
OK
to see the
videocamera viewfinder. Press
s
, or the camera key, to
start and stop recording.
Once you’ve taken your video, tap
3
to watch it on the
screen. Tap
W
to delete the video. Tap
Z
to return to the
videocamera viewfinder. Tap
D
to share the video with
friends.
video options
In the camera viewfinder, tap
8
to open the videocamera
menu. Use the menu bar to change
Capture Settings, Capture Mode,
Brightness, Resoltuion
and more.
play a video
Find it:
Start
>
Programs
>
Pictures & Videos
>
My Pictures
>
My Documents
>
My Videos
The video plays using
Windows Media Player
.
00:42:20
Mode
Indicator
Memory
(Phone or
Storage Card)
Time
Remaining
Tap to open Pictures & Videos Tap to open Videocamera Settings
Flash
White
Balance
Video
Dimensions
00:00 70%
Now Playing
Windows Media
Menu
30
set up music
Tip:
To play a video in full screen mode, tap
Menu
>
Full Screen
.
Videos recorded in low resolution may not play in full
screen mode.
If you receive a call while watching a video, the video
pauses and a call alert appears. You can choose to answer
the call or ignore it. To continue watching the video, tap
Play
.
manage your videos
Find it:
Start
>
Programs
>
Pictures & Videos
>
My Pictures
>
My Documents
>
My Videos
Tap
Play
to view a highlighted video. Tap
Menu
to send, edit,
delete and more.
Tip:
To view videos located in a folder other than the
default videos folder (including a storage card) tap
Start
>
Programs
>
Pictures & Videos
, then tap
Menu
>
Go To
>
Folders
and
select the folder that contains stored videos.
set up music
what you need to start...
what music transfer tools do I need?
To put music on your computer and then load it on your
phone, you need:
•
A Microsoft™ Windows™ PC
•
A USB data cable (may be sold separately)
do I need a storage card?
Your phone does have at least 30 MB of internal memory,
but it also supports removable microSD storage cards with
up to 32 GB capacity, allowing you to store much more.
Tip:
To see the available memory on your phone and
storage card, tap
Start
>
Settings
>
System
tab >
Memory
.
what music file formats can I play?
Your phone can play many types of files: MP3, MIDI, AAC,
WAV, WMA, WAX and WMV.
what headphones can I use?
Your phone has a 3.5mm headset jack for wired stereo
listening. Or, go wireless and use optional Bluetooth stereo
headphones to listen to your music.
31
get music
get music
rip and transfer...
rip a CD
Not literally. If you’re new to music, this means transferring
music from a music CD to your PC.
To rip a music CD on your PC, you can use Windows™
Media Player version 10 or later. You can download
Windows Media Player from
www.microsoft.com
.
1
On your computer, launch Windows Media Player.
2
Insert a music CD into your computer’s CD ROM drive.
Note:
Make sure you change the format to MP3, MIDI,
AAC, WAV, WMA, WAX or WMV in Rip Settings. (MP3
is the recommended format for best performance.)
3
In the Windows Media Player window, click on the
“Rip” tab.
4
Highlight the tracks you want to import and click “Rip
Music“.
The songs are imported to the Windows Media Player
Library. Next, transfer the songs from your computer to
your phone.
transfer music
Transfer music files from a computer to your phone or
storage card.
1
With a storage card inserted, and your phone in the
Today screen, insert the USB cable in your phone and
your Windows PC.
Note:
Your phone supports Microsoft™ Windows™ XP
and Windows Vista™. Other operating systems may
not be compatible.
2
Now that you’ve connected, use
Windows Media
Player
or
USB drag and drop
to copy your music.
Windows Media Player
1
On your Windows PC, open Microsoft Windows Media
Player 10 or later.
2
On the “Sync” tab, select “More Options”. Under
Device, select your phone.
3
Select “Properties”, check the “Create folder hierarchy
on device” box, and click “OK”.
4
Drag your music files over to the “Sync List” and press
“Start Sync”.
32
play music & media
USB drag & drop
1
Use the “My Computer” window to find “Removable
Device”.
2
Drag and drop your music to your phone folder. To help
manage your music, you can create more folders in
your phone folder.
3
When you’re done, use the “Safely Remove
Hardware” feature to finish.
play music & media
all your entertainment in one place
You can play audio and video files that are on your phone or
on the Web.
Your phone has Windows™ Media Player Mobile for
Smartphone version 10.2 or later, which can play these
types of files: Windows Media Audio (WMA), Windows
Media Video (WMV), MP3, AAC, and WAV.
Find it:
Start
>
Windows Media
media player controls
controls
play/pause
Tap
ó
or
î
.
previous/next
Tap
í
or
ì
.
volume
Press the side volume keys, or tap
ê
or
ë
.
Tip:
To turn the sound off quickly, tap
Á
. Tap
Â
to turn the sound
back on.
33
play music & media
To play audio or video files:
1
From the media player, tap
Menu
>
Library
.
2
Select
My Music
,
My Videos
,
My TV
,
My Playlists
, or
Now Playing
.
Tip:
Do you want to play a song or video on the Internet or
network? From the
Library
view, tap
Menu
>
Open URL
.
wake up media player
While the media player is active, your phone conserves
power by turning off the display and keypad backlights.
To turn the display and backlights back on, tap the display.
turn off media player
Find it:
Menu
>
Stop
media player tips
If you receive a call while using the media player, the media
player pauses. To ignore the call, tap
Ignore
, or tap
Answer
to
answer it. The media player resumes when you end the
call.
To hide your media player while a song is playing, close the
media player window. If the media player is hidden, you can
use other phone features.
To view the details, tap
Menu
>
Properties
.
streaming player
Find it:
Start
>
Programs
>
Streaming Player
Use the streaming player to play internet videos. Simply tap
Open
, enter the URL and tap
Connect
.
fast forward/
rewind
Tap
ì
or
í
.
controls
34
navigation
navigation
make sure you’re on the right track
Find it:
Start
>
Settings
>
System
tab >
External GPS
External GPS is a mobile personal navigation system
on your phone. It needs to be connected to an
external GPS application, such as Google Maps or
Destinator, to help you plan your route and provide
interactive guidance to your destination.
•
To select the port that programs will use to obtain GPS
data, tap the
Programs
tab.
•
To specify the hardware port that your GPS device is
connected to, tap the
Hardware
tab.
•
To allow multiple programs to obtain GPS data
simultaneously, tap the
Access
tab then check the
Manage
GPS automatically (recommended)
box.
GPSXtra
Find it:
Start
>
Programs
>
GPSXtra
To download GPS data that will enhance your GPS
performance, tap
Download Now
.
web browser
you don’t need a PC, surf the web with your phone
Find it:
Start
>
Programs
>
Internet Explorer
Note:
Not all Web file formats are supported.
•
To go to a Web page, enter the address and tap
ä
.
•
To go to a link in a Web page, tap the link.
•
To change connection options, tap
Start
>
Settings
>
Connections
tab >
Wireless Manager
>
Menu
>
Wi-Fi Settings
.
•
To add a Favorite, open the Web page and tap
Menu
>
Add to Favorites
.
Zoom Out
file://\windows\default.htm
History
Menu
hInternet Explorer Mobile
Microsoft®
Favorites
ä
>> >>
>
35
web browser
Note:
If you’re not set up for internet access, contact your
service provider for settings.
third-party applications
Third-party applications, or add-on programs, can include
e-mail, security, mobile office, and productivity software.
These products can typically be downloaded and installed
immediately. Compatible commercial and free applications
are available on the Internet.
Warning:
Downloading and installing numerous third-party
applications can negatively affect memory usage and the
performance of the phone. Proceed with moderation.
Note:
Applications written for previously released devices
or older versions of Windows Mobile may not function
reliably on this phone. Contact the application provider to
check compatibility before installing the application on this
phone.
Tip:
To maximize the performance of your phone, install the
third-party applications on your storage card (see page 9).
Internet Sharing
You can use your phone to dial in to a network. To do this,
you need a Bluetooth wireless or USB cable connection.
Find it:
Start
>
Programs
>
Internet Sharing
On your computer, you must have ActiveSync 4.5 or later or
Windows Mobile Device Center on Windows Vista™, and
have enabled a Personal Area Network (PAN) server.
Note:
When you activate Internet Sharing, your phone’s
e-mail, Web browsing, Microsoft™ ActiveSync or
Windows™ Mobile Device Center, and text messaging
services are suspended until you deactivate
Internet Sharing.
Internet Sharing with Bluetooth wireless
To use Bluetooth wireless to link to a network:
Note:
You must have a computer that has
Bluetooth capabilities for Internet Sharing to work with
Bluetooth wireless.
1 On your phone
, tap
Start
>
Settings
>
Connections
tab >
Wireless Manager
>
Bluetooth On
.
2 On your computer
, launch the Bluetooth devices
applet from the task bar.
3
On your computer, right-click the Bluetooth icon in the
Windows task bar and select “Quick Connect” >
“Dial-up Networking” > “Find Devices”. The computer
36
web browser
finds your phone and shows the dial up networking
window.
Note:
Not all computers have the same procedure to
locate the Bluetooth window. Please refer to your
computer’s help system for more information.
4 On your phone
, tap
Start
>
Programs
>
Internet Sharing
.
5
Set
PC Connection
to
Bluetooth PAN
and set
Network Connection
to
Personal Network.
6
Tap
Connect
. The
Status
changes to
Connected
.
7
Tap
Menu
>
Bluetooth Settings
. When you see the name of
your computer in the list of personal networks, select
it and tap
Add
to make a connection.
Internet Sharing with a cable
Note: Do not connect
your data cable to your phone and
computer until the following steps tell you to do so.
On your phone:
Enable Internet Sharing on your phone and install phone
drivers:
1
On your phone, tap
Start
>
Settings
>
Connections
tab
>
Connections
to set up the proxy information as specified
by your service provider. These settings are the same
as for connecting to the Internet.
2
Using the USB data cable, connect the phone to your
computer.
The driver is installed on your computer and ready for
setting up a network connection.
3 On your phone
, tap
Start
>
Programs
>
Internet Sharing
.
4
Set
PC Connection
to
USB
and tap
Connect
. The
Status
changes
to
Connected
.
On your computer:
After you set up your computer and phone, you can make a
new network connection on your computer:
Note:
This procedure might not work on all computers.
Please refer to your computer’s help system for more
information.
5
Right-click on “My Computer” and select “Properties”
> “Hardware” tab.
6
Press the “Device Manager” button and expand the
“Modems” list.
7
Right-click “Smartphone Wireless USB Modem” and
select “Properties”.
8
Select the “Advanced” tab, and enter extra
initialization commands required by your service
provider. For details, contact your service provider.
37
web browser
9
Open the “Network Connections” window. On some
computers, you select “Start” > “Control Panel”
> “Network and Internet Connections” > “Network
Connections”. Your computer might be a little different.
10
In the “Network Connections” window, select “Create
a new connection” under “Network Tasks”.
11
Follow the prompts to connect to the Internet using a
modem:
•
Network Connection Type:
Connect to the Internet
•
Getting Ready:
Set up My Connection Manually
•
Internet Connection:
Connect using a dial-up modem
•
Connection Name: Enter a unique identifier for ISP
name.
•
Number to Dial:
*99#
•
Connection Availability:
Anyone's Use
•
User Name: available from your service provider.
•
Password: available from your service provider.
•
If you do not plan to use your phone as the default
Internet connection,
do not
check
Make this the default
Internet connection
.
•
If a firewall is not enabled,
do not
check
Turn on
Internet connection firewall for this connection
.
Note:
You might need to deactivate your computer
proxy server settings to let Internet Sharing access the
Internet. To do this, tap
Start
>
Settings
>
Connections
tab
>
Connections
>
Set Up My Proxy Server
, then deselect
This network
uses a proxy server to connect to the Intenret
.
disconnect Internet Sharing
On your computer
:
1
Go to task bar and right-click on the Network
Connection icon.
2
Select “Disconnect”.
Note:
You may need to reactivate your computer’s proxy
settings. Check with your Internet provider.
38
Google
Google
just Google it
Find it:
Start
>
Programs
>
Google
Use the Google feature to do an online search,
quickly access your Gmail account, or upload your
videos to YouTube.
•
To do an online Google search, tap
Search
.
Enter your search and tap ‘Search’.
•
To access your Gmail account, tap
Gmail
.
Enter your login details and tap ‘Sign in’.
Tip:
Tap ‘Remember me’ to skip the login process the
next time you access your Gmail account.
•
To access YouTube, tap
YouTube
.
Tap ‘Sign in’ to login.
Bluetooth® wireless
lose the wires and go wireless
Your phone supports Bluetooth wireless connections. You
can connect your phone with a Bluetooth audio device,
such as a handsfree headset or music system. You can also
connect your phone with a phone or computer that
supports Bluetooth connections to share files.
Note:
Using a mobile phone while driving may cause
distraction. End a call if you can’t concentrate on driving.
Also, using a mobile or accessory may be prohibited or
restricted in certain places. Always obey the laws and
regulations on the use of these products.
For maximum Bluetooth security
, you should always
connect Bluetooth devices in a safe, private environment.
turn Bluetooth power on or off
If Bluetooth
Power
is
On
, your phone can automatically pair
with the Bluetooth device you have used before. Just turn
on the Bluetooth device or move it near your phone.
Find it:
Start
>
Settings
>
Connections
tab >
Wireless Manager
>
Bluetooth
On
or
Off
.
The Bluetooth indicator
O
appears in the Today screen.
39
Bluetooth® wireless
Note:
To extend battery life, set Bluetooth
Power
to
Off
when
not in use. Your phone will not pair with devices until you
set Bluetooth
Power
back to
On
and pair your phone with the
Bluetooth device again.
pair with a headset or handsfree device
Before you try to pair your phone with a headset or
handsfree device
, make sure your phone’s Bluetooth
power is
on
and the Bluetooth device is
on
and
ready
in
pairing or bonding mode (see the user’s guide for the
device). You can pair your phone with multiple other
devices, but only use it with one headset at a time.
Your phone lists the Bluetooth devices it finds within range.
Note:
Your phone's Bluetooth features and Bluetooth Class
1 power levels are not allowed for outdoor operation in
France. To avoid unlawful interference with radio signals, do
not use the Bluetooth features in France unless you are
indoors.
1
Tap
Start
>
Settings
>
Connections
tab >
Bluetooth
>
Devices
tab
>
Add New Device
.
2
Select the Bluetooth device from the list and tap
Next
.
3
If prompted, enter the Bluetooth device passkey (such
as 0000 or 1234), and tap the
Accept
key.
When the Bluetooth devices are paired, an icon appears at
the top of the Today screen, in the Bluetooth Task Tray.
send (beam) objects to another device
You can use Bluetooth pairing to beam e-mail,
contacts, tasks, calendar events, audio, ringtones,
pictures, video, and voice notes from your phone to
a computer or other Bluetooth device.
Simply select the object then tap
Menu
>
Beam
> device
name >
ok
.
Note:
Ensure that the destination device is paired (see
page 39) and that its Bluetooth power is on.
advanced Bluetooth features
features
make phone visible to other Bluetooth device
Allow a Bluetooth device to discover your phone:
Start
>
Settings
>
Connections
tab >
Bluetooth
>
Mode
tab
>
Make this device visible to other devices
connect to recognized device
Start
>
Settings
>
Connections
tab >
Bluetooth
>
Devices
tab
>device name
40
cable connections
cable connections
your computer wants a friend
Your phone has a micro USB port (see page 4) so you can
connect it to a computer to transfer data.
You can use data cables and supporting software on your
computer to:
•
Transfer files between your phone’s storage card and
the computer (see page 40).
•
Synchronize phonebook and agenda information
between your phone and a computer or hand-held
device (see page 42).
After you connect a cable, tell your phone the type of USB
connection by tapping
Start
>
Settings
>
Connections
tab >
USB to PC
.
Note:
Motorola Original USB data cables and
supporting software may be sold separately.
Check your computer or hand-held device to
determine the type of cable you need.
connect your storage card to a PC
Note:
Storage cards are optional. To insert a storage
card, see page 6.
drop pairing with device
Start
>
Settings
>
Connections
tab >
Bluetooth
>
Devices
tab
then tap and hold device name >
Delete
receive all incoming beams
Start
>
Settings
>
Connections
tab >
Beam
>
Receive all
incoming beams
edit device properties / change device name
Start
>
Settings
>
Connections
tab >
Bluetooth
>
Devices
tab
then tap and hold device name >
Edit
features
41
cable connections
You can use a cable connection to access your phone’s
storage card with a computer. When your phone is
connected to a computer, you can only access the storage
card through the computer.
Note:
When your phone is plugged into a computer and is
being used for mass storage, it cannot be used for anything
else, including making emergency calls. To restore the
phone to normal use, disconnect it from the PC.
Note:
The unauthorized copying of copyrighted materials is
contrary to the provisions of the Copyright Laws of the
United States and other countries. This device is intended
solely for copying non-copyrighted materials, materials in
which you own the copyright, or materials which you are
authorized or legally permitted to copy. If you are uncertain
about your right to copy any material, please contact your
legal advisor.
on your phone:
1 Connect the cable
to your phone and to an available
USB port on your computer.
2
Tap
Start
>
Settings
>
Connections
tab >
USB to PC
>
USB Mass
Storage Mode
This directs the USB connection to your storage card.
on your computer:
1
Open your “My Computer” window, where your
phone’s storage card appears as a “Removable Disk”
icon.
2
Click on the “Removable Disk” icon to access the files
on your phone’s storage card.
3
Drag and drop files into these folders on the storage
card (you might need to create folders on your storage
card):
music:
media files \ audio \ music
ringtones:
media files \ audio \ ringtones
pictures:
media files \ image
videos:
media files \ video
Note:
Do not use capital letters in folder names. You
can also use the Multimedia Services plug-ins supplied
on the CD to work with Windows™ Media Player to
transfer files.
4
When you finish, disconnect your phone by selecting
the “Safely Remove Hardware” icon in the system tray
at the bottom of your computer screen. Then
disconnect the “USB Mass Storage Device.”
5
Disconnect the cable from your phone and computer.
42
synchronize
synchronize
connect and synchronize
You can synchronize the information on your phone in two
ways, either directly with a computer or over the air (OTA).
sync with a computer
You can use Microsoft™
ActiveSync version 4.5 or later
,
or Windows™
Mobile Device Center
to synchronize
information between your phone and computer.
install ActiveSync
To synchronize information on your phone with a PC, you
need to use Windows Mobile Device Center (on a PC
running Windows Vista) or install Microsoft ActiveSync (on
a PC running Windows XP™ or earlier).
Note:
Synchronization software is included on the
Getting Started CD packed with your phone. Before
installing the software, verify that your computer and
operating system meet the
minimum requirements
stated on the CD-ROM or Microsoft Windows™ Mobile
Web site (
www.microsoft.com/windowsmobile
). This Web site also
lets you download the
latest software
for ActiveSync.
1
Install Microsoft ActiveSync (for Windows XP or
earlier) or Windows Mobile Device Center (for
Windows Vista) on your PC.
2
After setup completes, connect your phone to the PC.
The device drivers install on your computer and then
the Sync Setup Wizard automatically starts.
3
Follow the instructions on the screen to complete the
wizard.
The wizard prompts you for the Exchange Server’s
name, your user name, your password, and the
domain name. If you don’t have this information,
contact the server’s system administrator.
When you finish the wizard, ActiveSync starts to
synchronize automatically with your phone.
Note:
When synchronization completes, you can
disconnect your phone from your PC, and you may need to
restart your PC.
sync with a cable connection
Once Microsoft ActiveSync or Windows Mobile Device
Center is installed on your PC, you can connect it to your
phone and sync.
1
Turn on your phone.
43
synchronize
2
Connect your phone to your PC using a USB
cable.
Note:
For more detailed information, see “Connecting a
mobile device to a PC” in ActiveSync Help on your PC, the
Microsoft Web Site for ActiveSync or the Motorola support
Web site at
www.motorola.com/consumer/support
.
sync with a Bluetooth® connection
Once Microsoft ActiveSync or Windows Mobile Device
Center is installed on your PC, you can connect it to your
phone and sync with a Bluetooth connection.
Note:
In order to use this feature, your PC needs Bluetooth
wireless or a Bluetooth PC adaptor accessory.
1
Follow the instructions in ActiveSync Help for
configuring Bluetooth connections on your PC to
support ActiveSync.
2
Turn on the device.
3
On your phone, verify that Bluetooth wireless is turned
on (tap
Start
>
Settings
>
Connections
tab >
Wireless Manager
>
Bluetooth On
).
4
Tap
Start
>
Settings
>
Connections
tab >
USB to PC
.
5
Check
ActiveSync Mode
, then tap
ok
.
6
Tap
Menu
>
Connect via Bluetooth
. Ensure that your phone and
PC are within close range. If this is the first time you
have connected to this PC using Bluetooth wireless,
you need to complete the Bluetooth wizard on your
phone and set up a Bluetooth partnership with the PC
before synchronizing.
7
Tap
Sync
.
8
When finished, tap
Menu
>
Disconnect Bluetooth
. To conserve
battery power on your phone, turn off Bluetooth power
(see page 38).
sync over the air
To sync your phone over the air (OTA) you need to sync it
directly with your company’s Microsoft® Information
Server or Microsoft® Exchange Server (running the
appropriate version software). For more information about
this set-up, see the Motorola support Web site at:
www.motorola.com/myMotoSurf
Microsoft
™
Windows
™
Mobile and ActiveSync
Support:
www.microsoft.com/windowsmobile
.
You can also contact your system administrator to set up
this synchronization.
44
Wi-Fi
Wi-Fi
home, office, or hotspot
Connect your phone with Wi-Fi to exchange files, connect
with a printer, or to the Internet.
Note:
Wi-Fi features are not allowed for outdoor operation
in France. To avoid unlawful interference with radio signals,
do not use Wi-Fi features in France unless you are indoors.
turn Wi-Fi on
To turn on your phone’s Wi-Fi feature, tap
Start
>
Settings
>
Connections
tab >
Wireless Manager
>
Wi-Fi On
.
Note:
To extend battery life set
Wi-Fi Power
to
Off
when not in
use.
Wi-Fi search & connect
Find it:
Start
>
Settings
>
Connections
tab >
Wireless Manager
>
Wi-Fi
>
Menu
>
Wi-Fi Settings
Note:
Make sure the Wi-Fi network is secure.
1
Scroll to a network in the list and tap
Connect
.
2
Enter the connection settings and tap
Finish
.
Note:
Your phone will automatically connect to the network
using GPRS after losing a Wi-Fi connection.
tools
stay on top of things with these handy features
add calendar event
Find it:
Start
>
Calendar
>
Menu
>
New Appointment
Note:
To schedule an all-day event, select
Yes
under
All Day
.
set alarm
You can set three alarms on your phone:
Find it:
Start
>
Settings
>
System
tab >
Clock & Alarms
>
Alarms
tab
calculator
Find it:
Start
>
Programs
>
Calculator
documents to go
Find it:
Start
>
Programs
>
Documents To Go
View, edit or create documents, spreadsheets or
slideshows on your phone.
tasks
Find it:
Start
>
Programs
>
Tasks
45
security
security
help keep your phone safe
lock & unlock phone
To prevent accidental use of your phone
, use the
lock/unlock feature. Your current status is shown by the lock
indicator at the bottom of the Today screen (see page 10) .
Tap the indicator to toggle.
To keep others from using your phone
, you can set a
password and lock your phone:
1
From the Today screen, tap
Start
>
Settings
>
Lock
.
Tip:
If you want your phone to lock automatically when
you’re not using it, check the
Prompt if device unused for
checkbox, and choose the lock delay.
2
Choose a password that is either simple (4-digit
number) or strong alphanumeric (a hard-to-guess
password with at least 7 characters, including
uppercase and lowercase letters, numerals, and
punctuation).
Tip: Choose a PIN you will remember
. Without your
PIN, you can reset your phone, but you will lose your
personalized settings and all content stored in device
memory.
3
Enter and confirm your PIN.
Tip:
To enter a password hint, tap
Hint
tab.
4
Tap
ok
.
Note:
A locked phone still rings or vibrates for incoming
calls or messages,
and you do not need to unlock it to
answer
.
master clear
Caution:
Master clear erases all information you have
entered (including contacts and calendar events) and
content you have downloaded (including photos and
sounds) stored in your phone’s memory. It is
recommended that you synchronize this content with your
computer (see page 42) before attempting a master clear.
Find it:
Start
>
Programs
>
Master Clear
45
a
management
stay in control
file explorer
Find it:
Start
>
Programs
>
File Explorer
You can use File Explorer to sort, view, copy, and move
files, such as text, pictures, music, and video files, on your
phone or storage card.
wireless manager
Find it:
Start
>
Settings
>
Connections
tab >
Wireless Manager
View and edit your
Wi-Fi
,
Bluetooth
or
Phone
settings.
removing programs
To completely remove a program from your phone, from
the Today screen, tap
Start
>
Settings
>
System
tab >
Remove
Programs
. Select the program and tap
Remove
.
Windows update
Find it:
Start
>
Settings
>
System
tab >
Windows Update
Run the Windows update wizard to keep your phone
protected and up-to-date.
network
features
network settings
Start
>
Settings
>
Connections
tab >
Connections
Select a policy to open a connection, or enter a new
policy definition.
To close the secure connection, tap
Logoff
.
network wizard
Start
>
Settings
>
Connections
tab >
Network Wizard
Use the network wizard to enter all your network
settings.
46
service & repairs
Specific Absorption Rate Data
SAR Data
This model wireless phone meets the
government’s requirements for exposure to radio
waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission (FCC) of the U.S. Government and by the Canadian
regulatory authorities. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the
general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure
the safety of all persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit
of measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC and by the Canadian regulatory
authorities is 1.6 W/kg.
1
Tests for SAR are conducted using
standard operating positions accepted by the FCC and by Industry
Canada with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate
at multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a wireless
base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S.
and Canada, it must be tested and certified to the FCC and Industry
Canada that it does not exceed the limit established by each
government for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body)
reported to the FCC and available for review by Industry Canada.
The highest SAR value for this model phone when tested for use at
the ear is 0.799 W/kg, and when worn on the body, as described in
this user guide, is 1.02 W/kg. (Body-worn measurements differ
among phone models, depending upon available accessories and
regulatory requirements).
2
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the governmental
requirements for safe exposure. Please note that improvements to
this product model could cause differences in the SAR value for
later products; in all cases, products are designed to be within the
guidelines.
47
legal & safety
legal & safety
battery use & safety
IMPORTANT: HANDLE AND STORE BATTERIES PROPERLY TO AVOID INJURY
OR DAMAGE.
Most battery issues arise from improper handling of batteries, and
particularly from the continued use of damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or otherwise attempt to change
the form of your battery.
• Don’t let the phone or battery come in contact with water.
Water can get into
the phone’s circuits, leading to corrosion. If the phone and/or battery get wet, have
them checked by your carrier or contact Motorola, even if they appear to be working
properly.
• Don’t allow the battery to touch metal objects.
If metal objects, such as
jewelry, stay in prolonged contact with the battery contact points, the battery could
become very hot.
• Don’t place your battery near a heat source.
Excessive heat can damage the
phone or the battery. High temperatures can cause the battery to swell, leak, or
malfunction. Therefore:
•
Do
not
dry a wet or damp battery with an appliance or heat source, such as a hair
dryer or microwave oven.
•
Avoid leaving your phone in your car in high temperatures.
DOs
• Do avoid dropping the battery or phone.
Dropping these items, especially on a
hard surface, can potentially cause damage.
• Do contact your service provider or Motorola if your phone or battery has
been damaged from dropping or high temperatures.
IMPORTANT: USE MOTOROLA ORIGINAL PRODUCTS FOR QUALITY
ASSURANCE AND SAFEGUARDS.
To aid consumers in identifying authentic
Motorola batteries from non-original or counterfeit batteries (that may not have
adequate safety protection), Motorola provides holograms on its batteries. Consumers
should confirm that any battery they purchase has a “Motorola Original” hologram.
Motorola recommends you always use Motorola-branded batteries and
chargers.
Motorola mobile devices are designed to work with Motorola batteries. If
you see a message on your display such as
Invalid Battery
or
Unable to Charge
, take the
following steps:
•
Remove the battery and inspect it to confirm that it has a “Motorola Original”
hologram;
•
If there is no hologram, the battery is not a Motorola battery;
•
If there is a hologram, replace the battery and retry charging it;
•
If the message remains, contact a Motorola Authorized Service Center.
Important:
Motorola’s warranty does not cover damage to the phone caused by
non-Motorola batteries and/or chargers.
Warning:
Use of a non-Motorola battery or charger may present a risk of fire,
explosion, leakage, or other hazard.
PROPER AND SAFE BATTERY DISPOSAL AND RECYCLING
Proper battery disposal is not only important for safety, it benefits the environment.
Consumers may recycle their used batteries in many retail or service provider locations.
Additional information on proper disposal and recycling may be found on the Web:
•
www.motorola.com/recycling
•
www.rbrc.org/call2recycle/
(in English only)
Disposal:
Promptly dispose of used batteries in accordance with local
regulations. Contact your local recycling center or national recycling
organizations for more information on how to dispose of batteries.
Warning:
Never dispose of batteries in a fire because they may explode.
battery charging
Notes for charging your phone’s battery:
48
legal & safety
•
When charging your battery, keep it near room temperature. Never expose batteries
to temperatures below 0°C (32°F) or above 45°C (113°F) when charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time may take more time to charge.
•
Motorola batteries and charging systems have circuitry that protects the battery
from damage from overcharging.
service & repairs
If you have questions or need assistance, we're here to help.
Go to
www.motorola.com/support
, where you can select from a number of customer
care options. You can also contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456 (TTY/TDD United States for hearing
impaired), or 1-800-461-4575 (Canada).
The World Health Organization has stated that present scientific information does not
indicate the need for any special precautions for the use of mobile devices. They note
that if you want to reduce your exposure then you can do so by limiting the length of
calls or using a “hands-free” device to keep the mobile phone away from the head and
body.
Additional Information can be found on the websites of the World Health Organization
(
http://www.who.int/emf
) or Motorola, Inc. (
http://www.motorola.com/rfhealth
).
1. The tests are carried out in accordance with international guidelines for testing. The limit
incorporates a substantial margin for safety to give additional protection for the public and
to account for any variations in measurements. Additional related information includes the
Motorola testing protocol, assessment procedure, and measurement uncertainty range for
this product.
2. Please see the Safety and General Information section about body worn operation.
European Union Directives
Conformance Statement
EU Conformanc e
[France Only]
49
legal & safety
Hereby, Motorola declares that this product is in compliance with:
•
The essential requirements and other relevant provisions of Directive 1999/5/EC
•
All other relevant EU Directives
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to
R&TTE Directive) at
www.motorola.com/rtte
. To find your DoC, enter the Product
Approval Number from your product’s label in the “Search” bar on the Web site.
Safety and General
Information
Safety I nformation
This section contains important information on the safe and efficient
operation of your mobile device. Read this information before using your
mobile device.
Exposure to Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives and
transmits RF energy. When you communicate with your mobile device, the system
handling your call controls the power level at which your mobile device transmits.
Your Motorola mobile device is designed to comply with local regulatory requirements
in your country concerning exposure of human beings to RF energy.
Operational Precautions
For optimal mobile device performance, and to be sure that human exposure to RF
energy does not exceed the guidelines set forth in the relevant standards, always
follow these instructions and precautions.
Product Operation
When placing or receiving a phone call, hold your mobile device just like you would a
landline phone.
If you wear the mobile device on your body, always place the mobile device in a
Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do not
use a body-worn accessory supplied or approved by Motorola—or if you hang your
mobile device from a lanyard around your neck—keep the mobile device and its
antenna at least 2.5 centimeters (1 inch) from your body when transmitting.
Using accessories not supplied or approved by Motorola may cause your mobile device
to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved
accessories, visit our Web site at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external
sources if inadequately shielded, designed, or otherwise configured for RF energy
compatibility. In some circumstances your mobile device may cause interference with
other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to do so.
In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If
your mobile device offers an airplane mode or similar feature, consult airline staff about
using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or defibrillator, consult
your physician before using this mobile device.
0168
Product
Approval
Number
50
legal & safety
Persons with implantable medical devices should observe the following precautions:
•
ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the
implantable medical device when the mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to minimize the potential for
interference.
•
Turn OFF the mobile device immediately if you have any reason to suspect that
interference is taking place.
Read and follow the directions from the manufacturer of your implantable medical
device. If you have any questions about using your mobile device with your implantable
medical device, consult your healthcare provider.
Driving Precautions
The use of wireless phones while driving may cause distraction. Discontinue a call if
you can’t concentrate on driving.
Additionally, the use of wireless devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and regulations on the use of these
products.
Responsible driving practices can be found in the “Smart Practices While Driving”
section in this guide (or separate guide).
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always, posted and can
include fueling areas, such as below decks on boats, fuel or chemical transfer or
storage facilities, or areas where the air contains chemicals or particles, such as grain
dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not remove, install, or
charge batteries. In such areas, sparks can occur and cause an explosion or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as follows:
Batteries & Chargers
Caution: Improper treatment or use of batteries may present a danger of fire,
explosion, leakage, or other hazard. For more information, see the “battery use
& safety” section.
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a fire.
Your battery or mobile device may require recycling in accordance
with local laws. Contact your local regulatory authorities for more
information.
Do not throw your battery or mobile device in the trash.
Do not let your battery, charger, or mobile device get wet.
Listening at full volume to music or voice through a headset may
damage your hearing.
032374o
032376o
032375o
51
legal & safety
Keep Your Mobile Device and Its Accessories
Away From Small Children
These products are not toys and may be hazardous to children. For example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could break if the
product is dropped on a hard surface or receives a substantial impact. If glass breaks,
do not touch or attempt to remove. Stop using your mobile device until the glass is
replaced by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when exposed to
flashing lights, such as when playing video games. These may occur even if a person
has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult with your physician before playing video games or enabling
a flashing-lights feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following symptoms occur:
convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or
disorientation. It is always a good idea to hold the screen away from your eyes, leave
the lights on in the room, take a 15-minute break every hour, and stop use if you are
tired.
Caution About High Volume Usage
Warning:
Exposure to loud noise from any source for extended periods
of time may affect your hearing. The louder the volume sound level, the
less time is required before your hearing could be affected. To protect
your hearing:
•
Limit the amount of time you use headsets or headphones at high volume.
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness in
your ears, ringing in your ears, or muffled speech, you should stop listening to the
device through your headset or headphones and have your hearing checked.
For more information about hearing, see our Web site at
www.motorola.com/hearingsafety
(in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering finger-written
characters, you may experience occasional discomfort in your hands, arms, shoulders,
neck, or other parts of your body. If you continue to have discomfort during or after such
use, stop use and see a physician.
[Mar0108]
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind
Don’t expose your phone to water, rain, extreme humidity, sweat,
or other moisture. If it does get wet, don’t try to accelerate drying
with the use of an oven or dryer, as this may damage the phone.
extreme heat or cold
Avoid temperatures below 0°C/32°F or above 45°C/113°F.
microwaves
Don’t try to dry your phone in a microwave oven.
52
legal & safety
Industry Canada Notice to
Users
Indust ry Canada Not ice
Operation is subject to the following two conditions: (1) This device may not cause
interference and (2) This device must accept any interference, including interference
that may cause undesired operation of the device. See RSS-GEN 7.1.5.
FCC Notice to Users
FCC Notice
The following statement applies to all products that have received FCC
approval. Applicable products bear the FCC logo, and/or an FCC ID in the
format FCC-ID:XXX-XXXXX on the product label.
Motorola has not approved any changes or modifications to this device by the user. Any
changes or modifications could void the user’s authority to operate the equipment. See
47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation. See 47 CFR Sec. 15.19(3).
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Motorola Limited Warranty for
the United States and Canada
Warr ant y
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its telephones,
pagers, messaging devices, and consumer and professional two-way radios (excluding
commercial, government or industrial radios) that operate via Family Radio Service or
General Mobile Radio Service, Motorola-branded or certified accessories sold for use
with these Products (“Accessories”) and Motorola software contained on CD-ROMs or
other tangible media and sold for use with these Products (“Software”) to be free from
defects in materials and workmanship under normal consumer usage for the period(s)
outlined below. This limited warranty is a consumer's exclusive remedy, and applies as
follows to new Motorola Products, Accessories and Software purchased by consumers
in the United States or Canada, which are accompanied by this written warranty:
dust and dirt
Don’t expose your phone to dust, dirt, sand, food, or other
inappropriate materials.
cleaning solutions
To clean your phone, use only a dry soft cloth. Don’t use alcohol or
other cleaning solutions.
the ground
Don’t drop your phone.
53
legal & safety
Products and Accessories
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and replacement of parts due to
normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80% of their rated
capacity and batteries that leak are covered by this limited warranty.
Abuse & Misuse.
Defects or damage that result from: (a) improper operation, storage,
misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.)
to the surface of the product resulting from misuse; (b) contact with liquid, water, rain,
extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food;
(c) use of the Products or Accessories for commercial purposes or subjecting the
Product or Accessory to abnormal usage or conditions; or (d) other acts which are not
the fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories.
Defects or damage that result
from the use of non-Motorola branded or certified Products, Accessories, Software or
other peripheral equipment are excluded from coverage.
Unauthorized Service or Modification.
Defects or damages resulting from service,
testing, adjustment, installation, maintenance, alteration, or modification in any way by
someone other than Motorola, or its authorized service centers, are excluded from
coverage.
Altered Products.
Products or Accessories with (a) serial numbers or date tags that
have been removed, altered or obliterated; (b) broken seals or that show evidence of
tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola
housings, or parts, are excluded from coverage.
Communication Services.
Defects, damages, or the failure of Products, Accessories
or Software due to any communication service or signal you may subscribe to or use
with the Products Accessories or Software is excluded from coverage.
Software
Exclusions
Software Embodied in Physical Media.
No warranty is made that the software will
meet your requirements or will work in combination with any hardware or software
applications provided by third parties, that the operation of the software products will
be uninterrupted or error free, or that all defects in the software products will be
corrected.
Products Covered Length of Coverage
Products and Accessories
as
defined above, unless otherwise
provided for below.
One (1) year
from the date of purchase by
the first consumer purchaser of the product
unless otherwise provided for below.
Decorative Accessories and
Cases.
Decorative covers, bezels,
PhoneWrap™ covers and cases.
Limited lifetime warranty
for the lifetime
of ownership by the first consumer purchaser
of the product.
Monaural Headsets.
Ear buds
and boom headsets that transmit
mono sound through a wired
connection.
Limited lifetime warranty
for the lifetime
of ownership by the first consumer purchaser
of the product.
Consumer and Professional
Two-Way Radio Accessories.
Ninety (90) days
from the date of purchase
by the first consumer purchaser of the
product.
Products and Accessories that
are Repaired or Replaced.
The balance of the original warranty or
for ninety (90) days
from the date returned
to the consumer, whichever is longer.
Products Covered Length of Coverage
Software.
Applies only to physical defects in
the media that embodies the copy of the
software (e.g. CD-ROM, or floppy disk).
Ninety (90) days
from the date
of purchase.
54
legal & safety
Software NOT Embodied in Physical Media.
Software that is not embodied in
physical media (e.g. software that is downloaded from the internet), is provided “as is”
and without warranty.
Who Is Covered?
This warranty extends only to the first consumer purchaser, and is not transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the purchase price of
any Products, Accessories or Software that does not conform to this warranty. We may
use functionally equivalent reconditioned/refurbished/pre-owned or new Products,
Accessories or parts. No data, software or applications added to your Product,
Accessory or Software, including but not limited to personal contacts, games and ringer
tones, will be reinstalled. To avoid losing such data, software and applications please
create a back up prior to requesting service.
How to Obtain Warranty Service or Other
Information
You will receive instructions on how to ship the Products, Accessories or Software, at
your expense, to a Motorola Authorized Repair Center. To obtain service, you must
include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase;
(b) a written description of the problem; (c) the name of your service provider, if
applicable; (d) the name and location of the installation facility (if applicable) and, most
importantly; (e) your address and telephone number.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE
REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED
WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL
MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE)
FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY
OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS,
LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER
FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR
INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL
EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or exclusion of
incidental or consequential damages, or limitation on the length of an implied
warranty, so the above limitations or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights
that vary from state to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola certain exclusive
rights for copyrighted Motorola software such as the exclusive rights to reproduce and
distribute copies of the Motorola software. Motorola software may only be copied into,
used in, and redistributed with, the Products associated with such Motorola software.
No other use, including without limitation disassembly of such Motorola software or
exercise of the exclusive rights reserved for Motorola, is permitted.
USA Phones:
1-800-331-6456
Pagers:
1-800-548-9954
Two-Way Radios and Messaging Devices:
1-800-353-2729
Canada All Products:
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone number designated
above for the product with which they are used.
55
legal & safety
Hearing Aid Compatibility with
Mobile Phones
Heari ng Aids
Some Motorola phones are measured for compatibility with hearing aids. If the box for
your particular model has “Rated for Hearing Aids” printed on it, the following
explanation applies.
When some mobile phones are used near some hearing devices (hearing aids and
cochlear implants), users may detect a buzzing, humming, or whining noise. Some
hearing devices are more immune than others to this interference noise, and phones
also vary in the amount of interference they generate.
The wireless telephone industry has developed ratings for some of their mobile phones,
to assist hearing device users in finding phones that may be compatible with their
hearing devices. Not all phones have been rated. Phones that are rated have the rating
on their box or a label on the box.
The ratings are not guarantees. Results will vary depending on the user’s hearing device
and hearing loss. If your hearing device happens to be vulnerable to interference, you
may not be able to use a rated phone successfully. Trying out the phone with your
hearing device is the best way to evaluate it for your personal needs.
M-Ratings:
Phones rated M3 or M4 meet FCC requirements and are likely to generate
less interference to hearing devices than phones that are not labeled. M4 is the
better/higher of the two ratings.
T-Ratings:
Phones rated T3 or T4 meet FCC requirements and are likely to be more
usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated
phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices
have telecoils in them.)
Hearing devices may also be measured for immunity to this type of interference. Your
hearing device manufacturer or hearing health professional may help you find results
for your hearing device. The more immune your hearing aid is, the less likely you are to
experience interference noise from mobile phones.
Information from the World
Health Organization
WHO Informat ion
Present scientific information does not indicate the need for any special precautions for
the use of mobile phones. If you are concerned, you may want to limit your own or your
children’s RF exposure by limiting the length of calls or by using handsfree devices to
keep mobile phones away from your head and body.
Source: WHO Fact Sheet 193
Further information:
http://www.who.int./peh-emf
Product Registration
Registration
Online Product Registration:
www.motorola.com/us/productregistration
Product registration is an important step toward enjoying your new Motorola product.
Registering permits us to contact you for product or software updates and allows you to
subscribe to updates on new products or special promotions. Registration is not
required for warranty coverage.
Please retain your original dated sales receipt for your records. For warranty service of
your Motorola Personal Communications Product you will need to provide a copy of your
dated sales receipt to confirm warranty status.
Thank you for choosing a Motorola product.
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United States of America
and Canada. The Governments of the United States of America and Canada may restrict
the exportation or re-exportation of this product to certain destinations. For further
information contact the U.S. Department of Commerce or the Canadian Department of
Foreign Affairs and International Trade.
56
legal & safety
Caring for the Environment by
Recycling
Recycling Information
This symbol on a Motorola product means the product should not be disposed
of with household waste.
Disposal of your Mobile Device and
Accessories
Please do not dispose of mobile devices or electrical accessories (such as chargers,
headsets, or batteries) with your household waste. These items should be disposed of
in accordance with the national collection and recycling schemes operated by your local
or regional authority. Alternatively, you may return unwanted mobile devices and
electrical accessories to any Motorola Approved Service Center in your region. Details
of Motorola approved national recycling schemes, and further information on Motorola
recycling activities can be found at:
www.motorola.com/recycling
Disposal of your Mobile Device Packaging and
User’s Guide
Product packaging and user’s guides should only be disposed of in accordance with
national collection and recycling requirements. Please contact your regional authorities
for more details.
California Perchlorate Label
Perchlorat e Label
Some mobile phones use an internal, permanent backup battery on the printed circuit
board that may contain very small amounts of perchlorate. In such cases, California law
requires the following label:
“Perchlorate Material – special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
.”
There is no special handling required by consumers.
Privacy and Data Security
Privacy and Data Security
Motorola understands that privacy and data security are important to everyone.
Because some features of your mobile device may affect your privacy or data security,
please follow these recommendations to enhance protection of your information:
• Monitor access
—Keep your mobile device with you and do not leave it where
others may have unmonitored access. Lock your device’s keypad where this feature
is available.
• Keep software up to date
—If Motorola or a software/application vendor releases
a patch or software fix for your mobile device that updates the device’s security,
install it as soon as possible.
• Erase before recycling
—Delete personal information or data from your mobile
device prior to disposing of it or turning it in for recycling. For step-by-step
instructions on how to delete all personal information from your device, see the
section entitled “master clear” or “delete data” in the user’s guide.
Note:
For information on backing up your mobile device data before erasing it, go to
www.motorola.com
and navigate to the “downloads” section of the consumer
Web page for “Motorola Backup” or “Motorola Phone Tools.”
• Understanding AGPS
—To provide location information for emergency calls,
certain Motorola mobile devices incorporate Assisted Global Positioning System
(AGPS) technology. AGPS technology also can be used in non-emergency
applications to track and monitor a user’s location—for example, to provide driving
directions. Users who prefer not to permit such tracking and monitoring should avoid
using such applications.
If you have further questions regarding how the use of your mobile device may impact
your privacy or data security, please contact Motorola at
privacy@motorola.com
, or
contact your service provider.
Microsoft End User License
Agreement
Microsoft License
You have acquired a device (“DEVICE”) that includes software licensed by Motorola,
Inc. (“Motorola”) from Microsoft Licensing Inc. or its affiliates (“Microsoft”), for use in
57
legal & safety
connection with wireless network services provided under separate agreement
between you and a wireless telecommunications provider (“Mobile Operator”). Those
installed software products of Microsoft origin, as well as associated media, printed
materials, and “online” or electronic documentation (“SOFTWARE”) are protected by
international intellectual property laws and treaties. SOFTWARE includes software
already installed on the DEVICE (“DEVICE Software”) and Microsoft software contained
on any CD-ROM disk accompanying the DEVICE (“Desktop Software”).
The SOFTWARE is licensed, not sold. All rights reserved.
IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT (“EULA”), DO NOT
USE THE DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLY CONTACT
MOTOROLA FOR INSTRUCTIONS ON RETURN OF THE UNUSED DEVICE(S) FOR A
REFUND. ANY USE OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON THE
DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICATION OF
ANY PREVIOUS CONSENT).
1. GRANT OF SOFTWARE LICENSE. This EULA grants you the following license:
1.1. DEVICE Software. You may use the DEVICE Software as installed on the DEVICE
(including as installed on removable media installed in the DEVICE). All or certain
portions of the DEVICE Software may be inoperable if a proper account is not
established or maintained with an appropriate Mobile Operator, or if the Mobile
Operator’s network facilities are not operating or configured to operate with the DEVICE
software.
1.2. Desktop Software. Desktop Software is included with your DEVICE, and you may
install and use the Microsoft ActiveSync® 3.7.1 component on one (1) or more
computers to exchange information with one (1) or more computing devices that contain
a compatible version of the Microsoft Windows® for Smartphone 2003 Software. For
other software component(s) contained in the Desktop Software, you may install and
use such components only in accordance with the terms of the printed or online end
user license agreement(s) provided with such component(s). In the absence of an end
user license agreement for particular component(s) of the Desktop Software, you may
install and use only one (1) copy of such component(s) on the DEVICE or a single
computer with which you use the DEVICE.
1.3. Back-up Copy. If Motorola has not included a back-up copy of the DEVICE Software
with the DEVICE, you may make a single back-up copy of the DEVICE Software. You may
use the back-up copy solely for archival purposes.
1.4. Microsoft Windows® 2003. If Microsoft Outlook® 2002 is included with your
Device, the following terms apply to your use of Microsoft Outlook® 2002: (i)
regardless of the information contained in “Software Installation and Use” section of
the online EULA you may install one (1) copy of Microsoft Outlook® 2002 on one (1)
computer to use, exchange data, share data, access and interact with the DEVICE, and
(ii) the EULA for Microsoft Outlook® 2002 is between Motorola and the end user - not
between the PC manufacturer and end user.
2. Speech/Handwriting Recognition. If the Software includes speech and or
handwriting recognition component(s), you should understand that speech and
handwriting recognition are inherently statistical processes; that recognition errors are
inherent in the processes; that it is your responsibility to provide for handling such
errors and to monitor the recognition processes and correct any errors. Neither
Motorola nor its suppliers shall be liable for any damages arising out of errors in the
speech and handwriting recognition processes.
3. Limitations on Reverse Engineering, Decompilation and Disassembly. You may not
reverse engineer, decompile, or disassemble the SOFTWARE, except and only to the
extent that such activity is expressly permitted by applicable law notwithstanding this
limitation.
4. Single DEVICE. The Device Software is licensed with the DEVICE as a single
integrated product. The DEVICE Software may only be used as part of the DEVICE,
notwithstanding any installation of the DEVICE Software on removable media.
5. Single EULA. The package for the DEVICE may contain multiple versions of this EULA,
such as multiple translations and/or multiple media versions (e.g., in the user
documentation and in the software). Even if you receive multiple versions of the EULA,
you are licensed to use only one (1) copy of the DEVICE Software.
6. Rental. You may not rent or lease the SOFTWARE.
7. Software Transfer. You may not permanently transfer any of your rights under this
EULA with regard to the DEVICE Software or Desktop Software, except as permitted by
the applicable Mobile Operator. In the event that the Mobile Operator permits such
58
legal & safety
transfer, you may permanently transfer all of your rights under this EULA only as part of
a sale or transfer of the DEVICE, provided you retain no copies, you transfer all of the
SOFTWARE (including all component parts, the media and printed materials, any
upgrades or backup copies, this EULA and, if applicable, the Certificate(s) of
Authenticity), and the recipient agrees to the terms of this EULA. If the Software is an
upgrade, any transfer must include all prior versions of the SOFTWARE.
8. Termination. Without prejudice to any other rights, Motorola or Microsoft may
terminate this EULA if you fail to comply with the terms and conditions of this EULA. In
such event, you must destroy all copies of the SOFTWARE and all of its component
parts.
9. Security Updates. The SOFTWARE may include digital rights management
technology. If SOFTWARE does contain digital rights management technology, content
providers are using the digital rights management technology (“Microsoft DRM”)
contained in the SOFTWARE to protect the integrity of their content (“Secure Content”)
so that their intellectual property, including copyright, in such content is not
misappropriated. Owners of such Secure Content (“Secure Content Owners”) may, from
time to time, request Microsoft, Microsoft Corporation or their subsidiaries to provide
security related updates to the Microsoft DRM components of the SOFTWARE
(“Security Updates”) that may affect your ability to copy, display and/or play Secure
Content through Microsoft software or third party applications that utilize Microsoft
DRM. You therefore agree that, if you elect to download a license from the Internet
which enables your use of Secure Content, Microsoft Corporation or their subsidiaries
may, in conjunction with such license, also download onto your DEVICE such Security
Updates that a Secure Content Owner has requested that Microsoft, Microsoft
Corporation or their subsidiaries distribute. Microsoft, Microsoft Corporation or their
subsidiaries will not retrieve any personally identifiable information, or any other
information, from your DEVICE by downloading such Security Updates.
10. Consent to Use of Data. You agree that Microsoft, Microsoft Corporation and their
affiliates may collect and use technical information gathered in any manner as part of
product support services related to the SOFTWARE. Microsoft, Microsoft Corporation
and their affiliates may use this information solely to improve their products or to
provide customized services or technologies to you. Microsoft, Microsoft Corporation
and their affiliates may disclose this information to others, but not in a form that
personally identifies you.
11. Internet Gaming/Update Features. If the SOFTWARE provides, and you choose to
utilize, the Internet gaming or update features within the SOFTWARE, it is necessary to
use certain computer system, hardware, and software information to implement the
features. By using these features, you explicitly authorize Microsoft, Microsoft
Corporation and/or their designated agent to use this information solely to improve
their products or to provide customized services or technologies to you. Microsoft or
Microsoft Corporation may disclose this information to others, but not in a form that
personally identifies you.
12. Internet-Based Services Components. The SOFTWARE may contain components that
enable and facilitate the use of certain Internet-based services. You acknowledge and
agree that Microsoft Corporation or their affiliates may automatically check the version
of the SOFTWARE and/or its components that you are utilizing and my provide upgrades
or supplements to the SOFTWARE that may be automatically downloaded to your
Device.
13. Links to Third Party Sites. The SOFTWARE may provide you with the ability to link to
third party sites through the use of the SOFTWARE. The third party sites are NOT under
the control of Motorola, Microsoft, Microsoft Corporation or their affiliates. Neither
Motorola, Microsoft nor Microsoft Corporation nor their affiliates are responsible for (i)
the contents of any third party sites, any links contained in third sites, or any changes or
updates to third party sites, or (ii) webcasting or any other form of transmission
received from any third party sites. If the SOFTWARE provides links to third party sites,
those links are provided to you only as a convenience, and the inclusion of any link does
not imply an endorsement of the third party site by Motorola, Microsoft, Microsoft
Corporation or their affiliates.
14. Additional Software/Services. The SOFTWARE may permit Motorola, Microsoft,
Microsoft Corporation or their affiliates to provide or make available to you SOFTWARE
updates, supplements, add-on components, or Internet-based services components of
the SOFTWARE after the date you obtain your initial copy of the SOFTWARE
(“Supplemental Components”).
59
legal & safety
14.1. If Motorola provides or makes available to you Supplemental Components and no
other EULA terms are provided along with the Supplemental Components, then the
terms of this EULA shall apply.
14.2.If Microsoft, Microsoft Corporation or their affiliates make available Supplemental
Components, and no other EULA terms are provided, then the terms of this EULA shall
apply, except that the Microsoft, Microsoft Corporation or affiliate entity providing the
Supplemental Component(s) shall be the licensor of the Supplemental Component(s).
14.3. Motorola, Microsoft, Microsoft Corporation and their affiliates reserve the right to
discontinue any Internet-based services provided to you or made available to you
through the use of the SOFTWARE.
15. UPGRADES AND RECOVERY MEDIA.
15.1. DEVICE Software. If the DEVICE Software is provided by Motorola separate from
the DEVICE on media such as a ROM chip, CD ROM disk(s) or via web download or other
means, and is labeled “For Upgrade Purposes Only” or “For Recovery Purposes Only”,
you may install one copy of such DEVICE Software on the DEVICE as a replacement
copy for the existing DEVICE Software and use it in accordance with the Grant of
Software License section of this EULA.
15.2. Desktop Software. If any Desktop Software component(s) is provided by Motorola
separate from the DEVICE on CD ROM disk(s) or via web download or other means, and
labeled “For Upgrade Purposes Only” or “For Recovery Purposes Only”, you may (i)
install and use one copy of such component(s) on the computer(s) you use to exchange
data with the DEVICE as a replacement copy for the existing Desktop Software
component(s).
16. COPYRIGHT. All title and intellectual property rights in and to the SOFTWARE
(including but not limited to any images, photographs, animations, video, audio, music,
text and “applets”, incorporated into the SOFTWARE), the accompanying printed
materials, and any copies of the SOFTWARE, are owned by Microsoft or its suppliers
(including Microsoft Corporation). You may not copy the printed materials
accompanying the SOFTWARE. All title and intellectual property rights in and to the
content which may be accessed through use of the SOFTWARE is the property of the
respective content owner and may be protected by applicable copyright or other
intellectual property laws and treaties. This EULA grants you no rights to use such
content. All rights not specifically granted under this EULA are reserved by Microsoft
and its suppliers (including Microsoft Corporation).
17. EXPORT RESTRICTIONS. You acknowledge that SOFTWARE is subject to U.S. export
jurisdiction. You agree to comply with all applicable international and national laws
that apply to the SOFTWARE, including the U.S. Export Administration Regulations, as
well as end-user, end-use and destination restrictions issued by U.S. and other
governments. For additional information, see
http://www.microsoft.com/exporting/
.
18. PRODUCT SUPPORT. Product support for the SOFTWARE is NOT provided by
Microsoft, its parent corporation, Microsoft Corporation, or their affiliates or
subsidiaries.
19. NO LIABILITY FOR CERTAIN DAMAGES. EXCEPT AS PROHIBITED BY LAW,
MICROSOFT SHALL HAVE NO LIABILTIY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL
OR INCIDENTAL DAMAGES ARISING FROM OR IN CONNECTION WITH THE USE OR
PERFORMANCE OF THE SOFTWARE. THIS LIMITATION SHALL APPLY EVEN IF ANY
REMEDY FAILS OF ITS ESSENTIAL PURPOSE.
20. FOR APPLICABLE LIMITED WARRANTIES AND SPECIAL PROVISIONS PERTAINING
TO YOUR PARTICULAR JURISDICTION, PLEASE REFER TO YOUR WARRANTY BOOKLET
INCLUDED WITH THIS PACKAGE OR PROVIDED WITH THE SOFTWARE PRINTED
MATERIALS.
Smart Practices While Driving
Driving Safety
Drive Safe, Call Smart
Check the laws and regulations on the use of mobile devices and their
accessories in the areas where you drive. Always obey them. The use of these
devices may be prohibited or restricted in certain areas—for example,
handsfree use only. Go to
www.motorola.com/callsmart
(in English only) for
more information.
Your mobile device lets you communicate by voice and data—almost anywhere,
anytime, wherever wireless service is available and safe conditions allow. When
driving a car, driving is your first responsibility. If you choose to use your mobile device
while driving, remember the following tips:
60
• Get to know your Motorola mobile device and
its features such as speed dial and redial.
If
available, these features help you to place your call
without taking your attention off the road.
• When available, use a
handsfree device.
If possible, add
an additional layer of convenience
to your mobile device with one of
the many Motorola Original
handsfree accessories available today.
• Position your mobile device within easy reach.
Be able to access your mobile device without
removing your eyes from the road. If you receive an
incoming call at an inconvenient time, if possible, let
your voicemail answer it for you.
• Let the person you are speaking with know you
are driving; if necessary, suspend the call in
heavy traffic or hazardous weather conditions.
Rain, sleet, snow, ice, and even heavy traffic can be
hazardous.
• Do not take notes or look up phone numbers
while driving.
Jotting down a “to do” list or going
through your address book takes attention away
from your primary responsibility—driving safely.
• Dial sensibly and assess the traffic; if possible,
place calls when your car is not moving or
before pulling into traffic.
If you must make a call
while moving, dial only a few numbers, check the
road and your mirrors, then continue.
• Do not engage in stressful or emotional
conversations that may be distracting.
Make
people you are talking with aware you are driving
and suspend conversations that can divert your
attention away from the road.
• Use your mobile device to call for help.
Dial 911
or other local emergency number in the case of fire,
traffic accident, or medical emergencies.*
• Use your mobile device to help others in
emergencies.
If you see an auto accident, crime in
progress, or other serious emergency where lives are
in danger, call 911 or other local emergency number,
as you would want others to do for you.*
• Call roadside assistance or a special
non-emergency wireless assistance number
when necessary.
If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears injured,
or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless
number.*
* Wherever wireless phone service is available.
61
index
index
A
alarm 44
alert
set 26
B
background 26
battery life, extend 39, 47
Bluetooth connection 38
C
cable connection 40
cables 40
calculator 44
calendar event
add 44
call
emergency 15
ending 12
forward 14
international 14
recent 12
call times 15
callcosts 15
conference calls 13
contacts 14
copy files 39
customize 26
D
date 26
dialed calls 12
documents to go 44
E
e-mail 19
end a call 12
exchange server 19
F
file manager 46
forward message 21
G
getting started 9
GPS 34, 38
I
in-call menu 13
instant messaging 23
internet 34
internet sharing 35
J
jog ball 8
M
media
play 32
messages
replying 21
voicemail 24
modem 35
multimedia message 21
music
download 31
play 32
set up 30
62
index
N
navigation (GPS) 34, 38
network settings 46
networking 35
number redial 12
O
object exchange 39
over the air (OTA) 43
P
pause button 32
personalize 27
photos 27
play
music, video clips 32
profile 26
programs
remove 46
R
received calls 12
recent calls 12
record a video 29
redial 12
reply 21
restrict calls 15
return a call 12
ring style, setting 26
S
search 44
send and receive messages 18
shortcuts 25
speed dial 14
standby mode 25
status indicators 11
storage card 9
synchronize 42
T
task manager 26
tasks 44
text entry 23
text input settings 24
text message 20, 21
third party applications 34, 35
three way calling 13
time, setting 26
tips & tricks 25
Today screen 10, 26
U
unlock phone 45
USB cables 40
V
video
record 29
video recorder 29
voicemail 24
W
wallpaper 26
web browser 34
Wi-Fi 44
Windows update 46
wireless 38
wireless manager 46
WLAN 43
U.S. patent Re.34,976
63
legal & safety
Copyright
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Note:
Do not ship your phone to the above address. If you need to return your phone for
repairs, replacement, or warranty service, please contact the Motorola Customer
Support Center at:
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the capabilities and settings of your
service provider’s network. Additionally, certain features may not be activated by your
service provider, and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature availability and
functionality. All features, functionality, and other product specifications, as well as the
information contained in this user's guide are based upon the latest available
information and are believed to be accurate at the time of printing. Motorola reserves
the right to change or modify any information or specifications without notice or
obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark
Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola,
Inc. under license. Java and all other Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc. in the U.S. and other countries. Microsoft,
Windows and Windows Me are registered trademarks of Microsoft Corporation; and
Windows XP is a trademark of Microsoft Corporation. All other product or service
names are the property of their respective owners. is a Certification Mark of the
Wireless Fidelity Alliance, Inc
.
© 2008 Motorola, Inc. All rights reserved.
Caution:
Changes or modifications made in the radio phone, not expressly approved by
Motorola, will void the user’s authority to operate the equipment.
Software Copyright Notice
The Motorola products described in this manual may include copyrighted Motorola and
third-party software stored in semiconductor memories or other media. Laws in the
United States and other countries preserve for Motorola and third-party software
providers certain exclusive rights for copyrighted software, such as the exclusive rights
to distribute or reproduce the copyrighted software. Accordingly, any copyrighted
software contained in the Motorola products may not be modified, reverse-engineered,
distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the
purchase of the Motorola products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license under the copyrights, patents, or patent
applications of Motorola or any third-party software provider, except for the normal,
non-exclusive, royalty-free license to use that arises by operation of law in the sale of a
product.
Manual Number: 68XXXXX348-A
64
legal & safety

Navigation menu
