SIM7020 Series_AT Command
Manual_V1.00
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 2 2018-04-10
Document Title SIM7020 Series AT Command Manual
Version 1.00
Date 2018-04-10
Status Release
Document Control ID SIM7020 Series_AT Command Manual_V1.00
General Notes
SIMCom offers this information as a service to its customers, to support application and
engineering efforts that use the products designed by SIMCom. The information provided is based
upon requirements specifically provided to SIMCom by the customers. SIMCom has not
undertaken any independent search for additional relevant information, including any information
that may be in the customer’s possession. Furthermore, system validation of this product designed
by SIMCom within a larger electronic system remains the responsibility of the customer or the
customer’s system integrator. All specifications supplied herein are subject to change.
Copyright
This document contains proprietary technical information which is the property of Shanghai
SIMCom Wireless Solutions Ltd, copying of this document and giving it to others and the using or
communication of the contents thereof, are forbidden without express authority. Offenders are
liable to the payment of damages. All rights reserved in the event of grant of a patent or the
registration of a utility model or design. All specification supplied herein are subject to change
without notice at any time.
Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2018
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 3 2018-04-10
Contents
Version History ......................................................................................... 10
1 Introduction ......................................................................................... 11
1.1 Scope of the document ................................................................................... 11
1.1 Related documents ......................................................................................... 11
1.2 Conventions and abbreviations ...................................................................... 11
1.3 AT Command syntax ...................................................................................... 11
1.3.1 Basic syntax ............................................................................................................ 12
1.3.2 S Parameter syntax .................................................................................................. 12
1.3.3 Extended Syntax ...................................................................................................... 12
1.3.4 Combining AT commands on the same Command line .......................................... 12
1.3.5 Entering successive AT commands on separate lines .............................................. 13
1.4 Supported character sets ................................................................................ 13
1.5 Flow control ................................................................................................... 13
1.5.1 Software flow control (XON/XOFF flow control) .................................................. 13
1.5.2 Hardware flow control (RTS/CTS flow control) ..................................................... 14
1.6 Definitions ...................................................................................................... 14
1.6.1 Parameter Saving Mode .......................................................................................... 14
1.6.2 Max Response Time ................................................................................................ 14
2 AT Commands According to V.25TER ............................................. 15
2.1 Overview of AT Commands According to V.25TER ..................................... 15
2.1 Detailed Description of AT Commands According to V.25TER .................... 16
2.1.1 ATE Set Command Echo Mode ........................................................................... 16
2.1.2 ATI Display Product Identification Information .................................................. 16
2.1.3 ATL Set Monitor speaker loudness ...................................................................... 17
2.1.4 ATM Set Monitor Speaker Mode ......................................................................... 17
2.1.5 ATN1 some PC modem driver initial setting to handshake at highest speed larger
than S37 18
2.1.6 ATO Switch from Command Mode to Data Mode .............................................. 18
2.1.7 ATP Select Pulse Dialling .................................................................................... 18
2.1.8 ATQ Set Result Code Presentation Mode ............................................................ 19
2.1.9 ATS0 Set Number of Rings before Automatically Answering the Call................ 19
2.1.10 ATS1 Ring counter ............................................................................................... 20
2.1.11 ATS2 Set escape sequence character .................................................................... 21
2.1.12 ATS3 Set Command Line Termination Character ................................................ 21
2.1.13 ATS4 Set Response Formatting Character ........................................................... 22
2.1.14 ATS5 Set Command Line Editing Character ....................................................... 22
2.1.15 ATS6 Pause Before Blind Dialling ....................................................................... 23
2.1.16 ATS7 Set Number of Seconds to Wait for Connection Completion ..................... 23
2.1.17 ATS8 Set Number of Seconds to Wait for Comma Dial Modifier Encountered in
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 4 2018-04-10
Dial String of D Command ..................................................................................................... 24
2.1.18 ATS10 Set Disconnect Delay after Indicating the Absence of Data Carrier ........ 25
2.1.19 ATS12 Set Escape Code Guard Time .................................................................. 25
2.1.20 ATS25 Set DTR change time ............................................................................... 26
2.1.21 ATS95 Some PC modem driver initial setting to enable extended result codes ...... 27
2.1.22 ATT Select Tone Dialing ...................................................................................... 27
2.1.23 ATV TA Response Format .................................................................................. 28
2.1.24 ATX Set CONNECT Result Code Format and Monitor Call Progress ................ 29
2.1.25 ATZ Reset Default Configuration ........................................................................ 30
2.1.26 AT&C Set DCD Function Mode .......................................................................... 30
2.1.27 AT&D Set DTR Function Mode .......................................................................... 30
2.1.28 AT&F Factory Defined Configuration ................................................................. 31
2.1.29 AT&K Flow control setting .................................................................................. 31
2.1.30 AT&V Display Current Configuration ................................................................. 32
2.1.31 AT&W Store Active Profile ................................................................................. 32
2.1.32 AT+DR V.42bis data compression reporting control ........................................... 33
2.1.33 AT+DS V.42bis data compression control ........................................................... 34
2.1.34 AT+GCAP Request Complete TA Capabilities List ............................................. 35
2.1.35 AT+GMI Request Manufacturer Identification .................................................... 35
2.1.36 AT+GMM Request TA Model Identification ....................................................... 36
2.1.37 AT+GMR Request TA Revision Identification of Software Release ................... 36
2.1.38 AT+GOI Request Global Object Identification .................................................... 37
2.1.39 AT+GSN Request TA Serial Number Identification (IMEI) ................................ 37
2.1.40 AT+ICF Set TE-TA Control Character Framing .................................................. 38
2.1.41 AT+IFC Set TE-TA Local Data Flow Control ..................................................... 39
2.1.42 AT+ILRR Set TE-TA Local rate reporting mode ................................................. 40
2.1.43 AT+IPR Set TE-TA Fixed Local Rate .................................................................. 40
2.1.44 AT+FCLASS Set Fax Class ................................................................................. 42
3 AT Commands According to 3GPP TS 27.007 .................................. 43
3.1 Overview of AT Command According to 3GPP TS 27.007 ........................... 43
3.2 Detailed Descriptions of AT Command According to 3GPP TS 27.007 ........ 44
3.2.1 AT+CEER Extended Error Report ....................................................................... 44
3.2.2 AT+CGMI Request Manufacturer Identification ................................................. 47
3.2.3 AT+CGMM Request Model Identification .......................................................... 47
3.2.4 AT+CGMR Request TA Revision Identification of Software Release ................. 48
3.2.5 AT+CGOI Request global object identification ................................................... 48
3.2.6 AT+CGSN Request Product Serial Number Identification .................................. 49
3.2.7 AT+CIMI Request International Mobile Subscriber Identity ............................... 49
3.2.8 AT+CLCK Facility Lock ...................................................................................... 50
3.2.9 AT+CMAR Master reset ...................................................................................... 51
3.2.10 AT+CMEE Report Mobile Equipment Error ....................................................... 51
3.2.11 AT+COPS Operator Selection .............................................................................. 52
3.2.12 AT+CPIN Enter PIN ............................................................................................ 54
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 5 2018-04-10
3.2.13 AT+CPWD Change Password .............................................................................. 55
3.2.14 AT+CR Service Reporting Control ...................................................................... 56
3.2.15 AT+CREG Network Registration ......................................................................... 57
3.2.16 AT+CRSM Restricted SIM Access ...................................................................... 58
3.2.17 AT+CSCS Select TE Character Set ...................................................................... 59
3.2.18 AT+CSQ Signal Quality Report ........................................................................... 60
3.2.19 AT+CMUX Multiplexer Control .......................................................................... 61
3.2.20 AT+CNUM Subscriber Number ........................................................................... 62
3.2.21 AT+CPOL Preferred Operator List ...................................................................... 63
3.2.22 AT+CFUN Set Phone Functionality ..................................................................... 64
3.2.23 AT+CCLK Clock ................................................................................................. 65
3.2.24 AT+CSIM Generic SIM Access ........................................................................... 66
3.2.25 AT+CBC Battery Charge ..................................................................................... 67
3.2.26 AT+CTZR Time Zone Reporting ......................................................................... 67
3.2.27 AT+CTZU Automatic Time update ...................................................................... 68
3.2.28 AT+CPLS Selection of preferred PLMN list ....................................................... 69
3.2.29 AT+CPSMS Power saving mode setting ............................................................ 70
3.2.30 AT+CCIOTOPT CIoT optimization configuration ............................................ 71
3.2.31 AT+CEDRXS eDRX setting .............................................................................. 73
3.2.32 AT+CEDRXRDP eDRX Read Dynamic Parameters ....................................... 74
3.2.33 AT+CCHO Open UICC logical channel ............................................................ 75
3.2.34 AT+CCHC Close UICC logical channel .......................................................... 76
3.2.35 AT+CGLA Generic UICC logical channel access............................................ 76
3.2.36 AT+CPINR Remaining PIN retries ................................................................ 77
3.2.37 AT+CGATT GPRS/Packet Domain attach or detach ........................................... 78
3.2.38 AT+CGDCONT Define PDP Context .................................................................. 78
3.2.39 AT+CGACT PDP Context Activate or Deactivate ............................................... 81
3.2.40 AT+CGPADDR Show PDP Address .................................................................... 82
3.2.41 AT+CGEREP Packet Domain Event Reporting ................................................... 83
3.2.42 AT+CGREG Network Registration Status ........................................................... 86
3.2.43 AT+CGCONTRDP PDP Context Read Dynamic Parameters ............................. 87
3.2.44 AT+CGPIAF Printing IP Address Format ............................................................ 88
3.2.45 AT+CGDEL Delete Non-Active PDP Contexts ................................................... 90
3.2.46 AT+CGAUTH Define PDP Context Authentication Parameters ......................... 90
3.2.47 AT*MCGDEFCONT Set Default PSD Connection Settings ............................... 91
3.2.48 AT*MSACL Enable/Disable ACL feature ......................................................... 92
3.2.49 AT*MLACL Display ACL List .......................................................................... 93
3.2.50 AT*MWACL Write an ACL entry .................................................................... 94
3.2.51 AT*MDACL Delete an ACL entry ....................................................................... 94
3.2.52 AT+CNBIOTDT NB-IOT Data Type ................................................................... 95
4 AT Commands Special for SIMCom ................................................. 97
4.1 Overview ........................................................................................................ 97
4.2 Detailed Descriptions of Commands ............................................................. 97
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 6 2018-04-10
4.2.1 AT+CPOWD Power off ....................................................................................... 97
4.2.2 AT+CADC Read ADC ........................................................................................ 98
4.2.3 AT+CLTS Get Local Timestamp ......................................................................... 98
4.2.4 AT+CBAND Get and Set Mobile Operation Band .............................................. 99
4.2.5 AT+CENG Report Network State ...................................................................... 100
4.2.6 AT+CCID Show ICCID ..................................................................................... 104
4.2.7 AT+EXUNSOL Enable or Disable Proprietary Unsolicited Indications ............ 104
4.2.8 AT+GSV Display Product Identification Information........................................ 105
4.2.9 AT*CELLLOCK Set the List of ARFCN Which Needs to Be Locked .............. 105
4.2.10 AT+SLEDS Set the Timer Period of Net Light .................................................. 106
4.2.11 AT+CNETLIGHT Close the Net Light or Open It to Shining ........................... 107
4.2.12 AT+CSMINS SIM Inserted Status Reporting .................................................... 108
4.2.13 AT+CSPCHSC Set Scrambling Algorithm for NPDSCH ................................ 109
4.2.14 AT+CATWAKEUP Enable Deep Sleep Wakeup Indication .......................... 109
4.2.15 AT+CSCLK Configure Slow Clock .................................................................. 110
5 AT Commands for TCPIP Application Toolkit ............................... 112
5.1 Overview of AT Commands for TCPIP Application Toolkit ....................... 112
5.2 Detailed Descriptions of AT Commands for TCPIP Application Toolkit .... 112
5.2.1 AT+CSGACT Activate or deactivate a PDN context ....................................... 112
5.2.2 AT+CSOC Create a TCP/UDP socket ................................................................ 114
5.2.3 AT+CSOCON Connect socket to remote address and port ................................ 115
5.2.4 AT+CSOSEND Send data to remote via socket ................................................. 115
5.2.5 AT+CSOCL Close socket ................................................................................... 116
5.2.6 AT+CSOSENDFLAG Set TCP send flag .......................................................... 117
5.2.7 AT+CSOSTATUS Get socket status ................................................................... 117
5.2.8 AT+CSOACK Query Previous Connection Data Transmitting State ................ 118
5.2.9 +CSONMI Socket message arrived indicator .................................................... 118
5.2.10 +CSOERR Socket error indicator ...................................................................... 119
6 AT Commands for HTTP/HTTPS Client ......................................... 120
6.1 Overview of AT Commands for HTTP/HTTPS Client ................................ 120
6.2 Detailed Descriptions of AT Commands for HTTP/HTTPS Client ............. 120
6.2.1 AT+CHTTPCREATE Create a HTTP/HTTPS client instance .......................... 120
6.2.2 AT+CHTTPCON Establish the HTTP/HTTPS connection ............................... 121
6.2.3 AT+CHTTPDISCON Close the HTTP/HTTPS connection .............................. 122
6.2.4 AT+CHTTPDESTROY Destroy the HTTP/HTTPS client instance .................. 122
6.2.5 AT+CHTTPSEND Send HTTP/HTTPS package .............................................. 123
6.2.6 +CHTTPNMIH Header of the response from host ............................................ 124
6.2.7 +CHTTPNMIC Content of the response from host ........................................... 124
6.2.8 +CHTTPERR HTTP client connection error indicator ...................................... 125
7 AT Commands for PING Support .................................................... 126
7.1 Overview of AT Commands for PING Support ........................................... 126
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 7 2018-04-10
7.2 Detailed Descriptions of AT Commands for PING Support ........................ 126
7.2.1 AT+CIPPING Test IP network connectivity to a remote host ........................... 126
8 AT Commands for Network Command – LwM2M ......................... 128
8.1 Overview of AT Commands for Network Command – LwM2M ................ 128
8.2 Detailed Descriptions of AT Commands for Network Command – LwM2M128
8.2.1 AT+CLMCONF Configuration LwM2M instance and create the connection ... 128
8.2.2 AT+CLMADDOBJ Add LwM2M object .......................................................... 129
8.2.3 AT+CLMDELOBJ Delete LwM2M object ....................................................... 129
8.2.4 AT+CLMREAD Read notification and command ............................................. 129
8.2.5 AT+CLMWRITE Write notification and command .......................................... 130
8.2.6 AT+CLMEXECUTE Execute notification and command ................................. 131
8.2.7 AT+CLMNOTIFY Notify data change .............................................................. 131
8.2.8 AT+CLMDEL Delete LwM2M instance ........................................................... 132
8.2.9 +CLMOBSERVE Observed command ................................................................. 132
8.2.10 +CLMPARAMETER Observed command ........................................................... 132
8.2.11 +CLMERR Indicated there is some error ............................................................. 133
9 AT Commands for Network Command – MQTT ............................ 134
9.1 Overview of AT Commands for Network Command-MQTT ...................... 134
9.2 Detailed Descriptions of AT Commands for Network Command-MQTT ... 134
9.2.1 AT+CMQNEW New MQTT .............................................................................. 134
9.2.2 AT+CMQCON Send MQTT connection packet ................................................ 135
9.2.3 AT+CMQDISCON Disconnect MQTT ............................................................. 136
9.2.4 AT+CMQSUB Send MQTT subscribe packet ................................................... 136
9.2.5 AT+CMQUNSUB Send MQTT unsubscribe packet ......................................... 137
9.2.6 AT+CMQPUB Send MQTT publish packet ...................................................... 137
10 AT Commands for Network Command – CoAP........................... 139
10.1 Overview of AT Commands for Network Command-CoAP .................... 139
10.2 Detailed Descriptions of AT Commands for Network Command-CoAP . 139
10.2.1 AT+CCOAPSTA Start CoAP server .................................................................. 139
10.2.2 AT+CCOAPNEW Create a CoAP client instance ............................................. 139
10.2.3 AT+CCOAPSEND Send CoAP data .................................................................. 140
10.2.4 AT+CCOAPDEL Destory the CoAP client instance ......................................... 140
10.2.5 +CCOAPNMI Content from CoAP server ......................................................... 141
11 AT Commands for Network Command – SNTP........................... 142
11.1 Overview of AT Commands for Network Command-SNTP .................... 142
11.2 Detailed Descriptions of AT Commands for Network Command-SNTP . 142
11.2.1 AT+CSNTPSTART Start to query network time ............................................... 142
11.2.2 AT+CSNTPSTOP Stop querying network time ................................................. 142
11.2.3 +CSNTP Received network time ....................................................................... 143
12 AT Commands for Network Command – TLS ............................. 144
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 8 2018-04-10
12.1 Overview of AT Commands for Network Command- TLS ..................... 144
12.2 Detailed Descriptions of AT Commands for Network Command-TLS ... 144
12.2.1 AT+CTLSCFG Configure TLS parameters ....................................................... 144
12.2.2 AT+CTLSONN Create a TLS connection.......................................................... 145
12.2.3 AT+CTLSCLOSE Close a TLS connection ....................................................... 145
12.2.4 AT+CTLSSEND Send data ................................................................................ 146
12.2.5 AT+CTLSRECV Receive data ........................................................................... 146
13 AT Commands for Network Command –OneNET ....................... 148
13.1 Overview of AT Commands for Network Command- OneNet ................ 148
13.2 Detailed Descriptions of AT Commands for Network Command-OneNet149
13.2.1 AT+MIPLCREATE Create a OneNET instance ................................................ 149
13.2.2 AT+MIPLDELETE Delete a OneNET instance ................................................ 150
13.2.3 AT+MIPLOPEN Register to OneNET. .............................................................. 150
13.2.4 AT+MIPLCLOSE Deregister to OneNET. ........................................................ 151
13.2.5 AT+MIPLADDOBJ Add an object .................................................................... 152
13.2.6 AT+MIPLDELOBJ Delete an object. ................................................................ 152
13.2.7 AT+MIPLUPDATE Update registration ............................................................ 153
13.2.8 AT+MIPLREADRSP Read response from user ................................................. 153
13.2.9 AT+MIPLWRITERSP Write response from user .............................................. 155
13.2.10 AT+MIPLEXECUTERSP Execute response from user ................................. 155
13.2.11 AT+MIPLOBSERVERSP Observe response from user ................................ 156
13.2.12 AT+MIPLDISCOVERRSP Discover response from user ............................. 156
13.2.13 AT+MIPLPARAMETERRSP Set parameter from user ................................. 157
13.2.14 AT+MIPLNOTIFY Notify data value change from user ............................... 158
13.2.15 AT+MIPLVER Read version.......................................................................... 158
13.2.16 +MIPLREAD Read request to user ................................................................ 159
13.2.17 +MIPLWRITE Write request to user ............................................................. 159
13.2.18 +MIPLEXECUTE Execute request to user .................................................... 160
13.2.19 +MIPLOBSERVE Observe request to user ................................................... 160
13.2.20 +MIPLDISCOVER Discover request to user ................................................ 160
13.2.21 +MIPLPARAMETER Set parameter request to user ........................................ 161
13.2.22 +MIPEVENT Event indication to user ............................................................. 161
14 AT Commands for DNS ................................................................ 163
14.1 Overview of AT Commands for DNS Command ..................................... 163
14.2 Detailed Descriptions of AT Commands for DNS Command .................. 163
14.2.1 AT+CDNSCFG Configure Domain Name Server ................................................ 163
14.2.2 AT+CDNSGIP Query the IP Address of Given Domain Name ............................ 164
15 Supported Unsolicited Result Codes ............................................. 165
15.1 Summary of CME ERROR Codes ........................................................... 165
15.2 Summary of CMS ERROR Codes ........................................................... 165
15.3 Summary of Unsolicited Result Codes .................................................... 165
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 9 2018-04-10
16 AT Commands Examples .............................................................. 166
16.1 CoAP command ....................................................................................... 166
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 10 2018-04-10
Version History
Version
Date
Chapter
What is new
V1.00 2018-04-10 New version
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 11 2018-04-10
1 Introduction
1.1 Scope of the document
This document presents the AT Command Set for SIMCom SIM7020 Series, including SIM7020.
1.1 Related documents
You can visit the SIMCom Website using the following link:
http://www.simcomm2m.com
1.2 Conventions and abbreviations
In this document, the GSM engines are referred to as following term:
ME (Mobile Equipment);
MS (Mobile Station);
TA (Terminal Adapter);
DCE (Data Communication Equipment) or facsimile DCE (FAX modem, FAX board);
In application, controlling device controls the GSM engine by sending AT Command via its
serial interface. The controlling device at the other end of the serial line is referred to as
following term:
TE (Terminal Equipment);
DTE (Data Terminal Equipment) or plainly "the application" which is running on an embedded
system;
1.3 AT Command syntax
The "AT" or "at" or “aT” or “At”prefix must be set at the beginning of each Command line. To
terminate a Command line enter <CR>.
Commands are usually followed by a response that includes.
"<CR><LF><response><CR><LF>"
Throughout this document, only the responses are presented,<CR><LF> are omitted
intentionally.
The AT Command set implemented by SIM7020 Series is a combination of 3GPP TS 27.005,
3GPP TS 27.007 and ITU-T recommendation V.25ter and the AT commands developed by
SIMCom.
Note: Only enter AT Command through serial port after SIM7020 Series is powered on and Unsolicited Result
Code "RDY" is received from serial port. If auto-bauding is enabled, the Unsolicited Result Codes "RDY"
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 12 2018-04-10
and so on are not indicated when you start up the ME, and the "AT" prefix, or "at" prefix must be set at the
beginning of each command line.
All these AT commands can be split into three categories syntactically: "basic", "S parameter",
and "extended". These are as follows:
1.3.1 Basic syntax
These AT commands have the format of "AT<x><n>", or "AT&<x><n>", where "<x>"is the
Command, and "<n>"is/are the argument(s) for that Command. An example of this is "ATE<n>",
which tells the DCE whether received characters should be echoed back to the DTE according to
the value of "<n>". "<n>" is optional and a default will be used if missing.
1.3.2 S Parameter syntax
These AT commands have the format of "ATS<n>=<m>", where "<n>" is the index of the S
register to set, and "<m>"is the value to assign to it. "<m>" is optional; if it is missing, then a
default value is assigned.
1.3.3 Extended Syntax
These commands can operate in several modes, as in the following table:
Table 1: Types of AT commands and responses
Test Command AT+<x>=?
Command or by internal processes.
Read Command AT+<x>? This command
Write Command AT+<x>=<…> This command sets the user-
values.
Execution
Command
AT+<x> The execution command reads non-variable
parameters affected by internal processes in the GSM
engine.
1.3.4 Combining AT commands on the same Command line
You can enter several AT commands on the same line. In this case, you do not need to type the
"AT" or "at" prefix before every command. Instead, you only need type "AT" or "at" the
beginning of the command line. Please note to use a semicolon as the command delimiter after
an extended command; in basic syntax or S parameter syntax, the semicolon need not enter, for
example: ATE1Q0S0=1S3=13V1X4;+IFC=0,0;+IPR=115200.
The Command line buffer can accept a maximum of 4200 characters (counted from the first
command without "AT" or "at" prefix). If the characters entered exceeded this number then none
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 13 2018-04-10
of the Command will executed and TA will return "ERROR".
1.3.5 Entering successive AT commands on separate lines
When you need to enter a series of AT commands on separate lines, please Note that you need to
wait the final response (for example OK, CME error, CMS error) of last AT Command you
entered before you enter the next AT Command.
1.4 Supported character sets
The SIM7020 Series AT Command interface defaults to the IRA character set. The SIM7020
Series supports the following character sets:
GSM format
UCS2
IRA
The character set can be set and interrogated using the "AT+CSCS" Command (3GPP TS
27.007). The character set is defined in GSM specification 3GPP TS 27.005.
The character set affects transmission and reception of SMS and SMS Cell Broadcast messages,
the entry and display of phone book entries text field and SIM Application Toolkit alpha strings.
1.5 Flow control
Flow control is very important for correct communication between the GSM engine and DTE.
For in the case such as a data or fax call, the sending device is transferring data faster than the
receiving side is ready to accept. When the receiving buffer reaches its capacity, the receiving
device should be capable to cause the sending device to pause until it catches up.
There are basically two approaches to achieve data flow control: software flow control and
hardware flow control. SIM7020 Series support both two kinds of flow control.
In Multiplex mode, it is recommended to use the hardware flow control.
1.5.1 Software flow control (XON/XOFF flow control)
Software flow control sends different characters to stop (XOFF, decimal 19) and resume (XON,
decimal 17) data flow. It is quite useful in some applications that only use three wires on the
serial interface.
The default flow control approach of SIM7020 Series is hardware flow control (RTS/CTS flow
control), to enable software flow control in the DTE interface and within GSM engine, type the
following AT Command:
AT+IFC=1, 1
Ensure that any communications software package (e.g. Hyper terminal) uses software flow
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 14 2018-04-10
control.
NOTE:
Software Flow control should not be used for data calls where binary data will be transmitted or
received (e.g. TCP/IP) as the DTE interface may interpret binary data as flow control characters.
1.5.2 Hardware flow control (RTS/CTS flow control)
Hardware flow control achieves the data flow control by controlling the RTS/CTS line. When the
data transfer should be suspended, the CTS line is set inactive until the transfer from the
receiving buffer has completed. When the receiving buffer is ok to receive more data, CTS goes
active once again.
To achieve hardware flow control, ensure that the RTS/CTS lines are present on your application
platform.
1.6 Definitions
1.6.1 Parameter Saving Mode
For the purposes of the present document, the following syntactical definitions apply:
- NO_SAVE: The parameter of the current AT command will be lost if module is rebooted or
current AT command doesn't have parameter.
- AUTO_SAVE: The parameter of the current AT command will be kept in NVRAM
automatically and take in effect immediately, and it won't be lost if module is rebooted.
- AUTO_SAVE_REBOOT: The parameter of the current AT command will be kept in
NVRAM automatically and take in effect after reboot, and it won't be lost if module is
rebooted.
- -: "-" means this AT command doesn’t care the parameter saving mode.
1.6.2 Max Response Time
Max response time is estimated maximum time to get response, the unit is seconds.
"-" means this AT command doesn’t care the response time.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 15 2018-04-10
2 AT Commands According to V.25TER
These AT Commands are designed according to the ITU-T (International Telecommunication
Union, Telecommunication sector) V.25ter document.
2.1 Overview of AT Commands According to V.25TER
Command Description
ATE Set command echo mode
ATI
Display product identification information
ATL Set monitor speaker loudness
ATM
Set monitor speaker mode
ATN1 Some PC modem driver initial setting to handshake at highest speed larger
than S37
ATO
Switch from command mode to data mode
ATP Select pulse dialling
ATQ
Set result code presentation mode
ATS0 Set number of rings before automatically answering the call
ATS1 Ring counter
ATS2 Set escape sequence character
ATS3 Set command line termination character
ATS4
Set response formatting character
ATS5
Set command line editing character
ATS6 Pause before blind dialling
ATS7 Set number of seconds to wait for connection completion
ATS8 Set number of seconds to wait for comma dial
modifier encountered in dial
string of D command
ATS10
Set disconnect delay after indicating the absence of data carrier
ATS12 Set escape code guard time
ATS25 Set DTR change time
ATS95 Some PC modem driver initial setting to enable extended result codes
ATT Select Tone Dialing
ATV
TA response format
ATX
Set connect result code format and monitor call progress
ATZ Reset default configuration
AT&C Set DCD function mode
AT&D Set DTR function mode
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 16 2018-04-10
AT&F
Factory defined configuration
AT&K Flow control setting
AT&V
Display current configuration
AT&W Store Active Profile
AT+DR V.42bis data compression reporting control
AT+DS V.42bis data compression control
AT+GCAP Request complete TA capabilities list
AT+GMI
Request manufacturer identification
AT+GMM Request TA model identification
AT+GMR Request TA revision identification of software release
AT+GOI Request global object identification
AT+GSN Request TA serial number identification (IMEI)
AT+ICF Set TE-TA control character framing
AT+IFC
Set TE-TA local data flow control
AT+ILPR Set TE-TA Local rate reporting mode
AT+IPR
Set TE-TA fixed local rate
AT+FCLASS Set Fax Class
2.1 Detailed Description of AT Commands According to V.25TER
2.1.1 ATE Set Command Echo Mode
ATE Set Command Echo Mode
Execution
Command
ATE<value>
Response
This setting determines whether or not the TA echoes characters received
from TE during Command state.
OK
Parameters
<value> 0 Echo mode off
1 Echo mode on
Parameter Saving
Mode
Max Respons
e
Time
-
Reference
V.25ter
Note
2.1.2 ATI Display Product Identification Information
ATI Display Product Identification Information
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 17 2018-04-10
Execution
Command
ATI
Response
TA issues product information text
Example:
SIM7020 R1752
OK
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.3 ATL Set Monitor speaker loudness
ATL Set Monitor speaker loudness
Execution
Command
ATL<value>
Response
OK
Parameters
<value> 0..3 Volume
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
No effect in GSM
2.1.4 ATM Set Monitor Speaker Mode
ATM Set Monitor Speaker Mode
Execution
Command
ATM<value>
Response
OK
Parameters
<value> 0..2 Mode
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
No effect in GSM
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 18 2018-04-10
2.1.5 ATN1 some PC modem driver initial setting to handshake at highest speed larger
than S37
ATN1 Some PC modem driver initial setting to handshake at highest speed larger than S37
Execution
Command
ATN1
Response
OK
Parameters
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.6 ATO Switch from Command Mode to Data Mode
ATO Switch from Command Mode to Data Mode
Execution
Command
ATO[n]
Response
TA resumes the connection and switches back from c
ommand mode to data
mode.
CONNECT
If connection is not successfully resumed
ERROR
else
TA returns to data mode from command mode CONNECT <text>
Note: <text> only if parameter setting ATX>0
Parameter
<n> 0 Switch from command mode to data mode.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.7 ATP Select Pulse Dialling
ATP Select Pulse Dialling
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 19 2018-04-10
Execution
Command
ATP
Response
OK
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
No effect in GSM
2.1.8 ATQ Set Result Code Presentation Mode
ATQ Set Result Code Presentation Mode
Execution
Command
ATQ<n>
Response
This parameter setting determines whether or not the TA transmits any result
code to the TE. Information text transmitted in response is not affected by
this setting.
If <n>=0:
OK
If <n>=1:
(none)
Parameters
<n> 0 TA transmits result code
1 Result codes are suppressed and not transmitted
Parameter Saving
Mode
Max Response
Time
-
Reference
V.25ter
Note
This command only affects V.250 AT commands and not all other AT
commands in this specification (either 3GPP or MediaTek proprietary).
2.1.9 ATS0 Set Number of Rings before Automatically Answering the Call
ATS0 Set Number of Rings before Automatically Answering the Call
Read Command
ATS0?
Response
<n>
OK
Parameters
See Write Command
Write Command
Response
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 20 2018-04-10
ATS0=<n> This parameter setting determines the number of rings before auto-answer.
OK
ERROR
Parameters
<n> 0 Automatic answering is disable.
1-255 Number of rings the modem will wait for before an
swering
the phone if a ring is detected.
Parameter Saving
Mode
-
Max Response
Time
-
Reference
V.25ter
Note
If <n>
is set too high, the calling party may hang up before the call can be
answered automatically.
If using cmux port, ATH and AT+CHUP can hang up the call
(automatically answering) only in the CMUX channel 0.
If using dual-physical serial port, ATH and AT+CHUP can hang up the call
(automatically answering) only in UART1.
2.1.10 ATS1 Ring counter
ATS1 Ring counter
Read Command
ATS1?
Response
<n>
OK
Parameters
See Write Command
Write Command
ATS1=<n>
Response
This command will not alert the RING counter,but simply display
OK
ERROR
Parameters
<n>
The number of “RING” strings sent to the TE as a result of
receiving an incoming call.
0-255
Pa
rameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 21 2018-04-10
Reference
V.25ter
Note
If “RING” is not displayed on a particular channel due to other settings (such as
suppression of all unsolicited events (ATQ)) then this value should not be
incremented. This value
is reset to 0 when receiving a new incoming call. Note
that this command should also be made channel specific as with other ATS<x>
commands.
2.1.11 ATS2 Set escape sequence character
ATS3
Set escape sequence character
Read Command
ATS2?
Response
<n>
OK
Parameters
See Write Command
Write Command
ATS2=<n>
Response
This parameter setting determines the character recognized by the TA to
indicate the escape sequence.
OK
ERROR
Parameters
<n> 0-43-255 escape sequence character
Note: default 43 = ‘+’
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.12 ATS3 Set Command Line Termination Character
ATS3 Set Command Line Termination Character
Read Command
ATS3?
Response
<n>
OK
Parameters
See Write Command
Write Command
ATS3=<n>
Response
This parameter setting determines the character recognized by TA to
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 22 2018-04-10
terminate an incoming c
ommand line. The TA also returns this character in
output.
OK
ERROR
Parameters
<n> 0-13-127 Command line termination character
Parameter Saving
Mode
-
Max Response
Time
-
Reference
V.25ter
Note
Default 13 = CR. It only supports default value.
2.1.13 ATS4 Set Response Formatting Character
ATS4 Set Response Formatting Character
Read Command
ATS4?
Response
<n>
OK
Parameters
See Write Command
Write Command
ATS4=<n>
Response
This parameter setting determines the character generated by the TA for
result code and information text.
OK
ERROR
Parameters
<n> 0-10-127 Response formatting character
Parameter Saving
Mode
-
Max Response
Time
-
Reference
V.25ter
Note
Default 10 = LF. It only supports default value.
2.1.14 ATS5 Set Command Line Editing Character
ATS5 Set Command Line Editing Character
Read Command
ATS5?
Response
<n>
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 23 2018-04-10
OK
Parameters
See Write Command
Write Command
ATS5=<n>
Response
This parameter setting determines the character recognized by TA as a
request to delete from the c
ommand line the immediately preceding
character.
OK
ERROR
Parameters
<n> 0-8-127 Response formatting character
Parameter Saving
Mode
AT&W_SAVE
Ma
x Response
Time
-
Reference
V.25ter
Note
Default 8 = Backspace.
2.1.15 ATS6 Pause Before Blind Dialling
ATS6 Pause Before Blind Dialling
Read Command
ATS6?
Response
<n>
OK
Write Command
ATS6=<n>
Response
OK
ERROR
Parameters
<n> 0-2-10 Time
Parame
ter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
No effect in GSM
2.1.16 ATS7 Set Number of Seconds to Wait for Connection Completion
ATS7 Set Number of Seconds to Wait for Connection Completion
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 24 2018-04-10
Read Command
ATS7?
Response
<n>
OK
Parameters
See Write Command
Write Command
ATS7=<n>
Response
This parameter setting determines the amount of time to wait for the
connection completion in case of answering or originating a call.
OK
ERROR
Parameters
<n> 1-60-255 Number of seconds to wait for connection completion
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
If called party has specified a high value for ATS0=<n>, call setup may fail.
The correlation between ATS7 and ATS0 is important
Example: Call may fail if ATS7=30 and ATS0=20.
ATS7 is only applicable to data call.
2.1.17 ATS8 Set Number of Seconds to Wait for Comma Dial Modifier Encountered in
Dial String of D Command
ATS8 Set Number of Seconds to Wait for Comma Dial Modifier Encountered in
Dial
String of D Command
Read Command
ATS8?
Response
<n>
OK
Parameters
See Write Command
Write Command
ATS8=<n>
Response
OK
ERROR
Parameters
<n> 0 no pause when comma encountered in dial string
1-2-255 The value of this register determines how long the
modem should pause when it sees a comma in the dialing string.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 25 2018-04-10
Parameter Saving
Mode
-
Max Response
Time
-
Reference
V.25ter
Note
No effect in GSM
2.1.18 ATS10 Set Disconnect Delay after Indicating the Absence of Data Carrier
ATS10 Set Disconnect Delay after Indicating the Absence of Data Carrier
Read Command
ATS10?
Response
<n>
OK
Parameters
See Write Command
Write Command
ATS10=<n>
Response
This parameter setting determines the amount of time that the TA will
remain connected in absence of data carrier. If the data carrier is once more
detected before disconnecting, the TA remains connected.
OK
ERROR
Parameters
<n> 1-15-254 Number of tenths seconds of delay
Parameter Saving
Mode
-
Max Response
Time
-
Reference
V.25ter
Note
This command is not used, as there have been issues with in-
band DCD
dropping unexpectedly for CSD calls on some networks.
2.1.19 ATS12 Set Escape Code Guard Time
This command sets the escape code guard time in fiftieths of a second. The escape guard time is
used to measure when to detect the +++ escape sequence has been entered by the PC in order to
drop out of data mode back to AT command mode.
The guard time determines the time that forms a guard period before and after three escape
sequence characters. In order to distinguish an escape sequence from just three escape sequence
characters in the data stream there is timing associated to the three escape sequence characters of
an escape sequence.
The time between the last byte of the data stream and the first escape sequence character must be
at least the guard time and the time between each escape sequence character of the escape
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 26 2018-04-10
sequence must be less than the guard time and no other byte is received after the third escape
sequence character for the time of the guard time. If an escape sequence is detected, the OK
result code will be sent to the DTE. Otherwise, the DCE will stay in data mode.
For example: “<Guard time>+++<Guard time>”
ATS12 Set Escape Code Guard Time
Read Command
ATS12?
Response
<n>
OK
NB: <n> is in 3 decimal digits format (e.g. Default value is given as 050).
If error is related to wrong AT syntax:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
ATS12=<n>
Response
OK
ERROR
Parameters
<n> 0-50-255 Number of 20 ms.
Parameter
Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.20 ATS25 Set DTR change time
This command sets the S-register 25 Detect DTR change time that contain the threshold for
noticing a change in DTR. This time permits to the modem to ignore DTR before taking action
specified by &Dn (See AT&D Circuit 108 behavior).
The value unit is in 1/100 seconds. Default value is set to 5 (50ms delay after a DTR drop before
the modem acts on it).
ATS25 Set DTR change time
Read Command
ATS25?
Response
<n>
OK
NB: <n> is in 3 decimal digits format (e.g. Default value is given as 000).
If error is related to wrong AT syntax:
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 27 2018-04-10
+CME ERROR: <err>
Parameters
See Write Command
Write Command
ATS25=<n>
Response
OK
ERROR
Parameters
<n> 0-5-255 Number of 10 ms.
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.21 ATS95 Some PC modem driver initial setting to enable extended result codes
ATS95 Some PC modem driver initial setting to enable extended result codes
Read Command
ATS95?
Response
OK
Parameters
See Write Command
Write Command
ATS95=<n>
Response
OK
Some standard PC modem drivers will send this AT command to initialize the
setting, but it is meaningless in the 3gpp standard. So we just return OK and no
effect for the setting.
Parameters
<n> 0-255 meaningless for the GSM, and GPRS/Packet Domain setting
.
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.22 ATT Select Tone Dialing
ATT Select Tone Dialing
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 28 2018-04-10
Execution
Command
ATT
Response
OK
Parameter Saving
Mode
AUTO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.23 ATV TA Response Format
ATV TA Response Format
Execution
Command
ATV<value>
Response
This parameter setting determines the contents of the header and trailer
transmitted with result codes and information responses.
When <value>=0
0
When <value>=1
OK
Parameters
<value> 0 Information response: <text><CR><LF>
Short result code format: <numeric code><CR>
1 Information response: <CR><LF><text><CR><LF>
Long result code format: <CR><LF><verbose code>
<CR><LF>
The result codes, their numeric equivalents and brief descriptions of the use
of each are listed in the following table.
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
ATV1
ATV0
Description
OK 0 Acknowledges execution of a Command
CONNECT 1
A connection has been established; the DCE is moving from
Command state to online data state
RING 2
The DCE has detected an incoming call signal from
network
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 29 2018-04-10
NO CARRIER 3 The connection has
been terminated or the attempt to
establish a connection failed
ERROR 4
Command not recognized, Command line maximum length
exceeded, parameter value invalid, or other problem with
processing the Command line
NO DIALTONE 6 No dial tone detected
BUSY 7 Engaged (busy) signal detected
NO ANSWER 8
"@" (Wait for Quiet Answer) dial modifier was used, but
remote ringing followed by five seconds of silence was not
detected before expiration of the connection timer (S7)
PROCEEDING 9 An AT command is being processed
CONNECT
<text>
Manufacturer-
specific
Same as CONNECT, but includes manufacturer-specific
text that may specify DTE speed, line speed, error control,
data compression, or other status
2.1.24 ATX Set CONNECT Result Code Format and Monitor Call Progress
ATX Set CONNECT Result Code Format and Monitor Call Progress
Execution
Command
ATX<value>
Response
This parameter setting determines whether or not the TA detected the
presence of dial tone and busy signal and whether or not TA transmits
particular result codes.
OK
ERROR
Parameters
<value> 0 CONNECT result code only returned, dial tone and busy
detection are both disabled.
1 CONNECT<text>
result code only returned, dial tone and
busy detection are both disabled.
2 CONNECT<text> result code returned, dial tone
detection is enabled, busy detection is disabled.
3 CONNECT<text> result code returned, dial tone
detection is disabled, busy detection is enabled.
4 CONNECT<text> result code returned, dial tone and
busy detection are both enabled.
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 30 2018-04-10
2.1.25 ATZ Reset Default Configuration
ATZ Reset Default Configuration
Execution
Command
ATZ[<value>]
Response
TA sets all current parameters to the user defined profile.
OK
ERROR
Parameters
<value> 0 Restore profile 0
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
Parameter impacted by Z command: refer to AT&W
NOTE:
Parameters related to uart operation, like csclk, ipr, icf and ifc, will not be reset to default configuration.
2.1.26 AT&C Set DCD Function Mode
AT&C Set DCD Function Mode
Execution
Command
AT&C<value>
Response
This parameter determines how the state of circuit 109 (DCD)
relates to the
detection of received line signal from the distant end.
OK
ERROR
Parameters
<value> 0 DCD line is always ON
1 DCD
line is ON only in the presence of data carrier
Parameter Saving
Mode
-
Max Response
Time
-
Reference
V.25ter
Note
2.1.27 AT&D Set DTR Function Mode
AT&D Set DTR Function Mode
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 31 2018-04-10
Execution
Command
AT&D[<value>]
Response
This parameter determines how the TA responds when circuit 108/2
(DTR)
is changed from the ON to the OFF condition during data mode.
OK
or
ERROR
Parameters
<value> 0 TA ignores status on DTR.
1 ON->OFF on DTR: Change to Command mode with
remaining the connected call.
2 ON->OFF on DTR: Disconnect call, change to Command
mode. During state DTR = OFF is auto-answer off.
Parameter Saving
Mode
-
Max Response
Time
-
Reference
V.25ter
Note
2.1.28 AT&F Factory Defined Configuration
AT&F Factory Defined Configuration
Execution
Command
AT&F[<value>]
Response
TA sets all current parameters to the manufacturer defined profile.
OK
Parameters
<value> 0 Set all TA parameters to manufacturer defaults.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
Parameter impacted by &F command: refer to AT&W
NOTE:
Parameters related to uart operation, like csclk, ipr, icf and ifc, will not be reset to default configuration.
2.1.29 AT&K Flow control setting
AT&K Flow control setting
Execution
Command
Response
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 32 2018-04-10
AT&K[<value>] Parameters
<value> 0 No flow control
3 RTS /CTS flow control (hardware)
4 XON/XOFF flow control (software)
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
This command does not store anything in the profile data because it sets the
AT+IFC settings when used:
- AT&K0 is equivalent of entering AT+IFC=0,0
- AT&K3 is equivalent of entering AT+IFC=2,2
- AT&K4 is equivalent of entering AT+IFC=1,1
2.1.30 AT&V Display Current Configuration
AT&V Display Current Configuration
Execution
Command
AT&V[<n>]
Response
TA returns the current parameter setting.
<current configurations text>
OK
or
ERROR
Parameters
<n> 0 Responses in numeric format
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.31 AT&W Store Active Profile
AT&W Store Active Profile
Execution
Command
AT&W[<n>]
Response
TA stores the current parameter setting in the user defined profile.
OK
or
ERROR
Parameters
<n> 0 Store the current configuration in profile 0
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 33 2018-04-10
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
The user defined profile is stored in non volatile memory.
Parameter stored by &W
Command
Parameter name
Displayedby &V
ATS0 <num> Y
ATS3 <char> Y
ATS4 <char> Y
ATS5 <char> Y
ATS6
<short>
Y
ATS7 <time> Y
ATS8
<time>
Y
ATS10 <time> Y
ATV <format> Y
ATE <echo> Y
ATQ <result> Y
ATX
<result>
Y
AT&C <behavior> Y
AT&D
<behavior>
Y
AT+CLTS <timestamp> Y
AT+CREG <n> Y
AT+CGREG <n> Y
AT+CMEE
<n>
Y
AT+CSCLK
<n>
Y
AT+CSCS <chest> Y
AT+CSMINS <n> Y
AT+EXUNSOL <exunsol> Y
AT+IPR <n> Y
AT+IFC <TA_by_TE>, <TE_by_TA> Y
2.1.32 AT+DR V.42bis data compression reporting control
AT+DR
V.42bis data compression reporting control
Test Command
AT+DR=?
Response
+DR: (list of supported <value>s)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 34 2018-04-10
OK
Parameters
Read Command
AT+DR?
Response
+DR: <value>
OK
Parameters
See Write Command
Write Command
AT+DR=<value>
Response
This parameter setting determines whether the intermediate result code of the
current data compressing is reported by TA to TE after a connection
establishment.
OK
Parameters
<value> 0 reporting disabled
1 reporting enabled
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.33 AT+DS V.42bis data compression control
AT+DS
V.42bis data compression control
Test Command
AT+DS=?
Response
+DS: (list of supported <p0>s), (list of supported <n>s), (list of supported
<p1>s), (list of supported <p2>s)
OK
Parameters
See Write Command
Read Command
AT+DS?
Response
+DS: <p0>,<n>,<p1>,<p2>
OK
Parameters
See Write Command
Write Command
AT+DS=[<p0>,[<
Response
This parameter setting determines the possible data compression mode by TA at
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 35 2018-04-10
n>,[<p1>,[<p2>]]]
]
the compression negotiation with the remote TA after a call set up.
OK
Parameters
<p0> 0 NONE
1 transmit only
2 receive only
3 both direction, but allow negotiation
<n> 0 allow negotiation of p0 down
1 do not allow negotiation of p0 - disconnect on difference
<p1> 512-1024 dictionary size
Note: default determined by manufacturer
<p2> 6-20-64 maximum string size (default 20)
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
only for data call
GSM transmits the data transparent. The remote TA may support this
compression.
2.1.34 AT+GCAP Request Complete TA Capabilities List
AT+GCAP Request Complete TA Capabilities List
Execution
Command
AT+GCAP
Response
TA reports a list of additional capabilities.
+GCAP: list of supported <name>s
OK
Parameters
<name> +CGSM GSM function is supported
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.35 AT+GMI Request Manufacturer Identification
AT+GMI Request Manufacturer Identification
Test Command
AT+GMI=?
Response
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 36 2018-04-10
Parameters
Execution
Command
AT+GMI
TA reports one or more lines of information text which permit the user to
identify the manufacturer.
SIMCOM_Ltd
OK
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.36 AT+GMM Request TA Model Identification
AT+GMM Request TA Model Identification
Test Command
AT+GMM=?
Response
OK
Execution
Command
AT+GMM
TA reports one or more lines of information text which permit the user to
identify the specific model of device.
<model>
OK
Parameters
<model> Product model identification text
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.37 AT+GMR Request TA Revision Identification of Software Release
AT+GMR Request TA Revision Identification of Software Release
Test Command
AT+GMR=?
Response
OK
Execution
TA reports one or more lines of information text which permit the user to
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 37 2018-04-10
Command
AT+GMR
identify the revision of software release.
Revision: <revision>
OK
Parameters
<revision> Revision of software release
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.38 AT+GOI Request Global Object Identification
AT+GOI Request Global Object Identification
Test Command
AT+GOI=?
Response
OK
Execution
Command
AT+GOI
Response
TA reports one or more lines of information text which permit the user to
identify the device, based on the ISO system for registering unique object
identifiers.
<Object Id>
OK
Parameters
<Object Id> Identifier of device type
see X.208, 209 for the format of <Object Id>
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.39 AT+GSN Request TA Serial Number Identification (IMEI)
AT+GSN Request TA Serial Number Identification(IMEI)
Test Command
AT+GSN=?
Response
OK
Execution
Response
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 38 2018-04-10
Command
AT+GSN
TA reports the IMEI (international mobile equipment identifier) number in
information text which permit the user to identify the individual ME device.
<sn>
OK
Parameters
<sn> IMEI of the telephone(International Mobile s
tation Equipment
Identity)
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
V.25ter
Note
The serial number (IMEI) is varied by individual ME device.
2.1.40 AT+ICF Set TE-TA Control Character Framing
AT+ICF Set TE-TA Control Character Framing
Test Command
AT+ICF=?
Response
+ICF: (list of supported <format>s),(list of supported <parity>s)
OK
Parameters
See Write Command
Read Command
AT+ICF?
Response
+ICF: <format>,<parity>
OK
Parameters
See Write Command
Write Command
AT+ICF=<forma
t>[,<parity>]
Response
This parameter setting determines the serial interface character framing
format and parity received by TA from TE.
OK
Parameters
<format> 1 8 data 0 parity 2 stop
2 8 data 1 parity 1 stop
3 8 data 0 parity 1 stop
4 7 data 0 parity 2 stop
5 7 data 1 parity 1 stop
6 7 data 0 parity 1 stop
<parity> 0 odd
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 39 2018-04-10
1 even
2 mark(1)
3 space (0)
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
The Command is applied for Command state;
In <format> parameter, "0 parity" means no parity;
The <parity> field is ignored if the <format>
field specifies no parity and
string "+ICF: <format>,255" will be response to "AT+ICF? " Command.
2.1.41 AT+IFC Set TE-TA Local Data Flow Control
AT+IFC Set TE-TA Local Data Flow Control
Test Command
AT+IFC=?
Response
+IFC: (list of supported <dce_by_dte>s),(
list of supported
<dte_by_dce>s)
OK
Parameters
See Write Command
Read Command
AT+IFC?
Response
+IFC: <dce_by_dte>,<dte_by_dce>
OK
Parameters
See Write Command
Write Command
AT+IFC=<dce_b
y_dte>[,<dte_by
_dce>]
Response
This parameter setting determines the data flow control on the serial
interface for data mode.
OK
Parameters
<dce_by_dte> Specifies the method will be used by T
E at receive of
data from TA
0 No flow control
1 Software flow control
2 Hardware flow control
<dte_by_dce> S
pecifies the method will be used by TA at receive of data
from TE
0 No flow control
1 Software flow control
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 40 2018-04-10
2 Hardware flow control
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
2.1.42 AT+ILRR Set TE-TA Local rate reporting mode
AT+ILRR Set TE-TA Local rate reporting mode
Test Command
AT+ILRR=?
Response
+ILRR: (list of supported <value>s
OK
Parameters
See Write Command
Read Command
AT+ILRR?
Response
+ILRR: <value>
OK
Parameters
See Write Command
Write Command
AT+ILRR=<valu
e>
Response
This parameter setting determines whether an intermediate result code of
local
rate is reported at connection establishment. The rate is applied after the result
code of the connection is transmitted to TE.
OK
Parameters
<value>
0 Disables reporting of local port rate
1 Enables reporting of local port rate
Paramete
r Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
2.1.43 AT+IPR Set TE-TA Fixed Local Rate
AT+IPR Set TE-TA Fixed Local Rate
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 41 2018-04-10
Test Command
AT+IPR=?
Response
+IPR: (list of supported auto detectable <rate>s),(
list of supported
fixed-only <rate>s)
OK
Parameters
See Write Command
Read Command
AT+IPR?
Response
+IPR: <rate>
OK
Parameters
See Write Command
Write Command
AT+IPR=<rate>
Response
This parameter setting determines the data rate of the TA on the serial
interface. The rate of Command
takes effect following the issuance of any
result code associated with the current Command line.
OK
Parameters
<rate> Baud rate per second
0
110
300
1200
2400
4800
9600
19200
38400
57600
115200
230400
460800
921600
3000000
Parameter Savi
ng
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
Factory setting is "AT+IPR=0"(auto-bauding).
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 42 2018-04-10
2.1.44 AT+FCLASS Set Fax Class
AT+FCLASS Set Fax Class
Test Command
AT+FCLASS=?
Response
+FCLASS: (list of supported <n>s)
OK
Parameters
See Write Command
Read Command
AT+FCLASS?
Response
+FCLASS: <n>
OK
Parameters
See Write Command
Write Command
AT+FCLASS=<n
>
Response
This command has no effect in NB-
IoT and is supported for compatibility
reasons.
OK
Parameters
<n> 0 Data
1 Fax class 1 (TIA-578-A)
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
V.25ter
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 43 2018-04-10
3 AT Commands According to 3GPP TS 27.007
3.1 Overview of AT Command According to 3GPP TS 27.007
Command
Description
AT+CEER
Extended error report
AT+CGMI Request manufacturer identification
AT+CGMM Request model identification
AT+CGMR Request TA revision identification of software release
AT+CGOI Request global object identification
AT+CGSN Request product serial number identification (identical with +GSN)
AT+CIMI
Request international mobile subscriber identity
AT+CLCK Facility lock
AT+CMAR
Master reset
AT+CMEE Report mobile equipment error
AT+COPS Operator selection
AT+CPIN Enter PIN
AT+CPWD Change password
AT+CR
Service reporting control
AT+CREG Network registration
AT+CRSM Restricted SIM access
AT+CSCS Select TE character set
AT+CSQ Signal quality report
AT+CMUX Multiplexer control
AT+CNUM
Subscriber number
AT+CPOL
Preferred operator list
AT+CFUN Set phone functionality
AT+CCLK
Clock
AT+CSIM Generic SIM access
AT+CBC Battery charge
AT+CTZR Time zone reporting
AT+CTZU Automatic time zone update
AT+CPLS Selection of preferred PLMN list
AT+CPSMS Power saving mode selection
AT+CIPCA Enable/disable activation of PDN connection on attach.
AT+CEDRXS eDRX setting
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 44 2018-04-10
AT+CEDRXRDP
eDRX read dynamic parameters
AT+CCHO Open UICC logical channel
AT+CCHC Close UICC logical channel
AT+CGLA Generic UICC logical channel access
AT+CPINR Remaining PIN retries
AT+CGATT GPRS/Packet Domain attach or detach
AT+CGDCONT Define PDP context
AT+CGACT
PDP context activate or deactivate
AT+CGPADDR Show PDP address
AT+CGEREP Packet Domain Event Reporting
AT+CGREG Network registration status
AT+CGCONTR
DP
PDP Context Read Dynamic Parameters
AT+CGPIAF Printing IP Address Format
AT+CGDEL Delete Non-Active PDP Contexts
AT+CGAUTH Define PDP Context Authentication Parameters
AT*MCGDEFC
ONT
Set Default PSD Connection Settings
AT*MSACL Enable/Disable ACL feature
AT*MLACL Display ACL List
AT*MWACL Write an ACL entry
AT*MDACL Delete an ACL entry
AT+CNBIOTDT NB-IOT Data Type
3.2 Detailed Descriptions of AT Command According to 3GPP TS 27.007
3.2.1 AT+CEER Extended Error Report
AT+CEER Extended Error Report
Test Command
AT+CEER=?
Response
+CEER: (list of supported <n>s)
OK
Parameters
See Write Command
Read Command
AT+CEER?
Response
+CEER: <n>
OK
Parameters
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 45 2018-04-10
See Write Command
Write Command
AT+CEER=<n>
Response
OK
Parameter
<n> 0 The reason for last call release as text code
1 The reason for last call release as number code
Execution
Command
AT+CEER
Response
TA returns an extended report of the reason for the last call release.
+CEER: <report>
OK
Parameters
<report> If AT+CEER=0, return <s>
<s> a string that represents the Cause
If AT+CEER=1, return
Cause: <c>
<c> number representing the Cause
Parameters
<c>(number) <s>(string)
0 (No cause)
1 (unassigned (unallocated) number)
3 (no route to destination)
6 (channel unacceptable)
8 (operator determined barring)
16 (normal call clearing)
17 (user busy)
18 (no user responding)
19 (user alerting, no answer)
21 (call rejected)
22 (number changed)
26 (non-selected user clearing)
27 (destination out of order)
28 (invalid number format (incomplete number))
29 (facility rejected)
30 (response to STATUS ENQUIRY)
31 (normal, unspecified)
34 (emergency call not possible)
38 (network out of order)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 46 2018-04-10
41 (temporary failure)
42 (switching equipment congestion)
43 (access information discarded)
44 (requested circuit/channel not available)
47 (resource unavailable, unspecified)
49 (quality of service unavailable)
50 (Requested facility not subscribed)
55 (Incoming calls barred within the CUG)
57 (bearer capability not authorized)
58 (bearer capability not presently available)
63 (service or option not available, unspecified)
68 (ACM equal to or greater than ACMmax)
65 (bearer service not implemented)
69 (Requested facility not implemented)
70 (only restricted digital information bearer capability is
available)
79 (service or option not implemented,unspecified)
81 (invalid transaction identifier value)
87 (user not member of CUG)
88 (incompatible destination)
91 (invalid transit network selection)
95 (semantically incorrect message)
96 (invalid mandatory information)
97 (message type non-existent or not implemented)
98 (message type not compatible with protocol state)
99 (information element non-existent or not implemented)
100 (conditional IE error)
101 (message not compatible with protocol state)
102 (recovery on timer expiry)
111 (protocol error, unspecified)
127 (interworking, unspecified)
Parameter
Saving Mode
NO_SAVE
Max Response
-
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 47 2018-04-10
Time
Reference
3GPP TS 27.007
[13]
Note
3.2.2 AT+CGMI Request Manufacturer Identification
AT+CGMI Request Manufacturer Identification
Test Command
AT+CGMI=?
Response
OK
Execution
Command
AT+CGMI
Response
TA returns manufacturer identification text.
<manufacturer>
OK
Parameters
<manufacturer> The ID of manufacturer
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.3 AT+CGMM Request Model Identification
AT+CGMM Request Model Identification
Test Command
AT+CGMM=?
Response
OK
Execution
Command
AT+CGMM
Response
TA returns product model identification text.
<model>
OK
Parameters
<model> Product model identification text
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 48 2018-04-10
[13]
3.2.4 AT+CGMR Request TA Revision Identification of Software Release
AT+CGMR Request TA Revision Identification of Software Release
Test Command
AT+CGMR=?
Response
OK
Execution
Command
AT+CGMR
Response
TA returns product software version identification text.
Revision: <revision>
OK
Parameters
<revision> Product software version identification text
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.5 AT+CGOI Request global object identification
AT+CGOI Request global object identification
Test Command
AT+CGOI=?
Response
OK
Execution
Command
AT+CGOI
Response
TA returns global object id.
<Object Id>
OK
Parameters
<Object Id> identifier of device type
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 49 2018-04-10
3.2.6 AT+CGSN Request Product Serial Number Identification
AT+CGSN Request Product Serial Number Identification (Identical with +GSN)
Test Command
AT+CGSN=?
Response
OK
Execution
Command
AT+CGSN
Response
see +GSN
<sn>
OK
Parameters
<sn> International mobile equipment identity (IMEI)
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.7 AT+CIMI Request International Mobile Subscriber Identity
AT+CIMI Request International Mobile Subscriber Identity
Test Command
AT+CIMI=?
Response
OK
Execution
Command
AT+CIMI
Response
TA returns <IMSI>for identifying the individual SIM which is attached to
ME.
<IMSI>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<IMSI> International Mobile Subscriber Identity (string without
double quotes)
Parameter Saving
Mode
NO_SAVE
Max Response
Time
20s
Reference
3GPP TS 27.007
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 50 2018-04-10
[13]
3.2.8 AT+CLCK Facility Lock
AT+CLCK Facility Lock
Test Command
AT+CLCK=?
Response
+CLCK: (list of supported <fac>s)
OK
Parameters
See Write Command
Write Command
AT+CLCK=<fac
>,<mode>[,<pass
wd>[,<class>]]
Response
This Command is used to lock,
unlock or interrogate a ME or a network
facility <fac
>. Password is normally needed to do such actions. When
querying the status of a network service (<mode
>=2) the response line for
‘not active’ case (<status>=0) should be returned only if service is not
active for any <class>.
If <mode>≠2 and Command is successful
OK
If <mode>=2 and Command is successful
+CLCK: <status>[,<class1>[<CR><LF>+CLCK:
<status>,<class2>[…]]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<fac> "SC" SIM (lock SIM/UICC card) (SIM/UICC asks password
in MT power-up and when this lock command issued) Correspond to PIN1
code.
<mode> 0 unlock
1 lock
2 query status
<passwd> String type (Shall be the same as password specified for the
facility from the MT user interface or with command Change Password
+CPWD)
<class> Field not required for NB-IOT, so will be ignored
<status> 0 Not active
1 Active
Parameter Saving
Mode
NO_SAVE
Max Response
15s
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 51 2018-04-10
Time
Reference
3GPP TS 27.007
[14]
Note
- CME errors if SIM not inserted or PIN is not entered.
3.2.9 AT+CMAR Master reset
AT+CMAR Master reset
Test Command
AT+CMAR=?
Response
OK
Parameters
See Write Command
Write Command
AT+CMAR=<p
hone lock code>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<phone lock code> string type; Security code (Phone Lock code) must be
verified before performing the master reset.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.10 AT+CMEE Report Mobile Equipment Error
AT+CMEE Report Mobile Equipment Error
Test Command
AT+CMEE=?
Response
+CMEE: (list of supported <n>s)
OK
Parameters
See Write Command
Read Command
AT+CMEE?
Response
+CMEE: <n>
OK
Parameters
See Write Command
Write Command Response
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 52 2018-04-10
AT+CMEE=[<n
>]
TA disables or enables the use of result code +CME ERROR: <err> as an
indication of an error relating to the functionality of the ME.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<n> 0 Disable +CME ERROR: <err> result code and use
ERROR instead.
1 Enable +CME ERROR: <err> result code and use numeric
<err>
2 Enable +CME ERROR: <err> result code and use verbose
<err> values
Parameter Saving
Mode
-
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.11 AT+COPS Operator Selection
AT+COPS Operator Selection
Test Command
AT+COPS=?
Response
TA returns a list of quadruplets, each representing an operator present in
the network. Any of the formats may be unavailable and should then be an
empty field. The list of oper
ators shall be in order: home network,
networks referenced in SIM, and other networks.
+COPS: (list of supported<stat>,long alphanumeric<oper>,short
alphanumeric<oper>,numeric <oper>[,<AcT>])s[,,(list of supported
<mode>s),(list of supported <format>s)]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Read Command
AT+COPS?
Response
TA returns the current mode and the currently selected operator. If no
operator is selected,<format> and <oper> are omitted.
+COPS: <mode>[,<format>,<oper>,<AcT>]
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 53 2018-04-10
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+COPS=<mo
de>,[<format>[,
<oper>[,<AcT>]
]]
Response
TA forces an attempt to select and register the GSM network o
perator. If
the selected operator is not available, no other operator shall be selected
(except <mode
>=4). The selected operator name format shall apply to
further read commands (AT+COPS?).
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<stat> 0 Unknown
1 Operator available
2 Operator current
3 Operator forbidden
<oper> Refer to [27.007]
operator in format as per <format>
<mode> 0 Automatic mode; <oper> field is ignored
1 Manual (<oper> field shall be present, and <AcT>
optionally)
2 manual deregister from network
3 set only <format> (for read Command +COPS?) - not
shown in Read Command response
4 Manual/automatic (<oper> field shall be present); if
manual selection fails, automatic mode (<mode>=0) is
entered
<format> 0 Long format alphanumeric <oper>
1 Short format alphanumeric <oper>
2 Numeric <oper>; GSM Location Area Identification
number
<AcT> 9 NB-IoT
Parameter Saving
Mode
AUTO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[14]
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 54 2018-04-10
3.2.12 AT+CPIN Enter PIN
AT+CPIN Enter PIN
Test Command
AT+CPIN=?
Response
OK
Read Command
AT+CPIN?
Response
TA returns an alphanumeric string indicating whether some password is
required or not.
+CPIN: <code>
OK
Parameters
<code>
READY MT is not pending for any password
SIM PIN MT is waiting SIM PIN to be given
SIM PUK MT is waiting for SIM PUK to be given
PH_SIM PIN ME is waiting for phone to SIM card (antitheft)
PH_SIM PUK ME is waiting for SIM PUK (antitheft)
SIM PIN2
PIN2, e.g. for editing the FDN book possible only
if preceding Command was acknowledged with +CME
ERROR:17
SIM PUK2 P
ossible only if preceding Command was
acknowledged with error +CME ERROR: 18.
PH-SIM PIN ME is waiting for phone to SIM card (antitheft)
PH-NET PIN Network personalization password is required.
PH-NETSUB PIN Network subset is required.
PH-SP PIN
Service provider personalization password is
required.
PH-CORP PIN Corporate personalization password is required.
Write Command
AT+CPIN=<pin>
[,<new pin>]
Response
TA stores a required password (SIM PIN, SIM PUK, PH-SIM PIN, etc.). If
the PIN is to be entered twice, the TA shall automatically repeat the PIN. If
no PIN request is pending, no action is taken and an
error message, +CME
ERROR, is returned to TE.
If the PIN required is SIM PUK or SIM PUK2, the second pin is required.
This second pin,<new pin>, is used to replace the old pin in the SIM.
When a new password is set, a third optional parameter may also be
specified. This extra parameter is compared to the new password to check
they are equivalent as an additional security feature.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 55 2018-04-10
<pin> String type; password
<new pin> String ty
pe; If the PIN required is SIM PUK or SIMPUK2:
new password
Parameter Saving
Mode
NO_SAVE
Max Response
Time
5s
Reference
3GPP TS 27.007
[13]
Note
3.2.13 AT+CPWD Change Password
AT+CPWD Change Password
Test Command
AT+CPWD=?
Response
TA returns a list of p
airs which present the available facilities and the
maximum length of their password.
+CPWD: (list of supported <fac>s, list of supported <pwdlength>s)
OK
Parameters
<fac> See Write Command
<pwdlength> Integer max. length of password
Write Command
AT+CPWD=<fac
>,<oldpwd>,<ne
wpwd>
Response
TA sets a new password for the facility lock function.
OK
Parameters
<fac> "SC" SIM (lock SIM/UICC card) (SIM/UICC asks password in
MT power-up and when this lock command issued) Correspond to PIN1
code.
<oldpwd> String type (string should be included in quotation marks):
password specified for the facility from the user interface or with c
ommand.
If an old password has not yet been set, <oldpwd> is not to enter.
<newpwd> String type (string should be included in quotation marks):
new password
Parameter Saving
Mode
NO_SAVE
Max Response
Time
15s
Reference
3GPP TS 27.007
[13]
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 56 2018-04-10
3.2.14 AT+CR Service Reporting Control
AT+CR Service Reporting Control
Test Command
AT+CR=?
Response
+CR: (list of supported <mode>s)
OK
Parameters
See Write Command
Read Command
AT+CR?
Response
+CR: <mode>
OK
Parameters
See Write Command
Write Command
AT+CR=[<mode
>]
Response
TA controls whether or not intermediate result code +CR: <serv> is
returned from the TA to the TE at a call set up.
OK
Parameters
<mode> 0 Disable
1 Enable
2 Enable MediaTek proprietary intermediate result code
Intermediate result code
If enabled, an intermediate result code is transmitted at the point during
connect negotiation at which the
TA has determined which speed and
quality of service will be used, before any error control or data
compression reports are transmitted, and before any final result code (e.g.
CONNECT) is transmitted.
+CR: <serv>
Parameters
<serv> GPRS[<L2P>] GPRS / Packet Switched connection
<L2P> M-PT Packet Transport mechanism protocol for a PDP such
as IP
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
<L2P> value M-PT is MTK proprietary and represents no <L
2p> but raw
IP packet transfer.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 57 2018-04-10
3.2.15 AT+CREG Network Registration
AT+CREG Network Registration
Test Command
AT+CREG=?
Response
+CREG: (list of supported <n>s)
OK
Parameters
See Write Command
Read Command
AT+CREG?
Response
TA returns the status of result code presentation and an integer <stat>
which shows whether the network has currently indicated the registration
of the ME. Location information elements <lac> and <ci
> are returned
only when <n>=2 and ME is registered in the network.
+CREG: <n>,<stat>[,<lac>,<ci>[,<AcT>]]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CREG[=<n
>]
Response
TA controls the presentation of an unsolicited result code +CREG: <stat>
when <n>=1 and there is a change in the ME network registration status.
OK
Parameters
<n> 0 Disable network registration unsolicited result code
1 Enable network registration unsolicited result code
+CREG: <stat>
2 Enable network registration unsolicited result code with
location information +CREG:
<stat>[,<lac>,<ci>[,<AcT>]]
<stat> 0 Not registered, MT is not currently searching a new
operator to register to
1 Registered, home network
2 Not registered, but MT is currently searching a new
operator to register to
3 Registration denied
4 Unknown
5 Registered, roaming
6 registered for “SMS only”, home network (applicable
only when <Act> indicates NB-IOT
7 registered for “SMS only”, roaming (applicable only
when <Act> indicates NB-IOT
<lac> String type (string should be included in quotation marks);
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 58 2018-04-10
two byte location area code in hexadecimal format
<ci>
String type (string should be included in quotation marks);
four byte cell ID in hexadecimal format
<AcT> Access technology of the registered network 9 NB-IoT
Unsolicited Result Code
If <n>=1 and there is a change in the MT network registration status
+CREG: <stat>
If <n>=2 and there is a change in the MT network registration status or a
change of the network cell:
+CREG: <stat>[,<lac>,<ci> [,<AcT>]]
Parameters
See Write Command
Parameter Saving
Mode
-
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.16 AT+CRSM Restricted SIM Access
AT+CRSM Restricted SIM Access
Test Command
AT+CRSM=?
Response
OK
Write Command
AT+CRSM=<C
ommand>[,<file
Id>[,<P1>,<P2>,
<P3>[,<data>[,<
pathid>]]]]
Response
+CRSM: <sw1>,<sw2>[,<response>]
OK
ERROR
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<Command>
176 READ BINARY
178 READ RECORD
192 GET RESPONSE
214 UPDATE BINARY
220 UPDATE RECORD
242 STATUS
All other values are reserved; refer GSM 11.11.
<fileId> Integer type; this is the identifier for an elementary data file on
SIM. Mandatory for every Command except STATUS
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 59 2018-04-10
<P1>,<P2>,<P3> Integer type, range 0 – 255
Parameters to be passed on by the ME to the SIM; refer GSM
11.11.
<data> Information which shall be written to the SIM (hex-decimal
character format)
<sw1>,<sw2> Integer type, range 0 - 255
Status information from the SIM about the execution of the
actual Command. These parameters are delivered to the TE in
both cases, on successful or failed execution of the Command;
refer GSM 11.11.
<response> Response of a successful completion of the Command
previously issued (hexadecimal character format)
<pathid> String type; contains the path of an elementary file on the
SIM/UICC in hexadecimal format as defined in ETSI TS 102.211 (e.g.
“7F205F70” in SIM and UICC case). The <pathid> only used in the mode
“select path from MF” as defined in ETSI TS 102.211.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
GSM 11.11
Note
3.2.17 AT+CSCS Select TE Character Set
AT+CSCS Select TE Character Set
Test Command
AT+CSCS=?
Response
+CSCS: (list of supported <chset>s)
OK
Parameters
<chset> "GSM" GSM 7 bit default alphabet (3GPP TS 23.038);
"UCS2" 16-bit universal multiple-
octet coded character set
(ISO/IEC10646); UCS2 character strings are converted to
hexadecimal numbers from 0000 to FFFF; e.g.
"004100620063" equals three 16-bit characters with decimal
values 65, 98 and 99
"IRA" International reference alphabet (ITU-T T.50)
"HEX" Character strings consist only of hexadecimal
bers from 00 to FF;
"PCCP" PC character set Code
"PCDN" PC Danish/Norwegian character set
"8859-1" ISO 8859 Latin 1 character set
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 60 2018-04-10
Read Command
AT+CSCS?
Response
+CSCS: <chset>
OK
Parameters
See Test Command
Write Command
AT+CSCS=<chs
et>
Response
Sets which character set <chset> are used by the TE. The TA can then
convert character strings correctly between the TE and ME character sets.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Test Command
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.18 AT+CSQ Signal Quality Report
AT+CSQ Signal Quality Report
Test Command
AT+CSQ=?
Response
+CSQ: (list of supported <rssi>s),(list of supported <ber>s)
OK
Execution
Command
AT+CSQ
Response
+CSQ: <rssi>,<ber>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Execution Command returns received signal strength indication <rssi> and
channel bit error rate <ber
> from the ME. Test Command returns values
supported by the TA.
Parameters
<rssi> Integer type. Rx signal strength level
0 -110 dBm or less
1 -109 dBm <= rssi < -107 dBm
2 -107 dBm <= rssi < -105 dBm
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 61 2018-04-10
3…30 -105dBm <= rssi < -48 dBm
31 -48dBm <= rssi
99 Not known or not detectable
<ber> (in percent):
0...7 As RXQUAL values in the table in GSM 05.08 [20]
subclause 7.2.4
99 Not known or not detectable
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.19 AT+CMUX Multiplexer Control
AT+CMUX Multiplexer Control
Test Command
AT+CMUX=?
Response
+CMUX: (list of supported <mode>s),(list of supported <subset>s),(list
of supported<port_speed>s),(list of supported<N1
>s),(list of
supported<T1>s),(list of supported<N2>s),(list if supported<T2>s),(list of
supported <T3>s),<list of supported <k>s)
OK
Parameters
See Write Command
Read Command
AT+CMUX?
Response:
+CMUX:
[<mode>[,<subset>[,<port_speed>[,<N1>[,<T1>[,<N2>[,<T2>[,<T3>[,
<k>]]]]]]]]]
OK
or
ERROR
Parameters
<mode>
1 Multiplexer not active
0 27.010 multiplexer
<subset> The way in which the multiplexer control channel is set up
0 UIH frames used only
<port_speed> Transmission rate
1 9600 bits/t
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 62 2018-04-10
2 19200 bits/t
3 38400 bits/t
4 57600 bits/t
5 115200 bit/s
6 230400 bits/t
7 460800 bits/t
Proprietary values, available if MUX NEW PORT
SPEED FTR is activated
<N1> Maximum frame size
1-4096 (default value 31 for basic option)
<T1> Acknowledgement timer in units of ten milliseconds
1-255 Default:10 (100 ms)
<N2> Maximum number of re-transmissions
0-100 Default:3
<T2> Max Response Timer for the multiplexer control channel in
units of ten milliseconds
2-255 Default:30
<T3> Wake up Max Response Timers in seconds
1-255 Default:10
<k> Window size, for Advanced operation with Error Recovery
options
1-7 Default:2
Write Command
AT+CMUX=<m
ode>[,<subset>[,
<port_speed>[,<
N1>[,<T1>[,<N2
>[,<T2>[,<T3>[,
<k>]]]]]]]]
Response
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<mode> Multiplexer transparency mechanism
0 Basic option
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
- The values of <<subset>, <port_speed>, <N1>,<T>,<N2>,<T2>,
<T3>,<k> are only relevent to the 27.010 MUX control channel.
- <port_speed> set to 0 will set the MUX port rate at whatever the
AT+IPR setting is for the channel.
3.2.20 AT+CNUM Subscriber Number
AT+CNUM Subscriber Number
Test Command Response
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 63 2018-04-10
AT+CNUM=?
OK
Execution
Command
AT+CNUM
Response
+CNUM: [<alpha1>],<number1>,<type1>
[<CR><LF>+CNUM:[<alpha2>],<number2>,<type2>
[...]]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<alphax> Optional alphanumeric string associated with <numberx>;
used character set should be the one selected with Command Select TE
Character Set +CSCS.
<numberx> String type (string should be included in quotation marks)
phone number of format specified by <typex>
<typex> Type of address octet in integer format (refer GSM04.08[8]
subclause 10.5.4.7)
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.21 AT+CPOL Preferred Operator List
AT+CPOL Preferred Operator List
Test Command
AT+CPOL=?
Response
+CPOL: (list of supported <index>s),(list of supported <format>s)
OK
Parameters
See Write Command
Read Command
AT+CPOL?
Response
+CPOL:
<index1>,<format>,<oper1>[,<GSM_AcT1>,<GSMcomp_AcT1>,<UTR
AN_AcT1>,<E-UTRAN_Act1]
[<CR><LF>+CPOL: <index2>,<format>,<oper2>
[,<GSM_AcT2>,<GSMcomp_AcT2>,<UTRAN_AcT2,<E-UTRAN_AcT2>
]
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 64 2018-04-10
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CPOL=<in
dex>[,<format>,
<oper>]
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<index> Integer type: order number of operator in SIM preferred
operator list
<format> Indicates whether alphanumeric or numeric
format used (see +COPS Command)
0 Long format alphanumeric <oper>
1 Short format alphanumeric <oper>
2 Numeric <oper>
<oper> String type(string should be included in quotation marks)
<GSM_AcTn> GSM Access technology;
0 Access technology not selected
1 Access technology selected
<GSM_Comp_AcTn> GSM compact Access technology;
0 Access technology not selected
1 Access technology selected
<UTRAN_AcTn> UTRA Access technology;
0 Access technology not selected
1 Access technology selected
<E-UTRAN_AcTn> E-UTRAN Access technology;
0 Access technology not selected
1 Access technology selected
Parameter Saving
Mode
-
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
Not all USIMs support the preferred operator list.
3.2.22 AT+CFUN Set Phone Functionality
AT+CFUN Set Phone Functionality
Test Command
AT+CFUN=?
Response
+CFUN: (list of supported <fun>s),(list of supported <rst>s)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 65 2018-04-10
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Read Command
AT+CFUN?
Response
+CFUN: <fun>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CFUN=<fu
n>[,<rst>]
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<fun> 0 Minimum functionality
1 Full functionality (Default)
4 Disable phone both transmit and receive RF circuits.
7 Disable phone SIM only. Transmit and receive circuits
still active
<rst> 0 Set it to <fun> power level now, but do not reset the MT
1 Do not set it to <fun> power level, either do not reset the
MT before rebooting
2 Set it to <fun> power level now, and reset the MT
after rebooting
Parameter Saving
Mode
-
Max Response
Time
10s
Reference
3GPP TS 27.007
[13]
Note
3.2.23 AT+CCLK Clock
AT+CCLK Clock
Test Command
AT+CCLK=?
Response
OK
Read Command Response
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 66 2018-04-10
AT+CCLK? +CCLK: <time>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CCLK=<ti
me>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<time> String type(string should be included in quotation marks)
value; format is "yy/MM/dd,hh:mm:ss±zz", where characters indicate year
(two last digits),month, day, hour, minutes, seconds and time zone
(indicates the difference, expressed in quarters of an hour, between the
local time and GMT; range -47...+48). E.g. 6th of May 2010, 00:01:52
GMT+2 hours equals to "
10/05/06,00:01:52+08
".
Parameter Saving
Mode
AUTO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
If MT does not support time zone information then the three last characters of
<time> are not returned by +CCLK?.
3.2.24 AT+CSIM Generic SIM Access
AT+CSIM Generic SIM Access
Test Command
AT+CSIM=?
Response
OK
Write Command
AT+CSIM=<len
gth>,<Comman
d>
Response
+CSIM: <length>,<response>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<length> Integer type: length of characters sent to the TE in
<Command> or <response> (i.e. twice the number of octets in the raw
data).
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 67 2018-04-10
<Command> String type (string should be included in quotation
marks): hex format: GSM 11.11 SIM Command sent from the ME to the
SIM.
<response> String type(string should be included in quotation
marks): hex format: GSM 11.11 response from SIM to <Command>.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.25 AT+CBC Battery Charge
AT+CBC Battery Charge
Test Command
AT+CBC=?
Response
+CBC: (list of supported <bcl>),(<voltage>)
OK
Parameters
See Execution Command
Execution
Command
AT+CBC
Response
+CBC: <bcl>,<voltage>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<bcl> Battery connection level
1...100 battery has 1-100 percent of capacity remaining vent
<voltage> Battery voltage(mV)
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.26 AT+CTZR Time Zone Reporting
AT+CTZR Time Zone Reporting
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 68 2018-04-10
Test Command
AT+CTZR=?
Response
+CTZR: (list of supported <onoff>s)
OK
Parameters
See Execution Command
Read Command
AT+CTZR?
Response
+CTZR: <onoff>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CTZR=<on
off>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<onoff>
0 Disable time zone event reporting
1 Enable time zone event reporting
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.27 AT+CTZU Automatic Time update
AT+CTZU Automatic Time Update
Test Command
AT+CTZU=?
Response
+CTZU: (list of supported <onoff>s)
OK
Parameters
See Execution Command
Read Command
AT+CTZU?
Response
+CTZU: <onoff>
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 69 2018-04-10
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CTZU=<on
off>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<onoff>
0 Disable automatic time update via NITZ
1 Automatic time update via NITZ
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.28 AT+CPLS Selection of preferred PLMN list
AT+CPLS Selection of Preferred PLMN List
Test Command
AT+CPLS=?
Response
+CPLS: (list of supported <list>s)
OK
Parameters
See Execution Command
Read Command
AT+CPLS?
Response
+CPLS: <list>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CPLS=<list
>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 70 2018-04-10
Parameters
<list>:
0 (Default). User controlled PLMN selector with Access Technology
EFPLMNwAcT, if not found in the SIM/UICC then PLMN preferred list
EFPLMNSel (this file is only on SIM card or GSM application in UICC.
1 Operator controlled PLMN selector with Access Technology
EFOPLMNwAcT
2 HPLMN selector with Access Technology EFHPLMNwACT
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.29 AT+CPSMS Power saving mode setting
AT+CPSMS Power Saving Mode Setting
Test Command
AT+CPSMS=?
Response
+CPSMS: (list of supported <mode>s),(list of supported
<Requested_Periodic-
RAU>s),(list of supported
<Requested_GPRS-READY-
timer>s),(list of supported
<Requested_Periodic-
TAU>s),(list of supported
<Requested_Active-Time>s)
OK
Parameters
See Execution Command
Read Command
AT+CPSMS?
Response
+CPSMS:
<mode>,[<Requested_Periodic-RAU>],[<Requested_GPRS-READY-ti
mer>],[<Requested_Periodic-TAU>],[<Requested_Active-Time>]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CPSMS=[<
mode>[,<Reques
ted_Periodic-RA
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 71 2018-04-10
U>[,<Requested
_GPRS-READY
-timer>[,<Reque
sted_Periodic-T
AU>[,<Requeste
d_Active-Time>
]]]]]
Parameters
<mode>: integer type. Indication to disable or enable the use of PSM in
the UE.
0 Disable the use of PSM
1 Enable the use of PSM
2 Disable the use of PSM and discard all parameters for PSM or, if
available reset to the manufacturer specific default values.
<Requested_Periodic-RAU>: N/A for NB-IoT
<Requested_GPRS-READY-timer>: N/A for NB-IoT
<Requested_Periodic-TAU>: string type; one byte in an 8-bit format.
Requested extended periodic TAU value (T3412) to be allocated to the UE
in E-UTRAN. The requested extended periodic TAU value is coded as one
byte (octet 3) of the GPRS Timer 3 information element coded as bit
format (e.g. "01000111" equals 70 hours). For the coding and the value
range, see the GPRS Timer 3 IE in 3GPP TS 24.008 Table
10.5.163a/3GPP TS 24.008. See also 3GPP TS 23.682 and 3GPP TS
23.401. The default value, if available, is manufacturer specific.
<Requested_Active-Time>: string type; one byte in an 8-bit format.
Requested Active Time value (T3324) to be allocated to the UE. The
requested Active Time value is coded as one byte (octet 3) of the GPRS
Timer 2 information element coded as bit format (e.g. "00100100" equals 4
minutes). For the coding and the value range, see the GPRS Timer 2 IE in
3GPP TS 24.008 Table 10.5.163/3GPP TS 24.008. See also 3GPP TS
23.682, 3GPP TS 23.060 and 3GPP TS 23.401. The default value, if
available, is manufacturer specific.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.30 AT+CCIOTOPT CIoT optimization configuration
AT+CCIOTOPT CIoT Optimization Configuration
Test Command
AT+CCIOTOP
T=?
Response
+CCIOTOPT:
(list of supported <n>s),(list of supported
<supported_UE_opt>s),(list of supported <preferred_UE_opt>s)
OK
Parameters
See Execution Command
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 72 2018-04-10
Read Command
AT+CCIOTOP
T?
Response
+CCIOTOPT: <n>,<supported_UE_opt>,<preferred_UE_opt>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CCIOTOP
T=[<n>,[<suppo
rted
UE_opt>[,<pref
erred_UE_opt>]
]]
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<n>: integer type, enables or disables reporting of unsolicited result code
+CCIOTOPTI.
0 Disable reporting.
1 Enable reporting.
3 Disable reporting and reset the parameters for CIoT EPS optimization to
the default values.
<supported_UE_opt>: integer type; indicates the UE's support for CIoT
EPS optimizations.
0 No support
1 Support for control plane CIoT EPS optimization.
2 Support for user plane CIoT EPS optimization.
3 Support for both control plane CIoT EPS optimization and user plane
CIoT EPS optimization.
<preferred_UE_opt>: integer type; indicates the UE's preference for
CIoT EPS optimizations.
0 No preference
1 Preference for control plane CIoT EPS optimization
2 Preference for user plane CIoT EPS optimization
<supported_Network_opt>: integer type; indicates the Network support
for CIoT EPS optimizations.
0 No support
1 Support for control plane CIoT EPS optimization.
2 Support for user plane CIoT EPS optimization.
3 Support for both control plane CIoT EPS optimization and user
plane CIoT EPS optimization.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 73 2018-04-10
3GPP TS 27.007
[13]
3.2.31 AT+CEDRXS eDRX setting
AT+CEDRXS eDRX Setting
Test Command
AT+CEDRXS=?
Response
+CEDRXS: (list of supported <mode>s),(list of supported
<AcT-type>s),(list of supported <Requested_eDRX_value>s)
OK
Parameters
See Execution Command
Read Command
AT+CEDRXS?
Response
[+CEDRXS: <AcT-type>,<Requested_eDRX_value>
[<CR><LF>+CEDRXS: <AcT-type>,<Requested_eDRX_value>
[...]]]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CEDRXS=[
<mode>,[,<AcT-
type>[,<Request
ed_eDRX_value
>]]]
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<mode> Integer type, indicates to disable or enable the use of eDRX in
the UE. This parameter is applicable to all specified types of access
technology, i.e. the most recent setting of <mode> will take effect for all
specified values of <AcT>.
0 Disable the use of eDRX
1 Enable the use of eDRX
2 Enable the use of eDRX and enable the unsolicited result code
+CEDRXP: <AcT-type>[,<Requested_eDRX_value>[,<NW-
provided_eDRX_value>[,<Paging_time_window>]]]
3 Disable the use of eDRX and discard all parameters for eDRX or, if
available, reset to the manufacturer specific default values.
<AcT-type> Integer type, indicates the type of access technology. This
AT- command is used to specify the relationship between the type of
access technology and the requested eDRX value.
4 E-UTRAN (NB-S1 mode)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 74 2018-04-10
<Requested_eDRX_value> String type; half a byte in a 4-bit format.
The eDRX value refers to bit 4 to 1 of octet 3 of the Extended DRX
parameters information element (see sub-clause 10.5.5.32 of 3GPP TS
24.008). For the coding and the value range, see Extended DRX
parameters information element in 3GPP TS 24.008 Table 10.5.5.32/3GPP
TS 24.008. The default value, if available, is manufacturer specific.
<NW-provided_eDRX_value> String type; half a byte in a 4-bit format.
The eDRX value refers to bit 4 to 1 of octet 3 of the Extended DRX
parameters information element (see sub- clause 10.5.5.32 of 3GPP TS
24.008). For the coding and the value range, see Extended DRX
parameters information element in 3GPP TS 24.008 Table 10.5.5.32/3GPP
TS 24.008.
<Paging_time_window> String type; half a byte in a 4-bit format. The
paging time window refers to bit 8 to 5 of octet 3 of the Extended DRX
parameters information element (see sub-clause 10.5.5.32 of 3GPP TS
24.008). For the coding and the value range, see the Extended DRX
parameters information element in 3GPP TS 24.008 Table 10.5.5.32/3GPP
TS 24.008.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.32 AT+CEDRXRDP eDRX Read Dynamic Parameters
AT+CEDRXRDP eDRX Read Dynamic Parameters
Test Command
AT+CEDRXRD
P=?
Response
OK
Parameters
See Execution Command
Execution
Command
AT+CEDRXRD
P
Response
+CEDRXRDP:
<AcT-type>[,<Requested_eDRX_value>[,<NW-provided_eDRX_value
>[,<Paging_time_window>]]]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<AcT-type> Integer type, indicates the type of access technology. This
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 75 2018-04-10
AT-command is used to specify the relationship between the type of access
technology and the requested eDRX value.
0 Access technology is not using eDRX
4 E-UTRAN (NB-S1 mode)
<Requested_eDRX_value> String type; half a byte in a 4-bit format.
The eDRX value refers to bit 4 to 1 of octet 3 of the Extended DRX
parameters information element (see sub-clause 10.5.5.32 of 3GPP TS
24.008). For the coding and the value range, see Extended DRX
parameters information element in 3GPP TS 24.008 Table 10.5.5.32/3GPP
TS 24.008.
<NW-provided_eDRX_value> String type; half a byte in a 4-bit format.
The eDRX value refers to bit 4 to 1 of octet 3 of the Extended DRX
parameters information element (see sub-clause 10.5.5.32 of 3GPP TS
24.008). For the coding and the value range, see Extended DRX
parameters information element in 3GPP TS 24.008 Table 10.5.5.32/3GPP
TS 24.008.
<Paging_time_window> String type; half a byte in a 4-bit format. The
paging time window refers to bit 8 to 5 of octet 3 of the Extended DRX
parameters information element (see sub-clause 10.5.5.32 of 3GPP TS
24.008). For the coding and the value range, see the Extended DRX
parameters information element in 3GPP TS 24.008 Table 10.5.5.32/3GPP
TS 24.008.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.33 AT+CCHO Open UICC logical channel
AT+CCHO Open UICC Logical Channel
Write Command
AT+CCHO=<df
name>
Response
+CCHO: <sessionid>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<dfname> String type in hexadecimal character format. All selectable
applications in the UICC are referenced by a DF name coded on 1 to 16
bytes
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 76 2018-04-10
<sessionid> Integer type; a session Id to be used to target a specific
application on the smart card (e.g. (U)SIM, WIM, ISIM) using logical
channels mechanism
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.34 AT+CCHC Close UICC logical channel
AT+CCHC Close UICC Logical Channel
Write Command
AT+CCHC=<se
ssionid>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<sessionid> Integer type; the session used to target a specific application
on the smart card (e.g. (U)SIM, WIM, ISIM) using logical channels
mechanism
P
arameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GPP TS 27.007
[13]
Note
3.2.35 AT+CGLA Generic UICC logical channel access
AT+CGLA Generic UICC Logical Channel Access
Write Command
AT+CGLA=<se
ssionid>,<length
>,<command>
Response
+CGLA: <length>,<response>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<sessionid> Integer type; this is the identifier of the session used to send
the APDU commands to the UICC. It is mandatory to send commands to
the UICC when targeting applications on the smart card using a logical
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 77 2018-04-10
channel other than the default channel (channel "0").
<length> Integer type; length of the characters that are sent to TE in
<command> or <response> (two times the actual length of the command
or response)
<command> Command passed on by the MT to the UICC in the
format as described in 3GPP TS 31.101 (hexadecimal character format)
<response> R
esponse to the command passed on by the UICC to the MT
in the format as described in 3GPP TS 31.101 (hexadecimal character
format)
P
arameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
3GP
P TS 27.007
[13]
Note
3.2.36 AT+CPINR Remaining PIN retries
AT+CPINR Remaining PIN Retries
Test Command
AT+CPINR=?
Response
OK
Parameters
See Execution Command
Write Command
AT+CPINR[=<s
el_code>]
Response
[+CPINR: <code>,<retries>,[<default_retries>]
[<CR>,<LF>:CPINR: <code>,<retries>,[default_retries>]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<sel_code> String type. Same values as for the <code> parameter. These
values are strings and shall be indicated within double quotes.
Wildcard match by ‘*’, meaning match any (sub-)string, or ‘?’
meaning an character can be used.
<retries> Integer type. Number of remaining retries per PIN.
<default_retries> Integer type. Number of default/initial retries per PIN.
<code> Type of PIN. All values listed under the description of the
AT+CPIN Command, <code> parameter except “READY”.
P
arameter Saving
Mode
NO_SAVE
Max Response
-
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 78 2018-04-10
Time
Reference
3GPP TS 27.007
[13]
Note
3.2.37 AT+CGATT GPRS/Packet Domain attach or detach
AT+CGATT GPRS/Packet Domain attach or detach
Test Command
AT+CGATT=?
Response
+CGATT: (list of supported <state>s)
OK
Parameters
See Write Command
Read Command
AT+CGATT?
Response
+CGATT: <state>
OK
Parameters
See Write Command
Write Command
AT+CGATT=<st
ate>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<state> Indicates the state of GPRS/Packet Domain attachment
0 Detached
1 Attached
Other values are reserved and will result in an ERROR response to the
Write Command.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
3.2.38 AT+CGDCONT Define PDP Context
AT+CGDCONT Define PDP Context
Test Command
AT+CGDCONT
=?
Response
+CGDCONT: (range of supported <cid>s),<PDP_type>,,,
(list of
supported <d_comp>s),(list of supported <h_comp>s),(list of supported
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 79 2018-04-10
<IPv4AddrAlloc>s),(list of supported <request_type>s),(list of
supported <P-
CSCF_discovery>s),(list of supported
<IM_CN_Signalling_Flag_Ind>s) ,(list of supported <NSLPI>s),(lis
t of
supported <securePCO>s),(list of supported
<IPv4_MTU_discovery>s),(list of supported <Local_Addr_Ind>s),(list
of supported <Non-IPMTUdiscovery>s)
[<CR><LF>+CGDCONT: (range of supported
<cid>s),<PDP_type>,,,(list of supported <d_comp>s),(list of suppo
rted
<h_comp>s),(list of supported <IPv4AddrAlloc>s),(list of supported
<request_type>s),(list of supported <P-
CSCF_discovery>s),(list of
supported <IM_CN_Signalling_Flag_Ind>s) ,(list of
supported <NSLPI>s),(list of supported <securePCO>s,(list of
suppor
ted <IPv4_MTU_discovery>s),(list of supported
<Local_Addr_Ind>s),
,(list of supported <Non-IP_MTU_discovery>s)[...]]
OK
Parameters
See Write Command
Read Command
AT+CGDCONT
?
Response
+CGDCONT:
<cid>,<PDP_type>,<APN>,<PDP_addr>,<d_comp>,<h_comp>[,<IPv4
AddrAlloc>[,<request_type>[,<P-CSCF_discovery>[,<IM_CN_Signalli
ng_Flag_Ind>[,<NSLPI>[,<securePCO>[,<IPv4_MTU_discovery>[,<L
ocal_Addr_Ind>[,<Non-IP_MTU_discovery>]]]]]]]]]]
[<CR><LF>
+CGDCONT:
<cid>,<PDP_type>,<APN>,<PDP_addr>,<d_comp>,<h_comp>[,<IPv4
AddrAlloc>[,<request_type>[,<P-CSCF_discovery>[,<IM_CN_Signalli
ng_Flag_Ind>[,<NSLPI>[,<securePCO>[,<IPv4_MTU_discovery>[,<L
ocal_Addr_Ind>[,<Non-IP_MTU_discovery>]]]]]]]]]
OK
Parameters
See Write Command
Write Command
AT+CGDCONT
=<cid>[,<PDP_ty
pe>[,APN>[,<PD
P_addr>[,<d_co
mp>[,<h_comp>]
]]]]
Response
OK
or
ERROR
Parameters
<cid> (PDP Context Identifier) a numeric parameter that specifies a
particular PDP context definition.
The parameter is local to the UE-TE interface and is used in other PDP
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 80 2018-04-10
context-related commands.
The range of permitted values (minimum value = 1 or if the initial PDP
context is supported minimum value = 0) is returned by the test form of the
command.
<PDP_type>
(Packet Data Protocol type) a string parameter which specifies
the type of packet data protocol :
IP Internet Protocol (IETF STD 5)
IPV6 Internet Protocol, version 6 (IETF RFC 2460)
IPV4V6 Virtual <PDP_type>) introduced to handle dual IP stack UE
capability (see 3GPP Technical Specifications 24.301).
Non-IP Transfer of Non-IP data to external packet data Network (see
3GPP Technical Specifications 24.301).
<APN> (Access Point Name) a string parameter, a logical name to
select the GGSN or the external packet data network. If the value is null or
omitted, then the subscription value will be requested.
<PDP_addr> A string parameter that identifies the UE in the address space
applicable to the PDP. If the value is null or omitted, then a value may be
provided by the TE during the PDP startup procedure or, failing that, a
dynamic address will be requested. The read form of the command will
continue to return the null string even if an address has been allocated
during the PDP startup procedure. The allocated address may be read using
the +CGPADDR command.
NOTE: For EPS, this field is omitted.
<d_comp> A numeric parameter that controls PDP data compression
(applicable for SNDCP only) (refer 3GPP TS 04.65)
0 off (default if value is omitted)
1 on (manufacturer preferred compression)
2 V.42bis
Other values are reserved.
<h_comp> A numeric parameter that controls PDP header compression
(refer 3GPP TS 04.65)
0 off (default if value is omitted)
1 on (manufacturer preferred compression)
2 RFC1144 (applicable for SNDCP only)
3 RFC 2507
4 RFC 3095 (ROHC) (applicable for PDCP only)
Other values are reserved.
<IPv4_MTU_discovery> Integer type; influences how the MT/TA
requests to get the IPv4 MTU size, see 3GPP TS 24.008 sub-clause
10.5.6.3.
0 Preference of IPv4 MTU size discovery not influenced by
+CGDCONT
1 Preference of IPv4 MTU size discovery through NAS signaling
<Non-IP_MTU_discovery> Integer type; influences how the MT/TA
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 81 2018-04-10
requests to get the Non-IP MTU size, see 3GPP TS 24.008 sub-clause
10.5.6.3.
0 Preference of Non-IP MTU size discovery not influenced by
+CGDCONT
1 Preference of Non-
IP MTU size discovery through NAS signaling
Parameter Saving
Mode
AUTO_SAVE
Max Response
Time
-
Reference
Note
3.2.39 AT+CGACT PDP Context Activate or Deactivate
AT+CGACT PDP Context Activate or Deactivate
Test Command
AT+CGACT=?
Response
+CGACT: (list of supported <state>s)
OK
Parameters
See Write Command
Read Command
AT+CGACT?
Response
+CGACT: <cid>,<state>[<CR><LF>+CGACT: <cid>,<state>…]
OK
Parameters
See Write Command
Write Command
AT+CGACT=<st
ate>[,<cid>]
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<state> Indicates the state of PDP context activation
0 Deactivated
1 Activated
Other values are reserved and will result in an ERROR
response to the Write Command.
<cid> A numeric parameter which specifies a particular PDP context
definition (see +CGDCONT Command). If the <cid> is
omitted, it only affects the first cid.
Parameter Saving
Mode
NO_SAVE
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 82 2018-04-10
Max Response
Time
150 seconds
Reference Note
If context is deactivated successfully, NO CARRIER is returned
If <cid>=0
for PDN activated during attach is enabled, then
AT+CGACT=<0 or 1>,0 will cause ERROR response.
3.2.40 AT+CGPADDR Show PDP Address
AT+CGPADDR Show PDP Address
Test Command
AT+CGPADDR=
?
Response
+CGPADDR: (list of defined <cid>s)
OK
or
OK
Parameters
See Write Command
Write Command
AT+CGPADDR=
[<cid>[,<cid>[,…
]]]
Response
+CGPADDR: <cid>,<PDP_addr>
[<CR><LF>+CGPADDR: <cid>,<PDP_addr>[…]]
OK
or
OK
or
ERROR
Parameters
<cid> a numeric parameter which specifies a particular PDP context
definition (see +CGDCONT command). If no <cid> is specified, the
addresses for all defined contexts are returned.
<PDP_addr> a string that identifies the MT in the address space applicable
to the PDP. The address may be static or dynamic.
For a static address, it will be the one set by the +CGDCONT command
when the context was defined.
For a dynamic address, it will be the one assigned during the last PDP
context activation that used the context definition referred to by <cid>.
<PDP_address> is omitted if none is available.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 83 2018-04-10
Write command returns address provided by the network if a connection has
been established.
3.2.41 AT+CGEREP Packet Domain Event Reporting
AT+CGEREP Packet Domain Event Reporting
Test Command
AT+CGEREP=?
Response
+CGEREP: (list of supported <mode>s) ,(list of supported <bfr>s)
OK
Parameters
See Write Command
Read Command
AT+CGEREP?
Response
+CGEREP: <mode>,<bfr>
OK
Parameters
See Write Command
Write Command
AT+CGEREP=<
mode>
Response
OK
or
ERROR
Parameters
<mode>
0 buffer unsolicited result codes in the UE; if UE result code buffer
is full, the oldest ones can be discarded. No codes are forwarded to the TE.
1 discard unsolicited result codes when UE-TE link is reserved (e.g.
in on-line data mode); otherwise forward them directly to the TE
2 buffer unsolicited result codes in the UE when UE-TE link is
reserved (e.g. in on-line data mode) and flush them to the TE when UE-TE
link becomes available; otherwise forward them directly to the TE
<bfr>
0 UE buffer of unsolicited result codes defined within this
command is cleared when <mode> 1 or 2 is entered
1 UE buffer of unsolicited result codes defined within this
command is flushed to the TE when <mode> 1 or 2 is entered (OK response
shall be given before flushing the codes)
Unsolicited Result Codes supported:
For network attachment, the following unsolicited result codes and the
corresponding events are defined:
+CGEV: NW DETACH
The network has forced a PS detach. This implies that all active contexts
have been deactivated. These are not reported separately.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 84 2018-04-10
+CGEV: ME DETACH
The mobile termination has forced a PS detach. This implies that all active
contexts have been deactivated. These are not reported separately.
For PDP context activation, the following unsolicited result codes and
the corresponding events are defined:
+CGEV: NW PDN ACT <cid>
The network has activated a context. The context represents a Primary PDP
context in GSM/UMTS. The <cid> for this context is provided to the TE.
The format of the parameter <cid> is found in command +CGDCONT.
NOTE 1: This event is not applicable for EPS.
+CGEV: ME PDN ACT <cid>[,<reason>[,<cid_other>]]
The mobile termination has activated a context. The context represents a
PDN connection in NB-IOT. The <cid> for this context is provided to the
TE. This event is sent either in result of explicit context activation request
(+CGACT), or in result of implicit context activation request associated to
attach request (+CGATT=1). The format of the parameter <cid> and <cid
other> are found in command +CGDCONT.
For PDP context deactivation, the following unsolicited result codes and
the corresponding events are defined:
+CGEV: NW PDN DEACT <cid>
The network has deactivated a context. The context represents a PDN
connection in NB-IOT. The associated <cid> for this context is provided to
the TE. The format of the parameter <cid> is found in command
+CGDCONT.
NOTE 2: Occurrence of this event replaces usage of the event
+CGEV: NW DEACT <PDP_type>, <PDP_addr>, [<cid>]
+CGEV: ME PDN DEACT <cid>
The mobile termination has deactivated a context. The context represents a
PDN connection in NB-IOT. The <cid> for this context is provided to the
TE. The format of the parameter <cid> is found in command +CGDCONT.
NOTE 3: Occurrence of this event replaces usage of the event +CGEV:
ME DEACT <PDP_type>, <PDP_addr>, [<cid>]
For other PDP context handling, the following unsolicited result codes
and the corresponding events are defined:
+CGEV: REJECT <PDP_type>, <PDP_addr>
A network request for context activation occurred when the UE was unable
to report it to the TE with a +CRING unsolicited result code and was
automatically rejected. The format of the parameters <PDP_type> and
<PDP_addr> are found in command +CGDCONT.
NOTE 6: This event is not applicable for EPS.
+CGEV: NW REACT <PDP_type>, <PDP_addr>, [<cid>]
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 85 2018-04-10
The network has requested a context reactivation. The <cid> that was used
to reactivate the context is provided if known to the UE. The format of the
parameters <PDP_type>, <PDP_addr> and <cid> are found in command
+CGDCONT.
NOTE 7: This event is not applicable for EPS.
Parameters
<PDP_addr>
Packet Data Protocol address (see +CGDCONT command}
<cid> Context Id (see +CGDCONT command)
Note: <cid> only given if known to the UE.
<class> GPRS mobile class (see +CGCLASS command)
<event_type> Integer type parameter indicates whether this is an
informational event of whether the TE as acknowledged it.
0 Informational event
1 Information request: Acknowledgement required. The
Acknowledgement can be accept or reject, see AT+CGANS.
<change_reason> Integer type parameter indicates what kind of change
occurred.
1 TFT only changed
2 QoS only changed
3 Both TFT and QoS changed
<reason> Integer type parameter indicates the reason why the context
activation request for PDP type IPV4V6 was not granted. This parameter is
only included if the requested PDP type associated with <cid> is IPV4V6,
and the PDP type assign by the network for <cid> is either IPV4 or IPV6
0 IPV4 only allowed
1 IPV6 only allowed
2 single address bearers only allowed
3 single address bearers only allowed and MT initiated context
activation for a second address type bearer was not successful
<cid_other> Indicated the context identifier allocated by MT for an MT
initiated context of a second address type. MT shall only include this
parameter if <reason> parameter indicates single address bearers only
allowed, and MT support MT initiated context activation of a second
address type without additional commands from the TE, and MT has
activated the PDN connection or PDP context associated with <cid_other>.
P
arameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 86 2018-04-10
3.2.42 AT+CGREG Network Registration Status
AT+CGREG Network Registration Status
Test Command
AT+CGREG=?
Response
+CGREG: (list of supported <n>s)
OK
Parameters
See Write Command
Read Command
AT+CGREG?
Response
+CGREG: <n>,<stat>[,<lac>,<ci>,<AcT>,<rac>]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CGREG=<n
>
Response
OK
or
ERROR
Parameters
<n> 0 Disable network registration unsolicited result code
1 Enable network registration unsolicited result code
+CGREG: <stat>
2 Enable network registration and location information unsolicited
result code +CGREG: <stat>[,<lac>,<ci>,<AcT>,<rac>]
<stat>
0 Not registered, MT is not cur
rently searching an operator to
register to.
1 Registered, home network.
2
Not registered, but MT is currently trying to attach or searching
an operator to register to.
3 Registration denied.
4 Unknown
5 Registered, roaming
6 registered for “SMS only”, home network (applicable only when
<Act> indicates E-UTRAN
7 registered for “SMS only”, roaming (applicable only when
<Act> indicates E-UTRAN
<lac> String type; two byte location area code in
hexadecimal format (e.g. "00C3" equals 195 in decimal)
<ci> String type; four byte UTRAN/GERAN/E-UTRAN cell ID in
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 87 2018-04-10
hexadecimal format
<AcT> Access technology of the registered network
9 NB-IoT
<rac> String type; one byte routing area code in hexadecimal format
Parameter Saving
Mode
-
Max Resp
onse
Time
-
Reference Note
3.2.43 AT+CGCONTRDP PDP Context Read Dynamic Parameters
AT+CGCONTRDP PDP Context Read Dynamic Parameters
Test Command
AT+CGCONTR
DP=?
Response
+CGCONTRDP: (list of <cid>s associated with active contexts)
OK
Parameters
See Write Command
Write Command
AT+CGCONTR
DP=[<cid>]
Response
+CGCONTRDP: <cid>, <bearer_id>, <apn>[, <local address and
subnet mask>[, <gw_addr>[, <DNS_prim_addr>[, <DNS_sec_addr>
[,<Serving_PLMN_rate_control_value>]]]]]
[<CR><LF>+CGCONTRDP: <cid>, <bearer_id>, <apn>[, <local
address and subnet mask>[, <gw_addr>[, <DNS_prim_addr>[,
<DNS_sec_addr> [,<Serving_PLMN_rate_control_value>]]]]]
[…]]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<cid> A numeric parameter which specifies a particular primary PDP
context definition. The parameter is local to the TE-UE interface and is
used in other PDP context-related commands.
<bearer_id> A numeric parameter which identifies the bearer, EPS
Bearer in EPS and NSAPI in UMTS/GPRS.
<APN> A
string parameter which is a logical name that was used to select
the GGSN or the external packet data network.
<local address and subnet mask>
A string parameter which shows the IP Address and subnet mask of
the UE. The string is given as dot-separated numeric (0-255)
parameters on the form:
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 88 2018-04-10
"a1.a2.a3.a4.m1.m2.m3.m4" for IPv4 or
"a1.a2.a3.a4.a5.a6.a7.a8.a9.a10.a11.a12.a13.a14.a15.a16.m1.m2.m3.
m4.m5.m6.m7.m8.m9.m10.m11.m12.m13.m14.m15.m16", for IPv6.
<gw_addr> A string parameter which shows the Gateway Address of the
UE. The string is given as dot-separated numeric (0-255) parameters.
<DNS_prim_addr> A string parameter which shows the IP Address of
the primary DNS Server.
<DNS_sec_addr> A string parameter which shows the IP address of the
secondary DNS Server.
<Serving_PLMN_rate_control_value> Integer type; indicates the
maximum number of uplink messages the UE is allowed to send in a
6-minute interval. This refers to octet 3 to 4 of the Serving PLMN rate
control IE as specified in 3GPP TS 24.301 sub-clause 9.9.4.28.
Parameter Saving
Mode
-
Max Response
Time
-
Reference
Note
3.2.44 AT+CGPIAF Printing IP Address Format
AT+CGPIAF Printing IP Address Format
Test Command
AT+CGPIAF=?
Response
+CGPIAF: (list of supported <IPv6_AddressFormat>s), (li
st of
supported <IPv6_SubnetNotation>s), (list of supported
IPv6_LeadingZeros>s), (list of supported IPv6_CompressZeros>s)
OK
Parameters
See Write Command
Read Command
AT+CGPIAF?
Response
+CGPIAF:
<IPv6_AddressFormat>,<IPv6_SubnetNotation>,<IPv6_LeadingZeros
>, <IPv6_CompressZeros>
OK
or
+CME ERROR: <err>
Parameters
See Write Command
Write Command
AT+CGPIAF=[I
Response
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 89 2018-04-10
Pv6_AddressFor
mat>[,<IPv6_Su
bnetNotation>[,<
IPv6_LeadingZe
ros>[,<IPv6_Co
mpressZeros>]]]]
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<IPv6_AddressFormat> Integer type, decides the IPV6 address format.
Relevant for all AT command parameters that can hold an IPV6 address.
0 Use IPV4-like dot-notation. IP address, and Subnetwork mask if
applicable, are dot-separated.
Example:
For <source address and subnet mask>:
“32.1.13.184.0.0.205.48.0.0.0.0.0.0.0.0.255.255.
255.255.255.255.255.240.0.0.0.0.0.0.0.0”
For other IP address parameters:
“32.1.13.184.0.0.205.48.0.0.0.0.0.0.0.0”
1 Use IPV6-like colon notation. IP address, and subnetwork mask if
applicable and when given explicitly, are separated by a space.
Example:
For <source address and subnet mask>:
“2001:0DB8:0000:CD30:0000:0000:0000:0000 FFFF:
FFFF:FFFF:FFF0:0000:0000:0000:0000”
For other IP address parameters:
“2001:0DB8:0000:CD80:0000:0000:0000:0000”
<IPv6_SubnetNotation> Integer type, decides the subnet-notation for
<source Address and subnet mask>. Setting does not apply
If <IPVv6_AddressFormat>=0.
0 Both IP Address and subnet mask are stated.Explicitly, separated
by a space.
Example:
“2001:0DB8:0000:CD30:0000:0000:0000:0000 FFFF:
FFFF:FFFF:FFF0:0000:0000:0000:0000”
1 The printout format is applying / (forward slash)
subnet-prefix Classless Inter-Domain Routing (CIDR)
notation:
Example:
“2001:0DB8:0000:CD30:0000:0000:0000:0000/60”
<IVv6_LeadingZeros> Integer type, decides whether leading zeros are
Omitted or not. Setting does not apply if
<IPv6_AddressFormat>=0.
0 Leading zeros are omitted.
Example:
“2001:DB8:0:CD30:0:0:0:0”
1 Leading zeros are included.
Example:
“2001:0DB8:0000:CD30:0000:0000:0000:0000”
<IPv6_CompressZeros> Integer type, decides whether 1-n instances of
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 90 2018-04-10
16 bit zero-values are replaced by only “..”. This applies only once. Setting
does not apply if <IPv6_AddressFormat>=0.
0 No zero compression.
Example: “2001:DB8:0:CD30:0:0:0:0”
1 Use zero compression.
Example: “2001:DB8:0:CD30::”
Parameter Saving
Mode
-
Max Response
Time
-
Reference
Note
3.2.45 AT+CGDEL Delete Non-Active PDP Contexts
AT+CGDEL Delete Non-Active PDP Contexts
Test Command
AT+CGDEL=?
Response
OK
Parameters
See Write Command
Write Command
AT+CGDEL=<ci
d>
Response
+CGDEL: <cid>[,<cid>[,…]]
OK
If error is related to wrong AT syntax:
+CME ERROR: <err>
Parameters
<cid> A numeric parameter which specifies a particular PDP context
Definition.
Parameter Saving
Mode
-
Max Response
Time
-
Reference Note
3.2.46 AT+CGAUTH Define PDP Context Authentication Parameters
AT+CGAUTH Define PDP Context Authentication Parameters
Test Command
AT+CGAUTH=?
Response
+CGAUTH: (range of supported <cid>s),(list of supported
<auth_prot>s),(range of supported <userid>s),(range of supported
<password>s)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 91 2018-04-10
OK
Parameters
See Write Command
Read Command
AT+CGAUTH?
Response
[+CGAUTH: <cid>,<auth_prot>,<userid>,<password>]
[<CR><LF>+CGAUTH: <cid>,<auth_prot>,<userid>,<password>
[…]]
OK
Parameters
See Write Command
Write Command
AT+CGAUTH=
<cid>[,<auth_pr
ot>[,<userid>[,<
password>]]]
Response
When <auth_prot>/<username>/<password> set:
OK
When no <auth_prot>/<username>/<password> set displays current
auth_prot username and password for <cid>:
+CGAUTH: <cid>,<auth_prot>,<username>,<password>
OK
If error is related to wrong AT syntax:
+CME ERROR: <err>
Parameters
<cid> A numeric parameter which specifies a particular PDP context
definition (see the +CGDCONT and +CGDSCONT commands).
<auth_prot> Numeric parameter. Authentication protocol used for this
PDP context.
0 None. Used to indicate that no authentication protocol is used for
this PDP context. Username and password are removed if previously
specified.
1 PAP
<userid> String type. User name for access to the IP network.
<password> String type. Password for access to the IP network.
Parameter Saving
Mode
-
Max Response
Time
-
Reference
Note
3.2.47 AT*MCGDEFCONT Set Default PSD Connection Settings
AT*MCGDEFCONT Set Default PSD Connection Settings
Test Command
AT*MCGDEFC
ONT=?
Response
*MCGDEFCONT: (List of supported <PDP_type>)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 92 2018-04-10
OK
Parameters
See Write Command
Read Command
AT*MCGDEFC
ONT?
Response
*MCGDEFCONT: <PDP_type>,<APN>,<username>,<password>
OK
Parameters
See Write Command
Write Command
AT*MCGDEFC
ONT=<PDP_typ
e>[,<APN>[,<use
rname>[,<passw
ord>]]]
Response
OK
If error is related to wrong AT syntax:
+CME ERROR: <err>
Parameters
<PDP_type> (Packet Data Protocol type) a string parameter which
specifies the type of packet data protocol :
IP Internet Protocol (IETF STD 5)
IPV6 Internet Protocol, version 6 (IETF RFC 2460)
IPV4V6 Virtual <PDP_type) introduced to handle dual IP stack UE
capability(see 3GPP TS 24.301).
Non-IP Transfer of Non-IP data to external packet data Network (see
3GPP TS 24.301).
<APN> (Access Point Name) a string parameter that is a logical name that
is used to select the GGSN or the external packet data network. If the value
is null or omitted, then the subscription value will be requested.
<username> String value. Username for the connection to the service
provider.
<password> String value. Password for the connection to the service
provider
Parameter Saving
Mode
AUTO_SAVE_REBOOT
Max Response
Time
-
Reference Note
3.2.48 AT*MSACL Enable/Disable ACL feature
AT*MSACL Enable/Disable ACL feature
Test Command
AT*MSACL=?
Response
*MSACL: (0-1)
OK
Parameters
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 93 2018-04-10
See Write Command
Read Command
AT*MSACL?
Response
*MSACL: <supported><enabled>
OK
Parameters
See Write Command
Write Command
AT*MSACL=<
mode>, [<PIN2>]
Response
OK
If error is related to wrong AT syntax:
+CME ERROR: <err>
Parameters
<mode> Action selected
0 ACL to be disabled
1 ACL to be enabled
<supported>
0 ACL not supported by SIM
1 ACL supported by SIM
<enabled>
0 ACL disabled by user
1 ACL enabled by user
Parameter Saving
Mode
-
Max Response
Time
-
Reference
Note
Enables/disables ACL feature for the mobile unit. If enabled and supported
by the SIM, PDP Activations are only possible with APNs which are
present in the ACL list.
If PIN2 is not confirmed before the command is issued, the PIN2 should be
supplied as a second parameter.
3.2.49 AT*MLACL Display ACL List
AT*MSACL Display ACL List
Test Command
AT*MLACL=?
Response
*MLACL: (0-255),(0-255)
OK
Parameters
See Write Command
Write Command
AT*MLACL=<f
Response
*MLACL: <index>,<APN>
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 94 2018-04-10
rom>, [<to>]
OK
If error is related to wrong AT syntax:
+CME ERROR: <err>
Parameters
<from> Start index
<to> End index
<index> Entry index
<APN> APN in textual format
Parameter Saving
Mode
-
Max Response
Time
-
Reference Note
Only applies to USIM (3G).
3.2.50 AT*MWACL Write an ACL entry
AT*MWACL Write an ACL entry
Test Command
AT*MWACL=?
Response
*MWACL: (0-255)
OK
Parameters
See Write Command
Write Command
AT*MWACL=<i
ndex>,<APN>,
[<PIN2>]
Response
OK
If error is related to wrong AT syntax:
+CME ERROR: <err>
Parameters
<index> Entry index
<APN> APN in textual format
Parameter Saving
Mode
-
Max Response
Time
-
Reference Note
Only applies to USIM (3G).
3.2.51 AT*MDACL Delete an ACL entry
AT*MDACL Delete an ACL entry
Test Command Response
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 95 2018-04-10
AT*MDACL=?
*MDACL: (0-255)
OK
Parameters
See Write Command
Write Command
AT*MDACL=<i
ndex>, [<PIN2>]
Response
OK
If error is related to wrong AT syntax:
+CME ERROR: <err>
Parameters
<index> Entry index
Parameter Saving
Mode
-
Max Response
Time
-
Reference Note
Deletes an ACL entry from the specific index in the list. The entry will be
deleted, and all the following entries moved to the previous index to cover
the deleted entry, leaving the continuous list. If PIN2 is not confirmed
before the command is issued, PIN2 should be supplied as a second
parameter.
3.2.52 AT+CNBIOTDT NB-IOT Data Type
AT+CNBIOTDT NB-IOT Data Type
Test Command
AT+CNBIOTDT
=?
Response
+CNBIOTDT: (list of supported <types>s)
OK
Parameters
See Write Command
Read Command
AT+CNBIOTDT
?
Response
Displays <type> for all active PDP contexts:
[+CNBIOTDT: <cid>,type]
[<CR><LF>+CNBIOTDT: <cid>,<type>]
[…]]
OK
Parameters
See Write Command
Write Command
AT+CNBIOTDT
Response
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 96 2018-04-10
=<type>[,<cid>[,
<cid>[,…]]]
If error is related to wrong AT syntax:
+CME ERROR: <err>
Parameters
<type> Integer type
0 Normal data (default)
1 Exceptional data
<cid> Integer type. Specifies a particular PDP context definition.
If no <cid>s are specified the command sets <type> for all active PDP
contexts.
Parameter Saving
Mode
-
Max
Response
Time
-
Reference Note
The UE will not remember this setting over sleep cycles (i.e. the UE will
fall back to default setting after sleep)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 97 2018-04-10
4 AT Commands Special for SIMCom
4.1 Overview
Command Description
AT+CPOWD Power off
AT+CADC Read ADC
AT+CLTS Get local timestamp
AT+CBAND
Get and set mobile operation band
AT+CENG
Switch on or off engineering mode
AT+CCID Show ICCID
AT+EXUNSOL Enable or disable proprietary unsolicited indications
AT+GSV Display product identification information
AT*CELLLOCK Set the list of ARFCN which needs to be locked
AT+SLEDS Set the timer period of net light
AT+CNETLIGHT
Close the net light or open it to shining
AT+CSMINS SIM inserted status reporting
AT+CSPCHSC
Set Scrambling Algorithm for NPDSCH
AT+CATWAKEUP Enable Deep Sleep Wakeup Indication
AT+CSCLK Configure Slow Clock
4.2 Detailed Descriptions of Commands
4.2.1 AT+CPOWD Power off
AT+CPOWD Power Off
Write Command
AT+CPOWD=<n
>
Response
[NORMAL POWER DOWN]
OK
Parameter
<n>
0 Power off urgently (Will not send out NORMAL POWER
DOWN)
1 Normal power off (Will send out NORMAL POWER DOWN)
Parameter Saving
Mode
NO_SAVE
Max Response
-
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 98 2018-04-10
Time
Reference Note
4.2.2 AT+CADC Read ADC
AT+CADC Read ADC
Test Command
AT+CADC=?
Response
+CADC: (list of supported <status>s),(list of supported <value>s)
OK
Parameters
<status> 1 Success
0 Fail
<value> Integer 0-1400
Read Command
AT+CADC?
Response
+CADC: <status>,<value>
OK
Parameters
See Test Command
Parameter Saving
Mode
NO_SAVE
Max Resp
onse
Time
2s
Reference Note
4.2.3 AT+CLTS Get Local Timestamp
AT+CLTS Get Local Timestamp
Test Command
AT+CLTS=?
Response
+CLTS: "yy/MM/dd,hh:mm:ss+/-zz"
OK
Read Command
AT+CLTS?
Response
+CLTS: <mode>
OK
Write Command
AT+CLTS=<mo
de>
Response
OK
If error is related to wrong AT syntax:
+CME ERROR: <err>
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 99 2018-04-10
Parameters
<mode>
0 Disable
1 Enable
Unsolicited Result Code
+CLTS: <year>,<month>,<day>,<hour>,<min>,<sec>,"<time zone>"
Parameters
<year> Year (from network)
<month> Month (from network)
<day> Day (from network)
<hour> Hour (from network)
<min> Minute (from network)
<sec> Second (from network)
<time zone> String type; network time zone.
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
Note
4.2.4 AT+CBAND Get and Set Mobile Operation Band
AT+CBAND Get and Set Mobile Operation Band
Test Command
AT+CBAND=?
Response
+CBAND: (list of supported <op_band>s)
OK
Parameter
See Write Command
Read Command
AT+CBAND?
Response
+CBAND: <op_band>[,<ALL_BAND>]
OK
Parameter
See Write Command
Write Command
AT+CBAND=<o
p_band>[,<ALL
_BAND>]
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameter
<op_band> Integer value indicating current selected NB-IOT band
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 100 2018-04-10
Valid values: ,2,3,5,8,11,12,13,17,18,19,20,25,26,28,
31,66,70,21
Parameter Saving
Mode
AUTO_SAVE
Max Response
Time
-
Reference Note
4.2.5 AT+CENG Report Network State
AT+CENG Report Network State
Test Command
AT+CENG=?
Response
TA returns the list of supported modes.
+CENG: (list of supported <mode>s)
OK
Parameters
See Write Command
Read Command
AT+CENG?
Response
<mode> = 0 display serving cell and up to 4 neighbor cell information:
+CENG:
<sc_earfcn>,<sc_earfcn_offset>,<sc_pci>,<sc_cellid>,[<sc_rsrp>],[<sc_r
srq>],[<sc_rssi>],[<sc_snr>],<sc_band>,<sc_tac>,[<sc_ecl>],[<sc_tx_pw
r>]
[<CR><LF>+CENG:
<nc_earfcn>,<nc_earfcn_offset>,<nc_pci>,<nc_rsrp>
[…]]
OK
<mode> = 1 display data transfer information only if modem in
RRC-CONNECTED state:
+CENG:
<RLC_UL_BLER>,<RLC_DL_BLER>,<MAC_UL_BLER>,<MAC_D
L_BLER>,<MAC_UL_total_bytes>,<MAC_DL_total_bytes>,<MAC_U
L_total_HARQ_TX>,<MAC_DL_total_HARQ_TX>,<MAC_UL_HAR
Q_re_TX>,<MAC_DL_HARQ_re_TX>,<RLC_UL_tput>,<RLC_DL_t
put>,<MAC_UL_tput>,<MAC_DL_tput>
OK
If error is related to wrong AT syntax or incorrect <mode> or UE in
incorrect state
+CME ERROR: <err>
Parameters
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 101 2018-04-10
See Write Command
Write Command
AT+CENG=<mo
de>
Response
OK
ERROR
Parameters
<mode> Integer value indicating requested engineering information.
0 Radio information for serving and neighbor cells
1 Serving Cell/Neighbor Cell information:
<sc_earfcn> Integer value indicating the EARFCN for serving cell. Range
0- 262143
<sc_earfcn_offset>
Integer value indicating the EARFCN offset for serving
cell:
0 Offset of -2
1 Offset of -1
2 Offset of -0.5
3 Offset of 0
4 Offset of 1
<sc_pci> Integer value indicating the serving cell physical cell ID. Range 0
– 503.
<sc_cellid>
String type; four byte (28 bit) cell ID in hexadecimal format for
serving cell.
<sc_rsrp> Signed integer indicating serving cell RSRP value in units of
dBm (can be negative value). Available only in RRC-IDLE state.
<sc_rsrq>
Signed integer indicating serving cell RSRQ value in units of dB
(can be negative value). Available only in RRC-IDLE state.
<sc_rssi>
Signed integer indicating serving cell RSSI value in units of dBm
(can be negative value). Available only in RRC-IDLE state.
<sc_snr> Signed integer value. Last SNR value for serving cell in units of
dB. Available only in RRC-IDLE state.
<sc_band> Integer value; current serving cell band
<sc_tac> String type; two byte tracking area code (TAC) in hexadecimal
format (e.g. "00C3" equals 195 in decimal).
<sc_ecl> Integer value. Last Enhanced Coverage Level (ECL) value for
serving cell. Range 0-2.
<sc_tx_pwr> Signed integer value indicating current UE transmit power.
Units of cBm Centibels relative to one milliwatt (can be negative value).
<nc_earfcn> Integer value indicating the EARFCN for neighbor cell.
Range 0-262143
<nc_earfcn_offset> Integer value indicating the EARFCN offset for
neighbor cell:
0 Offset of -2
1 Offset of -1
2 Offset of -0.5
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 102 2018-04-10
3 Offset of 0
4 Offset of 1
<nc_pci> Integer value indicating the neighbor cell physical cell ID. Range
0-503.
<nc_rsrp> Signed integer indicating neighbor cell RSRP value in units of
dBm (can be negative value).
Data Transfer Information:
<RLC_UL_BLER> Integer value. Represented in % value (range 0 to
100). UL block error rate (as per IRQ) in RLC. Calculated over all
established RLC AM radio bearers. Calculated from the beginning of
successfully established/resumed RRC connection or since previous
AT+CENG query with <mode>=1, whichever is later. Only valid in
RRC-CONNECTED state.
<RLC_DL_BLER> Integer value Represented in % value (range 0 to 100).
DL block error rate (as per ARQ) in RLC. Calculated over all established
RLC AM radio bearers. Calculated from the beginning of successfully
established / resumed RRC connection, or since previous AT+CENG query
with <mode>=1, whichever is later. Available only in RRC-CONNECTED
state.
<MAC_UL_BLER> Integer value. Represented in % value (range 0 to
100). UL block error rate (as per HARQ) in MAC for UL-SCH. Calculated
from the beginning of successfully established / resumed / re-established
RRC connection, or since previous AT+CENG query with <mode>=1,
whichever is later. Available only in RRC-CONNECTED state.
<MAC_DL_BLER> Integer value. Represented in % value (range 0 to
100). DL block error rate (as per HARQ) in MAC for DL-SCH, excluding
BCCH. Calculated from the beginning of successfully established / resumed
/ re-established RRC connection, or since previous AT+CENG query with
<mode>=1, whichever is later. Available only in RRC-CONNECTED state.
<MAC_UL_total_bytes> Integer value. Total number of transport block
bytes (re)transmitted on UL-SCH. Calculated for UL-SCH over all HARQ
transmissions and retransmissions. Calculated from the beginning of
successfully established / resumed / re-
established RRC connection, or since
previous AT+CENG query with <mode>=1, whichever is later. Available
only in RRC-CONNECTED state. Unit: bytes
<MAC_DL_total_bytes> Integer value. Total number of transport block
bytes (re)transmitted on DL-SCH, excluding BCCH. Calculated from
the beginning of successfully established / resumed / re-established RRC
connection, or since previous AT+CENG query with <mode>=1,
whichever is later. Available only in RRC-CONNECTED state. Unit: bytes
<MAC_UL_total_HARQ_TX> Integer value. Total number of HARQ
(re)transmissions for transport blocks on UL-SCH.
Calculated from the beginning of successfully established / resumed /
re-established RRC connection, or since previous AT+CENG query
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 103 2018-04-10
with <mode>=1, whichever is later. Available only in RRC-CONNECTED
state. Unit: (re)transmissions
<MAC_DL_total_HARQ_TX> Integer value. Total number of HARQ
(re)transmissions for transport blocks on DL-SCH, excluding BCCH.
Calculated from the beginning of successfully established / resumed /
re-established RRC connection, or since previous AT+CENG query with
<mode>=1, whichever is later. Available only in RRC-CONNECTED state.
Unit: (re)transmissions
<MAC_UL_HARQ_re_TX> Integer value. Number of HARQ
retransmissions for transport blocks on UL-SCH. Calculated from the
beginning of successfully established / resumed / re-established RRC
connection, or since previous AT+CENG query with <mode>=1,
whichever is later. Available only in RRC-CONNECTED state. Unit:
retransmissions
<MAC_DL_HARQ_re_TX> Integer value. Number of HARQ
retransmissions for transport blocks on DL-SCH, excluding BCCH.
Calculated from the beginning of successfully established / resumed /
re-established RRC connection, or since previous AT+CENG query with
<mode>=1, whichever is later. Available only in RRC-CONNECTED state.
Unit: retransmissions.
<RLC_UL_tput> Integer value. RLC uplink throughput. Calculated over
all established RLC AM radio bearers. Calculated from the beginning of
successfully established / resumed RRC connection, or since previous
AT+CENG query with <mode>=1, whichever is later. Available only in
RRC-CONNECTED state. Unit: kbits / s
<RLC_DL_tput> Integer value. RLC downlink throughput. Calculated
over all established RLC AM radio bearers Calculated from the beginning
of successfully established / resumed RRC connection, or since previous
AT+CENG query with <mode>=1, whichever is later. Available only in
RRC-CONNECTED state. Unit: kbits / s
<MAC_UL_tput> Integer value. UL throughput in MAC for UL-SCH.
Calculated from the beginning of successfully established / resumed /
re-established RRC connection, or since previous AT+CENG query with
<mode>=1, whichever is later. Available only in RRC-CONNECTED state.
Unit: kbits / s
<MAC_DL_tput> Integer value. DL throughput in MAC for DL-SCH,
excluding BCCH. Calculated fr
om the beginning of successfully established
/ resumed / re-established RRC connection, or since previous AT+CENG
query with <mode>=1, whichever is later. Available only in
RRC-CONNECTED state. Unit: kbits / s
Parameter Saving
Mode
NO_SAVE
Max Response
-
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 104 2018-04-10
Time
Reference Note
If modem is not in RRC-CONNECTED state then +CENG will not be
generated for <mode> = 1. Only OK response will be generated.
4.2.6 AT+CCID Show ICCID
AT+CCID Show ICCID
Test Command
AT+CCID=?
Response
OK
Execution
Command
AT+CCID
Response
Ccid data [ex. 898600810906F8048812]
OK
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
4.2.7 AT+EXUNSOL Enable or Disable Proprietary Unsolicited Indications
AT+EXUNSOL Enable or Disable Proprietary Unsolicited Indications
Test Command
AT+EXUNSOL=
?
Response
+EXUNSOL: (list of supported <exunsol>s)
OK
Parameters
See Write Command
Write Command
AT+EXUNSOL=
<exunsol>,<mode
>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<exunsol> String type(string should be included in quotation marks).
values are currently reserved by the present document
"SQ" Signal Quality Report
Displays signal strength and channel bit error rate (similar to
AT+CSQ) in form +CSQN: <rssi>,<ber>when values change.
<mode>
0 Disable
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 105 2018-04-10
1 Enable
2 Query
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
Note
4.2.8 AT+GSV Display Product Identification Information
AT+GSV Display Product Identification Information
Execution
Command
AT+GSV
Response
TA returns product information text
Example:
SIMCOM_Ltd
SIMCOM_SIM7020
Revision: 1752B01SIM7020
OK
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
4.2.9 AT*CELLLOCK Set the List of ARFCN Which Needs to Be Locked
AT*CELLLOCK Set the List of ARFCN Which Needs to Be Locked
Test Command
AT*CELLLOC
K=?
Response
OK
Parameter
See Write Command
Read Command
AT*CELLLOC
K?
Response
OK
Parameter
See Write Command
Write Command
AT*CELLLOC
K=<lock>[,<earf
Response
OK
If error is related to wrong AT syntax or incorrect parameters.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 106 2018-04-10
cn>,<earfcn_offs
et>[,<pci>]]
ERROR
Parameter
<lock> Integer value indicating whether to activate lock, or remove lock:
0: Remove lock
1: Activate lock
<earfcn> Integer value indicating requested EARFCN on which to lock.
Range 0-
262143. Value of 0 indicates to remove any lock for EARFCN and
Cell
<earfcn_offset> Integer value indicating requested EARFCN offset:
0: Offset of -2
1: Offset of -1
2: Offset of -0.5
3: Offset of 0
4: Offset of 1
<pci> Integer value: Physical cell ID. Range: 0-503
Parameter Saving
Mode
AUTO_SAVE
Max Response
Time
-
Reference
Note
4.2.10 AT+SLEDS Set the Timer Period of Net Light
AT+SLEDS Set the Timer Period of Net Light
Test Command
AT+SLEDS=?
Response
+SLEDS: (1-3),(0,40-65535),(0,40-65535)
OK
Parameters
See Write Command
Read Command
AT+SLEDS?
Response
+SLEDS: <mode>,<timer_on>,<timer_off>
OK
Parameters
See Write Command
Write Command
AT+SLEDS=<m
ode>,<timer_on>
Response
OK
ERROR
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 107 2018-04-10
,<timer_off> Parameters
<mode>
1 Set the timer period of net light while SIM7020 series
does not
register to the network
2 Set the timer period net light while SIM7020 series has already
registered to the network
3 Set the timer period net light while SIM7020 series is in the state of
PPP communication
<timer_on>
Timer period of "LED ON" in decimal format which range is 0 or
40-65535(ms)
<timer_off>
Timer period of “LED OFF” in decimal format which range is 0 or
40-65535(ms)
Parameter Saving
Mode
AUTO_SAVE
Max Response
Time
-
Reference Note
The default value is :
<mode>,<timer_on>,<timer_off>
1,64,800
2,64,3000
3,64,300
4.2.11 AT+CNETLIGHT Close the Net Light or Open It to Shining
AT+CNETLIGHT Close the Net Light or Open It to Shining
Test Command
AT+CNETLIGH
T=?
Response
+CNETLIGHT: (0,1)
OK
Parameters
See Write Command
Read Command
AT+CNETLIGH
T?
Response
+CNETLIGHT: <mode>
OK
Parameters
See Write Command
Write Command
AT+CNETLIGH
T=<mode>
Response
OK
ERROR
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 108 2018-04-10
Parameters
<mode>
0 Close the net light
1 Open the net light to shining
Param
eter Saving
Mode
AUTO_SAVE
Max Response
Time
-
Reference
Note
4.2.12 AT+CSMINS SIM Inserted Status Reporting
AT+CSMINS SIM Inserted Status Reporting
Test Command
AT+CSMINS=?
Response
+CSMINS: (list of supported <n>s)
OK
Parameter
See Write Command
Read Command
AT+CSMINS?
Response
+CSMINS: <n>,<SIM inserted>
OK
Parameters
See Write Command
Write Command
AT+CSMINS=<
n>
Response
OK
ERROR
If error is related to ME functionality:
+CME ERROR: <err>
Unsolicited Result Code
+CSMINS: <n>,<SIM inserted>
Parameters
<n> A numeric parameter to show an unsolicited event code
indicating whether the SIM has been inserted or removed.
0 Disable
1 Enable
<SIM inserted> A numeric parameter which indicates whether SIM
card has been inserted.
0 Not inserted
1 Inserted
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 109 2018-04-10
Parameter
Saving Mode
AT&W_SAVE
Max Response
Time
-
Reference
Note
4.2.13 AT+CSPCHSC Set Scrambling Algorithm for NPDSCH
AT+CSPCHSC Set Scrambling Algorithm for NPDSCH
Test Command
AT+CSPCHSC=
?
Response
+CSPCHSC: (0-1)
OK
Parameter
See Write Command
Read Command
AT+CSPCHSC?
Response
+CSPCHSC: <mode>
OK
Parameter
See Write Command
Write Command
AT+CSPCHSC=
<mode>
Response
OK
If error is related to wrong AT syntax or incorrect parameters.
ERROR
Parameter
<mode>
0 New algorithm
1 Old algorithm (default)
Parameter Saving
Mode
AUTO_SAVE
Max Response
Time
-
Reference
Note
4.2.14 AT+CATWAKEUP Enable Deep Sleep Wakeup Indication
AT+CATWAKEUP Enable Deep Sleep Wakeup Indication
Test Command
AT+CATWAKE
UP=?
Response
*CATWAKEUP: (0-1)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 110 2018-04-10
OK
Parameter
See Write Command
Read Command
AT+CATWAKE
UP?
Response
+CATWAKEUP: <enable>
OK
Parameter
See Write Command
Write Command
AT+CATWAKE
UP=<enable>
Response
OK
If error is related to wrong AT syntax or incorrect parameters.
ERROR
Parameter
<enable>
0 Disable indication on this channel when modem wakes up from
deep sleep
1 Enable indication on this channel when modem wakes up from
Deep sleep
Parameter Saving
Mode
AT&W_SAVE
Max Response
Time
-
Reference
Note
4.2.15 AT+CSCLK Configure Slow Clock
AT+CSCLK Configure Slow Clock
Test Command
AT+CSCLK=?
Response
+CSCLK: (list of supported <n>s)
OK
Parameters
See Write Command
Read Command
AT+CSCLK?
Response
+CSCLK: <n>
OK
Parameters
See Write Command
Write Command Response
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 111 2018-04-10
AT+CSCLK=<n> OK
or
ERROR
Parameters
<n> 0 Disable slow clock, module will not enter sleep mode.
1 Enable slow clock, it is controlled by DTR. When DTR is
high, module can enter sleep mode. When DTR changes to low
level, module can quit sleep mode.
2 Enable slow clock automatically. When there is no
interrupt (on air and hardware such as GPIO interrupt or data in
serial port),
module can enter sleep mode. Otherwise, it will quit
sleep mode.
Parameter Saving
Mode
Max Resp
onse
Time
-
Reference Note
- There are two caveats when you want to quit sleep mode in mode 2:
1, You should input some characters (at least one) to awake module
2, An interval time of 100ms more is necessary between waking characters
and following AT commands,otherwise the waking characters will not be
discarded completely,and messy codes will be produced which may leads
to UART baudrate re-adaptation.
-
The +CSCLK value can not be reset by AT&F or ATZ command.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 112 2018-04-10
5 AT Commands for TCPIP Application Toolkit
5.1 Overview of AT Commands for TCPIP Application Toolkit
Command
Description
AT+CSGACT
Activate or deactivate a PDN context
AT+CSOC Create a TCP/UDP socket
AT+CSOCON Connect socket to remote address and port
AT+CSOSEND Send data to remote via socket
AT+CSOCL Close socket
AT+CSOSENDF
LAG
Set TCP send flag
AT+CSOSTATU
S
Get socket status
AT+CSOACK
Query Previous Connection Data Transmitting State
+CSONMI
Socket message arrived indicator
+CSOERR Socket error indicator
5.2 Detailed Descriptions of AT Commands for TCPIP Application Toolkit
5.2.1 AT+CSGACT Activate or deactivate a PDN context
AT+CSGACT Activate or deactivate a PDN context
Write Command
AT+CSGACT=<
op>,<pdp_type/c
id>[,<apn>[,<use
r_name>,<pwd>[
,<bearer_type>[,
<sim_id>]]]]
Response
1) For activation/deactivation requirement
OK
If set Success:
+CSGACT: <cid>, 1
If set Failed:
+CSGACT: <cid>,0
2) For some errors，such as invalid parameter(s)
ERROR
3）Automatically reported URC for network reasons
+CSGACT: <cid>,2
4）If the PDN context is active/inactive
+CSGACT: <cid> ,<result>
OK
will return immediately for activate or deactivate requirement.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 113 2018-04-10
Parameters
<op> Integer type
0 deactivation requirement
1 activation requirement
<pdp_type/cid> Integer type
If <op> is 1, it is pdp_type. Otherwise, it is cid.
pdp_type It is the pdp_type wanted to activate
1 IPv4
2 IPv6
3 IPv4v6
4 Non-IP
cid It is a numeric parameter specifying a particular PDP
context. Here it should be equal to the <cid> returned by the
activation response.
<apn> String type
It is the access point name which is mandatory for the activation
requirement and should be omitted for the deactivation
requirement.
<user_name> String type
It is the user name for access to the IP network which is mandatory
for the activation requirement and should be
omitted for the
deactivation requirement.
<pwd> String type
It is the password for acces
s to the IP network which is mandatory
for the activation requirement and should be
omitted for the
deactivation requirement.
<bearer_type> Integer type
It is the type of bearer wanted to activate which is optional for the
activation requirement and should be omitted
for the deactivation
requirement.
1 NBIOT (Only NBIOT is supported currently)
<sim_id> Integer type
It is the id of the SIM Card wanted to use which is optional for the
activation requirement and should be omitted
for the deactivation
requirement.
1 SIM Card 1 (Only SIM Card 1 is supported currently).
<cid> Integer type
It is a numeric parameter specifying a particular PDP context.
<type> Integer type;
0 Result/URC for deactivation requirement
1 Result/URC for activation requirement
2 URC for passive deactivation
<result> Integer type;
0 Failure
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 114 2018-04-10
1 Success
<activated_pdp_type> Integer type;
It is the pdp_type actually activated.
1 IPv4
2 IPv6
3 IPv4v6
4 Non-IP
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
5.2.2 AT+CSOC Create a TCP/UDP socket
AT+CSOC Create a TCP/UDP socket
Test Command
AT+CSOC=?
Response
+CSOC: (1-2),(1-3),(1-3)
OK
Parameters
See Write Command
Read Command
AT+CSOC?
Response
OK
Parameters
See Write Command
Write Command
AT+CSOC=<do
main>,<type>,<p
rotocol>[,<cid>]
Response
+CSOC: <socket_id>
OK
Parameters
<socket_id> Integer socket_id
<domain> Integer
1 IPv4
2 IPv6
<type> Integer
1 TCP
2 UDP
3 RAW
<protocol> Integer
1 IP
2 ICMP
3 UDP_LITE
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 115 2018-04-10
<cid> Integer, PDP context ID, AT+CGACT response. [option]
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
5.2.3 AT+CSOCON Connect socket to remote address and port
AT+CSOCON Connect socket to remote address and port
Test Command
AT+CSOCON=?
Response
+CSOCON: <socket_id>,<remote_port>,<remote_address>
OK
Parameters
See Write Command
Read Command
AT+CSOCON?
Response
If connection exist.
+CSOCON: <socket_id>,<type>,1
OK
Parameters
See Write Command
Write Command
AT+CSOCON=<
socket_id>,<rem
ote_port>,<remo
te_address>
Response
OK
Parameters
<socket_id> Integer socket_id
<remote_port> Integer, remote port.
<remote_address> String, remote address.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
5.2.4 AT+CSOSEND Send data to remote via socket
AT+CSOSEND Send data to remote via socket
Test Command
AT+CSOSEND=
?
Response
+CSOSEND: <socket_id>,<data_len>,<data>
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 116 2018-04-10
Parameters
See Write Command
Read Command
AT+CSOSEND?
Response
OK
Parameters
See Write Command
Write Command
AT+CSOSEND=
<socket_id>,<dat
a_len>,<data>
Response
If CSOSENDFLAG is 0.
OK
If CSOSENDFLAG is 1.
OK
SEND: <socket_id>,<len>
Parameters
<socket_id> Integer socket_id, AT+CSOC’s response.
<data_len> Integer, length of data
<data> Raw_data, data context.
Maximum data size is 512 character.
If <data_len> is 0 you can send str to remote socket with Double
quotation,otherwise the format of data should be Hex and the lenth must be
Equal to the <data_len>.
<len> Integer, length of data
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
5.2.5 AT+CSOCL Close socket
AT+CSOCL Close socket
Test Command
AT+CSOCL=?
Response
OK
Parameters
See Write Command
Read Command
AT+CSOCL?
Response
+CSOCL: <socket_id>
OK
Parameters
See Write Command
Write Command Response
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 117 2018-04-10
AT+CSOCL=<so
cket_id>
OK
Parameters
<socket_id> Integer socket_id
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
5.2.6 AT+CSOSENDFLAG Set TCP send flag
AT+CSOSENDFLAG Set TCP send flag
Test Command
AT+CSOSENDF
LAG=?
Response
+CSOSENDFLAG: (0,1)
OK
Parameters
See Write Command
Read Command
AT+CSOSENDF
LAG?
Response
+CSOSENDFLAG: <flag>
OK
Parameters
See Write Command
Write Command
AT+CSOSENDF
LAG=<flag>
Response
OK
Parameters
<flag> TCP send flag
Parameter Saving
Mode
AUTO_SAVE
Max Respo
nse
Time
-
5.2.7 AT+CSOSTATUS Get socket status
AT+CSOSTATUS Get socket status
Test Command
AT+CSOSTATU
S=?
Response
+CSOSTATUS: (0,10)
OK
Parameters
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 118 2018-04-10
See Write Command
Read Command
AT+CSOSTATU
S?
Response
OK
Parameters
See Write Command
Write Command
AT+CSOSTATU
S=<socket_id>
Response
+CSOSTATUS: <socket_id>,<status>
OK
Parameters
<socket_id> Integer, socket id, AT+CSOC’s response.
<status> Integer
1 None socket
2 Socket create but not connect.
3 Connected.
5.2.8 AT+CSOACK Query Previous Connection Data Transmitting State
AT+CSOACK Query Previous Connection Data Transmitting State
Test Command
AT+CSOACK=?
Response
+CSOACK: (0,10)
OK
Parameters
See Write Command
Read Command
AT+CSOACK?
Response
OK
Parameters
See Write Command
Write Command
AT+CSOACK=<
socket_id>
Response
+CSOACK: <socket_id>,<txlen>, <acklen>, <nacklen>
OK
Parameters
<socket_id> Integer, socket id, AT+CSOC’s response.
<txlen> The data amount which has been sent
<acklen> The data amount confirmed successfully by the server
<nacklen> The data amount without confirmation by the server
5.2.9 +CSONMI Socket message arrived indicator
+CSONMI Socket message arrived indicator
Indicated there is received some data from network.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 119 2018-04-10
Response
+CSONMI: <socket_id>,<data_len>,<data>
Parameters
<socket_id> Integer socket_id
<data_len> Integer, length of data
<data> Raw_data, data context.
5.2.10 +CSOERR Socket error indicator
+CSOERR Socket error indicator
Indicated there is some error.
Response
+CSOERR: <socket_id>,<error_code>
Parameters
<socket_id> Integer, socket id, AT+CSOC’s response.
<error_code>
-1 common error
1 route error
2 conn abort error
3 reset error
4 connected error
5 value error
6 buffer error
7 block error
8 addr in use error
9 alr connecting error
10 alr connected error
11 NETIF error
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 120 2018-04-10
6 AT Commands for HTTP/HTTPS Client
6.1 Overview of AT Commands for HTTP/HTTPS Client
Command Description
AT+CHTTPCREATE Create a HTTP/HTTPS client instance
AT+CHTTPCON Establish the HTTP/HTTPS connection
AT+CHTTPDISCON
Close the HTTP/HTTPS connection
AT+CHTTPDESTROY
Destroy the HTTP/HTTPS client instance
AT+CHTTPSEND Send HTTP/HTTPS package
+CHTTPNMIH Header of the response from host
+CHTTPNMIC Content of the response from host
+CHTTPERR HTTP/HTTPS client connection error indicator
6.2 Detailed Descriptions of AT Commands for HTTP/HTTPS Client
6.2.1 AT+CHTTPCREATE Create a HTTP/HTTPS client instance
AT+CHTTPCREATE Create a HTTP/HTTPS client instance
Create an HTTP or HTTPS client instance and set configuration. If the <host> is start with
“https://”, our device will create an HTTPS client
Read Command
AT+CHTTPCR
EATE?
Response
+CHTTPCREATE: <httpclient_id>,<state>,<host>[<CR><LF>
+CHTTPCREATE: <httpclient_id>,<state>,<host>
[...]]
OK
Parameters
See Write Command
Write Command
AT+CHTTPCR
EATE=<host>[<
auth_user>,<aut
h_password>,<se
rver_cert>,<clien
t_cert>,<client_p
k>]
Response
+CHTTPCREATE: <httpclient_id>
OK
or
ERROR
Parameters
<host> Http server host
<auth_user> Authorization name [option]
<auth_password> Authorization password [option]
<server_cert> Server certification, for https [option]
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 121 2018-04-10
<client_cert> Client certification, for https [option]
<client_pk> Client private key, for https [option]
All optional parameter should be exist or not exist in one command.
<httpclient_id> An indica
tor of http client instance created by the
command.
<state> The create state of the httpclient_id
1 sucessfully
0 Failed
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
6.2.2 AT+CHTTPCON Establish the HTTP/HTTPS connection
AT+CHTTPCON Establish the HTTP/HTTPS connection
Use the created http instance to connect to target host.
Test Command
AT+CHTTPCO
N=?
Response
+CHTTPCON: (0-4)
OK
Parameters
See Write Command
Read Command
AT+CHTTPCO
N?
Response
+CHTTPCON: <httpclient_id>,<con_state>,<host>[<CR><LF>
+CHTTPCON: <httpclient_id>,<con_state>,<host>
[...]]
OK
Parameters
See Write Command
Write Command
AT+CHTTPCO
N=<httpclient_id
>
Response
OK
or
ERROR
Parameters
<httpclient_id> The indicator of http client instan
ce created by the
AT+CHTTPCREATE command
<con_state> The connected state of the httpclient_id
1 OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 122 2018-04-10
0 FAIL
<host> Http server host
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
-
AT+CHTTPCREATE should be set before this command.
6.2.3 AT+CHTTPDISCON Close the HTTP/HTTPS connection
AT+CHTTPDISCON Close the HTTP/HTTPS connection
Use the created http instance to disconnect the connection with host. After disconnected and
before detroy the http instance, you can use AT+CHTTPCON to connect it again.
Test Command
AT+CHTTPDIS
CON=?
Response
+CHTTPDISCON: (0-4)
OK
Parameters
See Write Command
Write Command
AT+CHTTPDIS
CON=<httpclien
t_id>
Response
OK
or
ERROR
Parameters
<httpclient_id> The indicator of http client in
stance created by the
AT+CHTTPCREATE command.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
-
AT+CHTTPCON should be set before this command
6.2.4 AT+CHTTPDESTROY Destroy the HTTP/HTTPS client instance
AT+CHTTPDESTROY Destroy the HTTP/HTTPS client instance
Use the created http instance to disconnect the connection with host.
Test Command
AT+CHTTPDES
TROY=?
Response
+CHTTPDESTROY: (0-4)
OK
Parameters
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 123 2018-04-10
See Write Command
Read Command
AT+CHTTPDES
TROY?
Response
+CHTTPDESTROY: <httpclient_id>,<state>,<host>[<CR><LF>
+CHTTPDESTROY: <httpclient_id>,<state>,<host>
[...]]
OK
Parameters
See Write Command
Write Command
AT+CHTTPDES
TROY=<httpclie
nt_id>
Response
OK
or
ERROR
Parameters
<httpclient_id> The indicator of http client instance create
d by the
AT+CHTTPCREATE command.
<state> The create state of the httpclient_id
1 sucessfully
0 Failed
<host> Http server host
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
-
AT+CHTTPCREATE should be set before this command
6.2.5 AT+CHTTPSEND Send HTTP/HTTPS package
AT+CHTTPSEND Send HTTP/HTTPS package
Test Command
AT+CHTTPSEN
D=?
Response
+CHTTPSEND: (0-4),(0-3),"path","http header","http content type",
"http content"
OK
Parameters
See Write Command
Write Command
AT+CHTTPSEN
D=<httpclient_id
>,<method>,<pat
h>,<customer_he
ader>,<content_t
Response
OK
or
ERROR
Parameters
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 124 2018-04-10
ype>,<content_st
ring>
<httpclient_id> The indicator of http client instance created by the
AT+CHTTPCREATE command.
<method> Http method,
HTTPCLIENT_GET = 0,
HTTPCLIENT_POST = 1,
HTTPCLIENT_PUT = 2,
HTTPCLIENT_DELETE =3
<path> The resource path on server, ex. “/html/login/index.html” means
the url full path is “<host>/html/login/index.html”
<customer_header> The string converted from customer header hex data.
<content_type> A string indicate the content type of the content, if the
method is not POST and PUT, it must be empty.
<content_string> The string converted from content hex data.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
- AT+CHTTPCON should be set before this command
6.2.6 +CHTTPNMIH Header of the response from host
+CHTTPNMIH Header of the response from host
The response from host have 2 parts. This is the header part and content part will follow this
URC.
Response
+CHTTPNMIH:
<httpclient_id>,<flag>,<header_max_length>,<header>
Parameters
<httpclient_id> The indicator of http client instance created by the
AT+CHTTPCREATE command
<flag> The flag to indicate if there are more data of the HTTP header
<header_max_length> The maximum length (buffer size) of the header
string
<header> header data of response
6.2.7 +CHTTPNMIC Content of the response from host
+CHTTPNMIC Content of the response from host
The response from host have 2 parts. This is the content part and follow by the header part
URC. And there are multi content URC follow one header URC.
Response
+CHTTPNMIC:
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 125 2018-04-10
<httpclient_id>,<flag>,<total_length><content_packge_len>,<content
_package_string>
Parameters
<httpclient_id> The indicator of http client instance created by the
AT+CHTTPCREATE command
<flag> The flag to indicate if there are more data of the HTTP header
<total_length> The total length of the content. It is get from header
“Content-Length : xxx“, so if the response
is not 200 OK, maybe the value is -1
<content_packge_len> content data length of current URC
<content_package_string> Content data string which is converted from
content hex data.The length must be original content hex data size * 2
6.2.8 +CHTTPERR HTTP client connection error indicator
+CHTTPERR HTTP client connection error indicator
When the URC send, there is some error happen on the http client. Normally is TCP
connection is disconnected.
Response
+CHTTPERR: <httpclient_id>[,<error_code>]
Parameters
<httpclient_id> The indicator of http client instance created by the
AT+CHTTPCREATE command
<error_code> normally is -1, means disconnected
-2 Connection was closed by a remote host.
-3 An unknown error occurred.
-4 A protocol error occurred.
-5 Could not resolve the hostname.
-6 A URL parse error occurred.
If the URC send out, the HTTP client will be disconnected automatically.
If user want to send HTTP message to server, he must use
AT+CHTTPCON command to connect.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 126 2018-04-10
7 AT Commands for PING Support
7.1 Overview of AT Commands for PING Support
Command
Description
AT+CIPPING
Test IP network connectivity to a remote host
7.2 Detailed Descriptions of AT Commands for PING Support
7.2.1 AT+CIPPING Test IP network connectivity to a remote host
AT+CIPPING Test IP network connectivity to a remote hos
Test Command
AT+CIPPING=?
Response
+CIPPING: (list of supported <retryNum>s),(list of supported
<dataLen>s),(list of supported <timeout>s)
OK
Parameters
See Write Command
Read Command
AT+CIPPING?
Response
+CIPPING: <retryNum>,<dataLen>,<timeout>
OK
Parameters
See Write Command
Write Command
AT+CIPPING=<
IPaddr>[,<retry
Num>[,<dataLen
>[,<timeout>]]]
Response
OK
+CIPPING: <replyId>,<Ip Address>,<replyTime>,<ttl>[<CR><LF>
+CIPPING: <replyId>,<Ip Address>,<replyTime>,<ttl>
[...]]
or
ERROR
or
+CME ERROR: <err>
Parameters
<IPaddr> Address of the remote host,string type.This par
ameter can be either:
- IP address in the format:”xxx.xxx.xxx.xxx”
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 127 2018-04-10
- Host name solved by a DNS query
<retryNum> The number of Ping Echo Requset to send
1-100 Default: 4
<dataLen> The length of Ping Echo Request data
0-1024 Default: 32
<timeout> The timeout,in units of 100 ms,waiting for a single
Echo Reply
1-600 Default: 100(10 seconds)
<replyId> Echo Reply number
<IP Address> IP Address of the remote host
<replyTime> Time,in units of 100 ms, required to receive the
Response
<ttl> Time to live
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
- Before sending PING Request the PDP context must be activated.
- When the Echo Request timeout expires (no reply received on time),
the response will contains <replyTime> setting to 100(default timeout)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 128 2018-04-10
8 AT Commands for Network Command – LwM2M
8.1 Overview of AT Commands for Network Command – LwM2M
Command
Description
AT+CLMCONF
Configuration LwM2M instance and create the connection
AT+CLMADDOBJ Add LwM2M object
AT+CLMDELOBJ Delete LwM2M object
AT+CLMREAD Read notification and command
AT+CLMWRITE Write notification and command
AT+CLMEXECUTE Execute notification and command
AT+CLMNOTIFY
Notify data change
AT+CLMDEL Delete LwM2M instance
+CLMOBSERVE
Observed command
+CLMPARAMETER Observed command
+CLMERR Indicated there is some error
8.2 Detailed Descriptions of AT Commands for Network Command – LwM2M
8.2.1 AT+CLMCONF Configuration LwM2M instance and create the connection
AT+CLMCONF Configuration LwM2M instance and create the connection
Write Command
AT+CLMCONF
=<configuration
>[,<cid>]
Response
+CLMCONF: <lwm2m_id>
OK
Parameters
<size> integer, configuration file size
<configuration> string (TLV), configuration file.
<cid> Integer, PDP context ID, AT+CSGACT response. [option]
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 129 2018-04-10
8.2.2 AT+CLMADDOBJ Add LwM2M object
AT+CLMADDOBJ Add LwM2M object
Write Command
AT+CLMADDO
BJ=<lwm2m_id>
,<object_id>,<ins
tance_id>,<resou
rce_count>,<reso
urce_id>,<resour
ce_id>,…
Response
OK
Parameters
<lwm2m_id> Integer, LwM2M id, AT+CLMCONF’s response.
<object_id> Integer, object id.
<instance_id> Integer, instance id
<resource_count> Integer, resource count.
<resource_id> Integer, resource id
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
-
AT+CLMCONF should be set before this command.
8.2.3 AT+CLMDELOBJ Delete LwM2M object
AT+CLMDELOBJ Delete LwM2M object
Write Command
AT+CLMDELO
BJ=<lwm2m_id>
,<object_id>
Response
OK
Parameters
<lwm2m_id> Integer, LwM2M id, AT+CLMCONF’s response.
<object_id> Integer, object id.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
-
AT+CLMADDOBJ should be set before this command.
8.2.4 AT+CLMREAD Read notification and command
AT+CLMREAD Read notification and command
Write Command
AT+CLMREAD
=<lwm2m_id>,<
object_id>,<insta
nce_id>,<resourc
e_cnt>,<resource
Response
This command used to indicated there is received a read operation. And
then using this command to send the read operation result.
OK
+CLMREAD:
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 130 2018-04-10
_id>,<value_type
>,<len>,<value>,
<resource_id>,<
value_type>,<len
>,<value>,<resou
rce_id>,<value_t
ype>,<len>,<valu
e>,…
<lwm2m_id>,<object_id>,<instance_id>,<count>,<resource_id>,<resou
rce_id>,<resource_id>
Parameters
<lwm2m_id> Integer, LwM2M id, AT+CLMCONF’s response.
<object_id> Integer, object id.
<instance_id> Integer, instance id.
<resource_cnt> Integer, if it is 0, means all readable resources of the
instance.
<resource_id> Integer, if count is 0, the resource id is not exsit.
<value_type> Char, value type.
I: Integer, F: Float, B: Boolean, D: UINT8 array data, S: String
<len> Integer, value length.
<value> Value type, value context.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
8.2.5 AT+CLMWRITE Write notification and command
AT+CLMWRITE Write notification and command
Write Command
AT+CLMWRIT
E=<lwm2m_id>,
<result>
Response
This command used to indicated there is received a write operation. And
then using this command to send the write operation result.
OK
+CLMWRITE:
<lwm2m_id>,<object_id>,<instance_id>,<resource_cnt>,<resource_id>
,<value_type>,<len>,<value>,<resource_id>,<value_type>,<len>,<value
>,<resource_id>,<value_type>,<len>,<value>,...
Parameters
<lwm2m_id> Integer, LwM2M id, AT+CLMCONF’s response.
<result> Integer, write result, result of write command, error code. 0 is
success, other value is error code in Spec.
<object_id> integer, object id.
<instance_id> integer, instance id.
<resource cnt> integer, if resource_id == -1, there will be set count.
<resource_id> integer, resource id, -1: all of resource about the instance.
<value_type> char, value type.
I: Integer, F: Float, B: Boolean, D: UINT8 array data, S: String
<len> integer, value length.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 131 2018-04-10
<value> value type, value context.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
8.2.6 AT+CLMEXECUTE Execute notification and command
AT+CLMEXECUTE Execute notification and command
Write Command
AT+CLMEXEC
UTE=<lwm2m_i
d>,<result>
Response
This command used to indicated there is received a execute operation. And
then using this command to send the execute operation result.
OK
+CLMEXECUTE:
<lwm2m_id>,<object_id>,<instance_id>,<resource_id>,<len>,<buffer>
Parameters
<lwm2m_id> Integer, LwM2M id, AT+CLMCONF’s response.
<result> Integer, result of write command, error code. 0 is success, other
value is error code in Spec.
<object_id> integer, object id.
<instance_id> integer, instance id.
<resource_id> integer, resource id, -1: all of resource about the instance.
<len> integer, data size.
<buffer> raw data in hex value but char format, execute command.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
8.2.7 AT+CLMNOTIFY Notify data change
AT+CLMNOTIFY Notify data change
Write Command
AT+CLMNOTI
FY=<lwm2m_id
>,<object_id>,<i
nstance_id>,<res
ource_id>
Response
OK
Parameters
<lwm2m_id> Integer, LwM2M id, AT+CLMCONF’s response
<object_id> Integer, object id
<instance_id> Integer, instance id
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 132 2018-04-10
<resource_id> Integer, resource id
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
8.2.8 AT+CLMDEL Delete LwM2M instance
AT+CLMDEL Delete LwM2M instance
Write Command
AT+CLMDEL=
<lwm2m_id>
Response
OK
Parameters
<lwm2m_id> Integer, LwM2M id, AT+CLMCONF’s response
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
-
AT+CLMCONF should be set before this command.
8.2.9 +CLMOBSERVE Observed command
+CLMOBSERVE Observed command
This command used to indicated there is received a observe command.
Response
+CLMOBSERVE:
<lwm2m_id>,<code>,<object_id>[,<instance_id>],<resource_id>
Parameters
<lwm2m_id> integer, LwM2M id, AT+CLMCONF’s response.
<code> integer, 0 - add observe, 1 - cancel observe.
<object_id> integer, object id.
<instance_id> integer, instance id, -1: all of instances of the object.
<resource_id> integer, resource id, -1: all of resource about the instance.
8.2.10 +CLMPARAMETER Observed command
+CLMPARAMETER Observed command
This command used to indicated there is received an observer’s parameter command.
Response
+CLMPARAMETER:
<lwm2m_id>,<object_id>,<instance_id>,<resource_id>,<toSet>,<toCl
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 133 2018-04-10
ear>,<minPeriod>,<maxPeriod>,<greaterThan>,<lessThan>,<step>
Parameters
<lwm2m_id> AT+CLMCONF result
<object_id> object id
<instance_id> instance id; -1:all of instances and resources
<resource_id> resource id; -1: all of resource about the instance
<toSet> toSet value, interger
<toClear> toClear value, interger
<minPeriod> min Period interger
<maxPeriod> max Period interger
<greaterThan> greater than, float
<lessThan> less than, float
<step> step, float
8.2.11 +CLMERR Indicated there is some error
+CLMERR Indicated there is some error
This command Indicated there is some error.
Response
+CLMERR: <lwm2m_id>,<error_code>
Parameters
<lwm2m_id> Integer, LwM2M id, AT+CLMCONF’s response.
<error_code> Integer, error code.
1 Reset by peer point.
2 Network disconnect.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 134 2018-04-10
9 AT Commands for Network Command – MQTT
9.1 Overview of AT Commands for Network Command-MQTT
Command
Description
AT+CMQNEW
New MQTT
AT+CMQCON Send MQTT connection packet
AT+CMQDISCON Disconnect MQTT
AT+CMQSUB Send MQTT subscribe packet
AT+CMQUNSUB Send MQTT unsubscribe packet
AT+CMQPUB Send MQTT publish packet
9.2 Detailed Descriptions of AT Commands for Network Command-MQTT
9.2.1 AT+CMQNEW New MQTT
AT+CMQNEW New MQTT
Test Command
AT+CMQNEW=
?
Response
+CMQNEW: "server","port", (list of supported
<command_timeout_ms>s), (list of supported <bufsize>s)
OK
Parameters
See Write Command
Read Command
AT+CMQNEW?
Response
+CMQNEW: <mqtt_id>, <used_state>,<server>
OK
Parameters
See Write Command
Write Command
AT+CMQNEW=
<server>,<port>,
<command_time
out_ms>,<bufsiz
e>[,<cid>]
Response
+CMQNEW: <mqtt_id>
OK
Parameters
<mqtt_id> Integer, MQTT id, from 0 to 4
<used_state> The used result of mqtt_id,0 not used,1 used.
<server> String, null or MQTT server IP address
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 135 2018-04-10
<port> String, MQTT server port.
<command_timeout_ms> Integer, AT command timeout (ms)
<bufsize> Integer, send buffer and read buffer size
<cid> Integer, PDP context ID, AT+CSGACT response. [option]
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
9.2.2 AT+CMQCON Send MQTT connection packet
AT+CMQCON Send MQTT connection packet
Test Command
AT+CMQCON=
?
Response
+CMQCON:
<mqtt_id>,<version>,<client_id>,<keepalive_interval>,<cleansession>,
<will_flag>
OK
Parameters
See Write Command
Read Command
AT+CMQCON?
Response
+CMQCON: <mqtt_id>, <connected_state>,<server>
OK
Parameters
See Write Command
Write Command
AT+CMQCON=
<mqtt_id>,<versi
on>,<client_id>,
<keepalive_inter
val>,<cleansessio
n>,<will_flag>[,<
will_options>][,<
username>,<pass
word>]
Response
OK
Parameters
<mqtt_id> Integer, MQTT id, AT+CMQNEW’s response.from 0 to 4
<connected_state> The conneted result of mqtt_id,0 not connected,
1 connected.
<server> String, null(not connect) or MQTT server IP address
<version> Integer , MQTT version, can be 3 or 4
<client_id> String, client ID, should be unique
<keepalive_interval> Integer , keep alive interval, don’t suggest to set it
to a small value because server may disconnect the device for some reason
<cleansession> Integer , clean session, can be 0 or 1
<will_flag> Integer , will flag, can be 0 or 1
<will_options> String, will options, mandatory if will_flag is 1, the
format is as follows:
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 136 2018-04-10
topic=xxx,QoS=xxx,retained=xxx,message_len=xxx,message=xxx
<username> String , user name (option)
<password> String , password (option)
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
- AT+CMQNEW should be set before this command.
9.2.3 AT+CMQDISCON Disconnect MQTT
AT+CMQDISCON Disconnect MQTT
Test Command
AT+CMQDISC
ON=?
Response
+CMQDISCON: <mqtt_id>
OK
Parameters
See Write Command
Write Command
AT+CMQDISC
ON=<mqtt_id>
Response
This command is used to receive MQTT disconnect indication. This is
probably because the MQTT server has disconnected the device for some
reasons.
OK
+CMQDISCON: <mqtt_id>
Parameters
<mqtt_id>
Integer, MQTT id, AT+CMQNEW’s response.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
- AT+CMQCON should be set before this command.
9.2.4 AT+CMQSUB Send MQTT subscribe packet
AT+CMQSUB Send MQTT subscribe packet
Test Command
AT+CMQSUB=?
Response
+CMQSUB: <mqtt_id>,<topic>,<QoS>
OK
Parameters
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 137 2018-04-10
See Write Command
Write Command
AT+CMQSUB=
<mqtt_id>,<topi
c>,<QoS>
Response
OK
Parameters
<mqtt_id> Integer, MQTT id, AT+CMQNEW’s response.
<topic> String, topic of subscribe message.
<Qos> Integer, message QoS, can be 0, 1 or 2.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
9.2.5 AT+CMQUNSUB Send MQTT unsubscribe packet
AT+CMQUNSUB Send MQTT unsubscribe packet
Test Command
AT+CMQUNSU
B=?
Response
+CMQUNSUB: <mqtt_id>,<topic>
OK
Parameters
See Write Command
Write Command
AT+CMQUNSU
B=<mqtt_id>,<to
pic>
Response
OK
Parameters
<mqtt_id> Integer, MQTT id, AT+CMQNEW’s response.
<topic> String, topic of subscribe message.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
9.2.6 AT+CMQPUB Send MQTT publish packet
AT+CMQPUB Send MQTT publish packet t
Test Command
AT+CMQPUB=?
Response
+CMQPUB:
<mqtt_id>,<topic>,<QoS>,<retained>,<dup>,<message_len>,<message
>
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 138 2018-04-10
OK
Parameters
See Write Command
Write Command
AT+CMQPUB=
<mqtt_id>,<topi
c>,<QoS>,<retai
ned>,<dup>,<me
ssage_len>,<mes
sage>
Response
OK
+CMQPUB:
<mqtt_id>,<topic>,<QoS>,<retained>,<dup>,<message_len>,<message
>
Parameters
<mqtt_id> Integer, MQTT id, AT+CMQNEW’s response.
<topic> String, topic of publish message.
<Qos> Integer, message QoS, can be 0, 1 or 2.
<retained> Integer, retained flag, can be 0 or 1.
<dup> Integer, duplicate flag, can be 0 or 1.
<message_len> Integer, length of publish message.
<message> String, publish message.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 139 2018-04-10
10 AT Commands for Network Command – CoAP
10.1 Overview of AT Commands for Network Command-CoAP
Command
Description
AT+CCOAPSTA
Start CoAP server
AT+CCOAPNEW Create a CoAP client instance
AT+CCOAPSEND Send data to CoAP server with the created CoAP client instance.
AT+CCOAPDEL Destory the CoAP client instance
+CCOAPNMI Content from CoAP server
10.2 Detailed Descriptions of AT Commands for Network Command-CoAP
10.2.1 AT+CCOAPSTA Start CoAP server
AT+CCOAPSTA Start Coap server
Write Command
AT+CCOAPST
A=<ip_addr>,<p
ort>,<cid>
Response
+CCOAPSTA: <coap_id>
OK
Parameters
<ip_addr> String, CoAP server IP address.
<port> Integer, CoAP server port(spec default 5683).
<cid> Integer, PDP context ID, AT+CSGACT response.
<coap_id> Integer, CoAP server instance id created by the command.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
10.2.2 AT+CCOAPNEW Create a CoAP client instance
AT+CCOAPNEW
Create CoAP client
Write Command
AT+CCOAPNE
W=<ip_addr>,<
port>,<cid>
Response
+CCOAPNEW: <coap_id>
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 140 2018-04-10
Parameters
<ip_addr> String, CoAP server IP address.
<port> Integer, CoAP server port(spec default 5683).
<cid> Integer, PDP context ID, AT+CSGACT response.
<coap_id> Integer, CoAP client instance id created by the command.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
10.2.3 AT+CCOAPSEND Send CoAP data
AT+CCOAPSEND Send CoAP data
Write Command
AT+CCOAPSE
ND=<coap_id>,<
data_len>,<data
>
Response
OK
Parameters
<coap_id> Integer, CoAP client instance id created by the
AT+CCOAPNEW command.
<data_len> Integer, Send data length(by byte).
<data> String, the hex data streaming.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
AT+CCOAPNEW should be set before this command.
10.2.4 AT+CCOAPDEL Destory the CoAP client instance
AT+CCOAPDEL Free created CoAP client instance
Write Command
AT+CCOAPDE
L=<coap_id>
Response
OK
Parameters
<coap_id> Integer, CoAP client instance id created by the
AT+CCOAPNEW command.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
AT+CCOAPNEW should be set before this command.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 141 2018-04-10
10.2.5 +CCOAPNMI Content from CoAP server
+CCOAPNMI Indicate content from CoAP server
Write Command
+CCOAPNMI
Response
+CCOAPNMI: <coap_id>,<data_len>,<data>
Parameters
<coap_id> Integer, CoAP client instance id created by the
AT+CCOAPNEW command.
<data_len> Integer, data length(by byte).
<data> String, the hex data streaming.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 142 2018-04-10
11 AT Commands for Network Command – SNTP
11.1 Overview of AT Commands for Network Command-SNTP
Command
Description
AT+CSNTPSTART
Start to query network time
AT+CSNTPSTOP Stop querying network time
+CSNTP Received network time.
11.2 Detailed Descriptions of AT Commands for Network Command-SNTP
11.2.1 AT+CSNTPSTART Start to query network time
AT+CSNTPSTART Start to query network time
Write Command
AT+CSNTPSTA
RT =<url>
Response
OK
Parameters
<url> A string of SNTP server name or IP address.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
11.2.2 AT+CSNTPSTOP Stop querying network time
AT+CSNTPSTOP Stop querying network time
Write Command
AT+CSNTPSTO
P
Response
OK
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 143 2018-04-10
11.2.3 +CSNTP Received network time
+CSNTP Received network time
Indicated there is received some data from network.
Response
+CSNTP:
<year>,<month>,<day>,<hour>,<minute>,<second>,<millisecond>
Parameters
<year> Year
<month> Month
<day> Day
<hour> Hour
<minute> Minute
<second> Second
<millisecond> Millisecond
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 144 2018-04-10
12 AT Commands for Network Command – TLS
12.1 Overview of AT Commands for Network Command- TLS
Command
Description
AT+CTLSCFG
Configure TLS parameters
AT+CTLSONN Create a TLS connection
AT+CTLSCLOSE Close a TLS connection.
AT+CTLSSEND Send data
AT+CTLSRECV Receive data.
12.2 Detailed Descriptions of AT Commands for Network Command-TLS
12.2.1 AT+CTLSCFG Configure TLS parameters
AT+CTLSCFG Configure TLS parameters
Write Command
AT+CTLSCFG=
<tid>,<type>,<va
lue>[,<type>,<va
lue>[,<type>,<va
lue>[…]]]
Response
OK
Parameters
<tid> Integer type.It is the identifier of the TLS connection to be created.
<type> Integer type.It is the type of the parameter to be configured.
1 Server name (string);
2 Port (int, default value is 443);
3 Socket type (0-tcp, tcp supported only, default value is 0);
4 Auth_mode (int, 0-none, 1-optional, 2-required, default value is 2);
5 Debug level (int, 0~4, 0-no log, 4-all log enabled, default value is
0);
6 Server CA (<size><more><certificate>, size (int)-total size of the
certificate without the terminate null; more(int)-is there more certificate
content needed to be sent, 1-yes, 0-no; certificate (string)-the total or
particial of the certificate content. default value for type 6 is null);
7 Client certificate (same as 6-server CA, default value for type 7 is
null);
8 Client private key (<size><more><private-key>, size and more is
the same as 6-server CA, private-key (string)-the total or partical of the
private-key, default value for type 8 is null)
<value> Integer type.It is the value of the parameter to be configured.
Parameter Saving
Mode
NO_SAVE
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 145 2018-04-10
Max Response
Time
-
Reference
Note
12.2.2 AT+CTLSONN Create a TLS connection
AT+CTLSONN
Create a TLS connection
Write Command
AT+CTLSONN=
<tid>,<cid>
Response
OK
+CTLSONN: <tid>,<ret>
Parameters
<tid> Integer type. It is the identifier of the TLS connection to be
created.It shoud be the same as the one in CTLSCFG.
<cid> Integer type.It is a numeric parameter specifying a particular PDP
context returned by CSGACT.
<ret> Integer type.It tells the result of the TLS connection.If the
connection succeeds, it is 1.Otherwise,it is the error code.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
12.2.3 AT+CTLSCLOSE Close a TLS connection
AT+CTLSCLOSE Close a TLS connection
Write Command
AT+CTLSCLOS
E=<tid>
Response
OK
+CTLSCLOSE: <tid>,<ret>
Parameters
<tid> Integer type.It is the identifier of the TLS connection to be
created.It shoud be the same as the one in ETLSCFG.
<cid> integer type.It is a numeric parameter specifying a particular PDP
context returned by CSGACT.
<ret> integer type.It tells the result of the TLS connection closure.If the
closure succeeds, it is 1.Otherwise, it is the error code.
Parameter Saving
Mode
NO_SAVE
Max Response
-
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 146 2018-04-10
Time
Reference
Note
12.2.4 AT+CTLSSEND Send data
AT+CTLSSEND Send data
Write Command
AT+CTLSSEND
=<tid>,<data_len
>,<data>[,<enco
d_method>]
Response
OK
+CTLSSEND: <tid>,<ret>
Parameters
<tid> Integer type.It is the identifier of the TLS connection to be
created.It shoud be the same as the one in CTLSCFG.
<data_len> Integer type.It is the length of the encoded <data>.
<data> It is the length of the encoded <data>.
<encod_method> Integer type.It is the encode method used for <data>.
801 is for string encoding and it is the default value which can be omitted.
802 is for hex encoding. And 803 is for base64 encoding.
<ret> Integer type.It tells the result of the data sending.If it is greater than
0, it is the actual number of data send.Otherwise, it is the error code.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
12.2.5 AT+CTLSRECV Receive data
AT+CTLSRECV Send data
Write Command
AT+CTLSRECV
=<tid>,<max_nu
m>[,<encod_met
hod>]
Response
OK
+CTLSRECV: <tid>,<ret>[,<data>[,<encode_method>]]
Parameters
<tid> Integer type. It is the identifier of the TLS connection to be
created.It shoud be the same as the one in ETLSCFG.
<max_num> Integer type. It is the maximum number of plain data
without encoding that could be received.
<encod_method> Integer type. It is the encode method used for
<data>.801 is for string encoding and it is the default value which can be
omitted. 802 is for hex encoding. And 803 is for base64 encoding.
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 147 2018-04-10
<ret> Integer type.If it is greater than 0, it is the length of data received
after encoding .Otherwise, it is the error code.
<data> It is the data received with encoding.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 148 2018-04-10
13 AT Commands for Network Command –OneNET
13.1 Overview of AT Commands for Network Command- OneNet
Command
Description
AT+MIPLCREATE
Create a OneNET instance
AT+MIPLDELETE Delete a OneNET instance
AT+MIPLOPEN Register to OneNET.
AT+MIPLCLOSE Deregister to OneNET
AT+MIPLADDOBJ Add an object
AT+MIPLDELOBJ Delete an object
AT+MIPLUPDATE
Update registration
AT+MIPLREADRSP Read response from user
AT+MIPLWRITERSP
Write response from user
AT+MIPLEXECUTE
RSP
Execute response from user
AT+MIPLOBSERVE
RSP
Observe response from user
AT+MIPLDISCOVE
RRSP
Discover response from user
AT+MIPLPARAMET
ERRSP
Set parameter from to user
AT+MIPLNOTIFY Notify data value change from user
AT+MIPLVER Read version
+MIPLREAD
Read request to user
+MIPLWRITE
Write request to user
+MIPLEXECUTE Execute request to user
+MIPLOBSERVE
Observe request to user
+MIPLDISCOVER Discover request to user
+MIPLPARAMETER Set parameter request to user
+MIPEVENT Event indication to user
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 149 2018-04-10
13.2 Detailed Descriptions of AT Commands for Network
Command-OneNet
13.2.1 AT+MIPLCREATE Create a OneNET instance
AT+MIPLCREATE Create a OneNET instance
Test Command
AT+MIPLCREA
TE =?
Response
+MIPLCREATE: (list of supported <totalsize>),(list of supported <
config>),(list of supported <index>),(list of supported <currentsize>),(0-2)
OK
Parameters
See Write Command
Read Command
AT+MIPLCREA
TE?
Response
+MIPLCREATE: <ref>,<used_state>
OK
Parameters
See Write Command
Write Command
AT+MIPLCREA
TE =<totalsize>,
<config>,<index
>, <currentsize>,
<flag>
Response
OK
--message received correctly if index not equals to 0
<ref>
--message received correctly and return OneNET instance
+CIS ERROR: <errid>
Parameters
<totalsize> Integer, configuration file total size
<config> Hex string, configuration file, ex: 130033f1……
<index> Integer, configuration file index, from N-1 to 0
<currentsize> Integer, configuration file size in current AT command
<flag> Integer, message flag
--1 first message; 2 middle message; 0 last message
<used_state> The used result of AT+MIPLCREATE
0 not used; 1 used
<errid>
651 Memory error
652 Paramter error
653 Unsupported format
654 SDK error
655 Not find
Parameter Saving
Mode
NO_SAVE
Max Response
-
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 150 2018-04-10
Time
Reference
13.2.2 AT+MIPLDELETE Delete a OneNET instance
AT+MIPLDELETE Delete a OneNET instance
Test Command
AT+MIPLDELE
TE=?
Response
+MIPLDELETE: (list of supported <ref>)
OK
Parameters
See Write Command
Read Command
AT+MIPLDELE
TE?
Response
+MIPLDELETE: <ref>,<used_state>
OK
Parameters
See Write Command
Write Command
AT+MIPLDELE
TE=<ref>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> integer, OneNET instance returned by AT+MIPLCREATE
<used_state> The used result of <ref>
0 not used; 1 used
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.3 AT+MIPLOPEN Register to OneNET.
AT+MIPLOPEN Register to OneNET
Test Command
AT+MIPLOPEN
=?
Response
+MIPLOPEN: (list of supported <ref
>),( list of supported <
lifetime >),( list of supported <param >)
OK
Parameters
See Write Command
Read Command
AT+MIPLOPEN
?
Response
+MIPLOPEN: <ref >,<connected_state>
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 151 2018-04-10
Parameters
See Write Command
Write Command
AT+MIPLOPEN
=<ref>,<lifetime
>[,< param >]
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<lifetime> Integer, lifetime to register ONENET server
<param> Reserved
<connected_state> The connected result of AT+MIPLOPEN
0 not connected; 1 connected
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.4 AT+MIPLCLOSE Deregister to OneNET.
AT+MIPLCLOSE Deregister to OneNET
Test Command
AT+MIPLCLOS
E=?
Response
+MIPLCLOSE: (list of supported <ref >)
OK
Parameters
See Write Command
Read Command
AT+MIPLCLOS
E?
Response
+MIPLCLOSE: <ref >,<connected_state>
OK
Parameters
See Write Command
Write Command
AT+MIPLCLOS
E=<ref>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<connected_state> The connected result of < ref >
0 not connected; 1 connected
Parameter Saving
Mode
NO_SAVE
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 152 2018-04-10
Max Response
Time
-
Reference
13.2.5 AT+MIPLADDOBJ Add an object
AT+MIPLADDOBJ Add an object
Test Command
AT+MIPLADD
OBJ=?
Response
+MIPLADDOBJ: (list of supported <ref>),(list of supported
<objectid >),(list of supported <instancecount>),(list of supported
<instancebitmap >),(list of supported <attributecount>),(list of supported
<actioncount>)
OK
Parameters
See Write Command
Write Command
AT+MIPLADD
OBJ=<ref>,<obj
ectid>,<instancec
ount>,<instanceb
itmap>,<attribut
ecount>,<actionc
ount>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> integer, OneNET instance returned by AT+MIPLCREATE
<objectid> integer, object id
<instancecount> integer, instance count
<instancebitmap>
Binary string, instance bitmap, ex: “00101” (5
instances, only instance 1 & 3 are available)
<attributecount> integer, attribute count
(The Object that has read or
write operation, has the attribute)
<actioncount> integer, action count
(The Object that has execute
operation, has the action)
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.6 AT+MIPLDELOBJ Delete an object.
AT+MIPLDELOBJ Delete an object.
Test Command
AT+MIPLDELO
BJ =?
Response
+MIPLDELOBJ: (list of supported <ref>),(list of supported <objectid >)
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 153 2018-04-10
Parameters
See Write Command
Write Command
AT+MIPLDELO
BJ=<ref>,<objec
tid>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> integer, OneNET instance returned by AT+MIPLCREATE
<objectid> integer, object id
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.7 AT+MIPLUPDATE Update registration
AT+MIPLUPDATE Update registration
Test Command
AT+MIPLUPDA
TE=?
Response
+MIPLUPDATE: (list of supported <ref>),(list of supported <
lifetime >),(0-1)
OK
Parameters
See Write Command
Write Command
AT+MIPLUPDA
TE=<ref>,<lifeti
me>,<withObjec
tFlag>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> integer, OneNET instance returned by AT+MIPLCREATE
<lifetime> integer, lifetime to update registration
<withObjectFlag> integer, whether to update objects
0 not upate objects; 1 update objects
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.8 AT+MIPLREADRSP Read response from user
AT+MIPLREADRSP Read response from user
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 154 2018-04-10
Test Command
AT+MIPLREAD
RSP=?
Response
+MIPLREADRSP: (list of supported <ref>),(list of supported <
msgid >),(list of supported <result>), (list of supported <objectid>),(list of
supported <instanceid>),(list of supported <resourceid ),(1-5), (list of
supported <len>),(list of supported <value>),(list of supported
<index>),(0-2)
OK
Parameters
See Write Command
Write Command
AT+MIPLREAD
RSP=<ref>,<msg
id>,<result>[,<o
bjectid>,<instanc
eid>,<resourceid
>,<valuetype>,<l
en>,<value>,<in
dex>,<flag>]
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> integer, OneNET instance returned by AT+MIPLCREATE
<msgid> integer, message id,the same to +MIPLREAD
<result>
integer, read result, 1 indicates read success, should provide
read content in the same time
1 Read/Observe/Discover OK
2 Write/Execute/ Set parameter OK
11 400 Bad request
12 401 Unauthorized
13 404 Not Found
14 405 Method Not Allowed
15 406 Not Acceptable
<objectid> integer, object id
<instanceid > integer, instance id
<resourceid> integer, resource id
<valuetype> integer, read data value type
-- 1 string; 2 opaque; 3 integer; 4 float; 5 bool
<len> integer, read data length
<value> integer, read data value
<index> integer, message index, from N-1 to 0
<flag> integer, message flag
-- 1 first message; 2 middle message; 0 last message
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 155 2018-04-10
13.2.9 AT+MIPLWRITERSP Write response from user
AT+MIPLWRITERSP Write response from user
Test Command
AT+MIPLWRIT
ERSP=?
Response
+MIPLWRITERSP: (list of supported <ref>),(list of supported <
msgid >),(list of supported <result>)
OK
Parameters
See Write Command
Write Command
AT+MIPLWRIT
ERSP=<ref>,<m
sgid>,<result>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> integer, OneNET instance returned by AT+MIPLCREATE
<msgid> integer, message id, the same to +MIPLWRITE
<result> integer, write result, 2 indicates write success
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.10 AT+MIPLEXECUTERSP Execute response from user
AT+MIPLEXECUTERSP Execute response from user
Test Command
AT+MIPLEXEC
UTERSP=?
Response
+MIPLEXECUTERSP: (list of supported <ref>),(list of supported <
msgid >), (list of supported <result>)
OK
Parameters
See Write Command
Write Command
AT+MIPLEXEC
UTERSP=<ref>
<msgid>,<result
>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> integer, OneNET instance returned by AT+MIPLCREATE
<msgid> integer, message id, the same to +MIPLEXECUTE
<result> integer, execute result, 2 indicates execute success
Parameter Saving
NO_SAVE
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 156 2018-04-10
Mode
Max Response
Time
-
Reference
13.2.11 AT+MIPLOBSERVERSP Observe response from user
AT+MIPLOBSERVERSP Observe response from user
Test Command
AT+MIPLOBSE
RVERSP=?
Response
+MIPLOBSERVERSP: (list of supported <ref>),(list of supported <
msgid >),(list of supported <result>)
OK
Parameters
See Write Command
Write Command
AT+MIPLOBSE
RVERSP=<ref>
<msgid>,<result
>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> integer, OneNET instance returned by AT+MIPLCREATE
<msgid> integer, message id, the same to +MIPLOBSERVE
<result>
integer, (cancel) observe result, 1 indicates (cancel) observe
success
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.12 AT+MIPLDISCOVERRSP Discover response from user
AT+MIPLDISCOVERRSP Discover response from user
Test Command
AT+MIPLDISC
OVERRSP=?
Response
+MIPLDISCOVERRSP: (list of supported <ref>),(list of supported <
msgid >),(list of supported <result>), (list of supported <length>),(list of
supported <valuestring>)
OK
Parameters
See Write Command
Write Command
AT+MIPLDISC
Response
OK
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 157 2018-04-10
OVERRSP=<ref
>,<msgid>,<resu
lt><length>,<val
uestring>
+CIS ERROR: <errid>
Parameters
<ref> integer, OneNET instance returned by AT+MIPLCREATE
<msgid> integer, message id, the same to +MIPLDISCOVER
<result> integer, discover result, 1 indicates discover success
<length> integer, length of valuestring
<valuestring>
string, value string (attribute; attribute; …; attribute;
action; …; action), must start with “ and end with “
attribute + action count in valuestring is the same to attributecount +
actioncount in AT+MIPLADDOBJ
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.13 AT+MIPLPARAMETERRSP Set parameter from user
AT+MIPLPARAMETERRSP Set parameter from user
Test Command
AT+MIPLPARA
METERRSP=?
Response
+MIPLPARAMETERRSP: (list of supported <ref>),(list of supported <
msgid >),(list of supported <result>)
OK
Parameters
See Write Command
Write Command
AT+MIPLPARA
METERRSP=<r
ef>,<msgid>,<res
ult>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<msgid> Integer, message id, the same to +MIPLPARAMETER
<result> Integer, set parameter result, 1 indicates set parameter success
Parameter Saving
Mode
NO_SAVE
M
ax Response
Time
-
Reference
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 158 2018-04-10
13.2.14 AT+MIPLNOTIFY Notify data value change from user
AT+MIPLNOTIFY Notify data value change from user
Test Command
AT+MIPLNOTI
FY=?
Response
+MIPLNOTIFY: (list of supported <ref>),(list of supported <
msgid >),(list of supported <objectid>),(list of supported
<instanceid>),(list of supported <resourceid>),(1-5), (list of supported
<len>),(list of supported <value>),(list of supported <index>),(0-2)
OK
Parameters
See Write Command
Write Command
AT+MIPLNOTI
FY=<ref>,<msgi
d>,<objectid>,<i
nstanceid>,<reso
urceid>,<valuety
pe>,<len>,<value
>,<index>,<flag>
Response
OK
+CIS ERROR: <errid>
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<msgid> Integer, message id
<objectid> Integer, object id
<instanceid > Integer, instance id
<resourceid> Integer, resource id
<valuetype> Integer, read data value type
-- 1 string; 2 opaque; 3 integer; 4 float; 5 bool
<len> Integer, write data length
<value> Integer, write data value
<index> Integer, message index, from N-1 to 0
<flag> Integer, message flag
-- 1 first message; 2 middle message; 0 last message
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.15 AT+MIPLVER Read version
AT+MIPLVER Read version
Read Command
AT+MIPLVER?
Response
<version>
OK
Parameters
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 159 2018-04-10
<version > Onenet version, such as 2.1.1
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
13.2.16 +MIPLREAD Read request to user
+MIPLREAD Read request to user
Response
+MIPLREAD: <ref>, <msgid>, <objectid>, <instanceid>,<resourceid>
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<msgid> Integer, message id
<objectid > Integer, object id
<instanceid> I
nteger, instance id, read all resources of all instances of
the object if instanceid equals -1
<resourceid> I
nteger, resource id, read all resources of the instance if
resourceid equals -1
13.2.17 +MIPLWRITE Write request to user
+MIPLWRITE Write request to user
Response
+ MIPLWRITE: <ref>, <msgid>, <objectid>, <instanceid>,
<resourceid>, <valuetype>, <len>, <value>, <flag>, <index>
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<msgid> Integer, message id
<objectid > Integer, object id
<instanceid> Integer, instance id
<resourceid> Integer, resource id
<valuetype> Integer, write data value type
1 string; 2 opaque; 3 integer; 4 float; 5 bool
<len> Integer, write data length
<value> Integer, write data value
<flag> Integer, message flag
1 first message; 2 middle message; 0 last message
<index> Integer, message index, from N-1 to 0
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 160 2018-04-10
13.2.18 +MIPLEXECUTE Execute request to user
+MIPLEXECUTE Execute request to user
Response
+MIPLEXECUTE: <ref>, <msgid>, <objectid>, <instanceid>,
<resourceid>[, <len>, <arguments>]
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<msgid> Integer, message id
<objectid > Integer, object id
<instanceid> Integer, instance id
<resourceid> Integer, resource id
<len> Integer, parameter length
<arguments> String, parameter string
13.2.19 +MIPLOBSERVE Observe request to user
+MIPLOBSERVE
Observe request to user
Response
+ MIPLOBSERVE: <ref>, <msgid>, <flag>,<objectid>, <instanceid>,
[<resourceid>]
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<msgid> Integer, message id
<flag> Integer, observe fla
g, 1 indicates observe, 0 indicates cancel
observe
<objectid > Integer, object id
<instanceid> I
nteger, instance id, observe all resources of all instances
of the object if instanceid equals -1
<resourceid> Integer, resource id, observe all resources of the instance if
resourceid equals -1
13.2.20 +MIPLDISCOVER Discover request to user
+MIPLDISCOVER Discover request to user
Response
+MIPLDISCOVER: <ref>, <msgid>, <objectid>
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<msgid> Integer, message id
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 161 2018-04-10
<objectid > Integer, object id
13.2.21 +MIPLPARAMETER Set parameter request to user
+ MIPLPARAMETER Set parameter request to user
Response
+MIPLPARAMETER: <ref>, <msgid>, <objectid>, <instanceid>,
<resourceid>, <len>, <parameter>
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<msgid> Integer, message id
<objectid > Integer, object id
<instanceid> I
nteger, instance id, observe all resources of all instances
of the object if instanceid equals -1
<resourceid> Inte
ger, resource id, observe all resources of the instance if
resourceid equals -1
<len> Integer, parameter length
<parameter > String, parameter string, must start with "and end with"
pmin=xxx; pmax=xxx; gt=xxx; lt=xxx; stp=xxx
13.2.22 +MIPEVENT Event indication to user
+MIPEVENT Event indication to user
Response
+ MIPEVENT: <ref>, <evtid>[,<extend>]
Parameters
<ref> Integer, OneNET instance returned by AT+MIPLCREATE
<evtid> Integer, event id
1 BOOTSTRAP_START
2 BOOTSTRAP_SUCCESS
3 BOOTSTRAP_FAILED
4 CONNECT_SUCCESS
5 CONNECT_FAILED
6 REG_SUCCESS
7 REG_FAILED
8 REG_TIMEOUT
9 LIFETIME_TIMEOUT
10 STATUS_HALT
11 UPDATE_SUCCESS
12 UPDATE_FAILED
13 UPDATE_TIMEOUT
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 162 2018-04-10
14 UPDATE_NEED
15 UNREG_DONE
20 RESPONSE_FAILED
21 RESPONSE_SUCCESS
25 NOTIFY_FAILED
26 NOTIFY_SUCCESS
<extend > Integer, extend parameter
The events of RESPONSE_FAILED and NOTIFY_FAILED
can take
msgid
The events of UPDATE_NEED can take LIFETIME(unit is second)
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 163 2018-04-10
14 AT Commands for DNS
14.1 Overview of AT Commands for DNS Command
Command
Description
AT+CDNSCFG
Configure Domain Name Server
AT+CDNSGIP Query the IP Address of Given Domain Name
14.2 Detailed Descriptions of AT Commands for DNS Command
14.2.1 AT+CDNSCFG Configure Domain Name Server
AT+CDNSCFG Configure Domain Name Server
Test Command
AT+CDNSCFG=
?
Response
+CDNSCFG: ("Primary DNS"),("Secondary DNS")
OK
Parameters
See Write Command
Read Command
AT+CDNSCFG?
Response
PrimaryDns: <pri_dns>
SecondaryDns: <sec_dns>
OK
Parameter
See Write Command
Write Command
AT+CDNSCFG=
<pri_dns>[,<sec_
dns>]
Response
OK
ERROR
Parameters
<pri_dns> A string parameter wh
ich indicates the IP address of the
primary domain name server. Default value is 208.67.222.222 or 218.4.4.4.
<sec_dns> A string parameter which indicates the IP address of the
secondary domain name server. Default value is 0.0.0.0.
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 164 2018-04-10
14.2.2 AT+CDNSGIP Query the IP Address of Given Domain Name
AT+CDNSGIP Query the IP Address of Given Domain Name
Test Command
AT+CDNSGIP=
?
Response
ERROR
Write Command
AT+CDNSGIP=
<domain name>
Response
OK
ERROR
If successful, return:
+CDNSGIP: <IP>
If fail, return:
ERROR
Parameters
<IP> A string parameter which indicates the first IP address
corresponding to the domain name
Parameter Saving
Mode
NO_SAVE
Max Response
Time
-
Reference
Note
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 165 2018-04-10
15 Supported Unsolicited Result Codes
15.1 Summary of CME ERROR Codes
Final result code +CME ERROR: <err> indicates an error related to mobile equipment or
network. The operation is similar to ERROR result code. None of the following commands in the
same Command line is executed. Neither ERROR nor OK result code shall be returned.
<err> values used by common messaging commands:
Code of <err> Meaning
0
phone failure
15.2 Summary of CMS ERROR Codes
Final result code +CMS ERROR: <err> indicates an error related to message service or
network. The operation is similar to ERROR result code. None of the following commands in the
same Command line is executed. Neither ERROR nor OK result code shall be returned.
<err> values used by common messaging commands:
Code of <err> Meaning
1 Unassigned(unallocated) number
15.3 Summary of Unsolicited Result Codes
URC
Description
AT Command
*MATREADY: 1
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 166 2018-04-10
16 AT Commands Examples
16.1 CoAP command
Demonstration Syntax Expect Result
Start CoAP server AT+CCOAPSTA="
10.161.11.104",568
3,1
+CCOAPSTA:6
OK
Create CoAP client and
get CoAP client ID
AT+CCOAPNEW=
"10.161.11.104",56
83,1
+CCOAPNEW:1
OK
Get CoAP server
counter
AT+CCOAPSEND
=1,12,"400141C7B
7636F756E746572"
OK
N
notify CoAP server
counter "024" via URC
+CCOAPNMI:
1,11,"60457233c02105ff303234"
SIMCOM COMFIDENTIAL FILE
Smart Machine Smart Decision
SIM7020 Series_AT Command Manual_V1.00 167 2018-04-10
contact us:
Shanghai SIMCom wireless solutions Ltd.
Address: Building A, SIM Technology Building, No. 633 Jinzhong Road, Shanghai,
P. R. China 200335
Tel: +86 21 3252 3300
Fax: +86 21 3252 3020
URL: www.simcomm2m.com
SIMCOM COMFIDENTIAL FILE
