Light/Medium - Stain, Sealer,
Latex Paint, Oil-based Paint, Enamels
Medium/Heavy - Latex Paint, Oil-based
Paint, Some Latex Primers, All Oil-based
Primers, Barn & Fence Paints
Extra Heavy -
Block Filler, Specialty Coatings
TIP
SIZE
COATING MATERIAL
WHAT TIP SIZE SHOULD I USE?
HOW TO DETERMINE TIP SIZE:
Light -
Stain, Sealer, Polyurethane, Varnish
.011"
.013"
.015"
.017"
.019"
.021"
Medium -
Latex Paint, Oil-based Paint,
Floor Enamels
Heavy - Some Latex Primers,
All Oil-based Primers,
Some Elastomerics
Light
Light
Light
Light
Light
Light/Medium
Light/Medium
Light/Medium
Light/Medium
Light/Medium
Medium
Medium
Medium
Medium
Medium
Medium/Heavy
Medium/Heavy
Medium/Heavy
Medium/Heavy
Medium/Heavy
Heavy
Heavy
Heavy
Heavy
Heavy
Extra Heavy
SL107001AV 4/03
Double first
number for
minimum
height of
spray pattern
(2 x 5 = 10” height)
Last two
numbers indicate
orifice size in
thousandths of
an inch
(515 = .015” orifice)
5 5 15 15
Spray
Pattern
Orifice
