Data
Blazing Desktop Performance
Key Features and Benefits
• New level of reliability. Data
Protection System quickly verifies
drive integrity, while the exclusive
Shock Protection System protects
against potential points of failure
during shipping and installation
• Higher performance. 8.5 ms average
seek time with a 7,200 RPM
rotational speed, 2 MB buffer,
and Ultra ATA/66 interface
• Huge capacities. Room to handle
the largest desktop and personal
workstation applications — up to
30.0 GB in a 3.5-inch form factor
• Dependability. Full three-year warranty
Fireball Plus LM
10.2 AT
15.0 AT
20.5 AT
30.0 AT
The Market
Ever since its introduction, the award-
winning Quantum Fireball™disk drive
has defined performance in desktop
systems. Now, Quantum raises the bar
even higher with the Fireball Plus LM
drive that brings workstation-level
performance to the desktop. With
innovations in reliability and
performance, the Fireball Plus LM
drive is the optimum choice for the
most demanding applications,
including graphics-intensive desktop
publishing, complex CAD/CAM, MMX
multimedia, DVD, and sophisticated
financial modeling.
Two Innovative Reliability Features
The Quantum Fireball Plus LM
features the revolutionary Quantum
Data Protection System (DPS). In
less than 90 seconds, DPS lets a user
quickly and easily verify hard disk drive
functionality in the event of system
problems. The Fireball Plus LM drive
also has Quantum’s exclusive Shock
Protection System (SPS) that combats
one of the leading causes of hard disk
drive failures—mistreatment during
handling and integration. Combined,
these two systems help eliminate the
major causes of disk drive returns
—and give customers an
unprecedented level of
confidence that their data
will be preserved.
An Even Higher Level
of Performance
Along with a faster 7,200 RPM
rotational speed, the Fireball Plus LM
drive features an 8.5 millisecond (ms)
average seek time, and a 2 megabyte
(MB) buffer. To maximize I/O, the
Fireball Plus LM comes equipped with
the new Quantum-developed (patent
pending) Ultra ATA/66 interface.
Combined with available capacities,
the Fireball Plus LM offers customers
an unprecedented level of reliability,
performance, and capacity.
Quantum Quality and Reliability
With Quantum’s advanced DPS and
SPS systems and a full 3-year warranty,
the Fireball Plus LM drive achieves
a new level of dependability along with
proven performance. Good reasons
why when you build a system around
a Quantum drive you’re building
long-term trust with your customers.
Fireball Plus LM datasheet 1/5/00 2:01 PM Page 1
Specifications 10.2 15.0 20.5 30.0
Form Factor 3.5” (low profile) 3.5” (low profile) 3.5” (low profile) 3.5” (low profile)
Interface ATA/4, Ultra ATA/66, Ultra ATA/33 for all capacity points
Formatted Capacity (MB1) 10,273 15,020 20,547 30,020
Disk Drive Configuration
Recording Surfaces 2 3 4 6
ATA Logical
Cylinders 16,383 16,383 16,383 16,383
Heads 15 16 16 16
Sectors 63 63 63 63
Performance Specifications
Typical Seek Times2(ms)
Average 8.5
Track-to-Track 0.8
Full Stroke 15
Average Rotational Latency (ms) 4.17
Rotational Speed (RPM) 7,200
Data Transfer Rates (Buffer-to-Host)(MB/sec)
Ultra DMA/66 66.6
Ultra DMA/33 33.3
PIO Mode 4 16.6
DMA Mode 2 16.6
Buffer Size (KB) 2048 (2 MB)
Typical Power on to Drive Ready (sec) 15
Reliability Specifications
Start/Stop Cycles (ambient) 40,000
Nonrecoverable Data Errors (per bits read) <10 per 1015
Warranty3(years) 3
Physical Specifications
Dimensions-inches (mm)
Width 4.00 (101.6)
Length 5.787 (147.0)
Height 1.00 (25.4)
Weight-pounds (gr) 1.3 (580)
Environmental Limits
Operating
Temperature (˚C) 5 to 55
Non-Condensing Humidity (%) 10 to 85
Non-Operating
Temperature (˚C) -40 to 65
Non-Condensing Humidity (%) 5 to 95
Sound Power (bels, typ)
Idle 3.6
Seek 4.3
Power Specifications
Nominal Voltage (V) +5/+12
Voltage Margin (%) ±5/±10
Typical Power Draw (W)
Idle 6.9
Operating410.6
Peak Current (mA on +5/+12 V) 900/2,400
1. Quantum defines a megabyte (MB) as 106or 1,000,000 bytes. 2. Seek times are at nominal conditions and include settling. 3. This warranty is standard when products are purchased
directly through authorized Quantum distributors/dealers. Unless otherwise agreed, a one-year warranty is provided to all OEM purchasing directly from Quantum. End-user warranties
provided by computer manufacturers may vary. 4. Operating is defined as 40% seek, 30% read, 20% active, and 10% write.
Specifications subject to change without notice.
©2000 Quantum Corporation. All rights reserved. Quantum and the Quantum logo
are trademarks of Quantum Corporation, registered in the U.S.A and other countries.
Fireball is a trademark of Quantum Corporation.
Printed in the U.S.A. 100K HGD/CCP FLMDS0100
