1 General
The Report Contents file is an XML file. It is used to define the components
included in a report. A default report contents file is provided with the program
(see Note). When a report is created, the program uses the default report file
unless an alternate .xml file has been specified. Use the File menu > Report
Setup command in SAP2000, ETABS, or SAFE or the Orb > Report > Report
Setup command in CSiBridge to specify use of an .xml file other than the default
file for a report.
Note: The default xxxReportContents.xml must be located in the same directory
as the program executable file. The "xxx" is Sap, Etabs, Safe, or CSiBridge,
depending on the program in use. The following table identifies the .xml file and
the executable file for each CSi Program.
Program-Specific XML File Name and Program Executable File Name
Program
XML File
Program Executable File
SAP2000
SapReportContents.xml
Sap2000.exe
ETABS
EtabsReportContents.xml
Etabs.exe
SAFE
SafeReportContents.xml
Safe.exe
CSiBridge
CSiBridgeReportContents.xml
CSiBridge.exe
The use of the Report Contents file is currently available for SAP2000 Version 12
and later, SAFE Version 12 and later and CSiBridge Version 15 and later. It will
become available for ETABS with the next major release of the software.
2 Schema
The schema is in the file named xxxDefaultReportContents.xsd, which is located
in the same directory as the program executable file (see preceding table). Again
xxx is Sap, Etabs, Safe, or CSiBridge, depending on the program in use.
1
![](asset-6.png)
CSI Report Contents XML File
3 Element Description
As indicated in the schema (see program-specific .xsd file), the root of the Report
Contents XML file is <report>, which includes the following complex elements:
<report>
<control>
<item>
<section>
<picture>
<table>
<table_id>
<text>
<text_add>
<page_break>
<blank_line>
<more>
Following is a series of subsections that describe the simple elements included in
each complex element. Note that all elements in the .xml file are named using all
lower case letters with underscores at the internal spaces.
3.1 <control>
The <control> element defines control parameters for the report.
Simple Element
Description
Assumed
Value*
<version>
The program version to which the report contents
file applies.
Not specified
<format_file>
The format file that applies to each table in the
report unless a table is overwritten by a table-
specific format file in the complex table element.
Currently
specified
format file
<logo_file>
This item applies to the report cover page. If a
value is specified for this item, it is used to
overwrite the default user logo on the cover page.
This overwrite may be the full path of any
graphics file or one of the following built-in
values:
Default Undeformed
Default Deformed
None
See Notes.
Not specified
<company_name>
This item applies to the report cover page and
footer. This company name will be used if no
company name is specified in the project
information data for the model. See Notes.
Not specified
<report_title>
The title of the report on the cover page.
Not specified
* value assumed by the program if the simple element is not included in the
complex element
2
CSI Report Contents XML File
Notes:
1. By default, the user logo that appears on the middle of the report cover page
is picked up from the graphic file named UserLogo.xxx (where xxx is a
graphic extension such as .emf, .bmp, etc.). The program looks for the
UserLogo.xxx file in the same directory as the SAP2000.exe file (if you are
using SAP2000), the Safe.exe file (if you are using SAFE), or the
CSiBridge.exe file (if you are using CSiBridge).
The default user logo behavior can be overwritten using the <logo_file>
element to specify either another graphics file or one of three built-in options.
The Default Undeformed option replaces the user logo with an undeformed
plot of the model. The Default Deformed option replaces the user logo with a
deformed plot of the model, if a deformed plot is available. Otherwise, it
replaces it with an undeformed plot. The None option leaves the user logo
area on the cover page blank.
2. To fill in the company name on the report cover page and in the report footer,
the program first checks the project information specified for the model. If the
company name in the project information is blank, the program checks the
<company_name> element in the Report Contents XML file. If that is not
specified, the program uses the company name that was specified when the
program was first installed and saved in the registry.
3.2 <item>
Each <item> element contains one of the components of the report as a child
element. Two (or more) components cannot be included in a single <item>
element. The following elements are the components of the report:
<section>
<picture>
<table>
<text>
<text_add>
<page_break>
<blank_line>
3.3 <section> - A child of <item>
The <section> element, a child element of the <item> element, inserts a
section header into the report.
3
![](asset-8.png)
CSI Report Contents XML File
Simple Element
Description
Assumed
Value*
<header>
Header text for the section
Not specified
<level>
1, 2 or 3, indicating the section level
1
<is_numbered>
True or false, indicating if the section header
is automatically numbered based on its level
(true) or not (false)
true
<alignment>
Left, Center or Right, indicating the alignment
of the header text
Left
<conditional>
True or false, indicating if the section is
conditional (true) or not (false). See notes
below.
true
<page_break_before>
True or false, indicating if a page break is
inserted before the section header (true) or
not (false)
false
<page_break_after>
True or false, indicating if a page break is
inserted after the section header (true) or not
(false)
false
<blank_line_before>
The number of blank lines occurring before
the section header
0
<blank_line_after>
The number of blank lines occurring after the
section header
0
* value assumed by the program if the simple element is not included in the
complex element
Notes:
1. If the conditional flag is true for a section and if no tables, no pictures, and no
subsections exist for inclusion in the section, the remaining contents of the
section, including the section header, is omitted from the report. For example,
if the Report Contents XML file specifies including data for analysis results but
no analysis results are available when the report is created, the analysis
results subsection is omitted from the report. If the analysis results are
included in a separate section of the report, the entire section would be
omitted from the report. Thus, there would be no extraneous text in the
report concerning analysis results.
3.4 <picture> - A child of <item>
The <picture> element, a child element of the <item> element, inserts a
picture into the report.
4
![](asset-9.png)
CSI Report Contents XML File
Simple Element
Description
Assumed
Value*
<source>
The source of the picture:
1 Default undeformed view
2 Default deformed view
3 Specified graphics file
4 Named display
5 Plot function trace named set
6 Pushover named set
7 TH response spectrum named set
8 Function
1
<source_name>
This item applies when the <source>
element is 3 through 8. It is the name of
the source item. For example, if the
<source> element is 3, it is the full path
of the graphics file. If the <source>
element is 4, this is the name of a Named
display.
Not
specified
<aspect_ratio>
This is the desired aspect ratio (width
divided by height) of the picture when it is
captured. This item does not apply when
the <source> element is 3.
1
<max_height_width_units>
The units used for the <max_height>
and <max_width> elements:
1 inches
2 millimeters
1
<max_height>
The maximum desired height of the
picture as displayed in the report in the
units specified by the
<max_height_width_units> element; 0
means use the actual picture height; see
notes at the end of this table
0
<max_width>
The maximum desired width of the picture
as displayed in the report in the units
specified by the
<max_height_width_units> element; 0
means use the actual picture width; see
notes at the end of this table
0
<alignment>
Left, Center or Right, indicating the
alignment of the picture
Left
<is_numbered>
True or false, indicating if the picture is
automatically numbered (true) or not
(false)
true
<caption>
Text for the picture caption
Not
specified
<caption_location>
Below or Above, indicating the location of
the picture caption with respect to the
Below
<caption_alignment>
Left, Center or Right, indicating the
alignment of the picture caption
Left
5
![](asset-a.png)
CSI Report Contents XML File
Simple Element
Description
Assumed
Value*
<page_break_before>
True or false, indicating if a page break is
inserted before the picture
false
<page_break_after>
True or false, indicating if a page break is
inserted after the picture
false
<blank_line_before>
The number of blank lines occurring before
the picture
0
<blank_line_after>
The number of blank lines occurring after
the picture
0
<group>
This item applies only when the <source>
element is 4. Only objects included in this
group will be displayed when the picture is
captured from the named display.
All
<overwrite_loads>
True or false, indicating if loads are to be
overwritten (true) or not (false). It applies
only when the <source> element is 4 and
the specified named display is showing
either assigned load pattern data or
results.
false
<load>
Applies only when the overwrite_loads>
element is true. If the named display is
showing assigned load pattern data, this is
the name of the overwritten load pattern.
If it is showing results data, this is the
name of the overwritten load case or load
combination.
Not
specified
<result_type>
Applies only when the overwrite_loads>
element is true and the specified named
display is showing results. This is an
overwrite of the result type.
0 Single value
1 Max and min envelope
2 Max envelope
3 Min envelope
4 Step or time
0
<step>
Applies only when the overwrite_loads>
element is true, the specified named
display is showing results for a stepped
load case, and the <result_type>
element is 4. It is the step for which
results are desired.
0
<time>
Applies only when the
<overwrite_loads> element is true, the
specified named display is showing results
for a time history load case, and the
<result_type> element is 4. It is the
time for which results are desired.
0
6
![](asset-b.png)
CSI Report Contents XML File
Simple Element
Description
Assumed
Value*
<response_type>
Applies only when the
<overwrite_loads> element is true and
the specified named display is showing
results for a Steady State load case.
1. Magnitude
2. Phase angle
1
<phase_angle>
Applies only when the
<overwrite_loads> element is true, the
specified named display is showing results
for a Steady State load case, and the
<response_type> element is 2 (phase
angle).
0
* value assumed by the program if the simple element is not included in the
complex element
Notes:
1. When the picture size is adjusted based on the specified <max_height> and
<max_width> items, the size is adjusted to the largest possible size such
that the aspect ratio of the picture is not changed from its original aspect
ratio, and the specified maximum height and width are not exceeded.
3.5 <table> - A child of <item>
The <table> element, a child element of the <item> element, inserts a table
into the report. Note that the complex <table_id> element, discussed in the
next subsection, is a child of the <table> element.
Simple Element
Description
Assumed
Value*
<is_numbered>
True or false, indicating if the table is
numbered automatically (true) or not
(false)
true
<format_file>
The name of the format file used for this
table. If a valid file name is specified
here, that format file is used for this table
instead of the format file specified by the
complex control element. Specifying None
for this element means no format file is
used for the table.
Format file
specified by
complex control
element
<page_break_before>
True or false, indicating if a page break is
inserted before the table (true) or not
(false)
false
<page_break_after>
True or false, indicating if a page break is
inserted after the table (true) or not
(false)
false
<blank_line_before>
The number of blank lines occurring before
the table
0
<blank_line_after>
The number of blank lines occurring after
the table
0
7
![](asset-c.png)
CSI Report Contents XML File
* value assumed by the program if the simple element is not included in the
complex element
3.6 <table_id> - A child of <table>
The <table_id> element, a child element of the <table> element that itself is a
child element of the <item> element, specifies which table is to be inserted into
the report. The table is specified either by its table key or by its table name, but
not both. A value must be specified for one of these elements to include a table
in a report.
Simple Element
Description
Assumed
Value*
<key>
The table key for the table to be inserted into
the report
None, element
must be specified
<name>
The table name for the table to be inserted into
the report
None, element
must be specified
3.7 <text> - A child of <item>
The <text> element, a child element of the <item> element, inserts a new text
block into the report.
Simple Element
Description
Assumed
Value*
<title>
Title text for the text block
Not specified
<data>
Text data inserted into the current text block.
This text should be enclosed in quotes. Quotes
should not typically be included within this
text.
Not specified
<page_break_before>
True or false, indicating if a page break is
inserted before the text block (true) or not
(false)
false
<page_break_after>
True or false, indicating if a page break is
inserted after the text block (true) or not
(false)
false
<blank_line_before>
The number of blank lines occurring before
the text block
0
<blank_line_after>
The number of blank lines occurring after the
text block
0
* value assumed by the program if the simple element is not included in the
complex element
3.8 <text_add> - A child of <item>
The <text_add> element, a child element of the <item> element, appends
additional data to the current text block in the report, that is, to the text block
last initiated by a <text> element. The <text_add> element must have been
preceded by a <text> element.
8
![](asset-d.png)
CSI Report Contents XML File
Simple
Element
Description
Assumed
Value*
<data>
Text data appended to the current text block. This text
should be enclosed in quotes. Quotes should not typically be
included within this text.
Not specified
<return>
An integer value, greater than or equal to 1, indicating the
number of paragraph returns inserted into the current text
block
Not specified
* value assumed by the program if the simple element is not included in the
complex element
3.9 <page_break> - A child of <item>
The <page_break> element, a child element of the <item> element, inserts
one or more page breaks into the report.
Simple
Element
Description
Assumed
Value*
<number>
An integer value, greater than or equal to 1, indicating the
number of page breaks inserted
1
* value assumed by the program if the simple element is not included in the
complex element
3.10 <blank_line> - A child of <item>
The <blank_line> element, a child element of the <item> element, inserts one
or more blank lines into the report.
Simple Element
Description
Assumed Value*
<number>
An integer value, greater than or equal to 1,
indicating the number of blank lines inserted
1
* value assumed by the program if the simple element is not included in the
complex element
3.11 <more> - A child of <item>
The <more> element, a child element of the <item> element, inserts an
additional item into the report.
Simple Element
Description
Assumed
Value*
<type> SAFE only
The type of additional item:
1 Detailed Design output – Strip Design
2 Detailed Design output – Beam Design
3 Detailed Design output – Punching Check
1
<group>
The group of objects for which the specified
output data is provided.
All
9
![](asset-e.png)
CSI Report Contents XML File
Simple Element
Description
Assumed
Value*
<page_break_before>
True or false, indicating if a page break is
inserted before the specified item (true) or not
(false)
false
<page_break_after>
True or false, indicating if a page break is
inserted after the specified item (true) or not
(false)
false
<blank_line_before>
The number of blank lines occurring before the
specified item
0
<blank_line_after>
The number of blank lines occurring after the
specified item
0
* value assumed by the program if the simple element is not included in the
complex element
10
CSI Report Contents XML File
4 Example
Following is an example Report Contents XML file for SAP2000:
<?xml version="1.0"?>
<report xmlns="http://www.csiberkeley.com"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://www.csiberkeley.com
SapDefaultReportContents.xsd">
<control>
<version>12.0.0</version>
</control>
<item>
<section>
<header>Model Definition</header>
</section>
</item>
<item>
<picture>
<source>1</source>
<max_height>6</max_height>
<max_width>6</max_width>
<caption>Undeformed Model</caption>
</picture>
</item>
<item>
<table>
<table_id>
<name>Joint Coordinates</name>
</table_id>
<is_numbered>true</is_numbered>
</table>
</item>
<item>
<table>
<table_id>
<name>Connectivity-Frame</name>
</table_id>
<is_numbered>true</is_numbered>
</table>
</item>
</report>
11
