The latest addition to the NEAR A-Series all-weather loudspeaker family,

the new NEAR®A12 loudspeaker features a more powerful, more focused

driver complement for use in larger public spaces and with higher ambient

sound levels.

NEAR’s unique technologies have always produced the highest sound quality

in the most durable and reliable loudspeakers available. The A12’s rugged

construction resists water, snow, dust, salt spray, UV rays, and extreme

temperatures, making it the ideal choice for any outdoor application, including

theme and water parks, amphitheaters and athletic fields, seaside locations

and marine use.

The NEAR A12 is compatible with low-impedance and 70V systems, and is

rated for both 225 watts (@ 16-ohms) and 128 watts (@70V). NEAR’s Metal

Diaphragm Technology (MDT™) and Magnetic Liquid Suspension (MLS™)

make NEAR drivers extremely weather-resistant while still providing smooth,

accurate sound over the speaker’s entire coverage area.

Powerful Sound, Rugged Construction

©2009 Bogen Communications, Inc.

Specification subject to change.

54-9288-01A 1002

•16-ohm and 70V operation in one unit

•Purpose-built to be extremely durable

in all weather conditions

•225W of power at 16 ohms

•70V Power Taps: 128, 64, 32, 16, 8 watts

•Dual 6.5" anodized metal-alloy MDT ™ mid/bass speaker

cones are extremely stable in all environments

•Patented MLS™ Ferrofluid voice coil suspension replaces

distortion-causing mechanical spider and environmentally

seals magnet gap

•Dual-layer voice coil with separate inner and outer

windings for high output and ultra-low distortion

•Horn-loaded, 1" exit compression driver features a 1.9"

Mylar diaphragm for consistent long-term performance

•90°x 45°Horn delivers high-frequency pattern control

over the listening area

•Mineral-filled polypropylene cabinet

•Advanced polymer compound surrounds resist UV rays,

chemicals, and salt spray

•Gold-plated, rust-proof input connectors

•Heavy-gauge powder-coated stainless steel mounting

bracket with 180° swivel

•Model TMA812 Adjustable Tilt-Mount Adapter provides

wide selection of tilt angles (sold separately)

Frequency Response . . . . . . . . . . 55 Hz to 17.5 kHz

LF Driver . . . . . . . . . . . . . . . . . . . . . Dual Anodized Metal-Alloy

6.5-inch Cone Woofers

HF Driver . . . . . . . . . . . . . . . . . . . . . 1.9-inch Mylar Diaphragm with

Constant-Directivity Horn

Sensitivity (1W/1M) . . . . . . . . . . . . . 94.5 dBspl

Dispersion . . . . . . . . . . . . . . . . . . . 90° Horizontal, 45° Vertical

Impedance Ratings . . . . . . . . . . . . . Low (16 ohms) / High (70V)

Power Input (Max.) . . . . . . . . . . . . . 225W @ 16 ohms; 128W @ 70V

Power Settings (in watts) . . . . . . . . 70V: 128, 64, 32, 16, 8

Dimensions . . . . . . . . . . . . . . . . . . . 10-1/4" W x 17-7/8" H x 11-3/4" D

Product Weight . . . . . . . . . . . . . . . . 22 lb.

SPECIFICATIONS

NEAR A12 Features:

50 Spring Street, Ramsey, NJ 07446 USA

Tel: 201-934-8500 •Fax: 201-934-9832

www.bogen.com

1

2

3

4

5

6

7

8

9

10

11

A12 Rear Panel:

Input Terminals

ACCESSORY

TMA812

TILT-MOUNT

ADAPTER

Stainless Steel Construction,

Rust-resistant Hardware

1. DURABLE COMPOUND RUBBER CONE SURROUNDS

RESIST CHEMICALS

2. SPECIALLY ANODIZED METAL-ALLOY WOOFER CONES

3. HIGH-GAUSS FERROFLUID®DESIGNED TO PREVENT

OXIDATION IN THE MAGNET GAP AND TO KEEP THE

VOICE COIL COOL AND CLEAN

4. UNIQUE VENT COVERS SHED WATER YET ALLOW BASS

TUNING TO REMAIN ACCURATE AND POWERFUL.

5. HORN FLARE COLLECTS WATER FROM UPPER GRILLE

AND CHANNELS IT AWAY FROM HORN OPENING

6. HORN-LOADED COMPRESSION DRIVER WITH MYLAR

DIAPHRAGM IS EXCEPTIONALLY WEATHERPROOF

7. POLYPROPYLENE GRILLES WON’T RUST OR CORRODE

8. RUST-FREE STAINLESS STEEL, ALUMINUM, AND BRASS

HARDWARE THROUGHOUT

9. INPUT TERMINALS ARE GOLD-PLATED TO PREVENT

OXIDATION/CORROSION

10. MOLDED MINERAL-FILLED POLYPROPYLENE

ENCLOSURE WITH PATENTED RIB DESIGN

11. STAINLESS STEEL, POWDER-COATED

ADJUSTABLE MOUNTING BRACKET
