1
CS 6035 – Introduction to Information Security
Project 1 – Buffer Overflow
Contents
Goal ............................................................................................................................................................... 2
Task 1 - Understanding Buffer Overflow (40 points) .................................................................................... 2
Stack Buffer Overflow ............................................................................................................................... 2
Hints .......................................................................................................................................................... 2
Deliverable ................................................................................................................................................ 2
Grading rubric for Task 1........................................................................................................................... 2
Task 2 - Exploiting Buffer Overflow (60 points) ............................................................................................ 3
Lab Environment ....................................................................................................................................... 3
Hints .......................................................................................................................................................... 4
Deliverable ................................................................................................................................................ 4
Grading rubric for Task 2........................................................................................................................... 4
Appendix A – The Toy Program for Task 2 .................................................................................................... 5
Appendix B – Sample Data for Task 2 ........................................................................................................... 7
2
Goal
Students should be able to clearly explain:
1. What a buffer overflow is - understand the concepts of buffer overflow
2. Why a buffer overflow is dangerous
3. How to exploit a buffer overflow. Students are expected to launch an attack that exploits stack
buffer overflow vulnerability in the provided toy program.
Task 1 - Understanding Buffer Overflow (40 points)
Stack Buffer Overflow
Write a C/C++ program that contains the stack buffer overflow vulnerability. Show what the stack layout
looks like and explain how to exploit it. You are not required to write the real exploit code, but you may
want to use some figures to make your description clear.
Hints
1. Learn how to write a C/C++ program if you do not know how to do that
2. “Smashing The Stack For Fun And Profit”(http://phrack.org/issues/49/14.html)
Deliverable
An Adobe PDF file containing your vulnerable program (paste your code in the PDF directly) and your
explanation. For an example of how your stack layout should look, see chapter 10 in the text Stallings,
William, and Lawrie Brown. Computer Security Principles and Practice. Boston: Pearson, 2015 text. Also a
good example of a stack diagram can be found at: https://en.wikipedia.org/wiki/Stack_buffer_overflow.
Make sure to properly cite any references that you use.
Grading rubric for Task 1
1. Vulnerable Program (5 points)
2. Stack Layout (25 points)
Note: the stack layout should contain the following contents:
o Stack layout (5 points)
o High and low address of stack, stack grows direction (5 points)
o Size of each part on the stack (5 points)
o Content of each part of the stack (5 points)
o Overflowed area of the stack (5 points)
3. Exploiting Explanation (10 points)
3
Task 2 - Exploiting Buffer Overflow (60 points)
The C code shown in Appendix 1 contains possible stack buffer overflow vulnerability. Your task is to
write an exploit (e.g., Python script) to open a shell on Linux. The high level idea is to overwrite the
return address with the libc address of the function system(), and pass the parameter “sh” to this
function. Once the return instruction is executed, this function will be called to open a shell.
Lab Environment
Students are required to download the VirtualBox appliance (Project1.ova) from the assigned website
and following instructions to perform the project.
1. Install VirtualBox on your computer. You can either download it from official website or from
Google Drive, if you do not have the software installed already. The appliance will have the
guest additions CD already installed (version 5.0.14 r105127). If you download a newer
VirtualBox or have already have different version installed, you will need to install your own
guest additions CD by going to the VM Menu and selecting Devices Insert Guest Additions CD
Image. Then follow the screen prompts.
2. Download the VirtualBox appliance (Project1.ova) from Google Drive. The lab environment has
already been created; therefore you can start the lab on it directly.
a. Download link: https://drive.google.com/open?id=0B_260Z7EWPixMTNmSVRUNjUtUzg
b. Login Instructions - Username: Ubuntu / Password: 123456
c. Instructions on importing the Virtual Box Appliance:
https://docs.oracle.com/cd/E26217_01/E26796/html/qs-import-vm.html
3. Change to the directory of the Project 1 Package. The package has been placed on the Desktop
of the VM.
4. Compile the Toy program as follows: gcc sort.c -o sort -fno-stack-protector.
5. To run the program, add hexadecimal integers for sorting in the file data.txt and execute your
sort function by: ./sort data.txt
6. You will notice that when you put a very long list of integers in data.txt, that sort crashes with a
segment fault error; this is because the return address has been overwritten by your data.
7. Your job is to craft your own shellcode in data.txt. You are to overwrite the return address with
the address of function system() and pass it with the address of string “sh”.
8. Warning: Before you exploit the program, please first understand the logic of sort.c. Also, DO
NOT install any updates to the VM. Good Luck!
4
Hints
1. Why traditional buffer overflow exploits do not work? See DEP and W^X protections
2. How to bypass DEP and W^X? See “The advanced return-into-lib(c) exploits”
(http://phrack.org/issues/58/4.html ) and “Return-to-libc” (https://www.exploit-
db.com/docs/28553.pdf )
3. GDB is a helpful tool to understand the stack layout when buffer overflow happens and get the
addresses of system() and “sh”
Deliverable
Deliver either an exploit script (any scripting language is allowed, but your script must contain
everything, so that the TA can directly run it by ./script or the data.txt file you craft. The exploiting
results should be demonstrated with your screenshots (paste the screenshots in the same PDF file as
your Task 1 report).
Note: Ensure that data.txt does not have CRLF. To achieve this, if you use winSCP or similar
tools to transfer files, make sure the file is transferred as binary. Do not create the text file
with notepad or similar tools in a Windows system (Apple OSX should not have this problem).
Grading rubric for Task 2
1. Buffer overflow caused by your crafted data.txt and overflow proof in GDB (10 points)
2. Locate the Libc system() address in GDB (10 points)
3. Locate /bin/sh address in GDB (10 points)
4. Correct exploit payload in data.txt and being able to open the shell in terminal (30 points)
5
Appendix A – The Toy Program for Task 2
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
/*
* a toy program for learning stack buffer
* overflow exploiting
* It reads a list of hex data from the
* specified file, and performs bubble sorting
*/
long n = 0, c = 0, d = 0;
FILE *fp = NULL;
void bubble_sort()
{
long swap = 0;
long array[12];
// loading data to array
printf("Source list:\n");
char line[sizeof(long) * 2 + 1] = {0};
while(fgets(line, sizeof(line), fp)) {
if (strlen((char *)line) > 1) {
sscanf(line, "%lx", &(array[n]));
printf("0x%lx\n", array[n]);
++n;
}
}
fclose(fp);
// do bubble sorting
for (c = 0 ; c < ( n - 1 ); c++)
{
for (d = 0 ; d < n - c - 1; d++)
{
6
if (array[d] > array[d+1])
{
swap = array[d];
array[d] = array[d+1];
array[d+1] = swap;
}
}
}
// output sorting result
printf("\nSorted list in ascending order:\n");
for ( c = 0 ; c < n ; c++ )
printf("%lx\n", array[c]);
}
int main(int argc, char **argv)
{
if(argc!=2)
{
printf("Usage: ./sort file_name\n");
return -1;
}
fp = fopen(argv[1], "rb");
bubble_sort();
return 0;
}
7
Appendix B – Sample Data for Task 2
1
3
5
7
80
a
d0
