GENERAL 6 ELECTRIC

Lieu/ aim-40/

HE SENTRY BOX unit includes the

tuning condenser and dial mechanism as well

as the coils and switch compartments. Separ-

ate coils are used for each circuit and no

tapped coils are used. A unique type of con-

struction permits shortest possible leads -

coils are mounted directly on their respective

band change switches. Separate shielded

compartments house the R.F., detector and

oscillator circuits. The result is efficiency and

stability in performance heretofore impos-

sible of attainment.

Permanence of circuit alignment is assured

by the use of the PERMALINER trimmer

capacitor - a new air- dielectric trimmer,

sealed against moisture and dirt.

A cut -away view of the underside of SENTRY BOX

showing coil mountings and PERMALINERS. Note

the clean wiring and short, rigid leads.

MODEL A -82. A production broadcast receiver, yet built like a

commercial communications instrument. Eight Metal Tubes

Four Reception Bands Sentry Box Permaliners Sta-

bilized Dynamic Speaker Sliding -rule Tuning Scale

Lo -note Compensation CW Oscillator may be added.

$94.50

(Eastern List Price)
