EC2x&EG9x&EM05 SSL
AT Commands Manual
LTE Module Series
Rev. EC2x&EG9x&EM05_SSL_AT_Commands_Manual_V1.0
Date: 2017-11-22
Status: Released
www.quectel.com
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 1 / 29
Our aim is to provide customers with timely and comprehensive service. For any
assistance, please contact our company headquarters:
Quectel Wireless Solutions Co., Ltd.
7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China
Tel: +86 21 5108 6236
Email: info@quectel.com
Or our local office. For more information, please visit:
http://quectel.com/support/sales.htm
For technical support, or to report documentation errors, please visit:
http://quectel.com/support/technical.htm
Or email to: support@quectel.com
GENERAL NOTES
QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION
PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT
TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT
MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT
ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR
RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO
CHANGE WITHOUT PRIOR NOTICE.
COPYRIGHT
THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF
QUECTEL WIRELESS SOLUTIONS CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION
AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE
FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF
DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR
REGISTRATION OF A UTILITY MODEL OR DESIGN.
Copyright © Quectel Wireless Solutions Co., Ltd. 2017. All rights reserved.
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 2 / 29
About the Document
History
Revision
Date
Author
Description
1.0
2017-11-22
Duke XIN/
Jessica GENG
Initial
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 3 / 29
Contents
About the Document ................................................................................................................................... 2
Contents ....................................................................................................................................................... 3
Table Index ................................................................................................................................................... 5
1 Introduction .......................................................................................................................................... 6
1.1. SSL Version and Cipher Suite .................................................................................................... 6
1.2. The Process of Using SSL Function ........................................................................................... 8
1.3. Description of Data Access Modes ............................................................................................. 9
1.4. Validity Check for Certificate ..................................................................................................... 10
1.5. Server Name Indication ............................................................................................................ 10
2 Description of SSL AT Commands .................................................................................................. 11
2.1. Description of AT Commands ................................................................................................... 11
2.1.1. AT+QSSLCFG Configure Parameters of an SSL Context .......................................... 11
2.1.2. AT+QSSLOPEN Open an SSL Socket to Connect a Remote Server ........................ 15
2.1.3. AT+QSSLSEND Send Data via SSL Connection........................................................ 17
2.1.4. AT+QSSLRECV Receive Data via SSL Connection ................................................... 18
2.1.5. AT+QSSLCLOSE Close an SSL Connection .............................................................. 19
2.1.6. AT+QSSLSTATE Query the State of SSL Connection ................................................ 19
2.2. Description of URC ................................................................................................................... 20
2.2.1. Notify Received Data ..................................................................................................... 20
2.2.2. Notify Abnormal Close.................................................................................................... 21
3 Examples ............................................................................................................................................ 22
3.1. Configure and Activate a PDP Context ..................................................................................... 22
3.1.1. Configure a PDP Context ............................................................................................... 22
3.1.2. Activate a PDP Context .................................................................................................. 22
3.1.3. Deactivate a PDP Context ............................................................................................. 22
3.2. Configure an SSL Context ........................................................................................................ 22
3.3. SSL Client Works in Buffer Access Mode ................................................................................. 23
3.3.1. Set up an SSL Connection and Enter into Buffer Access Mode .................................... 23
3.3.2. Send Data in Buffer Access Mode ................................................................................. 23
3.3.3. Receive Data in Buffer Access Mode ............................................................................. 23
3.3.4. Close an SSL Connection .............................................................................................. 24
3.4. SSL Client Works in Direct Push Mode .................................................................................... 24
3.4.1. Set up an SSL Connection and Enter into Direct Push Mode ....................................... 24
3.4.2. Send Data in Direct Push Mode ..................................................................................... 24
3.4.3. Receive Data in Direct Push Mode ................................................................................ 24
3.4.4. Close an SSL Connection .............................................................................................. 24
3.5. SSL Client Works in Transparent Access Mode ....................................................................... 25
3.5.1. Set up an SSL Connection and Send Data in Transparent Access Mode..................... 25
3.5.2. Set up an SSL Connection and Receive Data in Transparent Access Mode ................ 25
3.5.3. Close an SSL Connection .............................................................................................. 25
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 4 / 29
4 Error Handling .................................................................................................................................... 26
4.1. Open SSL Connection Fails ...................................................................................................... 26
5 Summary of Error Codes .................................................................................................................. 27
6 Appendix A References ..................................................................................................................... 29
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 5 / 29
Table Index
TABLE 1: SSL VERSIONS .................................................................................................................................. 6
TABLE 2: SUPPORTED SSL CIPHER SUITES .................................................................................................. 7
TABLE 3: SUMMARY OF ERROR CODES ...................................................................................................... 27
TABLE 4: RELATED DOCUMENTS .................................................................................................................. 29
TABLE 5: TERMS AND ABBREVIATIONS ........................................................................................................ 29
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 6 / 29
1 Introduction
This document describes how to use the SSL functionality of Quectel EC2x&EG9x&EM05 modules. In
some cases, in order to ensure communication privacy, the communication between the server and the
client should be in an encrypted way so that it can prevent data from eavesdropping, tampering, or forging
during the communication process. The SSL function meets these demands.
This document is applicable to following Quectel modules.
- EC2x (including EC25, EC21, EC20 R2.0 and EC20 R2.1)
- EG9x (including EG91 and EG95)
- EM05
1.1. SSL Version and Cipher Suite
The following SSL versions are supported.
Table 1: SSL Versions
The following table shows SSL cipher suites supported by Quectel EC2x&EG9x&EM05 modules. For
detailed description of cipher suites, please refer to RFC 2246-The TLS Protocol Version 1.0.
SSL Versions
SSL3.0
TLS1.2
TLS1.1
TLS1.0
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 7 / 29
Table 2: Supported SSL Cipher Suites
Codes of Cipher Suites
0X0035
0X002F
0X0005
0X0004
0X000A
0X003D
0XC002
0XC003
0XC004
0XC005
0XC007
0XC008
0XC009
0XC00A
0XC011
0XC012
0XC013
0XC014
0xC00C
0XC00D
0XC00E
0XC00F
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 8 / 29
1.2. The Process of Using SSL Function
Step 1: Configure <APN>, <username>, <password> and other parameters of a PDP context by
AT+QICSGP. Please refer to Quectel_EC2x&EG9x&EM05_TCP(IP)_AT_Commands_Manual
for details.
Step 2: Activate the PDP context by AT+QIACT, then the assigned IP address can be queried by
AT+QIACT?. Please refer to Quectel_EC2x&EG9x&EM05_TCP(IP)_AT_Commands_Manual for
details.
Step 3: Configure the SSL version, cipher suite, path of trusted CA certificate and the security level for
the specified SSL context by AT+QSSLCFG.
Step 4: Open SSL client connection by AT+QSSLOPEN. <sslctxID> is used to specify SSL context, and
<access_mode> is used to specify data access mode.
Step 5: After the SSL connection has been established, data will be sent or received via the connection.
For details about how to send and receive data under each access mode, please refer to
Chapter 1.3.
Step 6: Close SSL connection by AT+QSSLCLOSE.
Step 7: Deactivate the PDP context by AT+QIDEACT.
0XC023
0xC024
0xC025
0xC026
0XC027
0XC028
0xC029
0XC02A
0XC02F
0XFFFF
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 9 / 29
1.3. Description of Data Access Modes
The SSL connection supports the following three kinds of data access modes:
- Buffer access mode
- Direct push mode
- Transparent access mode
When opening an SSL connection via AT+QSSLOPEN, the data access mode can be specified by the
parameter <access_mode>. After the SSL connection is established, customers can switch the access
mode via AT+QISWTMD.
1. In buffer access mode, data can be sent via AT+QSSLSEND command, and if the module has
received data from the Internet, it will report a URC as “+QSSLURC: “recv”,<clientID>”. Customers
can retrieve data via AT+QSSLRECV command.
2. In direct push mode, data can be sent via AT+QSSLSEND command, and if the module has received
data from the Internet, the data will be outputted directly via UART1/USB modem/USB AT port in the
following format: “+QSSLURC: “recv”,<clientID>,<currectrecvlength><CR><LF><data>”.
3. In transparent access mode, the corresponding port enters into exclusive mode. The data received
from COM port will be sent to the Internet directly, and the received data from Internet will be
outputted to COM port directly. Customers can use “+++” or DTR (AT&D1 should be set first) to
switch to buffer access mode. In transparent access mode, if SSL connection encounters any
abnormal disconnection, the module will report “NO CARRIER”.
4. To exit from transparent access mode, “+++” or DTR (AT&D1 should be set first) can be used. To
prevent the “+++” from being misinterpreted as data, the following sequence should be followed:
1) Do not input any character within 1s or longer before inputting “+++”.
2) Input “+++” within 1s, and no other characters can be inputted during the time.
3) Do not input any character within 1s after “+++” has been inputted.
4) Use “+++” or DTR (AT&D1 should be set first) to make the module exit from transparent access
mode, and wait until “OK” is returned.
5. There are two methods to return back to transparent access mode:
1) By AT+QISWTMD. Specify the <access_mode> as 2 when executing this command. If entering
into transparent access mode successfully, “CONNECT” will be returned.
2) By ATO. ATO will change the access mode of connection that exits from transparent access
mode lately. If entering transparent access mode successfully, “CONNECT” will be returned. If
there is no connection entering into transparent access mode before, ATO will return “NO
CARRIER”.
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 10 / 29
1.4. Validity Check for Certificate
To check whether a certificate is in the validity period, the certificate must be parsed, and compare the
local time with the “Not before” and “Not after” of the certificate. If the local time is earlier than the time of
“Not before” or later than the time of “Not after”, the certificate will be considered expired.
When validity check for certification is required (<ignoreltime> set as 0 when executing AT+QSSLCFG), in
order to avoid failure of certificate validity check, AT+CCLK command should be used to configure the
module time within the validity time period of the certificate.
1.5. Server Name Indication
SNI (Server Name Indication) is desirable for clients to provide Server Host Name information to facilitate
secure connections to servers that host multiple 'virtual' servers at a single underlying network address.
And this feature is only applicable for TLS protocol.
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 11 / 29
2 Description of SSL AT Commands
2.1. Description of AT Commands
2.1.1. AT+QSSLCFG Configure Parameters of an SSL Context
The command can be used to configure the SSL version, cipher suites, security level, CA certificate, client
certificate and client key. These parameters will be used in the handshake procedure.
<sslctxID> is the index of the SSL context. The module supports 6 SSL contexts at most. On the basis of
one SSL context, several SSL connections can be established. The settings such as the SSL version and
the cipher suite are stored in the SSL context, and they will be applied to the new SSL connections
associated with the SSL context.
AT+QSSLCFG Configure Parameters of an SSL Context
Test Command
AT+QSSLCFG=?
Response
+QSSLCFG: "sslversion",(0-5),(0-4)
+QSSLCFG:
"ciphersuite",(0-5),(0X0035,0X002F,0X0005,0X0004,0X00
0A,0X003D,0XC002,0XC003,0XC004,0XC005,0XC007,0X
C008,0XC009,0XC00A,0XC011,0XC012,0XC013,0XC014,
0XC00C,0XC00D,0XC00E,0XC00F,0XC023,0XC024,0XC0
25,0XC026,0XC027,0XC028,0XC029,0XC02A,0XC02F,0X
FFFF)
+QSSLCFG: "cacert",(0-5),<cacertpath>
+QSSLCFG: "clientcert",(0-5),<client_cert_path>
+QSSLCFG: "clientkey",(0-5),<client_key_path>
+QSSLCFG: "seclevel",(0-5),(0-2)
+QSSLCFG: "ignorelocaltime",(0-5),(0,1)
+QSSLCFG: "negotiatetime",(0-5),(10-300)
+QSSLCFG: "sni",(0-5),(0,1)
OK
Write Command
Configure the SSL version for the
specified SSL context:
AT+QSSLCFG="sslversion",<sslctxID
Response
If <sslversion> is omitted, query the SSL version for the
specified SSL context, and response:
+QSSLCFG: "sslversion",<sslctxID>,<sslversion>
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 12 / 29
>[,<sslversion>]
OK
If <sslversion> is not omitted, set the SSL version for the
specified SSL context, and response:
OK
Or
ERROR
Write Command
Configure the SSL cipher suites for the
specified SSL context:
AT+QSSLCFG="ciphersuite",<sslctxID
>[,<ciphersuites>]
Response
If <ciphersuites> is omitted, query the SSL cipher suites for
the specified SSL context, and response:
+QSSLCFG: "ciphersuite",<sslctxID>,<ciphersuites>
OK
If <ciphersuites> is not omitted, set the SSL cipher suite for
the specified SSL context, and response:
OK
Or
ERROR
Write Command
Configure the path of trusted CA
certificate for the specified SSL context:
AT+QSSLCFG="cacert",<sslctxID>[,<c
acertpath>]
Response
If <cacertpath> is omitted, query the path of trusted CA
certificate for the specified SSL context, and response:
+QSSLCFG: "cacert",<sslctxID>,<cacertpath>
OK
If <cacertpath> is not omitted, set the path of trusted CA
certificate for the specified SSL context, and response:
OK
Or
ERROR
Write Command
Configure the path of client certificate for
the specified SSL context:
AT+QSSLCFG="clientcert",<sslctxID>[
,<client_cert_path>]
Response
If <client_cert_path> is omitted, query the path of client
certificate for the specified SSL context, and response:
+QSSLCFG: "clientcert",<sslctxID>,<client_cert_path>
OK
If <client_cert_path> is not omitted, set the path of client
certificate for the specified SSL context, and response:
OK
Or
ERROR
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 13 / 29
Write Command
Configure the path of client private key for
the specified SSL context:
AT+QSSLCFG="clientkey",<sslctxID>[,
<client_key_path>]
Response
If <client_key_path> is omitted, query the path of client
private key for the specified SSL context , and response:
+QSSLCFG: "clientkey",<sslctxID>,<client_key_path>
OK
If <client_key_path> is not omitted, set the path of client
private key for the specified SSL context, and response:
OK
Or
ERROR
Write Command
Configure the authentication mode for the
specified SSL context:
AT+QSSLCFG="seclevel",<sslctxID>[,
<seclevel>]
Response
If <seclevel> is omitted, query the authentication mode for
the specified SSL context, and response:
+QSSLCFG: "seclevel",<sslctxID>,<seclevel>
OK
If <seclevel> is not omitted, set the authentication mode for
the specified SSL context, and response:
OK
Or
ERROR
Write Command
Configure whether to ignore validity
check for certification for the specified
SSL context:
AT+QSSLCFG="ignorelocaltime",<ssl
ctxID>[,<ignoreltime>]
Response
If <ignoreltime> is omitted, query whether the validity check
for certification is ignored for the specified SSL context , and
response:
+QSSLCFG: "ignorelocaltime",<sslctxID>,<ignoreltime>
OK
If <ignoreltime> is not omitted, set whether or not to ignore
certification validity check for the specified SSL context, and
response:
OK
Or
ERROR
Write Command
Configure the maximum timeout in SSL
negotiation stage for the specified SSL
context:
AT+QSSLCFG="negotiatetime",<sslct
xID>[,<negotiate_time>]
Response
If <negotiate_time> is omitted, query the maximum timeout
in SSL negotiation stage for the specified SSL context, and
response:
+QSSLCFG:
"negotiatetime",<sslctxID>,<negotiate_time>
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 14 / 29
Parameter
OK
If <negotiate_time> is not omitted, set the maximum timeout
in SSL negotiation stage for the specified SSL context, and
response:
OK
Or
ERROR
Write Command
Configure Server Name Indication feature
for the specified SSL context:
AT+QSSLCFG="sni",<sslctxID>[,<sni>
]
Response
If <sni> is omitted, query whether the Server Name
Indication feature is enabled for the specified SSL context,
and response:
+QSSLCFG: "sni",<sslctxID>,<sni>
OK
If <sni> is not omitted, disable/enable Server Name
Indication feature for the specified SSL context, and
response:
OK
Or
ERROR
<sslctxID> Numeric type. SSL context ID. The range is 0-5.
<sslversion> Numeric type. SSL Version.
0 SSL3.0
1 TLS1.0
2 TLS1.1
3 TLS1.2
4 All
<ciphersuites> Numeric type. SSL cipher suites.
0X0035 TLS_RSA_WITH_AES_256_CBC_SHA
0X002F TLS_RSA_WITH_AES_128_CBC_SHA
0X0005 TLS_RSA_WITH_RC4_128_SHA
0X0004 TLS_RSA_WITH_RC4_128_MD5
0X000A TLS_RSA_WITH_3DES_EDE_CBC_SHA
0X003D TLS_RSA_WITH_AES_256_CBC_SHA256
0XC002 TLS_ECDH_ECDSA_WITH_RC4_128_SHA
0XC003 TLS_ECDH_ECDSA_WITH_3DES_EDE_CBC_SHA
0XC004 TLS_ECDH_ECDSA_WITH_AES_128_CBC_SHA
0XC005 TLS_ECDH_ECDSA_WITH_AES_256_CBC_SHA
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 15 / 29
2.1.2. AT+QSSLOPEN Open an SSL Socket to Connect a Remote Server
The command is used to set up an SSL connection. During the negotiation between the module and the
Internet, parameters configured by AT+QSSLCFG will be used in the handshake procedure. After shaking
hands with the Internet successfully, the module can send or receive data via this SSL connection. Also
0XC007 TLS_ECDHE_ECDSA_WITH_RC4_128_SHA
0XC008 TLS_ECDHE_ECDSA_WITH_3DES_EDE_CBC_SHA
0XC009 TLS_ECDHE_ECDSA_WITH_AES_128_CBC_SHA
0XC00A TLS_ECDHE_ECDSA_WITH_AES_256_CBC_SHA
0XC011 TLS_ECDHE_RSA_WITH_RC4_128_SHA
0XC012 TLS_ECDHE_RSA_WITH_3DES_EDE_CBC_SHA
0XC013 TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA
0XC014 TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA
0xC00C TLS_ECDH_RSA_WITH_RC4_128_SHA
0XC00D TLS_ECDH_RSA_WITH_3DES_EDE_CBC_SHA
0XC00E TLS_ECDH_RSA_WITH_AES_128_CBC_SHA
0XC00F TLS_ECDH_RSA_WITH_AES_256_CBC_SHA
0XC023 TLS_ECDHE_ECDSA_WITH_AES_128_CBC_SHA256
0xC024 TLS_ECDHE_ECDSA_WITH_AES_256_CBC_SHA384
0xC025 TLS_ECDH_ECDSA_WITH_AES_128_CBC_SHA256
0xC026 TLS_ECDH_ECDSA_WITH_AES_256_CBC_SHA384
0XC027 TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256
0XC028 TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384
0xC029 TLS_ECDH_RSA_WITH_AES_128_CBC_SHA256
0XC02A TLS_ECDH_RSA_WITH_AES_256_CBC_SHA384
0XC02F TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256
0XFFFF Support all
<ignoreltime> Numeric format. How to deal with expired certificate.
0 Care about validity check for certification
1 Ignore validity check for certification
<cacertpath> String format. The path of the trusted CA certificate.
<client_cert_path> String format. The path of the client certificate.
<client_key_path> String format. The path of the client private key.
<seclevel> Numeric format. The authentication mode.
0 No authentication
1 Manage server authentication
2 Manage server and client authentication if requested by the remote
server
<negotiate_time> Numeric format. Indicates maximum timeout used in SSL negotiation stage.
Range: 10-300. The default value is 300. Unit: second.
<sni> Numeric format. Disable/enable Server Name Indication feature
0 Disable
1 Enable
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 16 / 29
the module can set up several SSL connections based on one SSL context.
According to steps mentioned in Chapter 1.2, before executing AT+QSSLOPEN, AT+QIACT command
should be executed first to activate the PDP context.
It is suggested to wait for a specific period of time (refer to the Maximum Response Time below) for
“+QSSLOPEN: <connectID>,<err>” URC to be outputted. If the URC response cannot be received during
the time, AT+QSSLCLOSE command can be used to close the SSL connection.
Parameter
AT+QSSLOPEN Open an SSL Socket to Connect a Remote Server
Test Command
AT+QSSLOPEN=?
Response
+QSSLOPEN:
(1-16),(0-5),(0-11),<serveraddr>,<server_port>[,(0-2)]
OK
Write Command
AT+QSSLOPEN=<pdpctxID>,<sslctxI
D>,<clientID>,<serveraddr>,<server_
port>[,<access_mode>]
Response
If the <access_mode> is transparent access mode and the
SSL connection is successfully set up, response:
CONNECT
If there is any error, response:
ERROR
Error description can be got via AT+QIGETERROR.
If the <access_mode> is buffer access mode or direct push
mode, response:
OK
+QSSLOPEN: <clientID>,<err>
<err> is 0 when SSL socket is opened successfully, otherwise
<err> is not 0.
If there is any error, response:
ERROR
Error description can be got via AT+QIGETERROR.
Maximum Response Time
Maximum network response time of 150s, plus configured
time of <negotiate_time>.
<pdpctxID> Numeric type. PDP context ID. The range is 1-16.
<sslctxID> Numeric type. SSL context ID. The range is 0-5.
<clientID> Numeric type. Socket index. The range is 0-11.
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 17 / 29
2.1.3. AT+QSSLSEND Send Data via SSL Connection
After the connection is established, the module can send data through the SSL connection.
<serveraddr> String type. The address of remote server.
<server_port> Numeric type. The listening port of remote server.
<access_mode> Numeric type. The access mode of SSL connection.
0 Buffer access mode
1 Direct push mode
2 Transparent mode
<err> Integer type. The error code of the operation. Please refer to Chapter 5.
AT+QSSLSEND Send Data via SSL Connection
Test Command
AT+QSSLSEND=?
Response
+QSSLSEND: (0-11)[,(1-1460)]
OK
Write Command
AT+QSSLSEND=<clientID>
After response “>”, input the data to be
sent. Tap CTRL+Z to send, and tap
ESC to cancel the operation.
Response
>
<input data>
<CTRL+Z>
If connection has been established and sending is successful,
response:
SEND OK
If connection has been established but sending buffer is full,
response:
SEND FAIL
If connection cannot be established, abnormally closed, or
the parameter is incorrect, response:
ERROR
Write Command
AT+QSSLSEND=<clientID>,<sendlen
>
After response “>”, input data until the
data length is equal to <sendlen>.
Response
>
<input data with specified length>
If connection has been established and sending is successful,
response:
SEND OK
If connection has been established but sending buffer is full,
response:
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 18 / 29
Parameter
2.1.4. AT+QSSLRECV Receive Data via SSL Connection
When an SSL connection is opened with <access_mode> specified as 0, the module will report URC as
“+QSSLURC: “recv”,<clientID>” when it receives data from the Internet. Customers can read the data
from buffer by AT+QSSLRECV command.
Parameter
SEND FAIL
If connection cannot be established, abnormally closed, or
the parameter is incorrect, response:
ERROR
<clientID> Numeric type. Socket index. The range is 0-11.
<sendlen> Numeric type. The length of sending data. The range is 1-1460. Unit: byte.
AT+QSSLRECV Receive Data via SSL Connection
Test Command
AT+QSSLRECV=?
Response
+QSSLRECV: (0-11),(1-1500)
OK
Write Command
AT+QSSLRECV=<clientID>,<readlen>
Response
If the specified connection has received data, response:
+QSSLRECV: <havereadlen><CR><LF><data>
OK
If the buffer is empty, response:
+QSSLRECV: 0
OK
If the parameters are incorrect or the connection cannot be
established, response:
ERROR
<clientID> Numeric type. Socket index. The range is 0-11.
<readlen> Numeric type. The length of data to be retrieved. The range is 1-1500. Unit: byte.
<havereadlen> Numeric type. The actual data length obtained by AT+QSSLRECV. Unit: byte.
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 19 / 29
2.1.5. AT+QSSLCLOSE Close an SSL Connection
The command is used to close an SSL connection. If all the SSL connections based on the same SSL
context are closed, the module will release the SSL context.
Parameter
2.1.6. AT+QSSLSTATE Query the State of SSL Connection
The command is used to query the socket connection status. It can only query the status of SSL
connection.
<data> The retrieved data.
AT+QSSLCLOSE Close an SSL Connection
Test Command
AT+QSSLCLOSE=?
Response
+QSSLCLOSE: (0-11)[,(0-65535)]
OK
Write Command
AT+QSSLCLOSE=<clientID>[,<close_
timeout>]
Response
If successfully closed, response:
OK
If failed to close, response:
ERROR
<clientID> Numeric type. Socket index. The range is 0-11.
<close_timeout> Numeric type. The timeout value of AT+QSSLCLOSE. The range is 0-65535, and
the default value is 10. Unit: second. 0 means close immediately.
AT+QSSLSTATE Query the State of SSL Connection
Test Command
AT+QSSLSTATE=?
Response
OK
Write Command
AT+QSSLSTATE=<clientID>
Response
+QSSLSTATE:
<clientID>,"SSLClient",<IP_address>,<remote_port>,<loc
al_port>,<socket_state>,<pdpctxID>,<serverID>,<access
_mode>,<AT_port>,<sslctxID>
OK
Execution Command
Response
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 20 / 29
Parameter
2.2. Description of URC
2.2.1. Notify Received Data
Notify received data which comes from peer.
AT+QSSLSTATE
List of
(+QSSLSTATE:
<clientID>,"SSLClient",<IP_address>,<remote_port>,<loc
al_port>,<socket_state>,<pdpctxID>,<serverID>,<access
_mode>,<AT_port>,<sslctxID>)
OK
<clientID> Numeric type. Socket index. The range is 0-11.
<IP_address> String type. The address of remote server.
<remote_port> Numeric type. The port of remote server.
<local_port> Numeric type. The local port.
<socket_state> Numeric type. The state of SSL connection.
0 “Initial” Connection has not been established
1 “Opening” Client is connecting
2 “Connected” Client connection has been established
4 “Closing” Connection is closing
<pdpctxID> Numeric type. PDP context ID. The range is 1-16.
<serverID> Numeric type. Reserved.
<access_mode> Numeric type. The access mode of SSL connection.
0 Buffer access mode
1 Direct push mode
2 Transparent access mode
<AT_port> String type. COM port.
<sslctxID> Numeric type. SSL context ID. The range is 0-5.
Notify Received Data
+QSSLURC: "recv",<clientID>
The URC of SSL data incoming in buffer access mode. SSL
data can be received by AT+QSSLRECV.
+QSSLURC:
"recv",<clientID>,<currentrecvlength>
<CR><LF><data>
The URC of SSL data incoming in direct push mode.
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 21 / 29
Parameter
2.2.2. Notify Abnormal Close
Notify that the connection has been disconnected. Lots of reasons can cause this phenomenon, such as
the Internet closes the connection or the state of GPRS PDP is deactivated. The SSL connection state
based on the specified socket will be “closing”. In such case, AT+QSSLCLOSE=<connectID> must be
executed to change the SSL connection state to “initial”.
Parameter
<clientID> Integer type. Socket index. The range is 0-11.
<currentrecvlength> Integer type. The length of actual received data.
<data> The received data.
Notify Abnormal Close
+QSSLURC: "closed",<clientID>
The SSL connection based on the specified socket is closed.
<clientID> Integer type. Socket index. The range is 0-11.
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 22 / 29
3 Examples
3.1. Configure and Activate a PDP Context
3.1.1. Configure a PDP Context
AT+QICSGP=1,1,"UNINET","","",1 //Configure context 1. APN is “UNINET” for China Unicom.
OK
3.1.2. Activate a PDP Context
AT+QIACT=1 //Activate context 1.
OK //Activated successfully.
AT+QIACT? //Query the state of context.
+QIACT: 1,1,1,"10.7.157.1"
OK
3.1.3. Deactivate a PDP Context
AT+QIDEACT=1 //Deactivate context 1.
OK //Deactivated successfully.
3.2. Configure an SSL Context
AT+QSSLCFG="sslversion",1,1
OK
AT+QSSLCFG="ciphersuite",1,0X0035
OK
AT+QSSLCFG="seclevel",1,1
OK
AT+QSSLCFG="cacert",1,"RAM:cacert.pem"
OK
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 23 / 29
3.3. SSL Client Works in Buffer Access Mode
3.3.1. Set up an SSL Connection and Enter into Buffer Access Mode
AT+QSSLOPEN=1,1,4,"220.180.239.212",8010,0
OK
+QSSLOPEN: 4,0 //Set up an SSL connection successfully.
AT+QSSLSTATE //Query the status of all SSL connections.
+QSSLSTATE: 4,"SSLClient","220.180.239.212",8010,65344,2,1,4,0,"usbmodem",1
OK
3.3.2. Send Data in Buffer Access Mode
AT+QSSLSEND=4 //Send changeable length data.
> Test data from SSL
<CTRL-Z>
SEND OK
AT+QSSLSEND=4,18 //Send fixed length data and the data length is 18 bytes.
> Test data from SSL
SEND OK
3.3.3. Receive Data in Buffer Access Mode
+QSSLURC: "recv",4 //The <clientID> 4 received data.
AT+QSSLRECV=4,1500 //Read data. The length of data to be retrieved is 1500 bytes.
+QSSLRECV: 18 //The actual received data length is 18 bytes.
Test data from SSL
OK
AT+QSSLRECV=4,1500
+QSSLRECV: 0 //No data in buffer.
OK
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 24 / 29
3.3.4. Close an SSL Connection
AT+QSSLCLOSE=4 //Close a connection whose <clientID> is 4. Depending on the
network, the maximum response time is 10s.
OK
3.4. SSL Client Works in Direct Push Mode
3.4.1. Set up an SSL Connection and Enter into Direct Push Mode
AT+QSSLOPEN= 1,1,4,"220.180.239.212",8011,1
OK
+QSSLOPEN: 4,0 //Set up SSL connection successfully.
AT+QSSLSTATE //Query the status of all SSL connections.
+QSSLSTATE: 4,"SSLClient","220.180.239.212",8011,65047,2,1,4,1,"usbmodem",1
OK
3.4.2. Send Data in Direct Push Mode
AT+QSSLSEND=4 //Send changeable length data.
>Test data from SSL
<CTRL-Z>
SEND OK
AT+QSSLSEND=4,18 //Send fixed length data and the data length is 18 bytes.
>Test data from SSL
SEND OK
3.4.3. Receive Data in Direct Push Mode
+QSSLURC: "recv",4,18
Test data from SSL
3.4.4. Close an SSL Connection
AT+QSSLCLOSE=4 //Close a connection whose <clientID> is 4. Depending on the
network, the maximum response time is 10s.
OK
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 25 / 29
3.5. SSL Client Works in Transparent Access Mode
3.5.1. Set up an SSL Connection and Send Data in Transparent Access Mode
AT+QSSLOPEN= 1,1,4,"220.180.239.212",8011,2 //Set up an SSL connection.
CONNECT //Enter into transparent access mode.
//Client is sending data from COM port to the Internet directly. (The data
is not visible in the example.)
OK //Use “+++” or DTR (AT&D1 should be set first) to exit from transparent
access mode. The “NO CARRIER” result code indicates that the
server has stopped the SSL connection.
3.5.2. Set up an SSL Connection and Receive Data in Transparent Access Mode
AT+QSSLOPEN= 1,1,4,"220.180.239.212",8011,2 //Set up an SSL connection.
CONNECT
<Received data> //Client is reading the data.
OK //Use “+++” or DTR (AT&D1 should be set first) to exit from transparent
access mode. The “NO CARRIER” result code indicates that the server
has stopped the SSL connection.
3.5.3. Close an SSL Connection
AT+QSSLCLOSE=4 //Close a connection whose <connectID> is 4. Depending on the network,
the maximum response time is 10s.
OK
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 26 / 29
4 Error Handling
4.1. Open SSL Connection Fails
If it is failed to open SSL connection, please check the following aspects:
1. Query the status of the specified PDP context: use AT+QIACT? command to check whether the
specified PDP context has been activated.
2. If the address of server is a domain name, please check whether the address of DNS server is valid
by AT+QIDNSCFG=<contextID>. Because an invalid DNS server address cannot convert domain
name to IP address.
3. Please check the SSL configuration by AT+QSSLCFG command, especially the SSL version and
cipher suite, so as to make sure they are supported on server side. If <seclevel> has been configured
as 1 or 2, customers must upload trusted CA certificate to the module by FILE AT command. If the
server side has configured “SSLVerifyClient required”, then the customer must upload the client
certificate and client private key to the module by FILE AT commands. For details about certificate
validity check, please refer to Chapter 1.4. And for more details about related FILE AT commands,
please refer to Quectel_EC2x&EG9x&EM05_FILE_AT_Commands_Manual.
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 27 / 29
5 Summary of Error Codes
If an “ERROR” is returned after executing SSL AT commands, the details of error can be queried by
AT+QIGETERROR. Please note that AT+QIGETERROR command just returns error code of the last SSL
AT command.
Table 3: Summary of Error Codes
<err>
0
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 28 / 29
565
566
567
568
569
570
571
572
573
574
LTE Module Series
EC2x&EG9x&EM05 SSL AT Commands Manual
EC2x&EG9x&EM05_SSL_AT_Commands_Manual 29 / 29
6 Appendix A References
Table 4: Related Documents
Table 5: Terms and Abbreviations
SN
Document Name
Remark
[1]
GSM 07.07
Digital cellular telecommunications (Phase 2+);
AT command set for GSM Mobile Equipment
(ME)
[2]
GSM 07.10
Support GSM 07.10 multiplexing protocol
[3]
Quectel_EC2x&EG9x&EM05_TCP(IP)_AT_
Commands_Manual
Introduction about EC2x&EG9x&EM05 TCP/IP
AT commands
[4]
Quectel_EC2x&EG9x&EM05_FILE_AT_
Commands_Manual
Introduction about EC2x&EG9x&EM05 FILE AT
commands
Abbreviation
Description
DNS
Domain Name Server
DTR
Data Terminal Ready
PDP
Packet Data Protocol
SSL
Security Socket Layer

Navigation menu
