RPM Installation Guide
Version 1.5
Revision History
Revision Description of Change Date
v1.0 Initial Release 2/2016
v1.1 Updated for OpenCPI Release 1.1 3/2017
v1.2 Updated for OpenCPI Release 1.2 8/2017
v1.3 Updated for OpenCPI Release 1.3 2/2018
v1.3.1 Updated for OpenCPI Release 1.3.1 4/2018
v1.4 Updated for OpenCPI Release 1.4 9/2018
v1.5 Updated for OpenCPI Release 1.5 4/2019
1
RPM Installation Guide ANGRYVIPER Team
Table of Contents
1 References 3
2 Document Overview 4
3 Installation Process 4
3.1 Background Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1.1 Description of Available RPMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.2 Installation File Host Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3 Acquiring and Installing OpenCPI from Physical Media . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3.1 Install.................................................. 6
3.3.2 LogOut................................................. 6
3.4 Acquiring and Installing OpenCPI from github.io . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.4.1 Configure Yum Repository . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.4.2 Install External Dependencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.4.3 List Available Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.4.4 Install OpenCPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.4.5 Install ANGRYVIPER IDE (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.4.6 LogOut................................................. 8
4 Post-Installation Tasks 8
4.1 Installing HDL Simulator(s) and/or Compiler(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.2 Using the opencpi Group ........................................... 8
4.3 Shell Environment Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 RPM Uninstallation Process 9
6 Testing the Installation 10
List of Tables
1 References.................................................... 3
2 RPM Decision Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 RPM Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2
RPM Installation Guide ANGRYVIPER Team
1 References
This document assumes a basic understanding of the Linux command line environment. It does not require a working
knowledge of OpenCPI. However, it is recommended that the user read the Getting Started document (up to the
“Installation of OpenCPI” section) or reference the Acronyms and Definitions document for various terms used
within.
Table 1: References
Title Link
OpenCPI Overview Overview.pdf
Acronyms and Definitions Acronyms and Definitions.pdf
Getting Started Getting Started.pdf
Installation Guide1OpenCPI Installation.pdf
Component Development Guide OpenCPI Component Development.pdf
RCC Development Guide OpenCPI RCC Development.pdf
HDL Development Guide OpenCPI HDL Development.pdf
FPGA Vendor Tools Installation Guide FPGA Vendor Tools Installation Guide.pdf
Managing Software with yum (Fedora Project) https://docs.fedoraproject.org/en-US/
Fedora_Core/5/html/Software_Management_
Guide/sn-managing-packages.html
RHEL6 Deployment Guide: Useful yum
commands (e.g. yum localinstall; Red Hat)
https://access.redhat.com/documentation/
en-us/red_hat_enterprise_linux/6/html/
deployment_guide/ch-yum
1The RPM installation process is quite different from the process explained in the OpenCPI Installation Guide, but the
OpenCPI Installation guide has applicable post-installation information for PCI-based boards, etc.
3
RPM Installation Guide ANGRYVIPER Team
2 Document Overview
This document describes how to install OpenCPI at a system level on a development host for multiple users
via RPMs. The host installation allows for local software-based execution of OpenCPI applications and components,
cross-building for non-x86 platforms, simulation of HDL, and, when available, hardware testing. Upon completion
of this Guide, the steps described in the Getting Started Guide must be followed by each OpenCPI
user.
The default host installation platform for OpenCPI development is CentOS 7 Linux x86 64 (64-bit). Other Linux vari-
ants and 32-bit systems have been used successfully, but this document expects the OS to be CentOS 7. “Development
host” installations can be on physical systems, virtual machines, or containers1.
This document assumes that CentOS is already installed and
proper administrative privileges have been established.
Additional installation options exist for other target processors and technologies such as the Xilinx Zynq SoC (with
ARM processor cores and FPGA resources). Preference when targeting non-x86 architectures is given to cross-
building, rather than self-hosting development. This limits the complexity of installing tools on different development
hosts.
3 Installation Process
The ANGRYVIPER Team’s recommended installation method for development is through the use of RPMs. The
framework can be built from source for a development host, but is not recommended for beginning users nor
Application Developers. The steps herein result in a development system with tooling and runtime software ready
to support development and native execution of OpenCPI components and applications.
3.1 Background Information
Understanding OpenCPI RPM naming convention
OpenCPI’s RPM naming follows that of the Red Hat Package Manager recommendations of <name>-<version>
-<release>.<dist>.<architecture>.rpm where:
1. name is the name describing the packaged software
2. version is the version of the packaged software
version following the Major.Minor.Sub-minor naming schema
3. release is the number of times this version of software has been packaged
this number is independent of the version
4. dist is the OS distribution that the package is built for (e.g. .el7)
5. architecture is shorthand name describing the type of hardware the packaged software is to be installed on
6. “devel” is sometimes appended to the package’s name to indicate development RPMs which are required for
building from source
OpenCPI “hijacks” this term as explained in Table 3.
When to Install
It is recommended that the user install these packages before additional tools described in Section 4.1 because the
RPMs force the installation of some otherwise-hidden dependencies that allow the other tool installations to be
smoother, e.g. 32-bit X11 libraries for ModelSim.
1Commonly provided by Docker
4
RPM Installation Guide ANGRYVIPER Team
3.1.1 Description of Available RPMs
It is recommended that the user installs all available packages whenever possible. If limited by available disk space,
Table 2 can be used to help determine which of the packages should be installed based upon the intended use of the
target machine.
Within OpenCPI, there are two types of implementations, called Workers, that are used in this framework: Resource-
Constrained C Language (RCC) Workers and Hardware Description Language (HDL) Workers. RCC Workers are
written using either C or C++ and are designed for either x86 or ARM architecture, while HDL Workers are written
in VHDL and are designed for Field Programmable Gate Arrays (FPGAs) or HDL Simulators. For further details
regarding RCC and HDL Workers see the OpenCPI RCC Development Guide and the OpenCPI HDL Development
Guide (cf. Table 1).
Table 2: RPM Decision Guide
Runtime RCC Host
Runtime HDL Host
RCC-Only Development
(x86 RCC exclusive)
RCC/HDL Development
(x86 RCC, non-SoC1FPGA HDL)
RCC/HDL Development
(Targeting non-x86 HW/SW platform)
angryviper-ide...rpm ✓ ✓ ✓
opencpi-...rpm ✓ ✓ ✓ ✓ ✓
opencpi-debuginfo...rpm ✓ ✓ ✓
opencpi-devel...rpm ✓ ✓ ✓
opencpi-doc...rpm ✓ ✓ ✓
opencpi-driver...rpm ✓ ✓ ✓
opencpi-project-bsp...rpm2✓ ✓ ✓
opencpi-*-platform...rpm ✓
1“Non-SoC” meaning a standalone FPGA without an integrated processor, e.g. Xilinx ML605.
2BSP RPMs may not be provided with the standard/basic RPMs, but represent a placeholder for
RPMs providing Board Support Package Projects.
The RPMs each have specific usage. Table 3 outlines what each of the RPMs are used for.
5
RPM Installation Guide ANGRYVIPER Team
Table 3: RPM Descriptions
RPMs Description
angryviper-ide-*.x86 64.rpm The ANGRYVIPER IDE (Eclipse with plugins)a.
opencpi-*.x86 64.rpm Base installation RPM includes the runtime portion of the Component
Development Kit (CDK) and the source for the ocpi.core and ocpi.
assets Projects containing framework essential components, workers,
platforms, etc.
opencpi-debuginfo-*.x86 64.rpm Debug symbols needed to debug the framework.
opencpi-devel-*.x86 64.rpm Additional header files and scripts for developing new assets as HDL
and/or RCC.
opencpi-doc-*.x86 64.rpm Includes most of the documentation found at github.io. A symlink can
be found at /opt/opencpi/documentation.html. If you receive the
RPM directly from the AV team, it may include BSP documentation
that is not available on GitHub.
opencpi-driver-*.noarch.rpm OpenCPI driver. Once installed, any subsequent kernel updates will
cause the driver to be built automatically on restart.
opencpi-hw-platform-X-Y-*.noarch.rpm Additional files necessary to build the framework targeting specific hard-
ware platform “X” when running RCC platform “Y” (“Y” can be “no
sw”). This RPM also includes hardware-specific SD Card images when
applicable.
opencpi-project-bsp-*.noarch.rpm A*.bsp.* Project (e.g. ocpi.bsp.e3xx) contains a Board Support
Package for a particular physical radio, e.g. RCC/HDL Platform
Support, Device Workers, etc. There are certain BSPs which are lo-
cated in the ocpi.assets Project and therefore do not require their
own separate BSP RPMs. As noted in Table 2, these RPMs are only
needed for development; the hw-platform RPMs contain all required
runtime files to deploy to an SD Card.
opencpi-sw-platform-*.noarch.rpm Additional files necessary to build the framework targeting specific
RCC/software platforms, independent of the final deployed hardware.
aThis RPM is not available on github.io; see Section 3.4.5
3.2 Installation File Host Locations
The ANGRYVIPER Team provides RPMs to their direct customers and other users can find RPMs and other
installation files on github.io.
3.3 Acquiring and Installing OpenCPI from Physical Media
If installation from ANGRYVIPER Team-released physical media is desired, follow the steps in this section.
3.3.1 Install
You can choose individual packages to install (cf. Tables 2 and 3). To install install all RPMs:
$ sudo yum localinstall --nogpgcheck <location of RPMs>/*rpm
3.3.2 Log Out
To enable the various ocpi* commands and set other variables, the user must log out and log back in. Opening a
new terminal session is not sufficient. This step can be delayed until after Section 4 is complete.
6
RPM Installation Guide ANGRYVIPER Team
3.4 Acquiring and Installing OpenCPI from github.io
WARNING: The IDE RPM is NOT hosted on github.io due to GitHub Pages’ file size
limitations.
This section contains additional instructions beyond yum install in order to install the
IDE RPM.
If RPM installation from github.iois desired, installation should be performed with the following commands:
3.4.1 Configure Yum Repository
$ sudo yum install yum-utils
$ sudo yum-config-manager --add-repo=https://opencpi.github.io/repo/opencpi-v1.5.0.repo
3.4.2 Install External Dependencies
$ sudo yum install epel-release
$ sudo yum install libXft.i686 libXext.i6862
3.4.3 List Available Packages
To see packages available in the repository (to cross-reference with Tables 2 and 3):
$ yum list ’opencpi*’
3.4.4 Install OpenCPI
To install all non-IDE RPMs:
$ sudo yum install ’opencpi-*’
3.4.5 Install ANGRYVIPER IDE (Optional)
The ANGRYVIPER IDE is implemented using Eclipse’s Neon release and a plugin developed by the ANGRYVIPER
team. RPM-based users can simply install the single RPM in a standard manner3 4. The following instructions only
apply to public users who were not provided an angryviper-ide-*.rpm file, but instead have access to the JAR file
provided on github.io,or users who want to use their own copy of Eclipse for another reason (e.g. they want to
use Oxygen).
1. Obtain the latest ANGRYVIPER plugin jar file:
$ wget https://opencpi.github.io/ide/av.proj.ide.plugin 1.5.jar
2. Install prerequisites:
$ sudo yum install oxygen-icon-theme jre
3. Install either the Neon or Oxygen release of Eclipse:
•To install the Eclipse Neon release:
(a) Download the Eclipse Neon IDE for C/C++ Developers
URL: https://www.eclipse.org/neon/
(b) Install Eclipse by extracting the archive in the desired location
(c) Start Eclipse
Go into the folder where it was installed and click/run eclipse
(d) Put the av.proj.ide.plugin_*.jar file in the eclipse/dropins folder
(e) Install Sapphire via the Eclipse Marketplace
In Eclipse, navigate to “Help →Eclipse Marketplace”. Search for “Sapphire”. There should be
one search result for Sapphire. Click the “Install” button. Sapphire and its dependencies will be
installed.
2Only required on some point releases of CentOS7; others will autodetect
3Possibly as simple as yum install angryviper-ide
4Once installed, the command “ocpigui” will launch it
7
RPM Installation Guide ANGRYVIPER Team
(f) Restart Eclipse when prompted.
•To install the Eclipse Oxygen release:
(a) The process to construct the IDE is the same as described above using the Oxygen release for C/C++
Developers.
(b) At this time, the ANGRYVIPER Team has not been able to 100% verify using the plugin in Oxygen
release. Eclipse Oxygen changed an API that caused problems for Sapphire, and Sapphire 9.1.1 has
been released to correct the issue. The unknown part of the process is whether or not the Eclipse
Marketplace will have the new version of Sapphire. If it does not, it can be installed manually as
follows:
i. Add the Sapphire 9.1.1 repository
ii. Click the “add” button (to add a new repository site), fill in the popup form:
name: Sapphire9.1.1
location: http://download.eclipse.org/sapphire/9.1.1/repository/
iii. Click “OK” to add it
iv. Select the down arrow at the end of the “work with:” input. Select the new Sapphire repository.
(c) Select Sapphire. If Samples and Tests appear in the list; deselect them.
(d) Install
3.4.6 Log Out
To enable the various ocpi* commands and set other variables, the user must log out and log back in. Opening a
new terminal session is not sufficient. This step can be delayed until after Section 4 is complete.
4 Post-Installation Tasks
4.1 Installing HDL Simulator(s) and/or Compiler(s)
For FPGA development and/or HDL simulation, OpenCPI requires vendor-provided tools (e.g. Xilinx Vivado,
Mentor Graphics ModelSim). Refer to the FPGA Vendor Tools Installation Guide from Table 1 for instruction in
installing and configuring these tools for use with OpenCPI.
Keep note of where the license files are, the version number of the tools, and where the tools are installed, as this
information will be needed to configure the required environment variables.
4.2 Using the opencpi Group
At this point, certain users can be added to the opencpi group. When a user creates a Project, it is likely that
the Project should be registered. Registering a Project allows other users and Projects to access its assets. The
default Registry on an RPM-configured system is located at /opt/opencpi/project-registry. In order for a user
to register Projects in this default location, the user will need to be a member of the opencpi group. To add a user
to the opencpi group, run the following command:
% sudo usermod -aG opencpi <username>
If this command is run as user <username>, the user will need to log out and back in to apply this change.
The sharing of projects in this manner has been known to be fragile for various reasons (e.g. incorrect
permission settings, default “umask” values, etc.) and is not recommended for new users.
Users should use a personal non-default Project Registry. For more information on this, please visit the OpenCPI
Component Development document or the Getting Started Guide (cf. Table 1).
8
RPM Installation Guide ANGRYVIPER Team
4.3 Shell Environment Setup
The Framework tries very hard to accept vendor default installation and configuration
without additional settings. This section is only required if Section 4.1 and/or the FPGA
Vendor Tools Installation Guide required a non-standard configuration.
Setting up the environment when installing from RPM requires root privileges. Navigate to $(OCPI_CDK_DIR)/env.d
and notice the following example scripts:
•altera.sh.example
•modelsim.sh.example
•site.sh.example
•xilinx.sh.example
Every time a new bash5login shell is opened, all *.sh files in /opt/opencpi/cdk/env.d are imported (“sourced”),
and all *.sh.example files in /opt/opencpi/cdk/env.d are ignored. To enable a script for execution, the name of
the script must be changed so that the .example suffix is removed. A simple demonstration is below:
% sudo cp altera.sh.example altera.sh
Now altera.sh will execute every time a new shell is opened.
If using the Altera tools, the altera.sh will need to be created and the variables OCPI_ALTERA_DIR,OCPI_ALTERA_
VERSION, and OCPI_ALTERA_LICENSE_FILE must be defined in altera.sh. The altera.sh script also calls another
script to set up the rest of the variables needed for the Altera tools.
If using the ModelSim tools, the modelsim.sh will need to be created and the variables OCPI_MODELSIM_DIR and
OCPI_MODELSIM_LICENSE_FILE must be defined in modelsim.sh.
If using the Xilinx tools, the xilinx.sh will need to be created and the variable OCPI_XILINX_LICENSE_FILE must
be defined in xilinx.sh. If using an installation of Xilinx Vivado that was not installed in the default /opt directory,
the variable OCPI_XILINX_VIVADO_DIR must be defined in xilinx.sh. If using a version other than the most recent
one installed in that location, the variable OCPI_XILINX_VIVADO_VERSION must be defined in xilinx.sh. If using an
installation of Xilinx ISE that was not installed in the default /opt directory, the variable OCPI_XILINX_DIR must
be defined in xilinx.sh. If not using the 14.7 version of ISE, the variable OCPI_XILINX_VERSION must be defined in
xilinx.sh. The xilinx.sh script also calls another script to set up the rest of the variables needed for the Xilinx
tools. See the FPGA Vendor Tools Installation Guide (cf. Table 1) for more information on Xilinx license setup.
The script site.sh.example has been provided as an example central location where any other variables can be
defined globally. Remember that the names of the scripts do not matter; only the *.sh extension. More configuration
variables can be found in the Getting Started Guide.
Once all the desired scripts have been created and edited, log out and back in and check to see that the environment
is now set up.
5 RPM Uninstallation Process
In the event that the OpenCPI RPM needs to be uninstalled, or reinstalled, the best way to remove the OpenCPI
RPM is to use yum to erase the RPMs from Table 3 as seen below:
% sudo yum erase <RPM name>
5Some problems have been reported when the user’s shell is set to /bin/sh and not /bin/bash.
9
RPM Installation Guide ANGRYVIPER Team
6 Testing the Installation
To verify the OpenCPI installation, there is a command ocpitest that presents various test options. ocpitest
--showtests will list all available. Some require additional files to be present or Projects to be built, but for a fresh
RPM install, you can use:
% ocpitest driver os datatype load-drivers container
The first test, driver, will require sudo access. A successful install will output “All tests passed.” at the end of the
test.
10
