ROBOT FRAMEWORK CODING STYLE GUIDE
Version 1.01
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page i
Document Control
Document Information
INFORMATION
Document Id
Document Owner
Roberto Galman
Issue Date
13-Apr-2015
Last Saved Date
13-Apr-2015
File Name
Robot_Framework_Coding_StyleGuide.docx
Document History
VERSION
ISSUE DATE
CHANGES
1.00
13-Apr-2015
Initial Doc
1.01
28-Apr-2015
Added Pre-condition and Post-Condition (Section 4.3)
Document Approvals
ROLE
NAME
SIGNATURE
DATE
Project Sponsor
Project Review Group
Project Manager
Quality Manager
(if applicable)
Procurement Manager
(if applicable)
Communications Manager
(if applicable)
Project Office Manager
(if applicable)
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page ii
TABLE OF CONTENTS
1 INTRODUCTION .................................................................................................................................. 3
2 FOLDER STRUCTURE & FILE ORGANIZATION ...................................................................................... 4
2.1 Test Automation Framework ................................................................................................... 4
2.2 Test Suite ................................................................................................................................ 4
3 CODE LAYOUT .................................................................................................................................. 5
3.1 Indentation & Max Line Length ............................................................................................... 5
3.2 Source File Encoding .............................................................................................................. 5
3.3 String Quotes .......................................................................................................................... 5
3.4 Whitespace in Expressions & Statements .............................................................................. 5
3.5 Comments ............................................................................................................................... 6
4 TEST SUITE STRUCTURE.................................................................................................................... 7
4.1 Test Data Table Names .......................................................................................................... 7
4.2 Settings Table ......................................................................................................................... 7
4.3 Pre-condition and Post-Condition ........................................................................................... 8
5 TEST CASE STRUCTURE .................................................................................................................... 9
5.1 Tags ........................................................................................................................................ 9
5.2 Abstraction Level ..................................................................................................................... 9
5.3 TestCase Structure ............................................................................................................... 10
6 USER KEYWORDS ........................................................................................................................... 11
6.1 General .................................................................................................................................. 11
6.2 Comments ............................................................................................................................. 11
6.3 Using Keywords .................................................................................................................... 11
7 VARIABLES ..................................................................................................................................... 12
7.1 Naming .................................................................................................................................. 12
7.2 Assigning Variable value ....................................................................................................... 12
8 REFERENCES .................................................................................................................................. 13
9 APPENDIX ....................................................................................................................................... 14
9.1 Definitions .............................................................................................................................. 14
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 3
1 INTRODUCTION
This document discusses a set of guidelines for writing Robot Framework (RF) Test Scripts including
Naming Conventions, Documentation, Test Suite/Case Structure, User Keywords, and Variables. The
purpose of this document is to create a readable, accurate, stable & maintainable RF Test Suite.
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 4
2 FOLDER STRUCTURE & FILE ORGANIZATION
Robot Framework Test Data is defined in tabular format using HTML, tab-separated values (TSV),
plain text, or reStructuredText (reST) formats.
It is recommended to use plain text format (.txt) with tabs used as separator.
2.1 TEST AUTOMATION FRAMEWORK
Robot Framework allows you to create or extend the Test Library to add new functionality. This
should be designed such that it can easily be integrated to a Test Suite by importing it. As
Robot Framework is written in Python (.py), it is suggested that user library is implemented in
Python as well.
It should support:
Command-line execution with parameterization
Unit Tests available in the repository to be used for quick checks & testing updates
Generates test execution logs with log-levels
The recommended folder structure should be:
+ <PRODUCT>_automationfwk
- - + src
- - - - <Library>
- - - - - */*
- - - - unit tests
- - - sw_dependencies.txt
2.2 TEST SUITE
When creating the Test Suite Folder structure to be committed in GitLab, this should be
consistent with the structure in ALM. This is for the purpose of traceability & mapping the test
cases.
The Test Suite Folder should follow the hierarchy: Module > Submodule > Functionality>*.
The naming convention should be consistent with ALM. It may follow a CamelCase format but
for long names, it can also be separated by underscores to improve readability. The same
convention can be implemented for file names.
<Module>_<Submodule>_<Function>_<Scenario/Action>_By_<Role>
e.g. FWK_ContextualAction_ContextualActionsDisplay_By_MGR
ALM vs Gitab Repository
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 5
3 CODE LAYOUT
3.1 INDENTATION & MAX LINE LENGTH
Use tabs per indentation level. If there is more data than readily fits the line, you may use
ellipsis (...) to continue the previous line. The maximum line length is 120. Limiting the
required editor window width makes it possible to have several files open side-by-side, and
works well when using code review tools that present the two versions in adjacent columns
(PEP-8).
3.2 SOURCE FILE ENCODING
Plain Text files are expected to use UTF-8 encoding.
3.3 STRING QUOTES
Always use double-quoted string format. However, when a string contains double quote
characters, use a single-quote to avoid backslashes in the string. This improves readability.
3.4 WHITESPACE IN EXPRESSIONS &
STATEMENTS
Avoid extra or missing whitespace in the following:
Whitespace in Conditional expressions
Assigning a keyword return value to a variable
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 6
Add single space between Test data Table and asterisks
*** Settings ***
*** Variables ***
*** Test Cases ***
*** Keywords ***
3.5 COMMENTS
Block comments generally apply to some (or all) code that follows them, and are indented to
the same level as that code. Each line of a block comment starts with a # and a single space
(PEP-8).
Avoid adding chain of #s to indicate start & end of a block comment. Also, do not use
# followed by a series of dash to start/end a block comment. This will make the code
look cluttered.
Don’ts:
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 7
4 TEST SUITE STRUCTURE
As discussed in Section 2.2, Test Suite Folder & Filename should be consistent with ALM. There
should be a 1:1 correspondence between the Test Instances in ALM & the Test Scripts in GitLab.
Hence, there should only be one Test Case per Test Suite (File).
4.1 TEST DATA TABLE NAMES
The Test Data Table should follow the convention:
*** + single whitespace + <tablename> + single whitespace + ***
Where:
Table name = Settings, Variables, Test Cases, Keywords
*** Settings ***
*** Variables ***
*** Test Cases ***
*** Keywords ***
The test scripter should follow the name, capitalization, spacing of the test data tables.
4.2 SETTINGS TABLE
You should add the Documentation at the Settings table. The description can be
picked-up from the test description in ALM.
Resource setting should only source the required Resource file. Other Test Libraries &
Resource Files needed can be sourced in the required Resource file. The master
Resource file should only include common/generic resource files used in the test suite.
Add Suite Teardown > Close Browser to ensure that the current browser will be closed
so as not to affect the succeeding tests e.g. Auto-logoff due to inactivity
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 8
*** Settings ***
Suite Setup Setup
Suite Teardown Cleanup
4.3 PRE-CONDITION AND POST-CONDITION
Add Preconditions in "Suite Setup" & Cleanup in "Suite Teardown”. This will ensure
that it will be triggered regardless if the test passed or failed.
Use "Setup" as Setup keyword & "Cleanup" for Teardown. These keywords are
defined in the resource file. Related Test cases using a common resource file should
have same Setup & Teardown steps. In case of a different set of tests using the same
flow but with different setup/teardown steps, you may use keyword -
Setup_<identifier>, Cleanup_<identifier>.
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 9
5 TEST CASE STRUCTURE
The TestCase name should be the same as the Test Suitename –i.e. Filename.
5.1 TAGS
Use [Tags] in your test case. The tags can be used to select tests for execution & can be set
in Jenkins.
[Tags] automatedby:<name>
[Tags] status:<wip/obsolete/ci>
[Tags] priority:<high/med/low>
[Tags] testtype:sanity/regression/browser_compatibility
[Tags] system/client:<system/client>
[Tags] module:<module>
[Tags] submodule:<submodule>
[Tags] functionality:<functionality>
5.2 ABSTRACTION LEVEL
Use appropriate Abstraction Level. Note that, the Test Case may be reviewed by non-technical
person not familiar with the Robot Framework. Ideally, the script implementation can easily be
traced from the Detailed Scenario. This means higher abstraction is expected for the Test
Case. The lower abstraction can be implemented in the Keywords or Test Library.
Don’t use too low abstraction level in your test case
Don’t rely on comments instead of abstraction
Sample Implementation:
(To be discussed)
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 10
5.3 TESTCASE STRUCTURE
Generally has these phases:
o Preconditions
o Action
o Verification
o Cleanup
Keyword should describe what a test does
o Use clear keywords with the appropriate abstraction level
o Should contain enough information to run manually
No complex logic
o No for loops or if/else constructs
o Test Cases should not look like scripts
Maximum of 15 steps, preferably less
Be consistent in the Abstraction Level used. Keep in mind, Customer/Product owner
may have to review your test implementation
Do not test without checks – so basically just the flow was verified
Avoid Tests with unrelated checks. This is redundant & eats up execution time.
Avoid dependencies between tests. The test suite should be standalone. The
preconditions & cleanup are implemented within the test script.
Use teardowns for cleanup
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 11
6 USER KEYWORDS
6.1 GENERAL
Name should be descriptive of the function & can easily be mapped in the Test Script
Implementation plan
All variables used in the keyword including the arguments, return & local variable in
the implementation should be in lower case.
It may contain programming logic (If/else, for loops)
6.2 COMMENTS
Add comments in your keyword to describe the action/flow if needed. Always keep in mind that
others will be maintaining your code, so include in your comments your assumptions, default
values, etc.
6.3 USING KEYWORDS
When using keywords in your Test Case or Keywords table, Robot framework may
allow you to use mixed cases – that is, “Close Browser” or ”close Browser” are
accepted. Use the case as it is written in the keyword definition. If you are using
eclipse, the intelliSense will do it for you.
Use [Arguments] , [Return] (Follow the case)
Add explicit waits & Capture page screenshot if needed in the keywords & not in the
test cases to hide the technical implementation.
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 12
7 VARIABLES
Variables are used to encapsulate long and/or complicated values, and pass values from the
command line or keywords.
7.1 NAMING
Clear but not too long. Do not use generic variable name e.g. ${a}.
Follow CamelCase Format. If name is long, you may use an underscore to improve
readability. Do not use space as separator. e.g ${FirstName}
Use case consistently:
o Upper Case for Global Variable e.g. ${BROWSER}
o CamelCase for Suite Variable (Declared in Variables table) e.g. ${JobType}
o Lower Case for local variable e.g. return values of keywords assign to a
variable. e.g. ${tmp}
7.2 ASSIGNING VARIABLE VALUE
When declaring a Variable in the Variables Table of the Test Suite, omit the equal
sign(=).
When assigning the return value of keyword to a variable, use the equal sign(=).
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 13
8 REFERENCES
#
REFERENCE
LOCATION
1
NGAHR_Test_Script_Implementation_Plan_Template.
dotx
https://drive.google.com/drive/#folders/0B-
6qCtvTgLEaQXFuMTloUUQ2T3M/0B-
6qCtvTgLEaVnRMeDBPSUtzcjQ/0B-
6qCtvTgLEafmRPbjJscjQ3NmlZY0YzNzRwQVNVV1NQZ0
1tcTJobWtqblFxVGZZZFVFMjA
2
Writing Stable & maintainable RF Test Scripts
https://drive.google.com/drive/#folders/0B-
6qCtvTgLEaX1VLdWJnM1dCSFE/0B-
6qCtvTgLEaM2tndnFPVGpWZ1U/0B-
6qCtvTgLEaLXI1NzVpRl9xUmM
3
Automation PostReg Test Script Cleanup
https://docs.google.com/a/ngahr.com/presentation/d/1pjQr
T43Q8DWY0nw12GRTkHHOsfout5Sxt7Bcv90FKlA/edit#sli
de=id.p25
4
Robot Framework – How to write Good TestCases
https://code.google.com/p/robotframework/wiki/HowToWrit
eGoodTestCases#Passing_and_returning_values
5
PEP 8 – Style Guide for Python
https://www.python.org/dev/peps/pep-0008/
6
writing_maintainable_automated_acceptance_tests.pdf
http://dhemery.com/pdf/writing_maintainable_automated_a
cceptance_tests.pdf
7
Robot Framework – Quick Start Guide
http://robotframework.googlecode.com/hg/doc/userguide/R
obotFrameworkUserGuide.html?r=2.8.5
8
Robot Framework Do’s & Don’ts
http://www.slideshare.net/pekkaklarck/robot-framework-
dos-and-donts
Robot Framework(RF) Coding Style Guide
Proprietary and Confidential to NGA Human Resources Page 14
9 APPENDIX
9.1 DEFINITIONS
#
NAME
DESCRIPTION
NGA Human Resources is a global leader in helping organizations transform their business-critical HR operations to
deliver more effective and efficient people-critical services.
We help our clients become better employers through smarter, more streamlined business processes — to save
money, manage employee life cycles, and support globally connected, agile organizations. This is how NGA makes
HR work.
What sets us apart is The NGA Advantage. It’s a combination of deep HR experience and insight, advanced
technology platforms and applications and a global portfolio of flexible service delivery options.
www.ngahr.com
