MC60 Series GNSS
AT Commands Manual
GSM/GPRS/GNSS Module Series
Rev. MC60_Series_GNSS_AT_Commands_Manual_V1.3
Date: 2017-08-03
www.quectel.com
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 1 / 21
Our aim is to provide customers with timely and comprehensive service. For any
assistance, please contact our company headquarters:
Quectel Wireless Solutions Co., Ltd.
7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China
Tel: +86 21 5108 6236
Email: info@quectel.com
Or our local office. For more information, please visit:
http://quectel.com/support/sales.htm
For technical support, or to report documentation errors, please visit:
http://quectel.com/support/technical.htm
Or email to: support@quectel.com
GENERAL NOTES
QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION
PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT
TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT
MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT
ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR
RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO
CHANGE WITHOUT PRIOR NOTICE.
COPYRIGHT
THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF
QUECTEL CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION AND EDITING OF THIS
DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE FORBIDDEN WITHOUT
PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS
ARE RESERVED IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL
OR DESIGN.
Copyright © Quectel Wireless Solutions Co., Ltd. 2017. All rights reserved.
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 2 / 21
About the Document
History
Revision
Date
Author
Description
1.0
2016-06-24
Hyman DING
Initial
1.1
2016-07-30
Hyman DING
Added the following new AT commands:
AT+QGNSSTS/AT+QGNSSEPO/
AT+QGREFLOC/AT+QGEPOAID
1.2
2016-11-11
Hyman DING
Added new AT command: AT+QGEPOF
1.3
2017-08-03
Matt YE
Modified the description and example of
AT+QGEPOF
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 3 / 21
Contents
About the Document ................................................................................................................................ 2
Contents .................................................................................................................................................... 3
Table Index ............................................................................................................................................... 4
1 Introduction ....................................................................................................................................... 5
2 AT Commands for MC60 Series GNSS ............................................................................................ 6
2.1. Overview of AT Commands for MC60 Series GNSS ................................................................ 6
2.1.1. AT+QGNSSC Control Power Supply of GNSS Module ............................................... 6
2.1.2. AT+QGNSSRD Read GNSS Navigation Information .................................................. 7
2.1.3. AT+QGNSSCMD Send Commands to GNSS Module ................................................ 8
2.1.4. AT+QGNSSTS Get Time Synchronization Status for GNSS Module .......................... 8
2.1.5. AT+QGNSSEPO Enable/Disable EPOTM Function ..................................................... 9
2.1.6. AT+QGREFLOC Set Reference Location Information for QuecFastFix Online ......... 10
2.1.7. AT+QGEPOAID Trigger EPOTM Function ...................................................................11
2.1.8. AT+QGEPOF EPOTM File Operation ..........................................................................11
3 Examples ......................................................................................................................................... 14
3.1. AT+QGNSSC ......................................................................................................................... 14
3.2. AT+QGNSSRD ....................................................................................................................... 14
3.3. AT+QGNSSCMD .................................................................................................................... 15
3.4. AT+QGNSSTS ....................................................................................................................... 15
3.5. AT+QGNSSEPO .................................................................................................................... 15
3.6. AT+QGREFLOC ..................................................................................................................... 16
3.7. AT+QGEPOAID ...................................................................................................................... 16
3.8. AT+QGEPOF .......................................................................................................................... 17
3.9. Complete Example for QuecFastFix Online ........................................................................... 17
4 Appendix A References .................................................................................................................. 20
4.1. Related Documents ................................................................................................................ 20
4.2. Terms and Abbreviations ........................................................................................................ 20
4.3. Summary of CME ERROR Codes Related to GNSS.............................................................. 21
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 4 / 21
Table Index
TABLE 1: OVERVIEW OF AT COMMANDS FOR MC60 SERIES GNSS ........................................................... 6
TABLE 2: RELATED DOCUMENTS .................................................................................................................. 20
TABLE 3: TERMS AND ABBREVIATIONS ........................................................................................................ 20
TABLE 4: DIFFERENT CODING SCHEMES OF +CME ERROR RELATED TO GNSS: <ERR> .................... 21
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 5 / 21
1 Introduction
GNSS, a featured function embedded in Quectel MC60 series module, can help customers get the
current accurate coordinates, high precision time, etc.
MC60 series integrates both GNSS and GSM engines which can work as a whole (All-in-one solution)
unit or work independently (Stand-alone solution) according to customer demands. In All-in-one solution,
the internal GNSS module can be regarded as a peripheral of the whole unit, and is completely controlled
by the GSM module, including power supply, UART communication, etc. In Stand-alone solution, the
internal GNSS module and the GSM module work independently, and the GNSS has to be controlled
separately.
MC60 series module currently includes two variants:
-OC: MC60CA-04-STD (supports BT3.0)
-OC: MC60ECA-04-BLE (supports BT4.0)
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 6 / 21
2 AT Commands for MC60 Series GNSS
2.1. Overview of AT Commands for MC60 Series GNSS
The commands below are effective only in All-in-one solution.
Table 1: Overview of AT Commands for MC60 Series GNSS
2.1.1. AT+QGNSSC Control Power Supply of GNSS Module
The command is used to control the power supply of GNSS module.
Command
Description
AT+QGNSSC
Control power supply of GNSS module
AT+QGNSSRD
Read GNSS navigation information
AT+QGNSSCMD
Send commands to GNSS module
AT+QGNSSETS
Get time synchronization status for GNSS module
AT+QGNSSEPO
Enable/Disable EPOTM function
AT+QGREFLOC
Set reference location information for QuecFastFix Online
AT+QGEPOAID
Trigger EPOTM function
AT+QGEPOF
EPOTM file operation
Test Command
AT+QGNSSC=?
Response
+QGNSSC: (list of supported <mode>s)
OK
Read Command
AT+QGNSSC?
Response
+QGNSSC: <mode>
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 7 / 21
Parameter
In Stand-alone solution, the power supply of GNSS is controlled by an external circuit rather than the PIN
GNSS_VCC_EN. In such case, command AT+QGNSSC cannot be used and thus can be ignored.
2.1.2. AT+QGNSSRD Read GNSS Navigation Information
The command is used to get the GNSS navigation information.
Parameter
OK
Write Command
AT+QGNSSC=<mode>
Response
OK
If there is an error related to ME functionality:
+CME ERROR: <err>
Test Command
AT+QGNSSRD=?
Response
+QGNSSRD: (list of supported <item>s)
OK
Read Command
AT+QGNSSRD?
Response
+QGNSSRD: (information of all supported <item>s)
OK
Write Command
AT+QGNSSRD=<item>
Response
+QGNSSRD: (information of <item>s)
OK
If there is an error related to ME functionality:
+CME ERROR: <err>
NOTE
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 8 / 21
2.1.3. AT+QGNSSCMD Send Commands to GNSS Module
The command is used to send commands to GNSS module, which allows customers to optionally use
some functions to meet application demands.
Parameter
Currently only <cmdType>=0 is supported.
2.1.4. AT+QGNSSTS Get Time Synchronization Status for GNSS Module
The command is used to get time synchronization status for GNSS module. Time plays a very important
role in EPOTM function.
Test Command
AT+QGNSSCMD=?
Response
+QGNSSCMD: (0,1),“cmdString”
OK
Write Command
AT+QGNSSCMD=<cmdType
>,<cmdString>
Response
OK
If there is an error related to ME functionality:
+CME ERROR: <err>
Test Command
AT+QGNSSTS=?
Response
+QGNSSTS: <status>
OK
NOTE
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 9 / 21
Parameter
Exact time is very important to EPOTM function. So customers must ensure the time is valid before using
EPOTM function.
2.1.5. AT+QGNSSEPO Enable/Disable EPOTM Function
The command is used to enable or disable EPOTM function.
Parameter
Read Command
AT+QGNSSTS?
Response
+QGNSSTS: <status>
OK
Test Command
AT+QGNSSEPO=?
Response
+QGNSSEPO: (list of supported <mode>s)[,<account_id>]
OK
Read Command
AT+QGNSSEPO?
Response
+QGNSSEPO: <mode>,<account_id>
OK
Write Command
AT+QGNSSEPO=<mode>[,<
account_id>]
Response
OK
If there is an error related to ME functionality:
+CME ERROR: <err>
NOTE
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 10 / 21
1. The parameter <account_id> only supports 2. It can be omitted and 2 will be its default value when it
is omitted.
2. The EPOTM function should be enabled after the time is synchronized successfully.
2.1.6. AT+QGREFLOC Set Reference Location Information for QuecFastFix Online
The command is used to set reference location information for QuecFastFix Online function.
Parameter
1. The range of <ref_latitude> is -90°~90° North Latitude, and the range of <ref_longitude> is
-180°~180° East Longitude. The input format of the parameter should retain 6 decimal places, and the
unit is degree.
2. The command works for QuecFastFix Online function and should be set before executing
AT+QGNSSEPO=1.
Test Command
AT+QGREFLOC=?
Response
+QGREFLOC: <ref_latitude>,<ref_longitude>
OK
Read Command
AT+QGREFLOC?
Response
+QGREFLOC: <ref_latitude>,<ref_longitude>
OK
Write Command
AT+QGREFLOC=<ref_latitud
e>,<ref_longitude>
Response
OK
If there is an error related to ME functionality:
+CME ERROR: <err>
NOTES
NOTES
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 11 / 21
2.1.7. AT+QGEPOAID Trigger EPOTM Function
The command is used to trigger EPOTM function.
1. If GNSS is powered on already, customers could use this command to trigger EPOTM function after
executing AT+QGNSSEPO=1.
2. If execute AT+QGNSSEPO=1 first and then power on GNSS, executing this command will not trigger
EPOTM function.
2.1.8. AT+QGEPOF EPOTM File Operation
The command is used to operate EPOTM related files, including deleting related files, getting file size and
querying validity period of EPOTM files.
Test Command
AT+QGEPOAID=?
Response
OK
Execution Command
AT+QEPOAID
Response
OK
If there is an error related to ME functionality:
+CME ERROR: <err>
Test Command
AT+QGEPOF=?
Response
+QGEPOF: (list of supported <mode>s), (list of supported <index>s)
OK
Write Command
AT+QGEPOF=<mode>,<inde
x>
Response
If <mode> is 0, response:
+QGEPOF: <size_a>,<size_b>,<size_c>
OK
If <mode> is 1, response:
OK
If <mode> is 2, response:
+QGEPOF: <time>
OK
NOTES
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 12 / 21
Parameter
If there is an error related to ME functionality:
+CME ERROR: <err>
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 13 / 21
1. If the EPOTM files are deleted, there is a need to trigger EPOTM function again. For more details,
please refer to Quectel_MC60_GNSS_AGPS_Application_Note.
2. If <mode> is 2, <index> can be omitted.
3. Commands AT+QGEPOF=1,1, AT+QGEPOF=1,2 and AT+QGEPOF=1,3 are only for testing
purpose. Please use AT+QGEPOF=1,255 in the real application.
NOTES
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 14 / 21
3 Examples
3.1. AT+QGNSSC
AT+QGNSSC? //Query GNSS power status.
+QGNSSC: 0 //GNSS is powered off.
OK
AT+QGNSSC=1 //Power on GNSS.
OK
3.2. AT+QGNSSRD
AT+QGNSSRD? //Inquire GNSS NMEA sentence.
+QGNSSRD: $GNRMC,034035.000,A,3150.8617,N,11711.9038,E,3.02,183.45,240516,,,A*75
$GNVTG,183.45,T,,M,3.02,N,5.59,K,A*20
$GNGGA,034035.000,3150.8617,N,11711.9038,E,1,4,1.50,40.9,M,0.0,M,,*44
$GPGSA,A,3,26,21,,,,,,,,,,,1.75,1.50,0.91*0A
$GLGSA,A,3,82,70,,,,,,,,,,,1.75,1.50,0.91*1C
$GPGSV,3,1,12,16,67,308,,26,58,021,16,23,40,307,,31,40,088,*7F
$GPGSV,3,2,12,08,17,199,,09,14,320,,21,10,086,14,14,10,153,*73
$GPGSV,3,3,12,22,09,226,,193,06,165,,32,03,154,,29,01,034,*45
$GLGSV,3,1,09,81,44,073,,79,40,041,,82,38,145,15,80,36,323,*66
$GLGSV,3,2,09,70,30,290,16,69,26,225,,78,12,078,,88,09,027,*64
$GLGSV,3,3,09,71,05,334,*5B
$GNGLL,3150.8617,N,11711.9038,E,034035.000,A,A*4C
OK
AT+QGNSSRD=”NMEA/RMC” //Inquire RMC information.
+QGNSSRD: $GNRMC,034036.000,A,3150.8612,N,11711.9045,E,2.74,178.00,240516,,,A*7C
OK
AT+QGNSSRD=”NMEA/GSA” //Inquire GSA information.
+QGNSSRD: $GPGSA,A,3,26,21,,,,,,,,,,,1.76,1.50,0.91*09
$GLGSA,A,3,82,70,,,,,,,,,,,1.75,1.50,0.91*1C
OK
AT+QGNSSRD? //Inquire GNSS NMEA sentence.
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 15 / 21
+QGNSSRD: $GNRMC,034039.000,A,3150.8596,N,11711.9049,E,2.13,194.12,240516,,,A*70
$GNVTG,194.12,T,,M,2.13,N,3.95,K,A*23
$GNGGA,034039.000,3150.8596,N,11711.9049,E,1,5,1.50,38.7,M,0.0,M,,*44
$GPGSA,A,3,22,26,21,,,,,,,,,,1.75,1.50,0.91*0A
$GLGSA,A,3,82,70,,,,,,,,,,,1.75,1.50,0.91*1C
$GPGSV,3,1,12,16,67,308,,26,58,021,17,23,40,307,,31,40,088,*7E
$GPGSV,3,2,12,08,17,199,,09,14,320,,21,10,086,12,14,10,153,*75
$GPGSV,3,3,12,22,09,226,16,193,06,165,,32,03,154,,29,01,034,*42
$GLGSV,3,1,09,81,44,073,,79,40,041,,82,38,145,16,80,36,323,*65
$GLGSV,3,2,09,70,30,290,16,69,26,225,,78,12,078,,88,09,027,*64
$GLGSV,3,3,09,71,05,334,*5B
$GNGLL,3150.8596,N,11711.9049,E,034039.000,A,A*4C
OK
3.3. AT+QGNSSCMD
AT+QGNSSCMD=0,"$PMTK605*31" //Inquire GNSS version information.
OK
+QGNSSCMD: $PMTK705,AXN_3.82_3333_16051101,0001,MC60-GNSS,1.0*2A
3.4. AT+QGNSSTS
AT+QGNSSTS=? //Test command
+QGNSSTS: (0,1)
OK
AT+QGNSSTS? //Read time synchronization mode and status.
+QGNSSTS: 1 //Time is synchronized successfully.
OK
3.5. AT+QGNSSEPO
AT+QGNSSEPO=? //Test command
+QGNSSEPO: (0,1)[,<account_id>]
OK
AT+CREG?;+CGREG? //Check network status.
+CREG: 0,1
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 16 / 21
+CGREG: 0,1
OK
AT+QGNSSEPO=1 //Enable EPOTM function.
OK
AT+QGNSSEPO? //Read EPOTM status.
+QGNSSEPO: 1,2
OK
3.6. AT+QGREFLOC
AT+QGREGLOC=? //Test command
+QGREFLOC: <ref_latitude>,<ref_longitude>
OK
AT+QGREFLOC=31.507985,117.119750
OK
3.7. AT+QGEPOAID
AT+QGNSSC=1 //Power on GNSS.
OK
AT+CREG?;+CGREG? //Check network status.
+CREG: 0,1
+CGREG: 0,1
OK
AT+QGNSSTS? //Inquire time synchronization status.
+QGNSSTS: 1
OK
AT+QGNSSEPO=1
OK
AT+QGEPOAID
OK
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 17 / 21
3.8. AT+QGEPOF
AT+QGEPOF=? //Test command
+QGEPOF: (0-2),(1-3,255)
OK
AT+QGEPOF=0,255 //Get EPOTM file size.
+QGEPOF: -9,48384,48384
OK
AT+QGEPOF=2 //Query validity period of EPOTM files.
+QGEPOF: 2017-02-19 00:00:00
OK
AT+QGEPOF=1,255 //Delete all EPOTM files.
OK
AT+QGEPOF=0,255
+QGEPOF: -9,-9,-9
OK
AT+QGEPOF=2
+QGEPOF: -9
OK
3.9. Complete Example for QuecFastFix Online
AT+QGNSSC=1 //Power on GNSS.
OK
AT+QIFGCNT=2
OK
AT+QICSGP=1,”CMNET”
OK
AT+QGNSSTS? //Read time synchronization status.
+QGNSSTS: 0
OK
AT+CREG?;+CGREG? //Check network status.
+CREG: 0,2
+CGREG: 0,2
OK
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 18 / 21
AT+CREG?;+CGREG? //Check network status.
+CREG: 0,1
+CGREG: 0,1
OK
AT+QGNSSTS? //Read time synchronization status.
+QGNSSTS: 1 //Time synchronization completed.
OK
AT+QGREFLOC=31.507985,117.119750 //Set reference location information for QuecFastFix Online.
OK
AT+QGNSSEPO=1 //Enable EPOTM function.
OK
AT+QGEPOAID //Trigger EPOTM function.
OK
AT+QGNSSRD?
+QGNSSRD: $GNRMC,125349.093,V,,,,,0.00,0.00,010716,,,N*50
$GNVTG,0.00,T,,M,0.00,N,0.00,K,N*2C
$GNGGA,125349.093,,,,,0,0,,,M,,M,,*54
$GPGSA,A,1,,,,,,,,,,,,,,,*1E
$GLGSA,A,1,,,,,,,,,,,,,,,*02
$GPGSV,1,1,02,09,,,29,06,,,29*74
$GLGSV,1,1,00*65
$GNGLL,,,,,125349.093,V,N*66
OK
AT+QGNSSRD?
+QGNSSRD: $GNRMC,125350.093,V,,,,,0.00,0.00,010716,,,N*58
$GNVTG,0.00,T,,M,0.00,N,0.00,K,N*2C
$GNGGA,125350.093,,,,,0,0,,,M,,M,,*5C
$GPGSA,A,1,,,,,,,,,,,,,,,*1E
$GLGSA,A,1,,,,,,,,,,,,,,,*02
$GPGSV,1,1,02,09,,,29,06,,,29*74
$GLGSV,1,1,00*65
$GNGLL,,,,,125350.093,V,N*6E
OK
…...
AT+QGNSSRD?
+QGNSSRD: $GNRMC,125353.092,A,3150.8278,N,11711.9888,E,0.31,111.02,010716,,,A*7C
$GNVTG,111.02,T,,M,0.31,N,0.58,K,A*2F
$GNGGA,125353.092,3150.8278,N,11711.9888,E,1,5,1.63,145.5,M,0.0,M,,*7A
$GPGSA,A,3,06,09,07,02,12,,,,,,,,1.83,1.63,0.83*0E
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 19 / 21
$GLGSA,A,3,,,,,,,,,,,,,1.83,1.63,0.83*1B
$GPGSV,4,1,15,02,68,022,28,05,61,286,,06,37,091,32,13,31,181,*73
$GPGSV,4,2,15,19,25,155,,29,24,318,,20,18,257,,12,17,243,25*7E
$GPGSV,4,3,15,25,13,278,,09,11,039,31,07,06,081,26,15,06,205,*7A
$GPGSV,4,4,15,30,05,107,,17,01,151,,193,,,*44
$GLGSV,1,1,04,85,77,105,,86,41,334,,84,26,139,,72,12,227,*65
$GNGLL,3150.8278,N,11711.9888,E,125353.092,A,A*4B
OK
AT+QGNSSRD?
+QGNSSRD: $GNRMC,125354.092,A,3150.8278,N,11711.9888,E,0.31,111.02,010716,,,A*7B
$GNVTG,111.02,T,,M,0.31,N,0.58,K,A*2F
$GNGGA,125354.092,3150.8278,N,11711.9888,E,1,5,1.63,145.5,M,0.0,M,,*7D
$GPGSA,A,3,06,09,07,02,12,,,,,,,,1.83,1.63,0.83*0E
$GLGSA,A,3,,,,,,,,,,,,,1.83,1.63,0.83*1B
$GPGSV,4,1,15,02,68,022,28,05,61,286,,06,37,091,32,13,31,181,*73
$GPGSV,4,2,15,19,25,155,,29,24,318,,20,18,257,,12,17,243,25*7E
$GPGSV,4,3,15,25,13,278,,09,11,039,31,07,06,081,26,15,06,205,*7A
$GPGSV,4,4,15,30,05,107,,17,01,151,,193,,,*44
$GLGSV,1,1,04,85,77,105,,86,41,334,,84,26,139,,72,12,227,*65
$GNGLL,3150.8278,N,11711.9888,E,125354.092,A,A*4C
OK
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 20 / 21
4 Appendix A References
4.1. Related Documents
Table 2: Related Documents
SN
Document Name
Remark
[1]
NMEA 0183 Version 3.01
Standard for Interfacing Marine Electronic
Devices
[2]
Quectel_MC60_Series_Hardware_Design
MC60 series hardware design
[3]
Quectel_MC60_GNSS_AGPS_Application_Note
MC60 GNSS AGPS application note
4.2. Terms and Abbreviations
Table 3: Terms and Abbreviations
Abbreviation
Description
GGA
Global Positioning System Fixed Data
GLL
Geographic Latitude and Longitude
GNSS
Global Navigation Satellite System
GSA
GNSS DOP and Active Satellites
GSM
Global System for Mobile Communication
GSV
GNSS Satellites in View
ID
Identification
GSM/GPRS/GNSS Module Series
MC60 Series GNSS AT Commands Manual
MC60_Series_GNSS_AT_Commands_Manual Confidential / Released 21 / 21
4.3. Summary of CME ERROR Codes Related to GNSS
Table 4: Different Coding Schemes of +CME ERROR Related to GNSS: <err>
ME
Mobile Equipment
NMEA
National Marine Electronics Association
RMC
Recommended Minimum Specific GNSS Data
UART
Universal Asynchronous Receiver & Transmitter
UTC
Coordinated Universal Time
VTG
Course Over Ground and Ground Speed
Code of <err>
Meaning
7101
Invalid parameter
7102
Not supported
7103
Operation failed

Navigation menu
