NVS 300 | DATASHEET | DEC10
GET INCREDIBLE VIEWS
NVIDIA® NVS™ 300
The standard for multi-display business graphics
NVIDIA® NVS™ 300 is the chosen solution
across financial institutions, emergency call
centers, digital signage systems and other
mission critical environments.
Featuring a unified architecture designed
to dynamically allocate GPU resources,
NVS 300 delivers optimized performance
for business graphics. Supporting up to
two VGA, single link DVI, Display Port or
HDMI displays up to 2560x1600 resolutions,
NVS 300 lets you drive a wide range displays
from a single board. In addition, NVS 300
provides high quality HD video output and high
memory bandwidth for today’s demanding
digital signage installations.
With the included NVIDIA Mosaic™ Technology
and nView® Desktop Manager software,
NVS 300 delivers maximum flexibility for
single or multi-display options. Mosaic
Technology enables spanning of your entire
Windows desktop and taskbar over multiple
displays or a single ultra high resolution
display with a single or multiple NVS graphics
cards. nView’s productivity enhancing features
provide you with unprecedented control of
the desktop experience. Features include:
Gridlines that divide single or multiple
displays into smaller sub-displays, Virtual
Desktops that seamlessly reduce desktop
clutter and User Profiles that assist with
enterprise deployments.
NVIDIA NVS 300 business graphics solution
is engineered and built by NVIDIA to provide
a reliable platform and is thoroughly tested
for compatibility with leading business
applications to meet the needs of today’s
most demanding business users.
PRODUCT SPECIFICATIONS
FORM FACTOR
>Low Profile 2.7”(H) x 5.7” (L)
FRAME BUFFER MEMORY
>512 MB DDR3
MEMORY INTERFACE
>64-bit
MEMORY BANDWIDTH
>12.6 GB/s
MAX POWER CONSUMPTION
> 17.5W
GRAPHICS BUS
>PCI Express x16 or x1
DISPLAY CONNECTORS
>DMS-59
FLEXIBLE DISPLAY OPTIONS
>2 single link DVI-I or 2 VGA or
2 Display Port
THERMAL SOLUTION
>Fanless heatsink
The NVIDIA® NVS™ 300 high resolution, multi-display business graphics
solution, designed for small and standard form factor systems, delivers
reliable hardware and software for a stable business environment.
To learn more about NVIDIA NVS, visit www.nvidia.com/nvs
1Mosaic Technology is supported in Win 7 only.
© 2010 NVIDIA Corporation. All rights reserved. NVIDIA, the NVIDIA logo, NVS, nView, Mosaic, CUDA are trademarks and/or registered
trademarks of NVIDIA Corporation. All company and product names are trademarks or registered trademarks of the respective owners
with which they are associated. Features, pricing, availability, and specifications are all subject to change without notice.
NVIDIA® NVS™ 300
SUPPORTED PLATFORMS
>Microsoft Windows 7 (64-bit and 32-bit)
>Microsoft Windows Vista
(64-bit and 32-bit)
>Microsoft Windows XP
(64-bit and 32-bit)
>Microsoft Windows 2000 (32-bit)
>Linux®-x86 and Linux-x86_64
>Solaris®
>AMD64, Intel EM64T
>PCI Express 2.0 Support
NVIDIA NVS 300 ARCHITECTURE
>Integrated DisplayPort, VGA &
TMDS (DVI & HDMI) support
>PCI Express 2.0 support
>NVIDIA nView® Desktop
Manager Software support
>NVIDIA® CUDA™ technology capable
>NVIDIA® Mosaic™ technology
>128-bit color precision
>12 pixels per clock rendering engine
>3D volumetric texture support
>3rd-generation occlusion culling
>16 textures per pixel in
fragment programs
>Window ID clipping functionality
>Compliant with professional OpenGL®
and DirectX® applications
ADVANCED DISPLAY FEATURES
>Supports versatile DMS59 Connector
>Drives two SL-DVI-I, VGA or
DisplayPort via supported DMS59
based break out cable adaptors
>DisplayPort outputs drives two
digital displays at resolutions
up to 2560 x 1600 @ 60Hz
>Single-link DVI-I outputs drive
two digital displays at resolutions
up to 1920x1200 @ 60Hz
>Internal 400 MHz DAC drives two analog
displays up to 2048 x 1536 @ 85Hz
>DisplayPort 1.1a, HDMI
1.3a,and HDCP support
>HDMI support using optional
DP-HDMI or DVI-HDMI dongles
>Support for integrated audio
via Display Port & HDMI
>Support for multiple display
modes including DualView,
Span and Clone modes
TECHNICAL SPECIFICATIONS
Features Benefits
INTELLIGENT POWER MANAGEMENT NVIDIA Power Management technology reduces overall system energy costs. It
intelligently adapts the total power utilization of the graphics subsystem based
on the applications being run by the end user. This power optimized design helps
reduce Total Cost of Ownership (TCO) and increase reliability.
HIGH RESOLUTION DISPLAY SUPPORT Drives ultra high resolution panels using integrated display technologies, producing
phenomenal photorealistic image quality from a range of display connectors. Supports
two simultaneous displays, including single-link DVI, DisplayPort, VGA or HDMI.
NVIEW® ADVANCED DESKTOP SOFTWARE The nView® Advanced Desktop Software delivers maximum flexibility for single large
display or multi-display options, providing unprecedented end-user control of the
desktop experience for increased productivity.
MULTIDISPLAY EXPERIENCE WITH
NVIDIA MOSAIC™ TECHNOLOGY
Mosaic™ Technology enables seamless taskbar spanning as well as transparent
scaling of any application across up to 8 displays. Works over multiple displays or
one ultra-high resolution display using a single or multiple NVS graphics cards.1
LOWPROFILE & FLEXIBLE FORM FACTOR Simplifies IT administration and deployment throughout an enterprise. Regardless
of desktop system (standard tower PC. workstation, small form factor system) or
the display type (LCD, DLP, plasma) NVS 300 has the ability to fit into any existing
installations without being disruptive.
NVIDIA CUDA™CUDA’s parallel computing architecture enables dramatic increases in computing
performance by harnessing the power of the GPU (graphics processing unit).
NVS 300 contains 16 CUDA™ parallel computing cores compatible with all CUDA
accelerated applications.
