ScichemTech –Malden, MA -02148, Massachusetts would like to dedicate this catalogue to

Thomas Alva Edison the Genius who has contributed the light to the World. Could we able to

imagine this world without light.

Test and Measurement is the light of all the Sciences, without this, science it will become dark.

In this special dedicated edition of ScichemTech Test & Measurement Catalog, SCT team would

like to present the Test and Measurement products such as Testers / Pocket meters, Handheld /

Portable Meters and the BenchTop meters of Water Testing and other essential Environmental

Parameters…

We at ScichemTech, where we always thrive to grow slowly and steadily, through inventing &

LQWURGXFLQJDOOSRVVLEOHTXDOLW\QHZSURGXFWVWRWKH³6FLHQWL¿FDQG,QGXVWULDO&RPPXQLW\´DQG

to our valuable customers.

ScichemTech Team…

Thomas Alva Edison

1847-1931

SCT Test and Measurement Products

383

sales@scichemtech.com www.scichemtech.com

383

ScichemTech - SCT ® TESTERS / POCKET METERS

SCT POCKET pH METER

SALIENT FEATURES:

Ɣ Reliable SCT Tester for basic & easy pH measurement.

Ɣ Ergonomic Design - Waterproof IP57 rated.

Ɣ Accurate & Fast in measurements 0.1 pH resolution.

Ɣ Removable & changeable electrode.

Ɣ Large and clear display

Ɣ Manual calibration through screw trim port 1 or 2 points.

Ɣ Battery operated.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.01

MODEL SCT-PH PEN-1

TYPE pH

RANGE 0~14.0

ACCURACY ±0.1+1 DIGIT

RESOLUTION 0.1 pH

ATC NO

POWER 3V X 2 LITHIUM BATTERY

DIMENSION FOR METER 33.5 X 170 MM AND WITH BOX L(230) X H(45)X W(120) MM

WEIGHT ONLY METER 85 G AND COMPLETE WITH BOX 280G

ORDERING INFORMATIONS:

SCT-108.001.01 SCT-PH PEN-1 SCT pH PEN-1 POCKET PH METER IS SUPPLIED WITH STANDARD SOLUTION, BATTERY,

SCREWDRIVER, AND INSTRUCTION MANUAL , PACKED IN COLOURFUL SUITABLE BOX.

SCT POCKET pH / TEMP METER (HIGH RESOLUTION + ATC)

SALIENT FEATURES:

Ɣ Reliable SCT Tester for high resolution pH measurement.

Ɣ Ergonomic Design - Waterproof IP57 rated.

Ɣ Accurate & Fast in measurements 0.01 pH resolution.

Ɣ Removable & changeable electrode.

Ɣ Large and clear display.

Ɣ Manual calibration through screw trim port 1 or 2 points.

Ɣ With Automatic Temperature Compensation (ATC).

Ɣ Battery operated.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.02

MODEL SCT-PH-PEN-2

TYPE pH

RANGE 0~14.0

ACCURACY ±0.01+1 DIGIT

RESOLUTION 0.01 pH

ATC YES

POWER 3V X 2 LITHIUM BATTERY

DIMENSION FOR METER 33.5 X 170 MM AND WITH BOX L(230) X H(45)X W(120) MM

WEIGHT ONLY METER 85 G AND COMPLETE WITH BOX 280G

ORDERING INFORMATIONS:

SCT-108.001.02 SCT-PH-PEN-2 SCT pH PEN-2 POCKET PH METER IS SUPPLIED WITH STANDARD SOLUTION, BATTERY,

SCREWDRIVER AND INSTRUCTION MANUAL, PACKED IN COLOURFUL SUITABLE BOX.

SCT-pH-PEN-1

Peace begins with a smile.

384 sales@scichemtech.com www.scichemtech.com

384

SCT POCKET CONDUCTIVITY METER

SALIENT FEATURES:

Ɣ Reliable SCT Tester for basic & easy Conductivity measurement.

Ɣ Ergonomic Design - Waterproof IP57 rated.

Ɣ Accurate & Fast in measurements 10 μS/CM resolution.

Ɣ Removable & changeable electrode.

Ɣ Large and clear display.

Ɣ Manual calibration through screw trim port 1 or 2 points.

Ɣ With Automatic Temperature Compensation (ATC).

Ɣ Battery operated.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.03

MODEL NO. SCT-CON-PEN-1

TYPE CONDUCTIVITY

RANGE 0-19990μS

ACCURACY ±1%FS

RESOLUTION 10μS/CM

ATC YES

POWER 3V X 2 LITHIUM BATTERY

DIMENSION FOR METER 33.5 X 170 MM AND WITH BOX L(230) X H(45)X W(120) MM

WEIGHT ONLY METER 85 G AND COMPLETE WITH BOX 280G

ORDERING INFORMATIONS:

SCT-108.001.03 SCT-CON-PEN-1 SCT CON PEN-1 POCKET CONDUCTIVITY METER IS SUPPLIED WITH STANDARD SOLUTION, BATTERY,

SCREWDRIVER, AND INSTRUCTION MANUAL , PACKED IN COLOURFUL SUITABLE BOX.

SCT POCKET CONDUCTIVITY METER (HIGH RESOLUTION)

SALIENT FEATURES:

Ɣ Reliable SCT Tester for high resolution Conductivity measurement.

Ɣ Ergonomic Design - Waterproof IP57 rated.

Ɣ Accurate & Fast in measurements 1 μS/CM resolution.

Ɣ Removable & changeable electrode.

Ɣ Large and clear display.

Ɣ Manual calibration through screw trim port 1 or 2 points.

Ɣ With better Conductivity resolution 1 μS/CM.

Ɣ With Automatic Temperature Compensation (ATC).

Ɣ Battery operated.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.04

MODEL NO. SCT-CON-PEN-2

TYPE CONDUCTIVITY

RANGE 0-1999μS

ACCURACY ±1%FS

RESOLUTION 1μS/CM

ATC YES

POWER 3V X 2 LITHIUM BATTERY

DIMENSION FOR METER 33.5 X 170 MM AND WITH BOX L(230) X H(45)X W(120) MM

WEIGHT ONLY METER 85 G AND COMPLETE WITH BOX 280G

ORDERING INFORMATIONS:

SCT-108.001.04 SCT-CON-PEN-2 SCT CON PEN-2 POCKET CONDUCTIVITY METER IS SUPPLIED WITH STANDARD SOLUTION, BAT-

TERY, SCREWDRIVER AND INSTRUCTION MANUAL, PACKED IN COLOURFUL SUITABLE BOX.

Peace is its own reward.

385

sales@scichemtech.com www.scichemtech.com

385

SCT POCKET TDS METER

SALIENT FEATURES:

Ɣ Reliable SCT Tester for basic & easy TDS measurement.

Ɣ Ergonomic Design - Waterproof IP57 rated.

Ɣ Accurate & Fast in measurements 10 ppm resolution.

Ɣ Removable & changeable electrode.

Ɣ Large and clear display.

Ɣ Manual calibration through screw trim port 1 or 2 points.

Ɣ With Automatic Temperature Compensation (ATC).

Ɣ Battery operated.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.05

MODEL SCT-TDS-PEN-1

TYPE TDS

RANGE 0-19990PPM

ACCURACY ±1%FS

RESOLUTION 10 PPM

ATC YES

POWER 3V X 2 LITHIUM BATTERY

DIMENSION FOR METER 33.5 X 170 MM AND WITH BOX L(230) X H(45)X W(120) MM

WEIGHT ONLY METER 85 G AND COMPLETE WITH BOX 280G

ORDERING INFORMATIONS:

SCT-108.001.05 SCT-TDS-PEN-1 SCT TDS PEN-1 POCKET TDS METER IS SUPPLIED WITH STANDARD SOLUTION, BATTERY, SCREW-

DRIVER AND INSTRUCTION MANUAL , PACKED IN COLOURFUL SUITABLE BOX.

SCT POCKET TDS METER (HIGH RESOLUTION)

SALIENT FEATURES:

Ɣ Reliable SCT Tester for high resolution TDS measurement.

Ɣ Ergonomic Design - Waterproof IP57 rated.

Ɣ Accurate & Fast in measurements 1 ppm resolution.

Ɣ Removable & changeable electrode.

Ɣ Large and clear display.

Ɣ Manual calibration through screw trim port 1 or 2 points.

Ɣ With better TDS resolution 1ppm

Ɣ With Automatic Temperature Compensation (ATC).

Ɣ Battery operated.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.06

MODEL SCT-TDS-PEN-2

TYPE TDS

RANGE 0-1999PPM

ACCURACY ±1%FS

RESOLUTION 1 PPM

ATC YES

POWER 3V X 2 LITHIUM BATTERY

DIMENSION FOR METER 33.5 X 170 MM AND WITH BOX L(230) X H(45)X W(120) MM

WEIGHT ONLY METER 85 G AND COMPLETE WITH BOX 280G

ORDERING INFORMATIONS:

SCT-108.001.06 SCT-TDS-PEN-2 SCT TDS PEN-2 POCKET TDS METER IS SUPPLIED WITH STANDARD SOLUTION, BATTERY,

SCREWDRIVER AND INSTRUCTION MANUAL , PACKED IN COLOURFUL SUITABLE BOX.

People always make war when they say they love peace.

386 sales@scichemtech.com www.scichemtech.com

386

SCT WATER PROOF POCKET DO / O2 / TEMP METER

SALIENT FEATURES:

Ɣ Reliable SCT tester for Dissolved Oxygen, Oxygen and Temperature measurements.

Ɣ Microprocessor based for fast and accurate measurements 0.01 mg/L resolution.

Ɣ 6SHFLDOYLHZLQJDQJOHGHVLJQHGRIZDWHUSURRIKRXVLQJ,3UDWHG,WÀRDWVRQZDWHU

Ɣ Large LCD display DO and Temperature simultaneously.

Ɣ Easy to calibrate by one keyboard and Automatic Temperature Compensation (ATC), Manual

Salinity (MSC) and Altitude (MAC) Compensation.

Ɣ Multi-functions with Data-hold, Max/Min and shows PTS after calibration. Degree OC/OF are

switchable.

Ɣ Auto power shut off after 10 minutes of non use.

Ɣ Easy to replace electrode module and the type of electrode would be recognized automatically and

shown in display during insertion.

Ɣ Battery operated. Low battery and consumption indicator.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.15

MODEL NO. SCT-DO-PEN-1

DO O2 TEMP

RANGE 0~20 mg/L 0~200% 0~90.0OC

ACCURACY ±0.2 + 1DIGIT ± 2% FS ±0.2+1 DIGIT

RESOLUTION 0.01 mg/L 0.1% 0.1OC

ATC 0~50 OC

MSC 0~50 PPT

MAC 0-20000 FT

CALIBRATION 100% IN AIR

POWER DC1.5V X 4 BATTERY

DIMENSIONS FOR METER 195 X 40 X 36 MM, KITS: L(235) X H(55) X W(210) MM

WEIGHT ONLY METER: 135g (WITH BATTERY), KITS: 780G

ORDERING INFORMATIONS:

SCT-108.001.15 SCT-DO-PEN-1

SCT DO PEN-1 HANDHELD DO/O2/TEMP METER IS SUPPLIED WITH STORAGE SOLUTION, LAN

CONNECTION, BATTERY AND INSTRUCTION MANUAL, PACKED IN A NICE SMALL CARRYING

PLASTIC CASE.

SCT POCKET ORP METER

SALIENT FEATURES:

Ɣ Reliable SCT Tester for basic & easy ORP measurement.

Ɣ Ergonomic Design - Waterproof IP57 rated.

Ɣ Accurate & Fast in measurements 1 mV resolution.

Ɣ Removable & changeable electrode.

Ɣ Large and clear display.

Ɣ Manual calibration through screw trim port 1 or 2 points.

Ɣ Battery operated.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.07

MODEL NO. SCT-ORP-PEN-1

TYPE ORP

RANGE ±1999 mV

ACCURACY ±2%FS

RESOLUTION 1 mV

ATC N/A

POWER 3V X 2 LITHIUM BATTERY

DIMENSION FOR METER 33.5 X 170 MM AND WITH BOX L(230) X H(45)X W(120) MM

WEIGHT ONLY METER 85 G AND COMPLETE WITH BOX 280G

ORDERING INFORMATIONS:

SCT-108.001.07 SCT-ORP-PEN-1 SCT ORP PEN-1 POCKET ORP METER IS SUPPLIED WITH STANDARD SOLUTION, BATTERY,

SCREWDRIVER, AND INSTRUCTION MANUAL , PACKED IN COLOURFUL SUITABLE BOX.

People have within their own hands the tools to fashion their own destiny.

387

sales@scichemtech.com www.scichemtech.com

387

SCT WATER PROOF POCKET pH / mV / TEMP METER (COMBO)

SALIENT FEATURES:

Ɣ 5HOLDEOH6&77HVWHUIRUS+253DQG7HPSHUDWXUHPHDVXUHPHQWV

Ɣ Microprocessor based for fast and accurate measurements.

Ɣ 6SHFLDOYLHZLQJDQJOHGHVLJQHGRIZDWHUSURRIKRXVLQJ,3UDWHG,WÀRDWVRQZDWHU

Ɣ Large LCD display pH, ORP and Temperature simultaneously.

Ɣ Easy to calibrate by one keyboard and Automatic Temperature Compensation (ATC),

Manual Salinity(MSC) and Altitude(MAC) Compensation.

Ɣ Multi-functions with Data-hold, Max/Min and shows PTS after calibration. Degree OC/OF are

switchable.

Ɣ Auto power shut off after 10 minutes of non use.

Ɣ Easy to replace electrode module and the type of electrode would be recognized automatically

and shown in display during insertion.

Ɣ Battery operated. Low battery and consumption indicator.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.16

MODEL NO. SCT-PH-PEN-3

pH mV TEMP.

RANGE -2 ~ 16.00 -1000 ~ 1000 0 ~ 90OC

ACCURACY ± 0.01 + 1DIGIT ±2 + 1DIGIT ± 0.2 + 1DIGIT

RESOLUTION 0.01 pH 1 mV 0.1OC

ATC 0 ~ 90OC

CALIBRATION pH 4.00, 7.00, 10.01

POWER DC1.5V X 4 BATTERY

DIMENSION FOR METER 195 X 40 X 36 MM, KITS: L(235) X H(55) X W(210) MM

WEIGHT METER - 135G (WITH BATTERY) COMPLETE 780G

* ORP (mV) Probe to be ordered separately (not included).

ORDERING INFORMATIONS:

SCT-108.001.16 SCT-PH-PEN-3

SCT pH PEN-3 WATERPROOF HANDHELD PH/mV/TEMP METER IS SUPPLIED WITH STANDARD SOLUTION,

STORAGE SOLUTION (PH4 & PH7), LANYARD CONNECTION, BATTERY AND INSTRUCTION MANUAL ,

PACKED IN A NICE SMALL CARRYING PLASTIC CASE.

SCT-108.001.16A ORP (mV) PROBE

SCT WATER PROOF POCKET COND / TDS / SALT / TEMP METER (COMBO 1)

SALIENT FEATURES:

Ɣ 5HOLDEOH6&77HVWHUIRU&RQGXFWLYLW\7'66DOLQLW\DQG7HPSHUDWXUHPHDVXUHPHQWV

Ɣ 0LFURSURFHVVRUEDVHGIRUIDVWDQGDFFXUDWHPHDVXUHPHQWV

Ɣ 6SHFLDOYLHZLQJDQJOHGHVLJQHGRIZDWHUSURRIKRXVLQJ,3UDWHG,WÀRDWVRQZDWHU

Ɣ /DUJH/&'GLVSOD\&RQGXFWLYLW\7'66DOLQLW\DQG7HPSHUDWXUH6LPXOWDQHRXVO\

Ɣ 6LPSOHWRFDOLEUDWHE\RQHNH\ERDUGDQGDXWRPDWLFWHPSHUDWXUHFRPSHQVDWLRQ$7&

Manual Salinity (MSC) and Altitude (MAC) Compensation.

Ɣ 0XOWLIXQFWLRQVZLWK'DWDKROG0D[0LQDQGVKRZV376DIWHUFDOLEUDWLRQ'HJUHHOC/OF are switchable.

Ɣ $XWRSRZHUVKXWRIIDIWHUPLQXWHVRIQRQXVH

Ɣ (DV\WRUHSODFHHOHFWURGHPRGXOHDQGWKHW\SHRIHOHFWURGHZRXOGEHUHFRJQL]HGDXWRPDWLFDOO\DQG

shown in display during insertion.

Ɣ Battery operated. Low battery and consumption indicator.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.17

MODEL NO. SCT-CON-PEN-3

COND. TDS SALT TEMP.

RANGE 0 ~ 2000 μS 0 ~ 1300 PPM 0 ~1000 PPM 0 ~ 90OC

2.00~20.00 mS 1.30 ~ 13.00 PPT 1.00 ~ 12.00 PPT

ACCURACY ± 2% FS ( COND., TDS, SALT) ± 0.2OC + 1DIGIT

RESOLUTION 1 μS/0.01 mS 1 PPM/0.01 PPT 1 PPM/0.01 PPT 0.1OC

ATC 0 ~ 50OC

CALIBRATION 0, 1413 μS, 12.88 mS

POWER DC1.5V X 4 BATTERY

DIMENSION FOR METER 195 X 40 X 36 MM, KITS: L(235) X H(55) X W(210) MM

WEIGHT METER - 135G (WITH BATTERY) COMPLETE 780G

ORDERING INFORMATIONS:

SCT-108.001.17 SCT-CON-PEN-3

SCT CON PEN-3 WATERPROOF HANDHELD COND, TDS, SALINITY & TEMP METER IS SUPPLIED WITH

STANDARD SOLUTION, STORAGE SOLUTION (PH4 & PH7), LANYARD CONNECTION, BATTERY AND

INSTRUCTION MANUAL , PACKED IN A NICE SMALL CARRYING PLASTIC CASE.

People may hear your words, but they feel your attitude.

388 sales@scichemtech.com www.scichemtech.com

388

SCT WATERPROOF POCKET pH/mV (ORP)/COND/TDS/SALT/TEMP METER (COMBO 2)

SALIENT FEATURES:

Ɣ 5HOLDEOH6&70XOWL7HVWHUIRUS+253&RQGXFWLYLW\6DOLQLW\DQG7HPSHUDWXUHPHDVXUHPHQWV

Ɣ 0LFURSURFHVVRUEDVHGIRUIDVWDQGDFFXUDWHPHDVXUHPHQWV

Ɣ 6SHFLDOYLHZLQJDQJOHGHVLJQHGRIZDWHUSURRIKRXVLQJ,3UDWHG,WÀRDWVRQZDWHU

Ɣ

Large LCD display for pH / ORP / Conductivity /TDS / Salinity and Temperature simultaneously.

Ɣ (DV\WRFDOLEUDWHE\RQHNH\ERDUG DQG$XWRPDWLF7HPSHUDWXUH &RPSHQVDWLRQ $7&0DQXDO

Salinity(MSC) and Altitude(MAC) Compensation.

Ɣ 0XOWLIXQFWLRQV ZLWK 'DWDKROG 0D[0LQ DQG VKRZV 376 DIWHU FDOLEUDWLRQ 'HJUHH OC/OF are

switchable. World best combination handhled meter.

Ɣ $XWRSRZHUVKXWRIIDIWHUPLQXWHVRIQRQXVH

Ɣ (DV\WRUHSODFHHOHFWURGHPRGXOHDQGWKHW\SHRIHOHFWURGHZRXOGEHUHFRJQL]HGDXWRPDWLFDOO\

and shown in display during insertion.

Ɣ Battery operated. Low battery and consumption indicator.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.18

MODEL NO. SCT-pH-PEN-4

pH mV (ORP) TEMP. COND. TDS SALT

RANGE -2 ~ 16.00 -1000 ~ 1000 0 ~ 90OC0 ~ 2000 μS

2.00~20.00 mS

0 ~ 1300 PPM

1.30 ~ 13.00 PPT

0 ~1000 PPM

1.00~12.00 PPT

ACCURACY ± 0.01 +1DIGIT ±2 + 1DIGIT ± 0.2+1 DIGIT ± 2% FS (COND., TDS, SALT)

RESOLUTION 0.01 pH 1 mV 0.1OC1 μS/0.01 mS 1 PPM/0.01 PPT 1 PPM/0.01 PPT

ATC 0 ~ 90OC

CALIBRATION pH 4.00, 7.00, 10.01 0, 1413 μS, 12.88 mS

POWER DC1.5V X 4 BATTERY

DIMENSION FOR METER 195 X 40 X 36 MM, KITS: L(235) X H(55) X W(210) MM

WEIGHT METER - 135G (WITH BATTERY) COMPLETE 780G

ORDERING INFORMATIONS:

SCT-108.001.18 SCT-pH-PEN-4

SCT pH PEN-4 WATERPROOF HANDHELD PH/mV/COND/TDS/SALT/TEMP METER IS SUPPLIED WITH

STANDARD SOLUTION (pH4, pH7 & 1413μS), LANYARD CONNECTION, BATTERY AND INSTRUCTION

MANUAL , PACKED IN A NICE SMALL CARRYING PLASTIC CASE.

SCT-108.001.18A ORP (mV) PROBE

* ORP (mV) Probe to be ordered separately (not included).

SCT pH METER FOR FOOD & SOIL

SALIENT FEATURES:

Ɣ 5HOLDEOH6&7)RRG6RLS+PHWHUZLWKVSHDUWLSS+HOHFWURGHLGHDOIRUS+PHDVXUHPHQWLQWR

soil, meats & cheese.

Ɣ (OHFWURGH IHDWXUHV D YHU\ GXUDEOH JODVV PHDVXULQJ VSHDU SDFNDJHG LQ D UXJJHG YLUWXDOO\

unbreakable epoxy body.

Ɣ $XWRFDOLEUDWLRQIRUS+S+RUS+

Ɣ %XLOGLQUHYHUVHGLVSOD\EXWWRQ

Ɣ 'DWDKROG

Ɣ $XWRSRZHURII

Ɣ &RPSDFWVL]HOLJKWZHLJKW

Ɣ :DWHUUHVLVWDQWRQIURQWSDQHO

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.19

MODEL NO. SCT-pH-PEN-5

MEASUREMENT RANGE 0 TO 14 pH

RESOLUTION 0.01 pH

ACCURACY

+ 0.07 pH (pH5 to pH9)

+ 0.01 pH (pH4 to pH4.9, pH9.1 to pH10)

+ 0.2 pH (pH1 to pH3.9, pH10.1 to pH13)

INPUT INPEDANCE 10^12 ohms.

SAMPLING TIME APPROX. 0.8 SECONDS

CALIBRATION METHOD AUTO CALIBRATION, pH7, pH 4 (or pH 10)

pH ELECTRODE CONNECTOR BNC CONNECTOR

OPERATING TEMPERATURE & HUMIDITY 0 TO 50OC (32 TO 122OF) / LESS THAN 80% RH.

POWER SUPPLY DC 1.5V BATTERY x 4 PCS.

DIMENSION

METER 1: 180 x 40 x 32 mm

ELECTRODE : BODY SIZE - 12 mm DIA x 160 mm

ELECTRODE CABLE LENGTH : APPROX 1000 mm

WEIGHT 220 gm

ORDERING INFORMATIONS:

SCT-108.001.19 SCT-pH-PEN-5 SCT pH-PEN-5 HANDHELD pH METER FOR FOOD & SOIL IS SUPPLIED WITH pH ELECTRODE, pH4, 7

BUFFER SOLUTION AND INSTRUCTION MANUAL.

Perfection is a road, not a destination. Every time i live, i get an education

389

sales@scichemtech.com www.scichemtech.com

389

SCT POCKET LCD DIGITAL THERMO HYGROMETER

SALIENT FEATURES:

Ɣ 5HOLDEOH6&77HVWHUIRU+XPLGLW\DQG7HPSHUDWXUHPHDVXUHPHQWV

Ɣ 6PDOODQGVLPSOHGHVLJQ Ɣ 2SWLRQWRVHOHFWOF/OC.

Ɣ O&7HPS5+UHVROXWLRQ Ɣ 7HPSHUDWXUH+XPLGLW\ZLWKPD[LPXPPLQLPXPLQOF/OC.

Ɣ :LWKUHPRYDEOHFDS Ɣ %DWWHU\RSHUDWHGZLWK/RZ%DWWHU\,QGLFDWRU

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.21

MODEL NO. SCT-THYG-PEN-1

TYPE SCT HANDHELD LCD DIGITAL THERMO HYGROMETER

RANGE 0OC ~ +50OC OR 32OF ~ +122OF / 20% ~ 100% R.H.

ACCURACY ±1.0OC OR ±1.8OF FOR WHOLE RANGE

RESOLUTION 0.1OC FOR WHOLE RANGE / 0.1% R.H. FOR WHOLE

RANGE

POWER 1 X 3 VOLTS

AMBIENT TEMPERATURE FOR PLASTIC CASE 0°C ~ +50OC OR 32OF ~ +122OF

DIMENSION (mm) 165 x 37 x 18

ORDERING INFORMATIONS:

SCT-108.001.21 SCT-THYG-PEN-1 SCT THYG-PEN-1 HANDHELD LCD DIGITAL THERMO HYGROMETER IS SUPPLIED WITH MANUAL & READY TO USE.

SCT POCKET LCD DIGITAL MOVING HEAD THERMO HYGROMETER

SALIENT FEATURES:

Ɣ 5HOLDEOH6&77HVWHUIRU+XPLGLW\DQG Ɣ (UJRQRPLF+HDGPRYLQJGHVLJQ

 7HPSHUDWXUHPHDVXUHPHQWV Ɣ +XPLGLW\7HPSHUDWXUH'XDO'LVSOD\

Ɣ 2SWLRQWRVHOHFWOF/O& Ɣ 0HPRU\UHFDOOLQJ

Ɣ PP3UREH Ɣ *RRGPHDVXULQJUDQJH

Ɣ %DWWHU\RSHUDWHG

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.22

MODEL NO. SCT-THYG-PEN-2

TYPE SCT HANDHELD LCD DIGITAL MOVING HEAD

RANGE 0°C ~ +50°C OR 32°F ~+122°F / 20% ~ 100% R.H.

ACCURACY ±1.0°C OR ±1.8°F FOR WHOLE RANGE

RESOLUTION 0.1°F FOR WHOLE RANGE / 0.1% R.H. FOR WHOLE RANGE

POWER 1 X 3 VOLTS

AMBIENT TEMPERATURE FOR

PLASTIC CASE 0°C ~ +50°C OR 32°F ~ +122°F

ORDERING INFORMATIONS:

SCT-108.001.22 SCT-THYG-PEN-2 SCT THYG PEN-2 HANDHELD LCD DIGITAL MOVING HEAD THERMO HYGROMETER WITH ON/OFF, MAX/MIN, OF/OC,

DUAL DISPLAY (TEMPERATURE AND HUMIDITY) IS SUPPLIED WITH MANUAL AND READY TO USE.

SCT DUAL DISPLAY THERMOHYGROMETER

SALIENT FEATURES:

Ɣ 5HOLDEOH6&73RFNHW7\SH0HWHUIRU+XPLGLW\ Ɣ&RPIRUW:DUP&RROLQGH[ZLWK'XDO'LVSOD\

 7HPSHUDWXUHPHDVXUHPHQWV Ɣ2SWLRQWRVHOHFW2)2&

Ɣ 0D[LPXPPLQLPXP)&WHPSHUDWXUH ƔPVHQVRUZLUHZLWKSUREHIRURXWGRRUPHDVXUHPHQW

 KXPLGLW\PHPRU\UHFDOOLQJ Ɣ,QGRRU2XWGRRU7HPSHUDWXUH+XPLGLW\'LVSOD\

Ɣ %DWWHU\RSHUDWHG Ɣ:LWK)OLSRXW6WDQG

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.23

MODEL NO. SCT-THYG-PEN-3

TYPE SCT JUMBO DUAL DISPLAY THERMO HYGROMETER

RANGE 0°C ~ +70°C OR 32°F ~ +150°F / 20% ~ 100% R.H.

ACCURACY ±1.0°C OR ±1.8°F IN THE RANGE OF -0°C ~ +70°C OR -4°C ~

+158°F; OTHERWISE MORE THAN ±1.0°C OR ±1.8°F

RESOLUTION ±0.1°F FOR WHOLE RANGE / ±0.1% R.H. FOR WHOLE RANGE

POWER 2 X 1.5V

AMBIENT TEMPERATURE FOR

PLASTIC CASE 0°C ~ +50°C OR +14°F ~ +122°F

ORDERING INFORMATIONS:

SCT-108.001.23 SCT-THYG-PEN-3

SCT THYG PEN-1 JUMBO DUAL DISPLAY THERMO HYGROMETER WITH INDOOR/OUTDOOR TEMPERATURE

MEASUREMENT, °F/°C SELECTABLE, MAX/MIN (°F /°C) MEMORY RECALLING, MAX/MIN HUMIDITY MEMORY

RECALLING, COMFORTABLE & UNCOMFORTABLE INDEX IS SUPPLIED WITH MANUAL AND READY TO USE.

Perseverance is failing 19 times and succeeding the 20th.

390 sales@scichemtech.com www.scichemtech.com

390

SCT TRI-THERMO HYGROMETER WITH ALARM CLOCK

SALIENT FEATURES:

Ɣ 5HOLDEOH6&73RFNHW7\SH0HWHUIRU+XPLGLW\7HPSHUDWXUHPHDVXUHPHQWZLWK7LPH'LVSOD\

Ɣ &RPIRUW:DUPFRROLQGH[ZLWK7LPH'LVSOD\

Ɣ 2SWLRQWRVHOHFWOF/OC.

Ɣ 0D[LPXPPLQLPXP)&WHPSHUDWXUHKXPLGLW\PHPRU\UHFDOOLQJ

Ɣ :LWKPVHQVRUIRURXWGRRUPHDVXUHPHQWV

Ɣ &ORFNZLWKDODUPVQRR]HKRXUIRUPDW

Ɣ %DWWHU\RSHUDWHG

Ɣ :LWK)OLSRXW6WDQG

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.24

MODEL NO. SCT-THYG-PEN-4

TYPE SCT JUMBO TRI-THERMO HYGROMETER WITH ALARM CLOCK

RANGE -50°C ~ +70°C OR -58°F ~+150°F / 20% ~ 100% R.H.

ACCURACY ±1.0°C OR ±1.8°F IN THE RANGE OF -20°C ~ +70°C OR -4°C ~

+158°F; OTHERWISE MORE THAN ±1.0°C OR ±1.8°F

RESOLUTION ± 0.1°F FOR WHOLE RANGE / ± 0.1% R.H. FOR WHOLE RANGE

POWER 2X 1.5V

AMBIENT TEMPERATURE

FOR PLASTIC CASE 0°C ~ +50°C OR +14°F ~ +122°F

ORDERING INFORMATIONS:

SCT-108.001.24 SCT-THYG-PEN-4

SCT THYG PEN-4 JUMBO TRI-THERMOHYGROMETER WITH ALARM CLOCK WITH

INDOOR/OUTDOOR TEMPERATURE MEASUREMENT, °F /°C SELECTABLE, MAX/MIN (°F

/°C) MEMORY RECALLING, MAX/MIN HUMIDITY MEMORY RECALLING, ALARM CLOCK

WITH SNOOZE IS SUPPLIED WITH MANUAL AND READY TO USE.

SCT-THYG PEN -5 : POCKET TYPE TEMPERATURE / HUMIDITY DATALOGGER

SALIENT FEATURES:

Ɣ 6&76&77+<*3(1KDVEHHQGHVLJQHGLQDFRPSDFWVLPSOHKDQG\ZD\

Ɣ 6&76&77+<*3(1KDVDZLGHPHDVXULQJUDQJH7HPSWRa5+

Ɣ 6&76&77+<*3(1KDVDVDPSOLQJWLPHRIVHFRQGVWLPHGDWDORJJLQJUHFRUGV

Ɣ 6&7 6&77+)53(1  LV VXLWDEOH IRU FRQWLQXRXV SRUWDEOH PRQLWRULQJ HDV\ WR XVH WKURXJK WKH

software for the parameter setting & analysis. With USB down load.

Ɣ 6&76&77+<*3(1FDQUHFRUGERWK7HPS5+RIWKHVDPHWLPH

Ɣ 6&76&77+<*3(1KDVDFOHDUGLJLWDO/&'72UHDG&DQPHDVXUHLQERWK

°C

°F

, and RH It has

internal Temperature / RH alarm.

Ɣ 6&76&77+<*3(1KDVZLGHUDQJHRIDSSOLFDWLRQVLQWKHYDULRXVLQGXVWULHV

Ɣ 7KLVPHWHUKDVEHHQPDQXIDFWXUHGDV SHU  WKH ,QWHUQDWLRQDO 6WDQGDUGV  ,62  TXDOLW\

standards.

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.001.25

MODEL NO SCT THYG PEN-5

Temperature Measurement Range -40 to 85°C(-40~185°F)

Accuracy ±1.2°C (0.6°F) from -4 to 122°C (-20 to 50°F)

±1.8°C(1.0°F) all other ranges

Resolution 0.1°C

Humidity Type Capacitor

Measurement Range 1%-99% RH

Accuracy ±3.0%RH(20~80%)

±5.0%RH(<20%,>80%)

Resolution 0.1%

Display 3 digits LCD

LED status Red LED of Alarm, greed LED of Record

Sampling rate 1 times/3second

Battery One 3.6V ½ AA lithium battery

Battery Life 1 year

External Power Supply 5 VDC with 0.5A

Operating temperature and humidity -40 to 85°C (-40~185°F),

0-95%, RH, non-condensing

Instrument Dimensions 83(L)*60(W)*24(H) mm

Weight About 77g.

Perseverance is not a long race; it is many short races one after the other.

391

sales@scichemtech.com www.scichemtech.com

391

ORDERING INFORMATIONS:

PRODUCT NO. MODEL NO. DESCRIPTION

SCT-108.001.25 SCT THYG PEN-5 SCT THYG PEN-5 Temperature Dataloggers supplied complete with instruction manual

SCT-TEHR PEN-8 : POCKET TYPE TEMPERATURE DATALOGGER

SALIENT FEATURES:

Ɣ 6&76&77+)53(1KDVEHHQGHVLJQHGLQDFRPSDFWVLPSOH+DQG\ZD\

Ɣ 6&76&77+)53(1KDVDZLGHPHDVXULQJUDQJHWR&a)

Ɣ 6&76&77+)53(1KDVDFOHDUGLJLWDO/&'WRUHDG&DQPHDVXUHLQERWK&)ZLWKLQWHUQDO

Temperature alarm.

Ɣ 6&76&77+)53(1KDVDVDPSOLQJWLPHRIVHFRQGVWLPHGDWDORJJLQJUHFRUGV

Ɣ 6&76&77+)53(1LVVXLWDEOHIRUFRQWLQXRXVSRUWDEOHPRQLWRULQJHDV\WRXVHWKURXJKWKH

software for the parameter setting & analysis.

With USB down load.

Ɣ 6&76&77+)53(1KDVZLGHUDQJHRIDSSOLFDWLRQVLQWKHYDULRXVLQGXVWULHV

Ɣ 7KLVPHWHUKDVEHHQPDQXIDFWXUHGDVSHUWKH,QWHUQDWLRQDO6WDQGDUGV,62TXDOLW\

standards.

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.001.26

MODEL NO SCT-THFR-PEN-7

Measurement Range -40 to 85°C (-40~185°F)

Accuracy ±1.2°C(0.6°F) from -4 to 122°C(-20 to 50°F)

±1.8°C (1.0°F) all other ranges

Resolution 0.1°C

Display 3 digits LCD

LED status Red LED of Alarm, greed LED of Record

Sampling rate 1 time /3second

Battery One 3.6V ½ AA lithium battery

Battery Life 1 year

External Power Supply 5 VDC with 0.5A

Operating Temperature & Humidity -40 to 85°C(-40~185°C),

0-95%, RH, non-condensing

Instrument Dimensions 83(L)*60(W)*24(H) mm

Weight About 77g

ORDERING INFORMATIONS:

PRODUCT NO MODEL NO DESCRIPTION

SCT-108.001.26 SCT-THFR-PEN-7 SCT-THFR-PEN-7 Temperature Data logger is supplied complete with instruction manual

SCT- THER-PEN-7 FRIDGE / FREEZER POCKET THERMOMETER

SALIENT FEATURES:

Ɣ 6&7 7+(53(1 )ULGJH  )UHH]HU 3RFNHW7KHUPRPHWHU KDV EHHQ GHVLJQHG  LQ D FRPSDFW

simple & Ergonomic way.

Ɣ 6&77+(53(1KDVDFOHDUGLVSOD\FDQPHDVXUHLQ&)

Ɣ 6&77+(53(1KDVZDUQLQJDODUPIXQFWLRQV

Ɣ 6&77+(53(1KDVPHWHUSUREHFDEOHZLWKWKH3UREH

Ɣ 6&77+(53(1KDV0D[0LQPHPRU\

Ɣ 7KLVPHWHUKDVEHHQPDQXIDFWXUHGDVSHUWKH,QWHUQDWLRQDO6WDQGDUGV,62TXDOLW\

standards.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.27

MODEL NO. SCT-THFR-PEN-8

Temperature Range -50~70°C/-58-158°F

AccuracY +/-1°C

Alarm Yes

Max /Min memory Yes

Sensor wire for outer door measurement 2 Meter

Material Plastic

Size 68X40X14mm

Box Size 75x65x42mm

ORDERING INFORMATIONS:

PRODUCT NO. MODEL NO. DESCRIPTION

SCT-108.001.27 SCT-THER-PEN-8 SCT- THER-PEN-7 Fridge / Freezer Pocket Thermometer, is supplied complete with 2 meter cable

with probe and the instruction manual

OPTIONAL ACCESSORIES (ORDER ONLY IF REQUIRED)

ACESSORY PRODUCT NO DESCRIPTION

Probe SCT-108.001.27 AA Probe with 2 meter cable

Battery SCT-108.001.27 AB Batteries for SCT- THER-PEN-7 Fridge / Freezer Pocket Thermometer



TXDOLW

Persistence. Perfection. Patience. Power. Prioritize your passion. It keeps you sane

392 sales@scichemtech.com www.scichemtech.com

392

SC T-HERSCHEL : IR THERMOMETER WITH THERMISTOR PROBE

SALIENT FEATURES:

Ɣ 6&7+(56&+(/KDVEHHQGHVLJQHGLQDFRPSDFWDWWUDFWLYH(UJRQRPLFZD\

Ɣ 6&7+(56&+(/KDVDZLGHPHDVXULQJUDQJHOC to 260OC / -31OF to 500OF

Ɣ 6&7+(56&+(/KDVPLQPD[7HPSUHFRUG

Ɣ 6&7+(56&+(/KDVRYHUUDQJHLQGLFDWLRQ

Ɣ 6&7+(56&+(/KDV'DWDKROG$XWRSRZHURII

Ɣ 6&7+(56&+(/KDV8VHUVHOHFWDEOHOC or OF

Ɣ 6&7+(56&+(/KDVFRQWDFWSUREHWRJLYHWKHDFFXUDWHUHVXOWV

Ɣ 6&7+(56&+(/KDVDTXLFNUHVSRQVHWLPH

Ɣ 6&7+(56&+(/KDVDOLJKWZHLJKWWRFDUU\XVHLWHDVLO\

Ɣ 6&7+(56&+(/KDVDZLGHUDQJHRI6FLHQWL¿F,QGXVWULDO$SSOLFDWLRQV

Ɣ 7KLVPHWHUKDVEHHQPDQXIDFWXUHGDVSHUWKH,QWHUQDWLRQDO6WDQGDUGV,62

 TXDOLW\VWDQGDUGV

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.28

MODEL NO SCT-HERSCHEL

IR Temp. Range -35OC to 260OC / -31OF to 500OF

IR Temp. Resolution 0.1OC/OF

Optical Resolution 1:1 Distance to Spot size

Emissivity Adjustable 0.10~1.0

Thermistor Temp. Range -40OC to 260OC / -40OC to 500OC

Resolution 0.1OC/OF

Response Time Less than 1s

Basic Accuracy ±2.0% of reading

Battery Lithium CR 2032 3V x 2

Weight & Dimensions (H*W*D) of the Meter. 80 g and 140mm*42mm*25mm

Warranty Standard one Year International warranty against man-

ufactural defects if any & based our SCT Terms & Con-

ditions Given in the operational Manual.

Quality & Standards This meter has been manufactured as per the Inter-

QDWLRQDO6WDQGDUGV,62TXDOLW\VWDQGDUGV

ORDERING INFORMATIONS:

PRODUCT NO. MODEL NO. DESCRIPTION

SCT-108.001.28 SCT-HERSCHEL

SCT-HERSCHEL Digital IR Thermometer with Thermistor probe supplied complete with instruction manual

OPTIONAL ACCESSORIES (ORDER ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

Probe SCT-108.001.28 AA Thermistor probe

Battery SCT-108.001.28 AB Batteries for SCT-HERSCHEL Digital IR Thermometer

SCT POCKET LCD DIGITAL MULTI-THERMOMETER

SALIENT FEATURES:

Ɣ 5HOLDEOH6&77HVWHUIRU7HPSHUDWXUHPHDVXUHPHQW

Ɣ 6PDOOGHVLJQDQGGLVSOD\

Ɣ 2SWLRQWRVHOHFWOF/OC.

Ɣ 2SWLRQWRKROGWHVWGDWD

Ɣ $XWRVKXWRIILQPLQXWHV

Ɣ 6HQVLQJWLPHVHFRQG

Ɣ PP6WDLQOHVVVWHHOVHQVRUSUREHSURWHFWLYHSODVWLFVOHHYHZLWKFOLS

Ɣ %DWWHU\RSHUDWHGZLWKORZEDWWHU\LQGLFDWRU

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.30

MODEL NO. SCT-THER-PEN-1

TYPE SCT LCD DIGITAL MULTI-THERMOMETER

RANGE -50°C ~ +300°C OR -58°F ~ +572°F

ACCURACY ±1°C IN THE RANGE OF -30°C ~ +250°C / ±1.8°F IN THE RANGE

OF -22°F ~ +482°F, OTHERWISE 2°C

RESOLUTION 0.1°C FOR -19.9°C ~ +199.9°C, OTHERWISE 1°C

POWER 1 X 1.5V

AMBIENT TEMPERATURE FOR

PLASTIC CASE 0°C ~ +50°C OR +14°F ~ +122°F

ORDERING INFORMATIONS:

SCT-108.001.30 SCT-THER-PEN-1

SCT THER PEN-1 LCD DIGITAL MULTI-THERMOMETER WITH 133 MM STAINLESS

STEEL PROBE, ON/OFF, H/T, °F/°C, MAX/MIN (°F/°C) MEMORY RECALLING FUNCTION IS

SUPPLIED WITH MANUAL AND READY TO USE.

Plan,think and work you will win and you should win.

393

sales@scichemtech.com www.scichemtech.com

393

SCT T-BAR DIGITAL MULTI-STEM THERMOMETER

SALIENT FEATURES:

Ɣ 5HOLDEOH6&77HVWHUIRU7HPSHUDWXUH0HDVXUHPHQWV

Ɣ 7%DUVKDSHGJRRGGHVLJQ

Ɣ *RRG7HPSHUDWXUHPD[PLQUDQJH

Ɣ 2SWLRQWRVHOHFW

OF/OC.

Ɣ 2SWLRQWRVHOHFWWHVWKROGGDWH

Ɣ 6HQVLQJWLPHVHFRQG

Ɣ 6WDLQOHVVVWHHOPPSUREH

Ɣ 3URWHFWLYHSODVWLFVOHHYHZLWKFOLSIRUVWDLQOHVVVWHHO

Ɣ %DWWHU\RSHUDWHGZLWKORZEDWWHU\LQGLFDWRU

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.31

MODEL NO. SCT-THER-PEN-2

TYPE SCT T-BAR DIGITAL STEM THERMOMETER

RANGE -50°C ~ +150°C OR -58°F ~+302°F

ACCURACY ± 1OC IN THE RANGE OF -30OC - +50OC (-22OF ~ +392OF)

RESOLUTION 0.1OC FOR -19.9OC ~ +199.9OC

POWER 1 X 1.5 V

AMBIENT TEMPERATURE

FOR PLASTIC CASE 0°C ~ +50°C OR +14°F ~ +122°F

ORDERING INFORMATIONS:

SCT-108.001.31 SCT-THER-PEN-2 SCT THER PEN-2 T-BAR DIGITAL STEM THERMOMETER WITH 133 MM STAINLESS STEEL

PROBE ON/OFF, MAX/MIN (°F/°C) IS SUPPLIED WITH MANUAL AND READY TO USE.

SCT WATERPROOF DIGITAL POCKET MULTI-STEM THERMOMETER

SALIENT FEATURES:

Ɣ 5HOLDEOH6&7:DWHUSURRI7HVWHUIRU7HPSHUDWXUHPHDVXUHPHQW

Ɣ *RRG7HPSHUDWXUHPD[PLQUDQJH

Ɣ 2SWLRQWRVHOHFW

OF/OC.

Ɣ 2SWLRQWRVHOHFWWHVWKROGGDWH

Ɣ 6HQVLQJWLPHVHFRQG

Ɣ 6WDLQOHVVVWHHOPPSUREH

Ɣ 3URWHFWLYHSODVWLFVOHHYHZLWKFOLSIRUVWDLQOHVVVWHHO

Ɣ %DWWHU\RSHUDWHGZLWKORZEDWWHU\LQGLFDWRU

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.32

MODEL NO. SCT-THER-PEN-3

TYPE SCT WATERPROOF DIGITAL POCKET MULTI-STEM THERMOM-

ETER

RANGE -50°C ~ +300°C OR -58°F ~ +572°F

ACCURACY 1°C IN THE RANGE OF -30°C ~ +250°C (-22OF ~ +482OF)

OTHERWISE MORE THAN ± 2°C

RESOLUTION 0.1°C FOR -19.9°C ~ +199.9°C, OTHERWISE 1°C

POWER 1 X 1.5V

AMBIENT TEMPERA-

TURE FOR PLASTIC

CASE

0°C ~ +50°C OR +14°F ~ +122°F

ORDERING INFORMATIONS:

SCT-108.001.32 SCT-THER-PEN-3

SCT THER PEN-3 WATERPROOF DIGITAL POCKET MULTI-STEM THERMOMETER WITH

133 MM STAINLESS STEEL PROBE ON/OFF, MAX/MIN (°F/°C) MEMORY RECALLING

FUNCTION IS SUPPLIED WITH MANUAL AND READY TO USE.

Pleasure in the job puts perfection in the work

394 sales@scichemtech.com www.scichemtech.com

394

SCT FOLDABLE THERMO WITH 10 MEMORIES MOVING HEAD WITH ADJUSTABLE

ANGLE OF 45°/90°/135°/180°

SALIENT FEATURES:

Ɣ 5HOLDEOH6&7)ROGLQJ0HWHUIRU7HPSHUDWXUH0HDVXUHPHQWV

Ɣ (UJRQRPLFGHVLJQ+HDGPRYLQJRSWLRQ

Ɣ 6HQVLQJWLPHVHFRQGIRURQRIIRSHUDWLRQ

Ɣ 2SWLRQWRVHOHFWOF/OC .

Ɣ 0D[0LQPHPRU\UHFDOOLQJ

Ɣ $XWRVKXWRII

Ɣ 6WDLQOHVV6WHHO3UREHPP

Ɣ 2SWLRQWRVHOHFWKROGWHVWGDWD

Ɣ %DWWHU\RSHUDWHGZLWK/RZ%DWWHU\,QGLFDWRU

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.34

MODEL NO. SCT-THER-PEN-5

TYPE SCT FOLDABLE THERMO WITH 10 MEMORIES MOVING HEAD WITH

ADJUSTABLE ANGLE OF 45°/90°/135°/180°

RANGE -50°C ~ +300°C OR -58°F ~+572°F

ACCURACY ±1°C IN THE RANGE OF -30°C ~ +250°C, OTHERWISE 2°C

RESOLUTION 0.1°C FOR -19.9°C ~ +199.9°C, OTHERWISE 1°C

POWER 1 X 1.5V "AAA"

AMBIENT TEMPERATURE FOR

PLASTIC CASE -10°C ~ +50°C OR +14°F ~ +122°F

ORDERING INFORMATIONS:

SCT-108.001.34 SCT-THER-PEN-5

SCT THER PEN-5 FOLDABLE THERMO WITH 133 MM STAINLESS STEEL PROBE 10

MEMORIES MOVING HEAD WITH ADJUSTABLE ANGLE OF 45°/90°/135°/180°WITH ON/OFF,

H/T, °F/°C, MAX/MIN (°F/°C) MEMORY RECALLING, 10 MEMORIES, MEMORY RECALLING,

MEMORY CLEARING, HIGH ALARM, LOW ALARM AND ALARM OFF

IS SUPPLIED WITH

MANUAL AND READY TO USE.

SCT WATER PROOF LCD DIGITAL MULTI-THERMOMETER

SALIENT FEATURES:

Ɣ 5HOLDEOH6&70XOWL7HVWHUIRU7HPSHUDWXUH0HDVXUHPHQWV

Ɣ 3URWHFWLYHSODVWLFFDSIRUVWDLQOHVVVWHHOSUREHSRFNHWFOLSVWDQGRQEDFNXQLWVHQVRUZLUHFRPSDUWPHQW

Ɣ 6HQVLQJWLPHVHFRQGIRURQRIIRSHUDWLRQ

Ɣ 2SWLRQWRVHOHFWOF/OC.

Ɣ 0D[0LQPHPRU\UHFDOOLQJ

Ɣ $XWRVKXWRII

Ɣ 6WDLQOHVV6WHHO3UREHPP

Ɣ 2SWLRQWRVHOHFWKROGWHVWGDWD

Ɣ %DWWHU\RSHUDWHGZLWK/RZ%DWWHU\,QGLFDWRU

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.35

MODEL NO. SCT-THER-PEN-6

TYPE SCT LCD DIGITAL MULTI-THERMOMETER

RANGE -50°C ~ +150°C OR -58°F ~+302°F

ACCURACY ±1°C IN THE RANGE OF -30°C ~ +150°C

RESOLUTION 0.1°C FOR -19.9°C ~ +199.9°C, OTHERWISE 1°C

POWER 1 X "G13"

AMBIENT TEMPERATURE FOR

PLASTIC CASE -10°C ~ +50°C OR +14°F ~+122°F

ORDERING INFORMATIONS:

SCT-108.001.35 SCT-THER-PEN-6

SCT THER PEN-6 LCD DIGITAL MULTI-THERMOMETER WITH ON/OFF, H/T, °F/°C, MAX/MIN

(°F/°C) MEMORY RECALLING, HIGH ALARM AND LOW ALARM FUNCTION IS SUPPLIED

WITH MANUAL AND READY TO USE.

Positive thinking will let you do everything better than negative thinking will.

395

sales@scichemtech.com www.scichemtech.com

395

SCT LCD DIGITAL AIR PRESSURE METER

SALIENT FEATURES:

Ɣ 5HOLDEOH6&77HVWHUIRU$LU3UHVVXUH$OWLWXGHDQG7HPSHUDWXUH0HDVXUHPHQWV

Ɣ &ORFNZLWKWLPHUDODUPVHWWLQJ

Ɣ $LU3UHVVXUH$OWLWXGH'LVSOD\ZLWK%DURJUDSK

Ɣ *UDSKLF'LVSOD\IRUZHDWKHUIRUHFDVW

Ɣ 7LPH'LVSOD\'DWH

Ɣ %DWWHU\RSHUDWHGZLWK/RZ%DWWHU\,QGLFDWRU

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.37

MODEL NO. SCT-AIR-PEN-1

TYPE SCT LCD DIGITAL AIR PRESSURE METER

AIR PRESSURE

TYPE ABSOLUTE

PRESSURE RANGE: 300 ~ 1100MB (HPA); 8.85 INHG ~ 32.45 INHG

RESOLUTION: 1 MB/HPA; 0.01 INHG

SENSING TIME: 15 MINUTES

ALTITUDE

ALTITUDE RANGE: -700M~+9000M, -2296FT ~+29520FT

RESOLUTION: 0.1M FOR -500.0M TO 999.9M; OTHERWISE 1M

SENSING TIME: 2 SECONDS

TEMPERATURE

TEMPERATURE RANGE: -10°C ~ +60°C OR +14°F ~ +140°F

RESOLUTION: 0.1°C OR 0.1°F

SENSING TIME: 1 MINUTE

DIRECTION

RANGE: 0-359°C

RESOLUTION: 1°C

SENSING TIME: 1 SECOND ( LAST FOR 1 MINUTE)

POWER 2 X 3 VOLTS

AMBIENT TEMPERATURE FOR

PLASTIC CASE 0°C ~ +50°C OR +14°F ~+122°F

ORDERING INFORMATIONS:

SCT-108.001.37 SCT-AIR-PEN-1 SCT AIR PEN-1 LCD DIGITAL AIR PRESSURE METER WITH ON/OFF, MODE

(WITH SETTING), BACKLIGHT IS SUPPLIED WITH MANUAL AND READY TO USE.

SCT POCKET VOLTAGE DETECTOR

SALIENT FEATURES:

Ɣ 5HOLDEOH6&78QLTXH7HVWHUIRU9ROWDJH0HDVXUHPHQWV

Ɣ $&9ROWDJH'HGXFWLRQIURP9WR9

Ɣ 1RQFRQGXFWGHGXFWLRQ

Ɣ $ODUP5HG/('9ROWDJH,QGLFDWRU

Ɣ %DWWHU\RSHUDWHGZLWKORZEDWWHU\LQGLFDWRU

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.001.38

MODEL NO. SCT-VOLT-PEN-1

TYPE SCT VOLTAGE DETECTOR

MEASUREMENT RANGE DETECTS FROM 90V TO 600V AC, 50/60 HZ

POWER 3 X 1.5 VOLTS

DIMENSIONS (MM) / WEIGHT (G) 21 X 23 X 130 / 30

AVAILABLE COLOR / PACKAGE GREY / SLIDING BLISTER WITH STANDARD

PRINT CARD

ORDERING INFORMATIONS:

SCT-108.001.38 SCT-VOLT-PEN-1 SCT VOLT PEN-1 LCD DIGITAL AIR PRESSURE METER WITH ON/OFF, MODE (WITH SET-

TING), BACKLIGHT IS SUPPLIED WITH MANUAL AND READY TO USE.

Practice does not make perfect. Perfect practice makes perfect.

396 sales@scichemtech.com www.scichemtech.com

396

ScichemTech® - SCT PORTABLE / HANDHELD METERS

SCT PORTABLE pH METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25S+2530($685(0(176

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+$6$8720$7,&&$/,%5$7,21

AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, FUNCTION SET-UP, SELF-DIAGNOSE

INFORMATION, AUTOMATIC POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ $8720$7,&,'(17,),&$7,212)S+67$1'$5'&$/,%5$7,2162/87,2167+5((237,2162)

STANDARD BUFFER SOLUTIONS: EUROPE AND AMERICAN SERIES AND NIST SERIES.

Ɣ $%/( 72 6(7 S+ 0($685(0(17 02'(6 2) +,*+ 385,7< :$7(5 $1' 385( :$7(5 :,7+

AMMONIA.

Ɣ &$/,%5$7,2162/87,21$1'3257$%/(&$6($1'68,7(',1),(/'$1'216,7(

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.01

MODEL NO. SCT-AIRA

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

MEASURING RANGE -2.00 ~ 19.99 pH

RESOLUTION 0.1/0.01 pH

ACCURACY ±0.01 pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.01 pH/3H

TEMP. COMPENSATION RANGE 0 ~ 100 (AUTOMATIC)

ORP

MEASURING RANGE (mV/ORP/EH) -1999mV ~ 0 ~ 1999 mV

RESOLUTION 1mV

ACCURACY ±0.1% FS, OVERALL: ±15mV

OTHER

TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE

MEASURING UNIT AND TEMPERATURE.

POWER 1.5V X 2

SIZE AND WEIGHT 0(7(5îî00*&$6(

îî00.*

QUALITY AND SAFETY

CERTIFICATION ISO9001:2000, CE

WORKING

CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.002.01 SCT-AIRA

SCT AIRA PORTABLE pH METER IS SUPPLIED WITH PLASTIC PH/ATC THREE-IN-ONE COMBINATION

ELECTRODE, pH STANDARD BUFFER SOLUTION (PH4.00, PH7.00 AND PH10.01/50ML, SCREW DRIVER,

SPARE BATTERIES, OPERATION MANUAL & CARRYING CASE.

* PLS NOTE: ORP ELECTRODE AND ORP SOLUTIONS ARE NOT INCLUDED IT MUST BE PURCHASED SEPARATELY. PLEASE SELECT FROM THE OPTIONAL

ACCESSORIES BELOW:

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO DESCRIPTION

pH COMBINATION ELECTRODE SCT-108.002.A1 PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE MEASURE pH AND TEMPERATURE

SIMUTANEOUSLY, ATC, GENERAL MEASUREMENT, 8 PIN CONNECTOR.

ORP COMBINATION ELECTRODE SCT-108.002.B1 PLASTIC ORP COMBINATION ELECTRODE, SUITED FOR REGULAR ORP MEASUREMENT, 8

PIN CONNECTOR.

SCT-108.002.AA pH 4.00 BUFFER 500 ML

pH BUFFER

SCT-108.002.AB pH 4.00 BUFFER 250 ML

SCT-108.002.AG pH 7.00 BUFFER 500 ML

SCT-108.002.AH pH 7.00 BUFFER 250 ML

SCT-108.002.AM pH 10.01BUFFER 500 ML

SCT-108.002.AN pH 10.01BUFFER 250 ML

ELECTRODE STORAGE SOLUTION SCT-108.002.CA COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

ORP STANDARD SOLUTION SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250 ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100 ML

CARRYING CASE SCT-108.002.KA &$55<,1*&$6(îî00

Pray as if everything depended on god. Work as if everything depended on you.

397

sales@scichemtech.com www.scichemtech.com

397

SCT PORTABLE ORP (OXIDATION REDUCTION POTENTIAL) METER

SALIENT FEATURES :

Ɣ $&203/(7(3257$%/(6&70(7(5)25S+2530($685(0(176

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+

AS DATA STORAGE, FUNCTION SET-UP, AUTOMATIC POWER-OFF AND

LOW VOLTAGE DISPLAY.

Ɣ (48,33(':,7+3/$67,&253(/(&752'()$675(63216($1'

ACCURATE RESULT.

Ɣ (48,33(':,7+25367$1'$5'62/87,21$1'3257$%/(&$6(

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.02

MODEL NO SCT-ALLY

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

ORP

MEASURING RANGE (mV/ORP/Eh) -1999mV ~ 0 ~ 1999mV

RESOLUTION 1mV

ACCURACY ±0.1% FS

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT AND

TEMPERATURE,

POWER 1.5V X 2

SIZE AND WEIGHT 0(7(5îî00*68,7&$6(îî

MM/1.6KG

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.002.02 SCT-ALLY

SCT ALLY PORTABLE ORP METER IS SUPPLIED WITH ORP ELECTRODE,PLASTIC ORP COMBINATION

ELECTRODE, 222mV ORP STANDARD SOLUTION, SCREW DRIVER, SPARE BATTERIES, OPERATION MANUAL

& CARRYING CASE

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO DESCRIPTION

ORP COMBINATION ELECTRODE SCT-108.002.B1 PLASTIC ORP COMBINATION ELECTRODE, SUITED FOR REGULAR ORP MEASUREMENT,

8 PIN CONNECTOR.

ELECTRODE STORAGE SOLUTION SCT-108.002.CA COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

ORP STANDARD SOLUTION SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250 ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100 ML

CARRYING CASE SCT-108.002.KA &$55<,1*&$6(îî00

Pray as though everything depended on god. Work as though everything depended on you.

398 sales@scichemtech.com www.scichemtech.com

398

SCT PORTABLE CONDUCTIVITY / TDS / SALINITY / RESISTIVITY METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25&2'8&7,9,7<0($685(0(176

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+$6$8720$7,&&$/,%5$7,21

AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, FUNCTION SET-UP, AUTOMATIC

POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ $8720$7,& ,'(17,),&$7,21 2)  &21'8&7,9,7< 67$1'$5' &$/,%5$7,21 62/87,216 7:2

OPTIONS OF STANDARD CALIBRATION SOLUTIONS: EUROPE AND AMERICA SERIES.

Ɣ $'237$'9$1&('&21'8&7,9,7<0($685(0(177(&+12/2*<86(&21'8&7,9,7<(/(&752'(

OF CONSTANT K=1, ONLY NEED ONE POINT CALIBRATION AND MEET THE MEASUREMENT PRECISION

5(48,5(0(172)Ȃ6&0a06&0

Ɣ $%,/,7< 72 6:,7&+ $021* &21'8&7,9,7< 7'6 6$/,1,7< $1' 5(6,67,9,7< 08/7,120,$/

CALCULATION FOR TDS AND SALINITY TO ENSURE THE CONVERSION PRECISION OF THE FULL

SCALE.

Ɣ &21'8&7,9,7< 0($685(0(17 02'( +$6 7+( )81&7,21 2) 121/,1($5 7(03(5$785(

COMPENSATION FOR HIGH PURITY WATER.

Ɣ 3/$67,& &21'8&7,9,7< (/(&752'( :,7+ $8720$7,& 7(03(5$785( &203(16$7,21 )$67

RESPONSE AND ACCURATE RESULT.

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.03

MODEL NO SCT-AVARI

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY0.00~19.99μS/CM 20.0~199.9μS/CM 200~1999μS/CM

2.00~19.99mS/CM 20.0~199.9mS/CM

TDS: 0 ~ 100G/L

SALINITY 0 ~ 100PPT

5(6,67,9,7<a0ȍā&0

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1 mS/CM

ACCURACY ±1.0% FS

TEMP. COMPENSATION RANGE 0 ~ 50 (MANUAL)

ELECTRODE CONSTANT 0.1 / 1 / 10 CM-1

BENCHMARK TEMPERATURE 25 20 AND 18

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT AND

TEMPERATURE,

POWER 1.5V X2

SIZE AND WEIGHT 0(7(5îî00*68,7&$6(îî00.*

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUST PROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.002.03 SCT-AVARI

SCT AVARI CONDUCTIVITY METER IS SUPPLIED WITH PLASTIC CONDUCTIVITY ELECTRODE, 1413μS/

CM CONDUCTIVITY STANDARD SOLUTION, SCREW DRIVER, SPARE BATTERIES, OPERATION MANUAL &

CARRYING CASE

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO DESCRIPTION

CONDUCTIVITY ELECTRODE SCT-108.002.C1 PLASTIC CONDUCTIVITY ELECTRODE, K=1.0 CM-1 ATC, SUITED FOR CONDUCTIVITY

MEASUREMENT OF GENERAL WATER SOLUTION, 8 PIN CONNECTOR.

CONDUCTIVITY STANDARD

SCT-108.002.BA 84 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BD 1413 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BE 1413 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BG 12.88 mS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BH 12.88 mS/CM CONDUCTIVITY STANDARD 250 ML

CARRYING CASE SCT-108.002.KA &$55<,1*&$6(îî00

Price is what you pay. Value is what you get

399

sales@scichemtech.com www.scichemtech.com

399

SCT PORTABLE DO (DISSOLVED OXYGEN) METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25',662/9('2;<*(10($685(0(176

Ɣ 0($685(0(1702'(2)',662/9('2;<*(1+$67+()81&7,212)$8720$7,&7(03(5$785(

COMPENSATION, AUTOMATIC SALINITY COMPENSATION AND MANUAL AIR PRESSURE

COMPENSATION.

Ɣ 1(: 32/$52*5$3+,& 7<3( ',662/9(' 2;<*(1 (/(&752'( &$1 0($685( 7(03(5$785(

SALINITY AND DISSOLVED OXYGEN SIMULTANEOUSLY, EQUIPPED WITH SPECIAL DISSOLVED

OXYGEN ELECTRODE CALIBRATION SET, POLARIZATION ONLY FOR 3~5 MIN.

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+$6$8720$7,&&$/,%5$7,21

DATA STORAGE, FUNCTION SET-UP, AUTOMATIC POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ &20%,1(' ',$3+5$*0 &$3 5(3/$&($%/( 6(16,7,9( 0(0%5$1( 6&5(: 1(: ',$3+5$*0

CAP TO ELECTRODE, EASY TO USE.

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.04

MODEL NO SCT-BEA

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

DISSOLVED OXYGEN

MEASURING RANGE 0 ~ 40.00 MG/L(PPM) 0 ~ 200.0 %

RESOLUTION 0.1/0.01 MG/L(PPM) 1/0.1 %

ACCURACY ±0.10 MG/L

RESPONSE TIME 6OC , 90%RESPONSE

RESIDUAL CURRENT 0*/

TEMP. COMPENSATION RANGE 0 ~ 45 (AUTOMATIC)

SALINITY COMPENSATION RANGE 0 ~ 45 PPT(AUTOMATIC)

ATMOSPHERIC PRESSURE COMPENSATION RANGE 66 ~ 200 KPA (MANUAL)

AUTOMATIC CALIBRATION AIR SATURATED BY WATER; WATER SATURATED BY AIR

ELECTRODE TYPE POLAROGRAM TYPE

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT

AND TEMPERATURE,

POWER 1.5V X 2

SIZE AND WEIGHT îî00*68,7&$6(îî00.*

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.002.04 SCT-BEA

SCT BEA DO METER IS SUPPLIED WITH DO ELECTRODE, MEMBRANE CAP (DO ELECTRODE USE),

DO ELECTRODE INNER SOLUTION CATHODE POLISHING PAPER, SCREW DRIVER, SPARE BATTERIES,

OPERATION MANUAL & CARRYING CASE

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO DESCRIPTION

DO ELECTRODE SCT-108.002.D1 DO ELECTRODE, POLAROGRAPHIC DO ELECTRODE, SUITED FOR APPLICATION IN LAB AND

FIELD, 8 PIN CONNECTOR.

DO ELECTRODE ACCESSORY

SCT-108.002.D2 DO ELECTRODE MEMBRANE CAP, COMBINED MEMBRANE CAP, SPECIAL FOR DO

ELECTRODE, SPECIFICATION: 3 UNITS PER GROUP.

SCT-108.002.IA DO ELECTRODE ELECTROLYTE, SUPPLEMENT ELECTROLYTE, SPECIAL FOR DO

ELECTRODE, SPECIFICATION: 30ML/BOTTLE.

SCT-108.002.IB NEGATIVE ELECTRODE POLISHING PAPER, POLISHING PAPER SPECIAL FOR CLEANING

NEGATIVE ELECTRODE, 2 PCS/PACK.

CARRYING CASE SCT-108.002.KA &$55<,1*&$6(îî00

3URJUHVVDOZD\VLQYROYHVULVNV<RXFDQ·WVWHDOVHFRQGEDVHDQGNHHS\RXUIRRWRQÀUVW

400 sales@scichemtech.com www.scichemtech.com

400

SCT PORTABLE pH/ORP / TEMP METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25S+2530($685(0(176

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+$6$8720$7,&&$/,%5$7,21

AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, FUNCTION SET-UP, SELF-DIAGNOSE

INFORMATION, AUTOMATIC POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ '28%/(3$5$0(7(50(7(5(48,33(':,7+7+5((,121(&20%,1$7,21S+(/(&752'($1'

ORP ELECTRODE, AUTOMATIC IDENTIFICATION OF ELECTRODE BY METER.

Ɣ $8720$7,&,'(17,),&$7,212)S+67$1'$5'&$/,%5$7,2162/87,2167+5((237,2162)

STANDARD BUFFER SOLUTIONS: EUROPE, AMERICA SERIES &NIST SERIES.

Ɣ $%/( 72 6(7 S+ 0($685(0(17 02'(6 2) +,*+ 385,7< :$7(5 $1' 385( :$7(5 :,7+

AMMONIA

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.05

MODEL NO SCT-BUCK

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

MEASURING RANGE -2.00 ~ 19.99 pH

RESOLUTION 0.1/0.01 pH

ACCURACY ±0.01pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.01 pH/3H

TEMP. COMPENSATION RANGE 0 ~ 100 (AUTOMATIC)

ORP

MEASURING RANGE (mV/ORP/EH) -1999mV ~ 0 ~ 1999mV

RESOLUTION 1mV

ACCURACY ±0.1% FS

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT AND

TEMPERATURE,

POWER 1.5V X 2

SIZE AND WEIGHT 0(7(5îî00*68,7&$6(îî00.*

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.002.05 SCT-BUCK

SCT BUCK pH/ORP METER IS SUPPLIED WITH PLASTIC PH/ATC THREE-IN-ONE COMBINED

ELECTRODE,PLASTIC ORP COMBINED ELECTRODE, pH STANDARD BUFFER SOLUTION,220mV ORP

STANDARD SOLUTION, SCREW DRIVER,SPARE BATTERIES,OPERATION MANUAL & CARRYING CASE

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO. DESCRIPTION

pH COMBINATION ELECTRODE SCT-108.002.A1 PLASTIC THREE-IN-ONE pH ELECTRODE, MEASURE pH AND TEMPERATURE

SIMULTANEOUSLY, ATC, SUITED FOR GENERAL pH MEASUREMENT, 8 PIN CONNCETOR.

ORP COMBINATION ELECTRODE SCT-108.002.B1 PLASTIC ORP COMBINATION ELECTRODE, SUITED FOR GENERAL ORP MEASUREMENT,

8 PIN CONNECTOR.

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500 ML

SCT-108.002.AB pH4.00 BUFFER 250 ML

SCT-108.002.AG pH7.00 BUFFER 500 ML

SCT-108.002.AH pH7.00 BUFFER 250 ML

SCT-108.002.AM pH10.01 BUFFER 500 ML

SCT-108.002.AN pH10.01 BUFFER 250 ML

ELECTRODE STORAGE SOLUTION SCT-108.002.CA pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

ORP STANDARD SOLUTION SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250 ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100 ML

CARRYING CASE SCT-108.002.KB &$55<,1*&$6(îî00

Put your heart, mind, and soul into even your smallest acts. This is the secret of success.

401

sales@scichemtech.com www.scichemtech.com

401

SCT PORTABLE pH / CONDUCTIVITY / TDS / SALINITY / RESISTIVITY METER

SALIENT FEATURES:

Ɣ A COMPLETE PORTABLE SCT METER FOR pH, CONDUCTIVITY / TDS / SALINITY / RESISTIVITY

MEASUREMENTS.

Ɣ DOUBLE-PARAMETER METER, EQUIPPED WITH pH ELECTRODE AND CONDUCTIVITY ELECTRODE,

AUTOMATIC IDENTIFICATION OF ELECTRODE BY METER.

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+$6$8720$7,&&$/,%5$7,21

AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, FUNCTION SET-UP, SELF-DIAGNOSE

INFORMATION, AUTOMATIC POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ $8720$7,& ,'(17,),&$7,21 2)  S+ 67$1'$5' %8))(5 62/87,216 7+5(( 237,216 2)

STANDARD BUFFER SOLUTIONS: EUROPE AND AMERICA SERIES & NIST SERIES

Ɣ $%/( 72 6(7 S+ 0($685(0(17 02'(6 2) +,*+ 385,7< :$7(5 $1' 385( :$7(5 :,7+

AMMONIA.

Ɣ $8720$7,& ,'(17,),&$7,21 2)  &21'8&7,9,7< 67$1'$5' &$/,%5$7,21 62/87,216 7:2

OPTIONS OF STANDARD CALIBRATION SOLUTIONS: EUROPE AND AMERICA SERIES.

Ɣ $'237$'9$1&('&21'8&7,9,7<0($685(0(177(&+12/2*<86(&21'8&7,9,7<(/(&752'(

OF CONSTANT K=1, ONLY NEED ONE POINT CALIBRATION AND MEET THE MEASUREMENT PRECISION

5(48,5(0(172)Ȃ6&0a06&0

Ɣ $%,/,7< 72 6:,7&+ $021* &21'8&7,9,7< 7'6 6$/,1,7< $1' 5(6,67,9,7< 08/7,120,$/

CALCULATION FOR TDS AND SALINITY TO ENSURE THE CONVERSION PRECISION OF THE FULL

SCALE.

Ɣ &21'8&7,9,7< 0($685(0(17 02'( +$6 7+( )81&7,21 2) 121/,1($5 7(03(5$785(

COMPENSATION FOR HIGH PURITY WATER.

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.06

MODEL NO SCT-BONO

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

MEASURING RANGE -2.00 ~ 19.99 pH

RESOLUTION 0.1/0.01 PH

ACCURACY ±0.01pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.01 pH/3H

TEMP. COMPENSATION RANGE 0 ~ 100 (AUTOMATIC)

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~19.99 μS/CM 20.0~199.9 μS/CM 200~1999 μS/

CM 2.00~19.99 mS/CM 20.0~199.9 mS/CM

TDS: 0 ~ 100G/L

SALINITY: 0 ~ 100 PPT

5(6,67,9,7<a0ȍā&0

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1 mS/CM

ACCURACY ±1.0% FS

TEMP. COMPENSATION RANGE 0 ~ 50 (MANUAL)

ELECTRODE CONSTANT 0.1 / 1 / 10 CM-1

BENCHMARK TEMPERATURE 25 20 AND 18

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT AND

TEMPERATURE,

POWER 1.5V X 2

SIZE AND WEIGHT 0(7(5îî00*68,7&$6(îî00.*

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.002.06 SCT-BONO

SCT BONO pH/CONDUCTIVITY METER IS SUPPLIED WITH PLASTIC PH/ATC THREE-IN-ONE COMBINED ELECTRODE,

PLASTIC CONDUCTIVITY ELECTRODE,PH STANDARD BUFFER SOLUTION,1413μS/CM CONDUCTIVITY STANDARD

SOLUTION,SCREW DRIVER,SPARE BATTERIES,OPERATION MANUAL & CARRYING CASE.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO DESCRIPTION

pH COMBINATION ELECTRODE SCT-108.002.A1 PLASTIC THREE-IN-ONE pH ELECTRODE, MEASURE pH AND TEMPERATURE

SIMULTANEOUSLY, ATC, SUITED FOR GENERAL pH MEASUREMENT, 8 PIN CONNCETOR.

CONDUCTIVITY ELECTRODE SCT-108.002.C1 PLASTIC CONDUCTIVITY ELECTRODE, K=1.0 CM-1 ATC, SUITED FOR CONDUCTIVITY

MEASUREMENT OF GENERAL WATER SOLUTION, 8 PIN CONNECTOR.

Put yourself in your customer’s place

402 sales@scichemtech.com www.scichemtech.com

402

PH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500 ML

SCT-108.002.AB pH4.00 BUFFER 250 ML

SCT-108.002.AG pH7.00 BUFFER 500 ML

SCT-108.002.AH pH7.00 BUFFER 250 ML

SCT-108.002.AM pH10.01 BUFFER 500 ML

SCT-108.002.AN pH10.01 BUFFER 250 ML

CONDUCTIVITY STANDARD

SCT-108.002.BA 84 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BD 1413 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BE 1413 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BG 12.88 mS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BH 12.88 mS/CM CONDUCTIVITY STANDARD 250 ML

ELECTRODE STORAGE SOLUTION SCT-108.002.CA pH, ORP COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB pH, ORP COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

CARRYING CASE SCT-108.002.KB &$55<,1*&$6(îî00

SCT PORTABLE pH / ORP / DISSOLVED OXYGEN METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25S+253$1'',662/9('2;<*(10($685(0(176

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+$6$8720$7,&&$/,%5$7,21

AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, FUNCTION SET-UP, SELF-DIAGNOSE

INFORMATION, AUTOMATIC POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ '28%/(3$5$0(7(5 0(7(5 (48,33(' :,7+ S+ (/(&752'( $1' ',662/9(' 2;<*(1

ELECTRODE, AUTOMATIC IDENTIFICATION OF ELECTRODE BY METER.

Ɣ $8720$7,& ,'(17,),&$7,21 2)  S+ 67$1'$5' %8))(5 62/87,216 7+5(( 237,216 2)

STANDARD BUFFER SOLUTIONS: EUROPE AND AMERICA SERIES & NIST SERIES.

Ɣ $%/( 72 6(7 S+ 0($685(0(17 02'(6 2) +,*+ 385,7< :$7(5 $1' 385( :$7(5 :,7+

AMMONIA.

Ɣ 0($685(0(1702'(2)',662/9('2;<*(1+$67+()81&7,212)$8720$7,&7(03(5$785(

COMPENSATION, AUTOMATIC SALINITY COMPENSATION AND MANUAL AIR PRESSURE

COMPENSATION.

Ɣ 1(: 32/$52*5$3+,& 7<3( ',662/9(' 2;<*(1 (/(&752'( &$1 0($685( 7(03(5$785(

SALINITY AND DISSOLVED OXYGEN SIMULTANEOUSLY, EQUIPPED WITH SPECIAL DISSOLVED

OXYGEN ELECTRODE CALIBRATION SET, POLARIZATION ONLY FOR 3~5 MIN.

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.07

MODEL NO SCT-BUD

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

MEASURING RANGE -2.00 ~ 19.99 pH

RESOLUTION 0.1/0.01 pH

ACCURACY ±0.01 pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.01 pH/3H

TEMP. COMPENSATION RANGE 0 ~ 100 (AUTOMATIC)

ORP

MEASURING RANGE (mV/ORP) -1999mV ~ 0 ~ 1999mV

RESOLUTION 1mV

ACCURACY ±0.1% FS

DISSOLVED OXYGEN

MEASURING RANGE 0 ~ 40.00MG/L (PPM) 0 ~ 200.0%

RESOLUTION 0.1/0.01 MG/L (PPM) 1/0.1 %

ACCURACY ±0.10 MG/L

RESPONSE TIME 65(63216(

RESIDUAL CURRENT 0*/

TEMP. COMPENSATION RANGE 0 ~ 45 (AUTOMATIC)

SALINITY COMPENSATION RANGE 0 ~ 45 PPT(AUTOMATIC)

ATMOSPHERIC PRESSURE COMPENSATION RANGE 66 ~ 200 KPA (MANUAL)

AUTOMATIC CALIBRATION AIR SATURATED BY WATER; WATER SATURATED BY AIR

ELECTRODE TYPE POLAROGRAM TYPE

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT AND

TEMPERATURE

POWER 1.5V X 2

SIZE AND WEIGHT 0(7(5îî00*68,7&$6(îî00.*

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

Quality means doing it right when no one is looking

403

sales@scichemtech.com www.scichemtech.com

403

ORDERING INFORMATIONS:

SCT-108.002.07 SCT-BUD

SCT BUD pH / mV / DO METER IS SUPPLIED WITH PLASTIC PH/ATC THREE-IN-ONE COMBINED

ELECTRODE, DO ELECTRODE,PH STANDARD BUFFER SOLUTION, MEMBRANE CAP, DO ELECTRODE

INNER SOLUTION, CATHODE POLISHING PAPER, SCREW DRIVER, SPARE BATTERIES,OPERATION

MANUAL AND CARRYING CASE.

* PLS NOTE: ORP ELECTRODE AND ORP SOLUTIONS ARE NOT INCLUDED MUST BE PURCHASED SEPARATELY. PLEASE SELECT FROM THE OPTIONAL

ACCESSORIES BELOW:

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO DESCRIPTION

pH COMBINATION ELECTRODE SCT-108.002.A1

PLASTIC THREE-IN-ONE pH ELECTRODE

MEASURE pH AND TEMPERATURE SIMULTANEOUSLY, ATC, SUITED FOR GENERAL pH

MEASUREMENT, 8 PIN CONNCETOR.

ORP COMBINATION

ELECTRODE SCT-108.002.B1 PLASTIC ORP COMBINATION ELECTRODE

SUITED FOR GENERAL ORP MEASUREMENT, 8 PIN CONNECTOR.

DO ELECTRODE SCT-108.002.D1 DO ELECTRODE, POLAROGRAPHIC DO ELECTRODE, SUITED FOR APPLICATION IN LAB AND

FIELD, 8 PIN CONNECTOR.

DO ELECTRODE ACCESSORY

SCT-108.002.D2 DO ELECTRODE MEMBRANE CAP, COMBINED MEMBRANE CAP, SPECIAL FOR DO

ELECTRODE, SPECIFICATION: 3 UNITS PER GROUP.

SCT-108.002.IA DO ELECTRODE ELECTROLYTE, SUPPLEMENT ELECTROLYTE, SPECIAL FOR DO

ELECTRODE, SPECIFICATION: 30ML/BOTTLE.

SCT-108.002.IB NEGATIVE ELECTRODE POLISHING PAPER, POLISHING PAPER SPECIAL FOR CLEANING

NEGATIVE ELECTRODE OF DO ELECTRODE, SPECIFICATION:2 PCS/GROUP.

PH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500 ML

SCT-108.002.AB pH4.00 BUFFER 250 ML

SCT-108.002.AG pH7.00 BUFFER 500 ML

SCT-108.002.AH pH7.00 BUFFER 250 ML

SCT-108.002.AM pH10.01 BUFFER 500 ML

SCT-108.002.AN pH10.01 BUFFER 250 ML

ELECTRODE STORAGE

SOLUTION

SCT-108.002.CA pH ORP COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB pH ORP COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

ORP STANDARD SOLUTION SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250 ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100 ML

CARRYING CASE SCT-108.002.KB &$55<,1*&$6(îî00

SCT PORTABLE CONDUCTIVITY / TDS / SALINITY / RESISTIVITY / DISSOLVED OXYGEN /

TEMP METER

SALIENT FEATURES:

Ɣ $ &203/(7( 3257$%/( 6&70(7(5 )25 &2'8&7,9,7< $1' ',662/9(' 2;<*(1

MEASUREMENTS.

Ɣ '28%/(3$5$0(7(5 0(7(5 (48,33(' :,7+ &21'8&7,9,7< (/(&752'( $1' ',662/9('

OXYGEN ELECTRODE, AUTOMATIC IDENTIFICATION OF ELECTRODE BY METER.

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+$6$8720$7,&&$/,%5$7,21

AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, FUNCTION SET-UP, AUTOMATIC

POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ $8720$7,& ,'(17,),&$7,21 2)  &21'8&7,9,7< 67$1'$5' &$/,%5$7,21 62/87,216 7:2

OPTIONS OF STANDARD CALIBRATION SOLUTIONS: EUROPE AND AMERICA SERIES.

Ɣ $'237$'9$1&('&21'8&7,9,7<0($685(0(177(&+12/2*<86(&21'8&7,9,7<(/(&752'(

OF CONSTANT K=1, ONLY NEED ONE POINT CALIBRATION AND MEET THE MEASUREMENT PRECISION

5(48,5(0(172)Ȃ6&0a06&0

Ɣ $%,/,7< 72 6:,7&+ $021* &21'8&7,9,7< 7'6 6$/,1,7< $1' 5(6,67,9,7< 08/7,120,$/

CALCULATION FOR TDS AND SALINITY TO ENSURE THE CONVERSION PRECISION OF THE FULL

SCALE.

Ɣ &21'8&7,9,7< 0($685(0(17 02'( +$6 7+( )81&7,21 2) 121/,1($5 7(03(5$785(

COMPENSATION FOR HIGH PURITY WATER.

Ɣ 0($685(0(1702'(2)',662/9('2;<*(1+$67+()81&7,212)$8720$7,&7(03(5$785(

COMPENSATION, AUTOMATIC SALINITY COMPENSATION AND MANUAL AIR PRESSURE

COMPENSATION.

Ɣ 1(: 32/$52*5$3+,& 7<3( ',662/9(' 2;<*(1 (/(&752'( &$1 0($685( 7(03(5$785(

SALINITY AND DISSOLVED OXYGEN SIMULTANEOUSLY, EQUIPPED WITH SPECIAL DISSOLVED

OXYGEN ELECTRODE CALIBRATION SET, POLARIZATION ONLY FOR 3~5 MIN.

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

Read it with anger and you will feel vengeful.

404 sales@scichemtech.com www.scichemtech.com

404

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.08

MODEL NO SCT-CADE

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~19.99 μS/CM 20.0~199.9 μS/CM 200~1999

μS/CM 2.00~19.99 mS/CM 20.0~199.9 mS/CM

TDS: 0 ~ 100 G/L

SALINITY: 0 ~ 100 PPT

5(6,67,9,7<a0ȍā&0

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1 mS/CM

ACCURACY ±1.0% FS

TEMP. COMPENSATION RANGE 0 ~ 50 (MANUAL)

ELECTRODE CONSTANT 0.1 / 1 / 10 CM-1

BENCHMARK TEMPERATURE 25, 20 AND 18

DISSOLVED OXYGEN

MEASURING RANGE 0 ~ 40.00 MG/L(PPM) 0 ~ 200.0 %

RESOLUTION 0.1/0.01 MG/L(PPM) 1/0.1 %

ACCURACY ±0.10 MG/L

RESPONSE TIME 65(63216(

RESIDUAL CURRENT 0*/

TEMP. COMPENSATION RANGE 0 ~ 45 (AUTOMATIC)

SALINITY COMPENSATION RANGE 0 ~ 45 PPT(AUTOMATIC)

ATMOSPHERIC PRESSURE COMPENSATION RANGE 66 ~ 200 KPA (MANUAL)

AUTOMATIC CALIBRATION AIR SATURATED BY WATER; WATER SATURATED BY AIR

ELECTRODE TYPE POLAROGRAM TYPE

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT AND

TEMPERATURE,

POWER 1.5V X 2

SIZE AND WEIGHT 0(7(5îî00*68,7&$6(îî

MM/1.6KG

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.002.08 SCT-CADE

SCT CADE CONDUCTIVITY/TDS/SALINITY/RESISTIVITY/DO/TEMP METER IS SUPPLIED WITH PLASTIC

CONDUCTIVITY ELECTRODE, DO ELECTRODE,1413μS/CM CONDUCTIVITY STANDARD SOLUTION,

MEMBRANE CAP (DO ELECTRODE USE), DO ELECTRODE INNER SOLUTION,CATHODE POLISHING

PAPER,SCREW DRIVER,SPARE BATTERIES, OPERATION MANUAL AND CARRYING CASE

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO DESCRIPTION

CONDUCTIVITY ELECTRODE SCT-108.002.C1 PLASTIC CONDUCTIVITY ELECTRODE K=1.0 CM-1 ATC, SUITED FOR CONDUCTIVITY

MEASUREMENT OF GENERAL WATER SOLUTION, 8 PIN CONNECTOR.

DO ELECTRODE SCT-108.002.D1 DO ELECTRODE, POLAROGRAPHIC DO ELECTRODE, SUITED FOR APPLICATION IN LAB AND

FIELD, 8 PIN CONNECTOR.

DO ELECTRODE

ACCESSORY

SCT-108.002.D2 DO ELECTRODE MEMBRANE CAP, COMBINED MEMBRANE CAP, SPECIAL FOR DO ELECTRODE,

SPECIFICATION: 3 UNITS PER GROUP.

SCT-108.002.IA DO ELECTRODE ELECTROLYTE, SUPPLEMENT ELECTROLYTE, SPECIAL FOR DO ELECTRODE,

SPECIFICATION: 30ML/BOTTLE.

SCT-108.002.IB NEGATIVE ELECTRODE POLISHING PAPER, POLISHING PAPER SPECIAL FOR CLEANING

NEGATIVE ELECTRODE OF DO ELECTRODE, SPECIFICATION:2 PCS/GROUP.

CONDUCTIVITY STANDARD

SCT-108.002.BA 84 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BD 1413 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BE 1413 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BG 12.88 mS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BH 12.88 mS/CM CONDUCTIVITY STANDARD 250 ML

CARRYING CASE SCT-108.002.KB &$55<,1*&$6(îî00

Read it with empathy and you will feel compassion.

405

sales@scichemtech.com www.scichemtech.com

405

SCT PORTABLE pH/ORP/CONDUCTIVITY/TDS/SALINITY/RESISTIVITY/TEMP METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25S+253$1'&21'8&7,9,7<0($685(0(176

Ɣ 08/7,3$5$0(7(5 0(7(5 (48,33(' :,7+ S+ (/(&752'( 253 (/(&752'( $1'

CONDUCTIVITY ELECTRODE, AUTOMATIC IDENTIFICATION OF ELECTRODE BY METER.

Ɣ %8,/7,1 0,&52352&(6625 &+,36 ,17(//,*(17 )81&7,216 68&+ $6 $8720$7,&

CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, FUNCTION SET-

UP, SELF-DIAGNOSE INFORMATION, AUTOMATIC POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ $8720$7,& ,'(17,),&$7,212)S+ 67$1'$5'%8))(562/87,2167+5((237,2162)

STANDARD BUFFER SOLUTIONS: EUROPE AND AMERICA SERIES & NIST SERIES

Ɣ $%/( 72 6(7 S+ 0($685(0(17 02'(6 2) +,*+ 385,7< :$7(5 $1' 385( :$7(5 :,7+

AMMONIA.

Ɣ $8720$7,&,'(17,),&$7,212)&21'8&7,9,7<67$1'$5'&$/,%5$7,2162/87,2167:2

OPTIONS OF STANDARD CALIBRATION SOLUTIONS: EUROPE AND AMERICA SERIES.

Ɣ $'237 $'9$1&(' &21'8&7,9,7< 0($685(0(17 7(&+12/2*< 86( &21'8&7,9,7<

ELECTRODE OF CONSTANT K=1, ONLY NEED ONE POINT CALIBRATION AND MEET THE

0($685(0(1735(&,6,215(48,5(0(172)Ȃ6&0a06&0

Ɣ $%,/,7< 72 6:,7&+$021* &21'8&7,9,7< 7'6 6$/,1,7<$1' 5(6,67,9,7< 08/7,120,$/

CALCULATION FOR TDS AND SALINITY TO ENSURE THE CONVERSION PRECISION OF THE FULL

SCALE.

Ɣ &21'8&7,9,7< 0($685(0(17 02'( +$6 7+( )81&7,21 2) 121/,1($5 7(03(5$785(

COMPENSATION FOR HIGH PURITY WATER.

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.09

MODEL NO SCT-CADY

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

MEASURING RANGE -2.00 ~ 19.99 pH

RESOLUTION 0.1/0.01 pH

ACCURACY ±0.01 pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.01 pH/3H

TEMP. COMPENSATION RANGE 0 ~ 100 (AUTOMATIC)

ORP

MEASURING RANGE (mV/ORP) -1999mV ~ 0 ~ 1999mV

RESOLUTION 1mV

ACCURACY ±0.1% FS

CONDUCTIVITY

MEASURING RANGE CONDUCTIVITY 0.00~19.99 μS/CM 20.0~199.9 μS/CM 200~1999μS/CM

2.00~19.99 mS/CM 20.0~199.9 mS/CM

TDS: 0 ~ 100 G/L

SALINITY: 0 ~ 100 PPT

5(6,67,9,7<a0ȍā&0

RESOLUTION 0.01/0.1/1mS/CM 0.01/0.1 mS/CM

ACCURACY ±1.0% FS

TEMP. COMPENSATION RANGE 0 ~ 50 (MANUAL)

ELECTRODE CONSTANT 0.1 / 1 / 10 CM-1

BENCHMARK TEMPERATURE 25 20 AND 18

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT AND

TEMPERATURE,

POWER 1.5V X 2

SIZE AND WEIGHT 0(7(5îî00*68,7&$6(îî00.*

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.002.09 SCT-CADY

SCT CADY PH/ORP/CONDUCTIVITY/TDS/SALINITY/RESISTIVITY/TEMP METER IS SUPPLIED WITH PLASTIC

pH/ATC THREE-IN-ONE COMBINED ELECTRODE,PLASTIC ORP COMBINED ELECTRODE, PLASTIC

CONDUCTIVITY ELECTRODE,PH STANDARD BUFFER SOLUTION,1413μS/CM CONDUCTIVITY STANDARD

SOLUTION, SCREW DRIVER, SPARE BATTERIES, OPERATION MANUAL AND CARRYING CASE

Read it with god and you will feel the truth.

406 sales@scichemtech.com www.scichemtech.com

406

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO. DESCRIPTION

PH COMBINATION ELECTRODE SCT-108.002.A1 PLASTIC THREE-IN-ONE pH ELECTRODE, MEASURE pH AND TEMPERATURE

SIMULTANEOUSLY, ATC, SUITED FOR GENERAL pH MEASUREMENT, 8 PIN CONNCETOR.

ORP COMBINATION ELECTRODE SCT-108.002.B1 PLASTIC ORP COMBINATION ELECTRODE, CLASS= ”TDBG01”, SUITED FOR GENERAL ORP

MEASUREMENT, 8 PIN CONNECTOR.

CONDUCTIVITY ELECTRODE SCT-108.002.C1 PLASTIC CONDUCTIVITY ELECTRODE, K=1.0 CM-1 ATC, SUITED FOR CONDUCTIVITY

MEASUREMENT OF GENERAL WATER SOLUTION, 8 PIN CONNECTOR.

PH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500 ML

SCT-108.002.AB pH4.00 BUFFER 250 ML

SCT-108.002.AG pH7.00 BUFFER 500 ML

SCT-108.002.AH pH7.00 BUFFER 250 ML

SCT-108.002.AM pH10.01 BUFFER 500 ML

SCT-108.002.AN pH10.01 BUFFER 250 ML

CONDUCTIVITY STANDARD

SCT-108.002.BA 84 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BD 1413 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BE 1413 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BG 12.88 mS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BH 12.88 mS/CM CONDUCTIVITY STANDARD 250 ML

ELECTRODE STORAGE

SOLUTION

SCT-108.002.CA pH ORP COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB pH ORP COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

ORP STANDARD SOLUTION SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250 ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100 ML

CARRYING CASE SCT-108.002.KB &$55<,1*&$6(îî00

SCT PORTABLE pH/CONDUCTIVITY/TDS/SALINITY/RESISTIVITY/DO/TEMP METER

SALIENT FEATURES:

Ɣ $ &203/(7( 3257$%/( 6&70(7(5 )25 S+ 253 &21'8&7,9,7<7'66$/,1,7<5(6,67,9,7<

DISSOLVED OXYGEN AND TEMP. MEASUREMENTS.

Ɣ 08/7,3$5$0(7(5 0(7(5 (48,33(' :,7+ S+ (/(&752'( &21'8&7,9,7< (/(&752'( $1'

DISSOLVED OXYGEN ELECTRODE, AUTOMATIC IDENTIFICATION OF ELECTRODE BY METER.

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+$6$8720$7,&&$/,%5$7,21

AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, FUNCTION SET-UP, SELF-DIAGNOSE

INFORMATION, AUTOMATIC POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ $8720$7,& ,'(17,),&$7,21 2)  S+ 67$1'$5' %8))(5 62/87,216 7+5(( 237,216 2)

STANDARD BUFFER SOLUTIONS: EUROPE AND AMERICA SERIES & NIST SERIES.

Ɣ $%/( 72 6(7 S+ 0($685(0(17 02'(6 2) +,*+ 385,7< :$7(5 $1' 385( :$7(5 :,7+

AMMONIA.

Ɣ $8720$7,& ,'(17,),&$7,21 2)  &21'8&7,9,7< 67$1'$5' &$/,%5$7,21 62/87,216 7:2

OPTIONS OF STANDARD CALIBRATION SOLUTIONS: EUROPE AND AMERICA SERIES.

Ɣ $'237$'9$1&('&21'8&7,9,7<0($685(0(177(&+12/2*<86(&21'8&7,9,7<(/(&752'(

OF CONSTANT K=1, ONLY NEED ONE POINT CALIBRATION AND MEET THE MEASUREMENT PRECISION

5(48,5(0(172)Ȃ6&0a06&0

Ɣ $%,/,7< 72 6:,7&+ $021* &21'8&7,9,7< 7'6 6$/,1,7< $1' 5(6,67,9,7< 08/7,120,$/

CALCULATION FOR TDS AND SALINITY TO ENSURE THE CONVERSION PRECISION OF THE FULL

SCALE.

Ɣ &21'8&7,9,7< 0($685(0(17 02'( +$6 7+( )81&7,21 2) 121/,1($5 7(03(5$785(

COMPENSATION FOR HIGH PURITY WATER.

Ɣ 0($685(0(1702'(2)',662/9('2;<*(1+$67+()81&7,212)$8720$7,&7(03(5$785(

COMPENSATION, AUTOMATIC SALINITY COMPENSATION AND MANUAL AIR PRESSURE

COMPENSATION.

Ɣ 1(: 32/$52*5$3+,& 7<3( ',662/9(' 2;<*(1 (/(&752'( &$1 0($685( 7(03(5$785(

SALINITY AND DISSOLVED OXYGEN SIMULTANEOUSLY, EQUIPPED WITH SPECIAL DISSOLVED

OXYGEN ELECTRODE CALIBRATION SET, POLARIZATION ONLY FOR 3~5 MIN.

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.10

MODEL NO SCT-DAVY

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

MEASURING RANGE -2.00 ~ 19.99 pH

RESOLUTION 0.1/0.01 pH

ACCURACY ±0.01pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.01 pH/3H

TEMP. COMPENSATION RANGE 0 ~ 100 (AUTOMATIC)

ORP

MEASURING RANGE (mV/ORP/EH) -1999mV ~ 0 ~ 1999mV

RESOLUTION 1mV

ACCURACY METER:±0.1% FS, OVERALL: ±15mV

Read it with hope and you will feel positive.

407

sales@scichemtech.com www.scichemtech.com

407

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~19.99 μS/CM 20.0~199.9 μS/CM 200~1999

μS/CM 2.00~19.99 mS/CM 20.0~199.9 mS/CM

TDS: 0 ~ 100 G/L

SALINITY 0 ~ 100 PPT

5(6,67,9,7<a0ȍā&0

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1 mS/CM

ACCURACY ±1.0% FS

TEMP. COMPENSATION RANGE 0 ~ 50 (MANUAL)

ELECTRODE CONSTANT 0.1 / 1 / 10 CM-1

BENCHMARK TEMPERATURE 25 / 20 AND 18

DISSOLVED OXYGEN

MEASURING RANGE 0 ~ 40.00MG/L(PPM) 0 ~ 200.0%

RESOLUTION 0.1/0.01 MG/L(PPM) 1/0.1 %

ACCURACY ±0.10 MG/L

RESPONSE TIME 65(63216(

RESIDUAL CURRENT 0*/

TEMP. COMPENSATION RANGE 0 ~ 45 (AUTOMATIC)

SALINITY COMPENSATION RANGE 0 ~ 45 PPT(AUTOMATIC)

ATMOSPHERIC PRESSURE COMPENSATION RANGE 66 ~ 200 KPA (MANUAL)

AUTOMATIC CALIBRATION AIR SATURATED BY WATER; WATER SATURATED BY AIR

ELECTRODE TYPE POLAROGRAM TYPE

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT AND

TEMPERATURE,

POWER 1.5V X 2

SIZE AND WEIGHT 0(7(5îî00*68,7&$6(îî00.*

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.002.10 SCT-DAVY

SCT DAVY pH/ORP/CONDUCTIVITY/TDS/SALINITY/RESISTIVITY/DO/TEMP METER IS SUPPLIED WITH

PLASTIC PH/ATC THREE-IN-ONE COMBINED ELECTRODE, PLASTIC CONDUCTIVITY ELECTRODE, DO

ELECTRODE, pH STANDARD BUFFER SOLUTION,1413 μS/CM CONDUCTIVITY STANDARD SOLUTION,

SCREW DRIVER, SPARE BATTERIES, OPERATION MANUAL AND CARRYING CASE.

* PLS NOTE: ORP ELECTRODE / ACCESSORIES ARE NOT INCLUDED MUST BE PURCHASED SEPARATELY. PLEASE SELECT FROM THE OPTIONAL

ACCESSORIES BELOW:

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO. DESCRIPTION

pH COMBINATION ELECTRODE SCT-108.002.A1

PLASTIC THREE-IN-ONE pH ELECTRODE

MEASURE pH AND TEMPERATURE SIMULTANEOUSLY, ATC, SUITED FOR GENERAL pH

MEASUREMENT, 8 PIN CONNCETOR.

ORP COMBINATION

ELECTRODE SCT-108.002.B1 PLASTIC ORP COMBINATION ELECTRODE, CLASS=”TDBG01”, SUITED FOR GENERAL ORP

MEASUREMENT, 8 PIN CONNECTOR.

CONDUCTIVITY ELECTRODE SCT-108.002.C1 PLASTIC CONDUCTIVITY ELECTRODE, K=1.0 CM-1 ATC, SUITED FOR CONDUCTIVITY

MEASUREMENT OF GENERAL WATER SOLUTION, 8 PIN CONNECTOR.

DO ELECTRODE SCT-108.002.D1 DO ELECTRODE, POLAROGRAPHIC DO ELECTRODE, SUITED FOR APPLICATION IN LAB AND

FIELD, 8 PIN CONNECTOR.

DO ELECTRODE ACCESSORY

SCT-108.002.D2 DO ELECTRODE MEMBRANE CAP, COMBINED MEMBRANE CAP, SPECIAL FOR DO ELECTRODE,

SPECIFICATION: 3 UNITS PER GROUP.

SCT-108.002.IA DO ELECTRODE ELECTROLYTE, SUPPLEMENT ELECTROLYTE, SPECIAL FOR DO ELECTRODE,

SPECIFICATION: 30ML/BOTTLE.

SCT-108.002.IB NEGATIVE ELECTRODE POLISHING PAPER, POLISHING PAPER SPECIAL FOR CLEANING

NEGATIVE ELECTRODE OF DO ELECTRODE, SPECIFICATION:2 PCS/GROUP.

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500 ML

SCT-108.002.AB pH4.00 BUFFER 250 ML

SCT-108.002.AG pH 7.00 BUFFER 500 ML

SCT-108.002.AH pH 7.00 BUFFER 250 ML

SCT-108.002.AM pH10.01 BUFFER 500 ML

SCT-108.002.AN pH10.01 BUFFER 250 ML

CONDUCTIVITY STANDARD

SCT-108.002.BA 84 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BD 1413 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BE 1413 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BG 12.88 mS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BH 12.88 mS/CM CONDUCTIVITY STANDARD 250 ML

ELECTRODE STORAGE

SOLUTION

SCT-108.002.CA pH ORP COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB pH ORP COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

ORP STANDARD SOLUTION SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250 ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100 ML

CARRYING CASE SCT-108.002.KB &$55<,1*&$6(îî00

Read it with humor and you will feel joy.

408 sales@scichemtech.com www.scichemtech.com

408

SCT PORTABLE pH/ORP/CONDUCTIVITY/TDS/SALINITY/RESISTIVITY/DO/TEMP METER

SALIENT FEATURES:

Ɣ $ &203/(7( 3257$%/( 6&70(7(5 )25 S+ 253 &21'8&7,9,7< $1' ',662/9(' 2;<*(1

MEASUREMENTS.

Ɣ %8,/7,10,&52352&(6625&+,36,17(//,*(17)81&7,21668&+$6$8720$7,&&$/,%5$7,21

AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, FUNCTION SET-UP, SELF-DIAGNOSE

INFORMATION, AUTOMATIC POWER-OFF AND LOW VOLTAGE DISPLAY.

Ɣ 08/7,3$5$0(7(5 0(7(5 (48,33(' :,7+ S+ (/(&752'( 253 (/(&752'( &21'8&7,9,7<

ELECTRODE AND DISSOLVED OXYGEN ELECTRODE, AUTOMATIC IDENTIFICATION OF ELECTRODE

BY METER.

Ɣ $8720$7,&,'(17,),&$7,212)S+67$1'$5'&$/,%5$7,2162/87,2167+5((237,2162)

STANDARD BUFFER SOLUTIONS: EUROPE AND AMERICA SERIES & NIST SERIES

Ɣ $%/( 72 6(7 S+ 0($685(0(17 02'(6 2) +,*+ 385,7< :$7(5 $1' 385( :$7(5 :,7+

AMMONIA.

Ɣ $8720$7,& ,'(17,),&$7,21 2)  &21'8&7,9,7< 67$1'$5' &$/,%5$7,21 62/87,216 7:2

OPTIONS OF STANDARD CALIBRATION SOLUTIONS: EUROPE AND AMERICA SERIES

Ɣ $'237$'9$1&('&21'8&7,9,7<0($685(0(177(&+12/2*<86(&21'8&7,9,7<(/(&752'(

OF CONSTANT K=1, ONLY NEED ONE POINT CALIBRATION AND MEET THE MEASUREMENT PRECISION

5(48,5(0(172)Ȃ6&0a06&0

Ɣ $%,/,7< 72 6:,7&+ $021* &21'8&7,9,7< 7'6 6$/,1,7< $1' 5(6,67,9,7< 08/7,120,$/

CALCULATION FOR TDS AND SALINITY TO ENSURE THE CONVERSION PRECISION OF THE FULL

SCALE.

Ɣ &21'8&7,9,7< 0($685(0(17 02'( +$6 7+( )81&7,21 2) 121/,1($5 7(03(5$785(

COMPENSATION FOR HIGH PURITY WATER.

Ɣ 0($685(0(1702'(2)',662/9('2;<*(1+$67+()81&7,212)$8720$7,&7(03(5$785(

COMPENSATION, AUTOMATIC SALINITY COMPENSATION AND MANUAL AIR PRESSURE

COMPENSATION.

Ɣ 1(: 32/$52*5$3+,& 7<3( ',662/9(' 2;<*(1 (/(&752'( &$1 0($685( 7(03(5$785(

SALINITY AND DISSOLVED OXYGEN SIMULTANEOUSLY, EQUIPPED WITH SPECIAL DISSOLVED

OXYGEN ELECTRODE CALIBRATION SET, POLARIZATION ONLY FOR 3~5 MIN.

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.11

MODEL NO SCT-DEON

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

MEASURING RANGE -2.00 ~ 19.99 pH

RESOLUTION 0.1/0.01 pH

ACCURACY ±0.01pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.01 pH/3H

TEMP. COMPENSATION RANGE 0 ~ 100 (AUTOMATIC)

ORP

MEASURING RANGE (mV/ORP/EH) -1999mV ~ 0 ~ 1999mV

RESOLUTION 1mV

ACCURACY ±0.1% FS

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~19.99 μS/CM 20.0~199.9 μS/CM 200~1999

μS/CM 2.00~19.99 mS/CM 20.0~199.9 mS/CM

TDS: 0 ~ 100 G/L

SALINITY: 0 ~ 100 PPT

5(6,67,9,7<a0ȍā&0

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1 mS/CM

ACCURACY ±1.0% FS

TEMP. COMPENSATION RANGE 0 ~ 50 (MANUAL)

ELECTRODE CONSTANT 0.1 / 1 / 10 CM-1

BENCHMARK TEMPERATURE 25 20 AND 18

DISSOLVED OXYGEN

MEASURING RANGE 0 ~ 40.00 MG/L(PPM) 0 ~ 200.0 %

RESOLUTION 0.1/0.01 MG/L(PPM) 1/0.1 %

ACCURACY ±0.10 MG/L

RESPONSE TIME 65(63216(

RESIDUAL CURRENT 0*/

TEMP. COMPENSATION RANGE 0 ~ 45 (AUTOMATIC)

SALINITY COMPENSATION RANGE 0 ~ 45 PPT(AUTOMATIC)

ATMOSPHERIC PRESSURE COMPENSATION RANGE 66 ~ 200 KPA (MANUAL)

AUTOMATIC CALIBRATION AIR SATURATED BY WATER; WATER SATURATED BY AIR

ELECTRODE TYPE POLAROGRAM TYPE

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 200 GROUPS

STORAGE CONTENT SERIES NUMBER, MEASURING VALUE MEASURING UNIT AND

TEMPERATURE,

POWER 1.5V X 2

SIZE AND WEIGHT 0(7(5îî00*68,7&$6(îî00.*

QUALITY AND SAFETY CERTIFICATION ISO9001:2000, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP57 DUSTPROOF AND WATERPROOF

5HDGLWZLWKORYHDQG\RXZLOOIHHOÁDWWHU\

409

sales@scichemtech.com www.scichemtech.com

409

ORDERING INFORMATIONS:

SCT-108.002.11 SCT-DEON

SCT DEON pH/ORP/CONDUCTIVITY/TDS/SALINITY/RESISTIVITY/DO/TEMP METER IS SUPPLIED WITH PLASTIC

PH/ATC THREE-IN-ONE COMBINATION ELECTRODE,PLASTIC ORP COMBINATION ELECTRODE,PLASTIC

CONDUCTIVITY ELECTRODE,DO ELECTRODE, pH STANDARD BUFFER SOLUTION, 1413μS/CM CONDUCTIVITY

STANDARD SOLUTION,MEMBRANE CAP, DO ELECTRODE INNER SOLUTION, CATHODE POLISHING PAPER,

SCREW DRIVER, SPARE BATTERIES, OPERATION MANUAL AND CARRYING CASE

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO DESCRIPTION

PH COMBINATION ELECTRODE SCT-108.002.A1 PLASTIC THREE-IN-ONE pH ELECTRODE, MEASURE pH AND TEMPERATURE

SIMULTANEOUSLY, ATC, SUITED FOR GENERAL pH MEASUREMENT, 8 PIN CONNCETOR.

ORP COMBINATION ELECTRODE SCT-108.002.B1 PLASTIC ORP COMBINATION ELECTRODE, CLASS=”TDBG01”, SUITED FOR GENERAL

ORP MEASUREMENT, 8 PIN CONNECTOR.

CONDUCTIVITY ELECTRODE SCT-108.002.C1 PLASTIC CONDUCTIVITY ELECTRODE, K=1.0 CM-1 ATC, SUITED FOR CONDUCTIVITY

MEASUREMENT OF GENERAL WATER SOLUTION, 8 PIN CONNECTOR.

DO ELECTRODE SCT-108.002.D1 DO ELECTRODE, POLAROGRAPHIC DO ELECTRODE, SUITED FOR APPLICATION IN LAB

AND FIELD, 8 PIN CONNECTOR.

DO ELECTRODE ACCESSORY

SCT-108.002.D2 DO ELECTRODE MEMBRANE CAP, COMBINED MEMBRANE CAP, SPECIAL FOR DO

ELECTRODE, SPECIFICATION: 3 UNITS PER GROUP.

SCT-108.002.IA DO ELECTRODE ELECTROLYTE, SUPPLEMENT ELECTROLYTE, SPECIAL FOR DO

ELECTRODE, SPECIFICATION: 30ML/BOTTLE.

SCT-108.002.IB NEGATIVE ELECTRODE POLISHING PAPER, POLISHING PAPER SPECIAL FOR CLEANING

NEGATIVE ELECTRODE OF DO ELECTRODE, SPECIFICATION:2 PCS/GROUP.

PH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500 ML

SCT-108.002.AB pH4.00 BUFFER 250 ML

SCT-108.002.AG pH7.00 BUFFER 500 ML

SCT-108.002.AH pH7.00 BUFFER 250 ML

SCT-108.002.AM pH10.01 BUFFER 500 ML

SCT-108.002.AN pH10.01 BUFFER 250 ML

CONDUCTIVITY STANDARD

SCT-108.002.BA 84 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BD 1413 μS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BE 1413 μS/CM CONDUCTIVITY STANDARD 250 ML

SCT-108.002.BG 12.88 mS/CM CONDUCTIVITY STANDARD 500 ML

SCT-108.002.BH 12.88 mS/CM CONDUCTIVITY STANDARD 250 ML

ELECTRODE STORAGE SOLUTION SCT-108.002.CA PH ORP COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB PH ORP COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

ORP STANDARD SOLUTION SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 500 ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 250 ML

CARRYING CASE SCT-108.002.KB %,*3257$%/(&$6(îî000$7&+08/7,(/(&752'(

SCT PORTABLE WATER HARDNESS METER

SALIENT FEATURES:

Ɣ $ &203/(7( 3257$%/( 6&70(7(5 )25 &$/&,80 $1' 0$*1(6,80 ,216 +$5'1(66

MEASUREMENTS.

Ɣ 3257$%/( 0(7(5)250($685(0(172):$7(5+$5'1(667+(727$/&21&(175$7,212)

CALCIUM ION AND MAGNESIUM ION).

Ɣ (/(&752'($'2376:$7(5+$5'1(66&20%,1$7,21(/(&752'(:,7+3$7(176758&785(,7

CONSISTS OF MEASUREMENT ELECTRODE, REFERENCE ELECTRODE AND TEMPERATURE PROBE.

REPLACEABLE MEASURING HEAD, STEADY POTENTIAL, FAST RESPONSE, EASY TO USE.

Ɣ 0(7(5$'2376,17(//,*(17&+,3'(6,*1$8720$7,&&$/,%5$7,21$8720$7,&7(03(5$785(

COMPENSATION, TIME DISPLAY, DATA STORAGE, LOW VOLTAGE DISPLAY, ETC.

Ɣ $%,/,7<726:,7&+$021*(,*+781,760PRO/PJ/&D&23), mg/L (CaO), Mmol/L (BOILER), mg/L

(Ca). THREE OPTIONS OF THREE UNITS : ºFH FRANCE ºDH GERMANY AND ºEH, UK FROM WH-LINK

COMMUNICATION SOFTWARE.

Ɣ (48,33(':,7+%%$1'%&$/,%5$7,2162/87,216

Ɣ 6&70(7(50((76,62&(67$1'$5'6$1':$7(53522),3

Read it with paranoia and you will feel confusion.

410 sales@scichemtech.com www.scichemtech.com

410

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.12

MODEL NO SCT-ETTA

CATEGORY PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

WATER HARDNESS

MEASURING RANGE

0 ~ 10 Mmol/L 0 ~ 401 mg/L(Ca)

0 ~ 1000 mg/L(CAaCO3) 0 ~ 100 ºFH(FRANCE DEGREE)

0 ~ 561 mg/L(CAO) 0 ~ 56 ºDH(GERMAN DEGREE)

0 ~ 20 Mmol/L (BOILER) 0 ~ 70 ºEH (ENGLAND DEGREE)

RESOLUTION 0.01 AND 0.1 WATER HARDNESS UNITS

ACCURACY ±5% FS

TEMP. COMPENSATION 5 ~ 50 AUTOMATIC

CALIBRATION SOLUTION

%&$/,%5$7,2162/87,21î0PRO/

%&$/,%5$7,2162/87,21î0PRO/

B3 CALIBRATION SOLUTION -- 2.00 Mmol/L

B3CALIBRATION SOLUTION ALSO CAN BE USED FOR

THE STORAGE SOLUTION OF ELECTRODE

CALIBRATION MODE

(A)B1/B2 CALIBRATION - USING B1 AND B2 CALIBRATION

62/87,2168,7$%/()25î0PRO//2:

CONCENTRATION WATER QUALITY FOR EXAMPLE,

BOILER WATER.

(B)CALIBRATION - USING B2 AND B3 CALIBRATION

SOLUTION SUITABLE FORGENERAL WATER QUALITY.

TEMPERATURE

MEASURING RANGE 0 ~ 60

RESOLUTION 0.1

ACCURACY ±0.5

OTHER TECHNICAL

PARAMETER

DATA STORAGE 99 GROUPS

CONTENT STORAGE

SERIAL NUMBER OF MEASURING VALUE, MEASURING

VALUE, UNITS, TEMPERATURE, ATC OR MTC, DATE,

TIME AND CALIBRATION WAY.

9î

POWER DIMENSION AND

WEIGHT

0(7(5îî00*&$55<&$6(

îî00*

QUALITY & SAFECERTIFICATE ISO9001:2000 AND CE

WORKING

CONDITIONS

AMBIENT TEMPERATURE (5~35)

AMBIENT HUMIDITY 5+

ORDERING INFORMATIONS:

SCT-108.002.12 SCT-ETTA

SCT ETTA WATER HARDNESS METER IS SUPPLIED WITH WATER HARDNESS ELECTRODE( WITH

TWO MEASURING HEADS AND ONE SCREW PLUG), CELL (1.5V ),100ML HARDNESS CALIBRATION

SOLUTION ( B1, B2 AND B3 ),20ML TEST CUP,TEST CUP PEDESTAL,REFERENCE SOLUTION,TOOLS

FOR FILLING REFERENCE SOLUTION,CARRING CASE,OPERATION MANUAL

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY CATEGORY PRODUCT NO DESCRIPTION

WATER HARDNESS ELECTRODE SCT-108.002.E1 WATER HARDNESS ELECTRODE, SUITED FOR MEASUREMENT OF TOTAL

CONCENTRATION OF CALCIUM ION AND MAGNESIUM ION, METER, 8 PIN CONNECTOR

WATER HARDNESS ELECTRODE

ACCESSORY

SCT-108.002.E2 WATER HARDNESS ELECTRODE MEASURING HEAD

SCT-108.002.HA WATER HARDNESS ELECTRODE INNER REFERENCE SOLUTION

SCT-108.002.HB REFERENCE SOLUTION FILLING TOOL

WATER HARDNESS CALIBRATION

SOLUTION

SCT-108.002.EA WATER HARDNESS CALIBRATION SOLUTION B1 250 ML

SCT-108.002.EB WATER HARDNESS CALIBRATION SOLUTION B1 100 ML

SCT-108.002.FA WATER HARDNESS CALIBRATION SOLUTION B2 250 ML

SCT-108.002.FB WATER HARDNESS CALIBRATION SOLUTION B2 100 ML

SCT-108.002.GA WATER HARDNESS CALIBRATION SOLUTION B3 250 ML

SCT-108.002.GB WATER HARDNESS CALIBRATION SOLUTION B3 100 ML

SCT-108.002.GD WATER HARDNESS ELECTRODE CALIBRATION SOLUTION (B1, B2, B3 X 100 ML)

SCT-108.002.JA PLASIC TEST CUP, SPECIFICATION 20ML

ACCESSORIES SCT-108.002.JB TEST CUP BASE, PLACE TEST CUP ON THE BASE

Read it with sorrow and you will feel hate.

411

sales@scichemtech.com www.scichemtech.com

411

SCT- JERA PORTABLE / HAND HELD TURBIDITY METER

SALIENT FEATURES:

Ɣ 6&7-(5$3257$%/(785%,',7<0(7(5,6'(6,*1(')25,7¶6&203$&71(66$1'(/(*$1&(

Ɣ 6&7-(5$23(5$7(6:,7+$0,&52352&(6625&,5&8,7)25,7¶6+,*+$&&85$&<$1'7+(5(/,$%/(

RESULTS..

Ɣ 6&7-(5$,686(5)5,(1'/<0(7(5%(&$86(,7¶6%8772166,03/(.(<3$'23(5$7,216

Ɣ 6&7 -(5$ 0((76 ,62   178 0($685,1* 81,767+( 81,7 23(5$7(6 :,7+ 7+( 1(3+(/20(75,&

PRINCIPLE.

Ɣ 6&7-(5$,6352'8&('720((7:,'(5$1*(2)0($685(0(17672178720((7$//7<3(

2)&86720(5¶61(('6$1'7+(81,7&$1%(&203$5$%/(%(77(57+$1$1</($',1*&200(5&,$/

BRANDS.

Ɣ 6&7-(5$+$6$ 81,48( 237,&66758&785(0$.(67+(,167580(17720($685(/2:72+,*+

VALUES OF TURBIDITY UP TO 1000 NTU.

Ɣ 6&7 -(5$ +$6 ,1%8,/7 %87721 )25 ($6< 7:2 32,176 &$/,%5$7,21 $1' 7+( 0(7(5 +$6 $ +,*+

RESOLUTIONS OF 0.01 NTU / 1.0 NTU

Ɣ 6&7 -(5$ ',63/$<6 7+( 5(68/76 ,1 $ &/($5 /$5*( /&':+,&+ 0$.(6 7+( 86(56 72 6(( 7+(

MEASUREMENTS CLEARLY.

Ɣ 6&7-(5$+$69(5<1,&()81&7,216/,.('$7$+2/',1*)25)((=,1*7+(8/7,0$7(9$/8($8726+87

OFF IF NOT OPERATED FOR LONG TIMES TO SAVE THE BATTERY.ALSO, IT HAS MEMORY RECALL FUNCTIONS

WITH RECORDING MIN-MAX READINGS.

Ɣ 6&7-(5$,6$+$1'+(/'%$77(5<23(5$7('),(/'216,7(7(67,1*0(7(566833/,(',1$5,*,'

NICE CARRYING CASE.

Ɣ 6&7-(5$,67(67(')2523(5$7,1*,1$1<67$1'$5'7(03(5$785(8372&$1'7+(5(/$7,9(

HUMIDITY RH 85%

Ɣ 6&7-(5$+$6$:,'(5$1*(2)$33/,&$7,216,17+(:$7(5)22'$1'(19,5210(17$/,1'8675,(6

ALSO,IT HAS FEW CLINICAL APPLICATIONS.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.15

MODEL NO. SCT-JERA

INTERNATIONAL STANDARDS MEETS ISO 7027

MEASURING RANGES 0.00 TO 50.00 NTU, 50 TO 1,000 NTU

* NTU : NEPHELOMETRIC TURBIDITY UNIT

* AUTO RANGE

RESOLUTIONS 0.01 NTU/ 1 NTU

TYPE OF THE CIRCUIT CUSTOM ONE-CHIP OF MICROPROCESSOR LSI CIRCUIT

DATA DISPLAY LCD SIZE : 41 MM X 34 MM

MEASURING ACCURACY ± 5 % F.S. OR ± 0.5 NTU, WHICH EVER IS GREATER

LIGHT SOURCE LED (LIGHT EMITTING DIODE) 850 NM

PRINCIPLE DETECTOR PHOTO DIODE

0(7(5¶65(63216(7,0( LESS THAN 10 SECONDS

SAMPLE VOLUME 10 ML

DATA HOLD FREEZE THE DISPLAY READING

MEMORY RECALL MAXIMUM & MINIMUM VALUE

DISPLAY SAMPLING TIME APPROX. 1 SECOND

POWER OFF AUTO SHUT OFF SAVES BATTERY LIFE OR MANUAL OFF BY PUSH BUTTON

CALIBRATION POINTS 2 POINTS, 0 NTU& 100 NTU

OPERATING TEMPERATURE TEMPERATURE 0 TO 50OC

OPERATING HUMIDITY HUMIDITY LESS THAN 85% R.H

POWER SUPPLY DC 1.5 V BATTERY ( UM4, AAA ) X 6 PCS OR EQUIVALENT

POWER STAND BY APPROX. DC 3.5 MA. TESTING APPROX. DC 36 MA

WEIGHT 320 G/0.70 LB. @ BATTERY IS INCLUDED

DIMENSIONS 155 X 76 X 62 MM ( 6.1 X 3.0 X 2.4 INCHES)

ORDERING INFORMATIONS:

SCT-108.002.15 SCT-JERA SCT TURBIDTY METER SUPPLIED COMPLETE WITH 0 NTU & 100 NTU STANDARD SOLUTION, SAMPLE

CUVETTES, CLEANING CLOTH, CLEANING SOLUTION ( DISTILL WATER ) AND HARD CARRYING CASE

OPTIONAL ACCESSORIES SELECT ONLY THE REQUIRED:

SCT-108.002.15A CALIBRATION SOLUTION 0 NTU

SCT-108.002.15B CALIBRATION SOLUTION 100 NTU

SCT-108.002.15C SAMPLE CUVETTE

SCT PORTABLE SUSPENDED SOLIDS (TSS) ANALYZER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)256863(1'('62/,'60($685(0(176

Ɣ 6&7.(9,10(7(5'(6,*1('720($685(7+(6863(1'('62/,'686,1*237,&$/6(1625

Ɣ 0(7(5 ,6 237,0,6(' )25 0/66$1' 5$6 '$7$ /2**,1* $1' '2:1/2$' 72 635($' 6+((7

THROUGH RS232 SERIAL PORT.

Ɣ ,1'(3(1'(17&$/,%5$7,21)250/66$1'5$6

Ɣ :$7(53522):,7+,35$7,1*$1'/$5*(%$&./,*+7*5$3+,&$/',63/$<

Ɣ 5($/7,0(66&21&(175$7,21)25352&(66&21752/

Ɣ 6&7.(9,10(7(5&$1$/62%(86('720($685(6/8'*(%/$1.(76,1&/$5,),(560(025<

OF SAFETY

Ɣ 0(7(523(5$7(6:,7+5(&+$5*($%/(%$77(5,(6$1'&+$5*(6)25+2856

Ɣ $8726+872))

Read it without bias and you will feel peace.

412 sales@scichemtech.com www.scichemtech.com

412

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.17

MODEL NO. SCT-KEVIN

MEASURING RANGE 250 TO 30,000 MG/L

ACCURACY 3% OF READING OR 20 MG/L, WHICHEVER IS GREATER

SENSITIVITY / RESOLUTION

1 MG/1 BELOW 1000 MG/L

10 MG/L BETWEEN 1,000 AND 8,889 MG/L

1000 MG/L ABOVE 10,000 MG/L

REPEATABILITY +/- 0.5%

SENSOR DRILL LESS THAN 1% PER YEAR

TEMPERATURE RANGE 0 OC TO 85OC

SENSOR CHECK AUTOMATIC SELF DIAGNOSTICS

OUTPUT RS-232 SERIAL

MEMORY BACKUP YES

DISPLAY

LCD GRAPHIC DISPLAY WITH UV PROTECTION

CONTRAST ADJUSTMENT VIA KEYPAD

ON DEMAND BACKLIGHTING

SENSOR CABLE LENGTH 20 FEET

AMBIENT HUMIDITY 0 TO 100 PERCENT

ENCLOSURE RATING NEMA 4X

WETTED MATERIALS EPOXY AND POLYURETHANE

MAXIMUM PRESSURE 100 PSI

SHIPPING WEIGHT APPROXIMATELY 4 POUNDS

ORDERING INFORMATIONS:

SCT-108.002.17 SCT-KEVIN SCT KEVIN PORTABLE SUSPENDED SOLIDS ANALYZER IS SUPPLIED WITH SENSOR, BATTERY AND

INSTRUCTION MANUAL.

SCT PORTABLE THERMO HYGROMETER

SALIENT FEATURES:

Ɣ $ &203/(7( 3257$%/( 6&7 0(7(5 )25 5(/$7,9( +80,',7< $1' 7(03(5$785(

MEASUREMENTS.

Ɣ MICROPROCESSOR BASED FOR FAST AND ACCURATE MEASUREMENTS.

Ɣ SIMULTANEOUS DISPLAY HUMIDITY AND TEMPERATURE - USER FRIENDLY.

Ɣ MULTI-FUNCTION FOR DATA-HOLD, MAX/MIN, AUTO/MANUAL POWER SHUT OFF.

Ɣ WITH 220 MM PROBE - DETACHABLE.

Ɣ COMPLETE HUMIDITY RANGE 0 - 100%.

Ɣ BATTERY OPERATED WITH OPTIONAL A/C.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.21

MODEL NO. SCT-LILIAN

RANGE -40OC TO 85OC

0 TO 100% RH

RESOLUTION 0.1OC/ 0.1 %

ACCURACY ±0.3OC/±2 % AT 25OC

SENSOR 100 OHM RTD/THIN POLYMER CAPACITOR

POWER 9 V OR AC ADAPTOR (OPTIONAL)

DIMENSION METER: 168 X 73 X 33 MM

PROBE: 20 DIA X 220 L MM

ORDERING INFORMATIONS:

SCT-108.002.21 SCT-LILIAN SCT LILIAN THERMO HYGRO METER IS SUPPLIED COMPLETE WITH TEMPERATURE, RH PROBE,BATTERY

AND CARRYING CASE

Real happiness is cheap enough, yet how dearly we pay for its counterfeit.

413

sales@scichemtech.com www.scichemtech.com

413

SCT THERMO HYGROMETER (IN-BUILT PROBE)

SALIENT FEATURES:

Ɣ $ &203/(7( 3257$%/( 6&7 0(7(5 )25 5(/$7,9( +80,',7< $1' 7(03(5$785(

MEASUREMENTS.

Ɣ ERGONOMIC DESIGN, LIGHTWEIGHT AND COMPACT.

Ɣ MICROPROCESSOR BASED FOR FAST AND ACCURATE MEASUREMENTS.

Ɣ SIMULTANEOUS DISPLAY HUMIDITY AND TEMPERATURE USER FRIENDLY.

Ɣ MULTI-FUNCTIONS: DATA-HOLD, MAX/MIN, RECORD, HI & LOW ALARM SETTING.

Ɣ AUTO/MANUAL POWER SHUT OFF.

Ɣ FIXED BUILT-IN PROBE

Ɣ BATTERY OPERATED WITH LOW BATTERY INDICATION.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.22

MODEL NO. SCT-LARK

RH TEMP

RANGE 1~99.9 % RH -40~60°C (-40~140°F)

ACCURACY ±2.5 % RH ±0.3°C

RESOLUTION 0.10% 0.1°C

SENSOR 100 OHM RTD/THIN POLYMER CAPACITOR

POWER DC 9V BATTERY, LIFE SPAN 200 CONSECUTIVE HOURS

WEIGHT 165 G

DIMENSION 85 X 30 X 1200 MM

ORDERING INFORMATIONS :

SCT-108.002.22 SCT-LARK SCT LARK THERMO HYGRO METER IS SUPPLIED COMPLETE WITH TEMPERATURE , RH PROBE

(IN-BUILT), BATTERY AND CARRYING CASE

SCT –DROP : DIGITAL PRECISION THERMO HYGROMETER

SALIENT FEATURES:

Ɣ SCT-DROP HAS BEEN DESIGNED IN A COMPACT,ATTRACTIVE & ERGONOMIC WAY.

Ɣ 6&7'523,60$'(720($685(7+(35(&,6(5(/$7,9(+80,',7<5+72'(:32,17

& THE TEMPERATURE (-4.0 TO 140.0OF & -20.0 TO 60.0OC ) OF THE TEST AREA.

Ɣ 6&7'523+$6'8$/',63/$<:,7+%$&./,*+7

Ɣ 6&7'523+$686(56(/(&7$%/(17&257<3(.0($685(0(176

Ɣ 6&7'523+$6'(:32,177(03(5$785(0($685(0(17

Ɣ 6&7'523+$6:(7%8/%'5<%8/%7(03(5$785(0($685(0(17

Ɣ 6&7'523+$686(56(/(&7$%/(2&2)

Ɣ 6&7'523+$60$;0,1+2/'02'(6

Ɣ 6&7'523+$6$8720$7,&32:(52)),)127,186(

Ɣ 6&7'523+$6/2:%$77(5<,1',&$7,21',63/$<

Ɣ 6&7'523+$6:,'(5$1*(2)6&,(17,),&,1'8675,$/$33/,&$7,216

Ɣ 7+,60(7(5+$6%((10$18)$&785('$63(57+(,17(51$7,21$/67$1'$5'6,62

QUALITY STANDARDS .

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.23

MODEL NO SCT-DROP

DISPLAY DUAL LCD

HUMIDITY 0.0 TO 100.0% RH

RANGE AND RESOLUTION

HUMIDITY OF

ACCURACY ±3%RH (20 TO 40% AND 60 TO 80%)

±4%RH (0 TO 20% AND 80 TO 100%)

TEMPERATURE -4.0 TO 140.0OF

Reason is our soul’s left hand, faith her right.

414 sales@scichemtech.com www.scichemtech.com

414

RANGE AND RESOLUTION (-20.0 TO 60.0OC)

±0.9OF (±0.5OC)

-22.0 TO – 3.9OF

AND 140.1 TO 212.0OF

(-30.0 TO -19.9OC

AND 60.1 TO 100.0OC)

±1.8OF (±1.0OC)

RESPONSE TIME: <15 SECONDS (90% OF FINAL VALUE IN MOVING AIR)

SENSOR TYPE HUMIDITY: PRECISION CAPACITANCE SENSOR

TEMPERATURE: THERMISTOR

ABSOLUTE HUMIDITY 0 TO 500G/M3, 0 TO 218.5GR/FT3 (CALCULATED FROM RH AND

AIR TEMPERATURE MEASUREMENTS)

WET BULB 32 TO 176OF (0 TO 80OC) (CALCULATED FROM RH AND AIR

TEMPERATURE MEASUREMENTS)

DEW POINT -22 TO 212OF (-30 TO 100OC) (CALCULATED FROM RH AND AIR

TEMPERATURE MEASUREMENTS)

OPERATING CONDITIONS 32 TO 122OF (0 TO 50OC); < 80% RH NON-CONDENSING

STORAGE CONDITIONS -40 TO 185OF (-40 TO 85OC); <99% RH NON-CONDENSING

BATTERY & LIFE 9 VOTLS APPROX. 48 HOURS

WEIGHT & DIMENSIONS

(H*W*D) OF THE METER.

400 G AND 220 MM* 63 MM* 28 MM

WARRANTY STANDARD ONE YEAR INTERNATIONAL WARRANTY AGAINST

MANUFACTURAL DEFECTS IF ANY & BASED OUR SCT TERMS

& CONDITIONS GIVEN IN THE OPERATIONAL MANUAL.

QUALITY & STANDARDS THIS METER HAS BEEN MANUFACTURED AS PER THE

INTERNATIONAL STANDARDS & ISO 9001:2008 QUALITY

STANDARDS

ORDERING INFORMATIONS:

PRODUCT NO MODEL NO DESCRIPTION

SCT-108.002.20 SCT-DROP DIGITAL SCT –DROP PRECISION THERMO HYGROMETER IS SUPPLIED COMPLETE WITH THE

INSTRUCTION MANUAL

OPTIONAL ACCESSORIES (ORDER ONLY IF REQUIRED)

ACCESSORY SCT-PRODUCT NO DESCRIPTION

PROBE SCT-108.002.20 AA PROBE- HUMIDITY: PRECISION CAPACITANCE SENSOR

TEMPERATURE: THERMISTOR

BATTERIES SCT-108.002.20 AB BATTERIES FOR SCT-DROP THERMO HYGROMETER.

SCT – MASER : PROFESSIONAL LASER DISTANCE METER

SALIENT FEATURES:

Ɣ 6&70$6(5+$6%((1 DESIGNED IN A COMPACT,ATTRACTIVE & ERGONOMIC WAY.

Ɣ 6&70$6(5,60$'(720($685(,1'225',67$1&(6$5($92/80(2)$1<522025&/26('

ENVIRONMENT AND MANY INDIRECT FUNCTIONS..

Ɣ 6&70$6(5+$6',63/$<,//80,1$7,21$1'08/7,/,1(',63/$<62)7728&+.(<3$'

Ɣ 6&70$6(5+$66&70$6(5+$6$5($92/80(&$/&8/$7,216

Ɣ 6&70$6(5+$6,1',5(&70($685(0(1786,1*3<7+$*25$6

Ɣ 6&70$6(5+$6$'',7,2168%75$&7,21)81&7,216

Ɣ 6&70$6(5+$6&217,182860($685(0(175(027(0($685(0(176

Ɣ 6&70$6(5+$60,10$;',67$1&(75$&.,1*

Ɣ 6&70$6(5+$6%8==(5,1',&$7,21/21*%$77(5</,)(

Ɣ 6&70$6(5+$608/7,)81&7,21$/(1'3,(&(60$,1/<86(')25,1'225$33/,&$7,216

Ɣ 6&70$6(5+$6$*22'0($685,1*5$1*(720)772)7

Ɣ 6&70$6(5+$6$:,'(5$1*(2)6&,(17,),&,1'8675,$/$33/,&$7,216

Ɣ 7+,60(7(5 +$6%((1 0$18)$&785('$63(5 THE INTERNATIONAL STANDARDS & ISO

9001:2008 QUALITY STANDARDS..

Reason, observation, and experience - the holy trinity of science.

415

sales@scichemtech.com www.scichemtech.com

415

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.24

MODEL NO SCT - MASER

MEASURING RANGE 0.05 TO 50M(0.15FT TO 164FT)

MEASURING ACCURACY TYPICALLY: ±1.5 MM(± 0.06 IN)

SMALLEST UNIT DISPLAYED 1MM

MEASURING UNITS M,IN,FT

STANDARD CLASS II 635NM,<1MW

IP RATING IP 54

HISTORY MEASUREMENT RECORDS 20

KEYBOARD TYPE SOFT-TOUCH KEYPAD

OPERATING TEMPERATURE 0°C TO 40°C(32°F TO 104°F)

OPERATING TEMPERATURE -10°C TO 60°C(14°F TO 140°F)

BATTERY LIFE UP TO 4,000 MEASUREMENTS

AUTO. LASER SWITCH-OFF AFTER 0.5 MIN

AUTO INSTRUMENT SWITCH-OFF AFTER 3 MIN

BATTERY AAA 1.5 V X 2

WEIGHT & DIMENSIONS (H*W*D) OF THE

METER

135 G AND 115 MM*48 MM*28 MM

WARRANTY STANDARD ONE YEAR INTERNATIONAL WARRANTY AGAINST MANUFACTURAL DEFECTS

IF ANY & BASED OUR SCT TERMS & CONDITIONS GIVEN IN THE OPERATIONAL MANUAL.

QUALITY & STANDARDS THIS METER HAS BEEN MANUFACTURED AS PER THE INTERNATIONAL STANDARDS & ISO

9001:2008 QUALITY STANDARDS

ORDERING INFORMATIONS:

PRODUCT NO. MODEL NO.

SCT-108.002.91 SCT - MASER

OPTIONAL ACCESSORIES (ORDER ONLY IF REQUIRED)

ACCESSORY SCT-PRODUCT NO

battery SCT-108.002.91 AB

SCT PORTABLE LUX (LIGHT) METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25,17(16,7<2)/,*+70($685(0(176

Ɣ GOOD DESIGN WITH HIGH PRECISION.

Ɣ MEASURING INTENSITIES OF ILLUMINATION IN LUX OR FOOTCANDLES.

Ɣ MEASURING LIGHTS SOURCE INCLUDES ALL VISIBLE.

Ɣ MULTI-FUNCTION FOR DATA HOLD, MAX. AND ZERO ADJUSTMENT.

Ɣ COSINE ANGULAR CORRECTED.

Ɣ BATTERY OPERATED.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.25

MODEL SCT-LUCKY

RANGE: 200, 2000, 20000, 200000 LUX

20, 200, 2000, 20000 FOOTCANDLES

ACCURACY: ±3%(CALIBRATED TO STANDARD INCANDESCENT LAMP 2856 K)

±8%(OTHER VISIBLE LIGHT SOURCE)

SENSOR: SILICON PHOTODIODE AND FILTER

ANGLE DEVIATION FROM

COSINE CHARACTERISTICS:

30° ±2%

60° ±6%

80° ±25%

BATTERY: DC 9V

DIMENSIONS: 185 X 55 X 38 MM

WEIGHT: 250 G (WITH BATTERY)

ORDERING INFORMATIONS:

SCT-108.002.25 SCT-LUCKY SCT LUCKY LUX METER IS SUPPLIED COMPLETE WITH ,BATTERY AND CARRYING CASE

Remember no one can make you feel inferior without your consent.

416 sales@scichemtech.com www.scichemtech.com

416

SCT –ADHES: DIGITAL COATING THICKNESS METER

SALIENT FEATURES:

Ɣ 6&7$'+(6+$6%((1'(6,*1(',1$&203$&7$775$&7,9((5*2120,&:$<

Ɣ 6&7$'+(6±,60$'(720($685(%27+)(55286121)(55286%$6('0(7$/

COATINGS THICKNESS.

Ɣ 6&7$'+(6 ± +$6 0$*1(7,&,1'8&7,21)25 )(55286 68%675$7(6$1' (''<

CURRENT MEASUREMENT FOR NON-FERROUS SUBSTRATES

Ɣ 6&7$'+(6±&$10($685(&2$7,1*61210$*1(7,&&2$7,1*6(*3$,17=,1&

ON STEEL; INSULATING COATINGS(E.G. PAINT, ANODIZING COATINGS) ON NO-FERROUS

METALS

Ɣ 6&7$'+(6±+$67+(352%(&$1:25.21%27+35,1&,3/(60$*1(7,&,1'8&7,21

AND ON THE EDDY CURRENT PRINCIPLE. ONE PROBE ONLY IS REQUIRED FOR COATING

MEASUREMENT BOTH ON FERROUS AND NON-FERROUS METAL SUBSTRATES. IT IS

ADAPTABLE TO SPECIFIC TASKS: I.E. THEY CAN BE USED ON SPECIAL GEOMETRIES OR

ON MATERIALS WITH SPECIAL PROPERTIES.

Ɣ 6&7$'+(6±&21)250672*%7*%7-%7--*

95, AND JJG 818-93

Ɣ 6&7$'+(6  ± +$6 $8720$7,& 68%675$7( 5(&2*1,7,21  ($6<72 86( 0(18

SYSTEM

Ɣ 6&7$'+(6  ±  +$6 7:2 0($685,1* 02'( &217,18($1' 6,1*/( 02'(  7:2

WORKING MODE: DIRECT AND GROUP MODE(4 GROUPS)

Ɣ 6&7$'+(6  ±  +$6 21( 32,17 &$/,%5$7,21 $1' 7:2 32,176 &$/,%5$7,21$1'

BASIC CALIBRATION CAN BE PERFORMED EASILY. MEMORY FOR 400 READINGS (80

DIRECT AND 320 GROUP READINGS).DELETE SINGLE READINGS AND ALL GROUP

READINGS EASILY

Ɣ 6&7$'+(6  ± +$6 67$7,67,& ',63/$< $9* 0$; 0,1 12 6'(9 67$1'$5'

DEVIATION)

Ɣ 6&7$'+(6  ± +$6 /2: %$77(5< (5525 ,1',&$7,21  86% ,17(5)$&( )25 3&

ANALYSIS SOFTWARE. DISABLE AUTO-POWER-OFF FUNCTION VIA MENU SETTING.

Ɣ 6&7$'+(6  ± +$6 7+5(( ',))(5(17$'-867$%/( 5(62/87,216 )25 ',))(5(17

APPLICATIONS & HIGH SPEED DATA COLLECTION

Ɣ 6&7$'+(6+$6:,'(5$1*(2)6&,(17,),&,1'8675,$/$33/,&$7,216

Ɣ 7+,60(7(5+$6%((10$18)$&785('$63(57+(,17(51$7,21$/67$1'$5'6

ISO 9001:2008 QUALITY STANDARDS .

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.26

MODEL NO. SCT- ADHES

SENSOR / PROBE F

WORKING PRINCIPLE MAGNETIC INDUCTION

MEASURING RANGE 0~1250UM

GUARANTEED TOLERANCE (OF

READING)

(+/- 3%+1)UM

LOW RANGE PRECISION 0.1UM

MINIMUM CURVATURE RADIUS 1.5MM

DIAMETER OF MINIMUM AREA 3MM

BASIC CRITICAL THICKNESS 0.5MM

BATTERY AAA 1.5 V X 2

WEIGHT & 110 G AND 114 MM* 54 MM* 27 MM

DIMENSIONS (H*W*D) OF THE

METER.

WARRANTY STANDARD ONE YEAR INTERNATIONAL WARRANTY AGAINST MANUFACTURAL DEFECTS IF

ANY & BASED OUR SCT TERMS & CONDITIONS GIVEN IN THE OPERATIONAL MANUAL.

QUALITY & STANDARDS THIS METER HAS BEEN MANUFACTURED AS PER THE INTERNATIONAL STANDARDS & ISO

9001:2008 QUALITY STANDARDS

ORDERING INFORMATIONS:

PRODUCT NO MODEL NO

SCT-108.002.26 SCT- ADHES

OPTIONAL ACCESSORIES (ORDER ONLY IF REQUIRED)

ACESSORY SCT-PRODUCT NO

Probe SCT-108.002.26 AA

Battery SCT-108.002.26 AB

Calibration-F SCT-108.002.26 AC

Calibration-N SCT-108.002.26 AD

Standard SCT-108.002.26 AE

Remember that failure is an event, not a person.

417

sales@scichemtech.com www.scichemtech.com

417

SCT –PASCAL : DIGITAL DIFFERNTIAL PRESSURE MANOMETER

SALIENT FEATURES:

Ɣ 6&73$6&$/+$6%((1'(6,*1(',1$&203$&7$775$&7,9((5*2120,&:$<

Ɣ 6&73$6&$/+$67+($%,/,7<720($685(7+(',))(5(17,$/35(6685(6

Ɣ 6&73$6&$/ ± 7+( 3257$%/( ',))(5(17,$/ 35(6685( 0(7(5 +$6 7+( $%,/,7<

HAVE MANY SELECTABLE UNITS LIKE; IN H20, PSI, BAR, MBAR, KPA, INHG, MMHG, OZIN,

FTH20, CMH20, KGCM

Ɣ 6&73$6&$/+$6$/$5*('8$//&':,7+%$&./,*+7 

Ɣ 6&73$6&$/±,60$'($6$86(5)5,(1'/<6,03/(7286( 

Ɣ 6&73$6&$/±,60$'(7286()25$*22'5$1*(2)',))(5(17,$/35(6685(6

Ɣ 6&73$6&$/±7+(3257$%/(',))(5(17,$/35(6685(0(7(5+$67+('$7$+2/'

FUNCTION.

Ɣ 6&73$6&$/ ± 7+( 3257$%/( ',))(5(17,$/ 35(6685( 0(7(5 +$6 7+($872

POWER OFF.

Ɣ 6&73$6&$/ ±  +$6 56 )25 &$3785,1* 5($',1* 72 $ 3& 86,1* 237,21$/

SOFTWARE

Ɣ 6&73$6&$/±,6%$77(5<23(5$7('$1'&$55<729$5,2867(67,1*/2&$7,216

Ɣ 6&73$6&$/+$6:,'(6&,(17,),&,1'8675,$/$33/,&$7,216 

Ɣ 7+,60(7(5+$6%((10$18)$&785('$63(57+(,17(51$7,21$/67$1'$5'6

ISO 9001:2008 QUALITY STANDARDS .

TECHNICAL SPECIFICATIONS :

PRODUCT NO. SCT-108.002.27

MODEL NO. SCT-PASCAL

ACCURACY ±0.3%FSO

REPEATABILITY ±0.2% (Max.+/ -0.5% FSO)

LINEARITY/HYSTERESIS ±0.29% FSO

PRESSURE RANGE ±5PSI (±138.3 inH2O)

UNITS AND RESOLUTION inH2O 0.1

PA 0.001

mbar 0.1

kPa 0.01

inHg 0.001

mmHg 0.1

ozin2 0.01

ftH2O 0.01

cmH2O 0.1

kgcm 0.001

bar 0.001

BATTERY 9 VOLTS BATTERY X 1

WEIGHT & DIMENSIONS

(H*W*D) OF THE METER

2000 G AND 400 MM* 290 MM* 110 MM

WARRANTY STANDARD ONE YEAR INTERNATIONAL WARRANTY AGAINST

MANUFACTURAL DEFECTS IF ANY & BASED OUR SCT TERMS

& CONDITIONS GIVEN IN THE OPERATIONAL MANUAL.

QUALITY & STANDARDS THIS METER HAS BEEN MANUFACTURED AS PER THE INTERNATIONAL STANDARDS & ISO 9001:2008

QUALITY STANDARDS

ORDERING INFORMATIONS:

PRODUCT NO MODEL NO DESCRIPTION

SCT-108.002.27 SCT-PASCAL SCT DIGITAL DIFFERENTIAL PRESSURE MANOMETER SUPPLIED COMPLETE WITH

INSTRUCTION MANUAL 9V BATTERY, USB CABLE, 9V POWER SUPPLIED WITH CARRYING

CASE

OPTIONAL ACCESSORIES (ORDER ONLY IF REQUIRED)

ACESSORY SCT-PRODUCT NO DESCRIPTION

Battery SCT-108.002.27 AB Batteries for SCT-PASCAL SCT Digital Differential Pressure Manometer

Repetition makes reputation and reputation makes customers.

418 sales@scichemtech.com www.scichemtech.com

418

SCT DIGITAL SOUND LEVEL METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25/(9(/2)6281'12,6(0($685(0(176

Ɣ &203$&7'(6,*1:,7+%$&./,*+7',63/$<

Ɣ AUTO RANGE AND AUTO POWER OFF.

Ɣ MIN/MAX STORAGE AND RECALL

Ɣ TEST RANGE FROM 30 TO 130 DB (DECIBELS) WITH 0.1 DB (DECIBELS) RESOLUTION.

Ɣ A & C FREQUENCY WEIGHTING.

Ɣ FAST & SLOW DYNAMIC CHARACTERISTIC MODELS

Ɣ %$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.28

MODEL NO. SCT-LYN

RANGE

LO: 30-80 DB

MED: 50-100 DB

HI: 80-130 DB

ACCURACY ±1.5 DB(REF 94DB@1 KHZ)

RESOLUTION 0.1 DB

MICROPHONE 1/2 INCH ELECTRET CONDENSER MICROPHONE

FREQUENCY WEIGHTING A, C

ANALOG DC OUTPUT 10mV/DB, IMPEDANCE APPROX. 100 OHM

DYNAMIC RANGE 50 DB

FREQUENCY RANGE 20 HZ-8 KHZ

BATTERY DC 9V

DIMENSIONS 280 X 80 X 32 MM

WEIGHT 290 G (WITH BATTERY)

ORDERING INFORMATIONS:

SCT-108.002.28 SCT-LYN SCT LYN SOUND LEVEL METER IS SUPPLIED COMPLETE WITH ,BATTERY AND CARRYING CASE

SCT-PLANK : RADIATION DETECTOR / SCANNER

SALIENT FEATURES:

Ɣ 6&73/$1&.+$6%((1'(6,*1(',1$&203$&7$775$&7,9((5*2120,&:$<

Ɣ 6&73/$1&.  ,6$ +$1'+(/' 0(7(5 72$/3+$ %(7$*$00$ $1' ; 5$< Į ޛ ȕ ޛ < DQG ; UD\

MEASURE RADIATIONS IN THE WORKING ENVIRONMENT OR OBJECTS.

Ɣ 6&73/$1&.,686,1**(,*(5&2817(56(1625 

Ɣ 6&73/$1&.+$66(/(&7%87721)25',))(5(175$<0($685(0(17/,.($/3+$%(7$*$00$

$1';5$<Įޛȕޛ<DQG;UD\ 

Ɣ 6&73/$1&.+$6+,*+'(),1,7,21/&'',63/$<:,7+%$&./,*+70($685,1*'<1$0,&5$<

CATEGORY, READING, REAL-TIME TIME, BATTERY INDICATION, MEASUREMENT SYMBOLS AND

SIMULATING DIAGRAM INDICATION.

Ɣ 6&73/$1&.+$6$'-867$%/(,1',&$7,212)$9(5$*(7,0(

Ɣ 6&73/$1&.+$6$&&808/$7,212)5$',$7,21'(7(&7,219$/8($1'&219(56,21%(7:((1

DIFFERENT MEASUREMENT UNITS

Ɣ 6&73/$1&.+$6$/$505($/7,0(7,0($1'%/8(7227+'$7$75$160,66,21)81&7,216

Ɣ 6&73/$1&.+$638/6(&2817,1*)81&7,21

Ɣ 6&73/$1&.+$6$8720$7,&6(/(&7,212)0($685(0(175$1*( 

Ɣ 6&73/$1&.+$6%/8(7227+&20081,&$7,21'$7$75$160,66,21)81&7,21$1'32:(5)8/

SOFTWARE FOR DATA EVALUATION. AND MINI IMPACT-RESISTANT DESIGN, LIGHT WEIGHT 206 GMS

ONLY & EASY TO CARRY

Ɣ 6&73/$1&.+$6/$5*(,17(51$/0(025<&$3$&,7<7+$7&$1',5(&7/<6725(*5283

OF DATA INSIDE, TRANSFER TO PC, AND NO NEED MANUAL RECORD.

Ɣ 6&73/$1.+$6WIDE RANGE OF SCIENTIFIC & INDUSTRIAL APPLICATIONS.

THIS METER HAS BEEN MANUFACTURED AS PER THE INTERNATIONAL STANDARDS & ISO 9001:2008 QUALITY STANDARDS .

TECHNICAL SPECIFICATIONS :

PRODUCT NO SCT-108.002.29

MODEL NO SCT-PLANCK

DETECTION RAY TYPES Įޛȕޛ<DQG;UD\

MEASURING RANGE 5DGLDWLRQGRVHUDWHȝ6YKȝ6YK3XOVHGRVHUDWHFSPFSV

(AUTO-SELECTION) Accumulated radiation dose value :

ȝ6Y6Y

Accumulated Pulse dose rate : 0- 9999

SENSITIVITY Under the environment of cobalt-60 rays that

$Wȝ6YKWKHUHDUHWLPHVRISXOVHRU

1 000 cpm/mR/hr.

ĮUD\IURP0HJDYROW

ȕUD\IURP0HJDYROW

Y-ray- from 0.02 Megavolt

X-ray -from 0.02 Megavolt

ACCURACY HVVWKDQȝ6YK

OHVVWKDQȝ6YK

SELECTION OF RAYS &RPELQDWLRQVHOHFWLRQRIĮȕ\;UD\V

Research is what i’m doing when i don’t know what i’m doing.

419

sales@scichemtech.com www.scichemtech.com

419

SENSOR Halogen compensating detector ( G.M Geiger counter tube )

OUTPUT PORT Wireless Bluetooth Transmission ( Space transmission distance is10m)

AVERAGE TIME Manual or automatic adjustable between 2 to

12 seconds

DISPLAY Large 4bit digital LCD display with bar graph

indications as below:

Radiation dose rate, pulse dose rate, Accumulated radiation dose rate, Accumulated pulse dose rate,

time, date, alarm value, Max radiation dose rate, type of rays, dynamic measuring icon, battery

indication etc.

ALARM FUNCTION Free to set the value of beep alarm ,

'()$8/7VHWXSLVȝ6YKU

NORMAL RADIATION VALUE OF

NATURAL ENVIRONMENT

Less than 0 - 0.2 uSv I h

INTERNAL MEMORY Auto-save 4000 groups of datas, record one group of date per second with detailed info as date, time,

reading and unit

BLUETOOTH Transmit one group of date every second with date, time, value and unit indicated

TRANSMISSION

SOFTWARE Integrated Real time data transmission, analysis, and recording

WORKING TEMP 0°c- 50°c

QUALITY CERTIFICATE European CE,US FCC-15

BATTERY 3.6 V High-energy li-battery

WEIGHT & 206 g and 200 mm*70 mm*45 mm

DIMENSIONS (H*W*D) OF THE METER.

WARRANTY Standard one Year International warranty against manufactural defects if any & based our SCT Terms &

Conditions Given in the operational Manual.

QUALITY & STANDARDS

7KLVPHWHUKDVEHHQPDQXIDFWXUHGDVSHUWKH,QWHUQDWLRQDO6WDQGDUGV,62TXDOLW\VWDQGDUGV

ORDERING INFORMATIONS:

PRODUCT NO MODEL NO DESCRIPTION

SCT-108.002.29 SCT-PLANCK SCT-PLANK Radiation Scanner supplied complete with instruction manual.

OPTIONAL ACCESSORIES (ORDER ONLY IF REQUIRED)

ACESSORY PRODUCT NO. DESCRIPTION

Battery SCT-108.002.29 AB Batteries for SCT-PLANK Radiation Scanner

SCT LCD DIGITAL ANEMOMETER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25$,5:,1'9(/2&,7<$1'7(03(5$785(0($685(0(176

Ɣ ,167$17',63/$<2)7+($,59(/2&,7<$1'7(03(5$785(

Ɣ 0$;,0800,1,080$1'$9(5$*(9$/8(&$/&8/$7,21

Ɣ ($6<$,5)/2:92/80(&$/&8/$7,21&)0&00

Ɣ 0(025,(6'$7$6725$*(5(&$//,1*&/($5,1*

Ɣ '$7$+2/'7(67)81&7,21

Ɣ 21(+285$8726+872)))81&7,21

Ɣ %$77(5<23(5$7(':,7+/2:%$77(5<,1',&$7,21

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.30

MODEL NO. SCT-LEN

FUNCTION

ON/OFF, HOLD/TEST, ºF/ºC, 10 MEMORIES, AIR

VELOCITY UNIT, AVG MULTI POINT, AIR FLOW VOLUME

MEASUREMENT, AVG/MAX/MIN READING

AIR VELOCITY MEASUREMENT

0.5 TO 45.0 M/S (METER PER SECOND)

1.8 TO 162.0 KM/HR (KILOMETER PER HOUR)

1.1 TO 100.0 MPH (MILE PER HOUR)

98 TO 8800 FT/ MIN (FEET PER MINUTE)

1.0 TO 88.0 KNOTS (NAUTICAL MILES PER HOUR)

AIR VELOCITY ACCURACY ±2%

AIR VELOCITY RESOLUTION 0.1

TEMPERATURE RANGE –50ºC ~ +70ºC OR –58ºF ~ +158ºF

TEMPERATURE ACCURACY

±0.5ºC FOR 0ºC ~ +50ºC

OR ±0.9ºF FOR +32ºF ~ +122ºF,

OTHERWISE ±1ºC OR 1.8ºF

TEMPERATURE RESOLUTION 0.1º FOR WHOLE RANGE

AMBIENT TEMPERATURE FOR

PLASTIC CASE 0ºC ~ +50ºC OR +32ºF ~ +122ºF

SENSOR TYPE NTC

BATTERY 3 X 1.5 VOLTS “AAA” SIZE OR EQUIVALENT

DIMENSION (MM) UNIT: 85 X 175 X 39

VANE PROBE: 76 X 67 X 32

LCD SIZE (MM) 54 X 35

WEIGHT (G) UNIT: 200

VANE PROBE: 130

ORDERING INFORMATIONS:

PRODUCT NO MODEL NO DESCRIPTION

SCT-108.002.30 SCT-LEN SCT LEN LCD DIGITAL ANEMOMETER IS SUPPLIED COMPLETE WITH ALL THE ACCESSORIES IN A BOX.

Respect is what we owe; love, what we give.

420 sales@scichemtech.com www.scichemtech.com

420

SCT IR (INFRA RED) THERMO ANEMOMETERS (NON CONTACT TYPE)

SALIENT FEATURES :

Ɣ $ &203/(7( 3257$%/( 6&7 0(7(5 )25 $,5 9(/2&,7< $,5 )/2: $1'

TEMPERATURE MEASUREMENTS.

Ɣ SIMULTANEOUS DISPLAY AIR FLOW IN CFM/CMM or AIR VELOCITY PLUS AMBIENT

TEMPERATURE

Ɣ COMBINATION OF HOTWIRE AND STANDARD THERMISTOR, DELIVER RAPID AND

PRECISE MEASUREMENTS EVENT AT LOW AIR VELOCITY

Ɣ INFRARED THERMOMETER MEASURES REMOTE SURFACE TEMPERATURE TO

999F (537C) WITH 30:1 DISTANCE TO SPOT RATIO AND LASER POINTER

Ɣ WIDE RANGE MEASUREMENTS OF AIR VELOCITY, FAST RESPONSE TIME

Ɣ MULTIFUNCTION FOR AIR FLOW MEASUEREMENTS : M/S, KM/H, FT/ MIN, KNOTS,

MILE/H

Ɣ SUPER LARGE LCD WITH DUAL FUNCTION DISPLAY, READ THE AIR VELOCITY AND

TEMPERATURE AT THE SAME TIME.

Ɣ AC POWER OPERATED.

TECHNICAL SPECIFICATION:

PRODUCT NO SCT-108.002.31 SCT-108.002.32

MODEL NO. SCT-LEMA SCT-LESA

MEASUREMENT AIR VELOCITY, M/S,FT/MIN,KM/H,MILE/H,KNOTS,

TEMP C& F

AIR VELOCITY, M/S,FT/MIN,KM/H,MILE/H,KNOTS,

AIR FLOW,CMM(M3/MIN)CFM(FT3/MIN), TEMP C& F

SENSORS AIR VELOCITY / AIR FLOW SENSOR HOT WIRE, TEMPERATURE THERMOPILE

SAMPLE TIME APPROX 0.5 SEC

OPERATING TEMP 0-50C (32-122F) 10 -90% RH

STORAGE TEMP -10 – 60 C ( 14-140F)

RECORD FUNCTION YES ( 9 POINTS)

DATA LOGGING NO YES ( 2000 POINTS )

TIME INTERVAL NO YES

PC INTERFACE NO USB

AC POWER YES YES

MULTIPLE LCD DISPLAY YES

MAX / MIN / AUG YES

AUTO POWER OFF YES

LCD BACK LIGHT YES

DATA HOLD YES

DIMENSION 184(L) X 70(W)X40 (H)mm

TELESCOPE PROBE APPROX 320 G APPROX 310 G

ACCESSORIES 9V BATTERY, INSTRUCTION MANUAL, CARRYING CASE, AC INPUT FOR SCT 108.002.32 INCLUDE USB

CABLE, PC INTERFACE, WINDOW BASED SOFTWARE

AIR VELOCITY

RANGE

M/S (METER PER SECOND) 0-40.00M/S

FT/MIN (FEET PER MINUTE ) 0-7874.0FT/MIN

KM/H (KILOMETER PER HOUR) 0-144.00 KM/H

MILE/ H(MILES PER HOUR) 0-89.5 MILE/H

KNOT (NAUTICAL MILES PER HOUR) 0-77.75 KNOT

RESOLUTION

M/S (METER PER SECOND) 0.01M/S

FT/MIN (FEET PER MINUTE ) 0.1FT/MIN

KM/H (KILOMETER PER HOUR) 0.01KM/H

MILE/ H(MILES PER HOUR) 0.01MILE/H

KNOT (NAUTICAL MILES PER HOUR) 0.01 KNOT

ACCURACY

M/S (METER PER SECOND) +/-(3% +0.03M/S) OF READING

FT/MIN (FEET PER MINUTE ) +/-(3% +5.9FT) OF READING

KM/H (KILOMETER PER HOUR) +/-(3% +0.11KM/H) OF READING

MILE/ H(MILES PER HOUR) +/-(3% +0.07MILE/H) OF READING

KNOT (NAUTICAL MILES PER HOUR) +/-(3% +0.06KNOT) OF READING

AIR FLOW CMM (M3/MIN)

RANGE 0-72,000(M3/MIN)

CFM(FT3/MIN)

RANGE 0-2542,700(FT3/MIN)

AREA RESOLUTION

CMM (m3/min) 0.001

CFM(FT3/MIN) 0.01

AREA

CMM (m3/min) 0.001-30M2

CFM(FT3/MIN): 0.01-322.92FT2

Respect yourself and others will respect you .

421

sales@scichemtech.com www.scichemtech.com

421

AIR TEMPERATURE

RANGE 0-70OC

RESOLUTION 0.1OC

ACCURACY 0.8OC

INFRARED THERMOMETER:

RANGE -32 -537.5OC

ACCURACY

+/- 3.0OC FROM -32.0C –20OC

+/-2.0OC FROM -20C -100.0OC

+/-2% FROM 100 -537.0

RESOLUTION 0.1OC

SPOT RATIO 8:1 30:1

EMISSIVITY 0.95 FIXED 0.10-1.00 ADJUST

ORDERING INFORMATIONS:

SCT-108.002.31 SCT-LEMA SCT LEMA IR THERMO ANEMOMETERS IS SUPPLIED COMPLETE WITH 9V BATTERY, INSTRUCTION

MANUAL AND CARRYING CASE

SCT-108.002.32 SCT-LESA SCT LESA IR THERMO ANEMOMETERS IS SUPPLIED COMPLETE WITH 9V BATTERY, INSTRUCTION

MANUAL AND CARRYING CASE, USB CABLE, PC INTERFACE, WINDOW BASED SOFTWARE

SCT PORTABLE TACHOMETERS (ROTATIONAL SPEED)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25527$7,21$/63(('5(90($685(0(176

Ɣ NON-CONTACT AND CONTACT MODE

Ɣ HIGHLY RELIABLE AND ACCURATE READING.

Ɣ NON-CONTACT AND CONTACT MODE

Ɣ LASER SIGHTING OPERATING RANGE UP TO 40 INCHES / 100 CM (LASER)

Ɣ AUTO RANGING / FIXED DECIMAL

Ɣ TRIPOD MOUNTING BUSHING

Ɣ CONTACT ADAPTORS

Ɣ BATTERY OPERATED WITH LOW BATTERY INDICATION.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.35 SCT-108.002.36

MODEL NO. SCT-MANS SCT-MORAL

ROTATION SPEED

(NON-CONTACT) 6.0 - 99999 RPM (REV/MIN) 6.0 - 99999 RPM (REV/MIN)

ROTATION SPEED

(CONTACT) 6.0 - 25000 RPM (REV/MIN)

SURFACE SPEED

(CONTACT)

0.6 - 2500.0 M/M (M/MIN),

0.7 - 2734.0 Y/M (YARD/MIN),

23.6 - 98425 I/M (INCH/MIN),

2.0 - 8202.1 F/M (FEET/MIN)

LENGTH (CONTACT)

0.1 - 9999.9 M (M)

0.1~10936 YD(YARD)

0.3~32808 FT(FEET)

TOTAL NUMBER OF

REVOLUTIONS 1-99999REV(REV)

ACCURACY

6.0 - 5999.9 RPM: ±0.01% AND ±1 DIGIT,

5999.9 - 99999 RPM: ±0.05% AND ±1

DIGIT)

6.0 - 5999.9 RPM: ±0.01% AND ±1 DIGIT,

5999.9 - 99999 RPM: ±0.05 AND ±1 DIGIT,

SURFACE SPEED,LENGTH 0.5%AND ± 1 DIGIT

DETECTION LASER DIODE LASER DIODE

RESOLUTION 6.0 - 9999.9RPM 6.0 - 9999.9: 0.1 RPM

10000 - 99999RPM: 1 (RPM) 10000 - 99999 RPM: 1 RPM

RESPONSE TIME 1 SECOND 1 SECOND

OPERATING TEMP. 0~50OC (32 TO 122OF), 10 TO 90% RH 0~50OC (32 TO 122OF), 10 TO 90% RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 30S AUTOMATICALLY AFTER APPROX. 30S

MAX/MIN/AVG YES YES

MEMORY 40 POINTS 40 POINTS

BATTERY TYPE 9V(006P,IEC6F22,NEDA1604) 9V(006P,IEC6F22,NEDA1604)

DIMENSIONS

147 X 49 X 29 MM (5.79'' X 1.93'' X 1.14'') 147 X 49 X 29 MM (5.79'' X 1.93'' X 1.14'')

INCLUDE CONTACT ADAPTERS.

WEIGHT 95G (3.35OZ) APPROX (WITHOUT

BATTERY)

95G (3.35OZ) APPROX (WITHOUT BATTERY)

CONTACT ADAPTERS : 50G(1.76OZ)

STANDARD

ACCESSORIES

9V BATTERY, INSTRUCTION

MANUAL,REFLECTIVE TAPE 15 X525

9V BATTERY, INSTRUCTION MANUAL, CONE

ADAPTER, FUNNEL ADAPTER, CONTACT

ADAPTER, MASTER WHEEL (10CM),

REFLECTIVE TAPE 15X525MM (0.59”X20.67”),

CARRYING CASE

(0.59'' X 20.67'' ), CARRYIMG CASE

ORDERING INFORMATIONS:

SCT-108.002.35 SCT-MANS SCT MANS TACHOMETER (NON-CONTACT), IS SUPPLIED WITH REFLECTIVE TAPE, W/ USER MANUAL,

CARRYING CASE , 9V BATTERY

SCT-108.002.36 SCT-MORAL SCT MORAL TACHOMETER (NON-CONTACT & CONTACT), IS SUPPLIED WITH CONE ADAPTER, FUNNEL

ADAPTER, CONTACT ADAPTER, MASTER WHEEL REFLECTIVE TAPE PACKED IN A BOX.

Responsibility is the price of freedom

422 sales@scichemtech.com www.scichemtech.com

422

SCT PORTABLE CO2 (CARBON DI OXIDE) ANALYZER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25&$5%21',2;,'(0($685(0(176

Ɣ LARGE DUAL LCD DISPLAY FOR CO2, %RH HUMIDITY AND TEMPERATURE.

Ɣ PRECISE ADJUSTMENT IN DIFFERENT BAROMETRIC LEVELS (OR PRESSURES).

Ɣ CO2: 0 ~ 9,999 PPM RANGE, DIFFUSION SAMPLING MODE.

Ɣ CONTINUOUS DATA LOGGING WITH TIME/DATE.

Ɣ ENERGY EFFICIENCY BY SAMPLING TIME MODULATION.

Ɣ DATA HOLD & MAXIMUM / MINIMUM WITH TIME STAMP.

Ɣ USB POWER SUPPLY.

Ɣ DATA MEMORY AND RECALL FUNCTION.

Ɣ EASY TO USE USB INTERFACE AND USER FRIENDLY SOFTWARE.

Ɣ FAST WARM UP TIME / AUDIBLE ALARM.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.40 SCT-108.002.41

MODEL NO. SCT-NASH SCT-NAVID

MEASURING RANGE 0 TO 9,999 PPM

ACCURACY 0 TO 5,000 PPM:± (50 PPM+2% OF M.V.)

5,001 TO 9,999 PPM:± (100 PPM+3% OF M.V.)

RESOLUTION 1 PPM

OPERATING TEMP. 0 TO 50°C (0 TO 122°F)

STORAGE TEMP. -20 TO 60°C (-4 TO 140°F)

MAX/MIN/AVG YES

AUDIO ALARM YES

TIME / DATE YES

DATA HOLD YES

USB POWER YES

AC POWER YES

DATA MEMORY YES

DIMENSIONS 184(L)X70(W)X40(H)MM (7.08” X2.75” X1.57”)

WEIGHT APPROX.217G (7.65 OZ.)

DATA LOGGING NO 20,000 POINTS

HUMIDITY NO YES

TEMPERATURE NO YES

PC INTERFACE NO USB

ACCESSORIES 9V BATTERY, INSTRUCTION MANUAL, CARRYING CASE, AC ADAPT ER, AC PLUG

(INCL.USA PIN, EUROPEAN PIN), USB CABLE. (PC INTERFACE WINDOW-BASED SOFTWARE)

ORDERING INFORMATIONS:

SCT-108.002.40 SCT-NASH SCT NASH CO2 DETECTOR -I, IS SUPPLIED WITH USER MANUAL, SLEEVE, CARRYING CASE, 9V

BATTERY

SCT-108.002.41 SCT-NAVID SCT NAVID CO2 DETECTOR -II, IS SUPPLIED WITH USER MANUAL, SLEEVE, CARRYING CASE, 9V

BATTERY, DATA LOGGING VIA USB, AC POWER ADAPTER

SCT PORTABLE UV METERS (ULTRA VIOLET)

SALIENT FEATURES:

Ɣ $ &203/(7( 3257$%/( 6&7 0(7(5 )25 ,17(16,7< 2) 8/75$ 9,2/(7 5$<6

MEASUREMENT (UV-A, C+AB)

Ɣ BACKLIGHT LCD AND 4 DIGITS DUAL DISPLAY

Ɣ HIGH AND LOW MEASUREMENTS

Ɣ RANGE IN A UNIT MW/CM2 OR UW/CM2

Ɣ SOCKET OF TRIPOD MOUNTING

Ɣ AUTOMATIC MEASURING

Ɣ MAGNETIC MOUNT

Ɣ 20 POINTS MEMORY

Ɣ BATTERY OPERATED WITH LOW BATTERY INDICATION.

TECHNICAL SPECIFICATION:

PRODUCT NO. SCT-108.002.46 SCT-108.002.47 SCT-108.002.48

MODEL NO. SCT-NEO SCT-QIANA SCT-RICKY

SPECTRUM RANGE 220~275 320~380 280~400

CALIBRATION POINT 254 NM 365 NM 365 NM

ILLUMINATION RANGE 1 UW/CM2 ~ 9999 UW/CM2 / 0.01 MW/CM2 ~ 40.00 MW/CM2

ACCURACY 23 ±5OC(73.5 ±9OF) ±4% ±1 DIGIT

OVER RANGE INDICATION “-HI-”

ZERO ADJUST YES

AUTO RECORD YES

SAMPLE TIME APPROX. 0.3 SEC.

Revolution is not a onetime event

423

sales@scichemtech.com www.scichemtech.com

423

DISPLAY BACKLIGHT LCD AND DUAL DISPLAY

MEMORY 20 POINTS AND 1 FOR INTERVAL TIME

OPERATION TEMPERATURE 0~50OC (32~122OF); 10~90% RH

BATTERY TYPE 9V (006P, IEC6F22, NEDA1604)

WEIGHT APPROX. 90G

DIMENSION 140 X 49 X 29 CM (5.51 X 1.93 X 1.14 INCH)

ACCESSORY 9V BATTERY, UV SENSOR PROBE, INSTRUCTION MANUAL

ORDERING INFORMATIONS:

SCT-108.002.46 SCT-NEO SCT NEO UV-A, METER IS SUPPLIED IWTH UV SENSOR PROBE, USER MANUAL, COLOR BOX, HARD CARRYING

CASE, 9V BATTERY

SCT-108.002.47 SCT-QIANA SCT QIANA UV-C, METER IS SUPPLIED IWTH UV SENSOR PROBE, USER MANUAL, COLOR BOX, HARD

CARRYING CASE, 9V BATTERY

SCT-108.002.48 SCT-RICKY SCT RICKY UV-AB, METER IS SUPPLIED IWTH UV SENSOR PROBE, USER MANUAL, COLOR BOX, SOFT

CARRYING CASE, 9V BATTERY

SCT PORTABLE MAGNETIC FIELD METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)250$*1(7,&),(/'0($685(0(176

Ɣ AN ELECTROMAGNETIC WAVE SIMPLY MEANS THE WAVE MOTION OF THE

ELECTROMAGNETIC FIELD (EMF).

Ɣ THIS METER IS APPLIED TO MEASURING ELECTROMAGNETIC FIELDS OF EXTREMELY LOW

FREQUENCY (ELF) OF 30HZ TO 300HZ.

Ɣ IT IS CAPABLE OF MEASURING THE ELECTROMAGNETIC FIELD RADIATION INTENSITY THAT

IS PRODUCED FROM ELECTRIC TRANSMISSION EQUIPMENT, POWER LINE, ELECTRIC

OVEN, AIR CONDITIONER, REFRIGERATOR, COMPUTER MONITOR, VIDEO/AUDIO DEVICE

AND SO FORTH.

THE MAGNETIC FIELD UNIT IS TESLA(T), GAUSS(G), MICRO-TESLA(UT) OR MILLI-GAUSS(MG).

Ɣ DATA HOLD, MAXIMUM HOLD, OVERLOAD INDICATION.

Ɣ %$77(5<23(5$7(':,7+/2:%$77(5<,1',&$7,21

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.50

MODEL NO. SCT-SKYE

RANGE a0*aȂ7

ACCURACY ±(2.5% + 6 DGT) AT 50 HZ/60HZ

RESOLUTION 0*Ȃ7

FREQUENCY RESPONSE 30 ~ 300 HZ

SENSOR SINGLE AXIS

POWER DC 9V BATTERY

DIMENSION 130 X 56 X 38 MM

WEIGHT 180 G

ORDERING INFORMATIONS:

SCT-108.002.50 SCT-SKYE SCT SKYE MAGNETIC FIELD METER IS SUPPLIED WITH 9V BATTERY AND INSTRUCTION MANUAL, PACKED

IN A BOX.

SCT PORTABLE FIELD STRENGTH METER (HF) & (EMF)

SALIENT FEATURES:

Ɣ $ &203/(7( 3257$%/( 6&7 0(7(5 )25 +,*+ )5(48(1&< +)$1' (/(&7521,& 0$*1(7,&

(EMF) FIELD MEASUREMENTS.

Ɣ MEASUREMENT RANGES: 0.1 ~ 2.700MW/CM2.

Ɣ THIS METER IS APPLIED TO MEASURING THE HIGH FREQUENCY(HF) ELECTROMAGNETIC FIELDS

FROM 50MHZ TO 3.5GHZ.

Ɣ IT IS CAPABLE OF MEASURING THE ELECTROMAGNETIC FIELD STRENGTH, WHICH PRODUCED

FROM ELECTRIC TRANSMISSION EQUIPMENT, MOBILE PHONE, WIRELESS LAN(WI-FI) AND

MICROWAVE OVEN.

Ɣ FUNCTION KEYS: POWER KEY, MAX/MIN KEY, HOLD KEY, ZERO KEY, FREQ TEAM KEY.

Ɣ BATTERY OPERATED.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.52

MODEL NO. SCT-STONE

RANGE 0.010 ~ 2.7 MW/CM2

ACCURACY FOR REFERENCE AT 1800MHZ

± 2 DB AT 2450 MHZ

RESOLUTION 0.01

POWER DC 9V BATTERY

DIMENSION 130 X 56 X 38 MM

WEIGHT 180 G

ORDERING INFORMATIONS:

SCT-108.002.52 SCT-STONE SCT STONE FIELD STRENGTH METER IS SUPPLIED WITH 9V BATTERY AND INSTRUCTION MANUAL, PACKED

IN A BOX.

Revolve your world around the customer and more customers will revolve around you.

424 sales@scichemtech.com www.scichemtech.com

424

SCT PORTABLE LEAK DETECTOR METER

SALIENT FEATURES:

Ɣ $&203/(7(6&73257$%/(0(7(5)255()5,*(5$17/($.'(7(&7,21

Ɣ &$1'(7(&7$//&+/252)/852&$5%216&)&

Ɣ 6$(-&203$7$%,/,7<+&)&$1'+)&6

Ɣ 7+5((5$1*(2)0($685(0(176***

Ɣ :,7+$8',2$/$50

Ɣ $87232:(56+872)),10,187(6

Ɣ %$77(5<23(5$7(':,7+/2:%$77(5<,1',&$7,21

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.53

MODEL NO. SCT-FRIDGE

SENSING HEATED DIODE

REFRIGERANTS R-22, R-134A, R-404A, R-410A, AND ALL CFCS, HCFC AND HFCS

SENSITIVITY LEVELS

HIGH 0.15 OZ. / YEAR (4G / YEAR)

MEDIUM 0.25 OZ. / YEAR (7G/YEAR)

LOW 0.5 OZ. / YEAR (14G/YEAR)

(COMPATIBILITY WITH SAE J2791)

RESET MANUALLY RESET TO BACKGROUND LEVEL

AUTOMATICALLY RESET TO BACKGROUND LEVEL

RESPONSE TIME LESS THAN 0.5 SECOND

WARM UP TIME APPROX. 45 SECONDS.

BATTERY TYPE 3.7V DC, 800M AH RECHARGEABLE LITHIUM BATTERY.

BATTERY LIFE 3 HOURS IN ALL @400 MA, 32OF ~ 113OF (0~45OC)

SENSOR FAILURE INDICATION YES

AUDIO ALARM YES (SPEAKER)

PUMP SYSTEM (FAN) YES

AUTO POWER OFF 10 MINUTES OF IDLE

LOW BATTERY INDICATOR YES

TIP LIGHT YES

FLEXIBLE PROBE LENGTH 18” (450MM)

OPERATING TEMP. AND % RH 32~122OF (0~50OC) <80% RH

STORAGE TEMP. AND % RH 14~140OF (-10 ~ 60OC) < 70% RH

DIMENSIONS 7.2” X 2.8” X 1.6” (184X70X40 MM)

WEIGHT 10.7 OZ (300 G)

ACCESSORIES 86(5¶6 0$18$/ &$55<,1* &$6( /($. 7(67 %277//( $&

ADAPTER, HOLSTER

ORDERING INFORMATIONS:

SCT-108.002.53 SCT-FRIDGE 6&7)5,'*(3257$%/(/($.,6'(7(&7256833/,('&203/(7(:,7+86(5¶60$18$/&$55<,1*

CASE, LEAK TEST BOTTLE AC ADAPTER, HOLSTER.

SCT PORTABLE SOLAR POWER METER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)2562/$532:(50($685(0(176

Ɣ (1'02817/,*+76(16256

Ɣ 6(/(&7(,7+(532:(52575$160,66,21

Ɣ 6(/(&7(,7+(5:025%78)7;+81,76

Ɣ '$7$+2/'0$;0,102'(6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.54

MODEL NO. SCT-SOLAR

RANGE 2000 W/M2 634 BTU (FT 2XH)

ACCURACY TYPICALLY WITHIN + 10 W/M2 [+3 BTU (FT2XH)] OR +5%

RESOLUTION 0.1 W/M2 0.1 BTU/(FT2XH)

POWER DC 9V BATTERY

DIMENSION 130 X 55 X 39 MM

WEIGHT 150 G

ORDERING INFORMATIONS:

SCT-108.002.54 SCT-SOLAR SCT SOLAR PORTABLE SOLAR POWER METER IS SUPPLIED COMPLETE WITH 9V BATTERY AND

INSTRUCTION MANUAL, PACKED IN A BOX.

Right or wrong, the customer is always right.

425

sales@scichemtech.com www.scichemtech.com

425

SCT K-TYPE THERMOCOUPLE THERMOMETER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)257(03(5$785(0($685(0(176

Ɣ ONE HOUR AUTO SHUT OFF

Ɣ TEMPERATURE SENSING TIME 1 SECOND.

Ɣ PVC HOLSTER WITH FLIP-OUT STAND AT THE BACK OF UNIT

Ɣ %$77(5<23(5$7(':,7+/2:%$77(5<,1',&$7,21

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.56

MODEL NO. SCT-STORM

MEASUREMENT RANGE -200°C ~ +1370°C OR -328°F ~ + 2498°F

RESOLUTION: 0.1°C FOR -199.9°C ~ +1369.9°C

ACCURACY

± 2°C FROM -200°C ~ -50°C (OR 4°F FROM -328°F ~ -58°F)

± 1°C FROM -49°C ~ +740°C (OR 1.8°F FROM -56.2°F ~ +1364°F)

± 2°C FROM +741°C ~ +1300°C (OR 4°F FROM +1365.8°F ~ +2372°F),

OTHERWISE MORE THAN 2°C OR 4°F.

ACCURACY IS SPECIFIED FOR OPERATING TEMPERATURES

OVER THE RANGE OF 18°C TO 28°C (64°F TO 82°F). THE BASIC

ACCURACY SPECIFICATION DOES NOT INCLUDE THE ERROR OF THE

THERMOCOUPLE PROBE.

AMBIENT TEMPERATURE FOR

PLASTIC CASING 0°C ~ +50°C (OR +14°F ~ +122°F)

OPERATION PRESS ON/OFF, THE TIMER BEGINS TO COUNT. THE TEMPERATURE

DISPLAYS.

TEMPERATURE MEASUREMENT PRESS °F/°C TO SELECT DESIRED UNIT.

HOLD/TEST FUNCTION

PRESS H/T, “HOLD” SIGN FLASHES ON THE DISPLAY TO RETAIN

TEMPERATURE TESTED. PRESS H/T AGAIN AND WILL GO BACK TO

TESTING MODE. “HOLD” SIGN WILL DISAPPEAR.

ORDERING INFORMATIONS:

SCT-108.002.56 SCT-STORM SCT-STORM K-TYPE THERMOCOUPLE THERMOMETER IS SUPPLIED COMPLETE WITH BATTERIES

AND INSTRUCTION MANUAL, PACKED IN A BOX.

* PLS NOTE PROBES ARE NOT INCLUDED, PLEASE SELECT FROM THE OPTIONAL ACCESSORIES IN THE NEXT PAGES.

SCT K-TYPE THERMOCOUPLE PROBES FOR SCT MODEL STORM

K-TYPE THERMOCOUPLE PROBE - PENETRATION PROBE

PRODUCT NO. LENGTH (MM) & DIAMETER TEMPERATURE

SCT-108.002.K1 225 X Ø6.4 -100°C ~ +1000°C OR -148°F ~ +1832°F

SCT-108.002.K2 225 X Ø4.8 -100°C ~ +900°C OR -148°F ~ +1652°F

SCT-108.002.K3 175 X Ø3.2 -100°C ~ +800°C OR -148°F ~ +1472°F

SCT-108.002.K4 133 X Ø3.5 -100°C ~ +300°C OR -148°F ~ +572°F

Risk comes from not knowing what you’re doing

426 sales@scichemtech.com www.scichemtech.com

426

K-TYPE THERMOCOUPLE PROBE – IMMERSION PROBE

L13

PRODUCT NO. LENGTH (MM) & DIAMETER TEMPERATURE

SCT-108.002.L1 225 X Ø6.4 -100°C ~ +1000°C OR -148°F ~ +1832°F

SCT-108.002.L2 225 X Ø4.8 -100°C ~ +900°C OR -148°F ~ +1652°F

SCT-108.002.L3 175 X Ø3.2 -100°C ~ +800°C OR -148°F ~ +1472°F

SCT-108.002.L4 148 X Ø4 -100°C ~ +300°C OR -148°F ~ +572°F

K-TYPE THERMOCOUPLE PROBE – SURFACE PROBE

PRODUCT NO. LENGTH (MM) & DIAMETER TEMPERATURE

SCT-108.002.M1 265 X Ø8.00 -100°C ~ +400°C OR -148°F ~ +752°F

SCT-108.002.M2 265 X Ø18.00 -100°C ~ +400°C OR -148°F ~ +752°F

SCT-108.002.M3 213 X Ø15.00 -100°C ~ +400°C OR -148°F ~ +752°F

SCT-108.002.M4 225 X Ø16.00 -100°C ~ +400°C OR -148°F ~ +752°F

SCT-108.002.M5 230 X Ø16.00 -100°C ~ +400°C OR -148°F ~ +752°F

SCT-108.002.M6 Ø18.00 -100°C ~ +400°C OR -148°F ~ +752°F

- N1

- N2

PRODUCT NO. LENGTH (MM) & DIAMETER TEMPERATURE

HANDLE PROBE PROBE HEAD

SCT-108.002.N1 150 X Ø18 219 X Ø6.4 Ø16 -100°C ~ +400°C OR -148°F ~ +752°F

SCT-108.002.N2 150 X Ø18 219 X Ø4.8 Ø13.7 -100°C ~ +400°C OR -148°F ~ +752°F

Rule 1: the customer is always right. Rule 2: if the customer is ever wrong, re-read rule 1.

427

sales@scichemtech.com www.scichemtech.com

427

PRODUCT NO. LENGTH (MM) & DIAMETER TEMPERATURE

PROBE PROBE HEAD

SCT-108.002.O1 230 X Ø4 Ø12 -100°C ~ +300°C OR -148°F ~ +572°F

PRODUCT NO. TEMPERATURE

SCT-108.002.P1 -100°C ~ +400°C OR -148°F ~ +752°F

SCT-108.002.P2 -100°C ~ +400°C OR -148°F ~ +752°F

PRODUCT NO. LENGTH (MM) & DIAMETER TEMPERATURE

SCT-108.002.Q1 150 X Ø8.00 -100°C ~ +600°C OR -148°F ~ +1112°F

SCT-108.002.Q2 Ø18.00 -100°C ~ +600°C OR -148°F ~ +1112°F

PRODUCT NO. LENGTH (MM) & DIAMETER TEMPERATURE

PROBE PROBE HEAD

SCT-108.002.R1 213 x ø3.5 40mm x 5.5mm -100°C ~ +300°C or -148°F ~ +572°F

SCT STORM-1 DIGITAL THERMOCOUPLE THERMOMETER

SALIENT FEATURES :

Ɣ 6&7 67250 +$6 %((1 '(6,*1('  ,1 $ &203$&T,ATTRACTIVE & ERGONOMIC

WAY.

Ɣ 6&767250+$6&/($5/&'',63/$<:,7+%$&./,*+7 

Ɣ6&767250+$6$:,'(5$1*(2)7(030($685(0(17OC / -58-2000OF

Ɣ 6&767250+$686(56(/(&7$%/(OC OR OF AND WITH RESOLUTION OF 0.1OC OR 1OC (0.1OF

OR 1OC)

Ɣ 6&767250+$67<3(.7+(502&283/(6$1'6,1*/(7+(502&283/(,1387

Ɣ6&767250+$60$;+2/'$1''$7$+2/')81&7,216 

Ɣ 7+,6 0(7(5 +$6 %((1 0$18)$&785(' $6 3(5 7+( ,17(51$7,21$/ 67$1'$5'6  ,62

9001:2008 QUALITY STANDARDS.

TECHNICAL SPECIFICATIONS :

PRODUCT NO SCT-108.002.57

MODEL NO SCT-STORM-1

TEMPERATURE -50-1300OC / -58-2000OF

ACCURACY ±(0.5%±1OC) / ± (0.5%±2OF)

RESOLUTION 0.1°

ORDERING INFORMATIONS:

PRODUCT NO MODEL NO. DESCRIPTION

SCT-108.002.57 SCT-STORM-1 SCT STORM-1 DIGITAL THERMOCOUPLE THERMOMETER IS SUPPLIED WITH 9V BATTERY,

HOLSTER WITH STAND, TYPE K TEMPERATURE WIRE PROBE WITH CARRYING CASE.

2SWLRQDO$FFHVVRULHVRUGHURQO\LIUHTXLUHG

ACCESSORY SCT-PRODUCT NO DESCRIPTION

PROBE SCT-108.002.57 AA K-TYPE TEMPERATURE PROBE

BATTERIES SCT-108.002.57 AB BATTERIES FOR SCT-STORM-1

P1 P2

Sales are contingent upon the attitude of the salesman - not the attitude of the prospect.

428 sales@scichemtech.com www.scichemtech.com

428

SCT PORTABLE LCD DIGITAL MULTI - THERMOMETER

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)257(03(5$785(0($685(0(176

Ɣ $8726+872))

Ɣ 7(03(5$785(6(16,1*7,0(6(&21'

Ɣ 213MM. STAINLESS STEEL SENSOR PROBE.

Ɣ MAX/MIN (°F/°C) MEMORY RECALLING FUNCTION.

Ɣ TEMPERATURE UNIT °F/°C SELECTABLE.

Ɣ DATA HOLD/TEST FUNCTION SELECTABLE .

Ɣ BATTERY OPERATED WITH LOW BATTERY INDICATION.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.60

MODEL NO. SCT-STAR

MEASUREMENT RANGE -50°C ~ +150°C OR -58°F ~+302°F

RESOLUTION 0.1°C FOR -19.9°C ~ +199.9°C, OTHERWISE 1°C

ACCURACY ±1°C IN THE RANGE OF -30°C ~ +150°C

±1.8°F IN THE RANGE OF -22°F ~ +302°F

AMBIENT TEMPERATURE FOR PLASTIC CASE 0°C ~ +50°C OR +14°F ~+122°F

BATTERY 1 X 1.5 VOLTS

ORDERING INFORMATIONS:

SCT-108.002.60 SCT-STAR

SCT-STAR LCD DIGITAL MULTI – THERMOMETER WITH 213 MM STAINLESS STEEL PROBE, ON/OFF,

H/T, °F/°C, MAX/MIN (°F/°C) MEMORY RECALLING IS SUPPLIED WITH TEMPERATURE PROBE (213 MM)

BATTERIES AND INSTRUCTIONS PACKED IN A BOX.

SCT LCD WATERPROOF SOIL THERMOMETER WITH HOLDER AND DETACHABLE PROBE

SALIENT FEATURES:

Ɣ $&203/(7( 3257$%/( 6&70(7(5 )257(03(5$785(0($685(0(176 ,162,/$1'&$1%(

USED FOR GENERAL APPLICATIONS.

Ɣ $8726+872))

Ɣ 265 mm x 5 mm DIA STAINLESS STEEL SENSOR PROBE

Ɣ MAX/MIN (°F/°C) MEMORY RECALLING FUNCTION

Ɣ TEMPERATURE UNIT °F/°C SELECTABLE

Ɣ DATA HOLD/TEST FUNCTION SELECTABLE

Ɣ OPTIONAL PVC HOLSTER

Ɣ RUBBER COATED HOUSING

Ɣ TEMPERATURE SENSING TIME 1 SECOND.

Ɣ BATTERY OPERATED WITH LOW BATTERY INDICATION.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.61

MODEL NO. SCT-STASH

MEASUREMENT RANGE -50°C ~ +300°C OR -58°F ~+572°F

RESOLUTION 0.1°C FOR -19.9°C ~ +199.9°C, OTHERWISE 1°C

ACCURACY ±1°C IN THE RANGE OF -30°C ~ +150°C

AMBIENT TEMPERATURE FOR PLASTIC CASE 0°C ~ +50°C OR +14°F ~ +122°F

BATTERY 1 X 1.5 VOLTS

ORDERING INFORMATIONS:

SCT-108.002.61 SCT-STASH

SCT-STASH LCD WATERPROOF THERMOMETER WITH HOLDER AND DETACHABLE 300 MM STAINLESS

STEEL PROBE WITH ON/OFF, H/T, MAX/MN (°F/°C) MEMORY RECALLING FUNCTION, °F/°C IS SUPPLIED

COMPLETE WITH BATTERIES AND INSTRUCTION PACKED IN A BOX.

Satisfaction lies in the effort, not in the attainment. Full effort is full victory-.

429

sales@scichemtech.com www.scichemtech.com

429

SCT PORTABLE INFRARED THERMOMETERS (GENERAL PURPOSE)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ 7(03(5$785(5$1*(OC TILL 320OC)

Ɣ RUGGED AND ERGONOMIC DESIGN FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ BACKLIGHT LCD DISPLAY / AUTO SHUT-OFF IN 6 SECONDS

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ 237,21726(/(&7OC/OF

Ɣ %$77(5<2(35$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.66

MODEL NO. SCT-KARAN

DISTANCE/SPOT RATIO 8:1

TEMPERATURE RANGE -20~320OC (-4OC~605 OF)

ACCURACY (ASSUMES OPERATION

AMBIENT TEMPERATURE OF 25OC/77OF)

±2% OF READING OR ±2OC WHICHEVER IS GREATER

THERMOPILE aȂ0

REPEATABILITY ±1OC (±2OF)

RESOLUTION 0.5OC (0.5OF)

RESPONSE TIME 500MS

OPERATION TEMP 0~50OC (32~122OF),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY FIXED AT 0.95

STORAGE TEMP. -10 ~ 60OC(14OF ~ 140OF)

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

DIMENSIONS îî00´î´î´

ORDERING INFORMATIONS:

SCT-108.002.66 SCT-KARAN SCT KARAN INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, CASE & MANUAL.

SCT PORTABLE INFRARED THERMOMETERS (WIDE RANGE)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ 7(03(5$785(5$1*(OC TILL 500OC)

Ɣ RUGGED AND ERGONOMIC DESIGN FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ BACKLIGHT LCD DISPLAY.

Ɣ AUTO SHUT-OFF IN 6 SECONDS.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ OPTION TO SELECT

OC/OF

Ɣ BATTERY OPERATED.

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.67

MODEL NO. SCT-THOMS

DISTANCE/SPOT RATIO 8:1

TEMPERATURE RANGE -20OC ~ 500OC (-4OF ~ 930OF)

ACCURACY (ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25OC/77OF)

±2.0OC (±3OF) FROM-20 ~ 100OC(-4OF ~ 212OF),

±2% FROM 100OC ~ 500OC (212OF ~ 930OF)

THERMOPILE aȂ0

REPEATABILITY ±1OC(±2OF)

RESOLUTION 0.2OC(0.2OF)

RESPONSE TIME 500 MS

OPERATION TEMP 0~50OC (32OF~122OF),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY FIXED AT 0.95

STORAGE TEMP. -10OC ~ 60OC (14OF ~ 140OF)

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

DIMENSIONS îî00´î´î´

ORDERING INFORMATIONS:

SCT-108.002.67 SCT-THOMS SCT THOMS INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, CASE & MANUAL

SCT-NON CONTACT THERMOMETER

Saying someone is ugly doesn’t make you any prettier

430 sales@scichemtech.com www.scichemtech.com

430

SCT PORTABLE INFRARED THERMOMETERS (HIGH PERFORMANCE 12:1)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ NEW SERIES INCLUDES HIGH PERFORMANCE, GENERAL PURPOSE.

Ɣ 7(03(5$785(5$1*(OC TO 535OC.

Ɣ ),;('(0,66,9,7<#

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUT DOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ HIGH DS RATIO.

Ɣ BACKLIGHT LCD DISPLAY.

Ɣ OPTION TO SELECT

OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ %$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.68

MODEL NO. SCT-VAND

DISTANCE/SPOT RATIO 12:1

TEMPERATURE RANGE -32~535°C (-25OF~999OF)

ACCURACY ( ASSUMES OPERATION

AMBIENT TEMPERATURE OF 25°C / 77°F)

±3OC (±5OF) FROM-32OC~-20OC (-25~-4OF)

±2OC (±3OF) FROM-20OC~100OC (-4~212OF)

±2%FROM 100OC~535OC (212OF~999OF)

THERMOPILE aȂ0

REPEATABILITY ±1OC (±2OF)

RESOLUTION 0.1OC (0.1OF)

RESPONSE TIME 500 MS

OPERATION TEMP 0~50OC (32~122OF),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6 SEC

EMISSIVITY 0.95

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 NO

AUTO-MEASURING NO

10 POINT MEMORY NO

AUDIO ALARM NO

BATTERY TYPE 9V, 006P, IEC6F22, NEDA1604

DIMENSIONS îî00´î´î´

WEIGHT 187G APPROX

ACCESSORY 9V BATTERY, INSTRUCTION MANUAL , CARRYING CASE

ORDERING INFORMATIONS:

SCT-108.002.68 SCT-VAND SCT VAND INFRARED THERMOMETERS IS SUPPLIED WITH 9V DC BATTERY, INSTRUCTION MANUAL,

CARRYING CASE

SCT PORTABLE INFRARED THERMOMETERS (HIGH PERFORMANCE)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ NEW SERIES INCLUDES HIGH PERFORMANCE, GENERAL PURPOSE (12:1)

Ɣ FIXED EMISSIVITY, FIXED @ 0.95.

Ɣ 7(0(35$785(5$1*(OC TO 535OC

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ HIGH DS RATIO.

Ɣ BACKLIGHT LCD DISPLAY WITH AUTO SHUT-OFF IN 6 SECONDS.

Ɣ OPTION TO SELECT

OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ BATTERY OPERATED.

Science and religion are not at odds. Science is simply too young to understand

431

sales@scichemtech.com www.scichemtech.com

431

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.69

MODEL NO. SCT-VINNY

DISTANCE/SPOT RATIO 12:1

TEMPERATURE RANGE -32°C~535°C (-25°C~999OF)

ACCURACY ( ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25°C / 77°F)

±3OC (±5OF) FROM -32°C~-20OC (-25OF~-4OF)

±2OC (±3OF) FROM -20~100OC (-4OF~212OF)

±2% FROM 100OC~535OC (212OF~999OF)

THERMOPILE aȂ0

REPEATABILITY ±1OC (±2OF)

RESOLUTION 0.1OC (0.1OF)

RESPONSE TIME 500 MS

OPERATION TEMP 0~50OC (32OF~122OF), 10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY 0.95

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

BATTERY TYPE 9V , 006P, IEC6F22 , NEDA1604

DIMENSIONS îî00´î´î´

WEIGHT 187G APPROX

ACCESSORY 9V BATTERY , INSTRUCTION MANUAL, CARRYING CASE

ORDERING INFORMATIONS:

SCT-108.002.69 SCT-VINNY SCT VINNY INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, INSTRUCTION MANUAL, CARRYING CASE

SCT PORTABLE INFRARED THERMOMETERS (HIGH PERFORMANCE & ACCURACY)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ NEW SERIES INCLUDES HIGH PERFORMANCE, HIGH ACCURACY.

Ɣ EMISSIVITY ADJUSTABLE FROM 0.1 TO 1.00 IN 0.01 STEPS (ADJUSTABLE).

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ HIGH DS RATIO Ɣ BACKLIGHT LCD DISPLAY.

Ɣ OPTION TO SELECT

OC/OF. Ɣ TEMPERATURE DATA STORAGE.

Ɣ $8',%/($/$506 Ɣ%$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.70

MODEL NO. SCT-WILL

DISTANCE/SPOT RATIO 12:1

TEMPERATURE RANGE -32~535°C(-25~999OF)

ACCURACY ( ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25°C / 77°F)

±3OC(±5OF) FROM-32~-20OC (-25~-4OF)

±2OC(±3OF) FROM-20~100OC (-4~212OF)

±2% FROM100~535OC (212~999OF)

THERMOPILE aȂ0

REPEATABILITY ±1OC(±2OF)

RESOLUTION 0.1OC(0.1OF)

RESPONSE TIME 500MS

OPERATION TEMP 0~50OC(32~122OF),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY ADJ 0.1-1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

BATTERY TYPE 9V , 006P , IEC6F22 , NEDA1604

DIMENSIONS îî00´î´î´

WEIGHT 187G APPROX

ACCESSORY 9V BATTERY , INSTRUCTION MANUAL , CARRYING CASE

ORDERING INFORMATIONS:

SCT-108.002.70 SCT-WILL SCT WILL INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, INSTRUCTION MANUAL,

CARRYING CASE

Science at its best is an open-minded method of inquiry, not a belief system.

432 sales@scichemtech.com www.scichemtech.com

432

SCT PORTABLE INFRARED THERMOMETERS (HIGH TEMPERATURE 999OC)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ 7(03(5$785(5$1*(OC TO 999OC

Ɣ ),;('(0,66,9,7<#

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ HIGH DS RATIO.

Ɣ BACKLIGHT LCD DISPLAY.

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ 237,21726(/(&7OC/OF

Ɣ %$77(5<2(35$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.71

MODEL NO. SCT-WIND

DISTANCE / SPOT RATIO 12:1

TEMPERATURE RANGE -50~999°C (-58~1830OF)

ACCURACY

(ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25°C/77°F)

±3OC(±5OF)FROM-50~-20OC (-58~-4OF)

±2OC(±3OF)FROM-20~100OC (-4~212OF)

±2% FROM100~-999OC (212~1830OF)

THERMOPILE aȂ0

REPEATABILITY ±1OC (±2OF)

RESOLUTION 1OC OR 1OF

RESPONSE TIME 500MS

OPERATING TEMP 0~50OC(32~122OF) , 10~90% RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY 0.95

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 NO

AUTO-MEASURING NO

10 POINT MEMORY NO

AUDIO ALARM NO

BATTERY TYPE 9V , 006P , IEC6F22 , NEDA1604

DIMENSIONS îî00´î´î´

WEIGHT 187G APPROX

ACCESSORY 9V BATTERY, INSTRUCTION MANUAL, CARRYING CASE

ORDERING INFORMATIONS:

SCT-108.002.71 SCT-WIND SCT WIND INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, INSTRUCTION MANUAL, CARRYING CASE

SCT PORTABLE INFRARED THERMOMETERS (HIGH PERFORMANCE & FIXED

EMISSIVITY)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ 7(03(5$785(5$1*(OC TO 999OC

Ɣ FIXED EMISSIVITY @ 0.95

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ +,*+'65$7,20$;0,1FI¨7

Ɣ BACKLIGHT LCD DISPLAY WITH AUDIO ALARM.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ 32,170(025<%$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.72

MODEL NO. SCT-XANDY

DISTANCE/SPOT RATIO 12:1

TEMPERATURE RANGE -50~999°C(-58~1830OF)

ACCURACY

(ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25°C/77°F)

±3OC(±5OF)FROM-50~-20OC(-58~-4OF)

±2OC(±3OF)FROM-20~100OC(-4~212OF)

±2%FROM 100~-999OC(212~1830OF)

THERMOPILE aȂ0

REPEATABILITY ±1OC(±2OF)

RESOLUTION 1OC OR 1OF

RESPONSE TIME 500MS

A brave man acknowledges the strength of others.

433

sales@scichemtech.com www.scichemtech.com

433

OPERATING TEMP 0~50OC(32~122OF) , 10~90% RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY 0.95

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

BATTERY TYPE 9V , 006P , IEC6F22 , NEDA1604

DIMENSIONS îî00´î´î´

WEIGHT 187G APPROX

ACCESSORY 9V BATTERY , INSTRUCTION MANUAL , CARRYING CASE

ORDERING INFORMATIONS:

SCT-108.002.72 SCT-XANDY SCT XANDY INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, INSTRUCTION MANUAL,

CARRYING CASE

SCT PORTABLE INFRARED THERMOMETERS (HIGH PERFORMANCE WITH ADJ. EMISSIVITY)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ 7(03(5$785(5$1*(OC TO 999OC

Ɣ $'-867$%/((0,66,9,7<)52072

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ +,*+'65$7,20$;0,19$9*¨7

Ɣ BACKLIGHT LCD DISPLAY.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ $8720($685,1*

Ɣ 232,1760(025<

Ɣ %$77(5<2(3$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.73

MODEL NO. SCT-XARIA

DISTANCE/SPOT RATIO 12:1

TEMPERATURE RANGE -50~999°C(-58~1830OF)

ACCURACY

(ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25°C/77°F)

±3OC(±5OF)FROM-50~-20OC(-58~-4OF)

±2OC(±3OF)FROM-20~100OC(-4~212OF)

±2%FROM 100~-999OC(212~1830OF)

THERMOPILE aȂ0

REPEATABILITY ±1OC(±2OF)

RESOLUTION 1OC OR 1OF

RESPONSE TIME 500MS

OPERATING TEMP 0~50OC(32~122OF) , 10~90% RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY ADJ 0.1-1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

BATTERY TYPE 9V, 006P, IEC6F22 , NEDA1604

DIMENSIONS îî00´î´î´

WEIGHT 187G APPROX

ACCESSORY 9V BATTERY , INSTRUCTION MANUAL , CARRYING CASE

ORDERING INFORMATIONS:

SCT-108.002.73 SCT-XARIA SCT XARIA INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, INSTRUCTION MANUAL,

CARRYING CASE

Science does not know its debt to imagination.

434 sales@scichemtech.com www.scichemtech.com

434

SCT PORTABLE INFRARED THERMOMETERS (MEDIUM SPOT RATIO 30:1)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ RUGGED & ERGONOMIC DESIGN.

Ɣ HIGH DS RATIO / SPOT RATIO 30:1

Ɣ ADJUSTABLE EMISSIVITY FROM 0.1 TILL 1.0

Ɣ BACKLIGHT DUAL DISPLAY LCD.

Ɣ NEW SERIES FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ %$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.74

MODEL NO. SCT-ZEAL

DISTANCE/SPOT RATIO 30:1

TEMPERATURE RANGE -32~ 760OC(-25.6~ 1400OF)

ACCURACY (ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25OC/77OF)

±3OC(±5OF) -32~ -20OC(-25.6~ -4OF)

±2OC(±3OF) -20~ 100OC(-4~ 212OF)

ABOVE 100OC(212OF):±2%

THERMOPILE aȂ0

REPEATABILITY ±1OC(±2OF)

RESOLUTION 0.1OC(0.1OF)

RESPONSE TIME 500MS

OPERATION TEMP 0~50OC(32~122OF),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6 SEC

EMISSIVITY ADJUSTABLE 0.1~1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

DUAL DISPLAY YES

TRIPOD MOUNT YES

DIMENSIONS îî00´î´î´

ORDERING INFORMATIONS:

SCT-108.002.74 SCT-ZEAL SCT ZEAL INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, CASE & MANUAL.

SCT PORTABLE INFRARED THERMOMETERS (Medium Spot Ratio 30:1, High Temp -32

C to 1300

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ TEMPERATURE RANGE : (-32OC TO 1300OC)

Ɣ RUGGED & ERGONOMIC DESIGN.

Ɣ HIGH DS RATIO / SPOT RATIO 30:1

Ɣ ADJUSTABLE EMISSIVITY FROM 0.1 TILL 1.0

Ɣ BACKLIGHT DUAL DISPLAY LCD.

Ɣ NEW SERIES FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ %$77(5<23(5$7('

6FLHQFHÀFWLRQDQ\VFLHQWLÀFDFFODLPWKDWRPLWVJRG

435

sales@scichemtech.com www.scichemtech.com

435

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.75

MODEL NO. SCT-ZIARRE

DISTANCE/SPOT RATIO 30:1

TEMPERATURE RANGE -32~ 1300OC (-25.6~2372OF)

ACCURACY (ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25OC/77OF)

±3OC(±5OF) -32~ -20OC(-25.6~ -4OF)

±2OC(±3OF) -20~ 100OC(-4~ 212OF)

ABOVE 100OC(212OF):±2%

THERMOPILE aȂ0

REPEATABILITY ±1OC(±2OF)

RESOLUTION 0.1OC OR 0.1OF(ABOVE 2000OF:1OF)

RESPONSE TIME 500MS

OPERATION TEMP 0~50OC(32~122OF),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6 SEC

EMISSIVITY ADJUSTABLE 0.1~1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

DUAL DISPLAY YES

TRIPOD MOUNT YES

DIMENSIONS îî00´î´î´

ORDERING INFORMATIONS:

SCT-108.002.75 SCT-ZIARRE SCT ZIARRE INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, CASE MANUAL.

SCT PORTABLE INFRARED THERMOMETERS (HIGH DS/SR 50:1)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ TEMPERATURE RANGE : (-32OC TO 1300OC)

Ɣ RUGGED & ERGONOMIC DESIGN.

Ɣ HIGH DS RATIO / SPOT RATIO 50:1

Ɣ ADJUSTABLE EMISSIVITY FROM 0.1 TILL 1.0

Ɣ BACKLIGHT DUAL DISPLAY LCD.

Ɣ NEW SERIES FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ %$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.76

MODEL NO. SCT-ZODY

DISTANCE/SPOT RATIO 50:1

TEMPERATURE RANGE -32~ 1300OC(-25.6~2372OF)

ACCURACY (ASSUMES OPERATION

AMBIENT TEMPERATURE OF 25OC/77OF)

±3OC(±5OF) -32~ -20OC(-25.6~ -4OF)

±2OC(±3OF) -20~ 100OC(-4~ 212OF)

ABOVE 100OC(212OF):±2%

THERMOPILE aȂ0

REPEATABILITY ±1OC(±2OF)

RESOLUTION 0.1OC OR 0.1OF(ABOVE 2000OF:1OF)

RESPONSE TIME 500MS

OPERATION TEMP 0~50OC(32~122OF),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6 SEC

EMISSIVITY ADJUSTABLE 0.1~1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

DUAL DISPLAY YES

TRIPOD MOUNT YES

DIMENSIONS îî00´î´î´

ORDERING INFORMATIONS:

SCT-108.002.76 SCT-ZODY SCT ZODX INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, CASE & MANUAL.

Science has proof without any certainty. Creationists have certainty without any proof .

436 sales@scichemtech.com www.scichemtech.com

436

SCT PORTABLE INFRARED THERMOMETERS WITH HIGH TEMP. -32OC TO 1650OC

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ TEMPERATURE RANGE : (-32OC TO 1650OC)

Ɣ RUGGED & ERGONOMIC DESIGN.

Ɣ HIGH DS RATIO / SPOT RATIO 50:1

Ɣ ADJUSTABLE EMISSIVITY FROM 0.1 TILL 1.0

Ɣ BACKLIGHT DUAL DISPLAY LCD.

Ɣ NEW SERIES FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ %$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.77

MODEL NO. SCT-REX

DISTANCE/SPOT RATIO 50:1

TEMPERATURE RANGE -32~ 1650OC(-25.6~3002OF)

ACCURACY

(ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25OC/77OF)

±3OC(±5OF) -32~ -20OC(-25.6~ -4OF)

±2OC(±3OF) -20~ 100OC(-4~ 212OF)

ABOVE 100OC(212OF):±2%

THERMOPILE aȂ0

REPEATABILITY ±1OC(±2OF)

RESOLUTION 0.1OC OR 0.1OF(ABOVE 2000OF:1OF)

RESPONSE TIME 500MS

OPERATION TEMP 0~50OC(32~122OF),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6 SEC

EMISSIVITY ADJUSTABLE 0.1~1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

DUAL DISPLAY YES

TRIPOD MOUNT YES

DIMENSIONS îî00´î´î´

ORDERING INFORMATIONS:

SCT-108.002.77 SCT-REX SCT- REX INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, CASE AND MANUAL.

SCT HIGH PERFORMANCE INFRARED THERMOMETERS (SPOT RATIO 30:1)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ TEMPERATURE RANGE : (-52OC TO 1000OC)

Ɣ RUGGED & ERGONOMIC DESIGN.

Ɣ HIGH DS RATIO / SPOT RATIO 30:1

Ɣ ADJUSTABLE EMISSIVITY FROM 0.1 TILL 1.0

Ɣ BACKLIGHT DUAL DISPLAY LCD.

Ɣ NEW SERIES FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ %$77(5<23(5$7('

Science is a way of thinking much more than it is a body of knowledge

437

sales@scichemtech.com www.scichemtech.com

437

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.78

MODEL NO. SCT-HEMS

DISTANCE/SPOT RATIO 30:1

TEMPERATURE RANGE -50~ 1000°C(-58~ 1832OF)

ACCURACY (ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25°C/77°F)

±3°C(±5°F) -50~ -20°C(-58~ -4°F)

±2°C(±3°F) -20~ 100°C(-4~ 212°F)

±2% 100~1000°C(212~1832°F)

THERMOPILE aȂ0

REPEATABILITY ±1°C(±2°F)

RESOLUTION 0.1°C(0.1°F)

RESPONSE TIME 500MS

OPERATION TEMP 0~50°C(32~122°F),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY ADJUSTABLE 0.1~1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

DUAL DISPLAY YES

TRIPOD MOUNT YES

USB DATA OUTPUT NO

THERMOCOUPLE K TYPE NO

DIMENSIONS 7.88X6.15X47.5MM(6.14”X3.95”X1.87”)

ORDERING INFORMATIONS:

SCT-108.002.78 SCT-HEMS SCT HEMS INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, CASE AND MANUAL

SCT HIGH PERFORMANCE INFRARED THERMOMETERS (SPOT RATIO 50:1)

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ TEMPERATURE RANGE : (-52OC TO 1000OC)

Ɣ RUGGED & ERGONOMIC DESIGN.

Ɣ HIGH DS RATIO / SPOT RATIO 50:1

Ɣ ADJUSTABLE EMISSIVITY FROM 0.1 TILL 1.0

Ɣ BACKLIGHT DUAL DISPLAY LCD.

Ɣ NEW SERIES FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ %$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.79

MODEL NO. SCT-MALAR

DISTANCE/SPOT RATIO 50:1

TEMPERATURE RANGE -50~ 1000°C(-58~ 1832OF)

ACCURACY (ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25°C/77°F)

±3OC(±5°F) -50~ -20°C(-58~ -4°F)

±2°C(±3°F) -20~ 100°C(-4~ 212°F)

±2% 100~1000°C(212~1832°F)

THERMOPILE aȂ0

REPEATABILITY ±1°C(±2°F)

RESOLUTION 0.1°C(0.1°F)

RESPONSE TIME 500MS

OPERATION TEMP 0~50°C(32~122°F),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6 SEC

EMISSIVITY ADJUSTABLE 0.1~1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

Science is a wonderful discipline, to which we are deeply indebted.

438 sales@scichemtech.com www.scichemtech.com

438

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

DUAL DISPLAY YES

TRIPOD MOUNT YES

USB DATA OUTPUT NO

THERMOCOUPLE K TYPE NO

DIMENSIONS 7.88X6.15X47.5MM(6.14”X3.95”X1.87”)

ORDERING INFORMATIONS:

SCT-108.002.79 SCT-MALAR SCT-MALAR INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY, CASE AND MANUAL.

SCT HIGH PERFORMANCE INFRARED THERMOMETERS WITH ‘K’ TYPE

THERMOCOUPLE AND USB DATA OUTPUT

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ 6833/,(':,7+µ.¶7<3(7+(502&283/(72+$9(&217$&77(03(5$785(0($685(0(17

Ɣ 86%'$7$287387

Ɣ TEMPERATURE RANGE : (-52OC TO 1000OC)

Ɣ RUGGED & ERGONOMIC DESIGN.

Ɣ HIGH DS RATIO / SPOT RATIO 50:1

Ɣ ADJUSTABLE EMISSIVITY FROM 0.1 TILL 1.0

Ɣ BACKLIGHT DUAL DISPLAY LCD.

Ɣ NEW SERIES FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ %$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.80

MODEL NO. SCT-MALIN

DISTANCE/SPOT RATIO 50:1

TEMPERATURE RANGE -50~ 1000°C (-58~ 1832OF)

ACCURACY (ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25°C/77°F)

±3°C (±5°F) -50~ -20°C (-58~ -4°F)

±2°C (±3°F) -20~ 100°C (-4~ 212°F)

±2% 100~1000°C (212~1832°F)

THERMOPILE aȂ0

REPEATABILITY ±1°C (±2°F)

RESOLUTION 0.1°C (0.1°F)

RESPONSE TIME 500MS

OPERATION TEMP 0~50°C (32~122°F), 10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY ADJUSTABLE 0.1~1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

DUAL DISPLAY YES

TRIPOD MOUNT YES

USB DATA OUTPUT YES

THERMOCOUPLE K TYPE YES

DIMENSIONS 7.88X6.15X47.5MM (6.14”X3.95”X1.87”)

ORDERING INFORMATIONS:

SCT-108.002.80 SCT-MALIN 6&7 0$/,1 ,1)5$5(' 7+(5020(7(5 ,6 6833/,(' :,7+ µ.¶ 7+(502&283/( 9 '& %$77(5<

INSTRUCTION AND CARRYING CASE.

Science is a wonderful thing if one does not have to earn one’s living at it.

439

sales@scichemtech.com www.scichemtech.com

439

SCT PLUS HIGH PERFORMANCE INFRARED THERMOMETERS (50:1) 50 ~ 1500OC

SALIENT FEATURES:

Ɣ $&203/(7(3257$%/(6&70(7(5)25121&217$&77(03(5$785(0($685(0(176

Ɣ TEMPERATURE RANGE : (-50OC TO 1500OC)

Ɣ RUGGED & ERGONOMIC DESIGN.

Ɣ HIGH DS RATIO / SPOT RATIO 50:1

Ɣ ADJUSTABLE EMISSIVITY FROM 0.1 TILL 1.0

Ɣ BACKLIGHT DUAL DISPLAY LCD.

Ɣ NEW SERIES FOR GENERAL PURPOSES.

Ɣ ULTRA LOW POWER CONSUMPTION IN SHUTDOWN MODE.

Ɣ EXTENDED LONG TIME MEASURING RELIABILITY.

Ɣ LASER SIGHTING ON/OFF IS SWITCHABLE.

Ɣ 237,21726(/(&7OC/OF

Ɣ ELECTRONIC TRIGGER LOCK.

Ɣ TEMPERATURE DATA STORAGE.

Ɣ AUDIBLE ALARMS.

Ɣ %$77(5<23(5$7('

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.81

MODEL NO. SCT-ZEN

DISTANCE/SPOT RATIO 50:1

TEMPERATURE RANGE -50~ 1500°C (-58~ 2732OF)

ACCURACY (ASSUMES OPERATION AMBIENT

TEMPERATURE OF 25°C/77°F)

±3OC (±5OF) -50~ -20OC (-58~ -4OF)

±2OC (±3OF) -20~ 100OC (-4~ 212OF)

±2% 100~1500OC (212~2732OF)

THERMOPILE aȂ0

REPEATABILITY ±1OC (±2OF)

RESOLUTION 0.1OC (0.1OF)

RESPONSE TIME 500MS

OPERATION TEMP 0~50OC(32~122OF),10~90%RH

AUTO POWER OFF AUTOMATICALLY AFTER APPROX. 6SEC

EMISSIVITY ADJUSTABLE 0.1~1.0

OC/OF SWITCHABLE YES

BACKLIGHT YES

LASER SIGHT SWITCHABLE YES

0$;0,1$9*ǻ7 YES

AUTO-MEASURING YES

10 POINT MEMORY YES

AUDIO ALARM YES

DUAL DISPLAY YES

TRIPOD MOUNT YES

USB DATA OUTPUT NO

THERMOCOUPLE K TYPE NO

DIMENSIONS 7.88X6.15X47.5MM(6.14”X3.95”X1.87”)

ORDERING INFORMATIONS:

SCT-108.002.81 SCT-ZEN SCT ZEN INFRARED THERMOMETER IS SUPPLIED WITH 9V DC BATTERY,INSTRUCTION AND CARRYING CASE.

Science is not only compatible with spirituality; it is a profound source of spirituality

440 sales@scichemtech.com www.scichemtech.com

440

ScichemTech® - SCT BENCHTOP METERS

SCT BASIC BENCHTOP pH METERS WITH RS232

SCT BASIC BENCHTOP pH/ORP/TEMP METER WHICH IS SUITABLE FOR GENERAL pH

MEASUREMENT IN LABORATORY CONSISTENT WITH THE BASIC REQUIREMENTS.

SALIENT FEATURES :

Ɣ 6&7%(1&+7230(7(5,6'(6,*1('720($685(S+2537(03(5$785(

Ɣ /$5*(/&':,7+%/8(%$&.*5281'&$1',63/$<%27+S+$1'7(03(5$785(9$/8($77+(

SAME TIME.

Ɣ ,7 +$6 ,17(//,*(17 )81&7,216 )25$8720$7,& &$/,%5$7,21 '$7$ 6725$*(  5(&$//$1'

MEMORY MAX. AND MIN. VALUE ETC.

Ɣ a32,17$8720$7,&&$/,%5$7,21$1',7&$1$8720$7,&$//<',63/$<7+(3(5&(17$*(2)

SLOPE AFTER FINISHING CALIBRATION

Ɣ (48,33(':,7+0$18$/7(03(5$785(&203(16$7,21

Ɣ 237,21726:,7&+%(7:((1OC/OF.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.01

MODEL NO SCT-BEN-pH-01

PARAMETER PRODUCT NAME SPECIFICATIONS

RANGE 0 ~ 14.00 pH

RESOLUTION 0.1/0.01 pH

ACCURACY ±0.01 pH

INPUT RESISTANCE îȍ

STABILITY ±0.01 pH/3H

TEMPERATURE COMPENSATION 0 ~ 100OC MANUAL

OPERATION FUNCTION AUTOMATIC CALIBRATION

RANGE -1999mV ~ 0 ~ 1999mV

RESOLUTION 1mV

ACCURACY ±0.1% FS±1DIGIT

TEMPERATURE

RANGE 0 ~ 100OC

RESOLUTION 0.1

ACCURACY ±1

OTHER TECHNICAL PARAMETERS

DATA STORAGE, RECORD MIX/MIN VALUE

POWER DC9V POWER ADAPTER

DIMENSION AND WEIGHT îî00*

QUALITY & SAFETY CERTIFICATION ISO9001:2008, CE

OPERATION CONDITION ENVIRONMENTAL TEMPERATURE 5 ~ 35OC

RELATIVE HUMIDITY 

ORDERING INFORMATIONS:

SCT-108.003.01 SCT-BEN-pH-01 SCT BEN-pH-01 pH METER IS SUPPLIED WITH PLASTIC pH COMBINATION ELECTRODE,STANDARD SOLU-

TION pH 4.00, 7.00, 10.01 (50ML), 9V POWER ADAPTER & OPERATION MANUAL.

PLEASE NOTE : ORP / TEMPERATURE ELECTRODE AND OTHER ACCESSORIES MUST BE ORDERED SEPARATELY.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE SCT-108.003.A1 PLASTIC COMBINATION pH ELECTRODE, SUITABLE FOR ROUTINE pH MEASUREMENTS, WIDELY USED,

BNC CONNECTOR

ORP COMPOSITE

ELECTRODE SCT-108.003.B1 PLASTIC ORP COMBINATION ELECTRODE, ORP MEASUREMENT FOR CONVENTIONAL, WIDE RANGE OF

USES, BNC PLUG

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA

PLUGS

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500ML

SCT-108.002.AB pH4.00 BUFFER250ML

SCT-108.002.AG pH7.00 BUFFER500ML

SCT-108.002.AH pH7.00 BUFFER250ML

SCT-108.002.AM pH10.01 BUFFER500ML

SCT-108.002.AN pH10.01 BUFFER250ML

ELECTRODE

STORAGE SOLUTION

SCT-108.002.CA pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 500ML

SCT-108.002.CB 222 mV ORP STANDARD SOLUTION 250ML

pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 250ML

ORP STANDARD

SOLUTION

SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100ML

ELECTRODE HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION

OF NEW PRODUCTS.

SCT-108.002.NC ELECTRODE HOLDER, CHEAP SIMPLE ELECTRODE HOLDER

Science is simply common sense at its best.

441

sales@scichemtech.com www.scichemtech.com

441

SCT BASIC BENCHTOP pH METERS WITH ATC & RS232

SCT BASIC BENCHTOP pH/ORP/TEMP METER WITH ATC AND WITH RS232 SUITABLE FOR

GENERAL pH MEASUREMENT IN LABORATORY

SALIENT FEATURES:

Ɣ 6&7%(1&+7230(7(5,6'(6,*1('720($685(S+2537(03(5$785(

Ɣ /$5*(/&':,7+%/8(%$&.*5281'&$1',63/$<%27+S+$1'7(03(5$785(9$/8($77+(

SAME TIME.

Ɣ ,7 +$6 ,17(//,*(17 )81&7,216 )25 $8720$7,& &$/,%5$7,21 $8720$7,& 7(03(5$785(

COMPENSATION, DATA STORAGE / RECALL, AND MEMORY MAX. AND MIN. VALUE ETC.

Ɣ a32,17$8720$7,&&$/,%5$7,21$1',7&$1$8720$7,&$//<',63/$<7+(3(5&(17$*(2)

SLOPE AFTER FINISHING CALIBRATION

Ɣ OC AND OF CAN BE SWITCHED FREELY.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.02

MODEL NO SCT-BEN-pH-2

PARAMETER PRODUCT NAME SPECIFICATIONS

RANGE 0 ~ 14.00 pH

RESOLUTION 0.1/0.01 pH

ACCURACY ±0.01 pH

INPUT RESISTANCE îȍ

STABILITY ±0.01 pH/3H

TEMPERATURE COMPENSATION 0 ~ 100OC AUTO/MANUAL

OPERATION FUNCTION AUTOMATIC CALIBRATION

RANGE -1999mV ~ 0 ~ 1999mV

RESOLUTION 1mV

ACCURACY ±0.1% FS±1DIGIT

TEMPERATURE

RANGE 0 ~ 100OC

RESOLUTION 0.1

ACCURACY ±1

OTHER TECHNICAL PARAMETERS

DATA STORAGE, RECORD MIX/MIN VALUE

POWER DC9V POWER ADAPTER

DIMENSION AND WEIGHT îî00*

QUALITY & SAFETY CERTIFICATION ISO9001:2008, CE

OPERATION CONDITION ENVIRONMENTAL TEMPERATURE 5 ~ 35

RELATIVE HUMIDITY 

ORDERING INFORMATIONS:

SCT-108.003.02 SCT-BEN-pH-2 SCT BEN-pH-2 BENCHTOP pH METER IS SUPPLIED WITH PLASTIC pH COMBINATION ELECTRODE, STANDARD

SOLUTION pH 4.00, 7.00, 10.01 (50 ML) 9V POWER ADAPTER ELECTRODE HOLDER & OPERATION MANUAL.

* ORP / TEMP. ELECTRODES AND ACCESSORIES MUST BE ORDERED SEPARATELY.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE SCT-108.003.A4 PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE, SIMULTANEOUS MEASUREMENT OF pH AND

TEMPERATURE, AUTOMATIC TEMPERATURE COMPENSATION, BNC + RCA PLUGS.

ORP COMPOSITE

ELECTRODE SCT-108.003.B1 PLASTIC ORP COMBINATION ELECTRODE, ORP MEASUREMENT FOR CONVENTIONAL, WIDE RANGE

OF USES, BNC PLUG

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA

PLUGS

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500ML

SCT-108.002.AB pH4.00 BUFFER250ML

SCT-108.002.AG pH7.00 BUFFER500ML

SCT-108.002.AH pH7.00 BUFFER250ML

SCT-108.002.AM pH10.01 BUFFER500ML

SCT-108.002.AN pH10.01 BUFFER250ML

ELECTRODE SOAKING SCT-108.002.CA pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 500ML

SCT-108.002.CB pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 250ML

ORP STANDARD

SOLUTION

SCT-108.002.DA 222 mV ORP STANDARD SOLUTION

SCT-108.002.DB 250ML/100ML/50ML (BOTTLE)

ELECTRODE HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN

360 DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER

COMBINATION OF NEW PRODUCTS.

SCT-108.002.NC ELECTRODE HOLDER, CHEAP SIMPLE ELECTRODE HOLDER

Science is the great antidote to the poison of enthusiasm and superstition

442 sales@scichemtech.com www.scichemtech.com

442

SCT BASIC BENCHTOP pH METERS WITH ATC & RS232

SCT BASIC BENCHTOP pH/ORP/TEMP METER WITH ATC AND WITH RS232 SUITABLE FOR

GENERAL pH MEASUREMENT IN LABORATORY.

EQUIPPED WITH PLASTIC 3 IN 1 pH COMBINATION ELECTRODE AND STIRRING TYPE

ELECTRODE HOLDER EASIER TO USE.

AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION

INSTRUMENT WITH pH RESOLUTION 0.01.

SALIENT FEATURES:

Ɣ 6&7%(1&+7230(7(5,6'(6,*1('720($685(S+2537(03(5$785(

Ɣ /$5*(/&':,7+%/8(%$&.*5281'&$1',63/$<%27+S+$1'7(03(5$785(9$/8($77+(

SAME TIME.

Ɣ ,7 +$6 ,17(//,*(17 )81&7,216 )25 $8720$7,& &$/,%5$7,21 $8720$7,& 7(03(5$785(

COMPENSATION, DATA STORAGE / RECALL, AND MEMORY MAX. AND MIN. VALUE ETC.

Ɣ a32,17$8720$7,&&$/,%5$7,21$1',7&$1$8720$7,&$//<',63/$<7+(3(5&(17$*(2)

SLOPE AFTER FINISHING CALIBRATION

Ɣ (48,367(03($5$785((/(&752'($1'67,55,1*7<3((/(&752'(+2/'(5:+,&+,6025(

SUITABLE FOR USING.

Ɣ OC AND OF CAN BE SWITCHED FREELY.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.03

MODEL NO SCT-BEN-pH-3

PARAMETER PRODUCT NAME SPECIFICATIONS

RANGE 0 ~ 14.00 pH

RESOLUTION 0.1/0.01 pH

ACCURACY ±0.01 pH

INPUT RESISTANCE îȍ

STABILITY ±0.01 pH/3H

TEMPERATURE COMPENSATION (0 ~ 100) AUTO/MANUAL

OPERATION FUNCTION AUTOMATIC CALIBRATION

RANGE -1999mV ~ 0 ~ 1999mV

RESOLUTION 1mV

ACCURACY ±0.1% FS±1DIGIT

TEMPERATURE

RANGE (0 ~ 100) OC

RESOLUTION 0.1 OC

ACCURACY ±1 OC

OTHER TECHNICAL PARAMETERS

DATA STORAGE, RECORD MIX/MIN VALUE

COMMUNICATION CONNECTOR RS-232

DIMENSION AND WEIGHT îî00*

POWER DC9V POWER ADAPTER

QUALITY & SAFETY CERTIFICATION ISO9001:2008, CE

OPERATION CONDITION ENVIRONMENTAL TEMPERATURE: 5 ~ 35 OC

RELATIVE HUMIDITY 

ORDERING INFORMATIONS:

SCT-108.003.03 SCT-BEN-pH-3

SCT BE-pH-3 BENCHTOP pH / ORP / TEMP METER SUPPLIED WITH PLASTIC pH COMBINATION ELECTRODE

TEMPERATURE ELECTRODE pH 4.00, 7.00, 10.01 (50 ML) STANDARD SOLUTION, 9V POWR ADAPTER,

STIRRING TYPE ELECTRODE HOLDER, pH LINK COMMUNICATION SOFTWARE, RS232 COMMUNICATION

CABLE AND OPERATION MANUAL.

* PLS NOTE ORP ELECTRODE / ACCESSORIES NOT INCLUDED TO BE ORDERED SEPARATELY.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE SCT-108.003.A4 PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE, SIMULTANEOUS MEASUREMENT OF pH

AND TEMPERATURE, AUTOMATIC TEMPERATURE COMPENSATION, BNC + RCA PLUGS.

ORP COMPOSITE

ELECTRODE SCT-108.003.B1 PLASTIC ORP COMBINATION ELECTRODE, ORP MEASUREMENT FOR CONVENTIONAL, WIDE

RANGE OF USES, BNC PLUG

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY,

RCA PLUGS

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500ML

SCT-108.002.AB pH4.00 BUFFER250ML

SCT-108.002.AG pH7.00 BUFFER500ML

SCT-108.002.AH pH7.00 BUFFER250ML

SCT-108.002.AM pH10.01 BUFFER500ML

SCT-108.002.AN pH10.01 BUFFER250ML

ELECTRODE STORAGE

SOLUTION

SCT-108.002.CA pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 500ML

SCT-108.002.CB pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 250ML

ORP STANDARD

SOLUTION

SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100ML

ELECTRODE HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN

360 DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER

COMBINATION OF NEW PRODUCTS.

SCT-108.002.NC ELECTRODE HOLDER

CHEAP SIMPLE ELECTRODE HOLDER

Science is what you know, philosophy is what you don’t know

443

sales@scichemtech.com www.scichemtech.com

443

SCT (GLP) GOOD LABORATORY PRACTICE BENCHTOP pH / ORP / TEMP METER

SCT (GLP) GOOD LABORATORY PRACTICE BENCHTOP pH / ORP / TEMP METER SUITABLE

FOR ROUTINE LABORATORY USE.

EQUIPPED WITH FLEXIBLE ELECTRODE HOLDER & QUICK OPERATION GUIDE EASIER TO

USE.

INSTRUMENT RATING 0.01.

SALIENT FEATURES:

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(683

TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, TIMING

MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE ETC.

Ɣ 7+5(( ',))(5(17 0($685(0(17 02'(6 67$%/( ',63/$< 02'( 7,0( 0($685(0(17 02'(

CONTINUOUS MEASUREMENT MODE.

Ɣ $8720$7,&$//< 5(&2*1,=( S+ %8))(5 62/87,21 86(5 &$1 &+226( $1<21( )520 7+5((

SERIES OF STANDARD BUFFER SOLUTIONS: EUROPE & USA SERIES, & NIST SERIES

Ɣ 6&7 '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.04

MODEL NO SCT-BEN-pH-4

PARAMETER PRODUCT NAME SPECIFICATIONS

MEASURING RANGE -1.99 ~ 19.99 pH

RESOLUTION 0.1/0.01/0.001 pH

ACCURACY ±0.01pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.001 pH/3H

TEMP. COMPENSATION RANGE (0 TO 100OC) AUTOMATIC OR MANUAL

MEASURING RANGE(mV/ORP/EH) -1999.9mV ~ 0 ~ 1999.9mV

RESOLUTION 0.1mV

ACCURACY ±0.03% FS

TEMPERATURE

MEASURING RANGE -10 ~ 110

RESOLUTION 0.1

ACCURACY 5~ 60 (RANGE) ±0.4 OTHER RANGE (±0.8)

OTHER TECHNICAL PARAMETERS

DATA STORAGE 300 GROUPS

STORAGE CONTENT MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND TIME

DC9V/300MA

POWER RS232

COMMUNICATION CONNECTOR îî00*

SIZE AND WEIGHT ISO9001:2008, CE

QUALITY AND SAFETY CERTIFICATION

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01 GRADE 15 ~ 30 (0.001GRADE)

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.003.04 SCT-BEN-pH-4

SCT BEN-pH-4 BENCHTOP GLP pH METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER, pH/ATC THREE-

IN-ONE COMBINATION ELECTRODE, pH STANDARD BUFFER SOLUTION 4.00, 7.00, 10.01 (50 ML), 9V POWER

ADAPTER,RS-232 COMMUNICATION CABLE, COMMUNICATION SOFTWARE CD,OPERATION MANUAL,PACKING

LIST

* ORP / TEMP ELECTRODES & ACCESSORIES NOT INCLUDED, TO BE ORDERED SEPARATELY.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE SCT-108.003.A5 PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE, SIMULTANEOUS MEASUREMENT OF pH AND

TEMPERATURE, AUTOMATIC TEMPERATURE COMPENSATION, BNC + RCA PLUGS.

ORP COMPOSITE

ELECTRODE SCT-108.003.B1 PLASTIC ORP COMBINATION ELECTRODE, ORP MEASUREMENT FOR CONVENTIONAL, WIDE RANGE OF

USES, BNC PLUG

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA

PLUGS

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500ML

SCT-108.002.AB pH4.00 BUFFER250ML

SCT-108.002.AG pH7.00 BUFFER500ML

SCT-108.002.AH pH7.00 BUFFER250ML

SCT-108.002.AM pH10.01 BUFFER500ML

SCT-108.002.AN pH10.01 BUFFER250ML

ELECTRODE

STORAGE SOLUTION

SCT-108.002.CA pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 500ML

SCT-108.002.CB pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 250ML

ORP STANDARD

SOLUTION

SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100ML

ELECTRODE

HOLDER SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

Science may set limits to knowledge, but should not set limits to imagination.

444 sales@scichemtech.com www.scichemtech.com

444

SCT PRECISION BENCHTOP pH / ORP / TEMP METER

SCT PRECISION pH/ORP/TEMP METER SUITABLE FOR PRECISE pH MEASUREMENTS FOR

RESEARCH AND QUALITY CONTROL.

(RESOLUTION 0.001 pH)

SALIENT FEATURES:

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(683

TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, TIMING

MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE ETC.

Ɣ 7+5(( ',))(5(17 0($685(0(17 02'(6 67$%/( ',63/$< 02'( 7,0( 0($685(0(17 02'(

CONTINUOUS MEASUREMENT MODE.

Ɣ $8720$7,&$//<5(&2*1,=(.,1'62)S+%8))(562/87,2186(5&$1&+226($1<21()520

FOUR SERIES OF STANDARD BUFFER SOLUTIONS: EUROPE & USA SERIES & NIST SERIES.

Ɣ +,*+385,),(':$7(5$1'$0021,$$''('385,),(':$7(5S+0($685,1*02'(&$1%(6(783

Ɣ :,7+(+5('2;327(17,$/0($685,1*02'(&$1',5(&7/<',63/$<2539$/8(:+,&+$*$,167

STANDARD POTENTIAL OF HYDROGEN ELECTRODE.

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522)$1':$7(53522)0(7(50((76,367$1'$5'6$//62&.(76$5(6($/3527(&7('

BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.05

MODEL NO SCT-BEN-pH-5

PARAMETER PRODUCT NAME SPECIFICATIONS

MEASURING RANGE -1.999 ~ 19.999 pH

RESOLUTION 0.1/0.01/0.001 pH

ACCURACY ±0.002 pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.002 pH/3H

TEMP. COMPENSATION RANGE (0 TO 100) (AUTOMATIC OR MANUAL)

MEASURING RANGE(mV/ORP/EH) -1999.9mV ~ 0 ~ 1999.9mV

RESOLUTION 0.1mV

ACCURACY ±0.03% FS

TEMPERATURE

MEASURING RANGE -10 ~ 110OC

RESOLUTION 0.1

ACCURACY 5~ 60 (RANGE) ±0.4 ( OTHER RANGE) ±0.8

OTHER TECHNICAL

PARAMETERS

DATA STORAGE 300 GROUPS

STORAGE CONTENT MEASURING VALUE SERIES NUMBER, MEASURING VALUE, TEMPERATURE, ATC

OR MTC STATE, MEASURING DATE AND TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 (0.01GRADE), 15 ~ 30 (0.001 GRADE)

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.003.05 SCT-BEN-pH-5

SCT BEN-pH-5 PRECISION pH/ORP/TEMP METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER,pH/

ATC THREE-IN-ONE COMBINATION ELECTRODE, GLASS pH COMBINATION ELECTRODE, TEMPERATURE

ELECTRODE, pH STANDARD BUFFER SOLUTION pH 4.00, 7.00, 10.01 (50 ML) , 9V POWER ADAPTER,RS-232

COMMUNICATION CABLE, COMMUNICATION SOFTWARE CD, OPERATION MANUAL, PACKING LIST

* ORP ELECTRODE & ACCESSORIES NOT INCLUDED TO BE ORDERED SEPARATELY.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE

SCT-108.003.A5

PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE, SIMULTANEOUS MEASUREMENT OF pH AND

TEMPERATURE, AUTOMATIC TEMPERATURE COMPENSATION, BNC + RCA PLUGS.

SCT-108.003.A6

GLASS COMBINATION pH ELECTRODE, FOR PRECISE pH TEST, USED TO MEASURE COMPLEX SAMPLES, BNC PLUG.

ORP COMPOSITE

ELECTRODE SCT-108.003.B1

PLASTIC ORP COMBINATION ELECTRODE, ORP MEASUREMENT FOR CONVENTIONAL, WIDE RANGE OF USES,

BNC PLUG

TEMP. ELECTRODE SCT-108.002.D1

TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

pH BUFFER

SCT-108.002.AA

pH4.00 BUFFER 500ML

SCT-108.002.AB

pH4.00 BUFFER250ML

SCT-108.002.AG

pH7.00 BUFFER500ML

SCT-108.002.AH

pH7.00 BUFFER250ML

SCT-108.002.AM

pH10.01 BUFFER500ML

SCT-108.002.AN

pH10.01 BUFFER250ML

ELECTRODE

STORAGE SOLUTION

SCT-108.002.CA

pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 500ML

SCT-108.002.CB

pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 250ML

ORP STANDARD

SOLUTION

SCT-108.002.DA

222 mV ORP STANDARD SOLUTION 250ML

SCT-108.002.DB

222 mV ORP STANDARD SOLUTION 100ML

ELECTRODE HOLDER

SCT-108.002.NA

FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360 DEGREES

AND VERTICAL LIFT

SCT-108.002.NB

STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION OF

NEW PRODUCTS.

SCT-108.002.NC

ELECTRODE HOLDER

CHEAP SIMPLE ELECTRODE HOLDER

Science never solves a problem without creating ten more.

445

sales@scichemtech.com www.scichemtech.com

445

SCT BENCHTOP pH / CONDUCTIVITY / TDS / SALINITY / RESISTIVITY / TEMP METER

SCT BENCHTOP pH / CONDUCTIVITY METER IS THE MOST WIDELY USED pH AND

CONDUCTIVITY DOUBLE PARAMETER MEASUREMENT METERS.

RESOLUTION pH 0.01 / CONDUCTIVITY 0.1.

SALIENT FEATURES:

Ɣ 6&7%(1&+7230(7(5,6'(6,*1('720($685(&21'8&7,9,7<S+$1'253

Ɣ 7+(0267:,'(/<86('S+&21'8&7,9,7<'28%/(3$5$0(7(50($685(0(170(7(5

Ɣ 0(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(683

TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, TIMING

MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE ETC.

Ɣ 7+5((',))(5(170($685(0(1702'(667$%/(',63/$<02'(7,0(0($685(0(1702'(

CONTINUOUS MEASUREMENT MODE.

Ɣ $8720$7,&$//<5(&2*1,=(S+ %8))(562/87,2186(5 &$1&+226($1<21()5207+5((

SERIES OF STANDARD BUFFER SOLUTIONS: EUROPE & USA SERIES, & NIST SERIES

Ɣ $'237 $'9$1&(' $1' 25,*,1$/ &21'8&7,9,7< 0($685(0(17 7(&+12/2*< 86(  3& 2)

CONDUCTIVITY ELECTRODE (K=1), IT CAN MEET MEASURING ACCURACY REQUIREMENT FOR

5$1*(:,7+,1Ȃ6&0a06&0%<86,1*21/<21(32,17&$/,%5$7,21

Ɣ 237,21726:,7&+&21'8&7,9,7<7'66$/,1,7<$1'5(6,67,9,7<

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.06

MODEL NO SCT-BEN-pH-6

PARAMETER PRODUCT NAME SPECIFICATIONS

MEASURING RANGE -1.99 ~ 19.99 pH

RESOLUTION 0.1/0.01/0.001 pH

ACCURACY ±0.01pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.01 pH/3H

TEMP. COMPENSATION RANGE (0 TO 100) AUTOMATIC OR MANUAL

MEASURING RANGE(mV/ORP/EH) -1999.9mV ~ 0 ~ 1999.9mV

RESOLUTION 0.1mV

ACCURACY ±0.03% FS

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~20.00 μS/CM 20.0~200.0 μS/CM

200~2000 μS/CM 2.00~20.00 mS/CM

20.0~200.0 mS/CM

5(6,67,9,7<a0ȍā&0

TDS: 0 ~ 100 G/L

SALINITY 0 ~ 100 PPT

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1/1 mS/CM

ACCURACY ±1.0% FS

TEMP. COMPENSATION RANGE 0 ~ 50 AUTOMATIC

ELECTRODE CONSTANT 0.1 / 0.5 / 1 / 5 / 10 / 50 / 100 CM-1

REFERENCE TEMPERATURE 25 20 AND 18

TEMPERATURE

MEASURING RANGE -10 ~ 110OC

RESOLUTION 0.1OC

ACCURACY 5~ 60 RANGE ±0.4 OTHER RANGE ±0.8

OTHER TECHNICAL

PARAMETERS:

DATA STORAGE 300 GROUPS

STORAGE CONTENT

MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND

TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE 15 ~ 30 0.001GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

Science without religion is lame, religion without science is blind

446 sales@scichemtech.com www.scichemtech.com

446

ORDERING INFORMATIONS:

SCT-108.003.06 SCT-BEN-pH-6

SCT BEN-pH-6 pH / CONDUCTIVITY BENCHTOP METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER,pH/

ATC THREE-IN-ONE COMBINATION ELECTRODE, PLASTIC CONDUCTIVITY ELECTRODE, pH STANDARD BUFFER

SOLUTION 4.00, 7.00, 10.01 (50 ML),1413 μS/CM CONDUCTIVITY STANDARD SOLUTION 50 ML,9V POWER ADAPTER,

RS-232 COMMUNICATION CABLE, COMMUNICATION SOFTWARE DISK, OPERATION MANUAL & PACKING LIST

* ORP ELECTRODE & ACCESSORIES NOT INCLUDED TO BE ORDERED SEPARATELY.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE SCT-108.003.A5 PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE, SIMULTANEOUS MEASUREMENT OF pH AND

TEMPERATURE, AUTOMATIC TEMPERATURE COMPENSATION, BNC+RCA PLUGS.

CONDUCTIVITY

ELECTRODE SCT-108.003.C3 PLASTIC CONDUCTIVITY ELECTRODE, K=1.0 CM-1 AUTOMATIC TEMPERATURE COMPENSATION FOR

LABORATORY AND FIELD TESTING, 4-PIN PLUG.

ORP COMPOSITE

ELECTRODE SCT-108.003.B1 PLASTICE ORP COMBINATION ELECTRODE, ORP MEASUREMENT FOR CONVENTIONAL, WIDE RANGE OF USES,

BNC PLUG

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500ML

SCT-108.002.AB pH4.00 BUFFER250ML

SCT-108.002.AG pH7.00 BUFFER500ML

SCT-108.002.AH pH7.00 BUFFER250ML

SCT-108.002.AM pH10.01 BUFFER500ML

SCT-108.002.AN pH10.01 BUFFER250ML

CONDUCTIVITY

CALIBRATION

SOLUTION

SCT-108.002.BA 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 500ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 250ML

SCT-108.002.BD 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 500ML

SCT-108.002.BE 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 250ML

SCT-108.002.BG 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 500ML

SCT-108.002.BH 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 250ML

ELECTRODE

STORAGE

SOLUTION

SCT-108.002.CA pH (ORP) COMBINATION ELECTRODE SOAKING SOLUTION 500ML

SCT-108.002.CB pH (ORP) COMBINATION ELECTRODE SOAKING SOLUTION 250ML

ORP STANDARD

SOLUTION

SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100ML

ELECTRODE

HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION OF

NEW PRODUCTS.

SCT-108.002.NC ELECTRODE HOLDER, CHEAP SIMPLE ELECTRODE HOLDER

SCT PRECISION GLP pH / CONDUCTIVITY / TDS / SALINITY / RESISTIVITY / TEMP METER

SCT BENCHTOP PRECISION GLP pH / CONDUCTIVITY METER IS SUITABLE FOR PRECISION

MEASUREMENT RESEARCH AND QUALITY CONTROL, RESOLUTION pH 0.001 AND

CONDUCTIVITY 0.5.

SALIENT FEATURES:

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(6

UP TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE,

TIMING MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE

ETC.

Ɣ 7+5((',))(5(170($685(0(1702'(667$%/(',63/$<02'(7,0(0($685(0(1702'(

CONTINUOUS MEASUREMENT MODE.

Ɣ $8720$7,&$//< 5(&2*1,=(  .,1'6 2) S+ %8))(5 62/87,21 86(5 &$1 &+226($1<21(

FROM FOUR SERIES OF STANDARD BUFFER SOLUTIONS: EUROPE & USA SERIES & NIST SERIES

Ɣ +,*+385,),(':$7(5$1'$0021,$$''('385,),(':$7(5S+0($685,1*02'(&$1%(6(7

UP.

Ɣ :,7+ (+ 5('2; 327(17,$/ 0($685,1* 02'( &$1 ',5(&7/< ',63/$< 253 9$/8( :+,&+

AGAINST STANDARD POTENTIAL OF HYDROGEN ELECTRODE.

Ɣ $8720$7,&$//< 5(&2*1,=(  .,1'6 2) &21'8&7,9,7< 67$1'$5' 62/87,21 86(5 &$1

CHOOSE ANYONE FROM TWO SERIES OF SOLUTIONS: EUROPE & USA SERIES

Ɣ $'237 $'9$1&(' $1' 25,*,1$/ &21'8&7,9,7< 0($685(0(17 7(&+12/2*< 86(  3& 2)

CONDUCTIVITY ELECTRODE (K=1), IT CAN MEET MEASURING ACCURACY REQUIREMENT FOR

5$1*(:,7+,1Ȃ6&0a06&0%<86,1*21/<21(32,17&$/,%5$7,21

Ɣ $8720$7,&$//<6(/(&7&21'8&7,9,7<0($685(0(175$1*(:+(10($685,1*+,*+385(

WATER, EQUIPMENT AUTOMATICALLY ENTER INTO TEMPERATURE COMPENSATION OF NONLINEAR

MODEL.

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

Shallow men believe in luck. Strong men believe in cause and effect.

447

sales@scichemtech.com www.scichemtech.com

447

TECHNICAL SPECIFICATIONS :

PRODUCT NO. SCT-108.003.07

MODEL NO SCT-BEN-pH-7

PARAMETER PRODUCT NAME SPECIFICATIONS

MEASURING RANGE -1.999 ~ 19.999 pH

RESOLUTION 0.1/0.01/0.001 pH

ACCURACY ±0.002 pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.002 pH/3H

TEMP. COMPENSATION RANGE (0 TO 100) AUTOMATIC OR MANUAL

MEASURING RANGE(mV/ORP/EH) -1999.9mV ~ 0 ~ 1999.9mV

RESOLUTION 0.1mV

ACCURACY ±0.03% FS

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~20.00 μS/CM 20.0~200.0 μS/CM

200~2000 μS/CM 2.00~20.00 mS/CM

20.0~200.0 mS/CM 200~2000 mS/CM K=10

5(6,67,9,7<a0ȍā&0

TDS: 0 ~ 100 G/L

SALINITY 0 ~ 100PPT

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1/1 MS/CM

ACCURACY ±0.5% FS

TEMP. COMPENSATION RANGE 0 ~ 50OC AUTOMATIC

ELECTRODE CONSTANT 0.1 / 0.5 / 1 / 5 / 10 / 50 / 100 CM-1

REFERENCE TEMPERATURE 25 20 AND 18

TEMPERATURE

MEASURING RANGE -10 ~ 110OC

RESOLUTION 0.1

ACCURACY 5~ 60 RANGE ±0.4 OTHER RANGE ±0.8

OTHER TECHNICAL

PARAMETERS:

DATA STORAGE 300 GROUPS

STORAGE CONTENT

MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND

TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE 15 ~ 30 0.001GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.003.07 SCT-BEN-pH-7

SCT BEN-pH-7 PRECISION GLP pH/CONDUCTIVITY METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER,

pH/ATC THREE-IN-ONE COMBINATION ELECTRODE, GLASS pH COMBINATION ELECTRODE,TEMPERATURE

ELECTRODE,CONDUCTIVITY ELECTRODE, pH STANDARD BUFFER SOLUTION 4.00, 7.00, 10.01 (50 ML) 1413μS/

CM CONDUCTIVITY STANDARD SOLUTION 50ML, 9V POWER ADAPTER, RS-232 COMMUNICATION CABLE,

COMMUNICATION SOFTWARE DISK, OPERATION MANUAL AND PACKING LIST

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE SCT-108.003.A5 PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE, SIMULTANEOUS MEASUREMENT OF pH AND

TEMPERATURE, AUTOMATIC TEMPERATURE COMPENSATION, BNC + RCA PLUGS.

SCT-108.003.A6 GLASS COMBINATION pH ELECTRODE, FOR PRECISE pH TEST, USED TO MEASURE COMPLEX SAMPLES,

BNC PLUG.

CONDUCTIVITY

ELECTRODE SCT-108.003.C2 GLASS CONDUCTIVITY ELECTRODE, K=1.0 CM-1 AUTOMATIC TEMPERATURE COMPENSATION, PRECISION

LABORATORY TEST FOR CONDUCTIVITY, 4-PIN PLUG.

ORP COMPOSITE

ELECTRODE SCT-108.003.B1 PLASTIC ORP COMBINATION ELECTRODE, ORP MEASUREMENT FOR CONVENTIONAL, WIDE RANGE OF

USES, BNC PLUG

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500ML

SCT-108.002.AB pH4.00 BUFFER250ML

SCT-108.002.AG pH7.00 BUFFER500ML

SCT-108.002.AH pH7.00 BUFFER250ML

SCT-108.002.AM pH10.01 BUFFER500ML

SCT-108.002.AN pH10.01 BUFFER250ML

Shown to a customer what he needs and he will move seas and mountains to get it.

448 sales@scichemtech.com www.scichemtech.com

448

CONDUCTIVITY

CALIBRATION

SOLUTION

SCT-108.002.BA 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 500ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 250ML

SCT-108.002.BD 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 500ML

SCT-108.002.BE 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 250ML

SCT-108.002.BG 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 500ML

SCT-108.002.BH 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 250ML

ELECTRODE STORAGE

SOLUTION

SCT-108.002.CA pH (ORP) COMBINATION ELECTRODE SOAKING SOLUTION 500ML

SCT-108.002.CB pH (ORP) COMBINATION ELECTRODE SOAKING SOLUTION 250ML

ORP STANDARD

SOLUTION

SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100ML

ELECTRODE HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION

OF NEW PRODUCTS.

SCT-108.002.NC ELECTRODE HOLDER, CHEAP SIMPLE ELECTRODE HOLDER

SCT BENCHTOP pH / ISE METER

SCT BENCHTOP pH / ISE METER IS THE HIGH PRECISION pH + ISE DOUBLE PARAMETER

MEASUREMENT METER WHICH IS SUITABLE FOR PRECISION MEASUREMENT RESEARCH

AND QUALITY CONTROL.

10 KINDS OF COMMON IONS CAN BE SELECTED IN THE ION CONCENTRATION MEASURING

MODE USER ALSO CAN SELF DEFEND OTHER IONS.

CAN SWTICH 4 KINDS OF CONCENTRATION UNIT pX, mol / L, mg/L and ppm.

INSTRUMENT RESOLUTION pH 0.001, ISE 0.01.

SALIENT FEATURES:

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(6

UP TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE,

TIMING MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE

ETC.

Ɣ 7+5((',))(5(170($685(0(1702'(667$%/(',63/$<02'(7,0(0($685(0(1702'(

CONTINUOUS MEASUREMENT MODE.

Ɣ $8720$7,&$//< 5(&2*1,=(  .,1'6 2) S+ %8))(5 62/87,21 86(5 &$1 &+226($1<21(

FROM FOUR SERIES OF STANDARD BUFFER SOLUTIONS: EUROPE & USA SERIES & NIST SERIES

Ɣ +,*+385,),(':$7(5$1'$0021,$$''('385,),(':$7(5S+0($685,1*02'(&$1%(6(7

UP.

Ɣ :,7+ (+ 5('2; 327(17,$/ 0($685,1* 02'( &$1 ',5(&7/< ',63/$< 253 9$/8( :+,&+

AGAINST STANDARD POTENTIAL OF HYDROGEN ELECTRODE.

Ɣ 7+(5( $5(  .,1'6 2) &20021 ,216 &$1 %( 6(/(&7(' ,1 7+( ,21 &21&(175$7,21

MEASURING MODE, USER ALSO CAN SELF-DEFINE OTHER IONS.

Ɣ &$16:,7&+.,1'62)&21&(175$7,2181,73;02//0*/$1'330

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.08

MODEL NO SCT-BEN-ISE-1

PARAMETER PRODUCT NAME SPECIFICATIONS

MEASURING RANGE -1.999 ~ 19.999 pH

RESOLUTION 0.1/0.01/0.001 pH

ACCURACY ±0.002 pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.002 pH/3H

TEMP. COMPENSATION RANGE (0 TO 100) AUTOMATIC OR MANUAL

MEASURING RANGE(mV/ORP/EH) -1999.9mV ~ 0 ~ 1999.9mV

RESOLUTION 0.1mV

ACCURACY ±0.03% FS

ION CONCENTRATION

MEASURING RANGE 0.00 ~ 14.00 PX

DISPLAY UNIT PX MOL/L MG/L PPM

ACCURACY METER:±0.5 % READING(MONOVALENT), ±1.0 % READING

(BIVALENT)

TEMP. COMPENSATION RANGE 0 TO 60 AUTOMATIC OR MANUAL

Sincerity is the way of heaven

449

sales@scichemtech.com www.scichemtech.com

449

TEMPERATURE

MEASURING RANGE -10OC ~ 110OC

RESOLUTION 0.1

ACCURACY 5~ 60 RANGE ±0.4 OTHER RANGE ±0.8

OTHER TECHNICAL

PARAMETERS:

DATA STORAGE 300 GROUPS

STORAGE CONTENT

MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND

TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5OC ~ 35OC 0.01GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.003.08 SCT-BEN-ISE-1

SCT BEN-ISE-1 BENCHTOP pH/ISE METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER,

INTELLIGENT STIRRER, pH/ATC THREE-IN-ONE COMBINATION ELECTRODE,GLASS pH COMBINATION

ELECTRODE,TEMPERATURE ELECTRODE DOUBLE SALT BRIDGE REFERENCE ELECTRODE, pH STANDARD

BUFFER SOLUTION 50 ML,9V POWER ADAPTER,6V POWER ADAPTER, STIRRING BEAD, BATTERY, RS-232

COMMUNICATION CABLE, COMMUNICATION SOFTWARE DISK, OPERATION MANUAL & PACKING LIST

* ION SELECTIVE ELECTRODES / ACCESSORIES IS NOT INCLUDED AND TO BE ORDERED SEPARATELY.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE

SCT-108.003.A5 PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE, SIMULTANEOUS MEASUREMENT OF pH AND

TEMPERATURE, AUTOMATIC TEMPERATURE COMPENSATION, BNC + RCA PLUGS.

SCT-108.003.A6 GLASS COMBINATION pH ELECTRODE, FOR PRECISE pH TEST, USED TO MEASURE COMPLEX SAMPLES, BNC

PLUG.

ION ELECTRODE

SCT-108.003.E1 SODIUM ION ELECTRODE, USED TO TEST THE CONCENTRATION OF SODIUM ION BNC PLUG

SCT-108.003.E2 CALCIUM COMPOSITE ELECTRODE, USED FOR TESTING CALCIUM CONCENTRATION BNC PLUG

SCT-108.003.E3 CALCIUM ELECTRODE PROBE, USED WITH ELECTRODE

SCT-108.003.E4 FLUORIDE ELECTRODE, USED TO TEST FLUORIDE CONCENTRATION BNC PLUG

SCT-108.003.E5 CHLORIDE ELECTRODE, USED TO TEST THE CONCENTRATION OF CHLORIDE ION BNC PLUG

SCT-108.003.E6 BROMINE ELECTRODE, USED TO TEST THE CONCENTRATION OF BROMINE ION BNC PLUG

SCT-108.003.E7 IODIDE ELECTRODE, USED TO TEST THE CONCENTRATION OF IODIDE ION BNC PLUG

REFERENCE

ELECTRODE SCT-108.003.F3 REFERENCE ELECTRODE, THE FIRST AND SECOND SALT BRIDGE SOLUTION CAN BE CHOSEN, FOR ALL

MEASUREMENT OCCASIONS, BANANA PLUGS.

ORP COMPOSITE

ELECTRODE

SCT-108.003.B1 PLASTIC ORP COMBINATION ELECTRODE, ORP MEASUREMENT FOR CONVENTIONAL, WIDE RANGE OF USES,

BNC PLUG

SCT-108.003.B2 GLASS ORP COMBINATION ELECTRODE, ORP MEASUREMENT OF ROUTINE LABORATORY, TEST STABILITY,

FAST RESPONSE, BNC PLUG

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500ML

SCT-108.002.AB pH4.00 BUFFER250ML

SCT-108.002.AG pH7.00 BUFFER500ML

SCT-108.002.AH pH7.00 BUFFER250ML

SCT-108.002.AM pH10.01 BUFFER500ML

SCT-108.002.AN pH10.01 BUFFER250ML

ELECTRODE

STORAGE SCT-108.002.CA pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 500ML

SCT-108.002.CB pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 250ML

ORP STANDARD

SOLUTION

SCT-108.002.DA 222 mV ORP STANDARD SOLUTION, 250ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION, 100ML

ELECTRODE

HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION OF

NEW PRODUCTS.

SCT-108.002.NC ELECTRODE HOLDER, CHEAP SIMPLE ELECTRODE HOLDER

Small deeds done are better than great deeds planned.

450 sales@scichemtech.com www.scichemtech.com

450

SCT BENCHTOP pH / DISSOLVED OXYGEN (D.O.) METER

SCT BENCHTOP pH / DO METER IS THE HGIH PRECISION pH/DO DOUBLE PARAMETER

MEASUREMENT METER WHICH IS SUITABLE FOR PRECISION MEASURMENT.

DO MEASUREMENT AS ATC/AUTOMATIC SALINITY COMPENSATION AND AUTOMATIC AIR

PRESSURE COMPENSATION.

POLARO GRApHIC TYPE OXYGEN ELECTRO, THE POLARISATION TIME IS SHORT, FAST

RESPONSE AND ACCURATE MEASUREMENT.

INSTRUMENT RESOLUTION pH 0.001.

SALIENT FEATURES:

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(6

UP TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE,

TIMING MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE

ETC.

Ɣ 7+5((',))(5(170($685(0(1702'(667$%/(',63/$<02'(7,0(0($685(0(1702'(

CONTINUOUS MEASUREMENT MODE.

Ɣ $8720$7,&$//< 5(&2*1,=(  .,1'6 2) S+ %8))(5 62/87,21 86(5 &$1 &+226($1<21(

FROM FOUR SERIES OF STANDARD BUFFER SOLUTIONS: EUROPE & USA SERIES & NIST SERIES.

Ɣ +,*+385,),(':$7(5$1'$0021,$$''('385,),(':$7(5S+0($685,1*02'(&$1%(6(7

UP.

Ɣ :,7+ (+ 5('2; 327(17,$/ 0($685,1* 02'( &$1 ',5(&7/< ',63/$< 253 9$/8( :+,&+

AGAINST STANDARD POTENTIAL OF HYDROGEN ELECTRODE.

Ɣ (48,36 1(: 7<3( 2) '2 (/(&752'( :+,&+ +$6 )81&7,21 2) $8720$7,& 7(03(5$785(

COMPENSATION AND AUTOMATIC SALINITY COMPENSATION AS WELL AS AUTOMATIC AIR PRESSURE

COMPENSATION INSIDE METER TO MAKE DO MEASURING MODE HAS TEMPERATURE, AIR

PRESSURE AND SALINITY AUTOMATIC COMPENSATION, EASY TO USE, ACCURATE TO MEASURE.

Ɣ 32/$52*5$07<3('2(/(&752'(+$663(&,$/(/(&752'(&$/,%5$7,21&$321/<1(('6

TO 5 MINUTES FOR ELECTRODE POLARIZATION. ELECTRODE ADOPTS COMBINATION DIAPHRAGM

CAP WHICH VERY CONVENIENT TO USE. EACH DO ELECTRODE EQUIPS WITH THREE SPARE

DIAPHRAGMS CAPS.

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.09

MODEL NO SCT-BEN-pH-8

PARAMETER PRODUCT NAME SPECIFICATIONS

MEASURING RANGE -1.999 ~ 19.999 pH

RESOLUTION 0.1/0.01/0.001 pH

ACCURACY ±0.002 pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.002 pH/3H

TEMP. COMPENSATION RANGE (0 TO 100) (AUTOMATIC OR MANUAL)

MEASURING RANGE(mV/ORP/EH) -1999.9mV ~ 0 ~ 1999.9mV

RESOLUTION 0.1mV

ACCURACY ±0.03% FS

DISSOLVED OXYGEN

MEASURING RANGE 0 ~ 40.00 MG/L(PPM) 0 ~ 200.0%

RESOLUTION 0.1/0.01 MG/L(PPM) 1/0.1 %

ACCURACY ±0.10 MG/L

RESPONSE TIME 65(63216(

RESIDUAL CURRENT 0*/

TEMP. COMPENSATION RANGE 0 ~ 45 (AUTOMATIC)

SALINITY COMPENSATION RANGE 0 ~ 45 PPT (AUTOMATIC)

AIR PRESSURE COMPENSATION 80 ~ 105 KPA (AUTOMATIC)

AUTOMATIC CALIBRATION AIR SATURATED BY WATER; WATER SATURATED BY AIR

ELECTRODE TYPE POLAROGRAM TYPE

TEMPERATURE

MEASURING RANGE -10~ 110OC

RESOLUTION 0.1OC

ACCURACY 5~ 60 RANGE (±0.4) OTHER RANGE(±0.8)

OTHER TECHNICAL

PARAMETERS:

DATA STORAGE 300 GROUPS

STORAGE CONTENT

MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND

TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 (0.01GRADE) 15 ~ 30 (0.001GRADE)

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

So little done, so much to do.

451

sales@scichemtech.com www.scichemtech.com

451

ORDERING INFORMATIONS:

SCT-108.003.09 SCT-BEN-pH-8

SCT BEN-pH-8 BENCHTOP pH / DO METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER, INTELLIGENT

STIRRER, pH/ATC THREE-IN-ONE COMBINATION ELECTRODE,GLASS pH COMBINATION ELECTRODE,

TEMPERATURE ELECTRODE, DO ELECTRODE, pH STANDARD BUFFER SOLUTION4.00, 7.00, 10.01 (50ML)

,9V POWER ADAPTER, 6V POWER ADAPTER MEMBRANE CAP, DO ELECTRODE INNER SOLUTION, CATHODE

POLISHING PAPER, STIRRING BEAD, BATTERY RS-232 COMMUNICATION CABLE, COMMUNICATION SOFTWARE

DISK, OPERATION MANUAL & PACKING LIST.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE SCT-108.003.A5 PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE, SIMULTANEOUS MEASUREMENT OF pH AND

TEMPERATURE, AUTOMATIC TEMPERATURE COMPENSATION, BNC + RCA PLUGS.

SCT-108.003.A6 GLASS COMBINATION pH ELECTRODE

FOR PRECISE pH TEST, USED TO MEASURE COMPLEX SAMPLES, BNC PLUG.

DO ELECTRODE SCT-108.002.D1 DO ELECTRODE, POLAROGRAPHIC-TYPE DO ELECTRODE FOR LABORATORY AND FIELD USING, 8-PIN PLUG

DO ELECTRODE

ATTACHMENT

SCT-108.003.D2 DO ELECTRODE MEMBRANE CAP, COMBINED MEMBRANE CAP DEDICATED TO THE DO500 DO ELECTRODE,

SIZE: 3 / GROUP

SCT-108.003.IA DO ELECTRODE ELECTROLYTE, ADDED ELECTROLYTE, DEDICATED TO THE DO500 DO ELECTRODE,

TECHNICAL SPECIFICATIONS: 30ML/BOTTLE

SCT-108.003.IB CATHODE POLISHING PAPER, POLISHING PAPER, DEDICATED TO CLEAN DO500 DO ELECTRODE CATHODE,

SIZE: 2 / GROUP.

ORP COMPOSITE

ELECTRODE SCT-108.003.B1 PLASTIC ORP COMBINATION ELECTRODE, ORP MEASUREMENT FOR CONVENTIONAL, WIDE RANGE OF

USES, BNC PLUG

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500ML

SCT-108.002.AB pH4.00 BUFFER250ML

SCT-108.002.AG pH7.00 BUFFER500ML

SCT-108.002.AH pH7.00 BUFFER250ML

SCT-108.002.AM pH10.01 BUFFER500ML

SCT-108.002.AN pH10.01 BUFFER250ML

ELECTRODE

STORAGE SOLUTION

SCT-108.002.CA pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB pH (ORP) COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

ORP STANDARD

SOLUTION

SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250 ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100 ML

ELECTRODE HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION

OF NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

SCT BENCHTOP pH/mV/ISE/CONDUCTIVITY/TDS/SALINITY/RESISTIVITY/DO/TEMP METER

SCT BENCHTOP pH / mV / ISE / CONDUCTIVITY / DO METER IS THE HIGH PRECISION MULTI

PARAMETER MEASUREMENT INSTRUMENT.

IT HAS HIGH PURE WATER pH / CONDUCTIVITY MEASUREMENT MODE.

IT HAS LARGE MEASUREMENT RANGE AND HIGH ACCURACY CONDUCTIVITY MEASUREMENT

MODE CAN BE SWITCH TO TDS SALINITY AND RESISTIVITY.

DO MEASUREMENT HAS ATC, AUTOMATIC SALINITY COMPENSATION AND AUTOMATIC AIR

PRESSURE COMPENSATION.

10 KINDS OF COMMON ION CAN BE SELECTED IN THE ION CONCENTRATION MEASURING

MODE. USER CAN SELF DEFINE OTHER IONS.

CAN SWTICH 4 KINDS OF CONCENTRATION UNIT pX, mol / L, mg/L and ppm.

INSTRUMENT RESOLUTION pH 0.001, CONDUCTIVITY 0.5, ISE 0.01.

SALIENT FEATURES:

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(6

UP TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE,

TIMING MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE

ETC.

Ɣ 7+(5( $5( 7+5(( ',))(5(17 0($685(0(17 02'(6 67$%/( ',63/$< 02'( 7,0(

MEASUREMENT MODE; CONTINUOUS MEASUREMENT MODE.

Ɣ $8720$7,&$//< 5(&2*1,=(  .,1'6 2) S+ %8))(5 62/87,21 86(5 &$1 &+226($1<21(

FROM FOUR SERIES OF STANDARD BUFFER SOLUTIONS: EUROPE & USA SERIES & NIST SERIES

Ɣ +,*+385,),(':$7(5$1'$0021,$$''('385,),(':$7(5S+0($685,1*02'(&$1%(6(7

UP.

Ɣ :,7+ (+ 5('2; 327(17,$/ 0($685,1* 02'( &$1 ',5(&7/< ',63/$< 253 9$/8( :+,&+

AGAINST STANDARD POTENTIAL OF HYDROGEN ELECTRODE.

Ɣ $8720$7,&$//< 5(&2*1,=(  .,1'6 2) &21'8&7,9,7< 67$1'$5' 62/87,21 86(5 &$1

CHOOSE ANYONE FROM TWO SERIES OF SOLUTIONS: EUROPE & USA SERIES.

Some of us think holding on makes us strong; but sometimes it is letting go.

452 sales@scichemtech.com www.scichemtech.com

452

Ɣ $'237 $'9$1&(' $1' 25,*,1$/ &21'8&7,9,7< 0($685(0(17 7(&+12/2*< 86(  3& 2)

CONDUCTIVITY ELECTRODE (K=1), IT CAN MEET MEASURING ACCURACY REQUIREMENT FOR

5$1*(:,7+,1Ȃ6&0a06&0%<86,1*21/<21(32,17&$/,%5$7,21

Ɣ $8720$7,&$//<6(/(&7&21'8&7,9,7<0($685(0(175$1*(:+(10($685,1*+,*+385(

WATER, EQUIPMENT AUTOMATICALLY ENTER INTO TEMPERATURE COMPENSATION OF NONLINEAR

MODE.

Ɣ (48,36 1(: 7<3( 2) '2 (/(&752'( :+,&+ +$6 )81&7,21 2) $8720$7,& 7(03(5$785(

COMPENSATION AND AUTOMATIC SALINITY COMPENSATION AS WELL AS AUTOMATIC AIR PRESSURE

COMPENSATION INSIDE METER TO MAKE DO MEASURING MODE HAS TEMPERATURE, AIR

PRESSURE AND SALINITY AUTOMATIC COMPENSATION, EASY TO USE, ACCURATE TO MEASURE.

Ɣ 32/$52*5$07<3('2(/(&752'(+$663(&,$/(/(&752'(&$/,%5$7,21&$321/<1(('6

TO 5 MINUTES FOR ELECTRODE POLARIZATION. ELECTRODE ADOPTS COMBINATION DIAPHRAGM

CAP WHICH VERY CONVENIENT TO USE. EACH DO ELECTRODE EQUIPS WITH THREE SPARE

DIAPHRAGMS CAPS.

Ɣ 7+(5( $5(  .,1'6 2) &20021 ,216 &$1 %( 6(/(&7(' ,1 7+( ,21 &21&(175$7,21

MEASURING MODE, USER ALSO CAN SELF-DEFINE OTHER IONS.

Ɣ &$16:,7&+.,1'62)&21&(175$7,2181,73;02//0*/$1'330

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.10

MODEL NO SCT-BEN-ISE-2

PARAMETER PRODUCT NAME SPECIFICATIONS

MEASURING RANGE -1.999 ~ 19.999 pH

RESOLUTION 0.1/0.01/0.001 pH

ACCURACY ±0.002 pH

INPUT CURRENT î$

INPUT IMPENDANCE îȍ

STABILITY ±0.002 pH/3H

TEMP. COMPENSATION RANGE (0 TO 100) (AUTOMATIC OR MANUAL)

MEASURING RANGE(mV/ORP/EH) -1999.9mV ~ 0 ~ 1999.9mV

RESOLUTION 0.1mV

ACCURACY ±0.03% FS

ION CONCENTRATION

MEASURING RANGE 0.00 ~ 14.00 PX

DISPLAY UNIT PX MOL/L MG/L PPM

ACCURACY ±0.5 %

TEMP. COMPENSATION RANGE 0 TO 60 AUTOMATIC OR MANUAL

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~20.00 μS/CM 20.0~200.0 μS/CM

200~2000 μS/CM 2.00~20.00 mS/CM

20.0~200.0 mS/CM 200~2000 mS/CM K=10

5(6,67,9,7<a0ȍā&0

TDS: 0 ~ 100 G/L

SALINITY 0 ~ 100 PPT

RESOLUTION Ȃ6&006&0

ACCURACY ±0.5% FS

TEMP. COMPENSATION RANGE 0 ~ 50 AUTOMATIC

ELECTRODE CONSTANT 0.1 / 0.5 / 1 / 5 / 10 / 50 / 100 CM-1

REFERENCE TEMPERATURE 25 20 AND 18

DISSOLVED OXYGEN

MEASURING RANGE 0 ~ 40.00 MG/L(PPM) 0 ~ 200.0 %

RESOLUTION 0.1/0.01 MG/L(PPM) 1/0.1 %

ACCURACY ±0.10 MG/L

RESPONSE TIME 65(63216(

RESIDUAL CURRENT 0*/

TEMP. COMPENSATION RANGE 0 ~ 45 AUTOMATIC

SALINITY COMPENSATION RANGE 0 ~ 45 PPT AUTOMATIC

AIR PRESSURE COMPENSATION 80 ~ 105 KPA AUTOMATIC

AUTOMATIC CALIBRATION AIR SATURATED BY WATER; WATER SATURATED BY AIR

ELECTRODE TYPE POLAROGRAM TYPE

TEMPERATURE

MEASURING RANGE -10~ 110

RESOLUTION 0.1

ACCURACY 5~ 60 RANGE ±0.4 OTHER RANGE ±0.8

OTHER TECHNICAL

PARAMETERS:

DATA STORAGE 300 GROUPS

STORAGE CONTENT MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE.

Sometimes good things fall apart so better things can fall together.

453

sales@scichemtech.com www.scichemtech.com

453

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE 15 ~ 30 0.001GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.003.10 SCT-BEN-ISE-2

SCT BEN-ISE-2 pH/mV/ISE/COND/DO METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER, INTELLIGENT

STIRRER, pH/ATC THREE-IN-ONE COMBINATION ELECTRODE, GLASS pH COMBINATION ELECTRODE,

TEMPERATURE ELECTRODE, CONDUCTIVITY ELECTRODE, DO ELECTRODE, DOUBLE SALT BRIDGE REFERENCE

ELECTRODE, pH STANDARD BUFFER SOLUTION 4.00, 7.00, 10.01 (50 ML), 1413μS/CM CONDUCTIVITY STANDARD

SOLUTION, 9V POWER ADAPTER, 6V POWER ADAPTER, MEMBRANE CAP, DO ELECTRODE INNER SOLUTION,

CATHODE POLISHING PAPER STIRRING BEAD, AA BATTERY, RS-232 COMMUNICATION CABLE, COMMUNICATION

SOFTWARE DISK, OPERATION MANUAL & PACKING LIST

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

pH COMBINATION

ELECTRODE

SCT-108.003.A5 PLASTIC THREE-IN-ONE COMBINATION pH ELECTRODE, SIMULTANEOUS MEASUREMENT OF pH AND

TEMPERATURE, AUTOMATIC TEMPERATURE COMPENSATION, BNC + RCA PLUGS.

SCT-108.003.A6 GLASS COMBINATION pH ELECTRODE FOR PRECISE pH TEST, USED TO MEASURE COMPLEX SAMPLES, BNC

PLUG.

ION ELECTRODE

SCT-108.003.E1 SODIUM ION ELECTRODE USED TO TEST THE CONCENTRATION OF SODIUM ION BNC PLUG

SCT-108.003.E2 CALCIUM COMPOSITE ELECTRODE USED FOR TESTING CALCIUM CONCENTRATION BNC PLUG

SCT-108.003.E3 CALCIUM ELECTRODE PROBE, USED WITH SCT-108.003.E2 ELECTRODE

SCT-108.003.E4 FLUORIDE ELECTRODE USED TO TEST FLUORIDE CONCENTRATION BNC PLUG

SCT-108.003.E5 CHLORIDE ELECTRODE USED TO TEST THE CONCENTRATION OF CHLORIDE ION BNC PLUG

SCT-108.003.E6 BROMINE ELECTRODE USED TO TEST THE CONCENTRATION OF BROMINE ION BNC PLUG

SCT-108.003.E7 IODIDE ELECTRODE USED TO TEST THE CONCENTRATION OF IODIDE ION BNC PLUG

REFERENCE

ELECTRODE

SCT-108.003.F1 REFERENCE ELECTRODE, SUITABLE FOR ROUTINE MEASUREMENTS, BANANA PLUGS.

SCT-108.003.F2 REFERENCE ELECTRODE, EQUIPPED WITH THE 7801 SODIUM ION ELECTRODE, BANANA PLUGS

SCT-108.003.F3 REFERENCE ELECTRODE, THE FIRST AND SECOND SALT BRIDGE SOLUTION CAN BE CHOSEN, FOR ALL

MEASUREMENT OCCASIONS, BANANA PLUGS.

CONDUCTIVITY

ELECTRODE SCT-108.003.C2 GLASS CONDUCTIVITY ELECTRODE, K=1.0 CM-1 AUTOMATIC TEMPERATURE COMPENSATION, PRECISION

LABORATORY TEST FOR CONDUCTIVITY, 4-PIN PLUG.

DO ELECTRODE SCT-108.002.D1 DO ELECTRODE, POLAROGRAPHIC-TYPE DO ELECTRODE FOR LABORATORY AND FIELD USING, 8-PIN PLUG

DO ELECTRODE

ATTACHMENT

SCT-108.003.D2 DO ELECTRODE MEMBRANE CAP, COMBINED MEMBRANE CAP DEDICATED TO THE DO ELECTRODE, SIZE: 3

/ GROUP

SCT-108.003.IA DO ELECTRODE ELECTROLYTE, ADDED ELECTROLYTE, DEDICATED TO THE DO ELECTRODE, TECHNICAL

SPECIFICATIONS: 30ML/BOTTLE

SCT-108.003.IB CATHODE POLISHING PAPER POLISHING PAPER, DEDICATED TO CLEAN DO ELECTRODE CATHODE, SIZE: 2 /

GROUP.

ORP COMPOSITE

ELECTRODE SCT-108.003.B1 PLASTIC ORP COMBINATION ELECTRODE ORP MEASUREMENT FOR CONVENTIONAL, WIDE RANGE OF

USES, BNC PLUG

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

pH BUFFER

SCT-108.002.AA pH4.00 BUFFER 500 ML

SCT-108.002.AB pH4.00 BUFFER 250 ML

SCT-108.002.AG pH7.00 BUFFER 500 ML

SCT-108.002.AH pH7.00 BUFFER 250 ML

SCT-108.002.AM pH10.01 BUFFER 500 ML

SCT-108.002.AN pH10.01 BUFFER 250 ML

CONDUCTIVITY

CALIBRATION

SOLUTION

SCT-108.002.BA 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 250 ML

SCT-108.002.BD 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 500 ML

SCT-108.002.BE 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 250 ML

SCT-108.002.BG 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 500 ML

SCT-108.002.BH 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 250 ML

ELECTRODE

STORAGE

SOLUTION

SCT-108.002.CA pH (ORP)COMBINATION ELECTRODE STORAGE SOLUTION 500 ML

SCT-108.002.CB pH (ORP)COMBINATION ELECTRODE STORAGE SOLUTION 250 ML

ORP STANDARD

SOLUTION

SCT-108.002.DA 222 mV ORP STANDARD SOLUTION 250 ML

SCT-108.002.DB 222 mV ORP STANDARD SOLUTION 100 ML

ELECTRODE

HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION

OF NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

Speak the truth even if your voice shakes

454 sales@scichemtech.com www.scichemtech.com

454

SCT BASIC LAB CONDUCTIVITY METER

SCT BASIC BENCHTOP CONDUCTIVITY METER FOR NORMAL CONDUCTIVITY MEASUREMENT.

AUTOMATIC CALIBRATION AND AUTOMATIC TEMPERATURE COMPENSATION.

INSTRUMENT RESOLUTION 1.0

SALIENT FEATURES:

Ɣ 6&7%(1&+7230(7(5,6'(6,*1('720($685(&21'8&7,9,7<$1'7(03(5$785(

Ɣ :,7+ %8,/7,1 0,&52352&(6625 &+,3 ,7 +$6 $8720$7,& &$/,%5$7,21 $8720$7,&

TEMPERATURE COMPENSATION, DATA STORAGE, AND FEATURE SETTING ETC.

Ɣ $'237 $'9$1&(' $1' 25,*,1$/ &21'8&7,9,7< 0($685(0(17 7(&+12/2*< 86(  3& 2)

CONDUCTIVITY ELECTRODE (K=1), IT CAN MEET MEASURING ACCURACY REQUIREMENT FOR

5$1*(:,7+,1Ȃ6&0a06&0%<86,1*21/<21(32,17&$/,%5$7,21

Ɣ $8720$7,&$//< 5(&2*1,=(  .,1'6 2) &21'8&7,9,7< 67$1'$5' 62/87,21 86(5 &$1

CHOOSE ANYONE FROM TWO SERIES OF SOLUTIONS: EUROPE & USA SERIES.

Ɣ (48,33(':,7+&21'8&7,9,7<$7&3/$67,&(/(&752'()2548,&.$1'35(&,6(5(68/76

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS :

PRODUCT NO. SCT-108.003.11

MODEL NO SCT-BEN-CON-1

PARAMETER PRODUCT NAME SPECIFICATIONS

CONDUCTIVITY

MEASURING RANGE CONDUCTIVITY: 0 ~199.9 μS/CM 200~1999 μS/CM 2.00~19.99

mS/CM 20.0~199.9 mS/CM

RESOLUTION 0.1/1μS/CM 0.01/0.1 mS/CM

ACCURACY ±1.0% FS

TEMP. COMPENSATION RANGE 0 ~ 50 (AUTOMATIC OR MANUAL)

ELECTRODE CONSTANT 0.1 / 1 / 10 CM-1

OTHER TECHNICAL

SPECIFICATIONS

DATA STORAGE 50GROUPS

STORAGE CONTENT MEASURING VALUE SERIAL NUMBER, MEASURING VALUE,

AND TEMPERATURE

POWER DC9V

SIZE AND WEIGHT îî00*0(7(5

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE.

WORKING CONDITION ENVIRONMENT TEMPERATURE 5 ~ 35 0.01

ENVIRONMENTAL HUMIDITY 

ORDERING INFORMATIONS:

SCT-108.003.11 SCT-BEN-CON-1

SCT BEN-CON-1 BASIC CONDUCTIVITY BENCHTOP METER IS SUPPLIED WITH PLASTIC CONDUCTIVITY

ELECTRODE, 1413μS/CM CONDUCTIVITY STANDARD SOLUTION , 9V POWER ADAPTER, ELECTRODE HOLDER

& OPERATION MANUAL

* TEMP. ELECTRODE / ACCESSORIES NOT INCLUDED, TO BE ORDERED SEPARATELY.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

CONDUCTIVITY

ELECTRODE

SCT-108.003.C2 GLASS CONDUCTIVITY ELECTRODE, K=1.0 CM-1 AUTOMATIC TEMPERATURE COMPENSATION, FOR

LABORATORY AND PRECISION CONDUCTIVITY TESTING , 4-PIN PLUG.

SCT-108.003.C3 PLASTIC CONDUCTIVITY ELECTRODE, K=1.0 CM-1,AUTOMATIC TEMPERATURE COMPENSATION FOR

LABORATORY AND FIELD TESTING, 4-PIN PLUG

TEMP. ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

CONDUCTIVITY

CALIBRATION

SOLUTION

SCT-108.002.BA Ȃ6&0&21'8&7,9,7<&$/,%5$7,2162/87,210/

SCT-108.002.BB Ȃ6&0&21'8&7,9,7<&$/,%5$7,2162/87,210/

SCT-108.002.BD Ȃ6&0&21'8&7,9,7<&$/,%5$7,2162/87,210/

SCT-108.002.BE Ȃ6&0&21'8&7,9,7<&$/,%5$7,2162/87,210/

SCT-108.002.BG 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 500 ML

SCT-108.002.BH 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 250 ML

ELECTRODE HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION

OF NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

Start where you are. Use what you have. Do what you can

455

sales@scichemtech.com www.scichemtech.com

455

SCT (GLP) GOOD LABORATORY PRACTICE BENCHTOP CONDUCTIVITY / TDS /

SALINITY / RESISTIVITY METER

SCT GLP CONDUCTIVITY BENCHTOP METER SUITABLE FOR NORMAL CONDUCTIVITY

MEASUREMENT.

ADVANCED AND ORIGINAL CONDUCTIVITY MEASUREMENT TECHNOLOGY WIDE

MEASUREMENT RANGE, HIGH ACCURACY, CONDUCTIVITY MEASURMENT MODE CAN BE

SWITCH TO TDS, SALINITY AND RESISTIVITY.

INSTRUMENT RESOLUTION 1.0.

SALIENT FEATURES:

Ɣ 6&7%(1&+7230(7(5,6'(6,*1('720($685(&21'8&7,9,7<$1'7(03(5$785(

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(6

UP TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE,

TIMING MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE

ETC.

Ɣ 7+5((',))(5(170($685(0(1702'(667$%/(',63/$<02'(7,0(0($685(0(1702'(

CONTINUOUS MEASUREMENT MODE.

Ɣ (48,36&21'8&7,9,7<$7&(/(&752'(,760($685(0(175(68/7,6)$67$1'35(&,6(

Ɣ $'237 $'9$1&(' $1' 25,*,1$/ &21'8&7,9,7< 0($685(0(17 7(&+12/2*< 86(  3& 2)

CONDUCTIVITY ELECTRODE (K=1), IT CAN MEET MEASURING ACCURACY REQUIREMENT FOR

5$1*(:,7+,1Ȃ6&0a06&0%<86,1*21/<21(32,17&$/,%5$7,21

Ɣ $%,/,7< 72 6:,7&+ $021* &21'8&7,9,7< 7'6 6$/,1,7< $1' 5(6,67,9,7< 08/7,120,$/

CALCULATION FOR TDS AND SALINITY TO ENSURE THE CONVERSION PRECISION OF THE FULL

SCALE.

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.12

MODEL NO SCT-BEN-CON-2

PARAMETER PRODUCT NAME SPECIFICATIONS

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~20.00 μS/CM 20.0~200.0 μS/CM

200~2000 μS/CM 2.00~20.00 mS/CM

20.0~200.0 mS/CM

5(6,67,9,7<a0ȍā&0

TDS: 0 ~ 100 G/L

SALINITY 0 ~ 100 PPT

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1/1 mS/CM

ACCURACY ±0.5% FS

TEMP. COMPENSATION RANGE 0 ~ 50 AUTOMATIC

ELECTRODE CONSTANT 0.1 / 0.5 / 1 / 5 / 10 / 50 / 100 CM-1

REFERENCE TEMPERATURE 25 20 AND 18

TEMPERATURE

MEASURING RANGE -10 ~ 110

RESOLUTION 0.1

ACCURACY 5~ 60 RANGE ±0.4 OTHER RANGE ±0.8

OTHER TECHNICAL

PARAMETERS:

DATA STORAGE 300 GROUPS

STORAGE CONTENT MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE 15 ~ 30 0.001GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

* TEMP. ELECTRODE / ACCESSORIES NOT INCLUDED, TO BE ORDERED SEPARATELY.

ORDERING INFORMATIONS:

SCT-108.003.12 SCT-BEN-CON-2

SCT GLP BENCHTOP CONDUCTIVITY METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER WITH

PLASTIC CONDUCTIVITY ELECTRODE, 1413 μS/CM CONDUCTIVITY STANDARD SOLUTION, 9V POWER

ADAPTER, RS-232 COMMUNICATION CABLE, COMMUNICATION SOFTWARE CD,OPERATION MANUAL &

PACKING LIST

Step with care and great tact, and remember that life’s a great balancing act.

456 sales@scichemtech.com www.scichemtech.com

456

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

CONDUCTIVITY

ELECTRODE SCT-108.003.C3 PLASTIC CONDUCTIVITY ELECTRODE, K=1.0 CM-1 AUTOMATIC TEMPERATURE COMPENSATION FOR

LABORATORY AND FIELD TESTING, 4-PIN PLUG.

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA

PLUGS

CONDUCTIVITY

CALIBRATION

SOLUTION

SCT-108.002.BA 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 250 ML

SCT-108.002.BD 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 500 ML

SCT-108.002.BE 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 250 ML

SCT-108.002.BG 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 500 ML

SCT-108.002.BH 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 250 ML

ELECTRODE

HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER

COMBINATION OF NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

SCT PRECISION BENCHTOP CONDUCTIVITY / TDS / SALINITY / RESISTIVITY METER

SCT PRECISION BENCHTOP CONDUCTIVITY METER FOR PRECISION CONDUCTIVITY

MEASUREMENT OF RESEARCH AND QUALITY CONTROL.

WITH WIDE MEASUREMENT RANGE, HIGH ACCURACY CONDUCTIVITY MEASUREMENT

MODE CAN BE SWITCH TO TDS, SALINITY AND RESISTIVITY.

INSTRUMENT RESOLUTION 1.0

SALIENT FEATURES:

Ɣ 6&7 %(1&+ 35(&,6,21 &21'8&7,9,7< 0(7(5 68,7$%/( )25 +,*+ 35(&,6,21 &21'8&7,9,7<

MEASUREMENT OF SCIENCE RESEARCH AND QUALITY CONTROL, WITH ACCURACY 0.5%.

Ɣ (48,36 &21'8&7,9,7<$7& */$66 (/(&752'( ,76 0($685(0(17 5(68/7 ,6 )$67 $1'

PRECISE. CAN CHOOSE 25OC, 20OC AND 18OC THREE KINDS OF BASIS TEMPERATURE.

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(6

UP TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE,

TIMING MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE

ETC.

Ɣ 7+5((',))(5(170($685(0(1702'(667$%/(',63/$<02'(7,0(0($685(0(1702'(

CONTINUOUS MEASUREMENT MODE.

Ɣ $8720$7,&$//< 5(&2*1,=(  .,1'6 2) &21'8&7,9,7< 67$1'$5' 62/87,21 86(5 &$1

CHOOSE ANYONE FROM TWO SERIES OF SOLUTIONS: EUROPE & USA SERIES

Ɣ (48,33('&21'8&7,9,7<$7&(/(&752'()2548,&.$1'35(&,6(5(68/76

Ɣ $'237 $'9$1&(' $1' 25,*,1$/ &21'8&7,9,7< 0($685(0(17 7(&+12/2*< 86(  3& 2)

CONDUCTIVITY ELECTRODE (K=1), IT CAN MEET MEASURING ACCURACY REQUIREMENT FOR

5$1*(:,7+,1Ȃ6&0a06&0%<86,1*21/<21(32,17&$/,%5$7,21

Ɣ $%,/,7< 72 6:,7&+ $021* &21'8&7,9,7< 7'6 6$/,1,7< $1' 5(6,67,9,7< 08/7,120,$/

CALCULATION FOR TDS AND SALINITY TO ENSURE THE CONVERSION PRECISION OF THE FULL

SCALE.

Ɣ &21'8&7,9,7< 0($685(0(17 02'( +$6 7+( )81&7,21 2) 121/,1($5 7(03(5$785(

COMPENSATION FOR HIGH PURITY WATER.

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.13

MODEL NO SCT-BEN-CON-2

PARAMETER PRODUCT NAME SPECIFICATIONS

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~20.00 μS/CM 20.0~200.0 μS/CM

200~2000 μS/CM 2.00~20.00 mS/CM

20.0~200.0 mS/CM 200~2000 mS/CM K=10

5(6,67,9,7<a0ȍā&0

TDS: 0 ~ 100 G/L

SALINITY 0 ~ 100 PPT

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1/1 mS/CM

ACCURACY ±0.5% FS

TEMP. COMPENSATION RANGE 0 ~ 50 AUTOMATIC

ELECTRODE CONSTANT 0.1 / 0.5 / 1 / 5 / 10 / 50 / 100 CM-1

REFERENCE TEMPERATURE 25 20 AND 18

Stop telling god what to do with his dice

457

sales@scichemtech.com www.scichemtech.com

457

TEMPERATURE

MEASURING RANGE -10 ~ 110OC

RESOLUTION 0.1OC

ACCURACY 5~ 60 RANGE ±0.4 OTHER RANGE ±0.8

OTHER TECHNICAL

PARAMETERS:

DATA STORAGE 300 GROUPS

STORAGE CONTENT MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE.

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE 15 ~ 30 0.001GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.003.13 SCT-BEN-CON-3

SCT PEN-CON-3 PRECISION BENCHTOP CONDUCTIVITY METER IS SUPPLIED WITH FLEXIBLE ELECTRODE

HOLDER, PLASTIC THREE-IN-ONE COMBINATION ELECTRODE,1413 μS/CM CONDUCTIVITY STANDARD SOLUTION

(50 ML), 9V POWER ADAPTER RS-232 COMMUNICATION CABLE, COMMUNICATION SOFTWARE CD,OPERATION

MANUAL & PACKING LIST

* TEMP. ELECTRODE / ACCESSORIES NOT INCLUDED, TO BE ORDERED SEPARATELY.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

CONDUCTIVITY

ELECTRODE SCT-108.003.C3 PLASTIC CONDUCTIVITY ELECTRODE, K=1.0 CM-1 AUTOMATIC TEMPERATURE COMPENSATION FOR

LABORATORY AND FIELD TESTING, 4-PIN PLUG.

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA

PLUGS

CONDUCTIVITY

CALIBRATION

SOLUTION

SCT-108.002.BA 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 250 ML

SCT-108.002.BD 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 500 ML

SCT-108.002.BE 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 250 ML

SCT-108.002.BG 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 500 ML

SCT-108.002.BH 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 250 ML

ELECTRODE HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION

OF NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

SCT PRECISION BENCHTOP CONDUCTIVITY / TDS / SALINITY / RESISTIVITY METER /

DISSOLVED OXYGEN METER

SCT PRECISION CONDUCTIVITY DO METER FOR HIGH PRECISION MEASUREMENT OF THE

CONDUCTIVITY AND DISSOLVED OXYGEN IN LABORATORY.

SUITABLE FOR BIO-TECHNOLOGY, AQUA CULTURE, POWER PLANT AND ENVIRONMENTAL

PROTECTION INDUSTRIES.

SALIENT FEATURES:

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(683

TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, TIMING

MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE ETC.

Ɣ 7+5(( ',))(5(17 0($685(0(17 02'(6 67$%/( ',63/$< 02'( 7,0( 0($685(0(17 02'(

CONTINUOUS MEASUREMENT MODE.

Ɣ $8720$7,&$//<5(&2*1,=(.,1'62)&21'8&7,9,7<67$1'$5'62/87,2186(5&$1&+226(

ANYONE FROM TWO SERIES OF SOLUTIONS: EUROPE & USA SERIES.

Ɣ $'237 $'9$1&(' $1' 25,*,1$/ &21'8&7,9,7< 0($685(0(17 7(&+12/2*< 86(  3& 2)

CONDUCTIVITY ELECTRODE (K=1), IT CAN MEET MEASURING ACCURACY REQUIREMENT FOR RANGE

:,7+,1Ȃ6&0a06&0%<86,1*21/<21(32,17&$/,%5$7,21

Ɣ $%,/,7< 72 6:,7&+ $021* &21'8&7,9,7< 7'6 6$/,1,7< $1' 5(6,67,9,7< 08/7,120,$/

CALCULATION FOR TDS AND SALINITY TO ENSURE THE CONVERSION PRECISION OF THE FULL SCALE.

Ɣ &21'8&7,9,7< 0($685(0(17 02'( +$6 7+( )81&7,21 2) 121/,1($5 7(03(5$785(

COMPENSATION FOR HIGH PURITY WATER.

Ɣ 7+( 1(: 7<3( 2) '2 (/(&752'( :+,&+ +$6 )81&7,21 2) $8720$7,& 7(03(5$785(

COMPENSATION AND AUTOMATIC SALINITY COMPENSATION AS WELL AS AUTOMATIC AIR PRESSURE

COMPENSATION INSIDE METER TO MAKE DO MEASURING MODE HAS TEMPERATURE, AIR PRESSURE

AND SALINITY AUTOMATIC COMPENSATION, EASY TO USE, ACCURATE TO MEASURE.

Ɣ 32/$52*5$07<3('2(/(&752'(+$663(&,$/(/(&752'(&$/,%5$7,21&$321/<1(('672

5 MINUTES FOR ELECTRODE POLARIZATION. ELECTRODE ADOPTS COMBINATION DIAPHRAGM CAP

WHICH VERY CONVENIENT TO USE. EACH DO ELECTRODE EQUIPS WITH THREE SPARE DIAPHRAGMS

CAPS.

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522)$1':$7(53522)0(7(50((76,367$1'$5'6$//62&.(76$5(6($/3527(&7('

BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

Stop thinking of what could go wrong and start thinking of what could go right.

458 sales@scichemtech.com www.scichemtech.com

458

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.14

MODEL NO. SCT-BEN-CON-4

PARAMETER PRODUCT NAME SPECIFICATIONS

CONDUCTIVITY

MEASURING RANGE

CONDUCTIVITY 0.00~20.00 μS/CM 20.0~200.0 μS/CM

200~2000 μS/CM 2.00~20.00 mS/CM

20.0~200.0 mS/CM 200~2000 mS/CM K=10

5(6,67,9,7<a0ȍā&0

TDS: 0 ~ 100 G/L

SALINITY 0 ~ 100 PPT

RESOLUTION 0.01/0.1/1μS/CM 0.01/0.1/1 mS/CM

ACCURACY ±0.5% FS

TEMP. COMPENSATION RANGE 0 ~ 50 AUTOMATIC

ELECTRODE CONSTANT 0.1 / 0.5 / 1 / 5 / 10 / 50 / 100 CM-1

REFERENCE TEMPERATURE 25 20 AND 18

DISSOLVED OXYGEN

MEASURING RANGE 0 ~ 40.00 MG/L(PPM) 0 ~ 200.0 %

RESOLUTION 0.1/0.01 MG/L(PPM) 1/0.1 %

ACCURACY ±0.10 MG/L

RESPONSE TIME 65(63216(

RESIDUAL CURRENT 0*/

TEMP. COMPENSATION RANGE 0 ~ 45 AUTOMATIC

SALINITY COMPENSATION RANGE 0 ~ 45 PPT AUTOMATIC

AIR PRESSURE COMPENSATION 80 ~ 105 KPA AUTOMATIC

AUTOMATIC CALIBRATION AIR SATURATED BY WATER; WATER SATURATED BY AIR

ELECTRODE TYPE POLAROGRAM TYPE

TEMPERATURE

MEASURING RANGE -10~ 110OC

RESOLUTION 0.1OC

ACCURACY 5~ 60 RANGE ±0.4 OTHER RANGE ±0.8

OTHER TECHNICAL

PARAMETERS:

DATA STORAGE 300 GROUPS

STORAGE CONTENT MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE.

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE 15 ~ 30 0.001GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

ORDERING INFORMATION:

SCT-108.003.14 SCT-BEN-CON-4

SCT BEN-CON-4 PRECISION CONDUCTIVITY / DO BENCHTOP METER IS SUPPLIED WITH FLEXIBLE ELECTRODE

HOLDER, INTELLIGENT STIRRER, CONDUCTIVITY ELECTRODE, DO ELECTRODE, 1413μS/CM CONDUCTIVITY

STANDARD SOLUTION, 9V POWER ADAPTER, 6V POWER ADAPTER, MEMBRANE CAP , DO ELECTRODE INNER

SOLUTION, CATHODE POLISH PAPER, B628 STIRRING BEAD, BATTERY, RS232 COMMUNICATION CABLE,

COMMUNICATION SOFTWARE CD, OPERATION MANUAL & PACKING LIST.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

CONDUCTIVITY

ELECTRODE SCT-108.003.C2 GLASS CONDUCTIVITY ELECTRODE, K=1.0 CM-1 AUTOMATIC TEMPERATURE COMPENSATION, PRECISION

LABORATORY TEST FOR CONDUCTIVITY, 4-PIN PLUG.

DO ELECTRODE SCT-108.002.D1 DO ELECTRODE, POLAROGRAPHIC-TYPE DO ELECTRODE FOR LABORATORY AND FIELD USING, 8-PIN PLUG

DO ELECTRODE

ATTACHMENT

SCT-108.003.D2 DO ELECTRODE MEMBRANE CAP, COMBINED MEMBRANE CAP DEDICATED TO THE DO ELECTRODE, SIZE: 3 /

GROUP

SCT-108.003.IA DO ELECTRODE ELECTROLYTE, ADDED ELECTROLYTE, DEDICATED TO THE DO ELECTRODE, SPECIFICATIONS:

30ML/BOTTLE

SCT-108.003.IB CATHODE POLISHING PAPER, POLISHING PAPER, DEDICATED TO CLEAN DO ELECTRODE CATHODE, SIZE: 2 /

GROUP.

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

CONDUCTIVITY

CALIBRATION

SOLUTION

SCT-108.002.BA 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 500 ML

SCT-108.002.BB 84 μS/CM CONDUCTIVITY CALIBRATION SOLUTION 250 ML

SCT-108.002.BD 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 500 ML

SCT-108.002.BE 1413 μS/CMCONDUCTIVITYCALIBRATION SOLUTION 250 ML

SCT-108.002.BG 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 500 ML

SCT-108.002.BH 12.88 mS/CMCONDUCTIVITYCALIBRATION SOLUTION 250 ML

ELECTRODE

HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION OF

NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

Strenght lies in the brain not in the muscle

459

sales@scichemtech.com www.scichemtech.com

459

SCT BENCHTOP DO (DISSOLVED OXYGEN) / TEMP METER

SCT BENCHTOP DO TEMPERATURE METER WITH AUTOMATIC SALINITY COMPENSATION

AND AUTOMATIC AIR PRESSURE COMPENSATION.

EQUIPPED WITH INTELLIGENT STIRRER, FLEXIBLE ELECTRODE HOLDER AND OPERATION

INSTRUCTION.

SALIENT FEATURES:

Ɣ 6&7%(1&+7230(7(5,6'(6,*1('720($685(',662/9('2;<*(1$1'7(03(5$785(

Ɣ 6&7 '2 0($685(0(17 +$6 $7& $8720$7,& 6$/,1,7< &203(16$7,21 $1' $8720$7,& $,5

PRESSURE COMPENSATION.

Ɣ 7+( 1(: 7<3( 2) '2 (/(&752'( :+,&+ +$6 )81&7,21 2) $8720$7,& 7(03(5$785(

COMPENSATION AND AUTOMATIC SALINITY COMPENSATION AS WELL AS AUTOMATIC AIR PRESSURE

COMPENSATION INSIDE METER TO MAKE DO MEASURING MODE HAS TEMPERATURE, AIR

PRESSURE AND SALINITY AUTOMATIC COMPENSATION, EASY TO USE, ACCURATE TO MEASURE.

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(6

UP TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE,

TIMING MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE

ETC.

Ɣ 7+5((',))(5(170($685(0(1702'(667$%/(',63/$<02'(7,0(0($685(0(1702'(

CONTINUOUS MEASUREMENT MODE.

Ɣ (/(&752'($'2376&20%,1$7,21',$3+5$*0&$3$66(0%/,1*6(16,7,9(0(0%5$1(:,7+

DIAPHRAGM CAP, WHICH VERY CONVENIENT TO REPLACE THE SENSITIVE MEMBRANE. THE USER

ONLY NEEDS TO SCREW THE NEW MEMBRANE CAP ON THE ELECTRODE.

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.15

MODEL NO SCT-BEN-DO-1

PARAMETER PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

DISSOLVED OXYGEN

MEASURING RANGE 0 ~ 40.00 MG/L(PPM) 0 ~ 200.0%

RESOLUTION 0.1/0.01 MG/L(PPM) 1/0.1 %

ACCURACY ±0.10 MG/L

RESPONSE TIME 65(63216(

RESIDUAL CURRENT 0*/

TEMP. COMPENSATION RANGE 0 ~ 45 (AUTOMATIC)

SALINITY COMPENSATION RANGE 0 ~ 45 (PPT AUTOMATIC)

AIR PRESSURE COMPENSATION 80 ~ 105 (KPA AUTOMATIC)

AUTOMATIC CALIBRATION AIR SATURATED BY WATER; WATER SATURATED BY AIR

ELECTRODE TYPE POLAROGRAM TYPE

TEMPERATURE

MEASURING RANGE -10 ~ 110OC

RESOLUTION 0.1OC

ACCURACY 5~ 60 RANGE ±0.4 OTHER RANGE ±0.8

OTHER TECHNICAL

PARAMETERS:

DATA STORAGE 300 GROUPS

STORAGE CONTENT MEASURING VALUE SERIES NUMBER, MEASURING VALUE,

TEMPERATURE, ATC OR MTC STATE, MEASURING DATE AND TIME

POWER DC9V/300MA

COMMUNICATION CONNECTOR RS232

SIZE AND WEIGHT îî00*

QUALITY AND SAFETY CERTIFICATION ISO9001:2008, CE.

WORKING CONDITION

ENVIRONMENT TEMPERATURE 5 ~ 35 0.01GRADE 15 ~ 30 0.001GRADE

ENVIRONMENTAL HUMIDITY 

IP RATING IP54 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.003.15 SCT-BEN-DO-1

SCT BEN-DO-1 BENCHTOP DO / TEMPERATURE METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER,INTELLIGENT

STIRRER, DO ELECTRODE, DO ELECTRODE INNER SOLUTION, MEMBRANE CAP (FOR DO ELECTRODE USE),CATHODE

POLISHING PAPER,9V POWER ADAPTER (FOR METER USE), 6V POWER ADAPTER (FOR STIRRER USE), RS-232

COMMUNICATION CABLE, COMMUNICATION SOFTWARE CD, STIRRING BEAD, AA BATTERY, OPERATION MANUAL &

PACKING LIST.

* TEMP. ELECTRODE / ACCESSORIES NOT INCLUDED, TO BE ORDERED SEPARATELY.

Strength and growth come only through continuous effort and struggle.

460 sales@scichemtech.com www.scichemtech.com

460

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

DO ELECTRODE SCT-108.002.D1 DO ELECTRODE, POLAROGRAPHIC-TYPE DO ELECTRODE FOR LABORATORY AND FIELD USING, 8-PIN PLUG

DO ELECTRODE

ATTACHMENT

SCT-108.003.D2 DO ELECTRODE MEMBRANE CAP, COMBINED MEMBRANE CAP DEDICATED TO THE DO ELECTRODE, SIZE: 3 /

GROUP

SCT-108.003.IA DO ELECTRODE ELECTROLYTE, ADDED ELECTROLYTE, DEDICATED TO THE DO ELECTRODE, SPECIFICATIONS:

30ML/BOTTLE

SCT-108.003.IB CATHODE POLISHING PAPER, POLISHING PAPER, DEDICATED TO CLEAN DO ELECTRODE CATHODE, SIZE: 2 /

GROUP.

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

ELECTRODE

HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION OF

NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

SCT BENCHTOP SODIUM ION METER

SCT BENCHTOP SODIUM ION METER IS SUITABLE FOR MEASURING LOW SODIUM ION

CONCENTRATION IN THE WATER.

SALIENT FEATURES:

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(6

UP TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE,

TIMING MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE

ETC.

Ɣ 7+5((',))(5(170($685(0(1702'(667$%/(',63/$<02'(7,0(0($685(0(1702'(

CONTINUOUS MEASUREMENT MODE.

Ɣ 62',80(/(&752'(5$1*(

Ɣ 62',80,21(/(&752'(5()(5(1&((/(&752'($1'7(03(5$785((/(&752'(

Ɣ &$16:,7&+.,1'62)&21&(175$7,2181,73;02//0*/$1'330

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.16

MODEL NO SCT-BEN-SOD-1

PARAMETER PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

SODIUM ION

MEASURING RANGE 0.00 TO 9.00 pNa

UNITS PNa, mol/L, mg/L AND ppm

ACCURACY Na+ +/- 0.01 pNa

TEMPERATURE

MEASURING RANGE -10 TO 110OC

UNITS OC

ACCURACY +/- 0.5OC

MEASURING RANGE +/- 1999.9 mV

UNITS mV

ACCURACY +/- 0.1% FULL SCALE

OTHER TECHNICAL

PARAMETERS

ATC- AUTOMATIC TEMPERATURE COMPENSATION 0 to 50OC

STORAGE DATA 600 GROUPS

COMMUNICATION CONNECTOR RS-232

POWER DC 9V / 300mA

DIMENSION AND WEIGHT (160 X 190 X 70 ) mm / 880 Gms

QUALITY CERTIFICATION ISO 9001:2008, CE

WORKING CONDITION

ENVIRONMENTAL TEMPERATURE 5 TO 35OC 0.01OC AND 15 TO 30OC 0.001OC

ENVIRONMENTAL HUMIDITY < 75%

IP RATING IP 54 DUST PROOF AND IP 57 WATER PROOF

IP RATING IP54 DUSTPROOF AND WATERPROOF

ORDERING INFORMATIONS:

SCT-108.003.16 SCT-BEN-SOD-1

SCT BEN-SOD-1BENCHTOP SODIUM ION METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER, INTELLI-

GENT STIRRER, STIR BEAD,SODIUM ION ELECTRODE, REFERENCE ELECTRODE, TEMPERATURE ELECTRODE,

pNA1.00 STANDARD SOLUTION, 10-1 mol/L CSCL REFERENCE SOLUTION, 9V POWER ADAPTER ,16V POWER

ADAPTER, AA BATTERY, RS-232 COMMUNICATION CABLE, COMMUNICATION SOFTWARE CD, OPERATION MAN-

UAL & PACKING LIST

Strength does not come from physical capacity. It comes from an indomitable will

461

sales@scichemtech.com www.scichemtech.com

461

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

ION ELECTRODE SCT-108.003.E1 SODIUM ION ELECTRODE, USED TO TEST THE CONCENTRATION OF SODIUM ION WITH BNC PLUG

REFERENCE

ELECTRODE SCT-108.003.F2 REFERENCE ELECTRODE, EQUIPPED WITH THE SODIUM ION ELECTRODE, BANANA PLUGS

TEMPERATURE

ELECTRODE SCT-108.003.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

ELECTRODE HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION

OF NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

SCT BENCHTOP CALCIUM ION METER

SCT BENCHTOP CALCIUM ION METER WIDELY USED IN DETECTING THE CONCENTRATION

OF CALCIUM IONS IN WATER.

SALIENT FEATURES:

Ɣ

SCT METER MEETS WITH THE REQUIREMENT OF INTERNATIONAL GLP STANDARDS. ITS FEATURES UP

TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE, TIMING

MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE ETC.

Ɣ 7+5(( ',))(5(17 0($685(0(17 02'(6 67$%/( ',63/$< 02'(7,0( 0($685(0(17 02'(

CONTINUOUS MEASUREMENT MODE.

Ɣ &$/&,80(/(&752'(5$1*(

Ɣ &$/&,80,21&20%,1$7,21(/(&752'($1'7(03(5$785((/(&752'(

Ɣ &$16:,7&+.,1'62)&21&(175$7,2181,73;02//0*/$1'330

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.17

MODEL NO SCT-BEN-CAL-1

PARAMETER PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

CALCIUM ION

MEASURING RANGE Ca2+ 0.00 TO 9.00 pCa

UNITS pCa, mol/L, mg/L AND ppm

ACCURACY Ca+ +/- 0.01 pCa

TEMPERATURE

MEASURING RANGE - 10 TO 110 OC

UNITS OC

ACCURACY +/- 0.5 OC

MEASURING RANGE +/- 1999.9 mV

UNITS mV

ACCURACY +/- 0.1% FULL SCALE

OTHER TECHNICAL

PARAMETERS

ATC- AUTOMATIC TEMPERATURE COMPENSATION 0 to 50 OC

STORAGE DATA 600 GROUPS

COMMUNICATION CONNECTOR RS-232

POWER DC 9V / 300mA

DIMENSION AND WEIGHT (160 X 190 X 70 ) mm / 880 Gms

QUALITY CERTIFICATION ISO 9001:2008, CE

WORKING CONDITION

ENVIRONMENTAL TEMPERATURE 5 TO 35OC 0.01OC AND 15 TO 30OC 0.001 OC

ENVIRONMENTAL HUMIDITY < 75%

IP RATING IP 54 DUST PROOF AND IP 57 WATER PROOF

ORDERING INFORMATIONS:

SCT-108.003.17 SCT-BEN-CAL-01

SCT BENCHTOP CALCIUM ION CONCENTRATION METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER,

INTELLIGENT STIRRER, STIR BEAD, CALCIUM ION COMBINATION ELECTRODE, CALCIUM ELECTRODE INNER

SOLUTION, CALCIUM ELECTRODE MEASURING HEAD, TOOL FOR FILLING CALCIUM ELECTRODE INNER

SOLUTION,TEMPERATURE ELECTRODE, pCa 1.00 STANDARD SOLUTION, 9V POWER ADAPTER ,6V POWER

ADAPTER, BATTERY, RS-232 COMMUNICATION CABLE, MP518 COMMUNICATION SOFTWARE CD, OPERATION

MANUAL & PACKING LIST

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

ION ELECTRODE SCT-108.003.E2 CALCIUM COMPOSITE ELECTRODE USED FOR TESTING CALCIUM CONCENTRATION BNC PLUG

REFERENCE ELECTRODE SCT-108.003.F2 REFERENCE ELECTRODE, EQUIPPED WITH THE SODIUM ION ELECTRODE, BANANA PLUGS

TEMP ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA

PLUGS

ELECTRODE HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER

COMBINATION OF NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

Strive not to be a success, but rather to be of value.

462 sales@scichemtech.com www.scichemtech.com

462

SCT BENCHTOP FLUORIDE (Fl) ION METER

SCT BENCHTOP FLUORIDE ION METER SUITABLE FOR DETECTING FLOURIDE ION IN THE

WATER SAMPLES.

SALIENT FEATURES:

Ɣ 6&70(7(50((76:,7+7+(5(48,5(0(172),17(51$7,21$/*/367$1'$5'6,76)($785(6

UP TO AUTOMATIC CALIBRATION, AUTOMATIC TEMPERATURE COMPENSATION, DATA STORAGE,

TIMING MEASUREMENT, CLOCK DISPLAY, RS-232 OUTPUT, FUNCTION SETTING AND SELF-DIAGNOSE

ETC.

Ɣ 7+(5( $5( 7+5(( ',))(5(17 0($685(0(17 02'(6 67$%/( ',63/$< 02'( 7,0(

MEASUREMENT MODE; CONTINUOUS MEASUREMENT MODE.

Ɣ (/(&752'(5$1*(

Ɣ )/825,'(,21(/(&752'(5()(5(1&((/(&752'($1'7(03(5$785((/(&752'(

Ɣ &$16:,7&+.,1'62)&21&(175$7,2181,73;02//0*/$1'330

Ɣ ($&+0(7(5,6&2'(':,7+81,48(6(5,$/180%(5

Ɣ '8673522) $1' :$7(53522) 0(7(5 0((76 ,3 67$1'$5'6 $// 62&.(76 $5( 6($/

PROTECTED BY THE SILICA GEL CAPS.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.003.18

MODEL NO SCT-BEN-FLU-1

PARAMETER PRODUCT NAME BASIC FEATURES AND SPECIFICATIONS

FLUORIDE ION

MEASURING RANGE )í72S)

UNITS S)íPRO/PJ/$1'SSP

ACCURACY )íS)

TEMPERATURE

MEASURING RANGE - 10 TO 110 OC

UNITS OC

ACCURACY +/- 0.5 OC

MEASURING RANGE +/- 1999.9 mV

UNITS mV

ACCURACY +/- 0.1% FULL SCALE

OTHER TECHNICAL

PARAMETERS

ATC- AUTOMATIC TEMPERATURE COMPENSATION 0 to 50 OC

STORAGE DATA 600 GROUPS

COMMUNICATION CONNECTOR RS-232

POWER DC 9V / 300mA

DIMENSION AND WEIGHT (160 X 190 X 70) mm / 880 Gms

QUALITY CERTIFICATION ISO 9001:2008, CE

WORKING CONDITION

ENVIRONMENTAL TEMPERATURE 5 TO 35OC 0.01 OC AND 15 TO 30 OC 0.001OC

ENVIRONMENTAL HUMIDITY < 75%

IP RATING IP 54 DUST PROOF AND IP 57 WATER PROOF

ORDERING INFORMATIONS:

SCT-108.003.18 SCT-BEN-FLU-1

SCT BENCHTOP FLUORIDE ION CONCENTRATION METER IS SUPPLIED WITH FLEXIBLE ELECTRODE HOLDER

INTELLIGENT STIRRER, STIR BEAD, FLUORIDE ION ELECTRODE, REFERENCE ELECTRODE,TEMPERATURE

ELECTRODE, PF1.00 STANDARD SOLUTION, 9V POWER ADAPTER, 6V POWER ADAPTER, BATTERY, RS-232

COMMUNICATION CABLE, COMMUNICATION SOFTWARE CD, OPERATION MANUAL & PACKING LIST

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

ION ELECTRODE SCT-108.003.E4 FLUORIDE ELECTRODE, USED TO TEST FLUORIDE CONCENTRATION BNC PLUG

REFERENCE

ELECTRODE SCT-108.003.F3 REFERENCE ELECTRODE, EQUIPPED WITH THE 7801 SODIUM ION ELECTRODE, BANANA PLUGS

TEMPERATURE

ELECTRODE SCT-108.002.D1 TEMPERATURE ELECTRODE, STAINLESS STEEL HOUSING, FAST RESPONSE, HIGH ACCURACY, RCA PLUGS

ELECTRODE

HOLDER

SCT-108.002.NA FLEXIBLE ELECTRODE HOLDER, NICE APPEARANCE OF THE ARC-TYPE BRACKET, YOU CAN TURN 360

DEGREES AND VERTICAL LIFT

SCT-108.002.NB STIRRING TYPE ELECTRODE HOLDER, THE ELECTRODE HOLDER AND MAGNETIC STIRRER COMBINATION

OF NEW PRODUCTS.

SCT-108.002.NC SIMPLE ELECTRODE HOLDER

Study history, study history. In history lies all the secrets of statecraft.

463

sales@scichemtech.com www.scichemtech.com

463

SCT BENCHTOP WATER HARDNESS METER

SALIENT FEATURES :

Ɣ 6&7%(1&+7230(7(5,6)250($685(0(172):$7(5+$5'1(667+(727$/&21&(175$7,21

OF CALCIUM ION AND MAGNESIUM ION).

Ɣ (/(&752'($'2376:$7(5+$5'1(66&20%,1$7,21(/(&752'(:,7+3$7(176758&785(,7

CONSISTS OF MEASUREMENT ELECTRODE, REFERENCE ELECTRODE AND TEMPERATURE PROBE.

REPLACEABLE MEASURING HEAD, STEADY POTENTIAL, FAST RESPONSE, EASY TO USE.

Ɣ 0(7(5$'2376,17(//,*(17&+,3'(6,*1$8720$7,&&$/,%5$7,21$8720$7,&7(03(5$785(

COMPENSATION, TIME DISPLAY, DATA STORAGE RS232 OUTPUT, ETC.

Ɣ $%,/,7<726:,7&+$021*(,*+781,76 002//0*/&$&2 0*/&$2002//%2,/(5

AND MG/L (CA). THREE OPTIONS OF THREE UNITS: ºFHFRANCE ºDH GERMANY AND ºEHUK FROM

WH-LINK COMMUNICATION SOFTWARE

Ɣ (48,33(':,7+%%$1'%&$/,%5$7,2162/87,216

Ɣ (48,33(':,7+ :+/,1.&20081,&$7,2162)7:$5(&211(&77(67,1* '$7$2)0(7(572

COMPUTER.

Ɣ 6&7%(1&+7230(7(50((76,62&(67$1'$5'6

TECHNICAL SPECIFICATION :

PRODUCT NO. SCT-108.003.19

MODEL NO SCT-BEN-HARD-1

PARAMETER PRODUCT NAME SPECIFICATIONS

WATER HARDNESS

MEASURING RANGE 0 ~ 10 MMOL/L 0 ~ 401 MG/L(CA)

RESOLUTION 0 ~ 1000 MG/L(CACO3) 0 ~ 100 ºFH(FRANCE DEGREE)

ACCURACY 0 ~ 561 MG/L(CAO) 0 ~ 56 ºDH(GERMAN DEGREE)

TEMP. COMPENSATION 0 ~ 20 MMOL/L(BOILER) 0 ~ 70 ºEH (ENGLAND DEGREE)

CALIBRATION SOLUTION 0.01 AND 0.1 WATER HARDNESS UNITS

CALIBRATION MODE

±5% FS

5 ~ 50 AUTOMATIC

%&$/,%5$7,2162/87,21²î002//

%&$/,%5$7,2162/87,21²î002//

B3 CALIBRATION SOLUTION — 2.00 MMOL/L

B3CALIBRATION SOLUTION ALSO CAN BE USED FOR THE SOAKING SOLUTION OF

ELECTRODE

(A)B1/B2 CALIBRATION—USING B1 AND B2 CALIBRATION SOLUTION SUITABLE FOR <

î002///2:&21&(175$7,21:$7(548$/,7<)25(;$03/(%2,/(5

WATER.

(B)CALIBRATION—USING B2 AND B3 CALIBRATION SOLUTION SUITABLE FORGENERAL

WATER QUALITY.

TEMPERATURE

MEASURING RANGE 0 ~ 60

RESOLUTION 0.1

ACCURACY ±0.5

OTHER TECHNICAL

PARAMETER

DATA STORAGE 128 GROUPS

CONTENT STORAGE SERIAL NUMBER OF MEASURING VALUE, MEASURING VALUE, UNITS, TEMPERATURE,

ATC OR MTC, DATE, TIME AND CALIBRATION WAY.

COMMUNICATION CONNECTOR RS232

POWER DC9V

DIMENSION AND WEIGHT îî00*

QUALITY AND SAFE CERTIFICATE ISO9001:2000 AND CE

WORKING CONDITIONS AMBIENT TEMPERATURE (5~35)

AMBIENT HUMIDITY 5+

ORDERING INFORMATIONS:

SCT-108.003.19 SCT-BEN-HARD-1

SCT BEN-HARD-1 BENCHTOP WATER HARDNESS METER IS SUPPLIED WITH WATER HARDNESS ELECTRODE

STIRRING TYPE ELECTRODE HOLDER, WATER HARDNESS CALIBRATION SOLUTION (B1, B2 & B23) 20 ML. TEST

CUP PEDESTAL IN A SOLUTION FOR WATER HARDNESS ELECTRODE TOOLS FOR FILLING REFERENCE SOLUTION

WH - LINK COMMUNICATION SOFTWARE, RS-232 COMMUNICATION CABLE AND OPERATION MANUAL.

OPTIONAL ACCESSORIES: (SELECT ONLY IF REQUIRED)

ACCESSORY PRODUCT NO. DESCRIPTION

WATER HARDNESS

ELECTRODE SCT-108.002.E2

WATER HARDNESS ELECTRODE

SUITED FOR MEASUREMENT OF TOTAL CONCENTRATION OF CALCIUM ION AND MAGNESIUM ION,

MATCH METER, BNC+RCA CONNECTOR

WATER HARDNESS

ELECTRODE ACCESSORY

SCT-108.002.E3 WATER HARDNESS ELECTRODE INNER REFERENCE SOLUTION, MATCH ELECTRODE

SCT-108.002.HB REFERENCE SOLUTION FILLING TOOL, MATCH ELECTRODE

WATER HARDNESS

CALIBRATION SOLUTION

SCT-108.002.EA WATER HARDNESS CALIBRATION SOLUTION B1 - 250 ML

SCT-108.002.FA WATER HARDNESS CALIBRATION SOLUTION B2 - 250 ML

SCT-108.002.GA WATER HARDNESS CALIBRATION SOLUTION B3 - 250 ML

Success consists of going from failure to failure without loss of enthusiasm.

464 sales@scichemtech.com www.scichemtech.com

464

SCT pH / TITRATION MAGNETIC STIRRERS

SCT MAGNETIC STIRRERS AND MAGNETIC STIRRER / HOTPLATES ARE MADE EXCLUSIVELY

FOR SCT WATER TESTING / MEASUREMENT. BENCHTOP SERIES : HOWEVER, CUSTOMER

CAN USE THESE PRODUCTS FOR YOUR GENERAL PURPOSES ALSO.

SALIENT FEATURES:

Ɣ 60$//$1'&203$&7

Ɣ 0$'(2)$%63/$67,&

Ɣ 5$1*(USP

Ɣ 67(3/(6663(('5(*8/$7,21

Ɣ /,75(67,55,1*&$3$&,7<

Ɣ 9'&32:(5$'$37(5

TECHNICAL SPECIFICATIONS:

PRODUCT NO. SCT-108.002.PA

MODEL NO. SCT-GDS-1

STIRRER

SPEED 0 - 2300 RPM (EMPTY LOAD)

MAX. STIRRING CONTENT 1000 ML

PLATE DIAMETER ) 120 MM

OTHER TECHNICAL

PARAMETERS

POWER ADAPTER DC6V

EXTERIOR DIMENSION AND WEIGHT ) 120 X 49 MM / 500 G

ORDERING INFORMATION:

SCT-108.002.PA SCT-GDS-1 SCT GDS-1 pH TITRATION MAGNETIC STIRRER IS SUPPLIED WITH DC6V POWER ADAPTER AND INSTRUCTION

MANUAL.

SCT pH / TITRATION HOTPLATE MAGNETIC STIRRERS

SCT MAGNETIC STIRRERS AND MAGNETIC STIRRER & HOTPLATES ARE MADE EXCLUSIVELY

FOR SCT WATER TESTING / MEASUREMENT. BENCHTOP SERIES : HOWEVER, CUSTOMER

CAN USE THESE PRODUCTS FOR YOUR GENERAL PURPOSES ALSO.

SALIENT FEATURES:

Ɣ 60$//$1'&203$&7

Ɣ 0$'(2)$%63/$67,&

Ɣ 5$1*(USP

Ɣ 67(3/(6663(('5(*8/$7,21

Ɣ 67,55(5:,7++($7,1*8372OC

Ɣ /,75(67,55,1*&$3$&,7<

Ɣ 9'&32:(5$'$37(5

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.002.PB

MODEL NO SCT-GDS-2

STIRRER

SPEED 0 - 2300 RPM (EMPTY LOAD)

HEATING 120OC

MAX. STIRRING CONTENT 1000 ML

PLATE DIAMETER ) 120 MM

OTHER TECHNICAL

PARAMETERS

POWER ADAPTER DC6V

EXTERIOR DIMENSION AND WEIGHT ) 120 X 49 MM / 500 G

ORDERING INFORMATIONS:

SCT-108.002.PB SCT-GDS-2 SCT GDS-2 pH TITRATION HOTPLATE MAGNETIC STIRRER IS SUPPLIED WITH DC6V POWER ADAPTER AND

INSTRUCTION MANUAL.

Success has a simple formula: do your best, and people may like it.

465

sales@scichemtech.com www.scichemtech.com

465

ScichemTech - SCT ® SDI TEST KITS

SCT PORTABLE & MANUAL SILT DENSITY INDEX (SDI) TEST METER

SALIENT FEATURES:

SCT SDI METER is completely assembled in a portable, COMPACT case, ready for on-site testing.

,QFOXGHV $670 LQVWUXFWLRQV IRU PHDVXULQJ VLOW GHQVLW\ LQGH[ )HHG SUHVVXUH UHTXLUHG 0LQ  SVL 

Assembled with Filter Holder, Pressure Gauge, Pressure Regulator, Ball Valve, Graduated Cylinder,

Thermometer, Tubing,

Filter Tweezers., Filters not included (please refer optional accessories).

ORDERING INFORMATIONS :

SCT-108.004.01 SCT-SEDIMENT-01

SCT SEDIMENT-1 PORTABLE MANUAL SILT DENSITY INDEX METER IS SUPPLIED COMPLETE WITH ASTM

instructions for measuring silt density index, Filter Holder, Pressure Gauge, Pressure Regulator, Ball Valve, Graduated

Cylinder, Thermometer, Tubing,Filter Tweezers

OPTIONAL ACCESSORIES (ORDER ONLY IF REQUIRED)

SCT-108.004.1A 0.45 Micron Filter (100 per package)

SCT-108.004.1B Replacement Filter Holder

Pressure

Gauge

Ball

Valve

From Sample

tap - 30 PSIG

or greater

Pressure

Regulator

Filter

Holder

500 ml

Graduated

Cylinder

Note 1. The value %P30 is commonly referred to as the “plugging factor”,

%P30 (plugging factor) should not exceed 75%. If you obtain values higher

than 75%, the test should be conducted using a shorter time for T, that is 5 or

10 minute measurements for Tf. If % P30 exceeds 75% on a 5 minute test,

you have water that need further treatment before a meaningful SDI result

can be obtained.

where % P30

= percent @ 30 psi feed pressure (see note 1)

= total elapsed flow time (see note 1)

= initial time required to collect 500 ml sample.

= time required to collect 500 ml sample

after test time T, (see note 1)

SDIT=%P30 1- tl

tf 100

Success is a great deodorant. It takes away all your past smells.

466 sales@scichemtech.com www.scichemtech.com

466

SCT PORTABLE & DIGITAL SILT DENSITY INDEX (SDI) TEST METER

SALIENT FEATURES:

 Performs SDI 5, 10 and 15 minute tests with both 100 ml and 500 ml sample size tests – provides

XVHIXO GDWD WKDW¶V LPSRVVLEOH WR REWDLQ ZLWK WKH PDQXDO PHWKRG (VSHFLDOO\ KHOSIXO RQ KLJK 6',

waters.

 Unattended operation. Start the test and return in 15 minutes for the results – saves you time.

 5HDOWLPHGLVSOD\RIUHVXOWVLQFOXGLQJ6',FXUUHQWÀRZUDWHDQGHODSVHGWLPH(QGRIWHVWGLVSOD\

includes SDI 5,10 & 15 with 100 ml and 500 ml results.

 More accurate than hand testing (ASTM D 4189-95) - consistent results provides better

information.

 Battery powered for true portability – conduct tests anywhere.

 8VHVVWDQGDUGPPPHPEUDQH¿OWHUV±IRUORZHUFRQVXPDEOHFRVWDQGZRUOGZLGHDYDLODELOLW\

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.004.02 SCT.108.004.03

SCT MODEL NO SEDIMENT-2 (110V) SEDIMENT-3 (220V)

Sample Water Pressure 35-100 psi

Sample Water Temperature 35-100°F

Sample water Solids Free of solids. Filter to 50 microns minimum.

Inlet 1/4” OD tubing.

Power Supply

110VAC-9VDC 500mA,

220VAC-9VDC 500mA

Pls specify upon ordering

Battery 6V 1.3 AH SLA type.13 hours testing/charge.

Weight 7 lbs, (3.2 kg)

Dimensions Inch (mm)WXDXH 10.75 (273) 9.75 (248) 5 (127)

ORDERING INFORMATIONS:

108.004.02 SCT-SEDIMENT-02

SCT SEDIMENT-2 Portable & Automated Silt Density Index Meter 110VAC is supplied with Power

6XSSO\%DWWHU\&KDUJHU$FFHVVRU\&DVHSDFNRIHDFKPLFURQPPPHPEUDQH¿OWHUV6SHFLDO

7ZHH]HUVIRUKDQGOLQJRIWKHPHPEUDQHVDQGDPLFURQSUH¿OWHU

108.004.03 SCT-SEDIMENT-03

SCT SEDIMENT-3 Portable & Automated Silt Density Index Meter 220VAC is supplied with Power

6XSSO\%DWWHU\&KDUJHU$FFHVVRU\&DVHSDFNRIHDFKPLFURQPPPHPEUDQH¿OWHUV6SHFLDO

7ZHH]HUVIRUKDQGOLQJRIWKHPHPEUDQHVDQGDPLFURQSUH¿OWHU

OPTIONAL ACCESSORIES (ORDER ONLY IF REQUIRED)

SCT-108.004.2A 0.45 Micron, 47 mm Filter (100 per package)

SCT-108.004.2B 3UH¿OWHU0LQOLQH

SCT-108.004.2C Battery 6V 1.3 AH SLA type

* This products has been manufactured for us, the brand name may differ but we inform that the orgin is from U.S.A.

Success is getting what you want, happiness is wanting what you get

467

sales@scichemtech.com www.scichemtech.com

467

ScichemTech ® SCT - MINI & MAXI CONTROLLERS FOR THE PROCESS AND INDUSTRY

6FLFKHP7HFK±5'7HDPDOZD\VWKLQNDKHDGDQGSURYLGHWKHEHVWFRPSHWLWLYHVROXWLRQVIRURXUYDOXHGVFLHQWL¿FDQGLQGXVWULDOFXVWRPHUV6&7

0LQLDQG0D[L6HULHVRIS+2537'6$1'(&FRQWUROOHUVDUHGHVLJQHGDQGPDQXIDFWXUHGWRFRYHUDOOWKHFXVWRPHUV¶QHHGVLQDVLQJOHVLPSOH

instrument.

We have designed Mini-series with 45x91mm and Maxi series with 92x92mm, face opening dimensions respectively, both are panel mounted

types.

We are one of the few manufacturers who supply the suitable electrode (or) probe along with the controllers. All the controllers have clear LED digital

Display for the easy viewing. All our pH, and ORP probes are supplied with 10 meters cable, and EC & TDS probes are supplied with 5 meter cable.

+LJKHUOHQJWKFDEOHVXSWRWRPHWHUVDQGVXLWDEOHWUDQVPLWWHUVDUHDYDLODEOHXSRQUHTXHVW)XUWKHUPRUH,QDOORXU(&$1'7'6FRQWUROOHUVD

wide measurement range Low, Medium, High are made possible in the same controller, No need to buy three different controllers( just with a small

knob, customer can shift to their modes on the rear panel)

All the SCT sensors and Probes are made in house precisely to withstand any adverse environmental conditions. They are very accurate in measuring

and easy and simple to maintain with a long life.

Our controllers are designed to suit many water related environmental applications like, Reverse Osmosis, Swimming pools, Hydroponics, Fisheries,

Agricultural, Food & Diary Industries, and Waste water Treatment Plants, Paper , Textile industries and Chemical Industries and many more, where

all pH, ORP, EC & TDS are need to be monitored and controlled precisely.

SCT pH MINI CONTROLLERS

SALIENT FEATURES:

 SCT –pH MINI online pH controller is an accurate instrument used for Industrial online measurement

and pH control

 Simple and compact design

 Meets all the international standards

 Easy to Install , Operates safely with less maintanence

 Output – Insulated 4- 20 mA

 Large and Clear LCD Display

 In line measurement and control of pH values

 pH electrode Supplied with standard 10 meter cable

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.005.01

SCT MODEL NO SCT-pH-MINI

Measurement range 0.00~14.00pH

Resolution ratio 0.02 pH

Accuracy ±0.1pH

Display òGLJLWDSKHOLRWURSLFOLTXLGFU\VWDOGLVSOD\

Calibration mode WKUHHSRLQWFDOLEUDWLRQDXWRPDWLFLGHQWL¿FDWLRQRIVROXWLRQV

Manual temperature compensation 0~80OC

Temperature of measured solutions 0~80OC

Compression resistance of electrodes 0~0.6MPa

Measurement distance VWDQGDUGFRQ¿JXUDWLRQPP

Output current LQVXODWHGaP$ȍ

Control output maximum and minimum (constantly open) contact point output

Capacity of contact points 3A/AC250V (with resistant loads)

Power supply AC 220V~240V 60Hz

Environmental conditions Temp : 0 to 50O&+XPLGLW\

External dimensions îîPPKHLJKWîZLGWKîGHSWK

Face Opening îPP

Installation Method panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.01 SCT-pH-MINI SCT pH MINI CONTROLLER IS SUPPLIED WITH pH PROBE, FIXATION CLAMPS AND

INSTRUCTION MANUAL

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED)

SCT-108.005.01A pH probe with 10 meter cable

SCT-108.002.AA pH 4.00 Buffer solution - 500ml

SCT-108.002.AG pH 7.00 Buffer solution - 500ml

SCT-108.002.AM pH 10.01 Buffer solution – 500ml

SCT-108.002.CA Electrode Storage solution – 500ml

SCT-108.005.01B Mounting clamps

Success is more a function of consistent common sense than it is of genius

468 sales@scichemtech.com www.scichemtech.com

468

SCT ORP (OXIDATION REDUCTION POTENTIAL) MINI CONTROLLER

SALIENT FEATURES:

 SCT –ORP MINI online ORP controller is an Industrial online analysis and monitoring

instruments

 Simple and Compact design

 Meets all the International Standards

 Easy to Install, Operates safety with less maintenance.

 ORP Electrode Supplied with standard 10 meter cable,

Measurement up to 40 meters.

 Large and clear display for easy reading

 Inline measurement and control of ORP values

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.005.02

SCT MODEL NO SCT-ORP-MINI

SCT PRODUCT NO SCT-108.005.02

SCT MODEL NO SCT-ORP-MINI

ORP measuring range ±1000mV

Resolution ±2mV

Accuracy ±2mV

Display òGLJLWDSKHOLRWURSLFOLTXLGFU\VWDOGLVSOD\

Pressure resistance of the electrode 0~0.6MPa

Power supply AC 220V±10% 50Hz

Measuring distance no larger than 40m

VWDQGDUGFRQ¿JXUDWLRQRIHOHFWURGHFDEOHLVP

Contact capacity 3A/AC 250V (resistive load)

Temperature of measured solution 0~80OC

Environmental conditions Temp : 0 to 50O&+XPLGLW\

Overall dimension îîPPKHLJKWîZLGWKîGHSWK

Opening of dial plate îPP

Installation method panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.02 SCT-ORP-MINI SCT ORP MINI CONTROLLER IS SUPPLIED WITH ORP PROBE, FIXATION CLAMPS AND

INSTRUCTION MANUAL

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED)

SCT-108.005.02A ORP probe with 10 meter cable

SCT-108.002.DA 222mV ORP Standard Solution -250ML

SCT-108.002.CA Electrode Storage solution – 500ml

SCT-108.005.02B Mounting clamps

SCT CONDUCTIVITY MINI CONTROLLERS

SALIENT FEATURES:

 SCT – EC MINI online Conductivity controller is an panel Instrument for online monitoring of

Industrial process conductivity

 Simple and compact design

 Three ranges of conductivity measurements in on single controller

 Range switch over and constant check can be easily adjusted from the rear panel.

 8QLTXHVLJQDOFROOHFWLQJDQGSURFHVVLQJWHFKQRORJ\

 6SHFLDOWKLQN¿OPFLUFXLWIRUDFFXUDWHPHDVXUHPHQWDQGVWDEOHRSHUDWLRQV

 Linearized data and automatic temperature compensations.

 In line measurement and control of conductivity.

 Conductivity electrode is supplied with 5 meter cable.

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.005.03

SCT MODEL NO SCT-EC-MINI

Measuring range aaaȝ6FP

Display OLTXLGFU\VWDOGLVSOD\ZLWKòELW/&'6HJPHQWFRGH

Accuracy 1.5% (FS)

Stability î)6K

Work pressure 0~0.5MPa

Media temperature 0~50OC

ne monitorin

6XFFHVVLVQRWÀQDOIDLOXUHLVQRWIDWDOLWLVWKHFRXUDJHWRFRQWLQXHWKDWFRXQWV

469

sales@scichemtech.com www.scichemtech.com

469

Temperature compensation with 25OC as the reference point, digital compensation

Output current isolation of 4~20mA active output

Optional electrode FPƎSLSHWKUHDG

Cable length 5m in normal condition

Environment condition temperature: 0~50O&KXPLGLW\5+

Power supply AC 220V±10% 50Hz

Overall dimension îîPPKHLJKW[ZLGWK[GHSWK

Face opening îPP

Installation method panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.03 SCT-EC-MINI SCT EC MINI CONTROLLER IS SUPPLIED WITH CONDUCTIVITY PROBE, FIXATION CLAMPS AND

INSTRUCTION MANUAL.

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED)

SCT-108.005.03A Conductivity probe with 5 meter cable

SCT-108.002.BA 84 μS/cm conductivity standard solution 500ml

SCT-108.002.BD 1413 μS/cm conductivity standard solution 500ml

SCT-108.005.03B Mounting clamps

SCT TDS (TOTAL DISSOLVED / SOLIDS) MINI CONTROLLERS

SALIENT FEATURES:

 SCT –TDS MINI online TDS controller is an panel Instrument for online monitoring of Industrial

process conductivity

 Simple and compact design

 Three ranges of TDS measurements in on single controller

 Range switch over and constant check can be easily adjusted from the rear panel.

 8QLTXHVLJQDOFROOHFWLQJDQGSURFHVVLQJWHFKQRORJ\

 6SHFLDOWKLQN¿OPFLUFXLWIRUDFFXUDWHPHDVXUHPHQWDQGVWDEOHRSHUDWLRQV

 Linearized data and automatic temperature compensations.

 In line measurement and control of TDS.

 TDS Electrode is supplied with 5 meter cable

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO SCT-108.005.04

SCT MODEL NO SCT-TDS-MINI

Measuring range 0~20, 0~200, 0~2000 ppm

Display /LTXLGFU\VWDOGLVSOD\ZLWKòELW/&'VHJPHQWFRGH

Accuracy 1.5% (Fs)

Stability î)VK

Work pressure 0~0.5mpa

Media temperature 0~50OC

Temperature compensation With 25OC as the reference point, digital compensation

Output current Isolation of 4~20ma active output

Optional electrode FPƎSLSHWKUHDG

Cable length 5m in normal condition

Environment condition Temperature: 0~50O&KXPLGLW\UK

Power supply AC 220v±10% 50hz

Overall dimension îîPPKHLJKW[ZLGWK[GHSWK

Face opening îPP

Installation method Panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.04 SCT-TDS-MINI SCT TDS MINI CONTROLLER IS SUPPLIED WITH TDS PROBE, FIXATION CLAMPS AND

INSTRUCTION MANUAL.

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED)

SCT-108.005.04A TDS probe with 5 meter cable

SCT-108.002.BA 84 μS/cm conductivity standard solution 500ml

SCT-108.002.BD 1413 μS/cm conductivity standard solution 500ml

SCT-108.005.04B Mounting clamps

panel.

Success is often achieved by those who don’t know that failure is inevitable.

470 sales@scichemtech.com www.scichemtech.com

470

SCT pH MINI VERTICAL CONTROLLERS

SALIENT FEATURES:

Ɣ SCT–pHMINIVERTICALonlinepHcontrollerisanaccurateinstrumentusedforIndustrial

onlinemeasurementandpHcontrol

Ɣ Simpleandcompactdesign

Ɣ Meetsalltheinternationalstandards

Ɣ EasytoInstall,Operatessafelywithlessmaintenance

Ɣ Output–Insulated4-20mA

Ɣ LargeandClearLCDDisplay

Ɣ InlinemeasurementandcontrolofpHvalues

Ɣ pHelectrodeSuppliedwithstandard10metercable

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.005.06

SCT MODEL NO SCT-PH-MINI-V

Measurementrange 0.00~14.00pH

Resolutionratio 0.02pH

Accuracy ±0.1pH

Display 31/2-DIG,7$PHELIOTROP,&/,QU,'&5Y67$/

DISPLAY

Calibrationmode THREE-P2,17&$/,B5$7,21(AU720$7,&

IDENTIF,&$7,212F62/UTIONS)

Manualtemperaturecompensation 0~80OC

Temperatureofmeasuredsolutions 0~80OC

Compressionresistanceofelectrodes 0~0.6MPA

Measurementdistance 67$1'$5'&21FIGU5$7,2110MM)

OutputcurrentINSU/$7('4~20MAȍ

Controloutput MAXIMU0$1'0,1,0U0(CONSTANTLY2PEN)

&217$&7P2,172UTPUT

Capacityofcontactpoints $$&9(W,7+5(6,67$17/2$'6)

Powersupply AC220V~240V60HZ

EnvironmentalconditionsTEMP072OCHUMIDITY:

Externaldimensions îî00(HEIGHT×:,'7+×DEPTH)

FaceOpening 42×73MM

InstallationMethod PANEL-MOUNTED

ORDERING INFORMATIONS:

6&7 SCT-PH-MINI-V SCTpHMINIVERTICALCONTROLLERISSUPPLIED:ITHpH3ROBE,)IXATIONCLAMPS,

ZINSTRUCTIONMANUAL



OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED)

6&7$ pHprobewith10metercable

SCT-108.002.AA pH4.00%uffersolution-PO

SCT-108.002.AG pH7.00%uffersolution-PO

SCT-108.002.AM pH10.01%uffersolution–PO

SCT-108.002.CA ElectrodeStoragesolution–PO

6&7B Mountingclamps

SCT ORP (OXIDATION REDUCTION POTENTIAL) MINI VERTICAL CONTROLLER

SALIENT FEATURES:

Ɣ 6&7±253MINIVERTICALonlineOR3controllerisanIndustrialonlineanalysisandmonitoring

instruments

Ɣ 6LPSOHandCompactdesign

Ɣ0HHWValltheInternationalStandards

Ɣ (DV\toInstall,Operatessafetywithlessmaintenance.

Ɣ253ElectrodeSuppliedwithstandard10metercable,

 0HDVXUHPHQWupto40meters.

Ɣ /DUJHandcleardisplayforeasyreading

Ɣ ,QOLQHmeasurementandcontrolofOR3values

TICAL

CONTROLLER

The good thing about science is that it’s true whether or not you believe in it

471

sales@scichemtech.com www.scichemtech.com

471

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.005.07

SCT MODEL NO SCT- ORP-MINI-V

ORP measuring range ±1000mV

Resolution ±2mV

Accuracy ±2mV

Display 3 1/2-digit apheliotropic liquid crystal display

Pressure resistance of the electrode 0~0.6MPa

Power supply AC 220V~240V 60Hz

Measuring distance no larger than 40m

(standard FRQ¿JXUDWLRQ of electrode cable is 10m)

Contact capacity 3A/AC 250V (resistive load)

Temperature of measured solution 0~80OC

Environmental conditions Temp 0 to 50OC Humidity: 

External dimensions 80×50×95MM (Height× Width× Depth)

Face Opening 42×73MM

Installation Method Panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.07 SCT-ORP-MINI-V SCT ORP MINI VERTICAL CONTROLLER IS SUPPLIED WITH ORP PROBE,

FIXATION CLAMPS, INSTRUCTION MANUAL

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED):

SCT-108.005.07A ORP probe with 10 meter cable

SCT-108.002.DA 222MV ORP Standard Solution -250ML

SCT-108.002.CA Electrode Storage solution – 500ml

SCT-108.005.07B Mounting clamps

SCT CONDUCTIVITY MINI VERTICAL CONTROLLERS

SALIENT FEATURES:

Ɣ 6&7 – EC MINI VERTICAL online Conductivity controller is an panel Instrument for online

monitoring of Industrial process conductivity

Ɣ 6LPSOH and compact design

Ɣ 7KUHH ranges of conductivity measurements in on single controller

Ɣ Range switch over and constant check can be easily adjusted from the rear panel.

Ɣ Unique signal collecting and processing technology.

Ɣ Special think ¿OP circuit for accurate measurement and stable operations.

Ɣ Linearized data and automatic temperature compensations.

Ɣ In line measurement and control of conductivity.

Ɣ Conductivity electrode is supplied with 10 meter cable.

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.005.08

SCT MODEL NO SCT-EC-MINI-V

Measuring range 0~20, 0~200, 0~2000 ȝ6FP

Display liquid-crystal display with 31/2 bit LCD Segment code

Accuracy  (FS)

Stability +/-2×10-3(FS)/24h

Work pressure 0~0.5MPa

Media temperature 0~50OC

Temperature compensation with 25OC as the reference point, digital compensation

Output current isolation of 4~20mA active output

Optional electrode 1.0cm-1 ƎSLSH thread

Cable length 10m in normal condition

Environment condition Temp: 0~50OC; humidity: 5+

Power supply AC 220V~240V 60Hz

External dimensions 80×50×95MM (Height× Width× Depth)

Face Opening 42×73MM

Installation Method Panel-mounted

3URJUHVVDOZD\VLQYROYHVULVNV<RXFDQ·WVWHDOVHFRQGEDVHDQGNHHS\RXUIRRWRQÀUVW

472 sales@scichemtech.com www.scichemtech.com

472

ORDERING INFORMATIONS:

SCT-108.005.08 SCT-EC-MINI-V SCT EC MINI VERTICAL CONTROLLER IS SUPPLIED WITH CONDUCTIVITY PROBE,

FIXATION CLAMPS, INSTRUCTION MANUAL

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED):

SCT-108.005.08A Conductivity probe with 10 meter cable

SCT-108.002.BA 84 uS/cm conductivity standard solution 500ml

SCT-108.002.BD 1413 uS/cm conductivity standard solution 500ml

SCT-108.005.08B Mounting clamps

SCT TDS (TOTAL DISSOLVED / SOLIDS) MINI CONTROLLERS

SALIENT FEATURES:

Ɣ 6&7 –TDS MINI online TDS controller is an panel Instrument for online monitoring of Industrial

process conductivity

Ɣ 6LPSOH and compact design

Ɣ 7KUHH ranges of TDS measurements in on single controller

Ɣ 5DQJH switch over and constant check can be easily adjusted from the rear panel.

Ɣ Unique signal collecting and processing technology.

Ɣ 6SHFLDO thin ¿OP circuit for accurate measurement and stable operations.

Ɣ /LQHDUL]HG data and automatic temperature compensations.

Ɣ ,Q line measurement and control of TDS.

Ɣ 7'6 Electrode is supplied with 10 meter cable

PRODUCT NO SCT-108.005.09

SCT MODEL NO SCT-TDS-MINI-V

Measuring range 0~20, 0~200, 0~2000 ppm

Display liquid-crystal display with 31/2 bit LCD Segment code

Accuracy 1.5% (FS)

Stability +/-2×10-3(FS)/24h

Work pressure 0~0.5MPa

Media temperature 0~50OC

Temperature compensation with 25OC as the reference point, digital compensation

Output current isolation of 4~20mA active output

Optional electrode 1.0cm-1 ƎSLSH thread

Cable length 10m in normal condition

Environment condition Temp: 0~50OC; humidity: 5+

Power supply AC 220V~240V +]

External dimensions 80×50×95MM (Height× Width× Depth)

Face Opening 42×73MM

Installation Method Panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.09 SCT-TDS-MINI-V SCT TDS MINI VERTICAL CONTROLLER IS SUPPLIED WITH TDS PROBE, FIXATION

CLAMPS, INSTRUCTION MANUAL

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED)

SCT-108.005.09A TDS probe with 10 meter cable

SCT-108.002.BA 84 uS/cm conductivity standard solution 500ml

SCT-108.002.BD 1413 uS/cm conductivity standard solution 500ml

SCT-108.005.09B Mounting clamps

The good times of today, are the sad thoughts of tomorrow.

473

sales@scichemtech.com www.scichemtech.com

473

SCT CONDUCTIVITY MINI-HR VERTICAL CONTROLLER (HIGH RANGE)

SALIENT FEATURES:

Ɣ SCT-ECMINI-HRVERTICALConductivitycontrollerisanpanelInstrumentforonlinemonitoring

ofIndustrialprocessconductivity

Ɣ Simpleandcompactdesign

Ɣ Highrangeofconductivitymeasurements&controller

Ɣ Uniquesignalcollectingandprocessingtechnology.

Ɣ Specialthin¿OPcircuitforaccuratemeasurementandstableoperations.

Ɣ Linearizeddataandautomatictemperaturecompensations.

Ɣ Inlinemeasurementandcontrolofconductivity.

Ɣ Conductivityelectrodeissuppliedwith10metercable.

TECHNICAL SPECIFICATIONS:

PRODUCT NO SCT-108.005.10

SCT MODEL NO SCT-EC-MINI-HR-V

Measuringrange 0~19.99mS/cm

Display liquid-crystaldisplaywith31/2bitLCDSegmentcode

Accuracy 1.5%(FS)

Stability +/-2×10-3(FS)/24h

Workpressure 0~0.5MPa

Mediatemperature 0~50OC

Temperaturecompensation with25OCasthereferencepoint,digitalcompensation

Outputcurrent isolationof4~20mAactiveoutput

Optionalelectrode 1.0cm-1ƎSLSHthread

Cablelength 10minnormalcondition

Environmentcondition Temp:0~50OC;humidity:5+

Powersupply AC220V~240V60Hz

Externaldimensions îî00(Height×:idth×Depth)

FaceOpening 42×73MM

InstallationMethod Panel-mounted





ORDERING INFORMATIONS:

6&7 SCT-EC-MINI-HR-V SCTECMINIHIGHRANGEVERTICALCONTROLLERISSUPPLIED:ITH

CONDUCTIVIT<3ROBE,)IXATIONCLAMPS,INSTRUCTIONMANUAL



OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED)

6&7$ Conductivityprobewith10metercable

6&7BA uS/cmconductivitystandardsolution500ml

6&7BD 1413uS/cmconductivitystandardsolution500ml

6&7B Mountingclamps



Put your heart, mind, and soul into even your smallest acts. This is the secret of success.

474 sales@scichemtech.com www.scichemtech.com

474

SCT- pH (POTENTIAL OF HYDROXIDE ) MAXI CONTROLLERS

SALIENT FEATURES:

Ɣ 6&7S+SRWHQWLDORI+\GUR[LGH0$;,&21752//(56 DUHGHVLJQHGZLWK FUHDWLYHQHVVWRJHW

WKHHOHJDQFHDQGSURGXFHGZLWKSURSHUTXDOLW\DQGPHHWVWKHVSHFL¿FDWLRQVIRUWKH:DWHUUHODWHG

applications with high level performance .

Ɣ 6&7S+SRWHQWLDORI+\GUR[LGH0$;,&21752//(56DUHVXSSOLHGZLWKWKHVXLWDEOHHOHFWURGH

with SCT standard 10 meters cable.(new series).

Ɣ 6&7 S+ SRWHQWLDO RI +\GUR[LGH 0$;, &21752//(56 DUH DQ LQGXVWULDO LQVWUXPHQW XVHG IRU

online analysis and monitoring.

Ɣ 6&7S+SRWHQWLDORI+\GUR[LGH0$;,&21752//(56DUHPDGHLQDDWWUDFWLYHSOHDVDQWFRORXU

with a Large and Clear blue white LCD Display

Ɣ 6&7S+SRWHQWLDORI+\GUR[LGH0$;,&21752//(56DUH0LFURSURFHVVRUEDVHGFRQWUROOHUV

which gives stable and accurate readings.

Ɣ 6&7 S+ SRWHQWLDO RI +\GUR[LGH 0$;, &21752//(56  XVHV /RZ SRZHU FRQVXPSWLRQ DQG

produces less internal heat.

Ɣ 6&7 S+ SRWHQWLDO RI +\GUR[LGH 0$;, &21752//(56   KDV DQ LVRODWHG  P$ FXUUHQW

output.

Ɣ 6&7S+SRWHQWLDORI+\GUR[LGH0$;,&21752//(56SURYHGWRZRUNFRQWLQXRXVO\LQDQ\KDUVK

environmental conditions for the In line measurement and control of accurate pH value and it give

the direct measurement and readings.

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO SCT-108.005.11

SCT MODEL NO SCT-pH-MAXI

Measurement range 0.00~14.00 pH

Accuracy ±0.1 pH

Display mode 3½ bit LCD with BACKLIGHT

pH calibration method Three-points calibration

pH temperature compensation Manual compensation with 25OC as the benchmark

Output current Isolate the active output of 4~20mA.

Output control Dual-contact output with both higher and lower limits

(normally open and normally-close respectively)

Contact capacity 7A/250V AC (resistive load)

Length of the cable 10 m

Screw size 3/4” pipe thread

5HTXLUHPHQWVRQZDWHUVDPSOHV 3UHVVXUH03D)ORZUDWHPV

Power supply AC 220V±10%; 50Hz

Environmental conditions Temperature: 0~50O&+XPLGLW\5+

Overall dimension 96x96x120mm (Height x Width x Depth)

Face Opening 92x92mm

Installation method Panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.11 SCT-pH-MAXI SCT pH MAXI CONTROLLER IS SUPPLIED WITH pH SENSOR, FIXATION CLAMPS AND

INSTRUCTION MANUAL

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED):

SCT-108.005.11A pH probe with 10 meter cable

SCT-108.002.AA pH 4.00 Buffer solution - 500ml

SCT-108.002.AG pH 7.00 Buffer solution - 500ml

SCT-108.002.AM pH 10.01 Buffer solution – 500ml

SCT-108.002.CA Electrode Storage solution – 500ml

SCT-108.005.11B Mounting clamps

SCT ORP (OXIDATION REDUCTION POTENTIAL) MAXI CONTROLLERS

SALIENT FEATURES:

Ɣ 6&72532[LGDWLRQ5HGXFWLRQ3RWHQWLDO0$;,&21752//(56DUHGHVLJQHGZLWKFUHDWLYHQHVV

WRJHWWKHHOHJDQFHDQGSURGXFHGZLWKSURSHUTXDOLW\DQGPHHWVWKHVSHFL¿FDWLRQVIRUWKH:DWHU

related applications with high level performance.

Ɣ 6&72532[LGDWLRQ5HGXFWLRQ3RWHQWLDO0$;,&21752//(56DUHVXSSOLHGZLWKWKHVXLWDEOH

electrode with SCT standard 10 meters cable.(new series).

Ɣ 6&7253 2[LGDWLRQ 5HGXFWLRQ 3RWHQWLDO 0$;, &21752//(56 DUH DQ LQGXVWULDO LQVWUXPHQW

used for online analysis and monitoring.

Ɣ 6&7253 2[LGDWLRQ 5HGXFWLRQ 3RWHQWLDO 0$;, &21752//(56  DUH PDGH LQ D DWWUDFWLYH

pleasant colour with a Large and Clear blue white LCD Display

Ɣ 6&7253 2[LGDWLRQ 5HGXFWLRQ 3RWHQWLDO 0$;, &21752//(56  DUH  0LFURSURFHVVRU EDVHG

controllers, which gives stable and accurate readings.

Ɣ 6&72532[LGDWLRQ5HGXFWLRQ3RWHQWLDO0$;,&21752//(56XVHV/RZSRZHUFRQVXPSWLRQ

and produces less internal heat.

Ɣ 6&72532[LGDWLRQ5HGXFWLRQ3RWHQWLDO0$;,&21752//(56KDVDQLVRODWHGP$FXUUHQW

output.

Ɣ 6&7253 2[LGDWLRQ 5HGXFWLRQ 3RWHQWLDO 0$;, &21752//(56 SURYHG WR ZRUN FRQWLQXRXVO\

in any harsh environmental conditions for the In line measurement and control of accurate ORP

value and it give the the direct measurement and readings .



PSWLR

DQ\

e and it

ive

Success is the child of audacity

475

sales@scichemtech.com www.scichemtech.com

475

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO SCT-108.005.12

SCT MODEL NO SCT-ORP-MAXI

Measurement range -1000~ +1000 mV

Accuracy ±2mV

Display mode 3½ bit LCD with BACKLIGHT

Output current Isolate the active output of 4~20mA.

Dual-contact output with both higher and lower limits (normally-

Output control open and normally-close respectively)

Contact capacity 7A/250V AC (resistive load)

Length of the cable 10m

Screw size 3/4” pipe thread

5HTXLUHPHQWVRQZDWHU

samples

SUHVVXUH03D

)ORZUDWHPV

Power supply AC 220V±10%; 50Hz

Environmental conditions Temperature: 0~50O&+XPLGLW\5+

Overall dimension 96x96x120mm (Height x Width x Depth)

Face Opening 92x92mm

Installation method Panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.12 SCT-ORP-MAXI SCT ORP MAXI CONTROLLER IS SUPPLIED WITH ORP SENSOR, FIXATION CLAMP AND

INSTRUCTION MANUAL

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED):

SCT-108.005.12A ORP probe with 10 meter cable

SCT-108.002.DA 222mV ORP Standard Solution -250ML

SCT-108.002.CA Electrode Storage solution – 500ml

SCT-108.005.12B Mounting clamps

SCT-108.002.CA Electrode Storage solution – 500ml

SCT-EC (ELECTRICAL CONDUCTIVITY) MAXI CONTROLLERS

SALIENT FEATURES:

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;, &21752//(56 DUH GHVLJQHG ZLWK FUHDWLYHQHVV WR JHW

WKHHOHJDQFHDQGSURGXFHGZLWKSURSHUTXDOLW\DQGPHHWVWKHVSHFL¿FDWLRQVIRUWKH:DWHUUHODWHG

applications with high level performance .

Ɣ 6&7(&(OHFWULFDO&RQGXFWLYLW\0$;,&21752//(56DUHVXSSOLHGZLWKWKHVXLWDEOHHOHFWURGH

with SCT standard 10 meters cable.(new series). 3 ranges of EC can be adjusted in a single

controller and the ranges can be switched easily.

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;, &21752//(56 DUH DQ LQGXVWULDO LQVWUXPHQW XVHG IRU

online analysis and monitoring.

Ɣ 6&7(&(OHFWULFDO&RQGXFWLYLW\0$;,&21752//(56DUHPDGHLQDDWWUDFWLYHSOHDVDQWFRORXU

with a Large and Clear blue white LCD Display

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;, &21752//(56 DUH 0LFURSURFHVVRU EDVHG FRQWUROOHUV

which gives stable and accurate readings.

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;, &21752//(56 XVHV /RZ SRZHU FRQVXPSWLRQ DQG

produces less internal heat.

Ɣ 6&7(&(OHFWULFDO&RQGXFWLYLW\0$;,&21752//(56KDVDQLVRODWHGP$FXUUHQWRXWSXW

Ɣ 6&7(&(OHFWULFDO&RQGXFWLYLW\0$;,&21752//(56SURYHGWRZRUNFRQWLQXRXVO\LQDQ\KDUVK

environmental conditions for the In line measurement and control of accurate EC value and it give

the direct measurement and readings.

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO SCT-108.005.13

SCT MODEL NO SCT-EC-MAXI

Measuring range (three-grade range,

keyboard selection) aaaȝVFP

Display method /LTXLGFU\VWDOGLVSOD\ZLWKòELW/&'VHJPHQWFRGH

Accuracy 1.5% (FS)

Stability î)6K

Work pressure 0~0.5mpa

Media temperature 0~50OC

Temperature compensation With 25OC as the reference point, digital compensation

Output current Isolation of 4~20ma active output

Control output Double contacts output of high limit (normally open) and

low limit (normally closed

Contact capacity 7A/250C ac (with resistance load)

Optional electrode 1.0cm-1 metal electrode

Cable length 5m in normal condition

Environment conditions Temperature: 0~50O&KXPLGLW\UK

Power supply AC 220v±10% 50hz

Overall dimension îîPPKHLJKW[ZLGWK[GHSWK

Face opening îPP

Installation method Panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.13 SCT-EC-MAXI SCT CONDUCTIVITY MAXI CONTROLLER IS SUPPLIED WITH CONDUCTIVITY

SENSOR, FIXATION CLAMPS AND INSTRUCTION MANUAL

Success is the result of perfection, hard work, learning from failure, loyalty, and persistence.

476 sales@scichemtech.com www.scichemtech.com

476

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED):

SCT-108.005.13A Conductivity probe with 5 meter cable

SCT-108.002.BA 84 μS/cm conductivity standard solution 500ml

SCT-108.002.BD 1413 μS/cm conductivity standard solution 500ml

SCT-108.005.13B Mounting clamps

SCT- TDS (TOTAL DISSOLVED SOLIDS) MAXI CONTROLLERS

SALIENT FEATURES:

Ɣ 6&77'67RWDO'LVVROYHG6ROLGV0$;,&21752//(56DUHGHVLJQHGZLWKFUHDWLYHQHVVWRJHW

WKHHOHJDQFHDQGSURGXFHGZLWKSURSHUTXDOLW\DQGPHHWVWKHVSHFL¿FDWLRQVIRUWKH:DWHUUHODWHG

applications with high level performance .

Ɣ 6&77'67RWDO'LVVROYHG6ROLGV0$;,&21752//(56DUHVXSSOLHGZLWKWKHVXLWDEOHHOHFWURGH

with SCT standard 10 meters cable.(new series).

Ɣ 6&77'67RWDO'LVVROYHG6ROLGV0$;,&21752//(56DUHDQLQGXVWULDOLQVWUXPHQWXVHGIRU

online analysis and monitoring.

Ɣ 6&7 7'6 7RWDO 'LVVROYHG 6ROLGV 0$;, &21752//(56  DUH  PDGH LQ D DWWUDFWLYH SOHDVDQW

colour with a Large and Clear blue white LCD Display

Ɣ 6&77'67RWDO'LVVROYHG6ROLGV0$;,&21752//(56DUH0LFURSURFHVVRUEDVHGFRQWUROOHUV

which gives stable and accurate readings.

Ɣ 6&77'67RWDO'LVVROYHG6ROLGV0$;,&21752//(56XVHV/RZSRZHUFRQVXPSWLRQDQG

produces less internal heat.

Ɣ 6&7 7'6 7RWDO 'LVVROYHG 6ROLGV 0$;, &21752//(56  KDV DQ LVRODWHG  P$ FXUUHQW

output.

Ɣ 6&77'67RWDO'LVVROYHG6ROLGV0$;,&21752//(56SURYHGWRZRUNFRQWLQXRXVO\LQDQ\

harsh environmental conditions for the In line measurement and control of accurate TDS value

and it give the direct measurement and readings .

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO SCT-108.005.14

SCT MODEL NO SCT-TDS-MAXI

Measuring range (three-grade range,

keyboard selection) 0~19.99, 0~199.9, 0~1999 ppm

Display method OLTXLGFU\VWDOGLVSOD\ZLWKòELW/&'6HJPHQWFRGH

Accuracy 1.5% (FS)

Stability î)6K

Work pressure 0~0.5MPa

Media temperature 0~50OC

Temperature compensation with 25OC as the reference point, digital compensation

Output current isolation of 4~20mA active output

Control output double contacts output of high limit (normally open) and

low limit (normally closed

Contact capacity 7A/250V AC (with resistance load)

Optional electrode 1.0 cm-1 metal electrode

Cable length 5m in normal condition

Environment conditions Temperature: 0~50O&+XPLGLW\5+

Power supply AC 220V±10% 50Hz

Overall dimension îîPPKHLJKW[ZLGWK[GHSWK

Face opening îPP

Installation method panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.14 SCT-TDS-MAXI SCT TDS MAXI CONTROLLER SUPPLIED WITH TDS SENSOR, FIXATION CLAMP AND

INSTRUCTION MANUAL

* Please contact us for High Range (Upto 17500 ppm) TDS Controllers

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED)

SCT-108.005.14A TDS probe with 5 meter cable

SCT-108.002.BA 84 μS/cm conductivity standard solution 500ml

SCT-108.002.BD 1413 μS/cm conductivity standard solution 500ml

SCT-108.005.14B Mounting clamps

SCT CONDUCTIVITY MINI-HR CONTROLLER (HIGH RANGE)

SALIENT FEATURES:

 SCT –EC MINI-HR online Conductivity controller is an panel Instrument for online monitoring of

Industrial process conductivity

 Simple and compact design

 Three ranges of conductivity measurements in on single controller

 Range switch over and constant check can be easily adjusted from the rear panel.

 8QLTXHVLJQDOFROOHFWLQJDQGSURFHVVLQJWHFKQRORJ\

 6SHFLDOWKLQN¿OPFLUFXLWIRUDFFXUDWHPHDVXUHPHQWDQGVWDEOHRSHUDWLRQV

 Linearized data and automatic temperature compensations.

 In line measurement and control of conductivity.

 Conductivity electrode is supplied with 5 meter cable.

UV

DQ\

lue

Success is the sum of small efforts – repeated day in and day out.

477

sales@scichemtech.com www.scichemtech.com

477

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO SCT-108.005.05

SCT MODEL NO SCT-EC-MINI-HR

Measuring range: 0~19.99mS/cm

Display OLTXLGFU\VWDOGLVSOD\ZLWKòELW/&'6HJPHQWFRGH

Accuracy 1.5% (FS)

Stability î)6K

Work pressure 0~0.5MPa

Media temperature: 0~50OC

Temperature compensation: with 25OC as the reference point, digital compensation

Optional electrode: FPƎSLSHWKUHDG

Cable length: 5m in normal condition

Environment condition: temperature: 0~50O&KXPLGLW\5+

Power supply: AC 220V±10% 50Hz

Overall dimension: îîPPKHLJKW[ZLGWK[GHSWK

Face opening: îPP

Installation method: panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.05 SCT-EC-MINI-HR

SCT EC MINI-HR CONTROLLER IS SUPPLIED WITH CONDUCTIVITY PROBE, FIXATION CLAMPS & INSTRUCTION MANUAL.

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED)

SCT-108.005.05A Conductivity probe with 5 meter cable

SCT-108.002.BA 84 μS/cm conductivity standard solution 500ml

SCT-108.002.BD 1413 μS/cm conductivity standard solution 500ml

SCT-108.005.05B Mounting clamps

SCT-EC (ELECTRICAL CONDUCTIVITY) MAXI-HR (HIGH RANGE) CONTROLLERS

SALIENT FEATURES:

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;,+5 +LJK 5DQJH &21752//(56 DUH GHVLJQHG ZLWK

FUHDWLYHQHVVWRJHWWKHHOHJDQFHDQGSURGXFHGZLWKSURSHUTXDOLW\DQGPHHWVWKHVSHFL¿FDWLRQV

for the Water related applications with high level performance.

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;,+5 +LJK 5DQJH &21752//(56 DUH VXSSOLHG ZLWK

the suitable electrode with SCT standard 10 meters cable.(new series). 3 ranges of EC can be

adjusted in a single controller and the ranges can be switched easily.

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;,+5 +LJK 5DQJH &21752//(56 DUH DQ LQGXVWULDO

instrument used for online analysis and monitoring.

Ɣ 6&7(&(OHFWULFDO&RQGXFWLYLW\0$;,+5+LJK5DQJH&21752//(56DUHPDGHLQDDWWUDFWLYH

pleasant colour with a Large and Clear blue white LCD Display

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;,+5 +LJK 5DQJH &21752//(56 DUH 0LFURSURFHVVRU

based controllers, which gives stable and accurate readings.

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;,+5 +LJK 5DQJH &21752//(56 XVHV /RZ SRZHU

consumption and produces less internal heat.

Ɣ 6&7(&(OHFWULFDO&RQGXFWLYLW\0$;,+5+LJK5DQJH&21752//(56KDVDQLVRODWHG

mA current output.

Ɣ 6&7(& (OHFWULFDO &RQGXFWLYLW\ 0$;,+5 +LJK 5DQJH &21752//(56 SURYHG WR ZRUN

continuously in any harsh environmental conditions for the inline measurement and control of

accurate EC value and it give the direct measurement and readings.

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO SCT-108.005.15

SCT MODEL NO SCT-EC-MAXI -HR

Measuring range 0~19.99mS/cm

Display method /LTXLGFU\VWDOGLVSOD\ZLWKòELW/&'VHJPHQWFRGH

Accuracy 1.5% (FS)

Stability î)6K

Work pressure 0~0.5mpa

Media temperature 0~50OC

Temperature compensation With 25OC as the reference point, digital compensation

Output current Isolation of 4~20ma active output

Control output Double contacts output of high limit (normally open) & low limit (normally closed

Contact capacity 7A/250C ac (with resistance load)

Optional electrode 1.0cm-1 metal electrode

Cable length 5m in normal condition

Environment conditions Temperature: 0~50O&KXPLGLW\UK

Power supply AC 220v±10% 50hz

Overall dimension îîPPKHLJKW[ZLGWK[GHSWK

Face opening îPP

Installation method Panel-mounted

ORDERING INFORMATIONS:

SCT-108.005.15 SCT-EC-MAXI - HR SCT CONDUCTIVITY MAXI CONTROLLER IS SUPPLIED WITH CONDUCTIVITY

SENSOR, FIXATION CLAMPS AND INSTRUCTION MANUAL

OPTIONAL ACCESSORIES (SELECT ONLY IF REQUIRED):

SCT-108.005.15A Conductivity probe with 5 meter cable

SCT-108.002.BA 84 μS/cm conductivity standard solution 500ml

SCT-108.002.BD 1413 μS/cm conductivity standard solution 500ml

SCT-108.005.15B Mounting clamps

Success is walking from failure to failure with no loss of enthusiasm

478 sales@scichemtech.com www.scichemtech.com

478

SCT CHLORINE MAXI CONTROLLERS:

SALIENT FEATURES:

Ɣ SCT-CL (Chlorine) MAXI CONTROLLERS are designed with creativeness to get the

HOHJDQFHDQGSURGXFHGZLWKSURSHUTXDOLW\DQGPHHWVWKHVSHFL¿FDWLRQVIRUWKH:DWHU

related applications with high level performance

Ɣ 6&7&/&KORULQH0$;,FRQWUROOHUVDUHDQLQGXVWULDOLQVWUXPHQWXVHGIRURQOLQHDQDO\VLV

and monitoring.

Ɣ 6&7&/&KORULQH0$;,&21752//(56DUHPDGHLQDDWWUDFWLYHSOHDVDQWFRORXUZLWK

a Large and Clear blue white LCD Display

Ɣ 6&7&/&KORULQH0$;,&21752//(56KDV0LFURSURFHVVRUEDVHGFRQWUROOHUVZKLFK

gives stable and accurate readings.

Ɣ 6&7&/&KORULQH 0$;,&21752//(56KDV /RZSRZHUFRQVXPSWLRQDQG SURGXFHV

less internal heat.

Ɣ 6&7&/&KORULQH0$;,&21752//(56KDVDQLVRODWHGP$FXUUHQWRXWSXW

Ɣ 6&7&/&KORULQH0$;,&21752//(56KDVD56FRPPXQLFDWLRQLQWHUIDFH

Ɣ 6&7&/&KORULQH0$;,&21752//(56KDVDQDXWRPDWHGVHQVRUFOHDQLQJFRQWURORXW

put.

Ɣ 6&7&/ &KORULQH 0$;, &21752//(56 KDV D GLDSKUDJP SRODJUDSKLF HOHFWURGHV

The electrode consists of cathode, anode, electrolyte and a layer of gas permeability

diaphragm on the cathode. The measured residual chlorine diffuse to the cathode

through diaphragm. The proper polarization voltage between the cathode and the anode,

which can deoxidize the residual chlorine on the cathode. These chemical actions

proportional to the residual chlorine which is in the measured medium. which gives

reliable measurements.

Ɣ 6&7&/&KORULQH0$;,&21752//(56DUHSDQHOPRXQWW\SHRIFRQWUROOHUV

Ɣ 6&7&/&KORULQH 0$;, &21752//(56 SURYHG WR ZRUN FRQWLQXRXVO\ LQ DQ\ KDUVK

environmental conditions for the In line measurement and control of accurate CHLORINE

value.

Ɣ 6&7&/&KORULQH0$;,&21752//(56KDVDPDMRUDGYDQWDJHWKDWQRUHDJHQWVDUH

used.it has the direct measurement and readings.

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO SCT-108.005.26

SCT MODEL NO SCT-CL-MAXI

Measuring range 0.00 ~ 19.99mg / L

Resolution 0.01mg /L

Zero point calibration range 2.00mg / L

Slope of the calibration range 20% ~ 180%

Temperature compensation 0 ~ 45OC (automatic or manual)

Relay control range 0.00 to 19.99

Automatic cleaning time 1s ~ 99m59s

Cleaning interval 1 ~ 720min

Output signal 4 ~ 20mA

Sensor type Diaphragm polarographic sensor

Sensor cleaning automatic cleaning control output

Serial communication RS485 communication interface

Environmental conditions temperature 0~50OC

Humidity 5+

Overall dimension 96x96x120mm (Height x Width x Depth)

Dimension of the hole 92x92mm

Installation method panel-mounted

Power supply AC 220 / 240V 50 / 60Hz

ORDERING INFORMATIONS:

SCT-108.005.26 SCT-CL-MAXI SCT CHLORINE CONTROLLER SUPPLIED WITH CHLORINE SENSOR, FIXATION

CLAMP AND INSTRUCTION MANUAL

Success isnt just about what you accomplish in your life its about what you inspire others to do

479

sales@scichemtech.com www.scichemtech.com

479

SCT DISSOLVED OXYGEN MAXI CONTROLLERS

SALIENT FEATURES:

Ɣ 6&7'2GLVVROYHG 2[\JHQ 0$;, &21752//(56 DUH GHVLJQHG ZLWK FUHDWLYHQHVV WR JHW WKH

HOHJDQFH DQG SURGXFHG ZLWK SURSHU TXDOLW\ DQG PHHWV WKH VSHFL¿FDWLRQV IRU WKH :DWHU UHODWHG

applications with high level performance

Ɣ 6&7'2GLVVROYHG2[\JHQ0$;,&21752//(56DUHDQLQGXVWULDOLQVWUXPHQWXVHGIRURQOLQH

analysis and monitoring.

Ɣ 6&7'2GLVVROYHG2[\JHQ0$;,&21752//(56DUHPDGHLQDDWWUDFWLYHSOHDVDQWFRORXUZLWK

a Large and Clear blue white LCD Display

Ɣ 6&7'2GLVVROYHG2[\JHQ0$;,&21752//(56DUH0LFURSURFHVVRUEDVHGFRQWUROOHUVZKLFK

gives stable and accurate readings.

Ɣ 6&7'2GLVVROYHG2[\JHQ0$;,&21752//(56XVHV/RZSRZHUFRQVXPSWLRQDQGSURGXFHV

less internal heat.

Ɣ 6&7'2GLVVROYHG2[\JHQ0$;,&21752//(56DUHKDVWKHSRODJUDSKLFW\SH'2HOHFWURGH

This oxygen electrode is a diaphragm polarographic (clark) electrode. The conductibility electrolyte

makes the polarization between cathode and anode. Between the cathode and the anode, the

proper polarization voltage can deoxidize the O2 at the Cathode electrode.

Cathode reaction: O2+ 2H2O +4e -- 4OH-

Anode reaction : 4AG +4Cl- -- 4AgCl + 4e

These chemical reactions produce the current which is proportional to the O2 in the test solution.

Ɣ 6&7'2GLVVROYHG2[\JHQ0$;,&21752//(56KDVDQLVRODWHGP$FXUUHQWRXWSXW

Ɣ 6&7'2GLVVROYHG2[\JHQ0$;,&21752//(56DUHSDQHOPRXQWW\SHRIFRQWUROOHUV

Ɣ 6&7'2GLVVROYHG 2[\JHQ 0$;, &21752//(56 SURYHG WR ZRUN FRQWLQXRXVO\ LQ DQ\ KDUVK

environmental conditions for the In line measurement and control of accurate CHLORINE value.

Ɣ 6&7'2GLVVROYHG2[\JHQ0$;,&21752//(56KDVDPDMRUDGYDQWDJHWKDWQRUHDJHQWVDUH

used.it has the direct measurement and readings..

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO. SCT-108.005.31

SCT MODEL NO. SCT-DO-MAXI

Measuring range 0.00 ~ 19.99mg / L

Resolution 0.01mg / L

Temperature compensation 0.0 ~ 45.0OC (automatic or manual)

Output signal 4 ~ 20mA

Control output mode ON / OFF relay output contacts

Current output load PD[LPXPDOORZDEOHORDGRIȍ

Environmental conditions temperature 0~50OC

Humidity 5+

Overall dimension 96x96x120mm (Height x Width x Depth)

Dimension of the hole 92x92mm

Installation method panel-mounted

Power supply AC 220 / 240V 50 / 60Hz

ORDERING INFORMATIONS:

SCT-108.005.31 SCT-DO-MAXI SCT DISSOLVED OXYGEN CONTROLLER SUPPLIED WITH DO SENSOR, FIXATION CLAMP

AND INSTRUCTION MANUAL

Successful people ask better questions, and as a result, they get better answers.

480 sales@scichemtech.com www.scichemtech.com

480

SCT RED ROCK DOSING PUMPS

In order to support our customers who are using many of our process water controllers,Our research and development

has decided to develop the metering dosing pumps to deliver the precise accurate delivery of various process

FKHPLFDO OLTXLGV DQG VROXWLRQV7KH GHPDQG IRU WKH JRRG TXDOLW\ SXPSV KDYH LQFUHDVHG D ORW LQ WKH SDVW GHFDGH

GXHWRYDULRXVSURFHVVUHODWHGZDWHUSXUL¿FDWLRQVZDWHUWUHDWPHQWDQGYDULRXVGRVLQJDSSOLFDWLRQVVXFKDVUHDJHQW

GRVLQJLQPLQHUDOSURFHVVLQJGRVLQJGLVLQIHFWDQWVLQGULQNLQJZDWHUSXUL¿FDWLRQV3XUHZDWHUSUHSDUDWLRQVLQLQGXVWULDO

cooling applications and pH adjustment applications and other dosigs like polyacrylamide,bleaching & electroplating

chemicals and petro chemicals etc.,

7KH 6FLFKHP7HFK¶V ³5(' 52&.´ 'RVLQJ 3XPSV DUH GHVLJQHG WR PDWFK WKH UHTXLUHPHQWV RI YDULRXV LQWHUQDWLRQDO VWDQGDUGV2XU SXPSV DUH

manufactured as per the BS 7782-1996 standards to match various international customers needs.Our R & D designed these diaphragm metering

SXPSVWRGHOLYHUWKHYDULRXVFKHPLFDOVVROXWLRQVDQGRWKHUUHODWHGVROXWLRQVZLWKPD[LPXPGLVFKDUJHSUHVVXUHDQGDGMXVWDEOHÀRZUDWHVRIWKHPHGLD

(solutions) ,this makes our pumps could be used for various precise and general applications in the water , chemical and other industries.

In general, we have categorized our pumps in to two categories like ..simple and general dosing ,The SCT-SOFT series Solenoid diaphragm metering

dosing pumps which mainly caters the general dosing and simple applications . And the next one SCT-HARD series Electromagnetic diaphragm

PHWHULQJGRVLQJSXPSV ZLWKDXWRPDWLFFRQWURORI WKHÀRZUDWHRIWKH PHGLXP XVLQJWKHLUSXOVH VLJQDOV ZLWKWKHH[WHUQDO FRQWURO ,QWKLVVHULHVWKH

P$DQDORJVLJQDOVRXWSXWLVSRVVLEOHZLWKSURSHUÀRZFRQWURORIWKHOLTXLGIURP±%RWKWKHVHULHVZHKDYHPDGHWKHÀRZUDWHVIURP

/LWHUVKRXUPD[SUHVVXUHEDUWLOO/LWHUVKRXUSUHVVXUHRIEDU+RZHYHUZHFDQVXSSO\SXPSVZLWKÀRZUDWHXSWR/LWHUVKRXU

$OORXUSXPSVDUHPDGHDVSHU,3FRPSOHWHO\VHDOHGFODVVWRHQVXUHWKHXVHU¶VVDIHW\DVWKHSULRULW\$QGDOVRDOORXUSXPSVDUHVXSSOLHG

FRPSOHWHO\ZLWKWKHWXEHLQMHFWLRQYDOYHVIRRWYDOYHVDQGWKHVWUDLQHU,QWKHIROORZLQJSDJHV\RXZLOO¿QGWKHRWKHUVDOLHQWIHDWXUHVDQGWKHWHFKQLFDO

VSHFL¿FDWLRQVRIWKHDOORXU6&7³5('52&.´'RVLQJSXPSV

SCT RED ROCK SOFT SERIES SOLENOID DIAPHRAGM METERING DOSING PUMPS

SALIENT FEATURES:

Ɣ 6&7³5('52&.62)7´ 'RVLQJSXPSVDUHGHVLJQHGDQG PDQXIDFWXUHGDVSHU%6

and meets the international standards.

Ɣ 6&7 ³5(' 52&.62)7´ 'RVLQJ SXPSV KDYH 3URJUDPPDEOH KLJK SUHFLVLRQ PLFURSURFHVVRU

control with digital display and with suitable keys, for easy adjustment and operations.

Ɣ 6&7³5('52&.62)7´'RVLQJSXPSVKDYHWKHÀRZUDWHFRQWUROIURP/+WLOO/+ZLWK

to 1.0 bar respectively.

Ɣ 6&7 ³5(' 52&.62)7´ 'RVLQJ SXPSV DUH PDGH RI SRO\SURS\OHQH KRXVLQJ DQG 37)(

diaphargm

Ɣ 6&7³5('52&.62)7´'RVLQJSXPSVKDYHWKHSXPS¶VKHDGPDGHRIUHLQIRUFHG3RO\3URS\OHQH

as standard and other materials such as PVC,PVDF and 316 Stainless steel are available as an

optional in the SCT”RED ROCK-HARD” series in the following section.

Ɣ 6&7³5('52&.62)7´'RVLQJSXPSVDUHPDGHDVSHU,3VDIHW\UHJXODWLRQV

Ɣ 6&7³5('52&.62)7´'RVLQJSXPSVKDYHWKHVWURNHIUHTXHQF\IURPWRVWURNHVSHU

minute.

Ɣ 6&7 ³5(' 52&.62)7´ 'RVLQJ SXPSV DUH VXLWDEOH IRU DOO WKH JHQHUDO FKHPLFDO DQG ZDWHU

treatment solutions which is compatible with Polypropylene as a standard.

Ɣ 6&7³5('52&.62)7´'RVLQJSXPSVFDQEHHDVLO\PRXQWHGRQDQ\GRVLQJWDQNVRUFDQEH¿[HG

in any angle.

Ɣ 6&7³5('52&.62)7´'RVLQJSXPSZHLJKVWR.JVQHWXQSDFNHGDQGWKHDSSUR[LPDWH

dimensions of Height 190 – 200 mm x Width 105-110 mm x Length 190-200 mm.

Ɣ 6&7³5('52&.62)7´'RVLQJSXPSVFRQVXPHVWRZDWWVSRZHUDQGRSHUDWHVLQ

YROWV+]IUHTXHQF\

TECHNICAL SPECIFICATIONS / ORDERING INFORMATION : (PLS. REFER THE PRODUCT NUMBERS)

SCT PRODUCT

NO. Maximum Flow Rate

(Liters / Hour)

Maximum

Discharge

Pressure (Bars)

SCT Pump’s

suction diameter /

Caliber (mm)

SCT-Dosing

Pump’s frequency

(Strokes /Minute)

SCT-Dosing

Pump’s head

SCT Dosing

pumps - power

usage in watts

SCT-108.006.01 0.5 L /H 12 Bars 6 mm 160 RPP 35 watts

SCT-108.006.02 1.0 L/H 12 Bars 6 mm 160 RPP 35 watts

SCT-108.006.03 3.0 L/H 8.0 Bars 6 mm 200 RPP 46 watts

SCT-108.006.04 5.0 L/H 4.0 Bars 6 mm 200 RPP 46 watts

SCT-108.006.05 7.0 L/H 3.5 Bars 6 mm 200 RPP 46 watts

SCT-108.006.06 10 L/H 3.0 Bars 6 mm 200 RPP 46 watts

SCT-108.006.07 14 L/H 1.7 Bars 6 mm 200 RPP 50 watts

SCT-108.006.08 20 L/H 1.5 Bars 6 mm 200 RPP 50 watts

SCT-108.006.09 25 L/H 1.2 Bars 6 mm 200 RPP 50 watts

SCT-108.006.10 34 L/H 1.0 Bar 6 mm 200 RPP 50 watts

Ɣ $OOWKH6&75HG5RFNSXPSVDUHVXSSOLHGZLWKWKHWXEHLQMHFWLRQYDOYHIRRWYDOYHDQGVWUDLQHU

SCT

RED

ROCK

Take time to deliberate; but when the time for action arrives, stop thinking and go in

MPS

481

sales@scichemtech.com www.scichemtech.com

481

SCT “RED ROCK” HARD SERIES ELECTROMAGNETIC SOLENOID DIAPHRAGM METERING DOSING PUMPS

PUMPS.

SALIENT FEATURES:

Ɣ 6&7³5('52&.+$5'´'RVLQJSXPSVGHVLJQHGDQGPDQXIDFWXUHGDVSHU%6DQG

meets the international standards.

Ɣ 6&7 ³5(' 52&.+$5'´ 'RVLQJ SXPSV KDYH 3URJUDPPDEOH KLJK SUHFLVLRQ PLFURSURFHVVRU

control with digital display and with suitable keys, for easy adjustment and operations.

Ɣ 6&7³5('52&.+$5'´'RVLQJSXPSVKDYHWKHÀRZUDWHFRQWUROIURP/+WLOO/+ZLWK

to 1.0 bar respectively.

Ɣ 6&7³5(' 52&.+$5'´'RVLQJSXPSVFDQEH HDVLO\ PRXQWHG RQDQ\GRVLQJWDQNVRU FDQ EH

¿[HGLQDQ\DQJOH

Ɣ 6&7 ³5(' 52&.+$5'´ 'RVLQJ SXPSV DUH PDGH RI SRO\SURS\OHQH KRXVLQJ DQG 37)(

diaphargm

Ɣ 6&7 ³5(' 52&.+$5'´ 'RVLQJ SXPSV SXPSV KDYH WKH SXPS¶V KHDG PDGH RI UHLQIRUFHG

Poly Propylene as standard and other materials such as PVC,PVDF and 316 Stainless steel as

optional.

Ɣ 6&7³5('52&.+$5'´'RVLQJSXPSVDUHPDGHDVSHU,3VDIHW\UHJXODWLRQV

Ɣ 6&7³5('52&.+$5'´'RVLQJSXPSVKDYHWKHVWURNHIUHTXHQF\IURPWRVWURNHVSHU

minute.

Ɣ 6&7 ³5(' 52&.+$5'´ 'RVLQJ SXPSV DUH VXLWDEOH IRU DOO WKH JHQHUDO FKHPLFDO DQG ZDWHU

treatment solutions which is compatible with Polypropylene as a standard.

Ɣ 6&7³5('52&.+$5'´'RVLQJ SXPSVUHFHLYHWKH SXOVHVLJQDOWR FRQWUROWKHÀRZ UDWHRIWKH

pump outside automatically by external control joint (5 core)

Ɣ 6&7 ³5(' 52&.+$5'´ 'RVLQJ SXPSV PD\ UHFLYH  P$  P$ DQDORJXH VLJQDOV WR

FRQWURORUWKHÀRZUDWHRIWKHSXPSRXWVLGHDXWRPDWLFDOO\E\H[WHUQDOFRQWUROMRLQW

( 5 core)

Ɣ 6&7³5('52&.+$5'´'RVLQJSXPSVZLOODODUPDQGVWRSZRUNLQJZKHQRSWLRQDOFRQWUROIXQFWLRQ

RIWKHVZLWFKFRQQHFWHGWRWKHOHYHOVZLWFKHVLQWHUIDFHFRUHOLTXLGOHYHOLVWRRORZ

Ɣ 6&7³5('52&.+$5'´'RVLQJSXPSZHLJKVWR.JVQHWXQSDFNHGDQGWKHDSSUR[LPDWH

dimensions of Height 190 – 200 mm x Width 105-110 mm x Length 190-200 mm.

Ɣ 6&7³5('52&.+$5'´'RVLQJSXPSVFRQVXPHVWRZDWWVSRZHUDQGRSHUDWHVLQ

YROWV+]IUHTXHQF\

TECHNICAL SPECIFICATIONS / ORDERING INFORMATIONS (PLS. REFER THE PRODUCT NUMBERS)

SCT PRODUCT

NO.

SCT-Dosing

Pump’s

head

Maximum Flow

Rate (Liters /

Hour)

Maximum

Discharge

Pressure

(Bars)

SCT Pump’s

suction diameter

/ Caliber (mm)

Signal out

put for the

automatic

control

SCT-Dosing

Pump’s

frequency

(Strokes /Minute)

SCT-Dosing

Pump’s

head

SCT PRODUCT

NO. For pump’s

head made of

PVDF

SCT-108.006.21 RPP 0.5 L /H 12 Bars 6 mm 4-20 mA 160 PVDF SCT-108.006.41

SCT-108.006.22 RPP 1.0 L/H 12 Bars 6 mm 4-20 mA 160 PVDF SCT-108.006.42

SCT-108.006.23 RPP 3.0 L/H 8.0 Bars 6 mm 4-20 mA 200 PVDF SCT-108.006.43

SCT-108.006.24 RPP 5.0 L/H 4.0 Bars 6 mm 4-20 mA 200 PVDF SCT-108.006.44

SCT-108.006.25 RPP 7.0 L/H 3.5 Bars 6 mm 4-20 mA 200 PVDF SCT-108.006.45

SCT-108.006.26 RPP 10 L/H 3.0 Bars 6 mm 4-20 mA 200 PVDF SCT-108.006.46

SCT-108.006.27 RPP 14 L/H 1.7 Bars 6 mm 4-20 mA 200 PVDF SCT-108.006.47

SCT-108.006.28 RPP 20 L/H 1.5 Bars 6 mm 4-20 mA 200 PVDF SCT-108.006.48

SCT-108.006.29 RPP 25 L/H 1.2 Bars 6 mm 4-20 mA 200 PVDF SCT-108.006.49

SCT-108.006.30 RPP 34 L/H 1.0 Bar 6 mm 4-20 mA 200 PVDF SCT-108.006.50

Ɣ $OOWKH6&75HG5RFNSXPSVDUHVXSSOLHGZLWKWKHWXEHLQMHFWLRQYDOYHIRRWYDOYHDQGVWUDLQHU

Talent wins games, but teamwork and intelligence wins championships.

482 sales@scichemtech.com www.scichemtech.com

482

SCT SHEAR CHEMICALS MIXING AGITATORS

SALIENT FEATURES:

Ɣ 6&7 'RVLQJ &KHPLFDOV 0L[HU LV PDQXIDFWXUHG ZLWK VLPSOH GHVLJQ ZLWK DOO WKH LQWHUQDWLRQDO

standards

Ɣ 6&7'RVLQJ&KHPLFDOV0L[HURSHUDWHVEHWZHHQWRUSPURWDWLRQSHUPLQXWH

Ɣ 6&7'RVLQJ&KHPLFDOV0L[HULVVXLWDEOHIRUDQ\FKHPLFDORUOLTXLGVZLWKGLIIHUHQWYLVFRVLWLHV

Ɣ 6&7'RVLQJ&KHPLFDOV0L[HUKDVWKHSURSHOOHUDQGVKDIWVPDGHRI6WDLQOHVVVWHHO±66OLQHG

with plastic coating.

Ɣ 6&7'RVLQJ&KHPLFDOV0L[HULVSURWHFWHGDVSHU,3VDIHW\FODVV

Ɣ 6&7'RVLQJ&KHPLFDOV0L[HULVVXLWDEOHPDQ\DSSOLFDWLRQVVXFKDVPL[LQJRIDQ\ZDWHUWUHDWPHQW

chemicals, solutions ,pharmaceutical solutions and any chemical solutions compatible with the

stainless steel.

Ɣ 6&7'RVLQJ&KHPLFDOV0L[HURSHWDWHVDWYROWVZLWK+]SKDVHOLQH

TECHNICAL SPECIFICATIONS :

SCT PRODUCT

NO. DOSING TANK

CAPACITY SHAFT

LENGTH (mm) REVOLVING

SPEED (rpm) BLADES POWER

WATTS VOTLAGE

(VOLTS)

SCT-108.006.70 100 Litres 650 80 Stainless Steel with plastic coating 180 W 380 V

SCT-108.006.71 200 Litres 800 80-120 Stainless Steel with plastic coating 250 W 380 V

SCT-108.006.72 500 Litres 1000 80-120 Stainless Steel with plastic coating 550 W 380 V

ORDERING INFORMATIONS:

SCT-108.006.70 SCT-SHEAR-1 SCT Dosing Chemicals Mixer for 100 litre dosing tank supplied with shaft length 650

mm, Revolving speed (rpm) 80, with stainless steel plastic coating blade.

SCT-108.006.71 SCT-SHEAR-2 SCT Dosing Chemicals Mixer for 200 litre dosing tank supplied with shaft length 800

mm, Revolving speed (rpm) 80-120, with stainless steel plastic coating blade.

SCT-108.006.72 SCT-SHEAR-3 SCT Dosing Chemicals Mixer for 500 litre dosing tank supplied with shaft length 1000

mm, Revolving speed (rpm) 80-120, with stainless steel plastic coating blade.

SCT DOSING TANKS

SALIENT FEATURES:

SCT DOSING TANKS ARE WITH RED SCREW FITTING LID WITH A RAISED SECTION TO MOUNT DOSING PUMPS, MIXERS , LEVEL

SENSORS ETC. MADE OF HIGH QUALITY LDPE ( LOW DENSITY POLYETHYLENE)

CYLINDRICAL IN SHAPE

TECHNICAL SPECIFICATIONS:

SCT PRODUCT NO SCT-108.007.01 SCT-108.007.02 SCT-108.007.03

SCT MODEL NO SCT-TANK-1 SCT-TANK-2 SCT-TANK-3

CAPACITY 100 LITRE 200 LITRE 500LITRE

GRADUATIONS YES YES NO

THICKNESS 4.5 MM THICKNESS 5 MM THICKNESS 6 MM THICKNESS

MATERIAL LDPE (LOW DENSITY POLYETHYLENE)

COLOUR WHITE IN COLOUR WITH RED LID

SHAPE CYLINDRICAL IN SHAPE

HEIGHT 75 CMS 93 CMS 111.5CM

BOTTOM DIA 46 CMS 58 CMS 80CM

TOP OPENING 12 CMS 12 CMS 12CM

ORDERING INFORMATIONS:

SCT-108.007.01 SCT-TANK-1 SCT DOSING TANK ( LDPE) – 100 LITRES

SCT-108.007.02 SCT-TANK-2 SCT DOSING TANK ( LDPE) – 200 LITRES

SCT-108.007.03 SCT-TANK-3 SCT DOSING TANK ( LDPE) – 500 LITRES

Ɣ 2WKHUWDQNVL]HVXSRQUHTXHVW3OVFRQWDFWXV

Teachers open the door. You enter by yourself

483

sales@scichemtech.com www.scichemtech.com

483

Note: G=BSP ZG=BSPT Z=NPT

SCT BOURDON SPRING PRESSURE GAUGES

AYTN - SERIES LIQUID FILLED PRESSURE GAUGES

ScichemTech® - SCT - PRESSURE GAUGES

That which does not kill us makes us stronger.

484 sales@scichemtech.com www.scichemtech.com

484

Note: G=BSP ZG=BSPT Z=NPT

:RUNLQJFRQGLWLRQRIOLTXLG¿OOHGSUHVVXUHJDXJH

Installation Size

SCT-AYTN - SERIES LIQUID FILLED PRESSURE GAUGES

The art of medicine consists in amusing the patient while nature cures the disease.

485

sales@scichemtech.com www.scichemtech.com

485

Technical Parameters of SCT-ZV series Flow Meter

The outline size of SCT-ZV series Flow Meter

The material and code of the parts of SCT-ZV series Flow Meter

)RURUGHUSOHDVHVSHFLI\WKHPRGHOVSHFL¿FDWLRQDQGFRGH

ScichemTech - SCT ® FLOWMETERS

SCT - ZV SERIES FLOWMETERS

The authority of those who teach is often an obstacle to those who want to learn.

486 sales@scichemtech.com www.scichemtech.com

486

The outline size of SCT-JZ series Flow Meter

)RU2UGHUSOHDVHVSHFLI\WKHPRGHOVSHFL¿FDWLRQDQGFRGH

The material and code of the parts of SCT-JZ series Flow Meter

SCT - JZ SERIES FLOWMETERS

The best preparation for good work tomorrow is to do good work today.

487

sales@scichemtech.com www.scichemtech.com

487

SCT - GV SERIES FLOWMETERS

The best revenge is massive success.

488 sales@scichemtech.com www.scichemtech.com

488

Technical parameters of SCT-SZ Series

The drawing and installation size of SCT-SZ Durable Plastic Tube Type

Rotameter Flow Meter

The material of SCT-SZ-part

The structure of

SCT-SZ-15-65

The structure chart of

SCT-SZ-100-125-150

SCT - SZ SERIES PLASTIC TUBE TYPE ROTAMETERS

The best thing about the future is that it comes one day at a time.

489

sales@scichemtech.com www.scichemtech.com

489

Main Technical Parameters

SCT-ZVL SERIES VARIABLE-AREA FLOWMETERS

7KHEHVWZD\WRÀQG\RXUVHOILVWRORVH\RXUVHOILQWKHVHUYLFHRIRWKHUV

490 sales@scichemtech.com www.scichemtech.com

490

Construction Pattern

Model Selection Guide

Model Selection and Instruction

Commutator function Combination

The best way to make your dreams come true is to wake up

491

sales@scichemtech.com www.scichemtech.com

491

The best way to predict the future is to invent it

492 sales@scichemtech.com www.scichemtech.com

492

The best way to predict your future is to create it

493

sales@scichemtech.com www.scichemtech.com

493

Electromagnetic Flowmeter

Measure principles

E=KBVD

SCT-DYL SERIES ELECTROMAGNETIC FLOWMETERS

The biggest mistake we could ever make is being too afraid to make one!

494 sales@scichemtech.com www.scichemtech.com

494

)HDWXUHVRIHOHFWURPDJQHWLFÀRZPHWHU

Main technical parameter

7KHGHHSHVWGHÀQLWLRQRI\RXWKLVOLIHDV\HWXQWRXFKHGE\WUDJHG\

495

sales@scichemtech.com www.scichemtech.com

495

(OHFWURPDJQHWLFÀRZPHWHU

The difference between ordinary and extraordinary is that little extra

496 sales@scichemtech.com www.scichemtech.com

496

The choice of electrode material

The distance between insanity and genius is measured only by success.

497

sales@scichemtech.com www.scichemtech.com

497

The choice of lining material

The essential question is not, how busy are you? But what are you busy at?

498 sales@scichemtech.com www.scichemtech.com

498

Flow selection table (Refer to the chart Diagram)

7KHÁRZHUWKDWEORRPVLQDGYHUVLW\LVWKHUDUHVWDQGWKHPRVWEHDXWLIXORIDOO

499

sales@scichemtech.com www.scichemtech.com

499

Flow selection table (Refer to the chart Diag)

We thank our valuable customers for sparing their precious time in reading our complete SCT Test & Measurement Catalog.

,Q FDVH VKRXOG \RX UHTXLUH DQ\ IXUWKHU FODUL¿FDWLRQV RU DGGLWLRQDO FRSLHV RI FDWDORJXHV RU &'¶V SOHDVH FRQWDFW XV WKURXJK HPDLO

at sales@scichemtech.Com

0DQXIDFWXUHUUHVHUYHWKHULJKWVWRFKDQJHWKHXQLWSDFNLQJVSHFL¿FDWLRQVZLWKRXWSULRUQRWLFH:HDVVXUH\RXWKDWDOORXUSURGXFWV

are manufactured and tested as per the International Standards.

The future belongs to those who believe in the beauty of their dreams.

Catalog TDS 382 W SCT AND MEASUREMENT

Navigation menu

Versions of this User Manual:

Views

Navigation
