24 HOUR TIME CONTROLS
4000, 4010 and 4210 Series -- One and One Half
Hour Minimum ON or OFF Time -- One to 7 ON/OFF
Operations per Day
24-hour dial with two to 14 replaceable trippers for one to 7 ON/OFF operations per
day. One and one half hour minimum and 22-1/2 hour maximum ON or OFF time.
Manual override lever temporarily reverses switch operation without permanently
disturbing preset schedule. Switch slider bar assures positive switching. Heavy
duty industrial type synchronous motor. Heavy duty terminals accommodate AWG
#8 wire.
4000 Series - Standard NEMA 1 indoor metal enclosure side hinged with
combination 1/2-3/4 inch knockouts in bottom and sides.
4010 Series - Standard NEMA 3 indoor/outdoor metal or NEMA Type 3R plastic
enclosure side hinged with combination 1/2-3/4 inch knockouts in bottom and sides.
4210 Series - Standard NEMA 3 indoor/outdoor metal enclosed side hinged with
combination 1/2 - 3/4 inch knockouts in bottom and sides. All have hasp for
padlock or seal.
Optional skip-a-day feature allows schedule to be omitted on any day or days of the
week without permanently disturbing preset schedule. Optional Astro Dial control
adjusts for seasonal changes turning lights ON automatically at sunset and
permitting OFF between 9:30 pm and 2:30 am or OFF at sunrise.
APPLICATIONS
Indoor/Outdoor Lighting - Heating/Ventilating Systems - Post Lanterns - Signs -
Pool Heaters - Air Conditioning - Music and Signal System - Conveyors - Blowers -
Electric Fences - Motors - Pumps - Fans - Poultry - Foggers - Filters
HOW TO SPECIFY
Installer shall furnish and install Paragon (model No. ) 24-Hour General Purpose
Time Control with (SPST, DPST, SPDT) switch. Contacts to be rated at 40 amperes
tungsten per pole up to 277 volts. Control shall be in (NEMA 1 indoor metal, NEMA
3 indoor/outdoor metal, NEMA type 3R plastic) enclosure. Optional: Control shall
have skip-a-day feature. Optional: Control shall have Astro Dial feature.
*4001-00
4001-00B
4001-00M
4002-71
4002-71B
4003-00
4003-00M
4004-71
4004-71B
4004-71M
4005-00B
4003-00S
*4003-00SB
4006-71S
*4003-00SM
4004-06S
4004-71S
4005-00S
4005-00SB
4007-06S
4007-06SB
**4003-00SZ32
**4004-71SZ32
**4005-00SZ32
**4006-71SZ32
21250
21255
21251
21210
21211
21290
21291
21220
21225
21385
21389
21350
21355
20420
21351
21316
21380
21390
21391
21552
21553
40415
40440
40465
40490
SPST
SPST
SPST
SPST
SPST
DPST
DPST
DPST
DPST
DPST
SPDT
DPST
DPST
SPDT
DPST
DPST
DPST
SPDT
SPDT
SPDT
SPDT
DPST
DPST
SPDT
SPDT
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
-
1
1
1
-
-
1
1
1
1
1
1
1
2
2
3
3
4
4
4
5
3
3
6
3
7
4
5
5
8
8
3
4
5
6
120
120
120
208-277
208-277
120
120
208-277
208-277
208-277
120
120
120
208-277
120
24
208-277
120
120
24
24
120
208-277
120
208-277
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
1
-
-
1
-
1
-
-
1
-
-
1
-
1
-
1
1
1
-
1
-
1
1
1
1
2-1/2
2-1/2
1-1/8
2-1/2
2-1/2
2-1/2
1-1/8
2-1/2
2-1/2
1-1/8
2-1/2
2-1/2
2-1/2
2-1/2
1-1/8
2-1/2
2-1/2
2-1/2
2-1/2
3-1/2
2
3
3
3
3
$45.61
46.41
44.27
50.80
54.39
50.54
48.40
52.97
57.04
51.55
52.24
64.59
67.31
77.41
68.61
84.12
75.21
67.21
69.80
80.48
85.77
105.62
118.61
109.29
118.10
PriceLb.
Enclosed
Type
NEMA
Volts Hz
EDP No.
4988 - Switch
Type Amp Amp T VA hp Wiring
Diagram #
4000 Series - Standard NEMA 1 indoor metal enclosed.
With Skip-A-Day - Allows schedule to be omitted on any day or days of the week without permanently disturbing preset schedule.
With Skip-A-Day and Astro Dial - Adjusts for seasonal changes in sunrise and sunset times.
* Available in 50Hz
**1 ON and 1 OFF operation per day.
Models with suffix "B" or "M" are recognized under the component program of UL
and CSA.
When ordering Astro Dial, indicate city and state nearest installation.
For enclosure dimensions just call any of the toll free numbers on the back of this
catalog.
Furnished with one set of ON/OFF trippers additional trippers available.
Suffix Key:
B=Bracket Mount
M=Movement
R=Resistor
S=Skip-A-Day
T=Transformer
Z=Astro Dial
Enclosure Key
1=NEMA 1 Indoor Metal
3=NEMA 3 Indoor/Outdoor Metal
3R=NEMA Type 3R Indoor.Outdoor Plastic
4000 Series
4210 Series
4010 Series
Time Control
Model No.
Switch Rating Per Pole AC Line
http://waterheatertimer.org/Paragon-timers-and-manuals.html#7000
24 HOUR TIME CONTROLS
4008-20S
4011-00
4011-00P
4013-00
4013-00P
4014-71
4014-71P
4013-00S
4014-71S
**4013-00SZ32
**4014-71SZ32
**4015-00SZ32
4213-00S
4214-20S
4214-27S
4215-00S
**4213-00SZ32
**4214-20SZ32
**4214-27SZ32
**4215-00SZ32
21560
21580
21585
21620
21621
21640
40147
21670
21698
40515
40540
40565
21810
21838
21931
21850
40590
40615
40640
40665
DPST
SPST
SPST
DPST
DPST
DPST
DPST
DPST
DPST
DPST
DPST
SPDT
DPST
DPST
DPST
SPDT
DPST
DPST
DPST
SPDT
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
690
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
-
1
4
1
1
3
3
4
4
3
4
3
4
5
3
4
4
5
3
4
4
5
208-240
120
120
120
120
208-277
208-277
120
208-277
120
208-277
120
120
208-240
277
120
120
208-240
277
120
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
1
3
3R
3
3R
3
3R
3
3
3
3
3
3
3
3
3
3
3
3
3
2-1/2
4-3/4
1-3/8
4-3/4
1-3/8
4-3/4
1-3/8
4-3/4
4-3/4
5-1/2
5-1/2
5-1/2
6
6
6
6
6-1/2
6-1/2
6-1/2
6-1/2
$75.29
72.40
53.97
80.99
58.82
78.24
61.18
96.10
101.77
132.18
134.85
134.85
302.77
307.61
307.61
302.77
402.28
407.60
407.60
402.28
PriceLb.
Enclosed
Type
NEMA
Volts Hz
EDP No.
4988 - Switch
Type Amp Amp T VA hp Wiring
Diagram #
Leaves load ON during days scheduled to be skipped
Time Control
Model No.
Switch Rating Per Pole AC Line
4010 Series - Standard NEMA 3 indoor - outdoor metal or NEMA type 3 R plastic enclosure.
With Skip-Day - Allows schedule to be omited on any day or days of the week without permanently disturbing preset schedule.
With Skip-A-Day and Astro Dial - Adjusts for seasonal changes in sunrise and sunset times.
4210 Series - Standard NEMA 3 indoor/outdoor metal enclosure with spring wound carry-over and Skip-A-Day.
With Skip-A-Day and Astro Dial
* Available in 50Hz
**1 ON and 1 OFF operation per day.
Models with suffix "B" or "M" are recognized under the component program of UL and CSA.
When ordering Astro Dial, indicate city and state nearest installation.
For enclosure dimensions just call any of the toll free numbers on the back of this catalog.
Furnished with one set of ON/OFF trippers additional trippers available.
Suffix Key:
B=Bracket Mount
M=Movement
R=Resistor
S=Skip-A-Day
T=Transformer
Z32=Astro Dial preset
Enclosure Key
1=NEMA 1 Indoor Metal
3=NEMA 3 Indoor/Outdoor Metal
3R=NEMA Type 3R Indoor/Outdoor Plastic
Typical wiring Diagram # 1: SPST,
120V Typical Wiring Diagram #2: SPST,
208-277V Typical Wiring Diagram #3: DPST,
120V Typical Wiring Diagram #4: DPST,
208-277V
Typical wiring Diagram # 5: SPDT,
120V Typical Wiring Diagram #6: SPDT,
208-277V Typical Wiring Diagram #7: DPST,
24V Typical Wiring Diagram #8: SPDT,
24V
24 HOUR TIME CONTROLS Continued
7 DAY TIME CONTROL
24-hour or 7-day programming - 7-
day programming allows greater
flexibility thus added energy savings
by allowing loads to remain on only
when needed
4-day minimum power outage carry-
over without the use of batteries.
Eliminates the need to replace
batteries and the environ-mental
concerns of battery disposal
16 setpoints
30 amp heavy duty relay output
allows switching most electrical loads
without the use of contactors
To-the-minute programming with just
four keys and a large easy to read
display that uses visual prompts for
ease of programming
EC7000
Series are single-channel, electronic
time controls that provide simple,
inexpensive control of electrical loads
with a time-of-day schedule. When
schedules vary from day to day, the
7-day programming capability allows
a different schedule for each day of
the week. With 16 setpoints avail-
able, the EC7000 Series provides
programming versatility.
Models are also available to provide
two individually programable dura-
tions of one to 59 seconds in addition
to the maintained ON and OFF
setpoints. This provides ideal control
for bell or chime ringing in schools
and factories.
The EC7000 Series Controls are
ideal for indoor and outdoor lighting,
billboard and security lighting, school
crossing lights, heating, ventilating,
bell, chime and buzzer ringing, water
heater and security system control.
Price
$ 112.81
110.34
110.34
107.95
107.95
123.34
134.84
155.88
147.68
147.68
Enclosure
Type
NEMA 1
NEMA 1
NEMA 1
NEMA 1
NEMA 1
NEMA 3R
NEMA 3R
NEMA 1
NEMA 1
NEMA 1
EDP No.
4988 -
70024
70120
70087
74120
74208
43740
43745
70124
71120
70107
Rating
Per Pole
20A
20A
20A
30A
30A
30A
30A
20A
20A
20A
Type of
Output
SPDT
SPDT
SPDT
SPST
SPST
DPST
DPST
SPDT
SPDT
SPDT
Model No.
EC7000/24V
EC7000/120V
EC7000/208-277V
EC7004/120V
EC7004/208-277V
EC7005PC/120,208-240V
EC7005PC/277V
EC7001/24V
EC7001/120V
EC7001/208-277V
One-Channel / 7-Day with Batteryless Carry-Over
One-Channel / 7-Day with Momentary Contact Signal Feature
NEW
SPST, SPDT, DPST switching
Designed for high immunity to
electrical noise
Momentary feature available
Recessed reset button
Available in NEMA Type 3R
(EC7005) or NEMA 1 (EC7000)
enclosures
SPECIFICATIONS
7 DAY TIME CONTROLS
7000 and 7210 Series
Four Pole, Three Hour Minimum ON or OFF Time. Four ON/OFF Operations per day, 28 per Week
7-day calendar permits different ON/OFF schedules on different days of the week. Maximum of four ON/OFF
operations per day and 28 per week. Three hour minimum and 21 hour maximum ON or OFF time per day.
Independent four pole design allows for SPST, DPST or SPDT switching. Manual override lever temporarily
reverses switch operation without permanently disturbing preset schedule. Switch slider bar assures positive
switching. Heavy duty industrial type synchronous motor. Heavy duty terminals accommodate up to AWG #8
wire. Optional spring wound carry-over to take over during power outage, keeping control running up to 10
hours. Only two hour wind up required for each hour of power outage.
7000 Series - Standard NEMA 1 indoor metal enclosure side hinged with combination 1/2-3/4 inch knockouts in
bottom and side. Hasp for padlock or seal. Standard 7210 Series - NEMA 3 indoor/outdoor metal enclosure side
hinged with combination 1/2-314 inch knockouts in bottom and sides. Hasp for padlock or seal.
Applications
· HVAC · Indoor/Outdoor Lighting · Fans · Pumps · Motors · 3 Phase Loads
How to Specify
Installer shall furnish and install Paragon ( Model No.) 7-Day General Purpose Time Control with (4PST-4 NO, 2
NO-2NC) switch. Contacts to be rated at (40 amperes tungsten, 40 amperes noninductive) per pole up to 277
volts. Control shall have (NEMA 1 indoor metal, NEMA 3 indoor/outdoor metal) enclosure. Optional: Control
shall have spring wound carry-over.
PriceLb.
Enclosed
Type
NEMA
Volts Hz
EDP No.
4988 - Switch
Type Amp Amp T VA hp Wiring
Diagram #
Time Control
Model No.
Switch Rating Per Pole AC Line
**7007-00
*7007-06
7007-71
7008-00
*700806
7008-71
7217-00
7217-20
7218-00
7218-20
22050
22056
22069
22070
22076
22090
22160
22168
22180
22188
4PST-4 NO
4PST-4NO
4PST-4 NO
2 NO-2 NC
2 NO-2 NC
2 NO-2 NC
4PST-4 NO
4PST-4 NO
2 NO-2 NC
2 NO-2 NC
40
40
40
40
40
40
40
40
40
40
40
-
40
-
-
-
40
40
-
-
690
345
690
690
345
690
690
690
690
690
-
-
-
1
-
1
-
-
1
1
1
1
1
2
2
2
1
1
2
2
120
24
208-277
120
24
208-277
120
208-240
120
208-240
60
60
60
60
60
60
60
60
60
60
1
1
1
1
1
1
3
3
3
3
6-1/2
6-1/2
6-1/2
6-1/2
6-1/2
6-1/2
10
10
10
10
$102.04
115.71
106.47
102.04
115.97
106.47
292.58
314.02
292.58
314.02
7210 Series - With spring wound carry-over
Furnished with 7 sets of ON/OFF trippers for addtional sets just call any of the toll free numbers on the back of this
catalog. SPDT, DPST or DPDT operation possible by using extra bridges (furnished). HP rating (one pole only).
*Not UL or CSA listed
** Available in 50 Hz
Typical Wiring Diagram #1:
DPST, 120V Typical Wiring Diagram #2"
1SPST-NO; 1SPST-NC, 120V
Prices listed in this catalog are for estimating
purposes. Prices were correct first column
net at the time the pages were composed.
Prices are subject to change without notice.
Quantity prices are available. Please call any
of the toll free numbers on the back cover for
current and/or quantity prices.
MULTI-CHANNEL 7-DAY ELECTRONIC TIME CONTROLS ARE AVAILABLE FROM PARAGON
Series EC72 and EC72D are seven-day, two-channel, time controls
that are used for switching two different electrical circuits according to
a perset, time-of-day program, providing precise control from a
central location and common time base. Each channel can be
programmed for 16 events per day, for a total capacity of 112 events
per week per channel.
The EC74 family of controls are designed for control of up to four
different loads with different ON/OFF time-of-day schedules. Each of
the four channels are independently programmable for each day of the
week, plus a special eighth day holiday program. The astro dial
feature on some models eliminates need for a photocell. The control
can be programmed for automatic daylight savings time changeover
for spring and fall.
The model EC74/192MA is capable of 192 total events, or 48 events
available for each of 4 channels. 16 events available per program;
each day of the week can be assigned an A, B and C set of events or
SKIP (no ON operating). The A, B and C programs of each cannel can
contain up to 8 ONs and 8 OFFs, or one momentary dfuration
ELECTRONIC TIME CONTROLS
EC4000/120
EC4000P/120
EC4000/240
EC4000P/240
EC4004/120
EC4004P/120
EC4004/240
EC4004P/240
*EC4005/120,
208-240
1/4
1/4
1/2
1/2
-
-
-
-
-
1
3R
1
3R
1
3R
1
3R
3R
2
2-1/2
2
2-1/2
2
2-1/2
2
2-1/2
2
Normally Open
Amp hp
Normally Closed
Amp hp
Output Switch Rating - 1 SPDT relay with
contacts rated as follows:
20
20
20
20
30
30
30
30
30
4 VA
4 VA
4 VA
4 VA
4 VA
4 VA
4 VA
4 VA
4 VA
50/60
50/60
50/60
50/60
50/60
50/60
50/60
50/60
50/60
120Vac
120Vac
208-240Vac
208-240Vac
120Vac
120Vac
208-240Vac
208-240Vac
120/208-240Vac
40120
47120
40240
42240
44120
43120
44240
43240
45120
Lb.
Enclosure
Type
NEMA
Power Consump-
tionHz
Voltage
EDP No.
4988 -
Time Control Model
No.
For addtional information please call any of the toll free numbers on the back
of this catalog and request Spec Data Sheet #2216
* DPST, 1 hp at 120Vac, 3 hp at 240 Vac.
NEW!!!
EC4000 Series
24-Hour, Single-Channel, Capacitor Carry-Over
The EC4000 Series are 24-hour, single-channel, electronic time controls that provide simple,
inexpensive control of electrical loads with a time-of-day schedule. As a 24-hour control, the same
ON/OFF schedule is utilized each day. Saturday and/or Sunday, or any other day(s) of the week
may be skipped. The skipped day(s) can be either load ON all day or load OFF all day, depending
upon the application. Sixteen events are available to provide programming versatility. An event
defines an activity either load ON or load OFF. The EC4000 Series are available in either a NEMA
1 metal enclosure or a NEMA Type 3R non-metallic enclosure for indoor or outdoor use.
Features
Power outage carry-over maintains time and program in the event of a power outage for a
minimum of four days without a battery.
16 events per day can accommodate almost any schedule.
Low cost to provide fast return on investment.
·20 or 30 amp heavy duty relays available to allow switching of most electrical loads without the
use of contactors.
Just four keys and a large easy to read display for easy programming.
Applications
Indoor/Outdoor Lighting · Security Lighting · Water Heaters Ventilating · Air Conditioning ·
Heating · Security Systems
How to Specify
Installer shall furnish and install Paragon EC4000, EC4004 or EC4005 Electronic Time Control.
The single-channel control shall have 24-hour capability with 16 events available. Control shall
have keyboard override until overridden again or until next event is reached. Control shall provide
4 days power outage carry-over without a battery. The digital time display shall be 5/8" in height.
Clock format shall be selectable, allowing a choice of 12 hour (AM/PM) or 24 hour fommat. An
"ON" or "OFF" display will indicate the current status of the load control contacts. Wiring terminals
shall have the capability to accommodate #16 to #10 AWG wire. Control shall be housed in a
NEMA 1 lockable steel enclosure or a NEMA type 3R nonmetallic lockable enclosure to guard
against vandalism or tampering.
Typical Wiring Diagram For EC4005 Typical Wiring Diagram For EC4005
Enclosure Key:
1=NEMA 1 indoor Metal
3=NEMA Indoor/Outdoor Metal
3R=NEMA Type 3R Indoor/Outdoor Plastic
Typical Wiring Diagram For EC4000
$55.56
79.77
72.55
92.83
55.38
78.06
70.04
80.63
102.85
Price
1
1
2
2
1
1
2
2
-
10
10
10
10
-
-
-
-
-
