VQ5100 Pneumatic Valve Cat

2479 28th Street S.W. - Grand Rapids, MI 49519

PNEUMATIC AIR VALVE

GUIDE

Cat. 100

6/12

VQC Valves

Pages 1 to 6

VQ4000 & VQ5000

Pages 7 to 9

SV2000 & SV3000

Pages 11 to 14

SY5000

Pages 15 to 18

Body Ported

Page 19 2 Port

Page 20

Air Pilot

Page 21

Mechanical Valves

Page 22

Hand & Foot Valves

Page 23

Shut Off Valves

Page 25

Exhaust Mufflers

Page 26

MFD Valves

Page 24

Valve Sizing

Page 29 to 30

VQC1000 Series

5 Port, Plug-in, Rubber Seal,

With Indicator Light

Position No. of Solenoid Part Number Volts CV

24VDC PNP 24VDC NPN

2 Position Single VQC1101-51 VQC1101N-51 24 DC .25

2 Position Double VQC1201-51 VQC1201N-51 24 DC .25

3 Position Closed Center VQC1301-51 VQC1301N-51 24 DC .25

3 Position Open Center VQC1401-51 VQC1401N-51 24 DC .25

3 Position Pressure Center VQC1501-51 VQC1501N-51 24 DC .25

Part Number

VVQ1000-10A-1

Blank Plate

Part Number

VVQ1000-16A

SUP Block

Disk

Part Number

VVQ1000-19A

EXH Block

Disk

Fitting

Assembly

Part Number

VVQ1000-50A-N1 ⅛

VVQ1000-50A-N7 1/4

Part Number

KQ2P-07

¼

Port Plug

D-Sub

Cable

Part Number

AXT100-DS25-050 5m

DSUB050SMC 5m

.25

Cv

PAGE 1

VQC1000 Series

Manifolds

• Connector on D side

• Sup/Exh ports 5/16”

• Cylinder ports 1/4”

 •Built In Exhaust

No of

Stations

Part Number

2 VV5QC11-02N7FD0-S

3 VV5QC11-03N7FD0-S

4 VV5QC11-04N7FD0-S

5 VV5QC11-05N7FD0-S

6 VV5QC11-06N7FD0-S

7 VV5QC11-07N7FD0-S

8 VV5QC11-08N7FD0-S

9 VV5QC11-09N7FD0-S

10 VV5QC11-10N7FD0-S

11 VV5QC11-11N7FD0-S

12 VV5QC11-12N7FD0-S

PAGE 2

•

D-SUB BASES

•

TERMINAL BOX

•

I/O BASES

D-SUB BASES

No of

Stations

Part Number

2 VV5QC11-02N7TD0-S

3 VV5QC11-03N7TD0-S

4 VV5QC11-04N7TD0-S

5 VV5QC11-05N7TD0-S

6 VV5QC11-06N7TD0-S

7 VV5QC11-07N7TD0-S

8 VV5QC11-08N7TD0-S

9 VV5QC11-09N7TD0-S

10 VV5QC11-10N7TD0-S

11 VV5QC11-11N7TD0-S

12 VV5QC11-12N7TD0-S

TERMINAL BOX BASES

IP67 compliant

No of

Stations

Part Number

Includes Device Net

For Inputs See Below

2 VV5QC11-02N7SDQN0-S-X160US

3 VV5QC11-03N7SDQN0-S-X160US

4 VV5QC11-04N7SDQN0-S-X160US

5 VV5QC11-05N7SDQN0-S-X160US

6 VV5QC11-06N7SDQN0-S-X160US

7 VV5QC11-07N7SDQN0-S-X160US

8 VV5QC11-08N7SDQN0-S-X160US

9 VV5QC11-09N7SDQN0-S-X160US

10 VV5QC11-10N7SDQN0-S-X160US

11 VV5QC11-11N7SDQN0-S-X160US

12 VV5QC11-12N7SDQN0-S-X160US

I/O BASES

M12 4 Inputs

EX250-IE2

M12 2 Inputs

EX250-IE1

M8 4 Inputs

EX250-IE3

EX250 DeviceNet

EX250-SDN1-X102

Replacement fuse LM05(Black)

Inputs

DeviceNet (Replacement Number)

End Plate

EX250-EA1

VQC2000 Series

5 Port, Plug-in, Rubber Seal,

With Indicator Light

Position No. of Solenoid Part Number Volts CV

24VDC PNP 24VDC NPN

2 Position Single VQC2101-51 VQC2101N-51 24 DC .80

2 Position Double VQC2201-51 VQC2201N-51 24 DC .80

3 Position Closed Center VQC2301-51 VQC2301N-51 24 DC .80

3 Position Open Center VQC2401-51 VQC2401N-51 24 DC .80

3 Position Pressure Center VQC2501-51 VQC2501N-51 24 DC .80

Part Number

VVQ2000-10A-1

Blank Plate

Part Number

VVQ2000-16A

SUP Block

Disk

Part Number

VVQ2000-19A

EXH Block

Disk

Fitting

Assembly

Part Number

VVQ2000-50A-N1 ⅛

VVQ2000-50A-N7 1/4

Port Plug

D-Sub

Cable

Part Number

AXT100-DS25-050 5m

DSUB050SMC 5m

.80

Cv

PAGE 3

Part Number

KQ2P-07

¼

VQC2000 Series

Manifolds

• Connector on D side

• Sup/Exh ports 3/8”

• Cylinder ports 1/4”

 • Built In Exhaust

No of

Stations

Part Number

2 VV5QC21-02N7FD0-S

3 VV5QC21-03N7FD0-S

4 VV5QC21-04N7FD0-S

5 VV5QC21-05N7FD0-S

6 VV5QC21-06N7FD0-S

7 VV5QC21-07N7FD0-S

8 VV5QC21-08N7FD0-S

9 VV5QC21-09N7FD0-S

10 VV5QC21-10N7FD0-S

11 VV5QC21-11N7FD0-S

12 VV5QC21-12N7FD0-S

PAGE 4

•

D-SUB BASES

•

TERMINAL BOX

•

I/O BASES

D-SUB BASES

No of

Stations

Part Number

2 VV5QC21-02N7TD0-S

3 VV5QC21-03N7TD0-S

4 VV5QC21-04N7TD0-S

5 VV5QC21-05N7TD0-S

6 VV5QC21-06N7TD0-S

7 VV5QC21-07N7TD0-S

8 VV5QC21-08N7TD0-S

9 VV5QC21-09N7TD0-S

10 VV5QC21-10N7TD0-S

11 VV5QC21-11N7TD0-S

12 VV5QC21-12N7TD0-S

TERMINAL BOX BASES

IP67 compliant

No of

Stations

Part Number

Includes Device Net

For Inputs See Below

2 VV5QC21-02N7SDQN0-S-X160US

3 VV5QC21-03N7SDQN0-S-X160US

4 VV5QC21-04N7SDQN0-S-X160US

5 VV5QC21-05N7SDQN0-S-X160US

6 VV5QC21-06N7SDQN0-S-X160US

7 VV5QC21-07N7SDQN0-S-X160US

8 VV5QC21-08N7SDQN0-S-X160US

9 VV5QC21-09N7SDQN0-S-X160US

10 VV5QC21-10N7SDQN0-S-X160US

11 VV5QC21-11N7SDQN0-S-X160US

12 VV5QC21-12N7SDQN0-S-X160US

I/O BASES

M12 4 Inputs

EX250-IE2

M12 2 Inputs

EX250-IE1

M8 4 Inputs

EX250-IE3

EX250 DeviceNet

EX250-SDN1-X102

Replacement fuse LM05(Black)

Inputs

DeviceNet(Replacement Number)

End Plate

EX250-EA1

VQC4000 Series

5 Port, Plug-in, Rubber Seal,

With Indicator Light

Position No. of Solenoid Volts CV

24VDC

2 Position Single VQC4101-5 24 DC 2.0

2 Position Double VQC4201-5 24 DC 2.0

3 Position Closed Center VQC4301-5 24 DC 2.0

3 Position Open Center VQC4401-5 24 DC 2.0

3 Position Pressure Center VQC4501-5 24 DC 2.0

Part Number

VVQ4000-10A-1

Blank Plate

Part Number

VVQ4000-16A

SUP Block

Disk

Part Number

VVQ4000-16A

EXH Block

Disk

D-Sub

Cable

Part Number

AXT100-DS25-050 5m

DSUB050SMC 5m

2.0

Cv

PAGE 5

Part Number

VVQ4000-20A-1

Interface Speed Control

Plug-in

Part Number

ARBQ4000-N0-A-1

ARBQ4000-N0-P-1

Regulator

VQC4000 Series

Manifolds

• Connector on D side

• Sup/Exh ports 1/2”

• Cylinder ports 3/8”

No of

Stations

Part Number

2 VV5QC41-0203TFD0-S

3 VV5QC41-0303TFD0-S

4 VV5QC41-0403TFD0-S

5 VV5QC41-0503TFD0-S

6 VV5QC41-0603TFD0-S

7 VV5QC41-0703TFD0-S

8 VV5QC41-0803TFD0-S

9 VV5QC41-0903TFD0-S

10 VV5QC41-1003TFD0-S

11 VV5QC41-1103TFD0-S

12 VV5QC41-1203TFD0-S

PAGE 6

•

D-SUB BASES

•

TERMINAL BOX

•

I/O BASES

D-SUB BASES

No of

Stations

Part Number

2 VV5QC41-0203TTD0-S

3 VV5QC21-0303TTD0-S

4 VV5QC21-0403TTD0-S

5 VV5QC21-0503TTD0-S

6 VV5QC21-0603TTD0-S

7 VV5QC21-0703TTD0-S

8 VV5QC21-0803TTD0-S

9 VV5QC21-0903TTD0-S

10 VV5QC21-1003TTD0-S

11 VV5QC21-1103TTD0-S

12 VV5QC21-1203TTD0-S

TERMINAL BOX BASES

IP67 compliant

No of

Stations

Part Number

Includes Device Net

For Inputs See Below

2 VV5QC21-0203TSDQN0-S-X160US

3 VV5QC21-0303TSDQN0-S-X160US

4 VV5QC21-0403TSDQN0-S-X160US

5 VV5QC21-0503TSDQN0-S-X160US

6 VV5QC21-0603TSDQN0-S-X160US

7 VV5QC21-0703TSDQN0-S-X160US

8 VV5QC21-0803TSDQN0-S-X160US

9 VV5QC21-0903TSDQN0-S-X160US

10 VV5QC21-1003TSDQN0-S-X160US

11 VV5QC21-1103TSDQN0-S-X160US

12 VV5QC21-1203TSDQN0-S-X160US

I/O BASES

M12 4 Inputs

EX250-IE2

M12 2 Inputs

EX250-IE1

M8 4 Inputs

EX250-IE3

EX250 DeviceNet

EX250-SDN1-X102

Replacement fuse LM05(Black)

Inputs

DeviceNet(Replacement Number)

End Plate

EX250-EA1

Position No. of Solenoid Part Number Volts CV

110VAC 50/60 Hz

2 Position Single VQ4101-3 110V 2.2

2 Position Double VQ4201-3 110V 2.2

3 Position Closed Center VQ4301-3 110V 2.0

3 Position Open Center VQ4401-3 110V 2.2

3 Position Pressure Center VQ4501-3 110V 2.2

24V DC

2 Position Single VQ4101-5 24 DC 2.2

2 Position Double VQ4201-5 24 DC 2.2

3 Position Closed Center VQ4301-5 24 DC 2.0

3 Position Open Center VQ4401-5 24 DC 2.2

3 Position Pressure Center VQ4501-5 24 DC 2.2

Sub-Base

3/8” Ports

Part Number Port

VQ4000-P-03T 3/8”

Part Number

VVQ4000-20A-1

Interface Speed Control

Plug-in

Sub-Base

VQ4000 Series

5 Port, Plug-in, Rubber Seal,

With Indicator Light

Available 110VAC and 24VDC

Part Number

VVQ4000-10A-1

Blank Plate

Part Number

ARBQ4000-N0-A-1

ARBQ4000-N0-P-1

Larger Gauge Option

RC-4400 Long Stem

RC-4401 Short Stem

Regulator

PAGE 7

2.2

Cv

Sub-Base

With 4 Pin Connector

Part Number

RC-VQ4000-P-CNP4

4 Pin 5m Cable

Part Number

R-FS4TZ-V075

VQ4000 Series

D-Sub Connector Manifold With Built-in Exhaust

No of Stations Part Number Connector

Side

Sup/Exh

Port

Cyl

Port

2 Station Manifold VV5Q41-0203TFD0-SU

VV5Q41-0203TFU0-SD

D-Side

U-Side ½ ⅜

3 Station Manifold VV5Q41-0303TFD0-SU

VV5Q41-0303TFU0-SD

D-Side

U-Side ½ ⅜

4 Station Manifold VV5Q41-0403TFD0-SU

VV5Q41-0403TFU0-SD

D-Side

U-Side ½ ⅜

5 Station Manifold VV5Q41-0503TFD0-SU

VV5Q41-0503TFU0-SD

D-Side

U-Side ½ ⅜

6 Station Manifold VV5Q41-0603TFD0-SU

VV5Q41-0603TFU0-SD

D-Side

U-Side ½ ⅜

7 Station Manifold VV5Q41-0703TFD0-SU

VV5Q41-0703TFU0-SD

D-Side

U-Side ½ ⅜

8 Station Manifold VV5Q41-0803TFD0-SU

VV5Q41-0803TFU0-SD

D-Side

U-Side ½ ⅜

9 Station Manifold VV5Q41-0903TFD0-SU

VV5Q41-0903TFU0-SD

D-Side

U-Side ½ ⅜

10 Station Manifold VV5Q41-1003TFD0-SU

VV5Q41-1003TFU0-SD

D-Side

U-Side ½ ⅜

11 Station Manifold VV5Q41-1103TFD0-SU

VV5Q41-1103TFU0-SD

D-Side

U-Side ½ ⅜

12 Station Manifold VV5Q41-1203TFD0-SU

VV5Q41-1203TFU0-SD

D-Side

U-Side ½ ⅜

MANIFOLDS

PAGE 8

VQ5000 Series

5 Port, Plug-in, Metal Seal,

With Indicator Light

Position No. of Solenoid Part Number Volts CV

24V DC

2 Position Single VQ5100-5W 24 DC 4.0

2 Position Double VQ5200-5W 24 DC 4.0

3 Position Closed Center VQ5300-5W 24 DC 4.0

3 Position Open Center VQ5400-5W 24 DC 4.0

3 Position Pressure Center VQ5500-5W 24 DC 4.0

Position No. of Solenoid Part Number Volts CV

110V DC

2 Position Single VQ5100-3W 110 VAC 4.0

2 Position Double VQ5200-3W 110 VAC 4.0

3 Position Closed Center VQ5300-3W 110 VAC 4.0

3 Position Open Center VQ5400-3W 110 VAC 4.0

3 Position Pressure Center VQ5500-3W 110 VAC 4.0

Part Number Port Size

VQ5000-P-04T 1/2 npt

Sub Base

PAGE 9

4.0

Cv

EX600-SEN1

EtherNet Protocol

EX600-SEN1-DU001911

With Web Interface

EX600-DXPD

PNP Input

M12 (5-Pin) Socket

24 VDC

EX600-ED2

M12 (5-Pin) Plug

24 VDC

EX600-ED3

7/8” (5-Pin) Plug

24 VDC

EX600-ZMV1

For VQC & SV

EX600-ZMV2

For SY

EX600-ZMB1

For Direct Mounting

Z-FS5KAV435

5-Pin • 7/8”-16 • 5Meters

EX9-AC020EN-PSRJ

4-Pin • M12 • RJ 45 • 2Meters

SI Unit

Digital Input Unit

End Plate

EX600-ED3-X2

7/8” (4-Pin) Plug

24 VDC

4 Pin DeviceNet Plug

Valve Plate

Reinforcing Brace

Power Cable

Z-FS4KAV425

4-Pin • 7/8”-16 • 5Meters

Communication Cable

Power Cable

PCA-1564930

5-Pin • M12 • 5Meters

Page 10

Now in Stock at

Rapid Control

EX600 Components

SV2000 Series

5 Port, Plug-in,

With Indicator Light

24VDC

Position No. of Solenoid Part Number Volts CV

24V DC

2 Position Single SV2100-FU 24 DC .50

2 Position Double SV2200-5FU 24 DC .50

3 Position Closed Center SV2300-5FU 24 DC .50

3 Position Open Center SV2400-5FU 24 DC .50

3 Position Pressure Center SV2500-5FU 24 DC .50

Part Number

SV2000-67-1A

Blank Plate

Part Number

SV2000-59-3A

SUP & EXH

Block Disk

Fitting

Assembly

Part Number

VVQ1000-51A-N7 ¼

VVQ1000-51A-N9 5/16

8mm

Part Number Ports

SV2000-00-A1 A

SV2000-N0-P Both

Regulator

D-Sub

Cable

Part Number

AXT100-DS25-050 5m

DSUB050SMC 5m

PAGE 11

.50

Cv

Din Rail

Part Number

RC-DIN RAIL

SV2000 Series

Manifolds with D-Sub Connector

And Built-in Exhaust

3/8” Supply Ports

1/4 Cylinder Ports

No of Stations Part Number Connector

Side

2 Station Manifold SS5V2-10FD1-02US-N7 D-Side

3 Station Manifold SS5V2-10FD1-03US-N7 D-Side

4 Station Manifold SS5V2-10FD1-04US-N7 D-Side

5 Station Manifold SS5V2-10FD1-05US-N7 D-Side

6 Station Manifold SS5V2-10FD1-06US-N7 D-Side

7 Station Manifold SS5V2-10FD1-07US-N7 D-Side

8 Station Manifold SS5V2-10FD1-08US-N7 D-Side

9 Station Manifold SS5V2-10FD1-09US-N7 D-Side

10 Station Manifold SS5V2-10FD1-10US-N7 D-Side

11 Station Manifold SS5V2-10FD1-11US-N7 D-Side

12 Station Manifold SS5V2-10FD1-12US-N7 D-Side

Tie Rod Style Manifold

PAGE 12

No of Stations Part Number Connector

Side

2 Station Manifold SS5V2-16FD1-02US-N7 D-Side

3 Station Manifold SS5V2-16FD1-03US-N7 D-Side

4 Station Manifold SS5V2-16FD1-04US-N7 D-Side

5 Station Manifold SS5V2-16FD1-05US-N7 D-Side

6 Station Manifold SS5V2-16FD1-06US-N7 D-Side

7 Station Manifold SS5V2-16FD1-07US-N7 D-Side

8 Station Manifold SS5V2-16FD1-08US-N7 D-Side

9 Station Manifold SS5V2-16FD1-09US-N7 D-Side

10 Station Manifold SS5V2-16FD1-10US-N7 D-Side

11 Station Manifold SS5V2-16FD1-11US-N7 D-Side

12 Station Manifold SS5V2-16FD1-12US-N7 D-Side

Cassette Style Manifold

SV3000 Series

5 Port, Plug-in,

With Indicator Light

24VDC

Position No. of Solenoid Part Number Volts CV

24V DC

2 Position Single SV3100-FU 24 DC .90

2 Position Double SV3200-5FU 24 DC .90

3 Position Closed Center SV3300-5FU 24 DC .90

3 Position Open Center SV3400-5FU 24 DC .90

3 Position Pressure Center SV3500-5FU 24 DC .90

Part Number

SV3000-67-1A

Blank Plate

Part Number

SV3000-59-3A

SUP & EXH

Block Disk

Fitting

Assembly

Part Number

VVQ2000-51A-N7 ¼

VVQ2000-51A-N11 3/8

Part Number Ports

SV3000-N0-A1 A

SV3000-N0-P Both

Regulator

D-Sub

Cable

Part Number

AXT100-DS25-050 5m

DSUB050SMC 5m

PAGE 13

.90

Cv

Din Rail

Part Number

RC-DIN RAIL

SV3000 Series

Manifolds with D-Sub Connector

And Built-in Exhaust

3/8” Supply Ports

1/4 Cylinder Ports

No of Stations Part Number Connector

Side

2 Station Manifold SS5V3-10FD1-02US-N7 D-Side

3 Station Manifold SS5V3-10FD1-03US-N7 D-Side

4 Station Manifold SS5V3-10FD1-04US-N7 D-Side

5 Station Manifold SS5V3-10FD1-05US-N7 D-Side

6 Station Manifold SS5V3-10FD1-06US-N7 D-Side

7 Station Manifold SS5V3-10FD1-07US-N7 D-Side

8 Station Manifold SS5V3-10FD1-08US-N7 D-Side

9 Station Manifold SS5V3-10FD1-09US-N7 D-Side

10 Station Manifold SS5V3-10FD1-10US-N7 D-Side

11 Station Manifold SS5V3-10FD1-11US-N7 D-Side

12 Station Manifold SS5V3-10FD1-12US-N7 D-Side

Tie Rod Style Manifold

PAGE 14

No of Stations Part Number Connector

Side

2 Station Manifold SS5V3-16FD1-02US-N7 D-Side

3 Station Manifold SS5V3-16FD1-03US-N7 D-Side

4 Station Manifold SS5V3-16FD1-04US-N7 D-Side

5 Station Manifold SS5V3-16FD1-05US-N7 D-Side

6 Station Manifold SS5V3-16FD1-06US-N7 D-Side

7 Station Manifold SS5V3-16FD1-07US-N7 D-Side

8 Station Manifold SS5V3-16FD1-08US-N7 D-Side

9 Station Manifold SS5V3-16FD1-09US-N7 D-Side

10 Station Manifold SS5V3-16FD1-10US-N7 D-Side

11 Station Manifold SS5V3-16FD1-11US-N7 D-Side

12 Station Manifold SS5V3-16FD1-12US-N7 D-Side

Cassette Style Manifold

SY5000 Series

5 Port, Plug-in,

With Indicator Light

24VDC

Position No. of Solenoid Part Number Volts CV

24V DC

2 Position Single SY5100-FU1 24 DC 1.0

2 Position Double SY5200-5FU1 24 DC 1.0

3 Position Closed Center SY5300-5FU1 24 DC 1.0

3 Position Open Center SY5400-5FU1 24 DC 1.0

3 Position Pressure Center SY5500-5FU1 24 DC 1.0

4 Position Dual 3 Port (NC/NC SY5A00-5U1 24 DC 1.0

Part Number

SY50M-26-1A

Blank Plate

Part Number

SV2000-59-2A

SUP & EXH

Block Disk

Fitting

Assembly

Part Number

VVQ1000-51A-N7 ¼

VVQ1000-51A-N11 3/8

Part Number Ports

SY50M-N0-P Both

Regulator

D-Sub

Cable

Part Number

AXT100-DS25-050 5m

DSUB050SMC 5m

PAGE 15

1.0

Cv

NEW

SY5000 Series

Manifolds

• Connector on D side

• Sup/Exh ports 1/4”

• Cylinder ports 3/8”

No of

Stations

Part Number

2 SS5Y5-10F1-02BS-N7

3 SS5Y5-10F1-03BS-N7

4 SS5Y5-10F1-04BS-N7

5 SS5Y5-10F1-05BS-N7

6 SS5Y5-10F1-06BS-N7

7 SS5Y5-10F1-07BS-N7

8 SS5Y5-10F1-08BS-N7

9 SS5Y5-10F1-09BS-N7

10 SS5Y5-10F1-10BS-N7

11 SS5Y5-10F1-11BS-N7

12 SS5Y5-10F1-12BS-N7

•

D-SUB BASES

•

CIRCULAR CONNECTOR

•

I/O BASES

D-SUB BASES

No of

Stations

Part Number

2 SS5Y5-10M-02BS-N7

3 SS5Y5-10M-03BS-N7

4 SS5Y5-10M-04BS-N7

5 SS5Y5-10M-05BS-N7

6 SS5Y5-10M-06BS-N7

7 SS5Y5-10M-07BS-N7

8 SS5Y5-10M-08BS-N7

9 SS5Y5-10M-09BS-N7

10 SS5Y5-10M-10BS-N7

11 SS5Y5-10M-11BS-N7

12 SS5Y5-10M-12BS-N7

CIRCULAR CONNECTOR

IP67 compliant

No of

Stations

Part Number

Includes Device Net

For Inputs See Below

2 SS5Y5-10SQ-02B-N7

3 SS5Y5-10SQ-03B-N7

4 SS5Y5-10SQ-04B-N7

5 SS5Y5-10SQ-05B-N7

6 SS5Y5-10SQ-06B-N7

7 SS5Y5-10SQ-07B-N7

8 SS5Y5-10SQ-08B-N7

9 SS5Y5-10SQ-09B-N7

10 SS5Y5-10SQ-10B-N7

11 SS5Y5-10SQ-11B-N7

12 SS5Y5-10SQ-12B-N7

I/O BASES

M12 4 Inputs

EX250-IE2

M12 2 Inputs

EX250-IE1

M8 4 Inputs

EX250-IE3

EX250 DeviceNet

EX250-SDN1-X102

Replacement fuse LM05(Black)

Inputs

DeviceNet (Replacement Number)

End Plate

EX250-EA1

SY5000 Series Manifold Valves

5 Port, Rubber Seal Solenoid Valve

Position No. of Solenoid Part Number Volts CV

110VAC 50/60 Hz

2 Position Single SY5140-3D 110V .59

2 Position Double SY5240-3D 110V .59

3 Position Closed Center SY5340-3D 110V .59

3 Position Open Center SY5440-3D 110V .59

3 Position Pressure Center SY5540-3D 110V .59

24V DC

2 Position Single SY5140-5D 24 DC .59

2 Position Double SY5240-5D 24 DC .59

3 Position Closed Center SY5340-5D 24 DC .59

3 Position Open Center SY5440-5D 24 DC .59

3 Position Pressure Center SY5540-5D 24 DC .59

Blank Plate

Part Number

SX5000-76-1A

Part Number

SX5000-77-1A

Blocking Disk

Part Number

SY5000-38-2TA

Supply (1/8)

SY5000-39-2TA

Exhaust (1/8)

Individual

Supply & Exhaust

Din Rail

Part Number

RC-DIN RAIL

3’ Lighted Cord Included

.59

Cv

PAGE 17

SY5000 Series Manifold Bases

Manifold for Individual Lead Wires

No of Stations Part Number Sup/Exh

Port

Cyl

Port

2 Station Manifold SS5Y5-45-02D-N7 ⅜ ¼

3 Station Manifold SS5Y5-45-03D-N7 ⅜ ¼

4 Station Manifold SS5Y5-45-04D-N7 ⅜ ¼

5 Station Manifold SS5Y5-45-05D-N7 ⅜ ¼

6 Station Manifold SS5Y5-45-06D-N7 ⅜ ¼

7 Station Manifold SS5Y5-45-07D-N7 ⅜ ¼

8 Station Manifold SS5Y5-45-08D-N7 ⅜ ¼

9 Station Manifold SS5Y5-45-09D-N7 ⅜ ¼

10 Station Manifold SS5Y5-45-10D-N7 ⅜ ¼

11 Station Manifold SS5Y5-45-11D-N7 ⅜ ¼

12 Station Manifold SS5Y5-45-12D-N7 ⅜ ¼

PAGE 18

5 Port Solenoid Valve

•

Body Ported

Position Part Number Volts Ports CV

2 Position NVK3120-5DZ-01T 24 DC ⅛ .15

2 Position NVK3120-3DZ-01T

110V ⅛ .15

Mounting

Bracket

VK300-43-2A

2 Position NVFS2120-5D-02T 24 DC ¼ 1.0

2 Position NVFS2120-3D-02T 110V ¼ 1.0

NVK Series

NVFS Series

Position No. of Solenoid Part Number Volts Ports CV

2 Position Single SY5120-3D-N7T-F2 110V ¼ .59

2 Position Double SY5220-3D-N7T-F2 110V ¼ .59

2 Position Single SY5120-5D-N7T-F2 24 DC ¼ .59

2 Position Double SY5220-5D-N7T-F2 24 DC ¼ .59

SY 5000 Series

.15

Cv

PAGE 19

.59

Cv

1.0

Cv

2 Port Valves

Solenoid Operated

Position Part Number Ports Volts

2 Way VXZ2230-02N-5D N/C ¼ 24 vdc

2 Way VXZ2230-03N-5D N/C ⅜ 24 vdc

2 Way VXZ2240-04N-5D N/C ½ 24 vdc

2 Way VXZ2350-06N-5D N/C ¾ 24 vdc

2 Way VXZ2230-02N-3D N/C ¼ 110 vac

2 Way VXZ2230-03N-3D N/C ⅜ 110 vac

2 Way VXZ2240-04N-3D N/C ½ 110 vac

2 Way VXZ2350-06N-3D N/C ¾ 110 vac

110VAC Coil for

VXZ Valves VX021-002DB-03

Bracket For

VXZ Valves VX070-022

2 Way 9N204.K501 N/C ½ 110 vac

PAGE 20

Position Part Number EXT Ports Pilot Ports CV

Single Pilot SYA5120-N7T-F2 ⅛ Push In 10-32 .59

Double Pilot SYA5220-N7T-F2 ⅛ Push In 10-32 .59

Single Pilot SYA7120-02T-F2 ¼ NPT ⅛ 1.1

3 Port Pilot VTA301-02-N ¼ ⅛ .66

Double Pilot SYA7220-02T-F2 ¼ NPT ⅛ 1.1

With Bracket

Air Pilot Valves

Part Number Description Cv Class

NVSA4114-00A Single Pilot 1.0 Class 1

NVSA4214-00A Double Pilot 1.0 Class 1

SPA0115 Base 3/8” Class 1

.59

Cv

1.0

Cv

PAGE 21

VTA301-02-N

1.1

Cv

SYA5120-N7T-F2 SYA7120-02T-F2

Mechanical Air Valves

NVM Series

NVM230-N02-01

Roller Lever Valve

3-Ways; 2 Ports

1/4” Ports

NVM230-N02-02

One Way Roller Lever

3-Way; 2 Ports

1/4” Ports

NVM230-N02-05

Straight Plunger

3-Way; 2 Ports

1/4” Ports

NVM230-N02-06

Roller Plunger

3-Way; 2 Ports

1/4” Ports

NVM130-N01-30R, B, G

Push Button (mushroom)

3-Way; 2 Ports

1/8” Ports

Available in red. black, or

green buttons

NVM230-N02-34B

Twist Selector

3-Way; 2 Ports

1/4” Ports

NVM830-N01-13

Adjustable Roller Lever

3 Ports

1/8” Ports

NVM131-N01-01S

Cam Lever Valve

3-Way, 2 Ports

1/8” Ports

PAGE 22

ROTARY HAND VALVES

Position Part Number EXT Ports CV

2 Position VH202-N02 ¼ 0.4

3 Position

Closed Center

VH300-N02 ¼ 0.9

3 Position

Closed Center

VH300-N03 ⅜ 1.1

Position Part Number Ports

3 Position

Spring Center

Closed center HY2 ¼

3 Position

Spring Center

Closed center HY3 ⅜

3 Position

Click Detent

Closed center HD2 ¼

2 Position

Friction Pos.

HE2 ¼

HAND & FOOT VALVES

Hand Valves

Foot Valves

Position Part Number Ports

2 Position

Friction Pos.

Treadle Actuated TE2 ¼

2 Position

Friction Pos.

Treadle Actuated TE3 ⅜

2 Position

Spring Return

Pedal Actuated FO2 ¼

3 Position

Spring Return

Treadle Actuated TY2 ¼

PAGE 23

Hand Lever Valve

Model M4H210-06 M4H310-08

Type 5 Ports 2 Position

Detent

5 Ports 2 Position

Detent

Flow Cv 0.78 Cv 1.39

Port Size 1/8” NPT 1/4” NPT

Model M4F210-08G

Type 5 Ports 2 Position

Port Size 1/4” NPT

Foot Valve W/ Guard

Model M3V1-06-24VDC M3V1-06-120VAC

Port Size 1/8” NPT 1/8” NPT

Type 3 Port 2 Position 3 Port 2 Position

Flow Cv .051 Cv .051

Connection DIN Connector DIN Connector

Coil Volts 24VDC 110VAC

Solenoid Valve

PAGE 24

Shut Off Valves

Part Number Ports

MV609-2 ⅛

MV609-4 ¼

MV609-3 ⅜

Part Number Ports

21104F ⅛

21106F ¼

21108F ⅜

21112F ½

Part Number Ports

VHK2-04F-04F 4mm

VHK2-06F-06F 6mm

VHK2-08F-08F 8mm

VHK2-07F-07F-X205 ¼

Part Number Ports EXH Ports

VHS20-N02-Z ¼ ⅛

VHS30-N03-Z ⅜ ¼

VHS40-N04-Z ½ ⅜

PAGE 25

MUFFLERS

EXHAUST

Part Number Size

AN200-N02 NYLON ¼

AN300-N03 NYLON ⅜

AN400-N04 NYLON ½

SQF-2 NYLON ¼

SQF-3 NYLON ⅜

SQF-4 NYLON ½

ASQF-1M METAL ⅛

ASQF-2M METAL ¼

ASQF-3M METAL ⅜

ASQF-4M METAL ½

ASQF-6M METAL ¾

ASQF-8M METAL 1

AN202-N02 High Noise

Reduction ¼

AN402-N04 High Noise

Reduction ½

1000-2-F High Noise

Reduction ¼

1000-3-F High Noise

Reduction ⅜

1000-3-4-F High Noise

Reduction ½

1000-4-F High Noise

Reduction ½

1000-4-6-F High Noise

Reduction ¾

1000-8-6-F High Noise

Reduction ¾

Part Number Size

ASP-1 Sintered

Body ⅛

ASP-2 Sintered

Body ¼

ASP-3 Sintered

Body ⅜

ASP-4 Sintered

Body ½

ASP-6 Sintered

Body ¾

ASP-8 Sintered

Body 1

ASP-1BV Beather

Vents ⅛

ASP-2BV Beather

Vents ¼

ASP-3BV Beather

Vents ⅜

ASP-4BV Beather

Vents ½

ASP-6BV Beather

Vents ¾

ASP-8BV Beather

Vents 1

ASP-1SC Speed

Control ⅛

ASP-2SC Speed

Control ¼

ASP-3SC Speed

Control ⅜

ASP-4SC Speed

Control ½

ASP-6SC Speed

Control ¾

PAGE 26

RECTANGULAR MULTI-CONNECTOR

Number of

connecting tubes

Plug Socket

10 KDM10P-N KDM10S-N

20 KDM20P-N KDM20S-N

CONNECTORS

Substantial reduction in mounting space

 In comparison with a model requiring many union

joints for panels and partitions, this model needs

only a small space.

One-touch tube connection

 Multiple pipes can be connected/ disconnected in

one touch operation without connection error.

Thus man-hours for connection/disconnection is

cut down substantially.

One-touch tube connection

 One-touch fittings substantially cuts down man-

hour for piping

KDMP-01 1/8

Plug KDMP-03 5/32

Fittings KDMP-07 1/4

KDMP-09 5/16

KDMP-06 6

PLUGS & SOCKETS

KDMS-01 1/8

Socket KDMS-03 5/32

Fittings KDMS-07 1/4

KDMS-09 5/16

KDMS-06 6

KDM10S

KDM10P

PAGE 27

Part Number Inlet Port

PVT-1170-C-4 Without Key ¼

PVT-1170-C-4-K With Key ¼

PNEUMATIC COUNTER

Part Number Ports

RC-FRL-2-LV ¼

RC-FRL-3-LV ⅜

RC-FRL-4-LV ½

FILTER

•

REGULATOR

• LUBRICATOR

COMBO

Part Number Ports

NVM430-N01-30R/MOD ⅛

STOP VALVE

3 Way palm button w/ air pilot return

PAGE 28

Figuring Cv for Valve Sizing

EXAMPLE

We want to extend a 3 1/4” bore cylinder 12” in one second.

We have a supply pressure of 80 psi.

Piston area: 8.3

Cylinder Stroke: 12 in

Compression Factor: 6.4

Pressure drop factor: 20.5

Cycle time (sec): 1

X 29

8.3 x 12 x 6.4

= 1.05 Cv

20.5 x 1 x 29

PAGE 29

PAGE 30

PNEUMATIC COMPONENTS•CYLINDERS•VALVES•FITTINGS•TUBING

RAPID CONTROL SERVICE, INC.

2479 28th Street

Grand Rapid, MI 49519

Ph: 616-538-1111 Fax: 616-538-6847

AUTO FEED DRILLS & TAPPERS FILTERS•REGULATERS•LUBRICATORS

AIR PRESSES•HIGH PRESSURE CYLINDERS

TIMERS•COUNTERS

ALUMINUM EXTRUSION

AIR CYLINDERS RODLESS CYLINDERS•SLIDES•GRIPPERS

SWITCHES

VACUUM PUMPS

RESISTANCE WELD CONTROLS WELD TIPS & CAPS

CABLES & SENSORS

AIR & WATER MANIFOLDS

AIR BAGS

VQ5100 Pneumatic Valve Cat

Navigation menu

Versions of this User Manual:

Views

Navigation
