With a ton
of trailer
behind you,
you really
need to be
in control.
The REDARC range of electric trailer brake controllers
put you in charge... not your trailer.
Designed for use with trailers, horse floats, camper-trailers,
boat trailers and caravans with electric brakes, you can
adjust the amount of braking with the turn of a knob.
Your trailer behaves exactly as you expect it to whenever
you apply the vehicle brakes.
What’s more, you can apply the trailer brakes independently
of the towing vehicle’s brakes, giving you absolute control
over your trailer (no more uncontrollable sway).
Benefits
n Ensures safe braking when towing a trailer
n No more hitting your knees on your brake controller
(remote head version)
n Simple, pop-out switch installation (remote head version)
n Allows towing of trailer from multiple vehicles
(trailer mount version)
n Simple to operate and
easy to install
www.redarc.com.au
Australia
Phone (08) 8322 4848
Fax (08) 8387 2889
International
Phone +61 8 8322 4848
Fax +61 8 8387 2889
REDARC Electronics
ABN 77 136 785 092
23 Brodie Road (North)
Lonsdale, South Australia
Australia 5160
power@redarc.com.au
N3533
See the REDARC electric trailer brake range at your nearest
auto-electrician or 4WD specialty store.
Copyright © 2012 REDARC Electronics Pty Ltd. All rights reserved.
3975-EB-121210
Electric trailer brake controller range and associated products
Model EB EBRH EBTM EB24A
Application 12V self-contained trailer
brake controller
12V remote head trailer
brake controller
12V trailer mount trailer
brake controller
Adaptor to permit use of EB,
EBRH or EBTM on 24V
1, 2 or
3 axles
Remote
head kit
In-vehicle
mount
Trailer
mount
EB range wiring for 12V system vehicle EB range wiring with EB24A for 24V system vehicle
Both installations apply to EB, EBRH and EBTM trailer brake controllers.
Also available - the REDARC Break-Safe range
Where the gross towed mass (GTM) exceeds 2 tonnes the electric
braking system must be fitted with a break-away system that
causes the brakes to be applied if the trailer becomes disconnected
from the towing vehicle.
The Break-Safe range
BA6000 to suit 2 and 4 wheel electric brakes
BA6000XP to suit 6 wheel electric brakes
RM6000 remote monitor to suit both kits
The EBRH electric trailer
brake controller with
remote head
The EBRH electric trailer brake
controller has all the features
of other EB models and more.
The dual-purpose remote mountable switch fits neatly into an
easily accessible position and:
n allows the driver to vary the braking power to the trailer
brakes when the vehicle brakes are applied
n has a push button which, when depressed, manually applies
the trailer brakes independently of the towing vehicle brakes.
The LED has two functions:
n it illuminates green indicating the vehicle is towing a trailer
which has electric brakes
n it illuminates red when the vehicle brakes are applied...
thestronger the braking, the more red it becomes.
