EC20 HTTP
AT Commands Manual
LTE Module Series
Rev. EC20_HTTP_AT_Commands_Manual_V1.0
Date: 2015-07-02
www.quectel.com
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 1 / 31
Our aim is to provide customers with timely and comprehensive service. For any
assistance, please contact our company headquarters:
Quectel Wireless Solutions Co., Ltd.
Office 501, Building 13, No.99, Tianzhou Road, Shanghai, China, 200233
Tel: +86 21 5108 6236
Mail: info@quectel.com
Or our local office, for more information, please visit:
http://www.quectel.com/support/salesupport.aspx
For technical support, to report documentation errors, please visit:
http://www.quectel.com/support/techsupport.aspx
Or Email: Support@quectel.com
GENERAL NOTES
QUECTEL OFFERS THIS INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION
PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT
TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT
MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT
ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR
RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO
CHANGE WITHOUT PRIOR NOTICE.
COPYRIGHT
THIS INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF
QUECTEL CO., LTD. TRANSMITTABLE, REPRODUCTION, DISSEMINATION AND EDITING OF THIS
DOCUMENT AS WELL AS UTILIZATION OF THIS CONTENTS ARE FORBIDDEN WITHOUT
PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS
ARE RESERVED IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL
OR DESIGN.
Copyright © Quectel Wireless Solutions Co., Ltd. 2015. All rights reserved.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 2 / 31
About the Document
History
Revision
Date
Author
Description
1.0
2015-07-02
Chris PENG
Initial
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 3 / 31
Contents
About the Document ................................................................................................................................... 2
Contents ....................................................................................................................................................... 3
Table Index ................................................................................................................................................... 4
1 Introduction .......................................................................................................................................... 5
1.1. The Process of Using HTTP AT Commands ............................................................................. 5
1.2. Description of HTTP Header ..................................................................................................... 6
1.2.1. Customize HTTP Request Header .................................................................................. 6
1.2.2. Output HTTP Response Header ...................................................................................... 6
1.3. Description of Data Mode ........................................................................................................ 6
1.4. Error Handling ......................................................................................................................... 7
1.4.1. Executing HTTP AT Command Fails ............................................................................... 7
1.4.2. PDP Activation Fails ......................................................................................................... 7
1.4.3. DNS Parse Fails ............................................................................................................... 8
1.4.4. Entering Online Data Mode Fails ..................................................................................... 8
1.4.5. Sending GET/POST Request Fails.................................................................................. 8
1.4.6. Reading Response Fails .................................................................................................. 9
2 Description of AT Command ............................................................................................................ 10
2.1. AT+QHTTPCFG Configure Parameters for HTTP(S) Server ............................................... 10
2.2. AT+QHTTPURL Set HTTP(S) Server URL .......................................................................... 12
2.3. AT+QHTTPGET Send GET Request to HTTP(S) Server .................................................... 13
2.4. AT+QHTTPPOST Send POST Request to HTTP(S) Server by UART/USB ....................... 14
2.5. AT+QHTTPPOSTFILE Send POST Request to HTTP(S) Server by File ............................ 16
2.6. AT+QHTTPREAD Read Response from HTTP(S) Server by UART/USB ........................... 18
2.7. AT+QHTTPREADFILE Read Response from HTTP(S) Server by File ............................... 18
3 Example .............................................................................................................................................. 20
3.1. Access to HTTP Server ........................................................................................................... 20
3.1.1. Send HTTP GET Request .............................................................................................. 20
3.1.2. Send HTTP POST Request ........................................................................................... 21
3.1.2.1. Post Body Obtained from UART/USB .................................................................. 21
3.1.2.2. Post Body Obtained from File System ................................................................. 22
3.2. Access to HTTPS Server ......................................................................................................... 23
3.2.1. Send HTTP GET Request .............................................................................................. 23
3.2.2. Send HTTP POST Request ........................................................................................... 25
3.2.2.1. Post Body Obtained from UART/USB .................................................................. 25
3.2.2.2. Post Body Obtained from File System ................................................................. 26
4 Summary of ERROR Code ................................................................................................................ 28
5 Summary of HTTP Response Code ................................................................................................. 30
6 Appendix A Reference ....................................................................................................................... 31
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 4 / 31
Table Index
TABLE 1: DIFFERENT CODING SCHEMES OF +CME ERROR : <ERR> ...................................................... 28
TABLE 2: DIFFERENT CODING SCHEMES OF HTTP RESPONSE CODE ................................................... 30
TABLE 3: RELATED DOCUMENTS .................................................................................................................. 31
TABLE 4: TERMS AND ABBREVIATIONS ........................................................................................................ 31
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 5 / 31
1 Introduction
EC20 provides HTTP application to HTTP(S) server. This document is a reference guide to all the AT
commands defined for HTTP.
1.1. The Process of Using HTTP AT Commands
Through EC20 TCPIP AT command, you can configure PDP context, activate and deactivate PDP context,
query PDP context status (Please refer to Quectel_EC20_TCPIP_AT_Commands_Manual), and through
EC20 HTTP AT command, you can send HTTP GET/POST request to HTTP server, and read HTTP
response from HTTP server. The general process is as follows:
Step 1: Configure the <apn>, <username>, <password> and other parameters of PDP context by
AT+QICSGP (Please refer to Quectel_EC20_TCPIP_AT_Commands_Manual). If QoS settings
need to be updated, configure them by the commands AT+CGQMIN, AT+CGEQMIN,
AT+CGQREQ and AT+CGEQREQ (For more details, please refer to Quectel_EC20_AT_
Commands_Manual).
Step 2: Activate PDP context by AT+QIACT, then the assigned IP address can be queried by
AT+QIACT? (Please refer to Quectel_EC20_TCPIP_AT_Commands_Manual).
Step 3: Set PDP context ID and SSL context ID by AT+QHTTPCFG command.
Step 4: Configure SSL context parameters by AT+QSSLCFG command (Please refer to
Quectel_EC20_SSL_AT_Commands_Manual).
Step 5: Set HTTP URL by AT+QHTTPURL command.
Step 6: Send HTTP request. AT+QHTTPGET command can be used for sending HTTP GET request,
AT+QHTTPPOST or QHTTPOSTFILE command can be used for sending HTTP POST
request.
Step 7: Read HTTP response information by AT+QHTTPREAD or QHTTPREADFILE command.
Step 8: Deactivate PDP context by AT+QIDEACT command. (For details, please refer to
Quectel_EC20_TCPIP_AT_Commands_Manual).
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 6 / 31
1.2. Description of HTTP Header
1.2.1. Customize HTTP Request Header
HTTP request header is filled by the modem automatically. If you want to customize the HTTP request
header, you can set <request_header> as 1 by AT+QHTTPCFG command, and then input HTTP request
header as below:
1. Follow HTTP header syntax.
2. The value of URI in HTTP request line and the “Host:” header must be in line with the URL configured
by AT+QHTTPURL command.
3. The HTTP request header must end with <CR><LF>.
The following example shows a valid HTTP POST request header:
POST/processorder.php HTTP/1.1<CR><LF>
Host: 220.180.239.201:8011<CR><LF>
Accept: */*<CR><LF>
User-Agent: QUECTEL_MODULE<CR><LF>
Connection: Keep-Alive<CR><LF>
Content-Type: application/x-www-form-urlencoded<CR><LF>
Content-Length: 42<CR><LF>
<CR><LF>
1.2.2. Output HTTP Response Header
HTTP response header will not output automatically. If you want to obtain HTTP response header
information, you can set <response header> to 1 by AT+QHTTPCFG command, and the HTTP response
header will be output with HTTP response body when you execute AT+QHTTPREAD or
AT+QHTTPREADFILE command.
1.3. Description of Data Mode
The mode of the COM port includes AT command mode and data mode. The difference between them is
as follows:
1) In AT command mode, the data input via COM port will be treated as AT command.
2) In data mode, the data input via COM port will be treated as data.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 7 / 31
You can exit from data mode by using “+++” or pulling up DTR (AT&D1 should be set).To prevent the
“+++” from being misinterpreted as data, it should comply with the following sequence:
1) Do not input any character within 1 second before inputting “+++”.
2) Input “+++” within 1 second, and no other characters can be input during this time.
3) Do not input any character wit in 1 second after “+++” has been input.
When you execute QHTTPURL, QHTTPHEAD, QHTTPOST and QHTTPREAD, the modem will enter
data mode. If you are using “+++” or DTR to make module exit from online data mode, the executing
procedure of these command will be interrupted before the executed result is returned, and you can’t
reenter online data mode by executing ATO command.
1.4. Error Handling
1.4.1. Executing HTTP AT Command Fails
If you execute HTTP AT command and receive response “ERROR” from modem, please check whether
the SIM card is inserted and the result of “AT+CPIN?” is “+CPIN: READY”.
1.4.2. PDP Activation Fails
If you failed to active PDP context by AT+QIACT command, please check the following aspects:
1. Query whether the PS domain is attached by AT+CGATT? command. If not, execute AT+CGATT=1
command to attach PS domain.
2. Query the PS domain status by AT+CGREG? command and make sure the PS domain has been
registered.
3. Query the PDP context parameters by AT+QICSGP command and make sure the APN of specified
PDP context has been set.
4. Make sure the specified PDP context ID is neither used by PPP nor activated by AT+CGACT
command.
5 The module only supports three PDP contexts activated simultaneously, so you must make sure the
amount of activated PDP context is less than 3.
If the result of above checking is OK, but the executing of AT+QIACT command still fails, please reboot
the modem to resolve this issue. After rebooting the modem, please follow the above checking at least
three times and each time at an interval of 10 minutes to avoid frequent rebooting of the module.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 8 / 31
1.4.3. DNS Parse Fails
When executing AT+QHTTPGET, AT+QHTTPPOST and QHTTPPOSTFILE commands, if “+CME
ERROR: 714” (714: HTTP DNS error) is returned, please check the following aspects:
1. Make sure the domain name of HTTP server is valid.
2. Query the status of PDP context via AT+QIACT? command to make sure the specified PDP context
has been activated successfully.
3. Query the address of DNS server via AT+QIDNSCFG command to make sure the address of DNS
server is not equal to “0.0.0.0”.
If the DNS server address is equal to “0.0.0.0”, there are two solutions:
1. Reassign a valid DNS server address by AT+QIDNSCFG command.
2. Deactivate the PDP context by AT+QIDEACT command, and re-activate the PDP context via
AT+QIACT command.
1.4.4. Entering Online Data Mode Fails
When executing QHTTPURL, QHTTPGET, QHTTPPOST and QHTTPREAD commands, if “+CME
ERROR: 704” (704: HTTP UART busy) is returned, please check whether there are other ports in online
data mode, since the modem only supports one port in online data mode simultaneously.
If you encounter this issue during executing QHTTPURL, QHTTPGET, QHTTPPOST and QHTTPREAD
command, please re-execute these commands after other ports exit from online data mode.
1.4.5. Sending GET/POST Request Fails
If you receive a failed result during executing AT+QHTTPGET, AT+QHTTPPOST and QHTTPPOSTFILE
command, please check the following aspects:
1. Make sure the URL input via HTTPURL command is valid and can be accessed.
2. Make sure the specified server supports GET/POST command.
3. Make sure the PDP context has been activated successfully.
If the result of above checking is OK, but the executing of AT+QHTTPGET, QHTTPPOST and
QHTTPPOSTFILE command still fails, please deactivate the PDP context via AT+QIDEACT and
reactivate the PDP context via AT+QIACT to resolve this issue. If you encounter failed result during
activating the PDP context, please refer to Chapter 1.4.2 to resolve it.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 9 / 31
1.4.6. Reading Response Fails
Before reading response by AT+QHTTPREAD and QHTTPREADFILE command, you should execute
AT+QHTTPGET, AT+QHTTPPOST and QHTTPPOSTFILE command and receive the URC information:
“+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]”/
“+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]”/
“+QHTTPPOSTFILE: <err>[,<httprspcode>,<content_length>]”
During executing AT+QHTTTPREAD and QHTTPREADFILE command, if you encounter some errors,
such as: “+CME ERROR: 717” (717: HTTP read error), please resend HTTP GET/POST request to HTTP
server by AT+QHTTPGET, AT+QHTTPPOST and QHTTPPOSTFILE command. If you encounter failed
result during sending GET/POST request to HTTP server, please refer to Chapter 1.4.5 to resolve it.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 10 / 31
2 Description of AT Command
2.1. AT+QHTTPCFG Configure Parameters for HTTP(S) Server
AT+QHTTPCFG is used to configure the parameters for HTTP service, including PDP context ID,
customizing HTTP request header and outputting HTTP response header and querying SSL settings. If
the write command only executes one parameter, it will query the current settings.
AT+QHTTPCFG Configure Parameters for HTTP(s) Server
Response
+QHTTPCFG: “contextid”,(1-16)
+QHTTPCFG: “requestheader”,(0,1)
+QHTTPCFG: “responseheader”,(0,1)
+QHTTPCFG: “sslctxid”,(0-5)
+QHTTPCFG: "contenttype",(0-3)
OK
Response
If <contextID> is not omitted:
OK
or
+CME ERROR: <err>
Else, query the current settings:
+QHTTPCFG: “contextid”,<contextID>
OK
Response
If <request_header> is not omitted:
OK
or
+CME ERROR: <err>
Else, query the current settings:
+QHTTPCFG: “requestheader”,<request_header>
OK
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 11 / 31
Parameter
Response
If <response header> is not omitted:
OK
or
+CME ERROR: <err>
Else, query the current settings:
+QHTTPCFG: “responseheader”,<response_header>
OK
Response
If <sslctxID> is not omitted:
OK
or
+CME ERROR: <err>
Else, query the current settings:
+QHTTPCFG: “sslctxid”,<sslctxID>
OK
Response
+QHTTPCFG: “contextid”,<contextID>
+QHTTPCFG: “requestheader”,<request_header>
+QHTTPCFG: “responseheader”,<response_header>
+QHTTPCFG: “sslctxid”,<sslctxID>
+QHTTPCFG: "contenttype",<content_type>
OK
<contextID> Numeric type, indicates PDP context ID, range is 1-16, default value is 1
<request_header> Numeric type, indicates whether to customize HTTP request header
0 Disable
1 Enable
<response_header> Numeric type, indicates whether to output HTTP response header or not
0 Disable
1 Enable
<sslctxID> Numeric type, indicates this SSL context ID will be used for HTTP. The range
is 0-5, default value is 1. You should configure the SSL parameter by
AT+QSSLCFG. (For details, please refer to the command AT+QSSLCFG in
Quectel_EC20_SSL_AT_Commands_Manual.)
<content_type> Numeric type, indicates the data type of HTTP body
0 application/x-www-form-urlencoded
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 12 / 31
2.2. AT+QHTTPURL Set HTTP(S) Server URL
To input URL, you must begin with “http://” or “https://”. If the URL begins with “http://”, it indicates you will
access to a HTTP server. If the URL begins with “https://”, it indicates you will access to a HTTPS server.
Parameter
<URL_length> Numeric type, indicates the length of URL, range is 1-700, unit: byte
<timeout> Numeric type, indicates the maximum time in seconds to input URL, range is
1 text/plain
2 application/octet-stream
3 multipart/form-data
<err> The type of error, please refer to Chapter 4
AT+QHTTPURL Set HTTP(S) Server URL
Test Command
AT+QHTTPURL=?
Response
+QHTTPURL: (1-700),(1-65535)
OK
Write Command
AT+QHTTPURL=<URL_length>[,<tim
eout>]
Response
a) If format is right, and it is not sending HTTP GET/POST
request at present:
CONNECT
TA switches to the transparent access mode, and the URL can
be input. When the total size of the input data reaches
<URL_length>, TA will return to command mode and report
the following codes:
OK
If the <timeout> has reached, but the received length of URL
is less than <URL_length>, TA will return to command mode
and report the following code:
+CME ERROR: <err>
b) If parameter format is not right or other errors occur:
+CME ERROR: <err>
Read Command
AT+QHTTPURL?
Response
[+QHTTPURL: <URL><CR><LF>]
OK
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 13 / 31
1-65535, default value is 60, unit: second
<err> The type of error, please refer to Chapter 4
2.3. AT+QHTTPGET Send GET Request to HTTP(S) Server
According to the configured parameter <request_header> in the command
AT+QHTTPCFG=“requestheader”[,<request_header>], the HTTPGET write command has two different
formats, the details are shown as below. Please note that if <request_header> equals to 1, after the
command AT+QHTTPGET has been sent, the CONNECT may be output in 125s to indicate that the
connection is successful. If it is not received during this time, the +CME ERROR: <err> will be output.
After the HTTPGET write command has been sent, it is suggested to wait a specific time (refer to the
Maximum Response Time below) after the result code OK is reported for the URC response
“+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]”.
In the URC “+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]”, the parameter <httprspcode> can
only be reported when <err> equals to 0. If HTTP response header contains “CONTENT-LENGTH”
information, the <content_length> information will be reported.
AT+QHTTPGET Send GET Request to HTTP(S) Server
Test Command
AT+QHTTPGET=?
Response
+QHTTPGET: (1-65535),(1-2048),(1-65535)
OK
If <request_header> equals to 0
(disable customizing HTTP request
header)
AT+QHTTPGET[=<rsptime>]
Response
a) If parameter format is right and no other errors occur:
OK
When modem has received response from HTTP server, it will
report the following URC:
+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]
b) If parameter format is not right or other errors occur:
+CME ERROR: <err>
If <request_header> equals to 1 (enable
customizing HTTP request header)
AT+QHTTPGET=<rsptime>,<data_len
gth>[,<input_time>]
Response
a) If connect HTTP server successfully:
CONNECT
TA switches to the transparent access mode, and the HTTP
GET request header can be input. When the total size of the
input data reaches <data length>, TA will return to command
mode and report the following codes:
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 14 / 31
Parameter
<rsptime> Numeric type, the range is 1-65535. The default value is 60, unit: second. It is
used to configure the timeout for the HTTP GET response URC “+QHTTPGET:
<err>[,<httprspcode>,<content_length>]” to report after the result code OK is
returned
<data_length> Numeric type, indicates the length of HTTP request information, including HTTP
request header and HTTP request body, range is 1-2048, unit: byte
<input_time> Numeric type, indicates the maximum time in seconds to input HTTP request
information, range is 1-65535. The default value is 60, unit: second
<err> Please refer to Chapter 4
<httprspcode> Please refer to Chapter 5
<request_header> Please refer to Chapter 2.1
<content_length> Numeric type, indicates the length of HTTP response body, unit: byte.
2.4. AT+QHTTPPOST Send POST Request to HTTP(S) Server by
UART/USB
You can send HTTP POST request via AT+QHTTPPOST command. According to the configured
parameter <request_header> in the command AT+QHTTPCFG=“requestheader”[,<request_header>],
the HTTPPOST write command has two different formats, if you set <request_header> to 0, you should
input post body by UART/USB, else if you set <request_header> to 1, you should input post header and
body by UART/USB.
OK
When modem has received response from HTTP server, it will
report the following URC:
+QHTTPGET: <err>[,<httprspcode>[,<content_length>]]
If the <input_time> has reached, but the length of received
data is less than <data length>, TA will return to command
mode and report the following code:
+CME ERROR: <err>
b) If parameter format is not right or other errors occur:
+CME ERROR: <err>
Maximum Response Time
Determined by <rsptime>
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 15 / 31
After the command AT+QHTTPPOST has been sent, the CONNECT may be output in 125s to indicate
the connection is successful, if it isn’t received during this time, the +CME ERROR: <err> will be output.
It is suggested to wait a specific time (refer to the Maximum Response Time below) after the result code
OK is reported for the URC response “+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]”.
AT+QHTTPPOST Send POST Request to HTTP(S) Server by UART/USB
Test Command
AT+QHTTPPOST=?
Response
+QHTTPPOST: (1-1024000),(1-65535),(1-65535)
OK
If <request_header> equals to 0
(disable customizing HTTP request
header)
AT+QHTTPPOST=<data_length>[,<in
put_time>,<rsptime>]
Response
a) If parameter format is right and HTTP server is connected
successfully and HTTP request header is sent completely, it
will prompt you to input body:
CONNECT
TA switches to the transparent access mode, and the HTTP
POST body can be input. When the total size of the input data
reaches <data_length>, TA will return to command mode and
report the following codes:
OK
When modem has received response from HTTP server, it will
report the following URC:
+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]
If the <input_time> has reached, but the received length of
data is less than <data_length>, TA will return to command
mode and report the following code:
+CME ERROR: <err>
b) If parameter format is not right or other errors occur:
+CME ERROR: <err>
If <request_header> equals to 1 (enable
customizing HTTP request header)
AT+QHTTPPOST=<data_length>[,<in
put_time>,<rsptime>]
Response
a) If parameter format is right and HTTP server is connected
successfully:
CONNECT
TA switches to the transparent access mode, and the HTTP
POST header and body can be input. When the total size of
the input data reaches <data_length>, TA will return to
command mode and report the following codes:
OK
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 16 / 31
Parameter
<data_length> Numeric type, if <request_header> is 0, it indicates the length of post body,
and if <request_header> is 1, it indicates the length of HTTP request
information, including HTTP request header and HTTP request body, range is
1-1024000, unit: byte
<input_time> Numeric type, indicates the maximum time in seconds to input post body or
HTTP request information, range is 1-65535. The default value is 60, unit:
second
<rsptime> Numeric type, range is 1-65535. The default value is 60, unit: second. It is
used to configure the timeout for the HTTP POST response URC
“+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]” to report after the
result code OK is returned
<err> Please refer to Chapter 4
<httprspcode> Please refer to Chapter 5
<request_header> Please refer to Chapter 2.1
<content_length> Numeric type, indicates the length of HTTP response body, unit: byte
2.5. AT+QHTTPPOSTFILE Send POST Request to HTTP(S) Server by
File
You also can send HTTP POST request in file via AT+QHTTPPOSTFILE command. According to the
<request_header> in the command AT+QHTTPCFG=“requestheader”[,<request_header>], the file
operated through HTTPPOSTFILE command has two different formats, if set <request_header> to 0, the
file in file system will be post body, else if set <request_header> to 1, the file in file system will be post
header and body.
When modem has received response from HTTP server, it will
report the following URC:
+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]
If the <input_time> has reached, but the length of received
data is less than <data_length>, TA will return to command
mode and report the following code:
+CME ERROR: <err>
b) If parameter format is not right or other errors occur:
+CME ERROR: <err>
Maximum Response Time
Determined by network and <rsptime>
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 17 / 31
The modem will report information “+QHTTPPOSTFILE: <err>[,<httprspcode>[,<content_length>]]” to
indicate the executing result of AT+QHTTPPOSFILE command. The parameter <httprspcode> can only
be reported when <err> equals to 0.
It is suggested to wait a specific time (refer to the Maximum Response Time below) after the result code
OK is reported for the URC response “+QHTTPPOSTFILE: <err>[,<httprspcode>[,<content_length>]]”.
Parameter
<file_name> String type, file name, the max length of file name is 80, unit: byte
<rsptime> Numeric type, the range is 1-65535. The default value is 60, unit: second. It
is used to configure the timeout for the HTTP POST response URC
“+QHTTPPOSTFILE: <err>[,<httprspcode>,<content_length>]” to report
after the result code OK is returned.
<err> Please refer to Chapter 4
<httprspcode> Please refer to Chapter 5
<request_header> Please refer to Chapter 2.1
<content_length> Numeric type, indicates the length of HTTP response body
AT+QHTTPPOSTFILE Send POST Request to HTTP(S) Server by File
Test Command
AT+QHTTPPOSTFILE=?
Response
+QHTTPPOSTFILE: <file_name>,(1-65535)
OK
Write Command
AT+QHTTPPOSTFILE=<file_name>[,<
rsptime>]
If <request_header> equals to 1, the
specified file must contain HTTP
request header information.
Response
a) If parameter format is right and HTTP server is connected
successfully:
OK
When modem has received response from HTTP server, it will
report the following URC:
+QHTTPPOSTFILE:
<err>[,<httprspcode>,<content_length>]
b) If parameter format is not right or other errors occur:
+CME ERROR: <err>
Maximum Response Time
Determined by <rsptime>
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 18 / 31
2.6. AT+QHTTPREAD Read Response from HTTP(S) Server by
UART/USB
After sending HTTP GET/POST request, you can retrieve HTTP response information from HTTP server
to UART/USB via AT+QHTTPREAD command. And before executing AT+QHTTPREAD, “+QHTTPGET:
<err>[,<httprspcode>[,<content_length>]]”, “+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]” or
“+QHTTPPOSTFILE: <err>[,<httprspcode>,<content_length>]” information must be received.
Parameter
<wait_time> Numeric type, indicates the maximum interval time between receiving two packets
of data. The default value is 60, unit: second
<err> Please refer to Chapter 4
2.7. AT+QHTTPREADFILE Read Response from HTTP(S) Server by File
After sending HTTP GET/POST request, you can retrieve HTTP response information from HTTP server
to file via AT+QHTTPREADFILE command. And before executing AT+QHTTPREADFILE, “+QHTTPGET:
<err>[,<httprspcode>[,<content_length>]]”, “+QHTTPPOST: <err>[,<httprspcode>[,<content_length>]]” or
AT+QHTTPREAD Read Response from HTTP(S) Server by UART/USB
Test Command
AT+QHTTPREAD=?
Response
+QHTTPREAD: (1-65535)
OK
Write Command
AT+QHTTPREAD[=<wait_time>]
Response
a) If parameter format is right and read successfully:
CONNECT
<Output HTTP response information >
OK
+QHTTPREAD: <err>
If <wait_time> reaches or other errors occur, but body has not
output completely, it will report the following codes:
+CME ERROR: <err>
b) If parameter format is not right or other errors occur:
+CME ERROR: <err>
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 19 / 31
“+QHTTPPOSTFILE: <err>[,<httprspcode>,<content_length>]” information must be received.
Parameter
<wait_time> Numeric type, indicates the maximum interval time between receiving two
packets of data, range is 1-65535. The default value is 60, unit: second
<file_name> String type, file name, the max length of file name is 80, unit: byte.
<err> Please refer to Chapter 4
AT+QHTTPREADFILE Read Response from HTTP(S) Server by File
Test Command
AT+QHTTPREADFILE=?
Response
+QHTTPREADFILE: <file_name>,(1-65535)
OK
Write Command
AT+QHTTPREADFILE=<file_name>[,
<wait_time>]
Response
a) If parameter format is right:
OK
When body is read over or <wait_time> reaches, it will report:
+QHTTPREADFILE: <err>
b) If parameter format is not right or other errors occur:
+CME ERROR: <err>
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 20 / 31
3 Example
3.1. Access to HTTP Server
3.1.1. Send HTTP GET Request
Following example shows how to send HTTP GET request with a customer HTTP request header, and
how to read HTTP GET response.
//How to send HTTP GET response.
AT+QHTTPCFG=“contextid”,1 //Set the PDP context ID as 1.
OK
AT+QHTTPCFG=“responseheader”,1 //Allow to output HTTP response header.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,“UNINET”,“”,“”,1 //Configure context 1, APN is “UNINET” for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
OK //Activate successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"10.7.157.1"
OK
AT+QHTTPURL=23,80 //Set the URL which will be accessed.
CONNECT
HTTP://www.sina.com.cn/ //Input URL which length is 23, note that this URL is an example,
please input the correct URL in practical test.
OK
AT+QHTTPGET=80 //Send HTTP GET request and maximum response time is 80s.
OK
+QHTTPGET: 0,200,547256 //If HTTP response header contains “CONTENT-LENGTH”
information, the <content_length> information will be reported.
//How to read HTTP response.
//Solution 1: Read HTTP response information and output by UART
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 21 / 31
AT+QHTTPREAD=80 //Read HTTP response information and output by UART, the
maximum time to wait for HTTP session to close is 80s.
CONNECT
HTTP/1.1 200 OK <CR><LF> //HTTP response header and body.
Content-Type: text/html<CR><LF>
Vary: Accept-Encoding<CR><LF>
X-Powered-By: shci_v1.03<CR><LF>
Server: nginx<CR><LF>
Date: Fri, 27 Dec 2013 02:21:43 GMT<CR><LF>
Last-Modified: Fri, 27 Dec 2013 02:20:01 GMT<CR><LF>
Expires: Fri, 27 Dec 2013 02:22:43 GMT<CR><LF>
Cache-Control: max-age=60<CR><LF>
Age: 1<CR><LF>
Content-Length: 547256<CR><LF>
X-Cache: HIT from xd33-85.sina.com.cn<CR><LF>
<CR><LF>
<body>
OK
+QHTTPREAD: 0 //Read HTTP response header and body successfully.
//Solution 2: Read HTTP response information and store it to RAM file.
AT+QHTTPREADFILE=“RAM:1.txt”,80 //Read HTTP response header and body and store them to
“RAM:1.txt”, the maximum time to wait for HTTP session to
close is 80s.
OK
+QHTTPREADFILE: 0 //HTTP response header and body are stored successfully.
3.1.2. Send HTTP POST Request
3.1.2.1. Post Body Obtained from UART/USB
Following example shows how to send HTTP POST request and retrieve post body from UART/USB. In
addition, it also shows how to read HTTP POST response.
AT+QHTTPCFG=“contextid”,1 //Set the PDP context ID as 1.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,“UNINET”,“”,“”,1 //Configure context 1, APN is “UNINET” for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 22 / 31
OK //Activate successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"172.22.86.226"
OK
AT+QHTTPURL=59,80 //Set the URL which will be accessed.
CONNECT
HTTP://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo? //Input URL which length is 59,
note that this URL is an
example, please input the
correct URL in practical test.
OK
AT+QHTTPPOST=20,80,80 //Send HTTP POST request, POST body is obtained from UART,
maximum input body time is 80s and maximum response time is
80s.
CONNECT
Message=HelloQuectel //Input post body which length is 20, note that post body is an
example, please input the correct post body in practical test.
OK
+QHTTPPOST: 0,200,177 //If HTTP response header contains “CONTENT-LENGTH”
information, the <content_length> information will be reported.
AT+QHTTPREAD=80 //Read HTTP response body and output by UART, the maximum
time to wait for HTTP session to close is 80s.
CONNECT
<?xml version="1.0" encoding="utf-8"?>
<string xmlns="httpHTTPs://api.efxnow.com/webservices2.3">Message='HelloQuectel' ASCII:72
101 108 108 111 81 117 101 99 116 101 108 </string> //Output HTTP response body.
OK
+QHTTPREAD: 0 //HTTP response body is output successfully.
3.1.2.2. Post Body Obtained from File System
Following example shows how to send HTTP POST request and retrieve post body from file system. In
addition, it also shows how to store HTTP POST response to file system.
AT+QHTTPCFG=“contextid”,1 //Set the PDP context ID as 1.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,“UNINET”,“”,“”,1 //Configure context 1, APN is “UNINET” for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 23 / 31
OK //Activate successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"172.22.86.226"
OK
AT+QHTTPURL=59,80 //Set the URL which will be accessed.
CONNECT
HTTP://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo? //Input URL which length is 59,
note that this URL is an
example, please input the
correct URL in practical test.
OK
AT+QHTTPPOSTFILE=“RAM:2.txt”,80 //Send HTTP POST request, POST body is obtained from
“RAM:2.txt”, and maximum response time is 80s.
OK
+QHTTPPOSTFILE: 0,200,177 //After HTTP POST request is sent success, you can execute
command AT+QHTTPREAD.
AT+QHTTPREADFILE=“RAM:3.txt”,80 //Read HTTP response body and store it to “RAM:3.txt”, the
maximum time to wait for HTTP session to close is 80s.
OK
+QHTTPREADFILE: 0 //HTTP response body is stored successfully.
3.2. Access to HTTPS Server
3.2.1. Send HTTP GET Request
Following example shows how to send HTTP GET request with a customer HTTP request header, and
how to read HTTP GET response.
//How to send HTTP GET request.
AT+QHTTPCFG=“contextid”,1 //Set the PDP context ID as 1.
OK
AT+QHTTPCFG=“responseheader”,1 //Allow to output HTTP response header.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,“UNINET”,“”,“”,1 //Configure context 1, APN is “UNINET” for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
OK //Activate successfully.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 24 / 31
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"10.7.157.1"
OK
AT+QHTTPCFG=“sslctxid”,1 //Set the SSL context ID.
OK
AT+QSSLCFG=“sslversion”,1,1 //Set the SSL version as 1, it means TLsV1.0.
OK
AT+QSSLCFG=“ciphersuite”,1,0x0005 //Set the SSL ciphersuite as 0x0005, it means RC4-SHA.
OK
AT+QSSLCFG=“seclevel”,1,0 //Set the SSL verify level as 0, it means you don’t need any CA
Cert.
OK
AT+QHTTPURL=19,80 //Set the URL which will be accessed.
CONNECT
HTTPs://mail.qq.com/ //Input URL which length is 19, note that this URL is an example,
please input the correct URL in practical test.
OK
AT+QHTTPGET=80 //Send HTTP GET request and maximum response time is 80s.
OK
+QHTTPGET: 0,200,10750 //If HTTP response header contains “CONTENT-LENGTH”
information, the <content_length> information will be
reported.
//How to read HTTP response.
//Solution 1: Read HTTP response information and output by UART.
AT+QHTTPREAD=80 //Read HTTP response information and output by UART,
the maximum time to wait for HTTP session to close is 80s.
CONNECT //HTTP response header and body.
HTTP/1.1 200 OK<CR><LF>
Server: nginx/1.2.7<CR><LF>
Date: Fri, 27 Dec 2013 02:38:27 GMT<CR><LF>
Content-Type: text/html; charset=GB18030<CR><LF>
Content-Length: 10750<CR><LF>
Connection: keep-alive<CR><LF>
<CR><LF>
<body>
OK
+QHTTPREAD: 0 //Read HTTP response header and body successfully.
//Solution 2: Read HTTP response information and store it to RAM file.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 25 / 31
AT+QHTTPREADFILE=“RAM:4.txt”,80 //Read HTTP response header and body and store it to
“RAM:4.txt”, the maximum time to wait for HTTP session to
close is 80s.
OK
+QHTTPREADFILE: 0 //HTTP response header and body are stored successfully.
3.2.2. Send HTTP POST Request
3.2.2.1. Post Body Obtained from UART/USB
Following example shows how to send HTTP POST request and retrieve post body from UART/USB. In
addition, it also shows how to read HTTP POST response.
AT+QHTTPCFG=“contextid”,1 //Set the PDP context ID as 1.
OK
AT+QIACT? //Query the state of context.
OK
AT+QICSGP=1,1,“UNINET”,“”,“”,1 //Configure context 1, APN is “UNINET” for China Unicom.
OK
AT+QIACT=1 //Activate context profile 1.
OK //Activate successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"172.22.86.226"
OK
AT+QHTTPCFG=“sslctxid”,1 //Set the SSL context ID.
OK
AT+QSSLCFG=“sslversion”,1,1 //Set the SSL Version as 1, it means TLsV1.0.
OK
AT+QSSLCFG=“ciphersuite”,1,0x0005 //Set the SSL ciphersuite as 0x0005, it means RC4-SHA.
OK
AT+QSSLCFG=“seclevel”,1,2 //Set the SSL verify level as 2, it means you should upload CA
Cert, client Cert and client private key by AT+QFUPL command.
OK
AT+QSSLCFG=“cacert”,1, “RAM:cacert.pem”
OK
AT+QSSLCFG=“clientcert”,1,“RAM:clientcert.pem”
OK
AT+QSSLCFG=“clientkey”,1,“RAM:clientkey.pem”
OK
AT+QHTTPURL=45,80 //Set the URL which will be accessed.
CONNECT
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 26 / 31
HTTPs://220.180.239.201:8011/processorder.php //Input URL which length is 45, note that URL is an
example, please input the correct URL in
practical test.
OK
AT+QHTTPPOST=48,80,80 //Send HTTP POST request , POST body is obtained from UART,
maximum input body time is 80s and maximum response time is
80s.
CONNECT
Message=1111&Appleqty=2222&Orangeqty=3333&find=1 //Input post body which length is 48, note
that this post body is an example, please
input the correct one in practical test.
OK
+QHTTPPOST: 0,200,285 //If HTTP response header contains “CONTENT-LENGTH”
information, the <content_length> information will be reported.
AT+QHTTPREAD=80 //Read HTTP response body and output by UART, the maximum
time to wait for HTTP session to close is 80s.
CONNECT //Read HTTP response body successfully.
<html>
<head>
<title>Quectel's Auto Parts - Order Results</title>
</head>
<body>
<h1>Quectel's Auto Parts</h1>
<h2>Order Results</h2>
<p>Order processed at 02:49, 27th December</p><p>Your order is as follows: </p>1111
message<br />2222 apple<br />3333 orange<br /></body>
</html>
OK
+QHTTPREAD: 0 //HTTP response body is output successfully.
3.2.2.2. Post Body Obtained from File System
Following example shows how to send HTTP POST request and retrieve post body from file system. In
addition, it also shows how to store HTTP POST response to file system.
AT+QHTTPCFG=“contextid”,1 //Set the PDP context ID as 1.
OK
AT+QIACT? //Query the state of context.
OK
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 27 / 31
AT+QICSGP=1,1,“UNINET”,“”,“”,1 //Configure context 1, APN is “UNINET” for China Unicom.
OK
AT+QIACT=1 //Activate context 1.
OK //Activate successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"172.22.86.226"
OK
AT+QHTTPCFG=“sslctxid”,1 //Set the SSL context ID.
OK
AT+QSSLCFG=“sslversion”,1,1 //Set the SSL version as 1, it means TLsV1.0.
OK
AT+QSSLCFG=“ciphersuite”,1,0x0005 //Set the SSL ciphersuite as 0x0005, it means RC4-SHA.
OK
AT+QSSLCFG=“seclevel”,1,2 //Set the SSL verify level as 2, it means you should upload CA
Cert, client Cert and client private key by AT+QFUPL command.
OK
AT+QSSLCFG=“cacert”,1,“RAM:cacert.pem”
OK
AT+QSSLCFG=“clientcert”,1,“RAM:clientcert.pem”
OK
AT+QSSLCFG=“clientkey”,1,“RAM:clientkey.pem”
OK
AT+QHTTPURL=45,80 //Set the URL which will be accessed.
CONNECT
HTTPs:// 220.180.239.201:8011/processorder.php //Input URL which length is 45, note that this URL is
an example, please input the correct URL in
practical test.
OK
AT+QHTTPPOSTFILE=“RAM:5.txt”,80 //Send HTTP POST request, POST body is obtained from
“RAM:5.txt”, and maximum response time is 80s.
OK
+QHTTPPOSTFILE: 0,200,285 //After HTTP POST request success, you can execute command
AT+QHTTPREAD.
AT+QHTTPREADFILE=“RAM:6.txt”,80 //Read HTTP response body and store it to “RAM:6.txt”, the
maximum time to wait for HTTP session to close is 80s.
OK
+QHTTPREADFILE: 0 //HTTP response body is stored successfully.
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 28 / 31
4 Summary of ERROR Code
Table 1: Different Coding Schemes of +CME ERROR : <err>
<err>
Meaning
0
Operation successful
701
HTTP unknown error
702
HTTP timeout
703
HTTP busy
704
HTTP UART busy
705
HTTP no get/post request
706
HTTP network busy
707
HTTP network open fail
708
HTTP network no config
709
HTTP network deactivated
710
HTTP network error
711
HTTP URL error
712
HTTP empty URL
713
HTTP IP address error
714
HTTP DNS error
715
HTTP socket create error
716
HTTP socket connect error
717
HTTP socket read error
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 29 / 31
718
HTTP socket write error
719
HTTP socket close
720
HTTP data encode error
721
HTTP data decode error
722
HTTP read timeout
723
HTTP response fail
724
Incoming call busy
725
Voice call busy
726
Input timeout
727
Wait data timeout
728
Wait HTTP response timeout
729
Alloc memory fail
730
Invalid parameter
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 30 / 31
5 Summary of HTTP Response Code
Table 2: Different Coding Schemes of HTTP Response Code
<httprspcode>
Meaning
200
OK
403
Forbidden
404
Not found
409
Conflict
411
Length required
500
Internal Server error
Quectel
Confidential
LTE Module Series
EC20 HTTP AT Commands Manual
EC20_HTTP_AT_Commands_Manual Confidential / Released 31 / 31
6 Appendix A Reference
Table 3: Related Documents
Table 4: Terms and Abbreviations
SN
Document Name
Remark
[1]
RFC2616
Hyper Text Transport Protocol
[2]
Quectel_EC20_TCPIP_AT_Commands_Manual
Introduction about EC20 TCPIP AT commands
[3]
Quectel_EC20_FILE_AT_Commands_Manual
Introduction about EC20 FILE AT commands
[4]
Quectel_EC20_AT_Commands_Manual
EC20 AT commands manual
[5]
Quectel_EC20_SSL_AT_Commands_Manual
Introduction about EC20 SSL AT commands
Abbreviation
Description
HTTP
Hyper Text Transport Protocol
SSL
Security Socket Layer
DTR
Data Terminal Ready
PPP
Point-to-Point Protocol
DNS
Domain Name Server
URL
Uniform Resource Locator
URI
Uniform Resource Identifier
Quectel
Confidential

Navigation menu
