1 November 28, 2018
Pure Storage Connector for
Cisco UCS Director User
Guide
2 November 28, 2018
Table of Contents
Preface ......................................................................................................................................... 3
Intended Audience ...................................................................................................................... 3
Software Version ......................................................................................................................... 3
Document Conventions .............................................................................................................. 3
Workflow Documents ................................................................................................................. 4
Chapter 1. Introduction .............................................................................................................. 5
Supported Storage Version ....................................................................................................... 5
Pure Storage Reports ................................................................................................................ 5
Supported Tasks ....................................................................................................................... 6
Supported Workflows ................................................................................................................ 7
Chapter 2. System Requirements and Installation .................................................................. 8
Summary of Steps ..................................................................................................................... 8
Required Hardware and Software ............................................................................................. 9
Add Pure Storage Connector .................................................................................................... 9
Prerequisites ........................................................................................................................ 9
Install and Deploy the Connector ........................................................................................ 9
Create a FlashStack Pod in Cisco UCS Director ................................................................. 9
Add Pure FlashArray Accounts to the Pod ........................................................................ 10
Test Connection to the Pure Storage Account .................................................................. 10
Chapter 3. Workflows and Tasks ............................................................................................. 11
Workflows ................................................................................................................................ 11
Import and Validate Pure Storage Workflows .................................................................... 11
Run Pure Storage Workflows ............................................................................................ 11
Tasks ....................................................................................................................................... 12
Action Button ........................................................................................................................... 13
REST API ................................................................................................................................ 14
Chapter 4. Logging and Troubleshooting .............................................................................. 16
Logging .................................................................................................................................... 16
View Logs .......................................................................................................................... 16
Troubleshooting ....................................................................................................................... 16
Storage Connector for Cisco UCS Director ....................................................................... 16
3 November 28, 2018
Preface
This document describes how to use the Pure Storage Connector for Cisco UCS® Director.
This preface includes the following information:
Intended Audience
Software Version
Document Conventions
Workflow Documents
Intended Audience
This user guide addresses users of the Pure Storage Connector for Cisco UCS®
Director. This user guide assumes that the reader is an experienced user of Cisco UCS
Director.
It is assumed the Administrator installing the Connector is well versed in administration of Pure
Storage FlashArray, including: creating accounts, licensing of hardware and software & storage
configuration. Content related to the administration of Pure Storage is not duplicated in this
document.
Software Version
This document revision applies to Pure Storage Connector for Cisco UCS Director software
version v02.2.0 and Cisco UCS Director version 6.5.
Document Conventions
This document uses the following typographic conventions:
Convention Description
Bold Indicates text on a window, other than the window title, including menus, menu
options, buttons, fields, and labels.
Example: Click OK.
Italic Indicates the file name. Example: copy source-file target-file
Hyperlink A reference to data that the reader can directly follow by clicking on the
hyperlinked text
4 November 28, 2018
Workflow Documents
Document Description
This document gives detailed description on how to deploy ESXi
ISCSi Boot on UCS Blade with Pure Storage FlashArray.
This document gives detailed description on how to deploy ESXi SAN
Boot on UCS Blade with Pure Storage FlashArray.
5 November 28, 2018
Chapter 1. Introduction
The Pure Storage Connector for Cisco UCS Director supports tasks that you can use
for inventory, orchestration, and in workflows. To aid in storage management and
troubleshooting, the Storage Connector for Cisco UCS Director provides system
logging options and troubleshooting support.
Supported Storage Version
The Storage Connector for Cisco UCS Director supports the following Pure storage
version.
• Purity v4 (4.x)
• Purity v5 (5.x)
Pure Storage Reports
The Pure Storage Connector for Cisco UCS Director collects the following storage
information that is displayed by the Cisco UCS Director:
• Inventory Report
• Storage capacity Report
• Volume Report
• Host Report
• Host Group Report
• Protection Group Report
• Snapshot Report
• Network Report
• Host Connections Report
• FC Target Report
• IQN Target Report
• Pod Report
• Space Report
• CloudSense Report
6 November 28, 2018
Supported Tasks
The Storage Connector for Cisco UCS Director supports the following tasks for the
supported Pure storage systems.
Grouping Task Name Description
Volume
Create Volume Create single or multiple volume.
Destroy Volume(s)-suffix range Delete the existing volume(s).
Resize Volume
Resize the existing volume.
Clone Volume Copy the exisiting volume.
Restore Volume Restore the exisiting Volume.
Host and
Host
Group
Create Host Create a new Host in Pure Storage FlashArray.
Delete Host Delete an existing Host
Connect Volume(s) to Host Connect existing volumes to Host
Disconnect Volume(s) with Host Disconnect the existing volumes from Host
Connect WWN(s)/IQN(s) to Host Provide the WWN/IQN to add in Host
Create Host Group Create a new host group.
Delete Host Group Delete an existing host group.
Connect Host to Host Group Connect existing Host to Host Group.
Connect Volume(s) to Host
Group Connect existing Volumes to the Host Group.
Disconnect Volume(s) with Host
Group Disconnect existing Volumes from Host Group
Disconnect Hosts(s) with Host
Group Disconnect exsiting Hosts from Host Group
Add Volume to ProtectionGroup Add existing Volume to the Protection Group
Add Host to ProtectionGroup Add existing Host to Protection Group
Add Target to ProtectionGroup Add existing Target to Protection Group
Protection
Group
Create ProtectionGroup Create a new Protection Group
Create ProtectionGroup with
HostGroup Create ProtectionGroup with the HostGroup
Delete ProtectionGroup Delete the existing ProtectionGroup
Remove Target from
ProtectionGroup Remove the existing Target from the
ProtectionGroup.
Remove Volume From
ProtectionGroup Remove the existing Volume from the
ProtectionGroup
Clone Snapshot Copy the existing Snapshot
7 November 28, 2018
Snapshot Delete Schedule Snapshot Delete the existing Schedule Snapshot
Delete Snapshot Delete the existing Snapshot
Schedule Volume Snapshot Create and schedule snapshot of the volume
Vlan Create Vlan Create a new Vlan
Delete Vlan Delete the existing Vlan
Supported Workflows
Pure Storage provides workflows for use with the Storage Connector for Cisco UCS
Director. Use of provided workflows is optional.
Workflow Description
Deploy ESXi Host on UCS Blade FC SAN
Boot with Pure Storage FlashArray
This workflow deploys ESXi host on UCS Blade server
using FC SAN Boot with Pure FlashArray.
Deploy ESXi Host on UCS Blade ISCSi
SAN Boot with Pure Storage FlashArray
This workflow deploys ESXi host on UCS Blade server
using FC SAN Boot with Pure FlashArray.
Deploy ESXi Host on UCS Blade FC SAN
Boot with Pure Storage FlashArray and
Service Profile Template
This workflow deploys ESXi host on UCS Blade server
using FC SAN Boot with Pure FlashArray.And It will use
Service Profile Template for creating Service Profile.
Deploy ESXi Host on UCS Blade ISCSi
SAN Boot with Pure Storage FlashArray
and Service Profile Template
This workflow deploys ESXi host on UCS Blade server
using ISCSi SAN Boot with Pure FlashArray.And It will
use Service Profile Template for creating Service Profile.
Provision VMware VM on Pure Storage
Datastore
Provision a VMware VM in Pure Storage Datastore (Pure
Storage Datastore must be selected in VMware Storage
Policy in UCS Director).
8 November 28, 2018
Chapter 2. System Requirements and Installation
This chapter gives an overview of installation process, required hardware and
software, and installation of the Connector for Cisco UCS Director.
Summary of Steps
1. Assemble the required hardware and software
2. Add the Pure Storage Open Automation Connector to Cisco UCS Director
3. In Cisco UCS Director, create a FlashStack pod
4. Add Pure FlashArray storage accounts to the pod
5. Test connections to the Pure storage account
6. (Optional) Import, validate, and run Pure storage workflows
9 November 28, 2018
Required Hardware and Software
• Supported Pure Storage and licenses
• Software: UCS Director 6.5 with appropriate license
Add Pure Storage Connector
Prerequisites
Locate the PureStorageUCSDirectorAdaptor file you downloaded from the Cisco Solution
Partners site or other sources.
Install and Deploy the Connector
1. Log in to Cisco UCS Director by using the Admin role credential.
2. In Cisco UCS Director, from the Administration menu, select Open Automation.
3. On the Connectors tab, click Add.
4. Extract the files from PureStorageUCSDirectorAdaptor. Click Open.
5. Click Upload, and then click Submit.
6. Select the newly added psucs module. Click Enable.
7. Use SSH to connect to the Cisco UCS Director instance and log in as shelladmin
(Default password is changeme).
8. To enable the Pure Storage Connector, stop all services (option 3), and then restart all
services (option 4).
Note: After the Cisco USC Director becomes available, be sure to check that the Connector is
Enabled/Active in the same location where it was added.
Create a FlashStack Pod in Cisco UCS Director
In Cisco UCS Director, create a Pure pod to contain all your Pure storage accounts. Alternatively,
locate an existing pod already in use for a Pure product such as Unified Computing System (UCP)
Select.
Note: A pod may contain more than one storage account, but a single storage account may not
be added to multiple pods.
1. In Cisco UCS Director, click on Converged in the menu. Click Add.
2. Complete the required fields.
3. Select FlashStack from the menu. Click Add.
10 November 28, 2018
Add Pure FlashArray Accounts to the Pod
For each storage system to be used, add a Pure storage account to your pod. Accounts are
available for generic pods or UCP Select pods.
Do the following to add a Pure storage account:
1. In Cisco UCS Director, from the Administration menu, select the Physical Accounts
tab. Click Add.
2. Select the pod you created.
3. Under Category, select Storage.
4. Select the FlashArray. Click Submit.
5. Complete the form as required. See the following table for a description of the fields.
Label Description Optional/
Required
Account Name
portion of the serial number to make identification easier Required
Description Description of the physical hardware Optional
Storage IP
Address
IPv4 address of the Pure Storage FlashArray Required
User Authorized user with storage administrator rights Required
Password User password (administrator privileges) Required
Contact Contact information for storage administrator Optional
Location Physical location of storage Optional
6. Click Submit.
The time required to add the account depends on the size of the storage system and network
speed.
Test Connection to the Pure Storage Account
Find out about connection problems in a few ways:
• After the Storage Connector for Cisco UCS Director is added to Cisco UCS
Director, the connector warns about connection problems.
• Use the Test Connection action within Cisco UCS Director:
o From the Administration menu, click Physical Accounts
o In the Physical Accounts tab, highlight the account to be tested
o Click Test Connection
11 November 28, 2018
Chapter 3. Workflows and Tasks
Pure provides storage workflows and tasks for use with the Storage Connector for Cisco UCS
Connector.
This chapter gives an overview about Import workflows, set task inputs, and validate workflows.
Workflows
Import and Validate Pure Storage Workflows
For each workflow that you import, you must set inputs for all tasks and validate each workflow.
1. Download the Pure Storage FlashArray End to End Workflows.wfdx file from the
Cisco Solution Partners site or Other Sources.
2. In Cisco UCS Director, under the Policies menu, select Orchestration.
3. Under the Workflows tab, click the Import button, and then browse to where you have
download Pure Storage FlashArray End to End Workflows.wfdx.
4. On the Workflows tab, open the folder Pure Storage FlashArray to view the imported
workflows.
5. Double-click on a workflow to open it in the Workflow Designer. The Workflow Designer
displays all tasks contained in the workflow, which you can be use as is or modify to fit
the environment.
Run Pure Storage Workflows
1. In Cisco UCS Director, open the Workflows tab.
2. Do one of the following:
• In the Workflows tab, click Execute Now.
• Open the Workflow Designer for the desired workflow. Click Execute Now.
• A dialog box appears and requests workflow inputs.
3. Enter workflow inputs as appropriate, and click Submit.
Note: All fields marked with * are required.
The workflow service request is executed. A message indicates whether the service request was
successful.
4. Click Show Detail Status for more information about the service request.
12 November 28, 2018
Tasks
Listed below are the tasks added to Cisco UCS Director after installing the Pure Storage
Connector.
Task
Description
Add Host to Protection Group
This task will add existing host to ProtectionGroup in
selected Pure Storage FlashArray
Add Target to Protection Group
This task will add existing Target to Protection Group in
selected Pure Storage FlashArray
Add volume to Protection Group
This task will add existing Volume to Protection Group
in selected Pure Storage FlashArray
Copy Snapshot
This task will Copy an existing Snapshot in selected
Pure Storage FlashArray
Copy Volume
This task will Copy an existing Volume in selected Pure
Storage FlashArray
Connect Host(s) to HostGroup
This task will add an existing or new host to a Host
Group in selected Pure Storage FlashArray
Connect Volume(s) to HostGroup
This task will connect the existing Volume(s) to the
Host Group in selected Pure Storage FlashArray
Connect Volume(s) to Host
This task will Connect the existing Volume(s) to the
Host in selected Pure Storage FlashArray.
Connect wwn(s)/iqn(s) to Host
This task will connect the WWN(s)/IQN(s) to the Host in
selected Pure Storage FlashArray.
Create HostGroup(s)-suffix range
This task will create a new Host Group. Optionally, a
start number and end number can be provided to
create multiple Host Group in selected Pure Storage
FlashArray.
Create Host
This task will create a new Host. Optionally, specify the
HBA WWN/IQN manually in selected Pure Storage
FlashArray.
Create Volume(s)-suffix range
This task will create a new Volume or multiple volumes
by provide start number and end number and size of
the volume in selected Pure Storage FlashArray.
Create HostGroup with ProtectionGroup
This task will create a new Protection Group with the
Host Group in selected Pure Storage FlashArray.
Create vLan Interface
This task will create a new vLan. Specify the vLan id, ip
address manually in selected Pure Storage FlashArray.
Delete HostGroup(s)-suffix range
This task will delete a Host Group in selected Pure
Storage FlashArray.
Delete Host
This task will delete a Host in selected Pure Storage
FlashArray.
Delete Protection Group
This task will delete the protection group in selected
Pure Storage FlashArray.
Disable Scheduled Volume Snapshot
This task will disable the scheduled Volume Snapshot
in selected Pure Storage FlashArray.
Delete vLan Interface
This task will delete a vLan Interface in selected Pure
Storage FlashArray.
Destroy Snapshot
This task will deletes an existing snapshot in selected
Pure Storage FlashArray
13 November 28, 2018
Destroy Volume(s)-suffix range
This task will delete an existing volumes in selected
Pure Storage FlashArray
Disconnect Volumes with Host Group
This task will disconnect an existing Volume(s) from the
Host Group in selected Pure Storage FlashArray
Disconnect Host(s) with Host Group
This task will disconnect an existing Host(s) from the
Host Group in selected Pure Storage FlashArray
Disconnect Volumes with Host
This task will disconnect an existing Volume(s) from the
Host in selected Pure Storage FlashArray
Remove Host from Protection Group
This task will remove an existing Host from protection
group in selected Pure Storage FlashArray.
Remove Target from Protection Group
This task will remove an existing Target from protection
group in selected Pure Storage FlashArray.
Remove Volume from Protection Group
This task will remove an exisitng Volume from
protection Group in selected Pure Storage FlashArray.
Resize Volume
This task will resize an existing Volume. Truncate
option is also available in the task in selected Pure
Storage FlashArray
Restore Volume From Snapshot
This task will restore the Volume from existing
Snapshot in selected Pure Storage FlashArray
RollBack Resize Volume Task
This task will be used to reverse or rollback the resize
of the Volume in selected Pure Storage FlashArray.
Schedule Replication
This task will create the schedule replication for
specified duration in selected Pure Storage FlashArray.
Schedule Volume Snapshot
This task will create and schedule the snapshot of
selected Volume for specified duration in selected Pure
Storage FlashArray.
Action Button
Listed below are the action buttons added to Cisco UCS Director after installing the Pure Storage
Connector.
Action Button
Description
Add Host
This button will add a new host in selected Pure
Storage FlashArray.
Add HostGroup
This button will add a new hostgroup in selected Pure
Storage FlashArray.
Add Host Protection Group
This button will add existing host to ProtectionGroup in
selected Pure Storage FlashArray.
Add ProtectionGroup
This button will add a new protectiongroup in selected
Pure Storage FlashArray.
Add Target Protection Group
This button will add an existing target to the
protectionGroup in selected Pure Storage FlashArray.
Add Volume
This button will add a new volume in selected Pure
Storage FlashArray
Add volume to Protection Group
This button will add existing Volume to Protection
Group in selected Pure Storage FlashArray.
Clone Snapshot
This button will Copy an existing Snapshot in selected
Pure Storage FlashArray
14 November 28, 2018
Copy Volume
This button will Copy an existing Volume in selected
Pure Storage FlashArray
Connect Host to HostGroup
This button will add an existing or new host to a Host
Group in selected Pure Storage FlashArray
Connect Volume to HostGroup
This button will connect the existing Volume to the Host
Group in selected Pure Storage FlashArray
Connect Volume to Host
This button will Connect the existing Volume to the
Host in selected Pure Storage FlashArray.
Destroy Volume
This button will delete a volume in selected Pure
Storage FlashArray.
Disconnect Host with Host Group
This button will disconnect the existing Host from the
Host Group in selected Pure Storage FlashArray.
Disconnect Volumes with Host
This button will disconnect the existing Volume from the
Host in selected Pure Storage FlashArray.
Disconnect Volume with Host Group
This button will disconnect the existing Volume from the
Host Group in selected Pure Storage FlashArray.
Remove Host from Protection Group
This button will remove Host from protection group in
selected Pure Storage FlashArray.
Remove Target from Protection Group
This button will remove target from protection group in
selected Pure Storage FlashArray.
Remove Volume from Protection Group
This button will remove volume from protection group in
selected Pure Storage FlashArray.
Rename Host
This button will rename host in selected Pure Storage
FlashArray.
Resize Volume
This button will resize an existing volume in selected
Pure Storage FlashArray.
Schedule Volume Snapshot
This button will create and schedule the snapshot of
selected Volume for specified duration in selected Pure
Storage FlashArray.
REST API
Listed below are the Rest API added to Cisco UCS Director after installing the Pure Storage
Connector.
Task
Description
Add Host to Protection Group
The host must be added to protection Group and
verified under the ProtectionGroup Report in UCSD as
well as Pure Storage FlashArray.
Add Target to Protection Group
The target must be added to protection Group and
verified under the ProtectionGroup Report in UCSD as
well as Pure Storage FlashArray.
Add volume to Protection Group
The volume must be added to protection Group and
verified under the ProtectionGroup Report in UCSD as
well as Pure Storage FlashArray.
Copy Snapshot
The snapshot is copied and verified under the
Snapshot Report in UCSD as well as Pure Storage
FlashArray
Copy Volume
The volume is copied and verified under the Volume
Report in UCSD as well as Pure Storage FlashArray
15 November 28, 2018
Connect Host(s) to HostGroup
The created host must be connected to hostGroup and
verified under the Host Group Report in UCSD as well
as Pure Storage FlashArray.
Connect Volume(s) to HostGroup
The created volume must be connected to hostGroup
and verified under the Host Group Report in UCSD as
well as Pure Storage FlashArray.
Connect Volume(s) to Host
The created volume must be connected to host and
verified under the Host Report in UCSD as well as Pure
Storage FlashArray.
Connect wwn(s)/iqn(s) to Host
The created wwn/iqn must be connected to host and
verified under the Host Report in UCSD as well as Pure
Storage FlashArray.
Create HostGroup(s)-suffix range
The HostGroup must be created and verified under the
Host Group Report in UCSD as well as Pure Storage
FlashArray.
Create Host
The Host must be created and verified under the Host
Report in UCSD as well as Pure Storage FlashArray.
Create Volume(s)-suffix range
The Volume must be created and verified under the
Volume Report in UCSD as well as Pure Storage
FlashArray.
Create HostGroup with ProtectionGroup
The protectionGroup must be created with hostgroup
and verified under the ProtectionGroup Report in
UCSD as well as Pure Storage FlashArray.
Delete HostGroup(s)-suffix range
The created hostGroup must be deleted and verified
under the HostGroup Report in UCSD as well as Pure
Storage FlashArray.
Delete Host
The created host must be deleted and verified under
the Host Report in UCSD as well as Pure Storage
FlashArray.
Delete Protection Group
The created protectionGroup must be deleted and
verified under the protectionGroup Report in UCSD as
well as Pure Storage FlashArray.
Destroy Snapshot
The created snapshot is deleted and verified under the
Snaphot Report in UCSD as well as Pure Storage
FlashArray
Destroy Volume(s)-suffix range
The created volume is created and verified under the
volume report in UCSD as well as Pure Storage
FlashArray
Disconnect Volumes with Host Group
The created volume must be disconnected from host
Group and verified under the Host Group report in
UCSD as well as Pure Storage FlashArray.
Disconnect Host(s) with Host Group
The created host must be disconnected from the
hostGroup must be deleted and verified under the
hostGroup report in UCSD as well as Pure Storage
FlashArray.
Disconnect Volumes with Host
The created volume must be disconnected from host
and verified under the host report in UCSD as well as
Pure Storage FlashArray.
Remove Host from Protection Group
The created host must be removed from
protectionGroup and verified under the
ProtectionGroup Report in UCSD as well as Pure
Storage FlashArray.
16 November 28, 2018
Remove Target from Protection Group
The created target must be removed from
protectionGroup and verified under the protectiongroup
Report in UCSD as well as Pure Storage FlashArray.
Remove Volume from Protection Group
The created volume must be removed from
protectionGroup and verified under Protectiongroup
Report in UCSD as well as Pure Storage FlashArray.
Resize Volume
The created volume must be resize and verified under
the volume Report in UCSD as well as Pure Storage
FlashArray.
Restore Volume From Snapshot
The created snapshot must be restored and verified
under the volume Report in UCSD as well as Pure
Storage FlashArray.
Schedule Volume Snapshot
The created volume must be scheduled for snapshot
and verified under the Snapshot Report in UCSD as
well as Pure Storage FlashArray
Chapter 4. Logging and Troubleshooting
This chapter gives an overview on how to view the logs and troubleshooting information for
Storage Connector for Cisco UCS Director
Logging
The Cisco UCS Director handles logging for the Connector.
View Logs
1. Within Cisco UCS Director, select Administration from the menu, and select Support
Information.
2. Within the Support Information drop down, select Show Log > Infra Manager> Show
Logs.
3. A browser page displays all recent activity. The page can be saved and shared with the
Pure Data Systems Support Center is desired.
Troubleshooting
Storage Connector for Cisco UCS Director
Symptom Possible Cause Resolution
The
psucs module has been
added, but no Pure
Cisco UCS Director services have
not been restarted after adding the
module.
Connect via SSH to the Cisco UCS
Director instance. Stop all
Director-related services, and then
restart.
17 November 28, 2018
Storage tasks are
available. The module is not enabled.
Highlight the module and click
Enable. Restart Cisco UCS
Director.
Unable to add the Pure
Storage FlashArray
physical account.
FlashArray accounts are only
available for FlashStack Pod.
Ensure that the pod type is
FlashStack.
The user does not have sufficient
rights.
Ensure that the user has
Administrator rights.
The IP address of Pure Storage
FlashArray is unreachable.
Ensure that IP address is reachable
from Cisco UCS Director network.

Navigation menu
