PCI DSS Quick Reference Guide

Understanding the Payment Card Industry

Data Security Standard version 2.0

For merchants and entities that store, process or transmit cardholder data

Contents

This Quick Reference Guide to the PCI Data Security Standard is provided by the PCI Security Standards Council

to inform and educate merchants and other entities that process, store or transmit cardholder data. For more

information about the PCI SSC and the standards we manage, please visit www.pcisecuritystandards.org.

The intent of this document is to provide supplemental information, which does not replace or supersede PCI

Security Standards Council standards or their supporting documents. Full details can be found on our Web site.

October 2010

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Introduction

Contents

Introduction: Protecting Cardholder Data with PCISecurityStandards ...........................4

Overview of PCI Requirements ............................................................................................ 6

The PCI Data Security Standard ...........................................................................................................8

PIN Transaction Security Requirements ..........................................................................................10

Payment Application Data Security Standard ...............................................................................10

Security Controls and Processes for PCI DSS Requirements .............................................11

Build and Maintain a Secure Network ..............................................................................................12

Protect Cardholder Data ......................................................................................................................14

Maintain a Vulnerability Management Program ...........................................................................16

Implement Strong Access Control Measures .................................................................................. 18

Regularly Monitor and Test Networks ..............................................................................................20

Maintain an Information Security Policy .........................................................................................23

Compensating Controls for PCI DSS Requirements ......................................................................24

How to Comply with PCI DSS .............................................................................................25

Choosing a Qualied Security Assessor ...........................................................................................26

Choosing an Approved Scanning Vendor ........................................................................................27

Scope of Assessment for Compliance ...............................................................................................28

Using the Self-Assessment Questionnaire (SAQ) ........................................................................... 30

Reporting .................................................................................................................................................31

Web Resources ...................................................................................................................32

About the PCI Security Standards Council ........................................................................33

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Introduction: Protecting Cardholder Data with

PCISecurityStandards

The twentieth century U.S. criminal Willie Sutton was said to rob banks because “that’s where the

money is.” The same motivation in our digital age makes merchants the new target for nancial fraud.

Occasionally lax security by some merchants enables criminals to easily steal and use personal consumer

nancial information from payment card transactions and processing systems.

It’s a serious problem – more than 510 million records with sensitive information have been breached

since January 2005, according to PrivacyRights.org. As a merchant, you are at the center of payment card

transactions so it is imperative that you use standard security procedures and technologies to thwart

theft of cardholder data.

Merchant-based vulnerabilities may appear almost anywhere in the card-processing ecosystem

including point-of-sale devices; personal computers or servers; wireless hotspots or Web shopping

applications; in paper-based storage systems; and unsecured transmission of cardholder data to service

providers. Vulnerabilities may even extend to systems operated by service providers and acquirers, which

are the nancial institutions that initiate and maintain the relationships with merchants that accept

payment cards (see diagram on page 5).

Compliance with the Payment Card Industry (PCI) Data Security Standard (DSS) helps to alleviate these

vulnerabilities and protect cardholder data.

RISKY BEHAVIOR

A survey of businesses in the U.S.

and Europe reveals activities that

may put cardholder data at risk.

81% store payment card

numbers

73% store payment card

expiration dates

71% store payment card

verication codes

57% store customer data from

the payment card magnetic stripe

16% store other personal data

Source: Forrester Consulting: The State of PCI

Compliance (commissioned by RSA/EMC)

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

The intent of this PCI DSS Quick Reference Guide is to help you understand the PCI DSS and to apply it to

your payment card transaction environment.

There are three ongoing steps for adhering to the PCI DSS: Assess — identifying cardholder data, taking

an inventory of your IT assets and business processes for payment card processing, and analyzing them

for vulnerabilities that could expose cardholder data. Remediate — xing vulnerabilities and not

storing cardholder data unless you need it. Report — compiling and submitting required remediation

validation records (if applicable), and submitting compliance reports to the acquiring bank and card

brands you do business with.

PCI DSS follows common sense steps that mirror best security practices. The DSS globally applies to

all entities that store, process or transmit cardholder data. PCI DSS and related security standards are

administered by the PCI Security Standards Council, which was founded by American Express, Discover

Financial Services, JCB International, MasterCard Worldwide and Visa Inc. Participating Organizations

include merchants, payment card issuing banks, processors, developers and other vendors.

PCI DSS COMPLIANCE IS A

CONTINUOUS PROCESS

ASSESS

REMEDIATE

REPORT

POS Merchant AcquirerService Provider

INTERNET

PUBLIC NETWORKS

WIRELESS

INTERNET

PUBLIC NETWORKS

WIRELESS

INTERNET

PUBLIC NETWORKS

WIRELESS

Overview of PCI

Requirements

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Overview of PCI Requirements

PCI security standards are technical and operational requirements set by the PCI Security Standards

Council (PCI SSC) to protect cardholder data. The standards apply to all entities that store, process or

transmit cardholder data – with guidance for software developers and manufacturers of applications

and devices used in those transactions. The Council is responsible for managing the security standards,

while compliance with the PCI set of standards is enforced by the founding members of the Council,

American Express, Discover Financial Services, JCB International, MasterCard Worldwide and Visa Inc.

PAYMENT CARD INDUSTRY SECURITY STANDARDS

Protection of Cardholder Payment Data

MANUFACTURERS

SOFTWARE

DEVELOPERS

MERCHANTS &

SERVICE

PROVIDERS PCI SECURITY

STANDARDS

& COMPLIANCE

PCI PTS

Payment Application

Vendors

Data Security

Standard

PIN Transaction

Security

PCI PA-DSS PCI DSS

Ecosystem of payment devices, applications, infrastructure and users

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

PCI Security Standards Include:

PCI Data Security Standard (DSS)

The PCI DSS applies to all entities that store, process, and/or transmit cardholder data. It covers technical

and operational system components included in or connected to cardholder data. If you are a merchant

who accepts or processes payment cards, you must comply with the PCI DSS.

PIN Transaction Security (PTS) Requirements

The PCI PTS (formerly PCI PED) is a set of security requirements focused on characteristics and

management of devices used in the protection of cardholder PINs and other payment processing related

activities. The requirements are for manufacturers to follow in the design, manufacture and transport

of a device to the entity that implements it. Financial institutions, processors, merchants and service

providers should only use devices or components that are tested and approved by the PCISSC

(www.pcisecuritystandards.org/approved_companies_providers/approved_pin_transaction_security.php).

Payment Application Data Security Standard (PA-DSS)

The PA-DSS is for software developers and integrators of payment applications that store, process

or transmit cardholder data as part of authorization or settlement when these applications are sold,

distributed or licensed to third parties. Most card brands encourage merchants to use payment

applications that are tested and approved by the PCI SSC. Validated applications are listed at:

www.pcisecuritystandards.org/approved_companies_providers/validated_payment_applications.php

The Council monitors new threats to cardholder data and may issue information supplements and other

guidance for compliance. Changes to the PCI Security Standards follow a three-year lifecycle; the newest

(version 2.0) was published in October 2010. For more information on the lifecycle, see:

www.pcisecuritystandards.org/pdfs/pci_lifecycle_for_changes_to_dss_and_padss.pdf

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

The PCI Data Security Standard

PCI DSS is the global data security standard adopted by the payment card brands for all entities that

process, store or transmit cardholder data. It consists of common sense steps that mirror security best

practices.

Goals PCI DSS Requirements

Build and Maintain a Secure

Network

1. Install and maintain a rewall conguration to protect cardholder

data

2. Do not use vendor-supplied defaults for system passwords and other

security parameters

Protect Cardholder Data 3. Protect stored cardholder data

4. Encrypt transmission of cardholder data across open, public networks

Maintain a Vulnerability

Management Program

5. Use and regularly update anti-virus software or programs

6. Develop and maintain secure systems and applications

Implement Strong Access

Control Measures

7. Restrict access to cardholder data by business need to know

8. Assign a unique ID to each person with computer access

9. Restrict physical access to cardholder data

Regularly Monitor and Test

Networks

10. Track and monitor all access to network resources and cardholder data

11. Regularly test security systems and processes

Maintain an Information

Security Policy

12. Maintain a policy that addresses information security for all personnel

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Tools for Assessing Compliance with PCI DSS

The PCI SSC sets the PCI security standards, but each payment card brand has its own program for

compliance, validation levels and enforcement. More information about compliance can be found at

these links:

• AmericanExpress:•www.americanexpress.com/datasecurity

• DiscoverFinancialServices:•www.discovernetwork.com/fraudsecurity/disc.html

• JCBInternational:•www.jcb-global.com/english/pci/index.html

• MasterCardWorldwide:•www.mastercard.com/sdp

• VisaInc:•www.visa.com/cisp

VisaEurope:•www.visaeurope.com/ais

Qualied Assessors. The Council manages programs that will help facilitate the assessment of

compliance with PCI DSS: Qualied Security Assessor (QSA) and Approved Scanning Vendor (ASV). QSAs

are approved by the Council to assess compliance with the PCI DSS. ASVs are approved by the Council

to validate adherence to the PCI DSS scan requirements by performing vulnerability scans of Internet-

facing environments of merchants and service providers. The Council also provides PCI DSS training for

Internal Security Assessors (ISAs). Additional details can be found on our Web site at:

www.pcisecuritystandards.org/approved_companies_providers/index.php

Self-Assessment Questionnaire. The Self-Assessment Questionnaire (SAQ) is a validation tool for

eligible organizations who self-assess their PCI DSS compliance and who are not required to submit

a Report on Compliance (ROC). Dierent SAQs are available for various business environments; more

details can be found on our web site at: www.pcisecuritystandards.org. An organization’s acquiring

nancial institution or payment brand can also determine if you should complete an SAQ.

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

PIN Transaction Security Requirements

These requirements, referred to as PCI PTS (formerly PCI PED), applies to companies which make

devices or components that accept or process personal identication numbers as a part of a PIN based

transaction and for other payment processing related activities. Recognized PTS laboratories validate

adherence to the PTS requirements. Financial institutions, processors, merchants and service providers

should ensure that they are using approved PTS devices or components. Non nancial institutions

should check with their acquiring nancial institution to understand requirements and associated

timeframes for compliance. The PTS requirements cover devices, including the physical and logical

security characteristics of their components, and device management. For details and a list of approved

PTS devices and components see: www.pcisecuritystandards.org/security_standards/ped/index.shtml

Payment Application Data Security Standard

The PA-DSS is a standard for developers of payment applications. Its goal is to help software vendors and

others develop secure commercial payment applications that do not store prohibited data, and ensure

that payment applications support compliance with the PCI DSS. The PA-DSS does not apply to payment

applications developed by merchants in-house; those are covered by the PCI DSS. Merchants and service

providers should ensure that they are using Council-approved payment applications; check with your

acquiring nancial institution to understand requirements and associated timeframes for implementing

approved applications. PA-DSS has 13 requirements: For details and a list of approved Payment

Applications, see: www.pcisecuritystandards.org/security_standards/index.php.

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Security Controls

and Processes for PCI

DSS Requirements

Security Controls and Processes for PCI DSS Requirements

The goal of the PCI Data Security Standard (PCI DSS) is to protect cardholder data wherever it is

processed, stored or transmitted. The security controls and processes required by PCI DSS are vital

for protecting cardholder account data, including the PAN – the primary account number printed on

the front of a payment card. Merchants and any other service providers involved with payment card

processing must never store sensitive authentication data after authorization. This includes sensitive

data that is printed on a card, or stored on a card’s magnetic stripe or chip – and personal identication

numbers entered by the cardholder. This chapter presents the objectives of PCI DSS and related 12

requirements.

CID

(American Express)

Expiration Date Magnetic Stripe

(data on tracks 1 & 2)

PAN

Chip

CAV2/CID/CVC2/CVV2

(Discover, JCB, MasterCard, Visa)

Types of Data on a Payment Card

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Build and Maintain a Secure Network

In the past, theft of nancial records required a criminal to physically enter an organization’s business

site. Now, many payment card transactions (such as debit in the U.S. and “chip and pin” in Europe) use

PIN entry devices and computers connected by networks. By using network security controls, entities can

prevent criminals from virtually accessing payment system networks and stealing cardholder data.

Requirement 1: Install and maintain a rewall and router conguration to protect

cardholder data

Firewalls are devices that control computer trac allowed into and out of an organization’s network, and

into sensitive areas within its internal network. Firewall functionality may also appear in other system

components. Routers are hardware or software that connects two or more networks. All such devices are

in scope for assessment of Requirement 1 if used within the cardholder data environment.

1.1 Establish rewall and router conguration standards that formalize testing whenever

congurations change; that identify all connections to cardholder data (including wireless); that

use various technical settings for each implementation; and stipulate a review of conguration rule

sets at least every six months.

1.2 Build rewall and router congurations that restrict all trac from “untrusted” networks and hosts,

except for protocols necessary for the cardholder data environment.

1.3 Prohibit direct public access between the Internet and any system component in the cardholder

data environment.

1.4 Install personal rewall software on any mobile and/or employee-owned computers with direct

connectivity to the Internet that are used to access the organization’s network.

CONTROLS FOR

NETWORK SECURITY

Firewall

Device that controls the passage

of trac between networks and

within an internal network

Router

Hardware or software that

connects trac between two or

more networks

Illustration / Photo: Wikimedia Commons

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Requirement 2: Do not use vendor-supplied defaults for system passwords and other

security parameters

The easiest way for a hacker to access your internal network is to try default passwords or exploits based

on default system software settings in your payment card infrastructure. Far too often, merchants do

not change default passwords or settings upon deployment. This is akin to leaving your store physically

unlocked when you go home for the night. Default passwords and settings for most network devices

are widely known. This information, combined with hacker tools that show what devices are on your

network can make unauthorized entry a simple task – if you have failed to change the defaults.

2.1 Always change vendor-supplied defaults before installing a system on the network. This includes

wireless devices that are connected to the cardholder data environment or are used to transmit

cardholder data.

2.2 Develop conguration standards for all system components that address all known security

vulnerabilities and are consistent with industry-accepted denitions. Update system conguration

standards as new vulnerability issues are identied.

2.3 Encrypt using strong cryptography all non-console administrative access such as browser/web-

based management tools.

2.4 Shared hosting providers must protect each entity’s hosted environment and cardholder

data (details are in PCI DSS Appendix A: “Additional PCI DSS Requirements for Shared Hosting

Providers.”)

TYPICAL DEFAULT

PASSWORDS THAT MUST

BE CHANGED

[none]

[name of product / vendor]

1234 or 4321

access

admin

anonymous

database

guest

manager

pass

password

root

secret

sysadmin

user

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Protect Cardholder Data

Cardholder data refers to any information printed, processed, transmitted or stored in any form on a

payment card. Entities accepting payment cards are expected to protect cardholder data and to prevent

their unauthorized use – whether the data is printed or stored locally, or transmitted over a public

network to a remote server or service provider.

Requirement 3: Protect stored cardholder data

In general, no cardholder data should ever be stored unless it’s necessary to meet the needs of the

business. Sensitive data on the magnetic stripe or chip must never be stored. If your organization stores

PAN, it is crucial to render it unreadable (see 3.4, and table below for guidelines).

3.1 Limit cardholder data storage and retention time to that required for business, legal, and/or

regulatory purposes, as documented in your data retention policy. Purge unnecessary stored data

at least quarterly.

3.2 Do not store sensitive authentication data after authorization (even if it is encrypted). See

guidelines in table below. Issuers and related entities may store sensitive authentication data if

there is a business justication, and the data is stored securely.

3.3 Mask PAN when displayed; the rst six and last four digits are the maximum number of digits you

may display. Not applicable for authorized people with a legitimate business need to see the full

PAN. Does not supersede stricter requirements in place for displays of cardholder data such as on a

point-of-sale receipt.

3.4 Render PAN unreadable anywhere it is stored – including on portable digital media, backup

media, in logs, and data received from or stored by wireless networks. Technology solutions for

this requirement may include strong one-way hash functions of the entire PAN, truncation, index

tokens with securely stored pads, or strong cryptography. (See PCI DSS Glossary for denition of

strong cryptography.)

ENCRYPTION PRIMER

Cryptography uses a

mathematical formula to render

plaintext data unreadable to

people without special knowledge

(called a “key”). Cryptography is

applied to stored data as well as

data transmitted over a network.

Encryption changes plaintext into

ciphertext.

Decryption changes ciphertext

back into plaintext.

Illustration: Wikimedia Commons

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

3.5 Protect any keys used for encryption of cardholder data from disclosure and misuse.

3.6 Fully document and implement all appropriate key management processes and procedures for

cryptographic keys used for encryption of cardholder data.

Guidelines for Cardholder Data Elements

Data Element Storage Permitted

Render Stored Account

Data Unreadable per

Requirement 3.4

Account Data

Cardholder

Data

Primary Account Number

(PAN) Yes Yes

Cardholder Name Yes No

Service Code Yes No

Expiration Date Yes No

Sensitive

Authentication

Data1

Full Magnetic Stripe

Data2No Cannot store per

Requirement 3.2

CAV2/CVC2/CVV2/CID No Cannot store per

Requirement 3.2

PIN/PIN Block No Cannot store per

Requirement 3.2

1 Sensitive authentication data must not be stored after authorisation (even if encrypted).

2 Full track data from the magnetic stripe, equivalent data on the chip, or elsewhere.

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Requirement 4: Encrypt transmission of cardholder data across open, public networks

Cyber criminals may be able to intercept transmissions of cardholder data over open, public networks

so it is important to prevent their ability to view these data. Encryption is a technology used to render

transmitted data unreadable by any unauthorized person.

4.1 Use strong cryptography and security protocols such as SSL/TLS, SSH or IPSec to safeguard

sensitive cardholder data during transmission over open, public networks (e.g. Internet, wireless

technologies, Global System for Mobile communications [GSM], General Packet Radio Service

[GPRS]). Ensure wireless networks transmitting cardholder data or connected to the cardholder

data environment use industry best practices (e.g., IEEE 802.11i) to implement strong encryption

for authentication and transmission. The use of WEP as a security control is prohibited.

4.2 Never send unprotected PANs by end user messaging technologies.

Maintain a Vulnerability Management Program

Vulnerability management is the process of systematically and continuously nding weaknesses in

an entity’s payment card infrastructure system. This includes security procedures, system design,

implementation, or internal controls that could be exploited to violate system security policy.

Requirement 5: Use and regularly update anti-virus software or programs

Many vulnerabilities and malicious viruses enter the network via users’ e-mail and other online activities.

Anti-virus software must be used on all systems aected by malware to protect systems from current

and evolving malicious software threats.

5.1 Deploy anti-virus software on all systems aected by malicious software (particularly personal

computers and servers).

5.2 Ensure that all anti-virus mechanisms are current, actively running, and generating audit logs.

VULNERABILITY

MANAGEMENT

Create policy governing security

controls according to industry

standard best practices

(e.g., IEEE 802.11i)

Regularly scan systems for

vulnerabilities

Create remediation schedule

based on risk and priority

Pre-test and deploy patches

Rescan to verify compliance

Update security software with

the most current signatures and

technology

Use only software or systems

that were securely developed by

industry standard best practices

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Requirement 6: Develop and maintain secure systems and applications

Security vulnerabilities in systems and applications may allow criminals to access PAN and other

cardholder data. Many of these vulnerabilities are eliminated by installing vendor-provided security

patches, which perform a quick-repair job for a specic piece of programming code. All critical systems

must have the most recently released software patches to prevent exploitation. Entities should apply

patches to less-critical systems as soon as possible, based on a risk-based vulnerability management

program. Secure coding practices for developing applications, change control procedures and other

secure software development practices should always be followed.

6.1 Ensure that all system components and software are protected from known vulnerabilities by

having the latest vendor-supplied security patches installed. Deploy critical patches within a

month of release.

6.2 Establish a process to identify and assign a risk ranking to newly discovered security vulnerabilities.

Risk rankings should be based on industry best practices and guidelines. Ranking vulnerabilities is

a best practice that will become a requirement on July 1, 2012.

6.3 Develop software applications (internal and external, and including web-based administrative

access) in accordance with PCI DSS and based on industry best practices. Incorporate information

security throughout the software development life cycle.

6.4 Follow change control processes and procedures for all changes to system components.

6.5 Develop applications based on secure coding guidelines and review custom application code to

identify coding vulnerabilities. Follow up-to-date industry best practices to identify and manage

vulnerabilities.

6.6 Ensure all public-facing web applications are protected against known attacks, either by

performing code vulnerability reviews at least annually or by installing a web application rewall

in front of public-facing web applications.

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Implement Strong Access Control Measures

Access control allows merchants to permit or deny the use of physical or technical means to access

PAN and other cardholder data. Access must be granted on a business need to know basis. Physical

access control entails the use of locks or restricted access to paper-based cardholder records or system

hardware. Logical access control permits or denies use of PIN entry devices, a wireless network, PCs and

other devices. It also controls access to digital les containing cardholder data.

Requirement 7: Restrict access to cardholder data by business need to know

To ensure critical data can only be accessed by authorized personnel, systems and processes must be in

place to limit access based on need to know and according to job responsibilities. Need to know is when

access rights are granted to only the least amount of data and privileges needed to perform a job.

7.1 Limit access to system components and cardholder data to only those individuals whose job

requires such access.

7.2 Establish an access control system for systems components with multiple users that restricts access

based on a user’s need to know, and is set to “deny all” unless specically allowed.

Requirement 8: Assign a unique ID to each person with computer access

Assigning a unique identication (ID) to each person with access ensures that actions taken on critical

data and systems are performed by, and can be traced to, known and authorized users. Requirements

apply to all accounts, including point of sale accounts, with administrative capabilities and all accounts

with access to stored cardholder data.

8.1 Assign all users a unique user name before allowing them to access system components or

cardholder data.

RESTRICTING ACCESS

IS CRUCIAL!

Restrict Access to Cardholder

Data Environments by employing

access controls such as RBAC (Role

Based Access Control)

Limit access to only those

individuals whose job requires

such access

Formalize an access control policy

that includes a list of who gets

access to specied cardholder data

and systems

Deny all access to anyone who is

not specically allowed to access

cardholder data and systems

Photo: Wikimedia Commons

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

8.2 Employ at least one of these to authenticate all users: something you know, such as a password or

passphrase; something you have, such as a token device or smart card; or something you are, such

as a biometric.

8.3 Implement two-factor authentication for remote access to the network by employees,

administrators, and third parties. For example, use technologies such as remote authentication and

dialin service (RADIUS) with tokens; terminal access controller access control system (TACACS) with

tokens; or other technologies that facilitate two-factor authentication. Using one factor twice (e.g.

using two separate passwords) is not considered two-factor authentication.

8.4 Render all passwords unreadable during storage and transmission, for all system components, by

using strong cryptography.

8.5 Ensure proper user identication and authentication management for non-consumer users and

administrators on all system components.

Requirement 9: Restrict physical access to cardholder data

Any physical access to data or systems that house cardholder data provides the opportunity for

persons to access and/or remove devices, data, systems or hardcopies, and should be appropriately

restricted. “Onsite personnel” are full- and part-time employees, temporary employees, contractors, and

consultants who are physically present on the entity’s premises. “Visitors” are vendors and guests that

enter the facility for a short duration - usually up to one day. “Media” is all paper and electronic media

containing cardholder data.

9.1 Use appropriate facility entry controls to limit and monitor physical access to systems in the

cardholder data environment.

9.2 Develop procedures to easily distinguish between onsite personnel and visitors, especially in areas

where cardholder data is accessible.

GIVE EVERY USER A

UNIQUE ID

Every user with access to the

Cardholder Data Environment

must have a unique ID. This allows

a business to trace every action to

a specic individual.

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

9.3 Ensure all visitors are authorized before entering areas where cardholder data is processed or

maintained; given a physical token that expires and that identies visitors as not onsite personnel;

and are asked to surrender the physical token before leaving the facility or at the date of

expiration.

9.4 Use a visitor log to maintain a physical audit trail of visitor information and activity, including

visitor name and company, and the onsite personnel authorizing physical access. Retain the log for

at least three months unless otherwise restricted by law.

9.5 Store media back-ups in a secure location, preferably o site.

9.6 Physically secure all media.

9.7 Maintain strict control over the internal or external distribution of any kind of media. Classify

media so the sensitivity of the data can be determined.

9.8 Ensure that management approves any and all media moved from a secured area, especially when

media is distributed to individuals.

9.9 Maintain strict control over the storage and accessibility of media.

9.10 Destroy media when it is no longer needed for business or legal reasons.

Regularly Monitor and Test Networks

Physical and wireless networks are the glue connecting all endpoints and servers in the payment

infrastructure. Vulnerabilities in network devices and systems present opportunities for criminals to

gain unauthorized access to payment card applications and cardholder data. To prevent exploitation,

organizations must regularly monitor and test networks to nd and x vulnerabilities.

PHYSICALLY SECURE THE

PAYMENT SYSTEM

Businesses must physically secure

or restrict access to printouts of

cardholder data, to media where

it is stored, and to devices used for

accessing or storing cardholder

data. It’s important to understand

that PCI DSS is about protecting

both electronic data and paper

receipts as well.

Illustration: Wikimedia Commons

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Requirement 10: Track and monitor all access to network resources and cardholder data

Logging mechanisms and the ability to track user activities are critical for eective forensics and

vulnerability management. The presence of logs in all environments allows thorough tracking and

analysis if something goes wrong. Determining the cause of a compromise is very dicult without

system activity logs.

10.1 Establish a process for linking all access to system components to each individual user – especially

access done with administrative privileges.

10.2 Implement automated audit trails for all system components for reconstructing these events:

all individual user accesses to cardholder data; all actions taken by any individual with root

or administrative privileges; access to all audit trails; invalid logical access attempts; use of

identication and authentication mechanisms; initialization of the audit logs; creation and deletion

of system-level objects.

10.3 Record audit trail entries for all system components for each event, including at a minimum: user

identication, type of event, date and time, success or failure indication, origination of event, and

identity or name of aected data, system component or resource.

10.4 Using time synchronization technology, synchronize all critical system clocks and times and

implement controls for acquiring, distributing, and storing time.

10.5 Secure audit trails so they cannot be altered.

10.6 Review logs for all system components related to security functions at least daily.

10.7 Retain audit trail history for at least one year; at least three months of history must be immediately

available for analysis.

MONITOR ALL ACTIVITY

Organizations must track and

monitor all access to cardholder

data and related network

resources – in stores, regional

oces, headquarters, and other

remote access.

Photo: Wikimedia Commons

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Requirement 11: Regularly test security systems and processes

Vulnerabilities are being discovered continually by malicious individuals and researchers, and being

introduced by new software. System components, processes, and custom software should be tested

frequently to ensure security is maintained over time. Testing of security controls is especially important

for any environmental changes such as deploying new software or changing system congurations.

11.1 Test for the presence of wireless access points and detect unauthorized wireless access points on a

quarterly basis. Typical methods are wireless network scans, physical/logical inspections of system

components and infrastructure, network access control (NAC), or wireless IDS/IPS.

11.2 Run internal and external network vulnerability scans at least quarterly and after any signicant

change in the network. After passing a scan for initial PCI DSS compliance, an entity must,

in subsequent years, pass four consecutive quarterly scans as a requirement for compliance.

Quarterly external scans must be performed by an Approved Scanning Vendor (ASV). Scans

conducted after network changes may be performed by internal sta.

11.3 Perform external and internal penetration testing, including network- and application-layer

penetration tests, at least annually and after any signicant infrastructure or application upgrade

or modication.

11.4 Use network intrusion detection systems and/or intrusion prevention systems to monitor all trac

at the perimeter of the cardholder data environment as well as at critical points inside of the

cardholder data environment, and alert personnel to suspected compromises. IDS/IPS engines,

baselines, and signatures must be kept up to date.

11.5 Deploy le integrity monitoring tools to alert personnel to unauthorized modication of critical

system les, conguration les or content les. Congure the software to perform critical le

comparisons at least weekly.

SEVERITY LEVELS

FOR VULNERABILITY

SCANNING

CVSS

Score

Severity

Level

Scan

Results

7.0

through

10.0

High

Severity Fail

4.0

through

6.9

Medium

Severity Fail

0.0

through

3.9

Low

Severity Pass

“To demonstrate compliance,

a scan must not contain high-

level vulnerabilities in any

component in the cardholder

data environment. Generally, to

be considered compliant, none of

those components may contain

any vulnerability that has been

assigned a Common Vulnerability

Scoring System (CVSS) base score

equal to or higher than 4.0.”

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Maintain an Information Security Policy

A strong security policy sets the tone for security aecting an organization’s entire company, and it

informs employees of their expected duties related to security. All employees should be aware of the

sensitivity of cardholder data and their responsibilities for protecting it.

Requirement 12: Maintain a policy that addresses information security for all personnel

12.1 Establish, publish, maintain, and disseminate a security policy that addresses all PCI DSS

requirements, includes an annual process for identifying vulnerabilities and formally assessing

risks, and includes a review at least once a year and when the environment changes.

12.2 Develop daily operational security procedures that are consistent with requirements in PCI DSS.

12.3 Develop usage policies for critical technologies to dene their proper use by all personnel. These

include remote access, wireless, removable electronic media, laptops, tablets, handheld devices,

email and Internet.

12.4 Ensure that the security policy and procedures clearly dene information security responsibilities

for all personnel.

12.5 Assign to an individual or team information security responsibilities dened by 12.5 subsections.

12.6 Implement a formal security awareness program to make all personnel aware of the importance of

cardholder data security.

12.7 Screen potential personnel prior to hire to minimize the risk of attacks from internal sources.

Example screening includes previous employment history, criminal record, credit history, and

reference checks.

“PCI DSS represents the

best available framework to

guide better protection of

cardholder data. It also presents

an opportunity to leverage

cardholder data security achieved

through PCI DSS compliance

for better protection of other

sensitive business data – and to

address compliance with other

standards and regulations.”

AberdeenGroup

IT Industry Analyst

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

12.8 If cardholder data is shared with service providers, maintain policies and procedures to formally

identify service provider responsibilities for securing cardholder data, and monitor service

providers’ PCI DSS compliance status at least annually.

12.9 Implement an incident response plan. Be prepared to respond immediately to a system breach.

Compensating Controls for PCI DSS Requirements

Compensating controls may be considered for most PCI DSS requirements when an entity cannot meet

a requirement explicitly as stated, due to legitimate technical or documented business constraints,

but has suciently mitigated the risk associated with the requirement through implementation of

compensating controls. In order for a compensating control to be considered valid, it must be reviewed

by a qualied assessor. The eectiveness of a compensating control is dependent on the specics

of the environment in which the control is implemented, the surrounding security controls, and the

conguration of the control. Entities should be aware that a particular compensating control will not be

eective in all environments. See PCI DSS, Appendices B and C for details.

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

How to Comply with PCI DSS

Merchants and other entities that store, process and/or transmit cardholder data must comply with

PCI DSS. While the Council is responsible for managing the data security standards, each payment card

brand maintains its own separate compliance enforcement programs. Each payment card brand has

dened specic requirements for compliance validation and reporting, such as provisions for performing

self-assessments and when to engage a QSA.

Depending on an entity’s classication or risk level (determined by the individual payment card brands),

processes for validating compliance and reporting to acquiring nancial institutions usually follow this

track:

1. PCI DSS Scoping – determine what system components are governed by PCI DSS

2. Assessing – examine the compliance of system components in scope

3. Compensating Controls – assessor validates alternative control technologies/processes

4. Reporting – assessor and/or entity submits required documentation

5. Clarications – assessor and/or entity claries/updates report statements (if applicable) upon

request of the acquiring bank or payment card brand

How to Comply With

PCI DSS

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Specic questions about compliance validation levels should be directed to your acquiring nancial

institution or payment card brand. Only the acquiring nancial institution can assign a validation level to

merchants. Links to card brand compliance programs include:

• AmericanExpress:•www.americanexpress.com/datasecurity

• DiscoverFinancialServices:•www.discovernetwork.com/fraudsecurity/disc.html

• JCBInternational:•www.jcb-global.com/english/pci/index.html

• MasterCardWorldwide:•www.mastercard.com/sdp

• VisaInc:•www.visa.com/cisp

VisaEurope:•www.visaeurope.com/ais

Choosing a Qualied Security Assessor

A Qualied Security Assessor (QSA) is a data security rm that has been trained and is certied by the PCI

Security Standards Council to perform on-site security assessments for verication of compliance with

PCI DSS. The QSA will:

• Verifyalltechnicalinformationgivenbymerchantorserviceprovider

• Useindependentjudgmenttoconrmthestandardhasbeenmet

• Providesupportandguidanceduringthecomplianceprocess

• Beonsiteforthevalidationoftheassessmentordurationasrequired

• ReviewtheworkproductthatsupportsthePCIDSSRequirementsandSecurityAssessment

Procedures

• EnsureadherencetothePCIDSSSecurityAssessmentProcedures

• Validatethescopeoftheassessment

• Selectsystemsandsystemcomponentswheresamplingisemployed

• Evaluatecompensatingcontrols

• Producethenalreport

PREPARING FOR A PCI

DSS ASSESSMENT

Gather Documentation: Security

policies, change control records,

operational procedures, network

diagrams, PCI DSS letters and

notications

Schedule Resources: Ensure

participation of a project manager

and key people from IT, security

applications, business operations,

human resources and legal

Describe the Environment:

Organize information about the

cardholder data environment,

including cardholder data ows

and locations of cardholder data

repositories

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

The QSA you select should have solid understanding of your business and have experience in assessing

the security of similar organizations. That knowledge helps the QSA to understand business sector-

specic nuances of securing cardholder data under PCI DSS. Also, look for a good t with your company’s

culture. The assessment will conclude whether you are compliant or not – but the QSA will also work

with your organization to help you understand how to achieve and maintain compliance. Many QSAs

also can provide additional security-related services such as ongoing vulnerability assessment and

remediation. A list of QSAs is available at www.pcisecuritystandards.org/approved_companies_

providers/qsa_companies.php.

Choosing an Approved Scanning Vendor

An Approved Scanning Vendor (ASV) is a data security rm using a scanning solution to determine

whether or not the customer is compliant with the PCI DSS external vulnerability scanning requirement.

ASVs have been trained and are qualied by the PCI Security Standards Council to perform external

network and system scans as required by the PCI DSS. An ASV may use its own software or an approved

commercial or open source solution to validate compliance. ASV solutions must be non-disruptive

to customers’ systems and data – they must never cause a system reboot, or interfere with or change

domain name server (DNS) routing, switching, or address resolution. Root-kits or other software should

not be installed unless part of the solution and pre-approved by the customer. Tests not permitted by

the ASV solution include denial of service, buer overow, brute force attack resulting in a password

lockout, or excessive usage of available communication bandwidth.

An ASV scanning solution includes the scanning tool(s), the associated scanning report, and the

process for exchanging information between the scanning vendor and the customer. ASVs may submit

compliance reports to the acquiring institution on behalf of a merchant or service provider.

A list of ASVs is available at www.pcisecuritystandards.org/approved_companies_providers/approved_

scanning_vendors.php.

ISA PROGRAM

The PCI SSC Internal Security

Assessor (ISA) Program provides

an opportunity for eligible internal

security assessment professionals

of qualifying organizations to

receive PCI DSS training and

certication that will improve

the organization’s understanding

of the PCI DSS, facilitate the

organization’s interactions with

QSAs, enhance the quality,

reliability, and consistency of the

organization’s internal PCI DSS

self-assessments, and support the

consistent and proper application

of PCI DSS measures and controls.

Please see the PCI SSC web

site for details – www.

pcisecuritystandards.org/

approved_companies_providers/

internal_security_assessors.php

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Scope of Assessment for Compliance

The rst step of a PCI DSS compliance eort is to accurately determine the scope of the environment.

The scoping process includes identifying all system components that are located within or connected to

the cardholder data environment. The cardholder data environment is comprised of people, processes,

and technology that handle cardholder data or sensitive authentication data. System components

include network devices (both wired and wireless), servers and applications. Virtualization components,

such as virtual machines, virtual switches/routers, virtual appliances, virtual applications/desktops, and

hypervisors, are also considered system components within PCI DSS.

Scoping must occur at least annually and prior to the annual assessment. Merchants and other entities

must identify all locations and ows of cardholder data to ensure all applicable system components are

included in scope for PCI DSS. Entities should conrm the accuracy and appropriateness of PCI DSS scope

by performing these steps:

• Theassessedentityidentiesanddocumentstheexistenceofallcardholderdataintheir

environment, to verify that no cardholder data exists outside of the currently dened cardholder

data environment (CDE).

• Oncealllocationsofcardholderdataareidentiedanddocumented,theentityusestheresultsto

verify that PCI DSS scope is appropriate (for example, the results may be a diagram or an inventory of

cardholder data locations).

• TheentityconsidersanycardholderdatafoundtobeinscopeofthePCIDSSassessmentandpartof

the CDE unless such data is deleted or migrated/consolidated into the currently dened CDE.

• TheentityretainsdocumentationthatshowshowPCIDSSscopewasconrmedandtheresults,for

assessor review and/or for reference during the next annual PCI SCC scope conrmation activity.

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Network Segmentation

Scope can be reduced with the use of segmentation, which isolates the cardholder data environment

from the remainder of an entity’s network. Reduction of scope can lower the cost of the PCI DSS

assessment, lower the cost and diculty of implementing and maintaining PCI DSS controls, and

reduce risk for the entity. For more information on scoping, see PCI DSS Appendix D: Segmentation and

Sampling of Business Facilities/System Components.

Sampling of Business Facilities and System Components

The assessor may independently select representative examples of business facilities and system

components to assess PCI DSS requirements. This practice, called sampling, is not required by PCI

DSS. Sampling must follow rules and processes dened in PCI DSS. Sampling does not reduce scope

of the cardholder data environment or the applicability of PCI DSS requirements. If sampling is used,

each sample must be assessed against all applicable PCI DSS requirements. Sampling of the PCI DSS

requirements themselves is not permitted. For more information on sampling, see PCI DSS Appendix D:

Segmentation and Sampling of Business Facilities/System Components.

Compensating Controls

On an annual basis, any compensating controls must be documented, reviewed, and validated by the

assessor and included with the Report on Compliance. For more information on compensating controls,

see PCI DSS Appendix B: Compensating Controls and Appendix C: Compensating Controls Worksheet.

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Using the Self-Assessment Questionnaire (SAQ)

The SAQ is a validation tool for eligible merchants and service providers who self-assess their PCI DSS

compliance and who are not required to submit a Report on Compliance (ROC). The SAQ includes

a series of yes-or-no questions for compliance. If an answer is no, the organization must state the

future remediation date and associated actions. In order to align more closely with merchants and

their compliance validation process, the SAQs provide exibility based on the complexity of particular

merchant environments (see chart below). The PCI DSS Self-Assessment Questionnaire Guidelines and

Instructions document provides more details on each SAQ type (see www.pcisecuritystandards.org).

SAQ Description

A Card-not-present (e-commerce or mail/telephone-order) merchants, all cardholder data

functions outsourced. This would never apply to face-to-face merchants.

B Imprint-only merchants with no electronic cardholder data storage, or standalone, dial-

out terminal merchants with no electronic cardholder data storage

C-VT Merchants using only web-based virtual terminals, no electronic cardholder data

storage

C Merchants with payment application systems connected to the Internet, no electronic

cardholder data storage

D All other merchants not included in descriptions for SAQ types A through C above, and

all service providers dened by a payment card brand as eligible to complete an SAQ

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Web Resources

Reporting

Reports are the ocial mechanism by which merchants and other entities verify compliance with PCI

DSS to their respective acquiring nancial institutions or payment card brand. Depending on payment

card brand requirements, merchants and service providers may need to submit an SAQ or annual

attestations of compliance for on-site assessments. Quarterly submission of a report for network

scanning may also be required. Finally, individual payment card brands may require submission of other

documentation; see their web sites for more information (URLs listed above).

Information Contained in PCI DSS Report on Compliance

The template for an entity’s annual Report on Compliance includes the following:

1. Executive Summary (description of entity’s payment card business; high level network diagram)

2. Description of Scope of Work and Approach Taken (description of how the assessment was made,

environment, network segmentation used, details for each sample set selected and tested, wholly-

owned or international entities requiring compliance with PCI DSS, wireless networks or applications

that could impact security of cardholder data, version of PCI DSS used to conduct the assessment)

3. Details about Reviewed Environment (diagram of each network, description of cardholder data

environment, list of all hardware and software in the CDE, service providers used, third party

payment applications, individuals interviewed, documentation reviewed, details for reviews of

managed service providers)

4. Contact Information and Report Date

5. Quarterly Scan Results (summary of four most recent ASV scan results)

6. Findings and Observations (detailed ndings on each requirement and sub-requirement, including

explanations of all N/A responses and validation of all compensating controls)

COMPLIANCE PROGRAM

Assess

Assess your network and IT

resources for vulnerabilities. You

should constantly monitor access

and usage of cardholder data. Log

data must be available for analysis

Remediate

You must x vulnerabilities that

threaten unauthorized access to

cardholder data

Report

Report compliance and present

evidence that data protection

controls are in place

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

Web Resources

PCI Security Standards Council Web site, including Frequently Asked Questions (FAQs): www.pcisecuritystandards.org

Membership Information

www.pcisecuritystandards.org/get_involved/join.php

Webinars

www.pcisecuritystandards.org/news_events/events.shtml

Training (for assessors)

QSAs: www.pcisecuritystandards.org/training/qsa_training.php

PA-DSS: www.pcisecuritystandards.org/training/pa-dss_training.php

PCI SSC approved applications and devices

PIN Transaction Security (PTS) Devices: www.pcisecuritystandards.org/approved_companies_providers/approved_pin_transaction_security.php

Payment Applications: www.pcisecuritystandards.org/approved_companies_providers/validated_payment_applications.php

PCI Data Security Standard (PCI DSS)

The Standard: https://www.pcisecuritystandards.org/documents/pci_dss_v2.pdf

Supporting Documents: https://www.pcisecuritystandards.org/security_standards/documents.php

Approved Assessors and Scanning Vendors: https://www.pcisecuritystandards.org/approved_companies_providers/index.php

Navigating the Standard: https://www.pcisecuritystandards.org/documents/navigating_dss_v20.pdf

Self-Assessment Questionnaire: https://www.pcisecuritystandards.org/merchants/self_assessment_form.php

Glossary: https://www.pcisecuritystandards.org/security_standards/glossary.php

Approved QSAs: https://www.pcisecuritystandards.org/approved_companies_providers/qualied_security_assessors.php

Approved ASVs: https://www.pcisecuritystandards.org/approved_companies_providers/approved_scanning_vendors.php

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

About the PCI

Security Standards

Council

About the PCI Security Standards Council

The PCI Security Standards Council (PCI SSC) is a global open body formed to develop, enhance,

disseminate and assist with the understanding of security standards for payment account security. The

Council maintains, evolves, and promotes the Payment Card Industry security standards. It also provides

critical tools needed for implementation of the standards such as assessment and scanning guidelines, a

self-assessment questionnaire, training and education, and product certication programs.

The PCI SSC founding members, American Express, Discover Financial Services, JCB International,

MasterCard Worldwide, and Visa Inc., have agreed to incorporate the PCI Data Security Standard as

part of the technical requirements for each of their data security compliance programs. Each founding

member also recognizes the Qualied Security Assessors and Approved Scanning Vendors qualied by

the PCI SSC to assess compliance with the PCI DSS.

The PCI SSC’s founding member card brands share equally in the Council’s governance and operations.

Other industry stakeholders participate in reviewing proposed additions or modications to the

standards, including merchants, payment card issuing banks, processors, hardware and software

developers, and other vendors.

PCI SSC FOUNDERS

PARTICIPATING

ORGANIZATIONS

Merchants, Banks, Processors,

Hardware and Software

Developers and Point-of-Sale

Vendors

This Guide provides supplemental information that does not replace or supersede PCI SSC Security Standards or their supporting documents.

PCI Data Security Standard

The PCI DSS is a set of comprehensive requirements for enhancing payment account data security. It represents common sense steps that mirror

security best practices. Learn more about its requirements, security controls and processes, and steps to assess compliance inside this PCI DSS

Quick Reference Guide.

Goals PCI DSS Requirements

Build and Maintain a Secure Network 1. Install and maintain a rewall conguration to protect cardholder data

2. Do not use vendor-supplied defaults for system passwords and other security parameters

Protect Cardholder Data 3. Protect stored cardholder data

4. Encrypt transmission of cardholder data across open, public networks

Maintain a Vulnerability Management

Program

5. Use and regularly update anti-virus software or programs

6. Develop and maintain secure systems and applications

Implement Strong Access Control

Measures

7. Restrict access to cardholder data by business need to know

8. Assign a unique ID to each person with computer access

9. Restrict physical access to cardholder data

Regularly Monitor and Test Networks 10. Track and monitor all access to network resources and cardholder data

11. Regularly test security systems and processes

Maintain an Information Security Policy 12. Maintain a policy that addresses information security for all personnel

PCI DSS V2.0 Quick Reference Guide

PCI%20DSS%20v2.0_Quick%20Reference%20Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
