Dell EMC OpenManage Python Software
Development Kit
Version 1.0
API Reference Guide
Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© Copyright2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners. Licensed under the Apache license version 2.0; you may not use this le except in compliance
with the license. You may obtain a copy of the license at https://www.apache.org/licenses/LICENSE-2.0. Unless applicable law required or agreed to in
writing, software distributed under the license is distributed on an AS IS BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or
implied. See the license for the specic language governing permissions and limitations under the license.
2018 - 08
Rev. A01
Contents
1 Introduction to OpenManage python software development toolkit............................................................... 5
SDK concepts and architectural components................................................................................................................5
2 Installation and Uninstallation of OMPSDK.................................................................................................... 6
Installing OMPSDK.............................................................................................................................................................6
Uninstalling OMPSDK........................................................................................................................................................6
3 OpenManage Python SDK API introduction................................................................................................... 7
OpenManage Python SDK API list...................................................................................................................................7
Monitoring API list........................................................................................................................................................7
Administration tasks API list...................................................................................................................................... 16
Export and Import Tasks API list...............................................................................................................................18
Server iDRAC Settings Conguration API list........................................................................................................ 26
Boot Settings Conguration API list........................................................................................................................44
RAID Conguration API list....................................................................................................................................... 49
iDRAC LC Jobs API list..............................................................................................................................................54
iDRAC LC Status Check API list.............................................................................................................................. 55
4 Getting Started........................................................................................................................................... 56
OMPSDK Infrastructure..................................................................................................................................................56
Initialization of OMPSDK Infrastructure..................................................................................................................56
API to setup share........................................................................................................................................................... 58
Setting up a remote network share......................................................................................................................... 58
iDRAC server information............................................................................................................................................... 58
Administration Tasks........................................................................................................................................................58
Server conguration prole overview........................................................................................................................... 59
Import export server conguration proles.................................................................................................................. 59
Export server conguration prole.......................................................................................................................... 59
Import server conguration prole.......................................................................................................................... 59
Exporting LC Logs........................................................................................................................................................... 60
Server iDRAC settings and conguration..................................................................................................................... 60
iDRAC User Conguration settings......................................................................................................................... 60
iDRAC Network Conguration................................................................................................................................. 60
iDRAC Service Conguration.................................................................................................................................... 61
iDRAC System Settings............................................................................................................................................. 61
BIOS Boot settings.......................................................................................................................................................... 62
BIOS Boot settings.................................................................................................................................................... 62
RAID Conguration.......................................................................................................................................................... 62
Create Virtual Disk..................................................................................................................................................... 62
Delete Virtual Disk......................................................................................................................................................62
iDRAC LC jobs.................................................................................................................................................................. 62
Job API's..................................................................................................................................................................... 62
Contents 3
iDRAC LC status check...................................................................................................................................................63
4 Contents
Introduction to OpenManage python software
development toolkit
DellEMC OpenManage python software development kit (OMPSDK) is a library for programatically managing DellEMC Servers and
Chassis. Using this library a user can perform lifecycle operations on DellEMC PowerEdge servers, chassis storage and switches. The
OMPSDK leverages the DMTF Redsh, DMTF's Web Services Management standard (WS-Man), and IETF's Simple Network Management
Protocol (SNMP) standard for managing and monitoring the DellEMC PowerEdge servers and chassis.
SDK concepts and architectural components
An OMPSDK is a complete set of APIs that allow you to perform most of actions you would need for creating, monitoring and managing
the servers or chassis applications. An SDK provides a set of APIs, relevant documentation, code samples, processes, that allows
developers to create software applications on a specic platform. Components in OMPSDK are:
• OMPSDK Infrastructure
• Driver
• Credential management
• Protocol Management
– Protocol preference and options
• Log Manager
1
Introduction to OpenManage python software development toolkit 5
Installation and Uninstallation of OMPSDK
Installing OMPSDK
To install OMPSDK, there are some prerequisites which are essential.
Prerequisites:
Ensure that you have the following:
• Python v2.7 or v3.4 and above.
• Package management system (pip).
Run the following command
pip install omsdk
OMPSDK is installed and the package is available in PyPI (Python package Index).
Uninstalling OMPSDK
To uninstall OMPSDK, use the following command:
pip uninstall omsdk
2
6 Installation and Uninstallation of OMPSDK
OpenManage Python SDK API introduction
OpenManage Python SDK (OMPSDK) API Module allows data center and IT administrators to automate and orchestrate the provisioning,
conguration, deployment, and update of Dell EMC PowerEdge Servers (12th generation of PowerEdge servers and later) by using the
management automation capabilities in-built into the integrated Dell remote access controller (iDRAC). This product evolves conservatively
and values simplicity in design and setup.
The traditional approach for creating a plug-in always starts from scratch, such as building communication module, business logic module,
user interface module, and native console data translation module. In most of the plug-ins the native console data translation module varies,
but all other modules remain more or less same. As a result, every plug-in maintains their own set of libraries which adds no uniformity in
implementation across plug-ins. Indirectly it increases the overhead sustaining cost of the plug-ins.
OMPSDK is targeted to provide
• A uniform implementation of communication module and core business logic module
• Abstraction of multiple communication protocols with data messaging
• Macro services as per use case—Monitoring, conguration, and more
• Optionally automatic code generating capability
• Quick integration to other DevOps.
OpenManage Python SDK API list
This section describes the resource URIs and related operations that are available in the OpenManage Python SDK(OMPSDK)
implementation.
Monitoring API list
sdkinfra.nd_driver
API string/Method: sdkinfra.find_driver.
Description: The sdkinfra.find_driver() method is used to initialize and load the device drivers.
Table 1. Parameters for sdkinfra.nd_driver
Parameter Name Type Allowed Values
ipaddr String NA
Description The IP address or hostname of the device.
3
OpenManage Python SDK API introduction 7
Table 2. Parameters for the Credentials
Parameter Name Type Allowed Values
creds Dictionary of credentials Snmpv2Credentials
UserCredentials
Description A bundle of credentials required to communicate to the device driver.
Snmpv2Credentials
UserCredentials
Table 3. Parameter for Protocol preference
Parameter Name Type Allowed Values
protopref Enumeration of preferred protocol ProtocolEnum.WSMAN
ProtocolEnum.SNMP
ProtocolEnum.REDFISH
Description The preferred protocol used if the device supports the protocol.
Table 4. Parameter for protocol specic options
Parameter Name Type Allowed Values
pOptions Dictionary of protocol-specic
options SNMPOptions
WSMANOptions
REDFISHOptions
Description A protocol-specic option for passed, port, timeout and so on.
SNMPOptions
WSMANOptions
REFISHOptions
Return type:
ObjectDevice driver: A driver handle to congure or monitor the drivers.
Example:
find_driver(ipaddr, creds, protopref=None, pOptions=None)
sdkinfra.get_driver
API string/Method: sdkinfra.get_driver.
Description: The sdkinfra.get_driver() method is used to get a device driver for the given IP address or hostname, and check for
a particular device type.
8OpenManage Python SDK API introduction
Table 5. Parameters for sdkinfra.get_driver
Parameter Name Type Allowed Values
ipaddr String NA
Description The IP address or hostname of the device.
Table 6. Parameters for device type
Parameter Name Type Allowed Values
driver_en Enumeration of the device type sdkinfra.driver_enum.iDRAC
sdkinfra.driver_enum.CMC
sdkinfra.driver_enum.Compellent
sdkinfra.driver_enum.EqualLogic
sdkinfra.driver_enum.MDArray
sdkinfra.driver_enum.F10
sdkinfra.driver_enum.NSeries
Description The enumeration of the device type.
Table 7. Parameters for credentials
Parameter Name Type Allowed Values
creds Dictionary of credentials Snmpv2Credentials
UserCredentials
Description A bundle of credentials to nd the device driver.
Snmpv2Credentials
UserCredentials
Table 8. Parameters for preferred protocol
Parameter Name Type Allowed Values
protopref Enumeration of preferred protocol NA
Description The preferred protocol used if the device supports the protocol.
Table 9. Parameters for protocol specic options
Parameter Name Type Allowed Values
pOptions Dictionary of protocol-specic
options SNMPOptions
WSMANOptions
REFISHOptions
Description A protocol-specic option for passed, port, timeout and so on.
SNMPOptions
WSMANOptions
REFISHOptions
OpenManage Python SDK API introduction 9
Return type:
ObjectDevice driver: A driver handle to congure or monitor the drivers.
Example:
get_driver(driver_en, ipaddr, creds, protopref=None, pOptions=None)
Sdkbase.iBaseDriver.get_entityjson
API string/Method: Sdkbase.iBaseDriver.get_entityjson.
Description: The Sdkbase.iBaseDriver.get_entityjson() is used to create the JSON of the device by fetching the attributes
from the device using the protocol. It internally creates the raw JSON of the device.
Return type:
Table 10. Return type
Returns Return type
True Boolean
Sdkbase.iBaseDriver.get_partial_entityjson
API string/Method: Sdkbase.iBaseDriver.get_partial_entityjson.
Description: The Sdkbase.iBaseDriver.get_partial_entityjson() is used to get the JOSN with the components which are
passed as an argument for the function.
Table 11. Parameters for Sdkbase.iBaseDriver.get_partial_entityjson
Parameter Name Type Allowed Values
en iDRACCompEnum
CMCCompEnum
iDRAC CMC
iDRACCompEnum.BIOS
iDRACCompEnum.ControllerBatter
y
iDRACCompEnum.Controller
iDRACCompEnum.CPU
iDRACCompEnum.Enclosure
iDRACCompEnum.EnclosureEMM
iDRACCompEnum.EnclosurePSU
iDRACCompEnum.EnclosureFanSe
nsor
iDRACCompEnum.EnclosureTempS
ensor
iDRACCompEnum.Fan
iDRACCompEnum.FC
iDRACCompEnum.HostNIC
iDRACCompEnum.iDRAC
iDRACCompEnum.iDRACNIC
iDRACCompEnum.License
CMCCompEnum.BladeSlot
CMCCompEnum.CMC
CMCCompEnum.ComputeModule
CMCCompEnum.Controller
CMCCompEnum.ControllerBattery
CMCCompEnum.Enclosure
CMCCompEnum.EnclosureEMM
CMCCompEnum.EnclosurePSU
CMCCompEnum.Fan
CMCCompEnum.IOModule
CMCCompEnum.KVM
CMCCompEnum.License
CMCCompEnum.PowerSupply
CMCCompEnum.PhysicalDisk
CMCCompEnum.PCIDevice
CMCCompEnum.StorageModule
CMCCompEnum.Slots_Summary
10 OpenManage Python SDK API introduction
Parameter Name Type Allowed Values
iDRACCompEnum.LogicalSystem
iDRACCompEnum.NIC
iDRACCompEnum.PCIDevice
iDRACCompEnum.PowerSupply
iDRACCompEnum.PresenceAndSta
tusSensor
iDRACCompEnum.PhysicalDisk
iDRACCompEnum.Sensors_Amper
age
iDRACCompEnum.Sensors_Battery
iDRACCompEnum.Sensors_Fan
iDRACCompEnum.Sensors_Intrusio
n
iDRACCompEnum.Sensors_Temper
ature
iDRACCompEnum.Sensors_Voltage
iDRACCompEnum.SystemMetrics
iDRACCompEnum.VFlash
iDRACCompEnum.Video
iDRACCompEnum.VirtualDisk
CMCCompEnum.System
CMCCompEnum.VirtualDisk
Description List of strings or enumeration of the components.
Return type:
Table 12. Return Type
Returns Return type
JSON JSON Only the components passed in enumeration.
Sdkbase.iBaseDriver.ContainmentTree
API string/Method: Sdkbase.iBaseDriver.ContainmentTree.
Description: The Sdkbase.iBaseDriver.ContainmentTree() is used to create and return the component tree of the device with
keys of the Components organized in a tree structure.
Sdkdevice.iDeviceDriver.get_json_device
API string/Method: Sdkdevice.iDeviceDriver.get_json_device.
Description: The Sdkdevice.iDeviceDriver.get_json_device() is used to apply the monitor lter on the raw entityJSON and
also lter the category of the attributes and components required for the client.
OpenManage Python SDK API introduction 11
Table 13. Parameters for Sdkdevice.iDeviceDriver.get_json_device
Parameter Name Type Allowed Values
monitorfilter MonitorScope MonitorScope.BasicInventory
MonitorScope.CongState
MonitorScope.Health
MonitorScope.Inventory
MonitorScope.Key
MonitorScope.MainHealth
MonitorScope.Metrics
MonitorScope.OtherHealth
MonitorScope.OtherInventory
Description The category of lters to apply.
Table 14. Parameter for Component
Parameter Name Type Allowed Values
compScope String or Enum iDRAC CMC
iDRACCompEnum.BIOS
iDRACCompEnum.ControllerBattery
iDRACCompEnum.Controller
iDRACCompEnum.CPU
iDRACCompEnum.Enclosure
iDRACCompEnum.EnclosureEMM
iDRACCompEnum.EnclosurePSU
iDRACCompEnum.EnclosureFanSensor
iDRACCompEnum.EnclosureTempSensor
iDRACCompEnum.Fan
iDRACCompEnum.FC
iDRACCompEnum.HostNIC
iDRACCompEnum.iDRAC
iDRACCompEnum.iDRACNIC
iDRACCompEnum.License
iDRACCompEnum.LogicalSystem
iDRACCompEnum.NIC
iDRACCompEnum.PCIDevice
iDRACCompEnum.PowerSupply
iDRACCompEnum.PresenceAndStatusSe
nsor
iDRACCompEnum.PhysicalDisk
iDRACCompEnum.Sensors_Amperage
iDRACCompEnum.Sensors_Battery
iDRACCompEnum.Sensors_Fan
iDRACCompEnum.Sensors_Intrusion
iDRACCompEnum.Sensors_Temperature
iDRACCompEnum.Sensors_Voltage
iDRACCompEnum.SystemMetrics
iDRACCompEnum.VFlash
CMCCompEnum.BladeSlot
CMCCompEnum.CMC
CMCCompEnum.ComputeModule
CMCCompEnum.Controller
CMCCompEnum.ControllerBattery
CMCCompEnum.Enclosure
CMCCompEnum.EnclosureEMM
CMCCompEnum.EnclosurePSU
CMCCompEnum.Fan
CMCCompEnum.IOModule
CMCCompEnum.KVM
CMCCompEnum.License
CMCCompEnum.PowerSupply
CMCCompEnum.PhysicalDisk
CMCCompEnum.PCIDevice
CMCCompEnum.StorageModule
CMCCompEnum.Slots_Summary
CMCCompEnum.System
CMCCompEnum.VirtualDisk
12 OpenManage Python SDK API introduction
Parameter Name Type Allowed Values
iDRACCompEnum.Video
iDRACCompEnum.VirtualDisk
Description The required components.
Return type:
Table 15. Parameter for return type
Returns Return type
JSON The formatted JSON of the device with all the applied process attributes—mapping, units
conversion.
NOTE: Before utilizing the APIs, ensure to apply the sdkinfra.find_driver or sdkinfra.get_driver.
Sdkcreds.Snmpv2Credentials
API string/Method: Sdkcreds.Snmpv2Credentials.
Description: Credentials for SNMP version 1 and version 2.
Table 16. Parameters for Sdkcreds.Snmpv2Credentials
Parameter Name Type
community String
Description Community string for the SNMP device.
Table 17. Parameter for write community
Parameter Name Type Allowed Values
writeCommunity String NA
Description Write community string for the SNMP device.
Sdkcreds.UserCredentials
API string/Method: Sdkcreds.UserCredentials .
Description: Credentials username and password for WSMAN communication with the device.
Table 18. Parameters for Sdkcreds.UserCredentials
Parameter Name Type
username String
Description User name for WSMAN communication.
OpenManage Python SDK API introduction 13
Table 19. Parameter for password
Parameter Name Type Allowed Values
password String NA
Description Password for WSMAN communication.
Sdkwsmanbase.WsManOptions
API string/Method: Sdkwsmanbase.WsManOptions .
Description: Options to establish WSMAN communication.
Table 20. Parameters for Sdkwsmanbase.WsManOptions
Parameter Name Type Allowed Values
authentication AuthenticationType NA
Description HTTP authentication type Basic, Digest.
Table 21. Parameter for port
Parameter Name Type Allowed Values
port Integer NA
Description HTTPS port number for WSMAN communication.
Table 22. Parameter for connection time-out
Parameter Name Type Allowed Values
connection_timeout Integer NA
Description Time in seconds to wait for the server to connect before giving up.
Table 23. Parameter for read time-out
Parameter Name Type Allowed Values
read_timeout Integer NA
Description Time in seconds to wait for the server to read data before giving up.
Table 24. Parameter for max retries
Parameter Name Type Allowed Values
max_retries Integer NA
Description HTTP connection retries in case of failures.
14 OpenManage Python SDK API introduction
Table 25. Parameter for verifying SSL certicate
Parameter Name Type Allowed Values
verify_ssl Boolean NA
Description SSL certicate verication.
Sdkredshbase.RedshOptions
API string/Method: Sdkredfishbase.RedfishOptions.
Description: Options to establish REDFISH communication.
Table 26. Parameters for Sdkredshbase.RedshOptions
Parameter Name Type
authentication AuthenticationType
Description HTTP authentication type Basic, Digest.
Table 27. Parameter for port
Parameter Name Type Allowed Values
port Integer NA
Description HTTPS port number for WSMAN communication.
Table 28. Parameter for connection time-out
Parameter Name Type Allowed Values
connection_timeout Integer NA
Description Time in seconds to wait for the server to connect before giving up.
Table 29. Parameter for read time-out
Parameter Name Type Allowed Values
read_timeout Integer NA
Description Time in seconds to wait for the server to read data before giving up.
Table 30. Parameter for max retries
Parameter Name Type Allowed Values
max_retries Integer NA
Description HTTP connection retries in case of failures.
OpenManage Python SDK API introduction 15
Table 31. Parameter for verify ssl
Parameter Name Type Allowed Values
verify_ssl Boolean NA
Description SSL certicate verication.
Administration tasks API list
This section lists the available Administration tasks APIs.
idrac.cong_mgr.power_boot
API string/Method: idrac.config_mgr.power_boot(Power_state).
Protocol Support: WSMAN.
Description: The idrac.config_mgr.power_boot(Power_state) allows you to power On/O the Server.
Table 32. Parameters for idrac.cong_mgr.power_boot(PowerBootEnum.Enabled)
Parameter Name Type Allowed Values
power_boot(power_state) Enum PowerBootEnum Enabled
Disabled
Reset
Description Allows you to power On/O the Server.
1 - Reset
2 - Enabled
3 - Disabled
Returns: None.
Return Type: None.
idrac.cong_mgr.reset_idrac
API string/Method: idrac.config_mgr.reset_idrac.
Protocol Support: Redfish.
Description: This method is used to reset the iDRAC.
Parameters:
16 OpenManage Python SDK API introduction
Table 33. Parameters for idrac.cong_mgr.reset_idrac
Parameter Name Type Allowed Values
Force ResetForceEnum ResetForceEnum.Graceful
ResetForceEnum.Force
Description Description: This method is used to reset the iDRAC.
0 - Graceful - Reset is performed after the device is properly restarted.
1 - Force - Reset is performed without a proper shutdown of the device.
idrac.cong_mgr.reset_to_factory
API string/Method: idrac.config_mgr.reset_to_factory.
Protocol Support: WSMAN, Redfish.
Description: This method is used to reset the iDRAC to factory default.
Parameters:
Table 34. Parameters for idrac.cong_mgr.reset_to_factory
Parameter Name Type Allowed Values
Force ResetForceEnum ResetForceEnum.Graceful
ResetForceEnum.Force
Description Description: This method is used to reset the iDRAC.
ResetForceEnum.Graceful - Reset is performed after the device is properly restarted.
ResetForceEnum.Force - Reset is performed without a proper shutdown of the device.
Table 35. Parameters for idrac.cong_mgr.reset_to_factory
Parameter Name Type Allowed Values
preserver_config ResetToFactoryPreserveEnum ResetToFactoryPreserveEnum.ResetExceptNIC
AndUsers
ResetToFactoryPreserveEnum.ResetAll
ResetToFactoryPreserveEnum.ResetAllExcept
DefaultUser
Description Allows you to preserve the conguration
0 - ResetToFactoryPreserveEnum.ResetExceptNICAndUsers
Allows you to reset the device without resetting the NIC and User settings.
1 - ResetToFactoryPreserveEnum.ResetAll
Allows you to reset the device along with the NIC and the User settings.
2 - ResetToFactoryPreserveEnum.ResetAllExceptDefaultUser
Allows you to reset without resetting the default user.
OpenManage Python SDK API introduction 17
Export and Import Tasks API list
This section lists the available Export and Import Tasks APIs.
idrac.cong_mgr.scp_export
API string/Method: idrac.config_mgr.scp_export.
Protocol Support: WSMAN, Redfish.
Description: This method is used to export the system conguration from the Lifecycle Controller to a local or a remote share location.
Parameters:
Table 36. Parameters for idrac.cong_mgr.scp_export
Parameter Name Type Allowed Values
export_format ExportFormatEnum ExportFormatEnum.XML
ExportFormatEnum.JSON
Description
Allows you to export the conguration detail as XML or JSON le.
0 - ExportFormatEnum.XML
1 - ExportFormatEnum.JSON
Default - XML
Table 37. Parameters for idrac.cong_mgr.scp_export
Parameter Name Type Allowed Values
export_use ExportUseEnum ExportUseEnum.Default
ExportUseEnum.Clone
ExportUseEnum.Replace
Description
The output le formats for export_use are:
ExportUseEnum.Default- By default, none of the options are selected.
ExportUseEnum.Clone - This option is used with Redsh protocol to generate an SCP that is ready for
cloning.
ExportUseEnum.Replace - This option is used to retire a server from the data center and replace it with
another.
Table 38. Parameters for idrac.cong_mgr.scp_export
Parameter Name Type Allowed Values
include_in_export IncludeInExportEnum IncludeInExportEnum.Default
IncludeInExportEnum.Include_Read_Only
IncludeInExportEnum.Include_Password_Hash
18 OpenManage Python SDK API introduction
Parameter Name Type Allowed Values
_Values
IncludeInExportEnum.Include_Both
Description
This API allows you to include more while exporting the le. The additional information added with
include_in_export are:
1 - IncludeInExportEnum.Include_Read_Only - Includes read only values.
2 - IncludeInExportEnum.Include_Password_Hash_Values - Includes password hash values.
3 - IncludeInExportEnum.Include_Both - Includes both the values.
IncludeInExportEnum.Default - 0
Table 39. Parameters for idrac.cong_mgr.scp_export
Parameter Name Type Allowed Values
job_wait Boolean True/False
Description True - Wait for the performed export Server Conguration Prole jobs to complete.
False - Returns only the JobID.
Table 40. Parameters for idrac.cong_mgr.scp_export
Parameter Name Type
share_path FileOnShare (for CIFS & NFS Share)
LocalFile (For Local Share)
Description
SCP exports can be directed to local le systems and network shares.
NFS - Network File System
IPAddress - Name of the NFS share server.
Sharename - Name of the shared le.
Mountpoint - To mount the shared le.
UserCredentials - Username and password for accessing the shared le.
CIFS - Common Internet File System
IPAddress - Name of the CIFS share server.
Sharename - Name of the shared le.
Sharepath - The share path where le needs to be exported.
UserCredentials - Username and password for accessing the shared le.
Table 41. Parameters for idrac.cong_mgr.scp_export
Parameter Name Type Allowed Values
Target SCPTargetEnum SCPTargetEnum.ALL
SCPTargetEnum.IDRAC
SCPTargetEnum.BIOS
OpenManage Python SDK API introduction 19
Parameter Name Type Allowed Values
SCPTargetEnum.NIC
SCPTargetEnum.RAID
Description
To identify the component for export. It identies one or more FQDDs. Selective list of FQDDs should be given
in comma-separated format.
SCPTargetEnum.IDRAC - The module exports only the iDRAC component in SCP le.
SCPTargetEnum.BIOS - The module exports BIOS conguration in SCP le.
SCPTargetEnum.NIC - The module exports NIC conguration in SCP le.
SCPTargetEnum.RAID - The module exports RAID conguration in SCP le.
This module will import the conguration component from the exported SCP
Default - SCPTargetEnum.ALL - This module exports the complete system conguration from the Lifecycle
Controller to a le on local or remote share location.
Table 42. Parameters for idrac.cong_mgr.scp_export
Parameter Name Type
time_to_wait unit16
Description The time to wait for the host to shut down. Default and minimum value is 300 seconds. Maximum value is
3600 seconds.
Table 43. Parameters for idrac.cong_mgr.scp_export
Parameter Name Type
Workgroup String
Description The applicable workgroup.
Returns: Success or Failure
Return type: JSON
idrac.cong_mgr.scp_import
API string/Method: idrac.config_mgr.scp_import.
Protocol Support: WSMAN, Redfish.
Description: This method is used to import the system conguration.
Parameters:
20 OpenManage Python SDK API introduction
Table 44. Parameters for idrac.cong_mgr.scp_import
Parameter Name Type Allowed Values
end_host_power_state EndHostPowerStateEnum EndHostPowerStateEnum.Off
EndHostPowerStateEnum.On
Description The desired host power state after the import operation is complete.
0 - Off
1 - On
Default value is 0
Table 45. Parameters for idrac.cong_mgr.scp_import
Parameter Name Type Allowed Values
job_wait Boolean True/False
Description This API raises a ag to wait for the job to complete. A false value will return the Job ID.
Table 46. Parameters for idrac.cong_mgr.scp_import
Parameter Name Type
share_path FileOnShare (for CIFS & NFS Share)
LocalFile (For Local Share)
Description SCP exports can be directed to local le systems and network shares.
NFS - Network File System
IPAddress - Name of the NFS share server.
Sharename - The NFS share name.
Mountpoint - To mount the shared le.
UserCredentials - Username and password for accessing the shared le.
CIFS - Common Internet File System
IPAddress - Name of the CIFS share server.
Sharename - The CIFS share name.
Sharepath - The share path where le needs to be imported.
UserCredentials - Username and password for accessing the shared le.
Table 47. Parameters for idrac.cong_mgr.scp_import
Parameter Name Type Allowed Values
Target SCPTargetEnum SCPTargetEnum.ALL
SCPTargetEnum.IDRAC
SCPTargetEnum.BIOS
OpenManage Python SDK API introduction 21
Parameter Name Type Allowed Values
SCPTargetEnum.NIC
SCPTargetEnum.RAID
Description To identify the component for Import. It identies one or more FQDDs. Selective list of FQDDs
should be given in comma-separated format.
SCPTargetEnum.IDRAC - The module imports iDRAC conguration in SCP le.
SCPTargetEnum.BIOS - The module imports BIOS conguration in SCP le.
SCPTargetEnum.NIC - The module imports NIC conguration in SCP le.
SCPTargetEnum.RAID - The module imports RAID conguration in SCP le.
This module will import the conguration component from the imported SCP
Default - SCPTargetEnum.ALL - This module imports the complete system conguration
from the Lifecycle Controller to a le on local or remote share location.
Table 48. Parameters for idrac.cong_mgr.scp_import
Parameter Name Type
time_to_wait unit16
Description The time to wait for the host to shut down. Default and minimum value is 300 seconds.
Maximum value is 3600 seconds.
Table 49. Parameters for idrac.cong_mgr.scp_import
Parameter Name Type
Workgroup String
Description The applicable workgroup.
Return type:
Table 50. Parameters for idrac.cong_mgr.scp_import
Parameter Name Return Type
(job-wait=True)]
(job-wait = False)
XML or JSON le
Description
Exports the server conguration prole to the provided network share or to the local path.
JobID - It is in the format JID_XXXXXXXXXXXX.
Job Status - It allows the user to check the status of job completion.
idrac.log_mgr.lclog_export
API string/Method: idrac.log_mgr.lclog_export.
Protocol Support: WSMAN.
Description: The ExportLCLog() method is used to export the log from the Lifecycle Controller to a remote share.
22 OpenManage Python SDK API introduction
Parameters:
Table 51. Parameters for idrac.log_mgr.lclog_export
Parameter Name Type Allowed Values
job_wait Boolean True/False
Description This API raises a ag to wait for the job to complete. A false value will return the Job ID.
Table 52. Parameters for idrac.log_mgr.lclog_export
Parameter Name Type
share_path FileOnShare (for CIFS & NFS Share)
LocalFile (For Local Share)
Description LC log exports can be directed to local le systems and network shares
NFS - Network File System
IPAddress - Name of the NFS share server.
Sharename - The NFS share name.
Mountpoint - To mount the shared le.
UserCredentials - Username and password for accessing the shared led.
CIFS - Common Internet File System
IPAddress - Name of the CIFS share server.
Sharename - The CIFS share name.
Sharepath - The share path where le needs to be exported.
UserCredentials - Username and password for accessing the shared le.
Table 53. Parameters for idrac.log_mgr.lclog_export
Parameter Name Type
work_group String
Description The applicable workgroup.
Example:
# Export LC Logs - NFS Share
nfs_share = FileOnShare(remote=<IP OR HOSTNAME>:/<NFS-SHARE-PATH>,
mount_point=<MOUNT-DRIVE>:\>, isFolder=<True/False>,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
lclog_file = nfs_share.new_file(<FILE-NAME>)
msg = idrac.log_mgr.lclog_export(lclog_file)
# Export LC Logs - CIFS Share
cifs_share = FileOnShare(remote=\\<IP OR HOSTNAME>\<CIFS-SHARE-PATH>, isFolder=<True/False>,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
lclog_file = cifs_share.new_file(<FILE-NAME>)
msg = idrac.log_mgr.lclog_export(lclog_file)
# Export LC Logs - Local Share
OpenManage Python SDK API introduction 23
local_share = LocalFile(local=os.path.join(, "path", "to", "lc-logs-file.xml"))
export_lclog_streaming = idrac.log_mgr.lclog_export(share_path=local_share)
Returns: Success or Failure
Return type: JSON
idrac.log_mgr.complete_lclog_export
API string/Method: idrac.log_mgr.complete_lclog_export.
Protocol Support: WSMAN.
Description: The complete_lclog_export() method is used to export the full log from the Lifecycle Controller to a remote share.
Parameters:
Table 54. Parameters for idrac.log_mgr.complete_lclog_export
Parameter Name Type Allowed Values
job_wait Boolean True/False
Description True - It will wait for the export the full LC logs job to complete and return the job completion
status.
False - It will return immediately with a JOB ID after queuing the export LC logs job in LC job
Table 55. Parameters for idrac.log_mgr.complete_lclog_export
Parameter Name Type
share_path FileOnShare (for CIFS & NFS Share)
LocalFile (For Local Share)
Description LC log exports can be directed to local le systems and network shares
NFS - Network File System
IPAddress - Name of the NFS share server.
Sharename - The NFS share name.
Mountpoint - To mount the shared le.
UserCredentials - Username and password for accessing the shared le.
CIFS - Common Internet File System
IPAddress - Name of the CIFS share server
Sharename - The CIFS share name.
Sharepath - The share path where le needs to be exported.
UserCredentials - Username and password for accessing the shared le.
Example:
# Export LC Full Logs - NFS Share
nfs_share = FileOnShare(remote=<IP OR HOSTNAME>:/<NFS-SHARE-PATH>,
mount_point=<MOUNT-DRIVE>:\>, isFolder=<True/False>,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
tsr_file = nfs_share.new_file(<FILE-NAME>)
24 OpenManage Python SDK API introduction
idrac.log_mgr.complete_lclog_export(tsr_file)
# Export LC Full Logs - CIFS Share
cifs_share = FileOnShare(remote=\\<IP OR HOSTNAME>\<CIFS-SHARE-PATH>, isFolder=<True/False>,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
tsr_file = cifs_share.new_file(<FILE-NAME>)
idrac.log_mgr.complete_lclog_export(tsr_file)
# Export LC Full Logs - Local Share
local_share = LocalFile(local=os.path.join(, "path", "to", <FILE_NAME>))
idrac.log_mgr.complete_lclog_export(local_share)
Returns: Success or Failure.
Return type: JSON
idrac.cong_mgr.export_tsr
API string/Method: idrac.config_mgr.export_tsr.
Protocol Support: WSMAN.
Description: The idrac.config_mgr.export_tsr is used to collects the TSR i.e hardware, OS and App data, then compressed
the .zip le saves into the respective remote share path—cifs/nfs.
Parameters:
Table 56. Parameters for idrac.cong_mgr.export_tsr
Parameter Name Type Allowed Values
data_selector_arra
y_in DataSelectorArrayInEnum DataSelectorArrayInEnum.HW_Data
DataSelectorArrayInEnum.OSApp_Data
DataSelectorArrayInEnum.TTY_Logs
DataSelectorArrayInEnum.Debug_Logs
Description The DataSelectorArrayIn allows you to select the one of the data
DataSelectorArrayInEnum.HW_Data - Technical support report for Hardware Data.
DataSelectorArrayInEnum.OSApp_Data - Technical support report for OSApp Data Without PII.
DataSelectorArrayInEnum.TTY_Logs - Technical support report for TTY Logs.
DataSelectorArrayInEnum.Debug_Logs - Technical support report for OSApp Data.
Table 57. Parameters for idrac.cong_mgr.export_tsr
Parameter Name Type Allowed Values
job_wait Boolean True/False
Description This API raises a ag to wait for the job to complete. A false value will return the Job ID.
OpenManage Python SDK API introduction 25
Table 58. Parameters for idrac.cong_mgr.export_tsr
Parameter Name Type Allowed Values
tsr_store_path FileOnShare—for CIFS and NFS Share
Description This method collects the TSR i.e hardware, OS and App data, then compresses and saves the .zip le to
remote share path.
The FileOnShare API allows you to view the share path where le needs to be exported.
Example:
#Export TSR - NFS Share
nfs_share = FileOnShare(remote=<IP OR HOSTNAME>:/<NFS-SHARE-PATH>,
mount_point=<MOUNT-DRIVE>:\>, isFolder=<True/False>,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
tsr_file = nfs_share.new_file(<FILE-NAME>)
idrac.config_mgr.export_tsr(tsr_file, data_selector_array_in = DataSelectorArrayInEnum.HW_Data)
# Export TSR - CIFS Share
cifs_share = FileOnShare(remote=\\<IP OR HOSTNAME>\<CIFS-SHARE-PATH>, isFolder=<True/False>,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
tsr_file = cifs_share.new_file(<FILE-NAME>)
idrac.config_mgr.export_tsr(tsr_file, data_selector_array_in = DataSelectorArrayInEnum.HW_Data)
Returns: Success or Failure.
Return type: JSON
Server iDRAC Settings Conguration API list
This section lists the available Server iDRAC Settings Conguration APIs.
iDRAC User Conguration
idrac.user_mgr.Users.new
idrac.user_mgr.Users.new
API string/Method: idrac.user_mgr.Users.new.
Protocol Support: Redfish.
Description: The idrac.user_mgr.Users.new() returns a JSON to create the user. For more details about the properties and
values, refer to iDRAC Attribute Registry Guide.
26 OpenManage Python SDK API introduction
Table 59. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
UserName_Users String User dened string
Description Allows you to create a user name.
Table 60. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
Password_Users String User dened string
Description Allows you to create a password.
Table 61. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
Privilege_Users ENUM Privilege_UsersTypes.Administrator
Privilege_UsersTypes.NoAccess
Privilege_UsersTypes.Readonly
Privilege_UsersTypes.Operator
Description Allows you to create a privileged user,
Table 62. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
IpmiLanPrivilege_Users ENUM IpmiLanPrivilege_UsersTypes.Administrator
IpmiLanPrivilege_UsersTypes.No_Access
IpmiLanPrivilege_UsersTypes.Operator
IpmiLanPrivilege_UsersTypes.User
Description Allows you to set IPMI LAN privilege for users.
Table 63. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
IpmiSerialPrivilege_Use
rs
ENUM IpmiSerialPrivilege_UsersTypes.Administra
tor
IpmiLanPrivilege_UsersTypes.No_Access
IpmiLanPrivilege_UsersTypes.Operator
IpmiLanPrivilege_UsersTypes.User
Description Allows you to set IPMI serial privilege for users.
OpenManage Python SDK API introduction 27
Table 64. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
Enable_Users ENUM Enable_UsersTypes.Enabled
Enable_UserTypes.Disabled
Description Allows you to enable a user.
Table 65. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
SolEnable_Users ENUM SolEnable_UsersTypes.Enabled
SolEnable_UsersTypes.Disabled
Description Allows you to enable a SOL user.
Table 66. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
ProtocolEnable_Users ENUM ProtocolEnable_UserTypes.Enabled
ProtocolEnable_UsersTypes.Disabled
Description Allows you to enable a protocol for a user.
Table 67. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
AuthenticationProtocol_
Users
ENUM AuthenticationProtocol_UsersTypes.SHA
AuthenticationProtocol_UsersTypes.MD5
AuthenticationProtocol_UsersTypes.T_None
Description Allows you to set the authentication protocol.
Table 68. Parameters for idrac.user_mgr.Users.new
Parameter Name Type Allowed Values
PrivacyProtocol_Users ENUM PrivacyProtocol_UsersTypes.AES
PrivacyProtocol_UsersTypes.DES
PrivacyProtocol_UsersTypes.T_None
Description Allows you to set the privacy protocol for a user.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
28 OpenManage Python SDK API introduction
idrac.user_mgr.Users.new
(
UserName_Users="Abc123",
Password_Users="Xyz123",
Privilege_Users=Privilege_UsersTypes.Administrator,
IpmiLanPrivilege_Users=IpmiLanPrivilege_UsersTypes.Administrator,
IpmiSerialPrivilege_Users=IpmiSerialPrivilege_UsersTypes.Administrator,
Enable_Users=Enable_UsersTypes.Enabled,
SolEnable_Users=SolEnable_UsersTypes.Enabled,
ProtocolEnable_Users=ProtocolEnable_UsersTypes.Disabled,
AuthenticationProtocol_Users=AuthenticationProtocol_UsersTypes.SHA,
PrivacyProtocol_Users=PrivacyProtocol_UsersTypes.AES
)
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: JSON Returns a json indicating whether the user was created successfully or not.
Return Type: JSON.
idrac.user_mgr.Users.remove
idrac.user_mgr.Users.remove
API string/Method: idrac.user_mgr.Users.remove.
Protocol Support: Redfish.
Description: The idrac.user_mgr.Users.remove() returns a JSON to create the user. For more details about the properties and
values, refer to iDRAC Attribute Registry Guide.
Table 69. Parameters for idrac.user_mgr.Users.remove
Parameter Name Type Allowed Values
UserName_Users String User Defined string
Description Allows you to create a user name.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
idrac.user_mgr.Users.remove(UserName_Users="XYZ123")
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: JSON Returns a json indicating whether the user was created successfully or not.
Return Type: JSON.
iDRAC Network Settings Conguration
idrac.cong_mgr.congure_dns
API string/Method: idrac.config_mgr.configure_dns.
Protocol Support: WSMAN, Redfish.
OpenManage Python SDK API introduction 29
Description: The idrac.config_mgr.configure_dns allows you to congure the DNS server.
Table 70. Parameters for idrac.cong_mgr.congure_dns
Parameter Name Type Allowed Values
register_idrac_on_dns Enum DNSRegister_NICTypes.Enabled
DNSRegister_NICTypes.Disabled
Description Allows you to register the iDRAC on DNS.
Table 71. Parameters for idrac.cong_mgr.congure_dns
Parameter Name Type Allowed Values
dns_idrac_name String None
Description Allows you to congure the DNS iDRAC name.
Table 72. Parameters for idrac.cong_mgr.congure_dns
Parameter Name Type Allowed Values
auto_config Enum DNSDomainNameFromDHCP_NICTypes.Enabled
DNSDomainNameFromDHCP_NICTypes.Disabled
Description Alows you to disable the DNS name from the DHCP.
Table 73. Parameters for idrac.cong_mgr.congure_dns
Parameter Name Type Allowed Values
statis_dns String User dened values
Description Congure the DNS server.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
#Configure iDRAC DNS COnfiguration
msg = idrac.config_mgr.configure_dns(register_idrac_on_dns = DNSRegister_NICTypes.Enabled,
dns_idrac_name = None,
auto_config = DNSDomainNameFromDHCP_NICTypes.Disabled, static_dns = None)
print(Prettifyer().prettify_json(msg))
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: JSON Returns a json indicating whether the user was created successfully or not.
Return Type: JSON.
idrac.cong_mgr.congure_ipv4
API string/Method: idrac.config_mgr.configure_ipv4.
Protocol Support: Redfish.
30 OpenManage Python SDK API introduction
Description: The idrac.config_mgr.configure_ipv4() allows you to congure the IPv4 Settings.
Table 74. Parameters for idrac.cong_mgr.congure_ipv4
Parameter Name Type Allowed Values
ip_address String IP Address
Description Enter an IP (IPv4) address or a hostname of the shared folder. The maximum character limit is
64.
Table 75. Parameters for idrac.cong_mgr.congure_ipv4
Parameter Name Type Allowed Values
enable_dhcp Enum DHCPEnable_IPv4Types.Enabled
DHCPEnable_IPv4Types.Disabled
Description Indicates whether the DHCP server is Enabled or Disabled.
Table 76. Parameters for idrac.cong_mgr.congure_ipv4
Parameter Name Type Allowed Values
dns_1 String User dened values
Description Indicates the static DNS server IPv4 address if DHCP is not used to get the DNS address.
Table 77. Parameters for idrac.cong_mgr.congure_ipv4
Parameter Name Type Allowed Values
dns_2 String User dened values
Description Indicates the static alternate DNS server IPv4 address if DHCP is not used to get the DNS
address.
Table 78. Parameters for idrac.cong_mgr.congure_ipv4
Parameter Name Type Allowed Values
dns_from_dhcp Enum DNSFromDHCP_IPv4Types.Enabled
DNSFromDHCP_IPv4Types.Disabled
Description Indicates whether DHCP is used to obtain primary and secondary DNS server addresses from
Table 79. Parameters for idrac.cong_mgr.congure_ipv4
Parameter Name Type Allowed Values
enable_ipv4 Enum Enable_IPv4Types.Enabled
Enable_IPv4Types.Disabled
Description Indicates whether the IPv4 protocol is Enabled or Disabled.
OpenManage Python SDK API introduction 31
Table 80. Parameters for idrac.cong_mgr.congure_ipv4
Parameter Name Type Allowed Values
gateway String User dened values
Description Congure the Default Gateway IP address.
Table 81. Parameters for idrac.cong_mgr.congure_ipv4
Parameter Name Type Allowed Values
net_mask String User dened values
Description Congure the iDRAC subnet mask.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
idrac.config_mgr.configure_ipv4
(
ip_address = "1.1.1.1", enable_dhcp = DHCPEnable_IPv4Types.Enabled,
dns_1 = None, dns_2 = None, dns_from_dhcp = DNSFromDHCP_IPv4Types.Enabled,
enable_ipv4 = Enable_IPv4Types.Enabled, gateway = None, net_mask = None
)
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_static_ipv4
API string/Method: idrac.config_mgr.configure_static_ipv4.
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_static_ipv4() allows you to congure the Static IPv4 Settings.
Table 82. Parameters for idrac.cong_mgr.congure_static_ipv4
Parameter Name Type Allowed Values
ip_address String IP Address
Description Displays the iDRAC NIC IPv4 address.
Table 83. Parameters for idrac.cong_mgr.congure_static_ipv4
Parameter Name Type Allowed Values
dns_1 String User dened values
Description Indicates the static DNS server IPv4 address if DHCP is not used to get the DNS address.
32 OpenManage Python SDK API introduction
Table 84. Parameters for idrac.cong_mgr.congure_static_ipv4
Parameter Name Type Allowed Values
dns_2 String User dened values
Description Indicates the static alternate DNS server IPv4 address if DHCP is not used to get the DNS
address.
Table 85. Parameters for idrac.cong_mgr.congure_static_ipv4
Parameter Name Type Allowed Values
dns_from_dhcp Enum DNSFromDHCP_IPv4Types.Enabled
DNSFromDHCP_IPv4Types.Disabled
Description Indicates whether DHCP is used to obtain primary and secondary DNS server addresses from
the DHCPv4 server.
Table 86. Parameters for idrac.cong_mgr.congure_static_ipv4
Parameter Name Type Allowed Values
gateway String User dened values
Description Congure the iDRAC subnet mask.
Table 87. Parameters for idrac.cong_mgr.congure_static_ipv4
Parameter Name Type Allowed Values
net_mask String User dened values
Description Congure the iDRAC subnet mask.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
#Perform iDRAC Static IPv4 configuration
idrac.config_mgr.configure_static_ipv4
(
ip_address = "1.1.1.1", dns_1 = None, dns_2 = None,
dns_from_dhcp = DNSFromDHCP_IPv4StaticTypes.Enabled, gateway=None,
net_mask=None)
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: Success of Failure.
Return Type: JSON.
idrac.cong_mgr.congure_timezone
API string/Method: idrac.config_mgr.configure_timezone.
Protocol Support: Redfish.
OpenManage Python SDK API introduction 33
Description: The idrac.config_mgr.configure_timezone() allows you to congure the time zone Settings.
Table 88. Parameters for idrac.cong_mgr.congure_timezone
Parameter Name Type Allowed Values
timezone String Timezone
Description Congures the time zone.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
# Configure Timezone
msg = idrac.config_mgr.configure_timezone('US/Pacific')
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: Success or Failure.
Return Type: JSON.
iDRAC Services Conguration API list
idrac.cong_mgr.congure_web_server
API string/Method: idrac.config_mgr.configure_web_server.
Protocol Support: WSMAN, Redfish.
Description: The idrac.config_mgr.configure_web_server() allows you to congure web server Settings.
Table 89. Parameters for idrac.cong_mgr.congure_web_server
Parameter Name Type Allowed Values
enable_web_server Enum Enable_WebServerTypes.Enabled
Enable_WebServerTypes.Disabled
Description Select Enabled to enable the iDRAC web server. This setting is enabled by default.
NOTE: Disabling the web server disables the current web interface session and you
cannot log in to iDRAC web interface or use remote RACADM.
Table 90. Parameters for idrac.cong_mgr.congure_web_server
Parameter Name Type Allowed Values
http_port Number HTTP Port number
Description Enter the port number that iDRAC uses to listen for a browser connection. The default value is
80. The value must be 1–65535.
34 OpenManage Python SDK API introduction
Table 91. Parameters for idrac.cong_mgr.congure_web_server
Parameter Name Type Allowed Values
https_port Number HTTPS Port number
Description Enter the port number that iDRAC uses to listen for a secure browser connection. The default
value is 443. The value must be 1–65535.
Table 92. Parameters for idrac.cong_mgr.congure_web_server
Parameter Name Type Allowed Values
Timeout Number Timeout seconds
Description Enter the time (in seconds) for which a connection is allowed to remain Idle.
The session is canceled when the time-out is reached.
Changes to the timeout setting do not aect the current session.
When you change this time, you must logout and log in again for the new setting to take eect.
Timeout range is 60–10,800 seconds.
The default value is 1800 seconds.
Table 93. Parameters for idrac.cong_mgr.congure_web_server
Parameter Name Type Allowed Values
ssl_encryption Enum SSLEncryptionBitLength_WebServerTypes.Aut
o_Negotiate
SSLEncryptionBitLength_WebServerTypes.
128–bit or higher
SSLEncryptionBitLength_WebServerTypes.
168–bit or higher
SSLEncryptionBitLength_WebServerTypes.
256–bit or higher
Description To specify the level of SSL encryption for providing authenticated and encrypted communication
between clients and servers, select one of the following options:
Auto Negotiate—Enables auto-negotiation of the SSL encryption between client and the
server by using all industry standard encryption algorithms.
NOTE: This option includes weaker SSL encryption algorithm, which reduces the
security.
128–bit or higher—Enables SSL encryption between client and server using the industry
standard 128-bit or higher.
168–bit or higher—Enables SSL encryption between client and server using 168-bit or
higher.
256–bit or higher—Enables SSL encryption between client and server using 256-bit or
higher.
If you select 256–bit or higher an are using Java, the following warning message is displayed:
Selecting a higher SSL encryption enhances the security.
However, the cryptography settings for your virtual machine
environment (JVM, IcedTea)
OpenManage Python SDK API introduction 35
Parameter Name Type Allowed Values
may require installing the Unlimited Strength Java ™ Cryptography
Extension Policy
Files to permit usage of iDRAC plugins such as vConsole with this
higher level of
encryption.
NOTE: Using this level of encryption may have import or export implications. For more
guidance, contact your legal department.
Table 94. Parameters for idrac.cong_mgr.congure_web_server
Parameter Name Type Allowed Values
tls_protocol Enum TLSProtocol_WebServerTypes.TLS 1.0 and
Higher
TLSProtocol_WebServerTypes.TLS 1.1 and
Higher
TLSProtocol_WebServerTypes.TLS 1.2 Only
Description To specify the minimum supported level of TLS protocol, select one of the following options:
TLS 1.0 and Higher
TLS 1.1 and Higher
TLS 1.2 Only
NOTE: TLS 1.1 and Higher is the default option. For better security, Dell recommends
to use TLS 1.2.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
#Configure iDRAC WebServer
idrac.config_mgr.configure_web_server
(
enable_web_server = Enable_WebServerTypes.Enabled,
http_port = 80,
https_port = 443,
timeout = 1800,
ssl_encryption = SSLEncryptionBitLength_WebServerTypes.T_128_Bit_or_higher,
tls_protocol = TLSProtocol_WebServerTypes.TLS_1_1_and_Higher
)
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_snmp
API string/Method: idrac.config_mgr.configure_snmp.
Protocol Support: Redfish.
36 OpenManage Python SDK API introduction
Description: The idrac.config_mgr.configure_snmp() allows you to congure SNMP Settings.
Table 95. Parameters for idrac.cong_mgr.congure_snmp
Parameter Name Type Allowed Values
snmp_enable Enum AgentEnable_SNMPTypes.Disabled
AgentEnable_SNMPTypes.Enabled
Description Allows you to enable to disable the SNMP server.
Table 96. Parameters for idrac.cong_mgr.congure_snmp
Parameter Name Type Allowed Values
community_name String User provided input
Description Enter the SNMP community name. The name can have up to 31 nonblank characters. The default
name is public. iDRAC uses it to validate SNMP queries and gets (received from remote systems
requesting SNMP data Access from iDRAC).
Table 97. Parameters for idrac.cong_mgr.congure_snmp
Parameter Name Type Allowed Values
alert_port Number Alert port number
Description Enter the SNMP port number that must be used for SNMP traps. The default value is 162.
Range is 1-65535.
Table 98. Parameters for idrac.cong_mgr.congure_snmp
Parameter Name Type Allowed Values
discovery_port Number Discovery port number
Description Allows the server to discover the available port.
Table 99. Parameters for idrac.cong_mgr.congure_snmp
Parameter Name Type Allowed Values
snmp_protocol Enum SNMPProtocol_SNMPTypes.All
SNMPProtocol_SNMPTypes.SNMPv3
Description Allows you to select one of the SNMP formats.
OpenManage Python SDK API introduction 37
Table 100. Parameters for idrac.cong_mgr.congure_snmp
Parameter Name Type Allowed Values
trap_format Enum TrapFormat_SNMPTypes.SNMPv1
TrapFormat_SNMPTypes.SNMPv2
TrapFormat_SNMPTypes.SNMPv3
Description Allows you to select one of the SNMP trap formats.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
# Configure SNMP Settings
msg = idrac.config_mgr.configure_snmp
(
snmp_enable = AgentEnable_SNMPTypes.Disabled,
community_name = "test",
snmp_protocol = SNMPProtocol_SNMPTypes.SNMPv3,
alert_port = 161,
discovery_port = 162,
trap_format = TrapFormat_SNMPTypes.SNMPv3
)
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: Success or Failure.
Return Type: JSON.
iDRAC System Settings API list
This section list the available iDRAC system setting APIs.
Syslog
idrac.cong_mgr.enable_syslog
API string/Method: idrac.config_mgr.enable_syslog.
Protocol Support: WSMAN.
Description: The idrac.config_mgr.enable_syslog() enables System Log conguration.
Allows you to enable the System Log conguration.
Return type: JSON
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
38 OpenManage Python SDK API introduction
# Enable Syslog
msg = idrac.config_mgr.enable_syslog()
idrac.cong_mgr.disable_syslog
API string/Method: idrac.config_mgr.disable_syslog.
Protocol Support: WSMAN.
Description: The idrac.config_mgr.disable_syslog() enables System Log conguration.
Allows you to disable the System Log conguration.
Return type: JSON
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
# Disable Syslog
msg = idrac.config_mgr.disable_syslog()
Lockdown
idrac.cong_mgr.enable_system_lockdown
API string/Method: idrac.config_mgr.enable_system_lockdown.
Protocol Support: WSMAN, Redfish.
Description: The idrac.config_mgr.enable_system_lockdown() method allows you to enable the Lockdown operation.
NOTE: Lockdown is supported only on 14th Generation of PowerEdge Servers
Return type: JSON
Example:
# Enable System Lockdown
msg = idrac.config_mgr.enable_system_lockdown()
idrac.cong_mgr.disable_system_lockdown
API string/Method: idrac.config_mgr.disable_system_lockdown.
Protocol Support: WSMAN, Redfish.
Description: The idrac.config_mgr.disable_system_lockdown() performs a Lockdown disable operation.
NOTE: Lockdown is supported only on 14th Generation of PowerEdge Servers.
Return type: JSON
Example:
# Enable System Lockdown
msg = idrac.config_mgr.disable_system_lockdown()
OpenManage Python SDK API introduction 39
CSIOR
idrac.cong_mgr.enable_csior
API string/Method: idrac.config_mgr.enable_csior.
Protocol Support: WSMAN.
Description: The idrac.config_mgr.enable_csior() method allows you to enable the CSIOR option in iDRAC which enables the
collection of system inventory on reboot.
CSIOR is an option in iDRAC which enables collecting of system inventory on reboot. It allows you the CSIOR to perform conguration.
Return type: JSON
idrac.cong_mgr.disable_csior
API string/Method: idrac.config_mgr.disable_csior.
Protocol Support: WSMAN.
Description: The idrac.config_mgr.disable_csior() method allows you to disable the CSIOR option in iDRAC which disables
the collection of system inventory on reboot.
Return type: JSON
idrac.cong_mgr.congure_idrac_alerts
API string/Method: idrac.config_mgr.configure_idrac_alerts.
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_idrac_alerts() allows you to enable or disable the iDRAC alerts Settings.
Table 101. Parameters for idrac.cong_mgr.congure_idrac_alerts
Parameter Name Type Allowed Values
enable_alerts Number
AlertEnable_IPMILanTypes.Enabled
AlertEnable_IPMILanTypes.Disabled
Description Congure the iDRAC alert settings.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
#Alert Configuration
idrac.config_mgr.configure_idrac_alerts
(
enable_alerts=AlertEnable_IPMILanTypes.Disabled
)
apply_status = idrac.config_mgr.apply_changes(reboot=False)
40 OpenManage Python SDK API introduction
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_snmp_trap_destination
API string/Method: idrac.config_mgr.configure_snmp_trap_destination.
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_snmp_trap_destination() allows you to congure the SNMP Trap
Destination Settings.
Table 102. Parameters for idrac.cong_mgr.congure_snmp_trap_destination
Parameter Name Type Allowed Values
destination_number Number Destination number
Description Displays up to 4 IPv4 and IPv6 addresses.
Table 103. Parameters for idrac.cong_mgr.congure_snmp_trap_destination
Parameter Name Type Allowed Values
destination String Destination Address
Description To receive trap alerts, enter the address (IPv4, IPv6, or FQDN). If all destination addresses
display existing IP addresses, you have congured all the existing alert destinations and must
reuse a disabled alert.
NOTE: The destination community must be the same as the iDRAC community.
Table 104. Parameters for idrac.cong_mgr.congure_snmp_trap_destination
Parameter Name Type Allowed Values
snmp_v3_username String User dened string
Description From the drop-down list, select the SNMP v3 user to whom you want to send the SNMP v3
format traps.
Table 105. Parameters for idrac.cong_mgr.congure_snmp_trap_destination
Parameter Name Type Allowed Values
state Enum State_SNMPAlertTypes.Enabled
State_SNMPAlertTypes.Disabled
Description To enable the IP address to receive traps, select this option.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
OpenManage Python SDK API introduction 41
# Configure SNMP Trap Destination Settings
idrac.config_mgr.configure_snmp_trap_destination
(
destination_number = 1,
destination = "1.1.1.1",
snmp_v3_username = None,
state = State_SNMPAlertTypes.Disabled
)
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: None.
Return Type: None.
idrac.cong_mgr.congure_smtp_server_settings
API string/Method: idrac.config_mgr.configure_smtp_server_settings.
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_smtp_server_settings() allows you to congure the SMTP Server
Settings.
Table 106. Parameters for idrac.cong_mgr.congure_smtp_server_settings
Parameter Name Type Allowed Values
smtp_ip_address String SMTP IP Address
Description Enter the IPv4 or IPv6 address of the SMTP server or the FQDN / DNS name. The IP address
entered must be in the dot separated format. For example, 143.166.154.1.
Table 107. Parameters for idrac.cong_mgr.congure_smtp_server_settings
Parameter Name Type Allowed Values
smtp_port Number SMTP Port numer
Description Enter the destination port for email alerts. The default value is 25. Range is 1-65535.
Table 108. Parameters for idrac.cong_mgr.congure_smtp_server_settings
Parameter Name Type Allowed Values
authentication Enum SMTPAuthentication_RemoteHostsTypes.Enabl
ed
SMTPAuthentication_RemoteHostsTypes.Disab
led
Description To specify the user name and password for SMTP mail server authentication, select this option.
42 OpenManage Python SDK API introduction
Table 109. Parameters for idrac.cong_mgr.congure_smtp_server_settings
Parameter Name Type Allowed Values
username String User dened string
Description To connect to the SMTP server, enter the user name.
Table 110. Parameters for idrac.cong_mgr.congure_smtp_server_settings
Parameter Name Type Allowed Values
password String User dened string
Description To connect for NFS or CIFS le system, enter the password. The maximum length is 255
characters.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
idrac.config_mgr.configure_smtp_server_settings
(
smtp_ip_address = "1.1.1.1", smtp_port = 26,
authentication = SMTPAuthentication_RemoteHostsTypes.Enabled,
username = None, password = None
)
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_email_alerts
API string/Method: idrac.config_mgr.configure_email_alerts.
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_email_alerts() allows you to congure the SNMP Trap Destination Settings.
Table 111. Parameters for idrac.cong_mgr.congure_email_alerts
Parameter Name Type Allowed Values
alert_number Number Alert number
Description Congure up to 4 email destinations that can be set to receive alerts.
OpenManage Python SDK API introduction 43
Table 112. Parameters for idrac.cong_mgr.congure_email_alerts
Parameter Name Type Allowed Values
state Enum Enable_EmailAlertTypes.Enabled
Enable_EmailAlertTypes.Disabled
Description Congure to receive the alerts, select this option.
Table 113. Parameters for idrac.cong_mgr.congure_email_alerts
Parameter Name Type Allowed Values
address String Destination email Address
Description Enter the email address that must receive the alerts.
Table 114. Parameters for idrac.cong_mgr.congure_email_alerts
Parameter Name Type Allowed Values
custom_message String Custom Message
Description Allows you to enter a custom email message.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
idrac.config_mgr.configure_email_alerts
(
alert_number = 4, state=Enable_EmailAlertTypes.Enabled,
address = "test@abc.com", custom_message = "test"
)
apply_status = idrac.config_mgr.apply_changes(reboot=False)
Returns: True or False.
Return Type: JSON.
Boot Settings Conguration API list
This section lists the available Boot settings conguration APIs.
idrac.cong_mgr.congure_boot_mode
API string/Method: idrac.config_mgr.configure_boot_mode.
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_boot_mode() allows you to congure the boot Mode.
44 OpenManage Python SDK API introduction
Table 115. Parameters for idrac.cong_mgr.congure_boot_mode
Parameter Name Type Allowed Values
boot_mode Enum Bios - BootModeTypes.BIOS
Uefi - BootModeTypes.Uefi
Description Congures the boot mode to BIOS or UEFI.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
# Configure Boot Mode
msg = idrac.config_mgr.configure_boot_mode(BootModeTypes.Uefi)
apply_status = idrac.config_mgr.apply_changes(reboot=True)
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_onetime_boot_mode
API string/Method: idrac.config_mgr.configure_onetime_boot_mode.
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_onetime_boot_mode() allows you to set the specied device as the rst
device in the boot order for the next boot cycle only. The device must be a device from the bootseq option device list.
Table 116. Parameters for idrac.cong_mgr.congure_onetime_boot_mode
Parameter Name Type Allowed Values
onetime_boot_mode Enum OneTimeBootModeTypes.Disabled
OneTimeBootModeTypes.OneTimeBootSeq
OneTimeBootModeTypes.OneTimeCustomBootSeq
Str
OneTimeBootModeTypes.OneTimeCustomHddSeqS
tr
OneTimeBootModeTypes.OneTimeCustomUefiBoo
tSeqStr
OneTimeBootModeTypes.OneTimeHddSeq
OneTimeBootModeTypes.OneTimeUefiBootSeq
Description Allows you to enable or disable the one time boot mode.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
OpenManage Python SDK API introduction 45
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
idrac.config_mgr.configure_onetime_boot_mode
(
OneTimeBootModeTypes.Disabled
)
apply_status = idrac.config_mgr.apply_changes(reboot=True)
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_boot_sequence
API string/Method: idrac.config_mgr.configure_boot_sequence.
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_boot_sequence() allows you to congure the boot sequence.
Table 117. Parameters for idrac.cong_mgr.congure_boot_sequence
Parameter Name Type Allowed Values
boot_mode Enum BootModeEnum.Bios
BootModeEnum.Uefi
Description Allows you to congure the boot mode to UEFI.
Table 118. Parameters for idrac.cong_mgr.congure_boot_sequence
Parameter Name Type Allowed Values
boot_sequence String Boot devices FQDDs (Comma separated) in the sequential
order for BIOS or UEFI Boot Sequence.
Description User dened boot sequence.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
idrac.config_mgr.configure_boot_sequence
(
boot_mode = BootModeEnum.Uefi,
boot_sequence="device-1, device-2, device-3"
)
apply_status = idrac.config_mgr.apply_changes(reboot=True)
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_nvme_mode
API string/Method: idrac.config_mgr.configure_nvme_mode.
46 OpenManage Python SDK API introduction
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_nvme_mode() allows you to congure the NVME Mode.
Table 119. Parameters for idrac.cong_mgr.congure_nvme_mode
Parameter Name Type Allowed Values
nvme_mode Enum NvmeModeTypes.NonRaid
NvmeModeTypes.Raid
Description Congure the NVME mode. This feature is available in the BIOS settings page.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
idrac.config_mgr.configure_nvme_mode
(
NvmeModeTypes.NonRaid
)
apply_status = idrac.config_mgr.apply_changes(reboot=True)
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_secure_boot_mode
API string/Method: idrac.config_mgr.configure_secure_boot_mode.
Protocol Support: Redfish.
Description: The idrac.config_mgr.configure_secure_boot_mode() allows you to congure the Secure boot Mode.
Table 120. Parameters for idrac.cong_mgr.congure_secure_boot_mode
Parameter Name Type Allowed Values
secure_boot_mode Enum SecureBootModeTypes.AuditMode
SecureBootModeTypes.DeployedMode
SecureBootModeTypes.SetupMode
SecureBootModeTypes.UserMode
Description Congures how the BIOS uses the Secure boot Policy.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
OpenManage Python SDK API introduction 47
idrac.config_mgr.configure_secure_boot_mode
(
SecureBootModeTypes.UserMode
)
apply_status = idrac.config_mgr.apply_changes(reboot=True)
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_boot_to_network_iso
API string/Method: idrac.config_mgr.configure_boot_to_network_iso.
Protocol Support: WSMAN.
Description: The idrac.config_mgr.configure_boot_to_network_iso() allows you to boot the provided ISO le for
operating system deployment.
Table 121. Parameters for idrac.cong_mgr.congure_boot_to_network_iso
Parameter Name Type Allowed Values
sharedetails String User dened network bootable ISO path.
Description Allows you to congure the network boot mode.
Table 122. Parameters for idrac.cong_mgr.congure_boot_to_network_iso
Parameter Name Type
network_iso_image Object
Description Allows you to reboot to a network ISO image.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\',
isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
msg = idrac.config_mgr.boot_to_network_iso(myshare, ' ' )
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.congure_update_from_repo
API string/Method: idrac.config_mgr.configure_update_from_repo.
Protocol Support: WSMAN.
Description: The idrac.config_mgr.configure_update_from_repo() allows you to update the server components rmware.
48 OpenManage Python SDK API introduction
Table 123. Parameters for idrac.cong_mgr.congure_update_from_repo
Parameter Name Type Allowed Values
catalog_path Enum User dened network catalog path.
Description Allows you to select the path of the catalog.
Table 124. Parameters for idrac.cong_mgr.congure_update_from_repo
Parameter Name Type Allowed Values
apply_update Boolean True
Description Allows you to apply the update to the rmware.
Table 125. Parameters for idrac.cong_mgr.congure_update_from_repo
Parameter Name Type Allowed Values
reboot_needed Boolean False
Description Allows you to perform a reboot.
Table 126. Parameters for idrac.cong_mgr.congure_update_from_repo
Parameter Name Type Allowed Values
job_wait Boolean True/False
Description True - Wait for the performed export Server Conguration Prole jobs to complete.
False - Returns only the JobID.
Example:
#Set liason share
myshare = (remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>")
myshare.addcreds(UserCredentials(<USERNAME>, <PASSWORD>))
myshare.printx()
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
idrac.update_mgr.update_from_repo
(
catalog_path = myshare,
apply_update = True,
reboot_needed = False,
job_wait = True
)
apply_status = idrac.config_mgr.apply_changes(reboot=True)
Returns: Success or Failure.
Return Type: JSON.
RAID Conguration API list
This section lists the available RAID conguration APIs.
OpenManage Python SDK API introduction 49
idrac.cong_mgr.RaidHelper.new_virtual_disk
API string/Method: idrac.config_mgr.RaidHelper.new_virtual_disk
Protocol Support: WSMAN, Redfish.
Description: The idrac.config_mgr.RaidHelper.new_virtual_disk() allows you to create a RAID.
Table 127. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
vd_name String User dened
Description Name of the virtual disk.
Table 128. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
Span_depth Number User dened values
Description Depth of the disk span.
Table 129. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
Span_length Number User dened values
Description Length of the disk span.
Table 130. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDTypes ENUM RAIDTypesTypes.RAID_0
RAIDTypesTypes.RAID_1
RAIDTypesTypes.RAID_10
RAIDTypesTypes.RAID_5
RAIDTypesTypes.RAID_50
RAIDTypesTypes.RAID_6
RAIDTypesTypes.RAID_60
Description Type of the RAID array.
Table 131. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDaction ENUM RAIDactionTypes.Create
Description RAID action to be performed.
50 OpenManage Python SDK API introduction
Table 132. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDinitOperation ENUM RAIDinitOperationTypes.Fast
RAIDinitOperationTypes.T_None
Description Initializes a RAID operation.
Table 133. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
DiskCachePolicy ENUM DiskCachePolicyTypes.Default
DiskCachePolicyTypes.Enabled
DiskCachePolicyTypes.Disabled
Description Allows you to set the default disk cache policy.
Table 134. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDdefaultWritePolicy String RAIDdefaultWritePolicyTypes.WriteThrough
RAIDdefaultWritePolicyTypes.WriteBackForc
e
RAIDdefaultWritePolicyTypes.WriteBack
Description Allows you to set the default RAID write policy.
Table 135. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDdefaultReadPolicy ENUM RAIDdefaultReadPolicyTypes.Adaptive
RAIDdefaultReadPolicyTypes.AdaptiveReadAh
ead
RAIDdefaultReadPolicyTypes.NoReadAhead
RAIDdefaultReadPolicyTypes.ReadAhead
Description Allows you to set the default RAID read policy.
Table 136. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDEnhancedAutoImportFore
ignConfig
ENUM RAIDEnhancedAutoImportForeignConfigTypes.
Enabled
RAIDEnhancedAutoImportForeignConfigTypes.
Disabled
Description Allows you to congure the auto import setting.
OpenManage Python SDK API introduction 51
Table 137. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDresetConfig ENUM RAIDresetConfigTypes.T_False
RAIDresetConfigTypes.T_True
Description Allows you to reset the RAID conguration.
Table 138. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDbgiRate Number User dened RAID bgi rate.
Description Allows you to set the speed of the background initialization of the virtual disks.
Table 139. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDprMode ENUM RAIDprModeTypes.Automatic
RAIDprModeTypes.Disabled
RAIDprModeTypes.Manual
Description
Table 140. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDrebuildRate Number User dened RAID rebuild rate.
Description Allows you to set the RAID rebuild speed.
Table 141. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDforeignConfig ENUM RAIDforeignConfigTypes.Clear
RAIDforeignConfigTypes.Ignore
RAIDforeignConfigTypes.Import
Description Allows you to set the external conguration types.
Table 142. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDreconstructRate Number User dened RAID reconstruct rate.
Description Allows you to set the RAID reconstruct rate.
52 OpenManage Python SDK API introduction
Table 143. Parameters for idrac.cong_mgr.RaidHelper.new_virtual_disk
Parameter Name Type Allowed Values
RAIDccMode ENUM RAIDccModeTypes.Normal
RAIDccModeTypes.StopOnError
Description Allows you to congure the CC mode.
Example:
myshare=FileOnShare(remote='<IP OR Hostname>:/<NFS Share Path>/',
mount_point='<mount path>',
isFolder=True,
creds=UserCredentials('<username>', '<password>'))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
pd_filter = '((disk.parent.parent is Controller and disk.parent.parent.FQDD._value ==
"{0}")'.format('RAID.Mezzanine.1-1' )
pd_filter += ' or (disk.parent is Controller and disk.parent.FQDD._value ==
"{0}"))'.format('RAID.Mezzanine.1-1')
msg=idrac.config_mgr.RaidHelper.new_virtual_disk
(
vd_name="newvdomsdk",
SpanDepth=1,
SpanLength=1,
NumberDedicatedHotSpare=1,
NumberGlobalHotSpare=1,
RAIDTypes=RAIDTypesTypes.RAID_0,
RAIDaction=RAIDactionTypes.Create,
RAIDinitOperation=RAIDinitOperationTypes.T_None,
DiskCachePolicy=DiskCachePolicyTypes.Default,
RAIDdefaultWritePolicy=RAIDdefaultWritePolicyTypes.WriteThrough,
RAIDdefaultReadPolicy=RAIDdefaultReadPolicyTypes.NoReadAhead,
StripeSize=64 * 1024,
RAIDEnhancedAutoImportForeignConfig=RAIDEnhancedAutoImportForeignConfigTypes.Enabled,
RAIDresetConfig=RAIDresetConfigTypes.T_False,
RAIDbgiRate="30",
RAIDprMode=RAIDprModeTypes.Automatic,
RAIDrebuildRate="30",
RAIDforeignConfig=RAIDforeignConfigTypes.Clear,
RAIDreconstructRate="30",
RAIDccMode=RAIDccModeTypes.Normal,
PhysicalDiskFilter=pd_filter
)
apply_status = idrac.config_mgr.apply_changes(reboot=True)
Returns: Success or Failure.
Return Type: JSON.
idrac.cong_mgr.RaidHelper.delete_virtual_disk
API string/Method: idrac.config_mgr.RaidHelper.delete_virtual_disk.
Protocol Support: WSMAN, Redfish.
Description: The idrac.config_mgr.RaidHelper.delete_virtual_disk() allows you to create a RAID.
OpenManage Python SDK API introduction 53
Table 144. Parameters for idrac.cong_mgr.RaidHelper.delete_virtual_disk
Parameter Name Type Allowed Values
Name String User dened
Description Name of the virtual disk.
Example:
#Set liason share
myshare = FileOnShare(remote="<IP OR HOSTNAME>:/<NFS-SHARE-PATH>/<FILE-NAME>",
mount_point='Z:\', isFolder=False,
creds=UserCredentials(<USERNAME>, <PASSWORD>))
liason_share_status = idrac.config_mgr.set_liason_share(myshare)
idrac.config_mgr.RaidHelper.delete_virtual_disk
(
Name="Virtual Disk 0"
)
apply_status = idrac.config_mgr.apply_changes(reboot=True)
Returns: None.
Return Type: None.
iDRAC LC Jobs API list
This section lists the available iDRAC LC Jobs APIs.
idrac.job_mgr.get_job_status
API string/Method: idrac.job_mgr.get_job_status.
Protocol Support: WSMAN.
Description: The get_job_status(jobid) method is used to get the job status for the provided job ID.
Return type: String
Example:
# Get Job Status
job_status = idrac.job_mgr.get_job_status(jobid=”jid_1234”)
idrac.job_mgr.delete_job
API string/Method: idrac.job_mgr.delete_job.
Protocol Support: WSMAN.
Description: The delete_job(jobid) method is used to delete a job.
Return type: String
54 OpenManage Python SDK API introduction
Example:
# Delete a job
job_status = idrac.job_mgr.delete_job(jobid=”jid_1234”)
idrac.job_mgr.delete_all_jobs
API string/Method: idrac.job_mgr.delete_all_jobs.
Protocol Support: WSMAN.
Description: The delete_all_jobs() is used to delete all jobs.
Return type: String
Example:
# Delete all jobs
job_status = idrac.job_mgr.delete_all_jobs()
iDRAC LC Status Check API list
This section lists the available iDRAC LC Status Check APIs.
idrac.cong_mgr.LCStatus
API string/Method: idrac.config_mgr.LCStatus.
Protocol Support: Redfish.
Description: The GetRemoteServicesAPIStatus() method is used to obtain the overall remote services API status that includes
host system status. The remote services - (Data Manager) status, and Real Time Status. The overall rolled up status shall be reected in
the Status output parameter.
Return type: String
Example:
# Check the LC status
msg = idrac.config_mgr.LCStatus
idrac.cong_mgr.LCReady
API string/Method: idrac.config_mgr.LCReady.
Protocol Support: WSMAN.
Description: This property provides the information regarding whether the LC is Ready.
Example:
msg = idrac.config_mgr.LCReady
OpenManage Python SDK API introduction 55
Getting Started
The following sections provide information about using OMPSDK to connect, disconnect and communicate with the device.
Topics:
• OMPSDK Infrastructure
• API to setup share
• iDRAC server information
• Administration Tasks
• Server conguration prole overview
• Import export server conguration proles
• Exporting LC Logs
• Server iDRAC settings and conguration
• BIOS Boot settings
• RAID Conguration
• iDRAC LC jobs
• iDRAC LC status check
OMPSDK Infrastructure
This section provides information to initialize to OMPSDK infrastructure.
Initialization of OMPSDK Infrastructure
Run the following command to initialize the OMPSDK infrastructure
sdkinfra
importPath
The above two methods initialize the SDK Infrastructure and loads the device drivers such as iDRAC, CMC, F10 etc present in the path
<python_lib> omdrivers.
Table 145. Drivers list
Method Description
importPath This function reads all the driver les that exist
in the omdrivers directory.
4
56 Getting Started
Table 146. Monitoring API methods
Method Description
get_driver This function creates and returns the driver instance based on the
input details including driver name and on successful connection.
User can specify a particular Driver type [e.g iDRAC, CMC, F10] and
get the driver instance back without looping through all the drivers
present inside omdrivers folder.
Parameters: driver_en Device driver enumerator. For example: iDRAC :
sd.driver_enum.iDRAC, CMC, Compellent.
ipaddr Device IP address or the hostname.
creds Device credentials - bundle of credentials for nding the device
driver.
protopref The preferred protocol to be used if the device supports the
protocol.
pOptions Other protocol specic parameters options to be passed. For
example: SNMP timeout, retry, port.
Returns The driver handle for further conguration or monitoring.
find_driver This function creates and returns the driver instance based on the
input details without any specic driver name and on successful
connection. It queries with the given device by trying each available
driver in omdrivers directory until it nds a appropriate driver. Once
the driver is found, it returns the driver instance.
Parameters: ipaddr Device IP address or the hostname.
creds Device credentials.
protopref The preferred protocol to be used if the device supports the
protocol.
pOptions Other protocol specic parameters options to be passed. For
example: SNMP timeout, retry, port.
Returns The device handle for further conguration or monitoring.
Table 147. Base Driver
Method Description
get_entityjson Returns the complete entity details in JSON format.
Returns True if successful
get_partial_entityjson Return the entity details in JSON format, after applying the
ltration criteria.
Paramaters: en List of Components of the device whose JSON is required
Returns JSON only the components passed in en.
Getting Started 57
Table 148. Base Driver Properties
Method Description
driver_enum Returns an python enumeration of the available drivers in the
system.
ComponentEnum Returns the list of components supported for the device.
ContainmentTree Returns the containment tree of iDRAC.
device_type Returns the type of this device.
API to setup share
The following section provides information about the network share.
Setting up a remote network share
To setup a network le share run the following command:
NOTE: This network share is required to have a share between iDRAC and OMPSDK for conguration.
Pre-requisite - The share needs to be manually mounted.
FileOnShare(remote = '<public_IP>:/Share', mount_point = '/mnt/Share',
isFolder = True, creds)
idrac.config_mgr.set_liason_share(myshare)
FileOnShare methods are: Network le share (NFS), Common internet le system (Windows Style, CIFS), Template (%D, %M, %Y... %ip),
access credentials.
Table 149. Methods of remote path
Command Description
remote path= IP:/Share For network le share (NFS).
remote path= \\\\IP\\Share For Common Internet File System (Windows) (CIFS).
Table 150. Methods of mount point
Command Description
mount_point= /mnt/share For systems running on Linux.
mount_point= Z:\\ For systems running on Windows.
iDRAC server information
The export server prole and import server prole features in iDRAC, that allows IT administrators to do a backup and restore conguration
and rmware for a PowerEdge server. User can import and export from local management station, and from a Network Share via NFS or
CIFS. Using SCP, you can select and import or export component level congurations for BIOS, NIC and RAID.
Administration Tasks
Power Conguration
58 Getting Started
Enables you to remotely perform power control operations on the managed system like: power-on, power-o and power reset.
idrac.config_mgr.power_boot(Power_state): Allows you to power On/O the Server.
iDRAC Reset conguration
disconnect(): Disconnects from device.
reset(): Disconnects and clean up the internal cache.
reconnect(): Disconnects and reconnects to device.
Server conguration prole overview
Server prole import and export is a feature of Dell Lifecycle Controller that enables IT administrators capture and restore BIOS and
rmware information in any system state. This capability provides a solution for hardware or rmware problems in scenarios such as
motherboard replacement.
Import export server conguration proles
The following section informs about import and export server conguration proles.
Export server conguration prole
You can export Server Conguration Prole (SCP) with various components such as iDRAC, BIOS, NIC, RAID together or with one of these
components. You can export SCP from iDRAC to a local or a network shared location. For shared location, make sure that a network share
path is established. While exporting SCP to Network File System (NFS) or (CIFS) share, provide the IP address of the network share where
the exported le needs to reside in the share_name parameter.
idrac.config_mgr.scp_export(): Method used to export the system conguration.
synchronous : When the status is synchronous, the server tracks end to end job completion providing the message ID or job ID, status of
the job and completion of the job.
asynchronous - In asynchronous status the job in the server returns the iob ID and result of the job.
job_wait = True|False. Use the job_mgr APIs to wait for the job to complete or get status.
Export modes are Clone or Replace. Clone mode exported SCP can be imported into another device. If you have to replicate the SCP to
another systems, you should use export in Clone mode. If you are using the replace mode, then it would retire the entire server.
While exporting you can export to a template %ip_%D%M%Y_%H%S.xml.
NOTE: Export features using CIFS shares may fail if there is a mismatch of the SMB version in iDRAC and OS.
Import server conguration prole
You can import the Server Conguration Prole (SCP) which was previously exported for that same server, or group of servers. Importing
SCP is useful in restoring the conguration of the server to the state stored in the prole. You can import SCP from a local or a remote
share to iDRAC. For a remote share, make sure that a network share path and the le name are available.
idrac.config_mgr.scp_import(): Method used to import the system conguration.
Getting Started 59
Exporting LC Logs
iDRAC provides Lifecycle log that contains events related to system, storage devices, network devices, rmware updates, congura tion
changes, license messages, and so on.
idrac.log_mgr.lclog_export: Allows you to export the log from the Lifecycle Controller to a remote share.
Export Complete LC Logs
idrac.log_mgr.complete_lclog_export(): Allows you to export the full log from the Lifecycle Controller to a remote share.
Export TSR Logs
idrac.config_mgr.export_tsr(): Allows you to collect the TSR i.e hardware, OS and App data, then compressed the .zip le save
into the respective remote share path.
Server iDRAC settings and conguration
The following attributes provide the information about the server iDRAC settings and congurations.
• iDRAC User Conguration
• iDRAC Network Conguration
• iDRAC Service Conguration
• iDRAC Systems Settings
iDRAC User Conguration settings
The following API's provides the user credentials settings for the WSMAN.
idrac.user_mgr.User.new(): Creates the user credentials for WSMAN communication.
idrac.user_mgr.Users.remove(): Deletes the user credentials for WSMAN communication.
iDRAC Network Conguration
The following API's provides information about the network conguration API's available.
• iDRAC DNS conguration
• iDRAC DHCP conguration
• iDRAC Static IP conguration
• iDRAC Time Zone conguration
iDRAC DNS conguration
idrac.config_mgr.configure_dns(): Allows you to congure the DNS server.
iDRAC DHCP conguration
idrac.config_mgr.configure_ipv4(): Allows you to congure the DCHP settings.
iDRAC Static IP conguration
idrac.config_mgr.configure_static_ipv4(): Allows you to congure the static IP settings.
60 Getting Started
iDRAC Time Zone conguration
idrac.config_mgr.configure_timezone(): Allows you to congure the time zone settings.
iDRAC Service Conguration
The following API's provide information of various service congurations available.
• SNMP Agent Conguration
• Alert Conguration
• WebServer Conguration
SNMP Agent Conguration
idrac.config_mgr_snmp(): Allows you to congure the SNMP Settings.
Alert Conguration
idrac.config_mgr.configure_idrac_alerts(): Allows you to enable or disable the iDRAC alerts Settings.
Webserver Conguration
idrac.config_mgr.configure_web_server(): Allows you to congure web server Settings.
iDRAC System Settings
The following API's provide information of various systems settings available.
• SysLog Conguration
• LockDown Conguration
• CSIOR Conguration
• SNMP traps Conguration
• SMTP (E-Mail) Conguration
SysLog Conguration
idrac.config_mgr.enable_syslog(): Allows you to enable the system log conguration.
idrac.config_mgr.disable_syslog(): Allows you to disable the system log conguration.
LockDown Conguration
idrac.config_mgr.enable_system_lockdown(): Allows you to enable the lockdown operation.
idrac.config_mgr.disable_system_lockdown(): allows you to disable the lockdown operation.
CSIOR Conguration
idrac.config_mgr.enable_csior(): Allows you to enable the CSIOR option in iDRAC which enables the collection of system
inventory on reboot.
idrac.config_mgr.disable_csior(): Allows you to disable the CSIOR option in iDRAC which disables the collection of system
inventory on reboot.
SNMP traps Conguration
Getting Started 61
idrac.config_mgr.configure_snmp_trap_destination(): Allows you to congure the SNMP trap destination settings.
SMTP (E-Mail) Conguration
idrac.config_mgr.configure_email_alerts(): Allows you to congure to receive the alerts.
BIOS Boot settings
The following section provides the information about the system BIOS Boot settings.
BIOS Boot settings
Using the System BIOS Settings utility, you can set the managed system to boot. The managed system attempts to boot from a bootable
device based on the boot order.
•idrac.config_mgr.configure_boot_mode(): Allows you to congure the boot mode.
•idrac.config_mgr.configure_onetime_boot_mode(): Allows you to et the specied device as the rst device in the boot
order for the next boot cycle.
•idrac.config_mgr.configure_boot_sequence(): Allows you to congure the boot sequence.
•idrac.config_mgr.configure_nvme_mode(): Allows you to congure the NVME mode.
RAID Conguration
Storage Management enables you to perform controller and enclosure functions for all supported RAID and non-RAID controllers and
enclosures. You can congure and manage the controller functions without accessing the BIOS.
Create Virtual Disk
A virtual disk refers to a storage created by a RAID controller from one or more physical disks. Although a virtual disk may be created from
several physical disks, it is viewed by the operating system as a single disk.
idrac.config_mgr.RaidHelper.new_virtual_disk(): To create the virtual disk.
Delete Virtual Disk
Deleting a virtual disk destroys all information including le systems and volumes residing on the virtual disk.
idrac.config_mgr.RaidHelper.delete_virtual_disk(): To delete the virtual disk.
iDRAC LC jobs
The following section provides information about the status of jobs.
Job API's
The following API's provide the information about the job status from LC.
Delete single job
62 Getting Started
idrac.job_mgr.delete_job(): Allows you to delete the job.
Delete all jobs
idrac.job_mgr.delete_all_jobs(): Allows you to delete all jobs.
View job status
idrac.job_mgr.get_job_status(): Allows you to get the job status for the provided job ID.
iDRAC LC status check
The following API provides the information to check the LC status.
idrac.config_mgr.LCStatus(): Provides the Status of LifeCycle Controller.
Getting Started 63

Navigation menu
