1 Introduction

This document describes how to use the SSL functionality of Quectel BG96 module. In some cases, in

order to ensure communication privacy, the communication between the server and the client should be in

an encrypted way. So that it can prevent data from eavesdropping, tampering, or forging during the

communication process. The SSL function meets these demands.

1.1. SSL Version and Cipher Suite

The following SSL versions are supported.

Table 1: SSL Versions

The following table shows SSL cipher suites supported by Quectel BG96 module. For detailed description

of cipher suites, please refer to RFC 2246-The TLS Protocol Version 1.0.

Table 2: Supported SSL Cipher Suites

SSL Version

SSL3.0

TLS1.2

TLS1.1

TLS1.0

Code of Cipher Suites

Name of Cipher Suites

0X0035

TLS_RSA_WITH_AES_256_CBC_SHA

0X002F

TLS_RSA_WITH_AES_128_CBC_SHA

0X0005

TLS_RSA_WITH_RC4_128_SHA

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 7 / 27

1.2. The Process of Using SSL Function

Step 1: Configure <APN>, <username>, <password> and other parameters of a PDP context by

AT+QICSGP. Please refer to Quectel_BG96_TCP(IP)_AT_Commands_Manual for details.

Step 2: Activate the PDP context by AT+QIACT, then the assigned IP address can be queried by

AT+QIACT?. Please refer to Quectel_BG96_TCP(IP)_AT_Commands_Manual for details.

Step 3: Configure the SSL version, cipher suite, path of trusted CA certificate and the security level for

the specified SSL context by AT+QSSLCFG.

Step 4: Open SSL client connection by AT+QSSLOPEN. <sslctxID> is used to specify SSL context, and

<access_mode> is used to specify data access mode.

Step 5: After the SSL connection has been established, data will be sent or received via the connection.

For details about how to send and receive data under each access mode, please refer to

Chapter 1.3.

Step 6: Close SSL connection by AT+QSSLCLOSE.

Step 7: Deactivate the PDP context by AT+QIDEACT.

0X0004

TLS_RSA_WITH_RC4_128_MD5

0X000A

TLS_RSA_WITH_3DES_EDE_CBC_SHA

0X003D

TLS_RSA_WITH_AES_256_CBC_SHA256

0XC011

TLS_ECDHE_RSA_WITH_RC4_128_SHA

0XC012

TLS_ECDHE_RSA_WITH_3DES_EDE_CBC_SHA

0XC013

TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA

0XC014

TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA

0XC027

TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256

0XC028

TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384

0XC02F

TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256

0XFFFF

Support all cipher suites above

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 8 / 27

1.3. Description of Data Access Modes

The SSL connection supports the following three kinds of data access modes:

- Buffer access mode

- Direct push mode

- Transparent access mode

When opening an SSL connection via AT+QSSLOPEN, the data access mode can be specified by the

parameter <access_mode>. After the SSL connection has been established, customers can switch the

access mode via AT+QISWTMD.

1. In buffer access mode, data are sent via AT+QSSLSEND command, and if the module has received

data from the Internet, it will report a URC as “+QSSLURC: “recv”,<clientID>”. Customers can

retrieve data via AT+QSSLRECV command.

2. In direct push mode, data are sent via AT+QSSLSEND command, and if the module has received

data from the Internet, the data will be outputted directly via UART1/USB modem/USB AT port in the

following format: +QSSLURC: “recv”,<clientID>,<currectrecvlength><CR><LF><data>.

3. In transparent access mode, the corresponding port enters into exclusive mode. The data received

from COM port will be sent to the Internet directly, and the received data from Internet will be

outputted to COM port directly. Customers can use “+++” or DTR (AT&D1 should be set first) to

switch to buffer access mode. In transparent access mode, if SSL connection encounters any

abnormal disconnection, the module will report “NO CARRIER”.

4. To exit from transparent access mode, “+++” or DTR (AT&D1 should be set first) can be used. To

prevent the “+++” from being misinterpreted as data, the following sequence should be followed:

1) Do not input any character within 1s or longer before inputting “+++”.

2) Input “+++” within 1s, and no other characters can be inputted during the time.

3) Do not input any character within 1s after “+++” has been inputted.

4) Use “+++” or DTR (AT&D1 should be set first) to make the module exit from transparent access

mode, and wait until “OK” is returned.

5. There are two methods to return back to transparent access mode:

1) By AT+QISWTMD. Specify the <access_mode> as 2 when executing this command. If entering

into transparent access mode successfully, “CONNECT” will be returned.

2) By ATO. ATO will change the access mode of connection that exits from transparent access

mode lately. If entering transparent access mode successfully, “CONNECT” will be returned. If

there is no connection entering into transparent access mode before, ATO will return “NO

CARRIER”.

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 9 / 27

1.4. Validity Check for Certificate

To check whether a certificate is in the validity period, the certificate must be parsed, and compare the

local time with the “Not before” and “Not after” of the certificate. If the local time is earlier than the time of

“Not before” or later than the time of “Not after”, the certificate will be considered expired.

When validity check for certification is required (<ignoreltime> set as 0 when executing AT+QSSLCFG), in

order to avoid failure of certificate validity check, AT+CCLK command should be used to configure the

module time within the validity time period of the certificate.

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 10 / 27

2 Description of SSL AT Commands

2.1. Description of AT Commands

2.1.1. AT+QSSLCFG Configure Parameters of an SSL Context

The command can be used to configure the SSL version, cipher suites, security level, CA certificate, client

certificate and client key. These parameters will be used in the handshake procedure.

<sslctxID> is the index of the SSL context. The module supports 6 SSL contexts at most. On the basis of

one SSL context, several SSL connections can be established. The settings such as the SSL version and

the cipher suite are stored in the SSL context, and they will be applied to the new SSL connections

associated with the SSL context.

AT+QSSLCFG Configure Parameters of an SSL Context

Test Command

AT+QSSLCFG=?

Response

+QSSLCFG: "sslversion",(0-5),(0-4)

+QSSLCFG:

"ciphersuite",(0-5),(0X0035,0X002F,0X0005,0X0004,0X00

0A,0X003D,0XC011,0XC012,0XC013,0XC014,0XC027,0X

C028,0XC02F,0XFFFF)

+QSSLCFG: "cacert",(0-5),<cacertpath>

+QSSLCFG: "clientcert",(0-5),<client_cert_path>

+QSSLCFG: "clientkey",(0-5),<client_key_path>

+QSSLCFG: "seclevel",(0-5),(0-2)

+QSSLCFG: "ignorelocaltime",(0-5),(0,1)

+QSSLCFG: "negotiatetime",(0-5),(10-300)

OK

Write Command

Configure the SSL version for the

specified SSL context:

AT+QSSLCFG="sslversion",<sslctxID

>[,<sslversion>]

Response

If <sslversion> is omitted, query the SSL version for the

specified SSL context, and response:

+QSSLCFG: "sslversion",<sslctxID>,<sslversion>

OK

If <sslversion> is not omitted, set the SSL version for the

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 11 / 27

specified SSL context, and response:

OK

Or

ERROR

Write Command

Configure the SSL cipher suites for the

specified SSL context:

AT+QSSLCFG="ciphersuite",<sslctxID

>[,<ciphersuites>]

Response

If <ciphersuites> is omitted, query the SSL cipher suites for

the specified SSL context, and response:

+QSSLCFG: "ciphersuite",<sslctxID>,<ciphersuites>

OK

If <ciphersuites> is not omitted, set the SSL cipher suite for

the specified SSL context, and response:

OK

Or

ERROR

Write Command

Configure the path of trusted CA

certificate for the specified SSL context:

AT+QSSLCFG="cacert",<sslctxID>[,<c

acertpath>]

Response

If <cacertpath> is omitted, query the path of trusted CA

certificate for the specified SSL context, and response:

+QSSLCFG: "cacert",<sslctxID>,<cacertpath>

OK

If <cacertpath> is not omitted, set the path of trusted CA

certificate for the specified SSL context, and response:

OK

Or

ERROR

Write Command

Configure the path of client certificate for

the specified SSL context:

AT+QSSLCFG="clientcert",<sslctxID>[

,<client_cert_path>]

Response

If <client_cert_path> is omitted, query the path of client

certificate for the specified SSL context, and response:

+QSSLCFG: "clientcert",<sslctxID>,<client_cert_path>

OK

If <client_cert_path> is not omitted, set the path of client

certificate for the specified SSL context, and response:

OK

Or

ERROR

Write Command

Configure the path of client private key for

the specified SSL context:

AT+QSSLCFG="clientkey",<sslctxID>[,

Response

If <client_key_path> is omitted, query the path of client

private key for the specified SSL context , and response:

+QSSLCFG: "clientkey",<sslctxID>,<client_key_path>

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 12 / 27

<client_key_path>]

OK

If <client_key_path> is not omitted, set the path of client

private key for the specified SSL context, and response:

OK

Or

ERROR

Write Command

Configure the authentication mode for the

specified SSL context:

AT+QSSLCFG="seclevel",<sslctxID>[,

<seclevel>]

Response

If <seclevel> is omitted, query the authentication mode for

the specified SSL context, and response:

+QSSLCFG: "seclevel",<sslctxID>,<seclevel>

OK

If <seclevel> is not omitted, set the authentication mode for

the specified SSL context, and response:

OK

Or

ERROR

Write Command

Configure whether to ignore validity

check for certification for the specified

SSL context:

AT+QSSLCFG="ignorelocaltime",<ssl

ctxID>[,<ignoreltime>]

Response

If <ignoreltime> is omitted, query whether the validity check

for certification is ignored for the specified SSL context , and

response:

+QSSLCFG: "ignorelocaltime",<sslctxID>,<ignoreltime>

OK

If <ignoreltime> is not omitted, set whether or not to ignore

certification validity check for the specified SSL context, and

response:

OK

Or

ERROR

Write Command

Configure the maximum timeout in SSL

negotiation stage for the specified SSL

context:

AT+QSSLCFG="negotiatetime",<sslct

xID>[,<negotiate_time>]

Response

If <negotiate_time> is omitted, query the maximum timeout

in SSL negotiation stage for the specified SSL context, and

response:

+QSSLCFG:

"negotiatetime",<sslctxID>,<negotiate_time>

OK

If <negotiate_time> is not omitted, set the maximum timeout

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 13 / 27

Parameter

in SSL negotiation stage for the specified SSL context, and

response:

OK

Or

ERROR

<sslctxID> Numeric type. SSL context ID. The range is 0-5.

<sslversion> Numeric type. SSL Version.

0 SSL3.0

1 TLS1.0

2 TLS1.1

3 TLS1.2

4 All

<ciphersuites> Numeric type. SSL cipher suites.

0X0035 TLS_RSA_WITH_AES_256_CBC_SHA

0X002F TLS_RSA_WITH_AES_128_CBC_SHA

0X0005 TLS_RSA_WITH_RC4_128_SHA

0X0004 TLS_RSA_WITH_RC4_128_MD5

0X000A TLS_RSA_WITH_3DES_EDE_CBC_SHA

0X003D TLS_RSA_WITH_AES_256_CBC_SHA256

0XC011 TLS_ECDHE_RSA_WITH_RC4_128_SHA

0XC012 TLS_ECDHE_RSA_WITH_3DES_EDE_CBC_SHA

0XC013 TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA

0XC014 TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA

0XC027 TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256

0XC028 TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384

0XC02F TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256

0XFFFF Support all

<ignoreltime> Numeric format. How to deal with expired certificate.

0 Care about validity check for certification

1 Ignore validity check for certification

<cacertpath> String format. The path of the trusted CA certificate.

<client_cert_path> String format. The path of the client certificate.

<client_key_path> String format, the path of the client private key.

<seclevel> Numeric format. The authentication mode.

0 No authentication

1 Manage server authentication

2 Manage server and client authentication if requested by the remote

server

<negotiate_time> Numeric format. Indicates maximum timeout used in SSL negotiation stage. The

value rang is 10-300, and the default value is 300. Unit: second.

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 14 / 27

2.1.2. AT+QSSLOPEN Open an SSL Socket to Connect a Remote Server

The command is used to set up an SSL connection. During the negotiation between the module and the

Internet, parameters configured by AT+QSSLCFG will be used in the handshake procedure. After shaking

hands with the Internet successfully, the module can send or receive data via this SSL connection. Also

the module can set up several SSL connections based on one SSL context.

According to steps mentioned in Chapter 1.2, before executing AT+QSSLOPEN, AT+QIACT command

should be executed first to activate the PDP context.

It is suggested to wait for a specific period of time (refer to the Maximum Response Time below) for

“+QSSLOPEN: <connectid>,<err>” URC to be outputted. If the URC response cannot be received during

the time, AT+QSSLCLOSE command can be used to close the SSL connection.

AT+QSSLOPEN Open an SSL Socket to Connect a Remote Server

Test Command

AT+QSSLOPEN=?

Response

+QSSLOPEN:

(1-16),(0-5),(0-11),<serveraddr>,<server_port>[,(0-2)]

OK

Write Command

AT+QSSLOPEN=<pdpctxID>,<sslctxI

D>,<clientID>,<serveraddr>,<server_

port>[,<access_mode>]

Response

If the <access_mode> is transparent access mode and the

SSL connection is successfully set up, response:

CONNECT

If there is any error, response:

ERROR

Error description can be got via AT+QIGETERROR.

If the <access_mode> is buffer access mode or direct push

mode, response:

OK

+QSSLOPEN: <clientID>,<err>

<err> is 0 when SSL socket is opened successfully, otherwise

<err> is not 0.

If there is any error, response:

ERROR

Error description can be got via AT+QIGETERROR.

Maximum Response Time

Maximum network response time of 150s, plus configured

time of <negotiate_time>.

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 15 / 27

Parameter

2.1.3. AT+QSSLSEND Send Data via SSL Connection

After the connection is established, the module can send data through the SSL connection.

<pdpctxID> Numeric type. PDP context ID. The range is 1-16.

<sslctxID> Numeric type. SSL context ID. The range is 0-5.

<clientID> Numeric type. Socket index. The range is 0-11.

<serveraddr> String type. The address of remote server.

<server_port> Numeric type. The listening port of remote server.

<access_mode> Numeric type. The access mode of SSL connection.

0 Buffer access mode

1 Direct push mode

2 Transparent mode

<err> Integer type. The error code of the operation. Please refer to Chapter 5.

AT+QSSLSEND Send Data via SSL Connection

Test Command

AT+QSSLSEND=?

Response

+QSSLSEND: (0-11)[,(1-1460)]

OK

Write Command

AT+QSSLSEND=<clientID>

After response “>”, input the data to be

sent. Tap CTRL+Z to send, and tap

ESC to cancel the operation.

Response

>

<CTRL-Z>

If connection has been established and sending is successful,

response:

SEND OK

If connection has been established but sending buffer is full,

response:

SEND FAIL

If connection has not been established, abnormally closed, or

the parameter is incorrect, response:

ERROR

Write Command

AT+QSSLSEND=<clientID>,<sendlen

>

After response “>”, input data until the

data length is equal to <sendlen>.

Response

>

If connection has been established and sending is successful,

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 16 / 27

Parameter

2.1.4. AT+QSSLRECV Receive Data via SSL Connection

When an SSL connection is opened with <access_mode> specified as 0, the module will report URC as

“+QSSLURC: “recv”,<clientID>” if it receives data from the Internet. Customers can read the data from

buffer by AT+QSSLRECV command.

response:

SEND OK

If connection has been established but sending buffer is

full, response:

SEND FAIL

If connection has not been established, abnormally closed, or

the parameter is incorrect, response:

ERROR

<clientID> Numeric type. Socket index. The range is 0-11.

<sendlen> Numeric type. The length of sending data. The range is 1-1500. Unit: byte.

AT+QSSLRECV Receive Data via SSL Connection

Test Command

AT+QSSLRECV=?

Response

+QSSLRECV: (0-11),(1-1500)

OK

Write Command

AT+QSSLRECV=<clientID>,<readlen>

Response

If the specified connection has received data, response:

+QSSLRECV: <havereadlen><CR><LF><data>

OK

If the buffer is empty, response:

+QSSLRECV: 0

OK

If parameters is incorrect or the connection cannot be

established, response:

ERROR

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 17 / 27

Parameter

2.1.5. AT+QSSLCLOSE Close an SSL Connection

The command is used to close an SSL connection. If all the SSL connections based on the same SSL

context are closed, the module will release the SSL context.

Parameter

2.1.6. AT+QSSLSTATE Query the State of SSL Connection

The command is used to query the socket connection status. It can only query the status of SSL

connection.

<clientID> Numeric type. Socket index. The range is 0-11.

<readlen> Numeric type. The length of data to be retrieved. The range is 1-1500. Unit: byte.

<havereadlen> Numeric type. The actual data length obtained by AT+QSSLRECV. Unit: byte.

<data> The retrieved data.

AT+QSSLCLOSE Close an SSL Connection

Test Command

AT+QSSLCLOSE=?

Response

+QSSLCLOSE: (0-11),(0-65535)

OK

Write Command

AT+QSSLCLOSE=<clientID>[,<close_

timeout>]

Response

If successfully closed, response:

OK

If failed to close, response:

ERROR

<clientID> Numeric type. Socket index. The range is 0-11.

<close_timeout> Numeric type. The timeout value of AT+QSSLCLOSE. The range is 0-65535, and

the default value is 10. Unit: second. 0 means close immediately.

AT+QSSLSTATE Query the State of SSL Connection

Test Command

AT+QSSLSTATE=?

Response

OK

Write Command

AT+QSSLSTATE=<clientID>

Response

+QSSLSTATE:

<clientID>,“SSLClient”,<IP_address>,<remote_port>,<loc

al_port>,<socket_state>,<pdpctxID>,<serverID>,<access

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 18 / 27

Parameter

2.2. Description of URC

2.2.1. Notify Received Data

Notify received data which comes from peer.

_mode>,<AT_port>,<sslctxID>

OK

Execution Command

AT+QSSLSTATE

Response

List of

(+QSSLSTATE:

<clientID>,“SSLClient”,<IP_address>,<remote_port>,<loc

al_port>,<socket_state>,<pdpctxID>,<serverID>,<access

_mode>,<AT_port>,<sslctxID>)

OK

<clientID> Numeric type. Socket index. The range is 0-11.

<IP_address> String type. The address of remote server.

<remote_port> Numeric type. The port of remote server.

<local_port> Numeric type. The local port.

<socket_state> Numeric type. The state of SSL connection.

0 “Initial” Connection has not been established

1 “Opening” Client is connecting

2 “Connected” Client connection has been established

4 “Closing” Connection is closing

<pdpctxID> Numeric type. PDP context ID. The range is 1-16.

<serverID> Numeric type. Reserved.

<access_mode> Numeric type. The access mode of SSL connection.

0 Buffer access mode

1 Direct push mode

2 Transparent access mode

<AT_port> String type. COM port.

<sslctxID> Numeric type. SSL context ID. The range is 0-5.

Notify Received Data

+QSSLURC: "recv",<clientID>

The URC of SSL data incoming in buffer access mode. SSL

data can be received by AT+QSSLRECV.

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 19 / 27

Parameter

2.2.2. Notify Abnormal Close

Notify that the connection has been disconnected. Lots of reasons can cause this phenomenon, such as

the Internet closes the connection or the state of GPRS PDP is deactivated. The SSL connection state

based on the specified socket will be “closing”. In such case, AT+QSSLCLOSE=<connectid> must be

executed to change the SSL connection state to “initial”.

Parameter

+QSSLURC:

"recv",<clientID>,<currentrecvlength>

The URC of SSL data incoming in direct push mode.

<clientID> Integer type. Socket index. The range is 0-11.

<currentrecvlength> Integer type. The length of actual received data.

<data> The received data.

Notify Abnormal Close

+QSSLURC: "closed",<clientID>

The SSL connection based on the specified socket is closed.

<clientID> Integer type. Socket index. The range is 0-11.

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 20 / 27

3 Examples

3.1. Configure and Activate a PDP Context

3.1.1. Configure a PDP Context

AT+QICSGP=1,1,“CMCIOT”,“”,“”,1 //Configure context 1. APN is “CMCIOT”.

OK

3.1.2. Activate a PDP Context

AT+QIACT=1 //Activate context 1.

OK //Activated successfully.

AT+QIACT? //Query the state of context.

+QIACT: 1,1,1,"10.7.157.1"

OK

3.1.3. Deactivate a PDP Context

AT+QIDEACT=1 //Deactivate context 1.

OK //Deactivated successfully.

3.2. Configure an SSL Context

AT+QSSLCFG=“sslversion”,1,1

OK

AT+QSSLCFG=“ciphersuite”,1,0X0035

OK

AT+QSSLCFG=“seclevel”,1,1

OK

AT+QSSLCFG=“cacert”,1,“cacert.pem”

OK

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 21 / 27

3.3. SSL Client Works in Buffer Access Mode

3.3.1. Set up an SSL Connection and Enter into Buffer Access Mode

AT+QSSLOPEN=1,1,4,"220.180.239.201",8010,0

OK

+QSSLOPEN: 4,0 //Set up an SSL connection successfully.

AT+QSSLSTATE //Query the status of all SSL connections.

+QSSLSTATE: 4,"SSLClient","220.180.239.201",8010,65344,2,1,4,0,"usbmodem",1

OK

3.3.2. Send Data in Buffer Access Mode

AT+QSSLSEND=4 //Send changeable length data.

> Test data from SSL

<CTRL-Z>

SEND OK

AT+QSSLSEND=4,18 //Send fixed length data and the data length is 18 bytes.

> Test data from SSL

SEND OK

3.3.3. Receive Data in Buffer Access Mode

+QSSLURC: “recv”,4 //The <clientID> 4 received data.

AT+QSSLRECV=4,1500 //Read data. The length of data to be retrieved is 1500 bytes.

+QSSLRECV: 18 //The actual received data length is 18 bytes.

Test data from SSL

OK

AT+QSSLRECV=4,1500

+QSSLRECV: 0 //No data in buffer.

OK

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 22 / 27

3.3.4. Close an SSL Connection

AT+QSSLCLOSE=4 //Close a connection whose <clientID> is 4. Depending on the

network, the maximum response time is 10s.

OK

3.4. SSL Client Works in Direct Push Mode

3.4.1. Set up an SSL Connection and Enter into Direct Push Mode

AT+QSSLOPEN= 1,1,4,"220.180.239.201",8011,1

OK

+QSSLOPEN: 4,0 //Set up SSL connection successfully.

AT+QSSLSTATE //Query the status of all SSL connections.

+QSSLSTATE: 4,"SSLClient","220.180.239.201",8011,65047,2,1,4,1,"usbmodem",1

OK

3.4.2. Send Data in Direct Push Mode

AT+QSSLSEND=4 //Send changeable length data.

>Test data from SSL

<CTRL-Z>

SEND OK

AT+QSSLSEND=4,18 //Send fixed length data and the data length is 18 bytes.

>Test data from SSL

SEND OK

3.4.3. Receive Data in Direct Push Mode

+QSSLURC: "recv",4,18

Test data from SSL

3.4.4. Close an SSL Connection

AT+QSSLCLOSE=4 //Close a connection whose <clientID> is 4. Depending on the

network, the maximum response time is 10s.

OK

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 23 / 27

3.5. SSL Client Works in Transparent Access Mode

3.5.1. Set up an SSL Connection and Send Data in Transparent Access Mode

AT+QSSLOPEN= 1,1,4,"220.180.239.201",8011,2 //Set up an SSL connection.

CONNECT //Enter into transparent access mode.

//Client is sending data from COM port to the Internet directly. (The data

is not visible in the example.)

OK //Use “+++” or DTR (AT&D1 should be set first) to exit from transparent

access mode. The “NO CARRIER” result code indicates that the

server has stopped the SSL connection.

3.5.2. Set up an SSL Connection and Receive Data in Transparent Access Mode

AT+QSSLOPEN= 1,1,4,"220.180.239.201",8011,2 //Set up an SSL connection.

CONNECT

<Received data> //Client is reading the data.

OK //Use “+++” or DTR (AT&D1 should be set first) to exit from transparent

access mode. The “NO CARRIER” result code indicates that the server

has stopped the SSL connection.

3.5.3. Close an SSL Connection

AT+QSSLCLOSE=4 //Close a connection whose <connectid> is 4. Depending on the network,

the maximum response time is 10s.

OK

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 24 / 27

4 Error Handling

4.1. Open SSL Connection Fails

If it is failed to open SSL connection, please check the following aspects:

1. Query the status of the specified PDP context by AT+QIACT? command to check whether the

specified PDP context has been activated.

2. If the address of server is a domain name, please check whether the address of DNS server is valid

by AT+QIDNSCFG=<contextID>. Because an invalid DNS server address cannot convert domain

name to IP address.

3. Please check the SSL configuration by AT+QSSLCFG command, especially the SSL version and

cipher suite, so as to make sure they are supported on server side. If <seclevel> has been configured

as 1 or 2, customers must upload trusted CA certificate to the module by FILE AT command. If the

server side has configured “SSLVerifyClient required”, then the customer must upload the client

certificate and client private key to the module by FILE AT commands. For details about certificate

validity check, please refer to Chapter 1.4. And for more details about related FILE AT commands,

please refer to Quectel_BG96_FILE_Application_Note.

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 25 / 27

5 Summary of Error Codes

If an “ERROR” is returned after executing SSL AT commands, the details of error can be queried by

AT+QIGETERROR. Please note that AT+QIGETERROR command just returns error code of the last SSL

AT command.

Table 3: Summary of Error Codes

<err>

Meaning

0

Operation successful

550

Unknown error

551

Operation blocked

552

Invalid parameter

553

Memory not enough

554

Create socket failed

555

Operation not supported

556

Socket bind failed

557

Socket listen failed

558

Socket write failed

559

Socket read failed

560

Socket accept failed

561

Open PDP context failed

562

Close PDP context failed

563

Socket identity has been used

564

DNS busy

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 26 / 27

565

DNS parse failed

566

Socket connection failed

567

Socket has been closed

568

Operation busy

569

Operation timeout

570

PDP context break down

571

Cancel send

572

Operation not allowed

573

APN not configured

574

Port busy

Quectel

Confidential

LTE Module Series

BG96 SSL AT Commands Manual

BG96_SSL_AT_Commands_Manual Confidential / Released 27 / 27

6 Appendix A References

Table 4: Related Documents

Table 5: Terms and Abbreviations

SN

Document Name

Remark

[1]

GSM 07.07

Digital cellular telecommunications (Phase

2+); AT command set for GSM Mobile

Equipment (ME)

[2]

GSM 07.10

Support GSM 07.10 multiplexing protocol

[3]

Quectel_BG96_TCP(IP)_AT_Commands_

Manual

Introduction about BG96 TCP/IP AT

commands

[4]

Quectel_BG96_FILE_AT_Commands_Manual

Introduction about BG96 FILE AT commands

Abbreviation

Description

DNS

Domain Name Server

DTR

Data Terminal Ready

PDP

Packet Data Protocol

SSL

Security Socket Layer

Quectel

Confidential

Quectel BG96 SSL AT Commands Manual V1.0

Quectel_BG96_SSL_AT_Commands_Manual_V1.0

Quectel_BG96_SSL_AT_Commands_Manual_V1.0

Quectel_BG96_SSL_AT_Commands_Manual_V1.0

Quectel_BG96_SSL_AT_Commands_Manual_V1.0

Quectel_BG96_SSL_AT_Commands_Manual_V1.0

Navigation menu

Versions of this User Manual:

Views

Navigation
