GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 1 / 16
Our aim is to provide customers with timely and comprehensive service. For any
assistance, please contact our company headquarters:
Quectel Wireless Solutions Co., Ltd.
7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China
Tel: +86 21 5108 6236
Email: info@quectel.com
Or our local office. For more information, please visit:
http://quectel.com/support/sales.htm
For technical support, or to report documentation errors, please visit:
http://quectel.com/support/technical.htm
Or email to: support@quectel.com
GENERAL NOTES
QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION
PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT
TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT
MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT
ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR
RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO
CHANGE WITHOUT PRIOR NOTICE.
COPYRIGHT
THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF
QUECTEL WIRELESS SOLUTIONS CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION
AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE
FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF
DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR
REGISTRATION OF A UTILITY MODEL OR DESIGN.
Copyright © Quectel Wireless Solutions Co., Ltd. 2017. All rights reserved.
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 2 / 16
About the Document
History
Revision
Date
Author
Description
1.0
2009-01-04
Jay XIN
Initial
1.1
2012-06-04
Will SHAO
Added Command AT+QHTTPDL
1.2
2015-04-13
Will SHAO
Added applicable modules
1.3
2015-12-29
Jelly WANG
Modified the problem that some AT
commands are displayed incompletely.
1.4
2017-11-13
Sherlock ZHAO
Added command AT+QHTTPCFG
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 3 / 16
Contents
About the Document ................................................................................................................................ 2
Contents .................................................................................................................................................... 3
1 Introduction ....................................................................................................................................... 4
1.1. AT Command Syntax ............................................................................................................ 4
2 Description of HTTP AT Commands ............................................................................................... 5
2.1. AT+QHTTPURL Set URL of HTTP Server .......................................................................... 5
2.2. AT+QHTTPGET Send GET Request to HTTP Server ........................................................ 5
2.3. AT+QHTTPPOST Send POST Request to HTTP Server ................................................... 6
2.4. AT+QHTTPREAD Read Response from HTTP Server ...................................................... 7
2.5. AT+QHTTPDL Download a File from HTTP Server ............................................................ 8
2.6. AT+QHTTPCFG Configure Parameters for HTTP Service ................................................. 8
3 Examples ......................................................................................................................................... 10
3.1. Send GET Request to HTTP Server ................................................................................... 10
3.2. Send POST Request to HTTP Server ..................................................................................11
3.3. Download a File From HTTP Server ................................................................................... 12
3.4. Customize HTTP Header and Show HTTP Response Header ........................................... 12
4 Summary of ERROR Codes ............................................................................................................ 14
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 4 / 16
1 Introduction
Quectel module provides an internal TCP/IP stack that is driven by AT commands and enables the host
application to easily access the Internet services which include TCP service, UDP service, FTP service
and HTTP service, etc. This document is a reference guide to all the AT commands and responses
defined for HTTP service. The advantage of this solution is that it eliminates the need for the application
manufacturer to implement own HTTP protocol, thus minimizing cost and time to integrate Internet
connectivity into a new or existing host application.
This document is applicable to all Quectel GSM modules.
1.1. AT Command Syntax
Test Command
AT+<x>=?
This command returns the list of parameters and value ranges
set by the corresponding Write Command or internal processes.
Read Command
AT+<x>?
This command returns the currently set value of the parameter
or parameters.
Write Command
AT+<x>=<…>
This command sets the user-definable parameter values.
Execution
Command
AT+<x>
This command reads non-variable parameters affected by
internal processes in the GSM engine.
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 5 / 16
2 Description of HTTP AT Commands
2.1. AT+QHTTPURL Set URL of HTTP Server
Parameter
2.2. AT+QHTTPGET Send GET Request to HTTP Server
AT+QHTTPURL Set URL of HTTP Server
Test Command
AT+QHTTPURL=?
Response
+QHTTPURL: (1-2048),(1-65535)
OK
Write Command
AT+QHTTPURL=<url_len>[,<input_ti
me>]
Response
CONNECT
If there is an error related to ME functionality:
ERROR
+CME ERROR: <err>
Maximum Response Time
Determined by <input_time> (default 120s)
<url_len> Numeric type. The length of URL. The range is 1-2048. Unit: byte.
<input_time> Numeric type. The maximum time for inputting URL. The range is 1-65535, and the
default value is 120. Unit: second.
<err> Integer type. The error code of the operation. Please refer to Chapter 4.
AT+QHTTPGET Send GET Request to HTTP Server
Test Command
AT+QHTTPGET=?
Response
+QHTTPGET: (1-65535)[,(15-65535)[,(0-102400)]]
OK
Write Command
Response
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 6 / 16
Parameter
2.3. AT+QHTTPPOST Send POST Request to HTTP Server
AT+QHTTPGET=<to_read_time>[,<wa
it_time>[,<data_size>]]
OK
If there is an error related to ME functionality:
ERROR
+CME ERROR: <err>
Maximum Response Time
Determined by <wait_time> (default 120s)
<to_read_time> The maximum timeout waiting for reading data from server after sending HTTP
GET request to server successfully. AT+QHTTPREAD will be invalid if idle time
after AT+QHTTPGET is longer than the time of <to_read_time>. The range is
1-65535, and the default value is 120. Unit: second.
<wait_time> The time waiting for data from server after sending HTTP GET request to server
successfully. If there is no data coming from server within timeout value, an error
will be returned. The range is 15-65535, and the default value is 120. Unit:
second.
<data_size> Integer type. Indicates the data bytes to download from HTTP server. The range is
0-102400, and the default value is 0.
<err> Integer type. The error code of the operation. Please refer to Chapter 4.
AT+QHTTPPOST Send POST Request to HTTP Server
Test Command
AT+QHTTPPOST=?
Response
+QHTTPPOST: (1-29696),(1-65535),(1-65535)
OK
Write Command
AT+QHTTPPOST=<body_size>[,<inpu
t_time>[,<to_read_time>]]
Response
CONNECT
<data>
OK
If there is an error related to ME functionality:
ERROR
+CME ERROR: <err>
Maximum Response Time
120s
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 7 / 16
Parameter
2.4. AT+QHTTPREAD Read Response from HTTP Server
Parameter
<body_size> Size of the post body. The range is 1-29696. Unit: byte.
<input_time> Maximum time for inputting the data. The range is 1-65535, and the default value is
120.
<to_read_time> The maximum timeout waiting for reading data from server after sending HTTP POST
request to server successfully. AT+QHTTPREAD will be invalid if the idle time after
AT+QHTTPGET is longer than the time of <to_read_time>. The range is 1-65535,
and the default value is 120. Unit: second.
<data> The POST data to input from UART.
<err> Integer type. The error code of the operation. Please refer to Chapter 4.
AT+QHTTPREAD Read Response from HTTP Server
Test Command
AT+QHTTPREAD=?
Response
+QHTTPREAD: (1-65535)
OK
Write Command
AT+QHTTPREAD=<wait_time>
Response
CONNECT
<data>
OK
If there is an error related to ME functionality:
ERROR
+CME ERROR: <err>
Maximum Response Time
Determined by <wait_time> (default 120s)
<wait_time> The maximum waiting time for reading response from HTTP Server. HTTP session will
be closed when timeout. The range is 1-65535, and the default value is 120. Unit:
second.
<data> The data of HTTP server responds.
<err> Integer type. The error code of the operation. Please refer to Chapter 4.
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 8 / 16
2.5. AT+QHTTPDL Download a File from HTTP Server
Parameter
2.6. AT+QHTTPCFG Configure Parameters for HTTP Service
AT+QHTTPDL Download a File from HTTP Server
Test Command
AT+QHTTPDL=?
Response
+QHTTPDL: "filename"[,<length>[,(1-65535)]]
OK
Write Command
AT+QHTTPDL=“<filename>”[,<length
>[,<wait_time>]]
Response
OK
Finally, if the file is downloaded successfully, response:
+QHTTPDL: <dl size>,<content-length>,<errcode>
If there is an error related to ME functionality:
ERROR
+CME ERROR: <err>
Reference
Determined by <wait_time> (default 120s)
<filename> The path of the file to be stored, such as “RAM:1.txt”.
<length> The maximum size of the file to be downloaded. The default value is 10240. Unit:
byte. It is only used for RAM file.
<wait_time> The maximum waiting time for downloading a file from HTTP Server. HTTP
session will be closed when timeout. The range is 1-65535, and the default value
is 120. Unit: second.
<dl size> The length of the data downloaded.
<content-length> The content length. If the <content-length> is unknown, then set it to -1.
<errcode> If all data has been downloaded, the <errcode> is 0, else it is a numeric to
indicate the type of error. Please refer to Chapter 4.
<err> Integer type. The error code of the operation. Please refer to Chapter 4.
AT+QHTTPCFG Configure Parameters for HTTP Service
Test Command
AT+QHTTPCFG=?
Response
+QHTTPCFG: ("requestheader","responseheader"),(0,1)
OK
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 9 / 16
Parameter
Write Command
AT+QHTTPCFG="requestheader"[,<r
equestheader>]
Response
If <requestheader> is not omitted, response:
OK
or
+CME ERROR: <errorcode>
Else, query the current setting
+QHTTPCFG: "requestheader",<requestheader>
OK
Write Command
AT+QHTTPCFG="responseheader"[,<
responseheader>]
Response
If <responseheader> is not omitted, response:
OK
or
+CME ERROR: <errorcode>
Else, query the current setting
+QHTTPCFG: "responseheader",<responseheader>
OK
Reference
<requestheader> Numeric type. It indicates if customizing HTTP request header is allowed or not.
0 Disable the customization HTTP request header
1 Enable the customization HTTP request header
<responseheader> Numeric type. It indicates if outputting HTTP response header is allowed or not
0 Disable the output of HTTP response header
1 Enable the output of HTTP response header
<errorcode> Integer type. The error code of the operation. Please refer to Chapter 4.
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 10 / 16
3 Examples
3.1. Send GET Request to HTTP Server
AT+QIFGCNT=0
OK
AT+QICSGP=1,"CMNET" //Set APN
OK
AT+QIREGAPP //Optional
OK
AT+QIACT //Optional
OK
AT+QHTTPURL=79,30 //Set URL
CONNECT
<Input data>
//For example, input 79 bytes:
http://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo?Message=helloquectel.
OK
AT+QHTTPGET=60 //Send GET Request to HTTP server.
OK
AT+QHTTPREAD=30 //Read the response of HTTP server.
CONNECT
<Output data> //Output the response data of HTTP server to UART.
//For example, UART outputs:
<?xml version="1.0" encoding="utf-8"?>
<string xmlns="https://api.efxnow.com/webservices2.3">Message='helloquectel' ASCII:104 101 108 108
111 113 117 101 99 116 101 108 </string>.
OK
AT+QIDEACT //Deactivate PDP context.
DEACT OK
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 11 / 16
3.2. Send POST Request to HTTP Server
AT+QIFGCNT=0
OK
AT+QICSGP=1,"CMNET" //Set APN
OK
AT+QIREGAPP //Optional
OK
AT+QIACT //Optional
OK
AT+QHTTPURL=58,30 //Set URL
CONNECT
<Input data>
//For example, input 58 bytes:
http://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo
OK
//POST the data whose size is 18 bytes and the maximum latency time for inputting is 50s.
//It is recommended to set the latency time as long as enough to download all the data in the latency time.
AT+QHTTPPOST=18,50,10
CONNECT
//This means module enters into data mode and is ready to receive data from UART.
//For example, input 18 bytes: Message=helloworld.
OK
//This means all data has been received, and DCD is set to high.
AT+QHTTPREAD=30 //Read the response of HTTP server.
CONNECT
<Output data> //Output the response data of HTTP server to UART.
//For example, UART outputs:
<?xml version="1.0" encoding="utf-8"?>
<string xmlns="https://api.efxnow.com/webservices2.3">Message='helloworld' ASCII:104 101 108 108
111 119 111 114 108 100 </string>
OK
AT+QIDEACT //Deactivate PDP context.
DEACT OK
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 12 / 16
3.3. Download a File From HTTP Server
AT+QIFGCNT=0
OK
AT+QICSGP=1,"CMNET" //Set APN
OK
AT+QIREGAPP //Optional
OK
AT+QIACT //Optional
OK
AT+QHTTPURL=36,30 //Set URL
CONNECT
<Input data>
//for example, input 36 bytes:
http://220.180.239.212:8005/100K.txt
OK
AT+QHTTPGET=60 //Send GET Request to HTTP server.
OK
AT+QHTTPDL="RAM:1.TXT",1024
//Download the file to RAM:1.TXT, and the maximum size of the file is 1024 bytes.
+QHTTPDL: 1024,102400,401
OK
3.4. Customize HTTP Header and Show HTTP Response Header
AT+QHTTPCFG="requestheader",1
OK
AT+QHTTPCFG ="responseheader",1
OK
AT+QHTTPURL=58
CONNECT
//Input URL "http://api.efxnow.com/DEMOWebServices2.8/Service.asmx/Echo".
OK
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 13 / 16
AT+QHTTPPOST=229
CONNECT
//Input customers’ own header like below:
POST /DEMOWebServices2.8/Service.asmx/Echo HTTP/1.1
Host: api.efxnow.com
Accept: */*
User-Agent: QUECTEL_MODULE
Connection: Keep-Alive
Content-Type: application/x-www-form-urlencoded
Content-Length: 18
Message=helloworld
OK
AT+QHTTPREAD=30
CONNECT
//The data returned from server is as below:
HTTP/1.1 200 OK
Cache-Control: private, max-age=0
Content-Type: text/xml; charset=utf-8
Server: Microsoft-IIS/7.0
X-AspNet-Version: 2.0.50727
X-Powered-By: ASP.NET
Date: Sat, 17 Aug 2013 05:06:23 GMT
Content-Length: 170
<?xml version="1.0" encoding="utf-8"?>
<string xmlns="https://api.efxnow.com/webservices2.3">Message='helloworld' ASCII:104 101 108
108 111 119 111 114 108 100 </string>
OK
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 14 / 16
4 Summary of ERROR Codes
The error code <err> indicates an error related to mobile equipment or network. The details about <err>
are described in the following table.
Table 1: Summary of Error Codes
<err>
Meaning
3801
HTTP timeout
3802
HTTP busy
3803
HTTP UART busy
3804
HTTP get no request
3805
HTTP network busy
3806
HTTP network open failed
3807
HTTP network no configuration
3808
HTTP network deactivated
3809
HTTP network error
3810
HTTP URL error
3811
HTTP empty URL
3812
HTTP IP address error
3813
HTTP DNS error
3814
HTTP socket create error
3815
HTTP socket connect error
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 15 / 16
3816
HTTP socket read error
3817
HTTP socket write error
3818
HTTP socket closed
3819
HTTP data encode error
3820
HTTP data decode error
3821
HTTP read timeout
3822
HTTP response failed
3823
Incoming call busy
3824
Voice call busy
3825
Input timeout
3826
Wait data timeout
3827
Wait HTTP response timeout
3828
Memory allocation failed
3829
HTTP need relocation
3830
Queclocator location failed
4000
Exceed max length
4001
Open file failed
4002
Write file failed
4003
Get size failed
4004
Read failed
4005
List file failed
4006
Delete file failed
4007
Get Disk info failed
GSM/GPRS Module Series
GSM HTTP AT Commands Manual
GSM_HTTP_AT_Commands_Manual 16 / 16
4008
No space
4009
Timeout
4010
File not found
4011
File too large
4012
File already exist
4013
Invalid parameter
4014
Driver error
4015
Create failed
4016
Access denied
4017
File too large
