En
User’s Manual
DIGITAL CAMERA
Trademark Information
•
Microsoft, Windows and Windows Vista are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries.
•
Macintosh, Mac OS, and QuickTime are trademarks of Apple Inc.
•
Adobe and Acrobat are registered trademarks of Adobe Systems Inc.
•
The SD logo is a trademark of the SD Card Association.
•
PictBridge is a trademark.
•
All other trade names mentioned in this manual or the other documentation provided
with your Nikon product are trademarks or registered trademarks of their respective
holders.
i
Introduction
First Steps
ABasic Photography and Playback: Auto Mode
CShooting Suited for the Scene
FTaking Pictures of Smiling Faces
(Smart Portrait Mode)
sFocusing on a Moving Subject in Subject
Tracking Mode
cMore on Playback/In-Camera Editing
DMovies
Connecting to Televisions, Computers and Printers
dShooting, Playback and Setup Menus
Technical Notes
ii
For Your Safety
To prevent damage to your Nikon product or injury to yourself or to others, read
the following safety precautions in their entirety before using this equipment.
Keep these safety instructions where all those who use the product will read them.
The consequences that could result from failure to observe the precautions listed
in this section are indicated by the following symbol:
WARNINGS
Turn off in the event of
malfunction
Should you notice smoke or an unusual
smell coming from the camera or
Charging AC Adapter, unplug the
Charging AC Adapter and remove the
battery immediately, taking care to
avoid burns. Continued operation
could result in injury. After removing or
disconnecting the power source, take
the equipment to a Nikon-authorized
service representative for inspection.
Do not disassemble
Touching the internal parts of the
camera or Charging AC Adapter could
result in injury. Repairs should be
performed only by qualified
technicians. Should the camera or
Charging AC Adapter break open as the
result of a fall or other accident, take the
product to a Nikon-authorized service
representative for inspection, after
unplugging the product and/or
removing the battery.
Do not use the camera or
Charging AC Adapter in the
presence of flammable gas
Do not use electronic equipment in the
presence of flammable gas, as this
could result in explosion or fire.
Handle the camera strap with
care
Never place the strap around the neck
of an infant or child.
Keep out of reach of children
Particular care should be taken to
prevent infants from putting the
battery or other small parts into their
mouths.
This icon marks warnings, information that should be read before using this Nikon
product, to prevent possible injury.
iii
For Your Safety
Observe caution when
handling the battery
The battery may leak or explode if
improperly handled. Observe the
following precautions when handling
the battery for use in this product:
•Before replacing the battery, turn the
product off. If you are using the
Charging AC Adapter/AC adapter, be
sure it is unplugged.
•Use only a Rechargeable Li-ion Battery
EN-EL12 (supplied). Charge the battery
inserting it into the camera and
connecting the Charging AC Adapter
EH-68P/EH-68P (AR) (supplied).
•When inserting the battery, do not
attempt to insert it upside down or
backwards.
•Do not short or disassemble the
battery or attempt to remove or
break the battery insulation or casing.
•Do not expose the battery to flame
or to excessive heat.
•Do not immerse in or expose to water.
•Replace the terminal cover when
transporting the battery. Do not
transport or store with metal objects
such as necklaces or hairpins.
•The battery is prone to leakage when
fully discharged. To avoid damage to
the product, be sure to remove the
battery when no charge remains.
•Discontinue use immediately should
you notice any change in the battery,
such as discoloration or deformation.
•If liquid from the damaged battery
comes in contact with clothing or
skin, rinse immediately with plenty of
water.
Observe the following
precautions when handling the
Charging AC Adapter
•Keep dry. Failure to observe this
precaution could result in fire or
electric shock.
•Dust on or near the metal parts of the
plug should be removed with a dry
cloth. Continued use could result in
fire.
•Do not handle the plug or go near
the Charging AC Adapter during
lightning storms. Failure to observe
this precaution could result in
electric shock.
•Do not damage, modify, forcibly tug
or bend the USB cable, place it under
heavy objects, or expose it to heat or
flames. Should the insulation be
damaged and the wires become
exposed, take it to a Nikon-
authorized service representative for
inspection. Failure to observe these
precautions could result in fire or
electric shock.
•Do not handle the plug or Charging
AC Adapter with wet hands. Failure
to observe this precaution could
result in electric shock.
•Do not use with travel converters or
adapters designed to convert from
one voltage to another or with DC-
to-AC inverters. Failure to observe
this precaution could damage the
product or cause overheating or fire.
iv
For Your Safety
Use appropriate cables
When connecting cables to the input
and output jacks, use only the cables
provided or sold by Nikon for the
purpose, to maintain compliance with
product regulations.
Handle moving parts with care
Be careful that your fingers or other
objects are not pinched by the lens
cover or other moving parts.
CD-ROMs
The CD-ROMs supplied with this device
should not be played back on audio CD
equipment. Playing CD-ROMs on an
audio CD player could cause hearing
loss or damage the equipment.
Observe caution when using
the flash
Using the flash close to your subject’s
eyes could cause temporary visual
impairment. Particular care should be
observed if photographing infants,
when the flash should be no less than
1 m (3 ft. 4 in.) from the subject.
Do not operate the flash with
the flash window touching a
person or object
Failure to observe this precaution could
result in burns or fire.
Avoid contact with liquid
crystal
Should the monitor break, care should
be taken to avoid injury caused by
broken glass and to prevent liquid
crystal from the monitor touching the
skin or entering the eyes or mouth.
Turn the power off when using
inside an airplane or the
hospital
Turn the power off while inside the
airplane during take off or landing.
Follow the instructions of the hospital
when using while in a hospital. The
electromagnetic waves given out by
this camera may disrupt the electronic
systems of the airplane or the
instruments of the hospital.
v
Notices
Notice for Customers in the
U.S.A.
Federal Communications
Commission (FCC) Radio
Frequency Interference
Statement
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC rules. These limits are
designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses, and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is no
guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
•Reorient or relocate the receiving
antenna.
•Increase the separation between the
equipment and receiver.
•Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.
•Consult the dealer or an experienced
radio/television technician for help.
CAUTIONS
Modifications
The FCC requires the user to be notified
that any changes or modifications
made to this device that are not
expressly approved by Nikon
Corporation may void the user’s
authority to operate the equipment.
Interface Cables
Use the interface cables sold or
provided by Nikon for your equipment.
Using other interface cables may
exceed the limits of Class B Part 15 of
the FCC rules.
Notice for customers in the State of
California
WARNING
Handling the cord on this product will
expose you to lead, a chemical known
to the State of California to cause birth
defects or other reproductive harm.
Wash hands after handling.
Nikon Inc.,
1300 Walt Whitman Road
Melville, New York 11747-3064
USA
Tel: 631-547-4200
COOLPIX S640
vi
Notices
Notice for customers in Canada
CAUTION
This Class B digital apparatus complies
with Canadian ICES-003.
ATTENTION
Cet appareil numérique de la classe B
est conforme à la norme NMB-003 du
Canada.
Notice for customers in Europe
This symbol indicates that this
product is to be collected
separately.
The following apply only to
users in European countries:
•This product is designated for
separate collection at an appropriate
collection point. Do not dispose of as
household waste.
•For more information, contact the
retailer or the local authorities in
charge of waste management.
This symbol on the battery
indicates that the battery is
to be collected separately.
The following apply only to
users in European countries:
•All batteries, whether marked with
this symbol or not, are designated for
separate collection at an appropriate
collection point. Do not dispose of as
household waste.
•For more information, contact the
retailer or the local authorities in
charge of waste management.
vii
Table of Contents
For Your Safety........................................................................................................................................ ii
WARNINGS..................................................................................................................................................................ii
Notices ....................................................................................................................................................... v
Introduction ...........................................................................................................................................1
About This Manual ................................................................................................................................ 1
Information and Precautions............................................................................................................. 2
Parts of the Camera............................................................................................................................... 4
The Camera Body ...................................................................................................................................................4
The Monitor................................................................................................................................................................6
Basic Operations..................................................................................................................................... 8
The A (shooting mode) Button...................................................................................................................8
The c (playback) Button .................................................................................................................................9
The Rotary Multi Selector................................................................................................................................10
The d button ...................................................................................................................................................12
Switching Between Tabs.................................................................................................................................12
Help Displays..........................................................................................................................................................13
Pressing the Shutter-Release Button Halfway/All the Way Down........................................13
Attaching the Camera Strap.........................................................................................................................13
First Steps............................................................................................................................................. 14
Inserting the Battery ...........................................................................................................................14
Removing the Battery.......................................................................................................................................15
Charging the Battery ..........................................................................................................................16
Turning On and Off the Camera.................................................................................................................19
Setting Display Language, Date and Time .................................................................................20
Inserting Memory Cards ....................................................................................................................22
Removing Memory Cards...............................................................................................................................22
A Basic Photography and Playback: Auto Mode ................................................................. 24
Step 1 Turn the Camera On and Select A (Auto) Mode .......................................................24
Indicators Displayed in A (Auto) Mode...............................................................................................25
Step 2 Frame a Picture .......................................................................................................................26
Using the Zoom....................................................................................................................................................27
Step 3 Focus and Shoot.....................................................................................................................28
Step 4 Viewing and Deleting Pictures ..........................................................................................30
Viewing Pictures (Playback Mode)............................................................................................................30
Deleting Pictures..................................................................................................................................................30
Using the Flash......................................................................................................................................32
Setting the Flash Mode....................................................................................................................................32
Taking Pictures with the Self-Timer...............................................................................................34
Macro Mode...........................................................................................................................................35
viii
Table of Contents
Exposure Compensation...................................................................................................................36
C Shooting Suited for the Scene................................................................................................ 37
Shooting in Scene Mode ...................................................................................................................37
Choosing a Scene Mode.................................................................................................................................37
Features .....................................................................................................................................................................38
Shooting in the Scene Mode Selected by the Camera (Scene Auto Selector).............45
Taking Pictures in Food Mode.....................................................................................................................47
Taking Pictures for a Panorama ..................................................................................................................49
F Taking Pictures of Smiling Faces (Smart Portrait Mode) .............................................. 51
Using Smart Portrait Mode...............................................................................................................51
Smart Portrait Menu...........................................................................................................................................52
s Focusing on a Moving Subject in Subject Tracking Mode........................................... 54
Subject Tracking Mode......................................................................................................................54
Subject Tracking Menu....................................................................................................................................56
c More on Playback/In-Camera Editing................................................................................. 57
Viewing Multiple Pictures: Thumbnail Playback ......................................................................57
Calendar Display...................................................................................................................................................59
Taking a Closer Look: Playback Zoom ..........................................................................................60
Viewing Pictures by Date (List by Date Mode) ..........................................................................61
Selecting a Date in List by Date Mode...................................................................................................61
Using List by Date Mode.................................................................................................................................62
List by Date Menu ...............................................................................................................................................63
Image Searching (Auto Sort Mode)...............................................................................................64
Displaying Pictures in the Auto Sort Mode .........................................................................................64
Auto Sort Mode ....................................................................................................................................................66
Auto Sort Menu ....................................................................................................................................................66
Voice Memos: Recording and Playback.......................................................................................67
Recording Voice Memos.................................................................................................................................67
Playing Voice Memos........................................................................................................................................68
Deleting Voice Memos.....................................................................................................................................68
Editing Pictures.....................................................................................................................................69
Enhancing Contrast and Saturation: Quick Retouch.....................................................................71
Enhancing Brightness and Contrast: D-Lighting..............................................................................72
Making Skin Appear Smoother: Skin Softening................................................................................73
Resizing Pictures: Small Picture...................................................................................................................74
Creating a Cropped Copy: Crop.................................................................................................................75
ix
Table of Contents
D Movies ............................................................................................................................................. 76
Recording Movies ................................................................................................................................76
The Movie Menu...................................................................................................................................77
DSelecting Movie Options..........................................................................................................................77
IAutofocus Mode ..........................................................................................................................................77
Movie Playback.....................................................................................................................................78
Deleting Movie Files...........................................................................................................................................78
Connecting to Televisions, Computers and Printers............................................................ 79
Connecting to a TV..............................................................................................................................79
Connecting to a Computer...............................................................................................................80
Before Connecting the Camera..................................................................................................................80
Transferring Pictures from the Camera to a Computer ...............................................................81
Charging While Connecting to a Computer ......................................................................................84
Connecting to a Printer......................................................................................................................85
Connecting the Camera to a Printer........................................................................................................86
Printing Pictures One at a Time ..................................................................................................................88
Printing Multiple Pictures ...............................................................................................................................89
Creating a DPOF Print Order: Print Set.........................................................................................92
d Shooting, Playback and Setup Menus ............................................................................. 95
Shooting Options: The Shooting Menu.......................................................................................95
Displaying the Shooting Menu ..................................................................................................................95
AImage Mode ...................................................................................................................................................96
BWhite Balance................................................................................................................................................98
GMetering........................................................................................................................................................100
CContinuous..................................................................................................................................................101
EISO Sensitivity ............................................................................................................................................102
FColor Options..............................................................................................................................................103
GAF-Area Mode ............................................................................................................................................104
IAutofocus Mode.......................................................................................................................................108
Functions that Cannot be Applied Simultaneously....................................................................109
Playback Options: The Playback Menu ..................................................................................... 110
Displaying the Playback Menu.................................................................................................................110
bSlide Show....................................................................................................................................................112
cDelete...............................................................................................................................................................113
dProtect ..........................................................................................................................................................113
fRotate Image...............................................................................................................................................114
hCopy.................................................................................................................................................................115
Basic Camera Setup: The Setup Menu....................................................................................... 116
Displaying the Setup Menu........................................................................................................................117
x
Table of Contents
aMenus .............................................................................................................................................................118
cWelcome Screen.......................................................................................................................................119
dDate ..................................................................................................................................................................120
eMonitor Settings......................................................................................................................................123
fDate Imprint ................................................................................................................................................124
gVibration Reduction...............................................................................................................................125
UMotion Detection.....................................................................................................................................126
hAF Assist........................................................................................................................................................127
uDigital Zoom ..............................................................................................................................................127
iSound Settings..........................................................................................................................................128
kAuto Off .........................................................................................................................................................128
l/mFormat Memory/Format Card..................................................................................................129
nLanguage.......................................................................................................................................................130
oVideo Mode ................................................................................................................................................130
VCharge by Computer.............................................................................................................................131
dBlink Warning .............................................................................................................................................132
pReset All..........................................................................................................................................................134
rFirmware Version ....................................................................................................................................136
Technical Notes................................................................................................................................137
Optional Accessories ....................................................................................................................... 137
Approved Memory Cards............................................................................................................................138
File and Folder Names..................................................................................................................... 139
Caring for the Camera..................................................................................................................... 140
Cleaning .................................................................................................................................................................142
Storage....................................................................................................................................................................143
Error Messages................................................................................................................................... 144
Troubleshooting................................................................................................................................ 148
Specifications ..................................................................................................................................... 154
Supported Standards.....................................................................................................................................157
Index...................................................................................................................................................... 158
1
Introduction
Introduction
About This Manual
Thank you for your purchase of a Nikon COOLPIX S640 digital camera. This manual
was written to help you enjoy taking pictures with your Nikon digital camera. Read
this manual thoroughly before use, and keep it where all those who use the
product will read it.
Symbols and Conventions
To make it easier to find the information you need, the following symbols and
conventions are used:
Notations
•A Secure Digital (SD) memory card is referred to as a “memory card”.
•The setting at the time of purchase is referred to as the “default setting”.
•The names of menu items displayed in the camera monitor, and the names of
buttons or messages displayed in a computer monitor are indicated in bold
text.
Screen Samples
In this manual, images are sometimes omitted from monitor display samples so
that monitor indicators can be more clearly shown.
Illustrations and Screen Display
Illustrations and text displays shown in this manual may differ from actual display.
CMemory Cards
Pictures taken with this camera can be stored in the camera’s internal memory or on removable
memory cards. If a memory card is inserted, all new pictures will be stored on the memory card and
delete, playback, and format operations will apply only to the pictures on the memory card. The
memory card must be removed before the internal memory can be formatted or used to store
pictures to, or delete, or view pictures.
This icon marks cautions,
information that should be read
before use, to prevent damage to
the camera.
This icon marks tips, additional
information that may be helpful
when using the camera.
This icon marks notes,
information that should be read
before using the camera.
This icon indicates that more
information is available
elsewhere in this manual or in
the Quick Start Guide.
A
BD
C
2
Introduction
Information and Precautions
Life-Long Learning
As part of Nikon’s “Life-Long Learning” commitment to ongoing product support and education,
continually updated information is available online at the following sites:
•For users in the U.S.A.: http://www.nikonusa.com/
•For users in Europe and Africa: http://www.europe-nikon.com/support/
•For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.com/
Visit these sites to keep up-to-date with the latest product information, tips, answers to frequently
asked questions (FAQs), and general advice on digital imaging and photography. Additional
information may be available from the Nikon representative in your area. See the URL below for
contact information:
http://imaging.nikon.com/
Use Only Nikon Brand Electronic Accessories
Nikon COOLPIX cameras are designed to the highest standards and include complex electronic
circuitry. Only Nikon brand electronic accessories (including battery chargers, batteries, Charging AC
Adapter and AC adapters) certified by Nikon specifically for use with this Nikon digital camera are
engineered and proven to operate within the operational and safety requirements of this electronic
circuitry.
THE USE OF NON-NIKON ELECTRONIC ACCESSORIES COULD DAMAGE THE CAMERA AND MAY
VOID YOUR NIKON WARRANTY.
The use of third-party rechargeable Li-ion batteries not bearing the Nikon holographic seal could
interfere with normal operation of the camera or result in the batteries overheating, igniting,
rupturing, or leaking.
For more information about Nikon brand accessories, contact a local authorized Nikon dealer.
Before Taking Important Pictures
Before taking pictures on important occasions (such as at weddings or before taking the camera on
a trip), take a test shot to ensure that the camera is functioning normally. Nikon will not be held liable
for damages or lost profits that may result from product malfunction.
About the Manuals
•No part of the manuals included with this product may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in any form, by any means, without
Nikon’s prior written permission.
•Nikon reserves the right to change the specifications of the hardware and software described in
these manuals at any time and without prior notice.
•Nikon will not be held liable for any damages resulting from the use of this product.
•While every effort was made to ensure that the information in these manuals is accurate and
complete, we would appreciate it were you to bring any errors or omissions to the attention of the
Nikon representative in your area (address provided separately).
Holographic seal: Identifies this
device as an authentic Nikon product.
3
Information and Precautions
Introduction
Notice Concerning Prohibition of Copying or Reproduction
Note that simply being in possession of material that was digitally copied or reproduced by means
of a scanner, digital camera or other device may be punishable by law.
•Items prohibited by law from being copied or reproduced
Do not copy or reproduce paper money, coins, securities, government bonds or local government
bonds, even if such copies or reproductions are stamped “Sample”. The copying or reproduction of
paper money, coins, or securities which are circulated in a foreign country is prohibited. Unless the
prior permission of the government was obtained, the copying or reproduction of unused postage
stamps or post cards issued by the government is prohibited.
The copying or reproduction of stamps issued by the government and of certified documents
stipulated by law is prohibited.
•Cautions on certain copies and reproductions
The government has issued cautions on copies or reproductions of securities issued by private
companies (shares, bills, checks, gift certificates, etc.), commuter passes or coupon tickets, except
when a minimum of necessary copies are to be provided for business use by a company. Also, do
not copy or reproduce passports issued by the government, licenses issued by public agencies and
private groups, ID cards and tickets, such as passes and meal coupons.
•Comply with copyright notices
The copying or reproduction of copyrighted creative works such as books, music, paintings,
woodcut prints, maps, drawings, movies and photographs is governed by national and international
copyright laws. Do not use this product for the purpose of making illegal copies or to infringe
copyright laws.
Disposing of Data Storage Devices
Please note that deleting images or formatting data storage devices such as memory cards or
built-in camera memory does not completely erase the original image data. Deleted files can
sometimes be recovered from discarded storage devices using commercially available software,
potentially resulting in the malicious use of personal image data. Ensuring the privacy of such data is
the user’s responsibility.
Before discarding a data storage device or transferring ownership to another person, erase all data
using commercial deletion software, or format the device and then completely refill it with images
containing no private information (for example, pictures of empty sky). Be sure to also replace any
pictures selected for the welcome screen (A119). Care should be taken to avoid injury or damage
to property when physically destroying data storage devices.
4
Introduction
Parts of the Camera
The Camera Body
213 54 67
9
8
Lens cover closed
1
Zoom control..................................................27
f
g
h
i
j
: Wide....................................................27
: Tele.......................................................27
: Thumbnail playback..........57, 59
: Playback zoom..............................60
: Help .....................................................13
2Shutter-release button......................13, 28
3Power switch/Power-on lamp
....................................................................... 19, 128
4Built-in microphone............................67, 76
5Built-in flash......................................................32
6Self-timer lamp...............................................34
AF-assist illuminator.................................127
7Speaker........................................................67, 78
8Lens.........................................................142, 154
9Lens cover
5
Parts of the Camera
Introduction
115910876
1716 18
12 13 14 15
1234
1Monitor ..........................................................6, 25
2Rotary multi selector...................................10
3A (shooting mode) button .................... 8
4Charge lamp............................................17, 84
Flash lamp.........................................................33
5Tripod socket
6d button........................ 12, 95, 110, 117
7l (delete) button.................30, 31, 68, 78
8Cover latch................................................14, 22
9Battery-chamber/
memory card slot cover....................14, 22
10 Power connector cover (for optional
AC adapter connection) ........................137
11 k (apply selection) button................... 10
12 Eyelet for camera strap............................. 13
13 c (playback) button........................... 9, 30
14 Cable connector............................79, 81, 86
15 Connector cover............................79, 81, 86
16 Battery latch .............................................14, 15
17 Battery chamber........................................... 14
18 Memory card slot......................................... 22
6
Parts of the Camera
Introduction
The Monitor
The following indicators may appear in the monitor during shooting and playback
(actual display varies with current camera settings).
The indicators and photo info displayed during shooting and playback will turn off
after a few seconds (A123).
Shooting
* Differs according to the current shooting mode. Refer to the sections on each mode for details.
1600
1600
F2.7
F2.7
1600 F2.7
1/250
1/250
2
2
999
999
999
999
9999
9999
9999 1m00 s
1m00 s
1m00 s
1m00 s
1m00 s
1m00 s
9
14
15
19
16
18
17
28
321
6
7
8
29
30
31
10 11
12
13
21
27
20
23 22242526
45
ab
1Shooting mode*............ 24, 37, 51, 54, 76
2Macro mode ....................................................35
3Zoom indicator......................................27, 35
4Focus indicator...............................................28
5AE/AF-L indicator..........................................50
6Flash mode.......................................................32
7Battery level indicator ................................24
8Vibration reduction icon ...............25, 125
9Motion detection icon....................25, 126
10 “Date not set” indicator...............120, 144
11 Travel destination indicator.................120
12 Date imprint..................................................124
13 Image mode ....................................................96
Movie options.................................................77
14
(a) Number of exposures remaining
(still pictures)...........................................24
(b) Movie length...........................................76
15 Internal memory indicator..................... 25
16 Smile timer....................................................... 53
17 Aperture............................................................. 28
18 Skin softening................................................. 52
19 Shutter speed................................................. 28
20 ISO sensitivity........................................33, 102
21 Exposure compensation value............ 36
22 Focus area...............................................28, 104
23 Focus area (for manual, center).........104
24 Focus area (Face Priority) ..............51, 104
25 Focus area
(Subject Tracking mode)......................... 54
26 Center-weighted metering area ......100
27 Color options................................................103
28 White balance mode................................. 98
29 Continuous shooting mode ...............101
30 Self-timer indicator..................................... 34
31 Blink proof ........................................................ 52
7
Parts of the Camera
Introduction
Playback
1 The icons for auto sorting playback folder selected in playback will appear.
2 Differs according to the selected option.
15/11/2009 12:00
15/11/2009 12:00
999999
999 999
9999
9999
9999
9999
1m00s
1m00s
1m00s
1m00s
9999 9999
15/11/2009 12:00
1m00s
1m00s
999999
999 999
7
6
2314
5
910
13 12
17
16
11
18
15
14
8
ab
1Date of recording .........................................20
2Time of recording.........................................20
3Protect icon...................................................113
4Volume indicator ..................................68, 78
5Auto sort folder icon1 ...............................64
6Battery level indicator ................................24
7Image mode2 .................................................96
Movie option2 ................................................78
8
(a) Current frame number/
total number of frames ....................30
(b) Movie length...........................................78
9Internal memory indicator .....................30
10 Movie playback indicator........................78
11 List by date guide ........................................ 61
12 Print-order icon ............................................. 92
13 Small picture ...................................................74
14 D-Lighting icon .............................................72
15 Quick retouch icon......................................71
16 Skin softening icon......................................73
17 Voice memo indicator............................... 68
18 File number and type............................. 139
8
Introduction
Basic Operations
The A (shooting mode) Button
Shooting-mode Selection Menu
Use the rotary multi selector (A10) to select the following shooting modes.
While the shooting-mode selection menu is displayed, press the A button to
continue shooting without changing the shooting mode.
•Press the A button in playback mode to change to
shooting mode.
•Press the A button in shooting mode to display
the “shooting-mode selection menu” and change
the shooting mode.
1. AAuto mode (A24)
2. xScene mode (A37)*
3. FSmart portrait mode (A51)
4. sSubject tracking mode (A54)
5. DMovie mode (A76)
* The icon displayed will differ according to the last chosen mode.
Auto mode
1
2
3
4
5
9
Basic Operations
Introduction
The c (playback) Button
Playback-mode Selection Menu
Use the rotary multi selector (A10) to select the following playback modes.
While the playback-mode selection menu is displayed, press the c button to
return to the current playback mode without changing the mode.
•Press the c button in shooting mode to change
to playback mode.
•Press the c button in playback mode to display
the “playback-mode selection menu” and change
the playback mode.
•When the camera is off, holding down the c
button will turn the camera on in playback mode.
1. cPlayback mode (A30)
2. FAuto sort mode (A64)
3. CList by date mode (A61)
Play
1
2
3
10
Basic Operations
Introduction
The Rotary Multi Selector
This section describes standard uses of the rotary multi selector to select modes,
select menu options and to apply selections.
Shooting
* Options can also be chosen by pressing the rotary multi selector up or down.
Playback
1 Subsequent or previous pictures can also be selected by rotating the rotary multi selector.
2 A histogram is a graph showing the distribution of tones in the image. The horizontal axis
corresponds to pixel brightness, with dark tones to the left and bright tones to the right. The
vertical axis shows the number of pixels.
The shooting information displayed includes the folder name, file name, shooting mode used,
shutter speed, aperture, exposure compensation, ISO sensitivity, and the current file number.
A will be displayed for shooting mode.
Press the k button again to return to full-frame playback.
Flash mode
Display o
(exposure compensation)
(A36) guide
Display n (self-timer)
(A34) menu
Display m (flash mode) (A32) menu
Display p (macro mode) (A35) menu
Rotate to select an item*
Apply selection
15/11/2009 15:30
15/11/2009 15:30
44
44
44
100NIKON
100
P
+1.0
1/250 F2.7
ISO
Choose the previous
Choose the next
Display histogram and
shooting information2
(except for movies)
11
Basic Operations
Introduction
Menu Display
* Options can also be chosen by rotating the rotary multi selector.
CNote on the Rotary Multi Selector
In this manual, up, down, left, and right presses of the rotary multi selector may be indicated with H,
I, J and K.
Scene auto selector
Shooting menu
Image mode
Metering
Continuous
ISO sensitivity
Exit
White balance
Apply selection
(advance display to the next
screen)
Choose the option
on the left*/
Return display to
the previous screen
Choose the option above*
Choose the option below*
Choose the option on the
right*/
Proceed to the next screen
(apply selection)
12
Basic Operations
Introduction
The d button
Switching Between Tabs
Press the d button to display the menu for the
current mode.
•Use the rotary multi selector to navigate the menus
(A11).
•Select a tab on the left side of the monitor to
display the corresponding menu.
•Press the d button again to exit the menu.
Displayed when the menu contains two or more pages
Displayed when there are one or more menu options to follow
• Upper tab:
Displays the menus for
the current mode used
•Lower tab:
Displays the setup menu
Shooting menu
Image mode
White balance
Metering
Continuous
ISO sensitivity
Exit
Shooting menu
Color options
AF area mode
Autofocus mode
Exit
AF area mode
Face priority
Auto
Manual
Center
Exit
Select an item, then press the k button or
the rotary multi selector K to proceed to
the next set of options.
Press the k button or the
rotary multi selector K to
apply selection.
Displayed when
there are previous
menu options
Shooting menu Shooting menu
Image mode
White balance
Metering
Continuous
ISO sensitivity
Image mode
White balance
Metering
Continuous
ISO sensitivity
Exit Exit
Set up
Menus
Welcome screen
Date
Monitor settings
Date imprint
Exit
Press the rotary multi
selector J to highlight
the tab.
Press the rotary multi
selector H or I to choose
another tab, and press
either the k button or K.
The chosen menu is
displayed.
13
Basic Operations
Introduction
Help Displays
Rotate the zoom control to g (j) when M/L is displayed at the bottom of the
menu screen to view a description of the currently selected menu option.
To return to the original menu, rotate the zoom control to g (j) again.
Pressing the Shutter-Release Button Halfway/All the Way
Down
The camera features a two-stage shutter-release button. To set focus and
exposure, press the shutter-release button halfway, stopping when you feel
resistance. Focus and exposure lock while the shutter-release button is held in this
position. To release the shutter and take a picture, press the shutter-release button
the rest of the way down.
Do not use force when pressing the shutter-release button, as this may result in
camera shake and blurred pictures.
Attaching the Camera Strap
For accurate color reproduction,
choose a setting that matches
the light source.
White balance
Exit Back
Press the shutter-
release button halfway
to set focus and
exposure.
Press the shutter-
release button the
rest of the way down
to shoot.
14
First Steps
First Steps
Inserting the Battery
Insert a Rechargeable Li-ion Battery EN-EL12 (supplied) into the camera.
•Charge the battery before first use or when the battery is running low (A16).
1Open the battery-chamber/memory card slot
cover.
Slide the cover latch toward Y (1) and open the
battery-chamber/memory card slot cover (2).
2Insert the battery.
•Confirm that the positive (+) and negative (–)
terminals are oriented correctly, as shown on the
label at the entrance of the battery chamber, and
insert the battery.
•Use the edge of the battery to push the orange
battery latch in the direction indicated by the
arrow (1) and fully insert the battery (2). When
the battery is fully inserted, the battery latch will
lock it in place.
BInserting the Battery Correctly
Inserting the battery upside down or backwards
could damage the camera. Be sure to check the
battery is in the correct orientation.
3Close the battery-chamber/memory card slot
cover.
•Close the battery-chamber/memory card slot cover
(1), and slide the cover latch to the Z position (2).
Battery latch
15
Inserting the Battery
First Steps
Removing the Battery
Turn the camera off (A19) and confirm that the
power-on lamp and the monitor are off before opening
the battery-chamber/memory card slot cover.
To eject the battery, open the battery-chamber/
memory card slot cover and slide the orange battery
latch in the direction shown (1). The battery can then
be removed by hand (2).
•Note that the battery may become hot during use;
observe due caution when removing the battery.
BNotes on the Battery
•Be sure to read and follow the warnings and cautions of “For Your Safety” (Aii) thoroughly
before using the battery.
•Be sure to read and follow the warnings for “The Battery” (A141) of the section “Caring for the
Camera” thoroughly before using the battery.
•If the battery will not be used for an extended period, recharge it at least once every six months
and run it flat before returning it to storage.
16
First Steps
Charging the Battery
Charge the supplied Rechargeable Li-ion Battery EN-EL12 inserted into the
camera, by connecting the supplied Charging AC Adapter EH-68P to the camera
via the supplied USB Cable UC-E6, and then plugging the Charging AC Adapter
into an electrical outlet.
1Prepare the Charging AC Adapter
EH-68P.
If a plug adapter* is included, attach the
plug adapter to the plug on the Charging
AC Adapter. Push the plug adapter firmly
until it is securely held in place. Once the
two are connected, attempting to forcibly
remove the plug adapter could damage the
product.
* The shape of the plug adapter varies
according to the country or region in which the camera was purchased.
For Customers in Argentina
If the camera was purchased in Argentina, the shape of
the Charging AC Adapter EH-68P (AR) differs from that
supplied in other countries, and a plug adapter is not
included. Proceed to step 2.
2Be sure that the power-on lamp and the monitor are off.
•Be sure to insert the battery into the camera (A14) and turn off the camera (A19).
3
Use the supplied USB cable to connect the Charging AC Adapter to the camera.
BConnecting the Cable
When connecting the cable, be sure that the camera connector is properly oriented. Do not use
force when connecting the cable to the camera. When disconnecting the cable, do not pull the
connector at an angle.
EH-68P (AR)
17
Charging the Battery
First Steps
4Plug the Charging AC Adapter into an
electrical outlet.
•The camera’s charge lamp slowly blinks green to
indicate that the battery is charging.
•About 4 hours are required to charge a fully exhausted
battery.
•The following chart explains charge lamp
status when the camera is plugged into the
electrical outlet.
5Disconnect the Charging AC Adapter from the electrical outlet and
then disconnect the USB cable.
Charge lamp Description
Blinks slowly (green) Battery charging.
Off Not charging. When the charge lamp changes from slow
blinking (green) to off, charging is complete.
Flickers (green) •Operating temperature range exceeded. Charge the
battery indoors with an ambient temperature of 5 °C to
35 °C (41 °F to 95 °F).
•A USB cable is not correctly connected, nor is a Charging
AC Adapter correctly plugged, or the battery is faulty.
Disconnect the USB cable or unplug the Charging AC
Adapter and correctly connect it again, or change the
battery.
18
Charging the Battery
First Steps
BNotes on Charging AC Adapter
•Do not use the Charging AC Adapter EH-68P with any device that is not supported.
•Be sure to read and follow the warnings and cautions of “For Your Safety” (Aii) thoroughly
before using the EH-68P.
•Be sure to read and follow the warnings for “The Battery” (A141) thoroughly before using the
battery.
•The EH-68P is compatible with AC 100-240 V, 50/60 Hz electrical outlets. When using in other
countries, use a third-party plug adapter as necessary. For more information about plug adapters,
consult your travel agency.
•The Charging AC Adapter EH-68P is for charging the battery inserted into the camera. When the
Charging AC Adapter is connected to the camera, the camera cannot be turned on.
•Do not, under any circumstances, use a Charging AC Adapter other than the EH-68P or a USB AC
adapter. Failure to observe this precaution could result in overheating or in damage to the camera.
CNote on AC Power Supply
•If the AC Adapter EH-62F (available separately; A137) is used, power is supplied to the camera
from an electrical outlet and taking pictures and playing back pictures are available with this
camera.
•Do not, under any circumstances, use any AC adapter other than the EH-62F. Failure to observe
this precaution could result in overheating or in damage to the camera.
DCharging Using Computer or Battery Charger
•Connecting the COOLPIX S640 to a computer also charges the Rechargeable Li-ion Battery EN-
EL12 (A131).
•Rechargeable Li-ion Battery EN-EL12 can also be charged using the Battery Charger MH-65
(available separately; A137).
19
Charging the Battery
First Steps
Turning On and Off the Camera
Press the power switch to turn on the camera. The
power-on lamp (green) will light for a moment and the
monitor will turn on.
Press the power switch again to turn off the camera.
When the camera turns off, both the power-on lamp
and monitor will turn off.
•When the camera is off, holding down the c button will turn the camera on in
playback mode (A30).
CAuto Power Off in Shooting Mode (Standby Mode)
If no operations are performed for about a minute (default setting), the monitor will turn off
automatically and the camera will enter standby mode. If no operations are performed for another
three minutes, the camera will turn off automatically (the auto off function).
•If the monitor is off in standby mode (the power-on lamp is blinking), press the power switch or
the shutter-release button to reactivate it.
•The time allowed to elapse before the camera enters standby mode can be changed from the
Auto off option (A128) in the setup menu (A116).
20
First Steps
Setting Display Language, Date and Time
A language-selection dialog is displayed the first time the camera is turned on.
1Press the power switch to turn on the camera.
•The power-on lamp (green) will light for a moment and
the monitor will turn on.
2Use the rotary multi selector to
choose the desired language and
press the k button.
•For information on using the rotary multi
selector, see “The Rotary Multi Selector”
(A10).
3Choose Yes and press the k button.
•If No is selected, the date and time will not be set.
4Press the rotary multi selector J or K to
select your home time zone (city name)
(A122) and press the k button.
DDaylight Saving Time
If daylight saving time is in effect, press the rotary multi selector H
in the time zone selection screen displayed in step 4 to turn on the
daylight saving time option.
When the daylight saving time option is enabled, W is displayed at
the top of the monitor. To turn off the daylight saving time option,
press I.
Date
Set time and date?
No
Yes
Cancel
Back
London
Casablanca
Back
London
Casablanca
21
Setting Display Language, Date and Time
First Steps
5Edit the date.
•Rotate the rotary multi selector, or press H or I to
edit the highlighted item.
•Press K to move the highlight in the following order:
D (day) ➝ M (month) ➝ Y (year) ➝ hour ➝ minute
➝ DMY (the order in which the day, month, and year
are displayed)
•Press J to return to the previous item.
6Choose the order in which the day, month
and year are displayed and press the k
button or K.
•The settings are applied and monitor display exits to
shooting mode.
DChanging the Date and Time
•Select Date from the Date (A120) in the setup menu (A116) to change the current date and
time and follow the procedure described in step 5 above.
•Select Time zone from the Date in the setup menu to change the time zone and daylight saving
time settings (A120).
200901
00 00
01
Date
DMY
Edit
11
15 10
2009
15
DMY
Edit
Date
22
First Steps
Inserting Memory Cards
Image, sound, and movie files are stored in the camera’s internal memory (approx.
45 MB) or on removable memory cards (available separately) (A138).
If a memory card is inserted in the camera, data are automatically stored
on the memory card, and data recorded to the memory card can be played
back, deleted, or transferred. Remove the memory card to store data in
the internal memory, or play back, delete, or transfer data from the
internal memory.
1Confirm that the power-on lamp and the
monitor are off and open the battery-
chamber/memory card slot cover.
•Be sure to turn off the camera before opening the
battery-chamber/memory card slot cover.
2Insert the memory card.
•Insert the memory card in the correct
orientation (as shown on the right) until it
clicks into place.
•Close the battery-chamber/memory card
slot cover after inserting the memory card.
BInserting the Memory Card Correctly
Inserting the memory card upside down or backwards
could damage the camera or the memory card. Be sure
to check the memory card is in the correct orientation.
Removing Memory Cards
Before removing memory cards, turn the camera off
and confirm that the power-on lamp and the monitor
are off.
Open the battery-chamber/memory card slot cover
and press the card in (1) gently to partially eject the
card. The card can then be removed by hand (2).
23
Inserting Memory Cards
First Steps
BFormatting a Memory Card
If the message at the right is displayed when the camera is turned
on, the memory card must be formatted before use. Note that
formatting (A129) permanently deletes all data on the
memory card. Be sure to make copies of any pictures you wish to
keep before formatting the memory card.
To format the memory card, use the rotary multi selector to choose
Yes and press the k button. When the confirmation dialog is
displayed, choose Format and press the k button to start formatting.
•Do not turn the camera off or open the battery-chamber/memory card slot cover until formatting
is complete.
•When you insert a memory card that has been used in another device into this camera for the first
time, be sure to format it (A129) with this camera.
BThe Write Protect Switch
Memory cards are equipped with a write protect switch.
When this switch is in the “lock” position, data cannot be
written to, or deleted from, the memory card. If the switch
is in the “lock” position, unlock it by sliding the switch to the
“write” position to record or delete pictures, or to format
the memory card.
BMemory Cards
•Use only Secure Digital memory cards.
•Do not perform the following during formatting, while data is being written to or deleted from the
memory card, or during data transfer to a computer. Failure to observe this precaution could result
in the loss of data or in damage to the camera or memory card:
- Eject the memory card
- Remove the battery
-Turn off the camera
- Disconnect the AC adapter
•Do not use a computer to format the memory card.
•Do not disassemble or modify.
•Do not drop, bend, or expose to water or strong physical shock.
•Do not touch the metal terminals with your fingers or metal objects.
•Do not affix labels or stickers to the memory card.
•Do not leave in direct sunlight, closed vehicles or areas exposed to high temperatures.
•Do not expose to humidity, dust, or to corrosive gases.
Card is not formatted.
Format card?
No
Yes
Write protect switch
24
Basic Photography and Playback: Auto Mode
Basic Photography and Playback: Auto Mode
Step 1 Turn the Camera On and Select
A
(Auto) Mode
This section describes how to take pictures in A (auto) mode, an automatic,
“point-and-shoot” mode recommended for first-time users of digital cameras.
1Press the power switch to turn on the camera.
•The power-on lamp (green) will light for a moment and
the monitor will turn on. The lens will also extend.
•Proceed to step 4 when A is displayed on the
monitor.
2Press the A button to display the
shooting-mode selection menu.
3Use the rotary multi selector to choose A and
press the k button.
•The camera enters A (auto) mode.
4Check the battery level and number of
exposures remaining in the monitor.
Battery Level
Number of Exposures Remaining
The number of exposures remaining will be displayed.
The number of pictures that can be stored depends on the remaining capacity of the
internal memory or memory card and the image mode setting (A97).
Monitor Description
NO INDICATOR Battery fully charged.
BBattery level low; prepare to charge
or replace the battery.
N
Battery
exhausted.
Cannot shoot. Recharge or replace
with a fully-charged battery.
Auto mode
13
13
13
Battery level indicator
Number of exposures
remaining
25
Step 1 Turn the Camera On and Select A (Auto) Mode
Basic Photography and Playback: Auto Mode
Indicators Displayed in A (Auto) Mode
The indicators and photo info displayed during shooting and playback will turn off
after a few seconds (A123).
If the monitor is turned off in standby mode to save power, press the power switch
or the shutter-release button to reactivate it (A128).
DFunctions Available in A (Auto) Mode
In A (auto) mode, macro mode (A35) and exposure compensation (A36) can be applied and
pictures can be taken using the flash mode (A32) and self-timer (A34). Pressing the d button
in A (auto) mode allows you to specify settings for all shooting menu options (A95).
DVibration Reduction and Motion Detection
•See Vibration reduction (A125) or Motion detection (A126) in the setup menu (A116)
for more information.
•Set vibration reduction to Off when using a tripod to stabilize the camera during shooting.
13
13
13
Shooting mode
A displayed in A
(auto) mode.
Image mode
The combination of image size and
image quality (compression) is
displayed. The default setting is L
Normal (4,000×3,000).
Motion detection icon
Reduces the effects of
subject movement and
camera shake.
Internal memory indicator
Pictures will be recorded to internal memory
(approx. 45 MB). When a memory card is
inserted,
C
is not displayed and pictures will
be recorded to the memory card.
Vibration reduction icon
Reduces the effects of
camera shake.
26
Basic Photography and Playback: Auto Mode
Step 2 Frame a Picture
1Ready the camera.
•Hold the camera steadily in both hands. Keep your
fingers, hair, strap and other objects away from the
lens, flash, AF-assist illuminator, microphone and
speaker.
•When taking pictures in the portrait (vertical)
orientation, turn the camera so that the built-in flash is
above the lens.
2Frame the picture.
•Position the main subject near the center of the
monitor.
13
13
13
27
Step 2 Frame a Picture
Basic Photography and Playback: Auto Mode
Using the Zoom
Rotate the zoom control to activate optical zoom.
Rotate in the direction of g to zoom in on the subject.
Or rotate in the direction of f to have a wider view.
A zoom indicator is displayed at the top of the monitor
when the zoom control is rotated.
Digital Zoom
When the camera is already at the maximum optical zoom magnification, rotating
the zoom control in the g direction will trigger digital zoom. The subject can be
magnified up to 4× of the maximum optical zoom ratio.
When using digital zoom, the camera will focus on the center of the frame and the
focus area will not be displayed.
CDigital Zoom and Interpolation
Unlike optical zoom, digital zoom uses a digital imaging process known as interpolation to magnify
images, resulting in slight deterioration of picture quality according to the image mode (A96) and
digital zoom magnification.
Interpolation is applied at zoom positions beyond V. When zoom is increased beyond the V
position, interpolation is initiated and the zoom indicator turns yellow to indicate that interpolation
is being applied.
The position of V moves to the right as image size decreases, allowing for confirmation of the
zoom positions at which shooting without interpolation is possible at the current image mode
setting.
•Digital zoom can be disabled from the Digital zoom option (A127) in the setup menu
(A116).
Zoom out Zoom in
Optical
zoom
Digital
zoom
Maximum optical zoom Digital zoom is in effect.
When the image size is small
28
Basic Photography and Playback: Auto Mode
Step 3 Focus and Shoot
1Press the shutter-release button halfway.
•The camera focuses when the shutter-release button is
pressed halfway (A13).
•Camera automatically selects the focus area (up to nine
areas) containing the subject closest to the camera.
When the subject is in focus, the focus area (active
focus area) glows green.
•When using digital zoom, the camera focuses on the subject in the center of the
frame, and the focus area is not displayed. When the subject is in focus, the focus
indicator (A6) glows green.
•Press the shutter-release button halfway to display the shutter speed and aperture.
•Focus and exposure remain locked while the shutter-release button is pressed
halfway.
•When the shutter-release button is pressed halfway and the camera is unable to
focus, the focus area or focus indicator blinks red. Change the composition and press
the shutter-release button halfway again.
2Press the shutter-release button the rest of
the way down.
•The shutter will be released and the picture will be
recorded to the memory card or internal memory.
13
13
13
Shutter speed Aperture
F2.7
F2.7
F2.71/250
1/250
1/250
29
Step 3 Focus and Shoot
Basic Photography and Playback: Auto Mode
BDuring Recording
While pictures are being recorded, the number of exposures remaining display will blink. Do not
open the battery-chamber/memory card slot cover while pictures are being recorded.
Cutting power or removing the memory card in these circumstances could result in loss of data or in
damage to the camera or card.
BAutofocus
Autofocus may not perform as expected in the following situations. In some rare cases, the subject
may not be in focus despite the fact that the active focus area, or focus indicator, glows green:
•Subject is very dark
•Objects of sharply differing brightness are included in the scene (e.g. the sun is behind the subject
and is in deep shadow)
•No contrast between the subject and surroundings (e.g. when the subject is standing in front of a
white wall, wearing a white shirt)
•Several objects are at different distances from the camera (e.g. the subject is inside a cage)
•Subject is moving rapidly
In the situations noted above, try pressing the shutter-release button halfway to refocus several
times, or focus on another subject and use focus lock (A105). When using focus lock, be sure that
the distance between the camera and the subject with which focus was locked is the same as that
for the actual subject.
DAF-assist Illuminator and Flash
If the subject is poorly lit, the AF-assist illuminator (A127) may light when the shutter-release
button is pressed halfway and the flash (A32) may fire when the shutter-release button is pressed
all the way down.
30
Basic Photography and Playback: Auto Mode
Step 4 Viewing and Deleting Pictures
Viewing Pictures (Playback Mode)
Press the c (playback) button.
•The last picture shot will be displayed in full-frame
playback mode.
•Rotate the rotary multi selector, or press H, I, J
or K, to view additional pictures (A10).
•Pictures may be displayed briefly at low resolution
while being read from the memory card or internal
memory.
•Press the A button or the shutter-release button
to return to shooting mode.
•When C is displayed, pictures stored in the internal
memory will be displayed. When a memory card is inserted,
C is not displayed and pictures stored on the memory card
will be displayed.
Deleting Pictures
1Press the l button to delete the
picture currently displayed in the
monitor.
2Use the rotary multi selector to choose Yes
and press the k button.
•Deleted pictures cannot be recovered.
•To exit without deleting the picture, choose No and
press the k button.
A (shooting mode) button
c (Playback)
button
Rotary multi
selector
15/11/2009 15:30
15/11/2009 15:30
4
4
4
4
Internal memory indicator
No
Yes
Erase 1 image?
31
Step 4 Viewing and Deleting Pictures
Basic Photography and Playback: Auto Mode
COptions Available in Playback Mode
The following options are available in full-frame playback mode.
CPressing the c Button to Turn on the Camera
When the camera is off, holding down the c button will turn the camera on in playback mode. The
lens will not extend.
CViewing Pictures
•Pictures stored in the internal memory can only be viewed if no memory card is inserted.
•Pictures that were shot using Face Priority (A106) will be rotated automatically when displayed
in full-frame playback mode according to the orientation of the face (excluding pictures that were
shot using Continuous, BSS and Multi-shot 16 (A101)).
•If the monitor is turned off in standby mode to save power, press the power switch or the shutter-
release button to reactivate it (A128).
CDeleting the Last Picture Taken While in Shooting Mode
In shooting mode, press the l button to delete the last picture
shot.
DDeleting Multiple Pictures
Choose Delete (A113) from the Playback menu (A110), List by Date menu (A63) or Auto sort
menu (A66) to delete multiple pictures.
Option Use Description A
Playback zoom g (i)
Enlarge the view of the picture currently
displayed in the monitor, up to about 10×.
Press the k button to return to full-frame
playback mode.
60
Thumbnail display/
Calendar display f (h)Display images by 4, 9 or 16 picture
thumbnails, or display the calendar. 57, 59
Display shooting
information k
Display the histogram and the shooting
information. Press the k button to return to
full-frame playback.
10
Change playback mode c
Display the playback-mode selection menu,
and switch to List by Date mode or Auto sort
playback mode.
61, 64
Switch to shooting
mode
A
Press the A button or the shutter-release
button. 30
No
Yes
Erase 1 image?
32
Basic Photography and Playback: Auto Mode
Using the Flash
The flash has a range of about 0.5 to 8.0 m (1 ft. 8 in. to 26 ft.) when the camera is
zoomed out all the way. With maximum optical zoom applied, the range is about
0.5 to 4.0 m (1 ft. 8 in. to 13 ft.) (when ISO sensitivity is set to auto). The following
flash modes are available.
Setting the Flash Mode
1Press X (flash mode).
•The flash mode menu is displayed.
2Use the rotary multi selector to choose the
desired flash mode and press the k button.
•The icon for the selected flash mode is displayed at the
top of the monitor.
•D will disappear after a few seconds regardless of
the current Photo info setting (A123).
•If a setting is not applied by pressing the k button
within a few seconds, the selection will be cancelled.
UAuto
Flash fires automatically when lighting is poor.
VAuto with red-eye reduction
Reduces “red-eye” in portraits (A33).
WOff
Flash will not fire even when lighting is poor.
XFill flash
Flash fires whenever a picture is taken. Use to “fill-in” (illuminate) shadows and
backlit subjects.
YSlow sync
Auto is combined with slow shutter speed.
Suitable for taking portrait images with the night landscape as the background.
Flash illuminates main subject; slow shutter speeds are used to capture background
at night or under dim light.
Flash mode
26
33
Using the Flash
Basic Photography and Playback: Auto Mode
BShooting When Lighting is Poor and When the Flash is Disabled (W)
•Use of a tripod is recommended to stabilize the camera during shooting and avoid the effects of
camera shake. Set Vibration reduction (A125) in the setup menu (A116) to Off when using
a tripod to stabilize the camera during shooting.
•The E indicator is displayed when the camera automatically increases sensitivity. Pictures taken
when E is displayed may be slightly mottled.
•When E is displayed and higher sensitivity is applied, noise reduction may be automatically
applied as pictures are recorded. This will result in increased recording times.
BNote on Using the Flash
Reflections from dust particles in the air may appear as bright spots in pictures. To reduce these
reflections, set the flash to W (off).
CThe Flash Lamp
The flash lamp indicates the flash status when the
shutter-release button is pressed halfway down.
•On : Flash will fire when picture is shot.
•
Blinks : Flash is charging. Wait a few seconds and try again.
•Off : Flash will not fire when picture is shot.
If the battery is low, the monitor display will turn off, and
remain off, until the flash is fully charged.
CFlash Setting
The default flash mode setting varies with shooting mode.
•A (auto): U auto.
•Scene mode: setting varies for different scene modes (A38-44).
•F
(smart portrait) mode: set to
W
off (when Blink Proof is on),
U
auto (when Blink Proof is off) (
A
53)
•Flash cannot be used simultaneously with certain features (A109).
•s (subject tracking): W off
The flash mode setting applied in A (auto) mode is stored in the camera’s memory even after the
camera is turned off, and reapplied the next time A (auto) mode is selected.
CRed-eye Reduction
This camera uses Advanced Red-eye Reduction (“In-Camera Red-Eye Fix”).
Pre-flashes are fired repeatedly at low intensity before the main flash, reducing the red-eye effect.
If the camera detects “red-eye” when a picture is taken, Nikon’s own In-Camera Red-Eye Fix
processes the image before it is recorded.
Note the following when taking pictures:
•Because pre-flashes are fired, there is a slight lag between when the shutter-release button is
pressed and when the picture is shot. This mode is not recommended when a quick shutter
response is required.
•The time required to save the picture increases slightly.
•Advanced red-eye reduction may not produce the desired results in some situations.
•In extremely rare instances, areas not subject to red-eye may be affected by advanced red-eye
reduction processing; in these cases, choose another mode and try again.
34
Basic Photography and Playback: Auto Mode
Taking Pictures with the Self-Timer
The camera is equipped with a ten-second and two-second timer for self-portraits.
When using the self-timer, use of a tripod is recommended. Set Vibration
reduction (A125) to Off in the setup menu (A116) when using a tripod.
1Press n (self-timer).
•The self-timer menu is displayed.
2Use the rotary multi selector to choose 10s or
2s and press the k button.
•10s (ten seconds): suited for important occasions (such
as weddings)
•2s (two seconds): suited for preventing camera shake
•The mode selected for self-timer is displayed.
•If a setting is not applied by pressing the k button
within a few seconds, the selection will be cancelled.
3Frame the picture and press the
shutter-release button halfway.
•Focus and exposure will be set.
4Press the shutter-release button the
rest of the way down.
•The self-timer starts, and the number of
seconds remaining the shutter is released is
displayed in the monitor. The self-timer lamp
will blink. The lamp stops blinking one
second before the picture is taken and
remains lit until the shutter is released.
•When the shutter is released, the self-timer
turns OFF.
•To stop the timer before a picture is taken,
press the shutter-release button again.
2s
10s
Self-timer
F2.7
F2.7
F2.7
1/250
1/250
1/250
F2.7
F2.7
F2.7
1/250
1/250
1/250
9
9
35
Basic Photography and Playback: Auto Mode
Macro Mode
Macro mode is used for taking pictures of objects as close as 2 cm (0.8 in.). Note that
the flash may be unable to light the entire subject at distances of less than 50 cm
(1 ft. 7 in.).
1Press p (macro mode).
•The macro mode menu is displayed.
2Use the rotary multi selector to choose ON
and press the k button.
•The macro mode icon (F) is displayed.
•If a setting is not applied by pressing the k button
within a few seconds, the selection will be cancelled.
3Use the zoom control and frame the picture.
•The closest distance at which the camera can focus
varies depending on the zoom position. At the zoom
position (wide angle position before the G icon)
where the F icon and zoom display glow green, the
camera can focus on subjects as close as 4 cm (1.6 in.)
from the lens. At the wide-most zoom position, the camera can focus on subjects as
close as 2 cm (0.8 in.) from the lens.
CAutofocus
When using A (auto) mode, if Autofocus mode (A108) is set to Full-time AF, the camera will
continually focus until the focus is locked when you press the shutter-release button halfway. A
sound will be heard while the camera focuses.
When using other shooting modes, Full-time AF is turned on automatically when macro mode is
turned on.
CThe Macro Mode Setting
The macro mode setting applied in A (auto) mode is stored in the camera’s memory even after the
camera is turned off, and reapplied the next time A (auto) mode is selected.
Macro mode
36
Basic Photography and Playback: Auto Mode
Exposure Compensation
Exposure compensation is used to alter the exposure from the value suggested by
the camera to make pictures brighter or darker.
1Press o (exposure compensation).
•The exposure compensation guide and histogram are
displayed.
2Use the rotary multi selector to adjust the
exposure and press the k button.
•When the subject is too dark: adjust the exposure
compensation to “+” side.
•When the subject is too bright: adjust the exposure
compensation to “–” side.
•Exposure compensation can be set to values between
–2.0 and +2.0 EV.
•If a setting is not applied by pressing the k button
within a few seconds, the selection will be cancelled.
•
When set to any value other than
0.0
, the value is displayed with the
H
icon in the monitor.
3Press the shutter-release button to take the
picture.
•To turn off exposure compensation, repeat from step 1
and set the value to 0.0, then press k.
CExposure Compensation Value
The exposure compensation value applied in A (auto) mode is stored in the camera’s memory even
after the camera is turned off, and reapplied the next time A (auto) mode is selected.
DUsing Exposure Compensation
•The camera tends to lower exposure when the frame is dominated by brightly lit objects (for
example, sunlit expanses of water, sand, or snow) or when the background is much brighter than
the main subject.
•Negative compensation may be called for when large areas of the frame contain very dark objects (for
example, a swath of dark green leaves) or when the background is much darker than the main subject.
DUsing the Histogram
A histogram is a graph showing the distribution of tones in the image.
•The horizontal axis corresponds to pixel brightness, with dark tones to the left and bright tones to
the right. The vertical axis shows the number of pixels.
•Increasing exposure compensation shifts tone distribution to the right, and decreasing it shifts
tone distribution to the left.
•Use as a guide when using exposure compensation and shooting without the flash.
Exposure compensation
Histogram
13
13
13
37
Shooting Suited for the Scene
Shooting Suited for the Scene
Shooting in Scene Mode
Camera settings are automatically optimized for the selected subject type. The
following scene modes are available.
Choosing a Scene Mode
1Display the shooting-mode
selection menu by pressing the A
button in shooting mode, and use
the rotary multi selector to choose
a scene icon.
•The icon for the scene mode that was
chosen previously will be displayed. The
default setting is x (Scene auto selector).
2Press K, choose a scene and press the k
button.
•The screen changes to the shooting mode screen.
•“Features“ ➝ A38
3Frame the subject and take the
picture.
CImage Mode
You can change the Image mode setting (A96) by pressing the d button to display the C
(scene) menu.
Changes made to the image mode setting apply to all shooting modes (except for the movie mode).
x
Scene auto selector
bPortrait cLandscape dSports
eNight portrait fParty/indoor gBeach/snow hSunset
iDusk/dawn jNight landscape kClose-up uFood
lMuseum mFireworks show nCopy oBacklight
pPanorama assist
Scene auto selector
Beach/snow
F2.7
F2.7
1/250
1/250
38
Shooting in Scene Mode
Shooting Suited for the Scene
Features
The following icons are used for descriptions in this section: X = flash mode
(A32), n = self-timer (A34), p = macro mode (A35), o = exposure
compensation (A36).
1 The camera automatically chooses the optimum flash mode setting for the scene mode it has
selected. W (off) can be selected.
2 Other settings can be selected.
3 Changes to On when the camera selects close-up scene mode.
* Other settings can be selected.
* Other settings can be selected.
Q: Indicates pictures shot in this scene mode are processed automatically to reduce noise, and
therefore may take more time to save.
xScene auto selector
By simply framing a picture, the camera automatically selects the optimum scene mode.
See “Shooting in the Scene Mode Selected by the Camera (Scene Auto Selector)” (A45)
for more information.
XU
1nOff2pOff3o0.02
bPortrait
Use this mode for taking portraits in which the main subject
stands out clearly.
•If the camera detects a face, it focuses on the face (Shooting
with Face Priority ➝ A106).
•If the camera detects multiple faces, the camera focuses on
the face closest to the camera.
•The skin softening feature can make the subject’s (up to three people) skin appear
smoother, then record the image (A52).
•If no face is recognized, the camera will focus on the subject in the center of the frame.
•Digital zoom is not available.
XV*nOff* pOff o0.0*
cLandscape
Use this mode for vivid landscapes and cityscapes.
•Camera focuses at infinity. When the shutter-release button
is pressed halfway, the focus area or focus indicator (A6)
always lights green; however, focus may not be set for near
subjects, while the camera focuses at infinity.
•AF-assist illuminator (A127) does not light.
XWnOff* pOff o0.0*
Q
Q
Q
39
Shooting in Scene Mode
Shooting Suited for the Scene
* Other settings can be selected.
1 Fixed to slow sync with red-eye reduction.
2 Other settings can be selected.
O: Indicates a tripod is recommended when using this scene mode. Turn Vibration reduction
(A125) to Off when using a tripod.
dSports
Use this mode for dynamic action shots that freeze the action
in a single shot and record motion in a series of pictures. With
continuous shooting, instantaneous movements in moving
subjects can be captured clearly.
•The camera focuses on the subject in the center of the
frame. The camera focuses continuously until focus is
locked by pressing the shutter-release button halfway.
•While the shutter-release button is held down, pictures are taken at rate of up to about
0.8 frames per second (fps) when image mode is set to I Normal (4000). Shooting
ends when the shutter-release button is released, or ten shots have been taken with the
shutter-release button held down.
•Focus, exposure compensation, and white balance are fixed at the values determined
with the first shot in each series.
•AF-assist illuminator (A127) does not light.
•The maximum frame rate with continuous shooting may vary, depending upon the
current image mode and the type of memory card used.
XWnOff pOff o0.0*
eNight portrait
Use this mode for portraits of a human subject shot in front of
background lighting at night. Flash is used to illuminate the
subject while maintaining the mood of the background.
•If the camera detects a face, it focuses on the face (Shooting
with Face Priority ➝ A106).
•If the camera detects multiple faces, the camera focuses on
the face closest to the camera.
•The skin softening feature can make the subject’s (up to three people) skin appear
smoother, then record the image (A52).
•If no face is recognized, the camera will focus on the subject in the center of the frame.
•Digital zoom is not available.
XV
1nOff2pOff o0.02
O
40
Shooting in Scene Mode
Shooting Suited for the Scene
1 Fill flash with slow sync and red-eye reduction. Other settings can be selected.
2 Other settings can be selected.
* Other settings can be selected.
* Other settings can be selected.
O: Indicates a tripod is recommended when using this scene mode. Turn Vibration reduction
(A125) to Off when using a tripod.
Q: Indicates pictures shot in this scene mode are processed automatically to reduce noise, and
therefore may take more time to save.
fParty/indoor
Suitable for taking pictures in parties. Captures the effects of
candlelight and other indoor background lighting.
•The camera focuses on the subject in the center of the
frame.
•Hold the camera steadily as pictures are easily affected by
camera shake. When shooting under low lighting, use of a
tripod is recommended. Set Vibration reduction (A125) to Off when using a tripod
to stabilize the camera during shooting.
XV
1nOff2pOff o0.02
gBeach/snow
Captures the brightness of such subjects as snowfields,
beaches, or sunlit expanses of water.
•The camera focuses on the subject in the center of the
frame.
XU*nOff* pOff* o0.0*
hSunset
Preserves the deep hues seen in sunsets and sunrises.
•Camera focuses at infinity. When the shutter-release button is
pressed halfway, the focus area or focus indicator (A6)
always lights green; however, focus may not be set for near
subjects, while the camera focuses at infinity.
•AF-assist illuminator (A127) does not light.
XWnOff* pOff o0.0*
Q
Q
OQ
41
Shooting in Scene Mode
Shooting Suited for the Scene
* Other settings can be selected.
* Other settings can be selected.
O: Indicates a tripod is recommended when using this scene mode. Turn Vibration reduction
(A125) to Off when using a tripod.
Q: Indicates pictures shot in this scene mode are processed automatically to reduce noise, and
therefore may take more time to save.
iDusk/dawn
Preserves the colors seen in the weak natural light before
sunrise or after sunset.
•Camera focuses at infinity. When the shutter-release button is
pressed halfway, the focus area or focus indicator (A6)
always lights green; however, focus may not be set for near
subjects, while the camera focuses at infinity.
•AF-assist illuminator (A127) does not light.
XWnOff* pOff o0.0*
jNight landscape
Use this mode to capture night landscapes. Slow shutter
speeds are used to produce stunning night landscapes.
•Camera focuses at infinity. When the shutter-release button
is pressed halfway, the focus area or focus indicator (A6)
always lights green; however, focus may not be set for near
subjects, while the camera focuses at infinity.
•AF-assist illuminator (A127) does not light.
XWnOff* pOff o0.0*
OQ
O
42
Shooting in Scene Mode
Shooting Suited for the Scene
* Other settings can be selected. Note that when shooting with the flash, the flash may be unable
to light the entire subject at distances of less than 50 cm (1 ft. 7 in.).
* Other settings can be selected.
* Other settings can be selected.
Q: Indicates pictures shot in this scene mode are processed automatically to reduce noise, and
therefore may take more time to save.
kClose-up
Use to photograph flowers, insects and other small objects at
close range.
•Macro mode (A35) will be turned on and the camera
automatically zooms to the position at the closest distance
at which the camera can focus.
•The closest distance at which the camera can focus varies
depending on the zoom position. At the zoom position (wide angle position before the
G icon) where the F icon and zoom display glow green, the camera can focus on
subjects as close as 4 cm (1.6 in.) from the lens. At the wide-most zoom position, the
camera can focus on subjects as close as 2 cm (0.8 in.) from the lens.
•AF area mode is set to Manual. Press the k button to choose the focus area in which
focus is acquired. (A104).
•The camera focuses continuously until focus is locked by pressing the shutter-release
button halfway.
•As pictures are easily affected by camera shake, be sure that Vibration reduction
(A125) is enabled and hold the camera steadily.
XW*nOff* pOn o0.0*
uFood
Use this mode when taking pictures of food. See “Taking
Pictures in Food Mode” (A47) for more information.
•AF area mode is set to Manual. Press the k button to
choose the focus area in which focus is acquired (A104).
mWnOff* pOn o0.0*
lMuseum
Use indoors where flash photography is prohibited (for
example, in museums and art galleries) or in other settings in
which you do not want to use the flash.
•Camera focuses on subject in center of frame.
•BSS (Best Shot Selector) (A101) is used when shooting.
•As pictures are easily affected by camera shake, be sure that
Vibration reduction (A125) is enabled and hold the camera steadily.
•AF-assist illuminator (A127) does not light.
XWnOff* pOff* o0.0*
Q
Q
43
Shooting in Scene Mode
Shooting Suited for the Scene
* Other settings can be selected.
* Other settings can be selected.
O: Indicates a tripod is recommended when using this scene mode. Turn Vibration reduction
(A125) to Off when using a tripod.
Q: Indicates pictures shot in this scene mode are processed automatically to reduce noise, and
therefore may take more time to save.
mFireworks show
Slow shutter speeds are used to capture the expanding burst of
light from fireworks.
•Camera focuses at infinity. When the shutter-release button is
pressed halfway, the focus area or focus indicator (A6)
always lights green; however, focus may not be set for near
subjects, while the camera focuses at infinity.
•AF-assist illuminator (A127) does not light.
XWnOff pOff o0.0
nCopy
Provides clear pictures of text or drawings on a white board or
in print.
•The camera focuses on the subject in the center of the
frame.
•Use macro mode (A35) to focus at short ranges.
•Colored text and drawings may not show up well.
XW*nOff* pOff* o0.0*
oBacklight
Use when light is coming from behind the subject, throwing
features or details in shadow. The flash fires automatically to
“fill in” (illuminate) shadows.
•The camera focuses on the subject in the center of the
frame.
XXnOff* pOff o0.0*
O
Q
44
Shooting in Scene Mode
Shooting Suited for the Scene
* Other settings can be selected.
Q: Indicates pictures shot in this scene mode are processed automatically to reduce noise, and
therefore may take more time to save.
pPanorama assist
Use to take a series of pictures that will later be joined to form a single panorama using the
supplied Panorama Maker software. See “Taking Pictures for a Panorama” (A49) for more
information.
mW*nOff* pOff* o0.0*
Q
45
Shooting in Scene Mode
Shooting Suited for the Scene
Shooting in the Scene Mode Selected by the Camera
(Scene Auto Selector)
By simply framing a picture, the camera automatically selects the optimum scene
mode for simpler shooting. When the camera is aimed at a subject in x scene
auto selector, the camera automatically selects one of the following scene modes.
1Display the shooting-mode
selection menu by pressing the A
button in shooting mode, and use
the rotary multi selector to choose
xScene auto selector (A37).
•Scene auto selector will be enabled.
2Frame the subject and take the picture.
•When the camera automatically selects a scene mode,
the shooting mode icon changes to that for the scene
mode currently enabled.
•Press the shutter-release button halfway to set focus and exposure. When the subject
is in focus, the active focus area glows green.
•Press the shutter-release button the rest of the way down to take the picture.
•Auto mode (typical photography) •Portrait (A38)
•Landscape (A38) •Night portrait (A39)
•Night landscape (A41) •Close-up (A42)
•Backlight (A43)
d: Auto mode g: Night landscape
e: Portrait i: Close-up
f: Landscape j: Backlight
h: Night portrait
Scene auto selector
16
13
13
46
Shooting in Scene Mode
Shooting Suited for the Scene
BNote on Scene Auto Selector Mode
Depending upon shooting conditions, the camera may not select the expected scene mode. Should
this occur, switch to A (auto) mode (A24) or choose the desired scene mode manually (A37).
CFocusing When Using Scene Auto Selector Mode
•When using scene auto selector mode, if the camera detects a face, it focuses on the face
(Shooting with Face Priority ➝ A106).
•When the shooting mode icon is d or i (Close-up), just as when AF area mode (A104) is
set to Auto, the camera automatically selects the focus area (up to nine areas) containing the
subject closest to the camera.
CFlash Mode in Scene Auto Selector Mode
U (auto) (default setting) and W (off) flash mode settings (A32) can be applied.
•When U (auto) is applied, the camera automatically chooses the optimum flash mode setting
for the scene mode it has selected.
•When W (off) is applied, the flash does not fire, regardless of shooting conditions.
CFunctions Restricted in Scene Auto Selector Mode
•Digital zoom is not available.
•The macro mode button on the rotary multi selector cannot be used (A10, 35).
47
Shooting in Scene Mode
Shooting Suited for the Scene
Taking Pictures in Food Mode
Use this mode when taking pictures of food.
1Display the shooting-mode
selection menu by pressing the A
button in shooting mode, and use
the rotary multi selector to choose
uFood (A37).
•Macro mode (A35) will be turned on
and the camera automatically zooms to
the position at the closest distance at which the camera can focus.
2Press the rotary multi selector H or I to
choose white balance.
•Press H to increase the amount of red, or I to
increase the amount of blue.
3Frame the picture.
•The closest distance at which the camera can focus
varies depending on the zoom position. At the zoom
position (wide angle position before the G icon)
where the F icon and zoom display glow green, the
camera can focus on subjects as close as 4 cm (1.6 in.)
from the lens. At the wide-most zoom position, the
camera can focus on subjects as close as 2 cm (0.8 in.)
from the lens.
•AF area mode is set to Manual (A104).
Press the k button to move the focus area. Rotate the
rotary multi selector or press H, I, J or K to move
the focus area to the desired position. Press the k
button again to lock the selected focus area.
•Self-timer (A34) and exposure compensation
(A36) settings can be adjusted while the focus area is
locked.
Food
13
13
13
13
13
13
Focus area
48
Shooting in Scene Mode
Shooting Suited for the Scene
4Press the shutter-release button to
take the picture.
•Focus is locked when the shutter-release
button is pressed halfway, and a picture is
taken when the shutter-release button is
pressed the rest of the way down.
•When the camera is unable to focus, the
focus area blinks red. Change the
composition and press the shutter-release
button halfway again.
BNote on Food Mode
•Flash mode is disabled. Macro mode setting (A35) is set to ON and cannot be changed.
•As pictures are easily affected by camera shake, be sure that Vibration reduction (A125) is
enabled and hold the camera steadily.
CWhite Balance Setting in Food Mode
•Increasing the amount of red or blue decreases the effects of lighting conditions.
•Adjusting the white balance setting while using food mode does not change the White balance
setting in the shooting menu (A98).
•The white balance setting applied in food mode is stored in the camera’s memory even after the
camera is turned off, and reapplied the next time food mode is selected.
F2.7
F2.7
1/250
1/250
F2.71/250
49
Shooting in Scene Mode
Shooting Suited for the Scene
Taking Pictures for a Panorama
The camera focuses on the subject in the center of the frame. Use a tripod for best
results.
Set Vibration reduction (A125) in the setup menu (A116) to Off when
using a tripod to stabilize the camera during shooting.
1Display the shooting-mode
selection menu by pressing the A
button in shooting mode, and use
the rotary multi selector to choose
pPanorama assist (A37).
•The I icon is displayed to show the
direction in which pictures will be joined.
2Use the rotary multi selector to choose the
direction and press the k button.
•Decide how pictures will be joined together in the
completed panorama; right (I), left (J), up (K) or
down (L).
•The yellow panorama direction icon (II) will move to
the direction pressed and press the k button to
choose the direction. A white panorama direction icon (I) will be displayed in the
chosen direction.
•Apply flash mode (A32), self-timer (A34), macro mode (A35) and exposure
compensation (A36) settings with this step, if necessary.
•Press the k button again to choose a different direction.
3Take the first picture.
•The picture taken will be displayed in 1/3 of
the monitor.
Panorama assist
13
13
13
F2.7
F2.7
F2.7
1/250
1/250
1/250
50
Shooting in Scene Mode
Shooting Suited for the Scene
4Shoot the second picture.
•Compose the next picture so that it overlaps
the first picture.
•Repeat until you have taken the necessary
number of pictures to complete the image.
5Press the k button when shooting is
complete.
•The camera returns to step 2.
BPanorama Assist
•Set flash mode, self-timer, macro mode and exposure compensation before taking the first picture.
They cannot be changed after the first picture is taken. Pictures cannot be deleted, nor can zoom
or Image mode setting (A96) be adjusted after the first picture is taken.
•The panorama series is terminated if the camera enters standby mode with the auto off function
(A128) during shooting. Increasing the time allowed to elapse before the auto off function is
enabled is recommended.
DR (exposure lock) Indicator
When using panorama assist mode, all pictures in the panorama
have the same exposure, white balance, and focus as the first
picture of the panorama.
When the first picture is shot, R is displayed to indicate that
exposure, white balance, and focus are locked.
DPanorama Maker
Install Panorama Maker from the supplied Software Suite CD.
Transfer pictures to a computer (A80) and use Panorama Maker (A83) to join them in a single
panorama.
DMore Information
See “File and Folder Names” (A139) for more information.
12
12
12
End
End
8
8
8
8
End
End
12
12
12
End
End
51
Taking Pictures of Smiling Faces (Smart Portrait Mode)
Taking Pictures of Smiling Faces (Smart Portrait Mode)
Using Smart Portrait Mode
At the default setting, the camera detects smiling faces using face priority and
releases the shutter automatically (smile timer function). The skin softening
function makes a human subject’s skin appear smoother.
1Display the shooting-mode
selection menu by pressing the A
button in shooting mode, use the
rotary multi selector to choose F,
and then press the k button.
•Smart portrait mode is selected.
2Frame the picture.
•Point the camera at the subject.
•When the camera detects a face, the focus area
containing the face will be displayed with a yellow
double border, and when focus is locked the double
border will turn green for a moment.
•Up to three faces can be detected. When more than
one face is detected, the face closest to the center of the frame is framed by a double
border and the others by single borders.
3The shutter is automatically released.
•If the camera detects that the face framed by the double border is smiling, the Smile
timer function (A53) automatically releases the shutter.
•When the camera detects a face, the self-timer lamp (A4) blinks. Immediately after
the shutter is released, the self-timer lamp flickers. Each time the shutter is released,
the camera repeats automatic shooting by face priority and smile detection.
•The shutter can also be released by pressing the shutter-release button. If no face is
detected, the camera focuses on the subject in center of frame.
•When the shutter is released, the camera makes the subject’s skin appear smoother,
then records the image (Skin softening (A52)).
4Finish shooting.
•To finish automatic shooting of smiling faces, either turn the camera off, set Smile
timer to Off, or press the A button and select another shooting mode.
Smart portrait
F2.7
F2.7
F2.7
1/250
1/250
1/250
52
Using Smart Portrait Mode
Taking Pictures of Smiling Faces (Smart Portrait Mode)
CFace Priority and Smiling Face Detection Features
•Under some shooting conditions, faces and smiling faces may not be detected properly.
•See “Notes on Face Priority” (A107) for more information about face priority.
CAuto Power Off When Using Smile Timer (Standby Mode)
When Smile timer is set to On, the auto off function (A128) will turn the camera off in the
following situations if no operations are performed.
•The camera is unable to detect any face.
•The camera has detected one or more faces, but is unable to detect a smiling face.
CFunctions Available in Smart Portrait Mode
•Flash mode is disabled when Blink proof is set to On. Flash mode (A32) will be changed to
U (auto) when Blink proof is set to Off (other settings can be selected).
•Exposure compensation (A36) can be adjusted.
•If Smile timer and Blink proof are both set to Off, self-timer (A34) can be set.
•Macro mode cannot be used.
•Digital zoom is not available.
•Press the d button to display the F (smart portrait) menu and change the settings for Image
mode, Skin softening, Smile timer, or Blink proof.
DMore Information
See “Autofocus” (A29) for more information.
Smart Portrait Menu
The smart portrait menu contains the following options.
Press the d button in smart portrait mode to display the smart portrait menu
and use the rotary multi selector to modify and apply settings.
Image mode
Allows you to set Image mode (A96).
Changes made to the image mode setting apply to all shooting modes (except
movie mode).
Skin softening
Set skin softening. When the shutter is released, the camera detects up to 3 faces and
processes the image to make the faces appear smoother, then records the image.
The effect of this feature can be set to High, Normal (default setting), and Low.
When Off is selected, skin softening is turned off.
•When skin softening is enabled, the icon for the current setting is displayed in the
monitor during shooting (A6). When Off is selected, an icon for the current
setting is not displayed. Additionally, the effects of the current skin softening
setting cannot be previewed in the monitor while shooting. To confirm, view the
pictures after shooting.
53
Using Smart Portrait Mode
Taking Pictures of Smiling Faces (Smart Portrait Mode)
BNotes on Skin Softening
•When taking pictures with skin softening, the time required to save the pictures increases slightly.
•Depending on shooting conditions, even if the camera detects a face on the monitor at the time
of shooting, effects of the skin softening function may not be visible, and areas other than the face
may be processed. If the desired effect is not achieved, set Skin softening to Off and shoot again.
•The amount of skin softening effect that is applied cannot be set while using the portrait or night
portrait scene modes.
•Skin softening can also be applied to pictures after they have been taken (A73).
Smile timer
•On (default setting): Among the detected faces, if a smile is detected in the face
that is framed by a double border, the camera automatically releases the shutter.
•Off: The camera does not release the shutter automatically using smile timer; the
shutter is only released when the shutter-release button is pressed.
•When smile timer is enabled, the current setting is displayed during shooting
(A6). When Off is selected, an icon for the current setting is not displayed.
Blink proof
When set to On, the shutter is released two times
each time a picture is taken; the camera chooses one
image in which the subjects’ eyes are open, and
saves it.
•The message on the right will be displayed for a
few seconds when the camera records an image in
which someone may have been blinking.
•When set to On, the flash cannot be used.
•The default setting is Off.
•When blink proof is enabled, the current setting is displayed during shooting
(A6). When Off is selected, an icon for the current setting is not displayed.
A blink was detected in the
picture just taken.
54
Focusing on a Moving Subject in Subject Tracking Mode
Focusing on a Moving Subject in Subject Tracking Mode
Subject Tracking Mode
Use this mode to shoot moving subjects. Subject tracking begins once you select
a subject to be focused on, and the focus area will move and follow the subject. At
the default setting, once the camera detects a person’s face it will automatically
begin tracking that person (face priority tracking).
1Display the shooting-mode
selection menu by pressing the A
button in shooting mode, use the
rotary multi selector to choose s,
and then press the k button.
•The camera enters subject tracking mode,
and a single border is displayed in the
center of the frame.
•The flash mode (A32) is set to W (off) (the setting can be changed).
2Select a subject.
•Frame the subject in the center of the single border,
and press the k button.
- The subject is registered.
- When the camera is unable to focus on the subject,
the single border will glow red. Change the
composition and try again.
•Once the subject is selected, it is framed by a yellow
double border, and subject tracking begins.
•If the camera detects a face, that face is automatically
registered as the subject to be tracked, and subject
tracking begins (A56).
•To change subjects, press the k button to cancel the
currently selected subject, then select a new subject.
•If the camera loses sight of the subject, the double border disappears; register the
subject again.
Subject tracking
Start
StartStart
Start
55
Subject Tracking Mode
Focusing on a Moving Subject in Subject Tracking Mode
3Press the shutter-release button to take the
picture.
•If the camera focuses on the focus area framed by the
double border when the shutter-release button is
pressed halfway, the double border turns green and
the focus is locked.
•If the camera is unable to focus, the double border will
blink. Press the shutter-release button halfway again to focus.
•If the shutter-release button is pressed halfway while the double border is not
displayed, the camera focuses on the subject at the center of the frame.
•Press the shutter-release button the rest of the way down to take the picture.
BSubject Tracking Mode
•Set the zoom position, flash mode, exposure compensation, and menu before registering a
subject. If any of these are changed after a subject is registered, the subject will be canceled.
•During certain conditions, such as when the subject is moving quickly, when there is a large
amount of camera shake, or when there are multiple subjects that look alike, the camera may not
be able to register or track a subject, or the camera may track a different subject. Additionally, the
subject may not be tracked properly depending on factors such as the subject's size and
brightness.
•In some rare cases shooting subjects with which autofocus may not perform as expected (A29),
the subject may not be in focus despite the fact that the double border glows green. Should this
occur, switch to auto mode and set AF area mode (A104) to Manual or Center, refocus on
another subject positioned at the same distance from the camera as the actual portrait subject,
and use focus lock (A105).
CUsable Functions in Subject Tracking Mode
•Digital zoom is not available.
•Flash mode (A32) and exposure compensation (A36) settings can be adjusted.
•Self-timer (A34) and macro mode (A35) cannot be used.
•Press the d button to display the s (subject tracking) menu and change the settings for
Image mode, Autofocus mode, or Face priority tracking (A56).
F2.7
F2.7
F2.7
1/250
1/250
1/250
56
Subject Tracking Mode
Focusing on a Moving Subject in Subject Tracking Mode
Subject Tracking Menu
The subject tracking menu contains the following options.
Press the d button in subject tracking mode to display the subject tracking
menu and use the rotary multi selector to modify and apply settings.
BNotes on Face Priority Tracking
•Only one subject can be tracked. If the camera detects multiple faces at the same time, the face
nearest the center of the frame is tracked.
•Depending on shooting conditions, such as whether or not the subject is facing the camera, faces
may not be detected properly. ➝ Notes on Face Priority (A107)
•When the subject you want to focus on cannot be tracked, press the k button to track again, or
set Face priority tracking to Off, frame the picture so that the subject is inside the single border
in the center of the frame, and press the k button to register the subject again.
Image mode
Allows you to set Image mode (A96).
Changes made to the image mode setting apply to all shooting modes (except
movie mode).
Autofocus mode
Allows you to set the Autofocus mode (A108) used for subject tracking mode
(the default setting is Full-time AF).
When using subject tracking mode while set to Full-time AF, the camera
continuously focuses once a subject is selected for subject tracking until the
shutter-release button is pressed halfway to lock the focus. The sound of the camera
focusing will be heard.
Changes made to the autofocus mode setting in this mode will not be applied to
the autofocus mode setting in the auto shooting mode. The autofocus mode
setting applied in subject tracking mode is stored in the camera’s memory even
after the camera is turned off.
Face priority tracking
When On is selected (default setting), if the camera detects a subject’s skin, that
subject is automatically registered as the subject to be tracked, and subject tracking
begins tracking that subject.
57
More on Playback/In-Camera Editing
More on Playback/In-Camera Editing
Viewing Multiple Pictures: Thumbnail Playback
Rotate the zoom control to f (h) in full-frame
playback mode (A30) to display pictures as
thumbnail images in thumbnail playback mode.
The following operations can be performed in
thumbnail playback.
To Use Description A
Choose pictures Rotate the rotary multi selector, or press H,
I, J or K to choose pictures. 10
Increase the number
of thumbnails
displayed/Calendar
display
f (h)
Rotate the zoom control towards the f (h)
direction to increase the number of
thumbnails from 4 ➝ 9 ➝16 ➝ Calendar
display.
In Calendar display, move and choose the
image according to the date (A59).
Rotate towards the g (i) direction to return to
thumbnail display. –
Decrease number of
picture thumbnails
displayed
g (i)
Rotate the zoom control towards the g (i)
direction to decrease the number of
thumbnails from 16 ➝ 9 ➝ 4.
Rotate towards g (i) again during 4
thumbnails display to return to full frame
playback.
Return to full-frame
playback kPress the k button. 30
Switch to shooting
mode
A
Press the A button or the shutter-release
button. 30
1/ 10
58
Viewing Multiple Pictures: Thumbnail Playback
More on Playback/In-Camera Editing
CIcons on the Thumbnails
When pictures that are marked for Print set
(A92) or Protect (A113) are selected in
thumbnail playback mode, the icons shown at
the right are displayed with them.
Movies are displayed as film frames.
CThumbnail Display in Auto Sort
When thumbnails are displayed in the auto sort mode (A64), the
icon representing the type of the pictures being played back will
appear at the top right corner of the screen.
1/ 10
Film frames
Print-set icon Protect icon
1/ 3
59
Viewing Multiple Pictures: Thumbnail Playback
More on Playback/In-Camera Editing
Calendar Display
Rotate the zoom control towards f (h) during
playback mode when 16 thumbnails are displayed
(A57) to change to Calendar display.
Move the cursor and choose the image according to the
date. Dates will be underlined in yellow if there are
pictures taken on that date.
The following operations can be performed while the Calendar is displayed.
BNotes on Calendar Display
•Images taken without the date set will be treated as images taken on “01.01.09”.
•l and d buttons are disabled while the Calendar is displayed.
DNote on List by Date Mode
Use list by date mode (A61) to playback images of the same date.
Playback menu (A63) operations can also be performed for the images of the chosen date.
To Use Description A
Select date Rotate the rotary multi selector, or press H,
I, J or K to select a date. 10
Return to full-frame
playback kChanges to the full-frame playback for the first
photo taken for the chosen date. 30
Return to thumbnail
display g (i) Rotate the zoom control to g (i). 57
3
60
More on Playback/In-Camera Editing
Taking a Closer Look: Playback Zoom
Rotating the zoom control to g (i) during full-frame
playback mode (A30) zooms in on the current
picture, enlarging and displaying the center of the
picture on the monitor.
•The guide at lower right shows which portion of the
picture is enlarged.
The following operations can be performed while pictures are zoomed in.
Pictures Taken Using the Face Priority Function
When zooming in (playback zoom) on a picture taken
using the face priority function (A106), the picture will
be enlarged with the face detected with shooting at the
center of the monitor (excluding pictures that were shot
using Continuous, BSS and Multi-shot 16 (A101)).
•If more than one face was detected, the picture will be
enlarged with the face on which focus was acquired at
the center of the monitor. Press the rotary multi selector H, I, J, or K to
display other faces that were detected.
•When rotating the zoom control towards the g (i) or f (h) direction to
adjust the zoom ratio, the center of the picture (normal playback zoom display),
rather than the face, is displayed at the center of the monitor.
To Use Description A
Zoom in g (i)Zoom increases each time the zoom control is
rotated to g (i), up to about 10×. –
Zoom out f (h)
Rotate the zoom control to f (h). When the
magnification ratio reaches 1×, the display
returns to full-frame playback mode.
–
Move the display
area
Press the rotary multi selector H, I, J or K to
move the display area to other areas of the
picture.
10
Return to full-frame
playback kPress the k button. 30
Crop picture dPress to crop the current picture to contain only
the portion visible in the monitor. 75
Switch to shooting
mode
A
Press the A button or the shutter-release
button. 30
61
More on Playback/In-Camera Editing
Viewing Pictures by Date (List by Date Mode)
In the C list by date mode, you can playback only the images taken on the same
date. In full-frame playback mode, just as with the normal playback mode, picture
displays can be enlarged, pictures can be edited, and movies can be played back.
By pressing the d button to display the “List by Date Menu” (A63), you can
delete all pictures with the same date, view a slide show of pictures with the same
date, and set print set or protect for all pictures with the same date.
Selecting a Date in List by Date Mode
1Display the playback-mode
selection menu by pressing the c
button in playback mode, use the
rotary multi selector to select C
and then press the k button.
•Dates for which pictures exist will be
listed.
2Select the desired date.
•Camera lists up to 29 dates. If pictures exist for more
than 29 dates, all pictures recorded earlier than most
recent 29 dates will be listed together as Others.
•When the k button is pressed, the first picture for that
date will be displayed in full-frame playback.
•Rotate the zoom control to f (h) in full-frame
playback mode to return to the list of shooting dates
screen.
BNotes on List by Date Mode
•Only the most recent 9,000 pictures can be displayed in list by date mode.
•Images taken without the date set will be treated as images taken on “01.01.09”.
•Histogram and shooting information (A10) cannot be displayed when using list by date mode.
List by date
20/11/2009 3
2
56
15/11/2009
List by date
Others
31
31
31
31
20/11/2009 15:30
20/11/2009 15:30
62
Viewing Pictures by Date (List by Date Mode)
More on Playback/In-Camera Editing
Using List by Date Mode
The following operations are possible from the list by date screen.
To Use Description A
Select date Rotate the rotary multi selector, or press H or I
to select a date. 10
Switch to full-frame
playback k
Press the k button to display the first picture
taken on the selected date.
Rotate the zoom control to f (h) in full-frame
playback to return to the list of shooting dates
screen.
31
Delete pictures l
Press the l button after selecting a date, and a
confirmation dialog will be displayed. Choose
Yes and press the k button to delete all pictures
taken on the selected date.
30
View list by date
menu dPress the d button to display the list by date
menu. 63
Change playback
mode cPress the c button to display the playback-
mode selection menu. 9
Switch to shooting
mode
A
Press the A button or the shutter-release
button. 30
63
Viewing Pictures by Date (List by Date Mode)
More on Playback/In-Camera Editing
List by Date Menu
Press the d button in list by date mode to operate the following menus to be
applied to only the pictures taken on the specified date.
Quick retouch* ➝A71
D-Lighting* ➝A72
Skin softening* ➝A73
Print set ➝A92
Slide show ➝A112
Delete ➝A113
Protect ➝A113
Rotate image* ➝A114
Small picture* ➝A74
Voice memo* ➝A67
* During full-frame playback only
When the d button is pressed in the list by date screen (A61), options can be
applied to all pictures taken on the same date, or all pictures taken on the same
date can be deleted.
To apply options to individual pictures, or to select individual pictures for deletion,
display a picture full-frame and press the d button.
64
More on Playback/In-Camera Editing
Image Searching (Auto Sort Mode)
Pictures and movies will automatically be sorted in any of the following folder
names after shooting them.
If the F auto sort mode is selected, you can display the pictures and movies by
selecting the folder name sorted in shooting.
In full-frame playback mode, just as with the normal playback mode, thumbnail
playback mode and calendar playback mode can be displayed, picture displays
can be enlarged, pictures can be edited, and movies can be played back.
By pressing the d button to display the “Auto Sort Menu” (A66), you can
delete all pictures in the same folder, view a slide show of pictures in the same
folder, and set print set or protect for all pictures in the same folder.
Displaying Pictures in the Auto Sort Mode
1Display the playback-mode
selection menu by pressing the c
button in playback mode, use the
rotary multi selector to select F,
and then press the k button.
•The auto sort folder list screen appears.
2Select the category.
•See “Types of Folders and their Content” (A65) for
more information about auto sort categories.
•Pictures in the selected folder will be displayed in full-
frame playback.
•The icon of the folder being played back currently will
be displayed in the top right of the screen.
aSmile YPortraits uFood
ULandscape VDusk to dawn DClose-ups
DMovie XRetouched copies WOther scenes
Auto sort
Portraits
41
1
1
1 4
15/11/2009 15:30
15/11/2009 15:30
65
Image Searching (Auto Sort Mode)
More on Playback/In-Camera Editing
Types of Folders and their Content
* The pictures taken using Scene auto selector (A38) are included.
BNotes when using the Auto Sort Mode
•Up to 999 images can be added per folder in the auto sort mode. A newly shot picture/movie
whose folder already contains 999 images cannot be registered nor displayed in the auto sort
mode. Display the picture/movie using the normal playback mode (A30) or the list by date
mode (A61).
•Pictures or movies copied from the internal memory or the memory card (A115) cannot be
displayed in the auto sort mode.
•Pictures or movies recorded by a camera other than the COOLPIX S640 cannot be displayed in the
auto sort mode.
Categories Description
aSmile Pictures taken in smart portrait mode (A51) while smile timer
was set to On.
YPortraits
Pictures taken in A (auto) mode (A24) using face priority
(A106).
Pictures taken in Portrait*, Night portrait*, Party/indoor, and
Backlight* scene modes (A37).
Pictures taken in smart portrait mode (A52) while smile timer
was set to Off.
ULandscape Pictures taken using the Landscape* scene mode (A37).
VDusk to dawn Pictures taken using the Night landscape*, Sunset, Dusk/
dawn, and Fireworks show scene modes (A37).
DClose-ups Pictures taken in A (auto) mode using macro (A35).
Pictures taken using the Close-up* scene mode (A37).
uFood Pictures taken using the Food (A47) scene mode (A37).
DMovie Movies recorded using the movie mode (A76).
XRetouched copies Edited pictures (A69).
WOther scenes All pictures that are not included in the other folders.
66
Image Searching (Auto Sort Mode)
More on Playback/In-Camera Editing
Auto Sort Mode
The following operations are possible from the auto sort folder list screen.
Auto Sort Menu
Operate the following menus by pressing the d button in the full-frame
playback of auto sort mode or in thumbnail display.
To Use Description A
Select the folder Rotate the rotary multi selector, or press
H,I,J or K to select the folder. 10
Switch to full-frame
playback kPress the k button to display the first picture
in the selected folder. 31
Deleting pictures l
Press the l button after selecting pictures
from the folder, and a confirmation dialog will
be displayed.
Choose Yes and press the k button to delete
all pictures from the folder.
30
Change playback
mode cPress the c button to display the playback-
mode selection menu. 9
Switch to shooting
mode
A
Press the A button or the shutter-release
button. 30
Quick retouch ➝A71 Delete ➝A113
D-Lighting ➝A72 Protect ➝A113
Skin softening ➝A73 Rotate image ➝A114
Print set ➝A92 Small picture ➝A74
Slide show ➝A112 Voice memo ➝A67
67
More on Playback/In-Camera Editing
Voice Memos: Recording and Playback
Use the camera’s built-in microphone to record voice memos for pictures.
Recording Voice Memos
1Choose the desired picture from full-frame
playback (A30) or thumbnail playback
(A57) and press the d button.
•The playback menu is displayed.
2Use the rotary multi selector to choose
EVoice memo and press the k button.
•The screen for recording a voice memo will be
displayed.
3Press and hold the k button to record voice
memo.
•Recording ends after 20 seconds or when the k
button is released.
•Do not touch the built-in microphone during
recording.
•During recording, o and p blink in the monitor.
•When recording ends, the voice memo playback
screen is displayed. Follow step 3 of “Playing Voice
Memos” (A68) to playback the voice memo.
•Press the d button before or after recording a voice
memo to return to full-frame playback.
DMore Information
See “File and Folder Names” (A139) for more information.
Playback menu
Protect
Rotate image
Small picture
Voice memo
Exit
Delete
17s
17s
20s
20s
20s
Back
68
Voice Memos: Recording and Playback
More on Playback/In-Camera Editing
Playing Voice Memos
Pictures for which voice memos have been recorded are indicated with p in full-
frame playback mode.
1Choose the desired picture from
full-frame playback (A30) or
thumbnail playback (A57) and
press the d button.
•The playback menu is displayed.
2Use the rotary multi selector to choose
EVoice memo and press the k button.
•The screen for playing a voice memo will be displayed.
3Press the k button to play voice memo.
•Playback ends when the voice memo ends or the k
button is pressed again.
•Use the zoom control g or f during playback to
adjust the volume.
•Press the d button before or after playing a voice
memo to return to full-frame playback.
Deleting Voice Memos
Choose a picture with a voice memo and press the l
button. Use the rotary multi selector to choose w and
press the k button. Only the voice memo will be
deleted.
BNotes on Voice Memos
•When a picture with a voice memo attached is deleted, both the picture and its voice memo are
deleted.
•Voice memos cannot be recorded for a picture that already has a voice memo attached on it. The
current voice memo must be deleted before a new voice memo can be recorded.
•Voice memos cannot be attached to images shot using cameras other than the COOLPIX S640.
44
44
15/11/2009 15:30
15/11/2009 15:30
Playback menu
Protect
Rotate image
Small picture
Voice memo
Exit
Delete
6s
6s
6s
Back
Back
Erase 1 image?
No
Yes
69
More on Playback/In-Camera Editing
Editing Pictures
Use the COOLPIX S640 to edit pictures in-camera and store them as separate files
(A139).
CNotes on In-camera Editing
•Pictures taken at an Image mode (A96) setting of P16:9 (3968) cannot be edited.
•The COOLPIX S640 cannot be used to edit images shot using cameras other than the COOLPIX
S640.
•If no faces can be detected in the image, the image cannot be edited with skin softening (A73).
•If a copy created using the COOLPIX S640 is viewed on a camera other than the COOLPIX S640, the
picture may not be displayed or may not be transferred to a computer.
•Editing functions are not available when there is not enough free space in the internal memory or
on the memory card.
CRestrictions on Picture Editing
The following limitations apply when editing pictures that were created by editing.
•Copies created by editing cannot be edited again using the same edit function.
•To use an editing function together with small picture or crop, use the other edit function first, and
use small picture or crop as the last edit function performed on that picture.
•Pictures that were taken using skin softening can be edited using skin softening.
Editing function Description
Quick retouch (A71) Easily create a copy with enhanced contrast and richer
colors.
D-Lighting (A72)
Create a copy of the current picture with enhanced
brightness and contrast, brightening dark portions of the
picture.
Skin softening (A73) Makes the subject’s skin appear smoother.
Small picture (A74) Create a small copy of pictures suitable for use on web
pages or as e-mail attachments.
Crop (A75)
Crop picture. Enlarge the image or refine the composition
and create a copy containing only the portion visible in
the monitor.
Copies Created By: Can Be Edited By:
Quick retouch
D-Lighting
Skin softening, small picture, or crop can be used.
Quick retouch and D-Lighting cannot be used together.
Skin softening Quick retouch, D-Lighting, small picture, or crop can be used.
Small picture
Crop No additional editing functions can be used.
70
Editing Pictures
More on Playback/In-Camera Editing
DOriginal Pictures and Edited Copies
•Copies created with editing functions are not deleted if the original pictures are deleted. The
original pictures are not deleted if copies created with editing functions are deleted.
•Edited copies are stored with the same recording date and time as the original.
•Even if the pictures that are marked for print set (A92) or protect (A113) are used for editing,
these settings will not be reflected on the edited copies.
71
Editing Pictures
More on Playback/In-Camera Editing
Enhancing Contrast and Saturation: Quick Retouch
Easily create retouched images in which contrast and saturation have been
enhanced. Retouched copies are stored as separate files.
1Choose the desired picture from full-frame
(A30) or thumbnail (A57) playback mode
and press the d button.
•The playback menu is displayed.
2Use the rotary multi selector to choose
kQuick retouch and press the k button.
•The original version will be shown on the left and the
edited version will be shown on the right.
3Choose the extent of the setting using H or
I of the rotary multi selector, and press the
k button.
•A retouched copy is created.
•To cancel, press the d button.
•Quick retouched copies can be recognized by the s
icon displayed during playback.
DMore Information
See “File and Folder Names” (A139) for more information.
Playback menu
Quick retouch
D-Lighting
Skin softening
Exit
Slide show
Print set
Quick retouch
Normal
Back
Amount
44
4
4
15/11/2009 15:30
15/11/2009 15:30
72
Editing Pictures
More on Playback/In-Camera Editing
Enhancing Brightness and Contrast: D-Lighting
D-Lighting can be used to create copies with enhanced brightness and contrast,
brightening dark portions of a picture. Enhanced copies are stored as separate
files.
1Choose the desired picture from full-frame
(A30) or thumbnail (A57) playback mode
and press the d button.
•The playback menu is displayed.
2Use the rotary multi selector to choose ID-
Lighting and press the k button.
•The original version will be shown on the left and the
edited version will be shown on the right.
3Choose OK and press the k button.
•A new copy with enhanced brightness and contrast is
created.
•To cancel, choose Cancel and press the k button.
•D-Lighting copies can be recognized by the c icon
displayed during playback.
DMore Information
See “File and Folder Names” (A139) for more information.
Playback menu
Quick retouch
D-Lighting
Exit
Slide show
Print set
Skin softening
D-Lighting
OK
Cancel
44
4
4
15/11/2009 15:30
15/11/2009 15:30
73
Editing Pictures
More on Playback/In-Camera Editing
Making Skin Appear Smoother: Skin Softening
Skin softening can be applied to faces that are detected in pictures already taken, to
make skin appear smoother. Pictures edited with this function are stored as separate files.
1Choose the desired picture from full-frame
(A30) or thumbnail (A57) playback mode
and press the d button.
•The playback menu is displayed.
2Use the rotary multi selector to choose e
Skin softening and press the k button.
•The screen that allows you to set the amount of skin
softening appears.
•If no faces can be detected in the image, a warning is
displayed and the screen returns to the playback menu.
3Press H or I to choose the amount of skin
softening to be applied, and press the k
button.
•A confirmation screen is displayed, and the image is
displayed zoomed in on the face edited by skin
softening.
4Confirm the results.
•Up to 12 faces, in order of proximity to the center of the
frame, can be enhanced.
•When multiple faces are edited using skin softening,
use the rotary multi selector J and K to switch the
face that is displayed.
•To adjust the amount of skin softening, press the d
button and return to step 3.
•Press the k button to create a copy edited with skin
softening.
•Copies created by editing with skin softening can be
recognized by the E icon displayed during playback.
CNotes on Skin Softening
Depending on conditions such as the direction the subject is facing or the brightness of the face, the
face may not be detected properly, or the desired effect may not be achieved.
Playback menu
Quick retouch
Slide show
Skin softening
D-Lighting
Print set
Exit
Skin softening
Normal
Back
Amount
Preview
Save
Save
Back
Back
15/11/2009 15:30
15/11/2009 15:30
44
44
74
Editing Pictures
More on Playback/In-Camera Editing
Resizing Pictures: Small Picture
Create a small copy of the current picture. Small copies are stored as separate files
with a compression ratio of 1:16. The following sizes are available.
1Choose the desired picture from full-frame
(A30) or thumbnail (A57) playback mode
and press the d button.
•The playback menu is displayed.
2Use the rotary multi selector to choose
gSmall picture and press the k button.
3Choose the desired copy size and press the k
button.
4Choose Yes and press the k button.
•A new, smaller copy is created.
•To cancel, choose No and press the k button.
•Images created using small picture are displayed with a
gray border.
DMore Information
See “File and Folder Names” (A139) for more information.
Option Description
l 640×480 Suitable for television playback.
m 320×240 Suitable for displaying on web pages.
n 160×120 Suitable for e-mail attachments.
Playback menu
Protect
Rotate image
Small picture
Voice memo
Exit
Delete
Small picture
Exit
320×240
160×120
640×480
No
Yes
Create small picture file?
75
Editing Pictures
More on Playback/In-Camera Editing
Creating a Cropped Copy: Crop
Create a copy containing only the portion visible in the monitor when
u
is displayed
with playback zoom (
A
60) enabled. Cropped copies are stored as separate files.
1Enlarge the desired picture during full-frame
display (A30) by rotating the zoom control to
the g (i) direction.
•To crop a picture displayed in “tall” (portrait) orientation,
zoom in on the picture until the black bars displayed on
the both sides of the monitor disappear. The cropped
picture will be displayed in landscape orientation. To
crop the picture in its current “tall” (portrait) orientation,
first, use the Rotate image option (A114) to rotate the picture so that it is
displayed in landscape orientation. Next, enlarge the picture for cropping, crop the
picture, and then rotate the cropped picture back to “tall” (portrait) orientation.
2Refine copy composition.
•Rotate the zoom control to g (i) or f (h) to adjust
the zoom ratio.
•Press the rotary multi selector H, I, J or K to move
the display area to other areas of the picture.
3Press the d button.
4Use the rotary multi selector to choose Yes
and press the k button.
•A new picture, containing only the portion visible in
the monitor, is created.
•To cancel, choose No and press the k button.
CImage Size
As the area to be saved is reduced, the image size (pixels) of the cropped copy is also reduced.
When the size of the cropped copy is 320 × 240 or 160 × 120, the copy is displayed with a gray
border during playback, and the small picture icon B or C is displayed on the left of the screen in
full-frame playback mode.
DMore Information
See “File and Folder Names” (A139) for more information.
Save this image as
displayed?
No
Yes
76
Movies
Movies
Recording Movies
To shoot movies with sound recorded via the built-in microphone, select shooting
mode and follow the steps below.
1Display the shooting-mode
selection menu by pressing the A
button in shooting mode, use the
rotary multi selector to select D,
and then press the k button.
•The amount of available recording time is
shown in the monitor (A77). Regardless
of the remaining memory on the memory card, the maximum size of a single movie is
2 GB, and the maximum length of a single movie is 25 minutes.
2Press the shutter-release button all
the way down to start recording.
•Camera focuses on the subject in center
of the frame.
•A progress bar at the bottom of the
monitor shows the amount of recording
time remaining.
•To end recording, press the shutter-release button all the way down again.
•Recording stops automatically when the available recording time runs out.
BShooting Movies
•Macro mode (A35) is enabled. Flash (A32), self-timer (A34), and exposure compensation
(A36) are disabled.
•Macro mode settings cannot be applied or changed while movies are being recorded. Apply or
change settings as necessary before movie recording begins.
•Optical zoom cannot be adjusted once movie recording begins. Digital zoom cannot be applied
before movie recording begins, but up to 2× digital zoom can be applied while movies are being
recorded.
BNote on Recording Movies
When the movie has been fully recorded to the internal memory or memory card, the monitor
display will revert to the normal shooting mode display. Do not open the battery-chamber/
memory card slot cover while movies are being recorded. Turning the camera off or removing
the memory card while movies are being recorded could result in loss of data or in damage to the
camera or card.
CChanging Movie Settings
Movie options and Autofocus mode settings can be changed in the movie menu (A77).
Movie
23s
23s
23s
77
Movies
The Movie Menu
Movie options
and
Autofocus mode
(
A
77) settings can be changed in the movie menu.
Press the d button in movie mode to display the movie menu and use the
rotary multi selector to modify and apply settings.
DSelecting Movie Options
The movie menu offers the options shown below.
CMaximum Movie Length
* All figures are approximate. The maximum recording time may vary with make of memory card.
Regardless of the remaining memory on the memory card, the maximum size of a single movie is
2 GB, and the maximum length of a single movie is 25 minutes. The amount of available recording
time is shown in the monitor while recording.
DMore Information
See “File and Folder Names” (A139) for more information.
IAutofocus Mode
Choose how the camera focuses in movie mode.
Set to D (Movie) M d (Movie menu) M DMovie options
Option Image size and frame rate
I TV movie 640 (default setting) Image size: 640 × 480 pixels
Frame rate: 30 frames per second
S Small size 320 Image size: 320 × 240 pixels
Frame rate: 30 frames per second
Option Internal memory
(approx. 45 MB) Memory card (512 MB)
I TV movie 640 (default setting) 32 s Approx. 5 min 30 s
S Small size 320 1 min 22 s Approx. 14 min 20 s
Set to D (Movie) M d (Movie menu) M IAutofocus mode
Option Description
ASingle AF
(default setting) Focus is locked when the shutter-release button is pressed.
BFull-time AF
Camera focuses continuously.
To prevent sound of camera focusing from interfering with
recording, use of Single AF is recommended.
78
Movies
Movie Playback
In full-frame playback mode (A30), movies are
recognized by the movie options (A77) icons. To play
a movie, display it in full-frame playback mode and
press the k button.
Use the zoom control g or f during playback to
adjust the volume.
Rotating the rotary multi selector enables fast-
forwarding/rewinding.
Playback controls appear at the top of the monitor.
Press the rotary multi selector J or K to choose a
control, then press the k button to perform the
selected operation. The following operations are
available.
* The rotary multi selector can also be rotated to advance or rewind the movie frame by frame.
Deleting Movie Files
Press the l button when displayed in full-frame
playback mode (A30) or when selected in thumbnail
(A57) playback mode.
A confirmation dialog is displayed. Select Yes and press
the k button to delete the movie, or select No to exit
without deleting the movie.
To Select Description
Rewind KRewind the movie when the k button is pressed down.
Advance LAdvance the movie when the k button is pressed down.
Pause O
Press the k button to pause playback.
The following operations can be performed while playback is
paused.
MPress the k button to rewind the movie by one frame.
Rewind continues while the button is pressed. *
NPress the k button to advance the movie by one frame.
Advance continues while the button is pressed. *
PPress the k button to resume playback.
End QPress the k button to return to full-frame playback mode.
0010. AVI
VIA0010.
15/11/2009 15:30
15/11/2009 15:30
10s
10s
4s
4s
4s
During
playback
Volume
indicator
Pausing
No
Yes
Erase 1 image?
79
Connecting to Televisions, Computers and Printers
Connecting to Televisions, Computers and Printers
Connecting to a TV
Connect the camera to a television using the supplied audio/video cable to play
back pictures on the television.
1Turn off the camera.
2Connect the camera to the TV using the supplied audio/video cable.
•Connect the yellow plug to the video-in jack on the TV, and the white plug to the
audio-in jack.
3Tune the television to the video channel.
•See the documentation provided with your television for details.
4Hold down the c button to turn on the
camera.
•The camera enters playback mode, and pictures
recorded to the internal memory, or memory card, will
be displayed on the television.
•While connected to the TV, the camera monitor will
remain off.
BConnecting the Audio/Video Cable
When connecting the audio/video cable, be sure that the connectors are oriented correctly. Do not
use force when connecting the audio/video cable. When disconnecting the audio/video cable, do
not pull the connector at an angle.
BWhen Nothing Appears on the TV
Be sure that the camera’s video mode setting in the Setup menu (A116) ➝ Video mode
(A130) conforms to the standard used by your television.
WhiteYellow
80
Connecting to Televisions, Computers and Printers
Connecting to a Computer
Use the supplied USB cable to connect the camera to a computer, and copy
(transfer) pictures to a computer with the supplied Nikon Transfer software.
Before Connecting the Camera
Install the Software
Before connecting the camera to a computer, software, including Nikon Transfer,
ViewNX for viewing transferred pictures, and Panorama Maker for creating
panorama images, must be installed from the supplied Software Suite CD.
For more information on installing the software, refer to the Quick Start Guide.
Compatible Operating Systems
Windows
Preinstalled versions of Windows Vista Service Pack 1 (32-bit Home Basic/Home
Premium/Business/Enterprise/Ultimate editions),
Windows XP Service Pack 3 (Home Edition/Professional)
Macintosh
Mac OS X (version 10.3.9, 10.4.11, 10.5.6)
Refer to the Nikon website for the latest information on operating system
compatibility.
BNote on Computer Connection
Disconnect other USB devices such as commercial USB chargers from the computer. Simultaneous
connection of the camera and other USB devices to the computer could result in operation
malfunction or excessive supply of power to the camera, causing damage to the camera or memory
card. Refer to the documentation supplied with other USB devices for more information.
BNotes on Power Source
•When connecting the camera to a computer to transfer pictures, use a fully charged battery to
prevent the camera from turning off unexpectedly.
•When the camera is connected to a computer via the supplied USB cable with Auto (default
setting) selected for the Charge by computer option (A84, 131) in the setup menu, the battery
inserted into the camera is automatically charged using power supplied by the computer. Pictures
can be transferred while the battery is charging.
•If the AC Adapter EH-62F is used, power can be supplied to the COOLPIX S640 from an electrical
outlet. Do not, under any circumstances, use another make or model of AC adapter other than EH-
62F. Failure to observe this precaution could result in overheating or in damage to the camera.
81
Connecting to a Computer
Connecting to Televisions, Computers and Printers
Transferring Pictures from the Camera to a Computer
1Start the computer to which Nikon Transfer was installed.
2Be sure that the camera is off.
3Connect the camera to the computer using the supplied USB cable.
4The camera automatically turns on.
The power-on lamp will light. The camera monitor will
remain off.
Windows Vista
When the AutoPlay dialog is displayed, click Copy
pictures to a folder on my computer using Nikon Transfer. Nikon Transfer will start.
To bypass this dialog in the future, check Always do this for this device.
Windows XP
When the action selection dialog is displayed, select Nikon Transfer Copy pictures to
a folder on my computer and click OK. Nikon Transfer will start.
To bypass this dialog in the future, check Always use this program for this action.
Mac OS X
Nikon Transfer will start automatically if Yes was selected in the Auto-Launch setting
dialog when Nikon Transfer was first installed.
BConnecting the USB Cable
•Be sure that connectors are properly oriented. Do not attempt to insert connectors at an angle,
and do not use force when connecting or disconnecting the USB cable.
•The connection may not be recognized if the camera is connected to the computer via a USB hub.
82
Connecting to a Computer
Connecting to Televisions, Computers and Printers
5Confirm that the source device is displayed in the transfer options
Source panel and click Start Transfer.
At the Nikon Transfer default settings, all pictures are transferred to the computer.
At the Nikon Transfer default settings, ViewNX starts automatically when transfer is
complete and transferred pictures can be viewed.
For more information on using Nikon Transfer or ViewNX, refer to help information
contained in Nikon Transfer or ViewNX (A83).
Disconnecting the camera
Do not turn off the camera or disconnect the camera from the computer during transfer.
When transfer is complete, turn off the camera and disconnect the USB cable.
The camera turns off automatically if there is no communication with the
computer for 30 minutes while the camera is connected via the USB cable.
CCharging the Battery
When the camera’s charge lamp is blinking slowly in green, the battery inserted in the camera is
charging (A84).
Start Transfer buttonSource device
83
Connecting to a Computer
Connecting to Televisions, Computers and Printers
CUsing a Card Reader
The pictures stored on the memory card inserted into a card reader or similar device can also be
transferred to the computer using Nikon Transfer.
•If the memory card has a capacity greater than 2 GB, or is SDHC-compliant, the intended device
must support these features of the memory card.
•Insert a memory card into the card reader or similar device, and refer to the steps 4 and 5 to
transfer pictures.
•To transfer pictures stored in the camera’s internal memory to the computer, the pictures must
first be copied to a memory card using the camera (A115).
DStarting Nikon Transfer or ViewNX Manually
Windows
Choose Start menu>All Programs>Nikon Transfer>Nikon Transfer (or All
Programs>ViewNX>ViewNX).
Double-clicking the Nikon Transfer or ViewNX shortcut icon on the desktop will also start Nikon
Transfer or ViewNX.
Macintosh
Open Applications and click Nikon Software>Nikon Transfer>Nikon Transfer (or Nikon
Software>ViewNX>ViewNX).
Clicking the Nikon Transfer or ViewNX icon on the Dock will also start Nikon Transfer or ViewNX.
DViewing Nikon Transfer and
ViewNX Help Information
For more information on Nikon Transfer or
ViewNX, start Nikon Transfer or ViewNX and
select Nikon Transfer Help or ViewNX Help
from the Help menu.
DPanorama Creation with Panorama Maker
•Use a series of pictures taken in Panorama assist scene mode (A49) to create a single
panorama photo with Panorama Maker.
•Panorama Maker can be installed on a computer using the supplied Software Suite CD.
•After installation is complete, follow the procedure described below to start Panorama Maker.
Windows
Choose Start menu>All Programs>ArcSoft Panorama Maker 4>Panorama Maker 4.
Macintosh
Open Applications and double-click the Panorama Maker 4 icon.
•For more information on using Panorama Maker, refer to the on-screen instructions and help
information contained in Panorama Maker.
DImage File Names and Folder Names
See “File and Folder Names” (A139) for more information.
84
Connecting to a Computer
Connecting to Televisions, Computers and Printers
Charging While Connecting to a Computer
When connecting the camera to a computer via the supplied USB cable while
Auto (default setting) is selected for the Charge by computer option (A131) in
the setup menu, the battery inserted into the camera is automatically charged
using power supplied by the computer.
See “Before Connecting the Camera” (
A
80) and “Transferring Pictures from the Camera
to a Computer” (
A
81) for more information on connecting the camera to a computer.
Charge Lamp
The following chart explains charge lamp status when the camera is connected to a computer.
BNotes on Charging with Connection to a Computer
•The battery cannot be charged, nor can data be transferred, when the camera is connected to a
computer before the camera’s date and time have been set (A20). If the camera’s clock battery
(A121) has been exhausted, the date and time must be reset before the battery can be charged
or images can be transferred with connection to a computer. In this case, use the Charging AC
Adapter EH-68P (A16) to charge the battery and then set the camera’s date and time.
•If the camera is turned off, charging will also stop.
•If a computer enters sleep mode while charging, charging will stop and the camera may be turned off.
•When disconnecting the camera from a computer, turn the camera off and then disconnect the
USB cable.
•It may take longer to charge the battery with connection to a computer than with charging using
the Charging AC Adapter. Charging time increases when images are transferred while the battery
is charging.
•When the camera is connected to a computer, an application installed on the computer, such as
Nikon Transfer, may start. If the camera was connected to the computer for the sole purpose of
charging the battery, exit the application.
•The camera turns off automatically if there is no communication with the computer for 30 minutes
after the battery has finished charging.
•Depending upon computer specifications, settings, and power supply and allocation, it may be
impossible to charge the battery inserted into the camera via computer connection.
Charge lamp Description
Slow blinking (green) Battery charging.
Off Not charging.
If the charge lamp changes from slow blinking (green) to off
while the power-on lamp is lit, charging is complete.
Fast blinking (green) •Operating temperature range exceeded. Charge the battery
indoors with an ambient temperature of 5°C to 35°C (41°F to
95°F) before use.
•A USB cable is not correctly connected or the battery is faulty.
Reconnect the USB cable correctly or replace the battery.
•Computer is in sleep mode and does not supply power.
Reboot a computer.
•The battery cannot be charged as computer’s specifications or
settings does not support power supply to the camera.
85
Connecting to Televisions, Computers and Printers
Connecting to a Printer
Users of PictBridge-compatible (A157) printers can connect the camera directly
to the printer and print pictures without using a computer. The steps for printing
are as follows.
BNotes on Power Source
•When connecting the camera to a printer, use a fully charged battery to prevent the power from
turning off unexpectedly.
•Use the optional AC Adapter EH-62F to charge the COOLPIX S640 using home electronic outlets.
Do not, under any circumstances, use another make or model of AC adapter. Failure to observe
this precaution could result in overheating or in damage to the camera.
DPrinting Pictures
In addition to printing pictures transferred to a computer and printing over a direct camera-to-
printer connection for images recorded in the memory card, the following options are also available
for printing pictures:
•Insert a memory card into a DPOF-compatible printer’s card slot.
•Take a memory card to a digital photo lab.
For printing using these methods, specify the pictures and the number of prints each using the
Print set (A92) option in the playback menu.
Take the pictures
Connect to printer (A86)
Print Pictures One at a Time
(A88) Print multiple pictures (A89)
Turn camera off and disconnect USB cable
Choose the pictures for
printing using the print set
option (Print set: A92)
86
Connecting to a Printer
Connecting to Televisions, Computers and Printers
Connecting the Camera to a Printer
1Turn off the camera.
2Turn on the printer.
•Check printer settings.
3Connect the camera to the printer using the supplied USB cable.
4The camera automatically turns on.
•When connected correctly, the PictBridge startup
screen (1) will be displayed in the camera monitor.
Then the Print selection screen (2) will be displayed.
15/11
2009
NO. 32
[
32
]
Print selection
12
87
Connecting to a Printer
Connecting to Televisions, Computers and Printers
BIf the PictBridge Screen is not Displayed
Turn off the camera and disconnect the USB cable. Set Charge by computer (A131) in the
camera’s setup menu to Off, then connect the camera again.
BConnecting the USB Cable
Be sure that connectors are properly oriented. Do not attempt to insert connectors at an angle, and
do not use force when connecting or disconnecting the USB cable.
88
Connecting to a Printer
Connecting to Televisions, Computers and Printers
Printing Pictures One at a Time
After connecting the camera to the printer correctly (A86), print pictures by
following the procedure below.
1Use the rotary multi selector to choose the
picture to be printed and press the k button.
•Rotate the zoom control to f (h) to display 12
thumbnails, or to g (i) to switch back to full-frame
playback.
2Choose Copies and press the k button.
3Choose the number of copies (up to nine) and
press the k button.
4Choose Paper size and press the k button.
5Choose the desired paper size and press the
k button.
•To specify paper size using printer settings, choose
Default in the paper size menu.
15/11
2009
NO. 32
Print selection
[
32
]
PictBridge
Start print
Copies
Paper size
Exit
4
Copies
Exit
PictBridge
Start print
Copies
Paper size
Exit
Paper size
8×10 in.
Letter
A4
4×6 in.
A3
Exit
89
Connecting to a Printer
Connecting to Televisions, Computers and Printers
6Choose Start print and press the k button.
7Printing starts.
•Monitor display returns to that shown in step 1 when
printing is complete.
•To cancel before all copies have been printed, press
the k button.
Printing Multiple Pictures
After connecting the camera to the printer correctly (A86), print pictures by
following the procedure below.
1When the Print selection screen is displayed,
press the d button.
•The Print menu is displayed.
2Use the rotary multi selector to choose Paper
size and press the k button.
•To exit the print menu, press the d button.
PictBridge
Start print
Copies
Paper size
Exit
002/004
Cancel
Printing
Current print/
total number of prints
Print menu
Print selection
Print all images
DPOF printing
Paper size
Exit
90
Connecting to a Printer
Connecting to Televisions, Computers and Printers
3Choose the desired paper size and press the
k button.
•To specify paper size using printer settings, choose
Default in the paper size menu.
4Choose Print selection, Print all images or
DPOF printing and press the k button.
Print selection
Choose the pictures (up to a maximum of 99)
and number of copies (up to nine per picture).
•Rotate the rotary multi selector, or press J or
K to choose the pictures, and press H or I to
set the number of copies for each.
•Pictures selected for printing can be
recognized by the check mark icon and the
numeral indicating the number of copies to be
printed. A check mark is not displayed with
pictures for which no copies have been specified and these pictures will not
be printed.
•Rotate the zoom control to g (i) to switch to full-frame playback, or f (h)
to switch to 12 thumbnails display.
•Press the k button when setting is complete.
•The menu shown at right will be displayed. To
print, choose Start print and press the k
button. Choose Cancel and press the k
button to return to the print menu.
Paper size
Default
Exit
3.5×5 in.
5×7 in.
4×6 in.
100×150 mm
Print menu
Print selection
Print all images
Paper size
Exit
DPOF printing
Print selection
Back
10
3
3
11
11
Print selection
010 prints
Start print
Cancel
Exit
91
Connecting to a Printer
Connecting to Televisions, Computers and Printers
5Printing starts.
•Monitor display returns to that shown in step 2 when
printing is complete.
•To cancel before all copies have been printed, press
the k button.
CPaper Size
The camera supports the following paper sizes: Default (the default paper size for the current
printer), 3.5×5 in., 5×7 in., 100×150 mm, 4×6 in., 8×10 in., Letter, A3, and A4. Only sizes
supported by the current printer will be displayed.
Print all images
All pictures stored in the internal memory, or on
the memory card, are printed one at a time.
•The menu shown at right will be displayed. To
print, choose Start print and press the k
button.
•Choose Cancel and press the k button to
return to the print menu.
DPOF printing
Print the pictures in the print order that was
created using Print set (A92).
•The menu shown at right will be displayed. To
print, choose Start print and press the k
button.
•Choose Cancel and press the k button to
return to the print menu.
•To view the current print order, choose View
images and press the k button. To print
pictures, press the k button again.
Print all images
prints018
Start print
Cancel
Exit
010 prints
Start print
View images
Cancel
Exit
DPOF printing
View images
Back
10
002/010
Printing
Cancel
Current print/
total number of prints
92
Connecting to Televisions, Computers and Printers
Creating a DPOF Print Order: Print Set
The Print set option in the playback menu is used to create digital “print orders” for
printing on DPOF-compatible printers or in print shops (A157).
When the camera is connected to a PictBridge-compatible printer, pictures can be
printed from the printer according to the DPOF print order you have created for
pictures on the memory card. If the memory card is removed from the camera, you
can create the DPOF print order for pictures in the internal memory and print
pictures according to the DPOF print order.
1Press the d button in playback mode.
•The playback menu is displayed.
2Use the rotary multi selector to choose Print
set and press the k button.
When viewing pictures by List by date or Auto sort mode
➝ step 4
3Choose Select images and press the k
button.
4Choose the pictures (up to a maximum of 99)
and number of copies (up to nine per picture).
•Rotate the rotary multi selector, or press J or K to
choose the pictures, and press H or I to set the
number of copies for each.
•Pictures selected for printing can be recognized by the
check mark icon and the numeral indicating the
number of copies to be printed. A check mark is not displayed with pictures for which
no copies have been specified and these pictures will not be printed.
•Rotate the zoom control to g (i) to switch to full-frame playback, or f (h) to
switch to 12 thumbnails display.
•Press the k button when setting is complete.
Playback menu
Quick retouch
Slide show
Skin softening
D-Lighting
Print set
Exit
Print set
Select images
Delete print set
Exit
Print selection
Back
3
3
11
11
93
Creating a DPOF Print Order: Print Set
Connecting to Televisions, Computers and Printers
5Choose whether or not to also print shooting
date and photo information.
•Choose Date and press the k button to print the date
of recording on all pictures in the print order.
•Choose Info and press the k button to print shooting
information (shutter speed and aperture) on all
pictures in the print order.
•Choose Done and press the k button to complete the print order.
Pictures selected for printing are recognized by the w
icon displayed with playback.
CDeleting All Print Orders
Choose Delete print set in step 3 and press the k button. Print orders for all pictures will be
deleted.
BNotes on the Print Set Option
When using Print set while viewing pictures by List by date or Auto
sort mode, if pictures other than the selected date or type are
already set for printing, the screen shown at right will be displayed.
•If Yes is selected, the current settings are added to the previous
settings.
•If No is selected, the previous settings are deleted and only the
current settings remain.
Print set
Done
Date
Info
Exit
4
44
4
4
15/11/2009 15:30
15/11/2009 15:30
Print set
No
Save print marking for other
dates?
Yes
Exit
Print set
No
Save print marking for other
images?
Yes
Exit
When using List by date
When using Auto sort
mode
94
Creating a DPOF Print Order: Print Set
Connecting to Televisions, Computers and Printers
If more than 99 pictures are selected as a result of adding the
current settings, the screen shown at right will be displayed.
•If Yes is selected, the previous settings are deleted and only the
current settings remain.
•If Cancel is selected, the current settings are deleted and only
the previous settings remain.
BNotes on Printing Shooting Date and Photo Information
When the Date and Info options are enabled in the Print set menu, shooting date and photo
information are printed on pictures when a DPOF-compatible (A157) printer which supports
printing of shooting date and photo information is used.
•Photo information cannot be printed when the camera is connected directly to a printer, via the
supplied USB cable, for DPOF printing (A91).
•Date and Info are reset each time the Print set menu is displayed.
•The date and time printed on the picture is the date and time
recorded on the camera when the picture was taken. The date
and time printed using this option will not be affected even if the
camera’s Date setting is changed from the setup menu after the
pictures are taken.
DDate Imprint
The shooting date and time can be imprinted in pictures at the time of shooting by using Date
imprint (A124) in the setup menu. This information can be printed even from printers that do not
support printing of date and time.
Only the date and time of date imprint on the pictures will be printed, even if Print set is enabled
with the date selected in the print set screen.
Print set
Cancel
Too many images selected.
Remove print marking for
other dates?
Yes
Exit
Print set
Cancel
Too many images selected.
Remove print marking from
other images?
Yes
Exit
When using List by date
When using Auto sort
mode
15.11.2009
15.11.2009
95
Shooting, Playback and Setup Menus
Shooting, Playback and Setup Menus
Shooting Options: The Shooting Menu
While shooting in A (auto) mode (A24), the shooting menu contains the
following options.
Displaying the Shooting Menu
Set the camera to A (auto) mode (A24).
Press the d button to display the shooting menu.
•Use the rotary multi selector to choose and apply settings (A10).
•Press the d button to exit the shooting menu.
BFunctions that Cannot be Applied Simultaneously
Some functions cannot be enabled in conjunction with others (A109).
AImage mode A96
Choose the image mode (a combination of the image size and image quality
(compression)) to be used when recording.
Also available when using other shooting modes (except movie mode).
BWhite balance A98
Match white balance to the light source.
GMetering A100
Choose how the camera meters exposure.
CContinuous A101
Change settings for Continuous and BSS (Best Shot Selector).
EISO sensitivity A102
Control the camera’s sensitivity to light.
FColor options A103
Apply color effects to pictures as they are recorded.
GAF area mode A104
Choose how the focus area is determined.
IAutofocus mode A108
Choose how the camera focuses.
13
13
13
Shooting menu
Image mode
White balance
Metering
Continuous
ISO sensitivity
Exit
96
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
AImage Mode
Choose an image mode, which is the combination of image size and image quality
(compression), according to how you plan to use the picture and the capacity of
the internal memory or memory card.
The larger the image, the larger the size at which it can be printed or displayed
without becoming noticeably “grainy”, limiting the number of pictures that can be
recorded.
The icon for the current setting is displayed in the monitor in shooting and
playback modes (A6, 7).
CImage Mode
•Changes made to the image mode setting apply to all shooting modes (except those available
from the movie mode).
•This feature cannot be used simultaneously with certain features. ➝ “Functions that Cannot be
Applied Simultaneously” (A109)
Set to A (Auto) M d (Shooting menu) M AImage mode
Image mode Image size
(pixels) Description
HHigh (4000P)4,000×3,000
Highest quality, suitable for enlargements
or high-quality prints. The compression
ratio is approximately 1:4.
INormal (4000)
(default setting) 4,000×3,000
The best choice in most situations. The
compression ratio is approximately 1:8.RNormal (3264) 3,264×2,448
LNormal (2592) 2,592×1,944
MNormal (2048) 2,048×1,536
Smaller size allows more pictures to be
stored. The compression ratio is
approximately 1:8.
NPC screen (1024) 1,024×768 Suited to display on computer monitor. The
compression ratio is approximately 1:8.
OTV screen (640) 640×480
Suited to full-screen display on a television
or distribution by e-mail or the web. The
compression ratio is approximately 1:8.
P16:9 (3968) 3,968×2,232
Pictures with an aspect ratio of 16:9 can be
taken. The compression ratio is
approximately 1:8.
97
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
CNumber of Exposures Remaining
The following table lists the approximate number of pictures that can be stored in internal memory
and on a 512 MB memory card. Note that the number of images that can be stored will differ
depending on the composition of the image (due to JPEG compression). In addition, this number
may differ depending on the make of memory card, even if the capacity for the memory card is the
same.
1 If the number of exposures remaining is 10,000 or more, the number of exposures remaining
display shows “9999”.
2 Print size at an output resolution of 300 dpi.
Print sizes are calculated by dividing the number of pixels by printer resolution (dpi) and
multiplying by 2.54 cm (1 in.). However, even with the same image size setting, images printed at
higher resolutions will print smaller than the size indicated, and those printed at lower resolutions
will print larger than the size indicated.
Setting
Internal
memory
(approx. 45 MB)
Memory card1
(512 MB)
Print size2
(cm/in.)
HHigh (4000 P)7 Approx. 80 34 × 25/13 × 10
INormal (4000) 13 Approx. 150 34 × 25/13 × 10
RNormal (3264) 19 Approx. 220 28 × 21/11 × 8
LNormal (2592) 31 Approx. 340 22 × 16/8.5 × 6.5
MNormal (2048) 49 Approx. 550 17 × 13/7 × 5
NPC screen (1024) 159 Approx. 1,700 9 × 7/3.5 × 2.5
OTV screen (640) 319 Approx. 3,400 5 × 4/2 × 1.5
P16:9 (3968) 18 Approx. 200 34 × 19/13 × 7.5
98
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
BWhite Balance
The human brain is able to adapt to changes in the color of the light source, with
the result that white objects appear white whether seen in the shade, direct
sunlight, or under incandescent lighting. Digital cameras can mimic this
adjustment of the human eye by processing images according to the color of the
light source. This is known as “white balance”. For natural coloration, choose a
white balance setting that matches the light source before shooting.
Although the default setting, Auto, can be used under most types of lighting, you
can apply the white balance setting suited to a particular light source to achieve
more accurate results.
The effects of the selected option can be previewed in the monitor. At settings
other than Auto, the icon for the current setting is displayed in the monitor (A6).
BWhite Balance
This feature cannot be used simultaneously with certain features. ➝ “Functions that Cannot be
Applied Simultaneously” (A109)
BFlash Mode
At white balance settings other than Auto or Flash, turn the flash off (W) (A32).
Set to A (Auto) M d (Shooting menu) M BWhite balance
aAuto (default setting)
White balance automatically adjusted to suit lighting conditions. Best choice in
most situations. Can be used in most situations.
bPreset manual
Neutral-colored object used as reference to set white balance under unusual
lighting conditions, see “Preset Manual” (A99) for details.
cDaylight
White balance adjusted for direct sunlight.
dIncandescent
Use under incandescent lighting.
eFluorescent
Use under most types of fluorescent lighting.
fCloudy
Use when shooting under overcast skies.
gFlash
Use with the flash.
99
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
Preset Manual
Preset manual is used with mixed lighting or to compensate for light sources with
a strong color cast when the desired effect has not been achieved with white
balance settings like Auto and Incandescent (for example, to make images shot
under a lamp with a red shade look as though they had been shot under white
light).
1Place a white or gray reference object under the lighting that will be
used during shooting.
2Display the shooting menu (A95), use the
rotary multi selector to set White balance to
b Preset manual, then press the k button.
•The camera zooms in.
3Choose Measure.
•To use the most recently measured value for preset
manual, choose Cancel and press the k button. The
most recently measured value will be set for White
Balance.
4Frame the reference object.
5Press the k button to measure the white balance value.
The shutter is released and the new white balance value is set (no picture is recorded).
CNote on Preset Manual
The camera cannot measure a white balance value for when the flash fires. When shooting with the
flash, set White balance to Auto or Flash.
White balance
Auto
Auto
Preset manual
Daylight
Daylight
Incandescent
Incandescent
Fluorescent
Fluorescent
Exit
Preset manual
Cancel
Measure
Exit
Preset manual
Cancel
Measure
Exit
Reference object frame
100
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
GMetering
The process of measuring the brightness of the subject to determine the exposure
is known as Metering.
Choose how the camera meters exposure.
BNote on Metering
When using digital zoom, Metering is set to Center-weighted, and the metered area is not
displayed in the monitor.
DMetering Area
The active metering area is displayed in the monitor when Center-weighted is selected for
Metering.
Set to A (Auto) M d (Shooting menu) M GMetering
GMatrix (default setting)
Camera sets exposure for entire frame. Recommended in most situations.
qCenter-weighted
Camera meters entire frame but assigns greatest weight to subject in center of
frame. Classic meter for portraits; preserves background details while letting lighting
conditions at center of frame determine exposure. Can be used with focus lock
(A105) to meter off-center subjects.
13
13
13
Active metering area
101
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
CContinuous
Change settings for Continuous and BSS (Best Shot Selector).
Flash will be switched off when Continuous, BSS, or Multi-shot 16 is selected.
Focus, exposure, and white balance are fixed at the values for the first image in
each series.
At settings other than Single, the indicator for the current setting is displayed in
the monitor (A6).
BNote on Continuous Shooting
•The maximum frame rate with continuous shooting may vary, depending upon the current image
mode and the type of memory card used.
•This feature cannot be used simultaneously with certain features. ➝ “Functions that Cannot be
Applied Simultaneously” (A109)
BNote on Best Shot Selector
BSS is best suited for shooting stationary subjects. It may not produce the desired results if the
subject moves or the composition changes while the shutter-release button is pressed all the way
down.
Set to A (Auto) M d (Shooting menu) M CContinuous
USingle (default setting)
One image is shot each time the shutter-release button is pressed.
VContinuous
While the shutter-release button is held down, the camera shoots up to 10 pictures
at a rate of up to about 0.8 frames per second (fps) (when image mode is set to
INormal (4000)). Shooting ends when the shutter-release button is released, or
ten shots have been taken with the shutter-release button held down.
jBSS (Best shot selector)
BSS is recommended for shooting under low lighting without the flash, with the
camera zoomed in, or in other situations in which camera shake is likely to blur pictures.
The camera takes up to ten images while the shutter-release button is held down.
The sharpest image (image with the most detail) in the series is automatically
selected and saved.
WMulti-shot 16
Each time the shutter-release button is pressed all the way
down, 16 pictures are shot at about 30 fps and the camera
arranges them in a single picture.
•Images are captured with the image mode locked at L2592.
•Digital zoom is not available.
102
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
BNote on Multi-shot 16
Smear (A143) visible in the monitor when shooting with Multi-shot 16 enabled will be recorded
with images. Avoiding bright objects such as the sun, reflections of the sun, and electric lights when
shooting with Multi-shot 16 enabled is recommended.
EISO Sensitivity
Sensitivity is a measure of how quickly the camera reacts to light. The higher the
sensitivity, the less light needed to make an exposure. Although a high ISO rating
is suited for taking pictures of subjects in action or in poor lighting, high sensitivity
is often associated with “noise” -randomly spaced, brightly colored pixels
concentrated in dark parts of the image.
If ISO sensitivity is locked, Motion detection (A126) will not function.
At settings other than Auto, the current setting is displayed in the monitor (A6).
If Auto is selected and the sensitivity is raised above an ISO 100, the E icon will
be displayed (A33). If Fixed range auto is selected, U + the maximum value
for ISO sensitivity will be displayed.
BNotes on ISO Sensitivity
This feature cannot be used simultaneously with certain features. ➝ “Functions that Cannot be
Applied Simultaneously” (A109)
Set to A (Auto) M d (Shooting menu) M EISO sensitivity
Auto (default setting)
Sensitivity is ISO 100 in bright places; in dark places the camera automatically raises
sensitivity to a maximum of ISO 1600.
Fixed range auto
Choose the range in which the camera automatically adjusts ISO sensitivity, from
ISO 100-400 or ISO 100-800. The camera will not raise sensitivity beyond the
maximum value in the selected range. Set the maximum value for ISO sensitivity for
effective control over the amount of “grain” that appears in images.
100, 200, 400, 800, 1600, 3200, 6400
ISO Sensitivity will be locked at the specified value.
103
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
FColor Options
Make colors more vivid or record pictures in monochrome.
At settings other than Standard color, the icon for the current setting is displayed
in the monitor (A6). Monitor color tones also change depending upon the
setting.
BNotes on Color Options
This feature cannot be used simultaneously with certain features. ➝ “Functions that Cannot be
Applied Simultaneously” (A109)
Set to A (Auto) M d (Shooting menu) M FColor options
nStandard color (default setting)
Use for pictures exhibiting natural color.
oVivid color
Use to achieve a vivid, “photoprint” effect.
pBlack-and-white
Record pictures in black-and-white.
qSepia
Record pictures in sepia tones.
rCyanotype
Record pictures in cyan-blue monochrome.
104
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
GAF-Area Mode
Choose how the focus area is determined.
When using digital zoom, the camera will focus on the subject in the center focus
area regardless of the applied AF area mode option.
Set to A (Auto) M d (Shooting menu) M GAF area mode
aFace priority
If the camera detects a face, it focuses on the face
(“Shooting with Face Priority” ➝ A106).
If the camera detects multiple faces, the camera
focuses on the face closest to the camera.
When shooting non-human subjects or when
framing the subject in such a way that a face cannot
be detected, the AF area mode becomes Auto, and
the camera automatically selects the focus area (up
to nine areas) containing the subject closest to the camera.
wAuto (default setting)
Camera automatically selects the focus area (one of
nine) containing the subject closest to the camera.
Press the shutter-release button halfway to activate
the focus area.
When the shutter-release button is pressed halfway,
the focus area selected by the camera will be
displayed in the monitor (up to nine areas).
xManual
Choose the focus area from 99 areas in the screen.
This option is suited to situations in which the
intended subject is relatively still and not positioned
in the center of the frame. Rotate the rotary multi
selector or press H, I, J or K to select one of 99
focus areas displayed in the monitor’s focus-area
selection screen, and shoot.
To end focus-area selection and adjust the flash
mode, macro mode, self-timer and exposure
compensation settings, press the k button. To
return to the focus-area selection screen, press the
k button again.
13
13
13
13
13
13
Focus areas
Focus area
Selectable areas
105
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
BNotes on AF Area Mode
This feature cannot be used simultaneously with certain features. ➝ “Functions that Cannot be
Applied Simultaneously” (A109)
DFocus Lock
Use focus lock to focus on off-center subjects when center is selected for AF area mode.
The following steps explain the usage of focus lock when Center is selected for AF area mode.
1 Position the subject in the center of the frame.
2 Press the shutter-release button halfway.
•Confirm that the focus area indicator is green.
•Focus and exposure are locked.
3 Continue holding down the shutter-release button halfway
and recompose the picture.
•Be sure that the distance between the camera and the subject does not
change.
4 Press the shutter-release button the rest of the way down to shoot.
DMore Information
See “Autofocus” (A29) for more information.
yCenter
The camera focuses on the subject in the center of
the frame.
The focus area is always positioned at the center of
the screen.
13
13
13
Focus area
13
13
13
F2.7
F2.7
1/250
1/250
F2.7
F2.7
1/250
1/250
106
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
Shooting with Face Priority
When the camera is pointed at a face, the face is automatically detected and the
camera focuses on the face.
The face priority function will be enabled for scenarios such as the following.
•Face priority is selected for AF area mode (A104)
•When Scene auto selector (A45), Portrait (A38) or Night portrait
(A39) is chosen for scene mode
•When using smart portrait mode (A51)
1Frame the picture.
•When the camera detects a face, that face will be
framed by a yellow double border.
•When the camera detects more than one face, operation varies, depending upon the
shooting mode, as follows.
2Press the shutter-release button halfway.
•The camera focuses on the face framed by the double
border. The double border will glow green and focus
will be locked.
•When the camera is unable to focus on a face, the
double border will blink. Press the shutter-release
button halfway again and focus.
•Press the shutter-release button all the way down to shoot.
•When using smart portrait mode, even if the shutter-release button is not pressed, the
shutter is released automatically if the camera detects that the face framed by the
double border is smiling (Smile timer) (A53).
Shooting mode Faces framed by a double
border
Number of faces
to be recognized
Auto mode (Face priority)The face closest to the
camera
* The other faces are
framed by a single border.
Up to 12
Scene auto selector, Portrait
or Night portrait scene modes
Smart portrait mode
The face closest to the
camera
* The other faces are
framed by a single border.
Up to 3
13
13
F2.71/250
1/250 F2.7
107
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
BNotes on Face Priority
•When Face priority is selected for AF area mode, the setting will automatically switch to Auto if
no face is detected when the shutter-release button is pressed halfway.
•If no face is recognized when the shutter-release button is pressed halfway in the Portrait or
Night portrait scene modes or smart portrait mode, the camera will focus on the subject in the
center of the frame.
•Depending on shooting conditions, such as whether or not the subject is facing the camera, faces
may not be detected.
•The camera may be unable to detect faces in the following situations:
- When faces are partially hidden by sunglasses or other obstructions
- When faces take up too much or too little of the frame
•When there are multiple people in the frame, the face on which the camera focuses depends on a
variety of shooting conditions, such as whether or not the subject is facing the camera.
•In some rare cases shooting subjects with which autofocus may not perform as expected (A29),
the subject may not be in focus despite the fact that the double border glows green. Should this
occur, switch to auto mode and set AF area mode to Manual or Center, refocus on another
subject positioned at the same distance from the camera as the actual portrait subject, and use
focus lock (A105).
•Images that were taken using face priority will be rotated and displayed automatically according
to the orientation of the faces detected, in full-frame and thumbnail playback modes (excluding
pictures that were shot using Continuous, BSS and Multi-shot 16 (A101)).
108
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
IAutofocus Mode
Choose how the camera focuses.
BNotes on Autofocus Mode
This feature cannot be used simultaneously with certain features. ➝ “Functions that Cannot be
Applied Simultaneously” (A109)
BNotes on the Autofocus Mode Setting for Subject Tracking Mode
You can set Autofocus mode for subject tracking mode. The default setting in subject tracking
mode is Full-time AF. Autofocus mode can be set independently for both subject tracking mode
and auto mode.
Set to A (Auto) M d (Shooting menu) M IAutofocus mode
ASingle AF (default setting)
Camera focuses when the shutter-release button is pressed halfway.
BFull-time AF
Camera focuses continuously until the shutter-release button is pressed down
halfway. Use with moving subjects.
A sound will be heard while the camera focuses.
109
Shooting Options: The Shooting Menu
Shooting, Playback and Setup Menus
Functions that Cannot be Applied Simultaneously
Certain settings in the shooting menu cannot be used with other functions.
Restricted Functions Setting Description
Flash mode Continuous (A101) If set to Continuous, BSS, or Multi-
shot 16, the flash cannot be used.
Image mode Continuous (A101) When using Multi-shot 16, Image
mode is fixed at L Normal (2592).
Continuous Self-timer (A34) Fixed at Single when using self-timer.
ISO sensitivity Continuous (A101)
When using Multi-shot 16, ISO
sensitivity is set automatically
according to the brightness.
White balance Color Options (A103)
When using Black-and-white, Sepia,
or Cyanotype, the White balance
setting is fixed at Auto.
Autofocus mode AF-Area Mode (A104) When using Face priority, Autofocus
mode is fixed Single AF.
Motion Detection Continuous (A101) When using Multi-shot 16, Motion
detection will not function.
ISO Sensitivity (A102) If ISO sensitivity is fixed, Motion
detection will not function.
Blink Warning Continuous (A101)
If set to Continuous, BSS, or Multi-
shot 16, the blink warning will not
function.
110
Shooting, Playback and Setup Menus
Playback Options: The Playback Menu
The following options are available in playback mode.
Displaying the Playback Menu
Enter the playback mode by pressing the c button (A30).
Display the playback menu by pressing the d button.
•Use the rotary multi selector to choose and apply settings (A10).
•To exit the playback menu, press the d button.
kQuick retouch A71
Easily create retouched images in which contrast and saturation have been enhanced.
ID-Lighting A72
Enhances brightness and contrast in dark portions of pictures.
eSkin softening A73
Make the subject’s skin appear smoother.
aPrint set A92
Select pictures to print and the number of copies for each.
bSlide show A112
View pictures stored in the internal memory or on a memory card in an automatic
slide show.
cDelete A113
Delete selected or all pictures.
dProtect A113
Protect selected pictures from accidental deletion.
fRotate image A114
Change the orientation of an existing picture.
gSmall picture A74
Create a small copy of the current picture.
EVoice memo A67
Record and play voice memo.
hCopy A115
Copy files between memory card and internal memory.
Playback menu
Quick retouch
D-Lighting
Exit
Skin softening
Slide show
Print set
15/11/2009 15:30
15/11/2009 15:30
44
44
111
Playback Options: The Playback Menu
Shooting, Playback and Setup Menus
Selecting Pictures
The picture selection screen, as shown at right, will be
displayed with the following menus:
•Playback menu:
Select images in Print set (A92)
Erase selected images in Delete (A113)
Protect (A113)
Rotate image (A114)
Selected images in Copy (A115)
•Setup menu:
Select an image in Welcome screen (A119)
Follow the procedure described below to select pictures.
1Rotate the rotary multi selector, or press J or
K to choose the desired picture.
•Only one picture can be selected for Rotate image
and Welcome screen. Proceed to step 3
•Rotate the zoom control to g (i) to switch to full-
frame playback, or f (h) to switch to 12 thumbnails
display.
2Press H or I to select ON or OFF (or the
number of copies).
•When ON is selected, a check mark is displayed in the
current picture. Repeat steps 1 and 2 to select
additional pictures.
3Press the k button to apply picture selection.
Erase selected images
Back
Erase selected images
Back
Erase selected images
Back
112
Playback Options: The Playback Menu
Shooting, Playback and Setup Menus
bSlide Show
View pictures stored in the internal memory or on a memory card in an automatic
slide show.
1Use the rotary multi selector to choose Start
and press the k button.
•To change the interval between pictures, choose
Frame intvl, select the desired interval time, and press
the k button before choosing Start.
•To repeat the slide show automatically, enable Loop
and press the k button before choosing Start. The
check mark (w) will be added to the loop option when enabled.
2The slide show begins.
•Press the rotary multi selector K while the slide show is
in progress to view images in the order recorded (hold
down to fast forward), or J to view images in reverse
order (hold down to rewind).
•Press the k button to pause the slide show.
3Choose End or Restart.
•When the slide show ends or is paused, choose End
and press the k button to return to the playback
menu or choose Restart to play the slide show again.
BNotes on Slide Show
•Movies are not included in slide shows.
•Slide shows play for a maximum of 30 minutes, even when Loop is selected (A128).
Press the c button (Playback mode) M d (Playback menu) M bSlide show
Slide show
Pause
Start
Frame intvl
Loop
Exit
Pause
Restart
End
Frame intvl
113
Playback Options: The Playback Menu
Shooting, Playback and Setup Menus
cDelete
Delete selected or all pictures.
BNotes on Deletion
•Once deleted, pictures cannot be recovered. Transfer important images to a computer before
deletion.
•pictures marked with the s icon are protected and cannot be deleted.
dProtect
Protect selected pictures from accidental deletion.
Select the picture and apply the setting in the picture selection screen (see
“Selecting Pictures” (A111) for more information).
Note, however, that formatting the camera’s internal memory or the memory card
will permanently erase protected files (A129).
Protected pictures are recognized by the s icon in playback mode (A7, 58).
Press the c button (Playback mode) M d (Playback menu) M cDelete
Erase selected images
Delete selected pictures (see “Selecting Pictures” (A111) for more information).
Erase all images
Delete all pictures.
Press the c button (Playback mode) M d (Playback menu) M dProtect
114
Playback Options: The Playback Menu
Shooting, Playback and Setup Menus
fRotate Image
Change the orientation of pictures played back in the camera’s monitor after
shooting.
Pictures can be rotated 90° clockwise or counterclockwise.
Pictures that were recorded in the portrait (vertical) orientation can be rotated up
to 180° in either direction.
Select a picture in the picture selection screen (A111), and press the k button
to display the Rotate image screen. Rotate the rotary multi selector or press J or
K to rotate the picture 90°.
Press the k button to set the orientation displayed, and save the orientation data
with the picture.
Press the c button (Playback mode) M d (Playback menu) M fRotate image
Rotate image
Back Rotate
Rotate image
Back Rotate
Rotate image
Back Rotate
Rotate 90°
counterclockwise
Rotate 90° clockwise
115
Playback Options: The Playback Menu
Shooting, Playback and Setup Menus
hCopy
Copy pictures between the internal memory and a memory card.
1Use the rotary multi selector to select an
option from the copy screen and press the k
button.
•q: Copy pictures from internal memory to
memory card.
•r: Copy pictures from memory card to internal
memory.
2Select a copy option and press the k button.
•Selected images: Copy pictures selected from the
picture selection screen (A111).
•All images: Copy all pictures.
BNotes on Copying Pictures
•JPEG-, AVI-, and WAV-format files can be copied. Files recorded in any other format cannot be
copied.
•If voice memos (A67) are attached to pictures selected for copying, voice memos are copied
with the pictures.
•Pictures recorded with another make or model of camera or that have been modified on a
computer cannot be copied.
•Edited copies have the same Protect (A92) as the original, but are not marked for Print set
(A113).
•Pictures or movies copied from the internal memory or the memory card (A64) cannot be
displayed in the auto sort mode.
CMemory contains no images. Message
If there are no pictures stored on the memory card when playback mode is applied, the message,
Memory contains no images., will be displayed. Press the d button to display the copy option
screen, and copy the pictures stored in the camera’s internal memory to the memory card.
DMore Information
See “File and Folder Names” (A139) for more information.
Press the c button (Playback mode) M d (Playback menu) M hCopy
Copy
Exit
Camera to card
Selected images
All images
Exit
116
Shooting, Playback and Setup Menus
Basic Camera Setup: The Setup Menu
The setup menu contains the following options.
aMenus A118
Choose how menus are displayed.
cWelcome screen A119
Select the welcome screen that is displayed when the camera is turned on.
dDate A120
Set camera clock and choose home and destination time zones.
eMonitor settings A123
Adjust monitor brightness and choose display style.
fDate imprint A124
Imprint date on pictures.
gVibration reduction A125
Reduce the effects of camera shake while shooting.
UMotion detection A126
Adjust the motion detection setting to reduce the effects of camera shake and
subject movement when shooting still pictures.
hAF assist A127
Enable or disable AF-assist illumination.
uDigital zoom A127
Enable or disable digital zoom.
iSound settings A128
Adjust sound settings.
kAuto off A128
Set time before camera enters standby mode to save power.
l/mFormat memory/Format card A129
Format internal memory or memory card.
nLanguage A130
Choose language used for camera monitor display.
oVideo mode A130
Adjust settings necessary for connection to TV.
VCharge by computer A131
Choose whether or not the battery is charged when the camera is connected
to a computer via USB cable.
dBlink warning A132
Choose whether or not to detect blinking human subjects when shooting
pictures using face priority.
117
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
Displaying the Setup Menu
Choose the z tab in the menu screen.
1Press the d button to display the menu
screen.
•When using A (auto) mode, smart portrait mode,
subject tracking mode, playback mode, and movie
mode
•When using scene mode
2Press J on the rotary multi selector.
•For information on using the rotary multi selector, see
“The Rotary Multi Selector” (A10).
•Tab will be selectable.
3Press H or I to select the z tab.
pReset all A134
Restore camera settings to default values.
rFirmware version A136
Display camera firmware version.
Shooting menu
Image mode
White balance
Metering
Continuous
ISO sensitivity
Exit
Image mode
High (4000 )
Normal (3264)
Normal (2048)
Normal (4000)
Normal (2592)
Exit
Shooting menu
Image mode
White balance
Metering
Continuous
ISO sensitivity
Exit
Set up
Menus
Welcome screen
Date
Monitor settings
Date imprint
Exit
118
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
4Press K or the k button.
•The setup menu options will be selectable.
•Use the rotary multi selector to choose and apply
settings (A10).
•To exit the setup menu, press the d button, or press
J and select another tab.
aMenus
Choose how menus are displayed.
Press the d button M z (setup menu) (A117) M aMenus
Text (default setting)
Menus are displayed in list format.
Icons
All menu options can be displayed in a single page.
Set up
Menus
Welcome screen
Date
Monitor settings
Date imprint
Exit
Set up
Menus
Welcome screen
Date
Monitor settings
Date imprint
Exit
Menus
Exit
Menu name
119
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
cWelcome Screen
Select the welcome screen that is displayed when the camera is turned on.
Press the d button M z (setup menu) (A117) M cWelcome screen
None (default setting)
Welcome screen is not displayed.
COOLPIX
Displays a welcome screen.
Select an image
Select a picture in the internal memory or on the memory card for the welcome
screen. Choose a picture in the picture selection screen (A111), and press the k
button.
As the selected picture is stored in the camera, the picture will appear in the
welcome screen even if the original picture is deleted.
•Pictures taken at an Image mode setting (A96) of 16:9, and copies created at
a size of 320 × 240 or smaller using the small picture (A74) or crop (A75)
functions, cannot be used.
120
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
dDate
Set the camera’s internal clock.
Setting the Travel Destination Time Zone
1Use the rotary multi selector to choose Time
zone and press the k button.
•The Time zone screen is displayed.
2Choose xTravel destination and press the
k button.
•The date and time displayed on the monitor changes
according to the region currently selected.
Press the d button M z (Setup menu) (A117) M dDate
Date
Set camera clock to current date and time.
Use the rotary multi selector to set the date and time.
•Highlight an item (day, month, year, hour, minute, and the order in which day,
month, and year are displayed): Press J or K.
•Edit the highlighted item: Press H or I, or rotate the rotary multi selector.
•Finish setting: After selecting the order in which the day, month, and year are
displayed, press the k button (A21).
Time zone
Set the home time zone (w) and enable or disable daylight saving time. When the
travel destination (x) is selected, the time difference (A122) between the travel
destination and the home time zone (w) is automatically calculated and the date
and time in the selected region are recorded. Useful when travelling.
15/11/2009 15:30
Date
Date
Time zone
Exit
London, Casablanca
15/11/2009 15:30
Time zone
Home time zone
Travel destination
Exit
121
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
3Press K.
•The time zone selection screen is displayed.
4Press J or K to choose the travel destination
time zone.
•When using the camera in an area where daylight
saving time is in effect, press H to set the clock to
daylight saving time. When daylight saving time is
turned on, the W icon is displayed and the clock
advances by one hour. To turn the setting off, press I.
•Press the k button to enter the travel destination time
zone.
•While the travel destination time zone is selected, the
Z icon will be displayed in the monitor when the
camera is in shooting mode.
BBackup Battery
The camera’s internal clock uses a backup battery that is independent from the camera’s battery. The
backup battery is charged while the main battery is installed or while the AC adapter is connected,
and will remember the clock settings for several days after about ten hours of charging.
Cw (Home Time Zone)
•To switch to the home time zone, choose wHome time zone in step 2 and press the k button.
•To change the home time zone, choose wHome time zone in step 2 and perform the steps for
xTravel destination to set the home time zone.
CDaylight Saving Time
When daylight saving time starts or ends, turn the daylight saving time option on or off from the
time zone selection screen displayed in step 4.
DImprinting the Date on Pictures
After setting the date and time, set the Date imprint setting in the setup menu (A124). Once
Date imprint is set, the shooting date and time can be imprinted on the image data when taking
pictures.
London, Casablanca
15/11/2009 15:30
Time zone
Home time zone
Travel destination
Exit
11:30
EDT:
New York
Toronto
Lima
Back
-
04:00
EDT:New York
Toronto, Lima
15/11/2009 11:30
Time zone
Home time zone
Travel destination
Exit
122
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
DTime Zones (A21)
The camera supports the time zones listed below.
For time differences not listed below, set the camera clock using Date.
UTC +/- Location UTC +/- Location
-11Midway, Samoa +1Madrid, Paris, Berlin
-10 Hawaii, Tahiti +2 Athens, Helsinki, Ankara
-9 Alaska, Anchorage +3 Moscow, Nairobi, Riyadh,
Kuwait, Manama
-8 PST (PDT): Los Angeles,
Seattle, Vancouver +4 Abu Dhabi, Dubai
-7 MST (MDT): Denver, Phoenix +5 Islamabad, Karachi
-6 CST (CDT): Chicago, Houston,
Mexico City +5.5 New Delhi
-5 EST (EDT): New York, Toronto,
Lima +6 Colombo, Dhaka
-4 Caracas, Manaus +7 Bangkok, Jakarta
-3 Buenos Aires, Sao Paulo +8 Beijing, Hong Kong,
Singapore
-2 Fernando de Noronha +9 Tokyo, Seoul
-1 Azores +10 Sydney, Guam
±0 London, Casablanca +11 New Caledonia
+12 Auckland, Fiji
123
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
eMonitor Settings
Change the settings for the options below.
Photo Info
The following display options are available.
See “The Monitor” (A6) for information on indicators in the monitor.
Press the d button M z (Setup menu) (A117) M eMonitor settings
Photo info
Choose information displayed in the monitor during shooting and playback mode.
Brightness
Choose from five settings for monitor brightness. The default setting is 3.
During Shooting During Playback
Show info
Auto info
(default setting)
The current settings or operation guide is displayed as in Show info
above. After a few seconds, display will be the same as Hide info.
Hide info
Framing grid +
Auto info
In A (auto) mode, a framing grid is
displayed to help frame pictures;
other current settings or operation
guide is displayed for a few
seconds, as in Auto info above.
In other shooting modes, the
current settings or operation guide
is displayed, as in Auto info above.
The current settings or operation
guide is displayed, as in Auto info
above.
13
13
13
15/11/2009 15:30
15/11/2009 15:30
44
44
13
13
13
15/11/2009 15:30
15/11/2009 15:30
44
44
124
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
fDate Imprint
The shooting date and time can be imprinted in pictures
at the time of shooting. This information can be printed
even from printers that do not support printing of date
and time (A94).
At settings other than Off, the icon for the current setting is displayed in the
monitor during shooting (A6).
BDate Imprint
•Imprinted dates form a permanent part of image data and cannot be deleted.
•Dates imprinted at an Image mode (A96) setting of TV screen (640) may be difficult to read.
Choose PC screen (1024) or larger when using date imprint.
•The date is recorded using the format selected in the setup menu’s Date option (A20, 120).
•Dates cannot be imprinted in the following situations.
- When using the Panorama assist scene mode
-Movie mode
CDate Imprint and Print Set
When printing from DPOF-compatible printers which support printing of shooting date and photo
information, the date and information can be printed on pictures without date and time imprinted
on them, using options in the Print set option (A92).
Press the d button M z (Setup menu) (A117) M fDate imprint
Off (default setting)
Date and time are not imprinted on pictures.
Date
The date is imprinted in pictures.
Date and time
The date and time are imprinted in pictures.
15.11.2009
15.11.2009
125
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
gVibration Reduction
Reduce the effects of camera shake while shooting. Vibration reduction effectively
corrects blur, caused by slight hand movement known as camera shake, that
commonly occurs when shooting with zoom applied or at slow shutter speeds.
Set vibration reduction to Off when using a tripod to stabilize the camera during
shooting.
When vibration reduction is enabled, the current setting is displayed during
shooting (when Off is selected, an icon for the current setting is not displayed)
(A6, 25).
BNotes on Vibration Reduction
•Vibration reduction may take a few seconds to activate after the power is turned on, or the camera
enters shooting mode from playback mode. Wait until the display stabilizes before shooting.
•Due to characteristics of the vibration reduction function, images displayed in the camera’s
monitor immediately after shooting may appear blurry.
•Vibration reduction may be unable to completely eliminate the effects of camera shake in some
situations.
Press the d button M z (Setup menu) (A117) M gVibration reduction
On (default setting)
Vibration reduction is enabled when shooting still pictures and recording movies.
Camera detects and factors out panning movements when reducing camera
shake. When camera is panned horizontally, for example, vibration reduction
reduces only vertical shake. If camera is panned vertically, vibration reduction
affects only horizontal shake.
Off
Vibration reduction is disabled.
126
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
UMotion Detection
Enable motion detection to reduce the effects of camera shake and subject
movement when shooting still pictures.
The motion detection setting can be confirmed in the monitor while shooting
(A6, 25).
The motion detection icon will glow green when the camera detects any vibration
and increases the shutter speed. When Off is selected, the icon for the current
setting is not displayed.
BNotes on Motion Detection
•Motion detection may be unable to completely reduce the camera shake and subject movement
in some situations.
•Motion detection may not function if the subject exhibits significant movement or is too dark.
•Pictures taken using motion detection may be somewhat grainy.
Press the d button M z (Setup menu) (A117) M UMotion detection
Auto (default setting)
When camera detects the movement of the subject or camera shake, the shutter
speed will be increased for reducing the effects of them.
However, motion detection does not function in the following situations.
•When the flash fires
•In auto mode, when ISO sensitivity (A102) is fixed
•In auto mode, when Multi-shot 16 is set (A101)
•In the following scene modes: Sport (A39), Night portrait (A39),
Fireworks show (A43), and Backlight (A43)
•When subject tracking mode is selected
Off
Motion detection is disabled.
127
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
hAF Assist
Enable or disable AF-assist illumination.
uDigital Zoom
Enable or disable digital zoom.
BNotes on Digital Zoom
•When using digital zoom, AF area mode is set to Center and cannot be changed (A104).
•Digital zoom cannot be used in the following situations.
- When Scene auto selector, Portrait or Night portrait is selected for scene mode
- When smart portrait mode is selected
- When subject tracking mode is selected
- When Multi-shot 16 is selected (A101)
- Before movie recording begins (digital zoom of up to 2× can be applied while movies are being
recorded)
•When using digital zoom, Metering is set to Center-weighted.
Press the d button M z (Setup menu) (A117) M hAF assist
Auto (default setting)
AF-assist illumination will be used to assist the focus operation when the subject is
poorly lit. The illuminator has a range of about 3.0 m (9 ft. 10 in.) at the maximum
wide-angle position and about 1.0 m (3 ft. 3 in.) at the maximum telephoto
position. However, note that for some scene modes, AF-assist illumination turns
off automatically (A38 to 44) even if Auto is set.
Off
Disable this function. The camera may be unable to focus if lighting is poor.
Press the d button M z (Setup menu) (A117) M uDigital zoom
On (default setting)
When the camera is zoomed in to the maximum optical zoom position, rotating
and hold the zoom control at g (i) triggers digital zoom (A27).
Off
Digital zoom will not be activated (except when shooting a movie).
128
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
iSound Settings
Adjust the following sound settings.
kAuto Off
If no operations are performed for the selected length of time, the monitor will
turn off and the camera enters standby mode (A19) to reduce drain on the
batteries. The power-on lamp blinks in standby mode. If no operations are
performed for another three minutes, the camera will turn off automatically.
Choose the time allowed to elapse before the camera enters standby mode if no
operations are performed from 30 s, 1 min (default setting), 5 min, and 30 min.
CCanceling Standby Mode
Standby mode is canceled when the following buttons are pressed.
•Power switch
•Shutter-release button
CNotes on Auto Off
Regardless of the option selected, the monitor will remain on as follows.
•While a menu is displayed: If auto off is set to 30 s or 1 min, it is extended to 3 minutes.
•Slide show playback: maximum of 30 minutes
•AC Adapter EH-62F is connected: 30 minutes
Press the d button M z (Setup menu) (A117) M iSound settings
Button sound
Turn button sound On (default setting) or Off. A beep will sound once when
operations are completed successfully, twice when the camera acquires focus on
the subject, and three times when error is detected. Start-up sound will also play
when the camera is turned on.
Shutter sound
Choose shutter sound from On (default setting) or Off.
Press the d button M z (Setup menu) (A117)M kAuto off
129
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
l/mFormat Memory/Format Card
Use this option to format the internal memory or a memory card.
Formatting the Internal Memory
To format the internal memory, remove the memory
card from the camera. The Format memory option
appears in the setup menu.
Formatting a Memory Card
When the memory card is inserted in the camera, the
Format card option appears in the setup menu.
BFormatting Internal Memory and Memory Cards
•Formatting the internal memory or memory cards permanently deletes all data. Be sure to transfer
important pictures to a computer before formatting.
•Do not turn the camera off, disconnect the AC adapter, or open the battery-chamber/memory
card slot cover during formatting.
•The first time you insert the memory cards used in other devices into this camera, be sure to
format them with this camera.
Press the d button M z (Setup menu) (A117) M lFormat memory/
mFormat card
Format memory
No
All images will
be deleted! OK?
Format
Exit
Format card
All images will
be deleted! OK?
No
Format
Exit
130
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
nLanguage
Choose one of 24 languages for display of camera menus and messages.
oVideo Mode
Adjust settings for connection to TV.
Choose from NTSC or PAL.
Press the d button M z (Setup menu) (A117) M nLanguage
Czech Polish
Danish Portuguese
German Russian
(default setting) Finnish
Spanish Swedish
Greek Turkish
French Arabic
Indonesian Simplified Chinese
Italian Traditional Chinese
Hungarian Japanese
Dutch Korean
Norwegian Thai
Press the d button M z (Setup menu) (A117) M oVideo mode
131
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
VCharge by Computer
Choose whether or not the battery inserted in the camera is charged when the
camera is connected to a computer via USB cable (A84).
BNotes on Connecting the Camera to a Printer
•The battery cannot be charged with connection to a printer, even if the printer complies with the
PictBridge standard.
•When Auto is selected for Charge by computer, it may be impossible to print pictures with
direct connection of the camera to some printers. If the PictBridge startup screen is not displayed
in the monitor after the camera is connected to a printer and turned on, turn the camera off and
disconnect the USB cable. Set Charge by computer to Off and reconnect the camera to the
printer.
Press the d button M z (Setup menu) (A117) M VCharge by computer
Auto (default setting)
When the camera is connected to a computer that is running, the battery inserted
into the camera is automatically charged using power supplied by the computer.
Off
The battery inserted into the camera is not charged when the camera is connected
to a computer.
132
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
dBlink Warning
Choose whether or not blinking eyes are detected when using face priority
(A106) in the following shooting modes.
•A (auto) mode (when AF area mode is set to Face priority) (A106)
•Scene auto selector (A38), Portrait (A38), or Night portrait (A39)
scene modes
BNote on Blink warning
When continuous is set to Continuous, BSS, or Multi-shot 16, blink warning does not function.
Press the d button M z (Setup menu) (A117) M dBlink warning
On
When the camera detects that one or more human subjects have closed their eyes
shortly after recognizing the faces and shooting them, the Did someone blink?
screen will appear on the monitor.
The face of the human subject that may have closed his/her eyes is framed by a
yellow border. You can check the picture taken and determine if you need to take
the picture again.
➝ “Operating the Did someone blink? Screen” (A133)
Off (default setting)
Blink warning doesn’t take effect.
133
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
Operating the Did someone blink? Screen
The following operations can be performed when the
Did someone blink? screen is displayed.
If no operations are performed for a few seconds, the
screen automatically returns to the shooting mode
screen.
To Use Description
Enlarge and display
the detected face g (i)Zoom increases each time the zoom control is rotated
to g (i).
Return to full-frame
playback f (h) Rotate the zoom control to f (h).
Select the face to be
displayed
If the camera detects more than one human subject
blinking, press J or K during playback zoom to display
other faces.
Delete the picture
taken lPress the l button.
The camera returns
to shooting mode.
k
Press the k button or the shutter-release button.
Did someone blink?
Exit
Exit
134
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
pReset All
When Reset is selected, the camera’s settings will be restored to their default
values.
Pop-up Menu
Shooting in the Scene Mode
Smart Portrait Menu
Subject Tracking Menu
Movie Menu
Press the d button M z (Setup menu) (A117) M pReset all
Option Default value
Flash mode (A32) Auto
Self-timer (A34) OFF
Macro mode (A35) OFF
Exposure compensation (A36) 0.0
Option Default value
Scene setting for shooting mode (A37) Scene auto selector
White balance setting in food mode (A47) Center
Option Default value
Skin softening (A52) Normal
Smile timer (A53) On
Blink proof (A52) Off
Option Default value
Autofocus mode (A56) Full-time AF
Face priority tracking (A56) On
Option Default value
Movie options (A77) TV movie 640
Autofocus mode (A77) Single AF
135
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
Shooting Menu
Setup Menu
Option Default value
Image mode (A96) INormal (4000)
White balance (A98) Auto
Metering (A100) Matrix
Continuous (A101) Single
ISO sensitivity (A102) Auto
Color options (A103) Standard color
AF area mode (A104) Auto
Autofocus mode (A108) Single AF
Option Default value
Menus (A118) Text
Welcome screen (A119) None
Photo info (A123) Auto info
Brightness (A123) 3
Date imprint (A124) Off
Vibration reduction (A125) On
Motion detection (A126) Auto
AF assist (A127) Auto
Digital zoom (A127) On
Button sound (A128) On
Shutter sound (A128) On
Auto off (A128) 1 min
Charge by computer (A131) Auto
Blink warning (A132) Off
136
Basic Camera Setup: The Setup Menu
Shooting, Playback and Setup Menus
Others
•Choosing Reset all also clears the current file number (A139) from the
memory. Numbering will continue from the lowest number available. To reset
file numbering to “0001”, delete all pictures (A113) before selecting Reset all.
•The following items remain unaffected when the camera is reset with Reset all.
Shooting menu:
Preset manual data (A99) acquired for White balance
Setup menu:
Date (A120), Language (A130), and Video mode (A130)
rFirmware Version
View the current camera firmware version.
Option Default value
Paper size (A88, 89) Default
Slide show (A112) 3 s
Press the d button M z (Setup menu) (A117) M rFirmware version
Back
COOLPIX S640 Ver.X.X
137
Technical Notes
Technical Notes
Optional Accessories
1When using in other countries, use a third-party plug adapter as necessary. For more
information about plug adapters, consult your travel agency.
Rechargeable battery Rechargeable Li-ion Battery EN-EL12
Charging AC Adapter Charging AC Adapter EH-68P/EH-68P (AR)1
Battery charger Battery Charger MH-65
AC adapter
AC Adapter EH-62F (connect as shown)
Insert the AC adapter cord into the groove deeply in the battery
chamber before closing the battery-chamber/memory card slot
cover. If part of the cord runs out of the groove, the cover or cord
may be damaged when the cover is closed.
USB cable USB Cable UC-E6
A/V cable Audio Video Cable EG-CP14
138
Optional Accessories
Technical Notes
Approved Memory Cards
The following Secure Digital (SD) memory cards have been tested and approved
for use in this camera.
•All cards of the designated make and capacity can be used, regardless of speed.
1 If the memory card will be used with a card reader or similar device, check that device
supports 2 GB cards.
2 SDHC-compliant. If the memory card will be used with a card reader or similar
device, check that device supports SDHC.
Operation is not guaranteed with other makes of card. Contact the manufacturer
for details on the above cards.
Refer to the Nikon website for the latest information on approved cards.
SanDisk 512 MB, 1 GB, 2 GB1, 4 GB2, 8 GB2, 16 GB2
TOSHIBA 512 MB, 1 GB, 2 GB1, 4 GB2, 8 GB2, 16 GB2
Panasonic 512 MB, 1 GB, 2 GB1, 4 GB2, 8 GB2, 16 GB2
Lexar 1 GB, 2 GB1, 4 GB2, 8 GB2
139
Technical Notes
File and Folder Names
Pictures, movies, and voice memos are assigned file names as follows.
•Files are stored in folders named with a folder number followed by a five-
character identifier: “P_” plus a three-digit sequence number for pictures shot
using Panorama assist (e.g. “101P_001”; A49), and “NIKON” for all other
pictures (e.g. “100NIKON”). When the number of files within a folder reaches
9999, a new folder will be created. File numbers will be assigned automatically
starting with “0001.”
•Voice memo file names have the same identifier and file number as the picture
to which the voice memo is attached.
•Files copied using Copy > Selected images is copied to the current folder,
where they are assigned new file numbers in ascending order starting from the
largest file number in memory. Copy > All images copies all folders from the
source medium; file names do not change but new folder numbers are
assigned in ascending order, starting from the largest folder number on the
destination medium (A115).
•A single folder can hold up to 200 pictures; if the current folder already contains
200 pictures, a new folder, named by adding one to the current folder name,
will be created the next time a picture is taken. If the current folder is numbered
999 and contains 200 pictures, or a picture is numbered 9999, no further
pictures can be taken until the internal memory or memory card is formatted
(A129), or a new memory card is inserted.
Identifier (not shown on camera monitor)
Original still pictures (voice
memo attachment
included), movies
DSCN
Small copies (voice memo
attachment included) SSCN
Cropped copies (voice
memo attachment included) RSCN
Quick Retouch, D-Lighting,
and Skin softening copies
(voice memo attachment
included)
FSCN
Extension (signifies the file type)
Still pictures .JPG
Movies .AVI
Voice memos .WAV
File number (assigned automatically in
ascending order, starting with “0001”)
140
Technical Notes
Caring for the Camera
To ensure continued enjoyment of this Nikon product, observe the following
precautions when using or storing the device.
BKeep dry
The device will be damaged if immersed in water or subjected to high humidity.
BDo not drop
The product may malfunction if subjected to strong shock or vibration.
BHandle the lens and all moving parts with care
Do not apply force to the lens, lens cover, monitor, memory card slot or battery chamber. These
parts are easily damaged. Applying force to the lens cover could result in camera malfunction or
damage to the lens. Should the monitor break, care should be taken to avoid injury caused by
broken glass and to prevent the liquid crystal from the display touching the skin or entering the eyes
or mouth.
BDo not point the lens at strong light sources for extended periods
Avoid pointing the lens at the sun or other strong light sources for extended periods when using or
storing the camera. Intense light may cause deterioration of the CCD image sensor, producing a
white blur effect in photographs.
BKeep away from strong magnetic fields
Do not use or store this device in the vicinity of equipment that generates strong electromagnetic
radiation or magnetic fields. Strong static charges or the magnetic fields produced by equipment
such as radio transmitters could interfere with the monitor, damage data stored on the memory
card, or affect the product’s internal circuitry.
BAvoid sudden changes in temperature
Sudden changes in temperature, such as when entering or leaving a heated building on a cold day,
can cause condensation to form inside the device. To prevent condensation, place the device in a
carrying case or a plastic bag before exposing it to sudden changes in temperature.
BTurn the product off before removing or disconnecting the power source
Do not remove the battery while the product is on, or while images are being recorded or deleted.
Forcibly cutting power in these circumstances could result in loss of data or in damage to product
memory or internal circuitry.
141
Caring for the Camera
Technical Notes
CThe Battery
•Check the battery level when taking the camera out, and charge the battery if necessary. Do not
continue charging once the battery is fully charged, as this will result in reduced battery
performance. If possible, carry a fully-charged spare battery when taking pictures on important
occasions.
•Do not use the battery at ambient temperatures below 0 °C (32 °F) or above 40 °C (104 °F). Failure
to observe this precaution could damage the battery or impair its performance.
•Charge the battery in an indoor environment that is between 5 and 35 °C (41 to 95 °F).
•When charging the battery by connecting the COOLPIX S640 to the Charging AC Adapter EH-68P/
EH-68P (AR) or to a computer, the chargeable capacity may decrease when the battery
temperature is between 45 to 60 °C (113 to 140 °F). The battery will not charge if its temperature is
below 0 °C (32 °F) or above 60 °C (140 °F).
•If an exhausted battery is used at a low temperature, the camera may not turn on. Be sure that the
battery is fully charged and spare batteries are prepared before heading outside to take pictures in
cold weather. Keep spare batteries in a warm place and exchange as necessary. Once warmed, a
cold battery that could not be used temporarily due to lowered performance may recover some of
its charge.
•Should the battery terminals become dirty, the camera may not turn on due to poor contact. Wipe
the terminals off with a clean, dry cloth before use.
•If the battery will not be used for some time, insert it in the camera and run it flat before removing
it for storage. Attach the included terminal cover to the battery and store it in a cool location with
an ambient temperature of 15 to 25 °C (59 to 77 °F). Do not store the battery in hot or extremely
cold locations.
•While the battery is in storage, charge it at least once every six months and then use the camera to
run it flat again before storing it in a cool location.
•Always remove the battery from the camera or battery charger when it is not being used. Left
installed, minute amounts of current flow even when unused, and the battery may become
excessively drained and no longer function.
•A marked drop in the time a fully-charged battery retains its charge, when used at room
temperature, indicates that the battery needs to be replaced. Purchase a new battery.
•Replace the battery when it no longer holds a charge. Used batteries are a valuable resource.
Please recycle used batteries in accordance with local regulations.
142
Caring for the Camera
Technical Notes
Cleaning
Do not use alcohol, thinner, or other volatile chemicals.
Lens
Avoid touching glass parts with your fingers. Remove dust or lint with a blower
(typically a small device with a rubber bulb attached to one end that is
pumped to produce a stream of air out the other end). To remove fingerprints
or other stains that cannot be removed with a blower, wipe the lens with a soft
cloth, using a spiral motion that starts at the center of the lens and working
toward the edges. If this fails, clean the lens using a cloth lightly dampened
with commercial lens cleaner.
Monitor Remove dust or lint with a blower. To remove fingerprints and other stains,
clean the monitor with a soft, dry cloth, being careful not to apply pressure.
Body
Use a blower to remove dust, dirt or sand, then wipe gently with a soft, dry
cloth. After using the camera at the beach or seaside, wipe off any sand or salt
with a dry cloth lightly dampened with fresh water, then dry thoroughly. Note
that foreign matter inside the camera could cause damage not covered by the
warranty.
143
Caring for the Camera
Technical Notes
Storage
Turn the camera off when not in use. Check that the power-on lamp is off before
putting the camera away. Remove the battery if the camera will not be used for an
extended period. Do not store the camera with naphtha or camphor moth balls, or
in any of the following locations:
•Next to equipment that produces strong electromagnetic fields, such as
televisions or radios
•Exposed to temperatures below -10 °C (14 °F) or above 50 °C (122 °F)
•Poorly ventilated or subject to humidities of over 60 %
To prevent mold or mildew, take the camera out of storage at least once a month.
Turn the camera on and release the shutter a few times before putting the camera
away again.
CNotes on the Monitor
•The monitor may contain a few pixels that are always lit or that do not light. This is a characteristic
common to all TFT LCD displays, and does not indicate a malfunction. Images recorded using the
product will not be affected.
•Images in the monitor may be difficult to see under bright lighting.
•The monitor is lit by an LED backlight. Should the monitor begin to dim or flicker, contact your
Nikon-authorized service representative.
CNotes on Smear
White or colored streaks of light may be visible in the monitor with framing of bright subjects. This
phenomenon, known as “smear,” occurs when extremely bright light strikes the image sensor. This is
due to characteristics of the image sensor and does not indicate a malfunction. Smear may also
cause partial discoloration in monitor display with shooting.
Smear does not affect recorded images except when shooting with Continuous set to Multi-shot
16 and when recording movies. When shooting in these modes, avoiding bright objects such as the
sun, reflections of the sun, and electric lights is recommended.
144
Technical Notes
Error Messages
The following table lists the error messages and other warnings displayed in the
monitor, as well as the solutions for dealing with them.
Display Problem Solution A
O (blinks) Clock not set. Set clock. 120
BBattery is running
low.
Prepare to charge or change
battery. 14, 16
N
Battery exhausted. Battery exhausted. Charge or replace battery. 14, 16
P
Battery temperature
high
Battery temperature
is high.
Turn off camera, and allow battery
to cool down before resuming
use. After five seconds, this
message will disappear, the
monitor will turn off, and the
power-on lamp will blink rapidly.
After the lamp blinks for three
minutes, the camera will turn off
automatically, but you can also
press the power switch to turn it
off manually.
19
Q (blinks red) Camera cannot
focus.
•Refocus.
•Use focus lock.
28, 29
105
P
Please wait for the
camera to finish
recording.
Camera cannot
perform other
operations until
recording is
complete.
Wait until message clears from
display automatically when
recording is complete.
–
N
Memory card is write
protected.
Write-protect switch
is in “lock” position.
Slide the write-protect switch to
“write” position. 23
P
This card cannot be
used. Error accessing
memory card.
•Use an approved card.
•Check that connectors are
clean.
•Confirm that memory card is
correctly inserted.
138
22
22
P
This card cannot be
read.
145
Error Messages
Technical Notes
P
Card is not formatted.
Format card?
No
Yes
Memory card has not
been formatted for
use in this camera.
All data stored on the memory
card will be deleted. If there is any
data on the card that you want to
keep, select No, and backup the
data to a computer before
formatting the memory card. To
format the memory card, select
Yes and press the k button.
23
N
Out of memory. Memory card is full.
•Choose smaller image mode.
•Delete unnecessary images.
•Replace memory card.
•Remove memory card and use
internal memory.
96
30, 78,
113
22
22
P
Image cannot be saved.
Error occurred while
recording picture.
Format internal memory or
memory card. 129
Camera has run out
of file numbers.
Replace the memory card, or
format the internal memory/
memory card.
139
Picture cannot be
used for welcome
screen.
The following pictures cannot be
used.
•Pictures taken at an Image
mode setting of 16:9
•Pictures created using the small
picture or crop functions that
are 320 × 240 or smaller in size
119
There is insufficient
space to save a copy. Delete pictures from destination. 113
P
Sound file cannot be
saved.
The image file
cannot have any
voice memos
attached to it.
•Choose an image that was
taken using this camera.
•Voice memos cannot be
attached onto movies.
68
–
N
A blink was detected in
the picture just taken.
Someone may have
had their eyes closed
when the picture
was taken.
Check results in playback mode. 30, 53
N
Image cannot be
modified.
Cannot edit selected
picture.
•Confirm the conditions that are
required for editing.
•These options cannot be used
with movies.
69
–
N
Cannot record movie.
Time out error while
recording movie.
Choose memory card with faster
write speed. 22
Display Problem Solution A
146
Error Messages
Technical Notes
N
Memory contains no
images.
No pictures in the
internal memory or
memory card.
•Pictures stored in the internal
memory can only be viewed if
no memory card is inserted.
•To copy files from internal
memory to memory card, press
the d button to display the
Copy screen, then copy the
files from internal memory to
memory card.
22
115
No pictures are
contained in the
folder selected in the
auto sort mode.
Select a folder containing the
sorted pictures. 64
No pictures can be
played back in the
auto sort mode.
Play back the pictures using the
playback mode or the list by date
mode.
65
N
File contains no image
data. File not created with
this camera.
File cannot be viewed on this
camera. View file using the
computer or any other devices
which was used to create or edit
this file.
–
P
This file cannot be
played back.
N
All images are hidden.
The picture cannot
be played back in a
slide show.
– 112
N
This image cannot be
deleted.
Picture is protected. Disable protection. 113
N
Travel destination is in
the current time zone.
Destination in same
time zone as home. – 122
Lens error
QLens error.
Turn camera off and then on
again. If error persists, contact
retailer or Nikon-authorized
service representative.
24
P
Communications error
Error occurred
during
communication with
printer.
Turn camera off and reconnect
cable. 86
Display Problem Solution A
147
Error Messages
Technical Notes
* See the documentation provided with your printer for further guidance and information.
System error
Q
Error has occurred in
camera’s internal
circuitry.
Turn camera off, remove and
reinsert battery, and turn camera
on. If error persists, contact retailer
or Nikon-authorized service
representative.
14, 19
PR
Printer error: check
printer status.
Printer error.
Check printer. After solving the
problem, select Resume and
press the k button to resume
printing. *
–
PR
Printer error: check
paper
Specified size of
paper is not loaded
in printer.
Load the specified type of paper,
select Resume and press the k
button to resume printing. *
–
PR
Printer error: paper jam
Paper has jammed in
the printer.
Remove the jammed paper, select
Resume and press the k button
to resume printing. *
–
PR
Printer error: out of
paper
No paper is loaded in
the printer.
Load the specified type of paper,
select Resume and press the k
button to resume printing. *
–
PR
Printer error: check ink Ink error.
Check ink, select Resume and
press the k button to resume
printing. *
–
PR
Printer error: out of ink
Ink cartridge is
empty.
Replace ink, select Resume and
press the k button to resume
printing. *
–
PR
Printer error: file corrupt
An error caused by
the image file has
occurred.
Select Cancel and press the k
button to cancel printing. –
Display Problem Solution A
148
Technical Notes
Troubleshooting
If the camera fails to function as expected, check the list of common problems
below before consulting your retailer or Nikon-authorized service representative.
Refer to the page numbers in the right-most column for more information.
Display, Settings and Power Supply
Problem Cause/Solution A
Monitor is blank.
•Camera is off.
•Battery is exhausted.
•Standby mode for saving power: press the power
switch or the shutter-release button.
•When flash lamp blinks red, flash is charging. Wait
until charging has finished.
•Camera is connected to computer via USB cable.
•Camera and TV are connected via audio/video cable.
•The camera cannot be turned on while connected to
an electrical outlet via the Charging AC Adapter.
19
24
13, 19
33
80
79
16
Monitor is hard to
read.
•Adjust monitor brightness.
•Monitor is dirty. Clean monitor.
123
140
Camera turns off
without warning.
•Battery is exhausted.
•Camera has turned off automatically to save power.
•Battery is cold.
•The camera turns off if it is connected to the Charging
AC Adapter while it is turned on.
•The camera turns off if the USB cable is disconnected
while the camera is connected to a computer or
printer. Connect the USB cable again.
24
128
141
16
81, 82, 86
Date and time of
recording are not
correct.
•Pictures recorded while the clock is not set (“Date not
set” indicator blinks during shooting) will have a time
stamp of “00/00/0000 00:00”; movies will be dated
“01/01/09 00:00.” Set the correct date and time using
Date in the setup menu. Set the correct date and
time using Date in the setup menu.
•Check camera clock regularly against more accurate
timepieces and reset as required.
20, 120
120
No information
displayed in monitor.
Hide info is selected for Photo info of the Monitor
settings option in the setup menu. 123
Date imprint not
available. Date has not been set. 20, 120
Date not appearing
on pictures even
when Date imprint is
enabled.
A shooting mode that does not support date imprint is
selected. 124
149
Troubleshooting
Technical Notes
Camera settings reset. Backup battery is exhausted; all settings were restored
to their default values. 121
Monitor turns off, and
the power-on lamp
blinks rapidly.
Battery temperature is high. Turn off camera, and allow
battery to cool down before resuming use. After the
lamp blinks for three minutes, the camera will turn off
automatically, but you can also press the power switch
to turn it off manually.
19
Battery inserted into
the camera is not
charged when the
camera is connected
to a computer.
•The battery is not charged when the camera is turned
off.
•Charging stops if the computer enters sleep mode
while the battery is charging. The camera may be
turned off.
•Depending upon computer specifications, settings,
and power supply and allocation, it may be
impossible to charge the battery inserted into the
camera via computer connection.
84
Problem Cause/Solution A
150
Troubleshooting
Technical Notes
Electronically Controlled Cameras
In extremely rare instances, unusual characters may appear in the monitor and the
camera may stop functioning. In most cases, this phenomenon is caused by a
strong external static charge. Turn the camera off, remove and replace the battery,
then turn the camera on again. In the event of continued malfunction, contact
your retailer or Nikon-authorized service representative. Note that disconnecting
the power source as described above may result in the loss of any data not
recorded to internal memory or the memory card at the time the problem
occurred. Data already recorded will not be affected.
Shooting
Problem Cause/Solution A
No picture taken
when shutter-release
button is pressed.
•When camera is in playback mode, press the A
button.
•When menus are displayed, press the d button.
•Battery is exhausted.
•When flash lamp blinks red, flash is charging.
8, 30
12
24
33
Camera cannot focus.
•The intended subject is one with which autofocus
does not perform well.
•Set AF assist in the setup menu to Auto.
•Turn camera off and then on again.
29
127
19
Pictures are blurred.
•Use flash.
•Use vibration reduction and motion detection.
•Use D (Best Shot Selector).
•Use a tripod to stabilize the camera (use with the self-
timer for best results).
32
125, 126
101
34
Streaks of light or
partial discoloration
appear in the display.
Smear may occur when the lens is aimed at bright
subjects. When using the multi-shot 16 shooting and
movie modes, we recommend that you avoid shooting
when direct sunlight, reflected sunlight, or electric
lights are in the display.
102, 143
Bright specks appear
in pictures shot using
flash.
Flash is reflecting off particles in air. Turn flash W (off). 33
Flash does not fire.
•Flash is W (off).
•Some scene modes that cannot turn on flash are
selected.
•Smart portrait mode selected, with Blink proof set
to On.
•D mode is selected.
•Another function that is set now is restricting the flash.
32
38
53
76
109
151
Troubleshooting
Technical Notes
Optical zoom cannot
be used. Optical zoom cannot be used while recording movies. 76
Digital zoom cannot
be used.
•Digital zoom is set to Off in the setup menu.
•Digital zoom cannot be used in the following
situations.
-When Scene auto selector, Portrait or Night
portrait is selected for scene mode
- When subject tracking mode is selected
- When smart portrait mode is selected
-When Multi-shot 16 is selected for Continuous
- Before movie recording begins (digital zoom of up
to 2× can be applied while movies are being
recorded)
127
38, 39, 45
54
51
101
76
Image mode not
available.
Another function that is set now is restricting Image
mode.109
No sound when
shutter is released.
•Off is selected for Shutter sound of the Sound
settings option in the setup menu.
•Continuous, BSS, or Multi-shot 16 is selected for
Continuous in shooting menu.
•When Sports, or Museum is selected in scene mode.
•Blink proof is set to On for smart portrait mode.
•D mode is selected.
•Do not block the speaker.
128
101
39, 42
52
76
4, 26
AF-assist illuminator
does not light.
•Off is selected for AF assist in the setup menu.
•AF-assist illuminator turns off automatically in some
scene modes.
127
38 – 43
Pictures appear
smeared. Lens is dirty. Clean lens. 140
Colors are unnatural. White balance does not match light source. 98
Randomly spaced
bright pixels (“noise”)
appear in image.
The subject is dark, so shutter speed is too slow or ISO
sensitivity is too high. Noise can be reduced by:
•Use flash.
•Specifying a lower ISO sensitivity setting.
•Using a scene mode which has noise reduction ability.
32
102
38
Pictures are too dark
(underexposed).
•Flash is W (off).
•Flash window is blocked.
•Subject is beyond flash range.
•Adjust exposure compensation.
•Raise the ISO sensitivity.
•Subject is backlit. Use Backlight or change the flash
mode to X (fill flash).
32
26
32
36
102
32, 43
Pictures are too bright
(overexposed). Adjust exposure compensation. 36
Problem Cause/Solution A
152
Troubleshooting
Technical Notes
Playback
Unexpected results
occurred when flash is
set to auto with red-
eye reduction.
When V (auto with red-eye reduction) or “fill flash
with slow sync and red-eye reduction” of the Night
portrait scene mode is applied during shooting, In-
Camera Red-Eye Fix may, in very rare cases, be applied
to areas not affected by red-eye. Set a flash mode other
than V (auto with red-eye reduction) and select a
scene mode other than Night portrait, then shoot.
32, 39
Skin softening results
are not as expected.
•Skin softening may not produce the desired results
depending on shooting conditions.
•For pictures with four or more faces, try using Skin
softening in the playback menu.
53
73
Saving images takes
time.
It may take more time to save images in the following
situations.
•When the noise reduction function is in operation
•When flash is set to V (auto with red-eye
reduction)
•When using skin softening while shooting
33, 38
33
38, 39, 52
Problem Cause/Solution A
File cannot be played
back.
File was overwritten or renamed by computer or
another make or model of camera. –
Cannot zoom in on
picture.
Playback zoom cannot be used with movies, small
pictures, or cropped copies smaller than 320 × 240
pixels.
–
Cannot record voice
memo.
•Voice memos cannot be attached to movies.
•Voice memos cannot be attached to pictures taken
by other cameras. Voice memos that are attached to
the picture using other cameras cannot be played
back on this camera.
78
67
Cannot use quick
retouch, D-Lighting,
skin softening, small
picture, or crop
options
•These options cannot be used with movies.
•
These options cannot be used with pictures taken when
P
16:9 (3968)
is applied in the
Image mode
setting.
•Select pictures that support quick retouch,
D-Lighting, skin softening, small picture, or crop.
•Pictures taken with another make or model of camera
cannot be edited.
•Other cameras may be unable to play back, or transfer
to a computer, pictures edited with this camera.
78
96
69
69
69
Problem Cause/Solution A
153
Troubleshooting
Technical Notes
Pictures not displayed
on television.
•The Video mode setting in setup menu has not
been set correctly.
•Memory card contains no pictures. Replace memory
card. Remove memory card to play back pictures
from internal memory.
130
22
The recorded pictures
are not displayed in
auto sort mode.
•The picture you want to display is sorted in another
folder.
•Pictures recorded by another camera, and pictures
copied using Copy on another camera cannot be
displayed in the auto sort mode.
•Pictures in the internal memory or memory card may
not be displayed if overwritten on a computer.
•Up to 999 images can be added to each folder in the
auto sort mode. If the desired folder already contains
999 pictures, new pictures cannot be added.
64
115
–
65
Nikon Transfer does
not start when
camera is connected.
•Camera is off.
•Battery is exhausted.
•USB cable is not correctly connected.
•Camera is not recognized by the computer.
•Confirm that the operating system used is
compatible with the camera.
•Computer is not set to launch Nikon Transfer
automatically.
For more information on Nikon Transfer, refer to help
information contained in Nikon Transfer.
19
24
81
–
80
83
The PictBridge startup
screen is not
displayed when the
camera is connected
to a printer.
With some PictBridge-compatible printers, the
PictBridge startup screen may not be displayed and it
may be impossible to print pictures when Auto is
selected for the Charge by computer option in the
setup menu. Set the Charge by computer option to
Off and reconnect the camera to the printer.
131
Pictures to be printed
are not displayed.
•Memory card contains no pictures. Replace memory
card.
•Remove memory card to print pictures from internal
memory.
22
Cannot select paper
size with camera.
Paper size cannot be selected from the camera in the
following situations, even for PictBridge compatible
printers. Use the printer to select page size.
•The page size selected using the camera is not
compatible with the printer.
•A printer that automatically sets the paper size is
being used.
88, 89
–
Problem Cause/Solution A
154
Technical Notes
Specifications
Nikon COOLPIX S640 Digital Camera
Type Compact digital camera
Effective pixels 12.2 million
Image sensor 1/2.33-in. CCD; approx. 12.39 million total pixels
Lens 5× optical zoom, NIKKOR lens
Focal length 5.0-25.0mm (equivalent with 35mm [135] format picture angle:
28-140mm)
f/-number f/2.7–6.6
Construction 7 elements in 6 groups
Digital zoom Up to 4× (equivalent with 35mm [135] format picture angle:
approx. 560mm)
Vibration reduction Lens shift
Autofocus (AF) Contrast-detect AF
Focus range (from
lens)
•
[W]: Approx. 45 cm (1 ft. 6 in.) to
∞
, [T]: Approx. 70 cm (2 ft.
4in.) to
∞
•Macro mode: Approx. 2 cm (0.8 in.) to ∞ (wide-end zoom
position)
Focus-area selection Face priority, auto (9-area automatic selection), manual with 99
focus areas, center
Monitor 2.7-in., approx. 230k-dot, wide viewing angle TFT LCD with
anti-reflection coating and 5-level brightness adjustment
Frame coverage
(shooting mode) Approx. 100% horizontal and 100% vertical
Frame coverage
(playback mode) Approx. 100% horizontal and 100% vertical
Storage
Media
Internal memory (approx. 45 MB), SD (Secure Digital) memory cards
File system DCF, Exif 2.2, and DPOF compliant
File formats
Still pictures: JPEG
Movies: AVI (Motion-JPEG compliant)
Sound files: WAV
Image size
(pixels)
•4000×3000 High (4000P)/Normal (4000)
•3264×2448 Normal (3264)
•2592×1944 Normal (2592)
•2048×1536 Normal (2048)
•1024×768 PC screen (1024)
•640×480 TV screen (640)
•3968×2232 16:9 (3968)
ISO sensitivity
(Standard output
sensitivity)
•ISO 100, 200, 400, 800, 1600, 3200, 6400
•Auto (auto gain from ISO 100 to 1600)
•Fixed range auto (ISO 100 to 400, 100 to 800)
155
Specifications
Technical Notes
Exposure
Metering 224-segment matrix, center-weighted
Exposure control Programmed auto exposure with motion detection and
exposure compensation (–2.0 to +2.0 EV in steps of 1/3 EV)
Range (ISO 100) [W]: –1.1 to +15.4 EV
[T]: 1.6 to 18.1 EV
Shutter Mechanical and charge-coupled electronic shutter
Speed
•1/1500 -8 s (when ISO sensitivity is set to 100, 200, 400)
•1/1500 -2 s (when ISO sensitivity is set to 800)
•1/1500 -1 s (when ISO sensitivity is set to Auto, 1600, 3200)
•1/1500 -1/2 s (when ISO sensitivity is set to 6400)
•4 s (Fireworks show scene mode)
Aperture Electronically-controlled ND filter (–2 AV) selection
Range 2 steps (f/2.7 and f/5.4 [W])
Self-timer Can be selected from 10 and 2 seconds duration
Built-in flash
Range (approx.)
(ISO sensitivity: Auto)
[W]: 0.5 to 8.0 m (1 ft. 8 in. to 26 ft.)
[T]: 0.5 to 4.0 m (1 ft. 8 in. to 13 ft.)
Flash control TTL auto flash with monitor preflashes
Interface Hi-Speed USB
Data transfer protocol MTP, PTP
Video output Can be selected from NTSC and PAL
I/O terminal Audio/video output; digital I/O
Supported languages
Arabic, Chinese (Simplified and Traditional), Czech, Danish,
Dutch, English, Finnish, French, German, Greek, Hungarian,
Indonesian, Italian, Japanese, Korean, Norwegian, Polish,
Portuguese, Russian, Spanish, Swedish, Thai, Turkish
Power sources One Rechargeable Li-ion Battery EN-EL12 (supplied)
AC Adapter EH-62F (optional)
Charging time Approx. 4 hours (when using Charging AC Adapter EH-68P/
EH-68P (AR) and when no charge remains)
Battery life* Approx. 270 shots (EN-EL12)
Dimensions (W × H × D) Approx. 91 × 55 × 20.5 mm (3.6 × 2.2 × 0.8 in.) (excluding
projections)
Weight Approx. 110 g (4.0 oz) (without battery and SD memory card)
Operating environment
Temperature 0 to 40 °C (32 to 104 °F)
Humidity Less than 85 % (no condensation)
156
Specifications
Technical Notes
•Unless otherwise stated, all figures are for a camera with a fully-charged
Rechargeable Li-ion Battery EN-EL12 operated at an ambient temperature of
25 °C (77 °F).
* Based on Camera and Imaging Products Association (CIPA) standards for measuring the life
of camera batteries. Measured at 23 (±2) °C (73 (±4) °F); zoom adjusted with each shot,
flash fired with every other shot, image mode set to INormal (4000). Battery life may
vary depending on shooting interval and length of time menus and images are displayed.
Rechargeable Li-ion Battery EN-EL12
Charging AC Adapter EH-68P/EH-68P (AR)
BSpecifications
•Nikon will not be held liable for any errors this manual may contain.
•The appearance of this product and its specifications are subject to change without notice.
Type Rechargeable lithium-ion battery
Rated capacity DC 3.7 V, 1050 mAh
Operating temperature 0 to 40 °C (32 to 104 °F)
Dimensions (W × H × D) Approx. 32 × 43.8 × 7.9 mm (1.3 × 1.7 × 0.3 in.)
Weight Approx. 22.5 g (0.8 oz) (excluding terminal cover)
Rated input AC 100-240 V, 50/60 Hz, 0.065-0.04 A
Rated capacity 6.5–9.6 VA
Rated output DC 5.0 V, 0.5 A
Operating temperature 0 to 40 °C (32 to 104 °F)
Dimensions (W × H × D) EH-68P: Approx. 55 × 22 × 65 mm (2.7 × 0.9 × 2.6 in.)
EH-68P (AR): Approx. 55 × 51.6 × 66 mm (2.2 × 2.0 × 2.6 in.)
Weight EH-68P: Approx. 60g (2.1 oz)
EH-68P (AR): 65 g (2.3 oz)
157
Specifications
Technical Notes
Supported Standards
•DCF: Design Rule for Camera File System is a standard widely used in the digital
camera industry to ensure compatibility among different makes of camera.
•DPOF: Digital Print Order Format is an industry-wide standard that allows
pictures to be printed from print orders stored on the memory card.
•Exif version 2.2: This camera supports Exif (Exchangeable Image File Format
for Digital Still Cameras) version 2.2, a standard that allows information stored
with photographs to be used for optimal color reproduction when images are
output from Exif-compliant printers.
•PictBridge: A standard developed cooperatively by the digital camera and
printer industries, allowing photographs to be output directly to a printer
without connecting the camera to a computer.
158
Technical Notes
Index
Symbols
R 50
k Apply selection button 10
A Auto mode 24
F Auto sort mode 64
l Delete button 30, 31, 68, 78
o Exposure compensation 36
m Flash mode 32
j Help 13
C List by date mode 61
p Macro mode 35
d Menu button 12
D Movie mode 76
c Playback button 9, 30
c Playback mode 30
i Playback zoom 60
C Scene mode 37
n Self timer 34
z Setup menu 116
A Shooting mode button 8
a Smart portrait mode 51
s Subject tracking mode 54
g Tele 27
h Thumbnail Playback 57, 59
f Wide 27
.AVI 139
.JPG 139
.WAV 139
A
AC adapter 137
AF area mode 104
AF assist 127
Aperture 28
Audio/video cable 79, 137
Audio/video-in jack 79
Auto 32
Auto mode 24
Auto off 128
Auto sort mode 64
Autofocus 55, 77, 108
Autofocus mode 56, 77, 108
AV cable 79, 137
B
Backlight o 43
Battery 14, 16, 121
Battery chamber 5
Battery charger 18, 137
Battery latch 14
Battery level indicator 24
Battery-chamber/memory card slot cover
14, 22
Beach/snow g 40
Best shot selector 101
Black-and-white 103
Blink proof 53
Blink warning 132, 133
BSS 101
Built-in flash 32
Button sound 128
C
Cable connector 79, 80, 85
Calendar display 59
Center-weighted 100
Charge by computer 131
Charge lamp 17
Charger 16, 137
Charging AC Adapter 16, 137
Close-up k 42
Color options 103
Compression ratio 96
Computer 80
Connector cover 5
Continuous 101
Copy n 43
Crop 75
Cyanotype 103
D
Date 20, 120
Date imprint 124
Daylight saving time 20, 121
159
Index
Technical Notes
Delete 30, 68, 78, 113
Digital zoom 27, 127
D-Lighting 72
DPOF 157
DPOF print 91
DSCN 139
Dusk/dawn i 41
E
EH-68P/EH-68P (AR) 16
EN-EL12 16
Exposure compensation 36
Extension 139
Eyelet for camera strap 5
F
Face priority 104
Face priority tracking 56
File name 139
Fill flash 32
Fireworks show m 43
Firmware version 136
Fixed range auto 102
Flash lamp 33
Flash mode 32, 33
Flash off 32
Focus 28, 77, 104
Focus indicator 6, 28
Focus lock 105
Folder name 139
Food u 42, 47
Format 23, 129
Format the internal memory 129
Formatting 23, 129
FSCN 139
Full-frame playback 30, 31
Full-time AF 77, 108
H
Help 13
Histogram 10, 36
I
Identifier 139
Image copy 115
Image mode 96, 97
Image size 96
Internal memory 22
Internal memory indicator 25
ISO sensitivity 33, 102
L
Lamp indicator 5
Landscape c 38
Language 130
Lens 4, 154
Lens cover 4
Li-ion rechargeable battery 14
List by date menu 63
List by date mode 61
Lithium-ion type battery 16, 137
M
Macro mode 35
Matrix 100
Memory capacity 24
Memory card 22, 138
Memory card slot 22
Menus 118
Metering 100
Microphone 4
Monitor 6, 142
Monitor brightness 123
Monitor display settings 123
Monitor settings 123
Motion detection 25, 126
Movie length 77
Movie menu 77
Movie mode 76
Movie playback 78
Movie recording 76
Movie settings 77
Multi-shot 16 101
Museum l 42
N
Night landscape j 41
160
Index
Technical Notes
Night portrait e 39
Nikon Transfer 80, 81
Number of exposures remaining 24, 97
O
Optical zoom 27
Optional accessories 137
P
Panorama assist p 44, 49
Panorama Maker 80, 83
Paper size 88, 89
Party/indoor f 40
PictBridge 85, 157
Playback 30, 57, 59, 60, 68, 78
Playback menu 110
Playback mode 30
Playback zoom 60
Playback-mode selection menu 9
Portrait b 38
Power 19, 20, 24
Power switch 19, 20, 24
Preset manual 99
Press halfway 13
Print 88, 89, 92
Print set 92
Print Set Date Option 93, 94
Printer 85
Protect 113
Q
Quick retouch 71
R
Rechargeable battery 137
Red-eye reduction 32, 33
Reset all 134
Rotary multi selector 20
Rotate image 114
RSCN 139
S
Scene auto selector x 38, 45
Scene mode 37, 38
Self-timer 34
Self-timer lamp 34, 51
Sepia 103
Setup menu 116
Shooting 24, 26, 28
Shooting info 10
Shooting menu 95
Shooting with Face Priority 106
Shooting-mode selection menu 8
Shutter button 13, 28
Shutter sound 128
Shutter speed 28
Single 101
Single AF 77, 108
Skin softening 52
Slide show 112
Slow sync 32
Small picture 74
Small size 77
Smart portrait menu 52
Smart portrait mode 51
Smile timer 53
Software Suite 80
Sound settings 128
Speaker 4
Sports d 39
SSCN 139
Standard color 103
Strap 13
Subject Tracking Menu 56
Subject tracking mode 54
Sunset h 40
T
Tele 27
Television 79
Thumbnail display 57
Time difference 122
Time zone 120, 122
Tripod socket 5
TV Movie 77
161
Index
Technical Notes
U
USB cable 81, 86, 137
V
Vibration reduction 25, 125
Video mode 130
ViewNX 82
Vivid color 103
Voice memo 67
Volume 68, 78
W
Welcome screen 119
White balance 98
Wide 27
Z
Zoom control 27
162
Printed in Europe
CT9G01(11)
6MM70511-01
No reproduction in any form of this manual, in whole or in part
(except for brief quotation in critical articles or reviews), may be
made without written authorization from NIKON CORPORATION.

Navigation menu
