PAX XXX Programming Guide Prolin+API+Programming+Guide(V2.1.1)

User Manual:

Open the PDF directly: View PDF PDF.
Page Count: 243 [warning: Documents this large are best viewed by clicking the View PDF Link!]

PAX Computer Technology(Shenzhen)Co.,Ltd.
Prolin API Programming
Guide
V 2.1.1
I
Copyright © 2000-2015 PAX Computer Technology (Shenzhen) Co., Ltd.
All rights reserved. No part of the contents of this document may be reproduced or
transmitted in any form without the written permission of PAX Computer Technology
(Shenzhen) Co., Ltd.
The information contained in this document is subject to change without notice. Although
PAX Computer Technology (Shenzhen) Co., Ltd. has attempted to ensure the accuracy of the
contents of this document, this document may include errors or omissions. The examples and
sample programs are for illustration only and may not be suited for your purpose. You should
verify the applicability of any example or sample program before placing the software into
productive use.
II
Revision History
Date
Version
Note
Author
2012-08-29
V1.0.0
Translated from Chinese standard version
of ‗Prolin API Programming Guide
v1.0.0‘.
Prolin
Team
2012-11-19
V1.0.1
Modified the interfaces.
Prolin
Team
2012-12-26
V1.0.2
1. Added the return code list in the
System function;
2. Added a new interface
OsVerifySignExternal();
3. Added the WIFI module;
4. Added the Register table in Appendix
Prolin
Team
2013-02-20
V1.0.3
1. Added descriptions in OsOpenFont ().
Prolin
Team
2013-03-06
V1.0.4
1. Modified the description of
OsModemOpen();
2. Added two return values -3219 and
-3220 in Modem;
3. Added the instruction of
DetectDailTone;
4. Added a new function
OsModemSwitchPower();
5. Modified the parameter description of
OsPrnOpen(), it does not support the
png format;
6. Modified the sci_get_fd ().
Prolin
Team
2013-04-17
V1.0.5
1. Modified the 14.4.1 open() node;
2. Updated the time setting code, Modify
the ―pow-hwclock -w‖ to
―pow-hwclock -w -u‖;
3. Updated the fifth term of OsWlInit()
instruction; when the return value is
ERR_WL_NOSIM (without SIM
card), application can use some
functions without SIM card.
4. Updated the instruction of the
OsCheckBattery ().
Prolin
Team
2013-05-17
V1.0.6
1. Modified the description of ‗Timer‘.
2. Added description of ‗Delay‘.
3. Added description for registry table.
4. Modified the parameter description of
Value inOsRegGetValue ().
Prolin
Team
III
5. Modified the parameter description of
ShaOut inOsSHA ().
6. Updated the description of GUI.
7. Added ‗1200, V22‘ and‗2400, FC‘ to
the parts of synchronous variable for
MODEM.
2013-08-09
V1.0.7
1. Modified the Registry table.
2. Modified the data structure of Font.
3. Updated the OsCheckBattery()
4. Updated the chapter 15 ICC Reader
and chapter 16 RF Reader.
Prolin
Team
2013-10-22
V1.0.8
1. Added 4.11 Save the crash report for
system function.
2. Modified the brightness level to
[0~10] in the chapter of LCD.In
particular , 0 indicates closing the
backlight
3. Updated the key value definitions in
the chapter of Keyboard.
Prolin
Team
2013-10-31
V1.0.9
1. Updated the chapter of System
function
2. Modified the OsCodeConvert() in the
character conversion.
3. Added new interfaces OsPortReset()
and OsPortCheckTx() in the
Communication chapter.
4. Updated the Audio chapter, add a new
interface OsPlayWave().
Prolin
Team
2013-11-20
V2.0.0
1. Added the KeyVarType parameter
associated with the description of
0x02
2. Modified the parameters value ranges
in several chapters associated with
PED.
3. Modified the description of parameter
ucATQ0 in OsPiccAntiSel ().
4. Deleted OsPiccGetParam() and
OsPiccSetParam().
5. Updated the instruction of
OsRegGetValue().
6. Added notes of OsPortOpen().
7. Updated instructions of OsSysSleep()
8. Updated the Return code list in
chapter Network Configuration.
9. Added instruction of OsNetDns().
Prolin
Team
2014-2-25
V2.0.1
1. Modified the instruction of
OsWlSelSim().
Prolin
Team
IV
2. Added a return value
forOsMsrOpen().
3. Added new interfaces
OsWlLoginEx(), OsMount(),
OsUmount().
4. Add chapter 26 Barcode.
5. Add AES functions.
6. Updated the Appendix 4.
7. Modified the parameter Name in the
OsInstallFile().
8. Added an error code
―ERR_APP_MODE‖ for
theOsInstallFile().
9. Added a new interface
OsCheckPowerSupply().
10. Since Prolin2.4 upgrade, deleted the
unsuccessful code in chapter 7 LCD.
2014-3-4
V2.0.2
1. Updated the OsSysSleep().
2. Updated the WIFI module.
Prolin
Team
2014-3-24
V2.0.3
1. Modified the WIFI module.
Prolin
Team
2014-4-16
V2.0.4
1. Updated OsWifiConnect() and
OsWifiCheck().
2. Added a new interface
OsSysSleepEx().
3. Added new interface OsReboot() and
OsPowerOff().
4. Removed the MS-MOVE in
parameter MountFlags.
Prolin
Team
2014-6-3
V2.0.5
1. Modified the instruction of
OsPrnSetIndent().
2. Modified the functionality description
of OsModemCheck().
3. Modified the description of the
parameter TimeoutMS in
OsPortRecv().
4. Modified the value range of the
parameter Volume in OsPlayWave().
5. Modified the OsMifareOperate().
6. Listed the corresponding relation
between device node and serial port.
7. Updated the instructions of
OsWlSwitchSleep() and
OsWifiSwitchPower().
Prolin
Team
2014-07-10
V2.0.6
1. Updated the instructions of OsLog().
2. Updated the return value of
OsPedSetInterval().
3. Added a new interface
Prolin
Team
V
OsPedCancelPinEntry().
4. Added return values for
OsVerifySign() and
OsVerifySignExternal().
5. Updated the instruction of
OsCheckBattery().
6. Updated the Appendix 3 and
Appendix 4.
2014-10-09
V2.0.7
1. Updated the return value of
OsWlLogin() and add the
corresponding new instruction.
2. Modified int OsWifiClose(void) to
void OsWifiClose(void);
3. Modified the nodes of LCD,
keypad, touch screen devices.
Prolin
Team
2014-11-26
V2.0.8
1. Modified the instrunction of the
OsRunApp().
2. Added the U disk file format
limitation in OsMount().
3. Added the specification about
S920 in parameter ‗Channel‘ in
OsPortOpen().
4. Added the instruction of
OsNetPing().
5. Modified the instruction of
OsNetDns().
6. Modified the instruction of
OsNetSetConfig().
7. Added the instruction of
OsNetStartDhcp().
8. Modified the function and added a
new return value for
OsNetSetRoute().
9. Modified the function, return
values and instruction of
OsNetGetRoute().
10. Modified the instruction of
OsPppoeLogin().
11. Modified the instruction of
OsWILogin().
12. Modified the instruction of
OsWILoginEx().
13. Added WAVE file sampling
frequency limitation in
OsPlayWave().
14. Added new instructions for S920
models in appendix 4.
Prolin
Team
2014-12-18
V2.0.9
1. Added a new function OsNetPingEx()
to check the the status of connection.
Prolin
VI
2. Added some return code in 2.2 general
return code.
3. Added a return value and instruction in
OsPrnOpen().
4. Added some return values and
instruction in OsWlLock().
5. Added a new return value and
instruction in OsWlLogout().
6. Modified the description of the return
value in OsCheckBattery().
7. Added a new instruction in
OsNetSetRoute().
8. Added a new system upgrade block
with two functions
OsFirmwareGetVersion() and
OsFirmwareUpgrade() in the chapter of
System Function.
Team
2015-02-06
V2.1.0
1. Added a new return value
ERR_APP_NOT_EXIST in
OsRunApp().
2. Modified the instruction of
OsPedSetInterval().
3. Updated the parameter DataIn in
OsPedUpdatePinBlock().
4. Modified the instruction of
OsPedDesDukpt().
5. Modified the parameter DataInLen in
OsPedRsaRecover().
6. Modified the Appendix 1.
7. Added a new return value
ERR_WL_NOREG in OsWlInit()
function indicating registering GPRS
network failed.
8. Added a new note in wifi module like
this: At present, Prolin WIFI only
supports module with keyword
ro.fac.wifi is ―RS9110-N-11-02‖ or
―01‖.
9. Added a new note in OsPortOpen()
function: calling this function will
functions of close software flow control
and hardware flow control.
10. Added two lines of code in set the
configuration parameters of
communication port.
Prolin
Team
VII
2015-04-13
V2.1.1
1. Added the instruction of LCD size
and rotation method of different POS
models in Appendix 4.
2. Added a new return value
ERR_BATTERY_ABSENT in
function OsWifiOpen() and its
corresponding instruction.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 1
Contents
1 Introduction ....................................................................................................................... 14
1.1 Purpose ................................................................................................................... 14
1.2 Readers ................................................................................................................... 14
1.3 Prerequisite ............................................................................................................ 15
1.4 Related Documents ................................................................................................ 15
1.5 Abbreviation .......................................................................................................... 15
1.6 Document Conventions .......................................................................................... 16
2 Return Code and Parameter ............................................................................................... 19
2.1 Return code classification ...................................................................................... 19
2.2 General return code ................................................................................................ 20
2.3 Parameter Specification ......................................................................................... 21
3 Thread ................................................................................................................................ 23
4 System Function ................................................................................................................ 25
4.1 Return code list ...................................................................................................... 25
4.2 Data Definition ....................................................................................................... 26
4.3 Timeset ................................................................................................................... 27
4.3.1 OsSetTime ...................................................................................................... 27
4.3.2 OsGetTime ...................................................................................................... 27
4.4 Timer ...................................................................................................................... 28
4.4.1 OsTimerSet ..................................................................................................... 28
4.4.2 OsTimerCheck ................................................................................................ 28
4.5 Delay ...................................................................................................................... 28
4.5.1 OsSleep ........................................................................................................... 28
4.6 Thread .................................................................................................................... 28
4.7 Log ......................................................................................................................... 29
4.7.1 OsLogSetTag .................................................................................................. 29
4.7.2 OsLog ............................................................................................................. 29
4.8 Get the count value ................................................................................................ 30
4.8.1 OsGetTickCount ............................................................................................. 30
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 2
4.9 Get Appliaction information .................................................................................. 30
4.9.1 OsGetAppInfo ................................................................................................ 30
4.10 Buzzer .................................................................................................................... 31
4.10.1 OsBeep ........................................................................................................ 31
4.11 Run Application ..................................................................................................... 31
4.11.1 OsRunApp ................................................................................................... 31
4.12 Set and Read the registry table ............................................................................... 32
4.12.1 OsRegSetValue ........................................................................................... 32
4.12.2 OsRegGetValue .......................................................................................... 32
4.13 Install and uninstall files ........................................................................................ 33
4.13.1 OsInstallFile ................................................................................................ 33
4.13.2 OsUninstallFile ........................................................................................... 34
4.14 System firmware upgrade ...................................................................................... 34
4.14.1 OsFirmwareGetVersion .............................................................................. 34
4.14.2 OsFirmwareUpgrade ................................................................................... 35
4.15 Verify signature ..................................................................................................... 35
4.15.1 OsVerifySign .............................................................................................. 35
4.15.2 OsVerifySignExternal ................................................................................. 36
4.16 Get system version ................................................................................................. 37
4.16.1 OsGetSysVer ............................................................................................... 37
4.17 Determine whether on the base .............................................................................. 37
4.17.1 OsOnBase ................................................................................................... 38
4.18 Save the crash report .............................................................................................. 38
4.18.1 OsSaveCrashReport .................................................................................... 38
4.19 Mount and Unmount the external file system ........................................................ 39
4.19.1 OsMount ..................................................................................................... 39
4.19.2 OsUmount ................................................................................................... 40
5 Encryption and Decryption ................................................................................................ 41
5.1 Return code list ...................................................................................................... 41
5.2 Random number ..................................................................................................... 41
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 3
5.2.1 OsGetRandom ................................................................................................ 41
5.3 SHA algorithm ....................................................................................................... 42
5.3.1 OsSHA ............................................................................................................ 42
5.4 DES algorithm ....................................................................................................... 42
5.4.1 OsDES ............................................................................................................ 43
5.5 AES algorithm ....................................................................................................... 43
5.5.1 OsAES ............................................................................................................ 43
5.6 RSAalgorithm ........................................................................................................ 44
5.6.1 OsRSA ............................................................................................................ 44
5.6.2 OsRSAKeyGen ............................................................................................... 45
6 PED .................................................................................................................................... 47
6.1 Return code list ...................................................................................................... 47
6.2 Data Definition ....................................................................................................... 49
6.2.1 Key type .......................................................................................................... 49
6.2.2 Display attribute of Asterisk ........................................................................... 49
6.3 Data Structure ........................................................................................................ 49
6.3.1 Structure of RSA key ...................................................................................... 49
6.3.2 RSA key structure for verifying the ciphertext IC card PIN .......................... 50
6.4 Basic PED .............................................................................................................. 50
6.4.1 OsPedOpen ..................................................................................................... 50
6.4.2 OsPedGetVer .................................................................................................. 51
6.4.3 OsPedSetInterval ............................................................................................ 51
6.4.4 OsPedVerifyPlainPin ...................................................................................... 51
6.4.5 OsPedVerifyCipherPin ................................................................................... 53
6.4.6 OsPedEraseKeys ............................................................................................. 54
6.4.7 OsPedSetFunctionKey .................................................................................... 55
6.4.8 OsPedClose ..................................................................................................... 55
6.4.9 OsPedCancelPinEntry .................................................................................... 56
6.5 MK/SK ................................................................................................................... 56
6.5.1 OsPedWriteKey .............................................................................................. 56
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 4
6.5.2 OsPedWriteTIK .............................................................................................. 58
6.5.3 OsPedWriteKeyVar ........................................................................................ 60
6.5.4 OsPedSetAsteriskLayout ................................................................................ 60
6.5.5 OsPedGetPinBlock ......................................................................................... 61
6.5.6 OsPedUpdatePinBlock ................................................................................... 62
6.5.7 OsPedGetMac ................................................................................................. 63
6.5.8 OsPedDes ........................................................................................................ 64
6.5.9 OsPedGetKcv ................................................................................................. 65
6.5.10 OsPedDeriveKey ......................................................................................... 66
6.6 DUKPT .................................................................................................................. 67
6.6.1 OsPedGetPinDukpt ......................................................................................... 67
6.6.2 OsPedGetMacDukpt ....................................................................................... 69
6.6.3 OsPedDesDukpt .............................................................................................. 70
6.6.4 OsPedGetKsnDukpt ........................................................................................ 71
6.6.5 OsPedIncreaseKsnDukpt ................................................................................ 71
6.7 RSA ........................................................................................................................ 72
6.7.1 OsPedReadRsaKey ......................................................................................... 72
6.7.2 OsPedWriteRsaKey ........................................................................................ 72
6.7.3 OsPedRsaRecover .......................................................................................... 73
6.7.4 OsPedReadCipherRsaKey .............................................................................. 73
6.7.5 OsPedWriteCipherRsaKey ............................................................................. 74
6.8 AES ........................................................................................................................ 74
6.8.1 OsPedWriteAesKey ........................................................................................ 74
6.8.2 OsPedAes ........................................................................................................ 76
7 LCD ................................................................................................................................... 79
7.1 OsScrContrast ........................................................................................................ 81
7.2 OsScrBrightness ..................................................................................................... 81
7.3 OsScrGetSize ......................................................................................................... 82
8 Keyboard ........................................................................................................................... 83
8.1 OsKbBacklight ....................................................................................................... 86
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 5
9 Touch Screen ..................................................................................................................... 87
10 Signature Pad ................................................................................................................. 88
11 Printer ............................................................................................................................ 89
11.1 Return code list ...................................................................................................... 89
11.2 Open and Close ...................................................................................................... 90
11.2.1 OsPrnOpen .................................................................................................. 90
11.2.2 OsPrnReset .................................................................................................. 90
11.2.3 OsPrnClose ................................................................................................. 91
11.3 Printer settings ....................................................................................................... 91
11.3.1 OsPrnSetSize ............................................................................................... 91
11.3.2 OsPrnSetDirection ...................................................................................... 91
11.3.3 OsPrnSetGray ............................................................................................. 92
11.4 TypeSetting ............................................................................................................ 92
11.4.1 OsPrnSetSpace ............................................................................................ 92
11.4.2 OsPrnSetReversal ....................................................................................... 92
11.4.3 OsPrnSetIndent ........................................................................................... 93
11.4.4 OsPrnCheck ................................................................................................ 93
11.4.5 OsPrnGetDotLine ....................................................................................... 93
11.4.6 OsPrnSetFont .............................................................................................. 94
11.4.7 OsPrnSelectFontSize ................................................................................... 94
11.4.8 OsPrnFeed ................................................................................................... 95
11.4.9 OsPrnPrintf ................................................................................................. 95
11.4.10 OsPrnPutImage ........................................................................................... 95
11.4.11 OsPrnStart ................................................................................................... 96
11.5 POSIX .................................................................................................................... 97
11.5.1 open ............................................................................................................. 97
11.5.2 read .............................................................................................................. 97
11.5.3 Write ........................................................................................................... 97
11.5.4 Close ........................................................................................................... 99
12 Font Library ................................................................................................................. 101
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 6
12.1 Data structure ....................................................................................................... 101
12.2 Font operation ...................................................................................................... 102
12.2.1 OsEnumFont ............................................................................................. 102
12.2.2 OsOpenFont .............................................................................................. 102
12.2.3 OsCloseFont .............................................................................................. 103
12.2.4 OsGetFontDot ........................................................................................... 103
13 Code ............................................................................................................................ 107
13.1 Code Convert ....................................................................................................... 107
13.1.1 OsCodeConvert ......................................................................................... 107
14 MSR ............................................................................................................................ 109
14.1 Return code list .................................................................................................... 109
14.2 Data structure ....................................................................................................... 110
14.3 MSR control interface .......................................................................................... 110
14.3.1 OsMsrOpen ............................................................................................... 110
14.3.2 OsMsrClose ............................................................................................... 111
14.3.3 OsMsrReset ............................................................................................... 111
14.3.4 OsMsrSwiped ............................................................................................ 111
14.3.5 OsMsrRead ............................................................................................... 112
14.4 POSIX .................................................................................................................. 112
14.4.1 Open .......................................................................................................... 113
14.4.2 Read .......................................................................................................... 113
14.4.3 Close ......................................................................................................... 113
15 ICC Reader .................................................................................................................. 114
15.1 Return Code List .................................................................................................. 114
15.2 Data Structure ...................................................................................................... 116
15.2.1 IC card device control block ..................................................................... 116
15.2.2 ATR structure ............................................................................................ 117
15.2.3 APDU Request Structure .......................................................................... 117
15.2.4 APDU Response Structure ........................................................................ 118
15.3 API index ............................................................................................................. 118
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 7
15.3.1 sci_open .................................................................................................... 119
15.3.2 sci_get_fd .................................................................................................. 119
15.3.3 sci_get_dcb ............................................................................................... 119
15.3.4 sci_set_dcb ................................................................................................ 119
15.3.5 sci_read ..................................................................................................... 120
15.3.6 sci_write .................................................................................................... 120
15.3.7 sci_close .................................................................................................... 120
15.3.8 sci_lock ..................................................................................................... 121
15.3.9 sci_unlock ................................................................................................. 121
15.3.10 sci_powerup .............................................................................................. 121
15.3.11 sci_powerdown ......................................................................................... 121
15.3.12 sci_detect .................................................................................................. 122
15.3.13 sci_cold_reset ........................................................................................... 122
15.3.14 sci_warm_reset ......................................................................................... 122
15.4 Protocol processing function ................................................................................ 122
15.4.1 emv_atr_parse ........................................................................................... 122
15.4.2 iso7816_atr_parse ..................................................................................... 123
15.4.3 iso7816_pps .............................................................................................. 123
15.4.4 iso7816_ocs ............................................................................................... 123
15.4.5 iso7816_t1_ifsd_request ........................................................................... 124
15.4.6 iso7816_t0_exchange ................................................................................ 124
15.4.7 iso7816_t1_exchange ................................................................................ 124
15.5 Encapsulated Interfaces ....................................................................................... 125
15.5.1 OslccOpen ................................................................................................. 125
15.5.2 OsIccDetect ............................................................................................... 125
15.5.3 OsIccInit .................................................................................................... 126
15.5.4 OsIccExchange ......................................................................................... 127
15.5.5 OsIccClose ................................................................................................ 127
16 RF Reader .................................................................................................................... 129
16.1 Return Code List .................................................................................................. 129
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 8
16.2 Data Structure ...................................................................................................... 130
16.2.1 User Configuration Structure .................................................................... 130
16.2.2 Configuration Parameter Definition ......................................................... 131
16.3 ISO14443 --- Type A ........................................................................................... 132
16.3.1 iso14443_3a_req ....................................................................................... 132
16.3.2 iso14443_3a_wup ..................................................................................... 132
16.3.3 iso14443_3a_antisel .................................................................................. 133
16.3.4 iso14443_3a_halt ...................................................................................... 133
16.3.5 iso14443_3a_rats ...................................................................................... 133
16.4 ISO14443 --- Type B ........................................................................................... 134
16.4.1 iso14443_3b_req ....................................................................................... 134
16.4.2 iso14443_3b_wup ..................................................................................... 134
16.4.3 iso14443_3b_attri ..................................................................................... 134
16.4.4 iso14443_3b_halt ...................................................................................... 134
16.5 Half-duplex transmission protocol ....................................................................... 135
16.5.1 iso14443_4_transfer .................................................................................. 135
16.6 Encapsulate Interfaces ......................................................................................... 135
16.6.1 OsPiccOpen ............................................................................................... 135
16.6.2 OsPiccClose .............................................................................................. 136
16.6.3 OsPiccResetCarrier ................................................................................... 136
16.6.4 OsPiccPoll ................................................................................................. 136
16.6.5 OsPiccAntiSel ........................................................................................... 136
16.6.6 OsPiccActive ............................................................................................. 137
16.6.7 OsPiccTransfer .......................................................................................... 138
16.6.8 OsPiccRemove .......................................................................................... 138
16.6.9 OsMifareAuthority .................................................................................... 138
16.6.10 OsMifareOperate ...................................................................................... 139
16.6.11 OsPiccInitFelica ........................................................................................ 140
16.6.12 OsPiccIsoCommand ................................................................................. 140
16.6.13 OsPiccSetUserConfig ............................................................................... 140
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 9
16.6.14 OsPiccGetUserConfig ............................................................................... 141
16.7 Note of touch screen and RF reader programming .............................................. 141
17 Communication Port ................................................................................................... 143
17.1 Data Definition ..................................................................................................... 143
17.2 Communication control ....................................................................................... 144
17.2.1 OsPortOpen ............................................................................................... 144
17.2.2 OsPortClose .............................................................................................. 145
17.2.3 OsPortSend ............................................................................................... 145
17.2.4 OsPortRecv ............................................................................................... 146
17.2.5 OsPortReset ............................................................................................... 146
17.2.6 OsPortCheckTx ......................................................................................... 147
17.3 POSIX .................................................................................................................. 147
17.3.1 Open .......................................................................................................... 147
17.3.2 Read .......................................................................................................... 148
17.3.3 Write ......................................................................................................... 148
17.3.4 Close ......................................................................................................... 148
17.3.5 Query the buffer data of communication port ........................................... 148
17.3.6 Clear the buffer data of communication port ............................................ 148
17.3.7 Set the configuration parameters of communication port ......................... 149
18 MODEM ...................................................................................................................... 153
18.1 Return code list .................................................................................................... 153
18.2 Data structure ....................................................................................................... 161
18.3 OsModemOpen .................................................................................................... 166
18.4 OsModemClose .................................................................................................... 166
18.5 OsModemSwitchPower ....................................................................................... 166
18.6 OsModemConnect ............................................................................................... 167
18.7 OsModemCheck .................................................................................................. 168
18.8 OsModemExCmd ................................................................................................ 169
18.9 OsModemHangup ................................................................................................ 170
18.10 OsModemSend ................................................................................................. 170
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 10
18.11 OsModemRecv ................................................................................................. 170
18.12 OsPppomLogin ................................................................................................. 171
18.13 OsPppomCheck ................................................................................................ 173
18.14 OsPppomLogout ............................................................................................... 173
19 Network Communication ............................................................................................ 175
19.1 TCP programming ............................................................................................... 175
19.2 UDPprogramming ................................................................................................ 178
20 Network Configuration ............................................................................................... 181
20.1 Return code list .................................................................................................... 181
20.2 Data Definition ..................................................................................................... 182
20.2.1 Physical channel list .................................................................................. 182
20.3 Network Configuration interface ......................................................................... 183
20.3.1 OsNetAddArp ........................................................................................... 183
20.3.2 OsNetPing ................................................................................................. 184
20.3.3 OsNetPingEx ............................................................................................. 184
20.3.4 OsNetDns .................................................................................................. 185
20.3.5 OsNetSetConfig ........................................................................................ 186
20.3.6 OsNetGetConfig ....................................................................................... 187
20.3.7 OsNetStartDhcp ........................................................................................ 188
20.3.8 OsNetCheckDhcp ..................................................................................... 188
20.3.9 OsNetStopDhcp ........................................................................................ 189
20.3.10 OsNetSetRoute ......................................................................................... 189
20.3.11 OsNetGetRoute ......................................................................................... 190
20.3.12 OsPppoeLogin .......................................................................................... 190
20.3.13 OsPppoeCheck .......................................................................................... 190
20.3.14 OsPppoeLogout ........................................................................................ 191
21 GPRS/CDMA .............................................................................................................. 193
21.1 Return code list .................................................................................................... 193
21.2 Wireless module interface .................................................................................... 194
21.2.1 OsWlLock ................................................................................................. 194
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 11
21.2.2 OsWlUnLock ............................................................................................ 195
21.2.3 OsWlInit() ................................................................................................. 195
21.2.4 OsWlSwitchPower .................................................................................... 196
21.2.5 OsWlSwitchSleep ..................................................................................... 196
21.2.6 OsWlGetSignal ......................................................................................... 197
21.2.7 OsWlCheck ............................................................................................... 197
21.2.8 OsWlLogin ................................................................................................ 198
21.2.9 OsWlLoginEx ........................................................................................... 200
21.2.10 OsWlLogout ............................................................................................. 202
21.3 Wireless module information settings ................................................................. 202
21.3.1 OsWlSelSim .............................................................................................. 202
22 WIFI ............................................................................................................................ 204
22.1 Return Code List .................................................................................................. 204
22.2 Encryption type List ............................................................................................. 205
22.3 Data Structure ...................................................................................................... 205
22.4 OsWifiOpen ......................................................................................................... 207
22.5 OsWifiClose ......................................................................................................... 208
22.6 OsWifiSwitchPower ............................................................................................ 208
22.7 OsWifiScan .......................................................................................................... 208
22.8 OsWifiConnect .................................................................................................... 209
22.9 OsWifiDisconnect ................................................................................................ 210
22.10 OsWifiCheck .................................................................................................... 210
22.11 OsWifiCmd ...................................................................................................... 211
23 File System .................................................................................................................. 213
24 System Information ..................................................................................................... 214
25 Audio ........................................................................................................................... 217
25.1 OsPlayWave ......................................................................................................... 217
26 Barcode ........................................................................................................................ 219
26.1 General Definiton ................................................................................................. 219
26.2 OsScanOpen ......................................................................................................... 219
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 12
26.3 OsScanRead ......................................................................................................... 220
26.4 OsScanClose ........................................................................................................ 220
27 Power Management ..................................................................................................... 221
27.1 OsCheckBattery ................................................................................................... 221
27.2 OsCheckPowerSupply ......................................................................................... 222
27.3 OsSysSleep .......................................................................................................... 222
27.4 OsSysSleepEx ...................................................................................................... 223
27.5 OsReboot .............................................................................................................. 223
27.6 OsPowerOff ......................................................................................................... 224
Appendix 1 PIN Block Format ............................................................................................... 225
Appendix 2 EPS PINBLOCK Format .................................................................................... 229
Appendix 3 Registry Table .................................................................................................... 230
Appendix 4 Validity of models and contents ......................................................................... 233
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 13
Table List
Table 1 Abbreviation ........................................................................................................ 15
Table 2 Return code classification List ............................................................................ 19
Table 3 General return code list ....................................................................................... 20
Table 4 System function return code list .......................................................................... 25
Table 5 Macro definitions of file types ............................................................................ 25
Table 6 Encryption and decryption return code list ......................................................... 41
Table 7 PED Return code list ........................................................................................... 47
Table 8 Key Types ........................................................................................................... 49
Table 9 Layout attributes of asterisk ................................................................................ 49
Table 10 The color values of asterisk ............................................................................... 49
Table 11 Printer return code list ....................................................................................... 89
Table 12 MSR return code list ....................................................................................... 109
Table 13 ICC reader return code list .............................................................................. 114
Table 14 Return Code List ............................................................................................. 129
Table 15 Macro definition list of communication ports ................................................. 143
Table 16 Return code list of USB port functions ........................................................... 143
Table 17 Modem return code list ................................................................................... 153
Table 18 Variable definition of ST_MODEM_SETUP ................................................. 162
Table 19 Network Configuration return code list .......................................................... 181
Table 20 Physical Channel List ...................................................................................... 182
Table 21 GPRS/CDMA return code list ......................................................................... 193
Table 22 Return Code List ............................................................................................. 204
Table 23 Encryption type List ........................................................................................ 205
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 14
1 Introduction
1.1 Purpose
This document was previously named as Prolin API Programming Guide.
Prolin SDK supports necessary tools and resources to create Prolin applications, they are
different from the application that running on the background of Prolin system. Based on the
Prolin OS devices, they can run as an independent executive program.
Local applications can access all features of Prolin OSsave data in the local file system and
can even communicate with various installed programs through custom URL. It uses the
default or customized GUI framework to develop the local GUI application program for
Prolin OS and installs GUI system package. This framework not only provides a lot of default
behaviors but also provides some connections. Developers can customize and extend its
behavior through these connections.
1.2 Readers
This document is primarily targeted for Prolin OS developers, who are expected to create
Prolin applications. The purpose is to introduce the framework of Prolin application program;
demonstrate some of the key customization points in GUI and other significant frameworks;
and provide programming aid to the API interfaces, which support driver control to the Prolin
OS hardware platform. It will also provide guidance to design.
The interface provided by Prolin is based on Linux system calls or POSIX interface.
Considering the compatibility requirements of the PaxME OS and applications, it will
encapsulate a set of OSAL interface which begins with the prefix ―Os‖. The access of other
devices and system functions will provide the demo code to guide developers how to use the
POSIX or system library to program.
For details, refer to the following document.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 15
In this document, the interface that begins with the prefix ―Os‖ has been defined in osal.h of
SDK, unless otherwise specified.
1.3 Prerequisite
The prerequisites for this document are as follows:
Basic understanding of Linux.
Basic information about processes, threads and Linux system functions and their roles in
application development.
Familiar with memory management and process management.
Familiar with Linux input subsystem and frame buffer.
For the Linux user, you should use Linux kernel version greater than 2.6.22 to run the Prolin
SDK. For the Windows user, you should use Windows XP or higher to run the Prolin SDK.
You can get the Prolin SDK from PAX support team.
1.4 Related Documents
Prolin Terminal Manager Operating Guide
Prolin SDK Tutorial
Prolin GUI Programming Guide
Prolin App Development Guide
Prolin PCKit Operating Guide
1.5 Abbreviation
Table 1 Abbreviation
Abbreviation
Description
API
Application Programming Interface
CDPD
Cellular Digital Packet Data
CHAP
Challenge Handshake Authentication Protocol
DHCP
Dynamic Host Configuration Protocol
DUKPT
Derived unique key per transaction
EMV
Europay, MasterCard, Visa
EMV is a global standard for credit and debit
payment cards based on chip card technology
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 16
GGSN
Gateway GPRS Support Node
GPRS
General Packet Radio Service
IC
Integrated circuit
IC Card
Integrated Circuit Card
IPCP
IP Control Protocol
KSN
Key Serial Number
KCV
Validation of the key plaintext.
LCP
Link Control Protocol
LRC
Longitude Redundancy Check
MODEM
Modulator-demodulator.
MSR
Magnetic Stripe Reader
NCP
Network Control Protocol
PAP
Password Authentication Protocol
PCD
Proximity Coupling Device
PED
PIN Entry Device
PICC
Proximity Integrated Circuit Card
POS
Point of Sale
PPP
Point-to-Point Protocol
PUK
Public Key
SAM
Security Authentication Module
SGSN
Serving GPRS Support Node
SIM
Subscriber Identity Module
SMS
Short Message Service
SSL
Secure Sockets Layer
TWK
Transaction working key
1.6 Document Conventions
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 17
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 19
2 Return Code and
Parameter
2.1 Return code classification
List the types and values of the return code which appeared in this document.
Table 2 Return code classification List
Type
Value(Decimal)
Description
General return code
-1000~-1999
As general return code for API.
System function
-2200~-2299
Power Management
-2300~-2399
Encryption and
Decryption
-2400~-2499
Font library
-2500~-2599
LED display
-2600~-2699
MSR
-2700~-2799
ICC Reader
-2800~-2899
RF Reader
-2900~-2999
Communication port
-3000~-3099
MODEM
-3100~-3299
IP Network
Configuration
-3300~-3399
PED
-3800~-3899
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 20
2.2 General return code
Table 3 General return code list
Macro
Value
Description
RET_OK
0
Success
ERR_INVALID_HANDLE
-1000
Invalid handle
ERR_TIME_OUT
-1001
Timeout
ERR_APP_NOT_EXIST
-1002
Application does not exists
ERR_INVALID_PARAM
-1003
Invalid Parameters
ERR_DEV_NOT_EXIST
-1004
Device not exists.
ERR_DEV_BUSY
-1005
Device is busy.
ERR_DEV_NOT_OPEN
-1006
Device is not open.
ERR_ACCESS_DENY
-1007
Access denied.
ERR_FONT_NOT_EXIST
-1008
Font does not exist.
ERR_FILE_FORMAT
-1009
File format error.
ERR_USER_CANCEL
-1010
User cancels.
ERR_NO_PORT
-1011
No communication port available.
ERR_NOT_CONNECT
-1012
Not Connected
ERR_MEM_FAULT
-1013
Memory fault.
ERR_SYS_BAD
-1014
System configuration error.
ERR_SYS_NOT_SUPPORT
-1015
System does not support this
function.
ERR_STR_LEN
-1016
Character string is too long.
ERR_TOO_MANY_HANDLE
-1017
Too many handle.
ERR_APP_MODE
-1018
Mode error.
ERR_FILE_NOT_EXIST
-1019
File does not exist.
ERR_TS_DISABLE
-1020
Touch screen is not open.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 21
ERR_FONT_CODE -1021 Character encoding error
ERR_VERSION_TOO_LOW
-1022
The version number is too low
ERR_BATTERY_ABSENT
-1023
The batter is absent
2.3 Parameter Specification
API parameters are divided into input parameters and output parameters. The type of the
parameters has been labeled in the detailed API specification.
All string input and output parameters end with "\x00", and String parameters must indicate
the length limit.
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 23
3 Thread
Prolin supports multithread development. The platform provides standard POSIX thread
library (pthread) for developers to use.
The pthread header file is located in the installation directory of Prolin SDK:
tool chains\arm-linux\arm-softfloat-linux-gnu\include\pthread.h
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 25
4 System Function
4.1 Return code list
Table 4 System function return code list
Macro
Value
Description
ERR_FILE_NOT_FOUND
-2201
File can‘t be found.
ERR_VERIFY_SIGN_FAIL
-2204
Verify signature failed.
ERR_NO_SPACE
-2205
No enough system space.
ERR_NEED_ADMIN
-2207
Permission denied. (Need higher
permissions.)
Table 5 Macro definitions of file types
Macro
Value
Description
FILE_TYPE_APP
1
Application package
FILE_TYPE_APP_PARAM
2
Application data file
FILE_TYPE_SYS_LIB
3
System dynamic library file
FILE_TYPE_PUB_KEY
4
User public key file
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 26
FILE_TYPE_AUP
5
Application upgrade package
4.2 Data Definition
LOG_T(Enumerate LOG types)：
LOG_T
：
typedef enum{
LOG_DEBUG, //Display debugging information
LOG_INFO, // Display prompt information
LOG_WARN, // Display warning information
LOG_ERROR, // Display error information
} LOG_T;
ST_TIME (structure of time)
ST_TIME
：
typedef struct{
int Year; //year 1970– 2037
int Month; //month 1 –12
int Day; //day 1 –31
int Hour; //hour 0 – 23
int Minute; //minute 0 –59
int Second; //second 0 –59
int DayOfWeek; //Monday–Sunday
（
Only effective for reading time
）
} ST_TIME;
ST_TIMER (structure of timer)
ST_TIMER
：
typedef struct{
unsigned long Start;
unsigned long Stop;
unsigned long TimeLeft;
} ST_TIMER;
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 27
ST_APP_INFO (structure of application information)
ST_APP_INFO
：
typedef struct{
char Id[32];
char Name[64];
char Bin[64];
char Artwork[64];
char Desc[64];
char Vender[32];
char Version[32] ;
} ST_APP_INFO;
4.3 Timeset
4.3.1 OsSetTime
Prototype
int OsSetTime(const ST_TIME *Time);
Function
Set the system time, the week value will not work.
Parameters
Time 【Input】
Time structure
Return
RET_OK
Success
ERR_NEED_ADMI
N
Need higher permissions.
ERR_INVALID_PA
RAM
Invalid parameter
Instruction
Only the main application has permission to set the time, otherwise, it will return
ERR_NEED_ADMIN.
4.3.2 OsGetTime
Prototype
void OsGetTime(ST_TIME *Time);
Function
Get the system time.
Parameters
Time 【Output】
Time structure
Return
None
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 28
4.4 Timer
4.4.1 OsTimerSet
Prototype
int OsTimerSet(ST_TIMER *Timer,
unsigned long Ms);
Function
Set the timer.
Parameters
Timer 【Output】
Timer
Ms 【Input】
Time【unit:ms】
Return
RET_OK
Success
ERR_INVALID_PAR
AM
Invalid parameter
Instruction
4.4.2 OsTimerCheck
Prototype
unsigned long OsTimerCheck(ST_TIMER *Timer);
Function
Check the remaining time of a specified time.
Parameters
Timer 【Input】
Timer
Return
>=0
The remaining time.【unit:ms】
ERR_INVALID_PA
RAM
Invalid parameter
Instruction
4.5 Delay
4.5.1 OsSleep
Prototype
voidOsSleep(unsigned int Ms);
Function
System delay, the delay process will not be interrupted by signal.
Parameters
Ms 【Input】
The delay time【unit:ms】
Return
None
Instruction
4.6 Thread
To implement the thread management, please refer to the following code.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 29
Example:
#include <pthread.h>
static pthread_t ntid;
static void *thread_fn(void *arg)
{
printf("This is child thread\n");
return ((void *)0);
}
int main()
{
printf("This is main thread\n");
if(pthread_create(&ntid, NULL, thread_fn, NULL) != 0)
printf("can't create thread\n");
sleep(5);
return 0;
}
4.7 Log
4.7.1 OsLogSetTag
Prototype
void OsLogSetTag(const char *Tag);
Function
Set the LOG tag.
Parameters
Tag【Input】
LOG information tag
Return
None
Instruction
Set the LOG tag, and the default tag is null.
Suggest setting Tag to be an application name. It supports up to 32 bytes, when
- it is greater than 32 bytes, just use the first 32 bytes.
When the Tag is an empty string or NULL, the OsLog () will not work.
4.7.2 OsLog
Prototype
int OsLog(LOG_T Prio,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 30
const char *fmt,
…);
Function
Record the LOG information.
Parameters
Prio【Input】
LOG type
fmt 【Input】
Format of log information
Return
RET_OK
Success
ERR_INVALID_PAR
AM
Invalid parameter
Instruction
If you forget to call OsLogSetTag(), the OsLog() function won‘t work.
4.8 Get the count value
4.8.1 OsGetTickCount
Prototype
unsigned long OsGetTickCount(void);
Function
Get the system count value.
Parameters
None
Return
>0
Count value.【unit:ms】
Instruction
The value represents the time from the boot to the present time.
4.9 Get Appliaction information
4.9.1 OsGetAppInfo
Prototype
int OsGetAppInfo(ST_APP_INFO AppInfo[],
int InfoCnt);
Function
Get the application information.
Parameters
AppInfo 【Output】
Array of AppInfo structure.
InfoCnt 【Input】
The number of Apps that can be stored in the array.
Return
>=0
Returns the number of obtained App information
ERR_NEED_ADMI
N
Need higher permission
ERR_INVALID_PA
RAM
Invalid parameter
Instruction
1. Only the main application has permission to get the information.
2. When the number of existing applications is more than InfoCnt, the
InfoCnt shall prevail.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 31
4.10 Buzzer
4.10.1 OsBeep
Prototype
void OsBeep(int ToneType, int DurationMs)；
Function
The buzzer.
Parameters
ToneType 【Input】
Tone type. The value ranges from 1 to 7.
DurationMs 【Input】
Duration: the value ranges from 10 to 10000.
【unit:ms】
Return
None
Instruction
If ToneType<1, set it to 1, if ToneType>7, set it as 7.
If DurationMs<10, set it to 10, if DurationMs>10000, set it to 10000.
4.11 Run Application
4.11.1 OsRunApp
Prototype
int OsRunApp(char *AppId,
char **Argv,
void *Data,
RUNAPP_CB CbOut,
RUNAPP_CB CbErr);
Function
Switch to a specified sub-application.
Parameters
AppId 【Input】
sub-application ID
Argv 【Input】
Argument list, it can be NULL if we do not need that.
Data 【Input】
Custom data, it will be passed to CbOut() and CbErr() to
call back.
CbOut 【Input】
Callback function of the standard output information.
CbErr 【Input】
Callback functions of the standard error information.
Return
RET_OK
Success
ERR_APP_NOT_EXIST
Sub-application does not exist.
ERR_ACCESS_DENY
Access denied
ERR_APP_MODE
Mode Error
ERR_INVALID_PARAM
Invalid parameter
ERR_NEED_ADMIN
Need higher permission.
Instruction
1. Only the main application has permission to switch application, otherwise,
it will return ERR_NEED_ADMIN.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 32
2. Switch to a specified sub-application, but switching to the main
application is not allowed, if ―MAINAPP‖ is passed in to AppId,
ERR_INVALID_PARAM will be returned.
3. This will output the standard output information and standard error
information of the sub-application to CbOut () and CbErr (), respectively.
For the multi-line standard output and standard error, the callback function
will be called multiple times.The callback function is defined as follows:
typedef void (*RUNAPP_CB)(char *appid, char *str, void *data);
4.12 Set and Read the registry table
OsGetTerminalInfo() and OsReadSn() which applied to Prolin 2.3 have been deleted, and the
related functions can be implemented by calling OsRegGetValue().
4.12.1 OsRegSetValue
Prototype
int OsRegSetValue(const char *Key,
const char *Value);
Function
Set system parameters.
Parameters
Key 【Input】
System configuration name, it needs
ending with'\0'.
Value 【Input】
The parameter value cannot be null and should
be less than 64 bytes. It needs ending with '\0'.
Return
RET_OK
Success
ERR_INVALID_PARAM
Invalid Parameters
ERR_NEED_ADMIN
Need higher permissions.
Instruction
The system configuration name can only be set beginning with ―persist.sys.‖
For example, ―persist.sys.app0.pic‖.
4.12.2 OsRegGetValue
Prototype
int OsRegGetValue(const char *Key,
char *Value);
Function
Read system parameters.
Parameters
Key 【Input】
System configuration name, it needs
ending with'\0'.
Value 【Output】
The parameter value cannot be null and it must
be more than 64 bytes.
Return
>=0
Read the string length
ERR_INVALID_PARAM
Invalid Parameters
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 33
Instruction
The system configuration name can only be set beginning with ―ro.fac.‖ or
―persist.sys.‖ About the ―ro.fac.‖, users can refer to registry table.
If the query parameter does not exist or the parameter value is empty, it‘ll
return 0 and the output parameter Value will be ―‖.
4.13 Install and uninstall files
4.13.1 OsInstallFile
Prototype
int OsInstallFile(const char *Name,
const char *FileName,int FileType);
Function
Install application and system files.
Parameters
Name 【Input】
When FileType is FILE_TYPE_PUB_KEY,
assign the value from "uspuk0" to "uspuk8" to
Name and it represents the user public key
ranging from 0 to 8.
When FileType is
FILE_TYPE_APP_PARAM N
Name is the corresponding ID of the
parameter files.
When FileType is the other type, Name is
invalid, and it can be NULL.
FileName 【Input】
The filename which needs to be installed.
FileType
FILE_TYPE_APP (the application package)
FILE_TYPE_APP_PARAM (the application
data file)
FILE_TYPE_SYS_LIB (the dynamic library
file)
FILE_TYPE_PUB_KEY (the user public key
file)
FILE_TYPE_AUP(the application update
package)
Return
RET_OK
Success
ERR_PUK_NOT_EXIST
The specified user public key does not exist.
ERR_FILE_NOT_FOUN
D
FileName does not exist.
ERR_FILE_FORMAT
FileName format error.
ERR_INVALID_PARA
M
Invalid Parameters
ERR_VERIFY_SIGN_F
AIL
Signature verification failed.
ERR_APP_MODE
Mode error
Instruction
Name will be valid only when the FileType is FILE_TYPE_PUB_KEY or
FILE_TYPE_APP_PARAM, other types are invalid.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 34
4.13.2 OsUninstallFile
Prototype
int OsUninstallFile(const char *AppName,
int FileType);
Function
Uninstall applications and system files.
Parameters
AppName【Input】
When the FileType is FILE_TYPE_APP, it means
AppName is the Application ID which needs to be
deleted.
When the FileType is FILE_TYPE_SYS_LIB,
AppName is the name of system library.
FileType
FILE_TYPE_APP (Application package, the
application has installed all the files.)
FILE_TYPE_SYS_LIB (System library file)
Return
RET_OK
Success
ERR_APP_NOT_EXIST
The application specified by AppName does
not exist.
ERR_FONT_NOT_EXIST
The font library does not exist.
Instruction
This function is only used for unloading application and parts of system files.
4.14 System firmware upgrade
4.14.1 OsFirmwareGetVersion
Prototype
int OsFirmwareGetVersion(char *Version, int Size);
Function
Acquire system firmware version.
Parameters
Version【output】
Pointer to the buffer, 64 bytes is recommended for the
buffer length.
Size 【Input】
Buffer length
Return
RET_OK
Success
ERR_INVALID_P
ARAM
Invalid parameter
Instruction
1. The acquired version information is MAIN_VERSION-SVN_VERSION
Take ―2.6.26-r1789‖ as an example, MAIN_VERSION is"2.6.26" and
SVN_VERSION is "r1789".
2. The user can decide whether the firmware needs upgrading by judging the
SVN_VERSION.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 35
4.14.2 OsFirmwareUpgrade
Prototype
int OsFirmwareUpgrade(const char *FwFileName);
Function
Upgrade system firmware.
Parameters
FwFileName
【Input】
Firmware filename, an example of filename format could be:
prolin-2.4.26-CCV-r1918.zip
Return
RET_OK
Update succeeded
RR_FILE_NOT_FOUND
‗FwFileName‘ file doesn‘t exist
ERR_VERSIN_TOO_LOW
System package version is too low
ERR_VERIFY_SIGN_FAIL
Verify signature failed
ERR_AP_MODE
Application mode error
ERR_INVALID_PARAM
Invalid parameter
Instruction
1. Only the main application gets the permission to upgrade the system
firmware.
2. The function will be obstructed during the upgrade process, if an interface
prompt is needed, then it has to be done by starting another process.
3. The power should never be cut off during the upgrade process, otherwise the
device won‘t be able to run again.
4. The upgrade will only take effect after reboot.
4.15 Verify signature
The Prolin provides a function to verify the file signature. Use this interface to verify the
signature before using the files.
4.15.1 OsVerifySign
Prototype
int OsVerifySign(const char *FileName,
int PUKType);
Function
Verify the file signature specified by FileName to see whether it is legal or not,
the signature data is included in the file.
Parameters
FileName 【Input】
The file name which contains the path.
PUKType【Input】
PUK_TYPE_M
The public key of manufacturers. It is used to do the
signature verification for firmware released by
manufacturer.
PUK_TYPE_US_PUK
The public key of user signature certificate, it is used
to do the signature verification for the public key
certificate.
PUK_TYPE_USER0~PUK_TYPE_USER8
The public key of users, it is used to do the signature
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 36
verification for user application.
Return
RET_OK
Success
ERR_VERIFY_SIGN_FAIL
Illegal signature.
ERR_FILE_NOT_EXIST
The file does not exist.
ERR_DEV_BUSY
Device is busy.
ERR_INVALID_PARAM
Invalid parameter
Instruction
1. This function is only used for the application to verify the application
parameter file, for example, to verify the root certificate defined by the
application.
2. In order to avoid validation repetition, it should not use this function to
verify the legitimacy of the file until the file is installed. (System will
verify automatically in OsInstallFile()).
4.15.2 OsVerifySignExternal
Prototype
int OsVerifySignExternal(const char *FileName,
const void *SignData,
int PUKType);
Function
Verify the file signature specified by FileName to see whether it is legal or not.
The file does not include the signature data.
Parameters
FileName 【Input】
The file name which contains the path.
SignData 【Input】
Signature data, it has 284 bytes.
PUKType【Input】
PUK_TYPE_M
The public key of Manufacturers. It is used to do
the signature verification for firmware released by
manufacturer.
PUK_TYPE_US_PUK
The public key of user signature certificate, it is
used to do the signature verification for the public
key certificate.
PUK_TYPE_USER
The public key of users, it is used to do the
signature verification for user application.
Return
RET_OK
Success
ERR_VERIFY_SIGN_FAIL
Illegal signature.
ERR_FILE_NOT_EXIST
The file does not exist.
ERR_DEV_BUSY
Device is busy.
ERR_INVALID_PARAM
Invalid parameter
Instruction
1. This function is only used for the application to verify the application
parameter file, for example, to verify the root certificate defined by the
application.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 37
2. In order to avoid repeating validation, –the user should use this function to
verify the legitimacy of the file before installing the file. (System will
verify automatically in OsInstallFile ()).
4.16 Get system version
This interface is reserved for future use.
4.16.1 OsGetSysVer
Prototype
void OsGetSysVer(int VerType,
char *Version);
Function
Read information of the system version.
Parameters
VerType
Version types:
TYPE_OS_VER Operating system version
TYPE_OSAL_VERAPI Library version
TYPE_DRIVER_VER Driver version
TYPE_PED_VER built-in PED version
TYPE_MSR_VER MSR version
TYPE_ICC_VER ICC Reader version
TYPE_PCD_VER PCD Reader version
TYPE_EMVL1_VER EMV Level1 version
TYPE_PRINTER_VER Printer version
TYPE _MODEM_VER Modem version
TYPE_ETH_VER Netcard version
TYPE_GPRS_VER GPRS version
TYPE_CDMA_VER CDMA version
TYPE_TD_VER TD version
TYPE_WIFI_VER WIFI version
TYPE_BT_VER Bluetooth version
Version【Output】
Version information. (Ending with ―\0‖, and length <=31
bytes)
Return
None
Instruction
1. If Version[0] is equal to 0x00,it means the corresponding module does not
exist,
2. The buffer size of version must be greater than31 bytes.
4.17 Determine whether on the base
Prolin can determine whether the handset is on the base or not. Since the S series doesn‘t have
any bases, so it can‘t support this function.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 38
4.17.1 OsOnBase
Prototype
int OsOnBase(void);
Function
Determines whether the handset is on the base.
Parameters
None
Return
1
yes
0
no
Instruction
This function is only applicable to handset with base.
4.18 Save the crash report
Prolin supports monitoring program state. Once the program crashes, it will generate crash
report in the directory‗/data/tombstones‘ after calling this function.
4.18.1 OsSaveCrashReport
Prototype
void OsSaveCrashReport(ing sig);
Function
Save the crash report.
Parameters
Sig
Signal value
Return
None
Instruction
Method one
Through the function signal(SIG_XXX, OsSaveCrashReport);
OsSaveCrashReport will be registered as signal handler, for example:
signal(SIGILL, OsSaveCrashReport);
signal(SIGABRT, OsSaveCrashReport);
signal(SIGBUS, OsSaveCrashReport);
signal(SIGFPE, OsSaveCrashReport);
signal(SIGSEGV, OsSaveCrashReport);
signal(SIGSTKFLT, OsSaveCrashReport);
Method two
During the signal handler process, call OsSaveCrashReport (sig) to save
the error message. For example:
int mysighandler(int sig)
{
do_something();
OsSaveCrashReport(sig);
}
The recommended signals are SIGILL, SIGABRT, SIGBUS, SIGFPE,
SIGSEGV and SIGSTKFLT.
After calling this function, it will ignore the signal that corresponds to sig. That
is, it calls the signal (sig, SIG_IGN) in function OsSaveCrashReport ().
In Terminal Manager(TM), it can export the report to U disk.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 39
4.19 Mount and Unmount the external file system
4.19.1 OsMount
Prototype
intOsMount(const char *Source,
const char *Target,
const char *FileSystemType,
unsigned long MountFlags,
const void *Data);
Function
Mount the source file system to the target file system.
Parameters
Source 【Input】
The file system that needs to be mounted, it is usually a
device that locates in /dev/block/directory and the
path length cannot exceed 128 bytes.
Target 【Input】
The target file directory that the file system will mount to
must be in the /mnt/ directory-whose length cannot
exceed 128 bytes.
FileSystemType
【Input】
File system type that needs to be mounted- can be signed
as vfat―
MountFlags
【Input】
Mount flag, it can be the combinations of the following
flags:
MS_DIRSYNC: Synchronize the directory updates.
MS_MANDLOCK: Allow the mandatory locks on
files.
MS_NOATIME: Need not to update the access
time.
MS_NODEV: Don't allow accessing to device file.
MS_NODIRATIME: Don't allow updating the
access time on directory.
MS_NOEXEC: Don't allow execute programs on
the mounted file system.
MS_NOSUID: When executing program, do not
follow to the set-user-ID and set-group-ID.
MS_RDONLY: Specify the file system as
read-only.
MS_RELATIME: When a file is accessed, if the
last access time (atime) is less than or equal to the
last modification time (mtime) or last status change
time (ctime), then update the last access time (atime)
values.
MS_SILENT: Stop writing warning information to
the system kernel log
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 40
MS_STRICTATIME: Always updating the last
access time(atime).
MS_SYNCHRONOUS: Synchronize the file
updates.
Data【Input】
The user-defined additional data.
Return
RET_OK
Success
ERR_INVALID_P
ARAM
Invalid parameter
ERR_STR_LEN
The string is overlength.
ERR_NEED_AD
MIN
Need higher permissions.
Instruction
Only the main application can mount, otherwise it will fail to mount and return
ERR_NEED_ADMIN.
Note: currently the only supported U disk format is FAT32;
4.19.2 OsUmount
Prototype
intOsUmount(const char *Target,
int Flags);
Function
Unmount the file system.
Parameters
Target 【Input】
The file system that needs to unmount, it must be in the
/mnt/ directory, and the path length cannot exceed128
bytes.
Flags 【Input】
Unmount flag, it can be combination of the following
flags:
MNT_DETACH: Lazy umount, the mount point
is inaccessible after execution; it will unmount
only when the mount point is not busy.
MNT_EXPIRE:The mount point is marked as
expired
UMOUNT_NOFOLLOW: If the target is a
symbolic link, do not reduce the reference count.
Return
RET_OK
Success
ERR_INVALID_PA
RAM
Invalid parameter
ERR_STR_LEN
The string is overlength.
ERR_NEED_ADMI
N
Need higher permissions.
Instruction
Only the main application can unmount, otherwise it fails to unmount and
returns ERR_NEED_ADMIN.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 41
5 Encryption and
Decryption
5.1 Return code list
Table 6 Encryption and decryption return code list
Macro
Value
Description
ERR_DATA_TOO_BIG
-2400
The encrypted data of RSA is greater
than module.
ERR_GEN_RANDOM
-2401
Fail to generate random numbers.
ERR_GEN_FAIL
-2402
Fail to generate RSA key pairs.
5.2 Random number
Prolin supports true random number, and provides the application interface to generate true
random number.
5.2.1 OsGetRandom
Prototype
void OsGetRandom(unsigned char *Random,
int RandomLen);
Function
Read the true random number.
Parameters
Random 【Output】
Storing the pointer of random number.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 42
RandomLen
Length of random number which needs to be read.
(<=4096bytes)
Return
None
Instruction
5.3 SHA algorithm
Prolin supports the SHA algorithms, such as SHA-1, SHA-2(SHA-256, SHA-512) and
truncates form of the SHA-2(SHA-224, SHA-384).
5.3.1 OsSHA
Prototype
void OsSHA(int Mode,
const void *Data,
int DataLen,
unsigned char* ShaOut);
Function
Calculate the Secure Hash value.
Parameters
Mode
SHA_TYPE_1
SHA_TYPE_224
SHA_TYPE_256
SHA_TYPE_384
SHA_TYPE_512
Data 【Input】
the input data buffer
DataLen
the input data length
ShaOut
Output value of SHA, the array should be equal to or more
than 64 bytes. The corresponding relations between Mode
value and ShaOut length are listed as following:
SHA_TYPE_1
20
SHA_TYPE_224
28
SHA_TYPE_256
32
SHA_TYPE_38
48
SHA_TYPE_512
64
Return
None
Instruction
Calculate the hash values of SHA family.
5.4 DES algorithm
Prolin supports DES & TDES algorithms.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 43
5.4.1 OsDES
Prototype
void OsDES(const unsigned char *Input,
unsigned char *Output,
const unsigned char *DesKey,
int KeyLen,
int Mode);
Function
Do DES / TDES encryption and decryption with 8bytes.
Parameters
Input 【Input】
8-byte input data
Output 【Output】
8-byte output data
DesKey 【Input】
DES/TDES key
KeyLen
8, 16 or 24 (bytes)
Mode
0- Decryption;
1- Encryption.
Return
None
Instruction
Do the encryption or decryption according to the mode selection.
If the parameters are invalid, there will be no operation.
5.5 AES algorithm
Prolin supports AES algorithm, including AES-128, AES-192, AES-256.
5.5.1 OsAES
Prototype
void OsAES(const unsigned char *Input,
unsigned char *Output,
const unsigned char *AesKey,
int KeyLen,
int Mode);
Function
Perform AES encryption and decryption operation.
Parameters
Input 【Input】
16-byte input data
Output【Output】
16-byte output data
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 44
AesKey【Input】
Key
KeyLen
16, 24 or 32 (bytes)
Mode
0- Decryption;
1- Encryption.
Return
None
Instruction
This function supports 128, 192 or 256 (bits) AES encryption and decryption.
If the parameter is invalid, there will be no any operations.
5.6 RSAalgorithm
Prolin supports RSA algorithm, including public/private key-pair generation, RSA encryption
and RSA decryption. Currently, Prolin supports a maximum length of 2048 bits.
5.6.1 OsRSA
Prototype
int OsRSA(const unsigned char * Module,
int ModulusLen,
const unsigned char *Exp,
int ExpLen,
const unsigned char *DataIn,
unsigned char *DataOut);
Function
Perform RSA encryption and decryption operation.
Parameters
Modulus 【Input】
Pointer to the RSA algorithm modulus buffer (n=p*q).
In the order of highest to lowest byte.
ModulusLen
Modulus length(byte)
Exp 【Input】
Pointer to the exponent buffer in RSA operation. In
the order of highest to lowest byte.
ExpLen
Exponent length.(byte)
DataIn 【Input】
Pointer to the input data buffer, its length is the same
as module.
DataOut 【Output】
Pointer to the output data buffer, its length is the same
as module.
Return
RET_OK
Success
ERR_INVALID_PAR
AM
Invalid parameter.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 45
ERR_DATA_TOO_B
IG
ExpLen is bigger than ModulusLen.
Instruction
1. This function performs RSA encryption/decryption operations; encryption
and decryption are performed by selecting different keys. If select a
private key, such as Modulus, Exp, it will do encryption; or a public key, it
will do decryption.
2. This function can perform RSA operation with the length of less than or
equal to 2048 bits.
5.6.2 OsRSAKeyGen
Prototype
Int OsRSAKeyGen(unsigned char *Modulus,
unsigned char *PriExp,
int ModulusLen,
const unsigned char * PubExp);
Function
Generate RSA Key pair.
Parameters
Modulus 【Output】
The key modulus. (High byte first)
PriExp 【Output】
Private key exponent. (High byte first)
ModulusLen
Module length. (It can be 64, 128, and 256 (bytes)).
PubExp 【Input】
Public key exponent.
It only can be:‖\x00\x00\x00\x03‖ or
―\x00\x01\x00\x01‖
Return
RET_OK
Success
ERR_INVALID_PA
RAM
Invalid Parameters
ERR_GEN_RAND
OM
Fail to generate random data.
ERR_GEN_FAIL
Fail to generate RSA Key pair.
Instruction
By calling this interface, it will randomly generate a RSA Key pair with a
specified exponent and modulus.
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 47
6 PED
Prolin provides a series of PED interface, including built-in PED, MK / SK, DUKPT, RSA
and other related interfaces.
6.1 Return code list
Table 7 PED Return code list
Macro
Value
Description
ERR_PED_NO_KEY
-3801
Key does not exist.
ERR_PED_KEY_IDX_ERR
-3802
Key index error.
ERR_PED_DERIVE_ERR
-3803
Key level error: When key is
written, the source key level is
lower than the destination
level.
ERR_PED_CHECK_KEY_FAIL
-3804
Key verification failed.
ERR_PED_NO_PIN_INPUT
-3805
No PIN input.
ERR_PED_INPUT_CANCEL
-3806
Cancel PIN input
ERR_PED_WAIT_INTERVAL
-3807
Calling function –time is
less than the minimum
interval.(Calculate
PINBLOCK/MAC)
ERR_PED_KCV_MODE_ERR
-3808
KCV mode error.
ERR_PED_KEY_TAG_ERR
-3809
Key tag error, the key can‘t be
used.
ERR_PED_KEY_TYPE_ERR
-3810
Key type error.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 48
ERR_PED_PIN_LEN_ERR
-3811
The input PIN length is not
equal to the expected PIN
length.
ERR_PED_DSTKEY_IDX_ERR
-3812
Destination key index error.
ERR_PED_SRCKEY_IDX_ERR
-3813
Source key index error.
ERR_PED_KEY_LEN_ERR
-3814
Key length error.
ERR_PED_INPUT_PIN_TIMEOUT
-3815
PIN input timeout.
ERR_PED_NO_ICC
-3816
IC card does not exist.
ERR_PED_ICC_INIT_ERR
-3817
IC card is not initialized.
ERR_PED_GROUP_IDX_ERR
-3818
DUKPT group index error.
ERR_PED_LOCKED
-3819
PED locked.
ERR_PED_NOMORE_BUF
-3820
No free buffer.
ERR_PED_NORMAL_ERR
-3821
PED general error.
ERR_PED_NEED_ADMIN
-3822
Not administration.
ERR_PED_DUKPT_KSN_OVERFLOW
-3823
DUKPT overflow.
ERR_PED_KCV_CHECK_FAIL
-3824
KCV check failed.
ERR_PED_SRCKEY_TYPE_ERR
-3825
Source key type error.
ERR_PED_UNSPT_CMD
-3826
Command does not support.
ERR_PED_ADMIN_ERR
-3827
Administration error
ERR_PED_DOWNLOAD_INACTIVE
-3828
PED download inactive.
ERR_PED_KCV_ODD_CHECK_FAIL
-3829
KCV parity check failed.
ERR_PED_PED_DATA_RW_FAIL
-3830
Read PED data failed.
ERR_PED_ICC_CMD_ERR
-3831
ICC operation failed.
ERR_PED_DUKPT_NEED_INC_KSN
-3832
DUKPT KSN needs to plus 1
first.
ERR_PED_DUKPT_NO_KCV
-3833
NO KCV.
ERR_PED_NO_FREE_FLASH
-3834
PED has not enough space.
ERR_PED_INPUT_CLEAR
-3835
Press [CLEAR] key to exit
PIN input.
ERR_PED_INPUT_BYPASS_BYFUNCTION
-3836
Press FN/ATM4 to cancel PIN
input.
ERR_PED_NO_PIN_MODE
-3837
PIN input mode is not set.
ERR_PED_DATA_MAC_ERR
-3838
Data MAC check error.
ERR_PED_DATA_CRC_ERR
-3839
Data CRC check error.
ERR_PED_KEY_VALUE_INVALID
-3840
The work key value already
exists or does not match the
requirements.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 49
6.2 Data Definition
6.2.1 Key type
Table 8 Key Types
Macro
Value
Description
PED_TLK
0x01
Loading Key
PED_TMK
0x02
Master Key
PED_TPK
0x03
PIN Key
PED_TAK
0x04
MAC Key
PED_TDK
0x05
Data Key
PED_TIK
0x10
DUKPT Initial Key
PED_TRK
0x07
MSR Key
PED_TAESK
0x20
AES Key
6.2.2 Display attribute of Asterisk
Table 9 Layout attributes of asterisk
Macro
Value
Description
PED_ASTERISK_ALIGN_LEFT
0
left-aligned
PED_ASTERISK_ALIGN_CENTER
1
center-aligned
PED_ASTERISK_ALIGN_RIGHT
2
right-aligned
Table 10 The color values of asterisk
Macro
Value
Description
RGB(_r, _g, _b)
...
According to the input of
three-primary colors to
generate color value with
16-bit.
6.3 Data Structure
6.3.1 Structure of RSA key
ST_RSA_KEY
typedef struct{
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 50
int ModulusLen;
/*Modulus length(bits) */
unsigned char Modulus[512];
/*Modulus, if the modulus length<512
bytes, store from right, add 0x00 in left. */
int ExponentLen;
/* ExponentLength (bits) */
unsigned char Exponent [512];
/*When exponent <512 bytes, add 0x00
in left.*/
unsigned char KeyInfo[128];
/* RSA key information */
}ST_RSA_KEY;
6.3.2 RSA key structure for verifying the ciphertext IC card PIN
ST_RSA_PINKEY
typedef struct{
int ModulusLen;
/*Modulus length(bits) */
unsigned char Modulus[256];
unsigned char Exponent [4];
/*Modulus of PIN public key*/
/* Exponent of PIN public key*/
int IccRandomLen;
/*Length of random data gets from IC
card*/
unsigned char IccRandom[8];
/*Random data gets from IC card*/
}ST_RSA_PINKEY;
6.4 Basic PED
6.4.1 OsPedOpen
Prototype
int OsPedOpen(void);
Function
Open PED device.
Parameters
None
Return
RET_OK
Success
ERR_DEV_BUSY
Device is busy.
Instruction
Other PED series functions can be called only after successfully opening the
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 51
PED device.
6.4.2 OsPedGetVer
Prototype
int OsPedGetVer (unsigned char * PedVer);
Function
Return PED version.
Parameters
PedVer 【Output】
PED version, buffer size is 6 bytes.
Return
RET_OK
Success
ERR_DEV_NOT_O
PEN
PED device is not open.
ERR_INVALID_PA
RAM
Invalid parameter.
Instruction
6.4.3 OsPedSetInterval
Prototype
int OsPedSetInterval(unsigned long TpkIntervalMs);
Function
Set the minimum interval time between consecutive operations of getting
PINBlock.
Parameters
TpkIntervalMs
= 0
Use the default value(30s)
<1000
Automatically set to 1000(1s)
>600000
Automatically set to 600000(10 min)
=0xffffffff
No change in current settings.
Return
RET_OK
Success
ERR_DEV_NOT_O
PEN
PED device is not open.
Instruction
Calculate the interval time of PINBLOCK:
It can only be called 4 times within the default time which is 120-second, that
is, the default value of TPKIntervalMs is 30-second, after reset by calling this
function, it is limited to call 4 times during the 4*TPKIntervalMs time, for
example, if the TPKIntervalMs is 20000(ms), then within 80 seconds, it can
only be called 4 times.
The timing function will restore the default values after switching machines.
6.4.4 OsPedVerifyPlainPin
Prototype
int OsPedVerifyPlainPin(int IccSlot,
const char * ExpPinLen,
int Mode,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 52
unsigned long TimeoutMs,
unsigned char * IccRsp);
Function
Verify the offline plaintext PIN
Get plaintext PIN.
According to card command and card slot number, then sending plaintext PIN
BLOCK to card.
Parameters
IccSlot
ICC slot number, and IccSlot=0.
ExpPinLen 【Input】
Enumeration of 0-12
Application enumerates all the possible lengths of
PIN, and uses ‗,‘to separate each length. If it is
allowed to input 4 or 6 digits password and confirm
without passwords, the string should be set to ‗0,
4, and 6‘.
0 means that user can press ‗Enter‘ to return without
inputting any digits.
Mode
0x00: IC card command mode. Currently supports
EMV2000 only.
TimeoutMs
The timeout of PIN input.【unit:ms】
Maximum is 300000.
0 means no timeout, and the PED doesn‘t do the
timeout control.
IccRsp 【Output】
2 bytes
Card response code (2 bytes: SWA++SWB)
Return
RET_OK
Success
ERR_DEV_NOT_OP
EN
PED device is not open.
ERR_INVALID_PAR
AM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
The internal processing is shown as follow:
1. Prompt cardholder to input PIN;
2. Prompt cardholder that it is in process;
3. Convert plaintext PIN to PIN BLOCK form.
Use OsIccexchange () to do the verification interaction with the card, as
follows:
ST_APDU_REQ apdu_s;
ST_APDU_RSP apdu_r;
memcpy (apdu_s.cmd, icc_command, 4);
apdu_s.lc = icc_command[4];
memcpy (apdu_s.data_in, PINBLOCK,apdu_s.lc );
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 53
apdu_s.le = 0;
if ( icc_exchange(icc_slot, 0, &apdu_s, &apdu_r) )
return CMDERR;
icc_resp[0] = apdu_r.swa;
icc_resp[1] = apdu_r.swb;
6.4.5 OsPedVerifyCipherPin
Prototype
int OsPedVerifyCipherPin(int IccSlot,
const ST_RSA_PINKEY * RsaPinKey,
const char * ExpPinLen,
int Mode,
unsigned long TimeoutMs,
unsigned char * IccRsp);
Function
Verify offline enciphered PIN.
Get plaintext PIN, and then use RsaPinKey provided by the application to
encrypt plaintext PIN according to EMV standards.
After that, according to card command and card slot number provided by
application, send plaintext PIN BLOCK to card.
Parameters
IccSlot
ICC slot number, Iccslot=0.
RsaPinKey【Input】
Encrypt the data structure.
ExpPinLen【Input】
Application enumerates all the possible lengths
of PIN, and uses the ‗,‘to separate each length. If
it is allowed to input 4 or 6 digits, confirm
without passwords, thus, the string should be set
to‗0, 4, 6‘.
0 means that user can press ‗Enter‘ to return
without inputting any digits.
Mode
0x00, currently supports EMV2000only.
TimeoutMs
The timeout of PIN input [ms]
Maximum is 300000.
0 means no timeout, and the PED doesn‘t do the
timeout control.
IccRsp【Output】
2 bytes
Card response code (2 bytes: SWA+SWB)
Return
RET_OK
Success
ERR_DEV_NOT_OPEN
PED device is not open.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 54
ERR_INVALID_PARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
Encryption algorithm:
Use the public key, and apply RSA functions to the following data listed in the
table to get enciphered PIN.
Name
Length
Description
Format
Head of Data
1
Hex. The value is ‗7F‘
b
PIN Block
8
PINBLOCK
b
unpredictable IC
card random data
8
The random number got from
card, and it is provided in
RSA_PINKEY,
b
Random padding
bytes
NIC–17
the padding data got from the
terminal application, it is
provided in RSA_PINKEY,
b
Note
1. Prompt message for PIN input;
2. Prompt cardholder that it is in process;
3. Convert plaintext PIN to PIN BLOCK;
4. Generate data, used for encryption(listed in above table)
5. Use public key, and apply RSA functions to encryption data which is
generated in step4, then getting Enciphered PIN.
Use OsIccExchange () to send verification command to card, as follows:
ST_APDU_REQ apdu_s;
ST_APDU_RSP apdu_r;
memcpy (apdu_s.cmd, icc_command, 4);
apdu_s.LC = icc_command[4];
memcpy (apdu_s.data_in, EncipheredPIN, apdu_s.LC);
apdu_s.LE = 0;
if (OsIccExchange(icc_slot, 0, &apdu_s, &apdu_r) )
return ERR_PED_ICC_CMD_ERR;
icc_resp[0] = apdu_r.SWA;
icc_resp[1] = apdu_r.SWB;
6.4.6 OsPedEraseKeys
Prototype
int OsPedEraseKeys(void);
Function
Clear all key information in PED.
Parameter
s
None
Return
RET_OK
Success.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 55
ERR_DEV_NOT_OPEN
PED device is not open.
Others
Refer to the PED Return code list .
Instructio
n
6.4.7 OsPedSetFunctionKey
Prototype
int OsPedSetFunctionKey (int KeyFlag);
Function
Set some functions of function key.
When PED is power on, the default function of CLEAR button is to clear input PIN.
Other different functions of CLEAR button can also be set by calling this function.
Parameters
KeyFlag
0x00: The PIN has already been cleared or there is no input PIN.
Press the CLEAR button, the PED will quit the input status
and will return ERR_PED_INPUT_CLEAR.
0x01: While calling this function, during the input process of the key
input interfaces (OsPedGetPinBlock, OsPedGetPinDukpt,
OsPedVerifyPlainPin, and OsPedVerifyCipherPin etc), press
CLEAR button to clear the latest input PIN digit by digit.
When all the input PIN has been deleted, there will be no
response if you keep pressing the CLEAR button, and it will
not exit the PIN input function.
0x02: It is allowed to press ATM4 button to end the PIN input. This
rule does not apply to the models without ATM button.
0x03: It is allowed to press Function button to end the PIN input.
This rule does not apply to the models without FN button.
0xff: It means restore the default function of the function keys.
(Press CLEAR button to clear all PIN; press ATM4/FN key
does not exit the PIN input function.)
Return
RET_OK
Success.
ERR_DEV_NO
T_OPEN
PED device is not open.
ERR_INVALID
_PARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
6.4.8 OsPedClose
Prototype
void OsPedClose(void);
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 56
Function
Close the PED device.
Parameters
None
Return
None
Instruction
This function should be called to close device before the program exits.
6.4.9 OsPedCancelPinEntry
Property
int OsPedCancelPinEntry(void);
Function
Terminate the PIN entry.
Parameter
None
Return
RET_OK
Success.
ERR_DEV_NOT_O
PEN
PED device is not open.
Instruction
Terminate the process of inputting PIN.
6.5 MK/SK
6.5.1 OsPedWriteKey
Prototype
int OsPedWriteKey (const unsigned char * KeyBlock);
Function
Write in a key, including write in and divergent of TLK, TMK and TWK, and
use KCV to check the key correction.
Parameters
KeyBlock【Input】
1 byte
Format: 0x03
1 byte
SrcKeyType:
PED_TLK
PED_TMK
PED_TPK/PED_TAK/PED_TDK
1 byte
SrcKeyIdx:
When SrcKeyType = PED_TLK,
SrcKeyIdx = 1;
When SrcKeyType = PED_TMK,
SrcKeyIdx = [1~100];
When writing in plaintext,
SrcKeyIdx = 0
1 byte
DstKeyIdx:
When DstKeyType = PED_TLK,
DstKeyIdx = 1;
When DstKeyType = PED_TMK,
DstKeyIdx = [1~100];
When DstKeyType = PED_TPK or
PED_TAK or PED_TDK,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 57
DstKeyIdx = [1~100].
7 bytes
Reserved domain. Random number.
1 byte
DstKeyType:
PED_TLK
PED_TMK
PED_TPK/PED_TAK/PED_TDK
1 byte
DstKeyLen: 8/16/24
8/16/24
bytes
DstKeyValue.
The destination key plaintext / ciphertext
1 byte
KcvMode:
0x00: No authentication
0x01: Performs DES/TDES encryption on
8-byte 0x00, and uses first 3 bytes in
ciphertext as KCV.
0x02: Firstly, performs parity check, then
does DES/TDES encryption on
―\x12\x34\x56\x78\x90\x12\x34\x56
‖, and uses first 3 bytes in ciphertext
as KCV.
0x03: Transfers in a string of KcvData, uses
source key to perform specified
MAC on [DstKeyValue + KcvData],
and then gets the result as KCV.
128
bytes
KcvData:
When KcvMode is 0x00/0x01/0x02,
padding with random numbers.
When KcvMode is 0x03, the first byte
of KcvData is the length of KCV data
which participate in the calculation, the
rest is KCV data. The first byte after
the KCV data represents the MAC
operation mode.
8 bytes
When KcvMode = 0x00, padding with
random numbers.
When KcvMode =0x01/0x02/0x03,
KcvValue points to the KCV value.
10 bytes
Padding with random number.
Return
RET_OK
Success.
ERR_DEV_NOT_O
PEN
PED device is not open.
ERR_INVALID_PA
RAM
Invalid parameter.
Others
Refer to the PED Return code list .
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 58
Instruction
Writing the ciphertext and plaintext to the specific index position of the specific
key type area. This function has following key points:
1. When SrcKeyIdx=0, system considers that the DstKeyValue is the
plaintext of key and does not judge SrcKeyType and SrcKeyIdx. Write the
DstKeyValue to DstKeyIdx in DstKeyType area directly.
2. Only when PED_TLK does not exist, to type-in plain text or download
any key is allowed.
3. When PED_TLK exist, it is not allowed to type in plaintext or download
key. PED_TLK can be 16 or 24 bytes.8-byte key is not allowed.
4. Format PED to clear all downloaded keys and then write in PED_TLK.
5. If SrcKeyIdx is valid, PED considers the DstKeyValue as the key
ciphertext, thus decrypt it using SrcKeyIdx key and write the key to
DstKeyIdx. DstKeyType >= SrcKeyType.
6. DstKeyLen only can be of 8, 16 or 24 bytes. If DstKeyLen = 8 bytes, the
key could only be used for DES calculation. If DstKeyLen = 16 or 24
bytes, the key could be used for TDES calculation. DstKeyLen <=
SrcKeyLen.
7. If DstKeyType=PED_TPK, the key only be used to encrypt PIN Block.
If DstKeyType=PED_TAK, the key can only be used for MAC
encryption.
If DstKeyType=PED_TDK, the key can only be used for *DES/TDES.
8. KCV is the verification for plaintext. If plaintext is typed-in directly, the
KcvMode of KeyIn is not 0 and the system will do the KCV verification
for plaintext according to the specified KcvMode.
9. The valid KeyBlock must be 184 bytes, and the users must pass in valid
parameters, otherwise an error will occur.
6.5.2 OsPedWriteTIK
Prototype
int OsPedWriteTIK (const unsigned char * KeyBlock);
Function
Write in a TIK, and check the key correction by KCV.
Parameters
KeyBlock【Input】
1 byte
Format: 0x03
1 byte
SrcKeyType:
PED_TLK
1 byte
SrcKeyIdx:
When SrcKeyType = PED_TLK,
SrcKeyIdx = 1;
When plaintext writing,
SrcKeyIdx = 0.
1 byte
DstKeyIdx:
DstKeyIdx = [1~100];
7 bytes
Reserved domain. Random number.
1 byte
DstKeyType:
PED_TIK
1 byte
DstKeyLen: 8/16
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 59
24 bytes
DstKeyValue.
The destination key plaintext / ciphertext
1 byte
KcvMode:
0x00: No authentication.
0x01: Performs DES/TDES encryption on
the 8-bytes 0x00, and uses first 3
bytes in ciphertext as KCV.
0x02: Performs parity check 1st, then
performs DES/TDES encryption on
8 bytes
―\x12\x34\x56\x78\x90\x12\x34\x56
‖, and uses first 3 bytes in ciphertext
as KCV.
0x03: Sends in data KcvData, uses source
key to perform specified mode of
MAC on [aucDesKeyValue +
KcvData], and use the result as
KCV.
128
bytes
KcvData:
When the KcvMode is
0x00/0x01/0x02, padding with random
numbers.
When the KcvMode is 0x03the first
byte of KcvData is the length of KCV
data which participate in the
calculation, the rest is KCV data. The
first byte after the KCV data represents
the MAC operation mode.
8 bytes
When KcvMode = 0x00, padding with
random numbers.
When KcvMode = 0x01/0x02/0x03,
KcvValue point to the KCV value.
10 bytes
Initialize KSN.
Return
RET_OK
Success
ERR_DEV_NOT_O
PEN
PED device is not open.
ERR_INVALID_PA
RAM
Invalid parameter
Others
Refer to the PED Return code list .
Instruction
Writes the cryptograph and plaintext of a key to the specific index position of
the specific key type area. This function has following key points:
1. When SrcKeyIdx=0, system considers that the DstKeyValue is the
plaintext of key and will not check the SrcKeyType and SrcKeyIdx. Write
the DstKeyValue to DstKeyIdx in DstKeyType area directly.
2. Only when PED_TLK does not exist, it is allowed to type-in plaintext or
download any key.
3. When PED_TLK exist, it is not allowed to type in plaintext or download
key.
4. If SrcKeyIdx is valid, PED considers the DstKeyValue as key
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 60
cryptography thus decrypts it by SrcKeyIdx key and writes the key to
DstKeyIdx. DstKeyType >= SrcKeyType.
5. KCV is verification for plaintext. If plaintext is typed-in directly, and the
KcvMode of KeyIn is not 0, the system will process KCV verification for
plaintext according to the specified KcvMode.
6. The valid KeyBlock must be 184 bytes, and the users must pass in valid
parameters, otherwise an error will occur.
6.5.3 OsPedWriteKeyVar
Prototype
int OsPedWriteKeyVar(int KeyType,
int SrcKeyIdx,
int DstKeyIdx,
const unsigned char * KeyVar);
Function
Uses the key plaintext that specified by source key index and key type, to do
operation with a string of data and write the result to the location, specified by
the destination key index with the same key type.
Parameters
KeyType
PED_TMK
PED_TPK
PED_TAK
PED_TDK
SrcKeyIdx
The source key index
DstKeyIdx
The destination key index
KeyVar 【Input】
24 bytes.
The extensible input data to be used in exclusive-or,
length of it should be same as the key.
Return
RET_OK
Success
ERR_DEV_NOT_O
PEN
PED device is not open.
ERR_INVALID_PA
RAM
Invalid parameter
Others
Refer to the PED Return code list .
Instruction
Please refer to AS2805.6.
6.5.4 OsPedSetAsteriskLayout
Prototype
int OsPedSetAsteriskLayout(int x,
int y,
int fontSize,
int fontColor,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 61
uchar align);
Function
Sets how to display the layout attributes of asterisk while inputting PIN.
Parameters
x
X-coordinate
y
Y-coordinate
fontSize
Font size of asterisk:
fontSize = 16, represents the character has 16 dots;
fontSize = 24, represents the character has 24 dots;
fontSize = 32, represents the character has 32 dots;
fontSize = 48,represents the character has 48 dots;
Display the asterisk with PED internal font, and it is not
relevant to system installed font.
fontColor
Font color of asterisk.
Using the macro definition RGB (_r, _g, _b) and according
to the input three-primary colors to generate color value with
16-bit.
align
Alignment:
PED_ASTERISK_ALIGN_LEFT;
PED_ASTERISK_ALIGN_CENTER
PED_ASTERISK_ALIGN_RIGHT
Return
RET_OK
Success
ERR_DEV_N
OT_OPEN
PED device is not open.
ERR_INVALI
D_PARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
1. The PIN input interface is displayed by the application, this function will
only display asterisk.
2. It needs to call this function to set the displaying layout of asterisk before
using PedVerifyPlainPin, PedVerifyCipherPin, PedGetPinBlock and
PedGetPinDukpt.
6.5.5 OsPedGetPinBlock
Prototype
int OsPedGetPinBlock (int KeyIdx,
const unsigned char * DataIn,
const char * ExpPinLen,
int Mode,
unsigned long TimeoutMs,
unsigned char * PinBlock);
Function
Scan the keyboard PIN entry and output the PIN BLOCK in a specific time.
Input the PIN in the length specified by ExpPinLenIn, output the PIN BLOCK
generated by algorithm encryption specified by Mode.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 62
Parameters
KeyIdx
[1-100]
Index of TPK.
DataIn【Input】
If Mode=0x00, DataIn is 16 bytes primary
account number after shifting.
If Mode=0x01, Input parameters for
participation in PinBlock formatting, 8 bytes
data. (Refer to ISO9564 standard, this data
can be Random number, transaction serial
number or time stamp, etc.)
If Mode=0x02, DataIn is 16 bytes primary
account number after shifting.
If Mode=0x03, DataIn is ISN [6 Bytes,
ASCII code].
ExpPinLen 【Input】
Enumeration of 0-12
Application enumerates all possible lengths of
PIN. ‗,‘ will be used to separate each number of
length. If no PIN, or 4 or 6 digits of PIN are
allowed, the string will be set as ‗0, 4, and 6‘.
0 means that no PIN is required and pressing
‗Enter‘ will return.
Mode
PIN BLOCK format
0x00 0x00 ISO9564 format 0
0x01 0x01 ISO9564 format 1
0x02 0x02 ISO9564 format 3
0x03 0x03 HK EPS format
TimeoutMs
The timeout of PIN entry [ms]
Maximum is 300000ms.
0: Without timeout or related control for PED.
PinBlock 【Output】
8bytes.
Point to the generated PINBlock.
Return
RET_OK
Success
ERR_DEV_NOT_OPEN
PED device is not open.
ERR_INVALID_PARA
M
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
Press ‗CANCEL‘ to cancel input.
6.5.6 OsPedUpdatePinBlock
Prototype
int OsPedUpdatePinBlock (int UpdateFlag,
const unsigned char * KeyInfo,
const unsigned char * DataIn,
unsigned char * PinBlock,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 63
int Mode);
Function
Recalculates PINBlock and chooses to replace TPK.
Parameters
UpdateFlag
0: Do not replace TPK,
Non zero: Replace TPK
KeyInfo【Input】
It has 184 bytes, please refer to the KeyBlock
definition in OsPedWriteKey() for more detail.
When UpdateFlag is 0, only ucDstKeyIdx is valid,
adopt ucDstKeyIdx, specified by TPK and recalculate
PINBLOCK.
When UpdateFlag is 1, please refer to the
OsWriteKey.
DataIn 【Input】
When UpdateFlag is 0 and Mode=0x03,
Transaction serial number ISN [6 Bytes, ASCII code].
When UpdateFlag is non-zero, it can be NULL.
PinBlock
【Output】
8 bytes.
Input original PINBlock data, output new PINBLOCK.
Mode
0x03 HK EPS dedication format[Appendix
EPS_PINBLOCK Format]
Return
RET_OK
Success
ERR_DEV_NOT
_OPEN
PED device is not open.
ERR_INVALID
_PARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
For EPS.
6.5.7 OsPedGetMac
Prototype
int OsPedGetMac(int KeyIdx,
const unsigned char *DataIn,
int DataInLen,
unsigned char *Mac,
int Mode);
Function
Use MAC key specified by the KeyID to do the MAC operation for the
following Mode algorithm, output the 8-byte result to Mac.
Parameters
KeyIdx
TAK index. [1~100]
DataIn【Input】
<=1024 bytes
The data package that needs to do the MAC operation.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 64
DataInLen
The length of data package. If the length is not a multiple
of 8, 0x00 will be padded automatically.
Mac【Output】
8 bytes, output of MAC.
Mode
1. 0x00: Performs the DES/TDES encryption for
BLOCK1 by using MAC key, and then do it again by
using TAK when and after bitwise XOR the previous
encryption result with BLOCK 2. Processes in turn to
get the 8 bytes encryption result.
2. 0x01: Performs s bitwise XOR for BLOCK1 and
BLOCK 2; and then do it again by using previous
XOR result with BLOCK3, and finally gets the 8
bytes XOR result. Use TAK to process DES/TDES
encryption for the result.
3. 0x02: ANSIX9.19 standard. Performs DES encryption
for BLOCK1 by using TAK (only take the first 8
bytes of the key). The encryption result will bitwise
XOR with BLOCK 2, and then does it again by using
TAK to get the 8 bytes encryption result. Until
DES/TDES encryption for the last time.
Return
RET_OK
Success
ERR_DEV_NOT
_OPEN
PED device is not open.
ERR_INVALID
_PARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
For EPS.
6.5.8 OsPedDes
Prototype
int OsPedDes(int KeyIdx,
unsigned char * InitVector,
const unsigned char *DataIn,
int DataInLen,
unsigned char *DataOut,
int Mode);
Function
Uses the TDK to do the DES/TDES decryption for the data and then outputs
plaintext or ciphertext. A specified TDK can be used for encryption and
decryption algorithms.
Parameters
KeyIdx
TDK index. [1~100].
InitVecto 【Input】
Used for CBC/OFB encryption or decryption. If set to
NULL, it will set the initialization vector as
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 65
―\x00\x00\x00\x00\x00\x00\x00\x00‖ by default.
It is not needed for ECB encryption or decryption, and
can be set to NULL.
DataIn 【Input】
Points to the data that needs to be calculated.
DataInLen
Data length. It should be <=1024 and multiple of 8.
DataOut【Output】
Points to the data that has been calculated.
Mode
0x00: ECB Decryption
0x01: ECB Encryption
0x02: CBC Decryption
0x03: CBC Encryption
0x04: OFB Decryption
0x05: OFB Encryption
Return
RET_OK
Success
ERR_DEV_NOT_
OPEN
PED device is not open.
ERR_INVALID_P
ARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
6.5.9 OsPedGetKcv
Prototype
int OsPedGetKcv (int KeyType,
int KeyIdx,
int KcvMode,
int KcvDataLen,
unsigned char * KcvData,
unsigned char * Kcv);
Function
Gets KCV value for key verification of two sides:
1. While it isn‘t TIK: uses specific key and algorithm to encrypt the data, and
then return the first 3 bytes of the cryptograph.
2. While it is TIK: returns the 8-byte KCV which was injected while
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 66
TIK-injection.
Parameters
KeyType
PED_TLK
PED_TMK
PED_TAK
PED_TPK
PED_TDK
PED_TIK
KeyIdx
Index number of the key, for example:
TLK can only be 1.
TMK takes range value from 1 to 100.
TWK takes range value from 1 to 100.
TIK takes range value from 1 to 100.
KcvMode
0x00: KCV check mode.
KcvDataLen
The data length used in the KCV calculation. It should be
<=128 bytes and be the multiple of 8.
It can be ―0‖ if the type is TIK.
KcvData【Input】
Points to the data that needs to be calculated. It can be
NULL if the type is TIK.
Kcv 【Output】
3 or 8bytes. Points to KCV.
KCV of TIK has 8 bytes, other types have 3 bytes.
Return
RET_OK
Success
ERR_DEV_NOT
_OPEN
PED device is not open.
ERR_INVALID
_PARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
6.5.10 OsPedDeriveKey
Prototype
int OsPedDeriveKey (int SrcKeyType,
int SrcKeyIdx,
int DstKeyType,
int DstFromKeyIdx,
int DstToKeyIdx,
int Mode);
Function
Divergent key. Uses the key specified by SrcKeyIdx to do the encryption or
decryption for the key specified by DstFromKeyIdx, then derives a new key
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 67
and save it as the specified key of DstToKeyIdx.
Parameters
SrcKeyType
Types of the source key.
PED_TLK
PED_TMK
PED_TAK
PED_TPK
PED_TDK
SrcKeyIdx
Index number of source key, for example:
TLK can only be 1.
TMK takes range value from 1 to 100.
TWK takes range value from 1 to 100.
DstKeyType
Types of the destination key
PED_TLK
PED_TMK
PED_TAK
PED_TPK
PED_TDK
DstFromKeyIdx
Source index of the destination key
DstToKeyIdx
Destination index of the destination key
Mode
0x00: DES/TDES decryption
0x01: DES/TDES encryption
Return
RET_OK
Success
ERR_DEV_NOT
_OPEN
PED device is not open.
ERR_INVALID
_PARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
The source key level should not be lower than the destination key type.
6.6 DUKPT
6.6.1 OsPedGetPinDukpt
Prototype
int OsPedGetPinDukpt(int GroupIdx,
const unsigned char * DataIn,
const char * ExpPinLen,
int Mode,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 68
unsigned long TimeoutMs,
unsigned char * Ksn,
unsigned char * PinBlock);
Function
Scans the input PIN in a specified time, and outputs the PINBlock which
generated by computing the PIN key of DUKPT.
Parameters
GroupIdx
DUKPT group ID. [ 1~100]
DataIn 【Input】
1. If Mode=0x20, DataIn is the 16 bytes primary
account number after shifting.
2. If Mode=0x21, inputs parameters for participation in
PinBlock formatting, 8 bytes data (refer to ISO9564
standard, this data can be Random numbers, the
transaction serial number or time stamp, etc.)
3. If Mode=0x22, DataIn is the 16 bytes primary
account number after shifting.
4. If Mode=0x23, DataIn is ISN [6 Bytes, ASCII
code]
ExpPinLen【Input】
0~12 enumerate set.
Application enumerates all possible lengths of PIN. ‗,‘
will be used to separate each length. If no PIN, or 4 or 6
digits PIN are allowed, the string should be set to ‗0, 4,
6‘.
0 means that no PIN is required and pressing ‗Enter‘ will
return.
Mode
Choose the format of PIN BLOCK
0x20: ISO9564 format 0, KSN not plus 1 automatically.
0x21: ISO9564 format 1, KSN not plus 1 automatically.
0x22: ISO9564 format 2, KSN not plus 1 automatically.
0x23: HK EPS format, KSN not plus 1 automatically.
TimeoutMs
The timeout of PIN entry [ms]
Maximum is 300000ms.
0 means there is no timeout time, PED doesn‘t have to do
the timeout control.
Ksn 【Output】
Points to the current KSN.(10 bytes)
PinBlock【Output】
Points to the generated PIN Block result.(8 bytes)
Return
RET_OK
Success
ERR_DEV_NOT_
OPEN
PED device is not open.
ERR_INVALID_P
ARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
When KSN does not plus 1, a DUKPT PIN key can only calculate the PIN
BLOCK for once.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 69
6.6.2 OsPedGetMacDukpt
Prototype
int OsPedGetMacDukpt(int GroupIdx,
const unsigned char *DataIn,
int DataInLen,
unsigned char *Mac,
unsigned char *Ksn,
int Mode);
Function
Calculate MAC by using MAC key of DUKPT.
Parameters
GroupIdx
DUKPT group ID. [1~100]
DataIn 【Input】
Points to the data that needs to calculate the MAC.
DataInLen
The data length should be <=1024. If the length is not the
multiple of 8, 0x00 will be padded automatically.
Mac 【Output】
Points to the obtained MAC.
Ksn 【Output】
Points to the current KSN.
Mode
1. 0x20: Perform TDES encryption for BLOCK1 by
using MAC key. Does TDES encryption again by
using TAK when and after bitwise XOR the
previous encryption result with BLOCK 2. Processes
in turn to get the 8 bytes encryption result.
2. 0x21: Does bitwise XOR for BLOCK1 and BLOCK
2; Does bitwise XOR again by using previous XOR
result with BLOCK3. Does it in turn and finally gets
the 8 bytes XOR result. Uses TAK to process TDES
encryption for the result.
3. 0x22: ANSIX9.19 standard, Does DES encryption
for BLOCK1 by using TAK (only take the first 8
bytes of key). The encryption result will bitwise
XOR with BLOCK2 and then does DES encryption
by using TAK again. Does it in turn and gets the 8
bytes encryption result. Uses TDES to encrypt in the
last time.
4. 0x20/0x21/0x22: KSN not plus 1 automatically.
5. 0x40/0x41/0x42: The MAC calculation method is
the same with 0x20/0x21/0x22.
6. 0x40/0x41/0x42: Chooses to response the MAC key.
7. 0x20/0x21/0x22: KSN chooses to request and
response MAC key
8. 0x40/0x41/0x42: KSN not plus 1 automatically.
9. Other values are reserved for extended MAC
algorithm.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 70
Return
RET_OK
Success
ERR_DEV_NOT_
OPEN
PED device is not open.
ERR_INVALID_P
ARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
If KSN does not increase, both the response MAC key and the response-request
MAC key can calculate MAC for unlimited times.
6.6.3 OsPedDesDukpt
Prototype
int OsPedDesDukpt (int GroupIdx,
int KeyVarType,
unsigned char *InitVector,
int DataInLen,
unsigned char *DataIn,
unsigned char *DataOut,
unsigned char *Ksn,
int Mode);
Function
Uses DES/MAC key of DUKPT to do encryption and decryption for the input
data.
Parameters
GroupIdx
DUKPT group ID. [1~100]
KeyVarType 【Input】
0x00: Uses the requests and responses of MAC key
0x01: Uses DES key of DUKPT
0x02: Uses the PIN variant to encrypt the data and it
is only available for ECB encryption that means
the Mode can only be 1.
InitVector 【Input】
Used for CBC/OFB encryption or decryption. If set to
NULL, it will set the initialization vector as
―\x00\x00\x00\x00\x00\x00\x00\x00‖ by default.(8
bytes)
It is not needed for ECB encryption, and can be set to
NULL.
DataInLen
The data needed to be calculated should be <= 8192
bytes.
DataIn 【Input】
Input data.
DataOut 【Output】
Points to the data that has been calculated.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 71
Ksn 【Output】
Current KSN(10 bytes)
Mode
0x00: ECB decryption
0x01: ECB encryption
0x02: CBC decryption
0x03: CBC encryption
0x04: OFB decryption
0x05: OFB encryption
Return
RET_OK
Success
ERR_DEV_NOT_OP
EN
PED device is not open.
ERR_INVALID_PAR
AM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
When KSN is unchanged, and KeyVarType is 0x00 or 0x01, a set of the
DUKPT key can do DES operations for 256 times at most. When
KeyVarType is 0x02, a set of the DUKPT key can only do the DES
operation for once.
6.6.4 OsPedGetKsnDukpt
Prototype
int OsPedGetKsnDukpt (int GroupIdx,
unsigned char * Ksn);
Function
Reads the current KSN value.
Parameters
GroupIdx
DUKPT group ID. [1-100]
Ksn 【Output】
Points to the current KSN. (10 bytes)
Return
RET_OK
Success
ERR_DEV_NOT
_OPEN
PED device is not open.
ERR_INVALID
_PARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
6.6.5 OsPedIncreaseKsnDukpt
Prototype
int OsPedIncreaseKsnDukpt (int GroupIdx);
Function
Increases KSN value of the specific DUKPT group.
Parameters
GroupIdx
1-100: DUKPT group ID
Return
RET_OK
Success
ERR_DEV_NOT
PED device is not open.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 72
_OPEN
ERR_INVALID
_PARAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
6.7 RSA
6.7.1 OsPedReadRsaKey
Prototype
int OsPedReadRsaKey (int RsaKeyIdx,
ST_RSA_KEY * RsaKey);
Function
Reads the RSA public key.
Parameters
RsaKeyIdx
1~10: Index of RSA Key.
RsaKey 【Output】
RSA public key.
Return
RET_OK
Success
ERR_DEV_NOT_O
PEN
PED device is not open.
ERR_INVALID_PA
RAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
It can only read the RSA public key, while reads private key, returns error.
6.7.2 OsPedWriteRsaKey
Prototype
int OsPedWriteRsaKey (int RsaKeyIdx,
ST_RSA_KEY * RsaKey);
Function
Inject RSA key into the PED.
Parameters
RsaKeyIdx
1~10: Index of RSA Key.
RsaKey 【Input】
Points to the RSA key that needs to be injected into
PED.
Return
RET_OK
Success
ERR_DEV_NOT_O
PEN
PED device is not open.
ERR_INVALID_PA
RAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
The type of RSA key is depending on the exponent‘s length, it is the private
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 73
key if the length equals to modulus.
6.7.3 OsPedRsaRecover
Prototype
int OsPedRsaRecover (int KeyIdx,
int DataInLen,
unsigned char * DataIn,
unsigned char * DataOut,
unsigned char * KeyInfo);
Function
Uses the RSA key stored in PED to process data operation.
Parameters
RsaKeyIdx
1~10: Index of RSA Key.
DataInLen
The length of operation data which is the same as the
RSA modulus, the size in bytes.
The length can be the value which is multiples of 8 and
should also between 64 bytes and 256 bytes.
DataIn 【Input】
Points to the data that needs to be calculated.
DataOut 【Output】
Points to the data that has been calculated.
KeyInfo 【Output】
Key information
Return
RET_OK
Success
ERR_DEV_NOT_O
PEN
PED device is not open.
ERR_INVALID_PA
RAM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
6.7.4 OsPedReadCipherRsaKey
Prototype
int OsPedReadCipherRsaKey (int RsaKeyIdx,
unsigned char * CipherRsaKey);
Function
Reads the ciphertext of RSA key.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 74
Parameters
RsaKeyIdx
Index of RSA Key. [1~10]
CipherRsaKey【Output】
Points to the ciphertext data of RSA key.
Return
>0
The byte length of the RSA ciphertext.
ERR_DEV_NOT_OPE
N
PED device is not open.
ERR_INVALID_PAR
AM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
6.7.5 OsPedWriteCipherRsaKey
Prototype
int OsPedWriteCipherRsaKey (int RsaKeyIdx,
int CipherRsaKeyLen,
unsigned char * CipherRsaKey);
Function
Writes the ciphertext of RSA key.
Parameters
RsaKeyIdx
Index of RSA Key. [1~10]
CipherRsaKeyLen
The byte length of the ciphertext data of RSA key.
CipherRsaKey【Input】
Points to the ciphertext data of RSA key.
Return
RET_OK
Success
ERR_DEV_NOT_OP
EN
PED device is not open.
ERR_INVALID_PAR
AM
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
6.8 AES
6.8.1 OsPedWriteAesKey
Prototype
intOsPedWriteAesKey (const unsigned char * KeyBlock);
Function
Write in an AES key and use KCV to check the key correction.
Parameters
KeyBlock【Input】
1 byte
Format: 0x03
1 byte
SrcKeyType:
PED_TLK
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 75
PED_TMK
1 byte
SrcKeyIdx:
When SrcKeyType = PED_TLK,
SrcKeyIdx = 1;
When SrcKeyType = PED_TMK,
SrcKeyIdx = [1~100];
If ucSrcKeyIdx = 0, key will be written
in PED as plain text.
1 byte
DstKeyIdx: [1-100].
7 bytes
Reserved domain. Random number.
1 byte
DstKeyType: PED_TAESK
1 byte
DstKeyLen: 16/24/32
32 bytes
DstKeyValue:
The destination key plain-text or
cipher-text.
1 byte
KcvMode:
0x00: No KCV check.
0x01: Performs AES ECB encryption on
16-byte 0x00, and use first 3 bytes as
KCV.
0x02: Perform parity check at first, then
perform AESECB encryption on 16
bytes
―\x12\x34\x56\x78\x90\x12\x34\x56
\x12\x34\x56\x78\x90\x12\x34\x56‖
, and use first 3 bytes as KCV.
0x03: Transfers in a string of KcvData, use
source key to perform specified
mode MAC on [DstKeyValue
(cipher) + KcvData], and use the
result as KCV.
128 bytes
KcvData:
When KcvMode is 0x00/0x01/0x02,
padding with random numbers.
When KcvMode is0x03, the first byte
of KcvData is the length of KCV data
which participates in the calculation,
the rest is KCV data. The first byte
after the KCV data represents the
MAC operation mode.
8 bytes
When KcvMode = 0x00, padding with
random numbers.
When KcvMode =0x01/0x02/0x03,
KcvValue point to the KCV value.
2 bytes
Padding with random number.
Return
RET_OK
Success
ERR_DEV_NOT_
Device is not open.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 76
OPEN
ERR_INVALID_P
ARAM
Invalid parameter.
Others
Refer to the PED Return code list.
Instruction
Writing the cryptograph and plaintext of an AES key to the specific index
position of the AES area. This function has following key points:
1. When SrcKeyIdx=0, system consider that the DstKeyValue is the plaintext
of key and does not judge SrcKeyType and SrcKeyIdx. Write the
DstKeyValue to DstKeyIdx in DstKeyType area directly.
2. Only when PED_TLK does not exist, to inject plaintext or download any
key into PED is allowed.
3. When PED_TLK exist, it is not allowed to inject in plaintext or download
key.
4. If SrcKeyIdx is valid, PED considers the DstKeyValue as the key
cryptography, thus decrypt it using SrcKeyIdx key and write the key to
DstKeyIdx.
5. The valid KeyBlock must be 184 bytes, and the users must pass a valid
parameter to it, otherwise an error will occur.
6.8.2 OsPedAes
Prototype
intOsPedAes(intKeyIdx,
unsigned char * InitVector,
const unsigned char *DataIn,
intDataInLen,
unsigned char *DataOut,
int Mode);
Function
Uses the specified AES key stored in PED to do the AES encryption or
decryption for the data and then output ciphertext or plaintext.
Parameters
KeyIdx 【Input】
TAESK index: 1~100.
InitVector 【Input】
Used for CBC/OFB encryption or decryption. If
set to NULL, it will set the initialization vector as
―\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\
x00\x00\x00\x00\x00‖ by default.
It is not needed for ECB encryption or decryption,
and can be set to NULL.
DataIn 【Input】
Points to the data that needs to be calculated.
DataInLen 【Input】
Data length. It should be <=1024, and multiple of
16.
DataOut 【Output】
Points to the data that has been calculated.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 77
Mode 【Input】
0x00: ECB Decryption
0x01: ECB Encryption
0x02: CBC Decryption
0x03: CBC Encryption
0x04: OFB Decryption
0x05: OFB Encryption
Return
RET_OK
Success
ERR_DEV_NOT_OPEN
Device is not open.
ERR_INVALID_PARA
M
Invalid parameter.
Others
Refer to the PED Return code list .
Instruction
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 79
7 LCD
In Prolin, the operation of displaying contents on LCD is managed by the GUI; it supports the
graphics systems such as Minigui, QT. In this chapter, it will provide OsScrBrightness(),
OsScrContrast(), OsScrGetSize() and some related interfaces for application use.
Application can adopt the XUI graphic interfaces that provided by PAX, for more details;
refer to the ―XUI Programming Guide‖. It also can develop the GUI system by itself, or it can
use FrameBuffer approach to test the validity of the LCD driver. OsScrContrast(),
OsScrBrightness(), OsScrGetSize() and the rest of the LCD operations are managed by the
GUI.
Applications (such as driver testing) can also operate FrameBuffer directly. Details are as
follows:
1. Open the FrameBuffer device, the device node is ―/dev/fb‖;
2. Get the fixed screen information through ioctl,
3. Get the variable screen information through ioctl,
4. Map device memory to the process space through mmap,
5. Write the FrameBuffer.
int open_screen(void)
{
char vtname[128];
int fd, nr;
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 80
unsigned y, addr;
struct fb_fix_screeninfo fix;
sb = (screen_buffer*)malloc(sizeof (screen_buffer));
if ((sb->dev_fd = open(FB_DEV_PATH, O_RDWR)) == -1) {
perror("open");
return -1;
}
int ret = ioctl(sb->dev_fd, FBIOGET_VSCREENINFO, &fb_vinfo);
if (ret) {
sb->width = FB_WIDTH;
sb->height = FB_HEIGHT;
sb->bytes_per_pixel = FB_BYTES_PER_PIXEL;
fprintf(stderr,"in %s line %d",__FUNCTION__,__LINE__);
} else {
sb->width = fb_vinfo.xres;
sb->height = fb_vinfo.yres;
sb->bytes_per_pixel = fb_vinfo.bits_per_pixel / 8;
}
if(sb->bytes_per_pixel == 3)
sb->bytes_per_pixel = 4;
if (ioctl(sb->dev_fd, FBIOGET_FSCREENINFO, &fix) < 0) {
close(sb->dev_fd);
return -1;
}
fbmemlen = sb->width * sb->height * sb->bytes_per_pixel;
if ((sb->buffer = (uint8_t *) mmap(NULL, fbmemlen, PROT_READ | PROT_
WRITE,MAP_FILE |MAP_SHARED, sb->dev_fd, 0)) == (uint8_t *) -1)
{
fprintf (stderr, "rw_sd_inand.c: Can't mmap frame buffer ++\n");
exit (1);
}
memset(sb->buffer, 0, fbmemlen);
return 0;
}
1. Close the FrameBuffer device
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 81
void close_screen(screen_buffer *sb)
{
if(!sb)
return;
// Unmap the framebuffer
munmap(sb->buffer, fbmemlen);
// Close framebuffer device
close(sb->dev_fd);
free(sb);
}
7.1 OsScrContrast
Prototype
void OsScrContrast(int Contrast);
Function
Sets the contrast.
Parameters
Contrast
Contrast level [0~7].
0: darkest
7: lightest
Default value: 4.
Other values: no action.
Return
None
Instruction
This function is only applicable to monochrome LCD.
7.2 OsScrBrightness
Prototype
void OsScrBrightness(int Brightness);
Function
Sets the screen brightness.
Parameters
Brightness
Brightness level [0~10].
0: turn off the backlight
10: lightest value
All brightness values are visible。
Default value: 8.
Other values: no action.
Return
None
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 82
7.3 OsScrGetSize
Prototype
void OsScrGetSize(int *Width,
int *Height);
Function
Gets the LCD Physical screen size.
Parameters
Width【Output】
Width (unit: pixel).
Height【Output】
Height (unit: pixel).
Return
None
Instruction
The screen size is just a read-only property.
The interface only applys to the applications that does not support GUI.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 83
8 Keyboard
The keyboard input of Prolin is managed by GUI.
Key value definition
Macro
Value
Description
KEY1
2
KEY‖1‖
KEY2
3
KEY ―2‖
KEY3
4
KEY―3‖
KEY4
5
KEY―4‖
KEY5
6
KEY―5‖
KEY6
7
KEY―6‖
KEY7
8
KEY―7‖
KEY8
9
KEY―8‖
KEY9
10
KEY―9‖
KEY0
11
KEY―0‖
KEYCANCEL
223
KEY―CANCEL‖
KEYCLEAR
14
KEY―CLEAR‖
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 84
KEYENTER
28
KEY―ENTER‖
KEYALPHA
69
KEY ―Alpha‖
KEYF1
59
At the bottom of S800 LCD, the
first key from left to right.
KEYF2
60
KEYF3
61
KEYF4
62
KEYFUNC
102
Key ―Function‖
KEYUP
103
At the bottom of S800 LCD, the
second key from left to right.
KEYDOWN
108
At the bottom of S800 LCD, the
third key from left to right.
KEYMENU
139
At the bottom of S800 LCD, the
fourth key from left to right.
The application developers can directly use the input subsystem when they need to test
keyboard drivers or transplant other GUI systems. The device node of the keyboard is "/dev/
keypad".
Details of calling the input subsystem are shown as follow:
#include <stdio.h>
#include <stdlib.h>
#include <fcntl.h>
#include <linux/input.h>
static int keypad_fd = -1;
struct input_event ev0[64];
//for handling /key/event
static int handle_event0() {
int button = 0, realx = 0, realy = 0, i, rd;
rd = read(keypad_fd, ev0, sizeof(struct input_event) * 64);
if ( rd < sizeof(struct input_event) ) return 0;
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 85
for (i = 0; i < rd / sizeof(struct input_event); i++) {
printf("", ev0[i].type, ev0[i].code, ev0[i].value);
if (ev0[i].type == 3 && ev0[i].code == 0)
realx = ev0[i].value;
else if (ev0[i].type == 3 && ev0[i].code == 1)
realy = ev0[i].value;
else if (ev0[i].type == 1) {
if (ev0[i].code == 158) {
//if key esc then exit
return 0;
}
}
else if (ev0[i].type == 0 && ev0[i].code == 0 && ev0[i].value == 0) {
realx = 0, realy = 0;
}
printf("event(%d): type: %d; code: %3d; value: %3d; realx: %3d;
realy: %3d\n", i,
ev0[i].type, ev0[i].code, ev0[i].value, realx, realy);
}
return 1;
}
int main(void) {
int done = 1;
printf("sizeof(struct input_event) = %d\n", sizeof(struct input_event));
keypad_fd = open("/dev/keypad", O_RDWR);
if ( keypad_fd < 0 )
return -1;
while ( done ) {
printf("begin handel_event0...\n");
done = handle_event0();
printf("end handel_event0...\n");
}
if ( keypad_fd > 0 ) {
close(keypad_fd);
keypad_fd = -1;
}
return 0;
}
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 86
8.1 OsKbBacklight
Prototype
void OsKbBacklight(int OnOff);
Function
Switches the keyboard backlight.
Parameters
OnOff
0: Turn off the backlight.
Non-zero: Turn on the backlight.
Return
None
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 87
9 Touch Screen
The touch screen input of Prolin is managed by GUI.
The application developers can directly use the input subsystem if they need to test touch
screen drivers or transplant other GUI systems.
About input subsystem calls, refer to the example of the keyboard, the node of touch screen is
―/dev/tp‖.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 88
10 Signature Pad
For more details, refer to the ―XUI Programming Guide‖.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 89
11 Printer
Prolin provides both virtual printing and physical printing function, and also provides the
unified interface for API. For physical printer, the senior application developers can
access the printer driver through a POSIX interface to achieve the specific print function.
11.1 Return code list
Table 11 Printer return code list
Macro
Value
Description
ERR_PRN_BUSY
-3701
Printer is busy
ERR_PRN_PAPEROUT
-3702
Out of paper
ERR_PRN_WRONG_PACKAGE
-3703
The format of print data
packet error.
ERR_PRN_OVERHEAT
-3704
Printer overheats
ERR_PRN_OUTOFMEMORY
-3705
The print data is too large
to exceed the buffer length.
ERR_PRN_OVERVOLTAGE
-3706
Voltage is too high.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 90
11.2 Open and Close
This part includes three functions: opening, resetting and closing the printer.
11.2.1 OsPrnOpen
Prototype
int OsPrnOpen(unsigned int printertype,
const char* targetname );
Function
Opens the printer (including physical and virtual).
Parameters
printertype 【Input】
Types of printer:
PRN_REAL: Physical printer.
PRN_BMP: Bmp virtual printer and it generates
bmp format files.
targetname 【Input】
For the physical printer, this parameter should be
NULL.
The other output file name of virtual printer, this
parameter should fill in the file name generated by
virtual printing, for example, /home/app/test.bmp.
Return
RET_OK
Success.
ERR_DEV_NOT_EX
IST
Device does not exist.
ERR_INVALID_PAR
AM
Invalid parameter
ERR_DEV_BUSY
ERR_BATTERY_AB
SENT
Device is occupied
The battery is absent
Instruction
1. This function needs to be called when the program starts to run, otherwise
the associated functions won‘t work.
2. Noted that S920 and D200 mobile terminals need battery to work.
11.2.2 OsPrnReset
Prototype
void OsPrnReset(void);
Function
Implements the print restoration and initialization.
Parameters
None
Return
None
Instruction
Calling this function will restore the printer default settings and clear buffer
data.
This function is applicable to both physical printers and virtual printers.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 91
11.2.3 OsPrnClose
Prototype
void OsPrnClose(void);
Function
Closes the printer.
Parameters
None
Return
None
Instruction
This function should be called to close the printer device when program exit.
11.3 Printer settings
11.3.1 OsPrnSetSize
Prototype
int OsPrnSetSize (unsigned int Width,
unsigned int Height);
Function
Sets printer parameters.
Parameters
Width【Input】
Width
Height【Input】
Height
Return
RET_OK
Success.
ERR_INVALID_PARAM
Invalid parameter.
Instruction
Only applicable to the virtual printer. The default size is 384*5000, and the
maximum size is 600*5000.
This function is effective in the first calling, and it will not change the first
settings in the following repeat calls.
11.3.2 OsPrnSetDirection
Prototype
int OsPrnSetDirection (unsigned char Mode);
Function
Sets the print direction.
Parameters
Mode 【Input】
0: print horizontally.
Non-zero: print vertically.
Return
RET_OK
Success
ERR_INVALID_PA
RAM
Invalid parameter.
Instruction
This function is applicable to both physical printers and virtual printers.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 92
11.3.3 OsPrnSetGray
Prototype
void OsPrnSetGray(int Level);
Function
Sets printing gray level.
Parameters
Level
Level =0, reserved,
Level =1, default level, normal print slip,
Level =2, reserved,
Level =3, two-layer thermal printing,
Level =4, two-layer thermal printing, higher gray level
than 3,
The default level is 1.
The illegal value does not change current settings.
Return
None
Instruction
Before setting gray level, it prints with the default level, after calling this
function it will print with the setting level.
This function is only applicable to the physical printer.
11.4 TypeSetting
11.4.1 OsPrnSetSpace
Prototype
void OsPrnSetSpace(int CharSpace,
int LineSpace);
Function
Sets the printing space.
Parameters
CharSpace
Character space (unit: pixel) (It is invalid to the mandatory
non-monospaced fonts, such as Arabic fonts, Thai fonts.)
LineSpace
Line space(unit: pixel)
Return
None
Instruction
1. Settings will be valid until they are set again or OsPrnReset() is called;
2. Printing character space is 0 by default;
3. Printing line spaces are 0 and 2 for thermal printer and stylus printer
respectively by default ;
4. The maximum line space can be 255;
5. The maximum character space can be 255;
6. Invalid parameter does not change the current settings.
11.4.2 OsPrnSetReversal
Prototype
int void OsPrnSetReversal(int Attr);
Function
Sets the reverse attribute of font, normal printing by default.
Parameters
Attr
0: normal
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 93
Non zero: reversal
Return
None
Instruction
This function is applicable to both physical printers and virtual printers
11.4.3 OsPrnSetIndent
Prototype
int OsPrnSetIndent (unsigned int Left,
unsigned int Right);
Function
Sets the left and right margins.
Parameters
Left 【Input】
The left margin: the valid range is [0, 100] and the
default value is 0.
Right 【Input】
The right margin: the valid range is [0, 100] and the
default value is 0.
Return
RET_OK
Success
ERR_INVALID_PA
RAM
Invalid parameter
Instruction
If the physical printer is set to print vertically, then the left margin should
correspond to the top margin of the page, and right margin corresponds to the
bottom margin.
11.4.4 OsPrnCheck
Prototype
int OsPrnCheck(void);
Function
Checks the current status of printer.
Parameters
None
Return
RET_OK
Success.
ERR_PRN_NOFONTLIB
Has no font library.
ERR_PRN_BUSY
Printer is busy.
ERR_PRN_PAPEROUT
Out of paper.
ERR_PRN_OVERHEAT
Printer overheated.
Instruction
This function can be used to check whether there is a printing font library,
whether there is paper, whether printing buffer is full, and whether the printer is
overheated
Only applicable to the physical printer.
11.4.5 OsPrnGetDotLine
Prototype
int OsPrnGetDotLine(void);
Function
Gets current printed dot line for slip alignment.
Parameters
None
Return
>=0
Current dot line.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 94
Instruction
Used for slip alignment.
This function is applicable to both physical printers and virtual printers.
11.4.6 OsPrnSetFont
Prototype
int OsPrnSetFont(const char * fontname);
Function
Selects print fonts.
Parameters
fontname【Input】
Font(file) name
Return
RET_OK
Success
ERR_FONT_NOT_EXIST
Font does not exist.
ERR_INVALID_PARAM
Invalid parameter.
Instruction
It can choose a different font style and font size for printing. The system
built-in font (file) name can be obtained by calling OsEnumFont () function.
11.4.7 OsPrnSelectFontSize
Prototype
void OsPrnSelectFontSize(int SingleCodeWidth,
int SingleCodeHeight,
int MultiCodeWidth,
int MultiCodeHeight);
Function
Sets the font size.
Parameters
SingleCodeWidth
The width control of single code font. (For non-
monospaced font, width of each character may not meets
the settings).
The value ranges from 8 to 64.
SingleCodeHeight
The height control of single code font.
The value ranges from 8 to 64.
MultiCodeWidth
The width control of multiple code fonts.
The value ranges from 12 to 64.
MultiCodeHeight
The height control of multiple code font
The value ranges from 12 to 64.
Return
None
Instruction
After the first calling of OsPrnOpen(), the font width and height are set to the
default values (12x24) (24x24).
This function is applicable to both physical printers and virtual printers.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 95
11.4.8 OsPrnFeed
Prototype
void OsPrnFeed(int Pixel);
Function
Feeds printing paper ―pixel‖ pixels in print buffer.
Parameters
Pixel
number of pixels
Return
None
Instruction
1. If the pixel value is positive, then the paper will feed forwards. If it is
negative, then feed backwards. If it is 0, then no action.
2. This function is applicable to both physical and virtual printers.
11.4.9 OsPrnPrintf
Prototype
void OsPrnPrintf(const char *Str, ...);
Function
Formats output string to print buffer.
Parameters
Str【Input】
Pointer of string that needs to be printed.
Return
None
Instruction
1. Support variable parameters;
2. Support ‗\n‘ (new line) and ‗\f‘ (new page) control characters in the string;
3. If the printing data package is too long, then the program will overflow;
4. If the string is longer than the printing boundary, it will automatically
change line and continue printing;
5. The maximum buffer size is 2048 bytes;
6. Store str in printing buffer, and print data in printing buffer in sequence of
writing into the buffer after calling OsPrnStart().
11.4.10 OsPrnPutImage
Prototype
void OsPrnPutImage(const unsigned char *Logo);
Function
Outputs images to the print buffer.
Parameters
Logo【Input】
Pointer to the logo information; the length cannot be more
than 20000 bytes.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 96
Return
None
Instruction
1. Bitmap data is generated as follows:
Draw a bitmap (usually a logo): use paintbrush program under
Windows to draw a bitmap and save it as a ―monochromatic, bmp
format‖ file.
Use ―Bitmap Converter‖ provided by PAX to convert the .bmp file
into a header file, for instance, Logo.h header file. (If more than
one .bmp files are selected, after the conversion, the head file contain
the same number of array\the definition of the name of the array will
be associated with the BMP filename.
Printing bitmap size limit: for thermal printer, up to 384 pixels in
width is allowed, for stylus printer, 180 pixels are allowed, but the
height is unlimited.
2. Use the generated array as the input parameter of this function.
3. If the bitmap width is larger than the limit of the printer, then it will be get
rid of the redundant data on the right. .
4. If the size of the data packet is too large, then this function will remove the
LOGO message.
11.4.11 OsPrnStart
Prototype
int OsPrnStart(void);
Function
Starts printer and prints the data in the buffer.
Parameters
None
Return
RET_OK
Success
ERR_PRN_BUSY
Printer is busy.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 97
ERR_PRN_PAPEROUT
Out of paper.
ERR_PRN_WRONG_PACKAGE
The format of printing data package error.
ERR_PRN_OVERHEAT
Printer overheats.
ERR_PRN_OUTOFMEMORY
The size of the printing data is too large.
Instruction
1. After calling this API, the printer will perform the printing task and return after
completing the whole printing task.
2. After completing the whole printing task, this API will return the printer status in
return value. Therefore the check printer status is not required.
3. If the printing process is completed, recalling this function will reprint the slip.
11.5 POSIX
Prolin physical printer driver module makes the POSIX programming interface open to the
application developers.
11.5.1 open
Opens the physical printer, the device name is ―/dev/printer‖
int handle = open(―/dev/printer‖, O_RDWR);
11.5.2 read
Read the printer status. The data format of the first byte buf[0] in Read buffer is defined
as follows:0x00 normal
0x01 printer is busy
0x02 out of paper
0x03 printer overheats
0x04~0xFF reserved
unsigned char buf[10];
int ret = read(handle, buf, 2);
if (ret > 0) {
//buf[0]
}
11.5.3 Write
Send the contents of printer configuration and print the buffer.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 98
The first two bytes of the buffer are gray settings and reserved bit, suppose that the buffer is
char buf [50], bit0~bit2 in the buf [0] represent the printing gray control values, bit3~bit7 are
reserved.
char 0: bit0~bit2: The control value of print grayscale,
000(0) Reserved
001(1) Normal gray level
010(2) Reserved
011(3) Two-layer thermal printing A
100(4) Two-layer thermal printing B
101(5) Reserved
110(6) Reserved
111(7) Reserved
The second byte buf [1] in the buffer: reserved.
From buf [2], a single line is composed of every 48 characters (384 dots); if it is less than 48
then it will be padding with blank by the driver.
unsigned char buf[50];
buf[0] = 0x01;
memset(buf + 2, 0xff, 48);
int ret = write(handle, buf, 50);
if (ret < 0) {
//Error handling……
}
The limit of the maximum data length is:
For the thermal printing of 384 dots, when prints horizontally, the driver can deal with 5000
lines each time at most, if out of the range, it will not print. When prints vertically, it can deal
with 384 lines each time, and each line can print 5000 dots at most, if there are more than 384
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 99
lines, it will not print. The longest length of a write buffer should be 384*5000/8 + 2 =
240002 Bytes.
11.5.4 Close
Closes the printer file handles.
close (handle);
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 101
12 Font Library
Prolin supports Freetype as the system font library. Therefore, the system supports a series of
vector font and bitmap font.
12.1 Data structure
FT_FONT
typedef struct {
char FileName[64];
/* Font file name */
char FontName[64];
/* Font name */
}FT_FONT;
FT_DOT
typedef struct {
unsigned char Left;
/*Font offsets left from the baseline*/
unsigned char Top;
/* Font offsets top from the baseline
*/
unsigned char Width;
/* Font width */
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 102
unsigned char Height;
/* Font height */
unsigned char Dot[3072];
/*Valid font data */
}FT_DOT;
12.2 Font operation
12.2.1 OsEnumFont
Prototype
int OsEnumFont(FT_FONT *FontList);
Function
Gets the vector font list provided by system.
Parameters
FontList【Output】
Vector fonts list
Return
>=0
Read the number of vector fonts
ERR_INVALID_P
ARAM
Invalid parameter.
ERR_FONT_NOT
_EXIST
Font library does not exist.
Instruction
Example:
int i, num;
FT_FONT *FontList;
num = OsEnumFont(&FontList);
if(num <= 0)
return -1;
for(i=0; i<num; i++)
printf("[%d]file name: %s, font name : %s\n",
i, FontList[i].FileName, FontList[i].FontName);
12.2.2 OsOpenFont
Prototype
int OsOpenFont ( const char *FileName);
Function
Loads vector fonts.
Parameters
FileName 【Input】
Font file name.
Return
>=0
Font handle
ERR_INVALID_P
ARAM
Invalid parameter.
ERR_FONT_NOT
_EXIST
System does not install font library.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 103
Instruction
It needs to cache the dot-matrix data after open the fonts, and it is
recommended to call OsGetFontDot() after 3 seconds.
12.2.3 OsCloseFont
Prototype
void OsCloseFont ( int Handle);
Function
Closes vector fonts.
Parameters
Handle 【Input】
Font handle
Return
None
Instruction
After using vector fonts, please promptly shut down to release the system
resources.
12.2.4 OsGetFontDot
Prototype
int OsGetFontDot ( int Handle,
const char *Utf8Code,
const int Width,
const int Height,
const int Style,
FT_DOT *FtDot);
Function
Gets the utf-8 encoding standard character font.
Parameters
Handle 【Input】
Font handle
Utf8Code 【Input】
Characters of UTF-8 encoding standards
Width 【Input】
Font width, value range is【8, 128】.
Height 【Input】
Font height, value range is【8, 128】.
Style 【Input】
Font style:
FONT_STYLE_NON
E
0
No style
FONT_STYLE_BOL
D
0x00000001
Bold type
FONT_STYLE_ITAL
IC
0x00000002
Italic type
FONT_STYLE_BOL
D|FONT_STYLE_IT
ALIC
bold italics
FtDot 【Output】
The output of font data structure.
Return
RET_OK
Success
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 104
ERR_INVALID_PAR
AM
Invalid parameter
ERR_FILE_NOT_EX
IST
File does not exist.
ERR_FONT_CODE
Font code error.
ERR_INVALID_HA
NDLE
Invalid handle
Instruction
Utf8Code input.
UTF-8 code is a variable length, and it needs to end with '\ 0', when the code is
composed of letters, Utf8Code requires two bytes where Utf8Code [0] represents
letter, Utf8Code [1] represents ' \ 0'; but for Chinese, Utf8Code requires four
bytes where Utf8Code [0-2] represents the Chinese and Utf8Code [3] represents '
\ 0'.
The Italic style dot matrix.
When using italics effects, the obtained dot matrix width is wider than the set
value. It is not recommended that the dot size should be not less than 24;
otherwise the dot may not show italics effects. For example, when the dot size of
Song typeface is less than 19, and the bold font dot size is less than 21, the italic
effects cannot be used for Chinese, but it is available for letters.
The format of font data.
1. All of the font dot matrix are in horizontal arrangement mode;
2. The point which corresponds to each byte, the sequence from left to right is
0x80 to 0x01;
3. If the character width that is not enough to make a integer multiple of 8,the
bytes of per line dot matrix are (width+7)/8
For example: For the character ― > ‖,with 10(width)x20(height)
The font data is:
0x00, 0x00,
0x20, 0x00,
0x10, 0x00,
0x10, 0x00,
0x08, 0x00,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 105
0x04, 0x00,
0x04, 0x00,
0x02, 0x00,
0x01, 0x00,
0x00, 0x80,
0x00, 0x80,
0x01, 0x00,
0x02, 0x00,
0x04, 0x00,
0x04, 0x00,
0x08, 0x00,
0x10, 0x00,
0x10, 0x00,
0x20, 0x00,
0x00, 0x00
After calling this function, the character returns:
Width = 10
Height = 20
Dot data:
0x00,0x00,0x20,0x00,0x10,0x00,0x10,0x00,
0x08,0x00,0x04,0x00,0x04,0x00,0x02,0x00,
0x01,0x00,0x00,0x80,0x00,0x80,0x01,0x00,
0x02,0x00,0x04,0x00,0x04,0x00,0x08,0x00,
0x10,0x00,0x10,0x00,0x20,0x00,0x00,0x00
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 107
13 Code
Prolin supports UTF8 as the system default code, and also provides the code-conversion
interface.
13.1 Code Convert
13.1.1 OsCodeConvert
Prototype
int OsCodeConvert (const char *FromCharset,
const char *ToCharset,
const char *InBuf,
char *OutBuf,
unsigned int LenOut);
Function
Implement conversion of character encoding.
Parameters
FromCharset 【Input】
The original character encoding
ToCharset 【Input】
The target character encoding
InBuf 【Input】
Character string of the original encoding, ending
with ‘ \0‘.Unicode should end with‖\0\0‘‘
OutBuf 【Output】
The converted encoding string
LenOut 【Input】
Size of array OutBuf, it should be at least 1.5 times of
the array InBuf.
Return
>=0
Success, then returns the length of converted
character string.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 108
ERR_INVALID_PARAM
Invalid parameter
Instruction
Supports conversions among the following codes.
ISO-8859-(1,2,3,4,5,6,7,8,9,10,11, 13,14,15,16)
cp(850,874,932,1250,1251,1252,1253,1254,1255,1256,1257,1258)
GBK/GB18030(2 bytes part)
BIG5
SHIFT_JIS
EUC-KR
UNICODE
UTF-8
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 109
14 MSR
Prolin provides the function of reading the magnetic stripe data and provides a unified API
reading interface for use. In addition, senior application developers can access to the magnetic
drive through the POSIX interface and directly get the magnetic stripe bit-stream to achieve
different logics of magnetic stripe decoding.
14.1 Return code list
Table 12 MSR return code list
Macro
Value
Description
ERR_MSR_FAILED
-2701
Failed
ERR_MSR_HEADERR
-2702
Did not find the head mark.
ERR_MSR_ENDERR
-2703
Did not find the end mark
ERR_MSR_LRCERR
-2704
LRC check error
ERR_MSR_PARERR
-2705
One bit of MSR check error.
ERR_MSR_NOT_SWIPED
-2706
No swiping
ERR_MSR_PED_DECRYPTERR
-2709
PED decryption failed.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 110
14.2 Data structure
MSR structure: Records information and status of each magnetic track.
ST_MSR_DATA:
typedef struct {
unsigned char TrackData[256];
/*Track data buffer*/
int DataLen;
/* Track data length*/
int Status;
/*Track data status, status equal 0
indicates read track data succeed,
other value indicates failed*/
}ST_MSR_DATA;
14.3 MSR control interface
14.3.1 OsMsrOpen
Prototype
int OsMsrOpen(void);
Function
Switches on magnetic stripe reader.
Parameters
None
Return
RET_OK
Success
ERR_DEV_NOT_EXIST
Device does not exist.
ERR_DEV_BUSY
Device is busy.
ERR_DEV_NOT_OPEN
Fail to open the device.
Instruction
Other functions can be operated only after open device successfully.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 111
14.3.2 OsMsrClose
Prototype
void OsMsrClose(void);
Function
Switches off magnetic stripe reader.
Parameters
None
Return
None
Instruction
This function should be called to close device when program exit.
14.3.3 OsMsrReset
Prototype
void OsMsrReset(void);
Function
Resets magnetic stripe reader
Parameters
None
Return
None
Instruction
When the magnetic reader is powered on, this function resets the reader and
clears the data in the buffer.
14.3.4 OsMsrSwiped
Prototype
int OsMsrSwiped(void);
Function
Checks whether a card is swiped or not.
Parameters
None
Return
TRUE
Card swiped
FALSE
Not swiped
ERR_DEV_NOT
_OPEN
Device is not open.
Instruction
1. This function returns the corresponding value immediately, doesn‘t matter
card is swiped or not.
2. Call this function to check whether a card is swiped or not.
3. After calling the OsMsrOpen(), OsMsrRead() or OsMsrReset(), the status
of swiping card will be clear.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 112
14.3.5 OsMsrRead
Prototype
int OsMsrRead(ST_MSR_DATA *Track1,
ST_MSR_DATA *Track2,
ST_MSR_DATA *Track3);
Function
Reads data of magnetic stripe card.
Parameters
Track1 【Output】
Output the data of Track1
Track2 【Output】
Output the data of Track2
Track3 【Output】
Output the data of Track3
Return
RET_OK
Success
ERR_MSR_NOT_S
WIPED
No swiping.
ERR_INVALID_PA
RAM
Invalid parameter.
ERR_DEV_NOT_O
PEN
Device is not open.
Instruction
If a certain track‘s data is not needed, set the corresponding pointer to NULL,
then the data will not be outputted.
After swiped card successfully, and users didn‘t call this interface to read the
track data, the data will be automatically emptied. And all of the returned track
data are 0x00.
14.4 POSIX
Prolin Magnetic driver module makes the POSIX programming interface open to the senior
application developers.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 113
14.4.1 Open
Opens the magnetic stripe reader, and the device name is‖/dev/msr‖
int handle = open(―/dev/msr‖, O_RDONLY);
14.4.2 Read
Read the bit stream data from magnetic stripe card.
The data format in Read buffer is defined as follows:
Variable length of data, but it is not more than 3 * 750 bytes. In the case of no card swiping,
the returned data length of read is 0, and the read () may return -1. When the first byte of the
buffer is 0, it presents that the following data will be plaintext magnetic track data.
The data bit stream is represented by using the ASCII code 0/1 and an ASCII code represents
a bit, tracks are separated by 0x0A.
010101010101010101000000000000000000000000000000000011111111111111111111111
111111\n
010101010101010101000000000000000000000000000000000011111111111111111111111
111111\n
010101010101010101000000000000000000000000000000000011111111111111111111111
111111\n
The second byte of the buffer is 1 that means the following data will be locked by using fixed
key encryption. Which needs PedMsrDecryptRaw() interface to do the decryption.
unsigned char buf[2250];
int ret = read(handle, buf, 2250);
if (ret > 0) {
/*Bit stream decode*/
}
14.4.3 Close
Closes file handles of the magnetic stripe reader.
After closing the handle, the original magnetic data stored in the drive buffer will be cleared.
close (handle);
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 114
15 ICC Reader
The basic protocol interface is customized according to the ISO7816/EMV.
15.1 Return Code List
Table 13 ICC reader return code list
Macro
Value
Description
ERR_SCI_HW_NOCARD
-2800
No card
ERR_SCI_HW_STEP
-2801
Exchange when no init, warm reset
when no active
ERR_SCI_HW_PARITY
-2802
Parity error
ERR_SCI_HW_TIMEOUT
-2803
Time out
ERR_SCI_TCK
-2804
TCK error
ERR_SCI_ATR_TS
-2810
TS error in ATR
ERR_SCI_ATR_TA1
-2811
TA1 error in ATR
ERR_SCI_ATR_TD1
-2812
TD1 error in ATR
ERR_SCI_ATR_TA2
-2813
TA2 error in ATR
ERR_SCI_ATR_TB1
-2814
TB1 error in ATR
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 115
ERR_SCI_ATR_TB2
-2815
TB2 error in ATR
ERR_SCI_ATR_TC2
-2816
TC2 error in ATR
ERR_SCI_ATR_TD2
-2817
TD2 error in ATR
ERR_SCI_ATR_TA3
-2818
TA3 error in ATR
ERR_SCI_ATR_TB3
-2819
TB3 error in ATR
ERR_SCI_ATR_TC3
-2820
TC3 error in ATR
ERR_SCI_T_ORDER
-2821
Protocol is not T0 or T1
ERR_SCI_PPS_PPSS
-2830
PPSS error in PPS
ERR_SCI_PPS_PPS0
-2831
PPS0 error in PPS
ERR_SCI_PPS_PCK
-2832
TC3 error in ATRPCK error in PPS
ERR_SCI_T0_PARAM
-2840
Data in transmitting is too long in T0
ERR_SCI_T0_REPEAT
-2841
Too many character repetition in T0
ERR_SCI_T0_PROB
-2842
Procedure byte error in T0
ERR_SCI_T1_PARAM
-2850
Data in transmitting is too long in T1
ERR_SCI_T1_BWT
-2851
BWT exceed in T1
ERR_SCI_T1_CWT
-2852
CWT exceed in T1
ERR_SCI_T1_BREP
-2853
Too many block repetition in T1
ERR_SCI_T1_LRC
-2854
LRC error in T1
ERR_SCI_T1_NAD
-2855
NAD error in T1
ERR_SCI_T1_LEN
-2856
LEN error in T1
ERR_SCI_T1_PCB
-2857
PCB error in T1
ERR_SCI_T1_SRC
-2858
SRC error in T1
ERR_SCI_T1_SRL
-2859
SRL error in T1
ERR_SCI_T1_SRA
-2860
SRA error in T1
ERR_SCI_PARAM
-2880
Parameter not allow
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 116
15.2 Data Structure
15.2.1 IC card device control block
sci_dcb_t:
/* device control block */
struct sci_dcb_t {
unsigned int voltage; /* operation condition: voltage */
/* frequency adjust integer, default value is 372 */
unsigned int fi;
/* speed adjust integer, default value is 1 */
unsigned int di;
unsigned int conv; /* logical converse direction */
unsigned int protocol; /* T=0 or T=1 */
unsigned char option_clock; /* stop clock options */
unsigned char option_voltage; /* voltage options */
unsigned char option_spu;
/* these members are appended, you must notice */
unsigned int spec;
unsigned int nego; /* support PPS protocol */
/* the guard time between characters, only for T=0 */
unsigned int cgt;
/* block guard time, default value is 22, only for T=1 */
unsigned int bgt;
/* RESET signal maintain LOW level clock cycles, default is 42500 */
unsigned int rstt;
unsigned int wtt; /* TS wait time, default value is ??? */
/* allowed maximum of ATR duration, only used in EMV mode
(spec=0) */
unsigned int twt;
unsigned int wwt; /* T=0, work wait time, default is 0x0A */
/* character repetition (in T=0), maximum is 6 */
unsigned int tpar_retry; /* send repeat time on parity error */
unsigned int rpar_retry; /* recv repeat time on parity error */
unsigned int bwt; /* T=1, block wait time, default is 0x00 */
unsigned int cwt; /* T=1, character wait time, default is 0x05 */
unsigned char repeat;
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 117
/* the maxium frame size of ICC, default value is 32 */
unsigned int fsc;
unsigned int fsd;
unsigned char sci_last_ipcb;
unsigned char icc_last_ipcb;
unsigned char sci_last_pcb;
unsigned char icc_last_pcb;
/* reset status: cold reset, warm reset, or activation */
unsigned int status;
};
15.2.2 ATR structure
sci_atr_t:
/* ATR */
struct sci_atr_t {
unsigned char ts;
unsigned char t0;
unsigned char ta_flag;
unsigned char tb_flag;
unsigned char tc_flag;
unsigned char td_flag;
unsigned char ta[8];
unsigned char tb[8];
unsigned char tc[8];
unsigned char td[8];
unsigned char hbytes[15];
unsigned char tck;
};
15.2.3 APDU Request Structure
ST_ APDU_REQ
typedef struct
{
Unsigned char Cmd[4]; /*CLA, INS, P1, P2*/
int LC; /* The valid length of DataIn sent to ICC */
unsigned char DataIn[512];/* The data sent to ICC */
int LE; /* The expected returned length */
}ST_ APDU_REQ;
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 118
15.2.4 APDU Response Structure
ST_ APDU_RSP:
typedef struct
{
Int LenOut; /* The actual returned data length */
unsigned char DataOut[512]; /* Returned data pointer from ICC */
unsigned char SWA; /*status word 1 of ICC */
unsigned char SWB; /* status word 2 of ICC */
}ST_ APDU_RSP;
15.3 API index
- sci_open ()
- sci_get_dcb ()
- sci_set_dcb ()
- sci_read ()
- sci_write ()
- sci_close ()
- sci_lock ()
- sci_detect ()
- sci_cold_reset ()
- sci_warm_reset ()
- emv_atr_parse ()
- iso7816_atr_parse ()
- iso7816_pps ()
- iso7816_ocs()
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 119
- sci_unlock()
- sci_powerup()
- sci_powerdown()
- iso7816_t1_ifsd_request()
- iso7816_t0_exchange()
- iso7816_t1_exchange()
15.3.1 sci_open
Prototype
int sci_open(int id);
Function
Opens the corresponding smartcard device.
Parameters
id 【Input】
device id
Return
0
opened successfully
others
failed to open, return an error code
Instruction
Other functions can be operated only after open device successfully.
15.3.2 sci_get_fd
Prototype
int sci_get_dcb(int id);
Function
Gets the corresponding smartcard device's fd.
Parameters
id 【Input】
Device id, 0-user slot, 1,2,3,4, sam1-sam4.
Return
>=0
device‘s id
others
device not open or return a error code
Instruction
When open a smartcard device, fd is stored in sci_logical_devices [id].fp, get it
by this function.
15.3.3 sci_get_dcb
Prototype
int sci_get_dcb(int id,
struct sci_dcb_t *dcb)
Function
Gets the device control block from the device driver layer.
Parameters
id【Input】
device id
dcb【Output】
device control block
Return
0
success
others
error
Instruction
15.3.4 sci_set_dcb
Prototype
int sci_set_dcb(int id,
struct sci_dcb_t *dcb);
Function
Sets the device control block to the device driver layer.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 120
Parameters
id【Input】
device id
dcb【Output】
device control block
Return
0
success
others
error
Instruction
15.3.5 sci_read
Prototype
int sci_read(int id,
unsigned char *pbuf,
int length);
Function
Reads bytes from the device driver layer.
Parameters
id【Input】
device id
pbuf【Output】
data buffer
length【Input】
data length
Return
0
success
others
error
Instruction
15.3.6 sci_write
Prototype
int sci_write(int id,
unsigned char *pbuf,
int length);
Function
Writes bytes into the device driver layer.
Parameters
id【Input】
device id
pbuf【Output】
data buffer
length【Input】
data length
Return
0
success
others
error
Instruction
15.3.7 sci_close
Prototype
int sci_close(int id);
Function
Closes the corresponding smartcard device.
Parameters
id【Input】
device id
Return
0
success
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 121
others
error
Instruction
This function should be called to close device while program exit.
15.3.8 sci_lock
Prototype
int sci_lock(int id);
Function
Locks the smartcard lock on the corresponding smartcard device.
Parameters
id【Input】
device id
Return
0
success
others
error
Instruction
On smartcard devices, locking the smartcard lock before cold reset, warm reset,
reading or writing has no effect on user card device (id = 0).
15.3.9 sci_unlock
Prototype
int sci_unlock(int id);
Function
Unlocks the smartcard lock on the corresponding smartcard device.
Parameters
id【Input】
device id
Return
0
success
others
error
Instruction
On smartcard devices, unlock the smartcard lock after getting all the data (or
error info) from transmission by read operation. It has no effect on user card
device (id = 0).
15.3.10 sci_powerup
Prototype
int sci_powerup(int id);
Function
Card activation on the corresponding smartcard device.
Parameters
id【Input】
device id
Return
0
success
others
error
Instruction
15.3.11 sci_powerdown
Prototype
int sci_ powerdown (int id);
Function
Card deactivation on the corresponding smartcard device.
Parameters
id【Input】
device id
Return
0
success
others
error
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 122
Instruction
15.3.12 sci_detect
Prototype
int sci_detect(int id);
Function
Detects whether the user card is in the socket or not.
Parameters
id【Input】
device id
Return
0
success
others
error
Instruction
Only id = 0 is accepted.
15.3.13 sci_cold_reset
Prototype
int sci_cold_reset(int id,
struct sci_atr_t *pstATR);
Function
Performs a cold reset sequence and receives the ATR data.
Parameters
id【Input】
device id
pstATR【Output】
pointer to ATR data
Return
0
success
others
error
Instruction
15.3.14 sci_warm_reset
Prototype
int sci_warm_reset (int id,
struct sci_atr_t *pstATR);
Function
Performs a warm reset sequence and receives the ATR data.
Parameters
id【Input】
device id
pstATR【Output】
pointer to ATR data
Return
0
success
others
error
Instruction
15.4 Protocol processing function
15.4.1 emv_atr_parse
Prototype
int emv_atr_parse (const struct sci_atr_t *pstATR,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 123
struct sci_dcb_t *dcb);
Function
Parses the ATR characters according to EMV v4.2 standard.
Parameters
pstATR【Input】
ATR point
dcb【Output】
device control block
Return
0
success
others
error
Instruction
15.4.2 iso7816_atr_parse
Prototype
int iso7816_atr_parse (const struct sci_atr_t *pstATR,
struct sci_dcb_t *dcb);
Function
Parses the ATR characters according to ISO7816 standard.
Parameters
pstATR【Input】
ATR point
dcb【Output】
device control block
Return
0
success
others
error
Instruction
15.4.3 iso7816_pps
Prototype
int iso7816_pps(int id,
struct sci_atr_t *pstATR, struct sci_dcb_t *dcb);
Function
PPS protocol process.
Parameters
id【Input】
device id
pstATR【Input】
ATR point
dcb【Output】
device control block
Return
0
success
others
error
Instruction
15.4.4 iso7816_ocs
Prototype
int iso7816_ocs(int id,
struct sci_atr_t *pstATR);
Function
Select operating conditions.
Parameters
id【Input】
device id
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 124
pstATR【Output】
pointer to ATR data
Return
0
success
others
card class selection abort
Instruction
Auto class selection, try 1.8V, then 3V, then 5V.It can be invoked as a cold
reset with auto vcc selection.
15.4.5 iso7816_t1_ifsd_request
Prototype
int iso7816_t1_ifsd_request(int id);
Function
If sd request in T=1.
Parameters
id【Input】
device id
Return
0
success
others
error
Instruction
15.4.6 iso7816_t0_exchange
Prototype
int iso7816_t0_exchange(int id,
ST_APDU_REQ *apdu_req,
ST_APDU_RSP *apdu_resp);
Function
Transmission on T=0 protocol under ISO 7816-3 standard.
Parameters
id【Input】
device id
apdu_req【Input】
pointer to APDU request, terminal request
information
apdu_resp【Output】
pointer to APDU response, card response
information
Return
0
success
1
success with a warning
others
Error
Instruction
15.4.7 iso7816_t1_exchange
Prototype
int iso7816_t1_exchange(int id,
ST_APDU_REQ *apdu_req,
ST_APDU_RSP *apdu_resp);
Function
Transmission on T=1 protocol under ISO 7816-3 standard.
Parameters
id【Input】
Device id
apdu_req【Input】
Pointer to APDU request, terminal request
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 125
information.
apdu_resp【Output】
Pointer to APDU response, card response
information.
Return
0
success
others
Error
Instruction
15.5 Encapsulated Interfaces
15.5.1 OslccOpen
Prototype
int OsIccOpen(int Slot);
Function
Open the ICC reader.
Parameters
Slot
channel number:
ICC_USER_SLOT User card
ICC_SAM1_SLOT SAM card slot 1
ICC_SAM2_SLOT SAM card slot 2
ICC_SAM3_SLOT SAM card slot 3
ICC_SAM4_SLOT SAM card slot 4
Return
RET_OK
Success
ERR_DEV_NOT_EXIST
Device does not exist.
ERR_DEV_BUSY
Device is busy.
Instruction
15.5.2 OsIccDetect
Prototype
int OsIccDetect(int Slot);
Function
Check whether there is a card in the specified slot.
Parameters
Slot
channel number:
Return
RET_OK
Card-inserted
Others
Please refer to ICC Return code list
Instruction
1. This function will return immediately no matter whether there is a card in
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 126
slot or not.
2. For USER_SLOT, if card-insert or card-extract happens, system will send
MSG_ICCSIG message to the application which is used to open the
device. This mechanism doesn‘t apply to SAM card.
15.5.3 OsIccInit
Prototype
int OsIccInit(int Slot,
unsigned long Option,
unsigned char *Atr);
Function
Initialize the IC card device.
Parameters
Slot
Channel number.
Please refer to OslccOpen()
Option
(Bit 0~1)card voltage options:
00 - 5V, 01 - 1.8V,
10 - 3V, 11 - 7V
(Bit 2)Support for PPS protocol:
0 – not support,
1 – support;
(Bit 3~4)Rate used in ATR
00 – Standard rate 9600
01 – Twice rate 19200
10 – Four times rate 38400
The rate mentioned here is a reference value
which the cards are operated under the typical
frequency (3.57MHz) condition
The communication rate between the IC card and
the reader component is closely related to the
working clock frequency which was provided to
card by a specific machine.
(Bit 5)Specification
0 – EMV
1 - ISO7816
If this bit specifically indicates EMV mode, the
power rate will be marked as invalid. It uses the
standard rate by default.
(Bit 6 ~31)Reserved
Option is set to 0 by default(that is 5V, not PPS,
Standard rate, and follow EMVx)
Atr 【Output】
1. Answer To Reset. Up to 34 bytes will be
returned from card.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 127
2. Content is composed of length of ATR (1
byte) and ATR[output]
Return
RET_OK
Success.
Others
Please refer to ICC Return code list
Instruction
1. ATR output buffer should be allocated at least 34 bytes.
2. Whether PPS communication coordination protocol is supported or not
depends on the specific cards is supported or not.
3. For SAM card, some terminals can only work with one card at a time. If
several cards need to be operated at the same time, initialize cards one by
one.(OsIccInit ( ) ) - > operation ( OsIccExchange ) - > close ( )
15.5.4 OsIccExchange
Prototype
int OsIccExchange(int Slot,
int CtrlFlag,
const ST_APDU_REQ *ApduReq,
ST_APDU_RSP *ApduRsp);
Function
Interacts with IC card using commands.
Parameters
Slot
Channel number.
Please refer to OslccOpen()
CtrlFlag
1. Bit0 represents whether to send "Get
Response" instruction automatically under
T=0 protocol.
1 Yes
0 No
2. Bit1~Bit31 Reserved
ApduReq 【Input】
The data structure sent to IC card.
ApduRsp 【Output】
The data structure received from IC card.
Return
RET_OK
Success.
Others
Please refer to ICC Return code list
Instruction
15.5.5 OsIccClose
Prototype
int OsIccClose(int Slot);
Function
Close the IC card device.
Parameters
Slot
Channel number.
Please refer to OslccOpen()
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 128
Return
RET_OK
Success.
Others
Please refer to ICC Return code list
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 129
16 RF Reader
This part mainly describe the applicaton programming interface of contactless IC card reader
conforming to the ISO14443 and ‗EMV Contactless Book D V2.1‘ regulation.
16.1 Return Code List
Table 14 Return Code List
Macro
Value
Description
PCD_ERR_PAR_FLAG
-2901
Parity error
PCD_ERR_CRC_FLAG
-2902
CRC error
PCD_ERR_WTO_FLAG
-2903
Timeout or no card
PCD_ERR_COLL_FLAG
-2904
several cardscollision.
PCD_ERR_ECD_FLAG
-2905
Frame format error
PCD_ERR_EMD_FLAG
-2906
Interference
PCD_ERR_COM_FLAG
-2907
Chip error, it cannot
communicate correctly.
PCD_ERR_AUT_FLAG
-2908
M1 authentication error
PCD_ERR_TRANSMIT_FLAG
-2909
Transmission error
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 130
PCD_ERR_PROTOCOL_FLAG
-2910
Protocol error
PCD_ERR_PARAMFILE_FLAG
-2911
Configuration file does not
exist
PCD_ERR_USER_CANCEL
-2912
Usercancelled the transaction
PCD_ERR_CARRIER_OBTAIN_FLAG
-2913
Didn‘t obtain the carrier
PCD_ERR_CONFIG_FLAG
-2914
Configuration register failed
PCD_ERR_NOT_ALLOWED_FLAG
-2951
Parameter error or obtaining
value isn‘t allowed
PCD_CHIP_ABNORMAL
-2952
Chip is abnormal or does not
exist
PCD_CHIP_NOT_OPENED
-2953
Module is not open
PCD_CHIP_CARDEXIST
-2954
Card isn‘t removed
PCD_ERR_NOT_IDLE_FLAG
-2955
Card is not in idle state
PCD_ERR_NOT_POLLING_FLAG
-2956
Card did not do thePOLLING
PCD_ERR_NOT_WAKEUP_FLAG
-2957
Card does not wakeup
PCD_ERR_NOT_ACTIVE_FLAG
-2958
Card is not activated
16.2 Data Structure
About request and response of data structure, please refer to the IC Card Reader section
15.2.3 and 15.2.4.
16.2.1 User Configuration Structure
PCD_USER_ST
typedef struct pcd_user_t{
unsigned char wait_retry_limit_w; /* Written enable for the number
of S(WTX) response*/
unsigned int wait_retry_limit_val; /* S(WTX) response to the times that
repeat most frequently.*/
unsigned char check_cancel_key_w; /*Written enable for checking the
cancel key*/
unsigned char check_cancel_key_val; /* 0 represents no response to the
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 131
cancel key, 1 represents response the
cancel key */
int (*check_cancel_key_function)(void);/* Check whether has pressed the cancel
key, if set check_cancel_key_w=1 and
check_cancel_key_val=1, the
check_cancel_key_function will be called
during the RF card transaction, when it
returns 0, it represents it hasn’t pressed
the cancel key, otherwise, it means it has,
in this case it will be forced to exit the
transaction */
unsigned char reserved[60]; /* Reserved byte, for future expansion */
} PCD_USER_ST;
16.2.2 Configuration Parameter Definition
struct PCD_PARAM_ST
/*Card protocol check enable switch,1- check;0 – do not check */
unsigned int uiProtocolCheckEn;
/*the maximum block length that the card received .(unit: byte) */
unsigned int uiFSC;
/*The longest time that waiting for card response, use the current ETU
time as a time unit*/
unsigned int uiFWT;
/*sending protection time, use the current ETU time as a unit */
unsigned int uiSFGT;
/*Electrical conductivity of the A card */
unsigned int uiTypeAConduct;
/*Reserved*/
unsigned int uiReserved;
/* Receiving sensitivity of the A card */
unsigned int uiTypeARxThreshold;
/* Antenna gain of A card */
unsigned int uiTypeAGain;
/* Electrical conductivity of the B card */
unsigned int uiTypeBConduct;
/* Modulation depth of B card*/
unsigned int uiTypeBModulDepth;
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 132
/* Receiving sensitivity of the B card */
unsigned int uiTypeBRxThreshold;
/* Antenna gain of B card */
unsigned int uiTypeBGain;
/* Electrical conductivity of the Felica card */
unsigned int uiFelicaConduct;
/* Modulation depthof Felica card */
unsigned int uiFelicaModulDepth;
/* Receiving sensitivity of the Felica card */
unsigned int uiFelicaRxThreshold;
/* Antenna gain of Felica card */
unsigned int uiFelicaGain;
/*Reserved for future use. */
unsigned int uiRFU[60];
};
16.3 ISO14443 --- Type A
16.3.1 iso14443_3a_req
Prototype
int iso14443_3a_req( unsigned char *atqa );
Function
Sends REQA command to PICC,and receives the ATQA from PICC.
Parameters
atqa【Output】
The buffer for ATQA,2 bytes
Return
0
Success, the ATQA is valid, consists of two bytes.
others
Error
Instruction
<EMV Contactless Book D - Contactless Comm Protocol 2.1,section 5.3.2>
16.3.2 iso14443_3a_wup
Prototype
int iso14443_3a_wup( unsigned char *atqa ) ;
Function
Sends WUPA command to PICC and receives the ATQA from PICC.
Parameters
atqa【Output】
the buffer for ATQA, 2 bytes
Return
0
Success, the ATQA is valid, consisting of two bytes.
others
Error
Instruction
<EMV Contactless Book D - Contactless Comm Protocol 2.1,section 5.3.2>
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 133
16.3.3 iso14443_3a_antisel
Prototype
int iso14443_3a_antisel( unsigned char *uid,
int uid_ln,
unsigned char *sak );
Function
Sends ANTICOLLISION command to PICC and receives the UID from PICC.
Parameters
uid
the unique identifier of PICC
uid_ln
the length of the unique identifier of PICC
sak
the last selected command response
Return
0
Success.
others
Error
Instruction
< EMV Contactless Book D - Contactless Comm Protocol 2.1, section
5.4.2>
< ISO/IEC 14443-3:2001(E) Section 6.4.3.1 and 6.4.4 >
16.3.4 iso14443_3a_halt
Prototype
int iso14443_3a_halt( );
Function
Sends HALT command to PICC.
Parameters
None
Return
0
Success.
Others
Error.
Instruction
16.3.5 iso14443_3a_rats
Prototype
int iso14443_3a_rats( unsigned char *ats );
Function
Requests answer to selection.( defined by iso14443-4)
Parameters
ats【Output】
the response from PICC(must be greater than 256 bytes)
Return
0
Success.
others
Error
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 134
16.4 ISO14443 --- Type B
16.4.1 iso14443_3b_req
Prototype
int iso14443_3b_req( unsigned char *atqb );
Function
Sends REQB command to PICC and receives the ATQB from PICC.
Parameters
atqb【Output】
The buffer for ATQB, 12 or 13 bytes
Return
0
Success, the ATQB is valid; consisting of 12 or 13 bytes.
others
Error
Instruction
<EMV Contactless Book D - Contactless Comm Protocol 2.1,section 5.3.2>
16.4.2 iso14443_3b_wup
Prototype
int iso14443_3b_wup( unsigned char* atqb );
Function
Sends WUPB command to PICC and receives the ATQB from PICC.
Parameters
atqb【Output】
the buffer for ATQB, 12 or 13 bytes
Return
0
Success, the ATQB is valid; consisting of 12 or 13 bytes.
others
Error
Instruction
<EMV Contactless Book D - Contactless Comm Protocol 2.1,section 5.3.2>
16.4.3 iso14443_3b_attri
Prototype
int iso14443_3b_attri( const unsigned char *pupi,
unsigned char* data,
int *txr_ln );
Function
PCD sends ATTRIB command to PICC and receives the SAK from PICC.
Parameters
pupi
the picc's uid, 4 bytes
dat【Input&Output】
higher layer INF.(command and response)
txr_ln
the number of higher layer INF.
Return
0
Success
others
Error
Instruction
16.4.4 iso14443_3b_halt
Prototype
int iso14443_3b_halt( );
Function
Sends HALTB command to PICC.
Parameters
None
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 135
Return
0
Success
others
Error
Instruction
16.5 Half-duplex transmission protocol
16.5.1 iso14443_4_transfer
Prototype
int iso14443_4_transfer( unsigned char *src,
int tx_ln,
unsigned char *des,
int *rx_ln );
Function
Implements the half duplex communication protocol with ISO14443-4.
Parameters
src
The data will be transmitted by PCD.
tx_ln
The number of transmitted data by PCD.
des
The data will be transmitted by PICC
rx_ln
The number of transmitted data by PICC.
Return
0
Success
others
Error
Instruction
16.6 Encapsulate Interfaces
16.6.1 OsPiccOpen
Prototype
int OsPiccOpen(void);
Function
Power on the PCD module and make the module enter into the preparatory
work state.
Parameters
None
Return
0
Success
Others
Failed to open device. (Details refer to the return
code list.)
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 136
16.6.2 OsPiccClose
Prototype
int OsPiccClose (void);
Function
Power off the PCD module.
Parameters
None
Return
0
Success
Others
Failed. (Details refer to the return code list.)
Instruction
16.6.3 OsPiccResetCarrier
Prototype
int OsPiccResetCarrier (void);
Function
Reset the carrier wave.
Parameters
None
Return
0
Success
Others
Failed. (Details refer to the return code list.)
Instruction
When doing the carrier reset operation for RF reader, the card state in the RF
field will be changed, no matter what the state is, the card will enter the idle
state after calling this interface.
16.6.4 OsPiccPoll
Prototype
int OsPiccPoll( char* pcPiccType,
unsigned char* pucATQx );
Function
Looks for cards, inlcuding the roll polling for type A card and type B card.
Parameters
pcPiccType【Output】
Card types:
‘A‘ - card A
‘B‘ - card B
pucATQx 【Output】
In response to the WUPA commands, a Picc of
card A will return an ATQA with a length of 2
bytes.
In response to the WUPB commands, a Picc of
card B will return an ATQB with a length of 12
bytes.
Return
0
Success.
Others
Failed. (Details refer to the return code list.)
Instruction
Mifare card is a special A card, after calling this interface, M card returns as a
type of A card.
16.6.5 OsPiccAntiSel
Prototype
int OsPiccAntiSel( const char pcPiccType,
unsigned char *pucUID,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 137
const unsigned char ucATQ0,
unsigned char* pucSAK );
Function
Do anti-collision and selection operations for cards.
Parameters
pcPiccType【Input】
Card types:
‘A‘ - card A
‘B‘ - card B
pucUID【Output】
Unique identifier of the card:
Card A-- 4, 7 or 10 bytes, the value of the
UID shall be a fixed number or a random
number which is dynamically generated by
the Picc.
Card B—4 bytes, the value of the pucUID of
Type B card shall be fixed number or a
random number which is dynamically
generated by the Picc.
ucATQ0【Input】
It is unused.
pucSAK【Output】
The response data of card while selecting card, it
has 1 byte.
SAK represents the data that response to the last
SELECT command of card A.
This parameter is ignored by card B.
Return
0
Success.
Others
Failed (Details refer to the return code list.)
Instruction
If users want to differentiate between the picc of card A and Mifare card, they
can make the distinction by output parameters value of the pucSAK.
16.6.6 OsPiccActive
Prototype
int OsPiccActive( const char pcPiccType,
unsigned char *pucRATS );
Function
Activate the card.
Parameters
pcPiccType【Input】
Card types:
‘A‘ –Type A card
‘B‘ – Type B card
pucRATS【Output】
The response data:
PucRATS represents the data that responds to
RATS command of card A.
PucRATS represents the data that responds to
ATTRIB command of card B.
Return
0
Success.
Others
Failed(Details refer to the return code list.)
Instruction
The output data of PucRATS mainly includes the card frame waiting time,
buffer size, maximum frame sizes, start-up frame guard time, etc. For details,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 138
see the ‗EMV Contactless Book D V2.1‘ in section 5.7 and 6.4.
16.6.7 OsPiccTransfer
Prototype
int OsPiccTransfer( const unsigned char *pucTxBuff,
int iTxLen,
unsigned char* pucRxBuff,
int *piRxLen );
Function
Carry out the transparent transmission/reception in accordance with the
half-duplex communication protocol in the ISO14443-4
Parameters
pucTxBuff【Input】
The data buffer to be transmitted.
iTxLen 【Input】
The length of data to be transmitted.
pucRxBuff【Output】
Response data buffer of receiving card.
piRxLen 【Output】
The length of receiving card‘s response data.
Return
0
Success
Others
Failed(Details refer to the return code list.)
Instruction
16.6.8 OsPiccRemove
Prototype
int OsPiccRemove ( void );
Function
In accordance with the EMV mode to remove card.
Parameters
None
Return
0
Success
Others
Failed. (Details refer to the return code list.)
Instruction
16.6.9 OsMifareAuthority
Prototype
int OsMifareAuthority(unsigned char *uid,
unsigned char blk_no,
unsigned chargroup,
unsigned char *psw);
Function
Verify the Mifare card.
Parameters
uid 【Input】
Card ID, 4 bytes.
blk_no 【Input】
Block number
group 【Input】
Password types, can be evaluated as ‗A‘ or ‗B‘
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 139
psw 【Input】
Authentication password, 6 bytes.
Return
0
Success.
Others
Failed. (Details refer to the return code list.)
Instruction
16.6.10 OsMifareOperate
Prototype
int OsMifareOperate ( unsigned charucOpCode,
unsigned charucSrcBlkNo,
unsigned char*pucVal,
unsigned char ucDesBlkNo );
Function
Do operations of reading and writing block for the specified blocks of Mifare
card, and increasing, decreasing or backup the specified data block of Mifare
card, and then update it into other specified value block.
Parameters
ucOpCode 【Input】
‗r‘ or ‗R‘ represents read operations,
‗w‘ or ‗W‘ represents write operations,
‗+‘ represents Increase value,
‗-‘ represents Decrease value,
‗>‘ represents transfer /backup operation.
ucSrcBlkNo【Input】
Specify the visiting block number.
pucVal【Input/Output】
If it is the read operation, pucVal outputs
the block contents, and points to the buffer
size of 16 bytes.
If it is the write operation, pucVal inputs
the block contents, and points to the buffer
size of 16 bytes.
If it is the ‗+‘or ‗-‘ operation, pucVal is
the first address of buffer, and points to
the buffer size of 4 bytes.
If it is the transfer operation, pucVal has
no practical meaning, but the incoming
pointer must be NULL.
ucUpdateBlkNo 【Input】
Specify the block number which used to written
in the operation result.(while reading and
writing block, it is NULL)
Return
0
Success.
Others
Failed. (Details refer to the return code list.)
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 140
16.6.11 OsPiccInitFelica
Prototype
int OsPiccInitFelica( unsigned char ucSpeed,
unsigned char ucModInvert );
Function
Initialize the configuration for the Felica card.
Parameters
ucSpeed【Input】
Set the transmission rate which is used to interact
with card.
1: 424Kbp
Others: 212Kbps
ucModInvert【Input】
Set the FeliCa modulate mode.
1: forward modulate output;
Others: reverse modulate output.
Return
0
Success.
Instruction
16.6.12 OsPiccIsoCommand
Prototype
int OsPiccIsoCommand(int cid,
ST_APDU_REQ *ApduReq,
ST_APDU_RSP *ApduRsp);
Function
Send the APDU format data and receive response in the specified channel.
Parameters
cid 【Input】
Used for specifying the logical channel number of the
card, its value ranges from 0 to 14, currently the
value is 0.
ApduReq 【Input】
The structure sending to PICC card.
ApduRsp 【Output】
The response structure returning from PICC card.
Return
0
Success.
Others
Failed (Details refer to the return code list.)
Instruction
16.6.13 OsPiccSetUserConfig
Prototype
int OsPiccSetUserConfig(PCD_USER_ST *pcd_user_config) ;
Function
Set the user configuration.
Parameters
pcd_user_config 【Input】
User configuration structure
Return
0
Success.
Others
Failed (Details refer to the return code list.)
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 141
16.6.14 OsPiccGetUserConfig
Prototype
int OsPiccGetUserConfig(PCD_USER_ST *pcd_user_config);
Function
Get the user configuration.
Parameters
pcd_user_config
【Output】
User configuration structure
Return
0
Success.
Others
Failed (Details refer to the return code list.)
Instruction
16.7 Note of touch screen and RF reader programming
It has configured touch screen and RF reader on S300 and S800. When the RF card does the
A/B transaction, application developers should note that touch screen cannot be used during
the period. The remove card function should be called after finishing the transaction. When
operating Mifare card, it must call OsPiccRemove () or OsPiccClose () at last. When
operating Felica card, the RF module should be closed at last.
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 143
17 Communication Port
17.1 Data Definition
Table 15 Macro definition list of communication ports
Macro
Value
Description
PORT_COM1
0
UART 1
PORT_COM2
1
UART 2
PORT_COM3
2
UART3
PORT_PINPAD
3
Built-out PinPad
PORT_USBDEV
11
USB device mode port
PORT_USBHOST
12
USB host mode port
Table 16 Return code list of USB port functions
Macro
Value
Description
USB_ERR_NOT_OPEN
-3403
Channel is not open.
USB_ERR_BUF
-3404
Send buffer error.
USB_ERR_NOT_FREE
-3405
No free port.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 144
USB_ERR_NO_CONF
-3411
The device has not completed
enumeration and configuration process.
USB_ERR_DISCONN
-3412
The device has been disconnected with
the host.
USB_ERR_MEM_SYSTEM
-3413
System memory is abnormal.
USB_ERR_BUSY
-3414
USB system is busy.
USB_ERR_RC_SYSTEM
-3415
The application for system resources is
failed.
USB_ERR_DEV_ABSENT
-3416
The device on USB host is absent.
USB_ERR_INVALID
-3417
USB communication state is invalid.
17.2 Communication control
17.2.1 OsPortOpen
Prototype
int OsPortOpen(int Channel,
const char *Attr);
Function
Opens communication port and sets communication parameters.
Parameters
Channel
Please refer to the Macro definition list of
communication ports, in S800, PORT_COM2 and
PORT_PINPAD can be multiplex used but only one
port at a time. While inS920, it only has ports of
PORT USBDEV and PORT USBHOST.Please refer to
Appendix 4.
Attr【Input】
When the channel is PORT_USBDEV or
PORT_USBHOST, attr does not work and it can be
NULL.
When the channel is UART port:
1. attr =―9600, 8, n, 1‖, it represents that the baud rate
is 9600bps; 8 data bits; no parity; 1 stop bit. ‗,‘ will
be used to separate characters.
2. Baud rate:
One of 1200, 2400, 4800, 9600, 19200, 38400,
57600,115200
3. Data bit: 7 or 8;
4. Parity method: o-odd parity; e-even parity; n-no
parity
5. Stop bit: 1 or 2
Return
RET_OK
Success.
ERR_DEV_BUSY
Device is busy.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 145
ERR_DEV_NOT_E
XIST
The port does not exist.
ERR_INVALID_PA
RAM
Invalid parameter.
Instruction
1. Other functions can be operated only after opening device successfully.
2. Calling this function will close the functions of software flow control and
hardware flow control.
17.2.2 OsPortClose
Prototype
void OsPortClose(int Channel);
Function
Closes the specified port.
Parameters
Channel
Please refer to the Macro definition list of communication
ports .
Return
None
Instruction
This function should be called to close the device while program exit.
17.2.3 OsPortSend
Prototype
int OsPortSend(int Channel,
const void *SendBuf,
int SendLen);
Function
Sends data to the specified communication port.
Parameters
Channel
Please Refer to the Macro definition of communication port
SendBuf【Input】
Sent data.
SendLen
Length of sending data.(<=8*1024)
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 146
Return
RET_OK
Success
ERR_DEV_NOT
_OPEN
Port is not open.
ERR_INVALID
_PARAM
Invalid parameter.
Instruction
1. The buffer size is 8K, when the sent data is less than the free space of the
buffer, this function will not block and the sent data will only be stored in
the send buffer.
2. When calling OsPortClose(), the system will block until the send buffer
data has been sent out.
17.2.4 OsPortRecv
Prototype
int OsPortRecv(int Channel,
void *RecvBuf,
int RecvLen,
int TimeoutMs);
Function
Receives data from specified communication port.
Parameters
Channel
Please Refer to the Macro definition of communication.
RecvBuf【Output】
Received data buffering.
RecvLen
The data length that want to receive. When the length is
0, it means clear the receive buffer.
TimeoutMs
Receive timeouts【unit:ms】
(The minimum precision is 100ms)
It should be <= 25500, otherwise, it will return
ERR_INVALID_PARAM.
Return
>=0
The actual length of receive data.
ERR_DEV_NOT_
OPEN
Port does not open.
ERR_INVALID_P
ARAM
Invalid parameter.
Instruction
1. The received data will return immediately when it is equal to the RecvLen.
2. If did not reach the RecvLen, it will wait for timeouts.
17.2.5 OsPortReset
Prototype
int OsPortReset (int Channel);
Function
Reset the port. This function will clear all the data in send and receive buffers
of COM port.
Parameters
Channel 【Input】
Please Refer to the Macro definition list of communication
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 147
ports.
Return
RET_OK
Success
ERR_DEV_NOT_OPEN
Port is not open
ERR_INVALID_PARAM
Invalid parameter
Instruction
17.2.6 OsPortCheckTx
Prototype
int OsPortReset(int Channel);
Function
Check the remaining bytes in sendbuffer of the specified COM port.
Parameters
Channel 【Input】
Please Refer to the Macro.
Return
>=0
The data size remained in the send buffer
ERR_DEV_NOT_OPEN
Port is not open
ERR_INVALID_PARAM
Invalid parameter
Instruction
17.3 POSIX
Prolin opens serial POSIX interfaces for applications developers to use.
The corresponding relation between device node and serial port is shown as below:
Device node
Serial port
The corresponding
module
applicable models
/dev/ttyAMA0
modem
modem
S800
/dev/ttyAMA1
wireless
wireless
S800/S900
/dev/ttyAMA2
PORT_COM1
COM1
S800/S900/S300/D200
/dev/ttyAMA3
PORT_PINPAD
pinpad
S800
/dev/ttyhost
PORT_USBHOST
usb
S800/S900/S300/D200
/dev/ttydev
PORT_USBDEV
usb
S800/S900/S300/D200
Concrete operations as follow:
17.3.1 Open
Opens the uart, and the device name are ttyAMA0, ttyAMA1, ttyAMA2, ttyAMA3.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 148
int fd;
/* Open the uart with read-write access mode*/
fd = open(“/dev/ttyAMA1”, O_RDWR);
if(-1 == fd){
perror (“Open uart error!”);
}
17.3.2 Read
Read data from communication port.
char buff [1024];
int Len = 1024;
int readByte = read (fd, buff, Len);
17.3.3 Write
Write data to the communication port. (send)
char buffer [1024];
int Length = 1024;
int nByte;
nByte = write (fd, buffer, Length);
17.3.4 Close
Close communication port.
close(fd);
17.3.5 Query the buffer data of communication port
int remain;
int count;
/* Inquiry the number of bytes remained in send buffer */
ioctl(fd, TIOCOUTQ, &remain);
/* Inquiry the number of bytes which remained in receive buffer */
ioctl(fd, TIOCINQ, &count);
17.3.6 Clear the buffer data of communication port
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 149
/* clear the buffer data*/
tcflush(fd, TCIOFLUSH);
17.3.7 Set the configuration parameters of communication port
/* Set the baud rate, data bits, parity bits and stop bits of uart*/
int SetTermios (int fd, int nSpeed, int nBits, char cEvent, int nStop)
{
struct termios newtio, oldtio;
/* Get configurations of the original uart */
if (tcgetattr (fd, &oldtio) != 0)
{
printf("Get serial error\n");
return -1;
}
/* Initialize the variable of new configuration */
bzero (&newtio, sizeof (newtio));
newtio.c_cflag |= CLOCAL | CREAD;
newtio.c_cflag &= ~CSIZE;
/* close soft flow control*/
newtio.c_iflag &= ~(ICRNL | IXON | IXOFF);
/* close hard flow control*/
newtio.c_cflag &= ~CRTSCTS;
/* set the data bits */
switch (nBits)
{
case 7:
newtio.c_cflag |= CS7;
break;
case 8:
newtio.c_cflag |= CS8;
break;
}
/* Configurate the parity bit*/
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 150
switch (cEvent)
{
case 'o':
newtio.c_cflag |= PARENB;
newtio.c_cflag |= PARODD;
newtio.c_iflag |= (INPCK | ISTRIP);
break;
case 'e':
newtio.c_iflag |= (INPCK | ISTRIP);
newtio.c_cflag |= PARENB;
newtio.c_cflag &= ~PARODD;
break;
case 'n':
newtio.c_cflag &= ~PARENB;
break;
}
/* Set the baud rate*/
switch (nSpeed)
{
case 1200:
cfsetispeed (&newtio, B1200);
cfsetospeed (&newtio, B1200);
case 2400:
cfsetispeed (&newtio, B2400);
cfsetospeed (&newtio, B2400);
break;
case 4800:
cfsetispeed (&newtio, B4800);
cfsetospeed (&newtio, B4800);
break;
case 9600:
cfsetispeed (&newtio, B9600);
cfsetospeed (&newtio, B9600);
break;
case 19200:
cfsetispeed (&newtio, B19200);
cfsetospeed (&newtio, B19200);
break;
case 38400:
cfsetispeed (&newtio, B38400);
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 151
cfsetospeed (&newtio, B38400);
break;
case 57600:
cfsetispeed (&newtio, B57600);
cfsetospeed (&newtio, B57600);
break;
case 115200:
cfsetispeed (&newtio, B115200);
cfsetospeed (&newtio, B115200);
break;
default:
printf ("Not support the speed %d\n", nSpeed);
cfsetispeed (&newtio, B9600);
cfsetospeed (&newtio, B9600);
return -1;
}
/* set the stop bits */
if (nStop == 1)
newtio.c_cflag &= ~CSTOPB;
else if (nStop == 2)
newtio.c_cflag |= CSTOPB;
/* Set the waiting time and the minimum number of characters, there is no
specific request for waiting time and receive characters ,and it can be set to 0
*/
newtio.c_cc[VTIME] = 0;
newtio.c_cc[VMIN] = 0;
/* Clear the send buffer*/
tcflush (fd, TCIFLUSH);
/* Set the new configuration message */
if ((tcsetattr (fd, TCSANOW, &newtio)) != 0)
{
printf("Set serial error\n");
return -1;
}
return 0;
}
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 153
18 MODEM
In Prolin, it can use the built-in UART to send AT commands to Modem and implement the
Modem communication functions; at the same time, it can encapsulate some Modem
communication interfaces for the developers to use.
18.1 Return code list
Table 17 Modem return code list
Macro
Value
Description
MODEM_CONNECTING
10
Dialing
MODEM_CONNECTED
0
Connected
MODEM_HAVE_DIALED
6
Start sending numbers (only
from automatically sending
mode to manually answering
mode)
MODEM_RECV_POOL_HAVE_DATA
8
Receive buffer is not empty
(received remote data)
MODEM_RECVDATA_SEND_IS_FULL
9
Receive buffer is not empty,
the send buffer is full.
MODEM_SEND_POOL_FULL
1
Send buffer is full. (In
OsModemCheck(), the full
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 154
status of send buffer represents
that the modem is using the
send buffer, at this time, the
OsModemSend() cannot be
used.)
MODEM_IDLE
11
Idle
ERR_MDM_TXOVER
-3100
Sending buffer full. (presents
return error. If synchronize, it
means the system is using the
send buffer; If asynchronize, it
means the send buffer is full. )
ERR_MDM_BYPASS_BUSY
-3101
The paralleled line is busy.
The hardware of NGFP S800
has no side telephone port, and
also no such return value.
ERR_MDM_LINE_BUSY
-3102
Telephone line is not properly
connected, or parallel line is
occupied.
ERR_MDM_NO_CARRIER
-3103
Carrier wave of telephone lost.
(Built synchronization chain
failure)
ERR_MDM_NO_ANSWER
-3104
No response for dialing.
ERR_MDM_CALLEE_BUSY
-3105
Line busy.
ERR_MDM_NO_LINE
-3106
Telephone line is not
connected (Line voltage is 0).
ERR_MDM_CMD_BUF_FULL
-3108
The excommand() buffer is
full.
ERR_MDM_CMD_TOO_LONG
-3109
Command of excommand() is
too long, exceeded 100.
ERR_MDM_CMD_NOT_SUPPORT
-3110
Excommand() does not
support the command.
OTHERS
-3XXX
(
-3111
~
-3199
Abnormal error code doesn‘t
appear frequently in practice.
Setting abnormal error code is
for the purpose of
maintainability. Details about
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 155
)
what error code means are not
important.
-3115
Calling synchronization
handshake receiving process 1
error
-3116
Calling synchronization
handshake receiving data
package error.
-3117
Calling synchronization
handshake receiving package
type error.
-3118
Calling synchronization
handshake receiving process 2
error
-3119
Calling synchronous
communication receiving
process 1 error
-3120
Calling synchronous
communication chip hang up
-3121
Calling synchronous
communication receiving
packet series number error
-3122
Calling synchronous
communication receiving
process 2 error
-3123
Calling synchronous
communication sent overload
-3124
Calling synchronous
communication sent under
load.
-3130
Calling synchronous
communication line rate is
illegal.
-3131
Calling synchronous
communication send state
packet 1 errors
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 156
-3132
Calling synchronous
communication sent data
packets retry more than the
specified time.
-3133
Calling synchronous
communication sent data
packets timeout
-3134
Calling synchronous
communication receiving the
acknowledgement packet retry
more than the specified time
-3135
Calling synchronous
communication sent stateful
packet 2 error
-3136
Calling synchronous
communication sent stateful
packet 3 error
-3137
Calling synchronous
communication sent stateful
packet 4 error
-3138
Calling synchronous
communication receiving data
packets retry more than the
specified time
-3139
Calling synchronous
communication sent stateful
packet 5 error
-3140
Calling synchronous
communication sent stateful
packet 6 error
-3144
Sent number automatically
and not to pick up the phone
timely.
-3145
Called synchronization
handshake sent handshake
packets failed
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 157
-3146
Called synchronization
handshake receiving
handshake packets failed
-3147
Called synchronization
handshake more than the
specified time.
-3148
Called synchronous
communication sent stateful
packet 1 error
-3149
Called synchronous
communication receiving
process 1 error
-3150
Called synchronous
communication chip hang up
-3151
Called synchronous
communication receiving
process 2 error
-3152
Called synchronous
communication receiving retry
more than the specified time
-3153
Called synchronous
communication sent stateful
packet 2 error
-3154
Called synchronous
communication sent data
packet error
-3155
Called synchronous
communication receiving
process 3 error
-3156
Called synchronous
communication receiving the
packet retry more than the
specified time
-3157
Called synchronous
communication sent stateful
packet 3 error
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 158
-3160
Called connection receiving
ring information error
-3161
Called connection detecting
the line voltage failed
-3162
Called connection detecting
the line voltage data format
error
-3163
Called connection voltage is
less than the threshold
-3164
Called connection timeout
-3165
Called asynchronous line rate
format is incorrect
-3166
Called asynchronous line rate
is illegal.
-3167
Called connection information
format is incorrectly.
-3170
Called connection set the
instruction string 1 failed
-3171
Called connection set the
instruction string 2 failed
-3172
Called connection set the
extended instruction string
failed
-3175
Calling connection set
instruction string 1 failed.
-3176
Calling connection set
instruction string 2 failed.
-3177
Calling connection set
instruction string 3 failed.
-3178
Calling connection set
instruction string 4 failed.
-3180
Calling connection set
instruction string 5 failed.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 159
-3181
Calling connection
asynchronous line rate is
illegal
-3182
Calling connection set
instruction string 6 failed.
-3183
Calling connection set
extended instruction string
failed
-3185
Calling connection has no dial
tone.
-3186
Calling connection chip
indicate an error.
-3187
Calling connection detect the
digital lines.
-3188
Calling connection has no dial
tone and the voltage is too
low.
-3189
Calling connection has other
exception errors.
-3192
Non-pre-dial-up dial up
timeout
(300s)
-3193
When FSK sends data, the
DCD signal timeout
-3194
When FSK sends data, the
CTS signal timeout
-3195
FSK sends data timeout.
-3196
Called synchronous
communication sent data
packet format error
-3197
Asynchronous communication
does not support the Connect
Format parameters
-3198
Daemon to create thread failed
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 160
-3199
The process with Daemon
communication failure or error
-3200
Modem is using the bound
uart.
-3201
Socket creation failed
-3202
Socket link failed
-3203
Socket send failed
-3204
Create semaphore failed
-3205
Set the semaphore value failed
-3206
Semaphore has been
pre-empted.
-3207
Semaphore cannot be released.
-3208
Semaphore initialization failed
-3209
Failed to get time of the day.
-3210
More than 2 links are using the
modem daemon
-3211
Received the cancel button in
the dial-up process.
-3212
The request of receiving data
is rejected. (Receive buffer is
empty.)
-3213
The command string 7 of
calling connection Setting is
failed.
-3214
The command string 8 of
calling connection Setting is
failed.
-3215
FSK sending is overtime, but
still has data in send buffer.
-3216
Invalid data length (len=0 or
len>2048), will not send data.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 161
ERR_MDM_INIT
-3217
Modem initialization failed.
-3218
If does not implement
OsModemConnect(), or
implemented
OsModemConnect() wrongly,
then implement
OsPppomLogin() or
OsPppomCheck().
-3219
The Modem or ModemPPP is
being used, Modem cannot be
powered off.
-3220
Modem does not power on.
18.2 Data structure
ST_MODEM_SETUP:
typedef struct {
int CallMode;
int CommMode;
int CodeType;
int CodeDuration;
int CodeSpacing;
int DetectLineVoltage;
int DetectDialTone;
int DialToneTimeout;
int CommaPauseTime;
char ConnectRate[20];
char ConnectFormat[20];
int ConnectTimeout;
int DialTimes;
int IdleTimeout;
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 162
int Pppom;
int Reserved[9];
}ST_MODEM_SETUP;
Table 18 Variable definition of ST_MODEM_SETUP
CallMode
MODEM_PRE_DIAL
Caller pre-dial
MODEM_DIAL
Caller dial
MODEM_WAIT_CALL
Called/Answered the call
CommMode
MODEM_COMM_SYN
C
synchronous
MODEM_COMM_ASY
NC
asynchronous
CodeType
MODEM_CODE_DTMF
DTMF(Dual Tone Multi Frequency) dialing
MODEM_CODE_PULS
E1
Pulse dialing 1(Pulse rate 10/s; Intermittent
proportion 1.6:1;Signal interval>=500ms)
MODEM_CODE_PULS
E2
Pulse dialing 2(Pulse rate 10/s; Intermittent
proportion 2:1; Signal interval >=600ms)
Other values
Reserved
CodeDuration
The duration of two-tone dialing a single number (Unit:10ms,valid range
5~25)
CodeSpacing
The interval time between two numbers of two-tone dial-up. It cannot be
set to any value in 93011 chip, and it is not applicable to S800.
(Unit:10ms, valid range 5~25)
DetectLineVoltage
TRUE
Detect the parallel telephone occupation
(Caller dialing, No assigned number
switch to manual answer mode)
FALSE
Doesn‘t not detect the parallel telephone
occupation (Caller dialing, if there is no
assigned number, switch to manual
answer mode)
DetectDialTone
TRUE
Dial tone detection. Refer to the
instruction of DailTone Timeout.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 163
FALSE
Does not detect dial tone.
If the 8th bit of DetectDialTone is
1(0x80), while set is called, it will not
postback in 8s and the drive will send 15
to client, or the drive will postback 15 to
client.
DialToneTimeout
Dial tone detection:
The longest time to wait for the dial tone. Exit waiting when the dial
tone has been detected during this time.
Dial tone not detected:
The waiting time for dial tone when hang up machine.
Unit: 100ms, both the minimum value and default value are 20, valid
range is 20~50.
In both cases, waits 450 to 500ms to start starts the timer after hanging
up the machine.
CommaPauseTime
―,‖wait time when dial outside line (Unit: 100ms). This value will be set
according to the actual application environment. It is better to keep
interface of manually setting in the application. (Range is 0~255. The
range is not applicable to S800)
The valid range of S800 is 1~26s (Because of the modem patch, it is
inconsistent with the Datasheet)
ConnectRate[20]
The rate of connection and communication(Expressed as a string
):
―1200‖//1200 bps fast connect
―1200,V22‖//1200 bps normal connect
―1200,V23C‖//1200 bps for V.23C(FSK)
―1200,B202‖//1200 bps for Bell 202(FSK)
―2400,FC‖//2400 bps fast connect
―2400‖//2400 bps normal connect
―4800‖//4800 bps
―7200‖//7200 bps
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 164
―9600‖//9600 bps
―12000‖//12000 bps
―14400‖//14400 bps
―19200‖//19200 bps
―24000‖//24000 bps
―26400‖//26400 bps
―28800‖//28800 bps
―31200‖//31200 bps
―33600‖//33600 bps
―48000‖//48000 bps
―56000‖//56000 bps
For null string "\ 0"and synchronous communication, the system will
select ―1200‖ by default.
For asynchronous communication, the system will by default select the
maximum rate that the chip can support.
S800 supports the baud rate.
Asynchronous:
―1200‖//1200 bps
―1200,V23C‖//1200 bps for V.23C(FSK)
―1200,B202‖//1200 bps for Bell 202(FSK)
―2400‖//2400 bps
―4800‖//4800 bps
―7200‖//7200 bps
―9600‖//9600 bps
―12000‖//12000 bps
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 165
―14400‖//14400 bps
―19200‖//19200 bps
―24000‖//24000 bps
―26400‖//26400 bps
―28800‖//28800 bps
―31200‖//31200 bps
―33600‖/33600 bps
―48000‖//48000 bps
―56000‖//56000 bps
Synchronous:
―1200‖//1200 bps
―1200,V22‖//1200 bps normal connect
―2400,FC‖//2400 bps fast connect
―2400‖//2400 bps
―9600‖//9600 bps
ConnectFormat[20
Format of connection and communication(Expressed as a string):
―8, n, 1‖
―8, e, 1‖
―8, o, 1‖
―7, e, 1‖
―7, o, 1‖
For null string "\ 0", the system will select―8, n, 1‖ by default.
For Synchronous communication, the system will select―8, n, 1‖
automatically.
ConnectTimeout
Timeouts of waiting for connection,【unit: s】,(valid range 0~300)
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 166
DialTimes
The total number of dial-up cycle (convert 0 to 1 if it is 0). Dialing all
the numbers in a dial number string is one cycle (valid range is 1~255).
IdleTimeout
There is no application-layer data exchange in the specified time.
MODEM then will hang up. Use 10s as a unit., no timeout if it is 0. The
maximum timeout is 900s.This value is invalid to Modem PPP.
Pppom
TRUE
Modem PPP communication
FALSE
Common communication
Reserved[9]
Reserved.
18.3 OsModemOpen
Prototype
int OsModemOpen(void);
Function
Switches on the Modem device.
Parameters
None
Return
RET_OK
Success
ERR_DEV_NOT_EXIST
Device does not exist.
ERR_DEV_BUSY
Device is busy.
ERR_NO_PORT
No communication port.
Instruction
Other functions can be operated only after opening the device successfully. It
should call the OsModemSwitchPower() to power on the device before using
the Modem.
18.4 OsModemClose
Prototype
void OsModemClose(void);
Function
Switches off the Modem device.
Parameters
None
Return
None
Instruction
This function can only close the modem that is opened by the local application.
When the modem device is not open, this function can‘t do any operation.
18.5 OsModemSwitchPower
Prototype
int OsModemSwitchPower(int OnOff);
Function
Manages the Modem Power.
Parameters
int OnOff
OnOff=1, power on,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 167
OnOff=0, power off.
Return
RET_OK
Success
-3219
The Modem or ModemPPP is being used,
Modem cannot be power off.
-3220
Modem does not power on.
Instruction
1. It should power on the Modem before using Modem or ModemPPP.
2. This function is independent of the interface functions in Modem module.
3. It will not automatically perform OsModemClose() when Modem module is
powered off.
18.6 OsModemConnect
Prototype
int OsModemConnect(const ST_MODEM_SETUP *Setup,
const unsigned char *TelNo);
Function
Sets the communication link function, for both calling and being called.
Parameters
Setup【Input】
Modem parameter.
While mdm_setup==NULL, default dialing
parameter will be used.
Default dialing mode includes: Synchronous,
1200, DTMF, connection timeout for 10
seconds, idle hang up for 60 seconds.
TelNo【Input】
Telephone number.
Return
RET_OK
Success
ERR_MDM_BYPASS_BUSY
The paralleled line is busy.
ERR_MDM_LINE_BUSY
Telephone line is not properly connected, or
parallel line is occupied.
ERR_MDM_NO_ANSWER
No response for dialing.
ERR_MDM_CALLEE_BUSY
Line is busy.
ERR_MDM_NO_LINE
Telephone line is not connected (Line voltage
is 0).
ERR_MDM_NO_CARRIER
Carrier wave of telephone lost.
ERR_INVALID_PARAM
Invalid parameter.
ERR_MDM_CANCEL_KEY
_DOWN
Press CANCEL key while dialing.
ERR_DEV_NOT_OPEN
Device is not open.
Instruction
1. The function can also be used to set Modem mode to being called.
2. Telephone icon will be controlled by a program. It shows hang-up icon
while connecting; it shows pickup icon when communication is
established, or during switching time of pre-dial after hang-up.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 168
3. It needs to call the OsModemCheck() to query the result of pre-dial.
4. It must call OsModemConnect() before using the ModemPPP, sets
ST_MODEM_SETUP.Pppom=1, and it doesn‘t need to call
OsModemOpen (), then calls OsPppomLogin().
18.7 OsModemCheck
Prototype
int OsModemCheck(void);
Function
Checks the status of Modem and telephone line.
Parameters
None
Return
MODEM_CONNECTING
Dialing
MODEM_CONNECTED
Connected
MODEM_IDLE
Idle
ERR_MDM_BYPASS_BUSY
The parallel line is busy.
ERR_MDM_LINE_BUSY
Telephone line is not properly connected, or
parallel line is occupied.
ERR_MDM_NO_ANSWER
No response for dialing.
ERR_MDM_CALLEE_BUSY
Line busy.
ERR_MDM_NO_LINE
Telephone line is not connected (Line voltage
is 0).
ERR_MDM_NO_CARRIER
Carrier wave of telephone lost.
ERR_MDM_RECVPOOL_N
OT_EMPTY
Receive buffer is not empty(received remote
data)
ERR_MDM_RECVPOOL_SE
NDPOOL_BOTH_NOT_EMP
TY
Receive buffer is not empty (received remote
data), and the send buffer is sending data.
ERR_DEV_NOT_OPEN
Device is not open.
Instruction
1. This function can be used to check whether communication has been
established or not by the pre-dial.
2. After calling OsModemOpen(), OsModemHangup() or OsModemClose(),
the status of the last Modem dial will become: MODEM_IDLE.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 169
18.8 OsModemExCmd
Prototype
int OsModemExCmd(const char *Cmd,
char *Rsp,
int *RespLen,
int TimeoutMs);
Function
Sets additional AT control command for OsModemConnect() to control the
connection behavior of Modem dialing.
Parameters
Cmd 【Input】
Input AT control command.
Rsp 【Output】
Contents of response data.
RespLen 【Output】
Length of response data.
TimeoutMs
Waiting time for response.(unit:ms)
Return
RET_OK
Success
ERR_INVALID_PARAM
Invalid parameter.
ERR_MDM_CMD_BUF_
FULL
Command buffer overflow.
ERR_MDM_CMD_TOO_
LONG
Command is too long.
ERR_MDM_CMD_NOT_
SUPPORT
Does not support the command. (command that
begin with AT,S3,S7,WT=)
ERR_DEV_NOT_OPEN
Device is not open.
Instruction
1. The function is needed to be called before OsModemConnect(), and it is
only valid for the entire process of OsModemConnect().
2. While the function is executing, it will automatically hang up current
dialing or communication process.
3. The function can be called 100 times continuously. If it is more than 100,
the exceeding callings will be discarded and report error.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 170
18.9 OsModemHangup
Prototype
void OsModemHangup(void);
Function
Hangs up Modem or terminates Modem dialing.
Parameters
None
Return
None
Instruction
If dialing the number again right after hanging up, the Modem will wait and
start redialing after 3 seconds in order to allow PABX finish hanging up and
transmitting dialing tone.
18.10 OsModemSend
Prototype
int OsModemSend(const void *SendBuf,
int SendLen);
Function
Sends packets out through Modem.
Parameters
SendBuf【Input】
Pointer of packets, which will be sent
SendLen
Length of packets, which will be sent (bytes)
Return
RET_OK
Success
ERR_NOT_CONNE
CT
Not connected.
ERR_MDM_TXOVE
R
Send buffer is full.
ERR_MDM_NO_CA
RRIER
No carrier waves.(Disconnected)
ERR_INVALID_PAR
AM
Invalid parameter
ERR_DEV_NOT_OP
EN
Device is not open.
Instruction
It can send 2048 bytes each time at most. Receiving and sending data of
synchronous called are up to 2053 bytes, because there are more than 5 control
characters.
18.11 OsModemRecv
Prototype
int OsModemRecv(void *RecvBuf,
int BufSize,
int Timeout);
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 171
Function
Receives packets by MODEM.
Parameters
RecvBuf 【Output】
Pointer of the packets that have been received.
[Buffer size can be defined according to the
requirements of different cases.]
BufSize
Size of RecvBuf (<=2048bytes)
Timeout
Timeouts【ms】
Return
>= 0
The actual number of receiving data.
ERR_NOT_CONNECT
Not connected.
ERR_MDM_NO_CARRIE
R
No carrier waves.(Disconnected)
ERR_INVALID_PARAM
Invalid parameter
ERR_DEV_NOT_OPEN
Device is not open.
Instruction
1. It can receive 2048 bytes each time at most. Receiving and sending data of
synchronous called are up to 2053 bytes, because it has 5 more control
characters.
2. If the size of actual data is not larger than the specified size of receive
buffer, it will return immediately.
3. While receiving data, if there‘s a line error, it will immediately return the
corresponding error code.
4. For SDLC synchronous communication, it will immediately return after
receiving a packet.(even if the received packet length is less than the
BufSize)
5. For asynchronous communication, it will immediately return after
receiving byte data of BufSize, or wait until the timeout.
6. For synchronous receiving, it will receive a complete frame each time, and
it is not limited by BufSize.
7. For FSK, the timeout does not work.
18.12 OsPppomLogin
Prototype
int OsPppomLogin(const char *Name
const char *Password,
long Auth,
int TimeOutMs);
Function
Establishes the Modem PPP network link.
Parameters
Name 【Input】
User name;
Length<=50 bytes;
It cannot be NULL.
For the 96169 background of ChinaTelecom, it can
enter any user name, and it must enter a character at
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 172
least.
Password 【Input】
Password;
Length<=50 bytes;;
It cannot be NULL.
For the 96169 background of ChinaTelecom, it can
enter any password, and it must enter a character at
least.
Auth
Authentication Algorithms;
Currently the following Authentication algorithms are
supported
PPP_ALG_PAP
0x1
PAP Authentication
Algorithm
PPP_ALG_CHAP
0x2
CHAP
Authentication
Algorithm
PPP_ALG_MSCH
APV1
0x4
MSCHAPV1
Authentication
Algorithm
PPP_ALG_MSCH
APV2
0x8
MSCHAPV2
Authentication
Algorithm
PPP_ALG_ALL
0xff
All Authentication
Algorithms
At least one type of authentication algorithm has to be
selected, more than one authentication algorithm will
also be allowed by using (+) or (|), for example,
PPP_ALG_PAP| PPP_ALG_CHAP. If the algorithm is
unknown, fill with parameter PPP_ALG_ALL.
TimeOutMs
Timeouts【unit:ms】;
The valid range is 0~3600000.
If timeout is <0, it will automatically be set to 0.
If more than 360000. It will automatically be set to
3600000.
Return
PPP_LOGINING
In process
RET_OK
The link established successfully.
ERR_INVALID_PAR
AM
Invalid parameter
ERR_NET_PASSWD
wrong password
ERR_NET_SERVER
_BUSY
Server is busy, communication failed.
Instruction
1. Before using this function, call OsModemConnect() first and set the
ST_MODEM_SETUP.Pppom to 1, also it doesn‘t need to call
OsModemOpen();
2. TimeOutMs=0 means return immediately,
3. Call OsPppomCheck() to check the link status
4. The login time may vary from settings to settings of ST_MODEM_SETUP
parameters. The modem chip of S800 supports up to 33600 asynchronous
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 173
baud rate, dial-up while the setting is less than or equal to 33600, there will
be a low re-training rate and high success rate.
5. For the 96169 background (Guidway A8010), if a re-training is occurred
and the time period after sending number is more than 20 seconds, then the
background communication will no longer confirm to ppp protocol, which
will end up in failure.
6. After the link has been set up successfully, it can communicate through the
IP network communication function.
7. In the process of dialing, when users want to hang up by pressing the cancel
button, the methods of operation are as follows: Application porting a thread
and take the key, if it is the cancel key, perform OsPppomLogin ("a", "a", 1,
-1), the first 3 parameters should be filled in accordance with the
requirements, and the fourth parameter must be set to -1, then ModemPPP
will hang-up and automatically logout.
18.13 OsPppomCheck
Prototype
int OsPppomCheck(void);
Function
Checks the link status of Modem network.
Parameters
None
Return
PPP_LOGOUTING
In disconnection state
PPP_LOGINING
In process
RET_OK
Established the link successfully.
ERR_NET_PASSWD
wrong password
ERR_NET_LOGOUT
Already called OsPppomLogout() to
disconnect the link.
ERR_NET_IF
Link has been disconnected.
Instruction
18.14 OsPppomLogout
Prototype
int OsPppomLogout(void);
Function
Exits network, disconnect the Modem PPP link.
Parameters
None
Return
RET_OK
Success
Instruction
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 175
19 Network
Communication
Prolin uses the unified TCP/IP stack to manage different physical connections. For the
network communications programming, it provides a standard socket programming (socket).
19.1 TCP programming
/* Server code in C */
#include <sys/types.h>
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <unistd.h>
int main(void)
{
struct sockaddr_in stSockAddr;
int SocketFD = socket(PF_INET, SOCK_STREAM, IPPROTO_TCP);
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 176
if(-1 == SocketFD)
{
perror("cannot create socket");
exit(EXIT_FAILURE);
}
memset(&stSockAddr, 0, sizeof(stSockAddr));
stSockAddr.sin_family = AF_INET;
stSockAddr.sin_port = htons(1100);
stSockAddr.sin_addr.s_addr = INADDR_ANY;
if(-1 == bind(SocketFD,(struct sockaddr *)&stSockAddr,
sizeof(stSockAddr)))
{
perror("error bind failed");
close(SocketFD);
exit(EXIT_FAILURE);
}
if(-1 == listen(SocketFD, 10))
{
perror("error listen failed");
close(SocketFD);
exit(EXIT_FAILURE);
}
for(;;)
{
int ConnectFD = accept(SocketFD, NULL, NULL);
if(0 > ConnectFD)
{
perror("error accept failed");
close(SocketFD);
exit(EXIT_FAILURE);
}
/* perform read write operations ...
read(ConnectFD,buff,size)*/
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 177
if (-1 == shutdown(ConnectFD, SHUT_RDWR))
{
perror("cannot shutdown socket");
close(ConnectFD);
exit(EXIT_FAILURE);
}
close(ConnectFD);
}
return EXIT_SUCCESS;
}
/* Client code in C */
#include <sys/types.h>
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <unistd.h>
int main(void)
{
struct sockaddr_in stSockAddr;
int Res;
int SocketFD = socket(PF_INET, SOCK_STREAM, IPPROTO_TCP);
if (-1 == SocketFD)
{
perror("cannot create socket");
exit(EXIT_FAILURE);
}
memset(&stSockAddr, 0, sizeof(stSockAddr));
stSockAddr.sin_family = AF_INET;
stSockAddr.sin_port = htons(1100);
Res = inet_pton(AF_INET, "192.168.1.3", &stSockAddr.sin_addr);
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 178
if (0 > Res)
{
perror("error: first parameter is not a valid address family");
close(SocketFD);
exit(EXIT_FAILURE);
}
else if (0 == Res)
{
perror("char string (second parameter does not contain valid
ipaddress)");
close(SocketFD);
exit(EXIT_FAILURE);
}
if (-1 == connect(SocketFD, (struct sockaddr *)&stSockAddr,
sizeof(stSockAddr)))
{
perror("connect failed");
close(SocketFD);
exit(EXIT_FAILURE);
}
/* perform read write operations ... */
shutdown(SocketFD, SHUT_RDWR);
close(SocketFD);
return EXIT_SUCCESS;
}
19.2 UDPprogramming
#include <stdio.h>
#include <errno.h>
#include <string.h>
#include <sys/socket.h>
#include <sys/types.h>
#include <netinet/in.h>
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 179
#include <unistd.h> /* for close() for socket */
#include <stdlib.h>
int main(void)
{
int sock = socket(PF_INET, SOCK_DGRAM, IPPROTO_UDP);
struct sockaddr_in sa;
char buffer[1024];
ssize_t recsize;
socklen_t fromlen;
memset(&sa, 0, sizeof sa);
sa.sin_family = AF_INET;
sa.sin_addr.s_addr = INADDR_ANY;
sa.sin_port = htons(7654);
fromlen = sizeof(sa);
if (-1 == bind(sock,(struct sockaddr *)&sa, sizeof(sa)))
{
perror("error bind failed");
close(sock);
exit(EXIT_FAILURE);
}
for (;;)
{
printf ("recv test....\n");
recsize = recvfrom(sock, (void *)buffer, sizeof(buffer), 0, (struct sockaddr
*)&sa, &fromlen);
if (recsize < 0) {
fprintf(stderr, "%s\n", strerror(errno));
exit(EXIT_FAILURE);
}
printf("recsize: %z\n ", recsize);
sleep(1);
printf("datagram: %.*s\n", (int)recsize, buffer);
}
}
#include <stdlib.h>
#include <stdio.h>
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 180
#include <errno.h>
#include <string.h>
#include <sys/socket.h>
#include <sys/types.h>
#include <netinet/in.h>
#include <unistd.h>
#include <arpa/inet.h>
int main(int argc, char *argv[])
{
int sock;
struct sockaddr_in sa;
int bytes_sent;
char buffer[200];
strcpy(buffer, "hello world!");
sock = socket(PF_INET, SOCK_DGRAM, IPPROTO_UDP);
if (-1 == sock) /* if socket failed to initialize, exit */
{
printf("Error Creating Socket");
exit(EXIT_FAILURE);
}
memset(&sa, 0, sizeof sa);
sa.sin_family = AF_INET;
sa.sin_addr.s_addr = inet_addr("127.0.0.1");
sa.sin_port = htons(7654);
bytes_sent = sendto(sock, buffer, strlen(buffer), 0,(struct sockaddr*)&sa,
sizeof sa);
if (bytes_sent < 0) {
printf("Error sending packet: %s\n", strerror(errno));
exit(EXIT_FAILURE);
}
close(sock); /* close the socket */
return 0;
}
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 181
20 Network Configuration
Prolin provides the interface for network configuration, including ARP settings, Ping services,
DNS configuration, network card configuration, DHCP service, routing settings and PPPoE
service etc.
20.1 Return code list
Table 19 Network Configuration return code list
Macro
Value
Description
ERR_NET_SERVER_BAD
-3301
IP server error.
ERR_NET_SERVER_BUSY
-3302
IP server is busy; it can only provide
service for at most 5 applications at a
time.
ERR_NET_NO_ROUTE
-3305
Haven‘t configured the router
ERR_NET_FULL
-3306
Connection is full; the application
can set up to 20 connections at a
time.
ERR_NET_IF
-3307
Network interface link is unavailable
(The link has not set up or there is no
corresponding device.)
ERR_NET_SESS_BROKEN
-3308
TCP / UDP session connection is
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 182
broken and unavailable.
ERR_NET_PASSWD
-3309
Password is incorrect.
ERR_NET_LOGOUT
-3310
Application logout initiatively.
ERR_NET_INIT
-3311
Initialization failed.
ERR_NET_DHCP_DISCOVER
-3312
Has not found DHCP Server.
ERR_NET_DHCP_OFFER
-3313
DHCP cannot be assigned the IP
address.
ERR_NET_DHCP_START
-3314
DHCP has not started.
ERR_NET_DNS
-3315
DNS cannot analyze the
corresponding domain.
ERR_NET_SERV_USING
-3316
The port specified by the server is in
use.
ERR_NET_NODNServer
-3317
Has not configured the domain name
server
ERR_NET_LINKDOWN
-3318
Link is disconnected by the server.
ERR_NET_CONN
-3319
Cannot connect to the specified
server.
ERR_NET_TIMEOUT
-3320
Connection timeout
ERR_NET_PPP
-3321
PPP connection error
ERR_NET_SERV
-3322
Has not found the PPPoE server
ERR_NET_AGAIN
-3323
The request resource wasn‘t found,
please try again.
ERR_NET_AUTH
-3324
Has no authority to access to the
RADIUS server.
NET_DOING
1
Some related operations are being
done.(such as PPP login, DHCP)
20.2 Data Definition
20.2.1 Physical channel list
Table 20 Physical Channel List
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 183
Macro
Description
NET_LINK_ETH
Ethernet
NET_LINK_WL
Wireless, including GPRS, CDMA, TDSCDM
A
NET_LINK_WIFI
WIFI
NET_LINK_PPPOE
ADSL link
NET_LINK_MODEM
Modem PPP link
20.3 Network Configuration interface
20.3.1 OsNetAddArp
Prototype
int OsNetAddArp(int NetLink,
const char *Addr,
const char MAC[6]);
Function
Adds the IP address to MAC address mapping table, which is static.
Parameters
NetLink
Physical channel can only be set to Ethernet and WIFI;
NET_LINK_ETH Ethernet;
NET_LINK_WIFI WIFI
Addr【Input】
IP address.
The format is ―XXX.XXX.XXX.XXX‖, and XXX ranges
from 0 to 255. For example: ―192.168.0.1‖;
Cannot be NULL.
MAC【Input】
the MAC address corresponding to the IP address;
Cannot be NULL, the space has 6 bytes.
Return
RET_OK
Success
<0
Failed, the value is error code.
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 184
1. Static ARP table is used to resist the attack from ARP Cheat,
2. If there is no static ARP table, the system will dynamically
obtain, and it doesn’t need to be configured by the
application.
20.3.2 OsNetPing
Prototype
int OsNetPing(const char *Addr,
int TimeOutMs);
Function
Pings a specific machine to check the status of network connection.
Parameters
Addr【Input】
The IP address of target device;
Format is ―XXX.XXX.XXX.XXX‖, XXX represents
0~255, for example:‖192.168.0.3‖;
TimeOutMs
Timeout【unit:ms】, the valid range is 3000~3600000.
Return
RET_OK
Success
ERR_NET_IF
Link is unavailable, means the link has not been set
correctly (or has been disconnected).
ERR_INVALID_P
ARAM
Invalid parameter
ERR_TIME_OUT
Timeout
Instruction
Use the default route to do the communication, and searching the route can be
done by calling OsNetGetRoute().
20.3.3 OsNetPingEx
Prototype
int OsNetPingEx(const char *Addr,
int TimeOutMs,
int Size);
Function
Pings a specific IP address to check the status of the network
connection.
Parameters
Addr 【Input】
IP address of the target device.
The format is ―XXX.XXX.XXX.XXX‖, the
range of XXX is 0~255, for example
―192.168.0.3‖.
TimeOutMs
【Input】
Timeout 【unit:ms 】the valid range is
3000~3600000.
Size 【Input】
The size of the data, it can‘t exceed 1024 bytes.
Return
>0
Success, the time takes to ping
ERR_NET_IF
Link is unavailable, means the link has not been
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 185
set correctly (or has been disconnected).
ERR_INVALID_
PARAM
Invalid parameter
ERR_TIME_OU
T
Timeout
Usage
Use the default route to do the communication, and searching the
route can be done by calling OsNetGetRoute().
20.3.4 OsNetDns
Prototype
int OsNetDns(const char *Name,
char *Addr,
int TimeOutMs);
Function
Analyzes the IP address corresponding to the domain name and stores the
results in Addr parameter.
Parameters
Name【Input】
Information of domain name, for example:
[www.sina.com.cn].
The maximum length cannot be NULL and cannot
exceed255 characters.
Addr【Output】
It is an output parameter;
Use to store the IP address, mapped by the domain name,
the format is ―XXX.XXX.XXX.XXX‖, XXX represents
0~255,e.g:‖192.168.0.3‖;
It cannot be NULL; there are at least 16 bytes in the
space.
TimeOutMs
Timeout【unit:ms】, the valid range is 1000~3600000
Return
RET_OK
Success
ERR_NET_IF
The Link is unavailable, means the link has not been set
correctly (or has been disconnected).
ERR_INVALID_P
ARAM
Invalid parameter
ERR_TIME_OUT
Timeout.
ERR_NET_DNS
The domain server cannot analyze the corresponding
domain, or it does not exist.
Instruction
Use the default route to do the communication, and searching the route can be
done by calling OsNetGetRoute().
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 186
20.3.5 OsNetSetConfig
Prototype
int OsNetSetConfig(int NetLink,
const char *Addr,
const char *Mask,
const char *Gateway,
const char *DNSServer);
Function
Configures the network information.
Parameters
NetLink
Physical channel can only be set to Ethernet and
WIFI;
NET_LINK_ETH Ethernet;
NET_LINK_WIFI WIFI
Addr【Input】
The address used by POS
Format is ―XXX.XXX.XXX.XXX‖, XXX
represents 0~255;
e.g: ―192.168.0.3‖;
If it is ― ‖ or NULL, means do not change the
previous configuration;
Mask【Input】
Mask code used by POS;
Format is ―XXX.XXX.XXX.XXX‖;
e.g.: ―255.255.255.0‖;
If it is ― ‖ or NULL, means do not change the
original configuration;
Gateway【Input】
Address of the default gateway
Format is ―XXX.XXX.XXX.XXX‖, XXX
represents 0~255;
e.g.: ―192.168.0.1‖;
if it is ― ‖ or NULL, means do not change the
previous configuration;
DNSServer【Input】
DNS server address
Format is ―XXX.XXX.XXX.XXX‖, XXX
represents 0~255;
e.g.: ―192.168.0.1‖;
if it is ― ‖ or NULL, means do not change the
previous configuration;
Return
RET_OK
Success
ERR_NET_IF
The link is unavailable, means the link has not
been set correctly (or has been disconnected).
ERR_INVALID_PARAM
Invalid parameter.
Instruction
1. After calling successfully, the system will stop the DHCP function.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 187
2. The function does not check the matching relationship between Addr,
Mask and Gateway; it only checks the validity of their formats.
3. Wireless link, PPPoE, and ModemPPP can only be dynamically
allocated and cannot be configured by this interface.
4. After setting the configuration successfully, this link will be set to be
the default route.
20.3.6 OsNetGetConfig
Prototype
int OsNetGetConfig(int NetLink,
char *Addr,
char *Mask,
char *Gateway,
char *DNSServer);
Function
Gets the network configuration information, such as IP, subnet mask, gateway
and DNS.
Parameters
NetLink
Physical channel can only be set to Ethernet and WIFI;
NET_LINK_ETH Ethernet;
NET_LINK_WIFI WIFI(Wireless Local Area
Network)
Addr【Output】
The address used by POS is an Output parameter. There are
at least 16 bytes in the space. The format is
―XXX.XXX.XXX.XXX‖, XXX represents 0~255;
e.g.: ―192.168.0.3‖;
It can be NULL.
Mask【Output】
Mask code used by POS is an Output parameter. There are
at least 16 bytes in the space.
Format is ―XXX.XXX.XXX.XXX‖;
e.g.: ―255.255.255.0‖;
It can be NULL.
Gateway
【Output】
Address of the default gateway is an Output parameter.
There are at least 16 bytes in the space.
Format is ―XXX.XXX.XXX.XXX‖, XXX represents
0~255;
e.g.: ―192.168.0.1‖;
It can be NULL.
DNSServer
【Input】
DNS server address is an Output parameter. There are at
least 16 bytes in the space.
Format is ―XXX.XXX.XXX.XXX‖, XXX represents
0~255;
e.g.: ―192.168.0.1‖;
It can be NULL.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 188
Return
RET_OK
Success
ERR_NET_IF
The link is unavailable, means the link has not been set
correctly.
Instruction
20.3.7 OsNetStartDhcp
Prototype
int OsNetStartDhcp(int NetLink);
Function
Starts the DHCP function to obtain a dynamically assigned address.
Parameters
NetLink
Physical channel can only be set to Ethernet and WIFI;
NET_LINK_ETH Ethernet;
NET_LINK_WIFI WIFI(Wireless Local Area
Network)
Return
RET_OK
Success
ERR_NET_IF
Has not configured Ethernet or WIFI.
Instruction
1. This interface is only used to start the DHCP function, does not wait
for assigning addresses.
2. It can check whether assigning address is completed by calling the
OsNetCheckDhcp () or not.
3. After acquiring the address successfully, this link is set to be the
default route.
20.3.8 OsNetCheckDhcp
Prototype
int OsNetCheckDhcp(int NetLink);
Function
Check DHCP status.
Parameters
NetLink
Physical channel can only be set to Ethernet and WIFI;
NET_LINK_ETH Ethernet;
NET_LINK_WIFI WIFI(Wireless Local Area
Network)
Return
NET_DOING
DHCP is doing the dynamic allocation.
RET_OK
Dynamic allocation has been done.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 189
ERR_NET_DHCP
_DISCOVER
DHCP Server has not been found.
ERR_NET_DHCP
_OFFER
DHCP cannot be assigned the IP address.
ERR_NET_DHCP
_START
DHCP does not start.
Instruction
20.3.9 OsNetStopDhcp
Prototype
void OsNetStopDhcp(int NetLink);
Function
Stops DHCP function.
Parameters
NetLink
Physical channel can only be set to Ethernet and WIFI;
NET_LINK_ETH Ethernet;
NET_LINK_WIFI WIFI(Wireless Local Area
Network)
Return
None
Instruction
1. After the DHCP function stops, the application needs to re-configure the
network using OsNetSetConfig ();
2. After DHCP, the system will regularly update the configuration
information, when the update fails, it will cause the network become
unusable.
20.3.10 OsNetSetRoute
Prototype
int OsNetSetRoute(int NetLink);
Function
Set system default route.
Parameters
NetLink
Physical channel, please refer to Physical channel list
Return
RET_OK
Success, the new route came into effect.
ERR_INVALID
_PARAM
ERR_NET_IF
Invalid parameter.
This link has not been set up.
Instruction
1. If only one link needs to set up, then it is not necessary to use this interface
to do the setup.
2. When there are several links have been set up, it is allowed to use this
function to switch the default router.
3. It is allowed to switch only when the default route has been set up,
otherwise return ERR_NET_IF.
4. If switch the router in the process of communication, it will cause a
communication failure.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 190
20.3.11 OsNetGetRoute
Prototype
int OsNetGetRoute(void);
Function
Reads the system default route.
Parameters
None
Return
>0
Physical channel, please refer to Physical
channel list .
ERR_NET_NO_ROUTE
There is no default route.
Instruction
This function will return ERR_NET_NO_ROUTE in following situations:
1. There is no link has been set up.
2. Any link that has been set up successfully will be configured as the
default route. When the last used link is being logged off, it will delete
this route. At this time, call OsNetSetRoute to reconfigure .
20.3.12 OsPppoeLogin
Prototype
int OsPppoeLogin(const char *Name,
const char *Password,
int TimeOutMs);
Function
PPPoE link Login.
Parameters
Name【Input】
User name;
Cannot exceed 50 bytes
Cannot be NULL, if there is no password, use an null string
― ‖;
Password【Input】
Password;
Cannot exceed 50 bytes
Cannot be NULL, if there is no password, use ― ‖;
TimeOutMs
Timeout,【unit:ms】
The valid range is 0~3600000;
Return
NET_DOING
Logging
RET_OK
Success
<0
Failed
Instruction
After the link has been set up successfully, this link will be set to be the default
route.
20.3.13 OsPppoeCheck
Prototype
int OsPppoeCheck(void);
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 191
Function
Checks the PPPoE link.
Parameters
None
Return
NET_DOING
Logging
RET_OK
The link has been successfully established.
<0
The link has been disconnected.
Instruction
20.3.14 OsPppoeLogout
Prototype
void OsPppoeLogout(void);
Function
Disconnects the PPPoE link.
Parameters
None
Return
None
Instruction
{ This page intentionally left blank }
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 193
21 GPRS/CDMA
Prolin provides supports for GPRS and CDMA, for the utility and configuration of these
wireless modules. It also provides a series of APIs for application developers to use.
21.1 Return code list
Table 21 GPRS/CDMA return code list
Macro
Value
Description
PPP_LOGINING
1
PPP is logging in.
PPP_LOGOUTING
2
PPP is logging out.
ERR_WL_POWER_ONING
-3501
Module is powered on, please
wait.
ERR_WL_POWER_OFF
-3502
Module is powered off.
ERR_WL_NOT_INIT
-3503
Has not called OsWlInit() to
initialize and cannot work
normally.
ERR_WL_NEEDPIN
-3504
SIM card needs PIN.
ERR_WL_RSPERR
-3505
Module response error.
ERR_WL_NORSP
-3506
Module has no response.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 194
ERR_WL_NEEDPUK
-3507
SIM card needs PUK.
ERR_WL_WRONG_PIN
-3508
PIN of SIM card error.
ERR_WL_NOSIM
-3509
SIM card not inserted
ERR_WL_NOREG
-3510
Cannot register on the GPRS
network.
ERR_WL_AUTO_RST
-3511
Module reset automatically.
ERR_WL_BUF
-3512
Module memory error.
ERR_WL_GET_SIGNAL
-3513
Getting the signal, please wait
for 3s.
ERR_WL_NOTYPE
-3514
Module cannot be recognized.
ERR_WL_PPP_ONLINE
-3515
PPP is on line, and it cannot be
sleeping.
ERR_WL_ERR_BUSY
-3516
Module is busy.
ERR_WL_SLEEP_ONING
-3517
Module is in sleeping.
ERR_WL_SLEEP_FAIL
-3518
Sleeping failed.
ERR_WL_SIM_FAILURE
-3519
SIM card Operation failed.
ERR_WL_NO_SIMSOCKET
-3520
The machine does not have a
SIM card slot.
ERR_WL_ONLY_ONE_SIMSOCKET
-3521
The machine only has one SIM
card slot.
ERR_WL_SIMSOCKET_CONFIGFILE
-3522
The ro.fac.simsocket in config
file is incorrectly set.
21.2 Wireless module interface
21.2.1 OsWlLock
Prototype
int OsWlLock(void);
Function
Opens the wireless module.
Parameters
None
Return
RET_OK
Open successfully.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 195
ERR_DEV_BUSY
Device is already in use.
ERR_DEV_NOT_
EXIST
ERR_BATTERY_
ABSENT
Device does not exist.
Battery is absent
Instruction
1. Before calling OsWlInit(), OsWlPowerSwitch(), OsWlLogin() or
OsWlLogout(), this function must be called to open the wireless module first.
2. OsWlUnLock() must be called to close wireless module when there is no
operation any more.
3. Noted that S920 and D200 mobile terminals need battery to work.
21.2.2 OsWlUnLock
Prototype
void OsWlUnLock(void);
Function
Close the wireless module.
Parameters
None
Return
None
Instruction
21.2.3 OsWlInit()
Prototype
int OsWlInit(const char *SimPin);
Function
Initializes wireless module.
Parameters
SimPin 【Input】
SIM card PIN,
The PIN length can't exceed 50 characters.
NULL means it does not need the PIN.
Return
RET_OK
Success
ERR_DEV_NOT_OPE
N
Fail to call WlOpen().
ERR_DEV_NOT_EXI
ST
Wireless module does not exist.
ERR_NO_PORT
Not enough physical ports.
ERR_WL_NEEDPIN
SIM card needs PIN.
ERR_WL_RSPERR
Response error.
ERR_WL_NORSP
Module does not respond
ERR_WL_NEEDPUK
SIM card needs PUK.
ERR_WL_WRONG_PI
N
PIN error.
ERR_WL_NOSIM
No SIM card.
ERR_WL_NOTYPE
ERR_WL_NOREG
Module cannot be recognized.
Registering GPRS network failed.
Instruction
1. Before using this function, make sure to call OsWlLock() successfully.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 196
2. This function needs to be called successfully at system startup time before
calling OsWlLogin() to establish the link.
3. SIM card will automatically check the password when the password is
required.
4. If the module does not power on, the system will automatically supply
power for it.
5. When ERR_WL_NOSIM is returned (No SIM card), the application can
use some functions that do not require SIM card.
6. After calling OsWlSwitchPower(), application should wait for at least 15
seconds until the module is stable, otherwise, calling OsWlInit() might
fail.
21.2.4 OsWlSwitchPower
Prototype
int OsWlSwitchPower(int OnOff);
Function
Powers on /off the wireless module.
Parameters
OnOff
0: Power off
1: Power on
Return
RET_OK
Success
ERR_DEV_NOT_EXIST
Wireless module does not exist.
ERR_DEV_NOT_OPEN
Fail to call OsWlLock().
Instruction
Reserved interface and it is not yet supported.
21.2.5 OsWlSwitchSleep
Prototype
int OsWlSwitchSleep(int OnOff);
Function
Makes the wireless module sleep or wake up.
Parameters
OnOff
0: Wake up
1: Sleep
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 197
Others: Errors.
Return
RET_OK
Success
ERR_DEV_NOT_EXIST
Module does not exist.
ERR_DEV_NOT_OPEN
Fail to call Os WlLock().
ERR_WL_PPP_ONLINE
PPP is on line.
Instruction
Reserved interface and it is not yet supported.
21.2.6 OsWlGetSignal
Prototype
int OsWlGetSignal(void);
Function
Gets the wireless signal strength.
Parameters
None
Return
0~5
Represents the signal strength, the higher the
number, the stronger the signal, 0 means no
signal and 5 represents the strongest signal.
ERR_DEV_NOT_EXIST
Module does not exist.
ERR_NO_PORT
Not enough physical uart.
ERR_WL_POWER_ONING
Module is power on.
Instruction
1. It doesn‘t need to call OsWLock() when use this function;
2. When the wireless link is not established, this API will get the signal
values from the module through AT commands;
3. OsWlGetSignal() can‘t obtain the current signal strength and returns
‗ERR_WL_RSPERR‘ after a wireless link established by calling
OsWlLogin(). In this time, module is in the data exchange mode, can‘t get
the real-time signal.
21.2.7 OsWlCheck
Prototype
int OsWlCheck(void);
Function
Checks the status of wireless link.
Parameters
None
Return
PPP_LOGOUTING
Link disconnecting.
PPP_LOGINING
Link establishing.
RET_OK
Link established successful.
ERR_DEV_NOT_EXIST
Module does not exist.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 198
ERR_WL_POWER_ONING
Module is powered on.
ERR_WL_POWER_OFF
Module is powered off.
ERR_WL_NOT_INIT
Initialization failed.
ERR_NET_PASSWD
Password is incorrect.
ERR_NET_LOGOUT
OsWlLogout() disconnect the link.
ERR_NET_IF
Link has been disconnected.
Instruction
21.2.8 OsWlLogin
Prototype
int OsWlLogin(const char *APN,
const char *Name,
const char *Password,
long Auth,
int TimeOutMs,
int KeepAlive,
int ReserParam);
Function
Log in on the wireless network and set up a wireless link.
Parameters
APN 【Input】
APN – Access Point Name for GPRS communication,
dialing number for CDMA.
Length <= 50 characters;
When pointer points to NULL, the application should
dial-up first and the protocol stacks directly log in on
PPP.
Name 【Input】
User name;
Length <= 50 bytes;
It cannot be NULL, if there is no user name, replace it
with an empty string ― ‖;
Password 【Input】
Password;
Length <= 50 characters;
It cannot be NULL, if there is no password, replace it
with an empty string ― ‖;
Auth
The supported authentication algorithms
PPP_ALG_PAP
0x00000001
PAP
authentication
algorithm
PPP_ALG_CHAP
0x0000000
CHAP
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 199
authentication
algorithm
PPP_ALG_MSCH
APV1
0x00000004
MSCHAPV1
authentication
algorithm
PPP_ALG_MSCH
APV2
0x00000008
MSCHAPV2
authentication
algorithm
PPP_ALG_ALL
0xff
All
algorithms
are supported
At least one type of authentication algorithm has to be
chosen; or choose more than one authentication
algorithm by using (+) or (|), for example,
PPP_ALG_PAP| PPP_ALG_CHAP. If the algorithm is
unknown, fill it with PPP_ALG_ALL.
TimeOutMs
Timeout,【unit:ms】;
The valid range is 0~3600000; if it is <0, automatically
set it to 0, if more than 360000, automatically set it to
3600000.
KeepAlive
Interval for link check, unit is ms;
The valid range is 10000~3600000;
If the link is longer than KeepAlive time but without
any messages; the system automatically starts the link
check interval;
ReserParam
Reserved parameter, used for extension.
Return
PPP_LOGINING
In process
PPP_LOGOUTING
The wireless module is logging out.
RET_OK
Set up link successfully.
ERR_DEV_NOT_E
XIST
Wireless module does not exist.
ERR_DEV_NOT_O
PEN
Performing OsWlLock() failed
ERR_INVALID_PA
RAM
Invalid parameter.
ERR_WL_POWER
_ONING
Module is powered on.
ERR_WL_POWER
_OFF
Module is powered off.
ERR_WL_NOT_IN
IT
Initialization failed.
ERR_NET_PASSW
D
Password is incorrect.
ERR_NET_SERVE
R_BUSY
Server is busy, communication failure.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 200
ERR_NET_AUTH
Has no authority to access to the RADIUS server.
Instruction
1. Before using this function, make sure to call OsWlLock() successfully.
2. When Timeouts=0,it means return immediately;
3. Calling OsWlCheck() to check the link status;
4. For different modules and different network environments, the login time
will be different; if within 60 seconds the login did not complete, it means
login failure or the module has an exception error.
5. Unsuccessful login for three consecutive times, it indicates the module has
no response, the application must call OsWlSwitchPower() to reset the
module.
6. After setting up the link successfully, the link will be set to be the default
route and communication can be done through the IP network
communication function.
7. When the return vaule is PPP_LOGOUTING, need to call OsWlCheck()
function to check whether it has finished logout, and OsWlCheck() returns
ERR_NET_LOGOUT means completing logout.
21.2.9 OsWlLoginEx
Prototype
int OsWlLoginEx(const char *DialNum,
const char *APN,
const char *Name,
const char *Password,
long Auth,
int TimeOutMs,
int KeepAlive,
int ReserParam);
Function
Log in on the wireless network and set up a wireless link.(it supports modifying
the dialing instructions)
Parameters
DialNum 【Input】
The PPP dialing instruction.
Length <= 50 characters;
When it is NULL, it adopts the default instruction of
system.
ANP 【Input】
APN – Access Point Name for GPRS communication,
dialing number for CDMA.
Length <= 50 characters;
It cannot be NULL.
Name 【Input】
User name;
Length <= 50 bytes;
It cannot be NULL, if there is no user name, replace it
with an empty string ― ‖;
Password 【Input】
Password;
Length <= 50 characters;
It cannot be NULL, if there is no password, replace it
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 201
with an empty string ― ‖;
Auth
The supported authentication algorithms:
PPP_ALG_PAP
0x00000001
PAP
authentication
algorithm
PPP_ALG_CHAP
0x0000002
CHAP
authentication
algorithm
PPP_ALG_MSCH
APV1
0x00000004
MSCHAPV1
authentication
algorithm
PPP_ALG_MSCH
APV2
0x00000008
MSCHAPV2
authentication
algorithm
PPP_ALG_ALL
0xff
All
algorithms
are supported
At least one type of authentication algorithm has to be
chosen; or choose more than one authentication
algorithms by using (+) or (|), for example,
PPP_ALG_PAP| PPP_ALG_CHAP. If the algorithm is
unknown, fill it with PPP_ALG_ALL.
TimeOutMs
Timeout,【unit:ms】;
The valid range is 0~3600000; if it is <0, automatically
set it to 0, if more than 360000, automatically set it to
3600000.
KeepAlive
Interval for link check, unit is ms;
The valid range is 10000~3600000;
If the link is longer than KeepAlive time but without
receiving any messages; the system automatically starts
the link check interval;
(This functionality does not work now, originally it was
designed for CDMA to prevent it forming going to
sleep.)
ReserParam
Reserved parameter, used for extension.
Return
PPP_LOGINING
In process
RET_OK
Set up link successfully.
ERR_DEV_NOT_E
XIST
Wireless module does not exist.
ERR_DEV_NOT_O
PEN
Performing OsWlLock() failed.
ERR_INVALID_PA
RAM
Invalid parameter.
ERR_WL_POWER
_ONING
Module is powered on.
ERR_WL_POWER
Module is powered off.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 202
_OFF
ERR_WL_NOT_IN
IT
Initialization failed.
ERR_NET_PASSW
D
Password is incorrect.
ERR_NET_SERVE
R_BUSY
Server is busy, communication failure.
Instruction
1. This function is similar to OsWlLogin(), when DialNum is NULL, the two
functions have the same functionality.
2. Before using this function, make sure to call OsWlLock() successfully.
3. When TimeOutMs=0,it means return immediately;
4. Calling OsWlCheck() to check the link status;
5. For different modules and different network environments, the login time
will be different; if the login did not complete in 60 seconds, it means
login failure or the module has an exception error.
6. Unsuccessful login for three consecutive times, it indicates the module has
no response, the application must call OsWlSwitchPower() to reset the
module.
7. After the link has been set up successfully, the link will be set to be the
default route and communication can be done through the IP network
communication function.
21.2.10 OsWlLogout
Prototype
int OsWlLogout(void);
Function
Exits the wireless network and disconnects the wireless link.
Parameters
None
PPP_LOGOUTING
The link is being disconnected
ERR_DEV_NOT_OPEN
Fail to call OsWlLock().
Instruction
1. Before using this function, make sure to call OsWlLock() successfully.
2. After calling this function, OsWlCheck() should be called to check the status
of the logout. Only when ERR_NET_LOGOUT is returned does that mean
disconnecting the link successfully.
21.3 Wireless module information settings
21.3.1 OsWlSelSim
Prototype
int OsWlSelSim(int simno);
Function
Selects SIM card.
Parameters
simno 【Input】
0: Selecting card slot 1
1: Selecting card slot 2
Others: Parameter error
Return
RET_OK
Success
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 203
ERR_DEV_NOT_EXIST
Module does not exist.
ERR_DEV_NOT_OPEN
Fail to call OsWlLock().
ERR_WL_ERR_BUSY
Module is busy.
Other non-zero value
Refer to the Return code list.
Instruction
1. Before using this function, make sure to call OsWlLock() successfully.
2. After selecting SIM card, the module will be powered on/off, and this
function blocks about 15 seconds. Application needs to re-call OsWilInit()
to initialize the module.
3. If users select a card slot with bad cards or without any cards, the function
will also return successfully. And it can detect the problems while logging
in.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 204
22 WIFI
Prolin WIFI supports two modes: STATION and IBSS(ad-hoc).
1) STATION mode refers to the communication between the wireless modems. IBSS
mode is referred to the direct communication between several devices. It can be used in
the following situations. Assume that there is an ad-hoc device named ‗A‘ in the network,
device ‗B‘ tries to connect to device ‗A‘. If the connection is successful, ‗A‘ and ‗B‘ can
ping successfully with each other; if not, device ‗B‘ will create an ad-hoc network by
itself;
2) In the network without an ad-hoc device, device ‗B‘ will create an ad-hoc network by
itself.
3) At present, Prolin WIFI only supports module with keyword ro.fac.wifi is
―RS9110-N-11-02‖ or ―01‖.
22.1 Return Code List
Table 22 Return Code List
Macro
Value
Description
ERR_WIFI_POWER_OFF
-3351
Module is powered off.
ERR_NOT_FOUND_AP
-3352
Has not found AP.
ERR_AUTH_SEC_MODE
-3353
Authentication mode or encryption
mode error.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 205
ERR_WIFI_BAD_SIGNAL
-3354
WIFI signal is bad.
RET_CONNECTING
1
Connecting
22.2 Encryption type List
Table 23 Encryption type List
Macro
Value
Description
PARE_CIPHERS_NONE
0x00000000
No encryption
PARE_CIPHERS_WEP64
0x00000001
Means 40 bit key with concatenated
24 bit initialization vector
PARE_CIPHERS_WEP128
0x00000002
Means 104 bit key with 24 bit
initialization vector
PARE_CIPHERS_WEPX
0x00000004
Unknown WEP key bits
PARE_CIPHERS_CCMP
0x00000010
AES in Counter mode with
CBC-MAC
PARE_CIPHERS_TKIP
0x00000020
Temporal Key Integrity Protocol
22.3 Data Structure
Authentication Modes:
enum WIFI_AUTH_MODE{
AUTH_NONE_OPEN=1,
AUTH_NONE_WEP,
AUTH_NONE_WEP_SHARED, /* The mode will be scanned as
AUTH_NONE_WEP */
AUTH_IEEE8021X,
AUTH_WPA_PSK,
AUTH_WPA_EAP,
AUTH_WPA_WPA2_PSK,
AUTH_WPA_WPA2_EAP,
AUTH_WPA2_PSK,
AUTH_WPA2_EAP
};
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 206
Extension for WEP64 and WEP128:
typedef struct _WepSecKey{
char Key[4][40]; /* WEP key data */
int KeyLen; /* WEP key data length */
int Idx; /* WEP key index [0..3] of actually used key */
} WEP_SEC_KEY;
Extension for WPA/WPA2-PSK:
typedef struct _WpaPskKey{
char Key[64]; /* PSK-Key data */
int KeyLen; /* PSK-Key data length */
} WPA_PSK_KEY;
Extension for EAP:
typedef struct _WpaEapKey{
int EapType; /* EAP type */
char Pwd[132]; /* Password */
char Id[132]; /* Identity */
char CaCert[132]; /* Path and filename of CA certificate */
char CliCert[132]; /* Path and filename of client certificate */
char PriKey[132]; /* File path to client private key file */
char PriKeyPwd[132]; /* Password for private key file */
} WPA_EAP_KEY;
Scan the AP information:
typedef struct _WifiApInfo
{
char Essid[33]; /* AP name */
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 207
char Bssid[20]; /* MAC address */
int Channel; /* Channel */
int Mode; /* Connection mode, 0:Station; 1:IBSS */
int Rssi; /* Signal value, The value range is [-99,0] */
int AuthMode; /* Authentication mode*/
int SecMode; /* Encryption mode, NONE,WEP,TKIP,CCMP */
}ST_WifiApInfo;
Connect to AP settings:
typedef struct _WifiApSet
{
char Essid[33]; /* AP name, it can support 32 bytes at most, ending
with ’\0’*/
char Bssid[20]; /* MAC address, ending with ’\0’, if there is no any APs
with the same ESSID, Bssid can be ”\0”*/
int Channel; /* Channel, only valid in IBSS mode, 0:Auto set */
int Mode; /* Connection mode, 0:Station; 1:IBSS */
int AuthMode; /* Authentication mode */
int SecMode; /*Encryption mode, NONE,WEP,TKIP,CCMP*/
union KEY_UNION{ /* Key */
WEP_SEC_KEY WepKey; /* For wep */
WPA_PSK_KEY PskKey; /* For wpa,wpa2-psk authentication */
WPA_EAP_KEY EapKey; /* For wpa,wpa2-eap*/
} KeyUnion;
}ST_WifiApSet;
22.4 OsWifiOpen
Prototype
int OsWifiOpen(void);
Function
Get access to the WIFI module.
Parameters
None
Return
RET_OK
Success
ERR_DEV_NOT_
EXIST
Driver loading exception or module error.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 208
ERR_DEV_BUSY
WIFI is already in use.
ERR_BATTERY_
ABSENT
Battery does not exist.
Instruction
For D200 and S920 POS models, the battery must be installed in order to operate
the Wifi, otherwise ERR_BATTERY_ABSENT will be returned.
22.5 OsWifiClose
Prototype
void OsWifiClose (void);
Function
Release the WIFI module.
Parameters
None
Return
None
Instruction
22.6 OsWifiSwitchPower
Prototype
int OsWifiSwitchPower (int Type);
Function
Sets WIFI module into the state of power-on and power-off.
Parameters
Type
1: Set module hardware into the state of power-on
0: Set module hardware into the state of power-off
Return
RET_OK
Success
ERR_INVALID_P
ARAM
Invalid parameter
ERR_DEV_NOT_
EXIST
Driver loading exception or module error.
ERR_DEV_NOT_
OPEN
Fail to access to the WIFI device.
Instruction
The module will automatically power on after the boot, it doesn‘t need to call this
function.
Reserved interface and it is not yet supported.
22.7 OsWifiScan
Prototype
int OsWifiScan (ST_WifiApInfo **Aps);
Function
Search for APs.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 209
Parameters
Aps 【Output】
The searched AP information
Return
>=0
The number of searched APs
ERR_MEM_FAU
LT
Memory error
ERR_INVALID_P
ARAM
Invalid parameter
ERR_WIFI_POW
ER_OFF
WIFI module is powered off.
ERR_DEV_NOT_
OPEN
Fail to access to the WIFI device.
Instruction
/*For example:*/
int i, num;
ST_WifiApInfo * Aps;
num = OsWifiScan (&Aps);
if(num <= 0)
return -1;
for(i=0; i<num; i++)
printf("[%d] AP name: %s\n", i, Aps[i].Essid);
22.8 OsWifiConnect
Prototype
int OsWifiConnect(const ST_WifiApSet *Ap,
int TimeOutMs);
Function
Connects to AP.
Parameters
Ap 【Input】
The required connected AP information.
TimeOutMs 【Input】
The timeout,【unit:ms】
The valid value range is 0~3600000.
Return
RET_OK
Success
RET_CONNECTING
Connecting
ERR_NOT_CONNECT
Connection failed.
ERR_WIFI_BAD_SIGN
AL
WIFI signal is bad.
ERR_NOT_FOUND_AP
The AP can‘t be found.
ERR_ NET_PASSWD
Password error
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 210
ERR_AUTH_SEC_MOD
E
Authentication mode or encryption mode error
ERR_WIFI_POWER_OF
F
WIFI module is powered off.
ERR_DEV_NOT_OPEN
Fail to access to the WIFI device.
ERR_INVALID_PARA
M
Invalid parameter
Instruction
1. When the return value is RET_CONNECTING, users can call
OsWifiCheck() to check the connection state.
2. After a successful connection, it needs to call OsNetStartDhcp() to get IP, or
call OsNetSetConfig() to set the static IP.
3. In IBSS mode, when the connection time exceed 90 seconds, then it will
return ERR_NOT_CONNECT, but in the Station mode, it will
return a specific error code while the connection fails.
4. RET_CONNECTING will be returned if there is no connection to the
network in IBSS mode, at the same time, the network will be created
according to the connection parameter, RET-OK will be returned
when detected there is a terminal joining the network, if
no terminal is detected, and the time exceed 90 seconds, the network will be
aborted and returns ERR_NOT_CONNECT;
5. In IBSS mode, to determine whether the connection is successful, the first
step is to make sure it returns RET_OK, and then sets the IP, the
connection should only be considered successful if the IP can ping the peer
IP.
22.9 OsWifiDisconnect
Prototype
int OsWifiDisconnect(void);
Function
Disconnect AP connection.
Parameters
None
Return
RET_OK
Success
ERR_DEV_NOT_OPEN
Fail to access to the WIFI device.
Instruction
22.10 OsWifiCheck
Prototype
int OsWifiCheck(char *Essid,
char *Bssid,
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 211
int *Rssi);
Function
Gets the current status of WIFI. If the connection is successful, it can get the
ESSID, BSSID and signal strength of AP through the parameters.
Parameters
Essid 【Output】
It can‘t be NULL, and the size is 33byte.
Bssid 【Output】
The size is 20-byte, and it also can be NULL.
Rssi 【Output】
Signal strength. It can‘t be NULL, the value range is
【-99, 0】, 0 represents the strongest strength.
Return
RET_OK
Connection successful
RET_CONNECTIN
G
Connecting
ERR_NOT_CONN
ECT
No connection to the network
ERR_WIFI_BAD_S
IGNAL
WIFI signal is bad.
ERR_NOT_FOUN
D_AP
Has not fount AP
ERR_NET_PASSW
D
Password error
ERR_AUTH_SEC_
MODE
Authentication mode or encryption mode error
ERR_INVALID_PA
RAM
Invalid parameter.
Instruction
1. It does not need to call OsWifiOpen() before calling this interface.
2. It returns ERR_NOT_ CONNECT only in the following cases:
a) OsWifiConnect() has not been invoked by any application,
b) The connection time exceeds 90 seconds in IBSS mode,
c) OsWifiDisconnect() has been invoked by an application and
returns RET_OK.
3. If the connection fails in Station mode, it returns values other than
ERR_NOT_ CONNECT.
22.11 OsWifiCmd
Prototype
int OsWifiCmd (const char *Argv[],
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 212
int Argc,
char *Result,
int Len);
Function
Send commands to the WPA_Supplicant back-end service, and then obtain the
return results.
Parameters
Argv 【Input】
Commands supported by WPA_Supplicant, it can‘t be
NULL.
Argc 【Input】
t Argv two-dimensional array that used to store the number
of commands or parameters
Result 【Output】
Return result of WPA_Supplicant, it can‘t be NULL, and
the size must be at least 2048 bytes.
Len 【Input】
Length of Result array
Return
RET_OK
Sent successfully
ERR_INVALID_P
ARAM
Invalid parameter.
ERR_WIFI_POW
ER_OFF
WIFI module is power off.
ERR_DEV_NOT_
OPEN
Fail to access to the WIFI device.
Instruction
1. Argv represents all the commands and parameters that supported by
WPA_Supplicant, such as ‗SCAN‘ command.
2. If Argv only has one command, Argc=1.
3. It's worth noting that this function is invoked only when other WIFI APIs
cannot meet requirements.
4. Result is the original return value of WPA_Supplicant.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 213
23 File System
To access the file system, use the standard ANSI.C to operate API. For more details about
real-time operation, please refer to<stdio.h>. It is allowed to
use the standard POSIX interface to get the access.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 214
24 System Information
In Prolin, the system messages generated by the hardware device are implemented by
asynchronous notification. The system provides two kinds of hardware system messages,
magnetic cards and IC cards.
SIGMAG
SIGICC
The SIGMAG is only valid when the magnetic stripe reader device is open.
The code of registered asynchronous notification function is shown as follows:
EXAMPLE
#include <stdio.h>
#include <stdlib.h>
#include <signal.h>
#include <pthread.h>
#include <osal.h>
#include <cutils/log.h>
#define printf(...) LOGI(__VA_ARGS__)
static sigset_t mask;
void * handler_sigwait(void * arg)
{
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 215
int ret, signo;
while(1){
ret = sigwait(&mask, &signo);
if(ret != 0){
printf("sigwait err, ret=%d\n", ret);
break;
}
switch(signo){
case SIGMAG:
printf("Capture msr signal\n");
break;
case SIGICC:
printf("Capture icc signal\n");
break;
default:
printf("Capture other signal %d\n", signo);
break;
}
}
}
int main()
{
int ret;
sigset_t oldmask;
pthread_t tid;
ret = OsMsrOpen();
if (ret < 0)
exit(-1);
ret = OsIccOpen(ICC_USER_SLOT);
if (ret < 0){
OsMsrClose();
return -1;
}
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 216
sigemptyset(&mask);
sigaddset(&mask, SIGMAG);
sigaddset(&mask, SIGICC);
ret = pthread_sigmask(SIG_SETMASK, &mask, &oldmask);
if(ret != 0){
printf("pthread_sigmask error, ret=%d\n", ret);
exit(-1);
}
ret = pthread_create(&tid, NULL, handler_sigwait, 0);
if(ret != 0){
printf("pthread_create error, ret=%d\n", ret);
exit(-1);
}
pthread_join(tid, NULL);
OsMsrClose();
OsIccClose(ICC_USER_SLOT);
}
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 217
25 Audio
The speaker volume of Prolin is divided into five levels, ranging from 0 to 4,
0 means mute. In general, the volume setting is unified, and it can set in the TM interface.
25.1 OsPlayWave
Prototype
int OsPlayWave(const char *Buf,
int Len,
int Volume,
int DurationMs);
Function
Play WAV audio files.
Parameters
Buf 【Input】
The audio data buffer.
Len 【Input】
Length of the data buffer.
Volume 【Input】
Volume, the values range from 0 to 4.
0 represents playing in mute.
DurationMs【Input】
Play duration【Unit:ms】
Return
RET_OK
Success
ERR_FILE_FORMAT
File format error
ERR_ACCESS_DENY
Access denied
ERR_INVALID_PARAM
Invalid parameter
Instruction
1. The Volume value ranges from 0 to 4, when Volume<0, set it as the
system volume, that is the value of persist.sys.sound.volume, it can be set
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 218
in tm; when Volume>4, set is as 4.
2. If the DurationMs is more than the Len play time, it will play on a
continuous loop of the file. On the contrary, DurationMs shall prevail.
When DurationMs=0, the actual length of the audio data shall prevail.
3. Support WAVE audio file with single track or double track; Support 8-bit
sampling , 16 bit sampling. The supported sample frequencies are 8000
Hz,11025 Hz,6000 Hz,22050 Hz,24000 Hz,32000 Hz,44100 Hz
and 48000 Hz.
For example, FILENAME is the name of the audio file.
EXAMPLE
int fd, ret = 0;
char *buff;
int len;
struct stat state;
stat(FILENAME, &state);
len = state.st_size;
buff = (char *) malloc(len * sizeof(char));
fd = open(FILENAME, O_RDONLY);
if(fd<0)
printf("Open File Fail\n");
ret = read(fd, buff, len);
ret = OsPlayWave(buff, len, 3, 0);
if(ret != RET_OK)
printf("PlayWave Fail\n");
close(fd);
free(buff);
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 219
26 Barcode
26.1 General Definiton
Prolin barcode supports one-dimensional and two-dimensional barcode. One-dimensional
code is composed of vertical black and white bars with letters or digits at the bottom of the
bars, and the thickness of black and white is different. It used to identify the basic information
of products, such as name, price, etc.
Two-dimensional code is a dot matrix form with a rectangular structure. It has some polygon
images inside the code, and texture is black and white with different thickness.
Two-dimensional code could represent more detailed content in addition to the identification
function.
The usage of barcode is as follow: Firstly, OsScanOpen() is called to open the barcode
module; Then, OsScanRead() is called and the light beam will be emitted from barcode
scanning head, and the barcode scanning head align the code image to get the code
information; Lastly, OsScanClose() is called to close the barcode module.
26.2 OsScanOpen
Property
int OsScanOpen (void);
Function
Open the barcode scanning module.
Parameter
None
Return
RET_OK
Success
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 220
ERR_DEV_BUSY
Device has been occupied.
ERR_DEV_NOT_OPEN
Device is not open.
ERR_DEV_NOT_EXIST
Device does not exist.
Instruction
26.3 OsScanRead
Property
int OsScanRead(char *Buf,
int Len,
int TimeoutMs);
Function
Read the barcode.
Parameter
Buf 【Output】
The buffer is used to store the barcode data.
One-dimensional code recommends being more than
512 bytes, and two-dimensional code suggests being
3072 bytes.
Len 【Input】
Buffer length
TimeoutMs 【Input】
Timeout of reading barcode,【unit:ms】
The valid range is 1500~36000, if it is less than 1500,
set is to 1500, and if it is greater than 36000, set it to
36000. The margin of error between the actual timeout
value and the setting value may be less than 1s, it is
recommended to set the timeout value to 3000ms.
Return
>=0
The actual length of the read barcode data.
ERR_DEV_NOT_O
PEN
Device is not open.
ERR_TIME_OUT
Timeout.
ERR_INVALID_PA
RAM
Invalid parameter
Instruction
26.4 OsScanClose
Property
void OsScanClose (void);
Function
Close the scanning device.
Parameter
None
Return
None
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 221
27 Power Management
27.1 OsCheckBattery
Prototype
int OsCheckBattery(void);
Function
Checks the battery.
Parameters
None
Return
BATTERY_LEVEL_0
It needs immediately charge the battery. At this
point, it should not do the transaction, wireless
communications and printing.
When the battery capacity is low, the system will
automatically turn off.
0~5%battery
BATTERY_LEVEL_1
5%~15% battery
BATTERY_LEVEL_2
15%~40%battery
BATTERY_LEVEL_3
40%~70%battery
BATTERY_LEVEL_4
70%~100%battery
BATTERY_LEVEL_CHA
RGE
Battery is being charged.
BATTERY_LEVEL_COM
PLETE
Battery is fully charged, external power supplies
the electricity.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 222
BATTERY_LEVEL_ABS
ENT
Battery does not exist. It needs external power
supplies electricity.
ERR_SYS_NOT_SUPPOR
T
System does not support checking the battery.
S800/S300 returns this value.
Instruction
1. When using an electric power supply, it can detect whether the battery is full
charged or not, but the battery level only can be detected when the batter is
in use.
2. It is not recommended to call this function during printing, because the
printer requires high current in the printing procedure, otherwise, it will
make the interface obtain an inaccurate charge.
3. When RF searching the card, or wireless module attaching to the network, it
needs a higher power, then please note that the battery may fluctuate during
the above processes.
4. When the battery level is BATTERY_LEVEL_0, wireless module, printer,
RF module are probably can not continue to function normally, the battery
needs to be charged.
27.2 OsCheckPowerSupply
Prototype
int OsCheckPowerSupply (void);
Function
Check the power supply type.
Parameters
None
Return
POWER_BATTERY
Powered by the battery.
POWER_ADAPTER
Powered by the adapter.
POWER_USB
Powered by the USB, such as PC.
Instruction
27.3 OsSysSleep
Prototype
int OsSysSleep(void);
Function
Make the system enter the sleep mode to save power.
Parameters
None
Return
RET_OK
Success
ERR_SYS_NOT_SUPPORT
System does not support this function.
Instruction
The system will enter sleep mode by calling this function, otherwise, it never
sleep.
In sleep mode, CPU stops running and the screen is black; Terminal could be
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 223
awakened up by pressing key, the contents displayed in the screen are the same
as before calling this function. System continues running at the breakpoint which
was made before sleep. It is not recommended to hibernate during using RF card,
if so, after wake up, it must call OsPiccClose() firstly, and then call
OsPiccOpen() and other cards operations.
27.4 OsSysSleepEx
Prototype
int OsSysSleepEx(int Level);
Function
Make the POS terminal enter different levels of sleep mode, and
reduce the power consumption.
Parameters
Level
【Input】
Sleep level, value range is [0, 2].
0: System runs normally;
1: Screen save mode.
CPU works well, specific performance in turning
the LCD, key backlight, touch key, touch
screen off. You also can wake up them by
plastic button.
2: System hibernation.
CPU stops working, modules can only
be awakened by plastic button.
Return
RET_OK
Success
ERR_INVALID
_PARAM
Invalid parameter
ERR_SYS_NO
T_SUPPORT
System hibernation is not Supported.
Instruction
1. When Level=2, it is equivalent to calling the OsSysSleep();
2. The opened handle will not be closed in any sleep level.
3. The current working state of cards and communication modules
will not be changed in level 0 and level 1. In level 2, the modules
other than plastic button will be closed.
4. Under normal operation, it will enter the screen save mode if there
is no input event within the default interval of one minute. The
interval can be set by persist.sys.backlighttime(unit: minute), when
persist.sys.backlighttime = 0, it means turn off the screensaver.
27.5 OsReboot
Prototype
int OsReboot(void);
Function
Reboot the machine.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 224
Parameters
None
Return
ERR_SYS_BAD
System error
RET_OK
Success
Instruction
27.6 OsPowerOff
Prototype
int OsPowerOff (void);
Function
Turn off the power.
Parameters
None
Return
ERR_SYS_BAD
System error
RET_OK
Success
Instruction
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 225
Appendix 1 PIN Block Format
Format 0 PIN block
This PIN block is constructed by modulo-2 addition of two 64-bit fields: the plain text PIN
field and the account number field. The formats of these fields are described in 1.1.1 and 1.1.2
respectively.
The format 0 PIN block shall be reversibly enciphered when transmitted.
Plain text PIN field
The plain text PIN field shall be formatted as follows.
Bit
1 5 9 13 17 21 25 29 33 37 41 45 49 53 57 61 64
C
N
P
P
P
P
P
P/F
P/F
P/F
P/F
P/F
P/F
P/F
F
F
where
C = Control field: shall be binary 0000;
N = PIN length: 4-bit binary number with permissible values of 0100(4) to 1100(12);
P = Pin digit: 4-bit field with permissible values of 0000(zero) to 1001(9);
P/F = PIN/Fill digit: designation of these fields is determined by the PIN length field;
F = Fill digit: 4-bit field value 1111(15).
Account number field
The account number field shall be formatted as follows.
Bit
1 5 9 13 17 21 25 29 33 37 41 45 49 53 57 61 64
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 226
0
0
0
0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
where
0 = Pad digit: a 4-big field with the only permissible value of 0000(zero);
A1…A12 = Account number: content is the 12 rightmost digits of the primary account
number (PAN) excluding the check digit. A12 is the digit immediately preceding the PAN‘s
check digit. If the PAN excluding the check digit is less than 12 digits, the digits are right
justified and padded to the left with zeros. Permissible values are 0000 (zero) to 1001 (9).
Format 1 PIN block
This PIN block is constructed by concatenation of two fields: the plain text PIN field and the
transaction field.
The format 1 PIN block should be used in situations where the PAN is not available.
The format 1 PIN block shall be reversibly enciphered when transmitted.
The format 1 PIN block shall be formatted as follows.
Bit
1 5 9 13 17 21 25 29 33 37 41 45 49 53 57 61 64
C
N
P
P
P
P
P/T
P/T
P/T
P/T
P/T
P/T
P/T
P/T
T
T
where
C = Control field: shall be binary 0001;
N = PIN length: 4-bit binary number with permissible values 0100(4) to 1100 (12);
P = PIN digit: 4-bitfield with permissible values 0000 (zero) to 1001 (9);
P/T = PIN/Transaction digit: designation of these fields is determined by the PIN length field;
T = Transaction digit: 4-bit binary number with permissible values of 0000 (zero) to 1111
(15).
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 227
The transaction field is a binary number formed by [56-(N*4)] bits. This binary shall be
unique (except by chance) for every occurrence of the PIN block and can, for example, be
derived from a transaction sequence number, time stamp, random number or similar.
The transaction field should not be transmitted and is not required in order to translate the PIN
block to another format since the PIN length is known.
Format 2 PIN block
The format 2 PIN block has been specified for local use with IC cards. The format 2 PIN
block shall only be used in an offline environment and shall not be used for online PIN
verification.
Format 3 PIN block
Format 3 PIN block construction
The format 3 PIN block is the same as format 0 PIN block except for the fill digits.
This PIN block is constructed by modulo-2 addition of two 64-bit fields: the plain text PIN
field and the account number field. The formats of these fields are described in 1.4.2 and 1.4.3
respectively.
Plain text PIN field
The plain text PIN field shall be formatted as follows.
Bit
1 5 9 13 17 21 25 29 33 37 41 45 49 53 57 61 64
C
N
P
P
P
P
P/F
P/F
P/F
P/F
P/F
P/F
P/F
P/F
F
F
where
C = Control field: shall be binary 0011;
N = PIN number: 4-bit binary number with permissible values of 0100 (4) to 1100 (12);
P = PIN digit: 4-bit field with permissible values of 0000 (zero) to 1001 (9);
P/F = PIN/Fill digit: designation of these fields is determined by the PIN length field;
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 228
F = Fill digit: 4-bit field, with values from 1010(10) to 1111(15), where the
Fill-digit values are randomly or sequentially selected from this set of six possible values,
such that it is highly unlikely that the identical configuration of fill digits will be used more
than once with the same account number field by the same PIN encipherment device.
Account number field
The account number field shall be formatted as follows.
Bit
1 5 9 13 17 21 25 29 33 37 41 45 49 53 57 61 64
0
0
0
0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
For more details related to PIN Block format please refer to ISO 9564-1:2002(E).
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 229
Appendix 2 EPS PINBLOCK Format
String format: ―1234‖+ISN [6 byte] +PIN [Byte bit];
If the PIN is less than 6 bytes, add ‗0‘ before PIN;
The data string will be converted to BCD code, Using TPK to process DES/TDES encryption
for BCD code.
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 230
Appendix 3 Registry Table
The names begin with "ro.fac." can be read-only, for "persist.sys.", it can be both write and
read.
System configuration
name
Note
ro.fac.ubootver
Uboot version information
ro.fac.hwver
Hardware version number. Main board- Interface board.
ro.fac.mach
Product type name.
ro.fac.boardid
The information about the product ‘boardid’includes the
product model type and hardware version number ect.
ro.fac.conf.ver
Version information of configuration files.
ro.fac.pn
PN number
ro.fac.sn
SN number
ro.fac.prolin_debug_level
The current system Prolin debug_level information. Values of
release version system and debug version system are 0 and 1
respectively.
ro.fac.eth
Whether there is network cable.(0- does not exist, 1- exist)
ro.fac.usb.host
Whether there is the main device interface.(0- does not exist, 1-
exist)
ro.fac.usb.device
Whether there is an USB device interface.(0- does not exist, 1-
exist)
ro.fac.usb.otg
Whether there is an USB OTG interface.(0- does not exist, 1-
exist)
ro.fac.leddt
Whether there is LED digital tube.(0- does not exist, 1- exist)
ro.fac.keybroad
Key types.(0- have no keys, 1- indicates the presence of
physical buttons, 2- indicates the presence of a touch-screen
buttons)
ro.fac.buzzer
Whether there is a Buzzer module.(0- does not exist, 1- exist)
ro.fac.simsocket
The number of SIM card slot.
ro.fac.battery
Whether there is a battery.(0- does not exist, 1- exist)
ro.fac.wifi
Name of WIFI module.(If none, it means does not exist by
default)
ro.fac.bt
Name of Bluetooth module. (If none, it means does not exist by
default)
ro.fac.radio
Wireless module information, and the parameter information is
optional. It needs to isolate when there are multiple wireless
modules. (If none, it means does not exist by default)
ro.fac.modem
Name of Modem module. (If none, it means does not exist by
default)
ro.fac.printer
Name of Printer module. (If none, it means does not exist by
default)
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 231
ro.fac.pcd
Name of PCD module. (If none, it means does not exist by
default)
ro.fac.sci
Name of ICC Reader. (If none, it means does not exist by
default)
ro.fac.msr
Name of MSR Reader. (If none, it means does not exist by
default)
ro.fac.videocard
Name of video card module. (If none, it means does not exist
by default)
ro.fac.audiocard
Name of audio card module. (If none, it means does not exist
by default)
ro.fac.touchscreen
Name of Touch-screen module. (If none, it means does not
exist by default)
ro.fac.sdhc
The specification, capacity range and speed level supported by
SD card. (If none, it means does not exist by default)
ro.fac.scanner
Name of Scanner module. (If none, it means does not exist by
default)
ro.fac.pcd.param1
PCD antenna parameter 1. (If none, it needn't to fill in.)
ro.fac.pcd.param2
PCD antenna parameter 2. (If none, it needn't to fill in.)
ro.fac.pcd.param3
PCD antenna parameter 3. (If none, it needn't to fill in.)
ro.fac.lcd.rotate
The LCD clockwise rotation degrees. ("0","90","180","270")
persist.sys.eth0.enable
Supported Ethernet or not. ("true" or " "- support, "false"- does
not support)
persist.sys.eth0.dhcp
DHCP is open or not. ("true" - opened, "false" or " "- closed)
persist.sys.eth0.ip
Ethernet ip address
persist.sys.eth0.mask
Ethernet subnet mask
persist.sys.eth0.gateway
Ethernet gateway
persist.sys.dns1
System Preferred DNS
persist.sys.dns2
System alternative DNS
persist.sys.eth0.speed
network port speed.("eth_auto" represents automatic
configuration, "eth_10mhd" represents 10M half-duplex,
"eth_10mfd" represents 10M full-duplex, "eth_100mhd"
represents 100M half-duplex, "eth_100mfd" represents 100M
full-duplex)
persist.sys.prolin
Prolin system version information
persist.sys.language
System language
persist.sys.backlighttime
LCD backlight waits ‘backlighttime’ minutes, then it will
automatically turn off (value ranges from 0 to 32767, 0 means
LCD backlight is turned on)
persist.sys.key.backlight
Whether the button backlight is open or not (0 means close, 1
means open)
persist.sys.lcd.brightness
LCD brightness (value ranges from 1 to 10, the higher, the
brighter)
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 232
persist.sys.sound.enable
Whether the beep is open or not(false means close, true means
open)
persist.sys.sound.volume
Beep sound volume (value ranges from 1 to 99)
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 233
Appendix 4 Validity of models and contents
According to the differences of the hardware design, some OSAL interfaces cannot take into
effect on a certain model. For more, refer to the table below.
Chapters
S300
S800
S920
D200
Thread
√
√
√
√
System
Function
√
√
√
√
Encryption and
Decryption
√
√
√
√
PED
√
√
√
√
LCD
240*320, rotate
90°in clockwise
direction
320*240, rotate
90 °in clockwise
direction
240*320, rotate
90 °in clockwise
direction
240*320, no
rotation
Keyboard
√
√
√
√
Touch Screen
√
NA
√
NA
Signature Pad
√
NA
√
NA
Printer
NA
√
√
NA
Font Library
√
√
√
√
Code
√
√
√
√
MSR
√
√
√
√
ICC Reader
√
√
√
√
RF Reader
√
√
√
√
Prolin API Programming Guide
PAX Computer Technology (Shenzhen) Co., Ltd. 234
Communication
Port
PORT_COM1
PORT_USBDE
V
PORT_USBHOS
T
PORT_COM1
PORT_COM2
PORT_PINPAD
PORT_USBDEV
PORT_USBHOS
T
PORT_USBDEV
PORT_USBHOS
T
PORT_COM
1
PORT_
USBDEV
MODEM
N/A
√
N/A
N/A
Network
Communication
√
√
N/A
N/A
Network
Configuration
√
√
N/A
N/A
GPRS/CDMA
N/A
√
√
N/A
WIFI
N/A
N/A
√
√
File System
√
√
√
√
System
Information
√
√
√
√
Audio
√
√
√
N/A
Power
Management
N/A
N/A
√
√
Barcode
N/A
N/A
N/A
N/A
Bluetooth
N/A
N/A
√
√
Prolin API Programming Guide
