(En)(En)(En)

The Nikon Guide to Digital Photography

with the

DIGITAL CAMERA

Printed in Japan

Fuji Bldg., 2-3 Marunouchi 3-chome, TR4K09000201(11)

Chiyoda-ku, Tokyo 100-8331, Japan 6MA05111--

No reproduction in any form of this manual, in whole

or in part (except for brief quotation in critical articles

or reviews), may be made without written authoriza-

tion from NIKON CORPORATION.

Trademark Information

Apple, the Apple logo, Macintosh, Mac OS, Power Macintosh, PowerBook, and Quick

Time are registered trademarks of Apple Computer, Inc. Finder, Power Mac, iMac, and

iBook are trademarks of Apple Computer, Inc. Microsoft and Windows are registered

trademarks of Microsoft Corporation. Internet is a trademark of Digital Equipment

Corporation. Adobe and Acrobat are registered trademarks of Adobe Systems Inc. The

SD logo is a trademark of the SD Card Association. PictBridge is a trademark. D-Light-

ing technology is provided by Apical Limited. All other trade names mentioned in

this manual or the other documentation provided with your Nikon product are trade-

marks or registered trademarks of their respective holders.

Notices/For Your Safety

For Your Safety

To prevent damage to your Nikon product or injury to yourself or to others, read

the following safety precautions in their entirety before using this equipment.

Keep these safety instructions where all those who use the product will read them.

The consequences that could result from failure to observe the precautions listed

in this section are indicated by the following symbol:

WARNINGS

This icon marks warnings, information that should be read before using your

Nikon product to prevent possible injury.

Turn off immediately in the

event of malfunction

Should you notice smoke or an

unusual smell coming from the

equipment or from the AC adapter

(available separately), unplug the AC

adapter and remove the batteries

immediately, taking care to avoid

burns. Continued operation could

result in injury. After removing the

batteries, take the equipment to a

Nikon-authorized service center for

inspection.

Do not use in the presence of

flammable gas

Do not use electronic equipment in

the presence of flammable gas, as

this could result in explosion or fire.

Observe caution when using the

camera strap

Never place the strap around the

neck of an infant or child.

Do not disassemble

Touching the product's internal

parts could result in injury. In the

event of malfunction, the product

should be repaired only by a quali-

fied technician. Should the product

break open as the result of a fall or

other accident, take the product to a

Nikon-authorized service center for

inspection after unplugging the AC

adapter and removing the batteries.

Observe proper precautions

when handling batteries

Batteries may leak or explode if

improperly handled. Observe the fol-

lowing precautions when handling

batteries for use in this product:

•

Before replacing the batteries,

turn the camera off and make sure

the power-on lamp has gone out.

If you are using an AC adapter, be

sure it is unplugged.

•

Use a pair of rechargeable Nikon

EN-MH1 NiMH batteries, two ZR6

(AA) nickel manganese batteries,

LR6 (AA) alkaline batteries, or two

FR6/L91 (AA) lithium batteries. Do

not use other types of battery. Do

not mix batteries of different types.

• When inserting batteries, do not

attempt to insert them upside

down or backwards.

•

Do not short or disassemble batteries.

Notices/For Your Safety

• Do not expose batteries to flame

or to excessive heat.

•

Do not immerse in or expose to water.

•

Do not transport or store with metal

objects such as necklaces or hairpins.

•

Batteries are prone to leakage when

fully discharged. To avoid damage to

the product, be sure to remove the

batteries when no charge remains.

•

When the battery is not in use, at

tach the terminal cover and store in

a cool place.

•

Immediately after use, or when the

product is used on battery power

for an extended period, the batter-

ies may become hot. Before remov-

ing the batteries, turn the camera

off and allow the batteries to cool.

• Discontinue use immediately

should you notice any changes in

the batteries, such as discolora-

tion or deformation.

Use appropriate cables

When connecting cables to the

input and output jacks, use only the

cables provided or sold by Nikon for

the purpose, to maintain compli-

ance with product regulations.

Keep out of reach of children

Particular care should be taken to pre-

vent infants from putting the batteries

or other small parts into their mouths.

Removing memory cards

Memory cards may become hot during

use. Observe due caution when remov-

ing memory cards from the camera.

CD-ROMs

The CD-ROMs on which the software

and manuals are distributed should

not be played back on audio CD

equipment. Playing CD-ROMs on an

audio CD player could cause hearing

loss or damage the equipment.

Observe caution when operat-

ing the flash

Using the flash close to your sub-

ject's eyes could cause temporary

visual impairment. Particular care

should be observed if photograph-

ing infants, when the flash should

be no less than one meter (39″)

from the subject.

Avoid contact with liquid crystal

Should the monitor break, care

should be taken to avoid injury due

to broken glass and to prevent liq-

uid crystal from the monitor touch-

ing the skin or entering the eyes or

mouth.

iii

Notices/For Your Safety

Cautions

To ensure continued enjoyment of your Nikon product, observe the following

precautions when storing or using the device:

Keep dry

The device will be damaged if

immersed in water or subjected to

high levels of moisture.

Handle the lens and all moving

parts with care

Do not apply force to the lens or

lens cover, or to the connector, card

slot, or battery chamber covers.

These parts are especially suscepti-

ble to damage.

Turn the product off before

removing or disconnecting the

power source

Do not unplug the product or

remove the batteries while the

product is on, or while images are

being recorded or deleted. Forcibly

cutting power in these circum-

stances could result in loss of data

or in damage to product memory or

internal circuitry. To prevent an acci-

dental interruption of power, avoid

carrying the product from one

place to another while the AC

adapter (available separately) is

connected.

Do not drop

The product may malfunction if sub-

jected to strong shocks or vibration.

Keep away from strong mag-

netic fields

Do not use or store this device in

the vicinity of equipment that gen-

erates strong electromagnetic radia-

tion or magnetic fields. Strong static

charges or the magnetic fields pro-

duced by equipment such as radio

transmitters could interfere with the

monitor, damage data stored on the

memory card, or affect the prod-

uct's internal circuitry.

Avoid sudden changes in tem-

perature

Sudden changes in temperature,

such as occur when entering or leav-

ing a heated building on a cold day,

can cause condensation inside the

device. To prevent condensation,

place the device in a carrying case or

a plastic bag before exposing it to

sudden changes in temperature.

Do not point the lens at strong

light sources for extended peri-

ods

Avoid pointing the lens at the sun

or other strong light sources for

extended periods when using or

storing the camera. Intense light

may cause deterioration in the CCD

image sensor, producing a white

blur effect in photographs.

Notices/For Your Safety

Notices

•

No part of the manuals included with

this product may be reproduced, trans-

mitted, transcribed, stored in a retrieval

system, or translated into any language

in any form, by any means, without

Nikon's prior written permission.

• Nikon reserves the right to change the

specifications of the hardware and

software described in these manuals at

any time and without prior notice.

• Nikon will not be held liable for any

damages resulting from the use of this

product.

•

While every effort has been made to

ensure that the information in these

manuals is accurate and complete, we

would appreciate it were you to bring

any errors or omissions to the attention

of the Nikon representative in your

area (address provided separately).

Notice for customers in the U.S.A.

Federal Communications Commission (FCC) Radio Frequency Interference Statement

This equipment has been tested and found to

comply with the limits for a Class B digital de-

vice, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reason-

able protection against harmful interference in

a residential installation. This equipment gen-

erates, uses, and can radiate radio frequency

energy and, if not installed and used in accor-

dance with the instructions, may cause harm-

ful interference to radio communications.

However, there is no guarantee that interfer-

ence will not occur in a particular installation.

If this equipment does cause harmful interfer-

ence to radio or television reception, which

can be determined by turning the equipment

off and on, the user is encouraged to try to

correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equip-

ment and receiver.

• Connect the equipment into an outlet on a

circuit different from that to which the re-

ceiver is connected.

• Consult the dealer or an experienced radio/

television technician for help.

CAUTIONS

Modifications

The FCC requires the user to be notified that

any changes or modifications made to this de-

vice that are not expressly approved by Nikon

Corporation may void the user's authority to

operate the equipment.

Interface Cables

Use the interface cables sold or provided by Ni-

kon for your equipment. Using other interface

cables may exceed the limits of Class B Part 15

of the FCC rules.

Notice for customers in the State of California

WARNING: Handling the cord on this product will expose you to lead, a chemical known to the

State of California to cause birth defects or other reproductive harm. Wash hands after handling.

Nikon Inc.,

1300 Walt Whitman Road, Melville, New York

11747-3064, U.S.A.

Tel.: 631-547-4200

E5600/E4600

FOR HOME OR OFFICE USE

Tested To Comply

With FCC Standards

Notices/For Your Safety

Notice for customers in Canada

CAUTION

This class B digital apparatus meets all

requirements of the Canadian Interfer-

ence Causing Equipment Regulations.

ATTENTION

Cet appareil numérique de la classe B re-

specte toutes les exigences du Règlement

sur le matériel brouilleur du Canada.

Notice Concerning Prohibition of Copying or Reproduction

Note that simply being in possession of material that has been digitally copied or repro-

duced by means of a scanner, digital camera or other device may be punishable by law.

• Items prohibited by law from

being copied or reproduced

Do not copy or reproduce paper

money, coins, securities, govern-

ment bonds, or local government

bonds, even if such copies or repro-

ductions are stamped "Sample."

The copying or reproduction of

paper money, coins, or securities

which are circulated in a foreign

country is prohibited.

Unless the prior permission of the

government has been obtained, the

copying or reproduction of unused

postage stamps or post cards issued

by the government is prohibited.

The copying or reproduction of

stamps issued by the government

and of certified documents stipu-

lated by law is prohibited.

• Cautions on certain copies and

reproductions

The government has issued cautions

on copies or reproductions of securi-

ties issued by private companies

(shares, bills, checks, gift certificates,

etc.), commuter passes, or coupon

tickets, except when a minimum of

necessary copies are to be provided

for business use by a company.

Also, do not copy or reproduce pass-

ports issued by the government,

licenses issued by public agencies and

private groups, ID cards, and tickets,

such as passes and meal coupons.

• Comply with copyright notices

The copying or reproduction of

copyrighted creative works such as

books, music, paintings, woodcut

prints, maps, drawings, movies, and

photographs is governed by

national and international copyright

laws. Do not use this product for the

purpose of making illegal copies or

to infringe copyright laws.

Notices/For Your Safety

Before Taking Important Pictures

Before taking pictures on important occasions (such as at weddings or before

taking the camera with you on a trip), take a test shot to ensure that the camera

is functioning normally. Nikon will not be held liable for damages or lost profits

that may result from product malfunction.

Use Only Nikon Brand Electronic Accessories

Your Nikon COOLPIX camera is designed to the highest standards and includes

complex electronic circuitry. Only Nikon brand electronic accessories (including

battery chargers, batteries, and AC adapters) certified by Nikon specifically for

use with your Nikon digital camera are engineered and proven to operate within

the operational and safety requirements of this electronic circuitry.

THE USE OF NON-NIKON ELECTRONIC ACCESSORIES COULD DAMAGE YOUR CAMERA AND MAY

VOID YOUR NIKON WARRANTY.

For more information about Nikon brand accessories, contact your local autho-

rized Nikon dealer.

Design Rule for Camera File System (DCF)

Your camera conforms to the Design Rule for Camera File System (DCF), a stan-

dard widely used in the digital camera industry to ensure compatibility among

different makes of camera.

Exif Version 2.2

Your camera supports Exif (Exchangeable Image File Format for Digital Still Cam-

eras) version 2.2, a standard that allows information stored with pictures to be

used for optimal color reproduction when images are output on Exif-compliant

printers.

vii

Table of contents

For Your Safety ............................................................................................... i

Cautions ........................................................................................................iii

Notices ..........................................................................................................iv

Before You Begin........................................................................1

Introduction ................................................................................................... 1

Parts of the Camera........................................................................................2

The Monitor ................................................................................................... 4

The Mode Dial................................................................................................6

Navigating the Menus .................................................................................... 7

The Shutter-Release Button ............................................................................ 7

First Steps....................................................................................8

Inserting Batteries........................................................................................... 8

Inserting Memory Cards ...............................................................................10

Checking the Battery Level ........................................................................... 12

Basic Setup................................................................................................... 14

Basic Photography ....................................................................16

Step 1 - Select P (auto) Mode...................................................................16

Step 2 - Frame the Picture ............................................................................ 18

Step 3 - Focus and Shoot.............................................................................. 20

Step 4 - View the Results (Full-screen Playback Mode)...................................22

More on Photography..............................................................24

When Lighting Is Poor: Using the Flash ......................................................... 24

Taking a Self-Portrait: Using the Self-Timer ................................................... 26

Easy Close-ups: Macro Close-up Mode ......................................................... 27

Assist and Scene Modes ...............................................................................28

Framing Assist .............................................................................................. 30

e Scene Mode ......................................................................................... 35

More on Playback .....................................................................42

Viewing Pictures on the Camera................................................................... 42

Cropping Pictures ..................................................................................... 44

Adjusting a picture tone automatically...................................................... 45

Voice Memos: Recording and Playback (E5600 only)................................. 47

Viewing Pictures on TV.................................................................................48

Viewing Pictures on a Computer................................................................... 49

Printing Pictures............................................................................................ 52

Printing Via Direct USB Connection............................................................... 56

Movies .......................................................................................60

W Recording Movies ................................................................................... 60

Viewing Movies............................................................................................64

viii

The Shooting Menu ..................................................................65

Using the Shooting Menu............................................................................. 65

Image Mode................................................................................................. 67

White Balance ..............................................................................................69

Exp. +/- ........................................................................................................ 71

Continuous .................................................................................................. 72

Best Shot Selector......................................................................................... 73

Color Options............................................................................................... 74

The Playback Menu...................................................................75

Using the Playback Menu ............................................................................. 75

Slide Show ................................................................................................... 77

Delete .......................................................................................................... 78

Protect ......................................................................................................... 80

Transfer Marking.......................................................................................... 81

Small Picture................................................................................................. 83

Copy ............................................................................................................ 84

The Set-up Menu ......................................................................87

Using the Set-up Menu................................................................................. 87

Welcome Screen........................................................................................... 89

Date............................................................................................................. 90

Monitor Settings........................................................................................... 92

Date Imprint................................................................................................. 93

Sound Settings ............................................................................................. 94

Blur Warning................................................................................................95

Auto Off....................................................................................................... 96

Format memory/card .................................................................................... 97

Language ..................................................................................................... 99

Interface....................................................................................................... 99

Auto Transfer ............................................................................................. 100

Reset All..................................................................................................... 100

Battery Type ............................................................................................... 102

Menus........................................................................................................ 103

Firmware Version........................................................................................ 104

Technical Notes.......................................................................105

Optional Accessories................................................................................... 105

Caring for Your Camera .............................................................................106

Error Messages........................................................................................... 108

Troubleshooting ......................................................................................... 111

Specifications ............................................................................................. 114

Index.......................................................................................................... 116

Before You Begin

Introduction

Thank you for your purchase of a Nikon COOLPIX5600 (E5600)/COOLPIX4600

(E4600) digital camera. This manual has been written to help you enjoy taking

pictures with your Nikon digital camera. Read this manual thoroughly before use,

and keep it handy when using the product.

To make it easier to find the information you need, the following symbols and

conventions are used:

Illustrations and on-screen text in this manual may differ from the actual display.

Internal Memory and SD Memory Card

This camera uses both an internal memory and an SD memory card for storing

pictures. If you insert a card into the camera, pictures will automatically be stored

on the card instead of in the memory. To store, view or delete pictures in the

memory or to format the memory, remove the memory card first.

Life-Long Learning

As part of Nikon's "Life-Long Learning" commitment to ongoing product support and education,

continually-updated information is available on-line at the following sites:

• For users in the U.S.A.: http://www.nikonusa.com/

• For users in Europe: http://www.europe-nikon.com/support/

• For users in Asia, Oceania, the Middle East, and Africa: http://www.nikon-asia.com/

Visit these sites to keep up-to-date with the latest product information, tips, answers to fre-

quently-asked questions (FAQs), and general advice on digital imaging and photography.

Additional information may be available from the Nikon representative in your area. See the

URL below for contact information:

http://nikonimaging.com/

This icon marks cautions,

information you should read

before use to prevent damage

to your camera.

This icon marks tips, addi-

tional information you may

find helpful when using your

camera.

This icon marks notes, infor-

mation that you should read

before using your camera.

This icon indicates that more

information is available else-

where in this manual or in the

Quick Start Guide.

Before You Begin

Parts of the Camera

Shutter-release button (Q 7)

Power switch

(Q 12)

Viewfinder

(Q 18)

Built-in Speedlight

(Q 24)

Self-timer lamp

(Q 26)

Lens (Q 18)

Power-on lamp (Q 12)

Attaching the Camera Strap

Memory card slot

cover (Q 10)

Eyelet for

camera strap

Microphone (E5600 only) (Q 47)

Power connector cover

for AC adapter

Parts of the Camera

Before You Begin

Zoom (l/O ) buttons (Q 18)

Red (!) lamp (Q 20)

Monitor

(Q 5, 18)

Battery-chamber

cover (Q 8)

Mode dial (Q 6)

USB connector (

50, 56)

Audio/video (AV) out

connector (E5600 only) (

48)/

Video output connector

(E4600 only) (Q 48)

Interface connector cover

(Q 48, 50)

Tripod socket (Q 25, 26)

(delete) button

(Q 22, 23)

Viewfinder

(Q 18)

Multi selector

(!/Y/&/V)

(Q 7)

x(play) button

(Q 22)

Battery-chamber

cover latch (Q 8)

Interface connector cover

Green (AF) lamp

(Q 20)

Menu button (Q 65, 75)

Speaker

(E5600 only)

Before You Begin

The Monitor

Shooting

1Shooting mode . . . . . . . . . . . . . 16 12 Number of exposures remaining/

length of movie. . . . . . . . 16, 17, 60

2AE-L1. . . . . . . . . . . . . . . . . . . . . 40

3Focus indicator2. . . . . . . . . . . . . 20 13 Flash mode . . . . . . . . . . . . . . . . . 24

4Zoom indicator2. . . . . . . . . . . . . 18 14 Image mode . . . . . . . . . . . . . . . . 67

5Battery level indicator3. . . . . . . . 12 15 Exposure compensation . . . . . . . 71

6Internal memory/memory card

indicator. . . . . . . . . . . . . . . . . . . 16

16 Sensitivity gain indicator6 . . . . . .25

17 Continuous shooting mode. . . . .72

7Camera shake icon4. . . . . . . . . . 25 18 Best Shot Selector (BSS). . . . . . . .73

8"Date not set" icon5 . . . . . . . . . 14 19 White balance . . . . . . . . . . . . . . .69

9Time zone . . . . . . . . . . . . . . . . . 91 20 Color options . . . . . . . . . . . . . . . 74

10 Self-timer indicator. . . . . . . . . . . 26 21 Macro close-up mode . . . . . . . . .27

11 Date imprint indicator . . . . . . . . 93

Appears when taking pictures with Panorama

Assist.

Displayed when zoom buttons are pressed.

Appears when batteries are running low.

Appears at slow shutter speeds to warn that

pictures may be blurred.

Appears when camera clock has not been set.

Indicates that camera has raised sensitivity

automatically.

AE-L

999

AUTO

+1.0

134

1213

16 10

The Monitor

Before You Begin

Playback

Controlling the Monitor

To hide or display indicators in the monitor, select the Photo info option in the MONITOR SET-

TINGS menu. (Q 92)

Monitor turns off while flash is charging (Q 20).

2005

100NIKON

0008

JPG

0008

JPG

START

1Current folder . . . . . . . . . . . . . . 23 9Movie playback indicator . . . . . . 64

2File number and type . . . . . . . . . 23 10 Voice memo icon2 . . . . . . . . . . . 47

3Internal memory/memory card

indicator . . . . . . . . . . . . . . . . . . 16

11 Image mode. . . . . . . . . . . . . . . . 67

12 Movie indicator . . . . . . . . . . . . . 61

4Battery level indicator1. . . . . . . . 12 13 Protect icon . . . . . . . . . . . . . . . . 80

5Volume indicator2 . . . . . . . . . . . 64 14 Print-order icon . . . . . . . . . . . . . 52

6Voice memo recording guide2 . . .47 15 Transfer icon . . . . . . . . . . . . . . . 81

7Voice memo playback guide2. . . 47 16 Time of recording. . . . . . . . . .14-15

8Current frame number/total number

of frames/length of movie. . . .23, 64

17 Date of recording. . . . . . . . . .14-15

Appears when batteries are running low.

E5600 only.

AUTO

Monitor shows view

through lens only

Monitor off

Monitor shows current settings

and view through lens

Before You Begin

The Mode Dial

Using the mode dial, you can select from seven shooting modes and setup mode.

Choose a shooting mode according to shooting conditions.

To select a mode, align the mode icon with the "J" mark

next to the mode dial.

e Scene (Q 28, 35)

Choose from twelve "scenes"

suited to different subjects or

shooting conditions and let the

camera do the rest.

i Portrait Assist

N Landscape Assist

j Sports Assist

m Night Portrait Assist

Use framing assist to help compose

pictures suited to a particular type

of subject (

28-34).

P Auto (Q 16)

Choose this mode to take pictures.

Select from six shooting menus to

achieve the desired effect.

W Movie (Q 60-64)

Choose from three kinds of movies.

Make movies with sound using the

E5600, or using E4600 for silent

movies only.

f Setup (Q 87)

Choose this mode to display the SET-

UP menu, where you can perform

such tasks as setting the camera clock

and adjusting monitor brightness.

Before You Begin

Navigating the Menus

The multi selector is used to navigate through the camera menus.

Your camera has a two stage shutter-release button. The camera sets focus and

exposure when the button is pressed halfway. The green (AF) lamp next to the

viewfinder will light when the focus operation is complete. Focus and exposure

will remain locked while the shutter-release button is pressed halfway. To take

the picture, press the shutter-release button the rest of the way down.

Move cursor up.

Cancel and return to previous

menu, or move cursor left.

Move cursor down.

Display sub-menu,

move cursor right,

or make selection.

Press center (I) to

make selection.

The Shutter-Release Button

First Steps

Inserting Batteries

Your camera uses:

• LR6 (AA) alkaline batteries (×2), or

• Nikon EN-MH1 rechargeable nickel-metal hydride (NiMH) batteries (×2), or

• ZR6 (AA) nickel manganese batteries (×2), or

• FR6/L91 (AA) lithium batteries (×2)

Open the battery-chamber cover

• Slide the battery-chamber cover latch as illus-

trated (c), pull the battery-chamber cover (d)

and open (e).

Insert the batteries

• Insert the batteries as shown in the label inside

the battery chamber.

Close the battery-chamber cover

• Close the battery-chamber cover (c) and slide

it in until it latches (d). Be sure that the bat-

tery-chamber cover is properly latched.

[IMPORTANT] Battery Type

To improve battery performance, select the type of battery currently inserted in the camera in the

SET-UP menu. The default setting is the type of the included batteries. When any other type of bat-

tery is used, turn the camera on and change the setting (

102).

AA batteries

Inserting Batteries

First Steps

Replacing Batteries

Turn the camera off and make sure that the power-on lamp has gone out before removing or in-

serting batteries.

Read Battery Warnings

Read and follow all warnings and instructions supplied by the battery manufacturer.

Damaged Batteries

The following batteries can not be used:

• Batteries with peeling or damaged insulation. Using batter-

ies with damaged insulation could result in leakage, over-

heating, or rupture. Note that due to manufacturing

defects even new batteries may have faulty insulation.

• Batteries with insulation that covers only the sides of the

battery and not the area around the negative terminal.

• Batteries with a flat negative terminal. Do not use such bat-

teries even if the insulation adequately covers the area

around the negative terminal.

Alkaline Batteries

Performance of alkaline batteries may vary greatly depending on the manufacturer. Choose a reli-

able brand.

EN-MH1 Batteries

Using an MH-71 battery charger, charge EN-MH1 batteries before first use. Charge each pair of

batteries at the same time — do not charge batteries one at a time or mix batteries with different

charges. Note that EN-MH1 batteries may discharge quickly immediately after purchase or after the

batteries have been left unused for an extended period. This is normal, and the batteries will retain

a charge for longer periods after being used and recharged several times. For more information on

charging batteries, see the documentation provided with the MH-71.

Alternative Power Sources

To power the camera continuously for extended periods, use an EH-62B AC adapter (Q 105). Do

not, under any circumstances, use another make or model of AC adapter. Failure to observe

this precaution could result in overheating or in damage to the camera.

First Steps

Inserting Memory Cards

Pictures can be stored in the camera's internal memory (about 14 MB) or on Se-

cure Digital (SD) memory card. If no memory card has been inserted in the cam-

era, pictures will be stored in the memory, and if the camera contains a memory

card, then pictures will automatically be stored on the card.

To store pictures in the internal memory, remove the memory card.

Confirm that the camera is off

• The power-on lamp should be off.

Open the memory card slot cover

Insert the memory card

• Insert the memory card in the direction of the

arrow as shown. Insert straight without bend-

ing.

Inserting Memory Cards

Insert the memory card terminals first.

Inserting the card upside down or backwards could

damage the camera or the card. Check to be sure the

card is in the correct orientation.

Close the memory card slot cover

Front

Direction

of insertion

Terminals

Inserting Memory Cards

First Steps

Formatting Memory Cards

Memory cards must be formatted before first use. For information on formatting memory cards,

see "The SET-UP Menu: Format memory/card" (Q 97, 98).

Removing Memory Cards

Memory cards can be removed without loss of data when the

camera is off. To remove memory cards, turn the camera off

and confirm that the power-on lamp is off. Do not open the

memory card slot cover while the power-on lamp is lit.

Open the memory card slot cover and press the memory card

to partially eject the card. The card can then be removed by

hand.

Memory Cards

• Use only Secure Digital (SD) memory cards.

• Do not disassemble or modify.

• Do not drop, bend, or expose to water or strong physical shocks.

• Do not touch the metal terminals with your fingers or metal objects.

• Do not affix labels or stickers to the memory card.

•Do not leave in direct sunlight in a closed vehicle or in other areas exposed to high

temperatures.

• Do not expose to high levels of humidity or to corrosive gas.

The Write Protect Switch

SD cards are equipped with a write protect switch to prevent accidental loss of data. When this

switch is in the "lock" position, pictures can not be recorded, deleted, or edited, and the card can

not be formatted. Do not lock the card when taking, deleting, or editing pictures.

Write protect switch

When card is locked, pictures can be

played back but can not be recorded,

deleted, edited, or transferred using the

camera I (V) button.

First Steps

Checking the Battery Level

Turn the camera on

• Press the power switch. The power-on lamp

will light. Rotate the mode dial to a setting

other than f.

Check the battery level in the monitor

• When the camera is turned on for the first time,

a language selection dialog will be displayed.

Choose the desired language and press

(the

center of multi selector). See "First Steps: Basic

Setup" (

14).

• Before checking the battery level, select the

appropriate Battery type option in the SET-

UP menu (Q 102).

The red (!) and green (AF) lamps will blink when

the "BATTERY EXHAUSTED" warning is displayed.

The x Button

The camera can also be turned on by pressing the x button for about a second. Your most

recent picture will be displayed in the monitor (Q 22).

Display Meaning

NO ICON Batteries fully charged.

XLow battery.

WARNING!!

BATTERY

EXHAUSTED

Batteries exhausted.

Replace with new or fully charged

batteries.

AUTO

Checking the Battery Level

First Steps

Turning the Camera Off

To turn the camera off, press the power switch when the power-on lamp is lit. Do not remove the

batteries or disconnect the EH-62B AC adapter until the power-on lamp has gone out.

The Power-on Lamp

Auto Power Off (Standby Mode)

If no operations are performed for one minute (default setting), the monitor will turn off automat-

ically and the camera will enter standby mode to reduce the drain on the batteries. While the cam-

era is in standby mode, the power-on lamp will blink. If no operations are performed for three

minutes after the camera enters standby mode, the camera will turn off automatically and the

power-on lamp will go out. The camera will be reactivated from standby mode when you:

• Press the power switch

• Press the shutter-release button halfway

• Press the x button to view the last picture taken

• Press ^ button to display the menu for the current mode

• Rotate the mode dial to select a new mode

The length of time before the camera enters standby mode can be changed using the Auto

off option in the SET-UP menu (Q 96). However, when a menu or the SET-UP menu is dis-

played, the monitor will turn off after three minutes, and when pictures are being shown in

a non-stop slide show (Q 77) or when the camera is powered by an AC adapter, the mon-

itor will turn off after thirty minutes.

Sleep Mode

Turning sleep mode on will cause the camera to enter standby mode when there is no change in

the brightness of the subject, even before the time selected in the AUTO OFF menu has elapsed

(Q 96).

When the power on lamp is The camera is

On On

Blinking In standby mode

Off Off

First Steps

Basic Setup

The first time the camera is turned on, a language-selection dialog will be displayed in

the monitor. Follow the steps below to choose a language and set the time and date.

The Clock Battery

When the main batteries are installed or the camera is powered by an AC adapter, the clock battery

will charge in about ten hours. When fully charged, the clock battery can provide several days of

back-up power.

Highlight Yes and press I.

TIME ZONE menu displayed.

†

Display map of world time zones.

†

To turn daylight saving time on or off, press the multi selector down to high-

light DaylightSaving and press I. When DaylightSaving is checked, time

will automatically be advanced one hour (Q

91). To return to Step 3, press

the multi selector up to highlight current time zone.

Set

Cancel

Yes

Set time and date?

DATE

Set

DaylightSaving

TIME ZONE

Set

London, Casablanca

1. 2005.

Highlight

Deutsch

(German),

English

Español

(Spanish),

Français

(French),

Italiano

(Italian),

Nederlands

(Dutch),

Svenska

(Swedish), (Japanese),

(Simplified Chinese),

(Traditional Chinese) or (Korean)

and press

(the center of the multi se-

lector).

Select No to exit to mode currently se-

lected with mode dial. If you exit without

setting time and date, Z ("date not

set") icon will flash in monitor when

camera is in shooting mode and all pic-

tures will have time stamp of

"0000.00.00 00:00" (still images) or

"2005.01.01 00:00" (movies).

Set

Back

HOME TIME ZONE

London, Casablanca

Basic Setup

First Steps

Setting the Clock from PictureProject (Windows XP/Mac OS X Only)

If the camera is connected with the

USB

option set to

PTP

(

49), PictureProject (included) can be used to set

the camera clock to the same time and date as the computer. See the

PictureProject Reference Manual

for details.

Select home time zone.

Edit Day (order of Day, Month, and

Year may differ in some areas).

Highlight D M Y.

Display DATE menu.

Select Month. Repeat steps 8–9 to edit

Month, Year, hour, and minute.

Choose order in which Day, Month,

and Year will be displayed.

Exit to mode currently selected with

mode dial. Note that time and date of

recording will not be imprinted on pic-

tures unless Date or Date and time is

selected for Date imprint option

(Q93).

Set

Back

HOME TIME ZONE

London, Casablanca

0 : 0

Set

DATE

2005

YMD

13 : 0

0

Set

DATE

2005

YMD

AUTO

0 : 0

Set

DATE

2005

YMD

0 : 0

Set

DATE

2005

YMD

13 : 0

Set

DATE

2005

YDM

Basic Photography

Step 1 - Select P Mode

This section details the basic steps involved in taking pictures in P (auto) mode.

In this automatic, "point-and-shoot" mode, the majority of camera settings are

controlled by the camera in response to shooting conditions, producing optimal

results in most situations.

Rotate the mode dial to P

Turn the camera on

• The power-on lamp will light and the monitor

will display a welcome screen (Q 89). The

camera is ready to shoot when the monitor

shows the view through the camera lens.

AUTO

Image mode

Choose from five options depend-

ing on how you plan to use the pic-

ture (

67). The default setting is

(E5600) or

(E4600).

Shooting mode/scene mode

P indicates auto mode.

Flash mode

Choose from five modes de-

pending on lighting and your

creative intent (Q 24). The de-

fault setting is !# (auto).

Number of exposures remaining

The number of pictures that can be stored

depends on the capacity of the memory or

memory card and the option chosen for

Image mode (Q

Memory/memory card

When the camera contains a

memory card, / is displayed,

and when there is no card in

the camera, } is displayed.

Step 1 - Select P Mode

Basic Photography

Number of Exposures Remaining

If the number of exposures remaining is zero, the message "OUT OF MEMORY" will be displayed

in the monitor. No further pictures can be taken until you:

• choose a lower Image mode setting (Q

)

• insert a new memory card (Q10)

• delete some pictures (Q22-23, 78-79)

Shooting Menu

Pressing ^ button in P (auto) mode displays the SHOOTING MENU (Q 65). Using the SHOOT-

ING MENU, Image mode (Q 67), White balance (Q 69), Exp. +/- (Q 71), Continuous (Q 72),

BSS (Q 73) or Color options (Q 74) options are available for your shooting purpose.

Basic Photography

Step 2 - Frame the Picture

Ready the camera

Hold the camera steadily in both hands. Photo-

graphs can be framed in the monitor or the

viewfinder.

Frame your subject

Your Nikon digital camera is equipped with two

types of built-in zoom: optical zoom, in which the

camera's telescoping lens can be used to magnify the

subject up to 3 ×, and digital zoom, in which digital

processing is used to further magnify the image up

to 4 ×, for a total of 12 ×. Use the zoom buttons to

frame your subject in the center of the monitor:

• Press the l (W) button to zoom out from

your subject, increasing the area visible in the

frame.

• Press the O (T) button to zoom in on your sub-

ject so that it fills a larger area of the frame.

• When the camera is zoomed in to maximum

magnification, holding the O (T) button down

for about one second will trigger digital zoom.

The zoom indicator will turn yellow, and the

green (AF) lamp next to the viewfinder will

blink. Use the O (T) and l (W) buttons to ad-

just zoom in the digital zoom range. To cancel

digital zoom, press l (W) until the zoom in-

dicator turns white.

Don't Block the Shot

To avoid dark or partially obscured pictures, keep

your fingers and other objects away from the

lens, flash window and microphone (E5600 only).

Zoom out Zoom in

AUTO

Indicator in monitor shows

amount of zoom when ei-

ther button is pressed

Digital zoom

Step 2 - Frame the Picture

Basic Photography

Digital Zoom

In digital zoom, data from the camera's image sensor are processed digitally, enlarging the center

portion of the picture to fill the frame. Unlike optical zoom, digital zoom does not increase the

amount of detail visible in the picture. Instead, details visible at maximum optical zoom are simply

enlarged, producing a slightly "grainy" image. Note that the effects of digital zoom are not visible

in the viewfinder - use the monitor when framing pictures with digital zoom. Digital zoom is not

available when the monitor is off or when Multi-shot 16 is selected in the CONTINUOUS menu

(Q 72).

When Lighting Is Poor

When lighting is poor, sensitivity is raised to compensate and the image in the monitor may be

slightly mottled. This is normal and does not indicate a malfunction.

Monitor or Viewfinder?

Use the monitor to confirm camera settings at a glance while at the same time viewing an image

that shows how the final picture will appear. This is particularly useful when the image in the view-

finder does not accurately reflect what will appear in the final picture, for example when:

• your subject is less than a meter (3´3”) from the camera

• digital zoom is in effect

Use the viewfinder when you want to save power by turning the monitor off (Q5), or when

bright ambient lighting makes it difficult to see the display in the monitor.

Basic Photography

Step 3 - Focus and Shoot

Focus

Press the shutter-release button halfway to set

focus and exposure. In P mode, the camera

will automatically focus on the subject at the

center of the frame. Focus and exposure will

lock while the shutter-release button is pressed

halfway.

With the shutter-release button pressed half-

way, check focus and flash. Focus is indicated by

the green AF (autofocus) lamp next to the view-

finder and by the focus indicator in the monitor.

Flash status is indicated by the red ! (flash-

ready) lamp next to the viewfinder.

Monitor turns off while flash is charging.

Take the picture

Press the shutter-release button the rest of the

way down to take the picture. The shutter

sound is played when the shutter-release button

is pressed (default setting Q 94). To prevent

blur, press the shutter-release button down

smoothly. You can choose whether or not to

display the camera shake warning (Q 25).

On Flash will fire when picture is

taken.

Blinks Flash charging. Wait until lamp

comes on.

Off Flash off or not required.

On Subject in focus.

Flashes

Camera unable to focus on sub-

ject at center of frame. Using

focus lock, focus on another

subject at same distance, then

recompose picture and shoot.

AUTO

Red (!) lamp

Green (AF) lamp

Focus indicator

Red (!) lamp Green(AF)lamp/

focus indicator

Step 3 - Focus and Shoot

Basic Photography

During Recording

While pictures are being recorded to the memory or memory card, the green (AF) lamp blinks, and

the < icon lights or the memory icon }// blinks. You can continue to take pictures until the <

icon is displayed. Do not turn the camera off, eject the memory card, or remove or discon-

nect the power source while picture are being recorded. Cutting power or removing the

memory card in these circumstances could result in loss of data or in damage to the camera or card.

Getting Good Results with Autofocus

Autofocus performs best when there is contrast between the subject and the background and the

subject is evenly lit. It does not perform well if the subject is very dark or moving rapidly, if there are

objects of sharply differing brightness in the scene (e.g., the sun is behind your subject and their

features are in deep shadow), or if there are several objects at different distances from the camera

at the center of the frame (e.g., your subject is inside a cage).

Focusing on Off-Center Subjects: Focus Lock

If your subject is not at the center of the frame when the shutter-release button is pressed halfway,

your picture may be out of focus. To focus on an off-center subject:

nFocus

Position the subject in the center of the frame and

press the shutter-release button halfway.

oCheck the green (AF) lamp and focus indicator

With the shutter-release button pressed halfway,

check that the green (AF) lamp and focus indicator

glow steadily, indicating that the subject is in focus.

Focus and exposure will remain locked while the

shutter-release button is pressed halfway.

pRecompose the picture

Keeping the shutter-release button pressed half-

way, recompose your picture. Do not change the

distance between the camera and your subject

while focus lock is in effect. If your subject moves,

remove your finger from the shutter-release button

and focus again at the new distance.

qTake the picture

Press the shutter-release button the rest of the way

down to shoot.

AUTO

Basic Photography

Step 4 - View the Results (Full-screen Playback Mode)

Press the x button

View pictures in the monitor

To view additional pictures, press the multi se-

lector down or right to view pictures in the or-

der recorded, up or left to view pictures in

reverse order. To scroll quickly to a particular

frame number without viewing the intervening

pictures, press and hold the multi selector. O:

@ (voice memo recording guide) is displayed

(E5600 only).

To cancel full-screen playback and return to

shooting mode, press the x button again.

Deleting Unwanted Pictures

To delete the picture displayed in the monitor,

press the u button. A confirmation dialog will be

displayed. Press the multi selector up or down to

highlight Yes and then press the center of the multi

selector. To exit without deleting the picture, high-

light No and press I (the center of the multi selec-

tor).

2005

13:

100NIKON

0001.

JPG

0001.

JPG

Done

Yes

Erase 1 image (s)?

Set

Step 4 - View the Results (Full-screen Playback Mode)

Basic Photography

Deleting Your Last Shot

At any time during shooting, you can press the u button to delete the last

picture taken. The confirmation dialog shown at right will be displayed.

Delete the picture as described opposite under "Deleting Unwanted Pic-

tures."

Playback Tip

The first and last pictures in memory are linked. Pressing the multi selector up or left when the first

picture in memory is displayed will take you to the last picture. Pressing the multi selector down or

right when the last picture is displayed takes you to the first picture.

Image File and Folder Names

In the memory or on the memory card, pictures are identified by file names with three parts: a four

letter identifier, a four-digit file number assigned automatically by the camera in ascending order,

and a three-letter extension (e.g., "DSCN0001.JPG")

When a picture is viewed in the monitor, the file number and extension appear in the top right corner

of the display. The identifier is not displayed, but is visible when the picture is transferred to a computer.

Pictures are stored in folders created automatically by the camera and named with a three-digit fold-

er number followed by "NIKON" (e.g., "100NIKON"). Folders can hold up to 200 pictures; if you

take a picture when the current folder contains 200 pictures, a new folder will be created by adding

one to the current folder number. If you take a picture when the current folder contains a picture

numbered 9999, a new folder will be created and file numbering will begin again from 0001. If the

number of files reaches 200 or file numbering reaches 9999 when the memory or memory card

contains a folder numbered 999, no further pictures can be taken until the memory or memory card

has been formatted (

97) or a new memory card inserted.

Picture type Identifier Extension Q

Original Still picture DSCN .JPG 22

Movie DSCN .MOV 64

Copy

Small copy SSCN .JPG 83

Cropped copy RSCN .JPG 44

Copy created with

the D-Lighting function FSCN .JPG 45

Voice memo

appended to

still picture

(E5600 only)

Voice memo

DSCN

SSCN

RSCN

FSCN

.WAV 47

Yes

Erase 1 image (s)?

Set

More on Photography

When Lighting Is Poor: Using the Flash

The following flash modes are available:

To select the flash mode:

Display Flash menu. Highlight desired mode (to exit without

changing mode, wait for a while or press

the multi selector to left).

Auto with Red-eye Reduction

The E5600/E4600 Auto with red-eye reduction flash function uses an advanced red-eye reduc-

tion method. Several pre-flashes are fired before the main flash to reduce "red-eye." In addi-

tion, if red-eye is detected, the camera will automatically correct it when storing the picture

("In-Camera Red-Eye Fix"). When using this function, there is a slight delay before you can

press the shutter-release button again for the next shot. Depending on the situation, red-eye

reduction may not always produce the desired results. In some rare cases, other picture areas

may be affected. Choose another flash mode and try again.

Mode How it works When to use it

Auto

Flash fires when lighting is

poor. Best choice in most situations.

Auto with

red-eye

reduction

Flash fires before main

flash, reducing "red-eye."

Use for portraits (works best when sub-

ject is well within range of flash and

looking at pre-flash). When using this

mode, the red-eye reduction function

will also work automatically for the pic-

ture recorded. Not recommended when

quick shutter response is required.

Flash Cancel

(off)

Flash will not fire even

when lighting is poor.

Use to capture natural lighting under

dim light or where use of flash is prohib-

ited. If 2 (camera shake) icon appears,

care should be taken to avoid blurring.

Anytime Flash

( fill flash)

Flash fires whenever picture

is taken.

Use to "fill-in" (illuminate) shadows and

back-lit subjects.

(Slow sync)

Auto flash combined with

slow shutter speeds.

Use to capture both subject and back-

ground at night or under dim light.

Set

Flash

AUTO

Flash

Set

AUTO

When Lighting Is Poor: Using the Flash

More on Photography

Exit menu. Flash mode shown by icon at

bottom of monitor.

Sensitivity ( ISO Equivalency)

"Sensitivity" is a measure of how quickly the camera responds to light.

Your Nikon digital camera normally has a sensitivity roughly equivalent to

film with an ISO 50 rating. When lighting is poor and the flash is off ($),

the camera will automatically increase sensitivity, permitting faster expo-

sures and minimizing blur caused by inadvertent camera movement (cam-

era shake). An ISO icon will appear in the monitor to warn that the picture

may be slightly mottled.

The 2 (Camera Shake) Icon

When lighting is poor and the flash is off ($), shutter speeds will slow and

pictures may be blurred. If the shutter speed required for exposure is very

slow, a 2 (camera shake) warning will appear in the monitor. Use of a tri-

pod or support is recommended.

Flash Range

Flash range varies with zoom position. The range at minimum zoom is 0.4 - 3.3m (1´4” - 10´10”)

and 0.4 - 2.0 m (1´4” - 6´7”) at maximum zoom.

Close-Ups

The flash may not be able to light the entire subject at distances of less than 40 cm (1´4”). When

taking close-ups, play each picture back after shooting to check the results.

Flash Mode Selection

In P (auto) mode, the camera "remembers" the current flash mode setting even when the cam-

era is turned off. The most recent setting will automatically be restored whenever the mode dial is

set to P unless the Reset all option in the SET-UP menu is used to restore the default setting

(Q 100). Depending on the shooting mode selected, the flash mode may change automatically

when you choose a new shooting mode (Q 28-41).

More on Photography

Taking a Self-Portrait: Using the Self-Timer

When the self-timer is on, pictures are taken ten seconds after the shutter-release

button is pressed. This can be used to allow you to appear in your own pictures

or to prevent close-up or low-light shots from being blurred by the camera move-

ment that occurs when the shutter-release button is pressed.When using this op-

tion, you should either mount the camera on a tripod (recommended) or rest it

on a flat, level surface.

Display Self-timer menu.

Exit menu. Self-timer icon is displayed in

monitor.

Highlight ON (to exit without changing

mode, wait for a while or press multi se-

lector to left).

Frame picture and start timer. Countdown

timer shows number of seconds remaining

until picture is taken.

Focus and exposure lock when the shutter-release button is

pressed. The self-timer lamp on the front of the camera will

blink until one second before the picture is taken, staying lit

during the final second to warn that the shutter is about to be

released.

Stopping the Self-Timer

To stop the timer before the picture is taken, press the shutter-release button.

The Self-Timer

The self-timer is not available in some shooting modes (Q 28-41).

OFF

Self-timer

OFF

Self-timer

Set

OFF

AUTO

More on Photography

Easy Close-ups: Macro Close-up Mode

Macro close-up mode is used for taking close-up shots of small objects at very

short distances (minimum 4 cm/1.6″).

Display Macro close-up menu.

Exit menu. & icon appears in monitor

when camera is in macro close-up.

Highlight ON (to exit without changing

setting, wait for a while or press multi se-

lector to left).

Frame picture. If zoom indicator and &

icon are displayed in green, camera can

focus at a distance of 4 cm/1.6″.

Macro Close-up Mode

At short ranges, the viewfinder does not show the image that will appear in the final picture. Use

the monitor for close-ups.

In macro close-up mode, the camera focuses continuously, even when the shutter-release

button is not pressed halfway.

Macro close-up is not available in some shooting modes (Q 28-41).

OFF

Macro close-up

Set

OFF

Macro close-up

Set

AUTO

More on Photography

Assist and Scene Modes

Your Nikon digital camera offers a choice of four "assist" and twelve "scene"

modes. In these modes, camera settings are automatically optimized for the se-

lected subject type, sparing you the necessity of adjusting settings one-by-one.

Assist Modes

Assist modes are chosen by rotating the mode dial to the desired mode. Framing

assist options are available to help you compose your shots.

Scene Modes

Scene modes are selected by rotating the mode dial to e and selecting the de-

sired scene from a menu.

Mode Description Q

iPortrait assist Use for portraits in which the main subject stands out

clearly while background details are softened. 31

NLandscape assist

Use to enhance outlines, colors, and contrast in sky-

scapes, forests, and other landscape shots, or to take

portraits that feature a landmark in the background.

jSports assist

Use for sports shots that freeze motion in rapidly-moving subjects.

mNight portrait assist Use for portraits taken against a dimly-lit backdrop. 34

Mode Description Q

BPARTY/INDOOR

Use to capture background details or the effects of can-

dlelight and other indoor lighting.

CBEACH/SNOW Use for bright subjects such as snowfields, beaches, and

sunlit expanses of water. 36

DSUNSET

Use to preserve the deep hues seen in sunsets and sunrises.

EDUSK/DAWN Use to preserve the colors seen in the weak natural light

before sunrise and after sunset. 37

FNIGHT LANDSCAPE Use when taking landscape shots at night. 37

ACLOSE UP

Use to capture vivid colors in close-up shots of flowers,

insects, and other small objects.

GMUSEUM Use where flash photography is prohibited. 38

HFIREWORKS SHOW

Use to capture the expanding burst of light from a firework.

ICOPY Use to copy text and line drawings. 38

JBACK LIGHT Use when light is coming from behind your subject,

throwing their features into shadow. 39

MUNDERWATER Use when taking underwater photographs using the

water-proof case (WP-CP3). 39

PANORAMA ASSIST

Use when taking a series of pictures that will later be

joined to form a single scene. 40

Assist and Scene Modes

More on Photography

Assist and Scene Modes

Depending on your subject, assist and scene modes may not always produce the desired results. If

results are not to your satisfaction, choose P (auto) and try again.

Image Mode

The Image mode option is available in the assist

mode and scene mode menu (Q 67).

Assist and Scene Modes Help

Pressing O(T) button when displaying the assist or scene menu displays

the help for the selected assist or scene.

Set

Help

Exit

IMAGE MODE

Set

Help

Exit

IMAGE MODE

PORTRAIT

Use for portrait

pictures, create

soft skin tone effects.

Set

Back

Exit

More on Photography

Framing Assist

The four assist modes offer a selection of framing assist options that allow you

to compose pictures with the help of framing guides displayed in the monitor. To

use framing assist, rotate the mode dial to the desired mode and follow the steps

below.

After selecting mode, display framing as-

sist menu.

Make selection to return to shooting

mode. Framing guide appears in moni-

tor.

Choose composition type. Current selec-

tion shown by large icon and caption.

When taking pictures, position subject or

subjects in framing guide as described

on following pages.

Using the Guides

Your subject does not have to fit exactly in the framing guides. When framing pictures, pay at-

tention to your surroundings; be careful not to trip and fall.

PORTRAIT

Set

Help

Exit

PORTRAIT CLOSE-UP

Set

Help

Exit

Framing Assist

More on Photography

i Portrait Assist

(portrait assist) mode helps you frame portraits in which the

main subject stands out clearly while background details are

softened, lending the composition a sense of depth (the de-

gree of softening depends on the amount of light available).

A framing assist menu helps you frame off-center subjects and

compose tall or wide shots and two-person portraits.

* Other modes can be selected.

i PORTRAIT

No guides are displayed in monitor. Camera focuses on subject in center of

frame; focus lock can be used to focus on off-center subjects.

9 PORTRAIT LEFT

Use to compose shot with subject centered in left half of frame. Camera will

focus on subject in framing guide.

0 PORTRAIT RIGHT

Use to compose shot with subject centered in right half of frame. Camera

will focus on subject in framing guide.

: PORTRAIT CLOSE-UP

Use to compose shot with your subject's face positioned in top half of

frame. Camera will focus on face area in framing guide.

[ PORTRAIT COUPLE

Use to compose shot with two subjects positioned side-by-side. Camera will

focus on closest subject.

; PORTRAIT FIGURE

Use to compose shot with camera held as shown at right

and subject's face in top half of frame. Camera will focus

on face area in framing guide.

PORTRAIT

Set

Help

Exit

PORTRAIT LEFT

Set

Help

Exit

PORTRAIT RIGHT

Set

Help

Exit

PORTRAIT CLOSE-UP

Set

Help

Exit

PORTRAIT COUPLE

Set

Help

Exit

PORTRAIT FIGURE

Set

Help

Exit

! %*YOFF* &OFF

Framing Assist

More on Photography

NLandscape Assist

N (landscape assist) mode helps you frame vivid landscape

shots that enhance outlines, colors, and contrast. A framing

assist menu helps you frame not only natural landscapes but

also cityscapes and portrait shots featuring a landmark in

the background.

* Other modes can be selected.

N LANDSCAPE

No guides are displayed in monitor. Use to focus on distant objects through

foreground objects such as windows or a screen of branches. Focus is fixed

at infinity.

6 SCENIC VIEW

Use to compose landscapes with sky in top third of frame, distant objects in

middle third, and closer objects in bottom third. Match top of skyline with

wavy yellow guide.

7 ARCHITECTURE

Use to photograph buildings. A grid is displayed in the monitor to help keep

verticals and horizontals aligned with the frame.

LANDSCAPE

Set

Help

Exit

SCENIC VIEW

Set

Help

Exit

ARCHITECTURE

Set

Help

Exit

! $ Y OFF* &OFF

5 GROUP RIGHT

Use to compose portraits with portrait subjects to right and landmark or

other object in background at left of frame. Both portrait subject and back-

ground object will be in focus.

8 GROUP LEFT

Use to compose portraits with portrait subjects to left and landmark or

other object in background at right of frame. Both portrait subject and

background object will be in focus.

GROUP RIGHT

Set

Help

Exit

GROUP LEFT

Set

Help

Exit

!!#*YOFF* &OFF

Framing Assist

More on Photography

j Sports Assist

j (sports assist) mode is used for dynamic action shots that

capture moving objects. The assist menu lets you freeze the

action in a single shot or record motion in a series of pic-

tures.

Sports Assist

In Sports or Sports composite mode, the focus is constantly reset until it is locked by pressing the

shutter-release button halfway.

j SPORTS

While shutter-release button is held down, pictures are recorded at rate of

about 3 frames every 2 seconds (rate of shooting will slow when < icon is

displayed). With E5600, camera records eleven shots when image mode is

set to H Normal (2592). With E4600, camera records eight shots when

image mode is set to F Normal (2288). Focus, exposure, and white bal-

ance are determined by first shot in each series. Camera focuses continu-

ously, even when shutter-release button is not pressed.

\ SPORT SPECTATOR

Sport spectator is ideal for capturing those instants when you have no time

to compose the picture. Use at ranges of 3 m to infinity.

A series of shots can be taken by holding the shutter-release button down.

Number of shots that can be taken is the same as for j (Sports) mode.

] SPORT COMPOSITE

Each time shutter-release button is pressed, camera takes 16 shots in about

three seconds and arranges them in four rows to form a single c Economy

(1600) picture. Focus, exposure, and white balance are determined by first

shot in each series.

SPORTS

Set

Help

Exit

SPORT SPECTATOR

Set

Help

Exit

SPORT COMPOSITE

Set

Help

Exit

! $ Y OFF &OFF

Framing Assist

More on Photography

m Night Portrait Assist

m (night portrait assist) mode is used for taking portrait

shots at night, when it provides a natural balance between

the main subject and the background. Pictures taken at slow

shutter speeds are adjusted to improve quality, slightly in-

creasing processing time; to prevent blurring, mount the

camera on a tripod or rest it on a flat, stable surface. For

more information on framing assist options, see i Portrait Assist (Q 31).

* Other modes can be selected.

Flash Mode Selection in m Mode

Flash mode is automatically set to % (auto with red-eye reduction).

! % Y OFF* &OFF

More on Photography

e Scene Mode

(scene) mode offers a menu of twelve "scenes,"

each corresponding to a common situation, such as a

backlit subject, sunset, or interior shot. Camera settings

are automatically adjusted to suit the selected scene, spar-

ing you the necessity of adjusting each setting separately.

To take pictures in scene mode, rotate the mode dial to

and follow the steps below.

Display scene menu.

Make selection to return to shooting

mode. Selected scene shown by icon at

top left corner of monitor.

Choose scene. Current selection shown

by large icon and caption.

Scene mode

PARTY/INDOOR

Set

Help

Exit

AUTO

BEACH/SNOW

Set

Help

Exit

e Scene Mode

More on Photography

The following scenes are available:

* Other modes can be selected.

The 2 (Camera Shake) Icon

When the 2 icon appears in the monitor, pictures may be blurred. In this section, the precautions

that you can take to avoid blur are indicated by stars:

hold camera in both hands and brace elbows against your body.

 use a tripod or rest the camera on a flat, level surface.

BPARTY/INDOOR

Use for shots that include details of the background, or to capture

the effects of candlelight and other indoor background lighting.



CBEACH/SNOW

Vividly captures the brightness of such subjects as snowfields,

beaches, or sunlit expanses of water. Flash mode automatically set

to !AUTO; other modes can be selected.

DSUNSET

Preserves the deep hues seen in sunsets and sunrises.



! %*YOFF* &OFF

!!#*YOFF* &OFF

! $*YOFF* &OFF

e Scene Mode

More on Photography

* Other modes can be selected.

EDUSK/DAWN

Preserves the colors seen in the weak natural light before sunrise or

after sunset. Focus is fixed at infinity.



Pictures taken at slow shutter speeds are processed to improve quality, slightly increasing time

before pictures are saved to memory or memory card.

FNIGHT LANDSCAPE

A slow shutter speed is used to produce stunning night land-

scapes. Focus is fixed at infinity.



Pictures taken at slow shutter speeds are processed to improve quality, slightly increasing time

before pictures are saved to memory or memory card.

ACLOSE UP

Use to capture vivid colors in close-up shots of flowers, insects,

and other small objects, with the background artistically blurred.

Flash mode automatically set to !AUTO; other modes can be

selected. 

Camera focuses continuously, even when shutter-release button is not pressed halfway. Mini-

mum focus distance varies with zoom position. To focus on objects as close as 4 cm/1.6” to the

lens, adjust zoom until the macro close-up icon (&) in monitor turns green.

! $ Y OFF* &OFF

!!#*YOFF* &ON

e Scene Mode

More on Photography

* Other modes can be selected.

GMUSEUM

Flash turns off (

) automatically. Use this mode indoors where flash

photography is prohibited (for example, in museums and art galleries)

or in other indoor settings in which you do not want to use the flash.



•The Best Shot Selector (BSS;Q 73) turns on automatically, reducing the effects of inad-

vertent camera movement.

•Macro close-up turns off automatically; other modes can be selected.

•Photography may be prohibited altogether in some settings. Be sure to obtain permis-

sion first.

HFIREWORKS SHOW

Slow shutter speeds are used to capture the expanding burst of

light from a firework. The camera responds more rapidly to the

shutter-release button, ensuring that you can capture the start of

the burst. 

• Focus is fixed at infinity.

• Follow the firework as it ascends and press the shutter-release button all the way down

at the start of the burst.

ICOPY

Provides clear pictures of text or drawings on a white board or in

printed matter such as a business card.

• Flash and macro close-up turn off automatically; other modes can be selected.

• Colored text and drawings may not show up well in the final picture.

! $ Y OFF* &OFF*

! $ Y OFF &OFF

! $*YOFF* &OFF*

e Scene Mode

More on Photography

* Other modes can be selected.

JBACK LIGHT

Use when light is coming from behind your subject, throwing

their features into shadow, or when your subject is in the shade

but the background is brightly lit. The flash will fire automatically

to "fill in" (illuminate) shadows.

MUNDERWATER

Use when taking underwater photographs using the water-proof

case (WP-CP3).

! ! Y OFF* &OFF

!!#*YOFF* &OFF*

e Scene Mode

More on Photography

* Other modes can be selected.

To use panorama assist, follow the steps below.

Highlight K (PANORAMA ASSIST). Press I (the center of the multi se-

lector). Pan direction displayed in

greenish yellow.

Select how pictures will be joined together in completed panorama. This is the direc-

tion in which to pan the camera after each shot.

Make selection (to change selected pan di-

rection, press center of multi selector and

repeat steps 3–4). Pan direction displayed

in white.

KPANORAMA ASSIST

Use to take a series of photographs that you

will later join to form a single scene (for

example, a panorama or 360º virtual-reality

image).

! $*YOFF &OFF*

PANORAMA ASSIST

Set

Help

Exit

Bottom to top

Top to bottom

Left to right

Right to left

e Scene Mode

More on Photography

Compose the next shot to overlap with

the previous picture.

Take first picture. About one third of pic-

ture is shown superimposed on view

through lens (if pan direction is left to right,

picture will appear on left side of monitor).

Take the next picture.

Repeat steps 6 and 7 until all shots in se-

ries have been taken.

Panorama Assist

The pan direction, flash mode, macro close-up mode, and exposure compensation can not be changed after the

first picture is taken. To change the pan direction, press

button to end shooting and repeat steps 1–3.

Using a Tripod

Using a tripod makes it easier to compose shots so that they overlap.

Storage Locations for Panoramas

Each series of pictures taken at Panorama assist is stored in a separate folder with a name consisting

of "P" preceded by a three-digit folder number and followed by a three-digit sequence number

(e.g., "101P 002").

Joining Panorama Pictures

Transfer the pictures taken with Panorama Assist to your computer (Q 49) and use the Panorama

Maker function in PictureProject to join them into a single scene. For further information, see the

PictureProject Reference Manual (on CD-ROM).

AE-L

AE-LAE-L

AE-L

AE-LAE-L

8End series. Shooting will also end if a new mode is selected or camera

enters standby mode.

More on Playback

Viewing Pictures on the Camera

Viewing Multiple Pictures: Thumbnail Playback

Pressing the l (W) button in full-screen playback

displays the pictures in the memory or on the memory

card in "contact sheets" of four thumbnail images.

The following operations can be performed while

thumbnails are displayed:

To Press Description

Highlight

pictures

Press multi selector up, down, left or right to highlight

pictures. Press I (the center of the multi selector) to

return to full-screen playback.

Change

number of

pictures

displayed

l (W)/O (T)

With four thumbnails displayed, press l (W) button

once to view nine thumbnails. Press O (T) to "zoom in"

from nine thumbnails to four-thumbnail view, or, when

four thumbnails are displayed, to return to full-screen

playback.

Cancel

thumbnail

playback

Cancel thumbnail playback and return to full-screen

playback.

Delete

highlighted

picture u

Confirmation dialog will be dis-

played. Press the multi selector

up or down to highlight option,

and press I to select.

Yes

Erase 1 image (s)?

Set

Viewing Pictures on the Camera

More on Playback

Taking a Closer Look: Playback Zoom

Use the O (T) button to zoom in on still images dis-

played in full-screen playback. While the picture is

zoomed in, you can save a cropped copy of the pic-

ture that contains only the portion of the image visi-

ble in the monitor. Playback zoom and cropping are

not available when the current picture is a movie or a

copy created using the small picture option (Q64,

83). Cropped copies can not be further cropped.

To Press Description

Zoom in O (T)

Zoom increases each time button is pressed, to a maxi-

mum of 10×. While image is zoomed in, O icon and

zoom ratio are displayed in top left corner of monitor.

View other

areas of


Use the multi selector to scroll to areas of picture not vis-

ible in monitor. To use the multi selector to view other

pictures, cancel zoom.

Zoom out l (W)

Zoom decreases each time l (W) button is pressed. To

cancel zoom, zoom picture out until entire picture is dis-

played.

Cancel zoom Cancel zoom and return to full-screen playback.

Crop picture Only portion of picture visible in monitor can be

cropped.

Delete picture u

Confirmation dialog will be dis-

played. Press multi selector up

or down to highlight option,

press the center of the multi

selector to select.

4.0

Scroll

Zoom

Yes

Erase 1 image (s)?

Set

Viewing Pictures on the Camera

More on Playback

Cropping Pictures

This option lets you crop part of a picture and save it as a separate file.

Zoom picture in and out. Scroll picture. Repeat steps 1 and 2 until

desired portion of image is displayed in

monitor.

Confirmation dialog displayed. Select

Yes to create cropped copy, No to exit

without creating copy, then press I

(the center of the multi selector).

To view the new, cropped copy, press

the multi selector down until the copy

is displayed.

Cropped pictures are stored as JPEG files (compression ratio 1 : 8). Depending on

the size of the original and the zoom ratio at the time the copy was created, copies

will be 2,592 × 1,944 (E5600 only) 2,288 × 1,712, 2,048 × 1,536 , 1,600 × 1,200,

1,280 × 960, 1,024 × 768, 640 × 480, 320 × 240, or 160 × 120 pixels in size. Copies

are stored in separate files in the memory or on the memory card with names in the

form "RSCN

nnnn

.JPG." "

nnnn

" is a four-digit number assigned automatically by

the camera.

Photo Trim

• Cropped pictures are stored with the same recording date and time as the original.

• Resized copies and cropped copies can not be cropped.

• If a cropped copy created using the E5600/E4600 is viewed on a different digital camera,

the picture may not be displayed or may not be transferred to a computer.

1.2

Scroll

Zoom

4.0

Scroll

Zoom

Yes

Save this image as

displayed?

Save this image as

displayed?

Set

Viewing Pictures on the Camera

More on Playback

Adjusting a picture tone automatically

Press I (the center of the multi selector) in full-screen playback. The tone ad-

justed picture is created automatically as a separate picture. This function is called

D-Lighting in the E5600/E4600. Using D-Lighting, backlit or insufficient flash

light volumes can be adjusted brightly. Please see the D-Lighting samples on the

next page.

Select picture in full-screen playback. Press I. The tone adjusted picture is dis-

played.

• Select Yes to save the a copy, No to exit

without creating copy, then press I.

D-Lighting

• Copies created with D-Lighting are stored in a separate file.

• Copies created with D-Lighting are not deleted if the original pictures are deleted. The

original pictures are not deleted if copies created with D-Lighting are deleted.

•The Auto transfer option set to the original pictures is applied to copies created with D-

Lighting.

•The Print set option and Protect set to the original pictures are not applied to copies cre-

ated with D-Lighting.

• Copies created with D-Lighting are stored with names in the form "FSCNnnnn.JPG."

"nnnn" is a four-digit number assigned automatically by the camera.

• Copies created with D-Lighting are stored with the same recording date and time as the

original.

• Movies, small pictures, cropped copies and copies created with D-Lighting can not be tone

adjusted with D-Lighting.

• The D-Lighting function is not available when there is not enough free space in the mem-

ory or on the memory card.

• If a copy created with D-Lighting using the E5600/E4600 is viewed on a different digital

camera, the picture may not be displayed or may not be transferred to a computer.

• D-Lighting function may not be available for the pictures taken with non-E5600/E4600

digital cameras.

2005

13:

100NIKON

0001.

JPG

0001.

JPG

Yes

Set

Save this image as

displayed?

Save this image as

displayed?

Viewing Pictures on the Camera

More on Playback

D-Lighting Samples

Before After

Viewing Pictures on the Camera

More on Playback

Voice Memos: Recording and Playback (E5600 only)

Using the camera’s microphone, you can record a

voice memo by pressing the shutter-release button

while a picture with the O: @ icon is displayed in

full-screen playback (Q 22). Do not touch the micro-

phone during recording. Voice memos cannot be re-

corded or played back for movies (Q 60) or during

thumbnail playback (Q 42) or playback zoom (Q 43).

If a voice memo already exists for the current picture,

[1] (voice memo icon) and O: [1] (voice memo

playback guide) are displayed and a new voice memo

can not be recorded.

Voice Memos

Voice memo file names consist of an identifier ("DSCN" for memos appended to original pictures,

"SND_" for memos appended to copies), a four-digit file number copied from the associated pic-

ture, and the extension ".WAV" (e.g., "DSCN0015.WAV").

To Press Description

Record voice

memo

If O: @ icon is displayed on current picture, memo will

be recorded while shutter-release button is held down.

During recording, zREC icon blinks. Recording ends

after about 20s or when shutter-release button is

released. Do not touch microphone during recording.

Play voice

memo

Pictures for which voice memo exists are marked by 1

icon. Press shutter-release button to play voice memo.

Playback ends when voice memo ends or shutter-release

button is pressed again.

Change

volume

l (W)/

O (T)

Zoom buttons control volume during playback. Press

(

) to lower volume,

O (T) to increase. Volume can also

be adjusted using Sound settings > Volume option in

the SET-UP menu (Q 94).

Delete picture

or voice memo u

onfirmation dialog will be dis-

played. Press multi selector up or

down to highlight option, press

(the center of the multi selector) to

select.

•Select No to exit without delet-

ing picture or voice memo.

• Select [1] to delete voice memo

only.

•Select Yes to delete both picture

and voice memo.

2005

13:

100NIKON

0001.

JPG

0001.

JPG

Yes

Set

Erase 1 image (s)?

More on Playback

Viewing Pictures on TV

Using the EG-CP14 audio/video (AV) cable (E5600) or EG-CP11 video cable

(E4600) included with your camera, you can connect the camera to a television

or video-cassette recorder (VCR).

Choosing a Video Mode

The Video mode item in the Interface option of the SET-UP menu offers a choice of NTSC and

PAL standards (Q99). Be sure that the standard selected matches that used in the device.

Turn the camera off

• Turn the camera off before connecting or dis-

connecting the AV/video cable.

Connect the AV/video cable to the

camera

• Open the interface connector cover and insert

the black plug into the camera's interface con-

nector.

Connect the AV/video cable to the

television or VCR

• [E5600] Insert the yellow plug on the AV cable

into the video-in jack on the television or VCR

and the white plug into the audio-in jack.

• [E4600] Insert the yellow plug on the video ca-

ble into the video-in jack on the television or

VCR.

Turn the camera on

• Press the x button for about a second to turn

the camera on. The camera monitor will re-

main off and the television will display the im-

age normally shown in the monitor. If the

camera is connected to a VCR, images can be

recorded to video tape.

More on Playback

Viewing Pictures on a Computer

Using the UC-E6 USB cable and PictureProject software provided with your camera,

you can view your photographs and movies on a computer. Before you can transfer

(copy) pictures to your computer, you will need to install PictureProject. For more

information on installing PictureProject and transferring pictures to your computer,

see the Quick Start Guide and the PictureProject Reference Manual (on CD).

Before Connecting the Camera

Pictures can be copied from the camera to the computer by:

• Pressing the I (V) button on the camera (Q81)

• Clicking the button in PictureProject

Which method you will use depends on your computer's operating system and

the USB option selected in the SET-UP menu of the camera. After consulting the

following table, select the appropriate option using the USB item in the SET-UP

menu of the camera. The default option is Mass storage.

*The camera I (V) button can not be used to transfer pictures in the following cases. Use the

PictureProject button.

• When transferring pictures from the camera memory and Mass storage is selected for

the USB option

• When the memory card write-protect switch is in the "lock" position. Unlock by sliding

the switch to the "write" position before transferring pictures.

Operating system

Pictures transferred using:

Camera I (V)

button*

PictureProject

button

Windows XP Home Edition

Windows XP Professional Choose Mass storage or PTP.

Windows 2000 Professional

Windows Millennium Edition (Me)

Windows 98 Second Edition (SE)

Choose Mass storage.

Mac OS X 10.1.5 or later Choose PTP.Choose Mass storage

or PTP.

USB

Video mode

INTERFACE

Set

PTP

Mass storage

USB

Set

Blur warning

Auto off

Format memory

Language

SET-UP

2/3

SET-UP

2/3

Set

Help

Interface

Viewing Pictures on a Computer

More on Playback

Connecting the USB Cable

Turn the computer on and wait for it to start up. After confirming that the cam-

era is off, connect the UC-E6 USB cable as shown below. Connect the camera

directly to the computer; do not connect the cable via a USB hub or keyboard.

You can now turn the camera on and transfer pictures as described in the Quick

Start Guide.

Windows 2000 Professional, Windows Millennium Edition (Me),

Windows 98 Second Edition (SE)

Do NOT select PTP when connecting the camera to a computer running one of the above operat-

ing systems. If you have connected the camera to a computer running one of the above operating

systems with PTP selected in the USB menu, disconnect the camera as described below. Be sure to

select Mass storage before reconnecting the camera.

Windows 2000 Professional

A dialog will be displayed welcoming you to the Found New Hardware Wizard.

Click Cancel to close the dialog, and then disconnect the camera.

Windows Millennium Edition (Me)

After displaying a message stating that the hardware information database is being updat-

ed, the computer will start the Add New Hardware Wizard. Click Cancel to exit the wizard,

and then disconnect the camera.

Windows 98 Second Edition (SE)

The Add New Hardware Wizard will be displayed. Click Cancel to exit the wizard, and then

disconnect the camera.

UC-E6 USB cable

Viewing Pictures on a Computer

More on Playback

Disconnecting the Camera

If PTP is selected in the USB menu, you can turn the camera off and disconnect

the USB cable once transfer is complete. If you have not changed the USB option

in the camera SET-UP menu from its default setting of Mass storage, you must

remove the camera from the system as shown below before turning the camera

off or disconnecting the cable.

Windows XP Home Edition/Windows XP Pro-

fessional

Click the "Safely Remove Hardware" icon ( ) in

the taskbar and select Safely remove USB Mass

Storage Device from the menu that appears.

Windows 2000 Professional

Click the "Unplug or Eject Hardware" icon ( ) in

the taskbar and select Stop USB Mass Storage

Device from the menu that appears.

Windows Millennium Edition (Me)

Click the "Unplug or Eject Hardware" icon ( ) in

the taskbar and select Stop USB Disk from the

menu that appears.

Windows 98 Second Edition (SE)

In My Computer, click with the right mouse button

on the removable disk corresponding to the cam-

era and select Eject from the menu that appears.

Mac OS X

Drag the "NO_NAME" camera volume into the

Trash.

Mac OS X

More on Playback

Printing Pictures

Pictures stored in the memory or on the memory card can be printed in the same

way as pictures taken with a film camera. Using the Print set option in the PLAY-

BACK MENU, you can specify the pictures to be printed, the number of prints,

and the information to be included with each print.

Printing pictures

Pictures can be printed as follows.

• By printer or at a photo lab

Pictures can be printed by inserting a memory card containing pictures into a

printer or having prints made at a digital photo lab. If a print order has been

created, the printer or photo lab must support DPOF.

Pictures stored in the camera memory can be printed. They must be copied to

the memory card (Q 84). Copy the pictures before creating a print order.

• By a printer that supports PictBridge (Q 56)

Connect the camera to a printer that supports PictBridge to print pictures.

Print order data can be used.

• By transferring pictures to a PC and printing them

For more information, see the PictureProject Reference Manual.

Printing Pictures

More on Playback

Highlight Print set. Display PRINT SET menu.

Highlight Print selected. Pictures on memory card displayed as

thumbnail images.

Highlight picture. Select highlighted picture. Selected pic-

tures marked by d icon.

"Delete print set"

To cancel the current print order, highlight Delete print set in the PRINT SET menu and press the

multi selector to the right. Print marking will be removed from all pictures in the current print order;

the pictures themselves will not be deleted.

Print set

Slide show

Delete

Protect

Transfer marking

PLAYBACK MENU 1/2

Help

Set

Exit

Print selected

Delete print set

PRINT SET

Set

Exit

Print selected

Delete print set

PRINT SET

Set

Exit

PRINT SELECTION

2005

05 .

2005

05 .

Set

Back

2005

05 .

2005

05 .

PRINT SELECTION

Set

Back

2005

05 .

2005

05 .

PRINT SELECTION

Set

Back

Printing Pictures

More on Playback

Use the multi selector to specify number

of prints (up to 9). To deselect picture,

press the multi selector down until icon

disappears. Repeat steps 5-7 to select

additional pictures. To exit without alter-

ing print order, press ^ button.

Press I (the center of the multi selector)

to complete print order and display

menu of print options.

• To print date of recording on all pictures in

print order, highlight Date and press I.

Check will appear in box next to item.

• To print shutter speed and aperture on all

pictures in print order, highlight Info and

press I.

Check will appear in box next to item.

• To deselect checked item, highlight and

press I.

• To complete print order and return to

playback, highlight Done and press I.

Done is displayed and the screen returns

to the PLAYBACK MENU. Press ^ button

to return to full-screen playback. To exit

without altering print order, press ^ but-

ton.

2005

05 .

2005

05 .

PRINT SELECTION

Set

Back

Date

Info

PRINT SET

Set

Exit

Done

Printing Pictures

More on Playback

Print Set

If you display the PRINT SET menu after creating a print order, the Date and Info options will be

reset.

"Date"

If Date is selected, the date of recording will appear on pictures printed

using DPOF. The date is based on the photo information recorded with

the picture, and will not be correct if the camera clock was set incorrectly

when the picture was taken (Q14-15). The date will not be printed if the

print system does not support the DPOF date function.

The date stamp recorded when Date or Date and time is selected

for Date imprint (Q93) forms a permanent part of the image and

will appear whenever the pictures are printed, even if the printer

does not support the DPOF date function. Print set can not be used

to print the time and date of recording on pictures recorded when

Date or Date and time is selected for Date imprint.

2005.05.01

More on Playback

Printing Via Direct USB Connection

Your camera allows pictures to be printed directly from the camera using Pict-

Bridge. If the UC-E6 USB cable is used to connect the camera to a printer that

supports PictBridge, pictures can be printed directly from the memory or memory

card without having to be transferred to a computer.

Select PTP in the camera USB menu.

• For more information on selecting the

USB option, see "Viewing Pictures on a

Computer" (Q 49).

After confirming that the camera is off, connect the UC-E6 USB cable as shown

above.

You can now turn the camera and printer on.

The opening screen and the PictBridge menu is displayed when the camera has

recognized the printer.

PTP

Mass storage

USB

Set

Print selection

Print all images

DPOF printing

Cancel

PictBridge

Set

Option Description

Print selection Select picture and specify number of prints.

Print all images All pictures in internal memory or on memory card are printed.

DPOF printing Pictures for which print order has been created are printed

accordingly.

Printing Via Direct USB Connection

More on Playback

Highlight Print selection.* Display PRINT SELECTION dialog.

* To print one copy of all pictures on

memory card, highlight

Print all im-

ages

and press multi selector to right.

Scroll through pictures. Current picture

shown at bottom of display.

Use the multi selector to specify number

of prints (up to 9). To deselect picture,

press the multi selector down when

number of prints is 1. Repeat steps 6–8

to select additional pictures.

Select current picture and set number of

prints to 1. Selected pictures marked by

d icon.

View selected pictures. Press the multi se-

lector up, right, left, or down to view pic-

tures not visible in display.

Print selection

Print all images

DPOF printing

Cancel

PictBridge

Set

2005

05 .

2005

05 .

PRINT SELECTION

Set

Back

2005

05 .

2005

05 .

PRINT SELECTION

Set

Back

2005

05 .

2005

05 .

PRINT SELECTION

Set

Back

2005

05 .

2005

05 .

PRINT SELECTION

Set

Back

CONFIRM

Exit

Printing Via Direct USB Connection

More on Playback

Display confirmation dialog. Press the multi selector up or down to highlight option,

and press I (the center of the multi selector) to select.

• Select Start print to start printing. To interrupt printing, press I, then turn

camera off and disconnect USB cable.

• Select Back to return to print selection dialog shown in Step 5.

• Select Cancel to exit without printing pictures.

• Select Resume to return to Step 3.

Message shown above at right is displayed when printing is complete. Turn cam-

era off and disconnect USB cable.

To print the current print order:

Highlight DPOF printing. Display options.

Highlight Confirm. To exit without

printing pictures, highlight Cancel and

press I.

Display print order. Press the multi selec-

tor up, right, left, or down to view pic-

tures not visible in display.

PRINT SELECTION

Set

Back

Cancel

Start print

Printer ready?

007

prints

Printing

002/007

Cancel

Done

Resume

YOU MAY TURN

OFF THE CAMERA

ޓޓ

Print selection

Print all images

DPOF printing

Cancel

PictBridge

Set

DPOF PRINTING

Set

Confirm

Cancel

Start print

Printer ready?

007

prints

DPOF PRINTING

Set

Confirm

Cancel

Start print

Printer ready?

007

prints

CONFIRM

Exit

Printing Via Direct USB Connection

More on Playback

Display confirmation dialog. Press the multi selector up or down to highlight option, press

I (the center of the multi selector) to select.

• Select Start print to start printing. To interrupt printing, press I, then turn

camera off and disconnect USB cable.

• Select Cancel to exit without printing pictures.

Message shown above at right is displayed when printing is complete. Turn camera

off and disconnect USB cable.

Before Printing

Before printing via direct USB connection, make sure that the printer supports PictBridge or USB

Direct and check printer settings. See the printer manual for details.

Use a Reliable Power Source

When printing pictures via direct USB connection, be sure the battery is fully charged. If in doubt,

recharge the battery before printing or use the optional EH-62B AC adapter.

DPOF Printing

The DPOF printing option is only available if a print order has been created.

Error Messages

If an error message is displayed, an error has occurred. After checking the

printer and resolving any problems as directed in the printer manual, high-

light Resume and press I to resume printing. Select Cancel to exit with-

out printing the remaining images.

PictBridge

PictBridge is an industry standard for direct printing that ensures compatibility when different de-

vices are connected.

DPOF PRINTING

Set

Confirm

Cancel

Start print

Printer ready?

007

prints

Printing

002/007

Cancel

Done

Resume

YOU MAY TURN

OFF THE CAMERA

PRINTER ERROR

CHECK PRINTER

STATUS

Resume

Cancel

Movies

W Recording Movies

Movies can be recorded with sound recorded via the camera's built-in micro-

phone, using the E5600, or silent movies using the E4600:

Rotate the mode dial to W

Turn the camera on

The monitor shows the length of the movie that

can be recorded.

Start recording

Press the shutter-release button all the way down

to start recording. During recording, the zREC

icon blinks and progress is shown by the indicator

at the bottom of the monitor.

• Recording will end automatically when no

more memory is available in the memory or on

the memory card.

0h 0m20s

0h 0m12s

W Recording Movies

Movies

The type of movie recorded can be selected from the following options:

Total recording time shown is approximate. Time may vary depending on type of memory card

used.

*2 Total recording time is shorter with E5600 because movie is recorded with sound.

Flash Mode Selection in W Mode

The flash turns off ($) automatically when movie mode is selected.

Digital Zoom

Digital zoom can not be used while recording is in progress.

Macro Close-up Mode in W Mode

Macro close-up turns off automatically when focus mode is set to Continuous AF. If using

Macro close-up, set focus mode to Single AF.

Notes on Movies

Depending on the make of memory card used, recording may end before the memory card

is full (Q 109). During recording with E5600, do not touch the built-in microphone. To pre-

vent the sound of the camera focusing from interfering with recording, select a focus mode

of Single AF.

Movies

Movies are recorded as Quick Time movie files with the extension ".MOV" and can be

played back on a computer after transfer.

Movie Menu Help

Pressing O (T) button when displaying the MOVIE menu displays the help for the selected

item.

Typ e Description

Length of movie *1*2

Memory

Memory card

14 MB 128 MB

256 MB

TV movie 640

Movies are recorded at a rate of 15 frames

per second. Vertical interlacing is used to

achieve a size of 640 × 480 pixels, suitable

for television playback.

Approx.

24 s

Approx.

3 m 40 s

Approx.

7 m 23 s

Small size 320

(default option)

Movies are recorded at a rate of 15 frames

per second. Each frame has a size of 320 ×

240 pixels.

Approx.

49 s

Approx.

7 m 21 s

Approx.

14 m 47 s

Smaller size 160

Movies are recorded at a rate of 15 frames per

second.

Each frame has a size of 160 × 120 pixels.

Small size allows longer movies to be recorded.

Approx.

3 m 43 s

Approx.

33 m 7 s

Approx.

1 h

6 m 34 s

W Recording Movies

Movies

To select a movie mode:

Select W Mode. Display MOVIE menu.

Highlight Movie options. Display MOVIE OPTIONS menu.

Highlight mode.*

*To exit without changing mode,

press ^ button.

Make selection to return to the MOVIE

menu.

Return to shooting mode. Selected movie

mode shown in monitor.

0h 0m20s

Movie options

Auto-focus mode

MOVIE

Set

Help

Exit

Movie options

Auto-focus mode

MOVIE

Set

Help

Exit

TV movie 640

Small size 320

Smaller size 160

MOVIE OPTIONS

Set

Exit

TV movie 640

Small size 320

Smaller size 160

MOVIE OPTIONS

Set

Exit

0h 0m 8s

Movie options

Auto-focus mode

MOVIE

Set

Help

Exit

W Recording Movies

Movies

The MOVIE menu also includes the following focus options:

To choose a focus option from the MOVIE menu:

Highlight Auto-focus mode. Display options.

Highlight desired focus mode. Make selection.

Return to shooting mode.

Focus mode Description

Single AF Camera focuses when shutter-release button is pressed halfway.

Focus locks when focus operation is complete.

Continuous AF

Camera adjusts focus when necessary.

Help

Movie options

Auto-focus mode

MOVIE

Set

Exit

Single AF

Continuous AF

AUTO-FOCUS MODE

Set

Exit

Single AF

Continuous AF

AUTO-FOCUS MODE

Set

Exit

Help

Movie options

Auto-focus mode

MOVIE

Set

Exit

0h 0m20s

Movies

Viewing Movies

In full-screen playback mode (Q 22), movies can be

played with sound (E5600 only). Movies are indicated

by a W icon and can be viewed by pressing I (the

center of the multi selector). Playback controls are

displayed at the top of the monitor; press the multi

selector to left or right to highlight a control, then

press I to perform the selected operation.

Playback Volume (E5600 only)

The zoom buttons control volume during playback. Press l (W) to decrease volume, O (T)

to increase.

Deleting Movies

To delete a movie, press the u button. A confirmation dialog will be displayed; press the

multi selector up or down to highlight an option, then press the center of the multi selector.

•Yes: delete movie and return to full-screen playback

•No: exit to full-screen playback without deleting movie

To Press Description

Rewind (While movie is in progress, use multi selector to select

( icon, then press and hold center of multi selector.

Fast forward *

Use multi selector to select * icon, then press and

hold center of multi selector. Playback ends at the last

frame; once playback has ended, the first frame of

movie will be displayed.

Pause playback )Use multi selector to select ) icon, then press center

of multi selector to pause display.

Rewind movie

one frame ,

When movie is paused, use multi selector to select

icon, then press center of multi selector.

Advance movie

one frame -When movie is paused, use multi selector to select -

icon, then press center of multi selector.

Resume play-

back yWhen movie is paused, use multi selector to select y

icon, then press center of multi selector.

Stop playback =Use multi selector to select = icon, then press center

of multi selector to return to full-screen playback.

0h 0m25s

When Pausing

The Shooting Menu

Using the Shooting Menu

In P (auto) mode, the following settings can be adjusted from the SHOOTING

MENU:

In P (auto) mode, the SHOOTING MENU is displayed when ^ button is

pressed.

To display the SHOOTING MENU:

Icon Type Display

Using the Menus option of the SET-UP menu switches the menu display

between Text and Icons (Q 103).

Option Description Q

Image mode Choose image size and quality. 67-68

White balance Match white balance to your light source. 69

Exp. +/- Adjust exposure for very bright, very dark, or high-

contrast subjects. 71

Continuous Take pictures one at a time or in a sequence. 72

BSS Turn the Best Shot Selector (BSS) on or off. 73

Color Options Choose a standard color, vivid color, black-and-white,

sepia, or cyanotype effect for your pictures. 74

Image mode

White balance

Exp. +/-

Continuous

BSS

SHOOTING MENU 1/2

Set

Exit

Help

Image mode

Set

Help

Exit

Using the Shooting Menu

The Shooting Menu

To make a selection from the SHOOTING MENU:

Highlight menu item.

Highlight option. To return to previous

step, press the multi selector to left.

Display options.

Make selection. To exit menu and return

to shooting mode, press ^ button.

Shooting Menu Help

Pressing O(T) button when displaying the SHOOTING MENU displays the

help for the selected item.

Help

Image mode

White balance

Exp. +/-

Continuous

BSS

SHOOTING MENU 1/2

Set

Exit

+0.7

+0.3

Set

Exit

EXP. +/-

Set

Exit

EXP. +/-

+0.3

-0.3

AUTO

+0.3

Set image quality and

size.

Image mode

Back

Exit

The Shooting Menu

Image Mode

Image mode

Pictures taken with a digital camera are recorded as

image files. The size of the files, and with it the num-

ber of images that can be recorded in the memory or

on the memory card, depends on the size and quality

of the images. Before shooting, choose image quality

and size according to how you plan to use the picture.

* To reduce the amount of memory each shot occupies, pictures are compressed as they are saved

to the memory or memory card. Compression selectively reduces the quality of the image. The

more a picture is compressed, the more noticeable this loss of quality is likely to be. The figures

show the appropriate compression ratio for each setting.

† All figures are approximate. Dimensions in "Description" column assume a printer resolution of

approximately 200 dpi, dimensions in "Print size" column a resolution of approximately 300 dpi.

If in doubt, choose

Normal (2592)

Normal (2288)

. Pictures can be re-

duced or cropped when played back in the monitor after shooting (

44, 83).

Option Size

(pixels) Quality* Description Print size

(cm)†

G (2592*)

(E5600 only)

2,592 ×

1,944 1 : 4 High quality, suitable for enlarge-

ments or high-quality prints.

22 × 16.5

(8.6” × 6.5”)

E (2288*)

(E4600 only)

2,288 ×

1,712

19 × 14

(7.5” × 5.5”)

H (2592)

(E5600 only)

2,592 ×

1,944 1 : 8 Best choice in most situations.

22 × 16.5

(8.6” × 6.5”)

F (2288)

(E4600 only)

2,288 ×

1,712

19 × 14

(7.5” × 5.5”)

b (2048)

(E5600 only)

2,048 ×

1,536 1 : 8 Smaller size allows more pictures to

be stored on memory card.

17 × 13

(7” × 5”)

c (1600)

(E4600 only)

1,600 ×

1,200

13 × 10

(5” × 4”)

S PC screen

(1024)

1,024 ×

768 1 : 8 Suited to display on computer moni-

tors 17” or larger.

9 × 7

(3.5” ×

2.5”)

R TV screen

(640)

640 ×

480 1 : 8

Can be displayed full-screen on a

television or 13” monitor. Suited to

distribution by e-mail or the web.

5 × 4

(2” ×

1.5”)

High(2592 )

Normal(2592)

Normal(2048)

PC screen(1024)

TV screen(640)

IMAGE MODE

Set

Exit

Image Mode

The Shooting Menu

The following table shows the approximate number of pictures that can be

stored in the memory or on 128- and 256-megabyte memory cards at different

image mode settings.

*All figures are approximate. File size of pictures depends on scene recorded, producing wide vari-

ations in number of images that can be stored.

Image Mode and Number of Exposures Remaining

The figure shown in the monitor for the number of exposures remaining is only an approximation.

The file size of compressed images varies with the scene recorded, producing wide variations in the

number of pictures that can be stored.

Image Size

Smaller images create smaller files suited to transmission by e-mail or use in web pages. When

printed at larger sizes, however, small images will be rough and uneven in appearance.

Print Size

The size of images when printed depends on the printer resolution: the higher the resolution, the

smaller the final print size.

Image Mode

The current image mode setting is shown by an icon at the bottom left

corner of the monitor.

Image mode Memory Memory card

14 MB 128 MB 256 MB

High (2592*) (E5600 only) Approx. 5 Approx. 49 Approx. 99

High (2288*) (E4600 only) Approx. 7 Approx. 64 Approx. 129

Normal (2592) (E5600 only) Approx. 10 Approx. 97 Approx. 195

Normal (2288) (E4600 only) Approx. 14 Approx. 125 Approx. 252

Normal (2048) (E5600 only) Approx. 17 Approx. 153 Approx. 308

Normal (1600) (E4600 only) Approx. 27 Approx. 239 Approx. 482

PC screen (1024) Approx. 57 Approx. 511 Approx. 1028

TV screen (640) Approx. 123 Approx. 1096 Approx. 2203

AUTO

The Shooting Menu

White Balance

White balance

The color of the light reflected from an object varies

with the color of the light source. The human brain is

able to adapt to such changes in color, with the result

that we see white objects as white, regardless of

whether they are in the shade, direct sunlight, or under

incandescent lighting. Digital cameras can mimic this

adjustment by processing information from the cam-

era’s image sensor (CCD) according to the color of the

light source. This process is known as a "white balance

adjustment."

• If you cannot achieve the desired white balance with Auto (M) or you want to

lock the white balance for a specific light source or shooting conditions,

choose a setting other than Auto (M).

• When the white balance setting is changed, the new setting is reflected in the

picture in the monitor.

Option Description

M Auto White balance automatically adjusted to suit lighting condi-

tions. Best choice in most situations.

n White bal. preset Gray object used as reference to set white balance under

unusual lighting conditions.

Daylight White balance adjusted for direct sunlight.

Incandescent Use under incandescent lighting.

Fluorescent Use under most types of fluorescent lighting.

Cloudy Use when taking pictures under overcast skies.

Speedlight Use with the flash.

Set

Exit

Auto

White bal. preset

Daylight

Incandescent

Fluorescent

White balance 1/2

A-WB

PRE

White Balance

The Shooting Menu

Preset White Balance

Preset white balance is used when shooting under

mixed lighting or to compensate for light sources with

a strong color cast (for example, to make pictures tak-

en under a lamp with a red shade look as though they

had been taken under white light). When White bal.

preset is selected from the WHITE BALANCE menu,

the camera will zoom in and the menu shown at right

will be displayed in the monitor.

White Balance

At settings other than auto, white balance is shown by an icon in the mon-

itor.

Option Description

Cancel Recalls the most recent value for preset white balance from memory and

sets white balance to this value.

Measure

To measure a new value for white balance, place a gray object, such as a

piece of cardboard, under the lighting that will be used in the final picture.

Frame this object so that it fills the square in the center of the menu shown

above. Highlight Measure and press I (the center of the multi selector)

to measure a new value for white balance (shutter will be released and

camera will return to original zoom position, but no picture will be

recorded).

WHITE BAL PRESET

Set

Exit

Cancel

Measure

White balance measuring

window

AUTO

The Shooting Menu

Exp. +/-

The EXP. +/- (exposure compensation) menu is used

to alter exposure from the value suggested by the

camera, making pictures brighter or darker. Exposure

can be adjusted in the range -2.0 to +2.0 EV.

• When the exposure compensation is altered, the

new setting is reflected in the picture in the moni-

tor.

Choosing an Exposure Compensation Value

As a rule of thumb, select positive values when large areas of the frame are very brightly lit (for ex-

ample, when photographing an expanse of sunlit water, sand, or snow) or when the background

is much brighter than the main subject. Choose negative values when large areas of the frame are

very dark (for example, when photographing a forest of dark green leaves) or when the back-

ground is much darker than the main subject. This is because the camera, in order to avoid extreme

over- or under-exposure, tends to lower exposure when the frame is very bright and raise exposure

when the frame is very dark, which can make naturally bright subjects look dim and naturally dark

subjects appear over-bright, or "washed out."

Exposure Compensation

At settings other than 0, exposure compensation is shown in the monitor.

Set

Exit

EXP. +/-

+0.3

-0.3

AUTO

+1.0

The Shooting Menu

Continuous

Use the options in this menu to capture a fleeting ex-

pression on a portrait subject, photograph a subject

that is moving unpredictably, or capture motion in a

series of pictures.

Restrictions on Camera Settings

At settings other than Single, the flash (Q 24) turns off automatically and focus (Q 20), exposure

(Q 71), and auto white balance (Q 69) for all photos are determined by the first picture in each

series. When Multi-shot 16 is selected, digital zoom (Q 18) can not be used. Multi-shot 16 can

not be selected when digital zoom is in effect. BSS (Q 73) is available only at a setting of Single.

Continuous

At settings other than Single, the current Continuous setting is indicated

by an icon in the monitor.

Option Description

Single Camera takes one picture each time shutter-release button is

pressed.

Continuous

Camera takes pictures continuously while shutter-release button is

held down. Pictures are recorded at a rate of about three frames

every two seconds. With E5600, camera records eleven pictures

when image mode is set to H Normal (2592). With E4600,

camera records eight pictures when image mode is set to F

Normal (2288).

Multi-shot 16

When shutter-release button is pressed all the way, camera takes

sixteen consecutive images at a rate of about four frames every

two seconds. The sixteen images are arranged in four rows of four

images and saved as a single picture. Image mode is fixed at H

Normal (2592) with E5600 and F Normal (2288) with E4600.

Set

Exit

Single

Continuous

Multi-shot 16

CONTINUOUS

The Shooting Menu

Best Shot Selector

BSS

When the "Best Shot Selector" (BSS) is on, the cam-

era takes pictures as long as the shutter-release but-

ton is held down, to a maximum of ten. These images

are then compared and the sharpest picture (the pic-

ture with highest level of detail) saved to the memory

or memory card. BSS is recommended for situations in

which inadvertent camera movement can produce

blurred pictures, for example when:

• the camera is zoomed in

• lighting is poor and the flash can not be used

Notes on BSS

BSS may not produce the desired results with a moving subject or if you change the composition

while the shutter-release button is pressed all the way down.

"Continuous" and BSS

CONTINUOUS is automatically set to Single when BSS is on. Choosing another option for CON-

TINUOUS cancels BSS.

The Self-Timer

BSS will not take effect when the self-timer is on, even if On is selected in the BEST SHOT SELEC-

TOR menu.

BSS

When BSS is on, a BSS icon appears in the monitor.

Option Description

Off BSS off; camera functions normally.

BSS on. Flash turns off automatically and focus, exposure, and auto

white balance for all photos are determined by the first picture in each

series.

Set

Exit

Off

BEST SHOT SELECTOR

The Shooting Menu

Color Options

Use the options in this menu to add special effects to

your pictures. There are five special effects to choose

from.

• The effect you choose is reflected in the picture dis-

played in the monitor.

White Balance

When Black-and-white, Sepia or Cyanotype is selected, the White balance option is not avail-

able in the SHOOTING MENU.

Color Options Indicator

When an option other than Standard color is chosen, the selected mode

indicator is displayed in the monitor.

Option Description

Standard color Picture appears with natural colors.

Vivid color Picture appears in sharp colors.

Black-and-white Picture appears in black and white.

Sepia Picture appears in sepia tones.

Cyanotype Picture appears with blue cast.

Standard color

Vivid color

Black-and-white

Sepia

Cyanotype

COLOR OPTIONS

Set

Exit

AUTO

The Playback Menu

Using the Playback Menu

The PLAYBACK MENU contains the following options:

To display the PLAYBACK MENU:

Display the PLAYBACK MENU.

Option Description Q

Print set

Select pictures for printing on a DPOF-compatible device;

specify number of copies and information to be included on

prints.

52-55

Slide show View pictures in the memory or on the memory card in an

automatic slide show. 77

Delete Delete all or selected pictures. 78-79

Protect Protect selected pictures from accidental deletion. 80

Transfer

marking

Mark all or selected pictures for transfer to a computer; turn

auto transfer marking on or off. 81-82

Small pic. Create small copies of pictures. 83

Copy

Transfer pictures from internal memory to memory card or

vice versa. (This option is displayed only when the memory

card is inserted.)

84-86

Print set

Slide show

Delete

Protect

Transfer marking

PLAYBACK MENU 1/2

Help

Set

Exit

Using the Playback Menu

The Playback Menu

Icon Type Display

Using the Menus option of the SET-UP menu switches the menu display

between Text and Icons (Q 103).

Playback Menu Help

Pressing O(T) button when displaying the PLAYBACK MENU displays the

help for the selected item.

Print set

Set

Help

Exit

Select pictures for

DPOF printing and

choose the number of copies.

Print set

Back

Exit

The Playback Menu

Slide Show

Slide show

This option is used to play pictures back in an automated "slide show" with

about three seconds between each picture.

Highlight Start. Begin slide show.

The following operations can be performed during the show:

"Loop"

If Loop is selected in the starting screen, the slide show will repeat auto-

matically. To select or deselect the Loop option, highlight Loop and press

I. A check mark next to Loop indicates that the Loop option is selected.

Auto Off

The camera will enter standby mode if no operations are performed for thirty minutes during a slide show.

Small Pictures and Movies

Copies created with the small picture option (Q 83) are not displayed during slide shows. Movies

are displayed as still images showing the movie’s first frame.

SLIDE SHOW

Set

Exit

Pause

Start

Loop

To Press Description

Pause slide

show

Menu shown right will be dis-

played. Highlight Restart and press

I (the center of the multi selector)

to resume show. Highlight End and

press I to end show.

Skip to next

frame

Press the multi selector to right or down to skip to next

slide. Hold the multi selector down to fast forward

through show.

Return to

frame

Press the multi selector to left or up to return to previous

slide. Hold the multi selector down to rewind through

show.

End slide

show ^End slide show and return to playback.

Restart

Exit

Set

End

Pause

SLIDE SHOW

Set

Exit

Pause

Start

Loop

The Playback Menu

Delete

The DELETE menu contains the following options:

If no memory card is inserted in the camera, pictures

in the internal memory will be deleted.

If the camera contains a memory card, pictures on the

card will be deleted.

To delete pictures in the internal memory, re-

move the memory card.

Deleting Selected Pictures

Highlight Erase selected images.

Highlight picture.

Pictures in memory or memory card dis-

played as thumbnail images.

Select highlighted picture. Selected pic-

tures marked by u icon.

Repeat steps 3 and 4 to select additional pictures. To deselect picture, highlight and

press the multi selector down. To exit without deleting pictures, press ^ button.

Erase selected images

Erase all images

DELETE

Set

Exit

Erase selected images

Erase all images

DELETE

Set

Exit

2005

05 .

2005

05 .

Set

ERASE SELECTED IMAGES

Back

OFF

2005

05 .

2005

05 .

Set

ERASE SELECTED IMAGES

Back

OFF

2005

05 .

2005

05 .

Set

ERASE SELECTED IMAGES

Back

OFF

Delete

The Playback Menu

Confirmation dialog displayed. Select Yes

to delete pictures, No to exit without de-

leting pictures.

Deleting All Pictures

To delete all unprotected pictures in the memory or on the memory card:

Highlight Erase all images. Confirmation dialog displayed. Select

Yes to delete pictures, No to exit with-

out deleting pictures.

Before Deletion

Once deleted, pictures can not be recovered. Be sure that any pictures you would like to keep

have been transferred to a computer (Q 49-51).

Protected Pictures

Pictures marked with a U icon are protected and can not be deleted (Q 80).

Set

Erase 1 image (s)?

Yes

DELETE

Back

ޓޓ

Erase selected images

Erase all images

DELETE

Set

Exit

Set

Erasing all images

Yes

DELETE

Back

( excluded)

The Playback Menu

Protect

This option is used to protect pictures from accidental deletion. Protected files

can not be deleted by pressing the u button or using the options in the DELETE

menu. Note, however, that protected pictures will be deleted when the memory

or memory card is formatted.

Highlight picture.

Repeat steps 1 and 2 to select addi-

tional pictures. To deselect picture,

highlight and press multi selector

down. To exit without changing pro-

tected status of pictures, press ^

button.

Select highlighted picture. Selected pic-

tures marked by U icon.

Complete operation and return to the

PLAYBACK MENU.

Notes on Protecting Pictures

Protected pictures cannot be deleted using the Delete button or menu. However, all pictures, in-

cluding protected files, will be deleted when the memory or memory card is formatted.

The Protect Icon

During playback, a protect icon appears on all protected pictures.

2005

05 .

2005

05 .

Set

PROTECT

Back

OFF

2005

05 .

2005

05 .

Set

PROTECT

Back

OFF

Done

2005

100NIKON

0001

JPG

0001

JPG

The Playback Menu

Transfer Marking

Transfer marking

This option is used to mark pictures for transfer to a

computer and to turn automatic transfer marking on

and off.

Transferring More than 999 Pictures

No more than 999 pictures can be marked for transfer. If more than 999 pictures are marked,

use PictureProject to transfer the pictures. See the PictureProject Reference Manual (on CD)

for details.

Hidden Pictures

Some Nikon digital cameras allow you to hide pictures during playback. Hidden pictures can be

viewed on the E5600/E4600 but can not be selected for transfer.

The V Icon

Pictures that have been selected for transfer are identified by a V icon.

When you connect the camera to a computer via the UC-E6 USB cable and press

(the center of the multi selector) to transfer pictures, only pictures marked with a

icon will be transferred (

49).

Option Description

VAll on

(default option)

All pictures in memory or on memory card are marked for

transfer.

All off Remove transfer marking from all pictures in memory or

on memory card.

Select image(s) Mark selected pictures for transfer.

All on

All off

Select image(s)

TRANSFER MARKING

Set

Exit

2005

13:

100NIKON

0001.

JPG

0001.

JPG

Full-screen playback Thumbnail playback

Transfer Marking

The Playback Menu

Marking Selected Pictures for Transfer

Highlight Select image(s).

Highlight picture.

Repeat steps 3 and 4 to select addi-

tional pictures. To deselect picture,

highlight and press the multi selec-

tor down. To exit without changing

transfer status of pictures, press ^

button.

Pictures in memory or on memory card

displayed as thumbnail images.

Select highlighted picture. Selected pic-

tures marked by V icon.

Complete operation.

Marking Pictures for Transfer with Other Cameras

Pictures selected for transfer with another model of Nikon camera can not be transferred when the

memory card is inserted in the E5600/E4600. Use the E5600/E4600 to reselect the pictures.

All on

All off

Select image(s)

TRANSFER MARKING

Set

Exit

2005

05 .

2005

05 .

Set

TRANSFER MARKING

Back

OFF

2005

05 .

2005

05 .

Set

TRANSFER MARKING

Back

OFF

2005

05 .

2005

05 .

Set

TRANSFER MARKING

Back

OFF

Done

The Playback Menu

Small Picture

Small pic.

To create a small copy of a picture, select Small pic. after displaying the image

in full-screen playback or selecting it in the thumbnail display.

Highlight option. Confirmation dialog displayed. Select

Yes to create resized copy, No to exit

without creating copy.

To view the new, resized copy, press the multi selector down until the copy is dis-

played. The copy will be displayed after the last picture recorded (in thumbnail

playback, small pictures are indicated by a gray border). To reduce file size, copies

are stored in the memory or on the memory card as BASIC-quality JPEG files

(compression ratio 1 : 16). Copies are stored in separate files with names in the

form "SSCNnnnn.JPG." "nnnn" is a four-digit number assigned automatically by

the camera.

Copies can not be viewed or cropped using playback zoom.

Small Picture

Small pictures can not be created from resized copies or cropped copies.

Option Size (pixels) Description

q 640 × 480 640 × 480 Copy can be displayed full-screen on television or 13”

monitor with no drop in quality.

r 320 × 240 320 × 240 Suited to display on web pages. Small file size reduces

time needed to display picture in web browser.

s 160 × 120 160 × 120

Copy can be sent and received quickly as e-mail attach-

ment. Where application supports display of JPEG

images, picture can be viewed in message window.

640 × 480

320 × 240

160 × 120

SMALL PIC

Set

Exit

Yes

Save this image as

displayed?

Save this image as

displayed?

Set

Exit

The Playback Menu

Copy

This option is used to transfer pictures from the cam-

era's internal memory to the memory card, or vice

versa.

} indicates the camera's internal memory and /

the memory card.

This option is displayed only when the memory card

is inserted.

Copying Selected Pictures

Highlight (memory → memory

card) or (memory card → memo-

ry), press the multi selector to right.

Pictures in memory or on memory card

are displayed. (Based on when is

selected in step 1)

Highlight Selected images.

Highlight picture.

COPY

Set

Exit

COPY

Set

Exit

COPY

2005

05 .

2005

05 .

Set

Back

Selected images

All images

CAMERA TO CARD

Set

Exit

2005

05 .

2005

05 .

COPY

Set

Back

Copy

The Playback Menu

Select highlighted picture.

Selected pictures marked by A icon.

Repeat steps 4 and 5 to select additional

pictures. To deselect picture, highlight

and press the multi selector down.

Confirmation dialog displayed. Select

Yes to copy pictures, No to exit without

copying pictures.

Copying All Pictures

To copy all pictures in the memory or on the memory card:

Highlight (memory → memory

card) or (memory card → memo-

ry), press multi selector to right.

Confirmation dialog displayed. Select

Yes to copy pictures, No to exit without

copying pictures.

Highlight All images.

2005

05 .

2005

05 .

COPY

Set

Back

Selected images

will be copied. OK?

Selected images

will be copied. OK?

Yes

CAMERA TO CARD

Set

Back

COPY

Set

Exit

Set

All images will be

copied. OK?

All images will be

copied. OK?

Yes

CAMERA TO CARD

Back

ޓޓޓ

ޓޓ

Selected images

All images

CAMERA TO CARD

Set

Exit

Copy

The Playback Menu

Copy

• If there is not enough space in the memory or on the memory card to receive the copy,

the message "IMAGE CANNOT BE SAVED" will be displayed (Q 109). Delete unwanted

pictures or insert a new memory card (if using a memory card) before trying again.

• Copying of pictures taken with another make of camera or retouched on a computer is

not guaranteed by Nikon.

File Number

• When pictures are copied using the All images option, all the pictures in the folder are

copied with the same file numbers. The newly copied folder is assigned the lowest avail-

able number.

• When pictures are copied using the Selected images option, the newly copied pictures

are numbered consecutively from the largest number existing between the two memory

sources.

Ex: when the last number in the source memory is 32 (DSCN0032.JPG) and the last number

in the destination memory is 15 (DSCN0015.JPG)

The copied pictures are assigned numbers starting from DSCN0033.

After that, numbering will continue from the lowest number after the number of the last

file that was copied.

Print Set

If a print order has been created, the print order data will not be copied with the picture.

The Set-up Menu

Using the Set-up Menu

The SET-UP menu contains the following options:

To clear the SET-UP menu from the monitor, rotate the mode dial to another setting or

press the

button.

Option Description Q

Welcome screen Choose the welcome screen displayed when the camera

is turned on. 89

Date Set the camera clock. 90-91

Monitor settings Hide or display the monitor indicators and set the moni-

tor brightness. 92

Date imprint Imprint pictures with the date and/or time of recording. 93

Sound settings Adjust volume of button, shutter and start-up sounds. 94

Blur warning Choose whether or not to perform a camera shake

check. 95

Auto off Choose how long the monitor will remain on before

turning off automatically to save power. 96

Format memory/

card

Format internal memory or memory cards for use in the

camera. 97

Language Choose a language for camera menus and messages. 99

Interface Set USB mode or the video mode. 49, 99

Auto transfer Choose whether or not to set Transfer marking

option to the picture taken. 100

Reset all Restore camera settings to default values. 100

Battery type Choose the type of batteries inserted in the camera. 102

Menus Choose a type of the camera menu. 103

Firmware version Display the current firmware version. 104

Welcome screen

Date

Monitor settings

Date imprint

Sound settings

SET-UP

1/3

SET-UP

1/3

Set

Help

Using the Set-up Menu

The Set-up Menu

Icon Type Display

Using Menus option of the SET-UP menu switches the menu display be-

tween Text and Icons (Q 103).

Set-up Menu Help

Pressing O(T) button when displaying the SET-UP menu displays the help

for the selected item.

Welcome screen

Set

Help

Choose the image

displayed when the

camera is turned on.

Welcome screen

Back

The Set-up Menu

Welcome Screen

Welcome screen

This option is used to choose the welcome screen displayed

when the camera is turned on.

Small Pictures and Cropped Copies

Resized copies created with the small picture and cropping options can only be selected for the

welcome screen if they are (q) 640 × 480 pixels or larger.

"Select an Image"

When

Select an image

is selected, the chosen picture will appear

at startup even when the memory card containing the image is re-

moved from the camera. If you select

Select an image

after choos-

ing a custom welcome screen, the confirmation dialog shown at

right will be displayed. Select

Yes

to choose a new picture for the

welcome screen,

to exit leaving the welcome screen unchanged.

Option Description

Disable welcome

No welcome screen is displayed when camera is turned on.

Nikon Image shown at right is displayed when camera

is turned on.

Animation

(default option)

Short animation is displayed when camera is

turned on.

Select

an image

You can choose the welcome screen from pic-

tures currently stored in the memory or on the

memory card.

1 The SELECT IMAGE screen is displayed. High-

light a picture using the multi selector.

2 Press I (the center of the multi selector).

To select a picture stored in the camera

memory, remove the memory card.

Disable welcome

Nikon

Animation

Select an image

Set

WELCOME IMAGE SELECT

2005

05 .

2005

05 .

Set

Back

SELECT IMAGE

Set

Replace current

image?

Replace current

image?

Yes

WELCOME IMAGE SELECT

The Set-up Menu

Date

This option is used to set the camera clock.

This option is available after you have set the camera clock

when using your camera for the first time. For more infor-

mation on setting the camera clock, see "First Steps: Basic

Setup" (

14).

The Camera Clock

The camera clock is less accurate than most watches or household clocks. Check the clock regularly

against more accurate timepieces and reset as necessary.

Option Description

Date Set the date and time (Q 14).

Time zone

Select the time zone.

The normal time zone setting is (home time

zone).

If you select (travel destination time zone),

the time difference is automatically calculated

and the date and time in the selected region are

displayed.

1 Press the multi selector up or down to high-

light or , then press I (the center of

the multi selector).

Press the multi selector down to highlight

DaylightSaving and press I. The h icon

is displayed. Selecting daylight saving time

automatically advances the time one hour. To

cancel daylight saving time, press I again.

2 Press the multi selector right to display the

time zone screen.

3 Press the multi selector left or right to high-

light a time zone (region), then press I.

Date

Time zone

DATE

Set

2005. 0 1. 0 1 00 : 00

DaylightSaving

London, Casablanca

2005.

6. 13

DaylightSaving

Tokyo, Seoul

TIME ZONE

Set

Back

HOME TIME ZONE

London, Casablanca

Date

The Set-up Menu

(Travel Destination Time Zone)

To set the clock to the travel destination time zone, high-

light and press I (the center of the multi selector). While

the travel destination time zone is selected, a icon will

be displayed in the monitor when the camera is in shooting

mode. To choose a new travel destination, highlight and

press the multi selector to the right, then choose a location

as described on the previous page.

DaylightSaving (Daylight Saving Time)

To turn daylight saving time on or off, highlight DaylightSaving and press I.

Selecting daylight saving time automatically advances the time one hour.

The camera supports the following time zones:

Time Zones

The time zone can not be selected if the date and time have not been set.

Time zone increments of less than one hour are not supported. When travelling to or from

destinations at half- or quarter-hour increments from Greenwich Mean Time (GMT), such as

Afghanistan, Central Australia, India, Iran, Nepal, or Newfoundland, set the camera clock to

local time (Q 14).

GMT +/– Location GMT +/– Location

GMT –11 Midway, Samoa GMT –1 Azores

GMT –10 Hawaii, Tahiti GMT London, Casablanca

GMT –9 Alaska, Anchorage GMT +1 Madrid, Paris, Berlin

GMT –8 PST (PDT): Los Angeles,

Seattle, Vancouver

GMT +2 Athens, Helsinki

GMT +3 Moscow, Nairobi

GMT –7 MST (MDT): Denver,

Phoenix, La Paz

GMT +4 Abu Dhabi, Dubai

GMT +5 Islamabad, Karachi

GMT –6 CST (CDT): Chicago,

Houston, Mexico City

GMT +6 Colombo, Dhaka

GMT +7 Bangkok, Jakarta

GMT –5 EST (EDT): New York

Toronto, Lima

GMT +8

Beijing, HK, Singapore

GMT +9 Tokyo, Seoul

GMT –4 Caracas, Manaus GMT +10 Sydney, Guam

GMT –3 BuenosAires, SanPaulo GMT +11 New Caledonia

GMT –2 Fernando de Noronha GMT +12 Auckland, Fiji

AUTO

The Set-up Menu

Monitor Settings

Monitor settings

This option is used to set the monitor display.

Photo Info

Select this option to hide or display the

monitor indicators, or turn the monitor off.

Brightness

Press the multi selector up or down to

increase or decrease the brightness of the

monitor by moving the indicator on the left

of the display up or down. Press

(the

center of the multi selector) to make a

selection. To return to the SET-UP menu,

press the multi selector to the left.

Option Description

Show info Display current settings in monitor when taking or viewing pictures.

Hide info Current settings are hidden.

Monitor off Turn the monitor off (P mode only).

Photo info

Brightness

MONITOR SETTINGS

Set

Show info

Hide info

Set

PHOTO INFO

Monitor off

Set

BRIGHTNESS

The Set-up Menu

Date Imprint

Date imprint

The

Date imprint

option is used to imprint the date or the

date and time of recording on pictures as they are recorded

to the memory or memory card. It can not be used to im-

print a date stamp on pictures after recording.

Image Mode

Data imprinted at an Image mode setting of TV screen (640) may be difficult to read. Choose a

setting of PC screen (1024) or larger when using the Date imprint option.

Date Imprint

Imprinted data forms a permanent part of the image and will appear

whenever the image is printed, regardless of whether the Date option is

chosen in the PRINT SET menu. At settings other than Off, a Date icon is

displayed in the monitor during shooting. Check before shooting to make

sure that the camera clock is set to the correct time and date.

The date is recorded in the order selected in the DATE menu. You will not

be able to select Date or Date and time if the camera clock has not been set.

When shooting with the following, Date imprint is automatically canceled.

E5600: KPANORAMA ASSIST (Q 40) and Movie (Q 60)

E4600: DBSS (Q 73), CContinuous in the CONTINUOUS menu (Q 72), jSPORTS

and \SPORTS SPECTATOR in the j (Sports assist) mode (Q 33),

KPANORAMA ASSIST (Q 40) and Movie.

Print Set

The Print set option can be used to print the date and time of recording on images taken with Off

selected in the DATE IMPRINT menu.

Option Description

Off Time and date do not appear on pictures.

Date Date is imprinted at bottom right corner of all pictures taken

while this option is in effect.

Date and time Date and time are imprinted at bottom right corner of all pic-

tures taken while this option is in effect.

Off

Date

Date and time

DATE IMPRINT

Set

AUTO

The Set-up Menu

Sound Settings

Sound settings

The options in this menu control the sound settings listed

below.

With E4600, sound settings can only be set

Off

Choosing

Off

mutes button, shutter and start-up sounds.

Tone and volume cannot be adjusted.

Shutter sound

Regardless of setting chosen, no sound is played when j (sports assist) is selected in assist modes

(Q 33), Continuous settings other than Single (Q 72) are set, or D BSS is on (Q 73).

Option Description

Button sound

(E5600 only)

Control the sounds that alert you to camera's

functions:

•When the mode dial is set.

•When the mode is changed

(shooting ↔ playback).

•When menu settings are made.

•When an error occurs.

Shutter sound

(E5600 only)

There are three shutter sounds to choose from.

Press the multi selector up or down to highlight

option, and press I (the center of the multi

selector) to select.

Start-up sound

(E5600 only)

Adjust volume of sound played when camera is

turned on.

Volume

(E5600 only)

Adjust volume of voice memos, movies, and shut-

ter and start-up sounds. Choose volume for built-

in speaker from

Loud

and

Normal

. Choosing

Off

mutes shutter and start-up sounds, and plays

voice memos and movies at lowest volume.

Button sound

Shutter sound

SOUND SETTINGS

Set

Start-up sound

Volume

Set

Off

BUTTON SOUND

Set

SHUTTER SOUND

Off

Set

Off

START-UP SOUND

Set

Loud

Normal

VOLUME

Off

The Set-up Menu

Blur Warning

Blur warning

This option is used to display or hide the camera shake

warning after you have taken a picture.

Selecting

displays the warning only if inadvertent cam-

era movement has caused the picture you have just taken

to be blurred.

Select

Yes

to keep the picture or

to delete it.

Shooting modes where the Blur Warning does not function

In the shooting modes shown below, the blur warning is not available even if Blur warning option

is set to On: CContinuous (Q 72), ]Multi-shot 16 (Q 72), and DBSS (Q 73) modes, as

well as j(sports assist) (Q 33) of assist mode, GMUSEUM (Q 38), HFIREWORKS SHOW

(Q 38), and KPANORAMA ASSIST (Q 40) of scene mode.

Additionally, the Blur warning option is not available when self-timer is on.

Blur Check

If you want to check how blurred the picture is before deciding whether to delete it or not, select

Yes to save the picture and then press x.

Set

Off

BLUR WARNING

Yes

PICTURE IS BLURRED.

SAVE PICTURE?

PICTURE IS BLURRED.

SAVE PICTURE?

Set

The Set-up Menu

Auto Off

Auto off

To save battery power, the camera will enter standby

mode if no operations are performed for a preset

length of time.

Auto off

Sleep mode

AUTO OFF

Set

OFF

Option Description

Auto Off

Choose how long monitor will remain on

before turning off automatically. Choose

from thirty seconds (30s), one minute (1m)

default setting, five minutes (5m) and thirty

minutes (30m). Regardless of option chosen

in the AUTO OFF menu, monitor will remain

on for three minutes when menus are dis-

played. When powered by AC adapter, cam-

era will enter standby mode if no operations

are performed for thirty minutes.

Sleep mode

If On is selected, camera will enter standby

mode when there is no change in brightness

of subject, even before time selected in

AUTO OFF menu has elapsed.

The camera will enter sleep mode after thirty

seconds of non-operation when Auto off is

set to thirty seconds (30s) or one minute

(1m), and after one minute when Auto off

is set to five minutes (5m) or thirty minutes

(30m).

Set

30m

30s

AUTO OFF

Set

Off

SLEEP MODE

The Set-up Menu

Format memory/card

Format card

Format memory

This option is used when you need to format the cam-

era's internal memory or a memory card.

If no memory card is inserted in the camera, the inter-

nal memory will be formatted, and if the camera con-

tains a memory card, the card will be formatted.

To format the internal memory, remove the memory

card.

Highlight Quick format or Format*. To

exit without formatting the memory or

the card, press the multi selector left to

return to the SET-UP menu.

*When the internal memory is format-

ted, start the operation from step 2.

Highlight Format*. To exit without for-

matting the memory or the card, high-

light No and press I (the center of the

multi selector).

*When the memory card is not insert-

ed, the FORMAT MEMORY screen is

displayed.

Begin formatting. While formatting is in

progress, the message shown above will

be displayed.

Quick formatQuick format

Format

Set

MEMORY CARD FORMATMEMORY CARD FORMAT

Quick formatQuick format

Format

Set

MEMORY CARD FORMATMEMORY CARD FORMAT

Set

WARNING!

All images will be

deleted!

WARNING!

All images will be

deleted!

Format

MEMORY CARD FORMATMEMORY CARD FORMAT

FORMATTING

Format memory/card

The Set-up Menu

Formatting Memory/Card

• When formatting memory cards, use the Format card option of the camera. The camera

may be unable to access memory cards formatted using a computer or other device.

• Do not turn the camera off or remove the batteries or memory card when the message

"FORMATTING" is displayed on the monitor.

• When memory or memory cards are formatted, all data in the memory or the memory

cards is deleted. Before formatting transfer the pictures you wish to save to a computer.

Quick format and Format

•When Quick format is selected in the MEMORY CARD FORMAT menu, only the data re-

corded on the card is formatted. This option is used for formatting memory cards that

have been formatted with E5600/E4600.

•When Format is selected in the MEMORY CARD FORMAT menu, the entire card is for-

matted. This option is used for formatting memory cards not formatted with E5600/

E4600.

• New memory cards must be formatted with Format before use.

• Using Format regularly for memory cards is recommended to maintain the performance

of memory cards.

•Format requires more time than Quick format.

•Format is not available when X (Q 12) is displayed.

The Set-up Menu

Language

Choose the language for camera menus and messages from

Deutsch

(German),

English

Español

(Spanish),

Français

(French),

Italiano

(Italian),

Nederlands

(Dutch),

Svenska

(Swedish), (Japanese), (Simplified Chinese),

(Traditional Chinese) or (Korean).

Set USB mode or the video

mode. After choosing

USB

Video

mode

from the

SET-UP menu, choose

PTP

Mass storage

for the

USB

option, or choose

NTSC

PAL

for the

Video

mode

option.

Item Option Description

USB

PTP

Select this option when operating system of the USB

connected computer supports only PTP (Q 49).

Select this option when printing via direct USB con-

nection (Q 56).

Mass storage Select this option when connecting via USB other

than the above.

Video mode

NTSC Select this option when connecting the camera to

NTSC devices.

PAL Select this option when connecting the camera to

PAL devices.

Set

Back

Interface

NTSC

PAL

VIDEO MODE

Set

USB

Video mode

INTERFACE

Set

100

The Set-up Menu

Auto Transfer

Auto transfer

Choose whether or not to set

Transfer marking

option to

the picture taken.

When the

Auto transfer

option is set to

, all pictures

taken are set to be transferred and

icon is added

when displayed.

Select this option to restore the settings listed on the next

page to their original state.

Option Description

V On Select this option to set pictures or movies to be transferred auto-

matically when they are taken or recorded.

Off Select this option to set pictures or movies to not be transferred

automatically when they are taken or recorded.

Option Description

No Exit menu, leaving settings unchanged.

Reset Restore settings to default values.

Off

AUTO TRANSFER

Set

Reset All

Reset all

Set

Reset all settings

to default values

Reset all settings

to default values

Reset

RESET ALL

101

Reset All

The Set-up Menu

The following settings are affected:

Choosing

Reset

also clears the current file number (

23) from memory. Numbering will

continue from the lowest number available in the memory or on the memory card. All oth-

er settings are unaffected.

Resetting File Numbering to 0001

To reset file numbering (Q 23) to 0001, select Reset All after either deleting all pictures (Q 79)

or formatting the memory card (Q 97).

Setting Default

i Portrait assist Portrait

N Landscape assist Landscape

j Sports assist Sports

m Night portrait assist Night Portrait

e Scene PARTY/INDOOR

W Movie Small size 320, Single AF

Speedlight !#

Self-timer Off

Macro close-up Off

Image mode

E5600: Normal (2592), E4600: Normal (2288)

White balance Auto

Exp. +/- ±0

Continuous Single

Best Shot Selector Off

Color options Standard color

Transfer marking All on

Welcome screen Animation

Photo info Show info

Brightness 3

Date imprint Off

Button sound (E5600 only) On

Shutter sound 1 (E5600), On (E4600)

Start-up sound (E5600 only) On

Volume (E5600 only) Normal

Blur warning On

Auto Off 1m

Sleep mode Off

Auto transfer On

Menus Text

102

The Set-up Menu

Battery Type

Battery type

This option is used to choose the type of batteries inserted

in the camera.

Backup Battery

If the backup battery (Q 14) is not charged sufficiently, the battery type setting may revert to the

default setting.

Option Description

Alkaline Select this option when you have inserted alkaline (AA) batteries.

COOLPIX

(NiMH)

Select this option when you have inserted rechargeable EN-MH1 (AA)

nickel-metal hydride batteries.

Lithium Select this option when you have inserted lithium (AA) batteries or

nickel-manganese batteries.

Alkaline

COOLPIX(NiMH)

Set

BATTERY TYPE

Lithium

103

The Set-up Menu

Menus

This option is used to switch the menu display of the

SHOOTING MENU, PLAYBACK MENU or SET-UP menu to

Text

Icons

Tex t

Icons

MENUS

Set

104

The Set-up Menu

Firmware Version

Firmware version

Select this option to display the current firmware version.

Back

E5600 Ver.XX

105

Technical Notes

Optional Accessories

At the time of writing, the following optional accessories were available for your

Nikon digital camera. Contact your local retailer or Nikon representative for de-

tails.

*1Not available in U.S.

*2Not available in some areas.

Approved Memory Cards

The following memory cards have been tested and approved for use with your

Nikon digital camera:

* High speed type of 10 MB/s or over

Rechargeable battery Additional EN-MH1 NiMH batteries are available from

your retailer or local Nikon representative.

Battery charger MH-71, MH-70 battery charger for EN-MH1 batteries

AC adapter EH-62B AC adapter

Carrying case CS-CP18 soft case*1

Water-proof Case WP-CP3*2

SanDisk 16 MB, 32 MB, 64 MB, 128 MB, 256 MB, 256 MB*,

512 MB, 512 MB*, 1 GB

To s h i b a 16 MB, 32 MB, 64 MB, 128 MB, 128 MB*, 256 MB,

256 MB*, 512 MB

Panasonic 16 MB, 32 MB, 64 MB, 128 MB, 256 MB*, 512 MB*,

1 GB

106

Technical Notes

Caring for Your Camera

Cleaning

Lens

One key to cleaning the lens is to not touch it with your fingers. Remove dust or

lint with a blower (typically a small device with a rubber bulb attached to one end

that you pump to produce a stream of air out the other). To remove fingerprints

or other stains that can not be removed with a blower, wipe the lens with a soft

cloth, using a spiral motion that starts in the center of the lens and works out to

the edges.

Monitor

Remove dust or lint with a blower. To remove fingerprints and other stains, clean

the monitor with a soft, dry cloth, being careful not to apply pressure.

Avoid contact with liquid crystal

Should the monitor break, care should be taken to avoid injury due to broken

glass and to prevent the liquid crystal from the monitor touching the skin or en-

tering the eyes or mouth.

Body

Use a blower to remove dust and lint, then wipe gently with a soft, dry cloth.

After using the camera at the beach or seaside, wipe off any sand or salt with a

cloth lightly dampened with fresh water, then dry thoroughly.

Do not use alcohol, thinner, or other volatile chemicals.

Notes on the Monitor

• The monitor may contain a few pixels that are always lit or that do not light. This is a char-

acteristic common to all TFT LCD monitors, and does not indicate a malfunction. Images

recorded using the product will not be affected.

• When you frame bright subjects, vertical comet-like streaks that whiten toward either end

may appear in the monitor. This phenomenon, known as "smear," does not appear in the

final photograph and does not indicate a malfunction. Some smear may appear in movies.

• Images in the monitor may be difficult to see in a bright light.

• The monitor is lit by an LED backlit. Should the monitor begin to dim or flicker, contact

your Nikon service representative.

107

Caring for Your Camera

Technical Notes

Storage

Turn the camera off when not in use and check that the power-on lamp is off be-

fore putting the camera away. To prevent mold or mildew, store the camera in a

dry, well-ventilated area. If you will not be using the product for long periods, re-

move the batteries to prevent leakage and store the camera in a plastic bag con-

taining a desiccant. Do not store the camera case (available separately) in a plastic

bag, as this may cause the material to deteriorate. Note that desiccant gradually

loses its capacity to absorb moisture and should be replaced at regular intervals.

Do not store your camera with naptha or camphor moth balls or in locations that:

• are poorly ventilated or damp

• are next to equipment that produces strong electromagnetic fields, such as

televisions or radios

• are exposed to temperatures below -10 °C (14 °F) or above 50 °C (122 °F; for

example near a space heater or in a closed vehicle on a sunny day)

• are subject to humidities of over 60%

To prevent mold or mildew, take the camera out of storage at least once a

month. Turn the camera on and release the shutter a few times before putting

the camera away again.

Store the batteries in a cool, dry place.

Batteries

• When turning the camera on, check that

the batteries are charged. The monitor

will display a warning when batteries are

low.

• On cold days, the capacity of batteries

tends to decrease. Be sure that the batter-

ies are fully charged before heading out-

side to take pictures in cold weather.

Keep spare batteries in a warm place and

exchange as necessary. Once warmed, a

cold battery may recover some of its

charge.

• If the battery terminals are dirty, wipe

them off with a clean, dry cloth before

use.

• Repeatedly recharging NiMH batteries be-

fore they are fully exhausted may result in

a "memory" effect, causing the batteries

to lose their charge quickly. The batteries

will return to normal after being fully dis-

charged and recharged.

• NiMH batteries gradually lose their charge

when left unused. We recommend that

you charge NiMH batteries immediately

before use.

• Used batteries are a valuable resource.

Please recycle used batteries in accor-

dance with local regulations.

108

Technical Notes

Error Messages

The following table lists the error messages and other warnings that appear in

the monitor and how to deal with them.

Display Problem Solution Q

(Flashes) Clock not set. Set clock to current date and

time. 14

WARNING ! !

BATTERY

EXHAUSTED

Batteries exhausted. Turn camera off and replace

batteries. 8

AFz

(zflashes red) Camera cannot focus.

Use focus lock to focus on

another subject at same dis-

tance, then recompose picture.

2Slow shutter speed. Pictures

may be blurred.

Use flash, or steady camera

using tripod, by placing cam-

era on level surface, or by

holding camera in both hands

with elbows against torso.

18,

24-25

Recorded picture may be

blurred.

Select Yes to keep picture,

No to delete. Camera shake

warning can be hidden.

WARNING ! !

PLEASE WAIT

FOR THE CAM-

ERA TO FINISH

RECORDING

Camera turned off or x but-

ton pressed during recording.

The mode dial was rotated

during recording.

Message clears from display

automatically when recording

is complete.

MEMORY

CARD IS WRITE

PROTECTED

Write-protect switch is in

"lock" position.

Slide write-protect to "write"

position. 11

CARD IS NOT

FORMATTED

Format

No >

Memory card has not been

formatted for use in camera.

Press multi selector up to

highlight FORMAT and press

to right to format card, or

turn camera off and replace

card.

97,

10-11

Yes

PICTURE IS BLURRED.

SAVE PICTURE?

PICTURE IS BLURRED.

SAVE PICTURE?

Set

109

Error Messages

Technical Notes

THIS CARD

CANNOT BE USED

Error accessing memory card.

• Use approved card.

• Check that connectors are

clean.

105

WARNING ! !

THIS CARD CAN-

NOT BE READ

OUT OF

MEMORY

Camera in shooting mode:

Insufficient memory to record

pictures at current settings.

• Choose lower image qual-

ity/ size.

• Delete pictures.

Insert new memory card.

67-68

78-79

Camera connected to com-

puter: Not enough space on

memory card to record infor-

mation need for transfer.

Disconnect camera, delete

unwanted pictures, and try

again.

78-79

IMAGE CANNOT

BE SAVED

• Memory card has not been

formatted for use in cam-

era, or error occurred while

saving picture.

• Camera has run out of file

numbers.

• Camera can not copy pic-

ture using small picture, or

crop options.

• Image can not be adjusted

using D-Lighting.

• Reformat memory card.

• Insert new memory card or

delete pictures.

• Copies can not be created

from movies or from other

copies.

• Images can only be adjusted

using D-Lighting one time.

Further adjustments can not

be made.

10,

78-79

44, 45,

CANNOT

RECORD

MOVIE

• Memory card has not been

formatted for use in camera.

• Error occurred while saving

movie.

• Camera has run out of file

numbers.

• Takes long time to save

movie on memory card.

• Reformat memory card.

• Insert new memory card or

delete pictures or movies.

• Insert memory card with

faster processing speed.

10,

78-79

61,

105

MEMORY

CONTAINS

NO IMAGES

No pictures on memory card

or in memory. Press x button to return to

shooting mode. 22

ALL IMAGES

ARE HIDDEN

No pictures on memory card

that can be viewed on E5600/

E4600.

FILE CONTAINS

NO IMAGE DATA

File created by computer or

different make of camera.

View file on computer or cor-

rect make of camera. -

Display Problem Solution Q

110

Error Messages

Technical Notes

WARNING!

MODE DIAL IS

NOT IN THE

PROPER POSITION

Mode dial is positioned

between two modes.

Adjust mode dial to select

desired mode. 6

THIS IMAGE CAN-

NOT BE DELETED

Attempt to delete protected

picture.

Remove protection before

deleting picture. 80

COMMUNICA-

TIONS ERROR

USB cable disconnected or

memory card removed while

pictures are being transferred

to computer.

If error appears in computer

monitor, click

to exit Picture-

Project. Turn camera off, recon-

nect cable or replace memory

card, then turn camera on and

transfer pictures.

49-51

USB option set incorrectly.

Turn camera off and discon-

nect cable, then choose new

USB setting in the SET-UP

menu of the camera and

reconnect camera. If error per-

sists, use PictureProject

button to transfer pictures.

NO IMAGES

ARE MARKED

FOR TRANSFER

No pictures selected for trans-

fer when I (V) button

pressed to transfer pictures to

computer.

Disconnect camera and select

at least one picture for trans-

fer, then begin transfer

again.

51,

81-82

TRANSFER

ERROR

Error occurred when pictures

were transferred to computer.

Check that camera is con-

nected and that batteries are

fully charged.

NEW CITY IS IN

THE CURRENT

TIME ZONE

Travel destination is in same

time zone as home location.

No need to specify new time zone

if travel destination is in same

time zone as home location.

LENS ERROR Error has occurred during lens

operation.

Turn camera off and then on

again. If error persists, con-

tact retailer or Nikon repre-

sentative.

SYSTEM ERROR Error has occurred in camera's

internal circuitry.

Turn camera off, unplug

optional AC adapter (if

using), remove and reinsert

batteries, and turn camera

on. If error persists, contact

retailer or Nikon representa-

tive.

8-9,

Display Problem Solution Q

111

Technical Notes

Troubleshooting

If your camera fails to function as expected, check the list of common problems

below before consulting your retailer or Nikon representative. Refer to the page

numbers listed in the right-most column for information on solving the problems

listed here.

Electronically-Controlled Cameras

In extremely rare instances, unusual characters may appear in the monitor and the camera

may stop functioning. In most cases, this phenomenon is caused by a strong external static

charge. Turn the camera off, remove and replace the batteries, and turn the camera on

again, or, if you are using an AC adapter (available separately), disconnect and reconnect

the adapter, and turn the camera on again. In the event of continued malfunction, contact

your retailer or Nikon representative. Note that disconnecting the power source as described

above may result in the loss of any data not recorded to the memory or memory card at the

time the problem occurred. Data already recorded to the memory or memory card will not

be affected.

Problem Possible cause Q

Monitor is blank

• Camera is off.

• Batteries are not correctly inserted or battery-chamber

cover is not properly latched.

• Batteries are exhausted.

• EH-62B AC adapter (available separately) is not prop-

erly connected.

• Camera is in sleep mode. Press shutter-release button

halfway.

• Monitor is off.

• USB cable is connected.

• AV/Video cable is connected.

Camera turns off

without warning

• Batteries are low.

• Batteries are cold.

107

No indicators appear

in monitor

• Indicators are hidden. Select Show info for Photo

info option in the Monitor settings menu.

Monitor is hard to

read

• Ambient lighting is too bright: move to a darker loca-

tion or use viewfinder.

• Monitor brightness needs adjustment.

• Monitor is dirty: clean monitor.

106

112

Troubleshooting

Technical Notes

No picture is taken

when shutter-

release button is

pressed

• Camera is in playback mode.

• Batteries are exhausted.

•Red (!) lamp flickers: flash is charging.

• Green (AF) lamp flickers: camera unable to focus.

• Message "CARD IS NOT FORMATTED" appears in

monitor: memory card is not formatted for use in your

camera.

• Message "OUT OF MEMORY" appears in monitor:

insufficient memory to record picture at current Image

mode setting.

10-11,

Pictures are too dark

(underexposed)

• Flash is off.

• Flash window is blocked.

• Subject is outside range of flash.

• Exposure compensation is too low.

Pictures are too

bright (overexposed) • Exposure compensation is too high. 71

Pictures are out of

focus

• Subject was not in focus area when shutter-release

button was pressed halfway.

• Green (AF) lamp flickers: camera unable to focus.

Pictures are blurred

• Camera shook during shot. Blurring caused by camera

shake can be reduced by:

Using the flash

Using the Best Shot Selector (BSS)

Using the self-timer with a tripod

Randomly-spaced

bright pixels

("noise") appear in


• Shutter speed too slow. Noise can be reduced by:

Using the flash



(night portrait assist) mode is selected (E5600 only)

DUSK/DAWN

NIGHT LANDSCAPE

are

selected in

(scene) mode.

Colors are unnatural • White balance does not match light source.

•Color options is not set to Standard color.69

Flash does not fire

• Flash is off. Note that flash turns off automatically

when;

The mode dial is set to N(landscape assist),

j(sports assist), or W(movie), or to e(scene)

mode with any of DSUNSET, FNIGHT LAND-

SCAPE, GMUSEUM, HFIREWORKS SHOW, or

EDUSK/DAWN selected in scene menu.

32,

33,

60,

36-37

Picture can not be

played back

• Picture has been overwritten or renamed by computer

or other make of camera. -

Problem Possible cause Q

113

Troubleshooting

Technical Notes

Copy can not be cre-

ated using small pic-

ture, crop, or D-

Lighting option

• Picture is a movie.

• Picture was created with small picture, crop, or D-Light-

ing option.

• There is not enough free space in the memory or on

the memory card to store new copy.

44, 45,

Can not zoom in on


• Picture is a movie.

• Picture was created with small picture option.

• Picture has been cropped to size less than 320 × 240.

PictureProject does

not start when cam-

era is connected or

memory card

inserted in card

reader or card slot

• Camera is off.

• EH-62B AC adapter (available separately) is not prop-

erly connected, or batteries are exhausted.

• UC-E6 USB cable is not correctly connected, or card not

properly inserted in card reader or card slot.

•USB item in INTERFACE menu is set to PTP when cam-

era is connected to a computer running Windows

2000 Professional, Windows Millennium Edition (Me),

or Windows 98 Second Edition (SE).

• Camera is not registered in Device Manager (Windows

only).

See PictureProject Reference Manual (on CD) for further

information.

9, 12

10-11,

Problem Possible cause Q

114

Technical Notes

Specifications

Type E5600/E4600 digital camera

Effective pixels 5.1 million (E5600); 4.0 million (E4600)

CCD E5600 1/2.5” high-density CCD; total pixels: 5.36 million

E4600 1/2.5” high-density CCD; total pixels: 4.23 million

Image size (pixels)

2,592 × 1,944 (2592) (E5600 only)

2,288 × 1,712 (2288) (E4600 only)

2,048 × 1,536 (2048) (E5600 only)

1,600 × 1,200 (1600) (E4600 only)

1,024 × 768 (1024)

640 × 480 (640)

Lens 3 × Zoom Nikkor

Focal length

E5600: F=5.7 - 17.1 mm

(35-mm [135] camera-format equivalent: 35 - 105 mm)

E4600: F=5.7 - 17.1 mm

(35-mm [135] camera-format equivalent: 34 - 102 mm)

f/-number f/2.9 - f/4.9

Construction Seven elements in six groups

Digital zoom 4 × (35-mm [135] camera-format equivalent:

420 mm [E5600]/408 mm [E4600])

Autofocus (AF)

Contrast-detect through the lens (TTL) AF

Focus range 30 cm (1´) - ∞; macro mode 4 cm/1.6” (M) - ∞

Focus-area selection

Center with five-area selection in frame assist mode

Viewfinder Real-image zoom viewfinder with LED indication

Magnification 0.3 - 0.76 ×

Frame coverage

Approximately 82% horizontal and 82% vertical

Monitor 1.8”, 80,000-dot, amorphous silicon TFT LCD monitor

Frame coverage

(shooting mode) Approximately 97% horizontal and 97% vertical

Storage Media Internal memory (14 MB)/SD memory cards

File system Compliant with Design Rule for Camera File System

(DCF), Exif 2.2, and Digital Print Order Format (DPOF)

File formats Compressed: JPEG-baseline-compliant, Movies: QuickTime

Exposure

Metering 256-segment matrix metering linked to AF area

(when frame is displayed in frame-assisted scene mode)

Exposure control Programmed auto exposure with exposure compensation

(-2.0 - +2.0 EV in steps of 1/3 EV)

Range W: +1.1 - +17.1 EV

T: +2.6 - +18.6 EV

Shutter Mechanical and charge-coupled electronic shutter

Speed 4 - 1/3,000 s

Aperture Electronically-controlled preset aperture

Range Two steps (f/2.9 and f/4.9 [W])

115

Specifications

Technical Notes

Sensitivity

Approximately equivalent to ISO 50

(auto gain of two to four times) (up to equivalent of ISO 200)

Self-timer Ten-second duration

Built-in

Speedlight

Range (approx.)

W: 0.4 - 3.3 m/1´4” - 10´10”

T: 0.4 - 2.0 m/1´4” - 6´7”

Flash control Sensor flash system

Interface USB

Video output Can be selected from NTSC and PAL

I/O terminals • A/V out/digital I/O (E5600);

• Video out/digital I/O (E4600);

Power sources

• Two rechargeable Nikon EN-MH1 NiMH batteries

• Two LR6 (AA) alkaline batteries

• Two ZR6 (AA) nickel manganese batteries

• Two FR6/L91 (AA) lithium batteries

• EH-62B AC adapter

Number of frames taken in

succession

E5600: 220 frames (alkaline batteries)

340 frames (EN-MH1)

600 frames (lithium batteries)

E4600: 230 frames (alkaline batteries)

360 frames (EN-MH1)

630 frames (lithium batteries).

Measured at standard temperature (25°C/77°F) with fully

charged batteries based on CIPA standard: zoom adjusted

with each shot, flash used in approximately one half of

shots, image type set to Normal.

Dimensions (W × H × D) 85 × 60 × 35 mm (3.3” × 2.4” × 1.3”)

Approximate weight 130 g (4.6 oz) without battery or memory card

Operating

environment

Temperature 0 - 40 °C (32 - 104 °F)

Humidity Less than 85% (no condensation)

116

Index

Symbols

I button, 7

P (auto) mode, 6, 16

u (delete) button, 3, 22, 23,

42, 43, 64

! lamp, see Lamp, red (!)

N (landscape assist) mode, 6,

W (movie) mode, 6, 60-64

m (night portrait assist) mode,

6, 34

x (play) button, 3, 12, 22

i (portrait assist) mode, 6, 31

j (sports assist) mode, 6, 33

O:@ (voice memo), 47

AC adapter, i, iii, vi, 9, 59, 105

AF lamp, see Lamp, green (AF)

AFz, 4, 20

Audio/video (AV) cable

(EGCP12), 48

Audio/video (AV) output con-

nector, 3

Auto off, 13, 96

Auto transfer, 100

BACK LIGHT, 39

Backlit subjects, 35

Batteries, i-ii, 8-9, 12, 102,

107

charging, 9

EN-MH1, i, 8, 9, 96, 97,

107

FR6/L91 (AA), i, 8, 102

LR6 (AA), i, 8, 102

ZR6 (AA), i, 8, 102

Battery type, 8, 102

BEACH/SNOW, 36

Best Shot Selector, 73

Blur warning, 95

Blur, 24, 25, 36, 95

Brightness, 91

BSS, see Best Shot Selector

Clock, see Date

CLOSE UP, 37

Close-ups, 27, 41, 61

Color Options, 74

Computer, connecting to, 49-

Continuous, 72

COPY, 38

Cropping pictures, 44

copying pictures to, 84-86

Date imprint, 93

Date, 14-15, 54-55, 93

DCF, see Design rule for Cam-

era File system

Delete, 78

Deleting pictures, 78

all pictures, 79

during shooting, 23

in full-screen playback, 22

selected pictures, 78

Design rule for Camera File

system, vi

Digital Print Order Format, 52

D-Lighting, 45

DPOF, see Digital Print Order

Format

DUSK/DAWN, 37

E-mail, 67, 68, 82

EN-MH1, see Batteries

Error messages, 108-110

Exif 2.2, vi

Exif Print, see Exif 2.2

Exp. +/-, 71

Exposure compensation, see

Exp. +/-

File numbering, 23, 101

Fill flash, 24, 39

FIREWORKS SHOW, 38

Firmware version, 104

Flash, ii, 2, 24-25, 69

mode, 24-25

Focus lock, 7, 21

Focus, 7, 20-21, 63

Format card, 82, 97

Framing assist, 6, 28, 29-33

Framing pictures, 18-19, 29-

Help, 29, 61, 66, 76, 88

Icon type display, 65, 76, 88

Image mode, 16, 29, 67-68

Image quality, see Image

mode

Image size, see Image mode

Interface, 99

Internal memory, 10, 50, 77,

83, 96

copying pictures from and

to, 83

formatting, 96

ISO, 25

JPEG, 23

Lamp, green (AF), 3, 7, 12, 20

Lamp, red (!), 3, 12, 20

Language, 14, 99

Language, choosing, 14

Lens, iii, 2, 106

Macro mode, 27, 41-61

Memory cards, ii, 2, 10-11,

105

approved, 105

capacity of, 16, 68

formatting, 11, 80, 97

insertion and removal of,

10-11

MENU button, 3

Menus, see Icon type display

MH-70 battery charger, 105

MH-71 battery charger, 9, 105

Microphone, 2, 47

Mode dial, 3, 6

Monitor, ii, 3, 4-5, 18-19, 106

indicators in, 4-5

turning on and off, 5, 92

Monitor settings, 92

MOV, see Movies

Movie menu, the, 62

Movie options, 62

117

Index

Movies, 60-64

auto-focus mode, 63

recording, 60-63

viewing, 64

Multi selector, 3, 7

MUSEUM, 38

NIGHT LANDSCAPE, 37

NTSC, see Video mode

Number of exposures remain-

ing, 16, 17, 68

On/off, see Power switch

PAL, see Video mode

PANORAMA ASSIST, 40

PARTY/INDOOR, 28, 35, 36

PictBridge, 56, 59

PictureProject, 49

Play back, 22-23, 42-51

full-screen playback, 22-

movie playback, 64

on TV, 48

Playback menu, 76-86

Power switch, 2, 12-13

Power-on lamp, 2, 12-13, 16

Print set, 52-55, 76, 93

Printing pictures, 52-59, 68

direct printing, 56-59

DPOF printing, 52-54, 57-

Nikon Cool Pix 4600 Manual User Guide And Detail Specification

Navigation menu

Versions of this User Manual:

Views

Navigation
