PD4600
User Manual: PD4600
Open the PDF directly: View PDF
.
Page Count: 1
Aspect Ratio 16:9
Screen size ( H x V ) 1007 x 567.4mm
Resolution 852 x 480
Cell Pitch ( H x V ) 1.182 x 1.182mm
Displayable Colors 16.77 million Colors
Peak Bright 700 cd/m2
Contrast Ratio 800:1
Color Temperature Over 8000 oK
View angle Over 160o
Color(R, G, B) 16.7M(256 x 256 x 256)
Cell Type RGB Stripe(BM)
Video PC/DTV Signal Up to 1024 x 768, 85 Hz
Video System PAL/SECAM/NTSC
Video Signal (Component) 480p, 525i, 625i, 720p, 1080i
Function Key POWER, INPUT, MENU, UP/DOWN, LEFT/RIGHT
Specially Function Zoom, Freeze, PIP(with PC mode), Wide, WOW(surrounding sound)
OSD Language English / Chinese (simplified) / Chinese (Traditional)
PC Input D-SUB 15pin
DVI Input 30pins DVI connector
Audio System AMP. : 10Wx2 (Lever Terminal)
Add-on Speaker Box 10W +10W (Optional)
RS-232C D-SUB 9pin
Component Video In RCA x 3 (Y, Cb/Pb, Cr/Pr)
Audio Input 1 RCA x 2 (R and L) for Component Video and PC
S-Video In Mini-Din 4pin for S-VHS Video In
Composite Video In RCA x 1 for Composite Video in
Audio Input 2 RCA x 2 (R and L) for Composite Video and S-VHS video
Composite Video Out BNC x 1
Tuner
FCC(B), UL, C-UL, CE, TUV
1310 x 850 x 330 mm
40.0KG (Including stand) / 47.7KG (W/O Stand)
AC Input 90~110Vac / 216 ~ 264Vac, 50Hz / 60Hz
One year limited warranty on parts, labor
CTX INTERNATIONAL, INC.
16720 E. Gale Ave.
City of Industry, CA 91745
Website: www.ctxintl.com
Tel: 626.709.1000 Fax: 626.855.7481
© 2003 CTX International Inc. All rights reserved. Specifications are subject to change without notice.
> PD4600 Specifications >
PDP
Signal
Control
Packing Dimension (W x H x D)
Net Weight / Gross Weight
Warranty
I/O Ports
Option Video I/O Board
Safety Regulation
Dimemsion (W x H x D)
Model : PD4600
46" Plasma Dis
p
la
y
