Bankline import

file layout guide –

Bankline (CSV) format

947559 1 11/08/2010 15:13

Generated at: Wed Aug 11 15:10:54 2010

Bankline import file layout guide – Bankline (CSV) format

Contents

1. Introduction to Bankline import...........................................................................................................................2

1.1 What is Bankline import? ..............................................................................................................................2

1.2 How do I structure a Bankline import file? .........................................................................................................2

1.3 Can I import more than one record in a single file? .............................................................................................2

2. Import data table – guidance notes .....................................................................................................................3

2.1 General.....................................................................................................................................................3

2.2 Notation....................................................................................................................................................3

2.3 Character sets ............................................................................................................................................4

2.4 Debit and charge account format....................................................................................................................4

2.5 Credit account format ..................................................................................................................................5

2.6 Codewords ................................................................................................................................................6

3. Import data table ............................................................................................................................................7

4. Examples.....................................................................................................................................................35

4.1 Introduction .............................................................................................................................................35

4.2 Standard domestic payment ........................................................................................................................36

4.3 Standard domestic payment template ............................................................................................................38

4.4 Standard domestic payment from a template ...................................................................................................40

4.5 International payment ................................................................................................................................42

4.6 Standard domestic bulk list ..........................................................................................................................44

4.7 Standard domestic bulk payment ..................................................................................................................48

4.8 Inter Account Transfer (IAT) bulk list ..............................................................................................................52

4.9 Bulk Inter Account Transfer (IAT)...................................................................................................................56

4.10 Ad hoc bulk payment .............................................................................................................................60

5. Glossary of terms ..........................................................................................................................................64

Bankline import file layout guide – Bankline (CSV) format

1. Introduction to Bankline import

1.1 What is Bankline import?

Bankline allows your business to manage everyday banking over the internet, including domestic and international payments.

Bankline import enables you to import your payment instructions from a file, rather than manually keying them. This can save you time

and effort by allowing you to upload payment files straight from your accounting software.

Bankline supports the import of:

• standard domestic payments (both one off and from an existing Bankline payment template)

• urgent domestic payments (both one off and from an existing Bankline payment template)

• international payments (both one off and from an existing Bankline payment template)

• sterling and currency Inter Account Transfers (both one off and from an existing Bankline payment template)

• templates for all of the above payment types

• standard domestic bulk payments (from an existing Bankline bulk list only)

• standard domestic bulk lists

• sterling bulk Inter Account Transfers (from an existing Bankline bulk list only)

• sterling Inter Account Transfer bulk lists

• ad hoc bulk payments (without an existing Bankline bulk list)

This user guide explains how to structure an import record for all of the supported payment types, as well as some pointers to help

you get the most out of Bankline import.

1.2 How do I structure a Bankline import file?

The records in an import file must be in a Comma Separated Value (CSV) text file format.

A preceding comma before the first field is not required to define the start of the import record, and a trailing comma is not required

after the final field to define the end of the import record.

Each record type has its own requirements on how it should be structured. These individual requirements are set out in the import

data table.

1.3 Can I import more than one record in a single file?

Multiple records can be imported in a single import file, although there are some restrictions on the possible combinations:

• templates cannot be mixed in a file with anything other than templates

• payments from a template must reference an existing Bankline template

• bulk lists cannot be mixed in a file with anything other than bulk lists

• bulk payments / IATs must reference an existing Bankline bulk list

• there can only be one bulk payment / bulk IAT in any one file (i.e. a single debit and one or more credits).

Some standard domestic payments can be processed as Faster Payments whereas all can be processed as Bacs payments.

Bankline import file layout guide – Bankline (CSV) format

2. Import data table – guidance notes

2.1 General

Unless specified, if a field is populated with a valid value it does not need to be padded to reach the full character length for the field.

Some fields in the import data table are shown as being not applicable for any of the import records. This is deliberate, with these

fields having been reserved for future use.

2.2 Notation

We’ve used the following notations throughout the import data tables.

Scenario Notation

When defining the size of a field • ‘a’ denotes that the field is alphabetic

• ‘n’ denotes that the field is numeric

• ‘x’ denotes that the field is alphanumeric

When defining the validity of a field • ‘M’ denotes that the field is mandatory

• ‘O’ denotes that the field is optional

• ‘C’ denotes that the field is conditional

When defining the payment type • ‘Std’ denotes a standard domestic payment

• ‘Urg’ denotes an urgent domestic (CHAPS) payment

• ‘IAT’ denotes an Inter Account Transfer

• ‘Intl’ denotes an international payment

• ‘DR’ denotes a bulk list debit

• ‘CR’ denotes a bulk list credit

Bankline import file layout guide – Bankline (CSV) format

2.3 Character sets

For standard domestic (including bulk list) and sterling Inter Account Transfer payment types, any free format fields are limited to the

following character set.

A B C D E F G H I J K L M N O P Q R S T U V W X Y Z

0 1 2 3 4 5 6 7 8 9 . - / &

For urgent domestic, currency Inter Account Transfer and international payment types, any free format fields are limited to the

following character set.

A B C D E F G H I J K L M N O P Q R S T U V W X Y Z

a b c d e f g h i j k l m n o p q r s t u v w x y z

0 1 2 3 4 5 6 7 8 9 . - / ? : ( ) , + ‘

The last character (blank box) in both character sets is a space.

2.4 Debit and charge account format

These account formatting rules apply to the debit account (as represented by the debit Account identifier in field T010) and the debit

charges account (as represented by the debit charges Account identifier in field T011).

Payment type Formatting rules

Standard Domestic payments

Urgent Domestic payments

Standard Domestic Bulk payments

Bulk Inter Account Transfers (IATs)

Ad hoc bulk payments

For these payment types, the debit account is always a UK Sterling account. The sort code and account

number should be populated in field T010 in the format ‘6n8n’ i.e. a six digit sort code followed by an eight digit

account number.

Inter Account Transfers For Sterling Inter Account Transfers the debit account is always a UK Sterling account. For such payments the

sort code and account number should be populated in field T010 in the format ‘6n8n’.

For currency Inter Account Transfers the debit account may be either a UK Sterling account or a RBSG currency

account.

• For a UK Sterling account the sort code and account number should be populated in field T010 in the

format ‘6n8n’.

• For a RBSG currency account the account number should be populated in field T010 in the format

‘8a3a3a’ i.e. an (up to) eight character customer key, followed by a three character currency key and

then a (up to) three character suffix.

International payments

For these payment types the debit account may either be a UK Sterling account or an RBSG currency account.

• For a UK Sterling account the sort code and account number should be populated in field T010 in the

format ‘6n8n’.

• For an RBSG currency account the account number should be populated in field T010 in the format

‘8a3a3a’.

Likewise the debit charges account may be either a UK Sterling account or an RBSG currency account, and field

T011 should be populated accordingly.

Bankline import file layout guide – Bankline (CSV) format

2.5 Credit account format

These account formatting rules apply to the credit account (as represented by a combination of the account with Bank identifier in

field T022 and the beneficiary account Number in field T028).

Payment type Formatting rules

Standard Domestic payments

Urgent Domestic payments

Standard Domestic Bulk payments

Bulk Inter Account Transfers (IATs)

Ad hoc bulk payments

For these payment types the credit account is always a UK Sterling account. The sort code should be populated

in field T022 (in the format ‘6n’) and the account number in field T028 (in the format ‘8n’).

Inter Account Transfers For Sterling Inter Account Transfers the credit account is always a UK Sterling account. For such payments the

sort code should be populated in field T022 (in the format ‘6n’) and the account number in field T028 (in the

format ‘8n’).

For currency Inter Account Transfers the credit account may either be a UK Sterling account or an RBSG

currency account.

• For a UK Sterling account the sort code should be populated in field T022 (in the format ‘6n’) and the

account number should be populated in field T028 (in the format ‘8n’).

• For an RBSG currency account field T022 should not be populated and the account number should be

populated in field T028 (in the format ‘8a3a3a’).

International payments

For these payment types the credit account will most commonly be a non UK account, but may also be a UK

Sterling or UK currency account.

In general it is recommended that wherever possible a BIC be populated in field T022 with a corresponding IBAN

in field T028, both in a format appropriate for the destination country (field T007).

This is especially true for payments to Europe or other countries that support the use of IBANs, where failure to

adhere to this format may impact delivery timescales and increase payment charges. However, alternative

options are available for specifying the credit account.

• For a UK currency account or a non UK account (other than where the payment priority in field T008 is set

to ‘L’) an NCC may be populated in field T022 and an account number populated in field T028, both in a

format appropriate for the destination country (T008).

• For a non UK account where the payment priority (field T008) is set to ‘L’ fields T022 and T028 should be

populated in accordance with the low value payment rules for the destination country (field T007).

Bankline import file layout guide – Bankline (CSV) format

2.6 Codewords

These rules apply to additional codewords (fields T048, T050, through to T066) and additional codewords text (fields T049, T051,

through to T067).

Additional codewords should only be used where strictly necessary, as their use can delay the payment, prevent SEPA routing where

available, and increase payment charges. Furthermore, where a codeword requires an action by the receiving bank, the codeword

should only be used if the receiving bank has already agreed in advance that they will act on the codeword in question.

Finally, certain combinations of codewords are not permitted. For further information on usage of codewords please refer to the

SWIFT handbook.

Codeword Definition Additional text

CHQB Pay beneficiary by cheque

This codeword may only be used by Shipping customers, and when used the beneficiary account Number (field

T028) must not be populated.

CORT Settlement of a trade e.g. FX deal or securities transaction -

HOLD Pay on Identification

This codeword may only be used by Shipping customers.

Optional

INTC Intra-company payment -

REPA Related e-payments reference Optional

SDVA Execute with Same Day Value -

PHOB Advise beneficiary by phone Optional

TELB Advise beneficiary by most efficient means Optional

PHON Advise account with Institution by phone Optional

TELE Advise account with Institution by most efficient means Optional

PHOI Advise Intermediary Institution by phone

When used the Intermediary Bank identifier (field T043) must be populated.

Optional

TELI Advise Intermediary Institution by most efficient means

When used the Intermediary Bank identifier (field T043) must be populated.

Optional

Bankline import file layout guide – Bankline (CSV) format

3. Import data table

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std

Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

H001 16x Originating customer identifier

This field is reserved for internal use only and

should not be populated.

- - - - - - - - - - - - - - - - - -

H002 50x Import file name

Identifies the name of the import file.

This is a free format field.

If left blank field H002 defaults to the physical

import file name.

O O O O O O O O O O O O O O O O O O

H003 4x Bank identifier

This field is reserved for internal use only and

should not be populated.

- - - - - - - - - - - - - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T001 2n Record type

Identifies the underlying payment type being

imported.

Valid values are:

• ‘01’ = standard domestic payment

• ‘02’ = urgent domestic payment

• ‘03’ = Inter Account Transfer

• ‘04’ = international payment

• ‘06’ = bulk list debit

• ‘07’ = bulk list credit

• “08” = ad hoc bulk payment debit

• “09” = ad hoc bulk payment credit

M M M M M M M M M M M M M M M M M M

T002 1a Template indicator

Identifies the import of a new template or bulk

list.

The only valid value is ‘T’ indicating that this is

a new template or bulk list.

- - - - M M M M - - - - M - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T003 20x Template reference

Identifies the template being used in the import

of a new template or a payment from an

existing template. Also identifies the bulk list

being used in the import of a new bulk list or a

payment / transfer from an existing bulk list.

This is a free format field. However, the field

size is limited to ‘18x’ for the bulk list record

type.

- - - - M M M M M M M M M - M - - -

T004 1a Confidential indicator

Identifies whether a new bulk list is to be

marked as confidential or not.

Valid values are:

• ‘Y’ = confidential

• ‘N’ = not confidential

- - - - - - - - - - - - M - - - O -

T005 25x Beneficiary identifier

Identifies, in addition to the beneficiary name,

each beneficiary on a bulk list or bulk payment.

This is a free format field.

This field should only be populated for standard

domestic bulk payments and standard

domestic bulk lists.

- - - - - - - - - - - - - C - C - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T006 18x Customer payment reference

Identifies the payment as it will be known to

the remitter.

This is a free format field. However, the field

size is limited to ‘16x’ on the IAT and

international record types.

If left blank field T006 defaults to:

• The beneficiary name and address Line

number 1 (field T030) for standard

domestic, urgent domestic, and

international record types.

• The credit account name as held in

Bankline for the beneficiary account

Number (field T028 when read in

conjunction with the account with Bank

identifier in field T022) for the IAT record

type.

• For Ad Hoc Bulk Payments the first 16

characters of the import file name.

O O O O O O O O O O O O - - - O -

T007 2a Destination country

Identifies the payment destination country for

those payment types where the destination

country can be other than that where the debit

account is held.

Valid value is a recognised ISO country code.

- - - M - - - M - - - - - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T008 1a Priority

Identifies, for the international record type, the

payment priority for those record types where

the priority may be varied.

Valid values for the international record type

are:

• ‘U’ = urgent

• ‘N’ = normal

• ‘L’ = low value

The value of ‘L’ is only valid for payments to a

limited number of non SEPA countries, those

countries being Australia, Canada, New

Zealand, South Africa and the United States of

America.

When set to ‘L’ then no additional codewords

or additional codeword text should be used.

Identifies, for the bulk list record type, whether

it is a standard domestic bulk list or an Inter

Account Transfer bulk list. For payments / IATs

from a bulk list, this field should not be

populated. The payment type will be known

from the ‘bulk list reference’ supplied in field

T003.

Valid values are:

• ‘U’ = Inter Account Transfer

• ‘N’ = standard domestic

If left blank field T008 defaults to ‘N’.

- - - M - - - M - - - - C - - - O -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T009 1a Routing Method

Identifies any special routing method

requirements.

Valid values are:

• Blank = no special requirements

• ‘C’ = foreign draft (international record

type only)

- - - O - - - O - - - - - - - - - -

T010 34x Debit account identifier

Identifies the debit account for the payment.

For valid values please refer to section 2.4 of

this document.

M M M M M M M M M M M M M - M - M -

T011 34x Debit charges account identifier

Identifies the account from which any debit

charges are to be deducted.

For valid values please refer to section 2.4 of

this document.

If left blank field T011 defaults to the debit

account (field T010).

- - - O - - - O - - - O - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T012 3a Charges Code type

Identifies who will pay what, if any, charges

associated with the payment.

Valid values are:

• ‘OUR’ = remitter to pay all charges

• ‘BEN’ = beneficiary to pay all charges

• ‘SHA’ = remitter to pay debit charges

and beneficiary to pay credit charges.

If left blank field T012 defaults to ‘SHA’.

If the payment priority (field T008) is set to ‘L’

then field T012 must be set to ‘OUR’.

If the destination country (T007) is set to a

SEPA country and the payment currency

(T013) is set to ‘EUR’ then field T012 should

be set to ‘SHA’ to ensure the payment is SEPA

compliant. Failure to do so may result in the

payment costing more and taking longer to

reach the beneficiary.

- - - C - - - C - - - C - - - - - -

T013 3a Payment currency

Identifies the currency in which the payment

Amount (field T014) is expressed.

Valid value is a recognised ISO currency code.

- - M M M M M M M M M M - - - M - M

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T014 15n Payment amount

Identifies the amount of the payment as

expressed in the payment currency (field

T013).

Valid value is an amount in the format 12n.2n

where the number of decimal places may be

constrained by the local rules for the payment

currency (field T013).

M M M M - - - - M M M M - - - M - M

T015 Date Execution date

Identifies the date on which the payment is to

be initiated.

Valid value is a date in the format ddmmyyyy.

Only populate for bulk Inter Account Transfers.

- C C C - - - - - C C C - - C - - -

T016 Date Date payment to arrive (credit date)

Identifies the date on which the funds are to be

received by the beneficiary bank. Although not

guaranteed this will normally be the same date

on which the funds will be made available to

the beneficiary.

Valid value is a date in the format ddmmyyyy.

For the bulk list record type this should only be

populated for standard domestic bulk

payments.

M C C C - - - - M C C C - - C - M -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T017 16x Ordering Institution identifier

Identifies the ordering institution.

This field should only be populated by financial

institutions, and in such cases it must be

populated with:

• a valid BIC wherever possible (otherwise

delivery times and payment charges can

be impacted), or

• a valid sort code, or

• for non-UK financial institutions a

National Clearing Code, with the two

character country code as prefix, may be

used.

- C - C - C - C - C - C - - - - - -

T018 35x Ordering Institution name and address Line

number 1

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T019 35x Ordering Institution name and address Line

number 2

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T020 35x Ordering Institution name and address Line

number 3

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T021 35x Ordering Institution name and address Line

number 4

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T022 16x Account with bank identifier

Identifies the account holding institution at

which the beneficiary account in field T028 is

held.

For valid values and conditions applying to this

field please refer section 2.5 of this document.

If field T043 is completed (intermediary

Institution), then this field becomes mandatory.

M M C C M M C C - - - - - M - M - M

T023 34x Account with bank account number

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T024 35x Account with bank name and address Line

number 1

- - - C - - C - - - - - - - - - -

T025 35x Account with bank name and address Line

number 2

- - - C - - - C - - - - - - - - - -

T026 35x Account with bank name and address Line

number 3

- - - O - - O- - - - - - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T027 35x Account with bank name and address Line

number 4

- - - O - - O- - - - - - - - - - -

T028 34x Beneficiary account number

Identifies the beneficiary account number as

held (where appropriate) at the account with

Bank institution (i.e. the account holding

institution) in field T022.

For valid values please refer to section 2.5 of

this document.

For the international record type:

• if the Routing Method (field T009) is set

to ‘C’ then field T028 should be left

blank.

• if one of the additional codewords (fields

T048, T050 and so on through to T066)

is set to ‘CHQB’ field T028 should be left

blank.

• otherwise field T028 must be populated.

M M M C M M M C - - - - - M - M - M

T029 16x Beneficiary institution identifier

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T030 35x Beneficiary name and address line number

Identifies the beneficiary name.

This is a free format field.

For the bulk list record type field T030 is

mandatory for standard domestic bulk lists and

payments but must not be populated for Inter

Account Transfer bulk lists and bulk Inter

Account Transfers.

M M - M M M - M - - - - - C - C - M

T031 35x Beneficiary name and address line number

Identifies the first line of the beneficiary

address.

This is a free format field.

For the international record type:

• if the Routing Method (field T009) is set

to ‘C’ then field T031 must be populated

• if one of the additional codewords (fields

T048, T050 and so on through to T066)

is set to ‘CHQB’ then field T031 must be

populated.

- O - C - O - C - - - - - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T032 35x Beneficiary name and address line number

Identifies the second line of the beneficiary

address.

This is a free format field.

This field should not be populated if Beneficiary

name and address Line number 2 (field T031)

has not also been populated.

For the international record type:

• if the Routing Method (field T009) is set

to ‘C’ then field T032 must be populated

• if one of the additional codewords (fields

T048, T050 and so on through to T066)

is set to ‘CHQB’ then field T031 must be

populated.

- O - C - O - C - - - - - - - - - -

T033 35x Beneficiary name and address line number

Identifies the third line of the beneficiary

address.

This is a free format field.

This field should not be populated if beneficiary

name and address Line number 3 (field T032)

has not been populated.

- O - O - O - O - - - - - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T034 18x Beneficiary reference

Identifies the payment as it will be known to

the beneficiary.

This is a free format field.

For the bulk list record type, field T034 is

optional in all cases except for the debit side of

a bulk Inter Account Transfer (in which case,

the field must not be populated).

If left blank, field T034 defaults to the debit

account name as held in Bankline for the Debit

Account identifier (field T010).

Exceptions to this are as follows:

• Credit side of IAT bulk list will default to

debit side value of IAT bulk list

• Credit side of bulk IAT will default to value

present for credit side of IAT bulk list.

O - - - O - - - O - - - O O C O O O

T035 16n FX Deal reference

Identifies the reference of any FX deal

associated with the payment.

This is a free format field.

If a FX Deal reference is supplied then a

corresponding FX Deal Exchange Rate (field

T036) must also be supplied.

- - C C - - - - - - C C - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T036 15n FX Deal Exchange Rate

Identifies the exchange rate of any FX deal

associated with the payment. Valid value is an

amount in the format 8n.7n i.e. there may be

up to 8 digits before the decimal point and up

to 7 digits after the decimal point.

If an FX Deal Exchange Rate is supplied then a

corresponding FX Deal reference (field T035)

must also be supplied.

- - C C - - - - - - C C - - - - - -

T037 35x Information for the beneficiary line number

Payment details that will help identify the

payment to the beneficiary.

This is a free format field. However, the field

size is limited to ‘16x’ for the IAT record type.

If left blank for the IAT record type field T037

defaults to the debit account name as held in

Bankline for the debit account identifier (field

T010).

- O O O - O O O - O O O - - - - - -

T038 35x Information for the beneficiary line number

Additional payment details that will help

identify the payment to the beneficiary.

This is a free format field.

This field should not be populated if

Information for the beneficiary Line number 1

(field T037) has not also been populated.

- O - O - O - O - O - O - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T039 35x Information for the beneficiary Line number

Additional payment details that will help

identify the payment to the beneficiary.

This is a free format field.

This field should not be populated if

Information for the beneficiary Line number 2

(field T038) has not also been populated.

- O - O - O - O - O - O - - - - - -

T040 35x Information for the beneficiary Line number

Additional payment details that will help

identify the payment to the beneficiary.

This is a free format field.

This field should not be populated if

Information for the beneficiary Line number 3

(field T039) has not also been populated.

- O - O - O - O - O - O - - - - - -

T041 1a RTGS Required

Identifies whether the payment should be

settled via an RTGS settlement mechanism.

Valid values are:

‘Y’ = RTGS required

‘N’ = RTGS not required

For this field to be effective there must be a

corresponding RTGS agreement in place in

Bankline.

- - - O - - - O - - - O - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T042 3a Credit currency

Identifies the currency in which the payment

Amount (field T014) is to be remitted. This

need not be the same as the payment currency

(field T013) in which the payment Amount is

expressed, but it is normally the local currency

of the destination country (field T007).

Valid value is a recognised ISO currency code.

- - - M - - - M - - - M - - - - - -

T043 16x Intermediary bank identifier

Identifies the intermediary institution through

which the payment should be routed.

Use only where necessary as the use of

intermediaries can impact delivery timescales

and increase payment charges.

Valid value is a recognised BIC, and for the

urgent domestic record type that must be a UK

BIC.

If left blank the payment will be routed via the

most effective options available to RBSG.

- O - O - O - O - - - - - - - - - -

T044 35x Intermediary bank name and address Line

number 1

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T045 35x Intermediary bank name and address Line

number 2

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T046 35x Intermediary bank name and address Line

number 3

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T047 35x Intermediary bank name and address Line

number 4

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T048 4a Additional codewords number 1

Codewords that identify any special

instructions for the beneficiary bank.

For valid values please refer to section 2.6 of

this document. The field size is limited to ‘4a’

for urgent domestic and international records.

This field should not be populated unless the

customer is registered to use codewords.

Customers wishing to use codewords should

contact their relationship manager in the first

instance for further information.

- O - O - O - O - O - O - - - - - -

T049 29x Additional codewords text number 1

Identifies any additional text to accompany

additional codewords.

This is a free format field.

This field should not be populated unless a

corresponding codeword has been provided in

field T048.

- O - O - O - O - O - O - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T050 4a Additional codewords number 2

See field T048 for further information.

- O - O - O - O - O - O - - - - - -

T051 29x Additional codewords text number 2

See field T049 for further information.

- O - O - O - O - O - O - - - - - -

T052 4a Additional codewords number 3

See field T048 for further information.

- O - O - O - O - O - O - - - - - -

T053 29x Additional codewords text number 3

See field T049 for further information.

- O - O - O - O - O - O - - - - - -

T054 4a Additional codewords number 4

See field T048 for further information.

- O - O - O - O - O - O - - - - - -

T055 29x Additional codewords text number 4

See field T049 for further information.

- O - O - O - O - O - O - - - - - -

T056 4a Additional codewords number 5

See field T048 for further information.

- O - O - O - O - O - O - - - - - -

T057 29x Additional codewords text number 5

See field T049 for further information.

- O - O - O - O - O - O - - - - - -

T058 4a Additional codewords number 6

See field T048 for further information.

- O - O - O - O - O - O - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T059 29x Additional codewords text number 6

See field T049 for further information.

- O - O - O - O - O - O - - - - - -

T060 4a Additional codewords number 7

See field T048 for further information.

- O - O - O - O - O - O - - - - - -

T061 29x Additional codewords text number 7

See field T049 for further information.

- O - O - O - O - O - O - - - - - -

T062 4a Additional codewords number 8

See field T048 for further information.

- O - O - O - O - O - O - - - - - -

T063 29x Additional codewords text number 8

See field T049 for further information.

- O - O - O - O - O - O - - - - - -

T064 4a Additional codewords number 9

See field T048 for further information.

- O - O - O - O - O - O - - - - - -

T065 29x Additional codewords text number 9

See field T049 for further information.

- O - O - O - O - O - O - - - - - -

T066 4a Additional codewords number 10

See field T048 for further information.

- O - O - O - O - O - O - - - - - -

T067 29x Additional codewords text number 10

See field T049 for further information.

- O - O - O - O - O - O - - - - - -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T068 35x Regulatory Reporting Line number 1

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T069 35x Regulatory Reporting Line number 2

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T070 35x Regulatory Reporting Line number 3

This field is reserved for future use and should

not be populated.

- - - - - - - - - - - - - - - - - -

T071 1a Remittance advice indicator

Identifies whether there is a remittance advice

(or one or more remittance advices in the case

of a bulk list) associated with the payment.

Valid values are:

blank = no remittance advice

‘C’ = remittance advice

Remittance advices are only available on BACS

payments, so if a standard domestic payment

is processed as a Faster Payment then a value

of ‘C’ in field T071 will effectively be overruled.

For Inter Account Transfer bulk lists and bulk

Inter Account Transfers field T071 must not be

populated.

O - - - O - - - O - - - C - C - O -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T072 35x Remittance advice beneficiary address Line

number 1

Identifies the first line of the beneficiary

address on the remittance advice.

This is a free format field.

If there is a remittance advice associated with

this payment (as indicated by a ‘C’ in field

T071) then field T072 must be populated.

If a standard domestic payment is processed

as a Faster Payment then any information

provided in field T072 will be discarded.

For Inter Account Transfer bulk lists and bulk

Inter Account Transfers field T072 must not be

populated.

C - - - C - - - C - - - - C - C - C

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T073 35x Remittance advice beneficiary address Line

number 2

Identifies the second line of the beneficiary

address on the remittance advice.

This is a free format field.

If there is a remittance advice associated with

this payment (as indicated by a ‘C’ in field

T071) then field T073 must be populated.

If a standard domestic payment is processed

as a Faster Payment then any information

provided in field T073 will be discarded.

For Inter Account Transfer bulk lists and bulk

Inter Account Transfers field T073 must not be

populated.

C - - - C - - - C - - - - C - C - C

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T074 35x Remittance advice beneficiary address Line

number 3

Identifies the third line of the beneficiary

address on the remittance advice.

This is a free format field.

This field should only be populated if

Remittance advice beneficiary address Line

number 2 (field T073) has also been

populated.

If a standard domestic payment is processed

as a Faster Payment then any information

provided in field T074 will be discarded.

For Inter Account Transfer bulk lists and bulk

Inter Account Transfers field T074 must not be

populated.

O - - - O - - - O - - - - C - C - C

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T075 35x Remittance advice beneficiary address Line

number 4

Identifies the fourth line of the beneficiary

address on the remittance advice.

This is a free format field.

This field should only be populated if

Remittance advice beneficiary address Line

number 3 (field T073) has also been

populated.

If a standard domestic payment is processed

as a Faster Payment then any information

provided in field T075 will be discarded.

For Inter Account Transfer bulk lists and bulk

Inter Account Transfers field T075 must not be

populated.

O - - - O - - - O - - - - C - C - C

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T076 20x Remittance advice beneficiary Fax Number

Identifies the beneficiary fax number on the

remittance advice.

This is a free format field.

This field should not be populated if there is no

remittance advice associated with this payment

(as indicated by a blank in field T071).

If a standard domestic payment is processed

as a Faster Payment then any information

provided in field T076 will be discarded.

For Inter Account Transfer bulk lists and bulk

Inter Account Transfers field T076 must not be

populated.

O - - - O - - - O - - - - C - C - C

T077 50x Remittance advice beneficiary Email

address

Identifies the beneficiary email address on the

remittance advice.

This is a free format field.

This field should only be populated if there is a

remittance advice associated with this payment

(as indicated by a blank in field T071).

If a standard domestic payment is processed

as a Faster Payment then any information

provided in field T077 will be discarded.

For Inter Account Transfer bulk lists and bulk

Inter Account Transfers field T077 must not be

populated.

O - - - O - - - O - - - - C - C - C

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T078 34x By order of account

Identifies the account number of the originating

customer.

This field is mandatory for Financial Institution

customers. Wherever possible the originating

customers IBAN should be populated here.

For all other customers this field must not be

populated.

- C - C - C - C - C - C - - - - - -

T079 35x By order of name

Identifies the name of the originating customer.

Wherever possible the originating customers

account name should be populated here.

This field is mandatory for Financial Institution

customers and wherever possible the

originating customers account name should be

populated here.

This field is optional for non Financial Institution

customers with a valid ‘By order Of’ value pre-

registered in Bankline. It must be populated

with a pre-registered value.

For all other customers this field must not be

populated.

For Inter Account Transfer bulk lists and bulk

Inter Account Transfers field T079 must not be

populated.

C C - C C C - C C C - C C - C - C -

Bankline import file layout guide – Bankline (CSV) format

Payment Payment template Payment from template Bulk List Payment /

IAT from

Bulk List

Ad Hoc Bulk

Payment

Field tag Field name and notes

Std Urg IAT Intl Std Urg IAT Intl Std Urg IAT Intl DR CR DR CR DR CR

T080 35x By order of address Line number 1

Identifies the first line of address of the

originating customer.

This field is mandatory for Financial Institution

customers and must be populated with

information relating to the originating

customer.

For all other customers this field must not be

populated.

- C - C - C - C - C - C - - - - - -

T081 35x By order of address Line number 2

Identifies the second line of address of the

originating customer.

This field is optional for Financial Institution

customers and where populated must contain

information relating to the originating

customer.

For all other customers this field must not be

populated.

- C - C - C - C - C - C - - - - - -

T082 35x By order of address Line number 3

Identifies the third line of address of the

originating customer.

This field is optional for Financial Institution

customers and where populated must contain

information relating to the originating

customer.

For all other customers this field must not be

populated.

- C - C - C - C - C - C - - - - - -

Bankline import file layout guide – Bankline (CSV) format

4. Examples

4.1 Introduction

The following examples demonstrate how to structure and populate an import record, for a selection of payment types. These payment types are outlined below:

• standard domestic payment

• standard domestic payment template

• standard domestic payment from a template

• international payment

• standard domestic bulk list

• standard domestic bulk payment

• inter account transfer (IAT) bulk list

• bulk inter account transfer (IAT)

• ad hoc bulk payments

Bankline import file layout guide – Bankline (CSV) format

4.2 Standard domestic payment

The example below shows how to format an import record for a standard domestic payment.

,,,01,,,,,,,,,15100031806542,,,,166.42,,01102006,,,,,,151000,,,,,,44298801,,MR JOHN SMITH,,,,INVOICE 1234,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This is broken down below to illustrate how each field tag on the above import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 T028 44298801 T043 T058 T073

H002 T014 166.42 T029 T044 T059 T074

H003 T015 T030 MR JOHN SMITH T045 T060 T075

T001 01 T016 01102006 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 T018 T033 T048 T063 T078

T004 T019 T034 INVOICE 1234 T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 151000 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 15100031806542 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) – The value ‘01’ identifies a standard domestic payment. If field T003 (Template reference) had also been populated then this would have become a standard domestic

payment from an existing standard domestic payment template.

• T010 (Debit account identifier) – The value ‘15100031806542’ is a UK Sterling account with sort code 15-10-00 and account number 31806542. No dashes or spaces are required when

entering the sort code, or between the sort code and account number. The debit account must be a valid account registered to that customer in Bankline.

• T014 (Payment Amount) – No leading spaces are required when quoting the payment amount, and the decimal point is necessary only where the payment amount requires it. For a standard

domestic payment field T013 (payment currency) need not be completed as the ISO currency code GBP will be automatically associated with the payment amount in field T014.

• T016 (Date payment to Arrive / Credit Date) – The value ‘01102006’ equates to 1 October 2006.

• T022 (account with Bank identifier) – The value ‘151000’ is the UK Sterling sort code 15-10-00. As detailed above in field T001 this import record is in respect of a standard domestic payment,

therefore the account with Bank identifier must be a valid sort code for the receipt of standard domestic payments.

• T028 (Beneficiary account Number) – This is the beneficiary account Number held at the account with Bank identifier quoted in field T022.

• T030 (Beneficiary name and address Line number 1) – This is the name of the beneficiary customer linked to the beneficiary account Number quoted in field T028. For a standard domestic

payment only the beneficiary name requires to be quoted, but for other payment types the beneficiary address may also be quoted.

• T034 (Beneficiary reference) – This is the reference that will be advised to the beneficiary customer and as such should be meaningful to the beneficiary, such as an invoice number.

Bankline import file layout guide – Bankline (CSV) format

4.3 Standard domestic payment template

The example below shows how to format an import record for a new Bankline standard domestic payment template.

,,,01,T,STANDARD TEMP 01,,,,,,,15100031806542,,,GBP,,,,,,,,,151000,,,,,,59984654,,MR JOHN SMITH,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This is broken down below to illustrate how each field tag on the above import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 GBP T028 59984654 T043 T058 T073

H002 T014 T029 T044 T059 T074

H003 T015 T030 MR JOHN SMITH T045 T060 T075

T001 01 T016 T031 T046 T061 T076

T002 T T017 T032 T047 T062 T077

T003 STANDARD TEMP 01 T018 T033 T048 T063 T078

T004 T019 T034 T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 151000 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 15100031806542 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) and T002 (Template indicator) – The value ‘01’ in field T001 identifies the standard domestic payment type, and the value ‘T’ in field T002 identifies that this is a new

standard domestic payment template.

• T003 (Template reference) – The value ‘STANDARD TEMP 01’ is how the template will be known in Bankline.

• T010 (Debit account identifier) – The value ‘15100031806542’ is a UK Sterling account with sort code 15-10-00 and account number 31806542. No dashes or spaces are required when

entering the sort code, or between the sort code and account number. The debit account must be a valid account registered to that customer in Bankline.

• T013 (Payment currency) – This will always be ‘GBP’ for a standard domestic payment template.

• T022 (account with Bank identifier) – The value ‘151000’ is the UK Sterling sort code 15-10-00. As detailed above in field T001, this import record is in respect of the standard domestic

payment type, therefore the account with Bank identifier must be a valid sort code for the receipt of standard domestic payments.

• T028 (Beneficiary account Number) – This is the beneficiary account Number held at the account with Bank identifier quoted in field T022.

• T030 (Beneficiary name and address Line number 1) – This is the name of the beneficiary customer linked to the beneficiary account Number quoted in field T028. For a standard domestic

payment, the beneficiary name should be quoted, for other payment types the beneficiary address can also be quoted.

Bankline import file layout guide – Bankline (CSV) format

4.4 Standard domestic payment from a template

The example below shows how to format an import record for a standard domestic payment from an existing Bankline standard domestic payment template.

,,,01,,STANDARD TEMP 01,,,,,,,15100031806542,,,GBP,166.42,,01102006,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This is broken down below to illustrate how each field tag on the import record above has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 GBP T028 T043 T058 T073

H002 T014 166.42 T029 T044 T059 T074

H003 T015 T030 T045 T060 T075

T001 01 T016 01102006 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 STANDARD TEMP 01 T018 T033 T048 T063 T078

T004 T019 T034 T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 15100031806542 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) and T003 (Template reference) – The value ‘01’ in field T001 identifies the standard domestic payment type, and the value ‘STANDARD TEMP 01’ in field T003 identifies that

it is a standard domestic payment from an existing standard domestic payment template (of that name).

• T010 (Debit account identifier) – The value ‘15100031806542’ is a UK Sterling account with sort code 15-10-00 and account number 31806542. No dashes or spaces are required when

entering the sort code or between sort code and account number. The debit account must be a valid account registered to that customer in Bankline.

• T013 (Payment currency) – This will always be ‘GBP’ for a standard domestic payment from a template.

• T014 (Payment Amount) – No leading spaces are required when entering the payment amount and the decimal point is only necessary where the payment amount requires it. The payment

amount is in the currency quoted in field T013.

• T016 (Date payment to Arrive / Credit Date) - The value ‘01102006’ equates to 1 October 2006.

Bankline import file layout guide – Bankline (CSV) format

4.5 International payment

The example below shows how to format an import record for an international payment.

,,,04,,,,,,US,N,,15100031806542,,,USD,1266.42,01102006,,,,,,,IRVTUS3NIRD,,,,,,44298801,,MR JOHN SMITH,,,,,2006100112999,1.87,,,,,,USD,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This is broken down to illustrate how each field tag on the import record above has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 USD T028 44298801 T043 T058 T073

H002 T014 1266.42 T029 T044 T059 T074

H003 T015 01102006 T030 MR JOHN SMITH T045 T060 T075

T001 04 T016 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 T018 T033 T048 T063 T078

T004 T019 T034 T049 T064 T079

T005 T020 T035 2006100112999 T050 T065 T080

T006 T021 T036 1.87 T051 T066 T081

T007 US T022 IRVTUS3NIRD T037 T052 T067 T082

T008 N T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 15100031806542 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 USD T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) – The value ‘04’ identifies an international payment. If field T003 (Template reference) had also been populated then this would have become an international payment from

an existing international payment template.

• T007 (Destination country) – The value ‘US’ is the ISO country code for the United States of America.

• T008 (Priority) – The value ‘N’ identifies this as a normal or standard priority payment.

• T010 (Debit account identifier) – The value ‘15100031806542’ is a UK Sterling account with sort code 15-10-00 and account number 31806542. No dashes or spaces are required when

entering the sort code or between the sort code and the account number. The debit account must be a valid account registered to that customer in Bankline.

• T013 (Payment currency) – The value USD is the ISO currency code for US Dollars.

• T014 (Payment Amount) – No leading spaces are required when entering the payment amount, and the decimal point is only necessary where the payment amount requires it. The payment

amount should be in the currency quoted in field T013.

• T015 (Execution Date) – The value ‘01102006’ equates to 1 October 2006.

• T022 (account with Bank identifier) – The value ‘IRVTUS33NIRD’ is the BIC for the Bank of New York in New York City.

• T028 (Beneficiary account Number) – This is the beneficiary account Number held at the account with Bank identifier quoted in field T022.

• T030 (Beneficiary name and address Line number 1) – This is the name of the beneficiary customer linked to the beneficiary account Number quoted in field T028. For an international payment

up to three additional lines of beneficiary address information may be quoted in fields T031, T032 and T033.

• T035 (FX Deal reference) and T036 (FX Deal Exchange Rate) – The value ‘2006100112999’ in field T035 is the FX Deal reference and the value ‘1.87’ in field T036 is the FX rate associated

with that deal reference.

• T042 (Credit currency) – The value ‘USD’ is the ISO currency code for US Dollars.

Bankline import file layout guide – Bankline (CSV) format

4.6 Standard domestic bulk list

Debit -This example shows how to format an import record for a new Bankline standard domestic bulk list with a single beneficiary.

,,,06,T,SALARY MTH END 01,N,,,,,,15100031806542,,,,,,,,,,,,,,,,,,,,,,,,PAYROLL,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 T028 T043 T058 T073

H002 T014 T029 T044 T059 T074

H003 T015 T030 T045 T060 T075

T001 06 T016 T031 T046 T061 T076

T002 T T017 T032 T047 T062 T077

T003 SALARY MTH END 01 T018 T033 T048 T063 T078

T004 N T019 T034 PAYROLL T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 15100031806542 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) and T002 (Template indicator) – The value ‘06’ in field T001 identifies the payment type as, ‘bulk list debit’, and the value ‘T’ in field T002 indicates that the import is for a

‘bulk list’ (not a payment from a bulk list).

• T003 (Template reference) – The value ‘SALARY MTH END 01’ is how the bulk list will be known in Bankline.

• T008 (Priority) – This field is used to differentiate standard domestic bulk lists from IAT bulk lists. In this example, the field has been left blank. When left blank, this value will always default to

‘N’ for standard domestic.

• T010 (Debit account identifier) – The value ‘15100031806542’ is a UK Sterling account with sort code 15-10-00 and account number 31806542. No dashes or spaces are required when

entering the sort code, or between the sort code and the account number. The debit account must be a valid account registered to that customer in Bankline.

• T034 (Beneficiary reference) – This is the reference that will be advised to the beneficiary customer and should be meaningful to the beneficiary e.g. payroll reference. Note that if an individual

beneficiary is given their own reference (as specified on the standard domestic bulk list credit), this will override any reference supplied here for that individual beneficiary.

Bankline import file layout guide – Bankline (CSV) format

Credit

When importing a standard domestic bulk list debit one or more corresponding standard domestic bulk list credits must be imported simultaneously. Each standard domestic bulk list must have at

least one beneficiary.

,,,07,,,,1887,,,,,,,,,,,,,,,,,151000,,,,,,31803654,,MR JOHN SMITH,,,,PAYROLL 01,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 T028 31803654 T043 T058 T073

H002 T014 T029 T044 T059 T074

H003 T015 T030 MR JOHN SMITH T045 T060 T075

T001 07 T016 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 T018 T033 T048 T063 T078

T004 T019 T034 PAYROLL 01 T049 T064 T079

T005 1887 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 151000 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) – The value ‘07’ identifies the payment type as a ‘bulk list credit’.

• T005 (Beneficiary identifier) – This should uniquely identify each beneficiary on the bulk list and so a unique identifier should be used such as staff payroll reference.

• T022 (account with Bank identifier) – The value ‘151000’ is the UK Sterling sort code 15-10-00.

• T028 (Beneficiary account Number) – This is the beneficiary account Number held at the account with Bank identifier in field T022.

• T030 (Beneficiary name and address Line number 1) – This is the name of the beneficiary customer linked to the beneficiary account Number in field T028.

• T034 (Beneficiary reference) – Not a mandatory field. This is the individual reference that will be advised to the beneficiary customer (if the standard domestic bulk list debit is not used), it should

be meaningful to the beneficiary, e.g. payroll reference.

Bankline import file layout guide – Bankline (CSV) format

4.7 Standard domestic bulk payment

Debit - This example shows how to format an import record for a standard domestic bulk list payment with a single beneficiary.

,,,06,,SALARY MTH END 01,,,,,,,15100031806542,,,,,,01102006,,,,,,,,,,,,,,,,,,PAYROLL,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 T028 T043 T058 T073

H002 T014 T029 T044 T059 T074

H003 T015 T030 T045 T060 T075

T001 06 T016 01102006 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 SALARY MTH END 01 T018 T033 T048 T063 T078

T004 T019 T034 PAYROLL T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 15100031806542 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) and T002 (Template indicator) – The value ‘06’ in field T001 identifies the payment type as a ‘bulk list debit’.

• T003 (Template reference) – The value ‘SALARY MTH END 01’ identifies the bulk list from which the standard domestic bulk payment will be made from.

• T008 (Priority) – This field is used to differentiate standard domestic bulk payments from bulk Inter Account Transfers. In this example, the field has been left blank. When left blank, this value

will always default to ‘N’ for ‘standard domestic’.

• T010 (Debit account identifier) – The value ‘15100031806542’ is a UK Sterling account with sort code 15-10-00 and account number 31806542. No dashes or spaces are required when

entering the sort code, or between the sort code and the account number. The debit account must be a valid account as registered to that customer in Bankline.

• T016 (Date payment to Arrive / Credit Date) - The value ‘01102006’ equates to 1 October 2006.

• T034 (Beneficiary reference) – This is the reference that will be advised to the beneficiary customer. It should be meaningful to the beneficiary, e.g. a payroll reference. Note that if an individual

beneficiary is given their own reference (as specified on the standard domestic bulk payment credit) then that will override any reference supplied here.

Bankline import file layout guide – Bankline (CSV) format

Credit

When importing a standard domestic bulk list debit payment, one or more consecutive standard domestic bulk list credit payments must be imported at the same time. This is because each standard

domestic bulk list payment must have at least one beneficiary.

,,,07,,,,1887,,,,,,,,GBP,1566.23,,,,,,,,151000,,,,,,31803654,,MR JOHN SMITH,,,,PAYROLL 01,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 GBP T028 31803654 T043 T058 T073

H002 T014 1566.23 T029 T044 T059 T074

H003 T015 T030 MR JOHN SMITH T045 T060 T075

T001 07 T016 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 T018 T033 T048 T063 T078

T004 T019 T034 PAYROLL 01 T049 T064 T079

T005 1887 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 151000 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) – The value ‘07’ identifies the payment type as ‘bulk list credit’.

• T005 (Beneficiary identifier) – This should uniquely identify each beneficiary on the bulk list and so a unique identifier should be used such as staff payroll reference.

• T013 (Payment currency) – This will always be ‘GBP’ for a standard domestic bulk payment.

• T014 (Payment Amount) – No leading spaces are required when entering the payment amount and the decimal point is necessary only where the amount requires it. The payment amount is in

the currency in field T013.

• T022 (account with Bank identifier) – The value ‘151000’ is the UK Sterling sort code 15-10-00.

• T028 (Beneficiary account Number) – This is the beneficiary account Number held at the account with Bank identifier in field T022.

• T030 (Beneficiary name and address Line number 1) – This is the name of the beneficiary customer linked to the beneficiary account Number quoted in field T028.

• T034 (Beneficiary reference) – Not a mandatory field. This is the individual reference that will be advised to the beneficiary customer (if the standard domestic bulk list payment debit is not used).

It should be meaningful to the beneficiary, e.g. payroll reference.

Bankline import file layout guide – Bankline (CSV) format

4.8 Inter Account Transfer (IAT) bulk list

Debit - This example shows how to format an import record for a new Bankline Inter Account Transfer bulk list with a single credit account.

,,,06,T,LUMP SUM DISTRIB 1,N,,,,U,,15100031806542,,,,,,,,,,,,,,,,,,,,,,,,NARRATIVE 1,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 T028 T043 T058 T073

H002 T014 T029 T044 T059 T074

H003 T015 T030 T045 T060 T075

T001 06 T016 T031 T046 T061 T076

T002 T T017 T032 T047 T062 T077

T003 LUMP SUM DISTRIB 1 T018 T033 T048 T063 T078

T004 N T019 T034 NARRATIVE 1 T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 T037 T052 T067 T082

T008 U T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 15100031806542 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

‘bulk list’ (not a payment from a bulk list).

• T003 (Template reference) – The value ‘LUMP SUM DISTRIB 1’ is how the Inter Account Transfer bulk list will be known in Bankline.

• T004 (Confidential indicator) – The value ‘N’ identifies this bulk list as ‘not confidential’.

• T008 (Priority) – The value ‘U’ is used as a marker to identify the bulk list as an IAT bulk list. If the field was blank, the default value would be ‘N’, and the bulk list could only be used for standard

domestic bulk payments.

• T010 (Debit account identifier) – The value ‘15100031806542’ is a UK Sterling account with sort code 15-10-00 and account number 31806542. No dashes or spaces are required when

entering the sort code, or between the sort code and account number. The debit account must be a valid account registered to that customer in Bankline.

• T034 (Beneficiary reference) – The value ‘Narrative 1’ is the narrative that will be marked against each credit account included within the bulk Inter Account Transfer. Note that if an individual

credit account is marked with a different narrative (as specified on the IAT bulk list credit), this will override any narrative supplied here for that individual credit account. If left blank, the narrative

will default to the ‘debit account name’.

Bankline import file layout guide – Bankline (CSV) format

Credit

When importing an IAT bulk list debit, one or more consecutive IAT bulk list credits must be imported at the same time as each IAT bulk list must have at least one credit account.

,,,07,,,,,,,,,,,,,,,,,,,,,151000,,,,,,31803654,,,,,,NARRATIVE 2,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 T028 31803654 T043 T058 T073

H002 T014 T029 T044 T059 T074

H003 T015 T030 T045 T060 T075

T001 07 T016 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 T018 T033 T048 T063 T078

T004 T019 T034 NARRATIVE 2 T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 151000 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) – The value ‘07’ identifies the payment type as a, ‘bulk list credit’.

• T022 (Account with Bank identifier) – The value ‘151000’ is the UK Sterling sort code 15-10-00.

• T028 (Beneficiary account Number) – This is the Credit account Number held at the account with Bank identifier quoted in field T022.

• T034 (Beneficiary reference) – Not a mandatory field. This is the individual ‘narrative’ that will be marked against the credit account (if IAT bulk list debit reference is not used). In this example, a

value of ‘Narrative 2’ will be used instead of ‘Narrative 1’ (previously specified on the IAT bulk list debit).

Bankline import file layout guide – Bankline (CSV) format

4.9 Bulk Inter Account Transfer (IAT)

Debit - This example shows how to format an import record for a bulk Inter Account Transfer with a single credit account.

,,,06,,LUMP SUM DISTRIB 1,,,,,U,,15100031806542,,,,,01102008,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 T028 T043 T058 T073

H002 T014 T029 T044 T059 T074

H003 T015 01102008 T030 T045 T060 T075

T001 06 T016 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 LUMP SUM DISTRIB 1 T018 T033 T048 T063 T078

T004 Confidentatial Indicator T019 T034 T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 15100031806542 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) and T002 (Template indicator) – The value ‘06’ in field T001 identifies the payment type as, ‘bulk list debit’. A value has not been populated in field T002. This means that

the import is for a payment from a bulk list.

• T003 (Template reference) – The value ‘LUMP SUM DISTRIB 1’ identifies the bulk list from which the bulk Inter Account Transfer will be made from.

• T008 (Priority) – This field does not need to be populated for the import of a bulk IAT. The type of bulk payment is known from the ‘bulk list reference’ populated in field T003 (Template

reference).

• T010 (Debit account identifier) – The value ‘15100031806542’ is a UK Sterling account with sort code 15-10-00 and account number 31806542. No dashes or spaces are required when

entering the sort code, or between the sort code and account number. The debit account must be a valid account as registered to that customer in Bankline.

• T015 (Execution Date) - The value ‘01102006’ equates to 1 October 2008.

• T034 (Beneficiary reference) – This field should not be populated for a debit bulk Inter Account Transfer.

Bankline import file layout guide – Bankline (CSV) format

Credit

When importing a bulk Inter Account Transfer debit, one or more consecutive bulk Inter Account Transfer credits must be imported at the same time. This is because each bulk Inter Account Transfer

must have at least one beneficiary.

,,,07,,,,,,,,,,,,GBP,1566.23,,,,,,,,151000,,,,,,31803654,,,,,,NARRATIVE 3,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 GBP T028 31803654 T043 T058 T073

H002 T014 1566.23 T029 T044 T059 T074

H003 T015 T030 T045 T060 T075

T001 07 T016 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 T018 T033 T048 T063 T078

T004 T019 T034 NARRATIVE 3 T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 151000 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) –‘07’ identifies the payment type as, ‘bulk list credit’.

• T013 (Payment currency) – This will always be ‘GBP’ for a bulk Inter Account Transfer.

• T014 (Payment Amount) – No leading spaces are required when entering the payment amount and the decimal point is necessary only where the amount requires it. The payment amount is in

the currency quoted in field T013.

• T022 (Account with Bank identifier) – The value ‘151000’ is the UK Sterling sort code 15-10-00.

• T028 (Beneficiary account Number) – This is the beneficiary account Number held at the account with Bank identifier quoted in field T022.

• T034 (Beneficiary reference) – Not a mandatory field. This is the individual ‘narrative’ that will be marked against the credit account (if the IAT bulk list credit is not used). In this case, a value of

‘Narrative 3’ will be used instead of ‘Narrative 2’ (previously specified on the IAT bulk list credit).

Bankline import file layout guide – Bankline (CSV) format

4.10 Ad hoc bulk payment

Debit - This example shows how to format an import record for an ad hoc bulk payment with a single beneficiary.

,,,08,,,,,PAYROLLSEP,,,,15100031806542,,,,,,01102006,,,,,,,,,,,,,,,,,,PAYROLL,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 T028 T043 T058 T073

H002 T014 T029 T044 T059 T074

H003 T015 T030 T045 T060 T075

T001 08 T016 01102006 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 T018 T033 T048 T063 T078

T004 T019 T034 PAYROLL T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 PAYROLLSEP T021 T036 T051 T066 T081

T007 T022 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 15100031806542 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) and T002 (Template indicator) – The value ‘08’ in field T001 identifies the payment type as a ‘ad hoc bulk payment debit’.

• T006 [Customer payment reference] – Identifies the payment as it will be known to the remitter. If left balnk defaults to the first 16 characters of the import file name.

• T010 (Debit account identifier) – The value ‘15100031806542’ is a UK Sterling account with sort code 15-10-00 and account number 31806542. No dashes or spaces are required when

entering the sort code, or between the sort code and the account number. The debit account must be a valid account as registered to that customer in Bankline.

• T016 (Date payment to Arrive / Credit Date) - The value ‘01102006’ equates to 1 October 2006.

beneficiary is given their own reference (as specified on the standard domestic bulk payment credit) then that will override any reference supplied here.

Bankline import file layout guide – Bankline (CSV) format

Credit

When importing an ad hoc bulk payment, one or more consecutive ad hoc bulk credit payments must be imported at the same time. This is because each ad hoc bulk payment must have at least one

beneficiary.

,,,09,,,,,,,,,,,,GBP,1566.23,,,,,,,,151000,,,,,,31803654,,MR JOHN SMITH,,,,PAYROLL 01,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,

This can be broken down to illustrate how each field tag on the import record has been populated.

Field Value Field Value Field Value Field Value Field Value Field Value

H001 T013 GBP T028 31803654 T043 T058 T073

H002 T014 1566.23 T029 T044 T059 T074

H003 T015 T030 MR JOHN SMITH T045 T060 T075

T001 09 T016 T031 T046 T061 T076

T002 T017 T032 T047 T062 T077

T003 T018 T033 T048 T063 T078

T004 T019 T034 PAYROLL 01 T049 T064 T079

T005 T020 T035 T050 T065 T080

T006 T021 T036 T051 T066 T081

T007 T022 151000 T037 T052 T067 T082

T008 T023 T038 T053 T068

T009 T024 T039 T054 T069

T010 T025 T040 T055 T070

T011 T026 T041 T056 T071

T012 T027 T042 T057 T072

Bankline import file layout guide – Bankline (CSV) format

• T001 (Record type) – The value ‘09’ identifies the payment type as ‘ad hoc bulk payment credit’.

• T013 (Payment currency) – This will always be ‘GBP’ for a standard domestic bulk payment.

• T014 (Payment Amount) – No leading spaces are required when entering the payment amount and the decimal point is necessary only where the amount requires it. The payment amount is in

the currency in field T013.

• T022 (account with Bank identifier) – The value ‘151000’ is the UK Sterling sort code 15-10-00.

• T028 (Beneficiary account Number) – This is the beneficiary account Number held at the account with Bank identifier in field T022.

• T030 (Beneficiary name and address Line number 1) – This is the name of the beneficiary customer linked to the beneficiary account Number quoted in field T028.

• T034 [Beneficiary reference] - Identifies the payment as it will be known to the beneficiary. If left blank, field T034 defaults to the debit account name as held in Bankline for the Debit Account

identifier (field T010).

5. Glossary of terms

We’ve used these terms and abbreviations throughout this document

Term / Abbreviation Definition

Bacs Bank automated clearing system

Bacs payment Schemes Limited is the company responsible for the processing of standard

electronic payments within the UK.

The Bacs payment system operates in a 3-day cycle, whereby payments are originated,

processed and settled on a day in the payment lifecycle.

BIC Bank Identification Code

This is the structured code used by SWIFT to uniquely identify a financial institution, its

country of operation, and its branches.

Bulk IAT Bulk Inter Account Transfer

A single debit, multiple credit Inter Account Transfer made from a bulk list.

Domestic Domestic payments are those that are made to a beneficiary who is domiciled within the UK

(or the Isle of Man, Jersey, Guernsey or Gibraltar).

Faster Payment A near real time Sterling transfer between banks.

A Faster Payment may be classed as an immediate payment, a future dated payment or

standing order.

IAT Inter Account Transfer

A payment made by a customer from one of their own accounts to another of their accounts

held with the same bank.

IAT bulk list Inter Account Transfer bulk list

A bulk list that is used to make single debit, multiple credit Inter Account Transfers.

NCC National Clearing Code

The standard identification code for a country, used to uniquely identify a bank, branch or

other financial institution (e.g. a Sort Code in the UK or a Fedwire Number in the United

States of America).

RBSG The Royal Bank of Scotland Group

Sort Code The UK’s national clearing code used to uniquely label a bank, branch or other financial

institution. The sort code is registered in the Bacs industry database to show whether it is

valid for use on standard domestic or urgent domestic (CHAPS) payments.

SWIFT Society for Worldwide Interbank Financial Telecommunication

SWIFT operate and regulate the secure network used to transmit many of the inter-bank

electronic payment messages that will originate from Bankline.

National Westminster Bank Plc. Registered in England, No. 929027. Registered Oce: 135 Bishopsgate, London EC2M 3UR.

Authorised and regulated by the Financial Services Authority.

947559 6 11/08/2010 15:13

Generated at: Wed Aug 11 15:10:54 2010

Contents Natwest Bankline Import File Layout Guide CSV Format

Navigation menu

Versions of this User Manual:

Views

Navigation
