VERMEER.COM
OPERATOR PRESENCE SYSTEM. Control
handles for the boom swing, boom raise/lower
and machine propel are equipped with an operator
presence handle design which provides capacitance-
sensing capability. This user-friendly operator
presence system is intended to help protect the
operator and enhance operator safety.
YELLOW JACKET™ CUTTER SYSTEM.
The Vermeer-exclusive Yellow Jacket cutter system
is designed to provide faster, easier serviceability,
as well as extended pocket and tooth life.
AUTOSWEEP® SYSTEM. Optional. The AutoSweep
function monitors engine speed and automatically
adjusts cutter wheel sweep rate, and is designed to
reduce engine, drivetrain and structural stress.
TWO-SPEED GROUND DRIVE. The operator
may choose to operate in a high-range or low-range
ground speed setting of 0-133 ft/min (0-40.5 m/min)
to quickly move the machine or choose a slower
speed when near the stump by utilizing a low-range
setting of 0-66 ft/min (0-20.1 m/min).
POWERFUL STUMP REMOVAL. A 35 hp
(26.1 kW) Vanguard engine offers low vibration, low
emissions, smooth easy starting, extended starter life
and an instant return to maximum power. Also offers
a limited three-year warranty from Vanguard.
CONVENIENT BELT SERVICING. Belts on the
SC362 are serviceable from one side of the machine
with cutter drive belts being adjustable with movable
idlers. Additionally, each belt set may be adjusted
independently, without affecting adjustment of
other belts.
STUMP CUTTER
SC362
GENERAL
Weight: 1320 lb (598.7 kg)
Length: 110” (279.4 cm)
Width: 49.8” (126.5 cm)
Overall width transport (without duals): 35” (88.9 cm)
Height: 53” (134.6 cm)
ENGINE
Make and model: Briggs & Stratton Vanguard
Gross horsepower: 35 hp (26.1 kw)
Max torque: 53 ft-lb (71.9 Nm)
Fuel tank capacity: 6 gal (22.7 L)
Fuel type: Gasoline
HYDRAULIC SYSTEM
Tank capacity: 4 gal (15.1 L)
Recommended oil type: Vermeer HyPower 68
System type: Open-loop series system
ELECTRICAL SYSTEM
System voltage: 12 V
Battery: 400 CCA
Standard gauges: Hourmeter
Warning lights: Operator presence status, clutch engage/
disengage status
Switches: Two-speed ground drive, clutch engage/disengage,
operator presence handles
Shutdown system: Engine low oil pressure
GROUND DRIVE
Low speed travel: 0-66 ft/min (20.1 m/min)
High speed travel: 133 ft/min (40.5 m/min)
CUTTER WHEEL SYSTEM
Cutter diameter (without teeth): 17" (43.2 cm)
Cutter wheel thickness: .5" (1.3 cm)
Cutter wheel speed: 1400 rpm
Tooth description: Yellow Jacket™ cutter system
Number of teeth: 16
CUTTING DIMENSIONS
Cutter wheel cut above ground: 24" (61 cm)
Cutter wheel cut below ground: 15" (38.1 cm)
Width (straight line): 47” (119.4 cm)
Vermeer Corporation reserves the right to make changes in engineering, design and specifications; add improvements; or discontinue manufacturing at any time without notice or obligation.
Equipment shown is for illustrative purposes only and may display optional accessories or components. Please contact your local Vermeer dealer for more information on machine specifications.
Vermeer, the Vermeer logo and Equipped to Do More are trademarks of Vermeer Manufacturing Company in the U.S. and/or other countries. © 2014 Vermeer Corporation. All Rights Reserved.
Printed in the U.S.A. Please recycle.
SC362 STUMP CUTTER
NOTES:
PN 180007895
