PANAFAX
UF-590
A Multi-Function
Document Centre on
Your Desktop
High Performance Document Processing
Features
Compatibility ITU-T Group 3, ECM
Modem Speed 33,600 - 2,400 bps with automatic fallback
Coding Scheme MH/MR/MMR
Transmission Speed Approx. 3 seconds / page*5
Document Size Max. 257 mm x 2000 mm (with operator's assistance)
Min. 148 mm x 128 mm
Effective Scanning Width 208 mm
Automatic Document Feeder 30 sheets
Document Thickness Single sheet: 0.06 - 0.15 mm
Multi-sheet: 0.06 - 0.10 mm
Scanning Resolution (Fax) Standard: 8 dots/mm x 3.85 lines/mm
(203 dots/inch x 98 lines/inch)
Fine: 8 dots/mm x 7.7 lines/mm
(203 dots/inch x 196 lines/inch)
Super Fine: 8 dots/mm x 15.4 lines/mm
(203 dots/inch x 391 lines/inch)
16 dots/mm x 15.4 lines/mm*6
(406 dots/inch x 391 lines/inch)
Scanning Speed Approx. 3 second/page (A4, Standard mode)*7
Recording Method Laser printing on plain paper
Recording Speed*4Approx. 6 pages per minute (A4 size)
Recording Paper Size A4 / Letter / Legal, cut-sheet on plain paper
Effective Recording Width 202 mm (A4)
Recording Paper Capacity 250 sheets (using 75 g/m2paper)
With optional cassette: Approx. 500 sheets max.total
Recording Resolution Fax / Copy 406 dots/inch x 391 dots/inch
Printer 600 dots/inch x 600 dots/inch
Image Memory Capacity Approx. 120 pages*8
Optional Memory Card Base Memory plus approx. 160/320/640 pages*8
Printer / Scanner Interface Bi-directional Parallel (IEEE1284)
Scanner Driver TWAIN
Scanning Resolution (PC) 400 dots/inch x 400 dots/inch*6
Power Requirements 198 - 255 V AC 47 - 63 Hz Single phase
Power Consumption Standby (Sleep Mode : On): 2.4 Wh
Max.: Approx. 490 W
Dimensions (W x D x H) 370 mm x 474 mm x 250 mm*9
Weight 9.0 kg*9(Excluding consumable supplies and optional equipment)
Consumable
• All-In-One Toner Cartridge
(toner/developer/drum)
.(UG-3350) 7,500-page Toner*3
Specifications
Dimensions
UF-590 Control Panel
Panasonic UK Ltd
Willoughby Road, Bracknell RG12 8FP
Telephone: 08700 100464 Fax: 08700 102465
Website: www.panasonic.co.uk/fax
Email: panasonic@chaseresponse.com
Plain Paper Laser Fax
*1Panafax proprietary features work only with selected Panafax machines.
*2Not available in some countries.
*3 Based on ITU-T Image No. 1 scanned in multiple copy mode. Yield may vary according to
operating conditions and environment where the machine is installed.
*4 In multiple copy mode excluding the first copy.
*5 Transmission time applies to memory transmission of text data using only ITU-T Image No. 1
between the same models at maximum modem speed. Transmission time may vary in actual
usage. Usually public telephone lines can only support communications speeds of 28.8 kbps or
lower. Via PBX, transmission speed may fall back to a lower speed.
*6 Interpolated resolution (Optical Resolution: 8 dots/mm x 15.4 lines/mm)
*7 Scanning speed applies to the feeding process from the top to the end of a single page test chart.
The time for the feeding process does not include the time that it takes for the top edge of the
page to reach the scanning point and page ejection. Time for entire storing process is not
applied.
*8 Based on ITU-T Image No. 1 scanned in Standard mode.
*9 Dimensions and weight are approximate.
Super G3 is the classification given to a type of facsimile that conforms to the 33.6 kbps transmission
method standardised in accordance with the ITU-T V.34 recommendation.
Windows and Windows NT are registered trademarks of Microsoft Corporation.
ENERGY STAR is a U.S. registered mark.
All other brand or product names are the property of their respective holders.
Design and specifications are subject to change without notice.
ISO 9001 Quality Management System
Every aspect of Matsushita Graphic Communication Systems, Inc.
(MGCS)’s office information equipment business processes, from
manufacturing to marketing, conforms to ISO (International Organisation
for Standardisation) 9001 quality management system standard.
Design, development, manufacture, installation, repair and maintenance of
office information equipment, their associated devices and consumables.
• Auto Dialler
One-touch: up to 32 stations
Abbreviated: up to 100 stations
Digit of Telephone number
(up to 36 digits)
• Programme keys
(up to 4 Programmes)
• Multi-Tasking Operation
• Directory Search Dialling
• Directory Sheet Print
• Intelligent Redial
• Chain Dialling
• Distinctive Ring Detector (DRD)*2
• Quick Memory Transmission
• Multi-station Transmission
(up to 144 stations)
• Automatic Memory Retransmission
• Deferred Transmission
• Deferred Multi-station Transmission
• Priority Direct Transmission
•
Edit File Mode with View Mode
• Automatic Cover Sheet
• Receive to Memory
• Substitute Reception
• Selective Reception
• Number of memory job files
(Max. 10 files)
• Fax Forward
•
Polling / Multi-station Polling
• Deferred Polling/Deferred Multi-
Station Polling
• Memory Polling Transmission (1 file)
• Confidential Mail Box *1
• Password Transmission/Reception *1
• ITU-T Sub-address Transmission
• Panasonic Super Smoothing
(Fax/Copy)
• 64-Level Halftone
• Automatic/Fixed Reduction
• Overlapping Print
• Collation Stack
• Verification Stamp
• Communication Journal with image
data
• Header/Total Page Print
• Transaction Journal
with view mode
• Fax Access Code(Fax Lock)
• PIN Code Access*2
• Fax/Tel Auto Switch
• External TAM Interface
• Remote Reception*2
• Multi-Purpose LCD Display (20 x 2
lines)
• Multiple Copy with Sorting
(up to 99 copies)
• Reduction Copy
• Energy Saver
• Remote Diagnostic*2
• Check & Call Function*2
-----------------------------------
• Printer Interface
• Scanner Interface
• Class 2 Modem Interface
• PC-Fax software
• Document Manager
• Document Viewer with Annotation
Function
• Phone Book Editor
• Configuration Editor
• Status Monitor
Options
• 250-sheet Universal Paper Feed
Unit (UE-409070)
• 2-/4-/8 MB Flash Memory Cards
(UE-410046/UE-410047/UE-
410048)
• Handset Kit (UE-403176)*2
FAX
