MOTOROLA TETRA SURVEILLANCE PORTFOLIO
Motorola Discreet TCR1000 Covert Radio
Providing effective solutions for the surveillance operation is not just a matter of a
hiding TETRA radios, it requires a thought-through end-to-end system which will
ensure the effectiveness of the operation and the safety of the officers.
By designing communications with the end user in mind, Motorola sets the standard for highly
secure radio communications systems demanded by Government agencies around the world.
Technology That’s Second NatureTM means that surveillance officers can focus on the Mission, not
on the technology.
With the recent introduction of the ultra-thin, fully featured TETRA TCR1000 covert terminal,
Motorola further applies it’s extensive experience of TETRA terminal design to the covert operations
arena. The TCR1000 packs a fully featured Secure End to End TETRA terminal into a package
weighing less than 165gms and only 165 x 17 x 35mm. The TCR1000 offers a wide range of
accessories to customise the wearing solution.
MOTOROLA’S TOTAL
The TCR1000 covert radio has fast toggle between
TMO and DMO, an officer can immediately brake
out of a DMO call to make a TMO call. Tones and
Whisper mode enables officers to more safely
communicate in situations where they are exposed.
This innovative radio is not a solution on its own
and Motorola has worked to provide surveillance
solutions for foot and vehicle based users.
Surveillance requirements for different types of
vehicles are satisfied by the MTM800E. This has
a wide number of options for fitting including
dash, remote, motorcycle and desktop units.
Where gateways or repeaters are needed then the
CM5000 is available to meet these needs.
During potentially stressful or dangerous covert
surveillance operations the officers must have
absolute confidence in their communications
equipment. All Motorola terminals are designed
from first concept to meet Motorola’s Accelerated
Life Testing (ALT) which exceeds the exacting MIL
810C/D/E and ETS standards.
To ensure uncompromised secure communications
Motorola has developed End to End security
solutions which feature the highest level of
security deployed on TETRA networks. All
terminals support full End to End encryption
making use of Over the Air Rekeying (OTAR). This
ensures that the management of encryption keys
are taken out of the hands of the operators leaving
them to get on with their task.
The CM5000 Gateway function links a group of
officers in a local talk group (Direct Mode Operation)
with the command centre (using Trunked Mode
Operation), using the higher power available in a
vehicle radio. The repeater function improves the
links between radios in a DMO talk group. This
could be vital to improve connections to surveillance
officers in buildings or enclosed car parks.
E2EE
End to End Encription
MOTOROLA’S TOTAL
Providing effective solutions for the surveillance situation is not just a matter of a
hiding TETRA radios, it requires a thought-through end-to-end system which will
ensure the safety and effectiveness of the officers and the operation.
Networks
Motorola Dimetra IP and Dimetra Compact IP base station and switch
portfolio scale from small to national systems. Features have been added
over many years to ensure that the highest levels of functionality, security,
and capacity are available.
Command and Control
In the past covert teams have operated in an isolated communications
situation. This was limited by the range of the covert terminals. With the advent
of national TETRA systems communications can be seamless over the area of
coverage. This allows the management of covert teams to be centralised. To
this end Motorola has developed secure console solutions for its Dimetra IP
systems. This provides confidence that communications remain secure from
the operative on the ground to the manager in the command centre.
Terminal Management
Integrated Terminal Management is a powerful means to quickly configure
a set of radios with templates and other special features in readiness for a
surveillance operation.
Software Features
Dynamic control of talk groups (DENA) ensures that the senior officers can
react to a fast changing surveillance situation whilst maintaining maximum
operational effectiveness.
Officer safety is a paramount concern, the Ambience Listening feature
enables the command centre to open and then keep an audio link from the
radio open, even if it is then switched-off. This is a vital facility if the officer is
in a dangerous situation and is unable to respond to prompts or messages.
Collecting evidence for prosecution is aided by the Logging Recorder feature.
The system can log and record the calls made on the radio so the actual
conversation as well as the time and date information.
Many other features are supported which optimize the network for speed
and capacity, make the communication task easy and intuitive for the end
user, and provide advanced control functions such as location to optimise the
operation and maintain officer safety.
Command and Control
Location
Coordination
Dispatching
Operational Intelligence
Recording
SURVEILLANCE SOLUTION
Technology That’s Second Nature™
MCC 7500 Console
GPS location with MotoLocator
Key Features:
• Part of Motorola’s highly capable and industry
leading TETRA Radio portfolio
• Secure Communication for safety and
protection of information
• TMO TETRA Class 2 / 3 Air Interface Encryption
(SCK, CCK, DCK, GCK, and customer specic)
• End-End Encryption
• 1W, Class 4 Tx Power
• Whisper mode for discrete use
• Communication tones for speech-free operation
• Integrated GPS option that allows users to be
located in need of assistance
• Wide range of covert accessories to give
ofcers exibility in the way the radio can be
worn
• Connection to extension battery for increased
operational life
• Uses the same standard battery as cellular
handsets
• CPS-Lite facility for changing the talk groups
with a TETRA PDA
• Unique body worn double-loop antenna option
increases range
• Semi rigid antenna, adds exibility in terms of
how the radio can be worn
• Congurable alert tones keeps users informed
The need to conceal a TETRA radio under all
types of clothing has been the requirement of
Surveillance ofcers for some time. Motorola
listened carefully to these ofcers and used their
observations to:
• Design the world’s thinnest TETRA radio
• Design a simple and innovative user interface
• Accept no compromises in performance, full
power and up to 8 hour battery life (5/35/60)
• Design a very simple but powerful user
interface matched to surveillance operations
• Design an accessory portfolio to enhance
performance increase ease of use
The Discreet TCR1000 is the ideal solution to
ensure secure communications in surveillance
covert type operations allowing ofcers to blend
right into the crowd. Motorola’s TCR1000 Tetra
radio delivers high quality communication in a light
and discreet package for those critical undercover
applications.
There are no compromises in the design of the
TCR1000. Motorola worked closely with police
forces to ensure that it is intuitive and simple to
operate, truly Technology that’s Second Nature. The
Discreet TCR1000 incorporates control features
specically matched to the needs of ofcers in
Covert operations, and is engineered to be easily
hidden inside light clothing. Features available on
conventional Motorola radios such as Ambience
Listening are available on the Discreet TCR 1000. A
unique portfolio of Covert accessories complement
the Discreet TCR1000 and offer additional exible
options for undercover ofcers. This radio operates
at 1 Watt and the option for a body mounted antenna
ensures excellent coverage and maintains the
discreetness of the radio.
Discreet tetrA in
surveillAnce operAtions
tcr1000 covert rADio
Motorola’s TCR1000 Covert TETRA terminal
provides undercover officers with a communications
tool specially designed for their security, comfort
and intuitive use in all situations. Motorola also
offers a wide range of accessories to support other
portable solutions to meet the varying operational
needs of surveillance officers – flexible, rugged and
ready to go at a moments notice.
Body Worn Accessory Options: Designed to
ensure secure and discrete placement of your
radio. Vests and harnesses are made of lightweight
breathable fabrics and are available in different
sizes and colors to meet your specific covert
officer needs. Pockets are specifically sized to
securely store your radio, extended battery module
and microphones for enhanced communication
flexibility.
Audio Accessories: Wireless small and
comfortable earpieces of various colour skins
ensure discrete communications and comfort even
when wearing for extended periods. Inductive
patch and inductive loops provide flexible options
to the user for transmitting and receiving discrete
communications.
Antennas: A variety of antenna solutions are
available. They are optimized for on-body use to
ensure you get the coverage you need. Antennas
are either flexible or rigid. The most innovative dual-
loop antenna increases range and fits easily and
discreetly into the Covert vest.
Batteries and Charging Solutions: Undercover and
surveillance officers have unique needs which the
TCR1000 portfolio of battery and charging solutions
have been designed to meet Both the vehicular and
indoor battery charging solutions will be essential
for the user who relies on constant communication
while on the move. The additional extended battery
option ensures that officers can handle extra long
shifts and heavy communication needs.
CPS Lite software on the MTC100 TETRA PDA
allows in-field configuration of the TCR1000 and
modification of the Talkgroup Favourites list using a
simple user interface
Supporting Software
• CPS: Customer Programming SW
• CPS Lite: Talkgroup Management SW
TCR1000 DisCReeT ACCessoRies,
mATCheD To The suRveillAnCe
mission
actual size
Surveillance Accessories for Mobile portfolio MTM800 Enhanced
Motorola has a wide variety of solutions to conceal the radio in the vehicle or on the Motorcycle. The accessory portfolio offers a complimentary
solution range to keep the officer undercover. This means accessories such as covert antennas, microphones, push-to-talk devices,
loudspeakers, inductive loop system and control accessories are able to be installed quickly and discretely in as many positions as required.
In a vehicle, remote mount configurations allow you to store the base of the unit in the trunk and have the control head discretely mounted
in the radio dash. A visor microphone and a foot Push-to-talk can be discretely installed and give officers an easy and safe hands-free
communication solution.
Discrete options are available for motorcycle officers as well. Remote mounting kits allow the officer to store the base of the unit easily
in a secure trunk on the back of the motorcycle. Officers are equipped with discrete fist size microphones and can communicate easily
and securely.
Surveillance Accessories for the Portable portfolio MTH800 and MTP850
Along with the industry-leading TCR1000 covert solution, Motorola offers a suite of surveillance accessories to help conceal the Tetra
MTH800 or MTP850 portable. One, two or three-wire surveillance kits allow officers to transmit and receive communications securely and
discretely. A variety of wireless earpiece-neck loop combinations or wired discrete earpieces are designed to be comfortable even when
extended wear is required.
Motorola is a leader in innovation and provides a suite of accessories and complementary solutions that meet the demanding and variable
requirements of our surveillance audience. Whether in a vehicle or on a motorcycle, on foot as an undercover officer or simply need to
communicate in a discrete manner, Motorola provides the accessories to support you.
Motorola works closely with world leading partners such as Sonic to constantly expand the range of accessories.
Mobile Radio accessoRies
PoRtable Radio accessoRies
accessoRies, the Key to effective
suRveillance
Surveillance operations vary considerably and the equipment for communication must be flexible, rugged, and ready to go at a
moments notice. Officers already in the field may be called upon to participate at short notice in surveillance duties, whilst others
have time to prepare. Accessories which help to conceal conventional radios will help officers to join surveillance operations at
short notice. Vehicle mounting kits can be used in unmarked cars, vans or motorcycles. Motorola has a constantly expanding
range of accessories for use with both conventional radios such as the MTP850 handheld and the MTM800E mobile radios.
In addition the TCR1000 Discreet Covert radio has been introduced with a full range of antenna, power, and concealment
accessories to enhance its flexibility for surveillance operations.
Covert Antenna
Examples of surveillance accessories
GPS Antenna Visor Microphone
Examples of accessories
Remote PTT 5W Small Loudspeaker
As well as TETRA radios and infrastructure the
MOTOA4 portfolio includes associated technologies
that can be used for in secure communications.
These include taskworker devices, rugged
computers, high speed radio links, MESH networks,
and WiMax technology. Motorola is very well placed
to bring and integrated a wide range of technologies
to meet the needs of mission critical operators.
MOTOA4™ Mission Critical Communications Portfolio
For nearly 80 years, Motorola continues to be the recognized leader in
providing wireless communications networks, devices, applications and
services. We have installed more than 350 TETRA networks worldwide
and are responsible for over a quarter of the world’s TETRA systems.
Only Motorola enables its customers to confidently take the next step in
mission critical communications, beyond the basics, to the most reliable
and innovative wireless solutions available. Motorola is the trusted name in
mission critical networks.
To learn more about the MOTOA4 mission critical communications portfolio,
visit us at www.motorola.com/TETRA today and experience Technology
that’s Second Nature™.
Motorola Surveillance
SolutionS - tetra and
a lot More...
Point to Point Technology
MW810 (12” Screen)
MC75
MTS4 Tetra BTS
Mesh Technology
WiMax Technology
American International Radio Inc.
3601 E. Algonquin Rd.#800 Rolling Meadows,IL 60008
www.airadio.com +1 847 818 9999
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other
trademarks are the property of their respective owners. © 2011 Motorola Solutions, Inc. All rights reserved. TCR1000/BRO-ENG(03/09)
